5-45

NATIONAL WIRE & CABLE custom cable manufacturing & molding • www.nationalwire.com Order Desk 323-225-5611

National Wire & Cable Corporation manufactures a complete line of DUAL-RATED

multiconductor NEC TRAY CABLE Type CL2, for signal, instrumentation and control

uses. Also UL rated for use as 300 Volt Appliance Wiring Material (AWM). These are

available as cables singles or pairs, with optional overall shield of aluminum-Mylar foil

with drain wire.

Cabled conductors use stranded tinned copper wire with 0.010” wall of tough extruded

poly-vinyl-chloride (PVC) insulation, rated for 300 Volt use under U.L. Style 2464.

All wires are color coded using 10 standard solid colors plus white with stripes. Cables

singles are color coded the same as our NQ and NX cable families per MIL-STD-681.

Cabled pairs are color coded the same as our NQP and NXP cable families. View View

Color Table in the National Wire Cable Designers Guide, page 7-13.

Conductors are helically cabled and laid for optimum exiblility, with a Mylar tape

barrier wrap (or Mylar + Foil) applied between cabled wire bundle and outer jacket.

Shielded cables have an overall Aluminum-Mylar foil shielding tape helically wrapped

over cable and a tinned uninsulated drain wire for shield connection. (Use FSJ part

Number sufx.) For optional composite tinned copper CFI braid(s) + foil shielding,

consult factory.

Outer jacket is a special highly exible abrasion-resistant gray polyvinylchloride (PVC)

thermoplastic. DUAL-RATED jacket compound meets the requirements of both U.L./

AWM Style 2464 and U.L. 13 Type CL2 TRAY CABLE. Jacket is surface printed with

both UL AWM 2464 and U.L. 13 Type CL2 TRAY CABLE identiers. Jacket wall

thickness is .032” nom.

Finished cables comply with applicable U.L. tests for N.E.C. Type CL2 TRAY CABLE

Vertical Tray Flame Spread. All materials are ame-spread retardant and fungus

resistant. The products are DUAL-RATED for AWM use as U.L. Style 2464 300 Volt,

80°C, OR for U.L. 13 Type CL2 TRAY CABLE 105°C use.

Standard Putups: 500 ft. and 1000 ft. No-deposit reels. For shorter quantities or

specic lengths consult factory.

CABLED SINGLE CONDUCTORS

Standard CL2 Cables

• NEC 725 Tray Cables

• Cabled Singles (NL Series)

UNSHIELDED

24, 22 AWG

Part No. No.

Cond

Cond.

AWG

Nom.

O.D.

Weight

LB/K ft.

NL-224J 2 24 .156 11

NL-324J 3 24 .163 14

NL-424J 4 24 .174 17

NL-524J 5 24 .187 19

NL-624J 6 24 .200 22

NL-724J 7 24 .200 24

NL-824J 8 24 .231 28

NL-924J 9 24 .244 31

NL-1024J 10 24 .244 33

NL-1224J 12 24 .251 37

NL-1524J 15 24 .275 45

NL-1924J 19 24 .288 54

NL-2724J 27 24 .339 73

NL-3724J 37 24 .376 96

NL-4824J 48 24 .424 121

NL-6024J 60 24 .464 148

NL-222J 2 22 .168 14

NL-322J 3 22 .176 17

NL-422J 4 22 .188 21

NL-522J 5 22 .203 25

NL-622J 6 22 .218 29

NL-722J 7 22 .218 32

NL-822J 8 22 .253 37

NL-922J 9 22 .268 40

NL-1022J 10 22 .268 43

NL-1222J 12 22 .276 50

NL-1522J 15 22 .303 60

NL-1922J 19 22 .318 73

NL-2722J 27 22 .376 100

NL-3722J 37 22 .418 131

NL-4822J 48 22 .473 167

NL-6022J 60 22 .520 207

OVERALL FOIL SHIELD WITH DRAIN

24, 22 AWG

Part No. No.

Cond

Cond.

AWG

Nom.

O.D

Weight

LB/K ft.

