Command Line Interface Reference Guide R77 CP CLI

User Manual:

Open the PDF directly: View PDF PDF.
Page Count: 145 [warning: Documents this large are best viewed by clicking the View PDF Link!]

14 September 2016
Reference Guide
Command Line Interface
R77
Classification: [Protected]
© 2016 Check Point Software Technologies Ltd.
All rights reserved. This product and related documentation are protected by copyright and
distributed under licensing restricting their use, copying, distribution, and decompilation. No part
of this product or related documentation may be reproduced in any form or by any means without
prior written authorization of Check Point. While every precaution has been taken in the
preparation of this book, Check Point assumes no responsibility for errors or omissions. This
publication and features described herein are subject to change without notice.
RESTRICTED RIGHTS LEGEND:
Use, duplication, or disclosure by the government is subject to restrictions as set forth in
subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at DFARS
252.227-7013 and FAR 52.227-19.
TRADEMARKS:
Refer to the Copyright page http://www.checkpoint.com/copyright.html for a list of our
trademarks.
Refer to the Third Party copyright notices http://www.checkpoint.com/3rd_party_copyright.html
for a list of relevant copyrights and third-party licenses.
Important Information
Latest Software
We recommend that you install the most recent software release to stay up-to-date with the latest
functional improvements, stability fixes, security enhancements and protection against new and
evolving attacks.
Latest Documentation
The latest version of this document is at:
http://supportcontent.checkpoint.com/documentation_download?ID=24833
To learn more, visit the Check Point Support Center http://supportcenter.checkpoint.com.
For more about this release, see the R77 home page
http://supportcontent.checkpoint.com/solutions?id=sk104859.
Revision History
Date
Description
13 September 2016 Updated sample script for Adding a Rule (on page 17)
10 March 2016 Updated fwm getpcap (on page 94)
25 February 2016 Updated fw monitor Filters (on page 80)
6 August 2014 Updated fwm dbload (on page 93) and cplic check
(on
page 31)
10 June 2014 Corrected example for the cp_merge list_policy (on page
42) command
6 June 2014 Cover changed to be relevant for all R77 versions
9 December 2013 • Added Running CLI Commands in Automation Scripts (on
page 10)
• General updates
27 August 2013 First release of this document
Feedback
Check Point is engaged in a continuous effort to improve its documentation.
Please help us by sending your comments
mailto:cp_techpub_feedback@checkpoint.com?subject=Feedback on Command Line Interface R77
Reference Guide.
Contents
Important Information ................................................................................................... 3
CLI Commands for Software Blades ............................................................................. 9
CLI Commands in Other Guides ................................................................................ 9
Running CLI Commands in Automation Scripts .......................................................... 10
Introduction to Automation Scripts ......................................................................... 10
Creating a Domain Management Server ........................................................................ 10
Working with dbedit ................................................................................................ 11
Introduction to dbedit .................................................................................................... 11
Using Automation Scripts .............................................................................................. 12
Create or Modify Policy Objects (Hosts, Networks) ........................................................ 13
Changing a Rule Base .................................................................................................... 17
Pushing the Security Policy to Security Gateways ......................................................... 19
Error Codes in dbedit..................................................................................................... 20
Using XML to Export Settings for a Domain Management Server ........................... 20
Security Management Server and Firewall Commands .............................................. 21
comp_init_policy ..................................................................................................... 22
cp_admin_convert .................................................................................................. 22
cpca_client .............................................................................................................. 22
cpca_client create_cert ................................................................................................. 22
cpca_client revoke_cert ................................................................................................ 23
cpca_client lscert .......................................................................................................... 23
cpca_client init_certs .................................................................................................... 24
cpca_client set_mgmt_tool ........................................................................................... 24
cpca_client set_sign_hash ............................................................................................ 25
cpca_client search......................................................................................................... 25
cpca_client get_crldp .................................................................................................... 26
cpca_client get_pubkey ................................................................................................. 26
cpca_client double_sign ................................................................................................ 26
cp_conf .................................................................................................................... 26
cp_conf sic ..................................................................................................................... 27
cp_conf admin ............................................................................................................... 27
cp_conf ca ..................................................................................................................... 27
cp_conf finger ............................................................................................................... 28
cp_conf lic ..................................................................................................................... 28
cp_conf client ................................................................................................................ 28
cp_conf ha ..................................................................................................................... 29
cp_conf snmp ................................................................................................................ 29
cp_conf auto .................................................................................................................. 29
cp_conf sxl .................................................................................................................... 30
cpconfig ................................................................................................................... 30
cpinfo ...................................................................................................................... 30
cplic ......................................................................................................................... 31
cplic check ..................................................................................................................... 31
cplic db_add .................................................................................................................. 32
cplic db_print ................................................................................................................ 33
cplic db_rm ................................................................................................................... 33
cplic del ......................................................................................................................... 34
cplic del <object name> ................................................................................................. 34
cplic get ......................................................................................................................... 34
cplic put ......................................................................................................................... 35
cplic put <object name> ... ............................................................................................. 36
cplic print ...................................................................................................................... 37
cplic upgrade ................................................................................................................. 38
cp_merge ................................................................................................................ 39
cp_merge delete_policy ................................................................................................ 39
cp_merge export_policy ................................................................................................ 40
cp_merge import_policy and cp_merge restore_policy ................................................ 41
cp_merge list_policy ..................................................................................................... 42
cppkg ....................................................................................................................... 42
cppkg add ...................................................................................................................... 42
cppkg delete .................................................................................................................. 43
cppkg get ....................................................................................................................... 44
cppkg getroot ................................................................................................................ 44
cppkg print .................................................................................................................... 44
cppkg setroot................................................................................................................. 44
cpridrestart ............................................................................................................. 45
cpridstart ................................................................................................................ 45
cpridstop ................................................................................................................. 45
cprinstall ................................................................................................................. 46
cprinstall boot ............................................................................................................... 46
cprinstall cpstart ........................................................................................................... 46
cprinstall cpstop ............................................................................................................ 46
cprinstall get ................................................................................................................. 47
cprinstall install ............................................................................................................ 47
cprinstall uninstall ........................................................................................................ 48
cprinstall verify ............................................................................................................. 49
cprinstall snapshot ........................................................................................................ 50
cprinstall show .............................................................................................................. 50
cprinstall revert ............................................................................................................ 50
cprinstall transfer ......................................................................................................... 51
cpstart ..................................................................................................................... 51
cpstat ...................................................................................................................... 51
cpstop ...................................................................................................................... 53
cpwd_admin ............................................................................................................ 54
cpwd_admin start .......................................................................................................... 54
cpwd_admin stop........................................................................................................... 54
cpwd_admin list ............................................................................................................ 55
cpwd_admin exist .......................................................................................................... 55
cpwd_admin kill ............................................................................................................ 55
cpwd_admin config ........................................................................................................ 55
disconnect_client .................................................................................................... 57
dbedit ...................................................................................................................... 57
dbver ....................................................................................................................... 59
dbver create .................................................................................................................. 59
dbver export .................................................................................................................. 60
dbver import .................................................................................................................. 60
dbver print ..................................................................................................................... 60
dbver print_all ............................................................................................................... 60
dynamic_objects ..................................................................................................... 61
fw ............................................................................................................................ 61
fw -i ............................................................................................................................... 61
