IBM Sterling
Connect:Enterprise for z/OS
Remote User’s Guide
Version 1.5
CEzOSRUG1107
This edition applies to the 1.5 Version of IBM® Sterling Connect:Enterprise® for z/OS® and to all subsequent releases and
modifications until otherwise indicated in new editions.
Before using this information and the product it supports, read the information in Notices on page 91.
Licensed Materials - Property of IBM
IBM® Sterling Connect:Enterprise® for z/OS®
© Copyright IBM Corp. 2000, 2011. All Rights Reserved.
US Government Users Restricted Rights - Use, duplication or disclosure restricted by GSA ADP Schedule
Contract with IBM Corp.
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 3
Contents
Chapter 1 Sterling Connect:Enterprise FTP Implementation 7
Data Representation and Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Data Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
ASCII . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
EBCDIC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Format Control for Character Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Data Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Transfer Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Stream . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Block. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Compressed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Controlling FTP Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Implementing Firewall Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Implementing the Clear Control Channel (CCC) Feature . . . . . . . . . . . . . . . . . . 14
Connecting to a Sterling Connect:Enterprise FTP Server . . . . . . . . . . . . . . . . . . . . . 14
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Log On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Sterling Connect:Enterprise FTP Server and Equivalent Client Commands . . . . . . . 15
SITE Command Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Sample Output of STATUS Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
VSAM Batch Status Flags. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Different DIRFORM Layouts Returned by LIST . . . . . . . . . . . . . . . . . . . . . . . . . 31
Sterling Connect:Enterprise Variations from Standard FTP Commands. . . . . . . . . . 35
User Batch ID Syntax and Formats. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
delete or mdelete Command. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Sterling Connect:Enterprise FTP del, delete, and mdelete Command Syntax 37
Batch Selection with Sterling Connect:Enterprise FTP del Command . . . . . 37
dir Command. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Sterling Connect:Enterprise FTP dir Command Syntax . . . . . . . . . . . . . . . . 39
Batch Selection with Sterling Connect:Enterprise FTP dir Command . . . . . 39
get or mget Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Sterling Connect:Enterprise FTP get Syntax . . . . . . . . . . . . . . . . . . . . . . . . 40
Batch Selection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Batch Transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Batch Status Flags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Contents
4IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
put or mput Command (STOR) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Sterling Connect:Enterprise FTP put Syntax . . . . . . . . . . . . . . . . . . . . . . . . 42
put or mput Command (STOU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Sterling Connect:Enterprise FTP put Syntax . . . . . . . . . . . . . . . . . . . . . . . . 44
pwd Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
pwd Command Syntax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
cd Command. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
NLST Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Sterling Connect:Enterprise NLST Command Syntax . . . . . . . . . . . . . . . . . 46
Batch Selection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Preparing Batches for the Sterling Connect:Enterprise FTP Server . . . . . . . . . . . . . 47
Using $$Commands and /*Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
$$Commands and /*SIGNON with /*BINASC. . . . . . . . . . . . . . . . . . . . . . . . 48
$$Commands and /*SIGNON without /*BINASC . . . . . . . . . . . . . . . . . . . . . 49
Syntax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
$$ADD Command Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Chapter 2 Communicating with SNA Sites 51
Start and End a Session . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Using Sterling Connect:Enterprise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Wildcard Characters in Sterling Connect:Enterprise Names. . . . . . . . . . . . . . . . . . . 52
Terminal-Dependent Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
SNA Sites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
MLU (Multiple Logical Unit) Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Device Media Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Console Display Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Data Compression . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Batch Separation Using FMHs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
SNA Transparency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Disconnect Interval . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
EBCDIC Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Sample Data Streams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
SNA Site Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Chapter 3 Communicating with BSC Sites 65
Start and End a Session . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Sterling Connect:Enterprise Support for Signon (BSC Sites) . . . . . . . . . . . . . . . 65
Host-Initiated Communications (Auto Connect) . . . . . . . . . . . . . . . . . . . . . . . . . 66
Using Sterling Connect:Enterprise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Wildcard Characters in Sterling Connect:Enterprise Names. . . . . . . . . . . . . . . . . . . 67
Terminal-Dependent Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
BSC Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Free-Form BSC SIGNON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Blank Compression . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Blank Truncation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Blocked Data Records . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Contents
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 5
BSC Transparency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Record Separator Override . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Use of $TURNLINE$. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Temporary Text Delay (TTD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
WAIT Acknowledgement (WACK). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Sample Data Streams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
BSC Site Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Chapter 4 Remote User Commands 73
Submit Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
$$ADD Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
$$ADD Defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Multiple Batches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Syntax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
$$DELETE Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Syntax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
$$DIRECTORY Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Syntax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
SNA Logon System Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Syntax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
SNA LOGOFF and $$LOGOFF System Functions . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Syntax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
$$REQUEST Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Syntax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Parameter Interrelationships . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
$$REQUEST Sample Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Chapter 5 Error Messages 85
Remote User Error Messages (*** ERROR ***) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Notices 91
Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Index 95
Contents
6IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 7
Chapter 1
Sterling Connect:Enterprise FTP
Implementation
The IBM® Sterling Connect:Enterprise® for z/OS® FTP feature provides the standard FTP
interface to an FTP client. It operates as an FTP server for connections from remote FTP clients.
Sterling Connect:Enterprise places restrictions on the use and meaning of some FTP commands,
which are discussed in this chapter. In addition, remote users can embed $$ADD commands in an
FTP data stream to add data to the host data repository on the Sterling Connect:Enterprise FTP
server. The last section in this chapter deals with using the $$ADD command and how data files
must be formatted in order for the Sterling Connect:Enterprise FTP server to properly scan and
interpret the $$ADD command including the data.
Data Representation and Storage
Transferring files between different computer systems introduces a myriad of issues emanating
from the differences between computer systems. The IBM System z/OS architecture uses an 8-bit
EBCDIC byte to represent character data. The IBM PS/2 system uses an 8-bit ASCII byte to
represent character data. Some computers use a 7-bit ASCII code. The IBM PS/2 system organizes
files as a continuous stream of data. The IBM System z/OS organizes files into records. With all
these differences, Sterling Connect:Enterprise must provide a method of transferring these files and
making them available for use on the receiving system.
The Sterling Connect:Enterprise FTP feature deals with these issues. FTP provides for FTP client
and FTP server implementations to negotiate the data representation and storage types through the
use of the data type, data structure, and transmission mode standard specifications.
Note: You are responsible for specifying the Sterling Connect:Enterprise FTP server options and the
remote FTP client options so that the data transferred is usable by the receiving host.
Chapter 1 Sterling Connect:Enterprise FTP Implementation
8IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
Data storage attributes are determined by the host system. The Sterling Connect:Enterprise FTP
feature stores character data in EBCDIC and image (binary) data as received. Data received as
NVT-ASCII is converted to EBCDIC before being added to the current working data repository.
Sterling Connect:Enterprise performs the role of FTP server and the types are set by the remote FTP
client.
The Sterling Connect:Enterprise FTP feature transfers data as 8-bit bytes. If your remote FTP client
uses a different byte length, it is up to you to implement the appropriate conversion between local
byte size and the Sterling Connect:Enterprise FTP feature 8-bit byte transfer length.
Data Type
Data type specifies how the receiver interprets the data bits being transferred. The receiver is either
the Sterling Connect:Enterprise FTP server or the remote FTP client.
Sterling Connect:Enterprise FTP server assumes that the remote FTP client uses the ASCII
character set. If the remote site does not use the ASCII character set, the remote FTP client must
send the TYPE command to change the data type to EBCDIC or BINARY.
The FTP standard includes four data types: ASCII, EBCDIC, image, and local. Sterling
Connect:Enterprise FTP server provides the ability to specify three data types: ASCII, EBCDIC,
and image. The local byte size is 8 bits (L 8) for Sterling Connect:Enterprise, and cannot be
changed.
ASCII
ASCII is character data. The sender converts the data from its internal representation into standard
8-bit NVT-ASCII before sending the data. Each line of data ends with a carriage-return-line-feed
(<CRLF>). An ASCII <CRLF> is hexadecimal '0D0A'.
If Sterling Connect:Enterprise is receiving, the data is translated from NVT-ASCII to EBCDIC and
the <CRLF> sequences are replaced with a new line (<NL>) character before the data is added to
the current data repository. An EBCDIC <NL> is hexadecimal '15'.
If Sterling Connect:Enterprise is sending, the data is translated from EBCDIC into NVT-ASCII and
the <NL> characters are replaced with the <CRLF> characters before transmitting the data to the
remote FTP server.
ASCII (TYPE A) is the default data type for Sterling Connect:Enterprise FTP feature.
EBCDIC
EBCDIC is character data. The EBCDIC data type is the most efficient way to transfer data between
EBCDIC hosts.
If Sterling Connect:Enterprise is receiving, the data is not translated before being added to the
current data repository.
If Sterling Connect:Enterprise is sending, the data is not translated before being transmitted.
Not all remote ASCII hosts accept data type EBCDIC. Some remote FTP servers reject data type
EBCDIC. Some hosts accept data type EBCDIC and store it as binary. Other hosts accept data type
EBCDIC as binary, and then translate the data into data type ASCII.
Data Representation and Storage
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 9
Format Control for Character Data
Data types ASCII and EBCDIC have a second, optional parameter called format control. The
format control parameter specifies the presence and type of vertical formatting control in the data
being transferred. The Sterling Connect:Enterprise FTP implementation ignores ASCII and
EBCDIC format controls. The following table shows the data types accepted by Sterling
Connect:Enterprise FTP and the TELNET codes associated with the data types.
Image is noncharacter data. Data is sent and received as contiguous bits packed into 8-bit bytes. No
translation takes place by Sterling Connect:Enterprise. Sterling Connect:Enterprise also assumes
that no translation takes place at the remote FTP server. Character data can be transmitted as image,
but no translation occurs.
Type Description
A
See Note 1.
ASCII nonprint
A C
See Note 1.
ASCII nonprint
A N
See Note 1.
ASCII nonprint
A T
See Note 1.
ASCII telnet
E
See Note 2.
EBCDIC nonprint
E C
See Note 2.
EBCDIC nonprint
E N
See Note 2.
EBCDIC nonprint
E T
See Note 2.
EBCDIC telnet
I Image (binary)
1 Data types A, A C, A N, and A T are identical in the Sterling Connect:Enterprise FTP
implementation.
2 Data types E, EC, E N, and E T are identical in the Sterling Connect:Enterprise FTP implementation.
Chapter 1 Sterling Connect:Enterprise FTP Implementation
10 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
The four standard ASA control characters are:
Data Structure
The FTP client specifies the structure of files being transferred to and from Sterling
Connect:Enterprise. Data structure is significant when transferring files between systems that have
different methods of storing files. Some systems store files as file-oriented, whereas others store
them as record-oriented.
The FTP standard includes three data structures: file, record, and page. Sterling Connect:Enterprise
FTP provides the ability to specify two FTP data structures: file and record. Sterling
Connect:Enterprise FTP does not support the page structure.
File
File has no internal structure and is considered a continuous sequence of bytes. File structure can
be used with all transfer modes and data types. End-of-file (<EOF>) is indicated when the sender
closes the data connection. File is the default data structure for Sterling Connect:Enterprise.
Term Definition
CC Indicates that data contains ASA control characters in the first position of every line.
The first character determines the vertical movement of the paper before the data is
printed. The ASA control character is not printed. The first character after the ASA
control character is printed on the first position of the output line on the paper.
NONPRINT Indicates the data does not include format control characters. Nonprint format control
is generally accepted by all FTP implementations. This format can be used for data
destined for storage or processing. A print processor can assume that nonprint data
contains standard values for spacing and margins.
TELNET The file contains ASCII or EBCDIC vertical format controls that a printer Process can
interpret. Some examples of TELNET vertical form control are carriage return
(<CR>), line feed (<LF>), new line (<NL>), and vertical tab (<VT>). The <CRLF>
sequence denotes end-of-line, not vertical control.
Character Vertical Spacing
blank Move paper up one line.
0 Move paper up two lines.
1 Move paper to top of next page (form).
+ No movement. Overtype the previous line.
Data Representation and Storage
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 11
Record
The data is sent as a set of sequential records. The record structure is only valid with transfers of
text files (data type ASCII or data type EBCDIC). End-of-record (<EOR>) indicators for all
records, including the final record, must be explicit.
Page
The page structure is not implemented in the Sterling Connect:Enterprise FTP feature.
Transfer Mode
Transfer mode indicates which transmission services Sterling Connect:Enterprise must provide for
z/OS FTP server.
There are three transfer modes defined in the FTP standard and implemented in Sterling
Connect:Enterprise: stream, block, and compressed.
Stream
Data is transferred as a stream of bytes. Use any of the data types or data structures implemented in
the Sterling Connect:Enterprise FTP feature. Stream mode is the default transfer mode for the
Sterling Connect:Enterprise server.
For the file structure, end-of-file is indicated when the sending host closes the data connection. All
bytes transferred are data bytes.
For the record structure, the end-of-record (<EOR>) and end-of-file (<EOF>) is identified by
2-byte control sequences. The <EOR> control sequence must be explicit, including the last record.
The <EOR> and <EOF> control sequences are not stored as a part of the batch's data.
The first byte of a control sequence is the escape code—hexadecimal 'FF'. An <EOR> sequence is
hexadecimal 'FF01'. An <EOF> sequence is hexadecimal 'FF02'. <EOR> and <EOF> can be
indicated together on the last byte of the data as hexadecimal 'FF03'. An implicit <EOF> is indicated
when the sender closes the data connection without receiving the <EOF> sequence.
If a data byte contains hexadecimal 'FF', two bytes of hexadecimal 'FFFF' are transmitted and
received to prevent the loss of data. The single byte of hexadecimal 'FF' is stored with the batch, not
the two bytes of hexadecimal 'FFFF'.
Block
Data is transferred as a series of blocks. Any of the data types are valid for a block mode transfer.
Any of the file structures are valid for block mode transfer.
A header precedes each data block. The header is three (3) bytes long and contains a descriptor code
and byte count field. The descriptor code is a binary code and is not data type sensitive. The byte
count field is an unsigned half-word integer, and is not data type sensitive.
The descriptor code is the high-order byte (8 bits) of the header, and defines the block's attributes.
The following table contains the valid descriptor codes:
Chapter 1 Sterling Connect:Enterprise FTP Implementation
12 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
The count field is the low order two bytes (16 bits) of the header, and contains of the number of
bytes in the block excluding the header.
Compressed
Data is transferred as a series of blocks in a compressed format. ASCII and EBCDIC are the only
valid data types for a compressed mode transfer. The only valid data structure for a compressed
mode transfer is file. Compressed format transfers contain three kinds of information:
uncompressed data, compressed data, and control information.
Uncompressed data is transferred as a byte string, and is proceeded by a 1-byte count field. The
maximum length of an uncompressed string is 127 bytes. If the byte contains a value from 1 through
127 (hexadecimal '01' through '7F'), it is a count field that describes the number of uncompressed
bytes that follow.
There are two types of compressed data: replication and filler.
Replication compressed data is represented by a 1-byte count field in front of the replicated
character. The count field is the number of times the single character occurs in the data. If the
byte contains a value from 128 to 191 (hexadecimal '80' through 'BF'), it is a count of the
number of times the next byte is replicated. The first two bits of the byte are ignored. The last
six bits contain the number of times the character is replicated. The maximum length of a
compressed replicated field is 63 bytes. The replicated character is included in the count field.
Filler compressed data is represented by a 1-byte count field. The count field is the number of
filler characters that occur in the data. The filler byte is a blank character. If the byte contains a
value from 192 to 255 (hexadecimal 'C0' through 'FF'), it is a count of the number of filler
bytes to expand into the data. The first two bits of the byte are ignored. The last six bits contain
the number of filler bytes. For ASCII and EBCDIC, the filler byte is a blank character. A blank
is ASCII code 32 (hexadecimal '20') or EBCDIC code 64 (hexadecimal '40'). The maximum
length of a compressed filler field is 63 bytes.
Control information is sent as a 2-byte control sequence. The first byte is an escape (<ESC>)
character. The second byte contains a descriptor code. Control information is optional. The count
and control sequence fields are not part of the data. The count and control field lengths are not
included in the length of the information fields.
Data that is read from the TCP/IP stack is decompressed before any translation is done. Each byte
read from the TCP/IP stack is examined for the count or control sequence field.
Dec Code Value Meaning
128 X'80 'End of byte count is EOR
64 X'40 'End of byte count is EOF
32 X'20 'Suspected errors in data block (informational only)
16 X'10 'Data block is a restart marker
0 X'00 'Data continues to next block
Controlling FTP Connections
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 13
If the value of the byte is zero (hexadecimal '00'), it is the first byte of a 2-byte control sequence.
The first byte of zero is the escape character. The second byte contains a descriptor code. The
descriptor codes have the same meaning as in block mode and apply to the succeeding string of
bytes. The succeeding string can be an uncompressed data string, a compressed replicated character,
or a compressed filler character.
The compression count information fields are eliminated when the file is decompressed. The
compression <EOR> control sequence field (hexadecimal 0080') is replaced with the <EOR>
control sequence field, hexadecimal 'FF01'. The compression <EOB> control sequence field
(hexadecimal '0040') is replaced with the <EOB> control sequence field, hexadecimal 'FF02'.
The following table shows which transfer modes you can specify for a given data type and data
structure when using the Sterling Connect:Enterprise FTP server. Transfer mode stream, data type
ASCII, and data structure file are the defaults for Sterling Connect:Enterprise FTP server.
When selecting among the options listed, consider the purpose of the file transfer. If programs on
the receiving host use the transferred file, select options that make the file usable on the receiving
host. If the receiving host is being used as an intermediate storage location for the transferred file,
and the file will be retrieved again by the original host, you can select data type image, data structure
file, and transfer mode stream.
Controlling FTP Connections
This section describes considerations for navigating firewalls and using the Clear Control Channel
feature.
Implementing Firewall Navigation
Certain parameters defined in the Option Definition File (ODF) in Sterling Connect:Enterprise
enable you to apply restrictions to FTP operations in active and passive FTP mode, enabling you to
control FTP connections through your firewall. These parameters enable you to define port ranges,
the number of retries if socket acquisition fails, and how long to wait between retries.
Although you can specify all available ports on a system in each range, you can control firewall
navigation more effectively by assigning a limited number of ports for FTP operations.
Transfer Mode Data Type Data Structure
ASCII EBCDIC Image File Record
Stream XXXXX
Block XXXXX
Compressed XXXXX
Note: The combinations marked by a dagger are not currently supported by the IBM z/OS FTP server.
Chapter 1 Sterling Connect:Enterprise FTP Implementation
14 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
Implementing the Clear Control Channel (CCC) Feature
Using the CCC feature provides a way to negotiate the control connection from an encrypted
content to a clear text content. After the user ID and password have been transmitted in encrypted
format, the remainder of the control transmission is in clear text until the connection ends. All data
and objects transferred between the client and server remain encrypted.
Connecting to a Sterling Connect:Enterprise FTP Server
The following procedure describes how to connect to a Sterling Connect:Enterprise FTP server.
This is a generic procedure and assumes that you have access to an FTP client software package.
Your FTP client software can require different procedures.
Prerequisites
Obtain the following information from your Sterling Connect:Enterprise administrator:
Sterling Connect:Enterprise FTP server IP address or host name and port number or range of
ports
User name or remote name and password
Mailbox ID
Log On
1. At the command line prompt, issue the following command:
If your FTP client does not allow parameters on the initial ftp command, use the following two
commands to establish the connection:
where “host_name” and “port_number” are the server IP address or host name and port
number obtained from the Sterling Connect:Enterprise administrator, and “port_range(s)”
limits the port or range of ports available for FTP transmissions through firewalls.
Note: The CCC command is valid for Secure FTP only, and each endpoint of the connection must support
the use of this command.
Note: Point and Click FTP systems do not have a command line. The prerequisite information is included
during installation.
