Checkstand Service Parts

& Accessories Catalog

January 2012

From our President

2 www.panoston.com

Thank you for your interest in our growing company. For over 40 years we have consistently delivered

a long line of innovative, superior quality and high value American made checkout and display

solutions to the grocery industry. Pan-Oston has the experience and expertise to deliver on your metal

or wood front-end or display needs better than anyone else.

With our standard checkout lanes we have a lane to fit any budget. Our Reddy lanes are our best value

line and our Vantage lanes offer more options for you to choose from. Our Ergolane is leading the

industry in terms of performance, features, aesthetics and represents our commitment to a “green”

environment. We also have a very long history of providing our clients with made-to-order solutions

throughout their stores.

Within in this catalog, you will find parts to keep your lanes running smoothly and accessories to

improve the checkout experience for your customers and employees.

With practical and traditional items, Pan-Oston also brings you checkout innovation. Utopia is

the only “Plug and Go” self-checkout solution that is affordable, allows you to use your existing

peripherals works seamlessly with 98% of POS software. Utopia self-checkout provides your

customers with greater convenience and speed of service and delivers significant labor and margin

improvements to your store.

We also offer high quality and good value display solutions for tobacco, beer and wine, bakery,

deli, floral and books/magazines as well as checkout display racks and an unsurpassable array

of food service equipment and small ware products.

If you are looking for solutions for a single store or multiple stores that will increase customer

satisfaction, efficiency and revenue, please give us a call and see why Pan-Oston is the one-stop

grocery store outfitter.

Best Regards,

Jim Vance

President

800.569.5742 3

Our History

Pan-Oston has been an industry leader in the design and manufacture of smart and innovative wood and metal retail

counter and checkout solutions for over 40 years. Recently, the company has received rave reviews for it’s smart and

simple self-checkout technology solution designed for independent grocers and C-Stores that is considered by many

to be “best in the world.”

Pan-Oston prides itself on developing superbly engineered, premier quality, high value, long lasting and ‘Made in

America’ products that are LEED compatible and truly solve problems for their customers while enhancing the overall

shopping experience.

1968 Subsidiary of Halton, OY, a Finnish manufacturer introduces checkout/counter products to North

American markets.

1978 North American production began in Peterborough, Canada.

1988 Glasgow, KY plant expands to accommodate growing demand for Pan-Oston products and services.

1992 Glasgow, KY plant expansion to meet increased demand.

2002 Pan-Oston acquired by Houchens Industries, Inc. of Bowling Green, KY, one of the largest ESOP

companies in the United States.

2005 RelocatedGlasgowmanufacturingplanttonewstate-of-theart200,000squarefootgreenmanufacturing

facility and Corporate O ce in Bowling Green, KY. Among the many green features used in the翿

facility is the latest in powder paint technology.

2005 Acquisition of 75,000 square foot wood fixture and millwork facility in Hiram, Ga. that had state-of-

the-art CNC wood manufacturing and edge banding equipment.

2006 Expanded Bowling Green facility by an additional 100,000 square feet and acquired our first automated

Salvagnini metal machining and bending equipment. Began development of the patent pending Utopia

Self-Checkout and C-Flex family of products.

2008 Introduced Reddy, Vantage, Ergolane, C-Series, C-Flexand Utopiacatalog brands.

2009 Relocated Hiram, GA plant to Bowling Green expanding product and service value.

2009 Expanded Bowling Green operations with a 5,000 square feet dedicated “clean and controlled”

Electronic Assembly Area to accommodate growing demand for Utopia self-checkout technology and

a 24/7/365 control center to monitor live Utopia checkout lanes.

Pan-Oston is proud to export our “American made” products to Asia, South America, Europe, New Zealand,

Australia and the Caribbean. Th e pride, commitment to excellence and “it can be done” attitude of our 250 plus

associates will ensure that Pan-Oston continues to be an industry leader in retail checkout, display and counter fixtures

for decades.