fw ctl .............................................................................................................................. 62
fw ctl debug ................................................................................................................... 63
fw ctl affinity .................................................................................................................. 64
fw ctl engine .................................................................................................................. 66
fw ctl multik stat ............................................................................................................ 67
fw ctl sdstat ................................................................................................................... 67
fw fetch .......................................................................................................................... 68
fw fetchlogs ................................................................................................................... 69
fw hastat ........................................................................................................................ 70
fw isp_link ..................................................................................................................... 70
fw kill ............................................................................................................................. 70
fw lea_notify .................................................................................................................. 71
fw lichosts ..................................................................................................................... 71
fw log ............................................................................................................................. 71
fw logswitch .................................................................................................................. 74
fw lslogs ........................................................................................................................ 75
fw mergefiles ................................................................................................................ 76
fw monitor ..................................................................................................................... 77
fw putkey ....................................................................................................................... 83
fw repairlog ................................................................................................................... 84
fw sam ........................................................................................................................... 84
fw stat ............................................................................................................................ 88
fw tab ............................................................................................................................. 88
fw ver............................................................................................................................. 90
fwm ......................................................................................................................... 90
fwm dbimport ................................................................................................................ 90
fwm expdate .................................................................................................................. 92
fwm dbexport ................................................................................................................ 92
fwm dbload .................................................................................................................... 93
fwm ikecrypt .................................................................................................................. 94
fwm getpcap .................................................................................................................. 94
fwm load ........................................................................................................................ 95
fwm lock_admin ............................................................................................................ 95
fwm logexport ............................................................................................................... 95
fwm sic_reset ................................................................................................................ 97
fwm unload <targets> .................................................................................................... 97
fwm ver ......................................................................................................................... 97
fwm verify ...................................................................................................................... 97
GeneratorApp .......................................................................................................... 98
inet_alert ................................................................................................................ 98
ldapcmd ................................................................................................................ 100
ldapcompare ......................................................................................................... 101
ldapconvert ........................................................................................................... 102
ldapmodify ............................................................................................................ 104
ldapsearch ............................................................................................................ 105
log_export ............................................................................................................. 106
queryDB_util ......................................................................................................... 109
rs_db_tool ............................................................................................................. 110
sam_alert .............................................................................................................. 111
svr_webupload_config .......................................................................................... 112
VPN Commands......................................................................................................... 113
Overview ................................................................................................................ 113
vpn crl_zap ............................................................................................................ 113
vpn crlview ............................................................................................................ 113
vpn debug .............................................................................................................. 114
vpn drv .................................................................................................................. 115
vpn export_p12 ..................................................................................................... 115
vpn macutil ............................................................................................................ 116
vpn nssm_toplogy ................................................................................................. 116
vpn overlap_encdom ............................................................................................. 117
vpn sw_topology.................................................................................................... 118
vpn tu .................................................................................................................... 118
vpn ver................................................................................................................... 119
SmartView Monitor Commands ................................................................................. 120
Overview ................................................................................................................ 120
rtm debug .............................................................................................................. 120
rtm drv .................................................................................................................. 120
rtm monitor ........................................................................................................... 121
rtm rtmd ................................................................................................................ 123
rtm stat ................................................................................................................. 123
rtm ver .................................................................................................................. 123
rtmstart ................................................................................................................. 124
rtmstop ................................................................................................................. 124
ClusterXL Commands ............................................................................................... 125
cphaconf ................................................................................................................ 125
cphaprob ............................................................................................................... 126
cphastart ............................................................................................................... 126
cphastop ................................................................................................................ 127
Identity Awareness Commands ................................................................................. 128
Introduction ........................................................................................................... 128
pdp ........................................................................................................................ 128
pdp monitor ................................................................................................................. 129
pdp connections ........................................................................................................... 130
pdp control .................................................................................................................. 130
pdp network ................................................................................................................ 130
pdp debug .................................................................................................................... 131
pdp tracker .................................................................................................................. 131
pdp status .................................................................................................................... 132
pdp update ................................................................................................................... 132
pdp ad associate .......................................................................................................... 132
pdp ad disassociate ..................................................................................................... 132
pep ........................................................................................................................ 133
pep show ..................................................................................................................... 133
pep debug .................................................................................................................... 135
adlog ..................................................................................................................... 135
adlog query .................................................................................................................. 135
adlog dc ....................................................................................................................... 136
adlog statistics ............................................................................................................ 136
adlog debug ................................................................................................................. 136
adlog control ............................................................................................................... 136
adlog service_accounts ............................................................................................... 137
test_ad_connectivity ............................................................................................. 137
IPS Commands .......................................................................................................... 139
Overview ................................................................................................................ 139
ips bypass stat ....................................................................................................... 139
ips bypass on|off ................................................................................................... 139
ips bypass set ........................................................................................................ 140
ips debug ............................................................................................................... 140
ips pmstats ............................................................................................................ 141
ips pmstats reset .................................................................................................. 141
ips refreshcap ....................................................................................................... 141
ips stat ................................................................................................................... 141
ips stats ................................................................................................................. 142
Index.......................................................................................................................... 143
Command Line Interface Reference Guide R77 | 9
CHAPT ER 1
CLI Commands for Software Blades
In This Section:
CLI Commands in Other Guides .....................................................................................9
This guide documents CLI (Command Line Interface) commands for Check Point Software Blades
and features. For more about CLI commands for Check Point operating systems:
•
R77 Gaia Administration Guide
http://supportcontent.checkpoint.com/documentation_download?ID=24828
•
R77 Gaia Advanced Routing Administration Guide
http://supportcontent.checkpoint.com/documentation_download?ID=24803
•
R77 SecurePlatform Administration Guide
http://supportcontent.checkpoint.com/documentation_download?ID=24810
•
R77 SecurePlatform Advanced Routing Suite CLI Reference Guide
http://supportcontent.checkpoint.com/documentation_download?ID=24835
CLI Commands in Other Guides
• For CoreXL and Multi-queue commands, see the
R77 Performance Tuning Administration
Guide
http://supportcontent.checkpoint.com/documentation_download?ID=24808
.
