Big Promo 3 2017 Digital Version
User Manual: Big promo 3 2017 digital version
Open the PDF directly: View PDF
.
Page Count: 20
Passion.Technology.Design.
3 2017
TRADE PRICES VALID FROM 1st SEPTEMBER TO 31st DECEMBER 2017
Products NOW Ex Stock - This oer is valid only for products available on stock.
Trade prices are in Pounds, Net, excluding VAT and valid for security trade customers only.
Information is subject to change without notice.
COMELIT
BIGPROMO
WIKIT040AUK
New ready made 4 channels HD Wi-Fi CCTV kit: easy to set up and use, ideal for home or
business, simple mobile remote viewing
Comelit View S
IP100
New range of NVR’s for professional installations, up to 128
channels, 4K resolution
IP EASY SERIES
IPCAM062A
FULL-HD BULLET IP CAMERA,
2.8-12 MM, IR 25M, IP66
Camera sensor: 1/2.8” CMOS Sony
Sensitivity (lux): 0.5 (colour) / 0 (B/W, led IR ON)
IR filter: Mechanical
Video resolution (H x V): 1920x1080 (FULL-HD 1080p)
Video compression: H.264 (Dual streaming)
Main functions: Privacy mask, Motion detection
No. IR LEDs / Max. distance (m): 28 led / 25m
DC supply voltage: 12V
POE power supply: Standard IEEE 802.3af
£57
IPCAM064A
4MP BULLET IP CAMERA,
2.8-12MM, IR 25M, IP66
Camera sensor: 1/3’’ CMOS Sony
Sensitivity (lux): 0.5 (colour) / 0 (B/W, led IR ON)
IR filter: Mechanical
Video resolution (H x V): 2592x1520 (4MP)
Video compression: H.264, H.265 (Dual streaming)
Main functions: Privacy mask, Motion detection
No. IR LEDs / Max. distance (m): 28 led / 25m
DC supply voltage: 12V
POE power supply: Standard IEEE 802.3af
Compatible only with
IPNVR006A-xxx and
IPNVR036A-xxx
MOTORIZED LENS AND AUTOFOCUS
IPCAM065A
5MP BULLET IP CAMERA,
2.8-12MM, IR 25M, IP66
Camera sensor: 1/3.2’’ CMOS Sony
Sensitivity (lux): 0.5 (colour) / 0 (B/W, led IR ON)
IR filter: Mechanical
Video resolution (H x V): 2592x1944 (5MP)
Video compression: H.264, H.265 (Dual streaming)
Main functions: Privacy mask, Motion detection
No. IR LEDs / Max. distance (m): 28 led / 25m
DC supply voltage: 12V
POE power supply: Standard IEEE 802.3af
MOTORIZED LENS AND AUTOFOCUS
IPCAM020A
FULL-HD BULLET IP CAMERA,
3.6 MM, IR 30M, IP66
£96
Camera sensor: 1/2.8” CMOS Sony
Sensitivity (lux): 0.5 (colour) / 0 (B/W, led IR ON)
IR filter: Mechanical
Video resolution (H x V): 1920x1080 (FULL-HD 1080p)
Video compression: H.264 (Dual streaming)
Main functions: Privacy mask, Motion detection
No. IR LEDs / Max. distance (m): 30 led / 30m
DC supply voltage: 12V
POE power supply: Standard IEEE802.3af
FULL HD
IPCAM040A
4MP BULLET IP CAMERA,
3.6MM, IR 30M, IP66
£50
Camera sensor: 1/3’’ CMOS
Sensitivity (lux): 0.5 (colour) / 0 (B/W, led IR ON)
IR filter: Mechanical
Video resolution (H x V): 2592x1520 (4MP)
Video compression: H.264, H.265 (Dual streaming)
Main functions: Privacy mask, Motion detection
No. IR LEDs / Max. distance (m): 30 led / 30m
DC supply voltage: 12V
POE power supply: Standard IEEE 802.3af
Compatible only with
IPNVR006A-xxx and
IPNVR036A-xxxx
4MP
IPCAM050A
5MP BULLET IP CAMERA,
3.6MM, IR 30M, IP66
£63
Camera sensor: 1/3.2’’ CMOS
Sensitivity (lux): 0.5 (colour) / 0 (B/W, led IR ON)
IR filter: Mechanical
Video resolution (H x V): 2592x1944 (5MP)
Video compression: H.264, H.265 (Dual streaming)
Main functions: Privacy mask, Motion detection
No. IR LEDs / Max. distance (m): 30 led / 30m
DC supply voltage: 12V
POE power supply: Standard IEEE 802.3af
Compatible only with
IPNVR006A-xxx and
IPNVR036A-xxx
5MP
£77
£100
Compatible only with
IPNVR006A-xxx and
IPNVR036A-xxx
FULL HD
2
IPCAM067A
FULL-HD MINIDOME IP
CAMERA, 3.6 MM, IR 30M, IP66
£51
Camera sensor: 1/2.7” CMOS
Sensitivity (lux): 0.5 (colour) / 0 (B/W, led IR ON)
IR filter: Mechanical
Video resolution (H x V): 1920x1080 (FULL-HD 1080p)
Video compression: H.264 (Dual streaming)
Main functions: Privacy mask, Motion detection
No. IR LEDs / Max. distance (m): 36 led / 30m
DC supply voltage: 12V
POE power supply: Standard IEEE 802.3af
FULL HD
IPCAM074A
4MP MINIDOME IP CAMERA,
3.6MM, IR 30M, IP66
Camera sensor: 1/3’’ CMOS
Sensitivity (lux): 0.5 (colour) / 0 (B/W, led IR ON)
IR filter: Mechanical
Video resolution (H x V): 2592x1520 (4MP)
Video compression: H.264, H.265 (Dual streaming)
Main functions: Privacy mask, Motion detection
No. IR LEDs / Max. distance (m): 36 led / 30m
DC supply voltage: 12V
POE power supply: Standard IEEE 802.3af
4MP
Compatible only with
IPNVR006A-xxx and
IPNVR036A-xxx
£69
IPCAM069A
FULL-HD MINIDOME IP CAMERA,
2.8-12 MM, IR 30M, IP66
£56
Camera sensor: 1/2.7” CMOS
Sensitivity (lux): 0.5 (colour) / 0 (B/W, led IR ON)
IR filter: Mechanical
Video resolution (H x V): 1920x1080 (FULL-HD 1080p)
Video compression: H.264 (Dual streaming)
Main functions: Privacy mask, Motion detection
No. IR LEDs / Max. distance (m): 30 led / 30m
DC supply voltage: 12V
POE power supply: Standard IEEE 802.3af
FULL HD
Camera sensor: 1/3’’ CMOS
Camera optical zoom: 4x
Sensitivity (lux): 0.5 (colour) / 0 (B/W, led IR ON)
IR filter: Mechanical
Video resolution (H x V): 2592x1520 (4MP)
Video compression: H.264, H.265 (Dual streaming)
Main functions: Privacy mask, Motion detection
No. IR LEDs / Max. distance (m): 30 led / 30m
DC supply voltage: 12V
POE power supply: Standard IEEE 802.3af
£96
Compatible only with
IPNVR006A-xxx and
IPNVR036A-xxx
4MP
IPCAM084A
4MP MINIDOME IP CAM,
2.8-12MM MOT., IR 30M, IP66
WIKIT040AUK
WI-FI KIT, WINVR040A,
4 WICAM010A, HDD 1TB
WINVR040A
Video inputs: 4
Main video output: 1 (VGA), 1 (HDMI), 1920x1080@60Hz
Video compression: H.264
Hard disk included: 1TB (4TB max)
WICAM010A
Camera sensor: 1/3’’ CMOS Progressive Scan
Camera lens: 4 mm
Electronic shutter (s): 1/25 ÷ 1/25000
IR filter: Mechanical
Video resolution (H x V): 1280x960 (HD - 960p)
Power supply included.
