2014 will see some excing new developments of our highly successful ATRIUM product. In response to
our installers, ATRIUM will increase to 100 door capacity whilst maintaining a mix of IP and tradional RS485
connecons.
For more detailed informaon on ATRIUM or any other product, please contact us to supply you with a technical
data sheet - we can supply this in a paper or electronic form.
Our commitment to develop products which are environmentally friendly (green) connues, and we strive for the
most energy ecient products possible.
We have a support team who are able to give expert and friendly advice
from 08:30 - 17:30 Monday to Friday.
Whatever your requirement, call us now.
Tel: 01628 531300
Email: support@cdvi.co.uk
We hope you enjoy this product selector,
CDVI UK team
CDVI Ltd UK & IRELAND EDITION
3
www.cdvi.co.uk
01628 531300
INDEX
STANDALONE KEYPADS
STANDALONE ACCESS CONTROL
ONLINE ACCESS CONTROL
READERS, CARDS & TAGS
ELECTROMAGNETIC LOCKING DEVICES
ELECTRIC LOCKING & STRIKES
EXIT BUTTONS, DEVICES, TIMERS ETC
POWER SUPPLIES
DOOR AUTOMATION
WIRELESS CONTROLS
INTERCOM POSTS
GENERAL INFORMATION
P. 4
P. 6
P. 8
P. 14
P. 18
P. 32
P. 38
P. 45
P. 46
P. 48
P. 52
P. 53
CONTENTS PAGE No.
4
Self-contained
Self-contained
Compact, aordable
Sturdy polycarbonate
100 user codes
Timed relay output
Exit buon input
Simple surface mount
12V ac/dc
100mA max
145 x 80 x 28mm
DGA
PROMI ECO
KEYPADS
Backlit for convenience
Vandal resistant
100 user codes
2 med/latching relays
Secure surface mount
12-48Vdc/12-24Vac
100mA max
120 x 98 x 25mm
Remote electronics (included)
Backlit for convenience
Stylish & vandal resistant
Remote electronics for added security
100 user codes
2 or 3 med/latching relays
Secure surface mount
12-48Vdc/12-24Vac
100mA max
110 x 75 x 15mm
GALEO
Reference Descripon Price
PROMI-ECO Compact keypad £54.80
Reference Descripon Price
DGA Backlit keypad £127.40
Reference Descripon Price
GALEO Stylish backlit keypad, 2 relays £131.60
GALEO3R Stylish backlit keypad, 3 relays £170.60
www.cdvi.co.uk
01628 531300
KEYPADS
5
KEYPADS
Self-contained or Remote electronics
Backlit for convenience
Narrow style to suit restricve frame sizes
Vandal resistant
100 user codes
2 med/latching relays
Remote electronics (oponal for added security)
Secure surface mount
12-48Vdc/12-24Vac
100mA max
165 x 43 x 27mm
PROFIL100E
Oponal
Self-contained
CBB & CAASE
High grade stainless steel
Vandal resistant
100 user codes
4, 5 or 6 digit codes
3 med/latching relays
Braille keys
Secure surface mount
12-48V dc
12-24V ac
120mA max
120 x 100 x 65mm
High grade stainless steel
Backlit
Vandal resistant
100 user codes
3 med/latching relays
Secure ush mount
12-48Vdc/12-24Vac
140mA max
125 x 100 x 3mm
CBB
CAASE
Reference Descripon Price
PROFIL100EINT Narrow backlit keypad, self contained £173.80
PROFIL100EC Narrow backlit keypad, remote electronics £188.40
Reference Descripon Price
CBB Heavy duty keypad £127.90
CAASE Flush backlit keypad £181.60
www.cdvi.co.uk
01628 531300
6
Long range reader/controller
PROMI 500/1000PC
DIGITAG LR
STANDALONE ACCESS CONTROL
Compact proximity reader/controller
Sturdy polycarbonate
Opon of 500 or 1000 users
Timed/latching relay output
Exit buon input
Remote read-head opon
Soware & reports (PROMI1000PC)
12V ac/dc
300mA
145 x 80 x 28mm
Oponal remote CDVI
readers Connecon
to PC
PROMI 1000PROMI 500
Self contained reader
30 users
Hands free operaon
Up to 15 metres range
Timed relay output
Exit buon input
Audible & visual signal
Uses DTXT range of cards
12-30Vdc
40mA
90 x 60 x 22mm
Reference Descripon Price
DTRR1434R Long range reader/controller £81.40
Reference Descripon Price
PROMI500 Reader/controller, 500 users £110.20
PROMI1000PC Reader/controller, 1000 users c/w soware £189.90
www.cdvi.co.uk
01628 531300
STANDALONE ACCESS
CONTROL
7
2-door controller
2-door controller
Assign users to door 1, door 2 or both
500 user capacity
2 med/latching relay outputs
2 exit buon inputs
Connects to CDVI readers (see below)
12V ac/dc
200mA
116 x 116 x 23mm
DG502
Readers & Cards
Proximity & hands free
STANDALONE ACCESS CONTROL
Reference Descripon Price
DG502UP 2-door controller £133.80
Door 1
Door 2
Reference Descripon Price
DGLP Standard prox reader £77.70
Reference Descripon Price
DGLPT Small retrot prox reader £110.90
Reference Descripon Price
DGLI Stainless prox reader £145.60
Reference Descripon Price
DGLPFN Narrow prox reader £86.70
Reference Descripon Price
DTRR1434R Long range reader/controller £81.40
Reference Descripon Price
DGLIFN Narrow stainless prox reader £162.50
Reference Descripon Price
METAL1 Robust prox fob, 10 pack £47.20
Reference Descripon Price
CPE Clamshell prox card, 10 pack £18.50
CPC ISO printable prox card, 25 pack £58.20
Reference Descripon Price
PPC Standard fob, 10 pack £18.30
Reference Descripon Price
DTXT5434 Acve card for use with DTRR1434R £21.30
Polycarbonate proximity reader
Internal or external use
103 x 81 x 23mm
Polycarbonate proximity reader
Internal or external use
139 x 41 x 23mm
Stainless steel proximity reader
Internal or external use
97 x 76 x 20mm
Stainless steel proximity reader
Internal or external use
140 x 35 x 22mm
Polycarbonate panel reader
Internal or external use
44mmØ x 31height x 18mm
Long range reader
Internal or external use
90 x 60 x 22mm
www.cdvi.co.uk
01628 531300
8
MAIN
FEATURES
ATRIUM
100 DOOR SYSTEM
Cards / Users 10,000
Doors/Readers 100
Areas 100
Monitored Inputs 500
Schedules /Periods 100
Access Levels 1000
Event Buer 10,000
2-Door Expanders 4 per AC22
IP Camera Monitoring* 2 per door
Embedded Web Server Yes
Free Soware Yes
Simplicity
A simple and logical wiring structure, plug & play hardware, step-by-step instrucons and our quick-start funcon allows you to get
your system up and running quickly. Customer specic programming can then be completed at your convenience with the system
already performing access control funcons.
Whether you prefer tradional hard-wiring, or are looking for a system which is fully IP, then
ATRIUM is the product for you. In fact, you can “mix-n-match” with some ATRIUM controllers
on a network, and some hard-wired. The system is so exible and straighorward, that
even new installers to access control will be able to condently provide customers with a
system that is user-friendly and reliable.
World-wide performance
The innovave ATRIUM with embedded web server is fast, simple and secure. From any place in the world, you can do tasks such
as user/card management, lock/unlock doors instantly, and view system events. The embedded web server provides instant results
using any recent web browser, smart phone or tablet.
Alternavely, you can use the free soware supplied and get full funconality and reporng from your local PC at your desk.
Flexibility
Oer your customer exactly what is required by them - local and/or remote control and monitoring, reports of user movements and
transacons, restricon of access to crical areas by the authorisaon level or me schedules, vericaon of access by connecon
to CCTV cameras, email nocaon when something is wrong....and so much more.
*Please check with CDVI Ltd for supported IP cameras
www.cdvi.co.uk
01628 531300
Go to www.atrium.cdvi.co.uk
from your phone, tablet or PC to
try Atrium and see its speed and
simplicity for yourself
Some features are becoming available during
2014 - please call us on 01628 531300 to talk
about your installaon
9
ONLINE ACCESS
CONTROL
AC22KITB
• Can be used standalone, web or PC based
• Access your system over the internet
• Speedy installaon
• Quick and simple system start
• Straighorward and user-friendly
• Fast and easy card enrolment
• Extremely compevely priced
• Free training in our demo room
• 5 year warranty
ATRIUM - innovave and accessible
www.cdvi.co.uk
01628 531300
Try it at www.atrium.cdvi.co.uk
10
Extremely simple and exible wiring conguraon
Web based monitoring
(WAN/LAN)
Internet connecon
IP
Server
wireless
connecon
AX22 AX22
AC22
Direct connecon
Ethernet RJ45
Local control
AC22
To more AC22’s
To more AX22’s RS485
RS485
An excellent product for your customer........