• For SmartProvisioning and SmartLSM Security Gateway commands, see the
R77
SmartProvisioning Administration Guide
http://supportcontent.checkpoint.com/documentation_download?ID=24829
.
• For Multi-Domain Security Management commands, see the
R77 Multi-Domain Security
Management Administration Guide
http://supportcontent.checkpoint.com/documentation_download?ID=24807
.
• For QoS commands, see the
R77 QoS Administration Guide
http://supportcontent.checkpoint.com/documentation_download?ID=24809
.
Command Line Interface Reference Guide R77 | 10
CHAPT ER 2
Running CLI Commands in Automation
Scripts
In This Section:
Introduction to Automation Scripts ............................................................................. 10
Working with dbedit ...................................................................................................... 11
Using XML to Export Settings for a Domain Management Server ............................. 20
Introduction to Automation Scripts
Use these CLI commands and tools to create automation scripts:
• dbedit - Creates and configures objects and rules in the database for the Security Policy.
• fwm load - Installs the specified Security Policy on Security Gateways. The Security Policy is
validated, and only valid Policies are installed.
• send_command - Runs functions which are not included with standard Check Point CLI
commands and tools.
We recommend that you use a separate SmartConsole administrator account for automation
scripts. This additional account lets you easily monitor automatic changes and ones made by
system administrators.
Creating a Domain Management Server
Prerequisites
• Name or Identifier of the domain, for example MyDomain
• Name or Identifier of the new Domain Management Server, for example MyDMS
• IPv4 address for the new Domain Management Server
• IPv4 Address for the Multi-Domain Server
• The Multi-Domain Server username and password for a Multi-Domain Superuser who has
permission to create the new Domain Management Server.
To create a new Domain Management Server:
1.
Open a terminal emulation program (such as PuTTY).
2.
Open an SSH connection to the Multi-Domain Server.
3.
Log in with the superuser credentials.
4.
Enter expert mode.
5.
Run these commands.
mdscmd addmanagement <domain_name> [-n <domain_server> | -i <ipv4> | -a
<ipv6>]
> mdscmd addcma Cust_ID -n Cust_CMA -i 192.0.2.61 -t 192.0.2.50 -m
192.0.2.50 -u admin -p vpn123
Running CLI Commands in Automation Scripts
Command Line Interface Reference Guide R77 | 11
> mdscmd startcma Cust_ID -n Cust_CMA -m 192.0.2.50 -u fwadmin -p vpn123
The Domain Management Server is created. Log in to 192.0.2.61 to configure the settings.
Working with dbedit
Introduction to dbedit
dbedit is a CLI utility that lets you make changes to objects in the Check Point databases. Run
dbedit in these modes:
• Interactive - For a few changes to the database
• Batch - Import many changes at one time
We recommend that you use batch mode (dbedit -f) for automation scripts. You can write the
script on the Security Management Server or Multi-Domain Server with standard Linux
commands, or import a text file with the script.
Launching the dbedit Utility
When the dbedit prompt is showing, you can run dbedit commands or scripts. Before you use
the dbedit utility, make sure that you can log in to Expert mode on the Security Management
Server or Multi-Domain Server.
To launch the
dbedit
utility:
1.
Log in to the CLI of the Security Management Server or Multi-Domain Server.
2.
Enter Expert mode, run expert
The Expert prompt is shown.
3.
Run dbedit
4.
Enter the name of the Security Management Server or Multi-Domain Server:
• For localhost, press Enter
• For a remote connection, enter the hostname or IP address
The dbedit prompt is shown.
Please enter a command, -h for help or -q to quit:
dbedit>
Using dbedit Commands in a Script
Use these dbedit commands to create and configure objects and rules:
• create - Creates the object
• modify - Changes the applicable object
• update - Commits the most recent change to the Security Management Server database
• update_all - Commits all the changes to the Security Management Server database
This table shows sample commands and the results.
Example
Result
create network net-internal Creates the object for the network net-internal
Running CLI Commands in Automation Scripts
Command Line Interface Reference Guide R77 | 12
Example
Result
modify network_objects
gateway-10 ipaddr 192.0.2.100 Changes the IP address of the gateway-10 object to
192.0.2.100
update network_objects
net-internal Saves the changes for the net-internal objects and
updates the Security Management Server database
Locking the Database
We recommend that you use the -globallock option when you use dbedit to make changes to
the Security Management Server database. dbedit partially locks the database, if a user
configures objects with SmartDashboard, there can be problems in the database. The
-globallock option does not let SmartDashboard or a dbedit user make changes to the
database.