Pan-Oston Company

6944 Louisville Road

Bowling Green, KY 42101

www.panoston.com

Phone: 270.783.3900

Fax: 270.783.3911

E-mail: info@panoston.com

Account Managers 800.569.5742

Field Operations/Support 800.472.6678

After Hours Support 800.808.0309

Table of Contents

I. Parts

Electrical Components 6

Belts 11

Hardware 12

Scan Kits 16

II. Accessories

Bag Racks 17

Lane Accessories 18

Lean Pads 19

Bumpers 20

POS Equipment 22

Cash Drawers & Cables 24

Terms & Conditions 26

Limited Waranty 27

6 www.panoston.com

Electrical Components

Part Number Description

652-250 10” Motor

652-300 12" Motor

652-350 14" Motor

652-400 16" Motor

652-500 20" Motor

652-550 22” Motor

652-600 24” Motor

Motors

Part Number Description

4717 2.5A Circuit Breaker

Circuit Breaker

Part Number Description

609-10

10uF Capacitor

.FUBMMJ[FEQPMZQSPQPMFOFmMNDBQBDJUPS

in plastic case with 6.3mm double prong

609-15

15uF Capacitor

.FUBMMJ[FEQPMZQSPQPMFOFmMNDBQBDJUPS

in plastic case with 6.3mm double prong

Capacitors

800.210.2302 7

Electrical Components

Part Number Description

603-9 Micro-Switch

603-10 Rear/Bagger Override Switch

603-13 Standard Switch

602-28 SPDT Maintained Switch

603-46 SPDT Momentary Switch

604 Foot Pedal

Switches

Waterproof rocker switch for Tri-Belt

8 www.panoston.com

Electrical Components

Part Number Description

57485 Single Belt Tri-Tronics Module (PM-7200)

69495 Dual Belt Tri-Tronics Module (PM-7203AB)

93471 Dual Belt Tri-Tronics Module (PM-7222)

76504 Tri-Belt Tri-Tronics Module (PM-7233A)

104373 Single Belt Tri-Tronics Module (PM-7400)

104374 Dual Belt Tri-Tronics Module (PM-7422)

Tri-Tronics Modules

800.210.2302 9

Electrical Components

Part Number Description

607-3 Photo Sensor-Emitter-Circuit Board

608-3 Photo Sensor-Receiver-Circuit Board

57486 Photo Sensor-Emitter-Tri-Tronics

Inside Mount

57487 Photo Sensor-Receiver-Tri-Tronics

Inside Mount

83268 Photo Sensor-Emitter-Tri-Tronics

Outside Mount

83269 Photo Sensor-Receiver-Tri-Tronics

Outside Mount

Photo Sensors

10 www.panoston.com

Electrical Components

Part Number Description

2109-4 Single Belt Standard Circuit Board

2109-9 Dual Belt Small Circuit Board (Rear Belt)

Part Number Description

BM-62673 Cooler Outlet

Note: 20 Amp dedicated circuit.

