BENITO™

FP8003**

Ceiling Fan

INSTALLATION REQUIREMENTS:

Ceiling fan attaches to electrical junction box securely anchored

and capable of withstanding a load of at least 50 lbs.

ELECTRICAL REQUIREMENTS:

Ceiling fan requires a grounded electrical supply line of 120 volts

AC, 60 Hz, 15 amp circuit.

MOTOR SPECS:

172 x 20 motor is designed for optimal performance with this fan.

220 VAC, 50 Hz export version available.

BLADE SETS:

Aset of five 21.5˝ reversible wood blades is included. Mahogany/Walnut included with Oil-Rubbed Bronze fan and

Cherry/Walnut included with Polished Nickel and Satin Nickel fans.

CONTROL OPTIONS:

LIGHTING OPTIONS:

DOWNROD OPTIONS:

Fan comes with a 1˝Dia. x 4.5˝ downrod. Optional downrods are available in 12˝,18˝,24˝,36˝,48˝,60˝, and 72˝. For

installations requiring a longer downrod, a downrod coupler is available. The Benito™fan can be mounted on a sloped

ceiling up to 30°. Most sloped ceiling installations require a downrod longer than the standard 4.5˝downrod. Optional

close-to-ceiling kit is available as well—sold separately. Call your local dealer for more information.

LOCATION USE:

Fan is rated for dry locations only.

Available Finishes

OB Oil-Rubbed Bronze with Opal Frosted Glass

PN Polished Nickel with Opal Frosted Glass

SN Satin Nickel with Opal Frosted Glass

AB

Fan w/4.5˝ downrod16.50˝ 11.42˝

Fan w/12˝ downrod 24.00˝ 18.92˝

Fan w/18˝ downrod 30.00˝ 24.92˝

Fan w/24˝ downrod 36.00˝ 30.92˝

Fan w/36˝ downrod 48.00˝ 42.92˝

Fan w/48˝ downrod 60.00˝ 54.92˝

Fan w/60˝ downrod 72.00˝ 66.92˝

Fan w/72˝ downrod 84.00˝ 78.92˝

Airflow / Energy Efficiency Info (120V)

Fan Speed Max RPM CFM

CFM / Watts

Amps Watts

High 157 4774 80 0.50 60

Med 95 2775 111 0.39 25

Low 60 1587 139 0.29 11

Floor

Ceiling

13° Blade Pitch

Net Hanging Weight: 19.6 lbs

5.67˝ dia

Blade Sweep = 52˝ dia 7´ min

AB

One bulb (100-watt halogen minican bulb -included) downlight fixture is included with this fan assembly. Maximum

downlight wattage not to exceed 100 watts.

TR24WH hand-held remote control with wall mount is included. Push button remote control has 3 fan speeds, infinite

light levels and off button. Optional CWRL4 wall control, CRL4WH and CRL8TS hand-held remote controls are available

—sold separately. Instructions are provided with each control.