PRECONFIGURED
£299
NEW
P2P
HD
HDD 1TB
WI-FI
IP EASY SERIES
Passion.Technology.Design.
3
IP EASY SERIES
IPNVR004BPOESL
NVR W/4 INPUTS, FULL-HD IP POE, NO HDD
Video inputs: 4 PoE (FULL-HD)
Main video output: 1 (VGA), 1 (HDMI 1.3), 1920x1080 @ 60Hz
Video compression: H.264
Display / recording frame rate: 100fps@FULL-HD Real Time
Installable hard drive: 1 x 4 TB max
Operating system: Linux embedded
Protocols supported: HTTP, TCP/IP, SMTP, DHCP, DDNS, ONVIF 2.3
Remote control via browser: Internet Explorer, Firefox, Chrome
Remote control by software: Comelit CMS
Remote control by mobile: APP Comelit View S (Android, iOS)
Type of connections/ports: 2xUSB, 4xEthernet 10/100Mbit/s PoE (IEEE 802.3af), 1xEthernet 10/100Mbit/s
AC supply voltage: 100÷240V / 50÷60Hz
FULL HD IP AUTO CONFIGURATION
£78
P2P
Comelit DNS
IPNVR004BPOE-2TBW
NVR 4 INPUTS IP FULL-HD POE,
HDD 2TB WD PURPLE
£161
HDD 2TB
“WD PURPLE”
IPNVR004BPOE-4TBW
NVR 4 INPUTS IP FULL-HD POE, HDD
4TB WD PURPLE
£227
HDD 4TB
“WD PURPLE”
IPNVR008BPOESL
NVR W/8 INPUTS, FULL-HD IP POE, NO HDD
Video inputs: 8 PoE (FULL-HD)
Main video output: 1 (VGA), 1 (HDMI 1.3), 1920x1080 @ 60Hz
Video compression: H.264
Display / recording frame rate: 200fps@FULL-HD Real Time
Installable hard drive: 2 x 4 TB max
Operating system: Linux embedded
Protocols supported: HTTP, TCP/IP, SMTP, DHCP, DDNS, ONVIF 2.3
Remote control via browser: Internet Explorer, Firefox, Chrome
Remote control by software: Comelit CMS
Remote control by mobile: APP Comelit View S (Android, iOS)
Type of connections/ports: 2xUSB, 8xEthernet 10/100Mbit/s PoE (IEEE 802.3af), 1xEthernet 10/100Mbit/s
AC supply voltage: 100÷240V / 50÷60Hz
FULL HD IP AUTO CONFIGURATION
£92
P2P
Comelit DNS
IPNVR008BPOE-2TBW
NVR 8 INPUTS IP FULL-HD
POE, HDD 2TB WD PURPLE
£177
HDD 2TB
“WD PURPLE”
IPNVR008BPOE-4TBW
NVR 8 INPUTS IP FULL-HD
POE, HDD 4TB WD PURPLE
£241
HDD 4TB
“WD PURPLE”
IPNVR008BPOE-8TBW
NVR 8 INPUTS IP FULL-HD
POE, HDD 8TB WD PURPLE
£390
HDD 8TB
“WD PURPLE”
4
IPNVR006ASL
NVR 16 INPUTS IP FULL-HD, NO HDD
Video inputs: 16 (FULL-HD) / 9 (4MP/5MP)
Main video output: 1 (VGA), 1 (HDMI 1.3), 1920x1080@60Hz
Alarm Inputs/Outputs: 4/1
Video compression: H.264
Display / recording frame rate: 400fps@FULL-HD Real Time
Installable hard drive: 2 x 4 TB max
Operating system: Linux embedded
Protocols supported: HTTP, TCP/IP, SMTP, DHCP, DDNS
Remote control via browser: Internet Explorer, Firefox, Chrome
Remote control by software: Comelit CMS
Remote control by mobile: APP Comelit View S (Android, iOS)
Type of connections/ports: 2xUSB, 1xEthernet 10/100/1000Mbit/s
AC supply voltage: 100÷240V / 50÷60Hz”
UP TO 5MP
£70
P2P
Comelit DNS
IPNVR006A-2TBW
NVR 16 INPUTS IP FULL-HD,
HDD 2TB WD PURPLE
£156
HDD 2TB
“WD PURPLE”
IPNVR006A-4TBW
NVR 16 INPUTS IP FULL-HD,
HDD 4TB WD PURPLE
£220
HDD 4TB
“WD PURPLE”
IPNVR006A-8TBW
NVR 16 INPUTS IP FULL-HD,
HDD 8TB WD PURPLE
£369
HDD 8TB
“WD PURPLE”
IPNVR036ASL
NVR 36 INPUTS IP FULL-HD, NO HDD
Video inputs: 36 (FULL-HD) / 16 (4MP/5MP)
Main video output: 1 (VGA), 1 (HDMI 1.3), 1920x1080@60Hz
Alarm Inputs/Outputs: 4/1
Video compression: H.264
Display / recording frame rate: 900fps@FULL-HD Real Time
Installable hard drive: 4 x 4 TB max
Operating system: Linux embedded
Protocols supported: HTTP, TCP/IP, SMTP, DHCP, DDNS
Remote control via browser: Internet Explorer, Firefox, Chrome
Remote control by software: Comelit CMS
Remote control by mobile: APP Comelit View S (Android, iOS)
Type of connections/ports: 2xUSB, 1xEthernet 10/100/1000Mbit/s
AC supply voltage: 100÷240V / 50÷60Hz
UP TO 5MP
£156
P2P
Comelit DNS
IPNVR036A-2TBW
NVR 36 INPUTS IP
FULL-HD,
HDD 2TB WD
PURPLE
£235
HDD 2TB
“WD PURPLE”
IPNVR036A-4TBW
NVR 36 INPUTS IP
FULL-HD,
HDD 4TB WD
PURPLE
£305
HDD 4TB
“WD PURPLE”
IPNVR036A-8TBW
NVR 36 INPUTS IP
FULL-HD,
HDD 8TB WD
PURPLE
£455
HDD 8TB
“WD PURPLE”
IPNVR036A-16TBW
NVR 36 INPUTS IP
FULL-HD,
HDD 16TB WD
PURPLE
£753
HDD 16TB
“WD PURPLE”
IPNVR036A-12TBW
NVR 36 INPUTS IP
FULL-HD,
HDD 12TB WD
PURPLE
£604
HDD 12TB
“WD PURPLE”
IP EASY SERIES
Passion.Technology.Design.