Circuit Boards

Cooler Outlet

800.210.2302 11

Belts

Part Number Description

601-201 546mm W x 3716mm L Endless Belt

601-131 509mm W x 3133mm L Endless Belt

601-24 264mm W x 1710mm L Endless Belt

601-212 546mm W x 2802mm L Endless Belt

601-74 559mm W x 4710mm L Endless Belt

601-58 507mm W x 3790mm L Endless Belt

601-86 559mm W x 3716mm L Endless Belt

601-127 559mm W x 3290mm L Endless Belt

601-13 559mm W x 2310mm L Endless Belt

601-18 559mm W x 2910mm L Endless Belt

601-19 559mm W x 3510mm L Endless Belt

601-20 559mm W x 3950mm L Endless Belt

601-36 559mm W x 2110mm L Endless Belt

601-38 559mm W x 3310mm L Endless Belt

601-68 559mm W x 4070mm L Endless Belt

601-97 307mm W x 1725mm L Endless Belt

Belts

12 www.panoston.com

Hardware

Part Number Description

3813 J-Nut

40102 1/4 Turn Fastener

57984 Tinnerman Clip for Photo Sensor Mount

83261 Screw for Photo Sensor

BM-9304 Motor Bracket Assembly

Fasteners & Brackets

Part Number Description

85132 5/16-18” x 1 ½” Leveler

28386 3/8-16” x 1 1/2” Leveler

85005 3/8-16” x 2” Leveler

Levelers

800.569.5742 13

Hardware

Part Number Description

105407 Carousel Bearing

83598 Carousel Hitch Pin

BM-52140 Carousel Bearing Assembly

26271-1 T-Mold – Cut Length for Carousel

Carousel Bearing with Accessories

Part Number Description

602-250 10” Idler Roller

602-300 12" Idler Roller

602-500 20" Idler Roller

602-550 22” Idler Roller

49205-550 21” Idler Roller

30057-1 12" Grooved Idler

30057-3 10" Grooved Idler

Idler Rollers

14 www.panoston.com

Hardware

Part Number Description

14014-22 Black Safety Edge 22” L

Safety Edge

Part Number Description

2183-29 12” Full Extension Drawer Slides

Pair

2183-21 20” Full Extension Drawer Slides

Pair

2183-4 14” Drawer Slide

Pair, Bolts to Drawer

2183-1 16” Drawer Slide

Pair

2183-2 14” Cabinet Slide

Pair, Bolts to Cabinet

2183-8 Accuride Ball Bearing 10”

Each

2183-53 Accuride Ball Bearing 14”

Each

84739-400 400mm Full Extension, Ball Bearing

Drawer Slides – Pair

Drawer Slides

800.569.5742 15

Hardware

Part Number Description

2168-4 Cam Lock, Keyed Alike

65518-A Sliding Drawer Lock

Part Number Description

20907 Snap-In Plastic Handle

Locks

Handle

Part Number Description

105168 Piano Hinge with

Pre-drilled Holes – 6 foot

104250 Stainless Steel ½” Knuckle Hinge – 6 foot

3815 Stainless Steel Offset Piano Hinge – 6 Foot

Hinges

16 www.panoston.com

Scan Kits

VANTAGE SCAN KITS

SCANNER LENGTH WIDTH DEPTH* HEIGHT* SIZE* SCAN KIT

MAGELLAN-383 508.0mm 292.0mm 100.0mm 131.0mm large BM-62416 (LH/RH)

MAGELLAN-384 508.0mm 292.0mm 100.0mm 131.0mm large BM-62416 (LH/RH)

MAGELLAN-8103 508.0mm 292.0mm 102.0mm 130.0mm large BM-62416 (LH/RH)

MAGELLAN-8104 508.0mm 292.0mm 102.0mm 130.0mm large BM-62416 (LH/RH)

MAGELLAN-8203 508.0mm 292.0mm 100.0mm 131.0mm large BM-62416 (LH/RH)

MAGELLAN-8204 508.0mm 292.0mm 100.0mm 131.0mm large BM-62416 (LH/RH)

MAGELLAN-8501 508.0mm 292.0mm 127.0mm 178.0mm Extra-large BM-62416 (LH/RH)

MAGELLAN-8502 508.0mm 292.0mm 127.0mm 178.0mm Extra-large BM-62416 (LH/RH)

MAGELLAN-9500 508.0mm 292.0mm 166.0mm 178.0mm large BM-62416 (LH/RH)

METROLOGIC MS2020 508.0mm 286.0mm 101.0mm 281.0mm Extra-large BM-62416 (LH/RH)

METROLOGIC MS2021 508.0mm 286.0mm 101.0mm 281.0mm Extra-large BM-62416 (LH/RH)

METROLOGIC MS2022 420.0mm 286.0mm 101.0mm 281.0mm N/A N/A

METROLOGIC MS2320 508.0mm 292.0mm 100.0mm 278.0mm Extra-large BM-62416 (LH/RH)

NCR-7870-1000 510.0mm 296.0mm 130.0mm 159.0mm large BM-62416 (LH/RH)

NCR-7870-2000 510.0mm 305.0mm 30.0mm 159.0mm large BM-62416 (LH/RH)

NCR-7872-1000 508.0mm 292.0mm 89.0mm 180.0mm large BM-62416 (LH/RH)

NCR-7872-2000 508.0mm 302.0mm 89.0mm 180.0mm large BM-62416 (LH/RH)

