BEST OVERVIEW 2012
CCTV
BEST OVERVIEW CCTV 2012
VIDEOCITOFONIA TELEFONIA DOMOTICATVCC AUTOMAZIONI
I t I n c lu d es a l s o t h e n e w
I P sys t e m R a n G e
Via Pontarola, 14/a
35011 Campodarsego PD - Italy
Tel. +39 049 920 2511
Fax +39 049 920 2601
www.elvox.com - elvoxexp@elvox.com
Elvox reserves the right to modify its products at any time without advance notication. Due to layout considerations, the images and drawings of the products are not in scale to each other DEP.RAP.ETV - ED00 - 03/2012
Our extensive and comprehensive
product catalogue is constantly updated
to include the latest technology, ensuring
that customers can choose from a
technologically sophisticated, state-of-
the-art range of products.
The ongoing renewal and expansion of
our range gives customers the chance
to customise their installation in order to
meet real specic needs.
Alongside the various product segments
that have been added to cover
professional needs, our range of indoor
and outdoor cameras includes Day &
Night, Varifocal, Infrared, Speed Dome
and TCP-IP. LCD monitors, a wide range
of xed and variable focus lenses and
other accessories round off the range.
BEST OVERVIEW
PRICE LIST E1
2
IP SYSTEMS
Small business solutions page 14
Professional solutions page 18
Enterprise solutions page 24
Optionals page 32
IP cameras page 36
Encoders page 49
Accessories page 50
CAMERAS
Day & Night colour cameras page 52
Colour cameras page 61
Black and white cameras page 63
TCP/IP systems page 64
Speed dome cameras page 65
Keypads page 68
Accessories for speed dome cameras
page 69
Waterproof housings and brackets page 70
Lenses page 72
Infrared illuminators page 74
IP SYSTEMS ANALOGUE SYSTEMS
Day & Night colour cameras with IR
BEST OVERVIEW Day & night colour cameras
BEST OVERVIEW
3
PRICE LIST E1
ACCESSORIES
Power supply units page 75
Transformers page 76
Distributors page 76
Video ampliers page 77
MONITORS
LCD-TFT colour monitors page 78
Accessories for LCD-TFT Monitors page 80
VIDEO RECORDERS CCTV
Digital video recorders pag. 87
DVR with TFT/LCD Colour Monitor pag. 91
CCTV
B/W CCTV kits pag. 95
Colour CCTV kits pag. 96
Passive transducers pag. 98
Active transducers pag. 100
Isolators - Repeaters pag. 103
RS 485 distributors pag. 104
CCTV accessories pag. 105
Day & Night colour cameras with IR BEST OVERVIEW
Day & night colour cameras BEST OVERVIEW
PRICE LIST E1
4
The new Elvox headquarters have been built in
Campodarsego, in the province of Padua. The 30,000 m2
installation is home to all of the company's activities
and expresses its dynamic and highly innovation-driven
character. The production building is comfortable and
functional, while the ofce environment is bright and
efcient, with a unique architecture that, in the future, will
continue to dene the image of Elvox.
The heart of the plant is surmounted by a at elliptical
roof, like an immense sail covered with curved aluminium
panels. Its rounded shape brings to mind an airship
tethered at each end and along the front by giant cables,
ready to break away from the ground and rise skywards,
taking with it the spacious cab and bridge.
Company
Dynamic and innovation-driven
Day & Night colour cameras with IR
BEST OVERVIEW Day & night colour cameras
BEST OVERVIEW
5
PRICE LIST E1
It lifts off from the water, which accentuates its upward
reach, exalting and reecting its transparency and drawing
attention to the pathways leading to the main entrance.
Besides its compositional design and the attention paid
to architectural aspects, the new facility is the result of
a specic space planning study centred on both the
production area and the ofces.
Its distributional organisation is based on: creation of open-
plan ofce spaces that are easy to modify; optimisation of
pathways both horizontal and and vertical to facilitate staff
interaction and integration; concentration of all showpiece
spaces and areas for meeting the public, with specially
equipped conference rooms.
Day & Night colour cameras with IR BEST OVERVIEW
Day & night colour cameras BEST OVERVIEW
PRICE LIST E1
6
Elvox by Arteco
Founded in 1954, Elvox, an Italian company at the
forefront of the electronic equipment sector, is increasingly
demonstrating its capacity for innovation based on its
cutting-edge technology and groundbreaking expertise.
The CCTV business is becoming of equal importance to
that of video door entry systems and the company has
been developing these products more than 15 years,
supplying accessories to complement video door entry
installations.
New technologies, new market opportunities, growing
public interest in security and the company's increasingly
organised structure have prompted Elvox to seek new
avenues for the growth of the CCTV sector, including
its partnership with Arteco, an Italian leader in IP video
surveillance systems, which is just the latest in a series of
initiatives.
The pursuit of excellence unites two Italian companies,
both leaders in their respective sectors. The Arteco-Elvox
partnership aims to supply tailor-made IP solutions to even
less expert users, with a professional and versatile range
Day & Night colour cameras with IR
BEST OVERVIEW Day & night colour cameras
BEST OVERVIEW
7
PRICE LIST E1
of products structured for different types of installation, as
well as professional technical and sales support delivered
through a pervasive network.
Elvox sees IP technology as a way to signicantly reinforce
and implement its range of CCTV solutions, which already
comprises an extensive catalogue of proposals for
analogue installations, including DVRs, video cameras,
monitors, accessories, and now even IP systems complete
with dedicated cameras and hybrid systems.
Arteco software and hardware solutions are designed
and produced in Italy at the company's Faenza plant.
The integrated design of these elements, without reliance
on subcontractors, is a dening trait of the Emilia-Romagna
based company, which enjoys a nationwide reputation as
an end-to-end solution provider.
Being responsible for the entire software development,
design and manufacturing process has similarly been a
longstanding component of the Elvox winning strategy,
enabling the rm to directly customise and improve its
range on an ongoing basis.
Day & Night colour cameras with IR BEST OVERVIEW
Day & night colour cameras BEST OVERVIEW
PRICE LIST E1
8
Network video technology, often referred to as
'video surveillance over' IP or 'surveillance over
IP' when applied to the security sector, uses a
wired or wireless IP network as a backbone for the
transportation of digital audio/video and other data.
This is made possible by PoE (Power over Ethernet)
technology, whereby equipment is powered using
the same cable that connects it to the Ethernet data
network.
A network video system enables video data to
be monitored and recorded from any point in the
network, whether it be a Local Area Network (LAN) or
Wide Area Network (WAN), such as the Internet.
IP Technology
Day & Night colour cameras with IR
BEST OVERVIEW Day & night colour cameras
BEST OVERVIEW
9
PRICE LIST E1
Day & Night colour cameras with IR BEST OVERVIEW
Day & night colour cameras BEST OVERVIEW
PRICE LIST E1
10
ETHERNET
ETHERNET
PoE
PoE
PoE
PoE
PoE
PoE
SERVER
SERVER
SERVER
UMTS
ROUTER
ETHERNET
ETHERNET
Headquarters
Oce
1
Branch
oce
Oce
2
INTERNET
PTZ IP
PTZ IP
analog
PTZ
WiFi
Network
Control
workstation
Control
workstation
VIDEO
SERVER
IP-CAM
IP-CAM IP-CAM
IP-CAM IP-CAM
Video
PAL/NTSC
analog
PTZ
VIDEO
SERVER
Video
PAL/NTSC
IP WiFi
ADSL
Remote accessibility
Network cameras and video encoders can be
congured and managed remotely, enabling multiple
authorised users to view live and recorded content at
any time, from any network location in the world.
High image quality
In video surveillance, image quality is fundamental
to acquiring clear images and identifying people and
objects. With progressive scan technologies and IP
cameras with megapixel resolution, it is possible to
deliver better quality images at a higher resolution
than an analogue camera.
Event control and intelligent video
When there is too much recorded video material
and insufcient time to analyse it properly, network
cameras and integrated analysis can solve this
problem by reducing the amount of uninteresting
recordings and allowing the use of programmed
responses. These functionalities are not available in
an analogue system.
The Advantages of IP Video Surveillance
Day & Night colour cameras with IR
BEST OVERVIEW Day & night colour cameras
BEST OVERVIEW
11
PRICE LIST E1
ETHERNET
ETHERNET
PoE
PoE
PoE
PoE
PoE
PoE
SERVER
SERVER
SERVER
UMTS
ROUTER
ETHERNET ETHERNET
Headquarters
Oce
1
Branch
oce
Oce
2
INTERNET
PTZ IP
PTZ IP
analog
PTZ
WiFi
Network
Control
workstation
Control
workstation
VIDEO
SERVER
IP-CAM
IP-CAM IP-CAM
IP-CAM IP-CAM
Video
PAL/NTSC
analog
PTZ
VIDEO
SERVER
Video
PAL/NTSC
IP WiFi
ADSL
Simple integration and expandability
All network video systems based on open standards
can be easily integrated with: information systems
with Ethernet connection, audio or security
systems and other digital devices, thanks to video
management software.
Scalability and exibility
A system with IP technology can be expanded
based on users' needs, enabling the addition of a
large number of IP cameras and video encoders.
The shared network can be wired or wireless. It
is therefore possible to progressively increase
the number of IP products in the system, without
changing the network infrastructure.
Day & Night colour cameras with IR BEST OVERVIEW
Day & night colour cameras BEST OVERVIEW
PRICE LIST E1
12
System functionalities
Power supply
Fanless
iPhone
Web browser
High Availability
Maps
Joystick
FPS
Wireless
Centralisation
Hard Disk
Burner
Two-way
GPS
Km/h
Email Audio
I-O
Motion
External power supply
12V, 80W
Does not make use
of cooling fans
View images via
smartphone including
iPhone
Joystick for PTZ control
from PC client
Compression type and
maximum frame rate
On-demand remote
connection with
UMTS modem
Two-way audio from
client to server
GPS antenna for
location tracking
Maximum licence plate
recognition speed
Access with Web client
directly from Internet
browser
Redundant recording
on remote client
Upload map of locality
or site in JPEG or
GIF format
Communication of
audio, video and vehicle
position to control room
500 GB, 1 TB
Option to include a
disk burner on request
System sends e-mail
notications and audio
in alarm mode
Indicates whether I/Os
are present in the server
or handled as optionals
Indicates the type
of motion detector
installed in the server
Day & Night colour cameras with IR
BEST OVERVIEW Day & night colour cameras
BEST OVERVIEW
13
PRICE LIST E1
Multiserver
SMS-MMS
Access points
Analysis
Gate camera
Privacy
Inputs
RAID
Users
Parking
SQLServer
O/S
Perspective
Trafc
Centralised control of
multiple servers from a
single workstation
Send SMS or MMS
messages to a specied
mobile phone number
Maximum number of
access points in an
Elvox Gate system
Parking management
function
Transfer to licence plate
database compatible
with Microsoft Excel
Platform used
by Windows XP
Embedded server
Privacy zone setup
function
Number of channels
that can be analysed
(analogue, hybrid, IP)
Abandoned object
control, no parking,
access point counting,
speed control
Special licence plate
reading camera
Image perspective
analysis
Vehicle counting,
classication, wrong
way detection, queue
detection
Memory expansion with
RAID devices up to 4TB
Indicates simultaneous
connections as well as
accounts
Day & Night colour cameras with IR BEST OVERVIEW
Day & night colour cameras BEST OVERVIEW
PRICE LIST E1
14
Hardware solutions up to 12 IP channels suitable for small-scale
installations.
Designed with the same reliable technology and offering the same
outstanding performance as our higher specication products, SMALL
BUSINESS solutions are ideal for creating simple and efcient CCTV
installations.
Small Business Solutions
Day & Night colour cameras with IR
BEST OVERVIEW Day & night colour cameras
BEST OVERVIEW
15
PRICE LIST E1
Day & Night colour cameras with IR BEST OVERVIEW
Day & night colour cameras BEST OVERVIEW
PRICE LIST E1
16
300E series
Active video surveillance
for small installations
from 4 to 12 IP channels
CONFIGURATION
UP TO
12 IP CH
1 CONNECTION
2 ACCOUNTS
(expandable)
O.S. Windows XP
Embedded
Record
View
Native IP
Web client Remote view via
Smartphone and
iPhone
500GB
HARD DISK
MOTION
DETECTION
Small Business
OPTIONAL
WIRELESS KIT
On-demand connection
with UMTS modem
Advanced Privacy
Filter
JOYSTICK for
PTZ control
Multiserver
control
300E is the ideal Elvox solution for simple and efcient digital CCTV installations. It
is discreet, can be installed in a matter of minutes and is ideal for indoor installations
(public premises, retail outlets, ofces, small businesses and residential installations).
300E can receive, display and record IP video sources (cameras and video
servers), with high-tech Elvox by Arteco software for efcient and versatile image
management.
The Elvox by Arteco-Logic software interface makes it easy and intuitive to use,
enabling remote access to data and images at any time and from any location
with the multiclient facility. It allows images to be exported instantly and without
compromising the security of the images themselves.
Equipped with a special wireless module, 300E is able to make images available
online even without ASDL coverage.
With its special and exclusive image blurring software module (optional), 300E
enables full compliance with applicable Privacy regulations, with password-controlled
playback of recordings in “clear” mode.
300E can handle images captured by numerous models of camera from the leading
international manufacturers.
TYPE 5253/4 € 1,715.00
Digital NVR with 4 IP video channels (500 GB HDD)
Day & Night colour cameras with IR
BEST OVERVIEW Day & night colour cameras
BEST OVERVIEW
17
PRICE LIST E1
PTZ
UMTS/SMS
GPRS
UMTS
ELVOX 300E
IP-CAM
ETHERNET
INTERNET
ADSL
LOGIC
LOGIC
LOGIC
PoE
SPECIFICATIONS
• Supply voltage 12 VDC, power cons.
60 W
• External adapter 230/110 VAC-12 VDC
• Operating temperature 0 - 40 °C, max
RH 80% n.c.
• Dimensions in mm: 210 x 55 x 210
WxHxD
• Weight: 1.6 kg
SOFTWARE
• From 4 to 12 IP sources
• Operating System Windows XP
Embedded
• Uniqueness of local and remote
interfaces
• Simultaneous Multiserver control
• Multiclient control
• Codec video compression
recording
- Native encoding for IP cameras
• Codec video compression display
- MJPEG software encoding
- MPEG4 software encoding
- Native encoding for IP cameras
• IP camera performance
- Dependent on brand, resolution and
number of sources in operation
- Use of native protocols to achieve
manufacturer's stated performance
• Motion detection
• For each channel, independent
regulation of:
- Resolution
- Frame rate
- Quality
- Continuous recording with event
marking
- Pre-event queue up to 10 minutes
• Layout: up to 7x7 – Congurable
layouts – digital zoom
• 5 event notication modes
- Visual: red frame image, event logs,
pop-up mode
- Audible: WAV, MP3, PC buzzer
- Email: HTML with photos and text
- I/O: through integrated IP cameras
- SMS (optional)
• PTZ control
- Manual (optional joystick)
- Automatic (programmable presets
and sequences)
• 3 different levels of user rights
- User, Power User, Administrator
• Access licences for Elvox
by Arteco-Logic or Elvox by
Arteco-Mobile
- 1 connection, 2 user accounts
- optional upgrade
HARDWARE
• 500GB HDD
• 2 PS/2 ports
• 4 USB 2.0 ports
• 1 VGA output
• 1 1GB Ethernet port
• 1 2.5 mm audio jack output
• 1 2.5 mm microphone input
• 12 V power supply connector
App for iPhone
and iPad
Day & Night colour cameras with IR BEST OVERVIEW
Day & night colour cameras BEST OVERVIEW
PRICE LIST E1
18
Hardware solutions up to 32 analogue channels or up to 72 IP channels
suitable for medium-sized installations.
Designed with the same reliable technology and offering the same
outstanding performance as our higher specication products,
together with various advanced motion detection functions to minimise
false events, the solutions in our Professional line offer an excellent
performance-price ratio.
Professional Solutions
Day & Night colour cameras with IR
BEST OVERVIEW Day & night colour cameras
BEST OVERVIEW
19
PRICE LIST E1
Day & Night colour cameras with IR BEST OVERVIEW
Day & night colour cameras BEST OVERVIEW
PRICE LIST E1
20
UP TO
8
ANALOGUE CH
OR 12 IP CH
2 CONNECTIONS
2 ACCOUNTS
(expandable)
View via PDA
O.S. Windows XP
Embedded
25FPS
4CIF (analogue)
Megapixel (IP)
500GB
HARD DISK
MOTION
DETECTION
Professional
PRIVACY FILTER
Multiserver
control
Web client
400E series
Active video surveillance for
small and medium installations
Up to 4 analogue channels
Up to 12 IP channels
CONFIGURATION
OPTIONAL
Compact and powerful, 400E can analyse up to 8 analogue channels or
12 IP channels, with Active Video Surveillance functions.
Each 400E can receive and record analogue or IP sources, analysing images
simultaneously and minimising redundant event signalling.
The powerful analysis functions enable the 400E to track the movement of objects
(e.g. people and vehicles) to detect in a reliable way whether a certain area has been
violated.
With its special and exclusive image blurring software module, 400E enables full
compliance with applicable Privacy regulations, with password-controlled playback
of recordings in “clear” mode.
Remote recording and playback at 25 FPS and 4-CIF resolution thanks to powerful
H264 hardware compression cards on all analogue video channels.
Remote recording and playback at 25 FPS and megapixel resolution with compatible
IP cameras (MJPEG - MPEG4 - H264 - MxPEG).
Expandable and exible: multiple 400E units can be integrated and controlled from a
single computer equipped with the Elvox by Arteco-Logic application.
When installed on a computer, the Elvox by Arteco-Logic software application gives
local and remote control over all functions.
400E can handle images captured by numerous models of camera from the leading
international manufacturers.
WIRELESS KIT
On-demand connection
with UMTS modem
Hardware I/Os
Logical I/Os
MAPS
PLUG-IN
JOYSTICK for
PTZ control
Perspective
MOTION
DETECTION
ENTERPRISE
TYPE 5254/A4 € 3,892.00
Digital DVR with 4 analogue video channels (500GB HDD)
TYPE 5254/A8 € 5,292.00
Digital DVR with 8 analogue video channels (500GB HDD)
TYPE 5254/4 € 3,052.00
Digital NVR with 4 IP video channels (500GB HDD)
Day & Night colour cameras with IR
BEST OVERVIEW Day & night colour cameras
BEST OVERVIEW
21
PRICE LIST E1
PTZ
UMTS/SMS
GPRS
UMTS
ELVOX 400E
IP-CAM Video
PAL/NTSC
ETHERNET
INTERNET
PoE
ADSL
LOGIC
LOGIC
SOFTWARE
• Operating System Windows
Embedded
• Operating System partition write
protection (optional)
• Uniqueness of local and remote
interfaces
• Codec video compression
recording
- H264 hardware encoding
- Native encoding for IP cameras
• Codec video compression display
- H264 hardware encoding
- MJPEG software encoding
- MPEG4 software encoding
- Native encoding for IP cameras
• Max display frame rate
- Analogue channel: up to 25 FPS @
704 x 576 (4CIF)
- IP channel: compatible with
megapixel full-frame resolution
• Max recording frame rate
- Analogue channel: up to 25 FPS @
704 x 576 (4CIF)
- IP channel: compatible with
megapixel full-frame resolution
- Certication on non-manipulation of
recorded images
• Network transmission rate
(352x288@10FPS, quality 75%):
- 60 Kbps for static images
- 180 Kbps for moving images
• 14 independent lters for each
video channel to minimise
redundant events
• Simple mode to adjust sensitivity
• Logical I/Os for PTZ tilt on event
(optional)
• For each channel, independent
regulation of:
- Resolution
- Frame rate
- Quality
- Continuous and event recording
- Pre-event queue up to 10 minutes
• Layout: up to 7x7 – Congurable
layouts – digital zoom
• 5 event notication modes
- Visual: red frame image, event logs,
pop-up mode
- Audible: WAV, MP3, PC buzzer
- Email: HTML with photos and text
- I/O: through integrated IP cameras
- SMS (optional)
• Manual and automatic PTZ control
• 3 different levels of user rights
- User, Power User, Administrator
• Access licences for Elvox
by Arteco-Logic or Elvox by
Arteco-Mobile
- 2 connections, 2 user accounts
- optional upgrade
HARDWARE
• 4-8 analogue video inputs
(PAL/NTSC) or up to 12 IP sources
• Dedicated hardware with H264
compression board
• 500 GB hard disk capacity
• Internal digital I/Os (optional):
- 4 inputs 0 - 12 VDC
- 4 outputs NO/NC, 1 A @ 24 VDC
• External digital I/Os, up to 31
modules of 8 I/Os:
- 8 inputs 0 - 12 VDC (optional)
- 8 outputs NO/NC, 1 A @ 30 VDC,
0.5 A @ 250 VAC (optional)
• Software on Compact Flash
• 2 PS/2 ports for mouse and
keyboard
• 2 USB 2.0 ports
• 9-pin RS-422/485 half duplex port
for PTZ control (optional)
• 1 25-pin LPT port
• 1 RS232 port
• 9-pin RS232 port for optional
external serial I/O modules
• 1 VGA output
• 1 100 Mbps Ethernet port
• 1 2.5 mm audio jack output
• 1 2.5 mm microphone input
SPECIFICATIONS
• Supply voltage 110 - 230 VAC,
50 - 60 Hz, power cons. 100 W
• Operating temperature 0 - 40 °C,
max RH 80% n.c.
• Dimensions in mm: 340 x 100 x 225
WxHxD
• Weight: 5 kg
App for iPhone
and iPad
Day & Night colour cameras with IR BEST OVERVIEW
Day & night colour cameras BEST OVERVIEW
PRICE LIST E1
22
UP TO
32
ANALOGUE CH
OR 72 IP CH
2 CONNECTION
2 ACCOUNTS
(expandable)
View via PDA
O.S. Windows XP
Embedded
25FPS
4CIF (analogue)
Megapixel (IP)
1 TB
HARD DISK
MOTION
DETECTION
Professional
PRIVACY FILTER
Multiserver
control
Web client
Perspective
600E series
Active video surveillance for
medium and large installations
Up to 32 analogue channels
up to 72 IP channels
CONFIGURATION
OPTIONAL
Able to analyse up to 32 analogue video sources or 72 IP sources, 600E is the
industrial video surveillance device in 19" rack format with Active event notication.
Instantly receiving these signals, users can display live images and corresponding
recordings in real time.
The powerful analysis functions enable the 600E to identify the movement of objects
(e.g. people and vehicles) to detect in a reliable way whether a certain area has been
violated.
With its special and exclusive image blurring software module, 600E enables full
compliance with applicable Privacy regulations, with password-controlled playback
of recordings in “clear” mode.
Remote recording and playback at 25FPS and 4CIF resolution with H264 hardware
compression available on all channels.
Remote recording and playback at 25 FPS and Megapixel Resolution with
compatible IP cameras (MJPEG - MPEG4 - H264 - MxPEG).
Expandable and exible: multiple 600E units can be integrated and controlled
from a single workstation using our Elvox by Arteco-Logic management software.
This software can be installed on multiple workstations to enable simultaneous
control by multiple operators.
Stringent testing and solid construction make the 600E the ideal product to
withstand even the most critical environmental conditions. 600E is equipped with
robust ltering functions to limit redundant signalling.
600E can handle images captured by numerous models of camera from the leading
international manufacturers.
WIRELESS KIT
On-demand connection with
UMTS modem
Hardware I/Os
Logical I/Os
MAPS
PLUG-IN
JOYSTICK for
PTZ control
MOTION
DETECTION
ENTERPRISE
4 TB RAID-5
(2 +2 TB – hot swap)
DVD burner
TYPE 5286/A8 € 6,076.00
Digital NVR with 8 analogue video channels (1TB HDD)
TYPE 5286/A16 € 8,092.00
Digital NVR with 16 analogue video channels (1TB HDD)
TYPE 5286/A32 € 14,672.00
Digital DVR with 32 analogue video channels (1TB HDD)
TYPE 5286/8 € 4,452.00
Digital NVR with 8 IP video channels (1TB HDD)
Day & Night colour cameras with IR
BEST OVERVIEW Day & night colour cameras
BEST OVERVIEW
23
PRICE LIST E1
PTZ
UMTS/SMS
GPRS
UMTS
ELVOX 600E
IP-CAM Video
PAL/NTSC
ETHERNET
INTERNET
ADSL
LOGIC
LOGIC
PoE
SOFTWARE
• Operating System Windows
Embedded
• Operating System partition write
protection (optional)
• Uniqueness of local and remote
interfaces
• Codec video compression
recording
- H264 hardware encoding
- Native encoding for IP cameras
• Codec video compression display
- H264 hardware encoding
- MJPEG software encoding
- MPEG4 software encoding
- Native encoding for IP cameras
• Max display frame rate
- Analogue channel: up to 25 FPS @ 704 x
576 (4CIF)
- IP channel: compatible with
megapixel full-frame resolution
• Max recording frame rate
- Analogue channel: up to 25 FPS @ 704 x
576 (4CIF)
- IP channel: compatible with
megapixel full-frame resolution
- Certication on non-manipulation of
recorded images
• Network transmission rate
(352x288@10FPS and quality 75%):
- 60 Kbps for static images
- 180 Kbps for moving images
• 14 independent lters for each
video channel to minimise
redundant events
• Simple mode to adjust sensitivity
• Logical I/Os for PTZ tilt on event
(optional)
• For each channel, independent
regulation of:
- Resolution
- Frame rate
- Quality
- Continuous and event recording
- Pre-event queue up to 10 minutes
• Layout: up to 7x7 – Congurable
layouts – digital zoom
• 5 event notication modes
- Visual: red frame image, event logs,
pop-up mode
- Audible: WAV, MP3, PC buzzer
- Email: HTML with photos and text
- I/O: through integrated IP cameras
- SMS (optional)
• Manual and automatic PTZ control
• 3 different levels of user rights
- User, Power User, Administrator
• Access licences for Elvox
by Arteco-Logic or Elvox by
Arteco-Mobile
- 2 connections, 2 user accounts
- optional upgrade
HARDWARE
• 8-16-32 analogue video inputs
(PAL/NTSC) or up to 72 IP sources
• Dedicated hardware with H264
compression board
• 1 TB hard disk capacity (MAX 4
HDD X 1 TB) (expandable) RAID 5
optional
• Internal digital I/Os (optional):
- 4 inputs 0 - 12 VDC
- 4 outputs NO/NC, 1 A @ 24 VDC
• External digital I/O, up to 31
modules of 8 I/O:
- 8 inputs 0 - 12 VDC (optional)
- 8 outputs NO/NC, 1 A @ 30 VDC,
0.5 A @ 250 VAC (optional)
• Software on Compact Flash
• DVD burner (optional)
• (x2) PS/2 ports for mouse and
keyboard
• (x6) USB 2.0 ports (2 front and
4 rear)
• 9-pin RS-422/485 half duplex port
for PTZ control
• 9-pin RS232 port for optional
external serial I/O modules
• 25-pin LPT port
• VGA output
• 1 Gbps Ethernet port
• 2.5 mm audio jack output
• 2.5 mm microphone input
App for iPhone
and iPad
SPECIFICATIONS
• Supply voltage 230 VAC, 50Hz,
power cons. 120 W
• Operating temperature 0 - 40 °C,
max RH 80% n.c.
• Dimensions in mm: 425 x 170 x 480
WxHxD
• Handles front +30 mm
• RAID depth + 60 mm
• Weight: 16.7 kg
Day & Night colour cameras with IR BEST OVERVIEW
Day & night colour cameras BEST OVERVIEW
PRICE LIST E1
24
Hardware solutions up to 32 hybrid channels or up to 72 IP channels
suitable for large installations.
Software solutions for handling an unlimited number of servers and
cameras.
Top performance, advanced motion detection with additional
backgrounds and lters for maximum congurability and effective video
analysis.
Enterprise Solutions
Day & Night colour cameras with IR
BEST OVERVIEW Day & night colour cameras
BEST OVERVIEW
25
PRICE LIST E1
Day & Night colour cameras with IR BEST OVERVIEW
Day & night colour cameras BEST OVERVIEW
PRICE LIST E1
26
UP TO
8 HYBRID
CH
OR 16 IP CH
4 CONNECTION
4 ACCOUNTS
(expandable)
View via PDA
O.S. Windows XP
Embedded
25FPS
4CIF (analogue)
Megapixel (IP)
500GB
HARD DISK
MOTION
DETECTION
Enterprise
PRIVACY FILTER
Multiserver
control
Web clientMAPS PLUG-INPERSPECTIVE
500E series
Active video surveillance for
small and medium installations
Up to 8 hybrid channels
Up to 16 IP channels
CONFIGURATION
OPTIONAL
Compact and powerful, 500E can simultaneously analyse up to 8 hybrid channels or
16 IP channels, minimising redundant event signalling.
Remote recording and playback at 25FPS and 4CIF resolution with H264 hardware
compression on all analogue video channels.
Remote recording and playback at 25 FPS and Megapixel Resolution with
compatible IP cameras (MPEG - MPEG4 - H264 - MxPEG).
500E is offered with an advanced analytics conguration for reliable motion event
detection thanks to the “Violated Area” control and the numerous included lters,
including perspective correction.
With its special and exclusive image blurring software module, 500E enables full
compliance with applicable Privacy regulations, with password-controlled playback
of recordings in “clear” mode.
Expandable and exible: multiple 500E units can be integrated and controlled from
a single computer equipped with the Elvox by Arteco-Logic application, which can
be installed on a computer to allow local and remote control of all functions. Using a
second monitor it is possible to view interactive maps of installed cameras.
500E can handle images captured by numerous models of camera from the leading
international manufacturers.
4 hardware I/Os
Logical I/Os
WIRELESS KIT
On-demand connection
with UMTS modem
High Availability
TRAFFIC PLUG-IN
Vehicle counting -
Classication - Queue
detection -
Wrong way
detection
PRO PLUG-IN
Abandoned object -
No parking - Access
point counting - Speed control
JOYSTICK for
PTZ control
TYPE 5255/I4 € 5,607.00
Digital NDVR with 4 hybrid video channels (500GB HDD)
TYPE 5255/I8 € 7,070.00
Digital NDVR with 8 hybrid video channels (500GB HDD)
TYPE 5255/4 € 4,396.00
Digital NVR with 4 IP video channels (500GB HDD)
Day & Night colour cameras with IR
BEST OVERVIEW Day & night colour cameras
BEST OVERVIEW
27
PRICE LIST E1
PTZ
UMTS/SMS
GPRS
UMTS
ELVOX 500E
IP-CAM Video
PAL/NTSC
ETHERNET
INTERNET
PoE
ADSL
LOGIC
LOGIC
SOFTWARE
• Operating System Windows
Embedded
• O.S. partition write protection
(optional)
• Uniqueness of local and remote
interfaces
• Codec image compression
recording and display
- H264 hardware encoding
- MJPEG software encoding
- MPEG4 software encoding
- Native encoding for IP cameras
• Total display frame rate for
16 channels
- Analogue channel: up to 25 FPS @
704 x 576 (4CIF)
- IP channel: compatible with
megapixel full-frame resolution
• Total recording frame rate for
16 channels
- Analogue channel: up to 25 FPS @
704 x 576 (4CIF)
- IP channel: compatible with
megapixel full-frame resolution
- Certication on non-manipulation of
recorded images
• Network transmission rate
(352x288@10FPS, quality 75%):
- 60 Kbps for static images
- 180 Kbps for moving images
• 18 independent lters for each
video channel to minimise
redundant events
• High Availability (optional)
• Simple and Advanced mode to
adjust sensitivity
• Logical I/Os for PTZ tilt on event
• Perspective correction
• Interactive maps
• For each channel, independent
regulation of:
- Resolution
- Frame rate
- Quality
- Continuous and/or event recording
- Pre-event queue up to 10 minutes
• Layout: up to 7x7 – Congurable
layouts – digital zoom
• 5 event notication modes
- Visual: red frame image, event logs,
pop-up mode
- Audible: WAV, MP3, PC buzzer
- Email: HTML with photos and text
- I/O: through integrated IP cameras
- SMS (optional)
• Manual or automatic PTZ control
• 3 different levels of user rights
- User, Power User, Administrator
• Access licences for Arteco-Logic or
Arteco-Mobile
- 4 connections, 4 user accounts
- optional upgrade
HARDWARE
• 4-8 hybrid channels (PAL, NTSC or
IP), up to 16 IP-only channels
• Dedicated hardware with H264
compression board
• Hard disk capacity: 500 GB
(expandable)
• Internal digital I/Os:
- 4 inputs 0 - 12 VDC
- 4 outputs NO/NC, 1 A @ 24 VDC
• External digital I/O, up to 31
modules of 8 I/O:
- 8 inputs 0 - 12 VDC (optional)
- 8 outputs NO/NC, 1 A @ 30 VDC,
0.5 A @ 250 VAC (optional)
• Software on Compact Flash
• (x2) PS/2 ports for mouse and
keyboard
• (x4) USB 2.0 ports
• 9-pin RS-422/485 half duplex port
for PTZ control
• 9-pin RS232 port for optional
external serial I/O modules
• 25-pin LPT port
• VGA output
• 1 Gbps Ethernet port
• 2.5 mm audio jack output
• 2.5 mm microphone input
App for iPhone
and iPad
SPECIFICATIONS
• Supply voltage 230 VAC, 50 Hz,
power cons. 80 W
• Operating temperature 0 - 40 °C,
max RH 80% n.c.
• Dimensions in mm: 85 x 360 x 290
WxHxD
• Weight: 5.2 kg
Day & Night colour cameras with IR BEST OVERVIEW
Day & night colour cameras BEST OVERVIEW
PRICE LIST E1
28
UP TO
8
ANALOGUE CH
12 IP CH
2 CONNECTION
2 ACCOUNTS
(expandable)
View via PDA
O.S. Windows XP
Embedded
25FPS
4CIF (analogue)
Megapixel (IP)
500GB
HARD DISK
MOTION
DETECTION
Professional
PRIVACY FILTER
Multiserver
control
Web clientMAPS PLUG-INPERSPECTIVE
CONFIGURATION
4 hardware I/Os
Logical I/Os
700E series
Active video surveillance for
large installations
Up to 32 hybrid channels
Up to 72 IP channels
OPTIONAL
Able to analyse up to 72 analogue video sources or 32 IP sources, 700E is
the industrial video surveillance device in 19" rack format with Active event
notication to users. Instantly receiving these signals, they can display live
images and corresponding recordings in real time.