> ftp host_name port_number
> ftp
> open host_name port_number [port_range(s)]
Sterling Connect:Enterprise FTP Server and Equivalent Client Commands
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 15
The Sterling Connect:Enterprise FTP server sends the following messages when the
connection is complete, where:
vv.rr.mm is the version, release, and modification level of Sterling Connect:Enterprise at
the host site.
opsys_name is the standard name for the operating system executing Sterling
Connect:Enterprise.
opsys_rel is the release information of the operating system.
discintv is the idle disconnect interval.
The idle disconnect interval is the number of seconds that the FTP client and FTP server
connection remains open with no activity. The Sterling Connect:Enterprise FTP server
forces the session to end by closing the control connection. Get the required disconnect
interval from the Sterling Connect:Enterprise administrator at the host site
hh:mm:ss and yyyy/mm/dd are the time and date of the connection.
The time and date of the connection is the Sterling Connect:Enterprise local time and date.
Batches added by the FTP client are posted using the Sterling Connect:Enterprise local
time and date.
2. The FTP client prompts you for your user name. The user name is assigned by the Sterling
Connect:Enterprise administrator and is referred to as the remote name. If the FTP client does
not prompt you for your user name, type the following command:
3. The FTP client prompts you for your password. The initial password is assigned by the
Sterling Connect:Enterprise administrator. When you are connected, the current working
mailbox ID is the same as your user name.
Sterling Connect:Enterprise FTP Server and Equivalent Client
Commands
This section describes the standard FTP commands that the Sterling Connect:Enterprise FTP server
accepts along with the typical FTP client commands that invoke them. They are labeled typical FTP
commands because some FTP client interface panels contain non-standard commands, like get,
instead of the standard FTP commands, like retr. The client software translates a non-standard FTP
client command into a standard FTP command before sending it to the FTP server.
220-Connect:Enterprise vv.rr.mm on opsys_name opsys_rel.
220-Connection will close if idle for more than discintv.
220 Ready (at local host date and time) yyyy/mm/dd at hh:mm:ss
> user username
Chapter 1 Sterling Connect:Enterprise FTP Implementation
16 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
The following table describes terminology specific to Sterling Connect:Enterprise FTP. The
Sterling Connect:Enterprise terms have synonyms that may be more familiar to experienced FTP
users.
The exact format in which you issue a command depends on your operating system and follows any
conventions required. For example, the Help command can provide help from your own operating
system but not from Sterling Connect:Enterprise.
The dialog feature of Sterling Connect:Enterprise provides a way to track and troubleshoot
inconsistencies that result from failure to adhere to your operating system conventions for
commands. All transmissions between Sterling Connect:Enterprise FTP client and server are
monitored and written to a dialog log file at the client site. This file lists each transmission, the
command you thought you were issuing, and the command that Sterling Connect:Enterprise
actually received. In addition, any error or confirmation messages returned by Sterling
Connect:Enterprise are recorded in this file. Coordinate with your host site administrator to turn
dialog on as the default for your site. If you do not want dialog on as a default, you can issue the
$$DIALOG command from the command line to turn it on temporarily and troubleshoot for a
particular session.
Sterling Connect:Enterprise FTP supports only the FTP commands in the following table, which
lists FTP client commands available for a remote FTP client and the equivalent FTP command
invoked by the Sterling Connect:Enterprise FTP server. When necessary, the Sterling
Connect:Enterprise FTP description states how the Sterling Connect:Enterprise FTP
implementation differs from the standard. Variations from the standard FTP commands are detailed
in Sterling Connect:Enterprise Variations from Standard FTP Commands on page 35.
Sterling
Connect:Enterprise Term
Synonym
Mailbox ID Directory
Batch ID or user batch ID File name
Batch Number Batch Number
Note: In Sterling Connect:Enterprise, it is possible for a mailbox ID to
contain identical batch IDs or file names. The unique identifier
for individual files in Sterling Connect:Enterprise thus becomes
the batch number.
Caution: If you are issuing FTP commands from a client that does not use a Point and Click system,
inconsistent results may occur if you do not follow the conventions of your operating system.
Sterling Connect:Enterprise FTP Server and Equivalent Client Commands
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 17
Command Invoked by
Sterling
Connect:Enterprise
FTP Server
FTP Client
Command
Standard Description Sterling
Connect:Enterprise FTP
Implementation
ABOR abort Terminates the current data
transfer. If a data transfer is not
occurring, ABOR does not
affect the session.
Invalid if issued prior to logon
completion.
Same as standard
AUTH AUTH Identifies the security
mechanism used. Required to
initiate a secure FTP session.
SSL and TLS are the only
security mechanism supported.
Must be received prior to the
USER and PASS commands.
Same as standard
CCC CCC Secure FTP only. Negotiates
the control connection from an
encrypted content to a
clear-text content after the user
ID and password have been
transmitted in encrypted format.
All data and objects transferred
between client and server
remain encrypted. Both ends of
the connection must support
this command.
Negotiate a clear-text control
channel.
CWD cd
See table
Note.
Change working directory
Invalid if issued prior to logon
completion.
Change current working
mailbox ID
DELE delete and
mdelete
See table
Note.
Delete a file
Invalid if issued prior to logon
completion.
Logically delete batches from
the current working
mailbox ID
This command does NOT
delete the batch permanently.
The information is
recoverable until a purge is
performed.
HELP HELP Display help information
Invalid if issued prior to logon
completion.
Same as standard
LIST dir List file information
Invalid if issued prior to logon
completion.
List batches in the current
working mailbox ID
Note: By default, anonymous remote sites can execute all commands except CWD and DELE. The
security exit or security interface can further limit the abilities of anonymous remote sites.
Chapter 1 Sterling Connect:Enterprise FTP Implementation
18 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
NLST ls, mdelete,
mget
Names only list
Invalid if issued prior to logon
completion.
List user batch IDs in the
current working mailbox ID
MODE mode Transfer mode Same as standard
NOOP NOOP No operation
Invalid if issued prior to logon
completion.
Same as standard
PASV PASV Listen on alternate port
Invalid if issued prior to logon
completion.
Same as standard
PASS PASS Password Same as standard
PBSZ PBSZ Specifies maximum buffer size
in bytes of encrypted data sent
or received during file transfer.
Must occur prior to PROT
command.
Valid if issued prior to logon
completion.
Same as standard
PORT port Host data port number Same as standard
PROT PROT Indicates the type of data
channel protection used by
client and server during
transfer.
P is the only value currently
supported. Indicates all data on
channel is encrypted.
Same as standard
PWD pwd Print current directory name Print current working
mailbox ID
QUIT QUIT Disconnect Same as standard
RETR RETR,
get, mget
Transfer (get) a file
Invalid if issued prior to logon
completion.
Retrieve batches from the
current working mailbox ID
SITE SITE Site-specific information
Invalid if issued prior to logon
completion.
Same as standard
STAT STAT Send status
Invalid if issued prior to logon
completion.
Same as standard
Command Invoked by
Sterling
Connect:Enterprise
FTP Server
FTP Client
Command
Standard Description Sterling
Connect:Enterprise FTP
Implementation
Note: By default, anonymous remote sites can execute all commands except CWD and DELE. The
security exit or security interface can further limit the abilities of anonymous remote sites.
SITE Command Parameters
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 19
Sterling Connect:Enterprise commands are not case-sensitive. Sterling Connect:Enterprise FTP
server translates all commands to upper case. For example, "Help" is the same as "help," "HELP,"
and "helP"
All commands end with a carriage-return-line-feed (<CRLF> is hexadecimal '0D0A') for ASCII
and new line (<NL> is hexadecimal '15') for EBCDIC.
The <SP> symbol denotes a single space (blank). A blank is ASCII code 32 (hexadecimal '30') and
EBCDIC code 64 (hexadecimal '40').
SITE Command Parameters
The SITE command sets parameters specific to Sterling Connect:Enterprise that affect adding
batches (STOR), retrieving batches (RETR), listing batches (LIST), and listing user batch IDs
(NLST). You can view the current values of the SITE command parameters using the STAT
command. Refer to Sample Output of STATUS Command on page 28.
Multiple parameters can be specified on the SITE command. Specifying the SITE command with
the RESET parameter sets all of the SITE parameter's values to the session default value. IDENT
parameters are not affected by RESET.
The values set for a SITE command parameter remain in effect for the remainder of the session,
except for the DIR_FILTER and LS_FILTER parameters. The DIR_FILTER and LS_FILTER
parameter value changes are only effective for the next execution of the LIST or NLST command,
STOR STOR,
put, mput
Transfer a file
Invalid if issued prior to logon
completion.
Add a batch to the current
working mailbox ID
STOU STOU Store a file with a unique name
Invalid if issued prior to logon
completion.
Add a batch to the current
working mailbox ID
STRU STRU Set file transfer structure Same as standard
SYST SYST Type of operating system Same as standard
TYPE TYPE Data representation type
Valid if issued prior to logon
completion.
Same as standard
USER USER User name Same as standard
Command Invoked by
Sterling
Connect:Enterprise
FTP Server
FTP Client
Command
Standard Description Sterling
Connect:Enterprise FTP
Implementation
Note: By default, anonymous remote sites can execute all commands except CWD and DELE. The
security exit or security interface can further limit the abilities of anonymous remote sites.
Chapter 1 Sterling Connect:Enterprise FTP Implementation
20 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
respectively. To make the DIR_FILTER and LS_FILTER parameter values effective for the
remainder of the session, specify the KEEP option.
No security checks are made for the SITE command.
The following table lists the parameters valid for the SITE command. The column labeled “FTP
server Command” lists the Sterling Connect:Enterprise FTP server command that is affected by the
parameter listed. The column labeled “Remote FTP Client Command” lists the typical FTP client
command that invokes the FTP server command affected by the parameter.
SITE Parameter Description FTP Server
Command
Remote FTP
Client
Command
BCHSEP=NONE|OPT3|OPT4
See Note 1.
Batch separation options.
Note: BCHSEP=OPT4 affects
the format of the
responses from an NLST
command, which can
affect the typical FTP client
mdelete and mget
commands. See Batch
Status Flags on page 41
for an explanation of the
BCHSEP options.
NLIST,
RETR
get, ls,
mdelete,
mget
BLKSIZE=0-32760 or blank Block size of allocated file being sent. STOR,
STOU
put, mput
BLOCKS Primary allocation amount of file
being sent is in BLOCKS.
STOR,
STOU
put, mput
BLOCKSIZE=0-32760 or blank Block size of file being sent. STOR,
STOU
put, mput
COLL_EMPTY_BATCH= NO|YES Specifies whether to collect a batch
containing no user data and treat it as
a valid empty batch. If NO is
specified, the incomplete flag is set
for empty batches. If YES is specified,
the incomplete flag is not set for
empty batches.
STOR,
STOU
put, mput
1 The default values for these parameters are specified in the *REMOTES sections of the ODF by the
Sterling Connect:Enterprise administrator.
2 FTIME, ORIGIN, and TTIME affect the contents of the response from an NLST command. The
response from the NLST command affects the typical client mdelete and mget commands.
SITE Command Parameters
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 21
CYLINDERS Primary allocation amount of file
being sent is in CYLINDERS.
STOR,
STOU
put, mput
DIR_FILTER [QUERY] Display batch exclusion filter. N/A N/A
DIR_FILTER DEFAULT|NONE|OFF
[KEEP]
Reset batch exclusion filter. LIST dir
DIR_FILTER=<flags> [KEEP]
See Note 1.
Specify batch exclusion filter. LIST dir
DIRECTORY=1-16777215 or blank Number of directory blocks allocated
for file being sent.
STOR,
STOU
put, mput
DIRFORM=BROWSER|
BROWSER64|MBOX_CLIENT|
MBOX_CLIENT64|
MBOX_EXT1_CLIENT64|
MBOX_ZOS|MBOX_ZOS64|
$MBINSDFXYKORV|UNIX|UNIX64
See Note 1.
Reply format options. The values
following the $ can be specified in any
order to achieve the desired directory
display format. Any number of options
can be specified. See Different
DIRFORM Layouts Returned by LIST
on page 31 for examples.
LIST dir
$ User-defined format
M 8-character mailbox ID
B 24-character user batch ID.
I 24-character batch ID.
N 7-digit batch number
(#nnnnnn)
S 8-11 digit file size in number of
bytes, based on high order
significant digit
(CT=nnnnnnnn[nnn])
D time/date of batch creation
(hhmm-yyddd)
. F Batch status flags.
X 64-character Batch ID
(BID=xxxx….xxxx)
Y 64-character Batch ID
(xxxx….xxxx)
K 15-digit file size in number of
bytes (CT=nnnnnnnnnnnnnnn)
SITE Parameter Description FTP Server
Command
Remote FTP
Client
Command
1 The default values for these parameters are specified in the *REMOTES sections of the ODF by the
Sterling Connect:Enterprise administrator.
2 FTIME, ORIGIN, and TTIME affect the contents of the response from an NLST command. The
response from the NLST command affects the typical client mdelete and mget commands.
Chapter 1 Sterling Connect:Enterprise FTP Implementation
22 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
O 8-character batch originator
(batch job or remote name)
R 11-digit record count
(REC=nnnnnnnnnnn)
V VBQ ID and allocation status
(VBQnn [OFFLINE])
EDI=NO | YES Specifies whether single byte x'15'
segment terminators are used.
EDI=YES indicates that X’15’
segment terminators are being used
and allows the translation table to
translate the X '15' to a single byte.
EDI=NO (the default) indicates that
X’15’ segment terminators are not
being used so standard EBCDIC to
ASCII translation is used to translate
the X '15' to the 2-byte X '0D0A'.
RETR mget, get
EO=NO|YES
See Note 1.
Extract once.
EO=YES specifies that the batch is
extracted and stored one time from a
remote client and cannot be
transmitted.
The default value EO=NO does not
prevent transmission or multiple
extractions.
STOR,
STOU
mput, put
FIXRECFM Sent by IBM–ignore. STOR,
STOU
put, mput
FTIME=<from_time>
See Note 2.
Limit batch selection by specifying the
starting date for all data selected for
processing. This value is used to
calculate dates relative to the current
date (for example, FROMDATE=3 is
resolved to the date three days ago).
The default is 1980001.
Valid formats:
nnn
hhmm
yyddd
ccyyddd
nnn:hhmm
yyddd:hhmm
ccyyddd:hhmm
DELE, LIST,
NLST,
RETR
delete, dir,
get, ls,
mdelete,
mget
SITE Parameter Description FTP Server
Command
Remote FTP
Client
Command
1 The default values for these parameters are specified in the *REMOTES sections of the ODF by the
Sterling Connect:Enterprise administrator.
2 FTIME, ORIGIN, and TTIME affect the contents of the response from an NLST command. The
response from the NLST command affects the typical client mdelete and mget commands.
SITE Command Parameters
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 23
IDENT PROD_ID=n
PROD_REL=x.x.xx
Identification of Sterling
Connect:Enterprise product.
N/A N/A
KALIVEOFF Turns off the KALIVEON parameter.
Note: KALIVEOFF is equivalent
to setting KALIVEON=0.
N/A N/A
KALIVEON=nnnnnnn Keeps remote control ports open for
the specified number of seconds
(0–2147460) for non-Sterling
Connect:Enterprise applications that
experience timeouts on their control
ports even though they have data port
activity.
N/A N/A
KIRN=YES | NO (KIRN stands for Keep Input Recsep
NL)
Sterling Connect:Enterprise removes
the record separator string so that the
batch is stored as a file structure
instead of being record-oriented or
keeps the record separator string, NL
(New Line feed), for incoming SFA
and SFE batches or allows. If the
batch is not recordized, this
parameter is ignored.
The default comes from the KIRN
setting in the *REMOTES record.
NO = Sterling Connect:Enterprise
removes the record separator string
after recordizing the batch.
YES = The Record separator strings
are kept in the batch. The
corresponding FTP_DEFAULT_RIFS
parameter must be set to YES.
For more information on recordizing,
see the chapter on configuring ODF
records for FTP connections in the
IBM Sterling Connect:Enterprise for
z/OS Administration Guide.
STOR,
STOU
put, mput
LRECL=0-32760 or blank or "x” LRECL of file being sent. STOR,
STOU
put, mput
LS_FILTER [QUERY] Display batch exclusion filter. NLST ls, mdelete,
mget
SITE Parameter Description FTP Server
Command
Remote FTP
Client
Command
1 The default values for these parameters are specified in the *REMOTES sections of the ODF by the
Sterling Connect:Enterprise administrator.
2 FTIME, ORIGIN, and TTIME affect the contents of the response from an NLST command. The
response from the NLST command affects the typical client mdelete and mget commands.
Chapter 1 Sterling Connect:Enterprise FTP Implementation
24 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
LS_FILTER DEFAULT|OFF|NONE
[KEEP]
Reset batch exclusion filter. NLST ls, mdelete,
mget
LS_FILTER=<flags> [KEEP]
See Note 1.
Specify batch exclusion filter. NLST ls,mdelete,
mget
MULTXMIT=NO|YES
See Note 1.
Multiple transmission flag. STOR,
STOU
put
NLIST_QUOTES=NO|YES Specifies whether or not single
quotes are to be used to delimit the
start/end of the User Batch ID in the
name list returned to the client, in
response to a NLST command. The
command will remain in effect for the
duration of the session or until the
command is issued again during that
session.
NLIST_QUOTES=NO tells the
system to not enclose the User Batch
ID in single quotes.
The default value
NLIST_QUOTES=YES encloses the
User Batch ID in single quotes.
NLST ls, mdelete,
mget
nnnnnn Sent by IBM–ignore. STOR,
STOR
put, mput
ONEBATCH=NO|YES
See Note 1.
Duplicate user batch ID RETR get, mget
ORIGIN=<originator>
See Note 2.
Limit batch selection. DELE, LIST,
NLST,
RETR
Delete, dir,
get, ls,
mdelete,
mget
PRIMARY=1-16777215 or blank Primary allocation amount of file
being sent.
STOR,
STOU
put, mput
RECFM=<recfm_list> RECFM value for file being sent. STOR,
STOU
put, mput
REMOTE_FILENAME_LENGTH=
SHORT|LONG|LONG64
See Note 1.
Length of remote file name. NLST ls, mdelete,
mget
RESET Set all values to default. DELE, LIST,
NLST,
RETR,
STOR,
STOU
delete, dir,
get, ls,
mdelete,
mget
SITE Parameter Description FTP Server
Command
Remote FTP
Client
Command
1 The default values for these parameters are specified in the *REMOTES sections of the ODF by the
Sterling Connect:Enterprise administrator.
2 FTIME, ORIGIN, and TTIME affect the contents of the response from an NLST command. The
response from the NLST command affects the typical client mdelete and mget commands.
SITE Command Parameters
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 25
RIFS=YES | NO (RIFS stands for Recordize Input File
Structure)
Changes the batch to record structure
or retains the batch as file structure.
YES = Recordizes the batch after
recognizing a record separator string
and uses CRLF for SFA batches and
NL for SFE batches.
NO = Retains file structure of batch
and does not recognize record
separator strings in SFA or SFE
batches.
The default comes from the RIFS
setting in the *REMOTES record.
For more information on recordizing,
see the chapter on configuring ODF
records for FTP connections in the
IBM Sterling Connect:Enterprise for
z/OS Administration Guide.
Note: Processing results cannot
be predicted or supported
when RIFS=NO and SCAN
is set to YES or ALL.
STOR,
STOU
put, mput
SITE Parameter Description FTP Server
Command
Remote FTP
Client
Command
1 The default values for these parameters are specified in the *REMOTES sections of the ODF by the
Sterling Connect:Enterprise administrator.
2 FTIME, ORIGIN, and TTIME affect the contents of the response from an NLST command. The
response from the NLST command affects the typical client mdelete and mget commands.
Chapter 1 Sterling Connect:Enterprise FTP Implementation
26 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
SCAN=NO|YES|ALL Specifies whether the Sterling
Connect:Enterprise FTP server scans
STOR or STOU received batches for
$$ commands and /* cards. For more
information, see Preparing Batches
for the Sterling Connect:Enterprise
FTP Server on page 47.
NO= Scanning for Sterling
Connect:Enterprise $$ commands is
not enabled. Sterling
Connect:Enterprise $$ commands,
/*SIGNON, and /*BINASC cards
embedded in a received batch are
treated as data.