NCR-7875-1000 510.0mm 296.0mm 130.0mm 181.0mm large BM-62416 (LH/RH)

NCR-7875-2000 510.0mm 307.0mm 130.0mm 178.0mm large BM-62416 (LH/RH)

NCR-7875-7200 510.0mm 296.0mm 181.0mm 182.0mm large BM-62416 (LH/RH)

NCR-7875-8200 510.0mm 307.0mm 181.0mm 178.0mm large BM-62416 (LH/RH)

ICL/ORION 9500 510.0mm 292.0mm 130.0mm 125.0mm large BM-62416 (LH/RH)

FJITSU Smart Scan 9950 500.00mm 292.0mm N/A 147.0mm large BM-62416 (LH/RH)

4ZNCPM1BSU#XPPEJOTFSU1BSU;CSBDLFUTBOETDSFXTXJMMmUPQFOJOHY 14$41&$3"1):4*$4."(&--"/BSFTBNFDPNQBOZ

SCANNER LENGTH WIDTH DEPTH* HEIGHT* SIZE* SCAN KIT STYLE

MAGELLAN-381 353.0mm 292.0mm 100.0mm 131.0mm Small BM-58091-LH Bucket Type

MAGELLAN-383 508.0mm 292.0mm 100.0mm 131.0mm large BM-50016 (LH/RH)

MAGELLAN-384 508.0mm 292.0mm 100.0mm 131.0mm large BM-50016 (LH/RH)

MAGELLAN-8100 353.0mm 292.0mm 102.0mm 130.0mm Small BM-58091-LH Bucket Type

MAGELLAN-8103 508.0mm 292.0mm 102.0mm 130.0mm large BM-50016 (LH/RH)

MAGELLAN-8104 508.0mm 292.0mm 102.0mm 130.0mm large BM-50016 (LH/RH)

MEGELLAN-8200 353.0mm 292.0mm 100.0mm 131.0mm Small BM-58091-LH Bucket Type

MAGELLAN-8203 508.0mm 292.0mm 100.0mm 131.0mm large BM-50016 (LH/RH)

MAGELLAN-8204 508.0mm 292.0mm 100.0mm 131.0mm large BM-50016 (LH/RH)

MAGELLAN-8501 508.0mm 292.0mm 127.0mm 178.0mm Extra-large BM-50016 (LH/RH)

MAGELLAN-8502 508.0mm 292.0mm 127.0mm 178.0mm Extra-large BM-50016 (LH/RH)

NCR-7870-1000 510.0mm 296.0mm 130.0mm 159.0mm large BM-50016 (LH/RH)

NCR-7870-2000 510.0mm 305.0mm 30.0mm 159.0mm large BM-50016 (LH/RH)

NCR-7872-1000 508.0mm 292.0mm 89.0mm 180.0mm large BM-50016 (LH/RH)

NCR-7872-2000 508.0mm 302.0mm 89.0mm 180.0mm large BM-50016 (LH/RH)

NCR-7875-1000 510.0mm 296.0mm 130.0mm 181.0mm large BM-50016 (LH/RH)

NCR-7875-2000 510.0mm 307.0mm 130.0mm 178.0mm large BM-50016 (LH/RH)

ICL/ORION 9500 510.0mm 292.0mm 130.0mm 125.0mm large BM-50016 (LH/RH)

FJITSU Smart Scan 9950 500.00mm 292.0mm N/A 147.0mm large BM-50016 (LH/RH)

SYMBOL LS7808 159.00mm 159.00mm 104.5mm N/A Small BM-57238 (LH/RH) Bucket Type

*Above and below counter. Size listed for Summit Series. PSC, SPECRA PHYSICS, MAGELLAN are same company.