NL-224FSJ 2 24 .158 13

NL-324FSJ 3 24 .165 15

NL-424FSJ 4 24 .176 18

NL-524FSJ 5 24 .189 21

NL-624FSJ 6 24 .202 24

NL-724FSJ 7 24 .202 26

NL-824FSJ 8 24 .233 30

NL-924FSJ 9 24 .246 32

NL-1024FSJ 10 24 .246 34

NL-1224FSJ 12 24 .253 39

NL-1524FSJ 15 24 .277 46

NL-1924FSJ 19 24 .290 55

NL-2724FSJ 27 24 .341 75

NL-3724FSJ 37 24 .378 97

NL-4824FSJ 48 24 .427 122

NL-6024FSJ 60 24 .466 149

NL-222FSJ 2 22 .170 16

NL-322FSJ 3 22 .178 20

NL-422FSJ 4 22 .190 23

NL-522FSJ 5 22 .205 27

NL-622FSJ 6 22 .220 31

NL-722FSJ 7 22 .220 34

NL-822FSJ 8 22 .255 39

NL-922FSJ 9 22 .270 43

NL-1022FSJ 10 22 .270 46

NL-1222FSJ 12 22 .278 52

NL-1522FSJ 15 22 .305 62

NL-1922FSJ 19 22 .320 75

NL-2722FSJ 27 22 .378 102

NL-3722FSJ 37 22 .420 134

NL-4822FSJ 48 22 .475 169

NL-6022FSJ 60 22 .528 207

OVERALL BRAIDED SHIELD

24, 22 AWG

Part No. No.

Cond

Cond.

AWG

Nom.

O.D

Weight

LB/K ft.

NL-224SJ 2 24 .176 19

NL-324SJ 3 24 .183 22

NL-424SJ 4 24 .194 25

NL-524SJ 5 24 .207 29

NL-624SJ 6 24 .220 33

NL-724SJ 7 24 .220 35

NL-824SJ 8 24 .251 41

NL-924SJ 9 24 .264 44

NL-1024SJ 10 24 .264 46

NL-1224SJ 12 24 .271 51

NL-1524SJ 15 24 .295 61

NL-1924SJ 19 24 .308 70

NL-2724SJ 27 24 .359 93

NL-3724SJ 37 24 .401 127

NL-4824SJ 48 24 .450 157

NL-6024SJ 60 24 .489 187

NL-222SJ 2 22 .188 22

NL-322SJ 3 22 .196 26

NL-422SJ 4 22 .208 31

NL-522SJ 5 22 .223 35

NL-622SJ 6 22 .238 40

NL-722SJ 7 22 .238 43

NL-822SJ 8 22 .273 51

NL-922SJ 9 22 .288 56

NL-1022SJ 10 22 .288 58

NL-1222SJ 12 22 .296 65

NL-1522SJ 15 22 .323 78

NL-1922SJ 19 22 .338 91

NL-2722SJ 27 22 .401 131

NL-3722SJ 37 22 .443 167

NL-4822SJ 48 22 .498 207

NL-6022SJ 60 22 .543 249

TECHNICAL DATA (ALL CABLES)

Rated Working

Voltage:

300 Volts for AWM uses.

Rated

Temperature:

DUAL-RATED:+105°C or +80°C dependent on AGENCY intended use.

Insulation

Breakdown

Voltage:

Greater than 3400 Volts AC RMS as 60 Hz.

Capacitance: Nominal capacitance from a wire to all else in a cable ranges from 25 to

45 PF/FT at 1 kHz, depending on AWG and position.

Insulation

Leakage:

100 megohms/1000 ft. min. at 500 VDC from a conductor to all else in a

cable, at 25°C,

U.L. Agency

Voltage &

Temperature

Ratings:

UL rated: +80°C AWM, 300 VOLT per UL Style 2464. UL rated +105°C

CL2 TRAY CABLE per UL 13, NEC Type CL2.

Bending

Characteristics:

All cables are suitable for exing to a circle diameter of 8 cable diameters

from +105°C to -10°C. Recommended ex diameter should be greater

than 20 cable diameters for exing at -20°C.

Characteristic

Impedance:

RF Impedance of twisted pairs or adjacent singles is: 87 ohms in AWG

24; 80 ohms in AWG 22. Suitable for digital signals.

RoHS COMPLIANT PRODUCTS: all RoHS products have the letter “R” written into the second position

of the Part No.

UNSHIELDED

24, 22 AWG

Part No. No.

Cond

Cond.

AWG

Nom.

O.D.

Weight

LB/K ft.