YES= Scanning for Sterling
Connect:Enterprise $$ commands is
enabled initially, but scanning for a
subsequent $$ADD card is not
automatic. Each $$ADD card must
include the parameter SCAN=YES to
continue scanning for $$ commands.
Use this value to make FTP
command scanning behave like it
does in SNA.
ALL= Scanning for Sterling
Connect:Enterprise $$ commands is
enabled for the entire batch unless
the batch contains a $$ADD card with
the parameter SCAN=NO. Use this
value to make FTP command
scanning behave like it does in BSC.
STOR,
STOU
put, mput
SECONDARY=1-16777215 or
blank
Secondary allocation amount of file
being sent.
STOR,
STOU
put, mput
TO=NO|YES
See Note 1.
Transmit once.
TO=YES specifies that the batch
being received can only be
transmitted once and is not
extractable. TO=YES can be thought
of as “transmit once, transmit only“.
TO=NO specifies that the batch is not
marked non-transmittable.
STOR,
STOU
put
TRACKS Primary allocation amount of file
being sent is in TRACKS.
STOR,
STOU
put, mput
SITE Parameter Description FTP Server
Command
Remote FTP
Client
Command
1 The default values for these parameters are specified in the *REMOTES sections of the ODF by the
Sterling Connect:Enterprise administrator.
2 FTIME, ORIGIN, and TTIME affect the contents of the response from an NLST command. The
response from the NLST command affects the typical client mdelete and mget commands.
SITE Command Parameters
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 27
TTIME=<to_time>
See Note 2.
Limit batch selection by specifying the
ending date for all data selected for
processing. This value calculates
dates relative to the current date. The
default is 1980001.
Valid formats:
nnn
hhmm
yyddd
ccyyddd
nnn:hhmm
yyddd:hhmm
ccyyddd:hhmm
DELE, LIST,
NLST,
RETR
delete, dir,
get, ls,
mdelete,
mget
VARRECFM Sent by IBM–ignore STOR,
STOU
put, mput
VBQ#=nn
Note: You cannot display or
update this parameter in
the ISPF and CICS
screens related to the
Options Definition File.
Only a SITE or LOCSITE
command can direct FTP
batches to a VBQ other
than the Current
Collection VBQ.
Specifies the number of the VBQ file
on which batches collected in FTP
sessions are to be stored.
To set this value for multiple
collections, the command is:
LOCSITE VBQ#=nn KEEP
KEEP must be the next parameter
after VBQ#=nn to retain the value for
more than one batch collection unless
it part of an MGET command. If nn is
00, the assignment resets to the
Current Collect VBQ. If nn is 01
through 20 that particular VBQ is
allocated.
STOR,
STOU
dir, get, list,
nlist, mget,
scget
XMIT=NO|YES
See Note 1.
Transmission control STOR,
STOU
put
XMIT_EMPTY_BATCH= NO|YES Specifies whether to transmit an
empty batch. If NO is specified, empty
batches are not transmitted. If YES is
specified, empty batches are
transmitted.
RETR get, mget
SITE Parameter Description FTP Server
Command
Remote FTP
Client
Command
1 The default values for these parameters are specified in the *REMOTES sections of the ODF by the
Sterling Connect:Enterprise administrator.
2 FTIME, ORIGIN, and TTIME affect the contents of the response from an NLST command. The
response from the NLST command affects the typical client mdelete and mget commands.
Chapter 1 Sterling Connect:Enterprise FTP Implementation
28 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
Sample Output of STATUS Command
The type of information returned depends on the remote server. If the remote FTP server is a
Sterling Connect:Enterprise system, the status and setting information is displayed in the following
messages:
In addition to the following SITE parameter setting information, the time the session started is
shown (in hh:mm:ss and yyyy.ddd format) along with the number of bytes and batches received and
sent during the session. The following table lists the information for each data label in alphabetical
order:
211-Connect:Enterprise at 10:09:49 on 2003.275 host time.
211-Session started at 10:09:33 on 2003/275 host time.
211-User: FTPRMT Current working Mailbox ID: FTPRMT
211-TYPE: A MODE: S STRUcture: F
211-Local SITE option values:
211- Allocation type=NONE BCHSEP=NONE BLKSIZE=0
211- DIR_FILTER=18Fe DIRECTORY=0 DIRFORM=MBOX_ZOS
211- EO=NO FTIME=1980001:0000 LRECL=0 LS_FILTER=BDI!RST
211- MULTXMIT=NO ONEBATCH=NO ORIGIN= PRIMARY=0
211- RECFM= REMOTE_FILENAME_LENGTH=LONG SECONDARY=0
211- TO=NO TTIME= XMIT=NO VBQ=01 SCAN=NO
211- 0 Kbytes received for 0 batches during this session
211 0 Kbytes sent from 0 batches during this session
211 COLL_EMPTY_BATCH=NO XMIT_EMPTY_BATCH=NO
Data Label Description
Allocation type The type of allocation used – BLOCKS, CYLINDER, TRACKS or
NONE.
AUTH The security mechanism used (SSL or TLS).
BCHSEP The batch separation option used – NONE, OPT3, or OPT4 option.
See BCHSEP=NONE|OPT3|OPT4 on page 20.
BLKSIZE The file block size.
Current working Mailbox ID The name of the current working mailbox.
DIR_FILTER The filter used by the LIST command to exclude batches from the
list returned to the remote FTP client. Refer to
DIR_FILTER=<flags> [KEEP] on page 21.
DIRECTORY The file directory size.
SITE Command Parameters
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 29
DIRFORM The DIRFORM reply format. Refer to DIRFORM=BROWSER|
BROWSER64|MBOX_CLIENT| MBOX_CLIENT64|
MBOX_EXT1_CLIENT64| MBOX_ZOS|MBOX_ZOS64|
$MBINSDFXYKORV |UNIX |UNIX64 on page 21.
EO Indicates if the file can be extracted once (EO) and transmitted (Yes
or No).
FTIME The date in year, month, day format followed by a semicolon and
time in hours and minutes representing the from time parameter.
Specifies the starting date for all data selected for processing.
The nnn (1–3 digit number) value calculates dates relative to the
current date. If nnn is specified, the FROMDATE value is calculated
as today-nnn (for example, FROMDATE=3 is resolved to the date
three days ago). The default is 1980001.
LRECL The file logical record length.
LS_FILTER A filter used by the NLST command to exclude batches from the list
returned to the remote FTP client.
MODE The mode – blocked (B), compressed (C), or stream (S).
MULTXMIT Indicates if the batch being received can be transmitted multiple
times (Yes or No).
ONEBATCH Indicates if only the first eligible batch can be selected for transfer
to the remote FTP client (Yes or No).
ORIGIN The name of the remote or user ID of the batch job that added the
batch.
PBSZ The size of the protection buffer.
PRIMARY The file primary allocation amount.
PROT The type of data channel protection used by client and server
during transfer. (P indicates all data on the channel is encrypted.)
RECFM The file record format.
REMOTE_FILENAME_LENGTH The length of the Batch ID returned by NLST (short or long).
SCAN The last known value of the remote (server-side) SCAN setting,
which indicates whether the Sterling Connect:Enterprise FTP
server is scanning RETR received batches for $$ commands and /*
cards. For more information, see the description for the SCAN
parameter on page 26.
SECONDARY The file secondary allocation amount.
STRUcture The file structure – file (F) or record (R).
TO Indicates if the file can only be transmitted once (TO) and cannot be
extracted (Yes or No).
Data Label Description
Chapter 1 Sterling Connect:Enterprise FTP Implementation
30 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
VSAM Batch Status Flags
The DIR_FILTER parameter uses the values in the following batch status flags. Some combinations
of these flags are always processed together or are not accepted.
For example:
A batch with flag 8 or 9 also has an F flag.
(DIR_FILTER=89 is stored in the Remote definition as DIR_FILTER=F)
(DIR_FILTER=!8!9 is stored in the Remote definition as DIR_FILTER=!F)
A batch with any combination of 1, 2, or 3 is not accepted.
TTIME The date in year, month, day followed by a semicolon and time in
hours and minutes representing the to time (TTIME) parameter.
TYPE The file type – ASCII (A), EBCDIC (B), or BINARY (I).
User The name of the user ID currently logged into the remote FTP
Server.
XMIT Indicates if the batch is available to be transmitted to other sites
(Yes or No).
VBQ The number of the VBQ file on which batches collected in FTP
sessions are to be stored.
Code Description
A The batch was added by the offline ADD utility.
B The batch originated at a BSC remote site.
C The batch was collected from a remote site through online Sterling Connect:Enterprise.
D The batch is flagged for deletion due to an online $$DELETE request or an offline DELETE utility.
e The batch was encrypted when added by the offline ADD utility.
E The batch was extracted by the offline EXTRACT utility. This flag does not inhibit another
EXTRACT from running and does not prevent online access to the batch.
F The batch originated at an FTP remote site.
I The batch is incomplete. Either no records were in the batch, or an online data collection was
interrupted due to an error condition. This batch is ignored by Sterling Connect:Enterprise and
only the EXTRACT utility can extract it.
M The batch is available for multiple transmission, can be transmitted to any remote site, and is not
marked T when transmitted unless mailboxID = AC Listname.
N Nontransmittable. The batch is locked for transmissions. The status is set immediately after the
batch is successfully collected, when the EO=Y option of a $$ADD command is specified. It is
also set following successful transmission of a batch added with the TO=Y parameter.
Data Label Description
SITE Command Parameters
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 31
Different DIRFORM Layouts Returned by LIST
The layout of the information returned by the LIST command depends on the value of the
DIRFORM parameter of the SITE command. The format returned when
DIRFORM=MBOX_ZOS64 is shown in the following example, which illustrates the
default directory list format.
R Requestable. A remote site can request the batch or a host-initiated Auto Connect can transmit
the batch.
S The batch originated at an SNA remote site.
T The batch was transmitted online to a remote site.
U Unextractable. When displayed, this status replaces the E status. The batch is locked for
extractions. This status is set immediately after the batch is added, when the TO=Y option added
the batch. It is also set following successful extraction of the batch when the EO=Y option was
used to add the batch.
X The batch contains transparent data.
Z EBCDIC data added through the APPC user API.
0 The batch is sorted on the VBQ as FILE_STRUCTURE (non record oriented). The batch was
added offline or collected online as a contiguous byte string with no logical record delineation.
1 FTP mode is blocked.
2 FTP mode is compressed.
3 FTP mode is stream.
4 FTP collected SSL.
8 FTP structure is file.
9 FTP structure is record.
(1) (2) (3) (4) (5) (6) (7) (8)
COMPANYB #0000047 CT=00000320 BID=LIST TEST 1508-01199 A R F O38 VBQ01 OFFLINE
COMPANYB #0000067 CT=00000420 BID=LIST 1046-01205 C T F O38 VBQ20
COMPANYB #0000068 CT=00000210 BID=LIST 1046-01205 C F O38 VBQ03
Column Description
(1) Mailbox where the batch resides.
(2) Batch number–zero filled.
(3) Size of batch in bytes.
(4) Batch ID
Code Description
Chapter 1 Sterling Connect:Enterprise FTP Implementation
32 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
The format returned when DIRFORM=BROWSER is shown below with an explanation of the
columns:
(5) Date batch added (HHMM-YYDDD)
(6) Batch flags in 20 character field in the following order:
I = Incomplete
A|C = Offline Added, Online Collected
D = Delete
N = Not Transmittable
U = Unextractable
R = Requestable
T = Transmitted
E = Extracted
M = Multi-transmittable
X = Transparent
B|F|S|Z = BSC, FTP, SNA or API
Space = Reserved for future use.
Space = Reserved for future use.
0 = File oriented data.
1|2|3 =FTP mode – blocked, compressed, stream
8|9 = FTP structure – file, record
e = Offline added with encryption (ENCR=)
Space = Reserved for future use.
Space = Reserved for future use.
Space = Reserved for future use.
(7) The number of the VSAM Batch Queue where the batch is stored.
(8) VBQ status–OFFLINE if VBQ is not available or blank if available.
(1) (2) (3) (4) (5) (6) (7)
A R 1 COMPANYB 0000047 00000320 JUL 18 15:08 LIST TEST
C T 1 COMPANYB 0000067 00000420 JUL 24 10:46 LIST
IC 1 COMPANYB 0000074 00000320 JUL 24 11:31 July Invoice
Column Description
SITE Command Parameters
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 33
The format returned when DIRFORM=MBOX_CLIENT is shown below with an explanation of the
columns.
Column Description
(1) Batch flags in 10-character field in the following format:
I = Incomplete
A|C = Offline added, Online Collected
D = Delete
R = Requestable
T = Transmitted
E = Extracted
M = Multi-transmittable
U = Unextractable
N = Not transmittable
X = Transparent
(2) Constant 1.
(3) Mailbox where batch resides.
(4) Batch number–zero filled.
(5) Size of batch in bytes.
(6) Date batch added (MMM DD HH-MM)
(7) Batch ID
(1) (2) (3) (4) (5) (6) (7)
COMPANYB #0000047 CT=00000320 BID=LIST TEST 1508-01199 A R COMPANYB
COMPANYB #0000067 CT=00000420 BID=LIST 1046-01205 C T COMPANYB
COMPANYB #0000068 CT=00000210 BID=LIST 1046-01205 C COMPANYB
Column Description
(1) Mailbox where batch resides.
(2) Batch number–zero filled.
(3) Size of batch in bytes.
(4) Batch ID
(5) Date batch added (HHMM-YYDDD)
Chapter 1 Sterling Connect:Enterprise FTP Implementation
34 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
The format returned when DIRFORM=UNIX is shown below with an explanation of the columns.
(6) Batch flags in 10-character field in the following order:
I = Incomplete
A|C = Offline Added, Online Collected
D = Delete
R = Requestable
T = Transmitted
E = Extracted
M = Multi-transmittable
U = Unextractable
N = Not transmittable
X = Transparent
(7) Batch job name or remote name that added the batch.
(1) (2) (3) (4) (5) (6) (7)
-A-R------ 1 CRONLY 2845 05 AUG 11 20:14 'CRONLY TEST '.#0002845
-A-R------ 1 CRONLY 2846 05 AUG 11 20:14 'CRONLY TEST '.#0002846
-A-R------ 1 CRONLY 2847 05 AUG 11 20:14 'CRONLY TEST '.#0002847
Column Description
(1) Batch flags in 10-character field in the following order:
I = Incomplete
A|C = Offline Added, Online Collected
D = Delete
R = Requestable
T = Transmitted
E = Extracted
M = Multi-transmittable
U = Unextractable
N = Not transmittable
X = Transparent
Note: A hyphen (-) is returned as a placeholder for each batch status which is not
present.
(2) Constant 1.
(3) Mailbox ID where batch resides.
Column Description
Sterling Connect:Enterprise Variations from Standard FTP Commands
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 35
Sterling Connect:Enterprise Variations from Standard FTP
Commands
The Sterling Connect:Enterprise FTP server uses a construct called a mailbox ID as the equivalent
of the directory in other FTP implementations. Sterling Connect:Enterprise supports a single level
of the directory, which is referred to as the current working mailbox ID.
The following table summarizes the typical FTP commands that are implemented by the Sterling
Connect:Enterprise FTP server in a manner that differs from other FTP server implementations. The
way that Sterling Connect:Enterprise implements each command is detailed. The syntax and format
for specifying user batch ID are also detailed.
.
User Batch ID Syntax and Formats
The value of the user batch ID is case-sensitive and you cannot use the following characters in the
user batch ID. The results of attempts to retrieve batches using FTP commands that contain
wildcards in the user batch ID are unpredictable.
(4) Size of batch in bytes
(5) Date batch added (YY month DD HH:MM), where month = Jan, Feb, ...., Nov, Dec.
(6) Batch ID, enclosed in single quotes with .#nnnnnnn appended, where nnnnnnn = batch
number, for example, '24 character batchid '.#0001234
FTP Command Sterling
Connect:Enterprise
FTP Server Command
Sterling Connect:Enterprise Implementation
del, delete, mdelete DELE Logically delete batches from the current working
mailbox ID
dir LIST, NLST List batches in the current working mailbox ID
get, mget RETR Retrieve batches from the current working
mailbox ID
ls, mdelete, mget NLST List the user batch IDs in the current working
mailbox ID
put, mput, STOU STOR, STOU Add a batch to the current working mailbox ID
cd CWD Change current working mailbox ID
pwd PWD Print current working mailbox ID
Column Description
Chapter 1 Sterling Connect:Enterprise FTP Implementation
36 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
Additionally, do not use the number symbol (#) as the first character in the user batch ID.
Pathnames, or ‘<pathname>’, consist of an optional Mailbox ID and a User Batch ID in the form:
‘[/<mailbox_ID>/]<batch_ID>’. Specifying the Mailbox ID in the <pathname> overrides the
setting of the current working mailbox for the current command and the current working Mailbox
ID is not changed. If <mailbox_ID> is not specified as part of the path name, then the current
working Mailbox ID is used.
The user batch ID can be specified in one of the following ways:
-.*?[]\/
Caution: Some systems support ID numbers using the # character, but Sterling Connect:Enterprise can
return inconsistent, redundant, or incorrect responses to queries that use # as the first character
of the user batch ID.
Format Description
nnnnnnn The 1–7 digit batch number from 1–9999999. Leading zeros are optional.
“generic-name” 1–64 characters used to identify batches in the current working mailbox ID. (The
quotation marks are required for this form of batch ID. Do not use wildcard characters
in the “generic-Name” value.)
‘specific’ 1–64 character user batch ID left justified, padded with trailing blanks. The single
quotes are required to delimit the ID. If the ID contains an apostrophe, two
apostrophes must be encoded for each single apostrophe in the ID.
Example: UID1235’BNK1 would need to be encoded ‘UID1235”BNK1’
If blanks are embedded within the ID, the single quotes must be left off.
Example: UID1235 BNK1
‘SPEC*?[]’ Indicates any batch that matches the specified pattern. 1–64 characters including
any wildcard card characters. The pattern is compared to all batches in the current
working mailbox ID and any matching batches are selected.
‘batch_ID.#nnnnn
nn’
1–64 character ID with trailing blanks truncated, followed by .# and the 7-digit batch
number from 0000001–9999999 (including leading zeros) and enclosed in single
quotes.
Without the single quotes, you cannot use embedded blanks in this ID.
This format is normally seen as part of a RETR or DELE command.
‘#nnnnnnn.dat’ # and the 7-digit batch number from 0000001–9999999 with leading zeros followed
by .dat and optionally enclosed in single quotes.
This format is typically used as part of a RETR or DELE command.
Sterling Connect:Enterprise Variations from Standard FTP Commands
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 37
delete or mdelete Command
In Sterling Connect:Enterprise, the DELE command logically deletes batches from the current
working mailbox ID specified by the <pathname> parameter. You can set the current working
mailbox ID using the FTP client cd command. Display the current working mailbox ID using either
the STAT command or the PWD command. A mailbox ID specified in <pathname> temporarily
overrides the permanent setting of the current working mailbox ID, for the duration of the current
command.
The FTIME, ORIGIN, and TTIME parameters of the SITE command affect DELE processing. Set
the FTIME, ORIGIN, and TTIME parameters using the SITE command and display them using
either the STAT command or the PWD command.
The following two security checks are made before the DELE command deletes a batch:
Session security exit call
Security interface security checks
Sterling Connect:Enterprise FTP del, delete, and mdelete Command Syntax
The typical FTP client delete and mdelete commands invoke the FTP server DELE command as
shown in the following table. Required parameters are displayed in bold font. No optional
parameters are available.
Batch Selection with Sterling Connect:Enterprise FTP del Command
If the user batch ID specified in <pathname> is in the form '#nnnnnnn', 'nnnnnnn',
'batch_ID.#nnnnnnn', or '#nnnnnnn.dat' and the batch is in the current working mailbox ID, the
single batch with batch number 'nnnnnnn' is deleted.
If the user batch ID specified in <pathname> is in form “generic-name”, 'specific', or 'spec*?[]', all
batches in the current working mailbox ID that match the value specified are eligible for deletion.