5
IP 100 SERIES
IPCAM162A
FULL-HD BULLET IP CAMERA,
2.8-12MM, IR 50M, IP66
IPCAM1622A
FULL-HD BULLET IP CAMERA,
6-22MM, IR 50M, IP66
Camera sensor: 1/2.8’’ CMOS Sony
Sensitivity (lux): 0 (B/W, led IR ON)
IR filter: Mechanical
Video resolution (H x V): 1920x1080 (FULL-HD 1080p)
Video compression: H.264, MJPEG (Dual streaming)
Main functions: Privacy mask, Motion detection, Tampering
No. IR LEDs / Max. distance (m): 66 led / 50m
DC supply voltage: 12V
POE power supply: Standard IEEE802.3af
Camera sensor: 1/2.8’’ CMOS Sony
Sensitivity (lux): 0 (B/W, led IR ON)
IR filter: Mechanical
Video resolution (H x V): 1920x1080 (FULL-HD 1080P)
Video compression: H.264, MJPEG (Dual streaming)
Main functions: Privacy mask, Motion detection, Tampering
No. IR LEDs / Max. distance (m): 66 led / 50m
DC supply voltage: 12V
POE power supply: Standard IEEE 802.3af
FULL HD
IPCAM102B
FULL-HD BULLET IP CAMERA,
3.6 MM, IR 15 M, IP66
£65
Camera sensor: 1/2.8”” CMOS Sony
Sensitivity (lux): 0 (B/W, led IR ON)
IR filter: Mechanical
Video resolution (H x V): 1920x1080 (FULL-HD 1080p)
Video compression: H.264, MJPEG (Dual streaming)
Main functions: Privacy mask, Motion detection, Tampering
No. IR LEDs / Max. distance (m): 30 led / 15m
DC supply voltage: 12V
POE power supply: Standard IEEE802.3af”
FULL HD
£87
£96
IPCAM163A
3MP BULLET IP CAMERA,
2.8-12MM, IR 50M, IP66
Camera sensor: 1/2.8’’ CMOS Sony EXMOR Starvis Technology
Sensitivity (lux): 0 (B/W, led IR ON)
IR filter: Mechanical
Video resolution (H x V): 2048x1536 (3MP)
Video compression: H.264, H.265, MJPEG (Dual streaming, Dual compression)
Main functions: Video Analytics, Privacy mask, Motion detection, Tampering
Video analytics: Counting, object stolen/abandoned, area detection (object ente-
ring/leaving), virtual guard
No. IR LEDs / Max. distance (m): 2 led arrays / 50m
Support SD card (card not included): Micro-SD (64GB max)
DC supply voltage: 12V
POE power supply: Standard IEEE 802.3af
3MP VIDEO ANALYSIS
WDR SONY STARVIS SENSOR
£128
IPCAM165A
5MP BULLET IP CAMERA,
2.8-12MM,IR 50M,IP66
Camera sensor: 1/1.8’’ CMOS Sony EXMOR Starvis Technology
Camera optical zoom: 3x
Sensitivity (lux): 0 (B/W, led IR ON)
IR filter: Mechanical
Video resolution (H x V): 2592x1944 (5MP)
Video compression: H.264, H.265, MJPEG (Dual streaming, Dual
compression)
Main functions: Video Analytics, Privacy mask, Motion detection, Tampering
Video analytics: Counting, object stolen/abandoned, area detection
(object entering/leaving), virtual guard
No. IR LEDs / Max. distance (m): 2 led arrays / 50m
Support SD card (card not included): Micro-SD (64GB max)
DC supply voltage: 12V
POE power supply: Standard IEEE 802.3af
5MP MOTORIZED LENS
VIDEO ANALYSIS SONY STARVIS SENSOR
£234
FULL HD
6
IPCAM168A
FULL-HD VANDALDOME IP
CAMERA, 2.8-12MM, IR 15M,
IP65
£96
Camera sensor: 1/4’’ CMOS
Sensitivity (lux): 0 (led IR ON)
IR filter: Mechanical
Video trasmission: Dual streaming (H.264, MJPEG)
Video resolution (H x V): 1920x1080 (FULL-HD 1080p)
Video compression: H.264, MJPEG
Main functions: Privacy mask, Motion detection
No. IR LEDs / Lighting distance (m): 18 led / 15 m
DC supply voltage: 12Vdc
POE power supply: POE (802.3af)
FULL HD
IPCAM169A
FULL-HD VANDALDOME IP
CAMERA, 6-22MM, IR 15M,
IP65
Camera sensor: 1/2.8’’ CMOS Sony
Sensitivity (lux): 0 (led IR ON)
IR filter: Mechanical
Video trasmission: Dual streaming (H.264, MJPEG)
Video resolution (H x V): 1920x1080 (FULL-HD 1080p)
Video compression: H.264, MJPEG
Main functions: Privacy mask, Motion detection
No. IR LEDs / Lighting distance (m): 18 led / 15 m
DC supply voltage: 12V
POE power supply: Standard IEEE 802.3af
IPCAM1638A
IP BULLET CAMERA 3MP,
ZOOM 2.8-12MM, SMART IR
Camera sensor: 1/2.8’’ CMOS Sony EXMOR Starvis Progressive scan
Camera optical zoom: 3x
Sensitivity (lux): 0 (B/W, led IR ON)
IR filter: Mechanical
Video resolution (H x V): 2048x1536 (3MP)
Video compression: H.264, H.265, MJPEG (Dual streaming, Dual compression)
Main functions: Video Analytics, Privacy mask, Motion detection, Tampering
Video analytics: Counting, object stolen/abandoned, area detection
(object entering/leaving), virtual guard
No. IR LEDs / Max. distance (m): 15 led SMD / 30m (SMART IR)
Support SD card (card not included): Micro-SD (64GB max)
DC supply voltage: 12V
POE power supply: Standard IEEE 802.3af
VIDEO ANALYSIS
MOTORIZED LENS
WDR
£121
IPPT-1004W
CONNECTION BOX FOR MINIDOME
IPCAM168A, IPCAM169A, WHITE £10
Connection box, suitable for minidome cameras
art. IPCAM168A, IPCAM169A, IPCAM183A and
IPCAM185A, suitable for indoor use, white colour.
IPCAM185A
5MP MINIDOME IP CAMERA,
3.6-10MM, IR 30M, IP66
Camera sensor: 1/1.8’’ CMOS Sony EXMOR Starvis Technology
Camera optical zoom: 3x
Sensitivity (lux): 0 (B/W, led IR ON)
IR filter: Mechanical
Video resolution (H x V): 2592x1944 (5MP)
Video compression: H.264, H.265, MJPEG (Dual streaming, Dual compression)
Main functions: Video Analytics, Privacy mask, Motion detection, Tampering
Video analytics: Counting, object stolen/abandoned, area detection (object
entering/leaving), virtual guard
No. IR LEDs / Max. distance (m): 28 led / 30m
Support SD card (card not included): Micro-SD (64GB max)
DC supply voltage: 12V
POE power supply: Standard IEEE 802.3af
£202
IPCAM183A
3MP MINIDOME IP CAMERA,
2.8-12MM, IR 30M, IP66
Camera sensor: 1/2.8’’ CMOS Sony EXMOR Starvis Technology
Sensitivity (lux): 0 (B/W, led IR ON)
IR filter: Mechanical
Video resolution (H x V): 2048x1536 (3MP)
Video compression: H.264, H.265, MJPEG (Dual streaming, Dual compression)
Main functions: Video Analytics, Privacy mask, Motion detection, Tampering
Video analytics: Counting, object stolen/abandoned, area detection (object
entering/leaving), virtual guard
No. IR LEDs / Max. distance (m): 28 led / 30m
Support SD card (card not included): Micro-SD (64GB max)
DC supply voltage: 12V
POE power supply: Standard IEEE 802.3af
3MP
WDR
VANDALDOME IK10
£124
5MP
MOTORIZED LENS
VANDALDOME IK10
IP 100 SERIES
Passion.Technology.Design.