When the -globallock option is enabled, dbedit commands run on a copy of the database.
After you change the database and run the savedb command, it is saved and committed on the
actual database. You can use the savedb command multiple times in a dbedit script.
At the end of a script, it is a best practice to run these commands:
# update_all
# savedb
Showing Parameters for a Sample Object
You can create sample objects in SmartDashboard that have the parameters that you are using in
a script or dbedit command. Export these objects to help make sure that you are using the
correct names for the parameters. You can show the parameters in plain or XML format.
To show the parameters for a sample SmartDashboard object:
1.
In SmartDashboard, create the object that uses the necessary parameters and settings.
2.
From the dbedit prompt ("Launching the dbedit Utility" on page 11), run one of these
commands:
• print network_objects <object name>
• printxml network_objects <object name>
Using Automation Scripts
You can use dbedit to configure the initial settings for a Security Gateway and the Security
Policy, then update and change the settings when necessary.
Note - Make sure that the script in the text files does not contain blank lines.
Otherwise the script will stop with an error.
Initial Configuration
1.
Create a text file with an automation script ("Create or Modify Policy Objects (Hosts,
Networks)" on page 13). The script can create and configure the necessary objects and rules
for the Security Policy.
2.
Make a database revision of the management. Use this revision if there is a problem with the
script and to identify unauthorized changes to the database.
Running CLI Commands in Automation Scripts
Command Line Interface Reference Guide R77 | 13
3.
Run fwm load and install the policy on one or more Security Gateways ("Pushing the Security
Policy to Security Gateways" on page 19).
Updating and Changing the Policy
1.
Make sure that the automation administrator changed the database most recently.
a) Run send_command -s <domain_server> –u <admin> –p <password> –o
db_change_since_last_save
The Last modifier field shows the administrator name.
b) If a different administrator changed the database, do not continue to use the automation
script. A system administrator must do an analysis of the database.
2.
Edit the automation script, create and configure objects and rules for the Security Policy
("Changing a Rule Base" on page 17).
3.
Run fwm load and install the policy on one or more Security Gateways ("Installing Policy with
a Multi-Domain Server" on page 20).
To update and change the commands for a Domain Management Server:
This sample script installs the Standard policy from Domain Management Server Cust_CMA on
the Security Gateway examplegw.
mdsenv Cust_CMA
send_command –s Cust_CMA –u admin –p admin –o db_change_since_last_save
dbedit –globallock -s Cust_CMA -u admin -p admin -f dbedit_modifiability_objects.txt
fwm load Standard examplegw
Create or Modify Policy Objects (Hosts, Networks)
This section shows sample scripts that create one or more new network or service objects. You
can combine one or more of these samples into one script file.
We recommend that you add the update_all command to the end of the script file.
Networks
You can use a script to manage database objects that include:
• Networks
• Hosts
• Address Ranges
These are sample scripts that show how to create and configure the database objects.
Creating a Network
Create an object for the database that represents a network. This sample script creates the
network net-internal with the IP address 190.0.2.0.
Create the object (of type network)
create network net-internal
Configure the network IP address
modify network_objects net-internal ipaddr 192.0.2.0
Configure the netmask (in dotted decimal notation) of the network
modify network_objects net-internal netmask 255.255.255.0
Add a comment to describe what the object is for (optional)
modify network_objects net-internal comments "Created by fwadmin with dbedit"
Running CLI Commands in Automation Scripts
Command Line Interface Reference Guide R77 | 14
Configuring Automatic NAT
If your network uses NAT (Network Address Translation), you can use dbedit to configure an
Automatic NAT rule. Add these lines to a script only for a network that uses Automatic NAT rules.
This sample script creates an Automatic NAT rule for the net-internal network that starts with
the IP address 190.0.2.100.
The next four modify lines are optional and are only needed if you want
to do an automatic NAT rule for this object.
modify network_objects net-internal add_adtr_rule true
modify network_objects net-internal NAT NAT
Set the NAT type, adtr_static or adtr_hide
modify network_objects net-internal NAT:netobj_adtr_method adtr_hide
Set the "valid" IP address for this object.
For a static NAT on a network, the assumption is there is a 1-to-1 ratio
between untranslated and translated addresses and the valid range is
contiguous. This setting is the first IP address in this range.
modify network_objects net-internal NAT:valid_ipaddr 192.0.2.100
Creating a Host
This sample script creates the host host-10 with the IP address 192.0.2.10.
Create the actual object (of type host_plain)
create host_plain host-10
Modify the host IP address
modify network_objects host-10 ipaddr 192.0.2.10
Add a comment to describe what the object is for (optional)
modify network_objects host-10 comments "Created by fwadmin with dbedit"
You can also add the lines to this script to configure Automatic NAT for the host ("Configuring
Automatic NAT" on page 14). The modify commands for this sample rule starts with: modify
network_objects host-10
Creating an Address Range
This sample script creates the address range object addr-range with the IP addresses
192.0.2.150 to 190.0.2.200.
Create the actual object (of type address_range)
create address_range addr-range
Modify the first IP address in the range
modify network_objects addr-range ipaddr_first 192.0.2.150
Modify the last IP address in the range
modify network_objects addr-range ipaddr_last 192.0.2.200
Add a comment to describe what the object is for (optional)
modify network_objects addr-range comments "Created by fwadmin with dbedit"
You can also add the lines to this script to configure Automatic NAT for the address range object
("Configuring Automatic NAT" on page 14). The modify commands for this sample rule starts
with: modify network_objects addr-range
Renaming and Deleting Objects
You can change the name of an object or delete it from the database. When you change the name
of an object the Security Policy is also updated with the new name.