An eligible batch is selected for deletion if the following conditions are met:
Note: Remote sites with the name anonymous are not permitted to use DELE.
FTP Command Sterling
Connect:Enterprise
FTP Server
Command
Syntax Parameter Description
del, delete,
mdelete
DELE DELE<SP><pathname> Required. <pathname> specifies the
batch or batches to delete.
Note: Your operating platform may not support using the number (#) character as the first character of a
batch_ID. See Transfer Mode on page 11.
Chapter 1 Sterling Connect:Enterprise FTP Implementation
38 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
1. The batch's creation date and time is on or after the value specified in the FTIME parameter.
2. The batch's creation date and time is on or before the value specified in the TTIME parameter.
3. The batch's origination matches the value of the ORIGIN parameter or the ORIGIN parameter
is blank.
If the user batch ID specified in <pathname> is in '#nnnnnnn', 'nnnnnnn', 'batch_ID.#nnnnnnn', or
'#nnnnnnn.dat' format, the SITE parameters FTIME, ORIGIN, and TTIME are ignored.
The SITE parameters FTIME and TTIME limit the selection of batches based on the batch's earliest
and latest creation date and time, respectively.
The ORIGIN parameter limits the selection of batches based on the name of the user or remote that
created the batch.
dir Command
In Sterling Connect:Enterprise the LIST command lists batches in the current working data
repository or the mailbox ID specified in the <pathname> parameter. You set the current working
mailbox ID using the FTP client cd command. Display the current working mailbox ID using either
the STAT command or the PWD command. For the dir command, the mailbox ID specified in
<pathname> overrides the setting of the current working mailbox ID, but does not change its value.
The DIR_FILTER, FTIME, ORIGIN, and TTIME parameters of the SITE command affect LIST
processing. The DIR_FILTER, FTIME, ORIGIN, and TTIME parameters are set using the SITE
command and displayed using either the STAT command or the PWD command.
The sequence of the list returned by the LIST command is in ascending order by mailbox ID. The
batches listed for each mailbox ID are sequenced based on the values of the batch transmission
status and batch age. The batches in the data repository that did not transmit are listed first in
ascending sequence by creation date and time. The batches that transmitted are listed last in
ascending sequence by creation date and time. The format of the list returned by the LIST command
depends on the value of the DIRFORM parameter of the FTP server SITE command. The
DIRFORM parameter is set using the FTP server SITE command and displayed using the FTP
server STAT command.
The following two security checks are made before the LIST command accesses the data repository:
Session security exit call
Security interface security checks
If you did not specify a data connection port (using either the PORT or PASV command) before
issuing the dir command, Sterling Connect:Enterprise assumes that the data uses the client's control
connection port and the server's port adjacent to the control port (for example, L–1). Always specify
the data connection port explicitly (through PORT or PASV commands) instead of assuming the
default.
Note: The current data representation must be either ASCII or EBCDIC. Image type is unsupported and
is not recognized.
Sterling Connect:Enterprise Variations from Standard FTP Commands
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 39
Sterling Connect:Enterprise FTP dir Command Syntax
The typical FTP client dir command invokes the FTP server LIST command as shown in the
following table. Required parameters are displayed in bold font.
Batch Selection with Sterling Connect:Enterprise FTP dir Command
If the user batch ID specified in <pathname> is formatted as '#nnnnnnn', 'nnnnnnn',
'batch_ID.#nnnnnnn', or '#nnnnnnn.dat' and the batch is in the current working mailbox ID, the
single batch with batch number 'nnnnnnn' is eligible for the list.
If the user batch ID specified in <pathname> is in the form “generic-name”, 'specific', or 'spec*?[]',
all of the batches in the current working data repository that match the specified value are eligible
for the list.
If <pathname> is not specified, all of the batches in the current working data repository are eligible
for the list. Eligible batches are selected for listing depending on the current settings of the SITE
parameters DIR_FILTER, FTIME, ORIGIN, and TTIME.
An eligible batch is listed if the following conditions are met:
The batch's status flags do not match any of the values specified in the DIR_FILTER
parameter.
The batch's creation date and time is on or after the value specified in the FTIME parameter.
The batch's creation date and time is on or before the value specified in the TTIME parameter.
The batch's origination matches the value of the ORIGIN parameter or the ORIGIN parameter
is blank.
If the user batch ID specified in <pathname> is in '#nnnnnnn', 'nnnnnnn', 'batch_ID.#nnnnnnn', or
'#nnnnnnn.dat format', the DIR_FILTER, FTIME, ORIGIN, and TTIME parameters are ignored.
The DIR_FILTER parameter limits the selection of batches based on a batch's status flags.
The FTIME and TTIME parameters limit the selection of batches based on the batch's earliest
and latest creation date and time, respectively.
The ORIGIN parameter limits the selection of batches based on the name of the user or remote
that created the batch.
get or mget Command
In Sterling Connect:Enterprise, the RETR command retrieves batches from the current working
data repository or the mailbox ID specified in the <pathname> parameter. For this command, the
mailbox ID specified in <pathname> overrides the setting of the current working mailbox ID, but
FTP
Command
Sterling
Connect:Enterprise
FTP Server
Command
Syntax Parameter Description
dir, LIST,
NLST
LIST LIST[<SP><pathname>] Optional. <pathname> specifies the
batch or batches to list
Chapter 1 Sterling Connect:Enterprise FTP Implementation
40 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
does not change its value. Set the current working mailbox ID using the FTP client cd command.
Display the current working date repository using either the STAT command or the PWD
command.
The FTP client creates the file names at the remote site using the typical FTP client get and mget
commands, and using the replies returned from the NLST command.
Several parameters of the SITE command affect RETR processing. You can set these parameters
using the SITE command and display them using either the STAT command or the PWD command.
Several other parameters of the SITE command cause file characteristics to be stored with the batch.
The following two security checks are made before the RETR command retrieves a batch:
Session security exit call
Security interface security checks
Before issuing this command, specify the data collection port using either the PORT command or
the PASV command. Sterling Connect:Enterprise assumes that the data connection uses the client's
control connection port and the server's port adjacent to the control port (for example, L–1). For
optimum performance, always specify the data connection port explicitly (through the PORT or
PASV commands) instead of assuming the default.
When the control connection is established and secure, SSL negotiation of the data connection is
expected.
Sterling Connect:Enterprise FTP get Syntax
The typical FTP client get and mget commands invoke the FTP server RETR command as shown
in the following table. Required parameters are displayed in bold font. No optional parameters are
available.
Batch Selection
If the user batch ID specified in <pathname> is in the form '#nnnnnnn', 'nnnnnnn',
'batch_ID.#nnnnnnn', or '#nnnnnnn.dat' and the batch is in the current working data repository, the
single batch with batch number 'nnnnnnn' is eligible for retrieval.
Note: BCHSEP does not affect the selection of batches. It only determines when a batch is marked
transmitted.
FTP Command Sterling
Connect:Enterprise
FTP Server
Command
Syntax Parameter Description
get, mget RETR RETR<SP><pathname> Required. <pathname> specifies the
batch or batches to be listed.
Sterling Connect:Enterprise Variations from Standard FTP Commands
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 41
If the user batch ID specified in <pathname> is in the form “generic-name”, 'specific', or 'spec*?[]',
all of the batches in the current working data repository that match the user batch ID are eligible for
retrieval.
Eligible batches are selected for listing depending on the current settings of the SITE parameters
TIME, ORIGIN, and TTIME, and of the data representation type.
A batch is selected for retrieval when the following conditions are met:
The batch is contained in an online VBQ.
The data representation type of the batch matches that of the TYPE parameter.
The batch's creation date and time is on or after the value specified in the FTIME parameter.
The batch's creation date and time is on or before the value specified in the TTIME parameter.
The batch's origination matches the value of the ORIGIN parameter or the ORIGIN parameter
is blank.
The batch is requestable.
If the user batch ID specified in <pathname> is in '#nnnnnnn', 'nnnnnnn', 'batch_ID.#nnnnnnn', or
'#nnnnnnn.dat' format, the SITE parameters FTIME, ORIGIN, and TTIME are ignored.
The FTIME and TTIME parameters limit the selection of batches based on the batch's earliest
and latest creation date and time, respectively.
The data representation type of the batch limits the selection of batches based on current
setting of the TYPE parameter.
The ORIGIN parameter limits the selection of batches based on the name of the user or remote
that created the batch.
Batch Transmission
If batches are selected for retrieval, the batches are transferred through the data connection.
If the user batch ID specified in <pathname> is in the form '#nnnnnnn', 'nnnnnnn',
'batch_ID.#nnnnnnn', or '#nnnnnnn.dat' and the batch is in the current working data repository, the
single batch with batch number 'nnnnnnn' is eligible for retrieval unless the data representation type
does not match.
If ONEBATCH=NO is specified, the RETR command concatenates all the batches selected and
sends them as one file. If ONEBATCH=YES is specified, the RETR command only sends the first
batch selected.
Batch Status Flags
The batch status flags have the following meaning.
If BCHSEP=NONE or BCHSEP=OPT4, each batch is flagged as transmitted (“T”) when it is
sent successfully. If a failure occurs during transmission, BCHSEP=NONE or
BCHSEP=OPT4 prevents batches previously sent from being retransmitted. If the
transmission is restarted to the same remote client file, the data from the previous batches is
replaced with the data from the unsent batches, and the data from the previously sent batches
are lost. If the transmission is restarted to a different remote client file, data sent in previous
batches are not lost.
Chapter 1 Sterling Connect:Enterprise FTP Implementation
42 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
If BCHSEP=OPT3, all batches are flagged as transmitted (“T”) when all of the batches are
sent successfully. If a failure occurs during transmission, BCHSEP=OPT3 permits all batches
to be transmitted again. If the transmission is restarted to the same remote client file, the data
from the previous batches are retransmitted with no loss of data. If the transmission is restarted
to a different remote client file, duplicate records are sent to the remote site.
put or mput Command (STOR)
In Sterling Connect:Enterprise, the STOR command adds a batch to the current working data
repository or the mailbox ID specified in the <pathname> parameter. Set the current working
mailbox ID using the FTP client cd command. Display the current working data repository using
either the STAT command or the PWD command. For this command, the mailbox ID specified in
<pathname> overrides the setting of the current working mailbox ID, but does not change its value.
Several parameters of the SITE command affect STOR processing. You can set these parameters
using the SITE command and display them using either the STAT command or the PWD command.
Several other parameters of the SITE command cause file characteristics to be stored with the batch.
The following two security checks are made before the STOR command adds a batch:
Session security exit call
Security interface security checks
A unique batch number is assigned to every batch that is added allowing Sterling
Connect:Enterprise to support duplicate user batch IDs.
Before issuing this command, specify a data connection port using either the PORT command or
the PASV command. Sterling Connect:Enterprise assumes that the data connection uses the client's
control connection port and the server's port adjacent to the control port (for example, L–1). Always
specify the data connection port explicitly (through the PORT or PASV commands) instead of
assuming the default.
Sterling Connect:Enterprise FTP put Syntax
The typical FTP client put and mput commands invoke the FTP server STOR command as shown
in the following table. Required parameters are displayed in bold font. No optional parameters are
available.
Sterling Connect:Enterprise Variations from Standard FTP Commands
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 43
put or mput Command (STOU)
In Sterling Connect:Enterprise, the STOU command adds a batch to the current working data
repository or the mailbox ID specified in the <pathname> parameter. Set the current working
mailbox ID using the FTP client cd command. Display the current working data repository using
either the STAT command or the PWD command. For this command, the mailbox ID specified in
<pathname> overrides the setting of the current working mailbox ID, but does not change its value.
Several parameters of the SITE command affect STOU processing. You can set these parameters
using the SITE command and display them using either the STAT command or the PWD command.
Several other parameters of the SITE command cause file characteristics to be stored with the batch.
The following two security checks are made before the STOU command adds a batch:
Session security exit call
Security interface security checks
The user batch ID returned by the STOU command is defined in the BID sub-parameter of the
RECEIVE_OPTIONS of the remote's definition in the *REMOTES section of the ODF. If the BID
sub-parameter is not specified, the user batch ID assigned is 'NONE'.
The format of the user batch ID returned by the STOU command is:
where batch_ID is the 1–64 character user batch ID, # is a constant, and #nnnnnnn is the
7-digit batch number with leading zeroes.
A unique batch number is assigned to every batch that is added allowing Sterling
Connect:Enterprise to support duplicate user batch IDs.
FTP Command Sterling
Connect:Enterprise
FTP Server
Command
Syntax Parameter Description
put, mput STOR STOR<SP><pathname> Required. <pathname> specifies the
1–64 character user batch ID of the
batch to be added. User batch IDs
can contain no wildcard characters,
('-', '.', '*', '?', '[', ']', '/', and '\').
Additionally, you cannot specify '#'
as the first character. If more than 64
characters are specified, a
command syntax error occurs.
batch_ID.#nnnnnnn
Chapter 1 Sterling Connect:Enterprise FTP Implementation
44 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
Sterling Connect:Enterprise FTP put Syntax
The typical FTP client put and mput commands invoke the FTP server STOU command. Required
parameters are displayed in bold font. No optional parameters are available.
pwd Command
For Sterling Connect:Enterprise FTP the PWD prints the current working mailbox ID. It prints to
your standard output. No security checks are made for the PWD command.
pwd Command Syntax
The typical FTP client pwd command invokes the FTP server PWD command as shown in the
following table. Required parameters are displayed in bold font. No optional parameters are
available.
cd Command
The typical FTP client cd command invokes the FTP server CWD command.
For Sterling Connect:Enterprise FTP the CWD command changes the current working mailbox ID
to the specified value. The slash character (/) must precede the mailbox ID. Subsequent commands
use the specified mailbox ID as the current working mailbox ID. The mailbox ID specified may or
may not exist. Display the current working data repository using either the Stat command or the
PWD command.
Note: Before issuing this command, specify a data connection port using either the PORT command or the
PASV command. Sterling Connect:Enterprise assumes that the data connection uses the client's
control connection port and the server's port adjacent to the control port (for example, L-1). For
optimum performance, always specify the data connection port explicitly (through the PORT or
PASV commands) instead of assuming the default
FTP Command Sterling
Connect:Enterprise
FTP Server
Command
Syntax Parameter Description
put, mput STOU STOU<SP><pathname> No parameters are required.
FTP Command Sterling
Connect:Enterprise
FTP Server
Command
Syntax Parameter Description
pwd PWD PWD None
Sterling Connect:Enterprise Variations from Standard FTP Commands
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 45
No security checks are made by this command. Authorization to use the specified mailbox ID is
determined when an FTP server command attempts to access Sterling Connect:Enterprise.
NLST Command
For Sterling Connect:Enterprise FTP the NLST command lists user batch IDs in the current
working data repository or the mailbox ID specified in the pathname parameter. For this command,
the mailbox ID specified in pathname overrides the setting of the current working mailbox ID, but
does not change its value. Set the current working mailbox ID using the FTP client cd command.
Display the current working data repository using the STAT command or the PWD command.
The SITE parameters BCHSEP, FTIME, LS_FILTER, ORIGIN,
REMOTE_FILENAME_LENGTH, and TTIME affect NLST processing. You display these
parameters using either the STAT command or the PWD command.
The current data representation type value does not affect NLST processing. Unless LS_FILTER is
used, output from NLST lists batches of any data type. Set the appropriate data type (ASCII or
EBCDIC) before retrieving batches.
The format of the list returned by the NLST command depends on the value of the BCHSEP
parameter of the SITE command. See Batch Status Flags on page 41 for a description of these
values.
The following two security checks are made before the NLST command lists a batch:
Session security exit call
Security interface security checks
Note: The values of 2 periods in a row (..) or a single period between two blank characters ( . ) are not
supported and are treated as syntax errors.
Note: Remote sites with the name “anonymous” are not permitted to use CWD. They are restricted to the
“PUBLIC” mailbox ID.
Note: The current data representation must be either ASCII or EBCDIC. Image type is unsupported and
is not recognized.
Note: Before issuing this command, specify a data connection port (using either the PORT or PASV
command). Sterling Connect:Enterprise assumes the data connection uses the client's control
connection port and the server's port adjacent to the control port (for example, L–1). Always specify
the data connection port explicitly (through the PORT or PASV commands) instead of assuming
the default.
Chapter 1 Sterling Connect:Enterprise FTP Implementation
46 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
Sterling Connect:Enterprise NLST Command Syntax
The typical FTP client ls, mdelete, and mget commands invoke the FTP server NLST command as
shown in the following table.
Batch Selection
If the user batch ID specified in <pathname> is in '#nnnnnnn', 'nnnnnnn', 'batch_ID.#nnnnnnn', or
'#nnnnnnn.dat' format, and the batch is in the current working data repository, the single batch with
batch number 'nnnnnnn' is eligible for the list.
If the user batch ID specified in <pathname> is in “generic-name”, 'specific', or 'spec*?[]' format,
all of the batches in the current working data repository that match the user batch ID are eligible for
the list.
If the user batch ID is not specified, all of the batches in the current working data repository are
eligible for the list.
Eligible batches are selected for listing depending on the current settings of the SITE parameters
FTIME, LS_FILTER, ORIGIN, and TTIME.
An eligible batch is selected for listing if the following conditions are met:
The batch is contained in an online VBQ.
The batch's status is not excluded by the values specified in the LS_FILTER parameter.
The batch's creation date and time is on or after the value specified in the FTIME parameter.
The batch's creation date and time is on or before the value specified in the TTIME parameter.
The batch's origination matches the value of the ORIGIN parameter or the ORIGIN parameter
is blank.
If eligible batches are available and selected, the list is returned through the data connection.
If the user batch ID specified in <pathname> is formatted as '#nnnnnnn', 'nnnnnnn',
'batch_ID.#nnnnnnn', or '#nnnnnnn.dat', the FTIME, LS_FILTER, ORIGIN, and TTIME
parameters are ignored.
The LS_FILTER parameter limits the selection of batches based on a batch's status flags.
The FTIME and TTIME parameters limit the selection of batches based on the batch's earliest and
latest creation date and time, respectively.
The ORIGIN parameter limits the selection of batches based on the name of the user or remote that
created the batch.
FTP
Command
Sterling
Connect:Enterprise
FTP Server
Command
Syntax Parameter Description
pwd PWD NLST[<SP><pathname>] Optional. <pathname> specifies the
1–64 character user batch ID of the
batch to be listed.
Preparing Batches for the Sterling Connect:Enterprise FTP Server
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 47
Preparing Batches for the Sterling Connect:Enterprise FTP
Server
The typical FTP client put and mput commands invoke the FTP server STOR or STOU command
to add batches of data to the host data repository on the Sterling Connect:Enterprise FTP server.
Scanning must be in effect on the Sterling Connect:Enterprise FTP server side for $$ADD
commands to function as instructions to add batches of data to the VSAM batch files for
transmission instead of being treated as data. If scanning is not in effect, all $$ADD and other
embedded $$ commands as well as /* cards (/*SIGNON and /*BINASC, which contain session
startup information) are treated as data.
No $$ADD batches transferred by one FTP command are considered complete until the final
$$ADD is complete.
To continue scanning for additional $$ADD commands after each $$ADD command, you can use
one of the following methods:
At the FTP client site, include the parameter, SCAN=YES in each $$ADD command, or set
the initial SCAN setting to ALL using the SITE command.
At the FTP server site, set the initial SCAN setting to ALL in the ODF or by using the
LOCSITE script command.
When you embed $$commands in data, use the following table to determine how to delimit records,
depending on the data structure, transfer mode, and data type.
For more information about how $$ADD commands are processed and how Sterling
Connect:Enterprise recordizes batches, see the chapter on configuring ODF records for FTP
connections in the IBM Sterling Connect:Enterprise for z/OS Administration Guide.
Data Structure Transfer Mode/Data Type End of Record Delimiter
Record Stream Explicit End of Record (control code x’FF02’)
File Block or Compressed EOR descriptor in block header (B) or Esc sequence
(C)
File Stream/ASCII Carriage Return-Line Feed (CRLF or x’0D0A’)
File Stream/EBCDIC New Line (NL or ‘x15’)
File Stream/Images Records not supported—only one $$ADD allowed and
must be delimited by either:
$$END with the rest of file being considered data
4096 bytes with data starting at the 4097th byte
after the first $ in ADD.