7
IP 100 SERIES
Camera sensor: 1/2.8’’ CMOS 2.13M Starvis
Camera lens: 4.7 - 94 mm
Camera optical zoom: 20x
Sensitivity (lux): 0.02 (colour) / 0 (B/W - led IR ON)
IR filter: Mechanical
Video compression: H264, MJPEG
Video resolution (H x V): 1920x1080 (FULL-HD 1080p)
Frame rate: 30 fps
Main functions: 255 Presets, 4 Tours, 4 Patterns, Defog, WDR,
3DNR, Motion detection, 8 privacy masks
No. IR LEDs / Lighting distance (m): 6 + 2 laser / 150 m
Alarm Input / Output: 2/1
Analogue video output: Yes
Support SD card (card not included): Micro-SD (32 GB max)
DC supply voltage: 24 V / POE IEEE 802.3at
Camera sensor: 1/2.8’’ CMOS 3.12M Starvis
Camera lens: 4.5 - 135 mm
Camera optical zoom: 30x
Sensitivity (lux): 0.05 (colour) / 0 (B/W - led IR ON)
IR filter: Mechanical
Video compression: H264, MJPEG
Video resolution (H x V): 2048x1536 (3MP)
Frame rate: 30 fps
Main functions: 255 Presets, 4 Tours, 4 Patterns, Defog,
WDR, 3DNR, Motion detection, 8 privacy masks
No. IR LEDs / Lighting distance (m): 6 + 2 laser / 150 m
Alarm Input / Output: 2/1
Analogue video output: Yes
Support SD card (card not included): Micro-SD (32 GB max)
DC supply voltage: 24 V / POE IEEE 802.3at
IPPTZ120IRD
IP PTZ FULL-HD CAMERA,
20X ZOOM, IR 150M, IP66
IPPTZ130IRB
CAMERA IP PTZ 3MP,
ZOOM 30X, IR 150M, IP66
IR 150M
IPPT-1201
POLE-MOUNTING ACCESSORY
FOR CAMERA ART. IPPTZ120IRD
AND IPPTZ130IRB
IPPT-1202
CORNER-MOUNTING ACCESSORY
FOR CAMERA ART. IPPTZ120IRD
AND IPPTZ130IRB
£501
£710
£24 £26 £42
IPPT-604
CEILING MOUNT BRACKET
ART. IPPTZ120IRD-130IRB
Wall mount bracket and power supply included
IPCAM1838A
IP MINIDOME CAMERA 3MP,
ZOOM 2.8-12MM, SMART IR
Camera sensor: 1/2.8’’ CMOS Sony EXMOR Starvis Progressive scan
Camera optical zoom: 3x
Sensitivity (lux): 0 (B/W, led IR ON)
IR filter: Mechanical
Video resolution (H x V): 2048x1536 (3MP)
Video compression: H.264, H.265, MJPEG (Dual streaming, Dual compression)
Main functions: Video Analytics, Privacy mask, Motion detection, Tampering
Video analytics: Counting, object stolen/abandoned, area detection (object entering/leaving), virtual guard
No. IR LEDs / Max. distance (m): 12 led SMD / 30m (SMART IR)
Support SD card (card not included): Micro-SD (64GB max)
DC supply voltage: 12V
POE power supply: Standard IEEE 802.3af
VIDEO ANALYSIS
MOTORIZED LENS
VANDALDOME IK10
WDR
Compatible only with IPNVR116D-xxx,
IPNVR125D-xxx AND IPNVR136D-xxx £135
FULL HD
ZOOM 20X
3MP
ZOOM 30X
IR 150M
Wall mount bracket and power supply included
8
IPNVR104EPOESL
NVR W/8 IP INPUTS, 5MP POE, NO HDD
Video inputs: 8 (4 PoE 3/5MP + 4 3/5MP)
Main video output: 1 (VGA), 1 (HDMI), 1920x1080@60Hz
Video compression: H.264
Main features: video analysis management (with dedicated cameras), dual password authentication,
instant playback
Operating system: Linux embedded
Protocols supported: HTTP, TCP/IP, UPnP, SMTP, DHCP, DDNS, Comelit DNS
Remote control via browser: Internet Explorer, Firefox, Chrome, Safari
Remote control by software: Comelit View 100
Remote control by mobile: app Comelit View 100 (Android, iOS)
Type of connections/ports: 2xUSB, 1xRS485, 4xEthernet 10/100Mbit/s PoE (IEEE 802.3af),
1xEthernet 10/100Mbit/s
UP TO 5MP IP AUTO CONFIGURATION
P2P
Comelit DNS
Camera sensor: 1/2.8’’ CMOS
Camera optical zoom: 10x
Sensitivity (lux): 0.06 (colour) / 0 (B/W - led IR ON)
IR filter: Mechanical
Video resolution (H x V): 1920x1080 (FULL-HD 1080p)
Video compression: H.264, MJPEG (Dual streaming)
Main functions: 255 Preset, 4 Tour, 4 Pattern, Home function
No. IR LEDs / Max. distance (m): 8 Smart IR leds / 80m
Wall support: Incluso
Support SD card (card not included): Micro-SD (32GB max)
DC supply voltage: 24V
POE power supply: IEEE802.3at
Sensitivity (lux): 0.06 (kleur) / 0 (Z/W, IR leds ON)
IPPTZ110IRA
CAMERA IP PTZ FULL-HD,
ZOOM 10X, IR 80M, IP66
£372 FULL-HD
IR 80M
IPPT-401
POLE-MOUNTING ACC. FOR
CAMERA ART. IPPTZ110IRA
£42
IPPT-402
CORNER-MOUNTING ACC. FOR
CAMERA ART. IPPTZ110IRA
£42
IPPT-403
FLUSH-MOUNTING ACC. FOR
CAMERA ART. IPPTZ110IRA
£46
Wall mount bracket and
power supply included
£92 NEW
IPNVR104EPOE-1TBW
NVR W/8 IP INPUTS, 5MP POE,
HDD 1TB WD PURPLE
£146
HDD 1TB
“WD PURPLE”
IPNVR104EPOE-2TBW
NVR W/8 IP INPUTS, 5MP POE,
HDD 2TB WD PURPLE
£181
HDD 2TB
“WD PURPLE”
IPNVR104EPOE-4TBW
NVR W/8 IP INPUTS, 5MP POE,
HDD 4TB WD PURPLE
£241
HDD 4TB
“WD PURPLE”
IPCAM167A
FULL-HD MINIDOME IP CAMERA,
3.6 MM, IR 15 M, IP65
£80
Camera sensor: 1/2.8’’ CMOS Sony 2.43MP
Sensitivity (lux): 0 (B/W, led IR ON)
IR filter: Mechanical
Video resolution (H x V): 1920x1080 (FULL-HD 1080p)
Video compression: H.264, MJPEG (Dual streaming)
Main functions: Privacy mask, Motion detection, tampering
No. IR LEDs / Max. distance (m): 36 led / 15m
DC supply voltage: 12V
POE power supply: Standard IEEE 802.3af
FULL HD
ZOOM 10X
IP 100 SERIES
Passion.Technology.Design.