NRL-224J 2 24 .156 11

NRL-324J 3 24 .163 14

NRL-424J 4 24 .174 17

NRL-524J 5 24 .187 19

NRL-624J 6 24 .200 22

NRL-724J 7 24 .200 24

NRL-824J 8 24 .231 28

NRL-924J 9 24 .244 31

NRL-1024J 10 24 .244 33

N RL-1224J 12 24 .251 37

NRL-1524J 15 24 .275 45

NRL-1924J 19 24 .288 54

NRL-2724J 27 24 .339 73

NRL-3724J 37 24 .376 96

NRL-4824J 48 24 .424 121

NRL-6024J 60 24 .464 148

NRL-222J 2 22 .168 14

NRL-322J 3 22 .176 17

NRL-422J 4 22 .188 21

NRL-522J 5 22 .203 25

NRL-622J 6 22 .218 29

NRL-722J 7 22 .218 32

NRL-822J 8 22 .253 37

NRL-922J 9 22 .268 40

NRL-1022J 10 22 .268 43

NRL-1222J 12 22 .276 50

NRL-1522J 15 22 .303 60

NRL-1922J 19 22 .318 73

NRL-2722J 27 22 .376 100

NRL-3722J 37 22 .418 131

NRL-4822J 48 22 .473 167

NRL-6022J 60 22 .520 207

OVERALL FOIL SHIELD WITH DRAIN

24, 22 AWG

Part No. No.

Cond

Cond.

AWG

Nom.

O.D

Weight

LB/K ft.

NRL-224FSJ 2 24 .158 13

NRL-324FSJ 3 24 .165 15

NRL-424FSJ 4 24 .176 18

NRL-524FSJ 5 24 .189 21

NRL-624FSJ 6 24 .202 24

NRL-724FSJ 7 24 .202 26

NRL-824FSJ 8 24 .233 30

NRL-924FSJ 9 24 .246 32

NRL-1024FSJ 10 24 .246 34

NRL-1224FSJ 12 24 .253 39

NRL-1524FSJ 15 24 .277 46

NRL-1924FSJ 19 24 .290 55

NRL-2724FSJ 27 24 .341 75

NRL-3724FSJ 37 24 .378 97

NRL-4824FSJ 48 24 .427 122

NRL-6024FSJ 60 24 .466 149

NRL-222FSJ 2 22 .170 16

NRL-322FSJ 3 22 .178 20

NRL-422FSJ 4 22 .190 23

NRL-522FSJ 5 22 .205 27

NRL-622FSJ 6 22 .220 31

NRL-722FSJ 7 22 .220 34

NRL-822FSJ 8 22 .255 39

NRL-922FSJ 9 22 .270 43

NRL-1022FSJ 10 22 .270 46

NRL-1222FSJ 12 22 .278 52

NRL-1522FSJ 15 22 .305 62

NRL-1922FSJ 19 22 .320 75

NRL-2722FSJ 27 22 .378 102

NRL-3722FSJ 37 22 .420 134

NRL-4822FSJ 48 22 .475 169

NRL-6022FSJ 60 22 .528 207

OVERALL BRAIDED SHIELD

24, 22 AWG

Part No. No.

Cond

Cond.

AWG

Nom.

O.D

Weight

LB/K ft.

NRL-224SJ 2 24 .176 19

NRL-324SJ 3 24 .183 22

NRL-424SJ 4 24 .194 25

NRL-524SJ 5 24 .207 29

NRL-624SJ 6 24 .220 33

NRL-724SJ 7 24 .220 35

NRL-824SJ 8 24 .251 41

NRL-924SJ 9 24 .264 44

NRL-1024SJ 10 24 .264 46

NRL-1224SJ 12 24 .271 51

NRL-1524SJ 15 24 .295 61

NRL-1924SJ 19 24 .308 70

NRL-2724SJ 27 24 .359 93

NRL-3724SJ 37 24 .401 127

NRL-4824SJ 48 24 .450 157

NRL-6024SJ 60 24 .489 187

NRL-222SJ 2 22 .188 22

NRL-322SJ 3 22 .196 26

NRL-422SJ 4 22 .208 31

NRL-522SJ 5 22 .223 35

NRL-622SJ 6 22 .238 40

NRL-722SJ 7 22 .238 43

NRL-822SJ 8 22 .273 51

NRL-922SJ 9 22 .288 56

NRL-1022SJ 10 22 .288 58

NRL-1222SJ 12 22 .296 65

NRL-1522SJ 15 22 .323 78

NRL-1922SJ 19 22 .338 91

NRL-2722SJ 27 22 .401 131

NRL-3722SJ 37 22 .443 167

NRL-4822SJ 48 22 .498 207

NRL-6022SJ 60 22 .543 249

5-46 NATIONAL WIRE & CABLE custom cable manufacturing & molding • www.nationalwire.com Order Desk 323-225-5611

CABLED SINGLE CONDUCTORS - CL2, NL

5-47

NATIONAL WIRE & CABLE custom cable manufacturing & molding • www.nationalwire.com Order Desk 323-225-5611

CABLED SINGLE CONDUCTORS

Standard CL2 Cables

• NEC 725 Tray Cables

• Cabled Singles (NL Series)

UNSHIELDED

20, 18 AWG

Part No. No.