700E is offered with an advanced analytics conguration for reliable motion
event detection thanks to the “Violated Area” control and the numerous included
lters, including perspective correction.
With its special and exclusive image blurring software module, 700E enables
full compliance with applicable Privacy regulations, with password-controlled
playback of recordings in “clear” mode. Includes option of inserting blurred ares
for privacy purposes, which can subsequently be removed by authorised users.
Remote recording and playback at 25FPS, 4CIF resolution with H264 hardware
compression for each analogue channel.
Remote recording and playback at 25 FPS and Megapixel Resolution with
compatible IP cameras (MJPEG - MPEG4 - H264 - MxPEG).
Expandable and exible: multiple 700E units can be integrated and controlled
from a single workstation using our Elvox by Arteco-Logic management
software, which can be installed on multiple workstations to enable simultaneous
control by multiple operators.
Stringent testing and solid construction make the 700E the ideal product to
withstand even the most critical environmental conditions.
700E can handle images captured by numerous models of camera from the
leading international manufacturers.
WIRELESS KIT
On-demand connection
with UMTS modem
TRAFFIC PLUG-IN
Vehicle counting - Classication
- Queue detection -
Wrong
way detection
JOYSTICK for
PTZ control
4 TB RAID-5
(2 +2 TB – hot swap)
DVD burner
TYPE 5287/I8 € 8,372.00
Digital NDVR with 8 hybrid video channels (1 TB HDD)
TYPE 5287/I16 € 11,312.00
Digital NDVR with 16 hybrid video channels (1 TB HDD)
TYPE 5287/I32 € 20,972.00
Digital NDVR with 32 hybrid video channels (1 TB HDD)
TYPE 5287/8 € 6,412.00
Digital NVR with 8 IP video channels (1 TB HDD)
High Availability
PRO PLUG-IN
Abandoned object -
No parking - Access
point counting - Speed control
Day & Night colour cameras with IR
BEST OVERVIEW Day & night colour cameras
BEST OVERVIEW
29
PRICE LIST E1
PTZ
UMTS/SMS
GPRS
UMTS
ELVOX 700E
IP-CAM Video
PAL/NTSC
ETHERNET
INTERNET
PoE
ADSL
LOGIC
LOGIC
SOFTWARE
• Operating System Windows XP
Embedded
• O.S. partition write protection
(optional)
• Desktop protected for User
• Uniqueness of local and remote
interfaces
• Codec image compression
recording and display
- H264 hardware encoding
- MJPEG/MPEG4 software encoding
- Native encoding for IP cameras
• Total display frame rate for 32
channels
- Analogue channel: up to 25 FPS @ 704 x
576 (4CIF)
- IP channel: compatible with megapixel
full-frame resolution
• Total recording frame rate for 32
channels
- Analogue channel: up to 25 FPS @ 704 x
576 (4CIF)
- IP channel: compatible with megapixel
full-frame resolution
- Certication on non-manipulation of
recorded images
• Network transmission rate
(352x288@10FPS and quality 75%):
- 60 Kbps for static images
- 180 Kbps for moving images
• 18 independent lters for each video
channel to minimise redundant
events
• High Availability (optional)
• Simple and Advanced mode to
adjust sensitivity
• Logical I/Os for PTZ tilt on event
• Perspective correction
• Interactive maps
• For each channel, independent
regulation of:
- Resolution
- Frame rate
- Quality
- Continuous and/or event recording
- Pre-event queue up to 10 minutes
• Layout: up to 7x7 – Congurable
layouts – digital zoom
• 5 event notication modes
- Visual: red frame image, event logs,
pop-up mode
- Audible: WAV, MP3, PC buzzer
- Email: HTML with photos and text
- I/O: through integrated IP cameras
- SMS (optional)
• Manual or automatic PTZ control
• 3 different levels of user rights
- User, Power User, Administrator
• Access licences for Arteco-Logic or
Arteco-Mobile
- 4 connections, 4 user accounts
- optional upgrade
HARDWARE
• 8-16-32 hybrid channels (PAL/
NTSC/IP) or up to 72 IP-only
channels
• Dedicated hardware with H264
compression
• Hard disk capacity: 1 TB (MAX 4
HDD x 1 TB) (expandable) RAID5
optional
• Internal digital I/Os:
- 4 inputs 0 - 12 VDC
- 4 outputs NO/NC, 1 A @ 24 VDC
• External digital I/O, up to 31
modules of 8 I/O:
- 8 inputs 0 - 12 VDC (optional)
- 8 outputs NO/NC, 1 A @ 30 VDC, 0.5
A @ 250 VAC (optional)
• Software on Compact Flash
• DVD burner (optional)
• (x2) PS/2 ports for mouse and
keyboard
• (x6) USB 2.0 ports (2 front and 4
rear)
• 9-pin RS-422/485 half duplex port
for PTZ control
• 9-pin RS232 port for optional
external serial I/O modules
• VGA output
• 1 Gbps Ethernet port
• 2.5 mm audio jack output
• 2.5 mm microphone input
SPECIFICATION
• Supply voltage 230 VAC, 50 Hz,
power cons. 120 W
• Operating temperature 0 - 40 °C,
max RH 80% n.c.
• Dimensions in mm: 425 x 480 x 170
WxHxD
• Handles front +30 mm
• RAID depth + 60 mm
• Weight: 16.7 Kg
App for iPhone
and iPad
Day & Night colour cameras with IR BEST OVERVIEW
Day & night colour cameras BEST OVERVIEW
PRICE LIST E1
30
Web client
GATE series
Customisable and scalable
licence plate reading system
based on web client
Versatile, simple to use and customisable, GATE is the licence plate reading system
designed to handle from 1 to 4 vehicle access points from each server.
Multiple servers can be managed simultaneously from one application through the
web client, to increase the number of access points that can be monitored by a
single application.
The process of plate recognition can be triggered in real time when the vehicle
passes in front of the camera or by triggering an I/O connected to GATE.
The monitoring function is facilitated by different viewing modes that enable both the
vehicle and the driver's photo to be displayed at the same time.
Digital I/O modules enable the system to be integration with other devices such as
automatic gates, infrared sensors, magnetic loops and alarms.
The performance of GATE can be maximised by using special licence plate
recognition video cameras with infrared optical lter and high power LEDs.
Instant email
or audible
notications
O.S. Windows XP
Embedded
Licence plate
reading up to
250 km/h without
trigger
From 1 to 4
access points
Parking
Management
EXCEL
compatible
CONFIGURATION
OPTIONAL
Special licence
plate reading
camera
SMS notication
Special camera for reading licence plates in any
lighting conditions, dedicated to the Elvox Gate
series, 1/3" Sony Exview sensor, 570 TV lines,
infrared frequency 850 Nm, infrared pulse frequency
2,000 W, protection rating IP66, supply voltage
20 - 36 VDC or 24 – 28 VAC (50 – 60 Hz).
Type 5E30/LT
Multiserver
control
GATE APR SERIES
525G/1VA € 14,336.00
Digital IVS automatic plate recognition at 1 access point
525G/2VA € 16,016.00
Digital IVS automatic plate recognition at 2 access points
525G/3VA € 17,416.00
Digital IVS automatic plate recognition at 3 access points
525G/4VA € 17,976.00
Digital IVS automatic plate recognition at 4 access points
GATE PAC SERIES
The PAC (Parking Access control) version requires the use of an external trigger and a physical
barrier in the lane of the vehicle, which limits its speed.
525G/1VP € 6,552.00
Digital IVS licence plate reading for control of 1 access point
525G/2VP € 8,509.00
Digital IVS licence plate reading for control of 2 access points
525G/3VP € 12,432.00
Digital IVS licence plate reading for control of 3 access points
525G/4VP € 13,552.00
Digital IVS licence plate reading for control of 4 access points
Day & Night colour cameras with IR
BEST OVERVIEW Day & night colour cameras
BEST OVERVIEW
31
PRICE LIST E1
AE 424 KN
CF 355 NY
SOFTWARE
• Operating System Windows XP
Embedded
• High reliability: 99% (used with
ground loops or infrared sensors)
• High recognition speed:
< 0.2 seconds
• OCR activated continuously or by
I/O
• Resolution up to 720 x 576 (PAL)
and 720 x 480 (NTSC) – Megapixel
(IP)
• Active count of vehicles in parking
facility (difference between vehicles
entering and leaving)
• Snapshot of vehicle, licence plate
or driver
• Licence plate database compatible
with Microsoft Excel (SQL Server)
• Multiple scanning technologies for
greater reliability
• Generation of alarms on detection
of an unlisted vehicle
• E-mail, SMS or audible notications
when a blacklisted vehicle is
detected
• Picture-in-picture window provides
live camera display and the last
recognised image
• Unlimited number of groups of
registered vehicles in database
• Activation of external devices based
on licence plate recognition
• Recognition, display, and storage of
the plate with a saved image in the
database
• Operator can match le photo of
vehicle/driver to captured licence
plate
• Search input/output devices for
vehicles by entering the licence
plate or any other parameter
recorded in the database
• Supports JPEG format (3 million
images stored in 250 GB HDD)
• Auto-deletion of old images when
hard disk is full
• Capability to congure archive
duration of sensitive data
ACCESS POINT
CHARACTERISTICS
GATE is available in two versions:
APR and PAC.
• The APR (Automatic Plate
recognition) version does not
require any external trigger or
physical barriers (e.g. bars) and can
detect the licence plates of cars at
speeds up to 250 km/h.
• The PAC (Parking Access control)
version requires the use of an
external trigger and a physical
barrier in the lane of the vehicle,
which limits its speed.
GATE is the licence plate
reading system designed to
handle from 1 to 4 vehicle
access points from each server
HOW IT WORKS
LICENCE PLATE
RECOGNITION DATABASE
INTUITIVE INTERFACE
LICENCE PLATES
RECORDED IN DATABASE
SPECIFICATIONS
• Supply voltage: 230 VAC 50 Hz
power consumption 120 W
• Operating temperature 0 - 40 °C,
max RH 80% n.c.
• Dimensions in mm: 425 x 170 x 480
WxHxD
• Handles front +30 mm
• Weight: 16.7 kg
Day & Night colour cameras with IR BEST OVERVIEW
Day & night colour cameras BEST OVERVIEW
PRICE LIST E1
32
OPTIONALS FOR 300E SERIES
52LZ/3C1 Licence for 1 additional channel from 5 to 12 € 196.00
52LZ/3C4 Expansion for 4 additional IP licences € 644.00
52LZ/PPZ Privacy Zone plug-in € 280.00
52LZ/1UA Expansion for 1 additional user € 196.00
52LZ/1CC Expansion for 1 simultaneous connection € 392.00
52LZ/CM Multiserver control plug-in (max 3 servers) € 532.00
52LZ/MMS Plug-in for SMS/MMS notication (includes modem) € 616.00
52LZ/WD Plug-in for on-demand Internet wireless connection (includes modem) € 1,232.00
52JO USB joystick for remote operation of PTZ video cameras € 952.00
OPTIONALS FOR 400E SERIES
52LZ/4C1 Licence for 1 additional IP channel from 5 to 12 € 364.00
52LZ/4C4 Expansion for 4 additional IP licences € 1,176.00
52LZ/DE License upgrade for Motion Detection Enterprise channel € 154.00
52LZ/3U Expansion for 3 additional users € 392.00
52LZ/1CC Expansion for 1 simultaneous connection € 392.00
52LZ/3UC Expansion (3 Users + 1 simultaneous conn.) € 616.00
52LZ/IOV Virtual I/Os plug-in € 812.00
52LZ/IOC Concatenated I/Os plug-in € 812.00
52LZ/MP Maps plug-in € 504.00
52LZ/MMS Plug-in for SMS/MMS notication (includes modem) € 616.00
52LZ/WD Plug-in for on-demand Internet wireless connection (includes modem) € 1,232.00
52LZ/4.4 Serial hardware module 4+4 internal I/O € 252.00
52LZ/8.8 Serial hardware module 8+8 I/O € 504.00
52RS/485 RS232-RS422/485 converter for remote PTZ control € 196.00
52JO USB joystick for remote control of PTZ video cameras € 952.00
OPTIONALS FOR 600E SERIES
52LZ/6L1 Licence for 1 additional IP channel from 9 to 72 € 364.00
52LZ/6L4 Expansion for 4 additional IP licences € 1,176.00
52LZ/MDE License upgrade for Motion Detection Enterprise channel € 154.00
52LZ/3U Expansion for 3 additional users € 392.00
52LZ/1CC Expansion for 1 simultaneous connection € 392.00
52LZ/3UC Expansion (3 Users + 1 simultaneous conn.) € 616.00
52LZ/IOV Virtual I/Os plug-in € 812.00
52LZ/IOC Concatenated I/Os plug-in € 812.00
52LZ/MP Maps plug-in € 504.00
52LZ/MMS Plug-in for SMS/MMS notication (includes modem) € 616.00
52LZ/WD Plug-in for on-demand Internet wireless connection (includes modem) € 1,232.00
52LZ/4.4 Serial hardware module 4+4 internal I/O € 252.00
52LZ/8.8 Serial hardware module 8+8 I/O € 504.00
52HD/1T Expansion 1TB HDD capacity (max. 4TB total) € 546.00
52RD/4 RAID5 4TB capacity (oversized housing with depth 9 cm) € 4,046.00
52MA DVD burner for data archiving € 112.00
52JO USB joystick for remote operation of PTZ video cameras € 952.00
Day & Night colour cameras with IR
BEST OVERVIEW Day & night colour cameras
BEST OVERVIEW
33
PRICE LIST E1
OPTIONALS FOR 500E SERIES
52LZ/5L1 Licence for 1 additional IP channel from 5 to 16 € 448.00
52LZ/5L4 Expansion for 4 additional IP licences € 1.509,00
52LZ/01T Optional 1TB capacity € 371.00
52LZ/AVA Pro channel license upgrade (advanced video analysis algorithms) € 431.00
52LZ/CT Trafc channel licence € 1,509.00
52LZ/RSB Local recording and stream broadcaster € 2,125.00
52LZ/3U Expansion for 3 additional users € 392.00
52LZ/1CC 1 additional simultaneous connection € 392.00
52LZ/3UC Expansion (3 Users + 1 simultaneous conn.) € 616.00
52LZ/CCI Expansion for simultaneous connections and unlimited users € 1,911.00
52LZ/MMS Plug-in for SMS/MMS notication (includes modem) € 616.00
52LZ/WD Plug-in for on-demand Internet wireless connection (includes modem) € 1,232.00
52LZ/8.8 Serial hardware module 8+8 I/O € 504.00
52JO USB joystick for remote operation of PTZ video cameras € 952.00
OPTIONALS FOR 700E SERIES
52LZ/7L1 Licence for 1 additional IP channel from 9 to 72 € 448.00
52LZ/7L4 Expansion for 4 additional IP licences € 1.509,00
52LZ/AVA Video analytics channel licence upgrade (PRO) € 431.00
52LZ/CT Trafc channel licence € 1,509.00
52LZ/RSB Local recording and stream broadcaster € 2,125.00
52LZ/3U Expansion for 3 additional users € 392.00
52LZ/1CC Expansion for 1 simultaneous connection € 392.00
52LZ/3UC Expansion (3 Users + 1 simultaneous conn.) € 616.00
52LZ/CCI Expansion for simultaneous connections and unlimited users € 1,911.00
52LZ/MMS Plug-in for SMS/MMS notication (includes modem) € 616.00
52LZ/WD Plug-in for on-demand Internet wireless connection (includes modem) € 1,232.00
52JO USB joystick for remote operation of PTZ video cameras € 952.00
52LZ/8.8 Serial hardware module 8+8 I/O € 504.00
52HD/1T Expansion 1TB HDD capacity (max. 4TB total) € 546.00
52MA DVD burner for data archiving € 112.00
52RD/4 RAID5 4TB capacity (oversized housing with depth 9 cm) € 4,046.00
OPTIONALS FOR GATE SERIES
5E30/LT ALPR licence plate reading camera € 3,668.00
52LZ/MMS Plug-in for SMS/MMS notication (includes modem) € 616.00
52LZ/8.8 Serial hardware module 8+8 I/O € 504.00
Day & Night colour cameras with IR BEST OVERVIEW
Day & night colour cameras BEST OVERVIEW
PRICE LIST E1
34
300E 400E 600E 500E 700E
HARDWARE
Power consumption 30-40W 90-100W 100-120W 60-80W 100-120W
Operating system Windows XP Embedded Windows XP Embedded Windows XP Embedded Windows XP Embedded Windows XP Embedded
O.S. write protection - yes (optional) yes (optional) yes (optional) yes (optional)
Compact Flash - yes yes yes yes
Hard Disk 500GB 500GB 1TB 500GB 1TB
Video channels (PAL / NTSC / IP) from 4 to 12 IP channels 4/8 analogue
from 4 to 12 IP only
8/16/32 analogue
from 8 to 72 IP only
4/8 analogue/IP
from 4 to 16 IP only
8/16/32 analogue/IP
from 8 to 72 IP only
Internal I/Os - 4 I/Os (optional, per 4 ch) 4 I/Os (optional) 4 I/Os 4 I/Os
8 external I/Os (up to 31 modules) - yes (optional) yes (optional) yes (optional) yes (optional)
RS-422/485 for PTZ control - yes (optional) yes yes yes
DVD burner - - yes (optional) - yes (optional)
Wireless Kit SW + Modem yes (optional) yes (optional) yes (optional) yes (optional) yes (optional)
USB joystick for PTZ control yes (optional) yes (optional) yes (optional) yes (optional) yes (optional)
4TB RAID-5 (2+2TB - hot swap) - - yes (optional) - yes (optional)
SOFTWARE
Recording encoder Native IP HW: H264 / Native IP HW: H264 / Native IP HW: H264 / Native IP
SW: MJPEG- MPEG-4
HW: H264 / Native IP
SW: MJPEG- MPEG-4
Display encoder Native IP
SW: MJPEG- MPEG-4
HW: H264 / Native IP
SW: MJPEG- MPEG-4
HW: H264 / Native IP
SW: MJPEG- MPEG-4
HW: H264 / Native IP
SW: MJPEG- MPEG-4
HW: H264 / Native IP
SW: MJPEG- MPEG-4
Frame rate acceleration on event - yes yes yes yes
Recording path - yes yes yes yes
Multiclient control yes yes yes yes yes
Multiserver control yes (optional) yes yes yes yes
Local recording - - - yes (optional) yes (optional)
Stream Broadcaster - - - yes (optional) yes (optional)
Simultaneous connections 1 (expandable) 2 (expandable) 2 (expandable) 4 (expandable) 4 (expandable)
Congurable users 2 (expandable) 2 (expandable) 2 (expandable) 4 (expandable) 4 (expandable)
Unlimited users and connections - yes (optional) yes (optional) yes (optional) yes (optional)
Watermarking yes yes yes yes yes
PTZ control yes yes yes yes yes
S.M.A.R.T. yes yes yes yes yes
Virtual Machine - - - - -
System event notication yes yes yes yes yes
Video analysis event notication yes yes yes yes yes
Screenshot yes yes yes yes yes
Pop-up mode yes yes yes yes yes
SMS notication yes (optional) yes (optional) yes (optional) yes (optional) yes (optional)
Congurable layouts (up to 7x7) yes yes yes yes yes
Live / Rec digital zoom yes yes yes yes yes
Rotating timed layouts yes yes yes yes yes
Privacy blurring yes (optional) yes yes yes yes
Maps - yes (optional) yes (optional) yes yes
View via PDA yes yes yes yes yes
Client/Server audio chat - - - yes yes
ANALYSIS
Advanced lters - yes (optional) yes (optional) yes yes
Advanced backgrounds - yes (optional) yes (optional) yes yes
View details - yes yes yes yes
View Advanced details - yes (optional) yes (optional) yes yes
Perspective - yes (optional) yes (optional) yes yes
Motion Detection Small Business yes yes yes yes yes
Motion Detection Professional - yes yes yes yes
Motion Detection Enterprise - yes (optional) yes (optional) yes yes
Object Analytics plug-in:
Abandoned object, parking prohibited, access
point counting, speed control
- - - yes (optional) yes (optional)
TRAFFIC plug-in:
Vehicle counting, classication, wrong way
detection, queue detection
- - - yes (optional) yes (optional)
Analysis Calendar yes yes yes yes yes
Concatenated Area Control - yes yes yes yes
Concatenated I/Os - yes (optional) yes (optional) yes yes
Virtual I/Os (recall PTZ preset) - yes (optional) yes (optional) yes yes
Day & Night colour cameras with IR
BEST OVERVIEW Day & night colour cameras
BEST OVERVIEW
35
PRICE LIST E1
300E 400E 600E 500E 700E
HARDWARE
Power consumption 30-40W 90-100W 100-120W 60-80W 100-120W
Operating system Windows XP Embedded Windows XP Embedded Windows XP Embedded Windows XP Embedded Windows XP Embedded
O.S. write protection - yes (optional) yes (optional) yes (optional) yes (optional)
Compact Flash - yes yes yes yes
Hard Disk 500GB 500GB 1TB 500GB 1TB
Video channels (PAL / NTSC / IP) from 4 to 12 IP channels 4/8 analogue
from 4 to 12 IP only
8/16/32 analogue
from 8 to 72 IP only
4/8 analogue/IP
from 4 to 16 IP only
8/16/32 analogue/IP
from 8 to 72 IP only
Internal I/Os - 4 I/Os (optional, per 4 ch) 4 I/Os (optional) 4 I/Os 4 I/Os
8 external I/Os (up to 31 modules) - yes (optional) yes (optional) yes (optional) yes (optional)
RS-422/485 for PTZ control - yes (optional) yes yes yes
DVD burner - - yes (optional) - yes (optional)
Wireless Kit SW + Modem yes (optional) yes (optional) yes (optional) yes (optional) yes (optional)
USB joystick for PTZ control yes (optional) yes (optional) yes (optional) yes (optional) yes (optional)
4TB RAID-5 (2+2TB - hot swap) - - yes (optional) - yes (optional)
SOFTWARE
Recording encoder Native IP HW: H264 / Native IP HW: H264 / Native IP HW: H264 / Native IP
SW: MJPEG- MPEG-4
HW: H264 / Native IP
SW: MJPEG- MPEG-4
Display encoder Native IP
SW: MJPEG- MPEG-4
HW: H264 / Native IP
SW: MJPEG- MPEG-4
HW: H264 / Native IP
SW: MJPEG- MPEG-4
HW: H264 / Native IP
SW: MJPEG- MPEG-4
HW: H264 / Native IP
SW: MJPEG- MPEG-4
Frame rate acceleration on event - yes yes yes yes
Recording path - yes yes yes yes
Multiclient control yes yes yes yes yes
Multiserver control yes (optional) yes yes yes yes
Local recording - - - yes (optional) yes (optional)
Stream Broadcaster - - - yes (optional) yes (optional)
Simultaneous connections 1 (expandable) 2 (expandable) 2 (expandable) 4 (expandable) 4 (expandable)
Congurable users 2 (expandable) 2 (expandable) 2 (expandable) 4 (expandable) 4 (expandable)
Unlimited users and connections - yes (optional) yes (optional) yes (optional) yes (optional)
Watermarking yes yes yes yes yes
PTZ control yes yes yes yes yes
S.M.A.R.T. yes yes yes yes yes
Virtual Machine - - - - -
System event notication yes yes yes yes yes
Video analysis event notication yes yes yes yes yes
Screenshot yes yes yes yes yes
Pop-up mode yes yes yes yes yes
SMS notication yes (optional) yes (optional) yes (optional) yes (optional) yes (optional)
Congurable layouts (up to 7x7) yes yes yes yes yes
Live / Rec digital zoom yes yes yes yes yes
Rotating timed layouts yes yes yes yes yes
Privacy blurring yes (optional) yes yes yes yes
Maps - yes (optional) yes (optional) yes yes
View via PDA yes yes yes yes yes
Client/Server audio chat - - - yes yes
ANALYSIS
Advanced lters - yes (optional) yes (optional) yes yes
Advanced backgrounds - yes (optional) yes (optional) yes yes
View details - yes yes yes yes
View Advanced details - yes (optional) yes (optional) yes yes
Perspective - yes (optional) yes (optional) yes yes
Motion Detection Small Business yes yes yes yes yes
Motion Detection Professional - yes yes yes yes
Motion Detection Enterprise - yes (optional) yes (optional) yes yes
Object Analytics plug-in:
Abandoned object, parking prohibited, access
point counting, speed control
- - - yes (optional) yes (optional)
TRAFFIC plug-in:
Vehicle counting, classication, wrong way
detection, queue detection
- - - yes (optional) yes (optional)
Analysis Calendar yes yes yes yes yes
Concatenated Area Control - yes yes yes yes
Concatenated I/Os - yes (optional) yes (optional) yes yes
Virtual I/Os (recall PTZ preset) - yes (optional) yes (optional) yes yes
Day & Night colour cameras with IR BEST OVERVIEW
Day & night colour cameras BEST OVERVIEW
PRICE LIST E1
36
Series: SPEED IP
Day & Night outdoor speed dome colour IP camera, 1/4" SONY Super HAD
sensor, 570 TV lines, 36X optical zoom, 16X digital zoom, H264 compression,
Davinci DSP, OSD control, PRIVACY function, mechanical IR cut filter, Motion
Detection, SD/SDHC card local storage, supply voltage 24 Vac. IP66 die-cast
aluminium housing.
Technical specifications:
Sensor 1/4" Sony Super HAD CCD
Resolution 540 TV lines colour – 570 TV lines B/W
Effective pixels PAL: 752(H) x 582(V) / NTSC: 768(H) x 494(V)
Electronic shutter 1/50 (1/60) X ~ 1/100,000 sec
Lens 36X optical zoom - 16X digital zoom
Focal length 3.4 mm ~ 122.4 mm - F 1.6 ~ F 4.5
BLC/WDR ON / OFF
Minimum illumination 0.2Lux (colour) - 0.02 Lux (B/W) F1.4
Privacy mask 15 Privacy areas
Preset positions 256
Patrol 8 patrol paths, each path up to 32 presets
Pattern 4 programmable patterns with max. recording time
10 minutes
Park function Preset – Patrol – Pattern – Horizontal Scan – Vertical Scan
Alarm inputs/outputs 7 inputs / 2 relay outputs
RS485 protocol Pelco D, Pelco P
Audio input 2 – 2.4 Vpp, Output impedance 1 KΩ. ± 10%
Audio output Impedance 600Ω
Ethernet 10 Base-T / 100 Base-TX, RJ45 connector
Image compression H264
Audio compression OggVorbis / 16 Kbps
Protocol TCP/IP, HTTP, DHCP, DNS, RTP, RTCP, PPPoE
Dual Stream YES
Local storage SD Cards - SDHC - Manual recording - Alarm recording
Rotation speed
Horizontal: Manual speed 0.1° F 1.6 – F 4.5 240°/ 320° /
400°/s
Vertical: Manual speed 0.1° ~ 140°/ 190° / 240°/s - Preset
speed 400°/s
Horizontal rotation 360°
Protection level TVS 3,000V - lightning protection, surge protection and
voltage transient protection
Protection rating IP66
Operating temperature -30°C ~ 65° - 90% RH
Supply voltage /
Power consumption
24 Vac power supply unit included - 15W (30W with
thermostatically-controlled heater on)
Dimensions / Weight Ø 220 x 299.2 mm - 5 kg
TYPE 51D3/E36 € 3,897.00
Day & Night colour cameras with IR
BEST OVERVIEW Day & night colour cameras
BEST OVERVIEW
37
PRICE LIST E1
Series: SPEED IP
Day & Night outdoor speed dome colour IP camera, 1/3" SONY progressive scan
sensor, 1.3 megapixels, 18X optical zoom, 12X digital zoom, H264 compression,
Davinci DSP, OSD control, mechanical IR cut filter, Motion Detection, SD/SDHC
card local storage, supply voltage 24 Vac. IP66 die-cast aluminium housing.
Technical specifications:
Sensor 1/3" Sony progressive scan CCD
Resolution 1.3 MEGAPIXELS
Effective pixels 1280(H) x 960(V)
Electronic shutter 1/25 X ~ 1/100,000 sec
Lens 18X optical zoom - 12X digital zoom
Focal length 4.7 mm – 84.6 mm with 18X
BLC/WDR ON/ OFF
Minimum illumination 0.1Lux (colour) - 0.01 Lux (B/W) F1.6
Preset positions 256
Patrol 8 patrol paths, each path up to 32 presets
Pattern 4 programmable patterns with max. recording time
10 minutes
Park function Preset – Patrol – Pattern – Horizontal Scan – Vertical Scan
Alarm inputs/outputs 1 input / 1 relay output
RS485 protocol Pelco D, Pelco P
Audio input 2 – 2.4 Vpp, Output impedance 1 KΩ. ± 10%
Audio output Impedance 600Ω
Ethernet 10 Base-T / 100 Base-TX, RJ45 connector
Image compression H264
Audio compression OggVorbis / 16 Kbps
Protocol TCP/IP, HTTP, DHCP, DNS, RTP, RTCP, PPPoE
(FTP, NTP, SNMP, connectable)
Dual Stream YES
Local storage SD Cards - SDHC - Manual recording - Alarm recording
Rotation speed Horizontal: Manual speed 0.1° ~ 240°/ 320° / 400°/s
Vertical: Manual speed 0.1° ~ 50° /s, - Preset speed 50°/s
Horizontal rotation 360°
Protection level TVS 3,000V - lightning protection, surge protection and
voltage transient protection
Protection rating IP66
Operating temperature -30°C ~ 65° - 90% RH
Supply voltage /
Power consumption
24 Vac power supply unit included - 15W (30W with
thermostatically-controlled heater on)
Dimensions / Weight Ø 220 x 299.2 mm - 5 kg
TYPE 51D3/EIP € 4,053.00
Day & Night colour cameras with IR BEST OVERVIEW
Day & night colour cameras BEST OVERVIEW
PRICE LIST E1
38
Series: SPEED IP
Day & Night indoor speed dome colour IP camera, 1/4" SONY Interline Transfer
sensor, 570 TV lines, 10X optical zoom, 10X digital zoom, H264 compression,
Davinci DSP, PoE, OSD control, mechanical IR cut filter, Motion Detection, SD/
SDHC card local storage, supply voltage 12 Vdc.
Technical specifications:
Sensor 1/4" Sony Interline CCD
Resolution 500 TV lines colour – 570 TV lines B/W
Effective pixels PAL 752(H) x 582(V) / NTSC: 768(H) x 494(V)
Electronic shutter 1/50 (1/60) sec X ~ 1/10,000 (1/10,000) sec
Lens 10X optical zoom - 10X digital zoom
Focal length 3.8 mm – 38 mm with 10X
BLC/WDR ON/ OFF
Minimum illumination 0.7Lux (colour) - 0.02 Lux (B/W) F1.4
Privacy mask 4 Privacy areas
Preset positions 256
Patrol 8 patrol paths, each path up to 32 presets
Pattern 4 programmable patterns with max. recording time
10 minutes
Park function Preset – Patrol – Pattern – Horizontal Scan – Vertical Scan
Alarm inputs/outputs 1 input / 1 relay output
RS485 protocol Pelco D, Pelco P
Audio input 2 – 2.4 Vpp, Output impedance 1 KΩ. ± 10%
Audio output Impedance 600Ω
Ethernet 10 Base-T / 100 Base-TX, RJ45 connector
Image compression H264
Audio compression OggVorbis / 16 Kbps
Protocol TCP/IP, HTTP, DHCP, DNS, RTP, RTCP, PPPoE
(FTP, NTP, SNMP, connectable)
Dual Stream YES
Local storage SD - SDHC - Manual recording - Alarm recording
Rotation speed Horizontal: Manual speed 0.1° ~ 240°/ 320° / 400°/s
Vertical: Manual speed 0.1° ~ 90°/s, - Preset speed 200°/s
Horizontal rotation 360°
Operating temperature -10°C ~ 50° - 90% RH
Supply voltage /
Power consumption 12 Vdc - PoE - 12W
Dimensions / Weight Ø 145 x 132.8 mm - 2 kg
TYPE 51D3/10 € 2,187.00
Day & Night colour cameras with IR
BEST OVERVIEW Day & night colour cameras
BEST OVERVIEW
39
PRICE LIST E1
Series: IP MEGAPIXEL
Day & Night colour IP camera, 1/3" Sony progressive scan sensor, 1.3 megapixels,
H264/MJPEG compression, PoE, mechanical IR cut filter, dual stream, SD/SDHC
card local storage, remote view via mobile phone, C/CS mount lens.
Lens purchased separately
Technical specifications:
Sensor 1/3" Sony progressive scan CCD
Resolution
1.3 MEGAPIXELS
50 Hertz – (1280 X 960):12.5 FPS, (1280 X 720): 25 FPS
60 Hertz – (1280 X 960): 15 FPS, (1280 X 720): 30 FPS
Effective pixels 1280(H) x 960(V)
Electronic shutter 1/25 X ~ 1/100,000 sec
Lens C/CS mount - DC Drive
Minimum illumination 0.1Lux (colour) F1.2 - 0.01 Lux (B/W) F1.6
Alarm inputs/outputs 1 input / 1 output
Audio input 2 – 2.4 Vpp, Output impedance 1 KΩ. ± 10% mini jack
Audio output Impedance 600Ω jack
Image compression H264 / MJPEG
Audio compression OggVorbis
Protocol TCP/IP, HTTP, DHCP, DNS, DDNS, RTP / RTSP, PPPoE,
SMTP, NTP
Local storage SD / SDHC (NAS)
Intelligent alarm Motion detection, Video Loss, Network Disconnect,
IP conict, Storage exception
Ports 1 RJ 45 - 10/100 M, 1 RS-485
Operating temperature -10°C ~ 60° - 90% RH
Supply voltage /
Power consumption 12Vdc ± 10%, or PoE - 7.5W/12.5W (max. with ICR on)
Dimensions / Weight 68 x 57 x 144.8 mm - 500 g
we recommend the use of lens: megapixel, manual or dc driver
TYPE 55IP/1 € 1,037.00
Day & Night colour cameras with IR BEST OVERVIEW
Day & night colour cameras BEST OVERVIEW
PRICE LIST E1
40
Series: IP MEGAPIXEL
Day & Night colour IP camera, 1/3" CMOS progressive scan sensor, 2 megapixels,
H264/MJPEG compression, PoE, mechanical IR cut filter, dual stream, SD/SDHC
card local storage, remote view via mobile phone, C/CS mount lens.