REDDY SCAN KITS

800.569.5742 17

Bag Racks

Part Number Description

46951-6 Black Closed Arm Bag Rack

10” W x 9.25” D x 2.5” H

108188 Black Corner Bag Rack

8” W x 11” D x 2” H

108189 Black Small Bag Rack

10” W x 7” D x 2.5” H

41462 Chrome Plated “S” Hook Bag Rack

.35” W x 2.35” D x 1.3” H

85211 Chrome Plated Bag Rack

10” W x 3” H x 4”D

85212 Chrome Plated “J” Hook Bag Rack

3” W x 2.3” D x 2” H

104583 Black Bag Rack for Recyclable or Plastic Bags

10” W x 9.25” D x 2.5” H

27429 T-Shirt Bag Rack

12.6” W x 12” D x 13.5” H

100283

Stainless Steel 10” Bag Rack Clip

10.6” W x .6” D x 1.75” H

Note: Clip angles are used to mount chair style bag

racks. Multiple clips may be used for bag rack

height adjustment.

Bag Racks

18 www.panoston.com

Lane Accessories

Part Number Description

3822-1 Grey 15” Bar

3822 Almond 15” Bar

BM-300009 Next Customer Divider Bar Kit - Wood Lane

Next Customer Bars

Metal

Part Number Description

19029 Magnetic Universal Width Aisle Closure

Wood

Part Number Description

BM-300052 Magnetic Universal Width Aisle Closure

Magnetic Aisle Close-Off Coils

Part Number Description

2184 3.2 Gallon Black Plastic Trash Can

12” H x 11.5” W x 8” D

Part Number Description

19851 Lane Closed Sign

White with Blue Letters – 12” L x 2” H

Part Number Description

19028 Convex Mirror – 3.75” Diameter

Trash Can

Lane Closed Sign

Convex Mirror

800.569.5742 19

Part Number Description

31800-5 400mm Black Lean Pad

31800-8 320mm Black Lean Pad

31800-2 290mm Black Lean Pad

31800-13 350mm Black Lean Pad

31800-7 545mm Black Lean Pad

31800-1 266mm Black Lean Pad

Lean Pads

Lane Accessories

20 www.panoston.com

Bumpers

Part Number Description

17284 Black Mounting Track for 1" Rigid Bumper - 12' L

17284-6 Black Mounting Track for 1" Rigid Bumper - 6' L

18068 1” Black Rigid Bumper - 12’ L

18068-6 1” Black Rigid Bumper - 6’ L

17285 1” Red Rigid Bumper - 12’ L

17285-6 1” Red Rigid Bumper - 6’ L

26415 1” Gray Rigid Bumper - 12’ L

26415-6 1” Gray Rigid Bumper - 6’ L

105401 1” Aluminum Gray Rigid Bumper - 12’ L

105401-6 1” Aluminum Gray Rigid Bumper - 6’ L

67301 1” Black Flex Bumper - 72’ L

82945 1” Aluminum Gray Flex Bumper - 72’ L

17286-1 Red End Cap for 1” Bumper

17286-2 Black End Cap for 1” Bumper

17286-7 Gray End Cap for 1” Bumper

17286-21 Aluminum Gray End Cap for 1” Bumper

18067-1 Red Corner Cap for 1” Bumper

18067-2 Black Corner Cap for 1” Bumper

18067-4 Gray Corner Cap for 1” Bumper

18067-10 Aluminum Corner Cap for 1” Bumper

78786 Black Mounting Track for 2” Rigid Bumper - 12’ L

78786-6 Black Mounting Track for 2” Rigid Bumper - 6’ L

53207 2” Black Rigid Bumper - 12’ L

53207-6 2” Black Rigid Bumper - 6’ L

66983 2” Gray Rigid Bumper - 12’ L

66983-6 2” Gray Rigid Bumper - 6’ L

78790 2” Red Flex Bumper - 72’ L