.......an excellent product for you
Connect from anywhere and monitor the site
Authorise card holders by door and me
Lock / unlock doors
www.cdvi.co.uk
01628 531300
11
2-door controller with web-server
Metal cased for security
Built in PSU and baery charger
Ample room to make connecons
Includes free soware
Includes quick start-up cards
Available as kit with readers
230Vac input
3.3A @ 24Vdc
400 x 320 x 90mm
AC22
Reference Descripon Price
AC22 ATRIUM 2-door controller £470.00
AC22KITB ATRIUM controller c/w 2 x NANOPB readers £610.30
AC22KITW ATRIUM controller c/w 2 x NANOPW readers £610.30
AC22KITBE ATRIUM controller c/w 1 x NANOPB reader & 1 x DGLIWLC reader £634.10
AC22KITWE ATRIUM controller c/w 1 x NANOPW reader & 1 x DGLIWLC reader £634.10
ATRIUM Controller
2-door expander
Metal cased for security
Built in PSU and baery charger
Ample room to make connecons
230Vac input
3.3A @ 24Vdc
290 x 280 x 80mm
AX22
ATRIUM Expander
ONLINE ACCESS
CONTROL
Connect up to 4 AX22’s
(RS485)
Connect up to 4
AX22’s per AC22
Reference Descripon Price
AX22 ATRIUM 2-door expander £355.00
AX22KITB ATRIUM expander c/w 2 x NANOPB readers £487.80
AX22KITW ATRIUM expander c/w 2 x NANOPW readers £487.80
AC22
AC22KITB
AX22
AX22KITB
To/from more AC22’s
(TCP/IP)
www.cdvi.co.uk
01628 531300
12
Centaur has evolved over the years to provide a simple and easy to manage system with the opon to make use of its powerful
features only if needed - this uncomplicated approach has enabled users to build their system as dictated by their requirements,
and remove the feeling of having a system “too big for our needs”.
From simple 2-door access control with central administraon and reporng, to a fully featured system incorporang mul-sites
with thousands of doors and cardholders, Centaur has proved it is capable of providing a simple to manage system regardless
of computer literacy.
Full training is provided for the installer and end user, all training at our facility being free of charge.
Simple architecture
Extremely cost eecve
Central administraon
Flexible control
Suits all requirements
Up to 16000 cards per site
Up to 2048 doors per site
Up to 64 sites
Powerful reporng tools
Integrates to 3rd party technology
Free design and specicaon service
Digital Video
Management (DVR/NVR)
IP Camera
Oponal
Workstaon(s)
Printer
(Also direct connecon)
TCP/IP
Connecon
(LAN/WAN)
Centaur
Door Controller
CTV900A
Hard wire
or
dial-up (modem)
connecons
also supported
SERVER
Intruder Alarm
Integraon
• Aimes
• Capture
• Dahua
• Dedicated Micros
• Digiop
• Digital Watchdog
• Everfocus
• HikVision
• Innova
• Microcom
• Milestone
• NUUO
• ONSSI
• Pelco
• Samsung
• Sphere
• View Gate
• Vivotek
• WatchNET
Supported DVR
manufacturers
To addional
controllers &
expansion modules
To addional
expansion modules
(3 in total)
Solution
Partner
www.cdvi.co.uk
01628 531300
ONLINE ACCESS
CONTROL
13
2-door controller
CTV900
2-door intelligent controller
Built-in power supply
Secure metal case
Ample space for cables
Baery standby provision
240Vac
2.5A maximum current
Accepts 2 x 12Vdc, 7AH baeries
400 x 337 x 105mm
Reference Descripon Price
CTV900ATR 2-door controller £481.90
2-door expander
CAA470
Reference Descripon Price
CAA470ATR 2-door expansion module £359.90
2-door expansion module
Built-in power supply
Secure metal case
Ample space for cables
Baery standby provision
240Vac
2.5A maximum current
Accepts 1 x 12Vdc, 7AH baeries
298 x 285 x 78mm
 Soware&plug-onmodules
MODULES
Soware supplied on DVD
Automac set up
Cardholder database
Customised events and reports
Reference Descripon Price
CSAC50-SUSB Centaur standard soware licence & key FOC
CSAC50-PUSB Centaur professional soware licence & key £1130.90
CSWSPACK-5 Centaur workstaon licence & key £332.70
CAA360USBRS USB - RS485 converter £76.40
CAETHRA RS232 - TCP/IP converter £102.40
CAA110P Lock control module £30.70
CAA460P Relay expansion module £122.70
CAA370P RS485 hub for star conguraon £221.90
Visitor management
Alarm management
Interacve graphics maps
Free soware training
www.cdvi.co.uk
01628 531300
14
Compact reader
Narrow style reader
Stylish design
Reecve backlight
Audible and visual feedback
Available in white or black
Wiegand 26 bit
12Vdc
120mA max
70 x 43 x 23mm
STAR
NANO
ONLINE READERS
SOLAR
NANOPW Reference Descripon Price
NANOPW Compact proximity reader, white £92.70
NANOPB Compact proximity reader, black £92.70
Reference Descripon Price
STARPW Narrow style proximity reader, white £101.70
STARPB Narrow style proximity reader, black £101.70
Standard reader
NANOPB
STARPW STARPB
SOLARPW SOLARPB
Stylish design
Narrow style
Reecve backlight
Audible and visual feedback
Available in white or black
Wiegand 26, 30 or 44 bit
12Vdc
120mA max
130 x 41 x 28mm
Stylish design
Reecve backlight
Audible and visual feedback
Available in white or black
Wiegand 26, 30 or 44 bit
12Vdc
120mA max
130 x 90 x 35mm
Reference Descripon Price
SOLARPW Standard proximity reader, white £101.70
SOLARPB Standard proximity reader, black £101.70
www.cdvi.co.uk
01628 531300
ONLINE ACCESS
CONTROL
15
ONLINE READERS
Combined reader & keypad
Backlit for convenience
Narrow style to t door frames
Rugged stainless steel construcon
Card & PIN for increased security
Audible and visual feedback
Wiegand 26, 30 or 44 bit
12Vdc
120mA max
190 x 43 x 27mm
SOLARKP
KCPROX
Reference Descripon Price
SOLARKPW Combined proximiy reader & keypad, white £155.90
SOLARKPB Combined proximity reader & keypad, black £155.90
Reference Descripon Price
KCPROXWLC Combined proximity reader & keypad, stainless £313.10
Combined reader & keypad
Rugged design
Suitable for harsh environments
High grade stainless steel
Audible and visual feedback
Available as standard or narrow style
Wiegand 26, 30 or 44 bit
12Vdc
120mA max
97 x 76 x 20mm (DGLIWLC)
140 x 35 x 22mm (DGLIFWLC)
DGLI
Reference Descripon Price
DGLIWLC Standard proximity reader, stainless £141.30
DGLIFWLC Narrow style proximity reader, stainless £141.30
Stainless readers
DGLIWLC
DGLIFWLC
Stylish design
Reecve backlight
Touch sensive keypad
Card & PIN for increased security
Audible and visual feedback
Available in white or black
Wiegand 26, 30 or 44 bit
12Vdc
120mA max
130 x 90 x 35mm
SOLARKPW SOLARKPB
www.cdvi.co.uk
01628 531300
16
Rugged keypad
Long range reader
Backlit for convenience
Stylish & vandal resistant
Secure surface mount
Wiegand 26 bit
12-48Vdc/12-24Vac
100mA max
110 x 75 x 15mm
DTRR1434
GALEOW
ONLINE READERS
WIEGAND RECEIVERS
Reference Descripon Price
GALEOW Stylish online keypad £134.90
Reference Descripon Price
DTRR1434 Long range reader £50.50
Radio receivers
Up to 15m range
Hands-free operaon
Ideal for car parks
Audible and visual feedback
Built-in antenna
Wiegand 26 bit
12-30Vdc
40mA max
90 x 60 x 22mm
Up to 100m range
Rolling code security
Single channel wiegand output
Oponal tuned antenna
Compable with all CDVI transmiers
see pages 48 & 49
12V AC/dc
12mA max
105 X 45 X 28mm (SELWR433)
On board PCB connector (DTFRW01)
Reference Descripon Price
SELWR433 Self contained wiegand receiver £74.80
DTFRW01 PCB pluggable wiegand receiver £74.80
SEA433 Tuned antenna £18.70
SELWR433
DTFRW01
SEA433
www.cdvi.co.uk
01628 531300
17
ONLINE ACCESS
CONTROL
ONLINE READERS
Standard MIFARE readers
Rugged design
Suitable for harsh environments
High grade stainless steel
Audible and visual feedback
Wiegand 26, 30 or 44 bit
12Vdc
120mA max
97 x 76 x 20mm (DGLIWLC)
SOLARMW
DGLIMWLC
Reference Descripon Price
SOLARMW Standard MIFARE reader, white £134.60
SOLARMB Standard MIFARE reader, black £134.60
Reference Descripon Price
DGLIMWLC Standard MIFARE reader, stainless £204.80
Stainless Mifare reader
CARDS & TAGS
Stylish design
Reecve backlight
Audible and visual feedback
Available in white or black
Wiegand 26, 30 or 44 bit
12Vdc
120mA max
130 x 90 x 35mm
Reference Descripon Price
METAL1 Robust prox fob, 10 pack £47.20
Reference Descripon Price
CPE Clamshell prox card, 10 pack £18.50
CPC ISO printable prox card, 25 pack £58.20
Reference Descripon Price
PPC Standard fob, 10 pack £18.30
Reference Descripon Price
DTXT5434 Hands-free acve card £21.30
Reference Descripon Price
METAL MIFARE fob, 10 pack £62.80
Reference Descripon Price
BV MIFARE card, 10 pack £46.30
www.cdvi.co.uk
01628 531300
18
 300kgmorcemagnet
400kg morce magnet
Monitored
Up to 300kg holding force
No moving parts
Fits AT300-H series housings
12/24Vdc
500mA@ 12Vdc
228 x 39 x 27mm
V4ER / M400M
V3ER / M300M
MORTICE MAGNETS - INTERNAL
V5E / M500
Reference Descripon Price
V3ER/M300M Morce magnet, monitored £71.90
Reference Descripon Price
V4ER/M400M Morce magnet, monitored £76.00
 500kgmorcemagnet
Monitored
Up to 400kg holding force
Oponal housing
No moving parts
12/24Vdc
500mA @ 12Vdc
228 x 44 x 30mm
Up to 500kg holding force
No moving parts
Morce directly into door/gate frames
12/24Vdc
500mA @ 12Vdc
288 x 64 x 37mm
Reference Descripon Price
V5E/M500 Morce magnet £115.90
www.cdvi.co.uk
01628 531300
LOCKING DEVICES
ELECTROMAGNETIC LOCKS
19
HORIZONTAL HOUSINGS - INTERNAL
 500kgmorcemagnet
AT500
Surface mount
SAA nish (San Anodised
Aluminium)
Easy installaon
Forms part of door frame
Visually aesthec
RAL colour nishes available
Single & double door versions
Horizontal or vercal x models
End caps and xing kit
Dimensions (LxWxD):
- AT300-1 series = 998 x 45 x 45mm
- AT300-2 series = 1998 x 45 x 45mm
- AT500-1 series = 995 x 70 x 50mm
- AH500-2 series = 1995 x 70 x 50mm
Note:
Each housing is supplied with end-caps, which are ed once the housings
are cut to t the door(s).