Cond

Cond

AWG.

Nom.

O.D.

Weight

LB/K ft

NL-220J 2 20 .184 18

NL-320J 3 20 .193 24

NL-420J 4 20 .207 29

NL-520J 5 20 .225 35

NL-620J 6 20 .242 41

NL-720J 7 20 .242 46

NL-820J 8 20 .283 53

NL-920J 9 20 .300 58

NL-1020J 10 20 .300 63

NL-1220J 12 20 .309 73

NL-1520J 15 20 .341 89

NL-1920J 19 20 .358 109

NL-2720J 27 20 .425 151

NL-3720J 37 20 .474 201

NL-218J 2 18 .204 24

NL-318J 3 18 .215 32

NL-418J 4 18 .231 40

NL-518J 5 18 .252 48

NL-618J 6 18 .272 56

NL-718J 7 18 .272 63

NL-818J 8 18 .320 73

NL-918J 9 18 .340 81

NL-1018J 10 18 .340 88

NL-1218J 12 18 .351 102

NL-1518J 15 18 .388 126

NL-1918J 19 18 .408 155

NL-2718J 27 18 .487 215

OVERALL BRAIDED SHIELDED

20, 18 AWG

Part No. No.

Cond

Cond

AWG.

Nom.

O.D.

Weight

LB/K ft

NL-220SJ 2 20 .204 28

NL-320SJ 3 20 .213 34

NL-420SJ 4 20 .227 40

NL-520SJ 5 20 .245 47

NL-620SJ 6 20 .262 54

NL-720SJ 7 20 .262 59

NL-820SJ 8 20 .303 69

NL-920SJ 9 20 .320 76

NL-1020SJ 10 20 .320 80

NL-1220SJ 12 20 .329 91

NL-1520SJ 15 20 .361 109

NL-1920SJ 19 20 .378 130

NL-2720SJ 27 20 .450 187

NL-3720SJ 37 20 .499 242

NL-218SJ 2 18 .224 35

NL-318SJ 3 18 .235 43

NL-418SJ 4 18 .251 52

NL-518SJ 5 18 .272 62

NL-618SJ 6 18 .292 71

NL-718SJ 7 18 .293 78

NL-818SJ 8 18 .340 91

NL-918SJ 9 18 .360 101

NL-1018SJ 10 18 .360 108

NL-1218SJ 12 18 .371 123

NL-1518SJ 15 18 .413 158

NL-1918SJ 19 18 .433 189

NL-2718SJ 27 18 .512 257

OVERALL FOIL SHIELD WITH DRAIN

20, 18 AWG

Part No. No.

Cond

Cond

AWG.

Nom.

O.D.

Weight

LB/K ft

NL-220FSJ 2 20 .186 22

NL-320FSJ 3 20 .195 28

NL-420FSJ 4 20 .209 33

NL-520FSJ 5 20 .227 39

NL-620FSJ 6 20 .244 45

NL-720FSJ 7 20 .244 49

NL-820FSJ 8 20 .285 56

NL-920FSJ 9 20 .302 62

NL-1020FSJ 10 20 .300 63

NL-1220FSJ 12 20 .311 77

NL-1520FSJ 15 20 .343 90

NL-1920FSJ 19 20 .360 113

NL-2720FSJ 27 20 .427 155

NL-3720FSJ 37 20 .476 205

NL-218FSJ 2 18 .206 20

NL-318FSJ 3 18 .217 38

NL-418FSJ 4 18 .233 46

NL-518FSJ 5 18 .254 54

NL-618FSJ 6 18 .274 62

NL-718FSJ 7 18 .274 69

NL-818FSJ 8 18 .322 79

NL-918FSJ 9 18 .342 87

NL-1018FSJ 10 18 .342 94

NL-1218FSJ 12 18 .353 108

NL-1518FSJ 15 18 .390 131

NL-1918FSJ 19 18 .410 180

NL-2718FSJ 27 18 .489 221

UNSHIELDED

20, 18 AWG

Part No. No.