9
IP 100 SERIES
IPNVR108DPOESL
NVR W/8 IP INPUTS, 5MP POE, NO HDD
Video inputs: 8 PoE (3MP/5MP)
Main video output: 1 (VGA), 1 (HDMI), 1920x1080@60Hz
Alarm inputs/output: 2/1
Video compression: H.264
Main features: video analysis management (with dedicated cameras), dual password
authentication, instant playback
Operating system: Linux embedded
Protocols supported: HTTP, TCP/IP, UPnP, SMTP, DHCP, DDNS, Comelit DNS
Remote control via browser: Internet Explorer, Firefox, Chrome, Safari
Remote control by software: Comelit View 100
Remote control by mobile: app Comelit View 100 (Android, iOS)
Type of connections/ports: 2xUSB, RS485, 8xEthernet 10/100Mbit/s PoE (IEEE 802.3af),
1xEthernet 10/100/1000Mbit/s
UP TO 5MP IP AUTO CONFIGURATION
P2P
Comelit DNS
£156 NEW
IPNVR108DPOE-2TBW
NVR W/8 IP INPUTS, 5MP POE,
HDD 2TB WD PURPLE
£242
HDD 2TB
“WD PURPLE”
IPNVR108DPOE-4TBW
NVR W/8 IP INPUTS, 5MP POE,
HDD 4TB WD PURPLE
£305
HDD 4TB
“WD PURPLE”
IPNVR108DPOE-8TBW
NVR W/8 IP INPUTS, 5MP POE,
HDD 8TB WD PURPLE
£455
HDD 8TB
“WD PURPLE”
IPNVR116DSL
NVR 16 IP INPUTS 5MP, NO HDD
Video inputs: 16 (FULL-HD / 3MP) / 9 (5MP) / 25 (HD)
Main video output: 1 (VGA), 1 (HDMI) - 1920x1080@60Hz, 1280x1024@60Hz
Alarm Inputs/Outputs: 4/1
Video compression: H.264, MJPEG / 16÷8000 kbps
Display / recording frame rate: 480 fps@5MP Real time
Installable hard drive: 2 x 4 TB max
Operating system: Linux embedded
Video analytics: Counting, object stolen/abandoned, area detection (object entering/
leaving), virtual guard
Protocols supported: HTTP, TCP/IP, UPnP, SMTP (SSL), DHCP, DDNS, PPPoE, NTP, P2P, RTSP,
Comelit DNS, ONVIF 2.2
Remote control via browser: Internet Explorer, Firefox, Chrome, Safari
Remote control by software: Comelit View 100
Remote control by mobile: app Comelit View 100 (Android, iOS)
Type of connections/ports: 2xUSB 2.0, USB 3.0, RS485, Ethernet 10/100/1000Mbit/s
AC supply voltage: 100÷240V / 50÷60Hz UP TO 5MP 4CH BACK-END VIDEO ANALYSIS
P2P
Comelit DNS
£125
IPNVR116D-2TBW
NVR 16 INPUTS IP 5MP,
HDD 2TB WD PURPLE
£214
HDD 2TB
“WD PURPLE”
IPNVR116D-4TBW
NVR 16 INPUTS IP 5MP,
HDD 4TB WD PURPLE
£274
HDD 4TB
“WD PURPLE”
IPNVR116D-8TBW
NVR 16 INPUTS IP 5MP,
HDD 8TB WD PURPLE
£423
HDD 8TB
“WD PURPLE”
10
IPNVR136DSL
NVR 36 IP INPUTS, 4K, NO HDD
Video inputs: 36 (4K / 5MP / 3MP / FULL-HD / HD)
Main video output: 1 (VGA), 1 (HDMI) - 3840x2160@30Hz, 1920x1080@60Hz, 1280x1024@60Hz
Alarm Inputs/Outputs: 4/4
Video compression: H.264, H.265 (High Profile@Level 4.2) / 16÷8000 kbps
Display / recording frame rate: 1080 fps@4K Real time
Installable hard drive: 8 x 6 TB max
Operating system: Linux embedded
Video analytics: Counting, object stolen/abandoned, area detection (object entering/leaving), virtual guard
Protocols supported: HTTP, TCP/IP, UPnP, SMTP (SSL), DHCP, DDNS, PPPoE, NTP, P2P, RTSP, Comelit DNS, ONVIF 2.2
Remote control via browser: Internet Explorer, Firefox, Chrome, Safari
Remote control by software: Comelit View 100
Remote control by mobile: app Comelit View 100 (Android, iOS)
Type of connections/ports: 2xUSB 2.0, USB 3.0, RS485, 2xEthernet 10/100/1000Mbit/s, eSATA
AC supply voltage: 100÷240V, 47÷63Hz
UP TO 4K 8CH BACK-END VIDEO ANALYSIS
P2P
Comelit DNS
£420
IPNVR136D-2TBW
NVR 36 IP INPUTS, 4K,
HDD 2TB WD PURPLE
£507
IPNVR136D-4TBW
NVR 36 IP INPUTS, 4K,
HDD 4TB WD PURPLE
£570
IPNVR136D-8TBW
NVR 36 IP INPUTS, 4K,
HDD 8TB WD PURPLE
£719
IPNVR136D-12TBW
NVR 36 IP INPUTS, 4K,
HDD 12TB WD PURPLE
£868
HDD 12TB “WD PURPLE”
IPNVR136D-16TBW
NVR 36 IP INPUTS, 4K,
HDD 16TB WD PURPLE
£1018
IPNVR136D-32TBW
NVR 36 IP INPUTS, 4K,
HDD 32TB WD PURPLE
£1615
HDD 16TB “WD PURPLE” HDD 32TB “WD PURPLE”
HDD 2TB “WD PURPLE” HDD 4TB “WD PURPLE” HDD 8TB “WD PURPLE”
IP 100 SERIES
Passion.Technology.Design.
11
IP 100 SERIES
IPNVR164DSL
NVR W/64 4K IP INPUTS, NO HDD
Video inputs: 64 (4K)
Main video output: 1 (VGA), 1 (HDMI), 3840 X 2160 (4k)
Alarm inputs/outputs: 4/4
Video compression: H.264, H.265
Main features: video analysis management (8 local + 56 with dedicated cameras), RAID (0, 1, 5, 6, 10), dual password, HDD grouping,
instant playback
Video analysis:target counting, object left/removed, enter area, line crosssing
Operating system: Linux embedded
Protocols supported: HTTP, TCP/IP, UPnP, SMTP, DHCP, DDNS, Comelit DNS
Remote control via browser: Internet Explorer, Firefox, Chrome, Safari
Remote control by software: Comelit View 100
Remote control by mobile: app Comelit View 100 (Android, iOS)
Type of connections/ports: 2xUSB 2.0, USB 3.0, RS485, 2xEthernet 10/100/1000Mbit/s, eSATA
AC supply voltage: 100÷240V, 50÷60Hz
UP TO 4K 4CH BACK-END VIDEO ANALYSIS
P2P
Comelit DNS
£511
NEW
IPNVR164D-4TBW
NVR W/64 4K IP
INPUTS, HDD 4TB
WD PURPLE
£660
IPNVR164D-8TBW
NVR W/64 4K IP
INPUTS,HDD 8TB
WD PURPLE
£809
IPNVR164D-12TBW
NVR W/64 4K IP
INPUTS, HDD 12TB
WD PURPLE
£959
HDD 12TB “WD PURPLE”
IPNVR164D-16TBW
NVR W/64 4K IP
INPUTS, HDD 16TB
WD PURPLE
£1108
IPNVR164D-32TBW
NVR W/64 4K IP
INPUTS, HDD 32TB
WD PURPLE
£1705
HDD 16TB “WD PURPLE” HDD 32TB “WD PURPLE”
HDD 4TB “WD PURPLE”
HDD 8TB “WD PURPLE”
IPNVR128DSL
NVR W/128 4K IP INPUTS NO HDD
Video inputs: 128 (4K)
Main video output: 1 (VGA), 1 (HDMI), 3840 X 2160 (4k)
Alarm inputs/outputs: 4/4
Video compression: H.264, H.265
Main features: video analysis management (8 local + 56 with dedicated cameras),
RAID (0, 1, 5, 6, 10), dual password, HDD grouping, instant playback
Video analysis:target counting, object left/removed, enter area, line crosssing
Operating system: Linux embedded
Protocols supported: HTTP, TCP/IP, UPnP, SMTP, DHCP, DDNS, Comelit DNS
Remote control via browser: Internet Explorer, Firefox, Chrome, Safari
Remote control by software: Comelit View 100
Remote control by mobile: app Comelit View 100 (Android, iOS)
Type of connections/ports: 2xUSB 2.0, USB 3.0, RS485, 2xEthernet
10/100/1000Mbit/s, eSATA
AC supply voltage: 100÷240V, 50÷60Hz
£1138
NEW
Please contact Sales for storage options up to 96TB
12
IPSWP080A
NETWORK SWITCH, GIGABIT, 8
PORTS POE
IP ACCESSORIES
IPSWP050A
NETWORK SWITCH, GIGABIT, 5
PORTS (4 POE)
IPSWC080A
NETWORK SWITCH, GIGABIT, 8
PORTS
IPSWP160A
NETWORK SWITCH, GIGABIT,
16 PORTS POE
£68
£23
£101
£171
IPSWC160A
NETWORK SWITCH, GIGABIT,
16 PORTS
£61
Network switch with 5 gigabit ports (4 PoE), max 26W per port, max 75W total.
Network switch with 8 gigabit PoE ports, max 30W per port, max 150W total.
Network switch with 16 PoE gigabit ports, max 30W per port, max 260W total.
Network switch with 16 gigabit ports.
Network switch with 8 gigabit ports. Power supply in equipment.
Passion.Technology.Design.