Rename the network object addr-range to IPv4-range
rename network_objects addr-range IPv4-range
When you delete an object, the references to it are also deleted from the Rule Base. The delete
command fails if there is a different object that is dependent on it.
Delete the network object addr-range
Running CLI Commands in Automation Scripts
Command Line Interface Reference Guide R77 | 15
delete network_objects addr-range
Network Groups
You can create and use a group object as a container for network and host objects.
Creating a Network Group
Create a network group that uses networks and hosts. Make sure that these objects are in the
management database before you create a network group.
This sample script creates the object host-group for the hosts host-100 and host-101.
Create a group object
create network_object_group host-group
Add the individual elements to the group
addelement network_objects host-group '' network_objects:host-100
addelement network_objects host-group '' network_objects:host-101
Configuring and Deleting a Network Group
You can remove a network or host from a network group. This sample script removes host-100
from host-group.
Remove individual elements from the group
rmelement network_objects host-group '' network_objects:host-100
You can rename or remove a network group almost the same as objects ("Renaming and Deleting
Objects" on page 14).
Rename the network object host-group to host-ipaddrs
Rename network_objects host-group host-ipaddrs
Delete the network object host-ipaddrs
delete network_objects host-ipaddrs
Services
Services are objects that are used for network protocols.
Creating a Service
This sample script creates these services:
• tcp_8081 - TCP protocol port 8081
• udp_8082 - UDP protocol port 8082
• inspect_svc - Inspect SVC protocol 6 and with an optional feature that uses the INSPECT
expression
Create a TCP service
create tcp_service tcp_8081
Set port 8081 for TCP service
modify services tcp_8081 port 8081
Create a UDP service
create udp_service udp_8082
Set port 8082 for UDP service
modify services udp_8082 port 8082
Create a service of type "other." This can be used for random IP protocols
as well as services that require more complex INSPECT code for matching.
Create the service of type other
create other_service inspect_svc
Modify the IP Protocol that matches the service
modify services inspect_svc protocol 6
Running CLI Commands in Automation Scripts
Command Line Interface Reference Guide R77 | 16
(Optional) Modify the INSPECT expression that matches this service.
modify services inspect_svc exp "dport=123”
Renaming and Deleting a Service
You can rename or remove a service almost the same as objects ("Renaming and Deleting
Objects" on page 14).
Rename inspect_svc to inspect_tcp123
rename services inspect_svc inspect_tcp123
Delete the network object inspect_tcp123
delete services inspect_tcp123
Service Groups
You can create and use a group object as a container for service objects.
Creating a Service Group
Create a service group for more than one service. Make sure that the service objects are in the
management database before you create a service group.
This sample script creates the object mysvc-group for the services SSH and HTTPS.
Create a group object
create service_group mysvc-group
Add the individual elements to the group
addelement services mysvc-group '' services:ssh
addelement services mysvc-group '' services:https
Configuring and Deleting a Service Group
You can remove a network or host from a network group. This sample script removes the SSH
service from mysvc-group.
Remove individual elements from the group
rmelement services mysvc-group '' services:ssh
You can rename or remove a network group almost the same as objects ("Renaming and Deleting
Objects" on page 14).
Rename the service group mysvc-group to myservices
rename services mysvc-group myservices
Delete the network object my services
delete services myservices
Object Naming Restrictions
These are some of the restrictions for object names:
• Objects names can contain only ASCII letters, numbers, and dashes. Other characters such as
a plus sign, asterisk, parenthesis, square brackets, and so on, are not supported.
• Object names can have a maximum of 100 characters.
• You cannot use reserved words for objects names and they include words that are policy
elements. For example, names of colors, common networks terms (ipv6, nets, routers,
servers, and so on).
To see a full list of the naming restrictions, go to sk40179
(http://supportcontent.checkpoint.com/solutions?id=sk40179).
Running CLI Commands in Automation Scripts
Command Line Interface Reference Guide R77 | 17
Changing a Rule Base
This section shows sample scripts that change the Policy on a Domain Management Server named
Standard. We recommend that you write the scripts in a text file and then you import the file to
dbedit.
Adding a Rule
When you use dbedit to add a rule, the rule must be added to the bottom of the rule base by
manually specifying the rule number. If the policy contains no other rules, the rule becomes the
policy’s first rule.
Note - Rules in SmartDashboard start with rule number 1. Rules in dbedit start with
rule number 0.
This sample script creates a new policy called DemoPolicy with a Rule Base that contains this rule
at the bottom:
Source Destination Service Action
Any Any Any Accept
create policies_collection ##DemoPolicy
modify policies_collections ##DemoPolicy comments "Demo"
modify policies_collections ##DemoPolicy default 1
update policies_collections ##DemoPolicy
create firewall_policy ##DemoPolicy
modify fw_policies ##DemoPolicy default 0
modify fw_policies ##DemoPolicy collection policies_collections:##DemoPolicy
addelement fw_policies ##DemoPolicy rule security_rule
modify fw_policies ##DemoPolicy rule:0:name "AcceptAll"
rmbyindex fw_policies ##DemoPolicy rule:0:track 0
addelement fw_policies ##DemoPolicy rule:0:track tracks:None
addelement fw_policies ##DemoPolicy rule:0:time globals:Any
addelement fw_policies ##DemoPolicy rule:0:install:'' globals:Any
addelement fw_policies ##DemoPolicy rule:0:action accept_action:accept
addelement fw_policies ##DemoPolicy rule:0:src:'' globals:Any
modify fw_policies ##DemoPolicy rule:0:src:op ''
addelement fw_policies ##DemoPolicy rule:0:dst:'' globals:Any
modify fw_policies ##DemoPolicy rule:0:dst:op ''
addelement fw_policies ##DemoPolicy rule:0:services:'' globals:Any
modify fw_policies ##DemoPolicy rule:0:services:op ''
update_all
Changing a Rule
This sample script changes this rule:
Source Destination Service Action
Original rule 4 Any Any Any Accept
New rule 4 Any DMZ SSH Accept
Modify Rule 4
Previous rule was any any any accept, it will now be any dmz ssh accept
modify fw_policies ##Standard rule:3:comments "Allow SSH to firewall with
logging"
Running CLI Commands in Automation Scripts
Command Line Interface Reference Guide R77 | 18
modify fw_policies ##Standard rule:3:disabled false
rmbyindex fw_policies ##Standard rule:3:track 0
addelement fw_policies ##Standard rule:3:track tracks:Log
rmbyindex fw_policies ##Standard rule:3:action 0
addelement fw_policies ##Standard rule:3:action accept_action:accept
rmelement fw_policies ##Standard rule:3:src:'' globals:Any
addelement fw_policies ##Standard rule:3:src:'' globals:Any
modify fw_policies ##Standard rule:3:src:op ''
rmelement fw_policies ##Standard rule:3:dst:'' globals:Any
addelement fw_policies ##Standard rule:3:dst:'' network_objects:DMZ
modify fw_policies ##Standard rule:3:dst:op ''
rmelement fw_policies ##Standard rule:3:services:'' globals:Any
addelement fw_policies ##Standard rule:3:services:'' services:ssh
modify fw_policies ##Standard rule:3:services:op ''
Adding a Rule - Middle of Rule Base
When it is necessary to add a rule to the middle of a Rule Base, you cannot use dbedit to simply
insert a rule.