We do oer a cung service, where we will cut the housings to
measurements supplied by you - these measurements to be supplied to us
in a wrien form.
Magnets are not included in the housing prices.
Architectural housings
AT-H HOUSINGS
Monitored
Up to 500kg holding force
No moving parts
Fits AT500-H series housings
12/24Vdc
500mA@ 12Vdc
228 x 39 x 27mm
Reference Descripon Price
AT500 Morce magnet £95.30
AT500M Morce magnet, monitored £98.70
Reference Descripon Price
AT300-1H 1M housing, 1 cut out for V3ER £81.90
AT300-2-1H 2M housing, 1 cut out for V3ER £136.10
AT300-2-2H 2M housing, 2 cut outs for V3ER £136.10
AT300-1L 1M L bracket for AT300-1H £43.10
AT300-2L 2M L bracket for AT300-2H £82.50
AT500-1H 1M housing, 1 cut out for AT500 £78.30
AT500-2-1H 2M housing, 1 cut out for AT500 £173.50
AT500-2-2H 2M housing, 2 cut outs for AT500 £173.50
AT500-1L 1M L bracket for AT500-1H £61.30
AT500-2L 2M L bracket for AT500-2H £125.90
www.cdvi.co.uk
01628 531300
20
SURFACE MAGNETS - INTERNAL
Micro magnet
Surface mount
Up to 300kg holding force
Innovave visual indicaon
No moving parts
Designed with safety features
Security “catch” ropes
12/24Vdc
550mA @ 12Vdc
225mA @ 24Vdc
248 x 45 x 26mm single
496 x 45 x 26mm double
V1SR / S180
V3 / S300 Series
Reference Descripon Price
V1SR/S180 Micro magnet, monitored £58.40
Reference Descripon Price
V3S/S300 Mini magnet £70.40
V3SR/S300M Mini magnet, monitored £77.80
SD300M Double mini magnet, monitored £155.50
Mini magnet
V4 / S400 Series
Reference Descripon Price
V4S/S400 Midi magnet £84.10
V4SR/S400M Midi magnet, monitored £86.90
Midi magnet
Surface mount
Monitored
Up to 180kg holding force
No moving parts
12/24Vdc
550mA @12Vdc
167 x 34 x 20mm
Surface mount
Up to 400kg holding force
Innovave visual indicaon
No moving parts
Designed with safety features
Security “catch” ropes
12/24Vdc
550mA @ 12Vdc
225mA @ 24Vdc
255 x 50 x 27mm single
Includes safety ropes to catch magnet
in case of loose xings. Rounded ends to
reduce impact damage. Compable with all
CDVI bracketry and accessories.
Includes safety ropes to catch magnet
in case of loose xings. Rounded ends to
reduce impact damage. Compable with all
CDVI bracketry and accessories.
www.cdvi.co.uk
01628 531300
SURFACE MAGNETS - INTERNAL
LOCKING DEVICES
ELECTROMAGNETIC LOCKS
21
Standard magnet
V5 / S500 Series
Includes safety ropes to catch magnet
in case of loose xings. Rounded ends to
reduce impact damage. Compable with all
CDVI bracketry and accessories.
Reference Descripon Price
V5S/S500 Standard magnet £94.30
V5SR/S500M Standard magnet, monitored £99.90
SD500 Double standard magnet £188.50
SD500M Double standard magnet. monitored £201.50
C Series
Magnec locks
Surface mount
Up to 400kg holding force
Innovave visual indicaon
No moving parts
Designed with safety features
Security “catch” ropes
12/24Vdc
550mA @ 12Vdc
225mA @ 24Vdc
255 x 50 x 27mm single
Surface mount
Up to 500kg holding force
Innovave visual indicaon
No moving parts
Designed with safety features
Security “catch” ropes
12/24Vdc
550mA @ 12Vdc
225mA @ 24Vdc
266 x 66 x 40mm single
532 x 66 x 40mm double
Morce & surface mount
Monitored as standard
Entry level products
12 month warranty
C3 series, up to 300kg
C5 series, up to 500kg
C3M11 = 228 x 38 x 27mm
C3S11 = 255 x 45 x 26mm
C3S12 = 504 x 45 x 26mm
C5S11 = 273 x 65 x 40mm
C5S12 = 540 x 65 x 40mm
12/24Vdc
550mA @ 12Vdc (per side if double)
225mA @ 24Vdc (per side if double)
C3M11
C3S11
C5S11
Reference Descripon Price
C3M11 Morce magnet, monitored £42.50
C3S11 Mini magnet, monitored £42.50
C3S12 Double mini magnet, monitored £84.90
C5S11 Standard magnet. monitored £75.20
C5S12 Double standard magnet, monitored £150.30
www.cdvi.co.uk
01628 531300
ELECTROMAGNETIC LOCKS - INTERNAL
RF-MAGNET
TX26-E2 TX26-E4
22
 Doorposionmonitoring
DPM Series
Retrot to V-series surface magnets
Signals door status (not lock)
Changeover signalling (Com, NO, NC)
Ideal for access control monitoring
Suitable for auto-relock
Reference Descripon Price
DPM300 DPM for 300 series surface magnets £4.90
DPM400 DPM for 400 series surface magnets £5.10
DPM500 DPM for 500 series surface magnets £5.20
Reference Descripon Price
RF-MAGNET-KIT1 Kit includes V3S, RF-PCB, 2 x TX26-E2 £133.20
TX26-E2 2 channel transmier £20.40
TX26-E4 4 channel transmier £22.90
RF-MAGNET-PCB RF-PCB to retrot into surface magnets £30.20
RF-MAGNET
 Radiomagnet&transmierkit
RF-MAGNET-KIT1
Surface mount V3S magnet
No moving parts
Fail safe
Built-in receiver
10 x user capacity
2 x TX26-E2 transmiers
248 x 45 x 26mm
10 user receiver
12Vdc
580mA
TX26-E2/E4
433.92MHz
2 or 4 channel
Keeloq code
83 x 48 x 16mm.