Chapter 1 Sterling Connect:Enterprise FTP Implementation
48 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
Using $$Commands and /*Cards
Files using embedded $$commands and /* cards must meet certain requirements. The first table
summarizes these requirements for a file with a /*BINASC card; the second table is for a file
without a /*BINASC card. In both tables, the file components are listed in the order of appearance
in the file.
The third column in both tables lists the character set for ASCII, Image, and EBCDIC data types.
The character set can be ASCII (A), Scanning (S), and E (EBCDIC). When a record is scanned, its
first byte determines the character set for that record:
/*SIGNON, /*BINASC, $$ADD, $$DEL, $$DIR, $$LOG, $$REQ.
Only look for /*SIGNON on first record.
Only look for /*BINASC immediately after the first $$ADD.
First check for EBCDIC then ASCII. The translate table used is specified in the TRANSLATE
parameter in the *REMOTES record for FTP Client and server connections in the Options
Definition File. This parameter specifies the name of the translation table to use when
converting ASCII data to EBCDIC data or EBCDIC data to ASCII data.
If no match for either type, data is assumed and is always binary.
The last column, Ends with, lists the delimiter used to mark the end of the file:
EOR stands for End of Record meaning the last byte of the record or $$END
EOB stands for End of batch meaning the last byte of the batch
EOF stands for End of File meaning the last byte of the file
$$Commands and /*SIGNON with /*BINASC
File Component Specification Char Set for TYPE =
A / I / E
Begins at Ends
with
/*SIGNON Optional A / S / E First byte of file EOR
First non-$$ADD
$$command
Optional A / S / E First byte of file or after
/*SIGNON
EOR
Subsequent
non-$$ADD
$$commands
Any number A / S / E After the previous non-
$$ADD $$cmd
EOR
First $$ADD
command
Optional A / S / E First byte of file or after the last
present one of the preceding
EOR
/*BINASC Present in file A / S / E First byte of file or after the last
present one of the preceding bytes
First data Required Binary After /*BINASC EOF
Subsequent
$$ADD and data
Not allowed
Preparing Batches for the Sterling Connect:Enterprise FTP Server
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 49
$$Commands and /*SIGNON without /*BINASC
Syntax
The syntax for the $$ADD command at FTP sites is:
Be sure to follow these rules:
The first $ of the command must be the first character of a record.
Use one or more blanks to separate each parameter.
You must specify a BATCHID within a pair of single quotes. Otherwise, the parameter is not
recognized. Once the string, BATCHID=’ is found, a corresponding close quote must be found
within 24 bytes or the rest of the $$ADD card is ignored.
Only ID and BATCHID values can have mixed case. All else must be upper case.
Both unrecognized and duplicate parameters are ignored without generating any messages. Only
the first parameter for each keyword is processed.
$$ADD Command Parameters
The following table describes the parameter that can be used with the $$ADD command at FTP
client sites:
File Component Specification Char Set for TYPE =
A / I / E
Begins at Ends
with
/*SIGNON Optional A / S / E First byte of file EOR
First non-$$ADD
$$command
Optional A / S / E First byte of file or after
/*SIGNON
EOR
Subsequent
non-$$ADD
$$commands
Any number A / S / E After the previous non-
$$ADD $$cmd
EOR
First $$ADD Optional A / S / E First byte of file or after the last
present one of the preceding
EOR
/*BINASC Not present
First data Required A / Binary / E First byte of file or after the last
present one of the preceding
EOF or
EOB
Subsequent
$$ADD
Any number A / S / E After last record of first data EOR
Subsequent data Any number A / S / E After a subsequent $$ADD EOF or
EOB
$$ADD ID=xxxxxxxx BATCHID=‘xxx...xxx’ EO=N|NO|Y|YES MULTXMIT=N|NO|Y|YES
SCAN=N|NO|Y|YES TO=N|NO|Y|YES VBQ#=n|nn XMIT=N|NO|Y|YES [$$END]
Chapter 1 Sterling Connect:Enterprise FTP Implementation
50 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
Parameter Description
ID=xxxxxxxx Optional. 1–8 bytes.
BATCHID=’xx...xxx’ Optional. 1–64 bytes. Default for STOR or RETR is the BID. For STOU, it is taken
from RECEIVE_OPTIONS BID parameter. If no BID parameter is specified, the
STOU $$ADD BID defaults to 'BATCH WITHOUT $$ADD', not 'NONE'.
A null BATCHID takes the default value, AC BATCH WITHOUT $$ADD.
EO=N|NO|Y|YES Optional. Extract once.
EO=YES specifies that the batch is extracted and stored one time from a remote
client and cannot be transmitted.
The default value EO=NO does not prevent transmission or multiple extractions.
MULTXMIT=N|NO|
Y|YES
Optional. Multi-Transmittable. The default is NO.
SCAN=N|NO|Y|
YES
Optional. Overrides current SCAN setting. The default is NO.
Specifies whether Sterling Connect:Enterprise scans received batches for $$
commands.
NO = Scanning for Sterling Connect:Enterprise $$ commands ends and the rest of
the file is treated as data.
YES = Scanning for Sterling Connect:Enterprise $$ commands continues. To keep
scanning in effect when a $$ADD card is encountered, each $$ADD card must
include the parameter SCAN=YES. Use this value to make FTP command scanning
behave like it does in SNA.
TO=N|NO|Y|YES Optional. Transmit once.
TO=YES specifies that the batch being received can only be transmitted once and is
not extractable. TO=YES can be thought of as “transmit once, transmit only“. The
default TO=NO specifies that the batch is not marked non-transmittable.
VBQ#=n|nn Optional. The default is the current collection VBQ.
Specifies the number of the VBQ file on which batches collected in FTP sessions are
to be stored.
To set this value for multiple collections, the command is:
LOCSITE VBQ#=nn KEEP
KEEP must be the next parameter after VBQ#=nn to retain the value for more than
one batch collection unless it part of an MGET command. If nn is 00, the assignment
resets to the Current Collect VBQ. If nn is 01 through 20 that particular VBQ is
allocated.
XMIT=N|NO|Y|YES Optional. Transmittable.
$$END Optional for all files except for files with a File data structure transferred in stream
mode containing images.
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 51
Chapter 2
Communicating with SNA Sites
This chapter contains procedures and information specific to operating Sterling Connect:Enterprise
with SNA sites.
Start and End a Session
The procedures for starting and ending a session are:
1. Establish a connection.
Your remote site may exist on a switched (dialup) or nonswitched (dedicated or leased) line.
You may have different procedures to follow when you first establish a connection with
Sterling Connect:Enterprise. Get the specific procedures to establish a connection from your
Sterling Connect:Enterprise system administrator.
2. Log on SNA.
This procedure is done either manually or automatically and is remote-site dependent.
3. Type the commands described in this chapter.
4. Log off SNA.
See Chapter 4, Remote User Commands for more information about logon and logoff functions for
SNA.
Host-Initiated Communications (Auto Connect)
Sterling Connect:Enterprise has a function called Auto Connect that enables the host site computer
to contact an unattended remote site. Using Auto Connect, Sterling Connect:Enterprise can both
transmit to and collect data batches from remote sites.
For Auto Connect to work, the remote site must appropriately respond to the host computer. Host
site personnel provide the actions you take to prepare your site for responding to an Auto Connect
from the host site.
Chapter 2 Communicating with SNA Sites
52 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
Sterling Connect:Enterprise is very flexible in the way it uses the Auto Connect function. For
example, Sterling Connect:Enterprise can be configured to transmit batches to your remote site at
different times throughout the night. Your remote site terminal or computer is then required to
receive the batches whenever the host makes contact.
Batches can be sent to the host site during Auto Connect. Since Auto Connect is often used with
remote sites that can operate unattended, program or set up these terminals to send batches when
the terminal is called by the host site.
Alternatively, you may receive a call from the host site at certain times of the day. You can then
manually send batches to the host, if instructed to do so.
Host-initiated sessions do not support any $$ commands from the remote other than $$ADD.
Using Sterling Connect:Enterprise
Sterling Connect:Enterprise is a command-driven application. For example, a remote site can
precede the transmittable data with a $$ADD header record.
The following command tells Sterling Connect:Enterprise to add the data that follows to the host
data repository and identify that batch as report summary from ACME:
The following command tells Sterling Connect:Enterprise to transmit all batches with an ID of
ACME and a batch identifier of ‘report summary’ to the requesting remote site:
The following command tells Sterling Connect:Enterprise to flag as deleted all batches with an ID
of ACME and a batch identifier of ‘report summary’:
Wildcard Characters in Sterling Connect:Enterprise Names
Sterling Connect:Enterprise, SPC Option 3.1, and IBM® Sterling Connect:Enterprise® for UNIX
3.1 use the following special characters as wildcard characters when making decisions for various
$$ADD ID=ACME BID=‘report summary’
$$REQUEST ID=ACME BID=‘report summary’
$$DELETE ID=ACME BID=‘report summary’
Terminal-Dependent Options
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 53
types of data repository processing. Use the following wildcard characters in selection checks, most
notably with BID values.
You may create batches with a BID value that include wildcard characters. However you may get
unexpected results if you use wildcard characters in requests. For example:
You create three batches with a BID value of ‘Test **’, ‘Test 123’, and ‘Test **456’
respectively. Because offline ADD processing and online collection processing do not restrict
putting wildcard characters in the BID parameter, the batches are added to Sterling
Connect:Enterprise without errors.
To collect the batch with the BID of ‘TEST **’ you create the following $$REQUEST card:
After submitting the request, you discover that you have collected data from all three batches.
To prevent the previous error, take one of the following steps:
Refrain from using the wildcard characters when defining any name in data repository. The
Sterling Connect:Enterprise System Administrator can enforce this rule by creating a Security
Exit 1 and Offline ADD Exit to restrict the use of these characters in name values when adding
data.
Continue to use wildcard characters in data repository name values, but do not use any
parameters that support wildcard characters. For example, use the #nnnnnnn parameter to
request a specific batch by number. Do not use BID=‘xxx-xxx’, as this parameter supports
wildcards. Using this method limits selection, but eliminates confusion.
Terminal-Dependent Options
A variety of terminals and devices can communicate with Sterling Connect:Enterprise, but they do
not all have the same capabilities. For this reason, Sterling Connect:Enterprise supports some
terminal-dependent options for SNA. Some of these options are used only if they are installed by
host site personnel. Other options do not require host site installation; they are used if your terminal
type supports them.
Wildcard Character Function
asterisk (*) Indicates any number of characters
question mark (?) Indicates a single character
square brackets ([ ]) with any number of
characters inside the brackets including an
exclamation mark (!)
Indicates a specific character, or characters within a
string of characters.
$$REQ ID=yourid BID=’TEST **’
Chapter 2 Communicating with SNA Sites
54 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
SNA Sites
SNA terminal-dependent options are enabled only if your remote terminal supports the capability.
These options include:
Multiple Logical Unit (MLU) support
Device media support
Console display use
Data compression
Batch separation using Function Management Headers (FMHs)
SNA transparency
Disconnect interval
Extended Binary Coded Decimal Information Code (EBCDIC) support
Detailed information about these options is provided in the sections that follow:
MLU (Multiple Logical Unit) Support
MLU Support permits a single remote terminal to be considered up to six terminals or sessions.
Each session can have a different transaction in progress with Sterling Connect:Enterprise for a
mixture of simultaneous data collections or transmissions on each of the separate terminals.
Type a logon command to Sterling Connect:Enterprise for each MLU session you wish to activate.
These sessions are used as pipelines to activate multiple inbound and outbound data streams that all
come from the same remote site. Alternatively, think of these sessions as logical remotes, with each
remote site appearing as a separate remote to Sterling Connect:Enterprise. It is possible to let your
remote terminal have one or more active sessions with Sterling Connect:Enterprise, along with
active sessions to other applications in the host, such as JES2. All these options depend on the
implementation of MLU capabilities in your remote terminal. Sterling Connect:Enterprise
automatically handles the MLU capability if it receives more than one logon for the same remote
site.
To implement MLU support:
1. Find out if and how your remote terminal supports MLU.
2. Logon multiple times to Sterling Connect:Enterprise.
3. Use any active MLU session to send or receive data.
Device Media Support
Some terminals have the capability to send or receive data on a certain medium.
You can send data to Sterling Connect:Enterprise from the following media:
Console keyboard
Card reader
Exchange disk (transmission format or basic exchange)
Printer output
Terminal-Dependent Options
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 55
You can receive data from Sterling Connect:Enterprise to the following media:
Console display
Card punch
Exchange disk (transmission format or basic exchange)
Printer
You always control the medium for inbound data sent to Sterling Connect:Enterprise. The medium
used for outbound data sent to your terminal is controlled by you or by defaults set by host site
personnel when Sterling Connect:Enterprise is installed.
When you request a batch from Sterling Connect:Enterprise, specify the medium that receives data
from Sterling Connect:Enterprise. If you do not specify the medium, the batch is sent to the default
medium for your remote site, as selected by host site personnel.
To implement device media support:
1. Determine if your remote terminal supports the receipt of data to a variety of media.
2. Ask your host site personnel to set a certain default medium for your remote site.
3. Specify the medium used when you request data from Sterling Connect:Enterprise, if different
from the default. (optional)
Console Display Use
Sterling Connect:Enterprise can direct specific short information messages or error messages to a
console display screen if your remote site is set up to handle the messages. Some types of messages
are:
A message following a successful logon to Sterling Connect:Enterprise
A message indicating that Sterling Connect:Enterprise is ready to receive data from your
terminal
A message following a security violation
These messages are very helpful, so use them whenever possible.
In order for Sterling Connect:Enterprise to send the messages, your host site personnel must set an
option for your remote site before Sterling Connect:Enterprise is brought online.
To implement console display:
1. Find out if your remote terminal can display control messages or other data on a console.
2. Ask host site personnel to define your remote site as a console device. This is the default
value.
Data Compression
If your device cannot receive data from Sterling Connect:Enterprise in a compressed format,
personnel at the host site need to know so they can specify COMPRESS=NO in the ODF. In
addition, ensure the host VTAM Logon Mode Table reflects that compression is not supported. If
these two areas are in conflict, message CMB184I is issued on the host system console.
Chapter 2 Communicating with SNA Sites
56 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
Batch Separation Using FMHs
Remote sites can sometimes insert Functional Management Headers (FMHs) at the beginning and
end of a batch sent to Sterling Connect:Enterprise. Your terminal probably controls the use of
FMHs, and you need not worry about them. Some terminals enable you to influence the insertion
of these FMHs, thereby indicating what is considered a batch to Sterling Connect:Enterprise. If your
terminal has this capability, Sterling Connect:Enterprise automatically supports it.
You have the option to control when the FMHs are used, or you may configure this Process to run
in the background.
If your terminal or the software package used on your terminal mentions FMHs, ensure your use of
FMHs is compatible with Sterling Connect:Enterprise. Sterling Connect:Enterprise assumes that an
FMH for Begin Data Set (BDS) marks the beginning of a batch, and an FMH for End Data Set
(EDS) marks the end of a batch. If you are sending a single batch to Sterling Connect:Enterprise,
this is probably handled automatically. If you are sending multiple batches or using nested send
functions, your terminal may or may not separate the batches with FMHs. If you want Sterling
Connect:Enterprise to consider the multiple batches as separate, you must ensure FMHs are
inserted.
To implement batch separation using FMHs:
1. Determine if you have any control over the insertion of FMHs. This control influences what
constitutes a batch to Sterling Connect:Enterprise.
2. No host site installation option is needed. Sterling Connect:Enterprise automatically handles
FMHs if present.
SNA Transparency
SNA transparency enables Sterling Connect:Enterprise to send and receive data that contains
special embedded control characters, such as object modules. This function is often needed when
sending data from a remote personal computer to the host site, but the data is not converted from
ASCII to EBCDIC.
Sterling Connect:Enterprise automatically supports the use of SNA transparency with two
restrictions:
Outbound data from Sterling Connect:Enterprise to your terminal does not use transparency
for data sent to the printer media or to the basic exchange media.
Sterling Connect:Enterprise cannot recognize control commands that are sent as transparent
data and not converted to EBCDIC transmission code.
To implement SNA transparency:
1. Choose the appropriate method for your terminal type to send transparent data to Sterling
Connect:Enterprise.
2. No host site installation option is needed. Sterling Connect:Enterprise automatically handles
transparent data.
Sample Data Streams
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 57
Disconnect Interval
The disconnect interval forces your session with Sterling Connect:Enterprise to terminate when
your session is inactive for a certain time interval.
The function of the Sterling Connect:Enterprise disconnect interval is to:
Reduce phone costs in a dial-up network
Provide added security
Host site personnel implement remote Sterling Connect:Enterprise disconnect intervals and define
time intervals, which are from 1-9 seconds, 999 seconds, or set to 0 to prevent any forced
disconnect.
If your remote site has a similar function, set a different disconnect interval than that used by
Sterling Connect:Enterprise. For information about setting a different disconnect interval, contact
your host site system administrator.
EBCDIC Support
Sterling Connect:Enterprise can receive any data format, but can only interpret data that uses
EBCDIC character code.
Sample Data Streams
The following are samples of valid data streams sent from a remote site to Sterling
Connect:Enterprise:
1. At SNA sites, request a directory listing of all batches associated with mailbox ID
BRANCH01 and send in two files containing data for a payroll job run at the host.
Note: If you lose your connection to Sterling Connect:Enterprise while transmitting data, the cause is
probably a network issue rather than the expiration of the disconnect interval.
$$DIRECTORY ID=BRANCH01
$$ADD ID=BRANCH01 BATCHID=‘4/23 PAYROLL DATA’ SCAN=Y
data record 1
data record 2
.
.
last data record
$$ADD ID=BRANCH01 BATCHID=‘4/24 PAYROLL DATA’ SCAN=N
data record 1
data record 2
.
.
last data record
Chapter 2 Communicating with SNA Sites
58 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
2. Request three data transmissions from the host: one for all batches waiting for transmission to
mailbox ID BRANCH01, and two for specific batches for mailbox ID MARY. Data requested
for mailbox ID MARY is sent directly to a printer.
3. For SNA sites the MEDIA operand is added so that the directory list is displayed on the
console display.
SNA Site Parameters
The following table describes the SNA site parameters:
Note: Because the $$ADD commands are processed first, the newly added batches are included in
the $$DIRECTORY output.
$$REQUEST ID=BRANCH01
$$REQUEST ID=MARY BATCHID=‘LETTER FROM JOE’ MEDIA=PR
$$REQUEST ID=MARY BATCHID=#14 MEDIA=PR
$$DELETE ID=MARY BATCHID=#67
$$DIRECTORY PASSWORD=SECRET MEDIA=CN
Operand Command Description
APPLID(xxxxxxxx) LOGON
LOGOFF
$$LOGOFF
The 1–8 character APPLID given to Sterling
Connect:Enterprise at the host site, as chosen by
your host site personnel.
BCHSEP=OPT3 $$REQUEST Separates batches sent to remote sites when
sending multiple batches in a single connection.
OPT3
BCHSEP must remain consistent throughout a
single connection and all $$ commands.
DATA(XXX,,XXX) LOGON Supplies your remote name to Sterling
Connect:Enterprise. Host site personnel supply
you with your own unique, confidential remote
name. If required, you may supply a password
(separated from the remote name by two
commas) and use the new password option. This
information resides in the logon, because it
determines some options to use during
communications.
SNA Site Parameters
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 59
EO=N | Y $$ADD Specifies that the batch is extracted only once
and cannot be transmitted. After extraction, the
batch is permanently locked.
FORMAT=BID24 | BID64 $$DIRECTORY Specifies the format to use when listing batches.
BID24 displays the directory using the first 24
characters of the User Batch ID.
BID64 displays the directory display using the full
64 characters of the User Batch ID.