Lens purchased separately
Technical specifications:
Sensor 1/3" CMOS progressive scan
Resolution
2 MEGAPIXELS
50 Hertz – (1600 X 1200):12.5 FPS, (1600 X 912):
12.5 FPS, (1280 X 960): 25 FPS (1280 x 720): 25 FPS
60 Hertz – (1600 X 1200): 15 FPS, (1600 X 912): 15 FPS,
(1280 X 960): 30 FPS (1280 x 960): 30 FPS
Effective pixels 1600(H) x 1200(V)
Electronic shutter 1/25 X ~ 1/100,000 sec
Lens C/CS mount - DC Drive
Minimum illumination 0.5Lux @ F1.2 – 0.1Lux @ (F1.2 sensitisation x 5) Colour
00.5 Lux @ F1.6 – 00.1Lux @ (F1.2 sensitisation x 5) B/W
Alarm inputs/outputs 1 input / 1 output
Audio input 2 – 2.4 Vpp, Output impedance 1 KΩ. ± 10% mini jack
Audio output Impedance 600Ω jack
Image compression H264 / MJPEG
Audio compression OggVorbis
Protocol TCP/IP, HTTP, DHCP, DNS, DDNS, RTP / RTSP, PPPoE,
SMTP, NTP
Local storage SD / SDHC (NAS)
Intelligent alarm Motion detection, Video Loss, Network Disconnect,
IP conict, Storage exception
Ports 1 RJ 45 - 10/100 M, 1 RS-485
Operating temperature -10°C ~ 60° - 90% RH
Supply voltage /
Power consumption 12Vdc ± 10%, or PoE - 4.5W/9.5W (max. with ICR on)
Dimensions / Weight 68 x 57 x 144.8 mm - 500 g
we recommend the use of lens: megapixel, manual or dc driver
TYPE 55IP/2 € 819.00
Day & Night colour cameras with IR
BEST OVERVIEW Day & night colour cameras
BEST OVERVIEW
41
PRICE LIST E1
Series: IP MEGAPIXEL
Day & Night colour IP camera, 1/3" CMOS progressive scan sensor, 3 megapixels,
H264/MJPEG compression, PoE, mechanical IR cut filter, dual stream, SD/SDHC
card local storage, remote view via mobile phone, C/CS mount lens.
Lens purchased separately
Technical specifications:
Sensor 1/3" CMOS progressive scan CCD
Resolution
3 MEGAPIXELS
50 Hertz – (2048 X 1536):12.5 FPS, (1920 X 1080):
25 FPS, (1600 X 1200): 25 FPS
60 Hertz – (2048 X 1536): 15 FPS, (1920 X 1080): 30 FPS,
(1600 X 1200): 30 FPS
Effective pixels 2048(H) x 1536(V)
Electronic shutter 1/25 X ~ 1/100,000 sec
Lens C/CS mount - DC Drive
Minimum illumination 0.5Lux @ F1.2 – 0.1Lux @ (F1.2 sensitisation x 5) Colour
0.05 Lux @ F1.6 – 0.01Lux @ (F1.2 sensitisation x 5) B/W
Alarm inputs/outputs 1 input / 1 output
Audio input 2 – 2.4 Vpp, Output impedance 1 KΩ. ± 10% mini jack
Audio output Impedance 600Ω jack
Image compression H264 / MJPEG
Audio compression OggVorbis
Protocol TCP/IP, HTTP, DHCP, DNS, DDNS, RTP / RTSP, PPPoE,
SMTP, NTP
Local storage SD / SDHC (NAS)
Intelligent alarm Motion detection, Video Loss, Network Disconnect,
IP conict, Storage exception
Ports 1 RJ 45 - 10/100 M, 1 RS-485
Operating temperature -10°C ~ 60° - 90% RH
Supply voltage /
Power consumption 12Vdc ± 10%, or PoE - 4.5W/9.5W (max. with ICR on)
Dimensions / Weight 68 x 57 x 144.8 mm - 500 g
we recommend the use of lens: megapixel, manual or dc driver
TYPE 55IP/3 € 1,255.00
Day & Night colour cameras with IR BEST OVERVIEW
Day & night colour cameras BEST OVERVIEW
PRICE LIST E1
42
Series: IP MEGAPIXEL
Day & Night colour IP camera, 1/2.5" CMOS progressive scan sensor, 5
megapixels, H264/MJPEG compression, PoE, mechanical IR cut filter, dual
stream, SD/SDHC card local storage, remote view via mobile phone, C/CS mount
lens.
Lens purchased separately
Technical specifications:
Sensor 1/2.5” CMOS progressive scan CCD
Resolution
5 MEGAPIXELS
50 Hertz - (2560 X 1920): 6 FPS, (2048 X 1536): 12.5
FPS, (1920 X 1080): 25 FPS (1600 X 1200): 25 FPS,
(1280 X 720): 25 FPS
60 Hertz – (2560 X 1920): 7.5 FPS, (2048 X 1536):
15 FPS, (1920 X 1080): 30 FPS (1600 X 1200): 30 FPS,
(1280 X 720): 30 FPS
Effective pixels 2560(H) x 1920(V)
Electronic shutter 1/25 X ~ 1/100000 sec
Lens C/CS mount - DC Drive
Minimum illumination 0.6 Lux @ F1.2 Colour - 0.08 Lux @ F1.2 B/W
Alarm inputs/outputs 1 input / 1 output
Audio input 2 – 2.4 Vpp, Output impedance 1 KΩ. ± 10%
Audio output Impedance 600Ω
Image compression H264 / MJPEG
Audio compression OggVorbis
Protocol TCP/IP, HTTP, DHCP, DNS, DDNS, RTP / RTSP, PPPoE,
SMTP, NTP
Local storage SD / SDHC (NAS)
Intelligent alarm Motion detection, Video Loss, Network Disconnect,
IP conict, Storage exception
Ports 1 RJ 45 - 10/100 M, 1 RS-485
Operating temperature -10°C ~ 60° - 90% RH
Supply voltage /
Power consumption 12Vdc ± 10%, or PoE - 5W/10W (max. with ICR on)
Dimensions / Weight 68 x 57 x 144.8 mm - 500 g
we recommend the use of lens: megapixel, manual or dc driver
TYPE 55IP/05 € 1,721.00
Day & Night colour cameras with IR
BEST OVERVIEW Day & night colour cameras
BEST OVERVIEW
43
PRICE LIST E1
Series: IP MEGAPIXEL
Day & Night colour dome IP camera, 1/3" CMOS progressive scan sensor,
2 megapixels, 3.3-12 mm varifocal lens, H264/MPEG4 compression, PoE,
mechanical IR cut filter, dual stream, SD/SDHC card local storage, remote view
via mobile phone, IP66 with IR LED.
Technical specifications:
Sensor 1/3" CMOS progressive scan CCD
Resolution
2 MEGAPIXELS
(1600 X 1200): 12.5 FPS, (1600 X 912):12.5 FPS,
(1280 X 720): 25 FPS, (704 X 576): 25 FPS, (704 X 480):
30 FPS
Effective pixels 1600(H) x 1200(V)
Electronic shutter 1/25 X ~ 1/100,000 sec
Lens 3.3-12mm auto-iris manual varifocal lens, F 1.4
Minimum illumination 0.5 Lux @ F 1.2 - 0.1 Lux @ F1.2 sensitisation x 5
0 Lux with IR
IR distance 10 ~15 m
Alarm inputs/outputs 1 input / 1 output
Audio input 1 input 2 – 2.4 Vpp, Output impedance 1 KΩ. ± 10%
Audio output 1 output - Impedance 600Ω
Image compression H264 / MJPEG
Audio compression OggVorbis
Protocol TCP/IP, HTTP, DHCP, DNS, RTP / RTCP, PPPoE
Local storage SD / SDHC
Ports 1 RJ 45 - 10/100 M, 1 RS-485
Protection rating IP66
Operating temperature -10°C ~ 60°
Supply voltage /
Power consumption 24 Vac ± 10% / 12 Vdc ± 10%, or PoE - 6 W
Dimensions / Weight Ø 156 x 134.5 - 1,400 g
TYPE 57IP € 999.00
Day & Night colour cameras with IR BEST OVERVIEW
Day & night colour cameras BEST OVERVIEW
PRICE LIST E1
44
Series: IP
Day & Night colour IP camera, 1.4" CMOS progressive scan sensor, H264/
MPEG4 compression, PoE, dual stream, SD/SDHC card local storage, remote
view via mobile phone, C/CS mount lens. Manual iris
Lens purchased separately
Technical specifications:
Sensor 1/4" CMOS progressive scan CCD
Resolution PAL 25 Hertz (704 X 576) / NTSC 30 FPS (704 X 480)
Effective pixels 640(H) x 480(V)
Electronic shutter 1/25 X ~ 1/100,000 sec
Lens C/CS mount
Minimum illumination 0.4Lux @ F1.2
Alarm inputs/outputs 1 input / 1 output
RS485 protocol Pelco D, Pelco P
Audio input 2 – 2.4 Vpp, Output impedance 1 KΩ. ± 10%
Audio output Impedance 600Ω
Image compression H264 / MPEG4
Audio compression OggVorbis
Protocol TCP/IP, HTTP, DHCP, DNS, DDNS, RTP / RTSP, PPPoE
Local storage SD / SDHC
Ports 1 RJ 45 - 10/100 M, 1 RS-485
Operating temperature -10°C ~ 60° - 90% RH
Supply voltage /
Power consumption 12Vdc ± 10%, or PoE - 3W
Dimensions / Weight 116 x 63 x 59 mm - 650 g
TYPE 53IP € 490.00
Day & Night colour cameras with IR
BEST OVERVIEW Day & night colour cameras
BEST OVERVIEW
45
PRICE LIST E1
Series: IP
Day & Night colour IP camera, 1/3" Sony Super HAD progressive scan sensor,
540 TV lines, H264/MPEG4 compression, PoE, dual stream, SD/SDHC card local
storage, remote view via mobile phone, C/CS , DC Drive mount lens.
Lens purchased separately
Technical specifications:
Sensor 1/3" Sony Super HAD progressive scan sensor
Resolution PAL 752(H) X 582(V) / NTSC 768(H) x 494(V)
Effective pixels 640(H) x 480(V)
Electronic shutter 1/50 (1/60)s ~ 1/100,000 sec
Lens C/CS mount - DC/VIDEO Drive
Minimum illumination 0.1 Lux @ F1.2
Alarm inputs/outputs 1 input / 1 output
Audio input 1 input, 2 – 2.4 Vpp, Output impedance 1 KΩ. ± 10%
Audio output 1 output, Impedance 600Ω
Image compression H264 / MPEG4
Audio compression G711
Protocol TCP/IP, HTTP, DHCP, DNS, DDNS, RTP / RTSP, PPPoE
Local storage SD / SDHC
Ports 1 RJ 45 - 10/100 M, 1 RS-485
Operating temperature -10°C ~ 60° - 90% RH
Supply voltage /
Power consumption 12Vdc ± 10%, or PoE - 4W
Dimensions / Weight 114 x 63 x 59 mm - 650 g
TYPE 54IP € 632.00
Day & Night colour cameras with IR BEST OVERVIEW
Day & night colour cameras BEST OVERVIEW
PRICE LIST E1
46
Series: IP
Vandalproof mini dome colour IP camera with Day & Night functionality, 1/4"
CMOS sensor, 4 mm fixed lens, three axes, H264/MPEG4/MJPEG compression,
PoE, dual stream, remote view via mobile phone, IP66.
Technical specifications:
Sensor 1/4" CMOS
Effective pixels 640(H) x 480(V)
Lens 4 mm xed - F 1.2 angle of view 71°
Lens adjustment 15° Vertical – 90° horizontal / ± 15° rotation
Adjustment axes 3 axes
Minimum illumination 0.1 Lux @ F1.2 Colour - 0.01 Lux @ F1.2 B/W
Alarm inputs/outputs 1 input / 1 output
Image compression H264 / MPEG4 / MJPEG
Protocol TCP/IP, HTTP, DHCP, DNS, DDNS, RTP / RTSP, PPPoE
Local storage No (NAS)
Ports 1 RJ 45 - 10/100 M
Protection rating IP66
Operating temperature -10°C ~ 60° - 90% RH
Supply voltage /
Power consumption 12Vdc ± 10%, or PoE - 3W
Dimensions / Weight 100 x 97.5 x 46.5 mm - 250 g
TYPE 56IP € 465.00
Day & Night colour cameras with IR
BEST OVERVIEW Day & night colour cameras
BEST OVERVIEW
47
PRICE LIST E1
Series: IP
Day & Night colour IP camera, 1/3" Sony Super HAD sensor, H264/MPEG4
compression, PoE, dual stream, remote view via mobile phone, IP66 with IR LED.
Without bracket
Technical specifications:
Sensor 1/3" Sony Super HAD
Resolution 540 TV lines (58IP) - 480 TV lines (58IP/3, 58IP/6)
Effective pixels PAL 752 (H) x 582 (V) / NTSC 768 (H) x 494 (V)
Lens 12 mm xed (58IP), 3 mm xed (58IP/3), 6 mm xed (58IP/6)
Minimum illumination 0.1 Lux @ F1.2 - 0 Lux with IR on
IR distance 30 m
Alarm inputs/outputs 1 input / 1 output
Audio input 1 input, 2 – 2.4 Vpp, Output impedance 1 KΩ. ± 10%
Audio output 1 output, Impedance 600Ω
Image compression H264 / MPEG4
Audio compression OggVorbis
Protocol TCP/IP, HTTP, DHCP, DNS, RTP / RTCP, PPPoE
Ports 1 RJ 45 - 10/100 M, 1 RS-485
Operating temperature -10°C ~ 60°
Supply voltage /
Power consumption 12Vdc ± 10% - 7W
Dimensions / Weight 228 x 86.5 x 83.2 mm - 1,400 g
TYPE 58IP € 788.00
Lens 12 mm xed, 540 TV lines
TYPE 58IP/3 € 600.00
Lens 3 mm xed, 480 TV lines
TYPE 58IP/6 € 600.00
Lens 6 mm xed, 480 TV lines
NEW
NEW
Day & Night colour cameras with IR BEST OVERVIEW
Day & night colour cameras BEST OVERVIEW
PRICE LIST E1
48
Series: IP
Mini colour IP camera with Day & Night functionality, 1/3" CMOS progressive
scan sensor, 4 mm fixed lens, H264/MJPEG compression, PoE, dual stream, SD
card local storage, remote view via mobile phone.
Technical specifications:
Sensor 1/3" CMOS progressive scan
Resolution 640(H) x 480(V) VGA
Lens 4 mm C/CS - F 1.8 angle of view 54.9°
Lens adjustment 15° Vertical – 90° horizontal / ± 15° rotation
Minimum illumination 0.9 Lux @ F1.28 - 0.4 Lux @ F1.28
Audio input / output Microphone input, loudspeaker output
Image compression H264 / MJPEG
Audio compression OggVorbis
Protocol TCP/IP, HTTP, DHCP, DNS, DDNS, RTP / RTsP, PPPoE,
SMPT, NTP
Local storage SD (NAS)
Ports 1 RJ 45 - 10/100 M
Operating temperature -10°C ~ 60° - 90% RH
Supply voltage /
Power consumption 12Vdc ± 10% or PoE - 4W
Dimensions / Weight 110 x 70 x 33 mm - 250 g
TYPE 59IP € 446.00
Day & Night colour cameras with IR
BEST OVERVIEW Day & night colour cameras
BEST OVERVIEW
49
PRICE LIST E1
Series: IP
Video encoder with one video and audio channel, H264 compression, PTZ
control, dual stream, one alarm input, one relay output.
Technical specifications:
Resolution
PAL- QCIF(176x144)/CIF(352x288)/2CIF(702x288)/
DCIF(528x384)/4CIF(704x576)
NTSC- QCIF(176x120)/CIF(352x240)/2CIF(702x240)/
DCIF(528x320)/4CIF(704x480)
Frame rate PAL 25 FPS / NTSC 30 FPS
Alarm inputs/outputs 1 input / 1 relay output
PTZ RS485 (T+, T-)
Video input 1 BNC video input (1Vpp – 1 KΩ)
Audio input 2 – 2.4 Vpp, Output impedance 1 KΩ. ± 10%
Audio output Impedance 600Ω
Ethernet 10 Base-T / 100 Base-TX, RJ45 connector
Image compression H264
Audio compression OggVorbis
Protocol TCP/IP, UDP, RTP, Multicast, DDNS, DHCP, PPPoE, HTTP
Local storage SD / SDHC (52WS/1)
Intelligent alarm Motion detection, Video Loss, Network Disconnect,
IP conict, Storage exception
Ports 1 RJ 45 - 10/100 M, 1 RS-485
Operating temperature -10°C ~ 55° - 10% ~ 90% RH
Supply voltage /
Power consumption 12Vdc, power supply unit included 12 Vdc 3.3A - 3W
Dimensions 120 x 70 x 45 mm
TYPE 52WS/1 € 480.00
TYPE 52WS/A1 € 400.00
Without local storage
NEW
Day & Night colour cameras with IR BEST OVERVIEW
Day & night colour cameras BEST OVERVIEW
PRICE LIST E1
50
Series: IP
Video encoder with 4 video channels and 4 audio channels, H264 compression,
PTZ control, dual stream, 4 alarm inputs, 2 relay outputs.
Technical specifications:
Resolution
PAL- QCIF(176x144)/CIF(352x288)/2CIF(702x288)/
DCIF(528x384)/4CIF(704x576)
NTSC- QCIF(176x120)/CIF(352x240)/2CIF(702x240)/
DCIF(528x320)/4CIF(704x480)
4 FPS for 4 inputs Format 4CF/DCIF/2CIF
25 FPS PAL / 30 FPS NTSC Format CIF
Frame rate PAL 25 FPS / NTSC 30 FPS
Alarm inputs/outputs 4 inputs / 2 relay outputs
PTZ RS485 (T+, T-)
Video input 4 BNC video inputs (1Vpp – 1 KΩ)
Audio input 4 BNC video inputs (1Vpp – 1 KΩ)
Audio output 1 output, Impedance 600Ω
Microphone input 1 - 2 Vpp 1 KΩ
Ethernet 10 Base-T / 100 Base-TX, RJ45 connector
Image compression H264
Audio compression OggVorbis, 16 Kbps
Protocol TCP/IP, UDP, RTP, Multicast, DDNS, DHCP, PPPoE, HTTP
Ports 1 RJ 45 - 10/100 M, 1 RS485
Operating temperature -10°C ~ 55° - 10% ~ 90% RH
Supply voltage /
Power consumption 12Vdc, power supply unit included 12 Vdc 3.3A - 7W
Dimensions / Weight 198 x 123 x 39 mm - 1 kg
TYPE 52WS/4 € 571.00
Day & Night colour cameras
BEST OVERVIEW
51
PRICE LIST no.E1
Day & Night colour cameras
BEST OVERVIEW IP System Accessories
5288/033 € 22.30
Articulated camera bracket, in zinc, for wall mounting.
Maximum load 2 kg, rotation angle 360°, tilt angle 120°,
metallic silver nish.
Dimensions: 220x108 mm
5288/034 € 22.30
Articulated camera bracket, in zinc, for wall and ceiling mounting.
Maximum load 2 kg, rotation angle 360°, tilt angle
120°, metallic silver nish.
Dimensions: 225 x 108 mm
529S/8 € 65.00
Wall bracket in aluminium with cable duct.
Wall bracket in aluminium with cable duct for cameras type 57IP.
Dimensions: 230x180x160.
Weight: 1.395 kg
529S/7M € 66.00
Wall bracket in aluminium with cable duct.
Wall bracket in aluminium with cable duct for outdoor speed dome cameras type 51D3/E36,
51D3/EIP.
Dimensions: 310x97x194 mm.
Weight: 1.07 kg.
529S/7S € 55.00
Ceiling bracket.
Ceiling bracket in aluminium with cable duct for
outdoor speed dome cameras type 51D3/E36, 51D3/EIP.
Dimensions: Ø 117x293 mm.
Weight: 1.015 kg.
529C € 43.00
Pole mount.
Pole mount for outdoor speed cameras type
51D3/E36, 51D3/EIP.
Dimensions: 194x117x100 mm.
Weight: 1.205 kg
ANALOGUE SYSTEMS >
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
52
Day & Night Colour Cameras
TYPE 52DN € 337.00
Day & Night colour camera. DSP. Supply voltage 85 to 265 VAC, 40- 400 Hz,
1/3" Sony Super HAD sensor, resolution 480 TV lines, C/CS mount lens and
mechanically adjustable back focus. Without IR filter. Not sensitive to infrared
light.
1/3" Sony Super HAD CCD sensor, effective pixels 752 (H) x 582 (V).
LL (line lock) external synchronisation, INT internal synchronisation, 480 TV lines horizontal
resolution, S/N ratio more than 52 dB, Minimum illumination 0.01 lux (F1.2) AGC On, ATW
large range: from 2400 K to 11000 K, C/CS lens mount, Adjustable back focus, Backlight
compensation, Electronic shutter 1/50, 1/120, 1/250, Manual exposure 1/500, 1/1000, 1/2000,
1/4000, 1/10000, DIP controls Int (internal) /LL (Line lock), AGC min/AGC max, Gamma 1 /
Gamma 2, Shutter ON/OFF, BLC ON/OFF, FLICKERLESS, Automatic exposure/Manual
exposure, Operating temperature: from -10 °C to + 50 °C, Humidity: within 90% RH, Voltage
265 VAC 85 VAC / 40 Hz - 400 Hz, Power consumption (approx) 2.3 W, Dimensions 70 (W) x
58 (D) x 130 (H) mm, Weight (approx) 450 g, BNC video connector.
Lens purchased separately. VIDEO / DC Drive, Manual lens compatibility.
TYPE 52DN/IR € 390.00
Day & Night colour camera. DSP. Supply voltage 85 to 265 VAC, 40- 400 Hz, 1/3"
Sony EXVIEW sensor, 550 TV line resolution, C/CS mount lens, Mechanically
adjustable back focus, with IR filter for infrared sensitivity from 400 to 850 Nm.
1/3" Sony EXVIEW CCD sensor, Effective pixels 752 (H) x 582 (V), Chip dimensions 6.0 mm (H) x
4.96 mm (V), LL (line lock) external synchronisation, INT internal synchronisation, 2:1 interlacing,
550 TV lines horizontal resolution, Aperture correction H (horizontal), V (vertical), Video output
level 1.0 (p-p) (75 Ohm, composite), S/N ratio more than 52 dB (AGC off), Minimum illumination
0.01 lux (F1.2) AGC On, Infrared wavelength 400 nm to 850 nm, DSP external A/D converter
10 bits, 1024 grey, White balance ATW large range: from 2400 K to 11000 K, C/CS lens mount,
Adjustable back focus, Backlight compensation, Active histogram for whole window control,
V-phase control +/- 90° adjustable, Electronic shutter 1/50, 1/120, 1/250, Manual exposure
1/500, 1/1000, 1/2000, 1/4000, 1/10000, DIP controls Int (internal) /LL (line lock), AGC min/
AGC max, Gamma 1 / Gamma 2, Shutter ON/OFF, BLC ON/OFF, FLICKERLESS, Automatic
exposure/Manual exposure, (incandescent Iighting) from 2 lux to 100,000 lux - (F1.2) from 2.7 to
130,000 lux - (F1.4), Operating temperature: from -10 °C to + 50 °C, Humidity: within 90% RH,
Voltage 265 VAC 85 VAC / 40 Hz - 400 Hz, Power consumption (approx) 2.3 W, Dimensions
70 (W) x 58 (D) x 130 (H) mm, Weight (approx) 450 g, NOTE: When the camera switches to
black/white the area can be illuminated using infrared spotlights with a wavelength from 400 to
850 Nm, BNC video connector.
Lens purchased separately. VIDEO / DC Drive, Manual lens compatibility.
Day & Night colour cameras
BEST OVERVIEW
53
PRICE LIST no.E1
Day & Night Colour Cameras
TYPE 52DT € 410.00
Day & Night colour camera. DSP. Supply voltage 85 to 265 VAC, 40- 400 Hz, 1/3"
Sony EXVIEW sensor, 550 TV line resolution, C/CS mount lens and mechanically
adjustable back focus. Filter for infrared sensitivity from 400 to 850 Nm and high
speed shutter for checking vehicle licence plates, even on moving vehicles.
1/3" Sony EXVIEW CCD sensor, Effective pixels 752 (H) x 582 (V), Chip dimensions 6.0 mm (H) x
4.96 mm (V), LL (line lock) external synchronisation, INT internal synchronisation, 2:1 interlacing,
550 TV lines horizontal resolution, Aperture correction H (horizontal) V (vertical). Video output
level 1.0 (p-p) (75 Ohm, composite), S/N ratio more than 52 dB (AGC off), Minimum illumination
0.01 lux (F1.2) AGC On, Infrared wavelength 400 nm to 850 nm, DSP external A/D converter
10 bits, 1024 grey, White balance ATW large range: from 2400 K to 11000 K, C/CS lens mount,
Adjustable back focus, Backlight compensation, Active histogram for whole window control,
V-phase control +/- 90° adjustable, Electronic shutter 1/50, 1/120, 1/250, Manual exposure
1/500, 1/1000, 1/2000, 1/4000, 1/10000, DIP controls Int (internal) /LL (line lock), AGC min/
AGC max, Gamma 1 / Gamma 2, Shutter ON/OFF, BLC ON/OFF, FLICKERLESS, Automatic/
manual exposure, Illumination (incandescence) from 2 lux to 100,000 lux - (F1.2) from 2.7 to
130,000 lux - (F1.4), Operating temperature: from -10 °C to + 50 °C, Humidity: within 90% RH,
Voltage 265 VAC 85 VAC / 40 Hz - 400 Hz, Power consumption (approx) 2.3 W, Dimensions 70
(W) x 58 (D) x 130 (H) mm, Weight (approx) 450 g, Special video camera with high speed shutter
for checking vehicle licence plates, checks the moving vehicle and even the glare of the licence
plate, BNC video connector.
Lens purchased separately. VIDEO / DC Drive, Manual lens compatibility.
TYPE 52D0/3 € 200.00
Day & Night colour camera, STAR LIGHT, 1/3" SONY sensor with HITACHI DSP,
resolution 540 lines improved to 620 TV lines. Mechanical IR filter. Blue crystal
filter (LPF). DNR function. Slow Shutter Sens-up 32X, 0.0001 lux, audio output, C/
CS mount lens. Mirror function, BNC video connector. Supply voltage: 12V VDC /
24 VAC ± 10%.
1/3" SONY Super HAD sensor with Hitachi DSP. Pixels, PAL: 795(H)x596(V). Horizontal
resolution, 540 lines improved to 620 TV lines. Lens, C/CS mount. Synchronisation, Internal/
Line-Lock. Gamma, 0.45. AGC Automatic Gain Control, Maximum 18 dB - Super 30 dB.
Minimum illumination, 0.0001 Lux (Sensup 32x). S/N signal-to-noise ratio, 60 dB (AGC Off).
Scanning frequency, Pal: 15.625 – 50 Hz. Scanning system, 2:1 interlaced. Electronic shutter.
1/50 s ~ 1/120,000. Lens control, DC, Drive and manual, SenseUp, Maximum 32 steps. DNR,
Digital Noise Reduction. Mirror, ON/OFF Selectable. Mechanical lter. Blue crystal lter (LPF).
White balance, ATW /AWB selectable. Mirror, ON/OFF selectable. Video output, 1 Vpp 75 W.
Audio output, 2 Vpp. Operating temperature, -10oC ~ 50 oC ~ 85 RH. Input current, DC 150 mA
– AC 100 mA / 2 W. Supply voltage, 12V VDC / 24 VAC ± 10%. Weight, 305 g. Dimensions
(mm), 58 (W) x 50(H) x 120 (D) mm. BNC video connector.
Lens purchased separately. DC Drive, Manual lens compatibility.
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
54
Day & Night Colour Cameras with OSD
TYPE 52D0/1 € 153.00
Day & Night colour camera, 1/3" SONY DSP sensor, resolution 580 TV lines,
audio output, OSD control, Super Digital Noise Reduction (SDNR), with Privacy
functions. Motion Detection. Mirror function. Adjustable backlight area, camera
titling, C/CS mount lens, mechanically adjustable back focus, BNC video
connector. Supply voltage: 12V VDC / 24 VAC ± 10%.
1/3" SONY Super HAD sensor with DSP. Pixels, PAL: 795(H)x596(V). Horizontal resolution, 580
TV lines. Lens, C/CS mount Mechanically adjustable back focus. Synchronisation, Internal/Line-
Lock. Gamma, 0.05 – 1.0 (OSD control). AGC Automatic Gain Control, automatic / xed (OSD
control). Minimum illumination Typical, 0.1 Lux / (F1.2, 56000°K). D/N mode, 0.01 Lux / (F1.2,
56000°K). S/N signal-to-noise ratio, > 48 dB (AGC Off). Scanning frequency, Pal: 15.625 –
50 Hz. Electronic shutter. AES: 1/50 s ~ 1/120.000 s / Manual 12 step. (OSD control). Super
Digital Noise Reduction (SDNR), Lens control, DC, Manual, (OSD control). Motion Detect, On
/ Off (4 programmable zones). Privacy zone, On / Off (4 programmable zones). Camera ID,
Camera text identication (OSD control). White balance, Manual / ATW /AWB (OSD control).
Backlight, Super BLC, 64 zones (OSD control). Mirror, ON/OFF selectable. Adjustments,
Contrast, Sharpness. CB, RB Adjustment (OSD control). Video output, 1 Vpp 75 W. Audio
outputs, 2 Vpp RCA. Operating temperature, -10oC ~ 50 oC ~ 85 RH. Input current, 250 mA
– 3.2 W. Supply voltage, 12V VDC / 24 VAC ± 10%. Weight, 310 g. Dimensions (mm), 65 (W) x
63(H) x 125 (D) mm.
Lens purchased separately. DC Drive, Manual lens compatibility.
TYPE 52D0/2 € 138.00
Day & Night colour camera, 1/3" SONY sensor with Nextchip DSP, resolution
480 TV lines, OSD control, with Privacy function. Motion Detection. Mirror
function. Adjustable backlight area, camera titling, 3.5 - 8 mm varifocal lens,
BNC video connector. Supply voltage: 12 VDC ± 10%.
1/3" SONY Super HAD sensor with Nextchip DSP. Pixels, PAL: 795(H)x597(V). Horizontal
resolution, 480 TV lines. Lens, 3.5 - 8 mm varifocal, Synchronisation, Internal. Gamma, 0.05
– 1.0 (OSD control). AGC Automatic Gain Control, ON/OFF adjustable (OSD control). Minimum
illumination, 0.5 Lux / F2.0. S/N signal-to-noise ratio, 50 dB (AGC Off). Scanning frequency, Pal:
15.625 – 50 Hz. Scanning system, 2:1 interlaced. Electronic shutter, AES: 1/50 s ~ 1/120,000 s
/ Manual 12 step (OSD control). Motion Detect, On / Off (4 programmable zones) (OSD control).
Privacy zone, On / Off (4 programmable zones) (OSD control). White balance, Manual / ATW /
AWB (OSD control). Backlight, Adjustable 64 areas (OSD control). Mirror, ON/OFF. Adjustments,
Contrast, Sharpness, CB – CR. Camera ID, Camera text identication (OSD control). Video
output, 1 Vpp 75 W. Operating temperature, -10oC ~ 50 oC ~ 90 Rh. Input current, 120 mA –
1.44 W. Supply voltage, 12V VDC ± 10%. Weight, 400 g. Dimensions (mm), 60 (W) x 55 (H) x
120 (D) mm.
Day & Night colour cameras
BEST OVERVIEW
55
PRICE LIST no.E1
Day & Night Colour Cameras with OSD
TYPE 52Z0 € 741.00
Day & Night colour camera. Auto focus and 22x zoom. Supply voltage 12 VDC
1 A. 1/4" Sony Super HAD sensor, resolution 540 TV lines, with mechanically
switching IR filter. OSD, includes IR remote control. RS 485 for external control
using keypad.
1/4" Sony Super HAD Interline CCD sensor. Video signal standard 1Vpp 75 Ohm Pixels 596(H) X
95(V). Scanning system PAL 2:1 interlaced (V: 50 Hz – H:15.625 kHz). Resolution 540 TV lines.
Zoom - X1. Minimum illumination 0.5 Lux F1.6-30 IRE. 0.01 Lux Night function. AGC congurable
FF/SAGC. 0~30 dB. Automatic electronic shutter 1/50 s ~ 1/10,000 s. White balance ATW
2500°k~9600°k. Day/Night Function. Mechanically switching IR lter. Signal-to-noise ratio more
than 48 dB. BLC backlight function settable ON/OFF. Flickerless function settable ON/OFF.
Automatic / Manual focus. Zoom speed maximum 4 seconds/cycle. OSD congurable. Preset
functions 8 parameters that can be saved in memory. Protocol Pelco-P Pelco-D. External control
RS 485 – 9600, 4800,2400. Baud rate. Lens 22x Zoom (f=3.9 mm~85.8 mm. F1.6~F3.7. Supply
voltage 12 VDC +/- 1V. maximum input current (1 A– 12 W). Operating temperature -10 °C ~
+50 °C. Operating humidity 10% ~ 80% RH. External dimensions: 60 x 65 x 106 mm. BNC video
connector. Includes IR remote control. Weight 350 g.
