2 WIRE NON-POLARISED SYSTEM

STYLE AND INNOVATION

2 wire system

ideas, technology, experience,

yesterday and today

* Extension is the sum of all cabled segments both in apartment and in riser column to the entry panel.

When using multicolour cables, NEVER short-circuit several conductors to increase the wire cross-section area.

Btwin is designed with installers in mind and styled according to modern market expectations it enables the

installation of a top-class system with state of the art functions in an easy way using only two wires throughout,

from entry panel to apartment handset. By taking advantage of the new innovations and technology in its

design a fully operational system of up to 4096 users can be installed more easily and in less time than ever

before. The system is easily set up using dip switch programming and includes intercom function and cycle

control for two cameras as standard with no other modules required.

System replacement using Btwin becomes easy without the need to replace wiring and a full range of monitors

and handsets are available to compliment any installation.

These are only some of the advantages of this system which brings a new era to the door entry market,

giving flexible solutions it is ideal for applications spanning from villas and apartment blocks, to residential

MT BETWEEN

2 wire system

ideas, technology, experience,

yesterday and today

System architecture using Btwin cable or Cat

TWO NON-POLARISED WIRES. THROUGHOUT.

All devices are connected using only two wires, including the entry panel.

FOR INSTALLERS, FOR THEIR CUSTOMERS.

Btwin is designed for installers: simple, rapid installation for making even complex systems with guaranteed

success. Top-notch satisfaction also for end users: Btwin provides the comfort of modern functional needs and

a wide assortment of apartment stations and entry panels.

Quick and easy installation, for new and modernisation projects

In Btwin, everything is studied to make the installer’s job easy. In modernisations, the advantages are truly

surprising: no wires need to be replaced to install Btwin. Using the existing wires, the system is updated and

and large residential compounds alike.

Only three components, many combinations

Only three components form the heart of the system: these components are enough to make a basic system

with standard colour camera and freeintercom function. All with only two wires.

Maximum result, certain guarantee

Reliable, simple: no mistakes are possible. Furthermore, the system guarantees service continuity even in case

of short-circuits. The branch protections make sure the column keeps on working. A great advantage for users!

Quick maintenance

Quick system management: all operations must be carried out with the system live. The short-circuit block

delimits the faulty area so that it can be promptly identified.

2 wire system

ideas, technology, experience,

yesterday and today

ideal monitor for the system Btwin: all the advanced features of this integrated video door entry system can be

controlled directly from a simple display with icons guide every step.

Videophone speakerphone black and

• Metal plate black or absolute white

• Display 3.5 "backlit colour

• Flush Mounting

• Removable terminal blocks

• Frame supplied

• Dimensions (W x H x D) 160 x 190 x 10mm

• Display

• DISPLAY MUTE CALL CONNECTED (green LED)

• AUTOMATIC DOOR RELEASE STATEMENT ON

(green LED)

• MESSAGES INDICATOR (green LED)

• MENU BUTTON

• DOOR OPEN INDICATION OR LACK OF

REPORTING ON (RED LED)

• BUTTON ON / OFF VOICE

• BUTTON RELEASE