1.
Delete all the rules that are after the new rule you are adding.
2.
Create one or more new rules.
3.
Add again the rules that you deleted in step 1.
This sample script adds a new rule number 2 in a Rule Base that has three rules.
Note - Rules in SmartDashboard start with rule number 1. Rules in dbedit start
with rule number 0.
Delete rule 2 and 3 (delete in reverse order)
rmbyindex fw_policies ##Standard rule 2
rmbyindex fw_policies ##Standard rule 1
Add new rule 2
addelement fw_policies ##Standard rule security_rule
modify fw_policies ##Standard rule:1:comments "Firewall stealth rule"
modify fw_policies ##Standard rule:1:disabled false
rmbyindex fw_policies ##Standard rule:1:track 0
addelement fw_policies ##Standard rule:1:track tracks:Log
addelement fw_policies ##Standard rule:1:time globals:Any
addelement fw_policies ##Standard rule:1:install:'' globals:Any
rmbyindex fw_policies ##Standard rule:1:action 0
addelement fw_policies ##Standard rule:1:action drop_action:drop
addelement fw_policies ##Standard rule:1:src:''
network_objects:net-internal
modify fw_policies ##Standard rule:1:src:op 'not in'
addelement fw_policies ##Standard rule:1:dst:'' globals:Any
modify fw_policies ##Standard rule:1:dst:op ''
addelement fw_policies ##Standard rule:1:services:'' globals:Any
modify fw_policies ##Standard rule:1:services:op ''
Running CLI Commands in Automation Scripts
Command Line Interface Reference Guide R77 | 19
Add New Rule 3 (Old Rule 2)
addelement fw_policies ##Standard rule security_rule
modify fw_policies ##Standard rule:2:comments "Allow selected hosts
outbound"
modify fw_policies ##Standard rule:2:disabled false
rmbyindex fw_policies ##Standard rule:2:track 0
addelement fw_policies ##Standard rule:2:track tracks:Log
addelement fw_policies ##Standard rule:2:time globals:Any
addelement fw_policies ##Standard rule:2:install:'' globals:Any
rmbyindex fw_policies ##Standard rule:2:action 0
addelement fw_policies ##Standard rule:2:action accept_action:accept
addelement fw_policies ##Standard rule:2:src:'' network_objects:flamer-100
addelement fw_policies ##Standard rule:2:src:'' network_objects:flamer-101
modify fw_policies ##Standard rule:2:src:op ''
addelement fw_policies ##Standard rule:2:dst:''
network_objects:net-internal
modify fw_policies ##Standard rule:2:dst:op 'not in'
addelement fw_policies ##Standard rule:2:services:'' globals:Any
modify fw_policies ##Standard rule:2:services:op ''
Add New Rule 4 (Old Rule 3)
addelement fw_policies ##MyPolicy rule security_rule
modify fw_policies ##MyPolicy rule:3:comments "Drop all"
modify fw_policies ##MyPolicy rule:3:disabled false
rmbyindex fw_policies ##MyPolicy rule:3:track 0
addelement fw_policies ##MyPolicy rule:3:track tracks:Log
addelement fw_policies ##MyPolicy rule:3:time globals:Any
addelement fw_policies ##MyPolicy rule:3:install:'' globals:Any
rmbyindex fw_policies ##MyPolicy rule:3:action 0
addelement fw_policies ##MyPolicy rule:3:action drop_action:drop
addelement fw_policies ##MyPolicy rule:3:src:'' globals:Any
modify fw_policies ##MyPolicy rule:3:src:op ''
addelement fw_policies ##MyPolicy rule:3:dst:'' globals:Any
modify fw_policies ##MyPolicy rule:3:dst:op ''
addelement fw_policies ##MyPolicy rule:3:services:'' globals:Any
modify fw_policies ##MyPolicy rule:3:services:op ''
Pushing the Security Policy to Security Gateways
After you change or update the Security policy, you can use fwm load command to push the
configuration to the Security Gateways. This command validates the policy and makes sure that
rules agree with each other.
In this example, the fwm load command successfully pushes the policy (Standard) to the
Security Gateway (samplegw).
# fwm load Standard samplegw
Installing policy on R77 compatible targets:
Standard.W: Security Policy Script generated into
CustomerPolicy.pf
Standard:
Compiled OK.
Installing Security Gateway policy on: examplegw ...
Security Gateway policy installed successfully on examplegw...