LOGMODE(xxxxxxxx) LOGON Supplies a value to determine the rules for
communications between Sterling
Connect:Enterprise and your remote site. It is a
1-8 character name, as chosen by your host site
personnel.
MEDIA=CN | PR | PU | EX | BX $$DIRECTORY
$$REQUEST
(SNA sites only.) This parameter asks the host
site to send the output data to the specified
media on the remote device.
Your remote device must support the requested
media, ensure the media is ready and available
for use.
CN sends output data to the console display. This
option causes Sterling Connect:Enterprise to use
an X‘15’ (new line) as a record separator.
PR sends output data to the printer. This option
causes Sterling Connect:Enterprise to use an
X‘15’ (new line) as a record separator.
PU sends output data to the card punch. This
option causes to use an X‘1E’ (standard IRS) as
a record separator.
EX sends output data to the exchange disk, and
uses transmission exchange format.
BX sends output data to the exchange disk, and
uses basic exchange format.
Many remote devices have the capability to
assign media. For example, output data sent to
the card punch is often assigned to a disk file on
a personal computer. Sterling Connect:Enterprise
is not aware of how you assign your remote site’s
media.
Operand Command Description
Chapter 2 Communicating with SNA Sites
60 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
MULTXMIT=NO | YES $$ADD (MX=)
NO indicates that the batch is not available for
multiple transmission. If a batch marked NO
transmits to a remote site, that batch is marked
with a T and is not available for transmission
unless requested by batch number.
YES indicates that the batch is available to all
remote sites and is not marked with a T when
requested by and transmitted to a remote site.
Note: When MULTXMIT=YES, XMIT is
forced to YES.
ONEBATCH=NO | YES $$REQUEST (OB=)
NO indicates all matching batches are returned.
YES indicates that when BATCHID= is specified,
only the first matching batch is returned.
PASSWORD=xxxxxxxx $$DIRECTORY (PSWD=) The PASSWORD, if used, must match
that supplied by host personnel for the Sterling
Connect:Enterprise system. This parameter is
required if the ID parameter is omitted.
RMT=xxxxxxxx LOGOFF
$$LOGOFF
Replace the xxxxxxxx with the 1-8 byte remote
name assigned to your remote terminal. It must
match the remote name supplied in the logon.
This operand is required.
SCAN=NO | YES $$ADD NO indicates that all $$ commands must begin at
the start of a data block. The default is NO.
YES indicates that each record of each data
block is decompressed and deblocked to SCAN
for embedded $$ commands. This removes the
requirement for starting $$ commands at the
beginning of a data block.
Use of this operand could result in system
degradation due to the increased overhead.
Note: Specifying SCAN=YES causes
Sterling Connect:Enterprise to scan for
only the next $$ command in
subsequent data blocks. Once the next
$$ command is found, further scanning
is controlled by repeated specification
of the SCAN= parameter.
Note: The SCAN=YES facility for the $$ADD
control card is ignored on remote sites
that have SC=YES defined in the
*REMOTES record in the ODF.
TO=N | Y $$ADD Specifies that the batch is not extracted. It
permits only one successful transmission, then
the batch is permanently locked.
Operand Command Description
SNA Site Parameters
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 61
TRUNC=NO | YES $$REQUEST This parameter specifies whether Sterling
Connect:Enterprise truncates all trailing blanks
from records before data transmission.
NO means no blanks are truncated.
YES means all blanks are truncated prior to data
compression and data transmission.
VBQ#=xx $$ADD Specifies the VBQxx (where xx is any number
from 1-20) file where you want to add the batch. If
this option is not specified, the batch is placed in
the current collection VBQ file. If the specified
VBQ is not allocated, the batch is added to the
current collection VBQ.
Operand Command Description
Chapter 2 Communicating with SNA Sites
62 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
WAIT=hh:mm:ss, C $$REQUEST Specifies the maximum Sterling
Connect:Enterprise wait time and retry cycle
used for the $$REQUEST.
Permits the remote site to wait for transmittable
batches for a specified time if no batches are
initially found.
The wait time is specified in hours, minutes, and
seconds. The following describes valid values for
the first subparameter:
ss— Specifies the amount of time to wait, in
seconds. The maximum allowable value in
this form is 59.
mm:ss—Specifies the amount of time to wait,
in minutes and seconds. The maximum
allowable value in this form is 59:59.
hh:mm:ss—Specifies the amount of time to
wait, in hours, minutes, and seconds. The
maximum allowable in this form is 23:59:59.
The second parameter is optional. It specifies the
number of wait and retry cycles to attempt before
failing the request if no batches are available.
The maximum allowable value is 999. The default
value is 1.
For example, use the following to request all
batches for an ID and to specify the wait period, if
no batches are found:
$$REQUEST ID=DALLAS WAIT=59,10
This request waits 59 seconds for a transmittable
batch and retries the search for a transmittable
batch 10 times. This effectively waits for a batch
for a total of 9 minutes and 50 seconds.
Once a request is satisfied by sending one or
more batches, the request is removed from the
wait loop. If all retries are done and no batches
are available for transmission, then the standard
message of no batches for transmission is sent to
the remote site.
Note: If your SNA session is through SPC,
verify that the disconnect interval
defined in SPC is adequate to support
appropriate processing.
XMIT=NO |YES $$ADD NO indicates that the batch is available only to
the host site.
YES indicates that the batch being sent to the
host is available for transmission to any remote
site that requests it with the appropriate
mailbox ID.
Operand Command Description
SNA Site Parameters
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 63
Chapter 2 Communicating with SNA Sites
64 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 65
Chapter 3
Communicating with BSC Sites
This chapter contains procedures and information specific to operating Sterling Connect:Enterprise
with BSC sites.
Start and End a Session
The specific procedures for starting and ending a session are:
1. Establish a connection.
Your remote site may exist on a switched (dialup) or nonswitched (dedicated or leased) line.
You may have different procedures to follow when you first establish a connection with
Sterling Connect:Enterprise. Get the appropriate procedures to establish a connection from
your Sterling Connect:Enterprise system administrator.
2. SIGNON (optional).
This procedure is done either manually or automatically and is remote-site dependent.
3. Type the commands described in this chapter.
Sterling Connect:Enterprise Support for Signon (BSC Sites)
Remote terminals that communicate with Sterling Connect:Enterprise are often designed to
communicate with special RJE (Remote Job Entry) systems on the host computer, such as JES.
Some RJE systems require a SIGNON record sent from the remote site when the transmission
connection is established. Sterling Connect:Enterprise does not require this SIGNON record, but
can accept it if your remote terminal sends it to the host site.
Sterling Connect:Enterprise is configurable to permit a free-form SIGNON record, which is
received by the host from your remote but is not validated. The host site personnel who install
Sterling Connect:Enterprise define one or more valid SIGNON records, and inform the remote sites
of the appropriate data to use.
Sterling Connect:Enterprise does not require the fixed-form SIGNON record. Begin your input data
with any of the Sterling Connect:Enterprise $$ commands other than the SIGNON.
Chapter 3 Communicating with BSC Sites
66 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
Host site personnel can also define optional free-form SIGNON records that create an environment
for security checking. Coordinate the use of this or other SIGNON support with the host site.
Host-Initiated Communications (Auto Connect)
Sterling Connect:Enterprise has a function called Auto Connect that enables the host site computer
to contact an unattended remote site. Using Auto Connect, Sterling Connect:Enterprise can both
transmit to and collect data batches from remote sites.
For Auto Connect to work, the remote site must appropriately respond to the host computer. Host
site personnel provide the actions you take to prepare your site for responding to an Auto Connect
from the host site.
Sterling Connect:Enterprise is very flexible in the way it uses the Auto Connect function. For
example, Sterling Connect:Enterprise is configurable to transmit batches to your remote site at
different times throughout the night. Your remote site terminal or computer is then required to
receive the batches whenever the host makes contact.
Batches can be sent to the host site during Auto Connect. Since Auto Connect is often used with
remotes that can operate unattended, program or set up these terminals to send batches when the
terminal is called by the host site.
Alternatively, you may receive a call from the host site at certain times of the day. You can then
manually send batches to the host, if instructed to do so.
Host-initiated sessions do not support any $$ commands from the remote other than $$ADD.
Using Sterling Connect:Enterprise
Sterling Connect:Enterprise is a command-driven application. For example, a remote site can
precede the transmittable data with a $$ADD header record.
The following command tells Sterling Connect:Enterprise to add the data that follows to the host
data repository and identify that batch as report summary from ACME:
The following command tells Sterling Connect:Enterprise to transmit all batches with an ID of
ACME and a batch identifier of ’report summary’ to the requesting remote site:
The following command tells Sterling Connect:Enterprise to flag as deleted all batches with an ID
of ACME and a batch identifier of ’report summary’:
$$ADD ID=ACME BID=‘report summary’
$$REQUEST ID=ACME BID=‘report summary’
$$DELETE ID=ACME BID=‘report summary’
Wildcard Characters in Sterling Connect:Enterprise Names
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 67
Wildcard Characters in Sterling Connect:Enterprise Names
Sterling Connect:Enterprise, SPC Option 3.1, and Sterling Connect:Enterprise for UNIX 3.1 use the
following special characters as wildcard characters when making decisions for various types of data
repository processing. Use the following wildcard characters in selection checks, most notably with
BID values.
You may create batches with a BID value that include wildcard characters. However you may get
unexpected results if you use wildcard characters in requests. For example:
You create three batches with a BID value of ’Test **’, ’Test 123’, and ’Test **456’
respectively. Because offline ADD processing and online collection processing do not restrict
putting wildcard characters in the BID parameter, the batches are added to Sterling
Connect:Enterprise without errors.
To collect the batch with the BID of ’TEST **’ you create the following $$REQUEST card:
After submitting the request, you discover that you have collected data from all three batches.
To prevent the previous error, take one of the following steps:
Refrain from using the wildcard characters when defining any name in data repository. The
Sterling Connect:Enterprise System Administrator can enforce this rule by creating a Security
Exit 1 and Offline ADD Exit to restrict the use of these characters in name values when adding
data.
Continue to use wildcard characters in data repository name values, but do not use any
parameters that support wildcard characters. For example, use the #nnnnnnn parameter to
request a specific batch by number. Do not use BID=’xxx-xxx’, as this parameter supports
wildcards. Using this method limits selection, but eliminates confusion.
Terminal-Dependent Options
A variety of terminals and devices can communicate with Sterling Connect:Enterprise, but they do
not all have the same capabilities. For this reason, Sterling Connect:Enterprise supports some
terminal-dependent options for BSC remote sites. Some of these options are used only if they are
Wildcard Character Function
asterisk (*) Indicates any number of characters
question mark (?) Indicates a single character
square brackets ([ ]) with any number of
characters inside the brackets including an
exclamation mark (!)
Indicates a specific character, or characters within a
string of characters.
$$REQ ID=yourid BID=’TEST **’
Chapter 3 Communicating with BSC Sites
68 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
installed by host site personnel. Other options do not require host site installation; they are used if
your terminal type supports them.
BSC Options
BSC terminal-dependent options are used only if your remote terminal supports them. These
options include:
Free-form BSC SIGNON
Blank compression
Blank truncation
Blocked data records
BSC transparency
Record separator override
Use of $TURNLINE$
Temporary Text Delay (TTD)
Wait acknowledgement (WACK)
Detailed information about these options is provided in the sections that follow:
Free-Form BSC SIGNON
This SIGNON requires a remote name and an optional password. It is optional and must be
coordinated with the Sterling Connect:Enterprise host site system administrator.
BSC SIGNON permits users to identify themselves as a specific remote. Without this SIGNON,
users are identified only by the line on which they connected. This line is typically shared by other
users and does not provide a unique identification.
For more information on the free-form BSC SIGNON, refer to the Defining the ODF chapter in the
IBM Sterling Connect:Enterprise for z/OS Installation Guide.
Blank Compression
Data sent over telecommunications systems may contain many blanks (spaces). By using the blank
compression method defined for the IBM 3780 data communication terminal, Sterling
Connect:Enterprise can remove four or more contiguous blank spaces and replace them with a
control character that indicates the number of compressed blanks. In order to specify blank
compression to Sterling Connect:Enterprise in a transmission request, the remote terminal must also
use the IBM 3780 method. In addition, both the host and the remote sites must use blank
compression/decompression for a given transmission or the data is invalid. A batch collected using
blank compression is stored in the VSAM batch files in compressed form and is automatically
decompressed by the EXTRACT utility when extracted from the data repository.
Terminal-Dependent Options
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 69
Blank Truncation
Text data sent over telecommunications systems may have a large number of blanks at the end of
each record. Sterling Connect:Enterprise can remove trailing blanks from records sent to remote
sites. If the trailing blanks are necessary, the remote site must have the capability to replace them.
Also, Sterling Connect:Enterprise can accept data with the trailing blanks stripped.
Blank truncation is restricted to 80-byte fixed-length records. Sterling Connect:Enterprise assumes
blank truncated records are 80-byte fixed-length and a control character indicating the number of
blanks removed is not required.
Blocked Data Records
It is more efficient to transmit blocks of data containing multiple records than it is to transmit
individual records. Sterling Connect:Enterprise sends and receives blocked data records. However,
the block size must not exceed 4096 bytes. If a record does not fit into a block, it is sent in the next
block. An Inter-Record Separator (IRS) X’1E’ or Inter-Unit-Separator (IUS) X’1F’ must separate
the records. X‘1E’ is the most commonly used and is the system default for an IRS. The record
separator used by Sterling Connect:Enterprise when transmitting is set by the host site personnel for
each BTAM transmission line at system installation. All terminals using the same line must handle
the record separator sent by the host. If the terminals cannot handle the record separator sent by the
host, the remote site must use the Record Separator Override option.
Blocked data collected by Sterling Connect:Enterprise is stored in the VSAM batch files in blocked
form. The EXTRACT utility automatically deblocks the blocked data while extracting it from the
data repository.
BSC Transparency
Sterling Connect:Enterprise is capable of sending and receiving transparent data. Transparent data
can contain embedded line control characters. BSC transparency is often a hardware function on
terminals and is invoked by setting a switch. When Sterling Connect:Enterprise receives a $$REQ
from a remote site in transparency form, it transmits all return data in transparency form. Refer to
your terminal or computer operation manual to determine the action required to use BSC
Transparent Data Transmission.
Record Separator Override
A Record Separator (control character) separates multiple records sent in a single nontransparent
block. A default IRS is set by the host site personnel for each line used by Sterling
Connect:Enterprise. If a remote site cannot process the default record separator, the site may request
a record separator override when it asks for data from Sterling Connect:Enterprise. The record
separator is typically either X‘1E’ or X‘1F.’
Note: All data, including record separators and BSC control characters (for example, STX (X‘02’), ETX
(X‘03’), and so forth), must fit in the block size. This is the BUFSIZ= value in the M$LINE user
assembly defined at the host site.
Chapter 3 Communicating with BSC Sites
70 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
Use of $TURNLINE$
The $TURNLINE$ capability provides a special method of limited conversational transmissions
between your remote site and Sterling Connect:Enterprise at the host site. Instead of the standard
send all-receive all mode of communications, your remote site can
send-receive-send-receive-send-receive, and so on, as done for conversational transmissions.
To use this option, coordinate the send-receive sequence exactly with the data batch being sent from
the host site. You send your terminal a signon record, receive data from your terminal, then send
data to your terminal. In this case, set up your terminal to receive the signon record, send data to the
host site, then receive data from the host site. Changing from receive to send, and vice versa, is
called a line turnaround.
The host site data batch being sent controls when the line turnaround occurs. The data batch must
contain a $TURNLINE$ record. When the host site detects a $TURNLINE$ record, it stops sending
and does a line turnaround to receive. The $TURNLINE$ record is not sent to the remote site. After
the receive is complete, the host site can again do a line turnaround to send.
Carefully coordinate the use of this option with the host site. If the $TURNLINE$ feature is used,
get any special requirements for its implementation from the host site personnel.
Temporary Text Delay (TTD)
Sterling Connect:Enterprise sends a BSC 3780 TTD to remotes when file I/O requires more than a
set period of time to complete (usually 3 seconds). TTD processing is invoked when Sterling
Connect:Enterprise is searching for a transmittable batch or when flagging batches matching the
Auto Connect listname as transmitted. The format of the TTD is STX ENQ or X‘022D’. The remote
must reply with a BSC NAK X‘3D’.
WAIT Acknowledgement (WACK)
Sterling Connect:Enterprise is capable of handling a variable number of WACKs (X’106B’) from
a remote site while waiting for the transmission to continue. Sterling Connect:Enterprise responds
with the appropriate ENQ (X’2D’) until the limit, which is controlled by the WACKMAX ODF
parameter, is reached. If you find that Sterling Connect:Enterprise disconnects before your remote
continues transmission, contact host site personnel about increasing the WACKMAX value.
Sample Data Streams
The following are samples of valid data streams sent from a remote site to Sterling
Connect:Enterprise:
1. At BSC sites, request three data transmissions from the host: one for all batches waiting for
transmission to mailbox ID BRANCH02, and two for specific batches for mailbox ID MARY.
Data requested for mailbox ID MARY is sent compressed, and all data is sent in blocks of six
records each.
$$REQUEST ID=BRANCH02 BLOCK=6
$$REQUEST ID=MARY BATCHID=‘LETTER FROM JOE’ BLOCK=6 CMP=Y
$$REQUEST ID=MARY BATCHID=#0014 BLOCK=6 CMP=Y
Sample Data Streams
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 71
2. Request Sterling Connect:Enterprise to delete a batch for mailbox ID MARY and send a
directory listing of all batches for all mailbox IDs on the VSAM batch files.
BSC Site Parameters
The following table describes the BSC site parameters.
$$DELETE ID=MARY BATCHID=#0067
$$DIRECTORY PASSWORD=SECRET
Operand Command Description
BCHSEP=NO | OPT1 |
OPT2 | OPT3
$$DELETE
$$DIRECTORY
$$REQUEST
Specifies the method Sterling Connect:Enterprise uses to
separate the data for multiple $$ commands.
NO indicates batches are not separated. If multiple batches
are sent in a single connection, they are concatenated and
sent as a single batch. Ensure remote sites using this line can
process concatenated data batches if this option is chosen.
OPT1 causes Sterling Connect:Enterprise to use a common
RJE method of separating batches. At the end of each batch,
Sterling Connect:Enterprise sends an EOT (x’37’) to the
remote, reads a response from the remote, and then sends
ENQ (x’02’)to request use of the line. Do not use OPT1 if the
remote site using this line cannot appropriately respond to this
protocol.
OPT2 Sterling Connect:Enterprise separates batches using
an ETX (X‘03’). Do not use OPT2 unless the remote can
appropriately respond to this protocol.
BCHSEP must remain consistent throughout a single
connection and all $$ commands.
BLOCK=xx $$DIRECTORY
$$REQUEST
The BLOCK operand prompts Sterling Connect:Enterprise to
send multiple records in a single data block, separated by
control characters.
xx–specifies the number of records sent per block, up to a
maximum of 99. If BLOCK is omitted, the records are
transmitted to the remote site unblocked. To use this operand,
a remote site terminal must be capable of deblocking the
records for use at the remote site. If the BLOCK factor
specified causes Sterling Connect:Enterprise to build a block
that is larger than the maximum buffer size (4096), a smaller
blocking factor forces the specific transmission size.
$$END $$ADD The $$END parameter signifies the end of a $$ADD card. It is
valid only for blocked BSC transparent transmissions. The
$$END characters are the last five bytes of the $$ADD record.
EO=N | Y $$ADD Specifies that the batch is extracted only once and cannot be
transmitted. After extraction, the batch is permanently locked.
Chapter 3 Communicating with BSC Sites
72 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
FORMAT=BID24 |
BID64
$$DIRECTORY Specifies the format to use when listing batches.
BID24 displays the directory using the first 24 characters of
the User Batch ID.
BID64 displays the directory display using the full 64
characters of the User Batch ID.
MULTXMIT=NO | YES $$ADD (MX=)
NO indicates that the batch is not available for multiple
transmission. If a batch marked NO transmits to a remote site,
that batch is marked with a T and is not available for
transmission unless requested by batch number.