13
HD ANALOGUE SYSTEM - AHD
Video inputs: 32 (AHD/TVI 720p/960p, IP 1080p, CVBS 960H)
Main video output: 1 (VGA - 1920x1080@60Hz), 1 (HDMI - 4K@30Hz)
Alarm Inputs/Outputs: 4/1
Video compression: H.264
Display / recording frame rate: 480fps@(AHD/TVI 720p, CVBS 960H, IP Easy FULL-HD)
Hard disk capacity supplied: 2TB (6TB max)
Additional Hard Disks (SATA): 1 (6TB max)
Operating system: Linux embedded
Protocols supported: TCP/IP, PPPoE, DHCP, DDNS, P2P, Comelit DNS
Remote control via browser: Internet Explorer, Firefox, Chrome
Remote control by software: Comelit CMS
Remote control by mobile: APP Comelit View S (Android, iOS)
Type of connections/ports: 1xRS485, 2xUSB 2.0, 1xEthernet 10/100/1000 Mbit/s
AC supply voltage: 100÷240V / 50÷60Hz
AHDVR0320A
4-HYBRID DVR, 32 HD
INPUTS, 480 IPS, 2TB HDD
£305 ANALOGUE HD
HDD 2TB
4-HYBRID (AHD, TVI,
ANALOGUE, IP EASY)
P2P
Comelit DNS
AHCAM608B
FULL-HD BULLET AHD CAMERA,
3.6MM, IR 25M, IP66
ANALOGUE FULL HD
Camera sensor: 1/2.8” CMOS Sony
Sensitivity (lux): 0.01 (colour) / 0 (B/W, led IR ON)
IR filter: Mechanical
Video output: AHD / CVBS (960H)
Video resolution (H x V): 1920x1080 (FULL-HD 1080p)
Main functions: Sense-Up, Defog
No. IR LEDs / Max. distance (m): 30 led / 25m
DC supply voltage: 12V
£29
AHCAM618B
FULL-HD BULLET AHD CAMERA,
2.8-12MM, IR 30M, IP66
Camera sensor: 1/2.8’’ CMOS Sony
Sensitivity (lux): 0.01 (colour) / 0 (B/W, led IR ON)
IR filter: Mechanical
Video output: AHD / CVBS (960H)
Video resolution (H x V): 1920x1080 (FULL-HD 1080p)
Main functions: OSD menu, Sense-Up, Defog
No. IR LEDs / Max. distance (m): 36 led / 30m
DC supply voltage: 12V
£42
AHCAM628B
FULL-HD MINDOME AHD CAMERA,
3.6MM, IR 20M, IP66
Camera sensor: 1/2.8’’ CMOS Sony
Sensitivity (lux): 0.01 (colour) / 0 (B/W, led IR ON)
IR filter: Mechanical
Video output: AHD / CVBS (960H)
Video resolution (H x V): 1920x1080 (FULL-HD 1080p)
Main functions: OSD menu, Sense-Up, Defog
No. IR LEDs / Max. distance (m): 24 led / 20m
DC supply voltage: 12V
AHCAM638B also available in grey colour - AHCAM638A/G
FULL-HD MINIDOME AHD CAMERA,
2.8-12MM, IR 30M, IP66
Camera sensor: 1/2.8’’ CMOS Sony
Sensitivity (lux): 0.01 (colour) / 0 (B/W, led IR ON)
IR filter: Mechanical
Video output: AHD / CVBS (960H)
Video resolution (H x V): 1920x1080 (FULL-HD 1080p)
Main functions: OSD menu, Sense-Up, Defog
No. IR LEDs / Max. distance (m): 36 leds / 30m
DC supply voltage: 12V
AHCAM638ZA
FULL-HD MINIDOME AHD CAMERA,
MOT. ZOOM 2.8-12MM
Camera sensor: 1/2.8’’ CMOS Sony
Sensitivity (lux): 0.05 (colour) / 0 (B/W, led IR ON)
IR filter: Mechanical
Video output: AHD / TVI / CVI / CVBS (960H)
Video resolution (H x V): 1920x1080 (FULL-HD 1080p)
Main functions: OSD menu, Sense-Up, Defog, UTC control
No. IR LEDs / Max. distance (m): 36 led / 30m
DC supply voltage: 12V
AHCAM618ZA
FULL-HD BULLET AHD CAMERA,
MOT.ZOOM 2.8-12MM, IR
Camera sensor: 1/2.8’’ CMOS Sony
Sensitivity (lux): 0.05 (colour) / 0 (B/W, led IR ON)
IR filter: Mechanical
Video output: AHD / TVI / CVI / CVBS (960H)
Video resolution (H x V): 1920x1080 (FULL-HD 1080p)
Main functions: OSD menu, Sense-Up, Defog, UTC control
No. IR LEDs / Max. distance (m): 36 led / 30m
DC supply voltage: 12V
£57 £61
ANALOGUE FULL HD
ANALOGUE FULL HD
MOTORIZED ZOOM AND
AUTOFOCUS
ANALOGUE FULL HD
£28
ANALOGUE FULL HD
£43
ANALOGUE FULL HD
MOTORIZED ZOOM AND
AUTOFOCUS
14
AHCAM633A
AHD VANDALDOME FULL-HD
CAMERA,6-22MM,IR 15M, IP66
Camera sensor: 1/2.8’’ CMOS Sony
Sensitivity (lux): 0.05 (colour) / 0 (B/W, led IR ON)
IR filter: Mechanical
Video output: AHD / TVI / CVI / CVBS (960H)
Video resolution (H x V): 1920x1080 (FULL-HD 1080p)
Main functions: OSD menu, Sense-Up, Defog
No. IR LEDs / Max. distance (m): 18 led / 15m
DC supply voltage: 12VDC
£64
ANALOGUE FULL HD
VANDALDOME IK10
MBRK631C
WALL-MOUNTING ACCESSORY FOR CAMERA
AHCAM631A AND AHCAM633A £11
AHCAM638AWDR
AHD FULL-HD MINIDOME CAMERA,
2.8-12MM WDR
Camera sensor: 1/2.8” CMOS Sony Starvis 2.13MP
Lens: varifocal 2.8-12mm
Video output: AHD/TVI/CVI CVBS (960H)
Video resolution (H x V): 1920x1080 (FULL-HD 1080p)
Sensitivity (lux): 0.0001 (colour) / 0 (B/W, led IR ON)
IR filter: Mechanical
Main functions: OSD menu, BLC, WDR (120dB), 3DNR
No. IR LEDs / Max. distance (m): 24 leds SMD / 35m
DC supply voltage: 12V
£49
ANALOGUE FULL HD
NEW
AHPTZ10IRB
FULL-HD PTZ AHD CAMERA,
10X ZOOM, IR 50M, IP66
Camera sensor: 1/3’’ CMOS Sony
Camera optical zoom: 10x
Sensitivity (lux): 0.1 (colour) / 0 (B/W, led IR ON)
IR filter: Mechanical
Video output: AHD
Video resolution (H x V): 1920x1080 (FULL-HD 1080p)
Main functions: 220 Preset, 3 Tour, Scan
No. IR LEDs / Max. distance (m): 6 Led array / 50m
DC supply voltage: 12V
£265
ANALOGUE FULL HD ZOOM 10X IR 50M
Wall mount bracket and power supply included
AHPT-1001B
CEILING-MOUNTING BRACKET FOR CAMERA ART. AHPTZ10IRB £29
Ceiling bracket for dome cameras art. AHPTZ10IR.
HD ANALOGUE SYSTEM - AHD
Passion.Technology.Design.