78792 2” Gray Flex Bumper - 72’ L

78795 2” Black Flex Bumper - 72’ L

83618 2” Aluminum Gray Flex Bumper - 72’ L

Bumpers

800.569.5742 21

Bumpers

Part Number Description

78787-H Black End Cap for 2” Bumper

78787-C Red End Cap for 2” Bumper

78787-E Gray End Cap for 2” Bumper

78787-L Aluminum Gray End Cap for 2” Bumper

66977-B Black Corner Cap for 2” Bumper

66977-D Red Corner Cap for 2” Bumper

66977-G Gray Corner Cap for 2” Bumper

66977-L Aluminum Gray Corner Cap for 2” Bumper

41402 Black Mounting Track for 2” Elipse Bumper - 12’ L

41402-6 Black Mounting Track for 2” Elipse Bumper - 6’ L

41403 2” Black Elipse Bumper - 12’ L

41403-6 2” Black Elipse Bumper - 6’ L

41404-2 Black End Cap for 2” Elipse Bumper

41405-2 Black Corner Cap for 2” Elipse Bumper

Bumpers

22 www.panoston.com

POS Equipment Accessories

Part Number Description

Must Provide Make/Model Keyboard Tray

Part Number Description

Must Provide Make/Model Monitor Mount, CRT

Must Provide Make/Model Monitor Mount, VESA

Part Number Description

Must Provide Make/Model Fixed EFT Tray

Must Provide Make/Model Rotating EFT Tray

Must provide make/model or dimensions of keyboard. Color is black.

Stands are available for VESA mount or CRT* models. Please provide mounting

method (rail or deck). *CRT monitor mount is not available as a rail mount.

CRT model shown in illustration. Color is black.

Must provide make/model of EFT. Please provide mounting method (rail or deck).

Color is black.

1SJDJOHJTCBTFEPOTUBOEBSEEFTJHOTBOEDPOmHVSBUJPOT1SJDFNBZCFTVCKFDUUPDIBOHF

Keyboard Tray

EFT Trays

Monitor Display Brackets

Metal Belted

Part Number Description

BM-70116 6.5” x 18” Shelf Railmount

BM-70117-LH 6.5” x 18” Shelf Cantilevered

BM-70117-RH 6.5” x 18” Shelf Cantilevered

Metal and Wood Non-Belted

BM-70118 6.5” x 18” Shelf Deck Mount

Wood Belted

BM-70119 6.5” x 18” Shelf Railmount

BM-70120-LH 6.5” x 18” Shelf Cantilevered

BM-70120-RH 6.5” x 18” Shelf Cantilevered

Note: Colors are black on pedestal and writing surface.

1SJDJOHJTCBTFEPOTUBOEBSEEFTJHOTBOEDPOmHVSBUJPOT

Price may be subject to change.

Check Writing Shelf for Reddy Lanes

800.569.5742 23

POS Equipment Accessories

Metal

Part Number Description

BM-51080-3 6.5” x 12” Shelf

BM-51080-4 6.5” x 18” Shelf w/ Hole

BM-62426-LH Cantilevered Shelf, LH

BM-62426-RH Cantilevered Shelf, RH

BM-62386-LH Cantilevered Shelf, LH w/ Hole

BM-62386-RH Cantilevered Shelf, RH w/ Hole

Wood

Part Number Description

BM-300048 6.5” x 12” Shelf

BM-300049 6.5” x 18” Shelf w/ Hole

BM-300050-LH Cantilevered Shelf, LH

BM-300050-RH Cantilevered Shelf, RH

BM-300051-LH Cantilevered Shelf, LH w/ Hole

BM-300051-RH Cantilevered Shelf, RH w/ Hole

Note: Colors are black on pedestal and writing surface.

1SJDJOHJTCBTFEPOTUBOEBSEEFTJHOTBOEDPOmHVSBUJPOT

Price may be subject to change.