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
56
IR LED Day & Night Colour Cameras
TYPE 5BL6 € 150.00
Day & Night colour camera. DSP. Supply voltage 12 VDC. Resolution 420 TV
lines. 1/3” Sony sensor. 8 mm fixed lens. Aluminium housing and sunshade.
IR anti-reflective glass. Protection rating IP66, 12 IR LEDs. Photo sensor for IR
activation. Supplied with bracket.
Day & Night DSP colour camera. 12 infrared LEDs. High S/N ratio. (AES) automatic (Electronic
Shutter). (AGC) automatic (gain control). (AWB) automatic (White balance). 1/3” Sony colour
CCD sensor. Pixels 500 (H) X 582 (V). Resolution 420 TV lines. Minimum illumination 0 Lux with
IR LEDs on. S/N ratio more than 48 dB. Automatic electronic shutter 1/50 s ~ 1/110,000 s.
Automatic white balance (2500 k ~ 9500 k). Gamma correction 0.45. Lens 8 mm. Supply voltage
12 VDC ± 10%. input current 250 mA. Operating temperature - 10 °C ~ + 50 °C. Protection
rating IP 66. IR range 20 metres. External dimensions Ø 50 x (D) 105 mm. BNC video connector.
TYPE 5AL6/A € 154.00
Day & Night colour camera. DSP. Supply voltage 12 VDC. Resolution 540 TV
lines. 1/3" Sony sensor. 4.3 mm fixed lens. Aluminium housing and sunshade.
IR anti-reflective glass. Protection rating IP66, 12 IR LEDs. Photo sensor for IR
activation. Complete with bracket, cables routed internally.
Day & Night DSP colour camera. 12 infrared LEDs. High S/N ratio. (AES) Automatic (Electronic
Shutter). (AGC) automatic (gain control). (AWB) automatic (White balance). 1/3" Sony Super
HAD colour sensor. Pixels 500 (H) X 582 (V). Resolution 540 TV lines. Minimum illumination 0 Lux
with IR LEDs on. S/N ratio more than 48 dB. Automatic electronic shutter 1/50 s ~ 1/110,000 s.
Automatic white balance (2500 k ~ 9500 k). Gamma correction 0.45. Lens 4.3 mm. Supply
voltage 12 VDC ± 10%. input current 250 mA. Operating temperature - 10 °C ~ + 50 °C.
Protection rating IP 66. IR range 20 metres. External dimensions Ø 50 x (D) 105 mm. BNC video
connector.
TYPE 5BL6/A € 154.00
Day & Night colour camera. DSP. Supply voltage 12 VDC. Resolution 540 TV
lines. 1/3" Sony sensor. 8 mm fixed lens. Aluminium housing and sunshade.
IR anti-reflective glass. Protection rating IP66, 12 IR LEDs. Photo sensor for IR
activation. Complete with bracket, cables routed internally.
Day & Night DSP colour camera. 12 infrared LEDs. High S/N ratio. (AES) Automatic (Electronic
Shutter). (AGC) automatic (gain control). (AWB) automatic (White balance). 1/3" Sony Super
HAD colour sensor. Pixels 500 (H) X 582 (V). Resolution 540 TV lines. Minimum illumination 0 Lux
with IR LEDs on. S/N ratio more than 48 dB. Automatic electronic shutter 1/50 s ~ 1/110,000 s.
Automatic white balance (2500 k ~ 9500 k). Gamma correction 0.45. Lens 4.3 mm. Supply
voltage 12 VDC ± 10%. input current 250 mA. Operating temperature - 10 °C ~ + 50 °C.
Protection rating IP 66. IR range 20 metres. External dimensions Ø 50 x (D) 105 mm. BNC video
connector.
Available soon
Day & Night colour cameras
BEST OVERVIEW
57
PRICE LIST no.E1
IR LED Day & Night Colour Cameras
TYPE 5GL6 € 292.00
Day & Night colour camera. DSP. Supply voltage 12 VDC. Resolution 480 TV
lines. 1/3" Sony sensor. 25 mm fixed lens. Aluminium housing and sunshade.
IR anti-reflective glass. Protection rating IP 66. 24 PIRANHA high luminosity IR
LEDs. Photo sensor for IR activation. Supplied with bracket.
Day & Night colour camera. 1/3" Sony Super HAD sensor. Pixels 500 (H) X 582 (V). Resolution
480 lines. Minimum illumination 0.04 lux (F 1.6 AGC on. 10 IRE). 0.6 lux (F 1.6 AGC ON. -
50 IRE). and ON – 0 lux. IR range 50m approx. 24 high luminosity LEDs - 850 nm. S/N ratio.
More than 48 dB (AGC OFF). Automatic electronic shutter 1/50 s ~ 1/110,000 s. AGC Automatic
gain control. White balance. Automatic (2500 k ~ 9500 k). Gamma correction 0.45. Lens 25 mm.
Automatic backlight. Beam angle 15°. Supply voltage 12 VDC ± 10%. Protection rating IP66.
Input current 500 mA 4.8 W maximum. Operating temperature: -10 °C ~ +50 °C. Dimensions:(ø)
85 x (D) 170 mm. BNC video connector.
TYPE 5AL4 € 109.00
Day & Night colour camera, 1/3" Sony sensor with DSP, resolution 520 TV lines,
3.6 mm fixed lens, aluminium housing and sunshade, IR anti-reflective glass,
23 IR LEDs, photo sensor for IR activation. Protection rating IP66. Bracket with
internal cable ducting. BNC video connector. Supply voltage: 12 VDC ± 10%
1/3" Sony Super HAD sensor, DSP. 23 infrared LEDs. High S/N ratio, more than 52 dB. (AES),
(AGC), (AWB) Automatic. Pixels 795 (H) X 586 (V). Horizontal resolution, 520 TV lines. Minimum
illumination 0 Lux with IR LEDs on. S/N ratio more than 52 dB. Automatic electronic shutter
1/50 s ~ 1/110,000 s. Automatic white balance. Gamma correction, 0.45. Lens 3.6 mm. Supply
voltage, 12 VDC ± 10%. Input current, 400 mA. Operating temperature, - 10 °C~ + 50 °C.
Protection rating, IP 66, IR range 20 metres approx. External dimensions, Ø 63 x 96. BNC video
connector.
TYPE 5AL9 € 115.00
Day & Night colour camera, 1/3" Sony sensor with Nextchip DSP, resolution
540 TV lines, 3.6 mm fixed lens, aluminium housing and sunshade, IR anti-
reflective glass, 23 IR LEDs, photo sensor for IR activation. Protection rating
IP66. Bracket with internal cable ducting. BNC video connector. Supply voltage:
12 VDC ± 10%,
1/3" Sony Super HAD sensor with Nextchip DSP. 23 infrared LEDs. High S/N ratio, more
than 52 dB. (AES), (AGC), (AWB). Pixels 795 (H) X 596 (V). Horizontal resolution, 540 TV lines.
Minimum illumination 0 Lux with IR LEDs on. S/N ratio more than 52 dB. Automatic electronic
shutter 1/50 s ~ 1/110,000 s. Automatic white balance. Gamma correction, 0.45. Lens 3.6 mm.
Supply voltage, 12 VDC ± 10%. Input current, 400 mA. Operating temperature, -10 °C~ +50 °C.
Protection rating, IP 66, IR range 15/20 metres approx. External dimensions, Ø 65 x 110. BNC
video connector.
TYPE 5AL8 € 89.00
Day & Night colour camera. DSP. Supply voltage 12 VDC. Resolution 420 TV
lines. 1/3" CCD sensor. 4 mm fixed lens. Aluminium housing. Waterproof. 23 IR
LEDs. Photo sensor for IR activation. Compact model. Supplied with bracket.
Day & Night colour camera. 1/3" CCD sensor. Pixels 512(H) x 582 (V). Electronic shutter 1/50
~ 1/100,000 sec. (automatic). Resolution 420 TV lines. White balance Automatic white balance
(2500° K ~ 9500° K). Internal synchronisation system. Sensitivity 0.2 lux; 0 lux at IR on / F2.0.
Automatic BLC. S/N ratio more than 48 dB. Automatic AGC. Gamma correction 0.45. IR range
10 metres based on reected IR light. 23 IR LEDs. Lens 4 mm standard. Supply voltage 12 VDC
250 mA ± 10%. Operating temperature -10 to 50 °C. Made of aluminium with weatherproof
protection. Dimensions 54 (ø) x 83 (D) mm. Weight 350 g. BNC video connector.
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
58
Varifocal Day & Night Colour Cameras
TYPE 5VL0 € 105.00
Day & Night camera with 4 - 9 mm VARIFOCAL lens. 1/3" SONY DSP sensor,
resolution 480 TV lines, aluminium housing and sunshade, IR anti-reective glass,
protection rating IP66, 36 LEDs Ø 5 mm. Photo sensor for IR activation. Complete
with bracket, cables routed internally. BNC video connector.
1/3" SONY Super HAD sensor with DSP. Pixels 500 (H) X 582 (V). Horizontal resolution, 480 TV
lines. Minimum illumination with LED ON, 0 Lux. IR range 30 m approx. 36 IR LEDs 5 mm Ø -
850 nm. S/N ratio more than 50 dB. Electronic shutter 1/50 s ~ 1/110,000 s. AGC Automatic
gain control. Automatic white balance. Gamma 0.45, 4 - 9 mm varifocal lens. Supply voltage
12 VDC ± 10%. Protection rating IP66. Input current 500 mA, Operating temperature -10 °C ~
+50 °C. External dimensions 150 x 100 x75 Ø mm. BNC video connector.
TYPE 5VL1 € 180.00
Day & Night colour video camera, DSP, Supply voltage 12 VDC. Resolution
480 TV lines. 1/3" Sony Super HAD sensor. 4 - 9 mm varifocal lens. Aluminium
housing and sunshade. IR anti-reflective glass. Protection rating IP 66. 36 high
luminosity IR LEDs ø 8 mm. Photo sensor for IR activation. Bracket with internal
cable channel.
Day & Night colour camera. DSP, 1/3" Sony Super HAD sensor. Pixels 500 (H) X 582 (V).
Resolution 480 lines. Minimum illumination level. LED ON – 0 lux IR range 50m approx. 36 high
luminosity LEDs ø 8 mm - 850 nm. S/N ratio. More than 48 dB. Automatic electronic shutter
1/50 s ~ 1/110,000 s. AGC Automatic gain control. Automatic white balance. Gamma correction
0.45. 4 - 9 mm varifocal lens. Supply voltage 12 VDC ± 10%. Protection rating IP66. Input
current 600 mA. Operating temperature -10 °C ~ +45 °C. Dimensions:(ø) 95 x (D) 150 mm. BNC
video connector.
TYPE 5VL2 € 254.00
Day & Night colour video camera, DSP, Supply voltage 12 VDC. Resolution
480 TV lines, 1/3" Sony Super HAD sensor, 9 - 22 mm varifocal lens, aluminium
housing and sunshade, IR anti-reflective glass, protection rating IP66, 36 high
luminosity IR LEDs Ø 8 mm. Photo sensor for IR activation, bracket with internal
cable channel.
Day & Night colour camera, DSP, 1/3" Sony Super HAD sensor, Pixels 500 (H) x 582 (V),
Resolution 480 lines, Minimum illumination level, LED ON – 0 lux, IR range 50 m approx., 36 high
luminosity LEDs ø 8 mm - 850 nm, S/N ratio more than 48 dB, Automatic electronic shutter
1/50 s ~ 1/110,000 s, AGC automatic gain control, Automatic white balance, Gamma correction
0.45, 9 - 22 mm varifocal lens, Supply voltage 12 VDC ± 10%, Protection rating IP 66, Input
current 600 mA. Operating temperature 10 °C ~ +45 °C. Dimensions:(ø) 95 x (D) 150 mm, BNC
video connector.
Day & Night colour cameras
BEST OVERVIEW
59
PRICE LIST no.E1
Varifocal and OSD Day & Night Cameras
Varifocal Day & Night Cameras
TYPE 5VL3 € 162.00
Day & Night camera with 4 - 9 mm VARIFOCAL lens. 1/3" SONY sensor with
Nextchip DSP, resolution 600 TV lines, aluminium housing and sunshade, IR anti-
reflective glass, protection rating IP66, 36 LEDs Ø 5 mm. Photo sensor for IR
activation. OSD control with Privacy functions, Motion Detection, Mirror function,
backlight, adjustable area. Complete with bracket, cables routed internally. BNC
video connector.
1/3" SONY Super HAD sensor with Nextchip DSP. Pixels 500 (H) X 582 (V). Horizontal resolution,
600 TV lines. Minimum illumination, LED ON - 0 lux. IR range 30 m approx. 36 LEDs Ø 5 mm -
850 nm. S/N ratio more than 52 dB. Electronic shutter, 1/50 s ~ 1/110,000 s (OSD adjustable).
Adjustable AGC automatic gain control. White balance, Adjustable ATW-AWB manual xed
(OSD control). Gamma correction, 0.05 – 1.0 (OSD control). Adjustable Day & Night function.
Backlight Super BLC, 64 zones (OSD control). OSD display: Camera ID. Mirror function. Motion
Detection. Privacy: 4 zones. Adjustments: contrast, brightness, sharpness. 4 - 9 mm varifocal
auto-iris lens.Supply voltage 12 VDC ± 10%, Protection rating, IP66. Input current, 500 mA.
Operating temperature, - 20 °C~ + 50 °C. External dimensions 146 x 84 x 80 Ø mm. BNC video
connector.
TYPE 52L4 € 272.00
Day & Night mini dome DSP colour camera, DSP, 1/3" Sony Super HAD sensor,
resolution 540 TV lines, 3.5 - 8 mm varifocal lens with superior characteristics,
vandalproof die-cast aluminium housing, IR anti-reflective glass, 28 IR LEDs,
photo sensor for IR activation. Protection rating IP66. BNC video connector.
Supply voltage 12 VDC ± 10%.
Day & Night DSP colour camera, 28 infrared LEDs. High S/N ratio. (AES), (AGC), (AWB)
automatic. 1/3" Sony Super HAD CCD colour sensor. Video signal standard PAL 1Vpp 75 Ohm.
Pixels 795 (H) X 596 (V). Resolution 540 TV lines. Minimum illumination 0 lux with IR LEDs on.
S/N ratio more than 48 dB. Automatic electronic shutter 1/50 s ~ 1/110,000 s. Automatic white
balance (2500 k ~ 9500 k). Gamma correction 0.45. 3.5 - 8 mm varifocal lens. Supply voltage
12 VDC ± 10%. Input current 490 mA. Operating temperature -10 °C ~ + 50 °C. Protection
rating IP 66. IR range ~30 metres. Dimensions:(ø) 119 x (D) 82.5 mm. BNC video connector.
TYPE 52L3 € 172.30
Day & Night colour camera. DSP. Mini dome. Supply voltage 12 VDC. Resolution
480 TV lines. 1/3" Sony sensor. 3.6 mm fixed lens. aluminium housing. IR anti-
reflective glass. Protection rating IP66. 24 IR LEDs. Photo sensor for IR activation.
Day & Night DSP colour camera. 24 infrared LEDs. High S/N ratio. (AES), (AGC), (AWB) automatic.
1/3" Sony colour CCD sensor. Video signal standard PAL 1Vpp 75 Ohm 320 k pixels. Pixels 500
(H) X 582 (V). Resolution 480 TV lines. Minimum illumination level 0.1 lux F1.2. 0 lux with IR LEDs
on. S/N ratio more than 48 dB. Automatic electronic shutter 1/50 s ~ 1/110,000 s. Automatic
white balance (2500 k ~ 9500 k). Gamma correction 0.45. Lens 3.6 mm. Supply voltage 12 VDC
± 10%. Input current 280 mA. Operating temperature -10 °C ~ + 50 °C. Protection rating IP 66.
IR range 10~15 metres. Dimensions:(ø) 94 x (D) 66 mm. BNC video connector.
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
60
Day & Night Colour Cameras
TYPE 52L2 € 97.30
Day & Night colour camera. Indoor mini dome. Supply voltage 12 VDC. Resolution
480 TV lines. 1/3" CCD sensor. 4 mm fixed lens. ABS housing. 20 IR LEDs. Photo
sensor for IR activation.
Day & Night camera. 1/3" CCD sensor. Pixels 512 (H) X 582 (V). Electronic shutter N: 1/60
– 1/100,000 sec. (automatic) P:1/50 – 1/100,000 sec. (automatic). Resolution 480 TV lines.
Automatic white balance (2500° K ~ 9500° K). Sensitivity 0.2 lux. 0 lux with IR on / F2.0.
Automatic BLC. S/N ratio more than 48 dB. IR range 15 metres based on reected IR light.
20 infrared LEDs. Lens 4 mm standard. input current (IR on): 200 mA. IR off: 120 mA. 12 VDC
5 mA. Supply voltage 12 VDC 300 mA ± 10%. Operating temperature from -10 to 50 °C. Video
output Composite. 1.0Vpp at 75 Ohm. BNC video connector. Dimensions:(ø) 115 x (D) 75 mm.
Weight 0.150 kg.
TYPE 50A2 € 75.80
Day & Night colour camera. Compact dimensions. Supply voltage 12 VDC.
Resolution 480 TV lines. 1/4" CCD sensor. 3.6 mm fixed lens, ABS housing, 6 IR
LEDs, for close-up illumination. Supplied with indoor bracket.
Day & Night colour camera, 6 infrared LEDs. Good S/N ratio. (AGC), (AWB) automatic. 1/4"
colour CCD sensor. Pixels 500 (H) X 582 (V). Resolution 480 TV lines. Minimum illumination level
0.1 lux F1.2. 0 lux with IR LEDs on. S/N ratio more than 48 dB AGC OFF. Automatic electronic
shutter 1/50 s ~ 1/110,000 s. Gamma correction 0.45. Lens 3.6 mm. Supply voltage 12 VDC
± 10%. Input current 150 mA. Operating temperature - 10 °C ~ + 50 °C. RH 95%. BNC video
connector.
Dimensions (W) 58 x (H) 50 x (D) 90 mm.
Day & Night colour cameras
TYPE 50A3 € 153.10
Mini indoor colour camera with aluminium mini bracket, 1/4" CCD sensor, 3.7 mm
pinhole lens. Resolution 480 TV lines.
¼" CCD sensor. Pixels 512 (H) X 582 (V), Resolution 480 TV lines, Minimum illumination
level 0.05 lux. S/N ratio more than 50 dB (AGC Off). Automatic electronic shutter, 1/50 s ~
1/110,000 s, Automatic white balance 2400 k ~ 11000 k. Gamma correction, 0.45. Backlight
(BLC). 3.7 mm xed lens, F 2.0. Supply voltage, 12 VDC ± 10%. Input current 175 mA, 2.1 W.
Operating temperature -10 °C ~ + 50 °C. Humidity 90%. Storage temperature -20 °C~+70 °C.
Humidity 70%. Dimensions:(ø) 22 x (D) 29.4 mm. Weight 17.5 g. BNC video connector. Material:
aluminium, supplied with mini bracket.
TYPE 50A4 € 153.10
Mini indoor colour camera in aluminium for flush mounting, ¼” CCD sensor,
3.7 mm pinhole lens. Resolution 480 TV lines.
¼" CCD sensor. Pixels 512 (H) X 582 (V), Resolution 480 TV lines, Minimum illumination
level 0.05 lux. S/N ratio more than 50 dB (AGC Off). Automatic electronic shutter, 1/50 s ~
1/110,000 s, Automatic white balance 2400 k ~ 11000 k. Gamma correction, 0.45. Backlight
(BLC). 3.7 mm xed lens, F 2.0. Supply voltage, 12 VDC ± 10%. Input current 175 mA, 2.1 W.
Operating temperature -10 °C~ + 50 °C. Humidity 90%. Storage temperature -20 °C~+70 °C.
Humidity 70%. Dimensions:(ø) 22 x (D) 29.4 mm. Weight 17.5 g. BNC video connector. Material:
aluminium, for ush mounting.
Day & Night colour cameras
BEST OVERVIEW
61
PRICE LIST no.E1
Colour Cameras
Day & Night Colour Cameras
TYPE 5WA5/1 € 212.80
Colour bullet camera. Sony 1/3" sensor with 3.6 mm lens, waterproof. Resolution
420 TV lines. Supplied with bracket.
1/3" Sony CCD sensor. Pixels: 500 (H) x 582 (V). Resolution: 420 TV lines Lens: 3.6 mm xed
focus. Minimum subject illumination (lux): 0.3 lux (F 2.0 AGC ON). Electronic shutter (iris):
1/50~1/100,000 sec (xed). Gamma correction: 0.45. Supply voltage: 12 VDC ±10%. Input
current: 100 mA. Operating temperature: -10 °C ~ +55 °C. Dimensions (ø) 24 x (D) 76 mm.
Indoor/outdoor compact waterproof camera. Supplied with 30 cm cable.
TYPE 52A1 € 463.00
DSP colour vandalproof mini dome camera. Supply voltage 12 VDC. Resolution
540 TV lines. 1/3" Sony Super HAD sensor. 3.5 - 8.5 mm auto-iris varifocal lens.
Water resistant indoor/outdoor die-cast aluminium housing.
Colour DSP camera, 2x varifocal lens 3.5 - 8.5 mm, 1/3" Sony Super HAD sensor. Pixels 752
(H) X 582 (V), Resolution 540 lines. Minimum illumination level 0.2 lux F1.2, S/N ratio more
than 48 dB), Automatic electronic shutter 1/50 s ~ 1/110,000 s, Gain Control, Super AGC
/ normal AGC selectable, White balance, automatic (2500 k ~ 9500 k), Gamma correction
0.45. Lens 3.5 mm / 8.5 mm, Synchronisation Internal Line Lock On/Off selectable Internal
Controls Electronic shutter On/Off, BLC On/Off,- AGC: Super, normal, Flickerless On/Off, Soft/
Sharp adjust, Supply voltage 12 VDC ± 10%, Input current 180 mA, Operating temperature,
-10 °C~ +50 °C, protection rating water resistant. Dimensions:(ø) 127 x (D) 100 mm. BNC video
connector.
TYPE 52A2 € 153.30
Mini dome DSP colour camera. Supply voltage 12 VDC Resolution 480 TV lines.
1/3" Sony Super HAD sensor. 3.6 mm fixed lens. Indoor ABS housing.
DSP colour camera. 1/3" Sony Super HAD CCD sensor. Pixels 500 (H) X 582 (V). Resolution
480 TV lines. Minimum illumination level 0.1 lux F1.2. S/N ratio more than 48 dB (AGC OFF).
Automatic electronic shutter. 1/50 s ~ 1/110,000 s. Automatic white balance 2500 k ~ 9500 k.
Gamma correction. 0.45. Automatic backlight BLC. 3.6 mm xed lens. Supply voltage. 12 VDC
± 10%, input current 100 mA. Operating temperature. -10 °C~ + 50 °C. Dimensions:(ø) 73 x (D)
50 mm. BNC video connector.
TYPE 52B2 € 157.10
DSP colour mini dome camera. Supply voltage 12 VDC. Resolution 480 TV lines.
1/3" Sony Super HAD sensor. 8 mm fixed lens. Indoor ABS housing.
DSP colour camera, 1/3" Sony Super HAD CCD sensor, Pixels 500 (H) X 582 (V), Resolution
480 TV lines, Minimum illumination level 0.1 lux F1.2, S/N ratio more than 48 dB (ACG Off),
Automatic electronic shutter, 1/50 s ~ 1/110,000 s, Automatic white balance 2500 k ~ 9500 k,
Gamma correction, 0.45, Automatic backlight (BLC), 8 mm xed lens, Supply voltage, 12 VDC
± 10%, Input current 100 mA, Operating temperature, -10 °C~ + 50 °C. Dimensions:(ø) 73 x (D)
50 mm. BNC video connector.
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
62
Colour Cameras
TYPE 52A3/I € 292.00
DSP colour mini dome camera. Supply voltage 12 VDC Resolution 540 TV lines.
1/3" Sony Super HAD sensor. 3.5 - 8.5 mm auto-iris varifocal lens. Indoor ABS
housing, for ceiling, suspended ceiling and wall mounting.
DSP colour camera. 2x varifocal lens 3.5 - 8.5 mm. 1/3" Sony Super HAD sensor. Pixels 752
(H) X 582 (V). Resolution 540 lines. Minimum illumination level 0.2 lux F1.2. S/N ratio more than
48 dB. Automatic electronic shutter 1/50 s ~ 1/110,000 s. Gain Control super AGC / normal
AGC selectable. Automatic white balance (2500 k ~ 9500 k). Gamma correction. 0.45. Lens
3.5 mm / 8.5 mm standard. Synchronisation. Internal Line Lock ON/OFF selectable. Internal
Controls Electronic shutter ON/ OFF. BLC ON/OFF. Flickerless ON/OFF. Soft/Sharp adjust.
Supply voltage 12 VDC ± 10%. input current 180 mA. Operating temperature. - 10 °C~ + 50 °C.
Dimensions:(ø) 127 x (H) 100 mm. BNC video connector.
TYPE 5AP6 € 120.60
Colour camera. DSP. Supply voltage 12 VDC. Resolution 420 TV lines. 1/3" CCD
sensor. 3.7 mm fixed lens. Indoor PIR housing made of ABS.
Colour DPS camera, 1/3" CCD colour sensor 3.7 mm. High S/N ratio. (AES), (AGC), (AWB)
automatic. Video signal standard PAL 1Vpp 75 Ohm. Pixels 500 (H) x 582 (V), 320 k pixels
PAL. Resolution 420 lines. Minimum illumination level 0.1 lux F1.2. S/N ratio more than 48 dB.
Automatic electronic shutter 1/50 s ~ 1/110,000 s. Automatic gain control. Automatic white
balance (2500 k ~ 9500 k). Gamma correction 0.45. Lens 3.7 mm / F2.0. Supply voltage 12 VDC
± 10%. input current 100 mA. Operating temperature - 10 °C ~ +50 °C. Dimensions:(ø) 130 x
(D) 58 mm. BNC video connector.
TYPE 5AP7 € 120.60
DSP colour video camera. Supply voltage 12 VDC. Resolution 420 TV lines. 1/3"
CCD sensor. 3.7 mm fixed lens. Indoor smoke-detector housing made of ABS.
Colour camera (DSP), 1/3" CCD colour sensor 3.7 mm. High S/N ratio. (AES), (AGC), (AWB)
automatic. Pixels 500 (H) x 582 (V), 320 k pixels PAL. Resolution 420 lines. Minimum illumination
level 0.1 lux F1.2. S/N ratio more than 48 dB. Automatic electronic shutter 1/50 s ~ 1/110,000 s.
Automatic white balance (2500 k ~ 9500 k). Gamma correction 0.45. Lens 3.7 mm / F2.0.
Supply voltage 12 VDC ± 10%. input current 100 mA. Operating temperature - 10 °C~ + 50 °C.
Dimensions:(ø) 130 x (D) 58 mm. BNC video connector.
Day & Night colour cameras
BEST OVERVIEW
63
PRICE LIST no.E1
Black and White Cameras
TYPE 52DM € 200.00
B/W CCIR camera, DSP. Supply voltage 85 to 265 VAC, 40-400 Hz. 1/3" Sony
Super HAD sensor. Resolution 600 TV lines. C/CS mount lens and mechanically
adjustable back focus.
1/3" Sony CCD sensor CCIR, Super HAD, Effective pixels 752 (H) x 582 (V), Horizontal resolution
600 TV lines, S/N ratio more than 52 dB (AGC off), Minimum illumination 0.01 lux (F1.2), ATW
large range: from 2400 K to 11000 K, C/CS lens mount, adjustable back focus, Backlight
compensation, DIP controls Int (internal) /LL (Line Lock) AGC min /AGC max, Gamma 1 /
Gamma 2, Shutter ON/OFF, BLC ON/OFF, automatic electronic iris: 1/50 (1/60) - 1/100,000 sec,
Operating temperature: from -10 °C to + 50 °C, Humidity: within 90% RH, Voltage 265 VAC
85 VAC / 40 Hz - 400 Hz, Power consumption (approx) 2.3 W, Dimensions 70 (W) x 58 (D) x 130
(H) mm. Weight 450 g BNC video connector. Lens purchased separately, VIDEO / DC Drive,
Manual lens compatibility.
TYPE 50A0 € 186.80
Waterproof B/W bullet camera with 3.6 mm lens. Resolution 380 TV lines.
Supplied with bracket.
Sensor: 1/3" CCD. Pixels: 500(H) x 582(V). Resolution: 380 TV lines Lens 3.6 mm xed focus.
Attachment for lens: Fixed lens. Signal-to-noise ratio: 45 dB (AGC OFF). Minimum subject
illumination (lux): 0.1 (F2.0 AGC ON). Electronic shutter (iris): 1/50~1/100,000 sec (xed). Gamma
correction: 0.45. Supply voltage: 9 ~ 14 VDC input current: 100 mA. Operating temperature:
-10 °C ~ +55 °C. Dimensions:(ø) 20 x (D) 53.5 mm. Waterproof indoor/outdoor bullet camera.
Supplied with 48 cm cable.
TYPE 522T/3 € 143.20
Waterproof B/W camera. Resolution 420 TV lines. Sony 1/3" sensor. 3.6 mm fixed
lens. Supply voltage: 12 VDC Colour: beige. Waterproof camera.
1/3" Sony CCD image sensor. Number of pixels EIA: 510 (H) x 492 (V) - CCIR: 500 (H) x 582 (V).
Automatic electronic shutter ON. Resolution 420 TV lines. S/N ratio more than 46 dB. Gamma
correction 0.45. Minimum illumination 0.02lux F/1.4. Horizontal sync frequency EIA: 15,734 kHz
- CCIR: 15,625 kHz. Vertical sync frequency 60 Hz (50 Hz). Power supply 12 VDC. Input
current 120 mA. Temperature - 10 °C ~ 60 °C. Lens 3.6 mm / F2.0. Shutter control EIA: 1/60 -
1/100,000 sec. CCIR: 1/50-1/100,000 sec. Dimensions 50 (W) X 80 (H). Gross weight 1000 g.
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
64
IP Cameras (LAN)
** Type 52IP, type 52IW, cannot be used in conjunction with products
300E, 400E, 500E, 600E, 700E, GATE
TYPE 52IP € 464.00
Colour camera for TCP/IP connection over LAN network: Supply voltage 12 VDC.
1/3" Sony Super HAD sensor. Resolution 420 TV lines. C/CS mount lens, MPEG4
compression format. 25 frames per second (FPS). Motion Detector. Alarm
transmission via e-mail. Internet browser. Built-in microphone, Backlight ON/
OFF selectable, BNC video output and RCA audio output, NC/NA alarm input/
output. RJ45 for Ethernet 10/100 Base. Password protection.
Includes power
supply unit.
Colour camera, 1/3" Sony Super HAD image sensor. Pixels NTSC: 512*492; PAL: 500*582 (H*V).
Resolution 420 TVL 1:2 interlaced. Minimum illumination (0.5 lux, F1.2). Automatic electronic
shutter AES: 1/60 s ~1/100,000 s. C or CS adjustable lens mount. Backlight compensation with
ON/OFF switch. Automatic iris control Video/DC. Video output 1Vpp composite / 75 Ohm MPEG4
compression format. Resolution 720x480. 360x240. (NTSC) 720x576. 360x288 (PAL). Refresh
frequency NTSC: Max 30FPS. PAL: max 25FPS. Quality Best / Super / High / Middle / Basic.
Alarm: activation mode. Motion detector. Sensor input. Action Relay output, e-mail transmission.
Input/Output 1/1 (NC&NO). Ethernet network 10/100 Base-T. RJ-45. Supported protocol TCP/
IP,HTTP,PPPoE,DDNS,DHCP,SMTP. Telnet. Audio input/output built-in microphone / RCA 2 Vpp
/ 50 Ohm. Built-in motion detector. Security password protection. Supply voltage 12V / 1 A – AC
100-240V A.C. External power supply unit as standard. Power consumption approx 7 W. Weight
approx 900 g. Dimensions: (W) 65 x (H) 53x (D) 110 mm. Operating temperature - 10 °C ~ 50 °C.
Storage temperature - 20 °C ~ 60 °C. Humidity 30% ~ 80% RH.
Lens purchased separately. VIDEO / DC Drive, Manual lens compatibility.
TYPE 52IW € 416.00
Indoor IP camera with ¼" CMOS sensor, 640x480 pixels, 0.5 lux, 4.5 mm fixed
lens (F2.8), Ethernet cable or wireless connection, with IR LEDs, MPEG4 – MJPEG
video compression. Protocols: TCP/IP, UDP, ICMP, DHCP, NTP, DNS, DDNS,
SMPT, FTP, HTTP, PPPoE, UPnP. Resolution VGA, QVGA, QQVGA, Motion
Detection function, 3GPP protocol for viewing on smartphones. Supply voltage
5 VDC 8 W.
Includes power supply unit.
Colour camera, ¼" CMOS image sensor
640x480 pixels, 3x digital zoom
. 4.5 mm xed lens F 2.8.
Minimum illumination (0.5 lux, F1.2). MPEG4 - MJPEG compression format. VGA resolution:
640x480. QVGA: 320x240 QQVGA 160x120. ARM9 network processor, ROM memory 8MB
NOR Flash, RAM memory 32MB SDRAM. Ethernet: one RJ 45 port IEEE 802.3U - 10/100 Mbps
Fast Ethernet with Auto-MDIX. Supported protocol TCP/IP, UDP, ICMP, DHCP, NTP, DNS, DDNS,
SMPT, FTP, HTTP, PPPoE, UPnP. Wireless IEEE 802.11b / 802.11g Wireless LAN. IP setting
Static, DHCP, PPPoE, email SMTP with two account congurations, two motion detection
parameters, event notication via email, FTP or Trigger output GPIO, system managed via Web-
based software application, Wireless Security WEP 64/128 bit; WPA (TKIP), WPA2. Supported
browser Internet Explorer 5.0 or higher, Firefox and Safari. Operating system Windows 2000,
Windows XP and Windows Vista. Automatic IP code search of cameras connected to LAN
Remote image view via 3GPP mobile phone. Power supply 12 VDC, external power supply
unit included as standard. Power consumption approx 8 W. Dimensions: (W) 65 x (H) 53x (D)
110 mm. Operating temperature - 0 °C ~ 45 °C. Storage temperature - 15 °C ~ 60 °C. Humidity
80% ~ 90% RH.