Modulaon: ASK
Baery: L1028-12V
www.cdvi.co.uk
01628 531300
 FixingSoluonsforMagnets&Armatures
Z&L
ACCESSORIES FOR ELECTROMAGNETIC LOCKS
Z&L Bracket
23
LOCKING DEVICES
ELECTROMAGNETIC LOCKS
300L
300/500Z
Example showing outward opening door
Example showing inward opening door
Door frame Door frame Door frame
“L” Bracket
“L” Bracket
Electromagnec lock Electromagnec lock Electromagnec
lock
Electromagnec lock
Electromagnec lock
Z bracket
L & Z bracket
Armature plate
Armature plate
Door
Door
Door frame
Door Door
L bracket
Reference Descripon Price
180ZL Z&L bracket for 180 series magnet £16.10
300L Adjustable L bracket for 300/400 series magnets £6.30
500L Adjustable L bracket for 500 series magnets £8.90
300ZL Z&L bracket for 300/400 series magnets £20.60
500ZL Z&L bracket for 500 series magnets £23.40
300-500Z Z bracket for 300/400/500 series magnets £14.50
300L-AC Architectural L bracket for 300 series magnets £21.60
300ZL-AC Architectural Z&L bracket for 300 series magnets £39.80
500L-AC Architectural L bracket for 500 series magnets £21.60
500ZL-AC Architectural Z&L bracket for 500 series magnets £44.20
300ZLAC
www.cdvi.co.uk
01628 531300
ACCESSORIES FOR ELECTROMAGNETIC LOCKS
Glass Door Fixings
The UBKs are U-brackets for mounng
magnec locks on glass doors:
- UBK-U = armature plate installaon
- UBK-P = electromagnec lock/bracket installaon
Suitable for glass 8-14mm thickness
UBK-U Dimensions (L x W x D): 185 x 62 x 33.5mm
UBK-P Dimensions (L x W x D): 266 x 62 x 33.5mm
Requirements for inward opening door:
2 No. UBK-P, 1 No. Z&L bracket
Requirements for outward opening door:
1 No. UBK-U, 1 No. UBK-P, 1 No. L bracket
UBK & ADH Series
Armature plate housings
AF & AS Series
Surface and ush armature housings
Removes need to drill through door
Neat, bevelled edge nish (AS)
Economy plate version (ASE)
300AS = 188 x 54.5 x 15mm
500AS = 193 x 74 x 14mm
24 www.cdvi.co.uk
cdvigroup.com
Reference Descripon Price
UBK-U U bracket for armature £27.10
UBK-P U bracket for electromagnec lock and/or brackets £44.50
ADH-KIT Adhesive kit for bonding to glass doors £45.40
300AS Reference Descripon Price
300AS Surface armature housing for 300 series £16.60
300ASE Economy surface armature housing for 300 series £10.30
300AF Flush armature housing for 300 series £10.30
500AS Surface armature housing for 500 series £19.60
500ASE Economy surface armature housing for 500 series £12.90
500AF Flush armature housing for 500 series £12.90
 Flush&surfacemagneclocks
External Series
Stainless steel construcon
Extremely reliable - no moving parts
Fail safe
Electronics internally protected
Flush & surface versions
For use in harsh environments
Face & side mount (surface magnets)
12 or 24V DC
550mA @ 12Vdc
225mA @ 24Vdc
I180ER/EM180 / I180SR/ES180
EM180 (ush) 206 x 32 x 25mm
ES180 (surface) 175 x 33 x 24mm
Holding force up to 180kg
Monitored
I300ER/EM300
228 x 39 x 27mm
Morce mount
Holding force up to 300kg
Monitored
I400SR/ES400
230 x 43 x 30mm
Surface mount
Holding force up to 400kg
Monitored
I500E/EM500
288 x 64 x 38mm
Morce mount
Holding force up to 500kg
I500SR/ES500
230 x 61 x 40 mm
Surface mount
Holding force up to 500kg
Monitored
P250D80
12/24Vdc
80mm diameter, 38mm depth
EXTERNAL ELECTROMAGNETIC LOCKS
I500SR/ES500I400SR/ES400I180SR/ES180
LOCKING DEVICES
ELECTROMAGNETIC LOCKS
25
www.cdvi.co.uk
cdvigroup.com
I500E/EM500I300ER/EM300I180ER/EM180
Reference Descripon Price
I180ER/EM180 Morce magnet, monitored £110.20
I300ER/EM300 Morce magnet, monitored £141.70
I500E/EM500 Morce magnet £132.40
I180SR/ES180 Surface magnet, monitored £115.70
I400SR/ES400 Surface magnet, monitored £98.10
I500SR/ES500 Surface magnet, monitored £117.20
ES-L-400 L bracket for I400SR/ES400 £7.20
ES-L-500 L bracket for I500SR/ES500 £9.30
ES-Z Z bracket for I400SR/ES400 & I500SR/ES500 £14.70
P250D80 Surface round magnet £140.10
P250D80
26
ELECTROMAGNETIC LOCKS
 VercalRetrotHousingSeries
BO600RP
Secure surface mount
Holding force spread evenly - no door exing
Easy & quick installaon
Pre assembled
SAA (san anodised aluminium) nish as standard
Aesthec
Monitored magnets
Suitable for metal, wood and glass doors
Ideal for retrot applicaons
Pre-drilled mounng holes
Opons:
- Full length handle 2500mm
- Mid posion handles 400mm & 600mm
- Aluminium rail spacer to pack out handle
- Aluminium cable tray for cable management
- Installaon on glass door (UBK25)
- RAL colour
- Cut to size
Holding force: up to 300kg per magnet
Dimensions (L x W x D):
BO600RP/BO600RP3V 2500 x 105 x 63mm
P300RP 400 x 105 x 63mm
P600RP 600 x 105 x 63mm
12/24Vdc
550mA @ 12Vdc (per magnet)
275mA @ 24Vdc (per magnet)
60
43,4
ALMA
REO
7,7
37
63,2
43,4
8,8
30,9
28,6
2,3
5
105
55
DOOR FRAME FIXED
LEAF
DOOR OPENING
LEAF
BO600RP
PLASTIC HANDLE
P300RP
40CM Handle
Reference Descripon Price
BO600RP 2500mm handle c/w 2 magnets £351.20
BO600RP3V 2500mm handle c/w 3 magnets £498.60
P300RP 400mm handle c/w 1 magnet £138.50
P600RP 600mm handle c/w 2 magnets £240.30
www.cdvi.co.uk
01628 531300
27
LOCKING DEVICES
ELECTROMAGNETIC LOCKS
 HorizontalRetrotHousing
BO600RH
Secure surface mount
Holding force spread evenly
Easy & quick installaon
Pre assembled
SAA nish as standard
Aesthec
Monitored magnets
Suitable for metal, wood and glass doors
Ideal for retrot applicaons
Pre-drilled mounng holes
Opons:
- Aluminium rail spacer to pack out handle
- Aluminium cable tray for cable management
- Installaon on glass door (UBK25)
- RAL colour
- Cut to size
Holding force: Up to 300kg per magnet
Dimensions (L x W x D): 925 x 105 x 63mm
12/24Vdc
Consumpon:
550mA @ 12Vdc (per magnet)
275mA @ 24Vdc (per magnet)
60
43,4
7,7
37
63,2
43,4
8,8
30,9
28,6
2,3
105
ALMA REO
555
DOOR
OPENING
LEAF
ALUMINIUM CABLE TRAY
ELECTROMAGNETIC LOCKS
DOOR
FRAME
Reference Descripon Price
BO600RH 925mm horizontal handle c/w 2 magnets £230.60
www.cdvi.co.uk
01628 531300
28
ALMA
REO
Aluminium Cable tray
Aluminium rail spacer
RETROFIT HOUSING AND HANDLE ACCESSORIES
Ideal for hiding cables
Can be adhered to glass doors/frames
Dimensions (L x W x D): 2500 x 43 x 10mm
Material: SAA nish
Stackable to pack out handle
Aluminium rail spacer for:
- BO600RH horizontal retrot housing
- BO600RP vercal retrot housing
- P300RP and P600RP handles
Dimensions (L x W x D): 2500 x 43 x 5mm
Materal: SAA nish
60
43,4
ALMA
REO
7,7
37
63,2
43,4
8,8
30,9
28,6
2,3
5
105
55
DOOR FRAME FIXED
LEAF
DOOR OPENING
LEAF
- for concealing cables
- spacer rail, can be stacked
to increase spacing as
required
Accessories to compliment the
handles & housings
Reference Descripon Price
REO Aluminium spacer £27.50
Reference Descripon Price
ALMA Aluminium cable tray £63.70
www.cdvi.co.uk
01628 531300
29
REOMA
UBK25
CABB
Cable tray & spacer kits
Glass door U-bracket
Extension cable for retrot housing (2 electromagnec locks)
RETROFIT HOUSING AND HANDLE ACCESSORIES
Kits include 2 cable trays and 2 spacers
600mm & 2500mm kits available
Material: SAA nish
Full length U bracket
Rubber glass protector
Requirements for single glass door, wood/metal frame:
1 No. UBK25
Requirements for single glass door & glass frame:
2 No. UBK25
Glass 8-14mm thick
Dimensions (L x W x D): 2500 x 62 x 33.5mm
Extension cable with terminal
block
Compable with all Diax® retrot housings
Length: 2000mm.
LOCKING DEVICES
ELECTROMAGNETIC LOCKS
Reference Descripon Price
REOMA60 600mm cable tray and spacer kit £42.70
REOMA 2500mm cable tray and spacer kit £164.60
Reference Descripon Price
CABB 2000mm extension cable £37.90
Reference Descripon Price
UBK25 2500mm glass door U bracket £170.70
www.cdvi.co.uk
01628 531300
30
ELECTROMAGNETIC LOCKS
 ArchitecturalLockingSoluons
BO800 SERIES
Armature Handle housing
Screw cover
400 kg
Cover
DOOR LEAF
BO800 prole PRP800
Secure surface mount
Holding force spread evenly - no door exing
Easy & quick installaon
Pre assembled
SAA nish as standard
Aesthec
Monitored magnets
Suitable for metal, wood and glass doors
Ideal for retrot applicaons
Pre-drilled mounng holes
Opons:
- Full length handle 2500mm
- Mid posion handles 400mm & 600mm
Holding force: up to 400kg per magnet
Dimensions (L x W x D):
BO800RN/BO1200RN 2500 x 136 x 68mm
BO800RN3M/BO1200RN3M 3000 x 136 x 68mm
PBO400RN40 400 x 136 x 68mm
PBO800RN60 600 x 136 x 68mm
12/24Vdc
550mA @ 12Vdc (per magnet)
275mA @ 24Vdc (per magnet)
Reference Descripon Price
BO800RN 2500mm handle c/w 2 magnets £369.80
BO800RN3M 3000mm handle c/w 2 magnets £413.10
BO1200RN 2500mm handle c/w 3 magnets £452.60
BO1200RN3M 3000mm handle c/w 3 magnets £499.70
PBO400RN40 400mm handle c/w 1 magnet £144.70
PBO800RN60 600mm handle c/w 2 magnets £239.90
PRP800 2500mm secon for reverse side of door £72.90
UBK25 2500mm glass door U bracket £170.70
www.cdvi.co.uk
01628 531300
31
IT REALLY IS A SIMPLE STORY........