Check Writing Shelf for Vantage Lanes

24 www.panoston.com

Cash Drawers & Cables

Part Number Description Size

T396-BL1616

Black powder coated steel case

ABS molded front and inner drawer

reduces weight

Adjustable media slot

$POmHVSBCMFVOEFSUJMMTUPSBHF

Cable not included

16”W x 16.7”D x 4.7”H

JB396-BL1816

#MBDLQPXEFSDPBUmOJTI

All steel construction

Dual media slots

Cable not included

18.0”W x 16.7”D x 4.2”H

MFS396-1-BL460 IBM 46xx

5 bill/8 coin removable till

Single media slot

4BWFTQBDFBOEJODSFBTFFGmDJFODZ

Top opens to 85 degrees

Lockable till cover

Hardwired interface includes cable

18.1”W x 6.77”D x 4.0”H

MFS396-2-BL460 IBM 72x/73x 18.1”W x 6.77”D x 4.0”H

MFS396-3-BL460 NCR 18.1”W x 6.77”D x 4.0”H

MFS396-4-BL460 Epson 18.1”W x 6.77”D x 4.0”H

MFS396-5-BL460 Fujitsu 18.1”W x 6.77”D x 4.0”H

AB396-4-BL1611

Unique short-depth, ergonomic deisgn

5 bill/8 coin removable till

4BWFTQBDFBOEJODSFBTFFGmDJFODZ

Lockable till cover

Single media slot

16”W x 11.5”D x 4.9”H

(U.S. Currency)

AB396-4-BL1811 18”W x 11.5”D x 4.9”H

(U.S. Currency)

AB396-4-BL1611-MP3 16”Wx11.5”Dx4.9”H

(Canadian Currency)

AB396-4-BL1811-MP3 18”Wx11.5”Dx4.9”H

(Canadian Currency)

AB396-4-BL1611-MP1 16”Wx11.5”Dx4.9”H

(Euro Currency)

AB396-4-BL1811-MP1 18”Wx11.5”Dx4.9”H

(Euro Currency)

Cash Drawer with 1 till insert

800.569.5742 25

Cash Drawers & Cables

Part Number Connects To Cable Length

CD-007 IBM 46xx Series 5 ft.

CD-007-10 IBM 46xx Series 10 ft.

CD-037 IBM 72x/73xx Series 10 ft.

CD-001A-D NCR System 5 ft.

CD-001A10-D NCR System 10 ft.

CD-005A Epson 5 ft.

CD-005A10 Epson 10 ft.

CD-034 Fujitsu 10 ft.

Cash Till Insert (optional)

Cables for Cash Drawers

Part Number Description

PK-15VTAP-BX 5 Bill-5 Coin Till Insert for US Currency

PK-15TA-MP1-BX 5 Bill-8 Coin Till Insert for European Currency

PK-15TA-MP3-BX 5 Bill-8 Coin Till Insert for Canadian Currency

26 www.panoston.com

Terms & Conditions

1. Delivery/Freight – All shipments made

F.O.B. from our plant. Not responsible

for delays caused by circumstances

beyond our control. If the purchaser or

carrier refuses delivery or delays

shipment or acceptance, the goods may

be stored according to Seller’s

directions, at Purchaser’s risk and

expense. During any period of storage

provided herein, title to the goods and

risk of loss shall be in Purchaser.

2. Returns – A written Return Material

Authorization (RMA) is required in cases

where a return is authorized. The RMA

number must be prominently displayed

on the returned product. Authorized

returns will be assessed a 25%

restocking fee. All return freight to be

paid by the Customer.

3. Shortages – Claims on shortages must

be made within five (5) days from date

of delivery.

4. Changes – Prior to acceptance of order,

prices, terms, and conditions are subject

to change without notice.

5. Order Changes and Cancellation –

Order changes and cancellation may

result in a charge that reflects any

materials, parts, or assemblies that are

unique to the order.

6. Taxes – Purchaser shall pay in addition

to the contract price any and all sales,

use, excise, retailers occupation and/or

other taxes payable by reason of this

transaction, with any interest and

penalties thereon.

7. Warranty – See Page 27.

8. Limitation of Liability – Seller will in no

event be liable for indirect, special or

consequential damages whatsoever

from claims of breach of warranty,

negligence, strict liability or otherwise

arising out of this agreement, and

Seller’s liability under no circumstances

will exceed the contract price for the

goods for which liability is claimed.

9. Terms of Payment – Payment in full is

due within terms of sale, unless

otherwise specifically agreed to by the

parties in writing. If payment is not

made in full when due, Seller may

require, with respect to any orders then

outstanding full or partial payment in

advance or shall be entitled to cancel or

defer any of such orders of items or

quantities thereon and shall be entitled

to payment to Purchaser for all

damages. Purchaser agrees to pay a

service charge of 1.5% per month or the

highest rate permitted by law, whichever

is less, from the date of any invoice

which is not paid in full when due.