Cond

Cond

AWG.

Nom.

O.D.

Weight

LB/K ft

NRL-220J 2 20 .184 18

NRL-320J 3 20 .193 24

NRL-420J 4 20 .207 29

NRL-520J 5 20 .225 35

NRL-620J 6 20 .242 41

NRL-720J 7 20 .242 46

NRL-820J 8 20 .283 53

NRL-920J 9 20 .300 58

NRL-1020J 10 20 .300 63

NRL-1220J 12 20 .309 73

NRL-1520J 15 20 .341 89

NRL-1920J 19 20 .358 109

NRL-2720J 27 20 .425 151

NRL-3720J 37 20 .474 201

NRL-218J 2 18 .204 24

NRL-318J 3 18 .215 32

NRL-418J 4 18 .231 40

NRL-518J 5 18 .252 48

NRL-618J 6 18 .272 56

NRL-718J 7 18 .272 63

NRL-818J 8 18 .320 73

NRL-918J 9 18 .340 81

NRL-1018J 10 18 .340 88

NRL-1218J 12 18 .351 102

NRL-1518J 15 18 .388 126

NRL-1918J 19 18 .408 155

NRL-2718J 27 18 .487 215

OVERALL BRAIDED SHIELDED

20, 18 AWG

Part No. No.

Cond

Cond

AWG.

Nom.

O.D.

Weight

LB/K ft

NRL-220SJ 2 20 .204 28

NRL-320SJ 3 20 .213 34

NRL-420SJ 4 20 .227 40

NRL-520SJ 5 20 .245 47

NRL-620SJ 6 20 .262 54

NRL-720SJ 7 20 .262 59

NRL-820SJ 8 20 .303 69

NRL-920SJ 9 20 .320 76

NRL-1020SJ 10 20 .320 80

NRL-1220SJ 12 20 .329 91

NRL-1520SJ 15 20 .361 109

NRL-1920SJ 19 20 .378 130

NRL-2720SJ 27 20 .450 187

NRL-3720SJ 37 20 .499 242

NRL-218SJ 2 18 .224 35

NRL-318SJ 3 18 .235 43

NRL-418SJ 4 18 .251 52

NRL-518SJ 5 18 .272 62

NRL-618SJ 6 18 .292 71

NRL-718SJ 7 18 .293 78

NRL-818SJ 8 18 .340 91

NRL-918SJ 9 18 .360 101

NRL-1018SJ 10 18 .360 108

NRL-1218SJ 12 18 .371 123

NRL-1518SJ 15 18 .413 158

NRL-1918SJ 19 18 .433 189

NRL-2718SJ 27 18 .512 257

OVERALL FOIL SHIELD WITH DRAIN

20, 18 AWG

Part No. No.

Cond

Cond

AWG.

Nom.

O.D.

Weight

LB/K ft

NRL-220FSJ 2 20 .186 22

NRL-320FSJ 3 20 .195 28

NRL-420FSJ 4 20 .209 33

NRL-520FSJ 5 20 .227 39

NRL-620FSJ 6 20 .244 45

NRL-720FSJ 7 20 .244 49

NRL-820FSJ 8 20 .285 .56

NRL-920FSJ 9 20 .302 62

NRL-1020FSJ 10 20 .300 63

NRL-1220FSJ 12 20 .311 77

NRL-1520FSJ 15 20 .343 90

NRL-1920FSJ 19 20 .360 113

NRL-2720FSJ 27 20 .427 155

NRL-3720FSJ 37 20 .476 205

NRL-218FSJ 2 18 .206 20

NRL-318FSJ 3 18 .217 38

NRL-418FSJ 4 18 .233 46

NRL-518FSJ 5 18 .254 54

NRL-618FSJ 6 18 .274 62

NRL-718FSJ 7 18 .274 69

NRL-818FSJ 8 18 .322 79

NRL-918FSJ 9 18 .342 87

NRL-1018FSJ 10 18 .342 94

NRL-1218FSJ 12 18 .353 108

NRL-1518FSJ 15 18 .390 131

NRL-1918FSJ 19 18 .410 180

NR L-2718FSJ 27 18 .489 221

RoHS COMPLIANT PRODUCTS: all RoHS products have the letter “R” written into the second position

of the Part No.

5-48 NATIONAL WIRE & CABLE custom cable manufacturing & molding • www.nationalwire.com Order Desk 323-225-5611

CABLED SINGLE CONDUCTORS - CL2, NL