..........QUICK, SIMPLE, SECURE
Visit www.youtube.com/watch?v=y4PezoEWoQM to view the
complete movie, and see for yourself how easy the unit is to install.
1 - Prepare for installaon 2 - Fit the pre assembled magnet housing
3 - Connect the wiring 4 - Snap on the magnet housing cover
5 - Align the armature handle 6 - Drill and x the armature handle
7 - Snap on handle cover, and test.
LOCKING DEVICES
ELECTROMAGNETIC LOCKS
www.cdvi.co.uk
01628 531300
32
FIRELOCK
Lock which operates under side load
FIRELOCK
Reference Descripon Price
FL12 Firelock, 12Vdc £359.30
FL2448 Firelock, 24/48Vdc £359.30
FLH Stainless surface housing for Firelock £47.30
The new re-launched version of the FIRELOCK from CDVI oers high quality,
fail safe locking with the important feature of operaon under side-load.
Firelock is a high performance and versale lock to suit many requirements.
• For use on emergency exits
• Non-handed
• 20mm stainless bolt
• Holding Force up to 500kg
• Tested to operate at 100kg side load
• Fail safe
• Robust
• Monitored as standard NO/NC
• For single or double door use
• Oponal: stainless surface housing
12Vdc or 24/48Vdc
500mA @ 12V dc
250mA @ 24V dc
125mA @ 48Vdc
350 x 34 x 48mm (lock)
150 x 34 x 22mm (keeper)
Self aligning shearlock
Tradional shearlock
Reference Descripon Price
P1200SHL30/SHL1200 Tradional shearlock £196.90
SHL1200H Stainless surface housing for SHL1200 £47.30
30mm wide
6mm gap tolerance
1200kg shear force
Monitored
Flush (surface housing available)
12-24Vdc
500mA, inrush 2.2A @ 12Vdc
250mA, inrush 1.1A @ 24Vdc
267 x 30 x 34mm (lock)
267 x 30 x 34mm (armature)
P/SHL1200
www.cdvi.co.uk
01628 531300
LOCKING DEVICES
ELECTRIC LOCKS
33
Self aligning shearlock
Self aligning shearlock
SHEARLOCKS
Reference Descripon Price
POWERMAG25R Self aligning shearlock £215.70
PMAGH Surface stainless housing for POWERMAG25R £47.30
Reference Descripon Price
CZ3000/CSL30 Self aligning shearlock 159.30
CSL30H Surface stainless housing for CSL30 £47.30
Patented self-aligning feature
Compact
Fail safe
Monitored
800kg shear force
Flush (surface housing available)
12/24Vdc
460mA @ 12Vdc
230mA @ 24Vdc
243 x 25 x 22mm (lock)
243 x 25 x 35mm (armature)
Patented self-aligning feature
Fail safe
Monitored
1500kg shear force
Flush (surface housing available)
12/24V dc
600mA @ 12V dc
300mA @ 24V dc
230 x 31 x 27mm (lock)
230 x 30 x 37mm (armature)
POWERMAG
CZ3000/CSL30
www.cdvi.co.uk
01628 531300
34
Solenoid bolt
Fail safe
Economical
Monitored
Relock mer
12-24Vdc
250mA, inrush 1.0A @ 12Vdc
140mA, inrush 500mA @ 24Vdc
212 x 48 x 22mm
DX200
ELECTRIC LOCKING
 Doubleaconlock
Fail safe or fail secure
Lock status monitoring
Double acon (swing doors)
Euro cylinder provision
High grade stainless steel
Oponal backsets
12Vdc
255mA fail safe version
320mA fail secure version
255 x 25 x 43mm (25mm backset)
255 x 25 x 48mm (30mm backset)
255 x 25 x 53mm (35mm backset)
Reference Descripon Price
SDA25 Fail secure, 25mm backset £113.30
SDA30 Fail secure, 30mm backset £113.30
SDA35 Fail secure, 35mm backset £113.30
SDA25I Fail safe, 25mm backset £113.30
SDA30I Fail safe, 30mm backset £113.30
SDA35I Fail safe, 35mm backset £113.30
SDA-SH Stainless surface housing for SDA series £47.30
Reference Descripon Price
DX200 Solenoid bolt £107.40
DX200H Stainless surface housing for DX200 £47.30
SDA
www.cdvi.co.uk
01628 531300
LOCKING DEVICES
ELECTRIC LOCKS
35
ELECTRIC LOCKING
Non handed motorised bolt
Surface mount
With or without manual override
Suitable for outdoor use
Audible signal for locking error
and unlocked mode
Includes round cylinder & keys
Nylon gears
12Vdc
20mA, inrush 410mA
126 x 96 x 42mm (lock)
96 x 40 x 36mm (keeper)
  Magnecdoorholder
Motorised bolt
Wall/oor mount
Test buon
50kg holding force
Universal armature
24Vdc
80mA
80 x 70 x 42mm (VIR5)
113 x 70 x 65mm (VIRP5)
SUP-VR-REG
Reference Descripon Price
VIR5024/VIR5 Wall mount magnec door holder £25.20
SUP-VR-REG Adjustable wall extension/oor bracket for VIR5 £31.20
VIRP5024/VIRP5 Floor mount magnec door holder £34.10
VIR5024/VIR5
VIRP5024/VIRP5
Reference Descripon Price
MVA Motorised lock £66.90
MVM Motorised lock with manual override £66.90
VIR
MVM/MVA
www.cdvi.co.uk
01628 531300
INTERNAL
SUPPRESSION
ADJUSTABLE
JAW
Euro Style
G & S SERIES
Non-symmetrical (G series)
Symmetrical (S series)
Le or right handed
Adjustable jaw opon
Built-in suppression
Available in kit form
Fire rated available
Surface & ush opons
Voltage: 12 & 24Vac/dc
Current: AC/DC
- 12Vdc = 630mA (380mA constant rated)
- 12Vac = 540mA
Current for fail safe:
- 12Vdc = 200mA
- 24Vdc = 100mA
ELECTRIC STRIKES
Stainless steel faceplates
Surface Rim cases
NON-SYMMETRICAL
STRIKE KIT
36
L
FACEPLATE
STAINLESS
FACEPLATE
FIRE RATED
STRIKE
Reference Descripon Price
GAE Fail secure strike kit, 12Vac/dc £13.70
GAER Fail secure strike kit, adjustable jaw, 12Vac/dc £13.70
GAEI Fail safe strike kit, 12Vdc £21.70
GAERI Fail safe strike kit, adjustable jaw, 12Vdc £21.70
GAER24 Fail secure strike kit, 24Vac/dc, adjustable jaw £13.70
GAERI24 Fail safe strike kit, 24Vdc, adjustable jaw £22.60
GP Fail secure monitored strike, 12Vac/dc £35.70
GIP Fail safe monitored strike, 12Vdc £42.90
GPCF Fire rated fail secure strike POA
GPCF12CC Fire rated fail secure strike, connuous rated POA
SAER Fail secure strike kit, adjustable jaw, 12Vac/dc £13.70
SAERI Fail safe strike kit, adjustable jaw, 12Vdc £25.30
SR Fail secure strike, 12Vac/dc £13.30
SRCC Fail secure strike, 12Vdc, connuous rated £20.10
SIR Fail safe strike, 12Vdc £17.50
SR24 Fail secure strike, 24Vdc £14.53
SIR24 Fail safe strike, 24Vdc £21.10
LStainless faceplate with cut out for deadbolt £2.90
T204 Grey surface rim case £7.40
T208 Brass surface rim case £15.30
T204
www.cdvi.co.uk
01628 531300
ANSI reversible strike
Stainless steel jaw
Reversible - fail secure/fail safe
Monitored as standard
Long and short faceplate included
Voltage: 12Vdc
Current: 250mA nominal
Lock body: 86 x 38 x 86mm (including lip)
Short faceplate: 124 x 32 x 2mm
Long faceplate: 165 x 32 x 2mm
ARUM C/W
LONG FACEPLATE
ELECTRIC STRIKES
SHORT FACEPLATE
37
LOCKING DEVICES
ELECTRIC STRIKES
Heavy Duty
Standard moulded body
Stainless steel jaw
Fail secure & fail safe models
Monitored as standard
Voltage: 12Vdc
Current: 360mA nominal
Dead bolt strike
Reference Descripon Price
ARUM ANSI reversible strike, 12Vdc, monitored £39.80
ELU25 25mm extension lip £21.20
ELU50 50mm extension lip £21.20
Reference Descripon Price
DBR310FL Fail secure dead bolt strike, 12Vdc, monitored £91.50
DBR310FS Fail safe dead bolt strike, 12Vdc, monitored £91.50
DBR
ARUM
www.cdvi.co.uk
01628 531300
 Internal,lighttomediumtracuse