Day & Night colour cameras
BEST OVERVIEW
65
PRICE LIST no.E1
Indoor / Outdoor Speed Dome
Series: Smart Dome
Day & Night colour camera. DSP mini speed dome. Sens Up function. DNR and
Privacy function. Auto/manual mechanical switching IR-cut filter. Remote control
for programming. Supply voltage 13 VDC / 2 A. Mirror function.
Supply voltage 13 VDC 2 A, remote control included as standard.
Technical specifications:
Sensor 1/4" Sony Exview (Super HAD)
Resolution 540 lines TV
Lens Canon 23x optical zoom / F 3.6~82.8 mm / F 1.6~3.8 +
10x digital zoom
Electronic shutter PAL: 1/50 - 1/1000,000 sec. CCIR: 1/60 X ~ 1/100,000 sec
BLC Super BLC / BLC 48 zones
OSD function Menu in On Screen Display
Rotation mode Automatic pan / Preset and Patrol positions
Rotation angle Horizontal (PAN) 0°~375° / Vertical (TILT) 0°~90°
Rotation speed Horizontal (PAN) 100°/sec - Vertical (TILT) 100°/sec
Programmable speed
Automatic: approx. 2.5~60°/sec (variable)
Manual: approx. 2.5~160°/sec (variable)
Preset: Maximum: 320°sec
Alarm inputs 4 inputs
Alarm outputs 1 output
Preset 128
Controls Remote control via RS 485 and IR remote controller
No. of cameras 256 cameras
Supply voltage 13 VDC / 2 A
Operating temperature 0 °C ~ 50° Less than 30% ~ 90% RH (52D1/5)
-30 °C ~ 60° Less than 30% ~ 90% RH (52D1/E5)
Installation Indoor type 52D1/5 / Outdoor type 52D1/E5
Material
Type 52D1/5: Dome - smoked, acrylic material, Base -
black nish
Type 52D1/E5: Waterproof aluminium housing IP66 with
thermostatically-controlled heater and fan. Supply voltage
13 VDC (same as camera), wall and ceiling bracket.
Dimensions 52D1/5: Ø143x120 - 52D1/E5: housing 175x219 dome
75x126 Aluminium
TYPE 52D1/5 € 1,880.00
Indoor speed dome camera
TYPE 52D1/E5 € 1,935.00
Outdoor speed dome camera with ventilated waterproof housing and thermostatically-controlled
heater powered at the same voltage as the camera. IP66.
Wall and ceiling bracket supplied.
Type 52D1/5
Type 52D1/E5
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
66
Vandalproof Speed Dome
Series: Smart Dome
Day & Night DSP MINI SPEED DOME colour camera, vandalproof, for indoor/
outdoor installation, IP66, Sens-Up function, DNR, PRIVACY function, Mirror
function. Auto/manual mechanical switching IR-cut filter. Remote control for
programming, Patrol function, various protocols.
Supply voltage 13 VDC 2 A, remote control included as standard.
Technical specifications:
Sensor 1/4" Sony Exview Super HAD
Resolution 540 lines TV
Lens Canon 23x optical zoom / F 3.6~82.8 mm / F 1.6~3.8 +
10x digital zoom
Electronic shutter PAL 1/50 - 1/1000,000 sec. CCIR: 1/60 X ~ 1/100,000 sec
BLC Super BLC / BLC 48 zones
OSD function Menu in On Screen Display
Rotation mode Automatic pan / Preset and Patrol positions
Rotation angle Horizontal (PAN) 0°~375° / Vertical (TILT) 0°~90°
Rotation speed Horizontal (PAN) 100°/sec - Vertical (TILT) 100°/sec
Programmable speed
Automatic: approx. 2.5~60°/sec (variable)
Manual: approx. 2.5~160°/sec (variable)
Preset: Maximum: 320°sec
Alarm inputs 4 inputs
Alarm outputs 1 output
Preset 128
Controls Remote control via RS 485 and IR remote controller
No. of cameras 256 cameras
Supply voltage 13 VDC / 2 A
Operating temperature 0 °C ~ 50° Less than 30% ~ 90% RH
Installation Indoor and Outdoor with bracket type 52S1/6
Material Dome - smoked nish, acrylic material, Base - black nish
Aluminium waterproof housing IP66
Dimensions Ø143x120 mm, 0.86 kg
Auto Tracking function Type 52D1/6T only
TYPE 52D1/6 € 2,074.00
Indoor/outdoor vandalproof MINI SPEED DOME camera
TYPE 52D1/6T € 2,709.00
Indoor/outdoor vandalproof MINI SPEED DOME camera with Auto Tracking function
Day & Night colour cameras
BEST OVERVIEW
67
PRICE LIST no.E1
Indoor / Outdoor Speed Dome
Series: Small Dome
Day & Night SPEED DOME colour camera, OSD control,
PRIVACY function,
mechanical IR cut filter, SSNR, Sens up, supply voltage
12 VDC / 0.8 A.
Wall and ceiling bracket supplied.
Technical specifications:
Sensor 1/4" Sony Interline
Resolution 540 lines TV
Lens 10x optical zoom + 10x digital zoom
Electronic shutter 1/60 X ~ 1/120000 sec
BLC OFF / Low / Medium / High
OSD function Menu in On Screen Display
Rotation mode 360 °Continuous Pan 180° Tilt (automatic ip)
Rotation speed Manual: 0.05 ~ 360° sec. Preset: 360° sec. Swing 1 ~
180° sec
Alarm inputs 4 inputs
Alarm outputs 1 output
Presets 127
Patterns 4
Swings 8
Groups 8 Groups (20 action entities per group)
Protocols Pelco D / Pelco P
Controls RS 485
No. of cameras 255 cameras
Supply voltage 12 VDC / 0.8 A / 8 W
Operating temperature - 10 °C + 50 °C
Installation Indoor type 52D0/8 / Outdoor type 52D0/E8
Material die-cast aluminium, white nish
IP66 for type 52D0/E8 only
Dimensions Type 52D0/8: Ø 125 x 190 - Type 52D0/E8: Ø 127.5 x 204
Weight 1 kg approx
TYPE 52D0/8 € 830.00
Indoor SPEED DOME camera.
TYPE 52D0/E8 € 865.00
Outdoor SPEED DOME camera IP66.
Type 52D0/8
Type 52D0/E8
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
68
Keypads for speed dome cameras
TYPE 52D8/5 € 672.00
Speed dome camera control keypad, compatible with all speed dome cameras,
can also control 500 series Performer DVRs in addition to zoom camera type 52Z0.
Keypad for RS-485 control system, can be extended to a medium or large system for integrated
controls. Extra-large LCD for easy information reading. Integral universal joystick, for easy
manoeuvring. Broad range of functions and straightforward installation. 2-axis joystick: right,
left, up, down movement. Protocol: (Pelco-D-P) Baud rate selectable. Voltage: 12 VDC 500 mA.
Power consumption: 6 W. Dimensions: (W) 320 x (H) 55 x (D) 190 mm. LCD display: 20x4 LCD.
Weight: 1.3 kg. Notes: Can also control cameras type 52ZO and 500 series DVRs.
TYPE 52D8/6 € 499.00
Control keypad for speed dome cameras: Type 52D1/5, 52D1/E5, 52D1/6,
52D1/6T. 3-axis movement: right, left, up, down, focus.
Speed dome control keypad.RS485 transmission. 20x4 LCD display. 3-axis joystick: right, left,
up, down, focus movement. Protocol Pelco D Pelco P. Baud Rate selectable. Supply voltage
12 VDC. Includes power supply unit. Power consumption 6 W. Dimensions W-310 x H-50 x
D-170 mm. Weight 1 kg.
TYPE 52D8/8 € 280.00
Small plastic keypad for Small Dome cameras, with Three Axis function, Protocol
Pelco D, Pelco P. Includes power supply unit 12 VDC 0.5 A.
Speed dome control keypad.RS485 half-duplex transmission. LCD display 65x15 3-axis joystick
with right, left, up, down, zoom in/out movement. Protocol Pelco D - Pelco P - TopHiD1 -
TopHiP1 - TopHiD2 - TopHiP2. Baud rate selectable. Supply voltage 12 VDC. Includes power
supply unit. Power consumption 6 W.
Dimensions: 200 x 57 x 140 mm (WxHxD). Weight 0.65 kg.
Day & Night colour cameras
BEST OVERVIEW
69
PRICE LIST no.E1
Mounting brackets
TYPE 52A1/5 € 111.70
Ring for suspended ceiling installation.
Ring for suspended ceiling installation of camera type 52D1/5.
TYPE 52S1/5 € 111.70
Bracket for wall mounting.
Wall bracket for indoor Speed Dome cameras type 52D1/5.
TYPE 52S1/6 € 111.70
Bracket for wall mounting.
Wall bracket for indoor/outdoor vandalproof IP66 Speed Dome cameras type 52D1/6, 52D1/6T.
TYPE 529F € 39.52
Corner bracket.
Corner adapter bracket in beige for Speed Dome waterproof housings type 52D1/E5.
TYPE 529B € 46.80
Pole mount with adapter for speed dome waterproof housing.
Pole mount type 529A in beige. Minimum pole diameter 60 mm. Maximum diameter 170 mm.
Dimensions: (W) 170 x (H) 110 mm. Maximum load capacity 30 kg. With adapter for tting
waterproof housing type 52D1/E5 adapter overall dimensions 141x81 mm.
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
70
Housings and brackets
TYPE 5299/001 € 173.30
Outdoor housing for CCTV cameras with thermostatically-controlled heater.
Housing dimensions: (W) 130 x (H) 120 x (D) 375 mm. Bracket dimensions: (W) 45 x (H) 80 x (D)
195 mm. Thermostatically-controlled heater: PTC 24 VAC 70 W. Protection rating: IP66. Weight:
2.5 kg. Material: Housing made of extruded aluminium with black painted nish, shelter made of
anodised die-cast aluminium.
TYPE 5299/004 € 253.00
Waterproof housing for camera with protected cable passage system.
Housing dimensions: (W) 128 x (H) 130 x (D) 410 mm. Bracket dimensions: length 235 mm.
Thermostatically-controlled heater: 230 Vac 13 W. Protection rating: IP66. Colour: RAL 9002.
Weight: 2.95 kg. Material: Body made of plastic material. Shelter made of aluminium.
TYPE 529P € 61.80
Waterproof aluminium housing with thermostatically-controlled heater, bracket
not supplied.
Housing dimensions: (W) 120 x (H) 110 x (D) 405 mm. Thermostatically-controlled heater:
230 VAC 21 W. Protection rating: IP 65. Weight: 1.2 kg. Material: Aluminium housing. Colour:
beige.
TYPE 529P/12 € 75.00
Waterproof aluminium housing, IP65, in beige with thermostatically-controlled
heater, without bracket. Bracket purchased separately. For use with power
supply unit type 5AA1 or 832/024.
Housing dimensions: (W) 120 x (H) 110 x (D) 405 mm. Thermostatically-controlled heater:
12 VDC or 24 VAC 10 W. Protection rating: IP 65. Weight: 1.2 kg. Material: Aluminium housing.
Colour: beige.
TYPE 529S € 20.57
Articulated wall bracket for housing 529P.
Bracket dimensions: (W) 73 x (H) 115 x (D) 238 mm. Load capacity: 8 kg. Material: aluminium.
Colour: beige. Weight: 0.35 kg.
TYPE 529A € 20.27
Pole mount for waterproof housings type 529P/529S.
Colour: beige. For installation of maximum two waterproof housings. Minimum pole diameter
60 mm. Maximum diameter 170 mm. Dimensions: (W) 170 x (H) 110 mm. Maximum load
capacity 30 kg.
TYPE 529A/17 € 46.00
Pole mount for waterproof housings Speed Dome type 52D0/8 - 52D0/E8.
Colour: white. For installation of maximum two waterproof housings. Minimum pole diameter
60 mm. Maximum diameter 170 mm. Dimensions: (W) 170 x (H) 110 mm. Maximum load
capacity 30 kg.
TYPE 5288/016 € 9.32
Articulated camera bracket for wall mounting.
Camera bracket in black ABS for wall mounting.
Dimensions: (W) 130 mm.
Day & Night colour cameras
BEST OVERVIEW
71
PRICE LIST no.E1
Mounting brackets
TYPE 5288/016.05 € 9.32
Articulated camera bracket for wall mounting.
Camera bracket in cream ABS for wall mounting.
Dimensions: (W) 130 mm.
TYPE 5288/017 € 19.56
Articulated camera bracket for ceiling mounting.
Camera bracket in black aluminium for ceiling mounting.
Dimensions: (H) 190 x (D) 150 mm.
TYPE 5288/029 € 6.59
Compact wall bracket.
Maximum load capacity 1 kg, H angle 360° V angle 90°. Material: zinc, plastic Colour: silver.
Dimensions:(ø) 50 x (D) 75 mm.
TYPE 5288/030 € 8.11
Medium-sized wall bracket.
Maximum load capacity 1 kg, H angle 360° V angle 90°. Material: zinc, plastic. Colour: silver.
Dimensions:(ø) 50 x (D) 95 mm.
TYPE 5288/031 € 18.24
Wall bracket.
Maximum load capacity 2 kg, H angle 360° V angle 90°. Material: aluminium, cables routed
internally. Colour: silver Dimensions:(ø) 50 x (D) 130 mm.
TYPE 5288/032 € 9.94
Wall bracket with extension up to 60 mm.
Maximum load capacity 1.5 kg. H angle 360°. V angle 90°. Material: aluminium, plastic. Colour:
beige. Dimensions:(ø) 46 x (D) 175 mm.
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
72
Lenses
TYPE 0002/308 € 126.60
3.5 - 8 mm VARI-FOCAL lens with 1.8 F aperture, CS mount and manual iris.
Focal length (mm): 3.5 - 8. Aperture (F): 1.8. Horizontal angle of view: 70° ~ 33.5°. Attachment
for lens: CS. Iris: manual. Notes: Manual zoom lens.
TYPE 0002/612 € 174.90
3.5 - 8 mm VARI-FOCAL lens with 1.4 F aperture, C mount and manual iris
Focal length (mm): 6 - 12. Aperture (F): 1.4. Horizontal angle of view: 43.6° ~ 33.5°. Attachment
for lens: C. Iris: manual. Notes: Manual zoom lens.
TYPE 0022/308 € 204.70
3 - 8 mm VARI-ZOOM lens with 1.4 F aperture, CS mount and auto-iris.
Focal length (mm): 3 ~ 8. Aperture (F): 1.4. Horizontal angle of view: 92.9° ~ 35.7°. Attachment
for lens: CS. Iris: automatic. Notes: Manual zoom lens.
TYPE 0022/612 € 204.70
6-12 mm VARI-ZOOM lens with 1.4 F aperture, C mount and auto-iris.
Focal length (mm): 6 ~ 12. Aperture (F): 1.4. Horizontal angle of view: 43.6° ~ 22.6°. Attachment
for lens: C. Iris: automatic. Notes: Manual zoom lens.
Megapixel Lenses
TYPE 0002/5M5 € 61.00
Manual zoom lens with manual iris, for Megapixel IR cameras size 1/3" CS mount.
Focal length (mm): 5 ~ 15. Aperture (F) 1.4 Horizontal angle of view: 52° ~ 18° on camera with
1/3" CCD, 39° ~ 14° on camera with 1/4" CCD. Minimum object distance 0.2m. Manual iris for
applications up to 50m. Dimensions: Ø 31 x 42.1 mm. Weight: 55 g.
Day & Night colour cameras
BEST OVERVIEW
73
PRICE LIST no.E1
Professional series DC Drive lenses
TYPE 0023/308 € 88.50
Varifocal, unamplified manual zoom lens with auto-iris, CS mount.
Focal length (mm): 3 ~ 8. Aperture (F): 1.4. Horizontal angle of view: 80° ~ 34° at 3 mm 80°,
at 8 mm. 34°. Attachment for lens: CS. Iris: unamplied automatic. DC Drive. Aspherical anti-
reective lens. Minimum object distance: 0.3 m.
TYPE 0023/550 € 216.60
Varifocal, unamplified manual zoom DC Drive lens with auto-iris, CS mount.
Focal length (mm): 5 ~ 55. Aperture (F): 1.4. Horizontal angle of view: 54° ~ 5.6° at 5 mm 54°,
at 55 mm. 5.6°. Attachment for lens: CS. Iris: unamplied automatic. DC Drive. Aspherical anti-
reective lens. Minimum object distance: 0.3 m.
Standard series DC Drive lenses
TYPE 0024/212 € 52.00
Varifocal, unamplified manual zoom DC Drive lens with auto-iris, CS mount.
Focal length (mm): 2.5 ~ 12. Aperture (F) 1,4 Horizontal angle of view: 90° ~ 23° at 2.5 mm 90°,
23° at 12 mm Attachment for lens: CS mount. Iris: unamplied automatic. DC Drive. Minimum
object distance: 0.3 m.
TYPE 0024/660 € 61.00
Varifocal, unamplified manual zoom DC Drive lens with auto-iris, CS mount.
Focal length (mm): 6 ~ 60. Aperture (F) 1,6 Horizontal angle of view: 44° ~ 4.7° at 6 mm 44°,
4.7° at 60 mm Attachment for lens: CS mount. Iris: unamplied automatic. DC Drive. Minimum
object distance: 0.3 m.
Megapixel Lenses
TYPE 0023/515 € 77.00
Manual zoom DC Drive lens with auto-iris, for Megapixel IR cameras size 1/3"
CS mount.
Focal length (mm): 5 ~ 15. Aperture (F) 1.4 Horizontal angle of view: 41° ~ 19° on camera with
1/3" CCD, 36° ~ 15° on camera with 1/4" CCD. Minimum object distance 0.2m. Manual iris DC
Drive for applications up to 50m. Dimensions: Ø 29 x 38.2 mm. weight: 58 g.
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
74
Infrared illuminators
TYPE 5250/L € 233.10
Infrared LED spotlight with built-in twilight sensor.
Illumination angle: 24°. Distance: 40 m ~. Wavelength: 880nm. Power: 9 W. Housing: extruded
aluminium and plastic. Polyester powder paint nish, colour RAL 7035 light grey. Operating
temperature: +20 °C ~ +50 °C.Installation: Indoor / outdoor. Protection rating: IP66. Weight:
1.5 kg. Supply voltage: 230 VAC with 1 m pre-wired cable. Notes: PF2 plate for mounting on
the housing supplied. Built-in adjustable twilight sensor. Trimmer for adjusting cut-in threshold.
Dimensions:(W) 110 x (H) 110 x (D) 200 mm.
TYPE 5251/L € 233.00
Infrared LED spotlight with built-in twilight sensor.
Illumination angle: 40°. Distance: 25 m ~. Wavelength: 880nm. Power: 9 W. Housing: extruded
aluminium and plastic. Polyester powder paint nish, colour RAL 7035 light grey. Dimensions:
(W) 110 x (H) 110 x (D) 200 mm. Operating temperature: -20 °C ~ +50 °C. Installation: Indoor
/ outdoor. Protection rating: IP66. Weight: 1.5 kg. Supply voltage: 230 VAC with 1 m pre-wired
cable. Notes: PF2 plate for mounting on the housing supplied. Built-in adjustable twilight sensor.
Trimmer for adjusting cut-in threshold.
TYPE 5250 € 279.00
50 W infrared spotlight with illumination angle of 10°.
Illumination angle: 10°. Maximum illumination distance: 10m. Wavelength: 750nm. Lamp life:
more than 2000h. Operating temperature: -10 °C ~ +50 °C. Supply voltage: 230 VAC - 50 Hz
Power: 50 W. Housing: Black die-cast aluminium. Protection rating: IP66. Dimensions:(ø) 100 x
(D) 180 mm. Weight: 850 g.
TYPE 5251 € 288.00
50 W infrared spotlight with illumination angle of 30°.
Illumination angle: 30°. Maximum illumination distance: 10m. Wavelength: 750nm. Lamp life:
more than 2000h. Operating temperature: -10 °C ~ +50 °C. Supply voltage: 230 VAC - 50 Hz
Power: 50 W. Housing: Black die-cast aluminium. Protection rating: IP66. Dimensions:(ø) 100 x
(D) 180 mm. Weight: 850 g.
Day & Night colour cameras
BEST OVERVIEW
75
PRICE LIST no.E1
Power supply units
TYPE 6582 € 47.79
Supplementary power supply unit 12 / 13.5 VDC 250 mA.
Power supply unit designed for wall mounting with plugs or on electrical panel with Omega DIN
rail with a size of 4 modules, to supply video distributors type 5556/004, amplier type 5559 and
12 VDC cameras Supply voltage: 230 VAC 50 Hz. Dimensions: (W) 75 x (H) 115 x (D) 65 mm
(with caps on).
TYPE 6583/12 € 143.74
Power supply unit for cameras in parallel 12 VDC 1.6 A.
Power supply unit designed for wall mounting with plugs or on electrical panel with Omega DIN
rail with a size of 12 modules, to supply multiple cameras in parallel. Supply voltage: 230 VAC.
50-60 Hz 60 VA.
TYPE 5AA0 € 15.60
Power supply unit with European plug. 12 VDC 0.6 A.
Input voltage 100~230 VAC - 50/60 Hz. Output voltage 12 VDC Max current 0.6 A. Max power
7.2 W. Electronic protection, output lead with standard jack connector. Plugs directly into socket
outlet. LED power-on indicator.
Dimensions: (W) 23 x (H) 70 x (D) 60 mm.
TYPE 5AA6 € 17.80
Power supply unit with European plug 12 VDC 1.25 A.
Input voltage 100~230 VAC – 50/60 Hz. Output voltage 12 VDC Max current 1.25 A Maximum
power 14 W. Electronic protection. Output lead with standard jack connector. Plugs directly into
socket outlet. Dimensions: (W) 45 x (H) 30 x (D) 70 mm.
TYPE 5AA1 € 31.42
Power supply unit for junction box type 503. 12 VDC 1 A.
Input voltage 100~230 VAC - 50/60 Hz. Output voltage 12 VDC Max current 1 A. Max power
12 W. PTC protection on primary. Input leads connected with screw terminals, output leads
connected with screw terminals. For tting to junction box type 503. Dimensions: (W) 45 x (H)
40 x (D) 23 mm.
TYPE 5AA2 € 43.58
Desktop power supply unit. 12 VDC 2 A.
Input voltage 100~230 VAC - 50/60 Hz. Output voltage 12 VDC. Max current 2 A. Max power
24 W. Electronic protection. Input power lead with Schuko plug. Output lead with standard jack
connector desktop mounting LED power-on indicator. Dimensions: (W) 50 x (H) 35 x (D) 93 mm.
TYPE 5AA5 € 67.90
Modular power supply unit. 12 VDC 4.2 A.
Input voltage 100~230 VAC - 50/60 Hz. Output voltage 12 VDC. Max current 4.2 A. Max
power 50 W. Electronic protection. Input leads and output leads connected with terminals, DIN
mounting, 2 modules, LED power-on indicator.
Dimensions: (W) 43 x (H) 60 x (D) 87 mm.
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
76
Accessories
Transformers
TYPE 832/024 € 26.12
Low-voltage safety transformer. 24 VAC 30 VA.
Description: Power supply unit designed for wall mounting with plugs or on electrical panel with
Omega DIN rail with a size of 4 modules, to supply thermostatically-controlled heater in housings
type 5299. 5299/001. 5299/002 or cameras with 24V supply voltage. Supply voltage: 230 VAC
50 Hz.
Dimensions: (W) 75 x (H) 115 x (D) 65 mm (with caps on).
Distributors
TYPE 5556/004 € 41.70
Video distributor with 4 outputs for coaxial cable.
Distributor designed for wall mounting with plugs or on electrical panel with Omega DIN rail with
a size of 4 modules, for oor video signal or for multiple cable risers, with 4 outputs. Supply
voltage: 12 VDC supplied by power supply unit type 6582.
Dimensions: (W) 75 x (H) 115 x (D) 65 mm (with caps on).
ART. 52DV/4 € 72,00
Video distributor with 4 outputs for coaxial cable.
Coaxial video distributor with 1 BNC video input and 4 BNC video outputs. Bandwidth 10 Hz
to 10 MHz, video input 1 Vpp 75 Ohm. Supply voltage 12 VDC input current 100mA. Includes
power supply unit. Material: ABS, Colour: black. Dimensions: 138x86x29.5 mm.
ART. 52DV/8 € 119,00
Video distributor with 8 outputs for coaxial cable.
Coaxial video distributor with 1 BNC video input and 8 BNC video outputs. Bandwidth 10 Hz
to 10 MHz, video input 1 Vpp 75 Ohm. Supply voltage 12 VDC input current 150 mA. Includes
power supply unit. Material: metal, Colour: black. Dimensions: 133x87x44 mm.
Day & Night colour cameras
BEST OVERVIEW
77
PRICE LIST no.E1
Video ampliers
TYPE 5559 € 180.02
Video signal amplifier.
Video amplier designed for wall mounting with plugs or on electrical panel with Omega DIN
rail with a size of 4 modules, for connection lines with 75 Ohm coaxial cable over 200 m long,
compensated up to 1000m. Supply voltage: 12 - 18 VDC. Dimensions: (W) 75 x (H) 115 x (D)
65 mm (with caps on).
TYPE 52AM € 61.40
Video signal amplifier for coaxial cable. Wide bandwidth and video gain
compensation. Input impedance adjustment. HF/MF/LF compensation for colour
gain. Highly balanced mode of video transmission for extra interference immunity.
Protected against extra current. LED power indicator. Transmission up to 1000 m
with RG59 coaxial cable. 12 VDC supply voltage. Includes power supply unit.
Essential for maintaining video signal quality over long distances to DVRs.
Video amplier with 1 input channel, 1 output channel. Video signal level 0.8~1.2 Vpp - 75 Ohm.
Output signal level 1 Vpp -75 Ohm. Bandwidth 10 Hz – 10 MHz. Transmission distance 1000 m.
Supply voltage 12 VDC input current 100 mA. Dimensions: (W) 138 x (H) 76 x (D) 32 mm. Weight
310 g. Material: ABS, Colour: black. Includes power supply unit 12 VDC 500 mA.
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
78
LCD-TFT Colour Monitors
TYPE 5212/C56 € 401.00
Colour desktop monitor with 5.6" TFT LCD screen with 2 video inputs and 1
audio input, includes 12 VDC power supply unit.
Screen LCD:5;6". type: TFT-LCD. Scanning system NTSC/PAL. Active display area: 4:3
(142 mm). Pixels: 114,640. Input signal: 1.0 Vpp composite video Controls: ON/OFF, volume,
L/R Mirror, video input V1-V2. Connections: RCA video input and output. Supply voltage: from
11 ~ 13 VDC 9 W. With external power supply unit included: input 230 VAC 50 Hz Output
12 VDC / 1.2 A. Dimensions: (W) 167 x (H) 129 x (D) 28.5 mm. Weight: 568 g. Operating
temperature: 0 °C ~ 40 °C. Notes: Supplied with articulated bracket and connection lead.
TYPE 5208 € 320.00
Desktop monitor with 8" TFT LCD high-resolution screen. OSD control. Video
inputs: 2 AV, 1 VGA. Desk bracket, also suitable for wall mounting. 12 Volt supply
voltage with power supply unit included. VGA cable not supplied.
8" LCD/TFT screen. Scanning system PAL / NTSC. Resolution 800x600 SVGA - 800x480 VGA.
Screen area 162x121.5 mm. Aspect ratio 4:3. Screen colours 262 K. Luminance (nit) 250 cd/m.
Contrast ratio 500:1. Angle of view 70/70/50/70. Response time 25 ms. Video input: 2 A/V
inputs composite video 1 Vpp – 75 Ohm BNC (yellow), 1 VGA/SVGA D-sub 15-pin connector.
Audio input 2 BNC (white). Supply voltage 12 VDC 0.5 A - 6 W includes power supply unit
12 VDC 1 A. Bracket for desktop or wall mounting, OSD functions. Dimensions: (W) 200 x (H)
165 x (D) 30 mm. Weight: 675 g. Operating temperature: 0° ~ 50 °C. Operating humidity 20%~
80%. Storage temperature -20 °C~70 °C. Storage humidity 20%~80%.
TYPE 5210 € 426.00
Desktop monitor with 10.2" high-resolution LCD TFT screen, 16:9 aspect ratio.
OSD control. Video inputs: 2 AV, 1 VGA-SVGA, 1 S-Video. Desk bracket, also
suitable for wall mounting. 12 Volt supply voltage with power supply unit included.
Remote controller.
10.2" LCD/TFT screen. Scanning system PAL / NTSC. Resolution 800x480. Screen area
220.0x113.2 mm. Aspect ratio 16:9. Screen colours 262 K. Luminance (cd/m²) 450. Contrast
ratio 300:1. Angle of view 50/60/60/60. Response time 30 ms. Video input and output: 2 -
BNC Input, 2 - BNC output Composite video 1.0 Vpp auto terminated – S-Video- Y (1.0Vpp)
C (0.285Vpp) – 4 P IN Min Din / INx1 / Outx1 – PC VGA IN - RGB-D-Sub 15 pin. Audio input
and output: 1 RCA IN – 1 RCA OUT 30 ~ 100 m Vpp (Mono) Output 8 Ohm 2 W. Control
buttons: OSD functions and On/Off. Power supply unit features: input 96~260 VAC / 50/60 Hz
Output 12 VDC 5 A. Monitor power consumption 12 VDC - 700 mA, 8.4 W. Attachment VESA
100/75 standard. Dimensions: (W) 275.5 x (H) 187 x (D) 45.5 mm. Weight: 1.7 kg. Operating
temperature: 0° ~ 50 °C. Operating humidity 20%~ 85%. Storage temperature -20 °C~60 °C.
Storage humidity 10%~85%. Includes remote control.
TYPE 5217/1 € 691.00
17" active matrix LCD colour monitor. 12 Volt supply voltage with power supply
unit included. Adjustable colour temperature. 2D comb filter.
17" LCD TFT screen. Scanning system PAL/NTSC. Resolution 1280x1024 – 75 Hz. Active area
37,920(H)x270,336(V). Pixel 0.264x0.264.Aspect ratio 5.4.- 16.7 million colours. Contrast ratio
500:1. Luminance 300~420 cd/m². Angle of view 140°/140°. Video input signal VGA- SVGA.
Analogue RGB (0.7Vpp 75 Ohm). Horizontal resolution, 625 TV lines 50 frames/sec PAL. OSD
controls Audio IN VGA power consumption 30 Watt max. 3 Watt in standby. Temperature
0~+50 °C. Humidity 20%~85%. Dimensions: (W) 395 x (H) 395 x (D) 170 mm. Net weight 5 kg.
Gross weight 7 kg. Power supply unit 12 VDC/4.2° INCLUDED.
Day & Night colour cameras
BEST OVERVIEW
79
PRICE LIST no.E1
LCD-TFT Colour Monitors
TYPE 5219/1 € 578.00
19" LCD colour monitor. 12 Volt supply voltage with power supply unit included.
OSD control.
Desktop monitor with high resolution LCD TFT 19” screen (1280x1024 pixels). OSD control.
Video inputs: 1 AV, 1 VGA-SVGA, SVideo. Supply voltage: 12 VDC 1.2A, adapter included
(230VAC 50Hz). Monitor power consumption 40W (1W in standby).
Dimensions (width x height x depth): 413x424x200 mm.
TYPE 5217/H € 850.00
17" active matrix LCD high-resolution colour monitor, 12 volt supply voltage with
power supply unit included. 3D comb filter colour temperature control.
17" LCD TFT screen. Scanning system PAL/NTSC. Resolution 1280x1024 – 75 Hz. Active
area 37,920(H)x270,336(V). Pixel 0.264x0.264.Aspect ratio 4.3.- 16.7 million colours. Contrast
ratio 800:1. Luminance 450 cd/m². Angle of view 140°/140°. Video input signal VGA- SVGA.
Analogue RGB (0.7Vpp 75 Ohm). Horizontal resolution, 625 TV lines 50 frames/sec PAL. OSD
controls Audio IN VGA. Power consumption 30 Watt max. 3 Watt in standby. Temperature
0~+50 °C. Humidity 20%~85%. Dimensions: (W) 395 x (H) 395 x (D) 170 mm. Net weight 5 kg.
Gross weight 7 kg. Power supply unit 12 VDC/4.2 A included.
LCD/TFT monitor VGA and Audio only
TYPE 5217/SB € 251.00
17" LCD TFT desktop monitor. OSD control. Video inputs: 1 VGA. Desk bracket,
also suitable for wall mounting. 12 Volt supply voltage with power supply unit
included.
Desktop monitor with high resolution LCD TFT 17” screen (1280x1024 pixels), 4:3 format. OSD
control. 1 VGA video input, 1 audio input. Desk stand, also suitable for wall mounting with Vesa
standard attachment. Supply voltage 100 to 240 Vac. Input current: 38 W.
Dimensions (width x depth x height): 366x389x171 mm
TYPE 5219/VGA € 548.00
Professional 19" LCD TFT desktop monitor. OSD control. Video inputs: 1 VGA/
SVGA/XGA/SXGA, 1 DVI. Desk bracket, also suitable for wall mounting. 12 Volt
supply voltage with power supply unit included.