15
HD ANALOGUE SYSTEM - AHD
AHCAM619ZA
AHD BULLET CAMERA 3MP,
ZOOM 2.8-12MM, IR 35M
ANALOGUE 3MP
MOTORIZED ZOOM AND AUTOFOCUS
Camera sensor: 1/3” CMOS
Sensitivity (lux): 0.01 (colour) / 0 (B/W, led IR ON)
IR filter: Mechanical
Video output: AHD / TVI / CVI / CVBS (960H)
Video resolution (H x V): AHD/TVI (3MP - 1536p) / CVI
(FULL-HD 1080p)
Main functions: OSD menu, UTC control
No. IR LEDs / Max. distance (m): 24 led SMD / 35m
DC supply voltage: 12V
£59
AHCAM639ZA
AHD MINIDOME CAMERA 3MP,
ZOOM 2.8-12MM, IR 35M
Camera sensor: 1/3”” CMOS
Sensitivity (lux): 0.01 (colour) / 0 (B/W, led IR ON)
IR filter: Mechanical
Video output: AHD / TVI / CVI / CVBS (960H)
Video resolution (H x V): AHD/TVI (3MP - 1536p) / CVI
(FULL-HD 1080p)
Main functions: OSD menu, Sense-Up, Defog, UTC control
No. IR LEDs / Max. distance (m): 24 led SMD / 35m
DC supply voltage: 12V” £63
AHCAM609A
AHD BULLET CAMERA 3MP,
3.6MM, IR 25M, IP66
ANALOGUE 3MP
Camera sensor: 1/3” CMOS
Sensitivity (lux): 0.01 (colour) / 0 (B/W, led IR ON)
IR filter: Mechanical
Video output: AHD / TVI / CVI / CVBS (960H)
Video resolution (H x V): AHD/TVI (3MP - 1536p) / CVI
(FULL-HD 1080p)
Main functions: OSD menu, UTC control
No. IR LEDs / Max. distance (m): 18 led SMD / 25m
DC supply voltage: 12V £29
AHCAM629A
AHD MINIDOME CAMERA 3MP,
3.6MM, IR 25M, IP66
ANALOGUE 3MP
Camera sensor: 1/3” CMOS
Sensitivity (lux): 0.01 (colour) / 0 (B/W, led IR ON)
IR filter: Mechanical
Video output: AHD / TVI / CVI / CVBS (960H)
Video resolution (H x V): AHD/TVI (3MP - 1536p) / CVI
(FULL-HD 1080p)
Main functions: OSD menu, Sense-Up, Defog
No. IR LEDs / Max. distance (m): 18 led SMD / 25m
DC supply voltage: 12V £30
ANALOGUE 3MP
MOTORIZED ZOOM AND AUTOFOCUS
16
AHDVR043ASL
5-HYBRID DVR, 4 3MP INPUTS, NO HDD
ANALOGUE 3MP 5-HYBRID (AHD, TVI, CVI,
ANALOGUE, IP EASY)
£72 P2P
Comelit DNS
Video inputs: 4 (AHD/TVI 3MP, CVI/IP 1080p, CVBS 960H)
Main video output: 1 (VGA), 1 (HDMI), 1920x1080 @ 60Hz
Video compression: H.264
Recording frame rate: 48fps@3MP-FULL-HD, 100fps@HD
Alarm Inputs/Outputs: 4/1
Installable hard drive: 1 x 4TB max
Operating system: Linux embedded
Protocols supported: TCP/IP, PPPoE, DHCP, DDNS, P2P, Comelit DNS
Remote control via browser: Internet Explorer, Firefox, Chrome
Remote control by software: Comelit CMS
Remote control by mobile: APP Comelit View S (Android, iOS)
Type of connections/ports: 1xRS485, 2xUSB 2.0, 1xEthernet 10/100Mbit/s
AC supply voltage: 100÷240V / 50÷60Hz
NEW
AHDVR043A-1TBW
£127
HDD 1TB
“WD PURPLE”
AHDVR043A-2TBW
£161
HDD 2TB
“WD PURPLE”
AHDVR043A-4TBW
£221
HDD 4TB
“WD PURPLE”
AHDVR083ASL
5-HYBRID DVR, 8 3MP INPUTS, NO HDD
£112
Video inputs: 8 (AHD/TVI 3MP, CVI/IP 1080p, CVBS 960H)
Main video output: 1 (VGA), 1 (HDMI), 1920x1080 @ 60Hz
Video compression: H.264
Recording frame rate: 96fps@3MP/FULL-HD, 200fps@HD
Alarm Inputs/Outputs: 4/1
Operating system: Linux embedded
Installable hard drive: 1 x 4TB max
Protocols supported: TCP/IP, PPPoE, DHCP, DDNS, P2P, Comelit DNS
Remote control via browser: Internet Explorer, Firefox, Chrome
Remote control by software: Comelit CMS
Remote control by mobile: APP Comelit View S (Android, iOS)
Type of connections/ports: 1xRS485, 2xUSB 2.0, 1xEthernet 10/100Mbit/s
AC supply voltage: 100÷240V / 50÷60Hz
AHDVR163ASL
5-HYBRID DVR, 16 3MP INPUTS, NO HDD
£199
Video inputs: 16 (AHD/TVI 3MP, CVI/IP 1080p, CVBS 960H)
Main video output: 1 (VGA), 1 (HDMI), 1920x1080 @ 60Hz
Video compression: H.264
Recording frame rate: 192fps@3MP, 240fps@FULL-HD, 400fps@HD
Alarm Inputs/Outputs: 4/1
Installable hard drive: 2 x 4TB max
Operating system: Linux embedded
Protocols supported: TCP/IP, PPPoE, DHCP, DDNS, P2P, Comelit DNS
Remote control via browser: Internet Explorer, Firefox, Chrome
Remote control by software: Comelit CMS
Remote control by mobile: APP Comelit View S (Android, iOS)
Type of connections/ports: 1xRS485, 2xUSB 2.0, 1xEthernet 10/100/1000Mbit/s
AC supply voltage: 100÷240V / 50÷60Hz
AHDVR083A-1TBW
£162
HDD 1TB
“WD PURPLE”
AHDVR083A-2TBW
£196
HDD 2TB
“WD PURPLE”
AHDVR083A-4TBW
£261
HDD 4TB
“WD PURPLE”
AHDVR163A-2TBW
£273
HDD 2TB
“WD PURPLE”
AHDVR163A-4TBW
£348
HDD 4TB
“WD PURPLE”
AHDVR163A-8TBW
£498
HDD 8TB
“WD PURPLE”
ANALOGUE 3MP 5-HYBRID (AHD, TVI, CVI,
ANALOGUE, IP EASY)
P2P
Comelit DNS
ANALOGUE 3MP 5-HYBRID (AHD, TVI, CVI,
ANALOGUE, IP EASY)
P2P
Comelit DNS
HD ANALOGUE SYSTEM - AHD
Passion.Technology.Design.
17
ACCESSORIES
JB-01W
ANALOGUE AHD MINIDOME SMALL
CONNECTION BOX, WHITE COLOUR
JB-01G
ANALOGUE AHD MINIDOME SMALL
CONNECTION BOX, GREY COLOUR
JB-02G
ANALOGUE AHD MINIDOME LARGE
CONNECTION BOX, GREY COLOUR
£5
Not waterproof £8
Not waterproof
43082UK
POWER SUPPLY, JACK CONN.,
OUTPUT 12VDC/1.5A, UK
PLUG
£6
JB-02W
ANALOGUE AHD MINIDOME LARGE
CONNECTION BOX, WHITE COLOUR
CONAL01A
POWER SUPPLY CONNECTOR.
MALE JACK TERMINAL
£2
CONAL02A
POWER SUPPLY CONNECTOR.