10. Price Terms – All prices quoted are

subject to change without notice until

Purchaser’s order is accepted by Seller.

Prices stated on Seller’s

acknowledgement for orders, or items or

quantities thereon, accepted by Seller

for scheduled shipment within 30 days

from date of order, are not subject to

upward or downward adjustment. All

prices for orders accepted by Seller for

scheduled shipment after 30 days from

date of acceptance are subject to

upward or downward adjustment at time

of shipment to Seller’s prices in effect on

scheduled date of shipment.

800.569.5742 27

Limited Warranty

1. Pan Oston warrants all new products to be free

from defects in material and workmanship at the

time of shipment.

2. In the event of any failure, the defective parts will be

replaced without charge for the part or labor, for a

period of one (1) year for metal and ninety (90)

days for wood from the day of shipment under

the following conditions only:

a) That the damage was sustained under normal

use and service and was not due to exterior

influences or operations beyond capacity.

b) That the products covered by this warranty

were used only in conjunction with Pan-Oston

approved parts.

c) That the Purchaser gives Pan-Oston immediate

written notice of such defect or defects and that

all faulty parts or equipment are returned to

Pan-Oston with prior authorization from Pan-

Oston.

d) Any alteration or repair by others in such a

manner as in Pan-Oston’s judgment materially

and adversely affects the product shall void this

warranty.

e) Thatthemethodofshipmentforanyreplacement

part will be regular ground at Pan-Oston’s

expense, with the carrier being determined by

Pan-Oston. Customer requests for alternate

carriers for shipment of replacement parts, will

be at the customer’s expense unless approved by

Pan-Oston.

3. (IF APPLICABLE) With respect to the motor, the

warranty shall be for a period of 3 (three) years,

subject to the same conditions listed in Item 2. After

the first year, the shipping and installation costs will

be the responsibility of the customer. With respect

to the idler roller and control module, the warranty

shall be one (1) year from the date of purchase. After

the first year warranty expires, all replacement costs

will be the responsibility of the customer.

4. Pan-Oston’sobligationunderthiswarrantyisexpressly

limited to the repair and replacement obligations set

forth in Paragraphs 2 and 3, in accordance with the

stipulations set forth in this warranty. Pan-Oston’s

obligation under this warranty shall not include any

transportation charges or cost of installation or any

liability for special, direct, indirect, or consequential

damages of delay. Correction of nonconformities, in

themannerprovidedabove,shallconstitutefulfillment

of all liabilities of Pan-Oston, whether based on

contract, negligence or otherwise with respect to, or

arising out of such products. In no event, whether in

contract, in tort, under any warranty, or otherwise

including, without limitation, the negligence of the

company, its employees or agents, shall Pan-Oston

be liable for any damages beyond the price of the

faulty or defective parts and equipment.

5. No person, company or corporation is authorized

to assume for Pan-Oston any other liability

in connection with said products. Under no

circumstances is Pan-Oston liable for damage

resulting from faulty or improperly installed

equipment or from misapplication beyond normal

intended use of said equipment. There shall be no

third party beneficiary to any warranties set forth

herein.

6. This constitutes the only warranty of the company

and no other warranty or condition, statutory or

otherwise shall be implied.

To The Purchaser (Non-Transferable)

Note: A word about this Catalog.

Pan-Oston believes the information in this brochure/catalog to be correct at the time of printing.

)PXFWFSJUFNTQSJDJOHBWBJMBCJMJUZTQFDJmDBUJPOTGFBUVSFTBOEDPMPSTBSFTVCKFDUUPDIBOHFXJUIPVU

notice. All previous brochures/catalogs, product descriptions and prices are no longer valid.

Pan-Oston cannot be held responsible for errors in typography or photography.

Checkstand

Service Parts

Catalog

& Accessories

6944 Louisville Rd. | Bowling Green, KY 42101

Phone: (270) 783.3900 | Toll Free: 800.210.2302

www.panoston.com

PartsAccessories 1.16.11 MS2022 CAT 1905 Parts Accessories V19

Navigation menu

Versions of this User Manual:

Views

Navigation