19" LCD/TFT screen. Scanning system PAL / NTSC. Resolution 1280x1024. Screen area
376.3x301 mm. Aspect ratio 4:3. Screen colours 16.7M. Luminance (cd/m²) 300. Contrast ratio
700:1. Angle of view 80/80/85/85. Response time 3.6/1.4 ms. Video input: PC VGA – SVGA /
RGB-D-Sub 15 pin - DVI. Audio input and output: 1 RCA IN – 1 RCA OUT 50 m~100 m Vpp
2 W. Control buttons: OSD functions and On/Off. Power supply unit features: input 90~260 VAC
/ 50/60 Hz Output 12 VDC 5 A. Monitor power consumption 12 VDC - 3 A - 36 W. Attachment
VESA 100/75 standard. Dimensions: (W) 430 x (H) 356 x (D) 66.78 mm. Weight: 4.8 kg. Operating
temperature: 0° ~ 40 °C. Operating humidity 10%~ 85%. Storage temperature -10 °C~50 °C.
Storage humidity 10%~85%
NEW
NEW
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
80
Accessories for LCD-TFT Monitors
TYPE 5288/028 € 39.52
Wall bracket, supports 15-30" LCD/TFT monitor.
Bracket supports 15" to 30" LCD/TFT monitor with VESA 75/100 adapter. Recommended for
most commercially available monitors. Made of metal with black polyester powder paint nish.
Wide range of adjustments both vertical (20° downward) and horizontal (90° right - left). Set of
screws for xing monitor included. Maximum load capacity 30 kg. Dimensions: (W) 140 x (H)
140 x (D) 70.5 mm.
TYPE 5288/S28 € 105.00
Wall or ceiling bracket, supports 15-30" LCD/TFT monitor.
Bracket supports 15" to 30" LCD/TFT monitor with VESA 75/100 adapter. Recommended for
most commercially available monitors. Made of metal with light grey polyester powder paint
nish. Wide range of adjustments both vertical (20° downward) and horizontal (90° right - left).
Internal cable ducting. Roof mount extendable from 510 to 900 mm. Set of screws for xing
monitor included. Maximum load capacity 30 kg. Dimensions: (W) 140 x (H) 140 x (D) minimum
510 maximum 900 mm.
Day & Night colour cameras
BEST OVERVIEW
81
PRICE LIST no.E1
Single-line wiring diagrams
Class: Practical
N. 4 Video Inputs
N. 1 Audio
Input
N. 1 Audio
Output
N. 1 VGA
Output
N. 4 Ingresso
Allarme
N. 1 Allarm
Output
N. 2 BNC
Outputs
Backup
(USB pen drive or
external HDD)
Software for backup view over USB
Series: 400
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
82
Single-line wiring diagrams
Class: Performer
N. 16 Ingressi video
N. 1 Audio
Input
N. 1 VGA
Output
N. 2 BNC
Outputs
Backup
(USB pen drive or
external HDD)
Other
Cameras
Other
Cameras
N. 1 Audio
Output
N. 16 Allarm
Input
N. 1 Allarm
Output
RS485 (PTZ)
RS485 (PTZ)
RS485 (PTZ)
LAN
LAN
Internet
3G Mobile Remote PC
Control Keypad to 16 DVR
Series: 500
Day & Night colour cameras
BEST OVERVIEW
83
PRICE LIST no.E1
Class: Performer
(Version for DVR type 524H/524 - 526 - 528)
Software for camera and backup view
Software for remote camera viewing
Software for camera view via mobile phone
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
84
Single-line wiring diagrams
Class: Performer Space
N. 4 Video Inputs
Backup
(USB pen drive or
external HDD)
Internet
iPhone Remote PC
RS485 (PTZ)
N. 1 Audio Input
N. 1 Audio Output
N. 1 Allarm Output
N. 4 Allarm Inputs
N. 1 BNC
Output
Software for remote camera viewing.
For 3G
Symbian
and Windows
Mobile 5/6 operating system on
PDA.
Smartphone: Nokia, Sony Ericsson
(
BlackBerry and iPhone from
software version K1.1.51).
Can send alarm or motion detection signals by mail or FTP.
Remote PC
N.1 BNC
Output
CMS software allows remote monitoring of 16 DVRs.
Essential for viewing up to 32 images from a single screen.
Day & Night colour cameras
BEST OVERVIEW
85
PRICE LIST no.E1
N.16 video inputs
N. 4 audio inputs
N. 1 audio output
N. 1 VGA
output
N. 16 Allarm
inputs
N. 1 Allarm
output
N. 2 BNC outputs
Backup
(USB pen drive or
external HDD)
RS485 (FTP)
Internet
3G Mobile Remote PC
LAN
N. 1 S-Video output
N. 16
Video loop
Class: Performer Space
Series: 600
Software for remote camera viewing
For 3G Symbian
and Windows
Mobile 5/6 operating system on
PDA.
Smartphone:
Nokia
,
Sony Ericsson,
BlackBerry, iPhone.
CMS software allows remote monitoring of 16 DVRs.
Essential for viewing up to 32 images from a single screen.
Software for
camera view via
mobile phone.
Can send alarm or motion detection signals by mail or FTP.
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
86
Single-line wiring diagrams
Class: Professional
Series: 800
N. 8/16 Video Inputs
N. 1 VGA
Output
N. 8/16 Allarm
Inputs
N. 4 Allarm
Outputs
N. 3 BNC
Outputs
Backup
(USB pen drive or
external HDD)
RS485
Internet
PDA Windows
Mobile Remote PC
LAN
N. 8/16 Audio Inputs N. 2 Audio
Outputs
N. 1 S-VIDEO
Output
N. 8/16 Video loop
Professional CMS software, allows remote monitoring of 256 cameras, with
E-Mapping function for easy identication of individual cameras. Essential for
centralised viewing of up to 16 DVRs from a single screen.
Software for viewing
cameras via PDA with
Windows Mobile 5/6 operating
system.
Day & Night colour cameras
BEST OVERVIEW
87
PRICE LIST no.E1
DVR Digital video recorders
Class: Practical Series: 400
Digital video recorder with 4 video inputs and 1 audio input. Alarm input and
motion detection, real-time display and programmable recording, without LAN
network, OSD in Italian, backup to USB. Control via mouse.
Technical specifications:
Input 4CH Inputs 1.0Vpp, 75 Ohm unbalanced (BNC type)
Output BNC x2 (master monitor 1 - slave monitor1), VGA
Horizontal resolution 640x448 (NTSC) / 640x554(PAL)
Screen division 1,4, sequence
Screen quality
Maximum: 720(H)x 480(V) Active Pixels (NTSC); 720(H) x
576(V) Active Pixels (PAL)
1/4 Screen: 360(H) x 240(V) Active Pixels (NTSC); 360(H) x
288(V) Active Pixels (PAL)
Display rate PAL 100 FPS
Maximum recording 50 FPS
Recording quality Super, High, Fine, Normal, Low
Image compression M-JPEG
Recording mode Continuous, Scheduled, Motion detect, Alarm
Search in playback mode Search by Events, or by Date, Time, Minutes, Seconds
Multi-channel playback 1.4
Operating mode Duplex
Motion Detect function
Area Division: 16 x12, sector selectable, ON/OFF.
Motion detect recording and relay on at the same time
Alarms 4 Input alarms / 1 relay output
Audio connectors RCA x 1/RCA x 1
USB 1 X USB Mouse - 1 X USB Backup
HDD capacity Type 523H/404: Without HDD
Type 524H/404: With 320 GB HDD
Supply voltage 12 VDC / 3 A
Weight Net: 6.2 kg / Gross 9.1 kg
Dimensions 215 (W) x 235 (D) x 50 (H) mm
Operating temp. 41 °F~104 °F (5 °C~+40 °C)
Operating humidity Less than 90%
TYPE 523H/404 € 212.00
Digital video recorder without HDD.
TYPE 524H/404 € 334.00
Professional digital video recorder with 320 GB HDD (maximum capacity 1TB) for digital video
recording.
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
88
DVR Digital video recorders
Class: Performer Series: 500
Digital video recorder with 4 video inputs. Remote view software allows you to
monitor, backup, playback and control the DVR. Complete with CMS (Central
Management System) software. Remote view via IE browser, smartphone, PDA
and iPhone.
Technical specifications:
Input 4CH Inputs 1.0Vpp, 75 Ohm unbalanced (BNC type)
Output BNC x2 (master monitor - slave monitor), S-Video and VGA
Horizontal resolution 720X480(NTSC) / 720X576(PAL)
Screen division 1,4, sequence
Screen quality Full: 720(H) x 480(V) Active pixels (NTSC); 720(H) x 576(V)
Active pixels (PAL)
Display rate 25 FPS PAL - 30 FPS NTSC per channel
Recording rate
D1 - PAL 50FPS (704x576) - NTSC 60FPS (704x480)
Half D1 - PAL 50FPS (704x288) - NTSC 60FPS (704x240)
CIF – PAL 100FPS (352x288) - NTSC120FPS (352x240)
Recording quality Super, High, Medium, Low
Image compression H264
Recording mode Normal, Scheduled, Motion detect, Alarm
FPS per channel Resolution D1 - Half D1 - CIF and FPS Programmable
per channel
Search in playback mode Search by Events, or by Time, Minutes, Seconds
Multi-channel playback 1.4
Operating mode Pentaplex
Motion Detect function Area division: 16x16 and adjustable sensitivity
for each camera
RJ45 network function Remote Viewer through static IP
Dynamic IP (DDNC) or PPPOE
Alarms 4 Input alarms / 1 relay output
Audio connectors RCA x 1
USB 1 X USB Mouse - 1 X USB Backup
Backup USB / network
PTZ control Multi-protocol
RS485 For control of external keypad
IR remote control Standard
HDD capacity 320 GB SATA HDD (max 1 HDD x 2 TB)
Supply voltage 12 VDC / 5 A
Weight Net: 6.2 kg / Gross 9.1 kg
Dimensions 290 (W) x 222 (D) x 60 (H) mm
Operating temp. 41 °F~104 °F (5 °C~+40 °C)
Operating humidity Less than 90%
TYPE 524H/524 € 495.00
Day & Night colour cameras
BEST OVERVIEW
89
PRICE LIST no.E1
DVR Digital video recorders
Class: Performer Series: 500
Digital video recorder with 8 video inputs. Remote view software allows you to
monitor, backup, playback and control the DVR. Complete with CMS (Central
Management System) software. Remote view via IE browser, smartphone, PDA
and iPhone.
Technical specifications:
Input 8CH Inputs 1.0Vpp, 75 Ohm unbalanced (BNC type)
Output BNC x2 (master monitor - slave monitor), S-Video and VGA
Horizontal resolution 720X480(NTSC) / 720X576(PAL)
Screen division 1,4,8 sequence
Screen quality Full: 720(H) x 480(V) Active pixels (NTSC); 720(H) x 576(V)
Active pixels (PAL)
Display rate 25 FPS PAL - 30 FPS NTSC per channel
Recording rate
D1 - PAL 50FPS (704x576) - NTSC 60FPS (704x480)
Half D1 - PAL 100FPS (704x288) - NTSC 120FPS
(704x240)
CIF – PAL 200FPS (352x288) - NTSC 240FPS (352x240)
Recording quality Super, High, Medium, Low
Image compression H264
Recording mode Normal, Scheduled, Motion detect, Alarm
FPS per channel Resolution D1 - Half D1 - CIF and FPS Programmable by
channel
Search in playback mode Search by Events, or by Time, Minutes, Seconds
Multi-channel playback 1,4,9
Operating mode Pentaplex
Motion Detect function Area division: 16x16 and adjustable sensitivity for each
camera
RJ45 network function Remote Viewer through static IP
Dynamic IP (DDNC) or PPPOE
Alarms 8 Input alarms / 1 relay output
Audio connectors RCA x 1
USB 1 X USB Mouse - 1 X USB Backup
Backup USB / network / CD - DVR/RW
PTZ control Multi-protocol
RS485 For control of external keypad
IR remote control Standard
HDD capacity 320 GB SATA HDD (max 1 HDD x 2 TB )
Supply voltage 12 VDC / 5 A
Weight Net: 6.2 kg / Gross 9.1 kg
Dimensions 340 (W) x 270 (D) x 70 (H) mm
Operating temp. 41 °F~104 °F (5 °C~+40 °C)
Operating humidity Less than 90%
TYPE 524H/528 € 614.00
TYPE 524H/58D € 730.00
Digital video recorder with DVD/RW burner
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
90
DVR Digital video recorders
Class: Performer Series: 500
Digital video recorder with 16 video inputs. Remote view software allows you to
monitor, backup, playback and control the DVR. Complete with CMS (Central
Management System) software. Remote view via IE browser, smartphone, PDA
and iPhone.
Technical specifications:
Input 16CH Inputs 1.0Vpp, 75 Ohm unbalanced (BNC type)
Output BNC x2 (master monitor - slave monitor), S-Video and VGA
Horizontal resolution 720X480(NTSC) / 720X576(PAL)
Screen division 1,4,8,13,16,sequence
Screen quality Full: 720(H) x 480(V) Active pixels (NTSC); 720(H) x 576(V)
Active pixels (PAL)
Display rate PAL 400 FPS (16x25) - NTSC 480 FPS (16x30)
Recording rate
D1 - PAL 100FPS (704x576) - NTSC 120FPS (704x480)
Half D1 - PAL 50FPS (704x288) - NTSC 60FPS (704x240)
CIF – PAL 100FPS (352x288) - NTSC 120FPS (352x240)
Recording quality Super, High, Medium, Low
Image compression H264
Recording mode Normal, Scheduled, Motion detect, Alarm
FPS per channel Resolution D1 - Half D1 - CIF and FPS Programmable by
channel
Search in playback mode
Search by Events, or by Time, Minutes, Seconds
Multi-channel playback
1,4,8,13,16
Operating mode Pentaplex
Motion Detect function Area division: 16x16 and adjustable sensitivity for each
camera
RJ45 network function Remote Viewer through static IP
Dynamic IP (DDNC) or PPPOE
Alarms 16 Input alarms / 1 relay output
Audio connectors RCA x 1 IN / RCA x 1 OUT
USB 1 X USB Mouse - 1 X USB Backup
Backup USB / network / CD-RW / DVR-RW
PTZ control Multi-protocol
RS485 For control of external keypad
IR remote control Standard
HDD capacity 320 GB SATA HDD (max 1 HDD x 2 TB)
Supply voltage 12 VDC / 6.7 A
Weight Net: 6.2 kg / Gross 9.1 kg
Dimensions 430 (W) x 320 (D) x 80 (H) mm
Operating temp. 41 °F~104 °F (5 °C~+40 °C)
Operating humidity Less than 90%
TYPE 524H/526 € 852.00
Day & Night colour cameras
BEST OVERVIEW
91
PRICE LIST no.E1
DVRs with TFT/LCD Colour Monitor
Class: Performer Space
Digital video recorder with 4 video inputs and 15" TFT LCD monitor. Remote
view software allows you to monitor, backup, playback and control the DVR with
authorised password. Remote view via IE browser, smartphone and PDA. Multi-
language OSD.
Technical specifications:
Input 4CH Inputs 1.0Vpp, 75 Ohm unbalanced (BNC type)
Output BNC x1
Horizontal resolution 720X480(NTSC) / 720X576(PAL)
Screen division 1,4, sequence
Recording resolution D1/ NTSC:720x240-PAL:720x288 - CIF/ NTSC:360x240-
PAL:360x288
Recording rate D1/ NTSC:720x240-60 FPS - PAL:720x288- 50 FPS
CIF/ NTSC:360x240-120 FPS - PAL:360x288- 100FPS
NTSC-PAL recording
1/30(1/30), 1/15(1/15), 1/10(1/10), 1/5 (1/5), 1/3 (1/3), 1/2 (1/2),
1(1), 2(2), 3(3.13), 5(5), 10 (8.33), 15(12.5), 30(25), 60(50
)
Recording quality Super, High, Fine, Normal, Low
Image compression H264, Low: 1 KB / Medium:2.2 KB / High:3.2 KB / Best:
6 KB
Recording mode Manual / Date-Time / Schedule
Search in playback mode Search by events, list or date
OSD function Date – Time - Menu programming
Operating mode Triplex
Connections 4 users simultaneously
RJ45 network function DDNS / PPPoE / DHCP / E-Mail / FTP
Alarms 4 Input alarms / 1 relay output
Audio connectors RCA x 1/RCA x 1
USB 1 X USB Mouse - 1 X USB Backup
Backup USB / network
PTZ control Pelco D / Pelco P
Monitor 15" LCD, resolution 1024x768
LCD Luminance/Contrast 250 Nit / 500:1
HDD capacity 320 GB HDD
Supply voltage 12 VDC / 5 A
Weight 8.3 kg
Dimensions 355 (W) x 228 (D) x 75 (H) mm
Operating temp. 0 °C~+40 °C)
Operating humidity 85%
TYPE 524H/615 € 1,262.00
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
92
DVR Digital video recorders
Class: Performer Space Series: 600
Digital video recorder with 16 video inputs. Remote view software allows you to
monitor, backup, playback and control the DVR. Complete with CMS (Central
Management System) software.
Remote view via IE browser, smartphone, PDA and iPhone.
Technical specifications:
Input Type 524H/616: 8CH Inputs (BNC / LOOP)
Output BNC x1 - BNC x1 Spot Monitor - SVideo x1 - VGA x1
Horizontal resolution 720X480(NTSC) / 720X576(PAL)
Screen division Type 524H/608: 1,4,9 -Type 524H/616: 1,4,9,13,16
Screen quality Full: 720(H) x 480(V) Active pixels (NTSC); 720(H) x 576(V)
Active pixels (PAL)
Display rate PAL 400 FPS (16x25) - NTSC 480 FPS (16x30)
Recording rate D1/ NTSC:720x240 - 120 FPS / PAL:720x288 - 100 FPS
CIF/ NTSC: 360x240 - 240 FPS / PAL:360x288 – 200 FPS
Recording resolution D1/ NTSC:720x240 / PAL:720x288
CIF/ NTSC:360x240 / PAL:360x288
Image compression H264 (Low: 1 Kb / Medium:2.2 Kb / High:3.2 Kb /
Best: 6 Kb)
Recording mode Manual / Date-Time / Schedule
Search in playback mode Search by events, or by list or date
Operating mode Triplex
RJ45 network function Remote Viewer through static IP
Dynamic IP (DDNS), PPPOE, DHCP, E-Mail, FTP
Alarms Type 524H/616: 16 Input alarms / 1 relay output
Audio connectors RCA x 1 IN / RCA x 1 OUT
USB 1 X USB Mouse - 1 X USB Backup
Backup USB / network / CD-RW / DVR-RW
Motion detector 30x24 grid, sensitivity adjustable 1-100
PTZ control Pelco D / Pelco P
RS485 For control of external keypad
OSD function Date – Time - plus Menu programming
Connections Up to 4 users simultaneously
HDD capacity 1 x 320 GB SATA HDD (max 2 x 1000 GB HDD)
Supply voltage 90 ~ 260 VAC - 45 W
Weight 1.3 kg
Dimensions 430 (W) x 380 (D) x 91 (H) mm
Operating temp. from 0 °C to 45 °
Operating humidity 85%
TYPE 524H/626 € 1,342.00
NEW
Day & Night colour cameras
BEST OVERVIEW
93
PRICE LIST no.E1
DVR Digital video recorders
Class: Professional Series: 800
Digital video recorder with 8 video inputs. Remote view software allows you to
monitor, backup, playback and control the DVR. Complete with CMS (Central
Management System) & E-MAPPING software. Remote view via IE browser and
PDA.
Technical specifications:
Input 8CH Inputs 1.0Vp-p, 75 Ohm unbalanced (BNC type)
8CH Audio inputs, (RCA type
Output BNC x2 - BNC x1 Spot Monitor - SVideo x1 - VGA x1
Horizontal resolution 720X480(NTSC) / 720X576(PAL)
Screen division 1,4,8, sequence
Zoom Available in Live & PB, 2 x 2 zoom
Display rate 200 FPS (8x25)
Recording rate
200 FPS
Recording quality NTSC - 240 FPS (352X240), 60 FPS (720X480)
PAL - 200 FPS (352X288), 50 FPS (720X576)
Compression MPEG 4 for Video, G.723 for Audio
Recording mode Continuous, Scheduled, Motion detect, Alarm
Search in playback mode Search by events, or by date, time, minutes, seconds
Multi-channel playback 1,4,8
Operating mode Pentaplex
Motion Detect function Area division: 16 x12, sector selectable, ON/OFF. Motion
detect recording and relay on at the same time
RJ45 network function Remote Viewer with Static IP code, or Dynamic TCP/IP,
UDP, HTTP, SMTP, NTP, DHCP, DDNS
Network operation
w/ AP: monitoring, remote setting, PTZ control, backup
and playback
w/ IE: viewer, event notication, multi-user access, two-
way audio, CMS and E-MAP
Alarms 8 Input alarms / 4 relay output
Audio connectors RCA x 8 IN / RCA x 2 OUT
USB 1 X USB Mouse - 1 X USB Backup
Backup USB / network / CD-RW / DVR-RW
PTZ control Multi-protocol
RS485 For control of external keypad
OSD function Date – Time - plus Menu programming
Connections Up to 5 users simultaneously
HDD capacity 1 x 320 GB SATA HDD (max 3 x 750 GB HDD)
Supply voltage 12 VDC - 6.7 A
Dimensions / Weight 430 (W) x 370 (D) x 90 (H) mm / 7.5 kg
Operating temp. 40 °F~104 °F (5 °C~+40 °C) - less than 80%
TYPE 524H/878 € 1,945.00
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
94
DVR Digital video recorders
Class: Professional Series: 800
Digital video recorder with 16 video inputs. Remote view software allows you to
monitor, backup, playback and control the DVR. Complete with CMS (Central
Management System) & E-MAPPING software. Remote view via IE browser and
PDA.
Technical specifications:
Input 16CH Inputs 1.0Vp-p, 75 Ohm unbalanced (BNC type)
16CH Audio inputs, (RCA type)
Output BNC x2 - BNC x1 Spot Monitor - SVideo x1 - VGA x1
Horizontal resolution 720X480(NTSC) / 720X576(PAL)
Screen division 1,4,8,13,16, sequence
Zoom Available in Live & PB, 2 x 2 zoom
Display rate 400 FPS (16x25)
Recording rate 400 FPS
Recording quality NTSC - 480 FPS (352X240), 120 FPS (720X480)
PAL - 400 FPS (352X288), 100 FPS (720X576)
Compression MPEG 4 for Video, G.723 for Audio
Recording mode Continuous, Scheduled, Motion detect, Alarm
Search in playback mode Search by events, or by date, time, minutes, seconds
Multi-channel playback 1,4,8,13,16
Operating mode Pentaplex
Motion Detect function Area division: 16 x12, sector selectable, ON/OFF. Motion
detect recording and relay on at the same time
RJ45 network function Remote Viewer with Static IP code, or Dynamic TCP/IP,
UDP, HTTP, SMTP, NTP, DHCP, DDNS
Network operation
w/ AP: Monitoring, remote setting, PTZ control, backup
and playback
w/ IE: viewer, event notication, multi-user access, two-
way audio, CMS and E-MAP
Alarms 16 Input alarms / 4 relay output
Audio connectors RCA x 16 IN / RCA x 2 OUT
USB 1 X USB Mouse - 1 X USB Backup
Backup USB / network / CD-RW / DVR-RW
PTZ control Multi-protocol
RS485 For control of external keypad
OSD function Date – Time - plus Menu programming
Connections Up to 5 users simultaneously
HDD capacity 1 x 320 GB SATA HDD (max 3 x 750 GB HDD)
Supply voltage 12 VDC - 6.7 A
Dimensions / Weight 430 (W) x 370 (D) x 90 (H) mm / 7.5 kg
Operating temp. 40 °F~104 °F (5 °C~+40 °C) - less than 80%
TYPE 524H/816 € 2,075.95
Day & Night colour cameras
BEST OVERVIEW
95
PRICE LIST no.E1
Black/white CCTV kits
TYPE 52PM € 336.00
CCTV kit comprising 1 B/W camera type 52DM. 1 lens type 23/308. 1 waterproof
aluminium housing type 529P and bracket type 529S.
Kit comprising: 1 DSP B/W camera with 1/3" Sony Super HAD high-resolution CCD sensor.
Supply voltage from 85 to 265 VAC type 52DM. 1 VARIFOCAL lens with manual zoom (3 to
8 mm - F 1.4) type 23/308. 1 IP 65 waterproof aluminium housing with thermostatically-controlled
heater 230 VAC 21 W type 529P. 1 articulated wall bracket for waterproof housing type 529S.
TYPE 52PM/550 € 426.00
CCTV kit comprising 1 B/W camera type 52DM. 1 lens type 23/550. 1 waterproof
aluminium housing type 529P and bracket type 529S.
Kit comprising: 1 B/W DSP camera with 1/3" Sony Super HAD high-resolution CCD sensor.
Supply voltage from 85 to 265 VAC type 52DM. 1 VARIFOCAL lens with manual zoom (5 to
55 mm - F 1.4) type 23/550. 1 IP 65 waterproof aluminium housing with thermostatically-
controlled heater 230 VAC 21 W type 529P. 1 articulated wall bracket for waterproof housing
type 529S.
Colour CCTV kits
TYPE 52PN € 473.00
CCTV kit comprising 1 colour camera type 52DN. 1 lens type 23/308. 1 waterproof
aluminium housing type 529P and bracket type 529S. Not sensitive to infrared
light.
Description: Kit comprising: 1 Day & Night DSP colour camera with 1/3" Sony Super HAD
high-resolution CCD sensor. Supply voltage from 85 to 265 VAC type 52DN. 1 VARIFOCAL
lens with manual zoom (3 to 8 mm - F 1.4) type 23/308. 1 IP 65 waterproof aluminium housing
with thermostatically-controlled heater 230 VAC 21 W type 529P. 1 articulated wall bracket for
waterproof housing type 529S.
TYPE 52PN/550 € 563.00
CCTV kit comprising 1 colour camera type 52DN. 1 lens type 23/550. 1 waterproof
aluminium housing type 529P and bracket type 529S. Not sensitive to infrared
light.
Kit comprising: 1 Day & Night DSP colour camera with 1/3" Sony Super HAD high-resolution CCD
sensor. Supply voltage from 85 to 265 VAC type 52DN. 1 VARIFOCAL lens with manual zoom
(5 to 55 mm - F 1.4) type 23/550. 1 IP 65 waterproof aluminium housing with thermostatically-
controlled heater 230 VAC 21 W type529P. 1 articulated wall bracket for waterproof housing
type 529S.
TYPE 52PR € 503.00
CCTV kit comprising 1 colour camera type 52DN/IR. 1 lens type 23/308.
1 waterproof aluminium housing type 529P and bracket type 529S.
Kit comprising: 1 Day & Night DSP colour camera with 1/3" Sony EXVIEW high-resolution CCD
sensor. Supply voltage from 85 to 265 VAC type 52DN/IR. 1 VARIFOCAL lens with manual zoom
(5 to 55 mm - F 1.4) type 23/308. 1 IP 65 waterproof aluminium housing with thermostatically-
controlled heater 230 VAC 21 W type 529P. 1 articulated wall bracket for waterproof housing
type 529S.
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
96
Colour CCTV Kits
TYPE 52PR/550 € 593.00
CCTV kit comprising 1 colour camera type 52DN/IR. For checking vehicle licence
plates. 1 lens type 23/550. 1 waterproof aluminium housing type 529P and
bracket type 529S.
Kit comprising: 1 Day & Night DSP colour camera with 1/3" Sony EXVIEW high-resolution CCD
sensor. Supply voltage from 85 to 265 VAC type 52DN/IR. 1 VARIFOCAL lens with manual zoom
(5 to 50 mm - F 1.4) type 23/550. 1 IP 65 waterproof aluminium housing with thermostatically-
controlled heater 230 VAC 21 W type 529P. 1 articulated wall bracket for waterproof housing
type 529S.
Colour CCTV kit for checking vehicle licence plates
TYPE 52PT € 546.00
CCTV kit comprising 1 colour camera type 52DN/IR, specially designed for
checking vehicle licence plates. 1 lens type 23/308. 1 waterproof aluminium
housing type 529P and bracket type 529S.
Kit comprising: 1 Day & Night DSP colour camera with 1/3" Sony EXVIEW high-resolution CCD
sensor. With IR lter and shutter speed control. Supply voltage from 85 to 265 VAC type 52DT.
1 VARIFOCAL lens with manual zoom (3 to 8 mm - F 1.4) type 23/308. 1 IP 65 waterproof
aluminium housing with thermostatically-controlled heater 230 VAC 21 W type 529P. 1 articulated
wall bracket for waterproof housing type 529S.
TYPE 52PT/550 € 636.00
CCTV kit comprising 1 colour camera type 52DN/IR, specially designed for
checking vehicle licence plates. 1 lens type 23/550. 1 waterproof aluminium
housing type 529P and bracket type 529S.
Kit comprising: 1 Day & Night DSP colour camera with 1/3" Sony EXVIEW high-resolution CCD
sensor. With IR lter and shutter speed control. Supply voltage from 85 to 265 VAC type 52DT.
1 VARIFOCAL lens with manual zoom (5 to 50 mm - F 1.4) type 23/550. 1 IP 65 waterproof
aluminium housing with thermostatically-controlled heater 230 VAC 21 W type 529P. 1 articulated
wall bracket for waterproof housing type 529S.
Day & Night colour cameras
BEST OVERVIEW
97
PRICE LIST no.E1
STAR LIGHT Colour CCTV Kits
TYPE 52P0/660 € 336.00
CCTV kit comprising: 1 Day & Night colour camera, Hitachi DSP, Starlight with
mechanical filter, 0.0001 lux type 52D0/3, 1 lens type 24/660. 1 waterproof
aluminium housing type 529P/12 and bracket type 529S.
Kit comprising: 1 indoor Day & Night DSP colour camera with 1/3" Sony Super HAD CCD sensor,
high resolution up to 620 TV lines. With mechanical IR lter, Slow Shutter, 0.0001 lux. Supply
voltage 12 VDC - 24 VAC Input current 150 mA VDC 100 mA VAC type 52D0/3. 1 VARIFOCAL
lens with manual zoom (6 to 60 mm - F 1.6) type 24/660. 1 IP 65 waterproof aluminium housing
with thermostatically-controlled heater 12 VDC / 24 VAC 10 W max type 529P/12. 1 articulated
wall bracket for waterproof housing type 529S.
NOTE: This kit can be powered with 12 VDC using power supply unit type 5AA1, 12 VDC 1 A.
Can also be installed directly in the waterproof housing.
Or with 24 VAC using 4-module DIN rail transformer type 832/024 24 VAC 30 VA.
TYPE 52P0/212 € 290.00
Kit comprising: 1 Day & Night colour camera, Hitachi DSP, Starlight with
mechanical filter, 0.0001 lux type 52D0/3, 1 lens type 24/212, 1 waterproof
aluminium housing with 12 VDC or 24 VAC thermostatically-controlled heater,
housing type 529P/12 and 1 bracket type 529S.
Kit comprising: 1 Day & Night colour camera, Hitachi DSP, Starlight with mechanical lter,
0.0001 lux, 1/3" Sony Super HAD CCD sensor, high resolution up to 620 TV lines, type 52D0/3,
1 VARIFOCAL lens with manual zoom (2.5 to 12 mm - F 1.4) type 24/212, 1 IP 65 waterproof
aluminium housing with thermostatically-controlled heater 12 VDC / 24 VAC 10 W max
type 529P/12. 1 articulated wall bracket for waterproof housing type 529S.
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
98
Passive transducers
TYPE 52TP € 5.77
Compact passive transducer, easy to install, BNC connector for connection to
camera, fixing screws for CAT5 cable connection. Maximum distance for colour
video 330 m. PAL/NTSC/SECAM/CCIR modes.
Transducer with direct connector. Frequency response: 8 MHz DC 60 dB. Transmission over
CAT5 twisted pair cable. Immune to background noise. Attenuation 0.5 dB. BNC connector
and xing screws for twisted pair cable. BNC impedance 75 Ohm. Terminated at 100 Ohm.
Operating temperature -10 °C ~ +70 °C. Storage temperature -30 °C ~ +70 °C. Operating
humidity 0~95%. Dimensions: (W) 184 x (H) 54 x (D) 60 mm body only. Weight 46 g. Material:
ABS plastic.
TYPE 52TP/1 € 5.77
Compact passive transducer, easy to install, 90° BNC connector for special
installations to camera, fixing screws for CAT5 cable connection. Maximum
distance for colour video 330 m. PAL/NTSC/SECAM/CCIR modes.
Transducer with 90° connector. Frequency response: 8 MHz DC 60 dB. Transmission over CAT5
twisted pair cable. Immune to background noise. Attenuation 0.5 dB. BNC connector and xing
screws for twisted pair cable. BNC impedance 75 Ohm. Terminated at 100 Ohm. Operating
temperature -10 °C ~ +70 °C. Storage temperature -30 °C ~ +70 °C. Operating humidity
0~95%. Dimensions: (W) 10 x (H) 10 x (D) 26 mm body only. Weight 46 g. Material: ABS plastic.
TYPE 52TP/2 € 5.77
Compact passive transducer, easy to install, BNC connector with 14 cm coaxial
cable for special installations to camera, fixing screws for CAT5 cable connection.
Maximum distance for colour video 330 m. PAL/NTSC/SECAM/CCIR modes.
Transducer with BNC connector with 14 cm coaxial cable. Frequency response: 8 MHz DC
60 dB. Transmission over CAT5 twisted pair cable. Immune to background noise. Attenuation
0.5 dB. BNC connector and xing screws for twisted pair cable. BNC impedance 75 Ohm.
Terminated at 100 Ohm. Operating temperature -10 °C ~ +70 °C. Storage temperature -30 °C ~
+70 °C. Operating humidity 0~95%. Dimensions: (W) 10 x (H) 10 x (D) 25 mm body only. Weight
46 g. Material: ABS plastic.
TYPE 52TP/3 € 14.96
Pair of compact passive transducers, easy-to-install transmitter / receiver,
BNC connector and connector for camera power supply, RJ45 for CAT5 cable
connection. Female / male DC jack for 12 VDC supply voltage. Allows video and
power to be transmitted up to 50 m through CAT5 cable. PAL/NTSC/SECAM/
CCIR modes.