YES indicates that the batch is available to all remote sites
and is not marked with a T when requested by and
transmitted to a remote site.
Note: When MULTXMIT=YES, XMIT is forced to YES.
ONEBATCH=NO |
YES
$$REQUEST (OB=) NO indicates all matching batches are returned.
YES indicates that when BATCHID= is specified, only the first
matching batch is returned.
PASSWORD=
xxxxxxxx
$$DIRECTORY (PSWD=) The PASSWORD, if used, must match that supplied
by host personnel for the Sterling Connect:Enterprise system.
This parameter is required if the ID parameter is omitted.
RECSEP=1E | 1F $$DIRECTORY
$$REQUEST
Temporarily overrides the assigned line Record Separator that
sends blocked records from the host site.
Either 1E or 1F is specified as the record separator.
TO=N | Y $$ADD Specifies that the batch is not extracted. It permits only one
successful transmission, then the batch is permanently
locked.
TRUNC=NO | YES $$REQUEST This parameter specifies whether Sterling Connect:Enterprise
truncates all trailing blanks from records before data
transmission.
NO means no blanks are truncated.
YES means all blanks are truncated prior to data compression
and data transmission.
VBQ#=xx $$ADD Specifies the VBQxx (where xx is any number from 1-20) file
where you want to add the batch. If this option is not specified,
the batch is placed in the current collection VBQ file. If the
specified VBQ is not allocated, the batch is added to the
current collection VBQ.
XMIT=NO | YES $$ADD NO indicates that the batch is available only to the host site.
YES indicates that the batch being sent to the host is
available for transmission to any remote site that requests it
with the appropriate mailbox ID.
Operand Command Description
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 73
Chapter 4
Remote User Commands
This chapter describes the following commands available to Sterling Connect:Enterprise remote
users.:
$$ADD sends a batch of data to the host site
$$DELETE flags a batch of data, as deleted, at the host site
$$DIRECTORY requests a formatted listing of batches from the host site
$$LOGOFF logs off from Sterling Connect:Enterprise at the host site
$$REQUEST requests a batch of data from the host site
In addition, this chapter gives session information and user instructions to assist you during a
Sterling Connect:Enterprise session.
Submit Commands
When a remote connection is established, the remote site communicates with Sterling
Connect:Enterprise by means of the command utilities, referred to as the $$ commands. These
commands are described in the following sections.
The $$ADD command is the only command available for a remote site when the connection is
initiated by the host using an Auto Connect.
$$REQUEST, $$DIRECTORY, $$DELETE, and $$LOGOFF (SNA only) are typed in these three
ways:
Individual commands from your remote computer console keyboard or from a data file
Commands before a $$ADD record at the start of a data batch
Commands after a $$ADD record with SCAN=Y (SNA sites)
When the host receives $$ commands that precede $$ADD, they are saved and processed in the
order received after all inbound data for the $$ADD is received. When the host receives $$
commands as single commands that do not precede $$ADD, they are processed immediately and
the output data is sent to your remote site.
Chapter 4 Remote User Commands
74 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
For BSC only, if multiple $$ output commands are received, the output data is sent as batches
separated by EOTs (X’37’) (see BCHSEP=OPT1 on page 3-11). If a remote site is unable to use
this method of batch separation, the remote must specify BCHSEP=OPT2 on each $$ output
command line. This separates batches with an ETX (X’03’).
The following rules apply to $$ commands:
Place the $$ command in column 1.
Code any number of blanks between operands.
Do not use commas between operands.
Type commands and operands in upper case.
Code must be EBCDIC.
Code each parameter value as documented in Chapter 3, Communicating with BSC Sites.
Short forms are not allowed.
Do not exceed the maximum record length. The maximum $$ remote command record length
is 100 for BSC and 256 for SNA.
The following worksheets can assist you in typing information pertinent to the $$ commands. The
worksheets can be duplicated and used routinely.
Submit Commands
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 75
$$ Command Worksheet
Command $$ADD | $$DELETE | $$DIRECTORY | LOGON | $$LOGOFF | $$REQUEST
Remote site IDs Contact your host site administrator for the following remote site IDs.
Mailbox ID: ID=_______________________________
User Batch ID: BATCHID=__________________________________________
Circle the appropriate option or contact you host site administrator for the values required for the following
operands.
SNA Options BSC Options
Operand Value Operand Value
BCHSEP = OPT3 BCHSEP = NO | OPT1 |OPT2 | OPT3
EO = N | Y EO = N | Y
FORMAT = BID24 | BID64 FORMAT = BID24 | BID64
MEDIA = CN | PR | PU | EX | BX CMP = NO | YES
MULTXMIT = NO | YES MULTXMIT = NO | YES
ONEBATCH = NO | YES RECSEP = NO | YES
SCAN = NO | YES TO = N | Y
TO = N | Y TRUNC = NO | YES
TRUNC = NO | YES XMIT = NO | YES
WAIT = hh:mm:ss, C
__________________
BLOCK =______________________
XMIT = NO | YES PASSWORD =______________________
APPLID =____________________ VBQ# =______________________
DATA =____________________
LOGMODE =____________________
PASSWORD =____________________
RMT =____________________
Chapter 4 Remote User Commands
76 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
$$ADD Command
$$ADD places batches of data into the data repository, and precedes the batch data that is sent. You
may send any number of $$ADD records and associated data files to the host site.
The data collection function is initiated by the remote site. Sterling Connect:Enterprise permits two
methods of initiating data collection:
The preferred method uses a $$ADD record that precedes the data
Another method is to send only data once communications are established. The drawback of
the second method is that the batch is identified by the remote name (BSC and SNA), BSC
line name, or BSC Auto Connect remote name (if BSC SIGNON is not used), rather than your
specific mailbox ID.
$$ADD Defaults
If a data batch is sent to the host site without a $$ADD record, the following defaults are used:
If a data batch is sent to the host site without a $$ADD record during a host-initiated Auto Connect
to the remote site, the following defaults are used:
Default Name Description
BATCHID BATCH WITHOUT $$ADD
ID LINEID for BSC remotes not using the free-form BSC SIGNON
MULTXMIT No
SCAN No
VBQ# Current collection VBQ
XMIT No
Default Name Description
BATCHID AC BATCH WITHOUT $$ADD
ID The remote name from the Auto Connect list
MULTXMIT No
SCAN No
VBQ# Current collection VBQ
XMIT No
$$ADD Command
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 77
Multiple Batches
If multiple batches are sent per transmission, precede each batch with a $$ADD record. If multiple
batches are sent to the host computer in a single transmission, and the batches are separated by
$$ADD records, use caution if the records are blocked by your remote terminal before they are sent
to the host site. Sterling Connect:Enterprise cannot detect a $$ADD record unless is the first record
in a block of data. Ensure that your remote terminal begins a new block for each $$ADD record.
Sterling Connect:Enterprise can also create multiple batches on the VSAM batch files as follows:
At SNA sites, use standard Function Management Headers (FMHs) to separate files sent to the
host site. If Sterling Connect:Enterprise receives an End Data Set FMH from the remote site
during a data collection, the current batch is marked complete and a new batch is started when
the next Begin Data Set FMH is received.
For BSC sites, if Sterling Connect:Enterprise receives a block ending with ETX (X’03’), the
current batch is marked complete and a new batch is started with the next data input from the
remote site.
A new $$ADD record at the beginning of a BSC block causes batch separation as if an ETX had
terminated the previous block.
Syntax
The syntax for the $$ADD command at SNA sites is:
The syntax for the $$ADD command at BSC sites is:
Description
Use any number of blanks to separate operands. Do not use commas to separate operands. $$ADD
must begin in the first record position.
$$ADD BATCHID=‘xxx...xxx’ EO=N|Y ID=xxxxxxxx MULTXMIT=NO|YES
SCAN=NO|YES TO=N|Y VBQ#=nn XMIT=NO|YES
$$ADD BATCHID=‘xxx...xxx’ EO=N|Y ID=xxxxxxxx MULTXMIT=NO|YES TO=N|Y
VBQ#=nn XMIT=NO|YES [$$END]
Note: The parameter setting, SCAN=YES, is ignored on SNA remote sites that have SC=YES defined in
the *REMOTES record in the Options Definition File. See the IBM Sterling Connect:Enterprise for
z/OS Administration Guide for more information on the SC parameter.
Chapter 4 Remote User Commands
78 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
$$DELETE Command
Any batch on the VSAM batch files can be flagged as deleted by a remote site. To delete a batch,
you must know the batch identifiers. Run a directory list to confirm you know the correct batch
identification data before deletion.
After the host receives the input requests, Sterling Connect:Enterprise processes the delete requests
and then turns the line around and sends a message to the remote site concerning the outcome of the
$$DELETE request. Ensure that your terminal is ready to first send the $$DELETE request to the
host site, then receive the output from the host in the same transmission session.
Syntax
To flag a batch as deleted from an SNA site, send the host a $$DELETE record in the following
format:
To flag a batch as deleted from a BSC site, send the host a $$DELETE record in the following
format:
Description
Use any number of blanks to separate operands. $$DELETE must begin in the first record position.
Abbreviate this command as $$DEL.
$$DIRECTORY Command
Remote sites can send inquiries about the contents of the VSAM batch files to the host by
submitting a directory request and their mailbox ID. The directory listing is received in mailbox ID
order. Sterling Connect:Enterprise searches the VSAM batch files for all batches that match the
submitted mailbox ID. A listing of the batch control information for each batch is sent back to the
remote site. It is only possible to obtain a listing of all batches for all mailbox IDs if two conditions
exist: 1) a password was defined when Sterling Connect:Enterprise was installed, and 2) the
password was appropriately submitted in the $$DIRECTORY command from the remote site.
Syntax
To request a directory listing from an SNA site, send the host a record in the following format:
$$DELETE BATCHID=#nnnnnnn ID=xxxxxxxx
$$DELETE BATCHID=#nnnnnnn BCHSEP=OPT1|OPT2 ID=xxxxxxxx
$$DIRECTORY Command
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 79
To request a directory listing from a BSC site, send the host a record in the following format:
Description
Use any number of blanks to separate operands. $$DIRECTORY must begin in the first record
position. Abbreviate this command as $$DIR.
After the host receives your $$DIRECTORY request, Sterling Connect:Enterprise turns the line
around and sends the requested data to the remote site. Ensure that your remote site is ready to send
the $$DIRECTORY request to the host site, and receive the output from the host in the same
transmission session.
Output
One record is returned to the remote site for each batch in the VSAM batch files that matches the
requested mailbox ID. The directory listings use the following format:
The contents of the fields are:
$$DIRECTORY ID=xxxxxxxx FORMAT=BID24|BID64 MEDIA=CN|PR|PU|EX|BX PASSWORD=xxxxxxxx
$$DIRECTORY BCHSEP=OPT1|OPT2 BLOCK=xx ID=xxxxxxxx FORMAT=BID24|BID64
PASSWORD=xxxxxxxx RECSEP=1E|1F
xxxxxxxx #nnnnnnn CT=nnnnnnnnn BID=x...x HHMM-YYDDD ICADNURTEMXBSZ
VBQnn|OFFLINE
Field Description
xxxxxxxxx The 8-byte mailbox ID with which the batch is associated
#nnnnnnn The 7-digit batch number assigned by Sterling Connect:Enterprise
CT=nnnnnnnnn The record/block count in the batch. Depending on the installation parameters,
this value is either the total number of records in the batch or the total number
of blocks in the batch. Contact your Sterling Connect:Enterprise administrator
to determine which value is being used. If the count = 0, then either the batch
data collection is in progress or is interrupted before completion.
Chapter 4 Remote User Commands
80 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
BATCHID=xx....xx The 64-byte user batch ID assigned to the batch when added to the VSAM
batch files. If the batch is created due to an online data collection without a
$$ADD record, this field contains:
BID=BATCH WITHOUT $$ADD (For Remote Connects)
BID=AC BATCH WITHOUT $$ADD (For Auto Connects)
If the batch is created in an online data collection with a $$ADD record, but no
BATCHID is specified, this field contains BID=NONE.
HHMM The time the batch is created
YYDDD The Julian date the batch is created
I|C|A|D|N|U|R|T|E|
M|X|B|S|Z
One or more of the letters ICADNURTEMXBSZ occurs in the directory listing. These
letters indicate the batch status.
I The batch is incomplete; collection is in progress or the transmission is
interrupted
C The batch is collected from a remote site while Sterling Connect:Enterprise is
online.
A The batch is added by the offline utilities
D The batch is flagged as deleted from the VSAM batch files
N The batch is nontransmittable (locked for transmissions). When displayed, this
status replaces the D status. This status is set immediately after the batch is
successfully collected when the EO=Y option of the $$ADD command is
specified. It is also set after a successful transmission of the batch added with
the TO=Y option
U The batch is unextractable (locked for extractions). When displayed, this
status replaces the D or N status. This status is set immediately after the batch
is added, when the TO=Y option adds the batch. It is also set after the batch’s
successful extraction when the EO=Y option added the batch.
R The batch is requestable through a $$REQUEST from a remote site.
T The batch is transmitted to a remote site. It is not transmitted on a transmit all
for the mailbox ID, but can be transmitted again by specific batch number.
E The batch is extracted by host site personnel
M The batch is available for multiple transmission and any remote site can
request it by its ID.
X The batch contains transparent data.
B The batch originated at an online BSC remote site
S The batch originated at an online SNA remote site.
Z EBCDIC data added through the APPC User API
Field Description
SNA Logon System Function
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 81
SNA Logon System Function
Logon is a system function, rather than a Sterling Connect:Enterprise command. Your remote
terminal must log on through VTAM to gain access to Sterling Connect:Enterprise at the host site.
The logon function may be totally automated by your remote site, or you may have to type a logon
or other command on your terminal’s keyboard. The procedures you must use are determined by
host site personnel, not by Sterling Connect:Enterprise. Therefore, this section cannot tell you
exactly how to type a logon, or if a logon is automatic for your terminal. It can give you a general
idea of the information Sterling Connect:Enterprise requires, but the exact format of the logon may
vary.
The following is a sample common logon. This example may not necessarily work for your
particular installation, and the names in parentheses probably differ for your installation.
If something is wrong with your logon, you receive the message SESSION NOT BOUND. This
means that your logon attempt is rejected, either by the system or by Sterling Connect:Enterprise.
Correct the logon format and retype the logon.
For MLU support, you must log on for each session you activate. The sessions can use the same
format for all the logons, or you may be instructed to use a different remote name for each logon.
This decision is made by your host site personnel. MLU supports a maximum of six sessions.
Syntax
Use the following format to log on from an SNA site. This format may not necessarily work for
your particular installation.
Description
Sterling Connect:Enterprise gains control when you type a logon. Three key logon items are
required.
VBQnn|OFFLINE The name of the VSAM batch queue where the data resides. If the batch
resides on a VSAM batch queue, which is not currently allocated to Sterling
Connect:Enterprise, OFFLINE is displayed instead of the VBQ name.
LOGON APPLID(MAILBOX) LOGMODE(RJE3770) DATA(RMT001)
LOGON APPLID(xxxxxxxx)
DATA(xxxxxxxx,,yyyyyyyy,zzzzzzzz)
LOGMODE(xxxxxxxxx)
Field Description
Chapter 4 Remote User Commands
82 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
SNA LOGOFF and $$LOGOFF System Functions
Type LOGOFF as a system function or as a Sterling Connect:Enterprise $$ command. In either
case, the purpose of the logoff is to end the session with the host site. When the logoff function is
processed from a dial-up line, the telephone connection is also dropped.
Type the LOGOFF system function as a command on your terminal’s keyboard or press a specified
function key. The exact procedure depends upon your terminal type and on the implementation by
host site personnel.
The $$LOGOFF Sterling Connect:Enterprise function is essentially a data string that Sterling
Connect:Enterprise interprets as a request to end the session. For security, correctly type your
remote name and the APPLID defined to Sterling Connect:Enterprise.
Syntax
The Sterling Connect:Enterprise logoff function is initiated by sending the host a record with the
following format:
Description
Use any number of blanks to separate operands. $$LOGOFF must begin in the first record position.
$$REQUEST Command
Data transmission to your remote site is initiated by sending a $$REQUEST. A request for a
transmission can identify a single batch on the VSAM batch files or can request transmission of all
batches associated with a mailbox ID. When requesting all batches for a mailbox ID, remember
that only batches not already flagged transmitted are sent. A transmission request for a single batch
by its batch number can access a batch flagged as already transmitted.
If multiple batches are transmitted to a remote site in response to a $$REQUEST for an ID (without
a BATCHID), Sterling Connect:Enterprise separates the batches using standard SNA FMHs, unless
BCHSEP=OPT3 is used, which concatenates the separate batches into one.
Note: The keywords APPLID, LOGMODE, and DATA are standards for typing a logon, but they are
determined by host site personnel. Different keywords may be used, or the information can be typed
as positional parameters instead.
$$LOGOFF APPLID=xxxxxxxx RMT=xxxxxxxx
$$REQUEST Command
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 83
Syntax
At SNA sites, the $$REQUEST record uses the following syntax:
At BSC sites, the $$REQUEST record uses the following syntax:
Abbreviate this command as $$REQ.
Description
Use any number of blanks to separate operands. $$REQUEST must begin in the first record
position.
Parameter Interrelationships
The following is a list of parameter interrelationships:
If TRUNC=Y and CMP=Y are both selected, the data is first truncated and then compressed.
Do not attempt to use BSC transparency in conjunction with blocked data, with TRUNC=Y, or
with CMP=Y.
If a batch is requested using BLOCK for blocked data, and if the requested batch is already
blocked on the VSAM batch files, double blocking can occur. This is appropriately handled by
Sterling Connect:Enterprise, but the remote terminal must be able to deblock such records.
$$REQUEST Sample Outputs
Sterling Connect:Enterprise uses certain criteria to determine which batches are sent to your remote
site for a $$REQUEST. The batch status indicators (such as those displayed for a $$DIRECTORY)
are checked and the following rules are applied:
Requesting all batches for an ID:
The batch must be marked R (requestable). The batch must not be marked T (already transmitted),
D (deleted), I (incomplete), or N (nontransmittable).
Requesting all batches by ID and batch ID:
$$REQUEST BATCHID=‘xx..xx’|“yyy...yyy”|#nnnnnnn BCHSEP=OPT3
ID=xxxxxxxx MEDIA=xx ONEBATCH=NO|YES TRUNC=NO|YES WAIT=hh:mm:ss,C
$$REQUEST BATCHID=‘xx..xx’|“yyy...yyy”|#nnnnnnn
BCHSEP=NO|OPT1|OPT2|OPT3 BLOCK=xx CMP=NO|YES ID=xxxxxxxx
ONEBATCH=NO|YES RECSEP=xx TRUNC=NO|YES
$REQUEST ID=xxxxxxxx
$$REQUEST ID=xxxxxxxx BATCHID=‘xxx...xxx’
Chapter 4 Remote User Commands
84 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
The rules are the same as for requesting all batches for an ID.
Requesting a single batch by ID and batch number:
The batch must be marked R (requestable). The batch must not be marked D (deleted) or N
(nontransmittable).
If you are unable to request a batch that is on the VSAM batch files, try a $$DIRECTORY and
examine the batch status indicators to determine the reason.
$$REQUEST ID=xxxxxxxx BATCHID=#nnnnnnn
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 85
Chapter 5
Error Messages
Usually the data collection and data transmission processing proceeds with no problems. However,
some error messages may occasionally transmit to the remote site.
Sometimes when the remote site is expecting to receive a batch data transmission, it may instead
receive a message that the requested batch does not exist. Use caution in processing received data
to ensure you are not processing an error message from Sterling Connect:Enterprise instead of
actual batch data.
If your SNA remote site is defined as a console device, you may display these messages on the
console screen.
All of the remote site messages are identified and explained in this chapter. They are also included
in the IBM Sterling Connect:Enterprise for z/OS Error Messages and Codes Guide.
Remote User Error Messages (*** ERROR ***)
The following is a list of all of the remote site messages. An identifier, description, and action for
these messages is included.
Message Description Action
*** ERROR *** An unidentifiable error occurred
at the host.