Security Gateway policy installation complete
Security Gateway policy installation succeeded for:
examplegw
Running CLI Commands in Automation Scripts
Command Line Interface Reference Guide R77 | 20
If the policy did not install successfully, the output of the fwm load command shows an error
message. The Security Gateway continues to enforce the policy that was installed before you ran
the script.
Installing Policy with a Multi-Domain Server
To install the policy for a Domain Management Server, run the necessary Multi-Domain Server CLI
commands. You can run them individually or as part of a script.
This sample script installs the Standard policy from Domain Management Server Cust_CMA on
the Security Gateway examplegw.
mdsenv Cust_CMA
dbedit –globallock -s Cust_CMA -u admin -p admin -f
dbedit_createpolicy_objects.txt
fwm load Standard examplegw
Error Codes in dbedit
• If there is a syntax error in the dbedit script, this error is shown:
“syntax error in line 1 Aborting.”
The script stops running at the error.
• When a script uses tables or objects that are not in the database, dbedit stops the script and
shows this message:
“Object Not Found”
“Error in line: 2”
• You can use the parameter ignore_script_failure to continue running the script and
ignore errors
• You can use the parameter continue_updating to ignore errors and run the update_all
command at the end of the script
Using XML to Export Settings for a Domain
Management Server
You can export the settings for a Domain Management Server to an XML file that you can use with
external automation systems. You can include the printxml commands in a script or run them
individually from the CLI.
This sample script exports these settings to XML:
• Security policy Rule Base
• Network objects
• Services
printxml fw_policies ##Standard
printxml network_objects
printxml services
Command Line Interface Reference Guide R77 | 21
CHAPT ER 3
Security Management Server and
Firewall Commands
In This Section:
comp_init_policy ........................................................................................................... 22
cp_admin_convert ........................................................................................................ 22
cpca_client .................................................................................................................... 22
cp_conf .......................................................................................................................... 26
cpconfig ......................................................................................................................... 30
cpinfo ............................................................................................................................. 30
cplic ............................................................................................................................... 31
cp_merge ...................................................................................................................... 39
cppkg ............................................................................................................................. 42
cpridrestart ................................................................................................................... 45
cpridstart ....................................................................................................................... 45
cpridstop ....................................................................................................................... 45
cprinstall ....................................................................................................................... 46
cpstart ........................................................................................................................... 51
cpstat ............................................................................................................................. 51
cpstop ............................................................................................................................ 53
cpwd_admin .................................................................................................................. 54
disconnect_client .......................................................................................................... 57
dbedit ............................................................................................................................. 57
dbver .............................................................................................................................. 59
dynamic_objects ........................................................................................................... 61
fw ................................................................................................................................... 61
fwm ................................................................................................................................
90
GeneratorApp ................................................................................................................ 98
inet_alert ....................................................................................................................... 98
ldapcmd ....................................................................................................................... 100
ldapcompare ............................................................................................................... 101
ldapconvert ................................................................................................................. 102
ldapmodify ................................................................................................................... 104
ldapsearch .................................................................................................................. 105
log_export ................................................................................................................... 106
queryDB_util ............................................................................................................... 109
rs_db_tool ................................................................................................................... 110
sam_alert .................................................................................................................... 111
svr_webupload_config................................................................................................ 112
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 22
comp_init_policy
Description Use the comp_init_policy command to generate and load, or to remove, the
Initial Policy.
The Initial Policy offers protection to the gateway before the administrator has installed a Policy
on the gateway.
Syntax
> $FWDIR/bin/comp_init_policy [-u] [-g]
Parameter Description
-u Removes the current Initial Policy, and ensures that it will not be generated in
future when cpconfig is run.
-g Can be used if there is no Initial Policy. If there is, make sure that after
removing the policy, you delete the $FWDIR\state\local\FW1\ folder.
Generates the Initial Policy and ensures that it will be loaded the next time a
policy is fetched (at cpstart, or at next boot, or via the fw fetch localhost
command). After running this command, cpconfig will add an Initial Policy
when needed.
The comp_init_policy -g command will only work if there is no previous
Policy. If you perform the following commands:
comp_init_policy -g + fw fetch localhost
comp_init_policy -g + cpstart
comp_init_policy -g + reboot
The original policy will still be loaded.
cp_admin_convert
Description Automatically export administrator definitions that were created in cpconfig to
SmartDashboard.
Syntax
> cp_admin_convert
cpca_client
Description These commands execute operations on the ICA (Internal Certificate Authority).
Syntax
> cpca_client
cpca_client create_cert
Description Prompt the ICA to issue a SIC certificate for the Security Management server.
Syntax
> cpca_client [-d] create_cert [-p <ca_port>] -n "CN=<common name>" -f
<PKCS12>
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 23
Parameter Description
-d Runs the command in debug mode
-p <ca_port> Specifies the port used to connect to the CA (if the CA was not run
from the default port 18209)
-n "CN=<common name>"
Sets the CN to <common name>
-f <PKCS12> Specifies the file name, <PKCS12>, that stores the certificate and
keys.
cpca_client revoke_cert
Description Revoke a certificate issued by the ICA.
Syntax
> cpca_client [-d] revoke_cert [-p <ca_port>] -n "CN=<common name>"
Parameter Description
-d Runs the command in debug mode
-p <ca_port> Specifies the port which is used to connect to the CA (if the CA was
not run from the default port 18209)
-n "CN=<common name>"
Sets the CN to <common name>
cpca_client lscert
Description Show all certificates issued by the ICA.
Syntax
> cpca_client [-d] lscert [-dn <substring>] [-stat
{Pending|Valid|Revoked|Expired|Renewed}] [-kind SIC|IKE|User|LDAP] [-ser
<ser>] [-dp <dp>]
Parameter Description
-d Runs the command in debug mode
-dn substring Filters results to those with a DN that matches this <substring>
-stat Filters results to the specified certificate status: Pending, Valid,
Revoke, Expire, or Renewed
-kind Filters results for specified kind: SIC, IKE, User, or LDAP
-ser <serial> Filters results for this serial number
-dp <dp> Filters results from this CDP (certificate distribution point)
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 24
cpca_client init_certs
Description Imports a list of DNs for users and creates a file with registration keys for each
user.