 Medium&heavytracuse
Surface as standard
Sturdy plasc
UK back-box format
Styles to suit all needs
Standard & architrave
Internal use
Dimensions:
- standard = 83 x 83 x 29mm
- architrave = 83 x 33 x 29mm
Flush or surface
Stainless steel
High impact buons
UK back-box format
External or internal use
Dimensions:
85 x 85 x 30mm standard surface
85 x 85 x 2mm standard ush
85 x 38 x 29mm architrave surface
85 x 38 x 2mm architrave ush
RTE-SS SERIES
RTE PLASTIC SERIES
BPDOORF
38
EXIT DEVICES PUSH BUTTONS
Reference Descripon Price
RTE001S Standard plasc exit buon £10.70
RTE002S Architrave plasc exit buon £12.90
BPDOORS Wide buon plasc exit buon, surface £11.60
BPDOORF Wide buon plasc exit buon, ush £9.60
RTE002S
RTEOO1S
Reference Descripon Price
RTESS Standard stainless exit buon, surface £22.50
RTESF Standard stainless exit buon, ush £14.90
RTEAS Architrave stainless exit buon, surface £26.20
RTEAF Architrave stainless exit buon, ush £17.10
RTESSD Domed stainless exit buon, surface £27.90
RTESFD Domed stainless exit buon, ush £21.40 RTEAF
RTESF
RTESSD
www.cdvi.co.uk
01628 531300
 Highprole,highimpact
All-acve target area
Push to make & break
Flush mount ts UK backbox
High quality stainless steel
“EXIT” or “Wheelchair Logo”
Dimensions: 85 x 85 x 42mm surface
85 x 85 x 14mm ush
39
EXIT DEVICES
PUSH BUTTONS
EXIT DEVICES PUSH BUTTONS
Reference Descripon Price
RTE85E-S All-acve switch, “EXIT”, surface £50.00
RTE85E-F All-acve switch, “EXIT”, ush £40.90
RTE85DL-S All-acve switch, “LOGO”, surface £50.00
RTE85DL-F All-acve switch, “LOGO”, ush £40.90
High prole, large target area
Reference Descripon Price
RTEPTO All-acve switch, “PUSH TO OPEN”, surface £64.70
RTEPTO-F All-acve switch, “PUSH TO OPEN”, ush £92.30
RTED All-acve switch, “LOGO”, surface £64.70
RTED-F All-acve switch, “LOGO”, ush £92.30
RTEPTOD All-acve switch, “PUSH TO OPEN” & “LOGO”, surface £64.70
RTEPTOD-F All-acve switch, “PUSH TO OPEN” & “LOGO”, ush £92.30
RTEPTOD-A Architrave switch, “PUSH TO OPEN” & “LOGO”, surface £37.50
Large all-acve target area
Push to make & break
Flush & surface available
High quality stainless steel
Suitable for DDA environments
Dimensions:
- standard = 130 x 130 x 42mm surface
130 x 130 x 14mm ush
- architrave = 114 x 43 x 43mm surface only
RTE ALL-ACTIVE SERIES
RTE ALL-ACTIVE SERIES
RTE85E-F
RTE85DL-F
RTE85E-S
RTEPTO
RTEPTOD
RTEPTOD-A
www.cdvi.co.uk
01628 531300
RTED
Emergency door release
Emergency unlock
Break-glass or reseable
Double-pole as standard
UK back-box format
Internal use
86 x 86 x 50mm
Reset keys included
EM SERIES
EM200
 Combinedexitbuon&emergencydoorrelease
40
EXIT DEVICES PUSH BUTTONS & EMERGENCY DOOR RELEASE
Reference Descripon Price
DBB-21-02 Stainless buon and breakglass £34.10
DBB-21-04 Domed buon and breakglass £42.60
DBB-22-02 Stainless buon and reseable door release £39.20
DBB-22-04 Domed buon and reseable door release £46.90
RTE-DBB Green double back box £9.40
MX-03 Protecve cover for emergency door release £2.10
Surface as standard
Stainless buons
Convenient and neat
UK back-box format
Styles to suit all needs
Internal use
188 x 98 x 57mm
Exit buon:
Stainless or green dome
Push to make & break
High impact
Emergency door release:
Reseable or break-glass
Double pole
Reset keys included
DBB-22-02
DBB-22-04
DBB-21-02
DBB-21-04
RTE-DBB
Reference Descripon Price
EM200 Break-glass version £10.90
EM201 Reseable version £12.90
EMKEY Spare reset key for EM201 - pack of 10 £12.30
EM200GDMGLASS Replacement glass for EM200 - pack of 10 £16.50
MX-03 Protecve cover for emergency door release £2.10
MX-03
MX-03
DBB SERIES
EM201
www.cdvi.co.uk
01628 531300
Key switches
Keyed alike or keyed to dier
Stainless steel
Surface, opon of ush
Supplied with 2 keys (round version)
Momentary or maintained versions
Euro prole opon (cylinder not included)
3-posion keyswitches available
Dimensions:
85 x 85 x 30mm standard surface
85 x 85 x 2mm standard ush
85 x 38 x 29mm architrave surface
85 x 38 x 2mm architrave ush
3-posion
keyswitch
Euro prole
keyswitch
41
EXIT DEVICES
KEYSWITCHES
EXIT DEVICES KEY SWITCHES
Reference Descripon Price
KEY-SSMAKA Surface keyswitch, maintained, keyed alike £38.80
KEY-SFMAKA Flush keyswitch, maintained, keyed alike £29.40
KEY-SSMAKD Surface keyswitch, maintained, keyed to dier £39.50
KEY-SFMAKD Flush keyswitch, maintained, keyed to dier £31.90
KEY-SSMOKA Surface keyswitch, momentary, keyed alike £38.80
KEY-SFMOKA Flush keyswitch, momentary, keyed alike £29.40
KEY-SSMOKD Surface keyswitch, momentary, keyed to dier £39.50
KEY-SFMOKD Flush keyswitch, momentary, keyed to dier £31.90
KEY-ASMAKA Surface narrow keyswitch, maintained, keyed alike £30.20
KEY-AFMAKA Flush narrow keyswitch, maintained, keyed alike £22.40
KEY-ASMOKA Surface narrow keyswitch, momentary, keyed alike £32.50
KEY-AFMOKA Flush narrow keyswitch, momentary, keyed alike £24.70
KEY-SS3MOKD 3-posion surface keyswitch, momentary, keyed to dier £48.30
KEY-SF3MOKD 3-posion ush keyswitch, momentary, keyed to dier £38.90
DW-SP-KS Digiway surface keyswitch £46.90
DW-SP-KF Digiway ush keyswitch £37.50
KEY-SSEUMA Surface euro keyswitch, maintained (no cylinder) £34.10
KEY-SFEUMA Flush euro keyswitch, maintained (no cylinder) £34.10
KEY-SSEUMO Surface euro keyswitch, momentary (no cylinder) £34.10
KEY-SFEUMO Flush euro keyswitch, momentary (no cylinder) £34.10
Digiway Plus
keyswitch
Standard
keyswitch
Architrave
keyswitch
KS SERIES
www.cdvi.co.uk
01628 531300
42
RTE-IR
EXIT DEVICES
Infrared exit device
Adjustable trigger range
Red/green indicators
Stainless faceplate
Simple to install
Fits standard UK back box
Surface version available
86 x 86 x 8mm
12-20Vdc
1A contacts @ 30V
0.5 - 20 seconds adjustable latch me
Reference Descripon Price
RTE-IR-F Infrared exit switch, ush £55.30
RTE-IR-S Infrared exit switch, surface £68.80
Microwave sensor
Small and neat design
Adjustable detecon area
Easy to install
Ideal for swing and sliding doors
Internal & external use
120 x 70 x 42mm
12-30Vdc/12-24Vac
80mA max
 Idealforreleasingmagneclocks
SAA standard nish
Green available as special order
Double pole switch COM/NC/NO
Simple surface mount
Can be cut down to 680mm
860 x 62 x 60mm
3A contacts @ 24V
Reference Descripon Price
MSPB Microswitch push bar, SAA nish £125.30
MSPBG Microswitch push bar, gloss green nish (special order) £134.80
Reference Descripon Price
DWHR50-UNI Microwave sensor for door release £136.70
DWHR50-WC Weathershield for DWHR50-UNI £10.60
RTE-IR-F
Surface
back box
MICROSWITCH PUSH BARS
DWHR50-UNI
www.cdvi.co.uk
01628 531300
ACCESSORIES
DOOR LOOPS, TIMERS
& RELAYS
43
Flexible power transfer
Facilitates transfer of cable/power