Transmitter / receiver with option of transmitting video and power through the same CAT5 twisted
pair cable. Frequency response: 8 MHz DC 60 dB. Immune to background noise. Attenuation
0.5 dB. BNC connector and RJ45 for twisted pair cable. BNC impedance 75 Ohm. Terminated
at 100 Ohm. Operating temperature -10 °C~ +70 °C. Storage temperature -30 °C ~ +70 °C.
Operating humidity 0~95%. Dimensions: (W) 21 x (H) 42 x (D) 21 mm body only. Material: ABS
plastic.
Day & Night colour cameras
BEST OVERVIEW
99
PRICE LIST no.E1
Passive transducers
TYPE 52TP/4 € 22.45
Passive transducer for rack or wall mounting, 4 BNC connectors with 14 cm
coaxial cable for input / output of 4 video signals. RJ45 for CAT5 cable connection.
Maximum distance for colour video 330 m, using passive transducers. Using
active receivers type 52RA - 52RA/4 – 52RA/8 – 52RA/16 the distance increases
to 1500 m. PAL/NTSC/SECAM/CCIR modes.
Transducer with 4 BNC connectors with 14 cm coaxial cable, for transmission/reception of
4 video signals in a single CAT5 twisted pair cable. Frequency response: 8 MHz DC 60 dB.
Immune to background noise. Attenuation 0.5 dB. BNC connectors and RJ45 for twisted pair
cable. BNC impedance 75 Ohm. Terminated at 100 Ohm. Operating temperature -10 °C ~
+70 °C. Storage temperature -30 °C~ +70 °C. Operating humidity 0~95%. Dimensions: (W) 75
x (H) 25 x (D) 50 mm. Material: ABS plastic.
TYPE 52TP/4A € 24.48
Passive transducer, 4 BNC connectors for 1 video input signal, 4 video output
signals. RJ45 and terminal block for CAT5 cable connection. Maximum distance
for colour 330 m, using passive transducers. Using active receivers type 52RA
- 52RA/4 – 52RA/8 – 52RA/16 the distance increases to 1500 m. PAL/NTSC/
SECAM/CCIR modes.
Transducer with 4 BNC connectors, for transmission/reception of 4 video signals in a single
CAT5 twisted pair cable. Frequency response: 8 MHz DC 60 dB. Immune to background noise.
Attenuation 0.5 dB. BNC connectors and RJ45 and terminal block for twisted pair cable. BNC
impedance 75 Ohm. Terminated at 100 Ohm. Operating temperature -10 °C~ +70 °C. Storage
temperature -30 °C~ +70 °C. Operating humidity 0~95%. Dimensions: (W) 105 x (H) 25 x (D)
58 mm. Material: aluminium.
TYPE 52TP/16 € 113.50
Passive transducer for rack installation, 16 BNC connectors for video input.
4 RJ45 and 4 terminal blocks for CAT5 cable connection. Maximum distance
for colour 330 m, using passive transducers. Using active receivers type 52RA
- 52RA/4 - 52RA/8 – 52RA/16 the distance increases to 1500 m. PAL/NTSC/
SECAM/CCIR modes.
Transducer with 16 BNC connectors, for transmission/reception of 16 video signals divided into
4 RJ45 connectors or 4 terminal blocks using CAT5 twisted pair cable. Frequency response:
8 MHz DC 60 dB. Immune to background noise. Attenuation 0.5 dB. BNC connectors and RJ45
for twisted pair cable. BNC impedance 75 Ohm. Terminated at 100 Ohm. Operating temperature
-10 °C~ +70 °C. Storage temperature -30 °C~ +70 °C. Operating humidity 0~95%. Dimensions:
(W) 430 x (H) 44 x (D) 169 mm. Material: metal Colour: black.
TYPE 52TP/32 € 153.10
Passive transducer for rack installation, 32 BNC connectors for video input.
8 RJ45 for CAT5 cable connection. Maximum distance for colour 330 m, using
passive transducers. Using active receivers type 52RA - 52RA/4 - 52RA/8 –
52RA/16 the distance increases to 1500 m. PAL/NTSC/SECAM/CCIR modes.
Transducer with 32 BNC connectors, for transmission/reception of 32 video signals divided
into 9 RJ45 connectors using CAT5 twisted pair cable. Frequency response: 8 MHz DC 60 dB.
Immune to background noise. Attenuation 0.5 dB. BNC connectors and RJ45 for twisted pair
cable. BNC impedance 75 Ohm. Terminated at 100 Ohm. Operating temperature -10 °C ~
+70 °C. Storage temperature -30 °C~ +70 °C. Operating humidity 0~95%. Dimensions: (W) 430
x (H) 44 x (D) 169 mm.Material: metal Colour: black.
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
100
Active transducers
TYPE 52TA € 22.45
Active transmitter for rack or wall mounting. Terminal block connector with
5 terminals, 2 for CAT5 cable connection, 2 for 12 VDC power supply, 1 for ground.
1 BNC for coaxial video input. Maximum distance for colour video combined with
active receiver type 52RA is 2400 m. PAL/NTSC/SECAM/CCIR modes.
Active transmitter for rack or wall mounting. Screw connector for connection of CAT5 twisted
pair cable, power supply and ground. BNC for video input. Frequency response: 8 MHz DC
60 dB. Immune to background noise. Attenuation 0.5 dB. BNC impedance 75 Ohm. Terminated
at 100 Ohm. Supply voltage: 12 VDC. LED power and video indicator. 3 amplication levels.
Combined with active receiver type 52RA it is possible to reach a maximum distance of 2400 m
for colour video. Up to 16 transmitters can be installed in rack panel type 52TA/Rack.Operating
temperature -10°~ +70°. Storage temperature -30°~ +70. Operating humidity 0~95%.
Dimensions: (W) 75 x (H) 25 x (D) 50 mm. Material: ABS plastic.
TYPE 52RA € 22.45
Active receiver for rack or wall mounting. Terminal block connector with
5 terminals, 2 for CAT5 cable connection, 2 for 12 VDC power supply, 1 for ground.
1 BNC for coaxial video output. Maximum distance for colour video combined
with active receiver type 52TA is 2400 m. PAL/NTSC/SECAM/CCIR modes.
Active receiver for rack or wall mounting. Screw connector for connection of CAT5 twisted pair
cable, power supply and ground. BNC for video input. Frequency response: 8 MHz DC 60 dB.
Immune to background noise. Attenuation 0.5 dB. BNC impedance 75 Ohm. Terminated at
100 Ohm. Supply voltage 12 VDC, power supply unit purchased separately*. LED power-on
and video indicator. 4 micro switches for control of up to 16 amplication levels, and brightness
control trimmers for medium and long distances. Combined with the range of passive
transducers type 52TP, 52TP/1, 52TP/2, 52TP/4, it is possible to reach a maximum distance
of 1500 m. Combined with active transmitter type 52TA it is possible to reach a maximum
distance of 2400 m for colour video. Up to 16 receivers can be installed in rack panel type 52TA/
Rack.Operating temperature -10°~ +70°. Storage temperature -30°~ +70. Operating humidity
0~95%. Dimensions: (W) 75 x (H) 25 x (D) 50 mm. Material: ABS plastic.
TYPE 52TA/4 € 76.00
Active transmitter for wall mounting to transmit 4 video signals. RJ45 connector for
CAT5 cable connection, terminal block for 12 VDC power supply and for ground.
4 BNC for coaxial video input. Maximum distance for colour video combined with
active receiver type 52RA- 52RA/4 is 2400 m. PAL/NTSC/SECAM/CCIR modes.
Active transmitter for wall mounting. RJ45 connector for connection of CAT5 twisted pair cable,
power supply and ground. 4 BNC for video input. Frequency response: 8 MHz DC 60 dB.
Immune to background noise. Attenuation 0.5 dB. BNC impedance 75 Ohm. Terminated at
100 Ohm. Supply voltage 12 VDC, power supply unit purchased separately*. LED power-on
and video indicator. 4 slide micro switches for control of 3 amplication levels. Combined with
active receiver type 52RA it is possible to reach a maximum distance of 2400 m for colour video.
Operating temperature -10 °C ~ +70 °C. Storage temperature -30 °C ~ +70 °C. Operating
humidity 0~95%. Dimensions: (W) 204 x (H) 49 x (D) 103 mm. Material: aluminium.
* The full range of 12 VDC active transducers, transmitters and receivers without power supply
unit can be used with power supply unit type 5AA0 - 12 VDC / 600 mA.
Day & Night colour cameras
BEST OVERVIEW
101
PRICE LIST no.E1
Active transducers
TYPE 52RA/4 € 76.00
Active transmitter for wall mounting to receive 4 video signals. RJ45 connector for
CAT5 cable connection, terminal block for 12 VDC power supply and for ground.
4 BNC for coaxial video output. Maximum distance for colour video combined
with passive transducers is 1500 m, whereas combined with active transmitters
type 52TA it is 2400 m. PAL/NTSC/SECAM/CCIR modes.
Active receiver for wall mounting. RJ45 connector for connection of CAT5 twisted pair cable,
power supply and ground. 4 BNC for video output. Frequency response: 8 MHz DC 60 dB.
Immune to background noise. Attenuation 0.5 dB. BNC impedance 75 Ohm. Terminated at
100 Ohm. Supply voltage 12 VDC, power supply unit purchased separately*. LED power-on and
video indicator. 4 micro switches for control of up to 16 amplication levels, 4 brightness control
trimmers for medium and long distances. Combined with the range of passive transducers
type 52TP, 52TP/1, 52TP/2, 52TP/4, it is possible to reach a maximum distance of 1500 m.
Combined with active transmitter type 52TA it is possible to reach a maximum distance of
2400 m for colour video. Operating temperature -10 °C~ +70 °C. Storage temperature -30 °C ~
+70 °C. Operating humidity 0~95%.
Dimensions: (W) 204 x (H) 49 x (D) 103 mm. Material: aluminium.
TYPE 52TA/DT € 44.57
Transmitter for wall mounting. Transmits video, receives/transmits RS485 data
and power. Linked to receiver type 52RA/DT. Terminal block connector with
3 terminals, 2 for data, 1 for ground. RJ45 for CAT5 cable. 1 BNC for coaxial
video input. Maximum distance for colour video combined with active receiver
type 52RA/DT is 1500 m. PAL/NTSC/SECAM/CCIR modes.
Transmitter for wall mounting. RJ45 connector for connection of CAT5 twisted pair cable,
terminal block with 3 terminals for data and ground. BNC for video input. Lead for camera
power supply output, for this function read the detailed instructions. Frequency response:
8 MHz DC 60 dB. Immune to background noise. Attenuation 0.5 dB. BNC impedance 75 Ohm.
Terminated at 100 Ohm. Combined with active receiver type 52RA/DT it is possible to reach a
maximum distance of 1500 m for colour video. Operating temperature -10 °C~ +70 °C. Storage
temperature -30 °C~ +70 °C. Operating humidity 0~95%.
Dimensions: (W) 105 x (H) 29 x (D) 58 mm. Material: aluminium.
TYPE 52RA/DT € 44.57
Active receiver for wall mounting. Receives video signal, receives/transmits
RS485 data and transmits power. Linked to transmitter type 52TA/DT. Terminal
block connector with 3 terminals, 2 for data, 1 for ground. RJ45 for CAT5 cable.
1 BNC for coaxial video output. Maximum distance for colour video combined
with transmitter type 52TA/DT is 1500 m. PAL/NTSC/SECAM/CCIR modes.
Receiver for wall mounting. RJ45 connector for connection of CAT5 twisted pair cable, terminal
block with 3 terminals for data and ground. BNC for video input. Connector for 12 or 36 VDC
supply voltage, power supply unit purchased separately*. For this function read the detailed
instructions. 4 micro switches for control of up to 16 amplication levels, and brightness control
trimmers, for medium and long distances. LED power-on and video indicator. Frequency
response: 8 MHz DC 60 dB. Immune to background noise. Attenuation 0.5 dB. BNC impedance
75 Ohm. Terminated at 100 Ohm. Combined with transmitter type 52TA/DT it is possible to
reach a maximum distance of 1500 m for colour video. Operating temperature -10 °C ~ +70 °C.
Storage temperature -30 °C ~ +70 °C. Operating humidity 0~95%. Dimensions: (W) 105 x (H)
29 x (D) 58 mm. Material: aluminium.
* The full range of 12 VDC active transducers, transmitters and receivers without power supply
unit can be used with power supply unit type 5AA0 - 12 VDC / 600 mA.
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
102
CCTV accessories
TYPE 52RA/8 € 153.10
Active transmitter for wall mounting to receive 8 video signals. 2 RJ45 connectors
for CAT5 cable connection. Supply voltage 90 to 260 VAC. 8 + 8 BNC loop
through for coaxial video output. Maximum distance for colour video combined
with passive transducers is 1500 m, whereas combined with active transmitters
type 52TA – 52TA/4 it is 2400 m. PAL/NTSC/SECAM/CCIR modes.
Active receiver for reception of up to 8 video signals. 2 RJ45 connectors for CAT5 twisted pair
cable connection. 8+8 BNC loop-through for video output. Frequency response: 8 MHz DC
60 dB. Immune to background noise. Attenuation 0.5 dB. BNC impedance 75 Ohm. Terminated
at 100 Ohm. Supply voltage 90 to 240 VAC. LED power-on and video indicator. 8 micro
switches for control of up to 16 amplication levels, 8 brightness control trimmers for medium
and long distances. Combined with the range of passive transducers type 52TP, 52TP/1,
52TP/2, 52TP/4, it is possible to reach a maximum distance of 1500 m. Combined with active
transmitter type 52TA, 52TA/4 it is possible to reach a maximum distance of 2400 m for colour
video. Operating temperature -10 °C~ +70 °C. Storage temperature -30 °C ~ +70 °C. Operating
humidity 0~95%. Dimensions: (W) 430 x (H) 44 x (D) 169 mm, not including BNC connectors.
Material: metal Colour: black.
TYPE 52RA/16 € 256.00
Active transmitter for wall mounting to receive 16 video signals. 4 RJ45 connectors
for CAT5 cable connection. Supply voltage 90 to 260 VAC. 16 + 16 BNC loop
through for coaxial video output. Maximum distance for colour video combined
with passive transducers is 1500 m, whereas combined with active transmitters
type 52TA – 52TA/4 it is 2400 m. PAL/NTSC/SECAM/CCIR modes.
Active receiver for reception of up to 16 video signals. 4 RJ45 connectors for CAT5 twisted pair
cable connection. 8+8 BNC loop-through for video output. Frequency response: 8 MHz DC
60 dB. Immune to background noise. Attenuation 0.5 dB. BNC impedance 75 Ohm. Terminated
at 100 Ohm. Supply voltage 90 to 240 VAC*. LED power-on and video indicator. 16 micro
switches for control of up to 16 amplication levels, 16 brightness control trimmers for medium
and long distances. Combined with the range of passive transducers type 52TP, 52TP/1,
52TP/2, 52TP/4, it is possible to reach a maximum distance of 1500 m. Combined with active
transmitter type 52TA, 52TA/4 it is possible to reach a maximum distance of 2400 m for colour
video. Operating temperature -10 °C ~ +70 °C. Storage temperature -30 °C ~ +70 °C. Operating
humidity 0~95%. Dimensions: (W) 430 x (H) 44 x (D) 169 mm, not including BNC connectors.
Material: metal Colour: black.
TYPE 52TA/Rack € 17.34
1-module rack panel for insertion of active transducers type 52TA – 52RA –
passive transducers type 52TP/4.
Day & Night colour cameras
BEST OVERVIEW
103
PRICE LIST no.E1
CCTV accessories
RS485 video isolators and repeaters
TYPE 52GL € 39.47
Video ground loop isolator, eliminates annoying ground loop interference when
two points connected from the coax are at different ground potentials.
Male and female BNC connector with 15 cm lead on each side. No power input required. Ultra
low loss 0.5 dB. Input/output resistance 75 Ohm. Frequency response 0 - 3 dB at 10 MHz.
Isolation voltage 600 VDC. Isolation resistance 100 Ohm. Dimensions: (W) 84 x (H) 21 x (D)
28 mm. Two 250 mm leads with BNC connectors. Material ABS, colour black.
TYPE 52GB € 46.27
Video ground loop isolator, eliminates annoying ground loop interference when
two points connected from the coax are at different ground potentials. Balun
coaxial cable specifically for DVR.
This lter is ideal for eliminating interference on DVRs. TYPE: unbalanced synchronisation due to
weak signals, or due to different impedances between two transmission points. Male and female
BNC connector with 15 cm lead on each side. No power input required. Ultra low loss 0.5 dB.
Input/output resistance 75 Ohm. Frequency response from 0 to 3 dB at 10 MHz. Isolation
voltage 600 VDC. Isolation resistance 100 Ohm. Dimensions: (W) 84 x (H) 21 x (D) 28 mm. Two
250 mm leads with BNC connectors. Material ABS, colour black.
TYPE 52RS € 120.90
RS485 digital data repeater. Doubles communication distance up to 1200 m.
Uses screw terminal blocks, 12 VDC supply voltage. Includes power supply unit.
Auto baud rate selection up to 115.2 Kbps. Isolation protection up to 2.5 kV.
Surge protection.
Digital signal repeater with input/output terminal block. Jack connector for 12 VDC supply
voltage, LED power indicator. RS485 terminated at input. Supply voltage 12 VDC +10~20V
350 mA. Includes power supply unit 12 VDC 500 mA. Operating temperature from 0° to 55 °C.
Storage temperature from – 20 °C to 85 °C. Humidity 95%. Dimensions: (W) 88 x (H) 27.5 x (D)
67 mm. Weight 120 g. Material: Metal Colour: black.
Video converter
TYPE 52CV € 108.50
Analogue to digital video converter. BNC – VGA/SVGA/XGA/SXGA.
Analogue to digital video converter. Video format PAL/NTSC auto switch. VGA resolution
800x600/1024x768/1280x1024 selectable (VGASVGA- XGA-SXGA). Frequency VGA
50/60/70/75 Hz. BNC video input. VGA output 15-pin D-Subx1. Supply voltage 12 VDC /
300 mA same as the monitor, power cord supplied. Dimensions: (W) 75 x (H) 25 x (D) 100 mm.
Weight 300 g.
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
104
CCTV accessories
RS485 distributors
TYPE 52DS/4 € 213.30
RS485 distributor can transmit up to 1200 m over CAT5 twisted pair cable.
Protection against electrostatic discharge. Isolated inputs and outputs. Possibility
of cascade connection with other distributors. Can simultaneously control up to
4 speed dome devices with different IDs.
Distributor for 4 terminated RS485 outputs. 3 inputs of which 2 / RS485 – 1/ RS232. The
three inputs can be in standby at the same time. One keypad can be inserted at a time. Supply
voltage 12 VDC input current 350 mA. Includes power supply unit 12 VDC 500 mA*. Operating
temperature 0° to +45°. Dimensions: (W) 133 x (H) 44 x (D) 76 mm. Weight 425 g. Material:
Metal Colour: black.
TYPE 52DS/8 € 309.00
RS485 distributor can transmit up to 1200 m over CAT5 twisted pair cable.
Protection against electrostatic discharge. Isolated inputs and outputs. Possibility
of cascade connection with other distributors. Can simultaneously control up to
8 speed dome devices with different IDs.
Distributor for 8 terminated RS485 outputs. 3 inputs of which 2 / RS485 – 1/ RS232. The
three inputs can be in standby at the same time. One keypad can be inserted at a time. Supply
voltage 12 VDC input current 350 mA. Includes power supply unit 12 VDC 500 mA*. Operating
temperature 0° to +45°. Dimensions: (W) 482 x (H) 44 x (D) 100 mm. (1 rack unit). Weight
1050 g. Material: Metal Colour: black.
TYPE 52DS/16 € 380.00
RS485 distributor can transmit up to 1200 m over CAT5 twisted pair cable.
Protection against electrostatic discharge. Isolated inputs and outputs. Possibility
of cascade connection with other distributors. Can simultaneously control up to
16 speed dome devices with different IDs.
Distributor for 16 terminated RS485 outputs. 3 inputs of which 2 / RS485 – 1/ RS232. The
three inputs can be in standby at the same time. One keypad can be inserted at a time. Supply
voltage 12 VDC input current 350 mA. Includes power supply unit 12 VDC 500 mA*. Operating
temperature 0° to +45°. Dimensions: (W) 482 x (H) 44 x (D) 100 mm. (1 rack unit). Weight
1100 g. Material: Metal Colour: black.
Day & Night colour cameras
BEST OVERVIEW
105
PRICE LIST no.E1
CCTV accessories
TYPE 5288/023 € 2.33
Straight BNC solder connector.
Straight BNC male solder connector for coaxial cables RG59, RG179 and cable type 0002/060.
TYPE 5288/024 € 2.33
90° BNC solder connector.
90° BNC male solder connector for coaxial cables RG59, RG179 and cable type 0002/060.
TYPE 5288/BNC € 2.23
Male BNC crimp connector for RG59 coaxial cables.
BNC male crimp connector for coaxial cables RG59, RG179 and cable type 0002/060.
TYPE 5288/VIT € 4.40
Male BNC connector for RG59 cables with easy screw-on installation.
BNC male screw connector for coaxial cables RG59, RG179 and cable type 0002/060.
TYPE 5288/A27 € 2.80
Plug for 12 VDC power supply with screw terminals
Connector for 12 VDC supply voltage.
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
106
CCTV accessories
TYPE 0002/060 € 90.90
75 Ohm shielded cable in 200 metre roll.
Video cable in PVC NPI CEI 20-22 II CEI 20-35 CEI 20-37 I, with 75 Ohm coaxial cable in 200 m
roll, cable diameter 3 mm2.
TYPE 0002/063 € 156.60
Cable with two 0.35 mm2 conductors and one 75 Ohm shielded wire in 200 metre
roll.
Cable in PVC NPI 12-48V CEI 20-200 II. CEI 20-35. CEI 20-37 I with 75 Ohm shielded wire and
two 0.35 mm2 conductors, in 200 metre roll.
TYPE 0002/163 € 194.20
Cable with two 0.70 sq. mm conductors and one 75 Ohm shielded wire in
200 metre roll.
Cable in PVC NPI 12-48V CEI 20-200 II. CEI 20-35. CEI 20-37 I with 75 Ohm shielded wire and
two 0.75 mm2 conductors, in 200 metre roll.
TYPE 522C/3 € 36.87
Cable with connectors for connecting CCTV kit type 5226/1.
20m cable for connecting camera with connectors.
TYPE 5297/12 € 17.74
Kit complete with thermostatically-controlled heater for waterproof housing
type 529P supply voltage 12 VDC - 24 VAC, 10 W
TYPE RT01 € 6.08
Adhesive “Area Under Surveillance” sticker in white PVC, dimensions
230x130 mm.
TYPE RT03 € 8.11
“Area Under Surveillance” sign in polypropylene (PPB), dimensions 230x130 mm
Day & Night colour cameras
BEST OVERVIEW
107
PRICE LIST no.E1
CCTV accessories
TYPE 5280 € 121.60
Automatic/manual sequential switcher for B/W and colour video signal with
8 video inputs and 8 alarm inputs, selectable buzzer alarm.
Sequential switcher with video input 1Vpp / 75 Ohm 8 camera inputs. Video output: alarm /
automatic – 1Vpp / 75 Ohm Video gain From attenuation to amplier: from 0.8Vpp to 1.4 Vpp.
Video bandwidth 20 MHz + 3 dB to – 3 dB. Crosstalk Better than 48 dB. Channel switch Bypass
/ Auto / Home. Interval Approx. 1 to 15 seconds. Video connector BNC.. video input. max 2.
Vpp. 8 alarm, one alarm output COM / NC / NO. Alarm hold time approx. 3 ~ 50 seconds. Alarm
time setting Trimmer on rear panel: short / long. Alarm setting switch. Buzzer OFF side: alarm.
buzzer off. ON side: alarm on. ON side (= no alarm). Alarm priority operation CHANNEL alarm
takes precedence even over BYPASS or AUTO or HOME setting. Red LED power indicator light.
Operating temperature - 5 °C ~ + 60 °C. power consumption 3 W. Supply voltage 110 VAC /
60 Hz 230 VAC / 50 Hz Material: steel. Grey enamel nish. Dimensions 218 mm (W) x 44 mm
(A) x 97 mm (D). Weight 830 g.
TYPE 52F1 € 20.27
Microphone for audio applications, compatible with the entire camera range.
Connectors: JACK power IN 12 VDC RCA audio signal. Input voltage 12 VDC ±10% Can be
powered using power supply unit type 5AA0.
TYPE 52F2 € 24.32
Microphone for audio applications, compatible with the full range of cameras
operating off 12 VDC supply.
Connectors: JACK power IN 12 VDC. JACK power OUT 12 VDC power supply to camera. RCA
audio signal. BNC video signal. Supply voltage 12 VDC ±10%, power supply to camera also
provides power for microphone.
TYPE 522V € 497.00
5.6" colour TFT/LCD monitor. For use as video tester. 2 video inputs, 2 audio
inputs, faux leather case. Rechargeable battery pack supplied.
Colour video tester with 5.6" screen and 230 VAC 2/13 VDC backup battery. Equipped with:
2 video and audio inputs, image mirror function, OSD function for display of adjustments.
Includes power supply unit 12 VDC 1 A.
Dimensions: (W) 160 x (H) 133 x (D) 37 mm.
TYPE 522P € 274.00
2.36" colour TFT/LCD monitor. For use as video tester. 2 BNC connectors for
video input and output. Supplied with two Velcro wrist straps and a shoulder
strap. Faux leather case with sun hood, 6 AA batteries supplied. Lead for
connection to external power supply unit (not supplied) 7~12 VDC 140 mA.
2.36" TFT/LCD screen with touch panel. Resolution 480x234. Display area 48.0 (H) X 35.685
(V). Dot pitch 0.1 (H) x 0.1525 (V). Colour conguration RGB Delta. LED backlighting. Input
signal PAL/NTSC with automatic switching, composite video 1.0Vpp 75 Ohm, negative. BNC
input and output connectors, auto termination. Angle of view 10/50/40/40. Luminance (cd/m²)
250. Contrast ratio 200:1. Response time 15Tr / 35Tf ms. Controls. Brightness, colour, ON/
OFF switch. Supply voltage 9 ~12 VDC power consumption 140 mA at 12 VDC – 1.7 W**.
Dimensions: (W) 133 x (H) 71 x (D) 37 mm. Operating temperature 0° to 60°. Operating humidity
85%. Storage temperature -20 °C~+50 °C. Storage humidity 85%. Weight 395 g. Power
supply unit purchased separately.
** Power supply unit not included, can be used with power supply unit type 5AA6 - 12 VDC / 1.25 A.
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
108
TYPE 0002/025
Lens with 25 mm focal length, 1.4 F aperture, C mount and manual iris
€ 128.60 *
TYPE 0002/060
75 Ohm shielded cable in 200 metre roll
€ 90.90 106
TYPE 0002/060.500
75 Ohm shielded cable in 500 metre roll
€ 227.10 *
TYPE 0002/063
Cable with two 0.35 mm2 conductors and one 75 Ohm shielded wire in 200 metre roll
€ 156.60 106
TYPE 0002/163
Cable with two 0.70 mm2 conductors and one 75 Ohm shielded wire in 200 metre roll
€ 194.20 106
TYPE 0002/163,500
Cable with two 0.70 mm2 conductors and one 75 Ohm shielded wire in 500 metre roll
€ 486.00 *
TYPE 0002/308
3.5 - 8 mm VARI-FOCAL lens with 1.8 F aperture, CS mount and manual iris
€ 126.60 72
TYPE 0002/5M5
5 - 15 mm VARI-FOCAL lens with 1.8 F aperture, CS mount and manual iris
€ 61.00 72
TYPE 0002/612
3.5 - 8 mm VARI-FOCAL lens with 1.4 F aperture, C mount and manual iris
€ 174.90 72
TYPE 0002/I06
Lens with 6 mm focal length, 1.2 F aperture, C mount and manual iris
€ 79.70 *
TYPE 0002/I16
Lens with 16 mm focal length, 1.4 F aperture, C mount and manual iris
€ 82.30 *
TYPE 0002/S03
Lens with 3 mm focal length, 1.3 F aperture, CS mount and manual iris
€ 112.20 *
TYPE 0002/S04
Lens with 4 mm focal length, 1.3 F aperture, CS mount and manual iris
€ 94.90 *
TYPE 0002/S08
Lens with 8 mm focal length, 1.4 F aperture, CS mount and manual iris
€ 60.940 *
TYPE 0022/003
Lens with 3 mm focal length, 1.4 F aperture, C mount and auto-iris
€ 154.30 *
TYPE 0022/005
Lens with 5.6 mm focal length, 1.3 F aperture, C mount and auto-iris
€ 411.00 *
TYPE 0022/006
Lens with 6 mm focal length, 1.3 F aperture, C mount and auto-iris
€ 204.70 *
TYPE 0022/012
Lens with 12.5 mm focal length, 1.3 F aperture, C mount and auto-iris
€ 204.70 *
TYPE 0022/016
Lens with 16 mm focal length, 1.3 F aperture, C mount and auto-iris
€ 204.70 *
TYPE 0022/025
Lens with 25 mm focal length, 1.3 F aperture, C mount and auto-iris
€ 204.70 *
TYPE 0022/050
Lens with 50 mm focal length, 1.3 F aperture, C mount and auto-iris
€ 246.90 *
TYPE 0022/308
3 - 8 mm VARI-ZOOM lens with 1.4 F aperture, CS mount and auto-iris
€ 204.70 72
TYPE 0022/612
6-12 mm VARI-ZOOM lens with 1.4 F aperture, C mount and auto-iris
€ 204.70 72
TYPE 0022/C00
Control panel for 22/Z00
€ 204.70 *
TYPE 0022/S04
Lens with 4 mm focal length, 1.4 F aperture, CS mount and auto-iris
€ 158.70 *
TYPE 0022/S08
Lens with 8 mm focal length, 1.3 F aperture, CS mount and auto-iris
€ 158.70 *
TYPE 0023/308
Varifocal, unamplied manual zoom lens with auto-iris
€ 88.50 73
TYPE 0023/515
5 - 15 mm varifocal lens with auto-iris
€ 77.00 73
TYPE 0023/550
Varifocal, unamplied manual zoom lens with auto-iris
€ 216.60 73
TYPE 0024/212
Varifocal unamplied manual zoom DC Drive lens with auto-iris
€ 52.00 73
TYPE 0024/660
Varifocal unamplied manual zoom DC Drive lens with auto-iris
€ 61.00 73
TYPE 0832/024
Transformer 24V 30 W
€ 26.12 76
TYPE 170/051
Video signal switching relay
€ 38.76 *
TYPE 170T
Timed relay
€ 42.00 *
TYPE 50A0
B/W mini-camera with 3.6 mm waterproof lens complete with bracket
€ 186.80 63
TYPE 50A2
Day & Night indoor colour video camera. Compact dimensions. Supply voltage 12 VDC. Medium resolution. 1/4" CCD sensor
€ 75.80 60
TYPE 50A3
Mini colour video camera with aluminium mini bracket. 1/4" CCD sensor. 3.7 mm pinhole lens
€ 153.10 60
TYPE 50A4
Flush-mounted mini colour video camera in aluminium. 1/4" CCD sensor. 3.7 mm pinhole lens
€ 153.10 60
TYPE 51D3/10
Indoor speed dome IP camera
€ 2187.00 38
TYPE 51D3/E36
Outdoor speed dome IP camera
€ 3897.00 36
TYPE 51D3/EIP
Indoor/outdoor speed dome IP camera
€ 4053.00 37
TYPE 5208
Colour desktop monitor with 8" screen with one VGA input
€ 320.00 78
TYPE 5210
Desktop monitor with 10.2" high-resolution LCD TFT screen, 16:9 aspect ratio. OSD control. Video inputs: 2 AV, 1 VGA-SVGA, 1 S-Video.
€ 426.00 78
TYPE 5212/C56
Colour desktop monitor with 5.6" TFT LCD screen with 2 video inputs and 1 audio input, includes 12 VDC power supply unit.
€ 401.00 78
TYPE 5217/1
17" active matrix LCD colour monitor. 12 Volt supply voltage with power supply unit included. Adjustable colour temperature. 2D comb lter.
€ 691.00 78
TYPE 5217/H
17" active matrix LCD high-resolution colour monitor, 12 volt supply voltage with power supply unit included.
€ 850.00 79
TYPE 5217/SB
Professional 17” LCD TFT desktop monitor OSD control. Video inputs: 1 VGA/SVGA/XGA/SXGA, 1 DVI.
€ 251.00 79
TYPE 5219/1
19” active matrix LCD colour monitor. 12 Volt supply voltage with power supply unit included.
€ 578.00 79
TYPE 5219/VGA
Professional 19" LCD TFT desktop monitor OSD control. Video inputs: 1 VGA/SVGA/XGA/SXGA, 1 DVI.
€ 548.00 79
TYPE 522P
2.36" TFT/LCD monitor for use as video tester 2 BNC connectors for video input and output
€ 274.00 107
TYPE 522T/3
B/W camera for CCTV kit type 5226/1, wide-angle lens and waterproof housing
€ 143.20 63
TYPE 522V
LCD colour monitor (video tester).
€ 497.00 107
TYPE 523H/404
Digital video recorder with 4 inputs. Without HDD. Up to 1 x 1 TB HDD can be installed.
€ 212.00 89
TYPE 524B
Control panel for types 528B and 528D
€ 323.00 *
TYPE 524H/263
Digital video recorder with 16 inputs. 160 GB HDD.
€ 1.924,00 *
TYPE 524H/404
Digital video recorder with 4 inputs. Professional 250GB HDD, dedicated line to DVRs. Up to 1 x 1 TB HDD can be installed.