Verify that your input data is correct,
and retry the data transmission at a
later time.
*** ERROR *** BATCH DATA
BLOCKS EXCEED BUFFER
SIZE.
You requested a batch with
record sizes that are larger than
allowed on the
telecommunications line.
Sterling Connect:Enterprise
cannot send the batch to you
using this line.
Try another line which may allow
larger records. If it still does not
work, you cannot access the batch.
Chapter 5 Error Messages
86 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
*** ERROR ***BSC SIGNON
SECURITY VIOLATION.
Your BSC SIGNON attempt has
failed.
Contact host site personnel for
further information.
*** ERROR *** COLLECTION
FAILED. ID VALIDATION
FAILED FOR ID=XXXXXXXX.
The Sterling Connect:Enterprise
system at the host site uses the
batch security option. The ID for
your input data batch is incorrect,
and your batch is rejected.
Correct the ID used if it is spelled
incorrectly, or contact host site
personnel to obtain a valid ID.
*** ERROR *** COLLECTION
FAILED. SECURITY
VIOLATION.
You attempted to send batches
without following security
procedures. These procedures
are unique for your installation
and are activated by a user
security exit.
Contact host site personnel if you
cannot correct the problem.
*** ERROR *** COLLECTION
FAILED. INVALID DATA COULD
NOT BE DEBLOCKED.
You attempted to send batches to
the host, but Sterling
Connect:Enterprise cannot
deblock your data to analyze its
contents. This is generally due to
a data format error or to a very
large data block.
Attempt to correct your input data
and retry the collection. If the
problem persists, contact host
personnel.
*** ERROR *** COLLECTION
FAILED. INVALID FMH SENT.
Your remote site sent a Function
Management Header (FMH) that
is not supported by Sterling
Connect:Enterprise. Sterling
Connect:Enterprise supports only
a 6-character FMH Type 1.
If you cannot correct the problem,
contact host personnel.
*** ERROR *** COLLECTION
FAILED. HOST SITE FILE
PROBLEM.
The host site experienced a
problem with its files while
attempting to process your data
collection. This is usually due to
a file full condition or to a very
large input data block.
If you cannot correct the problem,
contact host personnel.
*** ERROR *** DATA
COLLECTION REJECTED. TRY
AGAIN LATER.
A temporary busy condition is
encountered at the host site.
Retry the data collection at a later
time.
*** ERROR *** DATA
COLLECTION ABORTED. TRY
AGAIN LATER.
An error condition at the host or
on the line caused a data
collection in progress to fail. The
partial data batch is ignored and
must be retransmitted at a later
time. If this message occurs
repeatedly, check the data you
are sending the host.
Verify the data being transmitted if
you receive this error.
Message Description Action
Remote User Error Messages (*** ERROR ***)
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 87
*** ERROR *** ID VALIDATION
FAILED FOR ID=xxxxxxxx.
The Sterling Connect:Enterprise
system at the host site uses the
batch security option. The ID in
your input data is incorrect, and
your communications attempt is
rejected.
Correct the ID used if it is spelled
incorrectly or contact host site
personnel to obtain a valid ID.
*** ERROR *** INVALID
PASSWORD FOR FULL
DIRECTORY REQUEST.
You attempted a $$DIRECTORY
request without supplying a
mailbox ID, and you did not
supply the correct password.
Retype the request with the correct
password, or only attempt a
$$DIRECTORY for a single
mailbox ID.
*** ERROR *** INVALID
DELETE. BATCH NOT FOUND.
You attempted a $$DELETE for a
batch that does not exist.
Correct the $$DELETE to specify
the specific batch for deletion and
retry the transmission.
*** ERROR *** INVALID
DELETE. ENTER ID AND
BATCHID=#nnnnnnn.
You attempted a $$DELETE but
typed the batch identifiers
incorrectly.
Correct the $$DELETE request and
retry the transmission.
*** ERROR *** NO BATCHES
FOR TRANSMISSION.
You have requested a data
transmission with a $$REQUEST
record, but the batch requested
either does not exist or is not
available for a data transmission
to a remote site.
Use a $$DIRECTORY input to
verify the identification of the batch.
Note: Batches flagged T
(transmitted) do not transmit again if
you are requesting all batches for a
mailbox ID.
*** NOTE *** NO BATCHES FOR
TRANSMISSION.
The host site has initiated a data
transmission to your site through
the Auto Connect feature. At the
time of the Auto Connect, no
batches are available for
transmission to your remote site.
This is normally not an error.
None.
*** ERROR *** SECURITY
VIOLATION.
You attempted to access batches
without following security
procedures. These procedures
are unique for your installation
and are activated by a user
security exit.
Contact host site personnel if you
cannot correct the problem by
changing your batch identifiers.
*** ERROR ***SELECTED
BATCH ON DEALLOCATED
FILE.
The selected batch is not
accessible because it is located
on an offline VSAM batch queue.
Contact host site personnel to have
the VSAM batch queue allocated
and retry your request.
Message Description Action
Chapter 5 Error Messages
88 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
*** ERROR *** SNA BATCH
CANNOT BE CONVERTED TO
BSC.
You attempted to request
transmission of a batch which
originated at an SNA remote site.
The batch contains SNA control
characters and cannot be
converted and sent to your BSC
remote site. The batch is
accessible only to host site
personnel or to SNA remote
sites.
Verify batch selection. If correct,
contact host site personnel.
*** ERROR ***SYSTEM I/O
LIMIT REACHED TRY AGAIN
LATER.
Host system activity is too high to
satisfy this request.
Try your request later.
*** ERROR *** TRANSMIT
FAILED. INCORRECT
$$LOGOFF OPERAND.
You typed a $$LOGOFF
command, but failed to supply the
appropriate RMT or APPLID
parameters. The $$LOGOFF is
ignored.
Supply the appropriate $$LOGOFF
format and retype the request.
*** ERROR *** TRANSMIT
FAILED. ID VALIDATION
FAILED FOR ID=XXXXXXXX.
The Sterling Connect:Enterprise
system is installed at the host site
with the batch security option.
The ID you used is incorrect, and
your request is rejected.
Correct the ID used if it is spelled
incorrectly, or contact host site
personnel to obtain a valid ID.
*** ERROR *** TRANSMIT
FAILED. NO BATCHES FOR
TRANSMISSION.
You have requested a data
transmission with the
$$REQUEST function, but the
batch requested either does not
exist or is not available for a data
transmission to a remote site.
Use a $$DIRECTORY to verify the
identification of the batch and to
determine if it is transmittable.
*** NOTE *** TRANSMIT
FAILED. NO BATCHES FOR
TRANSMISSION DURING
Sterling Connect:Enterprise
AUTO CONNECT.
The host site initiated a
connection to your remote site
through the
Sterling Connect:Enterprise Auto
Connect feature. At this time, no
batches are ready for
transmission to your remote site.
This may not be an error. No
batches are sent to you, but you
may now have the opportunity to
send data to the host site.
None.
*** ERROR *** TRANSMIT
FAILED. INVALID PASSWORD
FOR FULL DIRECTORY
REQUEST.
You attempted a $$DIRECTORY
request without supplying an ID,
and did not supply the
appropriate system password.
Retype the $$DIRECTORY with the
appropriate password, or attempt a
$$DIRECTORY for a single
mailbox ID only.
Message Description Action
Remote User Error Messages (*** ERROR ***)
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 89
*** ERROR *** TRANSMIT
FAILED. SECURITY
VIOLATION.
You attempted to access host
data without following security
procedures. These procedures
are unique for your installation
and are activated by a user
security exit.
Contact host site personnel if you
cannot correct the problem.
*** ERROR *** TRANSMIT
FAILED. YOUR REMOTE SENT
NEGATIVE RESPONSE TO
TRANSMIT.
Sterling Connect:Enterprise
attempted a data transmission to
your remote site, but your remote
site rejected it by sending a
negative response. This can
occur for many reasons. For
example, your remote site may
want to send data to the host at
this time and not receive it. Or,
Sterling Connect:Enterprise has
directed the batch to a certain
media that is currently not ready
and available for use.
Sterling Connect:Enterprise
handles the negative response,
and you can retry the failed
transmission later if appropriate.
Ensure the appropriate output
media device is assigned and
ready for use.
If you cannot determine why your
remote site is rejecting a
transmission with a negative
response, contact host site
personnel. Sterling
Connect:Enterprise records the
transaction that failed and the
reason for failure. It may be
possible to recreate the problem
and have host site personnel
explain the negative response.
*** ERROR *** TRANSMIT
FAILED. DATA CANNOT BE
FORMATTED FOR YOUR
REMOTE.
The batch you have requested
cannot be sent to your remote
site due to a data formatting
problem. This can occur when
attempting to transmit BSC
originated data to an SNA remote
site, or vice versa.
If you are unable to correct the
problem, contact host site
personnel.
*** ERROR *** TRANSMIT
FAILED. RECORDS ARE TOO
LARGE FOR YOUR BUFFER
SIZE.
The batch you have requested
cannot be sent to your remote
site. One or more of the batch
data records exceeds the buffer
size for your remote.
Contact remote site personnel if the
problem persists and you require
access to the batch. They may
need to assign a larger buffer to
your remote site.
*** ERROR *** TRANSMIT
FAILED. SELECTED BATCH
REQUIRES A STERLING
CONNECT REMOTE
DEFINITION.
The batch you have requested
requires a Sterling Connect
remote definition to transmit
correctly. Your current remote
definition is not defined as such.
Make the appropriate changes to
support Sterling Connect remotes
and retry the $$REQUEST or
refrain from selecting this batch.
Message Description Action
Chapter 5 Error Messages
90 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 91
Notices
This information was developed for products and services offered in the U.S.A.
IBM may not offer the products, services, or features discussed in this document in other
countries. Consult your local IBM representative for information on the products and
services currently available in your area. Any reference to an IBM product, program, or
service is not intended to state or imply that only that IBM product, program, or service may
be used. Any functionally equivalent product, program, or service that does not infringe any
IBM intellectual property right may be used instead. However, it is the user's responsibility
to evaluate and verify the operation of any non-IBM product, program, or service.
IBM may have patents or pending patent applications covering subject matter described in
this document. The furnishing of this document does not grant you any license to these
patents. You can send license inquiries, in writing, to:
IBM Director of Licensing
IBM Corporation
North Castle Drive
Armonk, NY 10504-1785
U.S.A.
For license inquiries regarding double-byte character set (DBCS) information, contact the
IBM Intellectual
Property Department in your country or send inquiries, in writing, to:
Intellectual Property Licensing
Legal and Intellectual Property Law
IBM Japan Ltd.
1623-14, Shimotsuruma, Yamato-shi
Kanagawa 242-8502 Japan
The following paragraph does not apply to the United Kingdom or any other country
where such provisions are inconsistent with local law: INTERNATIONAL BUSINESS
MACHINES CORPORATION PROVIDES THIS PUBLICATION "AS IS" WITHOUT
WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT
NOT LIMITED TO, THE IMPLIED WARRANTIES OF NON-INFRINGEMENT,
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some states do
Notices
92 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
not allow disclaimer of express or implied warranties in certain transactions, therefore, this
statement may not apply to you.
This information could include technical inaccuracies or typographical errors. Changes are
periodically made to the information herein; these changes will be incorporated in new
editions of the publication. IBM may make improvements and/or changes in the product(s)
and/or the program(s) described in this publication at any time without notice.
Any references in this information to non-IBM Web sites are provided for convenience
only and do not in any manner serve as an endorsement of those Web sites. The materials
at those Web sites are not part of the materials for this IBM product and use of those Web
sites is at your own risk.
IBM may use or distribute any of the information you supply in any way it believes
appropriate without incurring any obligation to you.
Licensees of this program who wish to have information about it for the purpose of
enabling: (i) the exchange of information between independently created programs and
other programs (including this one) and (ii) the mutual use of the information which has
been exchanged, should contact:
IBM Corporation
J46A/G4
555 Bailey Avenue
San Jose, CA__95141-1003
U.S.A.
Such information may be available, subject to appropriate terms and conditions, including
in some cases, payment of a fee.
The licensed program described in this document and all licensed material available for it
are provided by IBM under terms of the IBM Customer Agreement, IBM International
Program License Agreement or any equivalent agreement between us.
Any performance data contained herein was determined in a controlled environment.
Therefore, the results obtained in other operating environments may vary significantly.
Some measurements may have been made on development-level systems and there is no
guarantee that these measurements will be the same on generally available systems.
Furthermore, some measurements may have been estimated through extrapolation. Actual
results may vary. Users of this document should verify the applicable data for their specific
environment.
Information concerning non-IBM products was obtained from the suppliers of those
products, their published announcements or other publicly available sources. IBM has not
tested those products and cannot confirm the accuracy of performance, compatibility or any
other claims related to non-IBM products. Questions on the capabilities of non-IBM
products should be addressed to the suppliers of those products.
All statements regarding IBM's future direction or intent are subject to change or
withdrawal without notice, and represent goals and objectives only.
Notices
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 93
This information is for planning purposes only. The information herein is subject to change
before the products described become available. This information contains examples of
data and reports used in daily business operations. To illustrate them as completely as
possible, the examples include the names of individuals, companies, brands, and products.
All of these names are ficticious and any similarity to the names and addresses used by an
actual business enterprise is entirely coincidental.
COPYRIGHT LICENSE:
This information contains sample application programs in source language, which illustrate
programming techniques on various operating platforms. You may copy, modify, and
distribute these sample programs in any form without payment to IBM, for the purposes of
developing, using, marketing or distributing application programs conforming to the
application programming interface for the operating platform for which the sample
programs are written. These examples have not been thoroughly tested under all conditions.
IBM, therefore, cannot guarantee or imply reliability, serviceability, or function of these
programs. The sample programs are provided "AS IS", without warranty of any kind. IBM
shall not be liable for any damages arising out of your use of the sample programs.
Each copy or any portion of these sample programs or any derivative work, must include a
copyright notice as follows:
© IBM 2011. Portions of this code are derived from IBM Corp. Sample Programs.
© Copyright IBM Corp. 2011.
If you are viewing this information softcopy, the photographs and color illustrations may
not appear.
Trademarks
The following terms are trademarks of the International Business Machines Corporation in
the United States, other countries, or both: http://www.ibm.com/legal/copytrade.shtml.
Adobe, the Adobe logo, PostScript, and the PostScript logo are either registered trademarks
or trademarks of Adobe Systems Incorporated in the United States, and/or other countries.
IT Infrastructure Library is a registered trademark of the Central Computer and
Telecommunications Agency which is now part of the Office of Government Commerce.
Intel, Intel logo, Intel Inside, Intel Inside logo, Intel Centrino, Intel Centrino logo, Celeron,
Intel Xeon, Intel SpeedStep, Itanium, and Pentium are trademarks or registered trademarks
of Intel Corporation or its subsidiaries in the United States and other countries.
Linux is a registered trademark of Linus Torvalds in the United States, other countries, or
both.
Microsoft, Windows, Windows NT, and the Windows logo are trademarks of Microsoft
Corporation in the United States, other countries, or both.
ITIL is a registered trademark, and a registered community trademark of the Office of
Government Commerce, and is registered in the U.S. Patent and Trademark Office.
Notices
94 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
UNIX is a registered trademark of The Open Group in the United States and other
countries.
Java and all Java-based trademarks and logos are trademarks or registered trademarks of
Oracle and/or its affiliates.
Cell Broadband Engine is a trademark of Sony Computer Entertainment, Inc. in the United
States, other countries, or both and is used under license therefrom.
Linear Tape-Open, LTO, the LTO Logo, Ultrium and the Ultrium Logo are trademarks of
HP, IBM Corp. and Quantum in the U.S. and other countries.
Connect Control Center®, Connect:Direct®, Connect:Enterprise, Gentran®,
Gentran:Basic®, Gentran:Control®, Gentran:Director®, Gentran:Plus®,
Gentran:Realtime®, Gentran:Server®, Gentran:Viewpoint®, Sterling Commerce™,
Sterling Information Broker®, and Sterling Integrator® are trademarks or registered
trademarks of Sterling Commerce, Inc., an IBM Company.
Other company, product, and service names may be trademarks or service marks of others.
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 95
Index
Symbols
$$ADD
example 66
header record 66
$$ADD command
defaults 76
example 52
header record 52
initiating 76
multiple batches 77
operands 77
syntax
BSC 77
FTP 49
SNA 77
$$DELETE
example 66
$$DELETE command
definition 73
example 52
operands 78
syntax
BSC 78
SNA 78
$$DIRECTORY command
definition 73
operands 79
output 79
syntax
BSC 79
SNA 79
$$LOGOFF command
definition 73
SNA 82
$$REQUEST
example 66
$$REQUEST command
definition 73
example 52
operands 83
syntax
BSC 83
SNA 83
using 83
$TURNLINE$ 70
A
ADD
utility
VSAM status flags 30
auto connect
configuration 51, 66
definition 51, 66
B
blocked data records 69
BSC
$TURNLINE$ 70
blank compression 68
blank truncation 69
blocked data records 69
options 68
record separator override 69
RJE
communication 65
SIGNON
implementation 68
temporary text delay 70
transparency 69
WAIT Acknowledgement (WACK) 70
C
CCC, see Clear Control Channel
Clear Control Channel 14
command conventions, FTP 16
Commands
$$ADD
Index
96 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
defaults 76
initiating 76
multiple batches 77
operands 77
syntax
BSC 77
FTP 49
SNA 77
$$DELETE
operands 78
syntax
BSC 78
SNA 78
$$DIRECTORY
operands 79
output 79
syntax
BSC 79
SNA 79
$$LOGOFF
SNA 82
$$REQUEST
operands 83
SNA 82
syntax
BSC 83
SNA 83
using 83
logoff 82
remote site 73
standard FTP syntax
del 37
dir 38
get 39
mput 42, 43
pwd 44
recv 39
submitting 73
configuration 51, 66
console display
implementing 55
messages 55
procedures 55
D
data compression 55
Data streams 57, 70
Definition
$$DELETE 73
$$DIRECTORY 73
$$LOGOFF 73
$$REQUEST 73
BSC
$TURNLINE$ 70
record separator override 69
temporary text delay 70
WAIT Acknowledgement (WACK) 70
del
standard FTP syntax
instructions 37
device media
procedures 55
dir
standard FTP syntax
instructions 38
disconnect interval
definition 57
E
EBCDIC 57
EXTRACT
utility
VSAM status flags 30
F
firewall navigation 13
FMH
batch separation 56
insertion 56
procedures 56
terminal control 56
free-form BSC SIGNON 68
FTP
data structure 10
data type 8
delimiting records with $$ commands 47
processing $$ADD commands 47
scanning for $$ADD commands 47
transfer mode 11
user batch ID syntax and formats 11
FTP Commands 15
standard FTP syntax
del 37
dir 38
Index
IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide 97
get 39
mput 42, 43
pwd 44
recv 39
FTP SITE command
parameters 19
G
get
standard FTP syntax
examples 40
format 40
instructions 39
H
host
initiated communication
definition 51
site 51
host initiated communication
definition 66
host site 66
I
IRS (inter-record separator) 69
L
log on, FTP 14
Logoff
command 82
SNA 82
syntax 82
Logon
requirements 81
SNA 81
M
media
device support 54
MLU, see Multiple Logical Unit
mput
instructions 42, 43
Multiple Logical Unit (MLU) 54
P
pwd
instructions 44
R
Record separator override
BSC 69
record separator override
blocked data records 69
recv
standard FTP syntax
examples 40
instructions 39
Remote site
commands 73
Requirements
BSC
$TURNLINE$ 70
logon 81
RJE communication 65
RJE SIGNON 66
S
SNA
logoff 82
logon
example of 81
syntax 81
procedures 56
terminal options 54
transparency 56
starting and stopping sessions
procedures 51, 65
T
Terminal options
SNA 54
transparency
SNA 56
TTD (temporary text delay) 70
Index
98 IBM Sterling Connect:Enterprise for z/OS Remote User’s Guide
V
VSAM batch
status flags
list of 30
VTAM Log Mode Table 55
W
WAIT acknowledgement (WACK) 70

Navigation menu