from frame to door leaf
FLEX30 & FLEX60 excellent value
with stainless steel loop and metal
end caps
FM tradional door loop, 45CM
ADL includes vandal
resistant screws, 60CM
CDL concealed on hinge-line
Flexible loop has 7mm
internal diameter
2 & 3 pin transfer hinges
Spring-loaded contacts, max 3A
DOOR LOOPS & HINGES
DOOR LOOPS & ACCESSORIES
FLEX30
FLEX60
ADL
FM
C2P C3P
VHLR
VHLD
CDL
Reference Descripon Price
FLEX30 30cm compact door loop £6.30
FLEX60 60cm compact door loop £8.40
GF45/FM 45cm tradional door loop £10.60
GF60/ADL 60cm vandal resistant door loop £12.80
GFI/CDL Concealed door loop £9.30
C2P 2-pin transfer hinge £6.90
C3P 3-pin transfer hinge £10.70
Accessories to compliment your system
Reference Descripon Price
TH827-240 7-day mer, 240Vac £27.80
TH827-12 7-day mer, 12Vac/dc £27.80
TH827-24 7-day mer, 24Vac/dc £27.80
TH857 7-day mer, 240Vac £32.70
VHLR Universal relay, 12-24Vac/dc £17.60
VHLD Delay module for fail safe devices £12.80
TPG1 0-20 second mer, 12Vdc £28.60
SM1228 24Vdc to 12Vdc reducing module £39.80
7-day mers, various input voltage
Handy relay module
Delay module for fail safe locks
0-20 second pcb mer
Voltage reducer 24Vdc to 12Vdc
All very useful accessories
TH827 series
TH857
SM1228
TPG1
TIMERS & RELAYS
www.cdvi.co.uk
01628 531300
44
INFRARED PHOTOCELLS
Adjustable & vandal resistant
 Flatxedphotocells
Acve infrared photocells
Flat style for discreet mounng
5 or 10M range
Internal or external use
12-24V ac/dc
Fixed opcs
IP55
90 x 60 x 22mm
Acve infrared photocells
Adjustable
10M or 20M range
Vandal resistant opon
Internal or external use
12-24V ac/dc
Adjustable opcs
IP55
90 x 60 x 60mm (SEF2420)
99 x 69 x 69mm (SEF2410AVN & 20AVN)
SEF2420
SEF2410AVN/20AVN
Reference Descripon Price
SEF2405 5 metre at photocell £30.80
SEF2410 10 metre at photocell £38.70
Reference Descripon Price
SEF2420 20 metre adjustable photocell £55.40
SEF2410AVN 10 metre adjustable photocell, vandal resistant case £62.90
SEF2420AVN 20 metre adjustable photocell, vandal resistant case £78.90
SEF SERIES
www.cdvi.co.uk
01628 531300
SEF SERIES
DC metal cased with charger
PSU SERIES
Full current to load
Addional baery charging current
Short circuit protecon
Mains transient protecon
Baery current liming circuit
12Vdc & 24Vdc available
1A, 2A & 3A versions
230 x 200 x 80mm standard case
355 x 330 x 80mm large case
8AH baery capacity standard case
18AH baery capacity large case
POWER MANAGEMENT
POWER SUPPLIES
45
B7.5
CA1A
CA1R
POWER MANAGEMENT POWER SUPPLIES
Reference Descripon Price
PSU12-1SM 12Vdc, 1A power supply, standard case £44.30
PSU12-2SM 12Vdc, 2A power supply, standard case £70.90
PSU12-2LSM 12Vdc, 2A power supply, large case £88.50
PSU12-3SM 12Vdc, 3A power supply, standard case £87.80
PSU24-2SM 24Vdc, 2A power supply, standard case £86.50
B7.5 12Vdc, 7AH rechargeable baery £29.90
DC & AC without charger
DIN rail mount
Sturdy polycarbonate
Regulated (not ARD212)
Primary & secondary protecon
12Vdc & 24Vdc models
Integral relay/mer model
142 x 92 x 60mm
Input voltage 230Vac
PSU SERIES
Reference Descripon Price
ARD12 12Vdc, 1.0A PSU £61.30
ARD12T 12Vdc, 1.0A PSU with integral relay and mer £72.70
ARD212 12Vdc, 2.0A PSU with addional 12Vac, 0.35A output £50.80
ARD24 24Vdc, 1.0A PSU £101.50
CA1A 4/8/12Vac transformer £16.90
CA1R 12/24Vac transformer, DIN mount £19.30
ARD12/ARD212/ARD24
ARD12T
ARD Range
Economical
AC transformer
4/8/12V ac, 12VA (CA1A)
12/24V ac, 24VA (CA1R)
81 x 56 x 43mm CA1A
90 x 65 x 55mm CA1R
CA Range
Standard case
Large case
www.cdvi.co.uk
01628 531300
46
 Doorautomaon
DIGIWAY PLUS
DOOR AUTOMATION
Reference Descripon Price
DWPS102U Digiway Plus with universal arm £813.90
DWSE55 55mm extension sha for DWPS102U £41.90
DWPCS Interconnecng cable for automaon of double-doors £15.50
DW-SP-KS Digiway surface keyswitch £46.90
DW-SP-KF Digiway ush keyswitch £37.50
SAA standard nish
Inward or outward opening doors
LCD prompt for easy installaon
Self learning mode
No end stops required
Built-in radio receiver
Includes radio transmier
Integral baery standby
Fully programmable
511 x 110 x 90mm
230Vac
Only weighs 5kg
13.5Vdc available for sensors
12Vdc, 1.0A available for locks
Free installer training at our facility in High Wycombe
Please check suitability of door and applicaon with CDVI
We welcome installers to aend our hands-on training modules held
at our facility in High Wycombe. We cover two main topics which are
benecial to you the installer:
1. The success of your installaon. Each door is dierent, so we
ensure you are familiar with all aspects of installaon and set up
depending on the door size and the type of use.
2. We ensure you understand the original BS7036 and the new EN16005
regulaons, and we will instruct you how to complete a risk assessment
and be familiar with the devices to sasfy the regulaons.
These training modules are free of charge, so call us now to book your
place on 01628 531300.
Door weight/height graph:
Zone A - High trac use
Zone B - Low trac use
Zone C - Use at reduced speed
Zone D - Not allowed
www.cdvi.co.uk
01628 531300
DIGIWAY
AUTOMATED DOOR ENTRY
47
Devices & compliance kits
DOOR AUTOMATION
DWSS-3M2/C
Infrared safety sensor
Posional sensing
Easy to install
Monitored sensor for EN16005
700 x 45 x 45mm
12/24V ac/dc
Changeover relay
EN16005
Complete kits available
Single & double door
Reference Descripon Price
DWHR50-UNI Microwave sensor for door release £136.70
DWHR50-WC Weathershield for DWHR50-UNI £10.60
DWSS-3M2/C Door safety sensor, monitored £357.20
DWS-FGW Fingerguard, white £56.10
DWS-KCSIGN Self adhesive “KEEP CLEAR” sign £5.40
DWS-ADSIGN Self adhesive “AUTOMATIC DOOR” sign £3.80
EN16005-KIT-U Digiway Plus and safety kit for single door £1602.60
EN16005-KIT-UD Digiway Plus and safety kit for double door £3205.10
DWS-ADSIGN
DWS-KCSIGN
DWS-FGW
EN16005-KIT-U DWPS102U, 2 x DWSS-3M2/C, DWS-FGW, 2 x DWS-KCSIGN, 2 x DWS-ADSIGN
EN16005-KIT-UD 2 x DWPS102U, 4 x DWSS-3M2/C, 2 x DWS-FGW, 4 x DWS-KCSIGN, 4 x DWS-ADSIGN, DWPCS
DWSS-3M2/C
Explanaon of kits:
SENSORS & SAFETY
Free installer training at our facility in High Wycombe
to EN16005 compliance standard
Digiway Plus
keyswitch
www.cdvi.co.uk
01628 531300
 Hand-heldtransmiers
Full range of hand-held transmiers
Rolling code
Integral prox opon
Wiegand output
Ideal for vehicle automaon
1, 2 & 4 channel models
Up to 200m range
Frequency: 433.92MHz
Modulaon: ASK
Range: 100-200M in open space
Dimensions:
- 83 x 48 x 16mm (TX26E1, E2 & E4)
- 60 x 36 x 16mm (TX26AM2)
48
TRANSMITTERS
We can oer our hand-held transmiers with the
opon of an integral proximity tag
Please contact our sales oce for details.