€ 334.00 89
TYPE 524H/524
Digital video recorder with 4 inputs and 1 audio. Professional 320GB HDD, dedicated line to DVRs
€ 495.00 88
TYPE 524H/526
Digital video recorder with 16 inputs and 1 audio. Professional 320GB HDD, dedicated line to DVRs
€ 852.00 90
TYPE 524H/528
Digital video recorder with 8 inputs and 1 audio. Professional 320GB HDD, dedicated line to DVRs
€ 614.00 89
TYPE 524H/58D
Digital video recorder with 8 inputs and 1 audio. Professional 320GB HDD, dedicated line to DVRs
€ 730.00 89
TYPE 524H/615
Digital video recorder with 4 inputs and 15" TFT LCD monitor. Seagate 250GB HDD dedicated line to DVRs.
€ 1,262.00 91
TYPE 524H/626
Digital video recorder with 16 inputs and 1 audio. Professional 250GB HDD, dedicated line to DVRs
€ 1,342.00 92
TYPE 524H/816
Digital video recorder with 16 video inputs and 16 audio inputs. CD/DVR/RW burner. 250GB HDD.
€ 2,075.95 94
TYPE 524H/878
Digital video recorder with 8 video inputs and 8 audio inputs. CD/DVR/RW burner. Seagate 250GB HDD dedicated line to DVRs.
€ 1,945.00 93
* CCTV items included in Elvox Price List no.E1
Alphanumeric index
Day & Night colour cameras
BEST OVERVIEW
109
PRICE LIST no.E1
TYPE 5250
50 W infrared spotlight with illumination angle of 10°.
€ 279.00 74
TYPE 5250/L
Infrared LED spotlight with built-in twilight sensor.
€ 233.10 74
TYPE 5251
50 W infrared spotlight with illumination angle of 30°.
€ 288.00 74
TYPE 5251/L
Infrared LED spotlight with built-in twilight sensor.
€ 233.00 74
TYPE 5253/4
Digital video recorder with 4 IP video inputs. 500 GB HDD.
€ 1,715.00 16
TYPE 5254/4
Digital video recorder with 4 IP video inputs. 500 GB HDD
€ 3,052.00 20
TYPE 5254/A4
Digital video recorder with 4 analogue video inputs. 500 GB HDD
€ 3,892.00 20
TYPE 5254/A8
Digital video recorder with 8 analogue video inputs. 500 GB HDD
€ 5,292.00 20
TYPE 5255/4
Digital video recorder with 4 IP video inputs. 500 GB HDD.
€ 4,396.00 26
TYPE 5255/I4
Digital video recorder with 4 analogue and IP video inputs. 500 GB HDD
€ 5,607.00 26
TYPE 5255/I8
Digital video recorder with 8 analogue and IP video inputs. 500 GB HDD
€ 7,070.00 26
TYPE 525A
Mini-matrix with 8 inputs
€ 663.00 *
TYPE 525B
Mini-matrix with 16 inputs
€ 1,165.00 *
TYPE 525C
Panel with 12 keys
€ 345.00 *
TYPE 525D
Panel with 23 keys
€ 382.00 *
TYPE 525G/1VA
Digital video recorder for licence plate recognition for 1 access point
€ 14,336.00
30
TYPE 525G/1VP
Digital video recorder for reading vehicle licence plates for 1 access point
€ 6,552.00 30
TYPE 525G/2VA
Digital video recorder for licence plate recognition for 2 access points
€ 16,016.00
30
TYPE 525G/2VP
Digital video recorder for reading vehicle licence plates for 2 access point
€ 8,509.00 30
TYPE 525G/3VA
Digital video recorder for licence plate recognition for 3 access points
€ 17,416.00
30
TYPE 525G/3VP
Digital video recorder for reading vehicle licence plates for 3 access points
€ 12,432.00
30
TYPE 525G/4VA
Digital video recorder for licence plate recognition for 4 access points
€ 17,976.00
30
TYPE 525G/4VP
Digital video recorder for reading vehicle licence plates for 4 access points
€ 13,552.00
30
TYPE 525H/404
Digital video recorder with 4 video inputs, 500GB HDD
€ 381.00
*
TYPE 525H/524
Digital video recorder with 4 video inputs, LAN network, 500GB HDD
€ 530.00
*
TYPE 525H/526
Digital video recorder with 16 video inputs, LAN network, 500GB HDD
€ 887.00
*
TYPE 525H/528
Digital video recorder with 8 video inputs, LAN network, 500GB HDD
€ 649.00
*
TYPE 525H/58D
Digital video recorder with 8 video inputs, LAN network, 500GB HDD
€ 765.00
*
TYPE 525H/626
Digital video recorder with 16 video inputs, LAN network, 500GB HDD
€ 1,377.00
*
TYPE 525H/816
Digital video recorder with 16 video inputs, burner, 500GB HDD
€ 2,641.00
*
TYPE 525H/878
Digital video recorder with 8 video inputs, burner, 500GB HDD
€ 2,477.00
*
TYPE 525W
Apparatus for digital transmission with built-in antenna, band 5.7Ghz
€ 382.00
*
TYPE 5280
Automatic/manual sequential switcher for B/W and colour video signal with 8 video inputs and 8 alarm inputs
€ 121.60 107
TYPE 5286/8
Digital video recorder with 8 IP video inputs, 1TB HDD
€ 4,452.00
22
TYPE 5286/A16
Digital video recorder with 16 analogue video inputs. 500 GB HDD
€ 8,092.00
22
TYPE 5286/A32
Digital video recorder with 32 analogue video inputs. 500 GB HDD
€ 14,672.00
22
TYPE 5286/A8
Digital video recorder with 8 analogue video inputs. 500 GB HDD
€ 6,076.00
22
TYPE 5287/8
Digital video recorder with 8 IP video inputs. 1 TB HDD
€ 6,412.00
28
TYPE 5287/I16
Digital video recorder with 16 analogue and IP video inputs. 1 TB HDD
€ 11,312.00
28
TYPE 5287/I32
Digital video recorder with 32 analogue and IP video inputs. 1 TB HDD
€ 20,972.00
28
TYPE 5287/I8
Digital video recorder with 8 analogue and IP video inputs. 500 GB HDD
€ 8,372.00
28
TYPE 5288/002
Bracket mount for pole
€ 54.40
*
TYPE 5288/005
Bracket for type 5000
€ 37.01
*
TYPE 5288/007
Wall bracket for 12" - 17" monitor
€ 175.00
*
TYPE 5288/008
Bracket for type 5A20, white nish
€ 28.36
*
TYPE 5288/016
Articulated camera bracket for wall mounting.
€ 9.32 70
TYPE 5288/016.05
Articulated camera bracket for wall mounting.
€ 9.32 71
TYPE 5288/017
Articulated camera bracket for ceiling mounting.
€ 19.56 71
TYPE 5288/023
Straight BNC solder connector.
€ 2.33 105
TYPE 5288/024
90° BNC solder connector.
€ 2.33 105
TYPE 5288/028
Wall bracket, supports 15-30" LCD/TFT monitor.
€ 39.52 80
TYPE 5288/029
Compact wall bracket.
€ 6.59 71
TYPE 5288/030
Medium-sized wall bracket.
€ 8.11 71
TYPE 5288/031
Wall bracket.
€ 18.24 71
TYPE 5288/032
Wall bracket with extension up to 60 mm.
€ 9.94 71
TYPE 5288/033
Wall bracket for cameras
€ 22.30 *
TYPE 5288/034
Wall and ceiling bracket for cameras
€ 22.30 *
TYPE 5288/A27
Plug for 12 VDC power supply with screw terminals.
€ 2.80 105
TYPE 5288/BNC
Male BNC crimp connector for RG59 coaxial cables.
€ 2.23 105
TYPE 5288/S28
Wall or ceiling bracket, supports 15-30" LCD/TFT monitor.
€ 105.00 80
TYPE 5288/VIT
Male BNC screw connector for RG59 coaxial cables.
€ 4.40 105
TYPE 528B
Indoor pan and tilt
€ 625.00 *
TYPE 528C
Outdoor pan
€ 1,070.00 *
TYPE 528D
Outdoor pan and tilt
€ 1,472.00 *
* CCTV items included in Elvox Price List no.E1
Alphanumeric index
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
110
TYPE 528E
Outdoor pan and tilt
€ 1,058.00 *
TYPE 528H/404
Digital video recorder with 4 inputs. 1TB HDD
€ 539.00 *
TYPE 528H/524
Digital video recorder with 4 inputs. 1TB HDD
€ 642.00 *
TYPE 528H/526
Digital video recorder with 16 inputs. 1TB HDD
€ 999.00 *
TYPE 528H/528
Digital video recorder with 8 inputs. 1TB HDD
€ 760.00 *
TYPE 528H/626
Digital video recorder with 16 inputs. 1TB HDD
€ 1,489.00 *
TYPE 528H/816
Digital video recorder with 16 inputs. Burner, 1TB HDD
€ 2,746.00 *
TYPE 528H/878
Digital video recorder with 8 inputs. 1TB HDD
€ 2,581.00 *
TYPE 5297/002
Thermostatically-controlled heater for type 5298/160 230 V
€ 40.92 *
TYPE 5297/004
Thermostatically-controlled heater for type 5299
€ 40.92 *
TYPE 5297/005
Thermostatically-controlled heater for type 5299/001 24V
€ 39.82 *
TYPE 5297/006
Thermostatically-controlled heater for type 5299/002
€ 31.54 *
TYPE 5297/007
Thermostatically-controlled heater for type 5298/025
€ 36.16 *
TYPE 5297/12
Kit complete with thermostatically-controlled heater for waterproof housing type 529P supply voltage 12-24 VDC/VAC.
€ 17.74 106
TYPE 5298/025.14
Outdoor housing for CCTV cameras with thermostatically-controlled heater and bracket
€ 163.50 *
TYPE 5298/035.14
Outdoor housing for CCTV cameras with thermostatically-controlled heater, with bracket
€ 248.30 *
TYPE 5298/1
Outdoor housing for speed dome CCTV cameras
€ 460.00 *
TYPE 5298/POE
Outdoor housing POE
€ 197.00 *
TYPE 5299
White outdoor housing for CCTV cameras with thermostatically-controlled heater and bracket
€ 144.30 *
TYPE 5299/001
Outdoor housing for CCTV cameras with thermostatically-controlled heater.
€ 173.30 70
TYPE 5299/002
Outdoor housing, 350 mm, for CCTV cameras with thermostatically-controlled heater.
€ 192.30 *
TYPE 5299/004
Waterproof housing for camera with protected cable passage system.
€ 253.00 70
TYPE 5299/POE
Waterproof housing for camera with protected cable passage system.
€ 211.00 ]
TYPE 529A
Pole mount for waterproof housings type 529P/529S.
€ 20.27 70
TYPE 529A/17
Pole mount for waterproof housings type 52D0/8 - 52D0/E8
€ 46.00 70
TYPE 529B
Pole mount with adapter for speed dome waterproof housing.
€ 46.80 69
TYPE 529C
Bracket with hooks for speed dome camera
€ 43.00 *
TYPE 529F
Corner bracket
€ 39.52 69
TYPE 529H/524
Digital video recorder with 4 inputs. 2TB HDD
€ 698.00 *
TYPE 529H/526
Digital video recorder with 16 inputs. 2TB HDD
€ 1,055.00 *
TYPE 528H/528
Digital video recorder with 8 inputs. 2TB HDD
€ 817.00 *
TYPE 529P
Waterproof aluminium housing with thermostatically-controlled heater. Bracket not supplied.
€ 61.80 70
TYPE 529P/12
Waterproof aluminium housing with thermostatically-controlled heater. Bracket not supplied. 12 VDC
€ 75.00 70
TYPE 529S
Articulated wall bracket for housing 529P.
€ 20.57 70
TYPE 529S/7M
Wall bracket for speed dome camera
€ 66.00 51
TYPE 529S/7S
Ceiling bracket for speed dome camera
€ 55.00 51
TYPE 529S/8
Curved bracket for speed dome camera
€ 65.00 51
TYPE 52A1
DSP colour vandalproof mini dome camera. Supply voltage 12 VDC. Ultra high resolution. 1/3" Sony Super HAD sensor
€ 463.00 61
TYPE 52A1/5
Ring for suspended-ceiling installation of cameras type 52D1/5
€ 111.70 69
TYPE 52A2
DSP colour mini dome camera. Supply voltage 12 VDC. Medium resolution. 1/3" Sony Super HAD sensor
€ 153.30 61
TYPE 52A3
DSP colour mini dome camera. Supply voltage 12 VDC. Ultra high resolution. 1/3" Sony Super HAD sensor
€ 463.00 *
TYPE 52A3/I
DSP colour mini dome camera. Supply voltage 12 VDC. Ultra high resolution. 1/3" Sony Super HAD sensor
€ 292.00 62
TYPE 52AM
Video signal amplier for coaxial cable
€ 61.40 76
TYPE 52B2
DSP colour mini dome camera. Supply voltage 12 VDC. Medium resolution. 1/3" Sony Super HAD sensor
€ 157.10 61
TYPE 52CV
Analogue to digital video converter. BNC – VGA/SVGA/XGA/SXGA
€ 108.50 103
TYPE 52D0
Day & Night colour camera. 1/3” SONY sensor.
€ 219.90 103
TYPE 52D0/1
Day & Night colour camera. 1/3" SONY sensor. Ultra high resolution. OSD control. Camera titling.
€ 153.00 54
TYPE 52D0/2
Day & Night colour camera. 1/3" SONY sensor. High resolution. OSD control. Camera titling. Varifocal
€ 138.00 54
TYPE 52D0/3
Day & Night colour camera. 1/3" SONY STAR LIGHT sensor. Ultra high resolution. DNR
€ 200.00 53
TYPE 52D0/8
Day & Night small dome indoor colour video camera
€ 830.00 67
TYPE 52D0/E8
Day & Night small dome outdoor colour video camera
€ 865.00 67
TYPE 52D1/5
Day & Night colour camera. DSP mini speed dome. 1/4" Sony Exview sensor. Ultra high resolution
€ 1,880.00 65
TYPE 52D1/6
Day & Night colour camera. DSP mini speed dome. 1/4" Sony Exview sensor. Ultra high resolution. Vandalproof
€ 2,074.00 66
TYPE 52D1/6T
Day & Night colour camera. DSP mini speed dome. 1/4" Sony Exview sensor. Ultra high resolution. Vandalproof
€ 2,709.00 66
TYPE 52D1/E5
Day & Night colour camera. DSP outdoor speed dome. 1/4" Sony Exview sensor. Ultra high resolution
€ 1,935.00 65
TYPE 52D8/5
Keypad for controlling speed dome camera, compatible with all cameras
€ 672.00 68
TYPE 52D8/6
Keypad for controlling speed dome camera, for speed dome type 52D1/5 - 52D1/E5 - 52D1/6 - 52D1/6T
€ 499.00 68
TYPE 52D8/8
Keypad for controlling small dome camera, with 3-axis function
€ 280.00 68
TYPE 52DM
B/W CCIR camera, DSP. Supply voltage 85 to 265 VAC, 40-400 Hz. 1/3" SONY SUPER HAD sensor
€ 200.00 63
TYPE 52DN
Day & Night colour camera. DSP. Supply voltage 85 to 265 VAC, 40-400 Hz. 1/3" SONY SUPER HAD sensor
€ 337.00 52
TYPE 52DN/IR
Day & Night colour camera. DSP. Supply voltage 85 to 265 VAC, 40-400 Hz. 1/3" SONY EXVIEW sensor
€ 390.00 52
TYPE 52DS/16
RS485 distributor for 16 speed dome devices
€ 380.00 104
TYPE 52DS/4
RS485 distributor for 4 speed dome devices
€ 213.30 104
TYPE 52DS/8
RS485 distributor for 8 speed dome devices
€ 309.00 104
* CCTV items included in Elvox Price List no.E1
Alphanumeric index
Day & Night colour cameras
BEST OVERVIEW
111
PRICE LIST no.E1
TYPE 52DT
Day & Night colour camera, DSP. Supply voltage 85 to 265 VAC, 40-400 Hz. 1/3" SONY EXVIEW sensor
€ 410.00 53
TYPE 52DV/4 Video distributor with 4 outputs for coaxial cable € 72.00 76
TYPE 52DV/8 Video distributor with 8 outputs for coaxial cable € 119.00 76
TYPE 52F1
Microphone for audio applications, compatible with the entire 12 VDC camera range
€ 20.27 107
TYPE 52F2
Microphone for audio applications, compatible with the entire 12 VDC camera range
€ 24.32 107
TYPE 52GB
Video ground loop isolator Balun coaxial cable specically for DVRs
€ 46.27 103
TYPE 52GL
Video ground loop isolator
€ 39.47 103
TYPE 52HD/1T
Expansion 1 TB HDD
€ 546.00 32
TYPE 52IP
Colour camera for TCP IP connection over LAN network. Supply voltage 12 VDC. Includes power supply unit
€ 464.00 64
TYPE 52IW
Indoor IP video camera with 1/4" Sony CMOS sensor
€ 416.00 64
TYPE 52JO
USB joystick for remote operation of PTZ video cameras
€ 952.00 32
TYPE 52L2
Day & Night colour camera. Indoor mini dome. Supply voltage 12 VDC. Medium resolution. 1/3" SHARP sensor.
€ 97.30 60
TYPE 52L3
Day & Night colour camera. DSP. Mini dome. Supply voltage 12 VDC. Medium resolution. 1/3" Sony sensor
€ 172.30 59
TYPE 52L4
Day & Night colour camera. DSP. Mini dome. Supply voltage 12 VDC. High resolution. 1/3" Sony sensor
€ 272.00 59
TYPE 52LZ/01T
Optional 1 TB capacity
€ 371.00 32
TYPE 52LZ/1CC
Expansion for 1 additional simultaneous connection
€ 392.00 32
TYPE 52LZ/1UA
Expansion for 1 additional user
€ 196.00 32
TYPE 52LZ/3C1
Licence for 1 additional channel from 5 to 12
€ 196.00 32
TYPE 52LZ/3C4 Expansion for 4 additional IP licences € 644.00 32
TYPE 52LZ/3U
Expansion for 3 additional users
€ 392.00 32
TYPE 52LZ/3UC
Expansion for 3 additional users and one connection
€ 616.00 33
TYPE 52LZ/4.4
Serial hardware module 4+4 internal I/O
€ 252.00 32
TYPE 52LZ/4C1
Licence for 1 additional channel from 5 to 12
€ 364.00 32
TYPE 52LZ/4C4 Expansion for 4 additional IP licences € 1,176.00 32
TYPE 52LZ/5L1
Licence for 1 IP channel from 5 to 16
€ 448.00 33
TYPE 52LZ/5L4 Expansion for 4 additional IP licences € 1,509.00 33
TYPE 52LZ/6L1
Licence for 1 IP channel from 9 to 72
€ 364.00 32
TYPE 52LZ/6L4 Expansion for 4 additional IP licences € 1,176.00 32
TYPE 52LZ/7L1
Licence for 1 IP channel from 9 to 72
€ 448.00 33
TYPE 52LZ/7L4 Expansion for 4 additional IP licences € 1,509.00 33
TYPE 52LZ/8.8
Serial hardware module 8+8 internal I/O
€ 504.00 32
TYPE 52LZ/AM
Arteco Mobile plug-in
€ 560.00 33
TYPE 52LZ/AVA
Video analytics channel licence upgrade
€ 431.00 33
TYPE 52LZ/CCI
Expansion for simultaneous connections and unlimited users
€ 1,911.00 33
TYPE 52LZ/CM
Multiserver control plug-in
€ 532.00 32
TYPE 52LZ/CT
Trafc channel licence
€ 1,509.00 33
TYPE 52LZ/DE
Licence upgrade for Motion Detection Enterprise channel
€ 154.00 32
TYPE 52LZ/IOC
Concatenated I/O plug-in
€ 812.00 32
TYPE 52LZ/IOV
Virtual I/O plug-in
€ 812.00 32
TYPE 52LZ/MDE
Licence upgrade for Motion Detection channel
€ 154.00 32
TYPE 52LZ/MMS
Plug-in for SMS/MMS notication
€ 616.00 32
TYPE 52LZ/MP
Maps plug-in
€ 504.00 32
TYPE 52LZ/PPZ
Privacy Zone plug-in
€ 280.00 32
TYPE 52LZ/RSB
Local recording stream broadcaster
€ 2,125.00 33
TYPE 52LZ/WD
Plug-in for on-demand Internet wireless connection
€ 1,232.00 32
TYPE 52MA
DVD burner
€ 112.00 32
TYPE 52P0/212
CCTV kit comprising 1 video camera type 52D0/3, 1 lens type 24/212, 1 waterproof aluminium housing type 529P/12 and bracket type 529S
€ 290.00 97
TYPE 52P0/660
CCTV kit comprising 1 colour camera type 52D0/3. 1 waterproof aluminium housing type 529P/12 and bracket type 529S
€ 336.00 97
TYPE 52PM
CCTV kit comprising 1 B/W camera type 52DM. 1 lens type 23/308. 1 waterproof aluminium housing type 529P and bracket type 529S
€ 336.00 95
TYPE 52PM/550
CCTV kit comprising 1 B/W camera type 52DM. 1 lens type 23/550. 1 waterproof aluminium housing type 529P and bracket type 529S
€ 426.00 95
TYPE 52PN
CCTV kit comprising 1 colour camera type 52DN. 1 lens type 23/308. 1 waterproof aluminium housing type 529P and bracket type 529S
€ 473.00 95
TYPE 52PN/550
CCTV kit comprising 1 colour camera type 52DN. 1 lens type 23/550. 1 waterproof aluminium housing type 529P and bracket type 529S
€ 563.00 95
TYPE 52PR
CCTV kit comprising 1 colour camera type 52DN/IR. 1 lens type 23/308. 1 aluminium waterproof housing type
€ 503.00 95
TYPE 52PR/550
CCTV kit comprising 1 colour camera type 52DT. For checking vehicle licence plates.
€ 593.00 96
TYPE 52PT
CCTV kit comprising 1 colour camera type 52DN/IR, specially designed for checking vehicle licence plates. 1 lens type 23/308
€ 546.00 96
TYPE 52PT/550
CCTV kit comprising 1 colour camera type 52DN/IR, specially designed for checking vehicle licence plates. 1 lens type 23/550
€ 636.00 96
TYPE 52RA
Active receiver for rack or wall mounting. Terminal block connector with 5 terminals
€ 22.45 100
TYPE 52RA/16
Active transmitter for wall mounting to receive 16 video signals
€ 256.00 102
TYPE 52RA/4
Active transmitter for wall mounting to receive 4 video signals
€ 76.00 101
TYPE 52RA/8
Active transmitter for wall mounting to receive 8 video signals
€ 153.10 102
TYPE 52RA/DT
Active receiver for wall mounting. Receives video signal, receives/transmits RS485 data
€ 44.57 101
TYPE 52RD/4
RAID5 4 TB capacity
€ 4,046.00 32
TYPE 52RS
RS485 digital data repeater
€ 120.90 103
TYPE 52RS/485
Converter RS232 - RS422/485
€ 196.00 32
* CCTV items included in Elvox Price List no.E1
Alphanumeric index
Day & Night colour cameras BEST OVERVIEW
PRICE LIST no.E1
112
Alphanumeric index
TYPE 52S1/5
Ring for wall installation of cameras type 52D1/5
€ 111.70 69
TYPE 52S1/6
Ring for wall installation of cameras type 52D1/6, 52D1/6T
€ 111.70 69
TYPE 52SP/8
Switch 8 ports
€ 19.00 *
TYPE 52SW/16P
Switch 8 ports + 8 POE
€ 695.00 *
TYPE 52SW/24
Switch 24 ports
€ 285.00 *
TYPE 52SW/24P
Switch 24 ports POE + 4 mixed Gigabit ethernet ports
€ 1,513.00 *
TYPE 52SW/5
Switch 5 ports
€ 96.00 *
TYPE 52SW/8
Switch 8 ports
€ 104.00 *
TYPE 52SW/8P
Switch 4 ports + 4 POE
€ 332.00 *
TYPE 52TA
Active transmitter for rack or wall mounting. Terminal block connector with 5 terminals
€ 22.45 100
TYPE 52TA/4
Active transmitter for wall mounting to transmit 4 video signals
€ 76.00 100
TYPE 52TA/DT
Transmitter for wall mounting. Transmits video, receives/transmits RS485 data and power
€ 44.57 101
TYPE 52TA/Rack
1-module rack panel for insertion of active transducers type 52TA – 52RA – passive transducers type 52TP/4
€ 17.34 102
TYPE 52TD
Pair of active transducers RIC/TRAS
€ 198.70 *
TYPE 52TP
Passive transducer, compact and easy to install, BNC connector for connection to video camera
€ 5.77 98
TYPE 52TP/1
Passive transducer, compact and easy to install, 90° BNC connector for special camera installations
€ 5.77 98
TYPE 52TP/16
Passive transducer for rack installation, 16 BNC connectors for video input
€ 113.50 99
TYPE 52TP/2
Passive transducer, compact and easy to install, BNC connector with 14 cm coaxial cable
€ 5.77 98
TYPE 52TP/3
Pair of compact passive transducers, easy-to-install transmitter / receiver
€ 14.96 98
TYPE 52TP/32
Passive transducer for rack installation, 32 BNC connectors for video input
€ 153.10 99
TYPE 52TP/4
Passive transducer for rack or wall mounting, 4 BNC connectors with 14 cm coaxial cable
€ 22.45 99
TYPE 52TP/4A
Passive transducer, 4 BNC connectors for 1 video input signal, 4 video output signals
€ 24.48 99
TYPE 52WS
Web server for TCP IP connection over LAN network for video signals. PTZ cameras. Supply voltage 5 VDC. Includes power supply unit
€ 633.00 *
TYPE 52WS/1
Video encoder with one channel, BNC input, RS485 control for PTZ, supply voltage 12 VDC
€ 480.00 49
TYPE 52WS/4
Video encoder with 4 channels, BNC input, RS485 control for PTZ, supply voltage 12 VDC
€ 571.00 50
TYPE 52WS/A1
Video encoder with 1 channels, BNC input, RS485 control for PTZ,
without local storage € 400.00 49
TYPE 52Z0.
Day & Night colour camera. Auto focus and 22x zoom
€ 741.00 55
TYPE 53IP
Day & Night colour IP camera with 1/3" CMOS sensor
€ 490.00 44
TYPE 54IP
Day & Night colour IP camera with 1/3" Sony Super HAD sensor
€ 632.00 45
TYPE 55IP/05
Day & Night colour IP camera with 1/3" progressive scan CMOS sensor, 5 megapixels
€ 1,721.00 42
TYPE 55IP/1
Day & Night colour IP camera with 1/3" progressive scan Sony CCD sensor, 1.3 megapixels
€ 1,037.00 39
TYPE 55IP/2
Day & Night colour IP camera with 1/3" progressive scan CMOS sensor, 2 megapixels
€ 819.00 40
TYPE 55IP/3
Day & Night colour IP camera with 1/3" progressive scan CMOS sensor, 3 megapixels
€ 1,255.00 41
TYPE 55IP/5
Day & Night colour IP camera with 1/3" progressive scan CMOS sensor, 5 megapixels
€ 2,499.00 *
TYPE 56IP
Day & Night vandalproof mini dome colour IP camera
€ 465.00 46
TYPE 57IP
Day & Night vandalproof dome colour IP camera, 1/3" CMOS sensor
€ 999.00 43
TYPE 58IP
Day & Night colour IP camera, 1/3" Sony Super HAD sensor,
lens 12 mm xed € 788.00 47
TYPE 58IP/3
Day & Night colour IP camera, 1/3" Sony Super HAD sensor,
lens 3 mm xed € 600.00 47
TYPE 58IP/6
Day & Night colour IP camera, 1/3" Sony Super HAD sensor,
lens 6 mm xed € 600.00 47
TYPE 59IP
Day & Night vandalproof dome indoor colour IP camera, 1/3" CMOS sensor
€ 446.00 48
TYPE 5556/004
Video distributor with 4 outputs for coaxial cable.
€ 41.70 76
TYPE 5559
Video signal amplier.
€ 180.02 76
TYPE 5AA0
Power supply unit with European plug. 12 VDC 0.6 A
€ 15.60 75
TYPE 5AA1
Power supply unit for junction box type 503. 12 VDC 1 A
€ 31.42 75
TYPE 5AA2
Desktop power supply unit. 12 VDC 2 A
€ 43.58 75
TYPE 5AA5
Modular power supply unit. 12 VDC 4.2 A
€ 67.90 75
TYPE 5AA6
Power supply unit with European plug 12 VDC 1.25 A
€ 17.80 75
TYPE 5AE0
Camera with 3 mm lens
€ 140.10 *
TYPE 5AL4
Day & Night colour camera. DSP. Supply voltage 12 VDC. High resolution. 1/3" Sony sensor. 3.6 mm xed lens.
€ 109.00 57
TYPE 5AL6/A
Day & Night colour camera. DSP. Supply voltage 12 VDC. Medium resolution. 1/3" Sony sensor. 4.3 mm xed lens.
€ 154.00 56
TYPE 5AL7
Day & Night colour camera. DSP. Supply voltage 12 VDC. Medium resolution. 1/3" CCD sensor. 4.3 mm xed lens
€ 100.00 57
TYPE 5AL7/S
Day & Night colour camera. DSP. Supply voltage 12 VDC. Medium resolution. 1/3" CCD sensor. 4.3 mm xed lens
€ 73.00 57
TYPE 5AL8
Day & Night colour camera, DSP. Supply voltage 12 VDC. Medium resolution. 1/3" CCD sensor. 4 mm xed lens.
€ 89.00 57
TYPE 5AL9
Day & Night colour camera. DSP. Supply voltage 12 VDC. High resolution. 1/3" Sony sensor. 3.6 mm xed lens.
€ 115.00 57
TYPE 5AP6
Colour camera. DSP. Supply voltage 12 VDC. Standard resolution. 1/3" CCD sensor. 3.7 mm xed lens
€ 120.60 62
TYPE 5AP7
Colour camera. DSP. Supply voltage 12 VDC. Standard resolution. 1/3" CCD sensor. 3.7 mm xed lens
€ 120.60 62
TYPE 5BL6
Day & Night colour camera. DSP. Supply voltage 12 VDC. Medium resolution. 1/3" Sony sensor. 8 mm xed lens
€ 150.00 56
TYPE 5AL6/A
Day & Night colour camera. DSP. Supply voltage 12 VDC. Medium resolution. 1/3" Sony sensor. 8 mm xed lens
€ 154.00 56
TYPE 5CL5
Day & Night colour camera. Supply voltage 12 VDC. Medium resolution. 1/3" CCD sensor. 12 mm xed lens
€ 219.30 *
TYPE 5DL5
Day & Night colour camera. DSP. Supply voltage 12 VDC. Medium resolution. 1/3" CCD sensor. 16 mm xed lens
€ 219.30 *
TYPE 5E30/LT
ALPR licence plate reading camera
€ 3,668.00 30
TYPE 5EL5
Day & Night colour camera. DSP. Supply voltage 12 VDC. Medium resolution. 1/3" CCD sensor. 4.3 mm xed lens
€ 219.00 *
TYPE 5FL5
Day & Night colour camera. DSP. Supply voltage 12 VDC. Medium resolution. 1/3" CCD sensor. 8 mm xed lens
€ 219.00 *
TYPE 5GL6
Day & Night colour camera. DSP. Supply voltage 12 VDC. Medium resolution. 1/3" Sony sensor. 25 mm xed lens
€ 292.00 57
* CCTV items included in Elvox Price List no.E1
Day & Night colour cameras
BEST OVERVIEW
113
PRICE LIST no.E1
TYPE 5SA0
B/W underwater camera, water-resistant to 3 atmospheres. Medium resolution. Protection rating IP66. 1/3" Sony sensor
€ 164.00 *
TYPE 5SB0
B/W underwater camera, water-resistant to 3 atmospheres. Medium resolution. Protection rating IP66. 1/3" Sony sensor
€ 164.00 *
TYPE 5VL0
Day & Night colour camera. Supply voltage 12 VDC. Medium resolution. 1/3" Sony sensor
€ 105.00 58
TYPE 5VL1
Day & Night colour camera. Supply voltage 12 VDC. Medium resolution. 1/3" Sony sensor
€ 180.00 58
TYPE 5VL2
Day & Night colour video camera, supply voltage 12 VDC. Medium resolution. 1/3" SONY sensor
€ 254.00 58
TYPE 5VL3
Day & Night colour video camera, supply voltage 12 VDC. High resolution. 1/3" SONY sensor
€ 162.00 59
TYPE 5WA0
Waterproof B/W bullet camera with 3.6 mm lens. Supplied with bracket
€ 226.00 *
TYPE 5WA5/1
Colour bullet camera. Sony 1/3" sensor with 3.6 mm lens, waterproof. Supplied with bracket
€ 212.80 61
TYPE 6582
Supplementary power supply unit 12 / 13.5 VDC 250 mA.
€ 47.79 75
TYPE 6583/12
Power supply unit for cameras in parallel 12 VDC 1.6 A.
€ 143.74 75
TYPE 832/024
Low-voltage safety transformer. 24 VAC 30 VA.
€ 26.12 76
TYPE RT01
Adhesive "Area Under Surveillance" sticker in white PVC, dimensions 210x125 mm.
€ 6.08 106
TYPE RT03
"Area Under Surveillance" sign in polypropylene (PPB), dimensions 210x125 mm.
€ 8.11 106
Alphanumeric index
BEST OVERVIEW 2011
CCTV
BEST OVERVIEW CCTV 2011
VIDEOCITOFONIA TELEFONIA DOMOTICATVCC AUTOMAZIONI
I t I n c lu d es a l s o t h e n e w
I P sys t e m R a n G e
Via Pontarola, 14/a
35011 Campodarsego PD - Italy
Tel. +39 049 920 2511
Fax +39 049 920 2601
www.elvox.com - elvoxexp@elvox.com
Elvox reserves the right to modify its products at any time without advance notication. Due to layout considerations, the images and drawings of the products are not in scale to each other DEP.RAP.ETV - ED00 - 03/2012

Navigation menu