FEMALE JACK TERMINAL
£2
Suitable for AHCAM628B and AHCAM629A Suitable for AHCAM638B-638A/G, AHCAM638ZA and AHCAM639ZA
JB-100BB
CONNECTION BOX FOR IPCAM161B-162A-163A-165A
JB-100MB
CONNECTION BOX FOR IPCAM101C-102B-1638A
JB-100MD
CONNECTION BOX FOR IPCAM166C-167A
JB-100SMD
CONNECTION BOX FOR IPCAM1838A
£10
£ 8Not waterproof
JB-04W
START AHD BULLET CONNECTION BOX, GREY
Suitable for SCAM118A, SCAM618A, AHCAM617A, AHCAM617B, AHCAM617C,
AHCAM618A, AHCAM618B, AHCAM618ZA and AHCAM619ZA £12
Not waterproof
NEW
PSU-20A18PUK
12V DC 20AMP 240W
18 PORT METAL BOX
PSU
PSU-5A4PUK
12V DC 5AMP 60W
4 PORT METAL BOX
PSU
PSU-10A9PUK
12V DC 10AMP 120W
9 PORT METAL BOX
PSU
£29 £34 £45
Until stock last
18
Video tester for analogue signal, AHD/TVI (720p/1080p), UTP cables
and RS485 serial (Pelco-P and Pelco-D protocol). 3.5” LCD screen,
resolution 960 x 240. Video pattern generator, 12Vdc/1A output for
camera power supply, battery life 8 hours. 9 Vdc/2A power supply
unit supplied. Dimensions (W x H x D): 105 x 188 x 44 mm.
WD20PURX
WD PURPLE
2TB 3.5” SATA
SURVEILLANCE
HD
VIDEOTEST
LCD TESTER FOR ANALOGUE AND AHD VIDEO, RS485
£134
MMON215A
21,5” LED-MONITOR, VGA,
HDMI, AUDIO, FULL-HD
Type of display: 21.5’’ led
Video inputs: 1(VGA), 1(HDMI)
Resolution: FULL-HD
Display brightness (cd/m2): 250
Type of display: 18.5'' led
Video inputs: 1(VGA), 1(BNC+1loop), 1(HDMI), 1(S-Video)
Resolution: HD
Display brightness (cd/m2): 250
SMON156A
15,6” LED-MONITOR, VGA,
AUDIO, HD
Type of display: 15.6’’ LED
Video inputs: 1 (VGA)
Resolution: HD
Display brightness (cd/m2): 220
HD
HD
MMON185A
18,5” LED-MONITOR, VGA,
BNC, HDMI, AUDIO, HD
Type of display: 18.5’’ led
Video inputs: 1(VGA), 1(BNC+1loop), 1(HDMI), 1(S-Video)
Resolution: HD
Display brightness (cd/m2): 250
FULL HD
HD
Framing ratio: 16:9
Displayable colours (million): 16.7
Audio inputs/outputs: 1/2 (speakers, 2 W)
AC supply voltage: 100÷240 V 50÷60 Hz
NEW
SMON185B
18,5” LED-MONITOR, VGA,
AUDIO, HD
£87 £119 £150 £240
WD30PURX
WD PURPLE
3TB 3.5” SATA
SURVEILLANCE
HD
WD40PURX
WD PURPLE
4TB 3.5” SATA
SURVEILLANCE
HD
WD60PURX
WD PURPLE
6TB 3.5” SATA
SURVEILLANCE
HD
£74
£106 £147 £142
Until stock last
ACCESSORIES
BNC
Passion.Technology.Design.
19
Passion.Technology.Design.
TRADE PRICES VALID FROM 1st SEPTEMBER TO 31st DECEMBER 2017
Products NOW Ex Stock - This oer is valid only for products available on stock. Trade prices are in Pounds, Net, excluding VAT and valid
for security trade customers only. Information is subject to change without notice.
COMELIT
BIGPROMO
Comelit Group UK Ltd
Unit 4 Mallow Park Welwyn - Garden City Herts AL7 1GX - UNITED KINGDOM
T: +44 01707377203 - F: +44 01707377204
Technical help and advice 01707 339888
www.comelitgroup.co.uk - cctv@comelitgroup.co.uk
cod.
2G36000347
UNITED STATES
OF AMERICA
COLOMBIA
GERMANY
BELGIUM
GREECE
REPUBLIC OF
SINGAPORE
AUSTRALIA
FRANCE
SPAIN
GREAT BRITAIN
UNITED ARAB
EMIRATES
RUSSIA
THE NETHERLANDS
IRELAND
Passion.Technology.Design. HONG KONG
[ IT ] Comelit Group Spa
Via Don Arrigoni 5
24020 Rovetta S. Lorenzo
Bergamo Italy
Tel. +39 (0) 346 750011
Fax +39 (0) 346 71436
www.comelitgroup.com
info@comelit.it
[ AU ] Comelit Australia Pty Ltd
Unit 6/11 Sabre Drive
Port Melbourne
Victoria 3207
Ph. 1300 889000
enquiries@comelitgroup.com.au
[ BE ] Comelit Group Belgium
Kleinewinkellan 24
1853 Grimbergen
Belgium
Tel. +32 2 411 50 99
Fax. +32 2 411 50 97
www.comelit.be
info@comelit.be
[ CO ] Comelit Colombia
Carrera 76#73-44, 2° piso
Bogotá, Colombia
Tel. (57-1) 4929358/79686
james.quimbaya@comelit.it
www.comelit.com.co
[ DE ] Comelit Group S.p.A.
Deutschland
Konrad-Zuse-Str. 2
41516 Grevenbroich
Tel. 0 21 82-82 96-0
Fax: 0 21 82-82 96-299
www.comelit.de
info@comelit.de
[ ES ] Comelit Group Spa
Sucursal en Espana
Calle Pintor Roig i Soler, 28
08916 - Badalona (Barcelona)
Tel. +34 932 430 376
Fax +34 934 084 683
www.comelit.es
info@comelit.es
[ FR ] Comelit Immotec
18, rue Séjourné
94000 CRETEIL CEDEX
Tél. +33 (0) 1 43 53 97 97
Fax +33 (0) 1 43 53 97 87
www.comelit.fr
contact@comelit-immotec.fr
[ GR ] Comelit Hellas
Telergo Security Ltd
Roumelis, 59
16451 Argiroupoli - Athens Greece
Tel. +30 210 99 68 605-6
Fax +30 210 99 45 560
www.comelit.gr
telergo@otenet.gr
[ IE ] Comelit Ireland
Ground Floor
14 Herbert Street - Dublin 2
Tel. +353 (0) 1 619 0204
Fax +353 (0) 1 619 0298
www.comelit.ie
info@comelit.ie
[ NL ] Comelit Nederland BV
Buitendijks 1-3356 LX
Papendrecht
Tel. +31 786511201
Fax +31 786170955
www.comelit.nl
info@comelit.nl
[ SG ] Comelit South East Asia Pte Ltd
Victory Centre
110 Lorong 23 Geylang, #05-10
388410 Singapore
Tel. +6567024780
www.comelit.sg
oce@comelit.sg
[ AE ] Comelit Middle East
Oce 1-154, Techno Hub
Dubai Silicon Oasis
Free zone - Dubai, UAE
www.comelit.ae
info@comelit.ae
[ GB ] Comelit Group UK Ltd
Unit 4 Mallow Park Watchmead
Welwyn Garden City Herts
AL7 1GX
Tel: +44 (0)1707377203
Fax: +44 (0)1707377204
www.comelitgroup.co.uk
info@comelitgroup.co.uk
[ US ] Comelit Usa
2021 S. Myrtle Avenue
Monrovia, CA 91016
Tel. +1 626 930 0388
Fax +1 626 930 0488
www.comelitusa.com
sales@comelitusa.com
[ RU ] Comelit Group Russia
Moscow,
Krasnogvardeisliy bulvar, 7A
tel: +7(495)789-49-33
www.comelit.ru
mail: tsn@comelit.ru
mail: info@comelit.ru
[ HK ] Comelit Hong Kong
Representative Oce
Rm 601, 6/F, Tung Hip
Commercial Building,
248 Dex Voeux Road Central,
Oce direct line:
+852 3582 1632
www.comelit.hk
info@comelit.hk