TX26-E1
TX26-AM2-BLACK
TX26-E4
TX26-E2
SESMT204
Reference Descripon Price
TX26-E1 1 channel transmier, rolling code £20.40
TX26-E2 2 channel transmier, rolling code £20.40
TX26-E4 4 channel transmier, rolling code £22.90
TX26-AM2-BLACK 2 channel mini transmier, rolling code, black £22.40
SESMT204 Holder for transmiers - pack of 10 £25.50
TX SERIES
Please contact the sales oce for xed code opons
www.cdvi.co.uk
01628 531300
TRANSMITTERS
Rolling code
Internal wall mount transmier
External wall mount transmier
Keypad transmier
Touch-sensive transmier
Infrared transmier
Adaptable transmier
Ideal for wire-free applicaons
Up to 200m range
Frequency: 433.92MHz
Modulaon: ASK
Range: 100-200M in open space
Encoding: Keeloq® Hopping code
 Wallmounttransmiers
TX SERIES
49
WIRELESS
TRANSMITTERS
Adaptable
transmier can be
ed into a variety
of switching devices
SETMC1C9V
TX26-TM
80 x 80 x 25mm
TSW2641E1
82 x 67 x 66mm
SENSRAD
90 x 60 x 25mm
GALEOR
110 x 75 x 15mm
Reference Descripon Price
TX26-TM 4 channel, internal wall mount transmier £30.40
TSW2641E1 1 channel, heavy duty external wall mount transmier £41.20
GALEOR 1 channel keypad transmier, 22 users £138.30
SENSRAD 1 channel, touch sensive wall mount transmier £42.30
SENSIR 1 channel, infrared wall mount transmier £38.00
SETMC1C9V 1 channel universal transmier for adapng switches £27.10
OPR-KIT 1 channel universal transmier and 1 channel NANO receiver £54.50
NANO
Receiver
SENSIR
90 x 60 x 25mm
www.cdvi.co.uk
01628 531300
Internal receivers
RX SERIES
1 & 2 channel receivers
Rolling code & xed code opon
Timed and pulse operaon
Wiegand receiver opon
Easy learn of transmiers
12-24V ac/dc
Extension tuned aerial (SEA433)
Frequency: 433.92MHz
Keeloq® Hopping code
Fixed code (RX39)
Modulaon: ASK
Range: 100-200m in open space
Memory:
- 85 transmiers (SEL2641R433NN & RX26-433I)
- Unlimited transmiers (SELWR433)
- 100 transmiers (RX39-433)
Dimensions:
- 50 x 32 x 20mm (SEL2641R433NN)
- 105 x 45 x 28mm (RX26-433I & RX39-433))
- 105 x 45 x 28mm (SELWR-433)
50
RECEIVERS
SEL2641R433NN (NANO)
50 x 32 x 20mm
RX26-433I/RX39-433
105 x 45 x 28mm
SELWR433
105 x 45 x 28mm
Reference Descripon Price
RX26NANO 1 channel receiver, rolling code £28.50
RX26433I 2 channel receiver, rolling code £44.90
SELWR433 Wiegand receiver, 26 bit £74.80
SEA433 Tuned antenna for increased range £18.70
Please contact the sales oce for xed code opons
www.cdvi.co.uk
01628 531300
51
RECEIVERS
WIRELESS
RECEIVERS
External rated receivers.
1, 2 & 4 channel.
12-24V ac/dc opon.
240V ac opon.
Rolling code units.
Extension tuned aerial (SEA433).
Frequency: 433.92MHz
Encoding: Keeloq® Hopping code
Modulaon: ASK
Range: 100-200m in open space
Memory: 85 transmiers
Dimensions:
- 80 x 80 x 50mm (RX26-Z1, Z2 & Z4)
- 140 x 115 x 53mm (RX26-433-C2V & C4V)
SEA433:
- RG58 cable
- 50 Ohm characterisc impedance
- 3.5M length
External receivers
RX SERIES
RX26-Z1
RX26-433-C4V
SEA433
Reference Descripon Price
RX26-Z1 1 channel receiver, rolling code, 12/24V ac/dc £40.80
RX26-Z2 2 channel receiver, rolling code, 12/24V ac/dc £44.90
RX26-Z4 4 channel receiver, rolling code, 12/24V ac/dc £54.10
RX26-C2V 2 channel receiver, rolling code, 230Vac £59.90
RX26-C4V 4 channel receiver, rolling code, 230Vac £68.30
SEA433 Tuned antenna for increased range £18.70
www.cdvi.co.uk
01628 531300
52 www.cdvi.co.uk
01628 531300
METAL FABRICATION
 Highqualitymetalfabricaon
READER/INTERCOM POSTS
GNP-1C
RPSS
SSP-PED
RPSS-CUT
RPSS100D
SSP-DDA-CAR
Reference Descripon Price
RPSS Stainless post, angled top, 100 x 100 x 1000mm £280.50
RPSS-CUT Stainless post, angled top, UK back box cut-out, 100 x 100 x 1000mm £335.90
RPSS-100D Stainless post, round, angled top, 100mm Ø x 1000mm £336.80
SSP-DDA-CAR Stainless post, 100 x 100 x 1200mm £280.50
SSP-PED Stainless post, 100 x 100 x 1600mm £285.60
GNP-1C Car height post, powder coated black, 50 x 50 x 1000mm £116.70
GNP-1L Lorry height post, powder coated black, 50 x 50 x 2100mm £196.00
GNP-2CL Dual car/lorry height post, powder coated black, 50 x 50 x 2100mm £206.00
A range of posts to compliment
and optimise any access control or
automation project. With an
understanding that aesthetics and
practicality are equally important,
these products are suitable to t in any
environment.
Where aesthetics are important, the
stainless steel range includes models to
cater for car, wheelchair and pedestrian
users. This range is manufactured from
high grade stainless steel and has a
polished and hardened grain nish.
The RPSS-CUT includes a 60 x 45mm hole
with M3.5 tapped holes to accept standard
UK plates to t exit buttons, key switches,
readers etc.
Where practicality is more important than
aesthetics, the GNP range is made from
steel with a black, hardened powder-coat
nish. These are ideal for car and lorry
parks.
For dimensional drawings, please contact
your local distributor or call CDVI.
GNP-2CL
GENERAL INFORMATION
53
GENERAL INFORMATION
www.cdvi.co.uk
01628 531300
FREE TRAINING
Training Modules
We oer free training modules for our complete range of products. Because everone is
dierent, we are able to tailor the modules to suit the expectaons and requirements of
those aending. Our modules include:
Online access control
An overview of Atrium and Centaur relang to the principles of online access control
System layout opons
Funcons of web, soware and hardware
Installaon from start to nish
Advanced acons, including macros, camera support etc
Locking
Overview of dierent door types & styles
Electromagnec locks and bracketry
Strikes - euro and ANSI
Shearlocks & solenoids
Architectural handles
Special exit devices
Digiway Plus
Digiway Plus overview
Safety devices for automated doors
BS7036 regulaons
EN16005 regulaons
Hands-on set up of Digiway Plus
Refreshments are provided throughout the day, including a buet lunch.
Please contact us now on 01628 531300 or email support@cdvi.co.uk to book your place.
In House
Our dedicated demonstraon and training room in High
Wycombe oers you the opportunity to get hands-on
experience of our products.
The training modules are designed to ensure you have
the essenal knowledge to install the whole range of
CDVI products. This allows you to specify our range with
condence, and gives a great benet to your customer.
We also encourage you to bring your customers along and
use the demonstraon room to show the products you are
oering - we will provide refreshments and any sales aids
you may require.
Our training courses are free of charge, as is the use of our
demo-room for your own use.
Call us now on 01628 531300 to book your place.
GENERAL INFORMATION
54
PERSONAL NOTES
www.cdvi.co.uk
01628 531300
GENERAL INFORMATION
55
Price list
Our price list is available in Excel or Word format, both in hard copy and electronically - please contact us for details.
Demonstraon/display material
In order to present our products, we have equipment and displays ready for customer demonstraons. In the case of presentaon of a system,
please contact your local sales manager.
Media sales support
CDVI is able to provide a variety of media communicaon to enhance your show-rooms, exhibion stands, open days etc. We can supply this
in the form of posters, POS, brochures, product sheets, pop-up displays ...
In House
Our dedicated demonstraon and training room in High Wycombe oers the opportunity to get hands-on experience of our products for your
customer or for you.
Our structured training modules are specic to product types and training required.
Sales support
We will be pleased to visit you at your premises to discuss our product range, and assist in specifying the right product for your project.
Product oers
From me to me we do publish product oers. These are generally transmied via email - if you wish to receive nocaon of these oers,
please ensure you register with our sales oce to be added to our e-shot database.
Price
Prices are believed to be correct at me of going to press, but may vary
without noce. CDVI Ltd reserve the right to amend any errors or omissions.
Prices do not include any taxes or delivery charges.
Selement Terms
Approved accounts are strictly net monthly. Unestablished clients will be
required to pay with order. Whilst payments remain overdue, we will refuse
to supply any further goods unl the account has been brought up to date.
Retenon of tle
All goods remain the property of CDVI Ltd unl paid for in full.
Shipping-delivery
By whatever delivery means, equipment is at the risk of the recipient to
control the package upon arrival and nofy CDVI Ltd or the carrier for any
damage found within three days of receipt, under penalty of foreclosure .
CDVI Ltd shall not be liable in any way for failure to deliver on me whatever
the reason.
Special equipment
Special equipment will only be made/fabricated following submission of
approved drawings and specicaons. CDVI Ltd will not accept return of any
special equipment.
Guarantee
CDVI Group manufactured products enjoys a warranty period
of 5 years against faulty design and manufacture excluding fair wear and
tear. Repairs of any kind will be carried out in our workshops.
3rd party
products will be guaranteed for a period of 12 months
from date of despatch
from CDVI Ltd warehouse.
Returned Goods
All goods to be returned must be accompanied by an RMA number - this can
be acquired from our technical department or directly from our website.
Goods returned for credit will only be accepted if they are in the original
boxes, complete with instrucons and the products have not been used
- a handling charge of 20% will apply.
Full details of our terms and condions are available
upon request
Please note - due to the manufacturing and packaging process, the BO series of architectural handles
and the CDVI series of metal posts cannot be returned for credit.
GENERAL INFORMATION
SALES AIDS
CONDITIONS OF SALE
www.cdvi.co.uk
01628 531300
Any specicaons within this document (photos, drawings, features and dimensions) may be changed without prior noce.
Distributed by:
The installer’s choice
CDVI Ltd
Unit B1, Knaves Beech Business Centre,
Davies Way, Loudwater,
High Wycombe, Bucks, HP10 9QR
Phone: 01628 531300
Email: support@cdvi.co.uk
01628 531300

Navigation menu