Syntax
> cpca_client init certs [-p <ca_port>] -i <input_file> -o <output_file>
Parameter
Description
-p <ca_port> Specifies the port which is used to connect to the CA. The
default port is 18265.
-i <input_file> Imports the specified file. Make sure to use the full path.
Make sure that there is an empty line between each DN in
the file:
CN=test1,OU=users
<empty line>
CN=test2,OU=users
-o <output_file> Saves the registration keys to the specified file.
cpca_client set_mgmt_tool
Description Starts or stops the ICA Management Tool.
Syntax
> cpca_client [-d] set_mgmt_tool {on|off|add|remove|clean|print} [-p
<ca_port>] [-no_ssl] {-a <administrator DN>, -u <user DN>, -c <custom user
DN>, ...}
Parameter Description
-d Runs the command in debug mode.
set_mgmt_tool
{on|off|add|remove|
clean|print}
• on - Starts ICA Management Tool
• off - Stops ICA Management Tool
• add - Adds an administrator, user, or custom user
• remove - Removes an administrator, user, or custom user
• clean -
Removes all the administrators, users, or custom users
•
print
- Shows the administrators, users, or custom users
-p <ca_port> Specifies the port which is used to connect to the CA. The default
port is 18265.
-no_ssl Configures the server to use HTTP instead of HTTPS.
-a <administrator DN>
Sets the DNs of the administrators that are permitted to use the ICA
Management Tool.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 25
Parameter Description
-u <user DN> Sets the DNs of the users that are permitted to use the ICA
Management Tool.
-c <custom user DN> Sets the DN for custom users that can use the ICA Management
Tool.
Comments
1.
If the command is run without -a or -u the list of the permitted users and administrators isn't
changed. The server can be stopped or started with the previously defined permitted users and
administrators.
2.
If two consecutive start operations are initiated, the ICA Management Tool will not respond,
unless you change the SSL mode. After the SSL mode has been modified, the server can be
stopped and restarted.
cpca_client set_sign_hash
Description Sets the hash algorithm that the CA uses to sign the file has. The default algorithm
is sha1.
Syntax
> cpca_client set_sign_hash {sha1|sha256|sha384|sha512}
cpca_client search
Description Searches for certificates in the ICA (Internal Certificate Authority).
Syntax
> cpca_client search <string> [-where {dn|comment|serial}] [-kind
[SIC|IKE|User|LDAP]] [-stat [Pending|Valid|Revoked|Expired|Renewed]] [-max
<max results>] [-showfp {y|n}]
Parameter
Description
-where
{dn|comment|serial} Where to search for the string, in the dn, serial number,
or comment field.
The default is all locations.
-kind
[SIC|IKE|User|LDAP] The type of certificate. You can enter multiple values in
this format: -kind value1 value2 value3. The
default is all values.
-stat
[Pending|Valid|Revok
ed|Expired|Renewed]
Filters according to the status of the certificate. You can
enter multiple values in this format: -stat value1
value2 value3. The default is all values.
-max <max results> Enter the maximum number of results to show. The
default setting is 200.
-showfp {y|n}
Show the certificate's fingerprint: yes or no. The default is
yes.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 26
Example > cpca_client search samplecompany -where comment -kind SIC LDAP
-stat Pending Valid Renewed
cpca_client get_crldp
Description Shows the name that the computer or server uses to initialize with the CA.
Syntax
> cpca_client get_crldp [-p <ca_port>]
Parameter
Description
-p <ca_port> Specifies the port which is used to connect to the CA. The
default port is 18265.
cpca_client get_pubkey
Description Saves the encoding of the public key for the ICA to a file.
Syntax
> cpca_client [-p <ca_port>] get_pubkey <output>
Parameter Description
-p <ca_port> Specifies the port which is used to connect to the CA. The default
port is 18265.
<output> Name of the file where the public key is saved
cpca_client double_sign
Description Creates a second signature for a certificate.
Syntax
> cpca_client [-p <ca_port>] -i <cert file> [-o <output file>]
Parameter Description
-p <ca_port> Specifies the port which is used to connect to the CA. The default
port is 18265.
-i <cert file> Imports the specified certificate only in PEM format.
[-o <output file>] Saves the certificate to the specified file.
cp_conf
Description Configure/reconfigure a Security Gateway installation. The configuration available
options for any machine depend on the installed configuration and products.
Syntax
> cp_conf
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 27
cp_conf sic
Description Use the cp_conf sic commands to manage SIC on the Security Management
Server.
Syntax
> cp_conf sic state
> cp_conf sic init <key> [norestart]
> cp_conf sic cert_pull <management> <object>
Parameter
Description
state Shows the SIC trust state.
init <key> Restarts SIC with the Activation Key <key>.
[no restart] By default, the Security Gateway runs cpstop and cpstart when
you restart SIC. Use the norestart
parameter to restart SIC and to
not run cpstop and cpstart.
cert_pull For DAIP Security Gateways, pulls a certificate from the Security
Management Server for the <object>
<management> Name or IP address of the Security Management Server
cp_conf admin
Description Manage Check Point system administrators for the Security Management Server
Syntax
> cp_conf admin get # Get the list of administrators.
> cp_conf admin add <user> <pass> {a|w|r}
> cp_conf admin del <admin1> <admin2>...
Parameter
Description
get Shows a list of the administrators
add <user> <pass> Adds a new administrator <user> with password <pass>
{a|w|r} Sets the permissions for the new administrator:
a - Read, write and manage administrators
w - Read and write
r - Read only
del <admin1> Deletes one or more administrators <admin1>, <admin2>, and so on
cp_conf ca
Description Initialize the Certificate Authority
Syntax
> cp_conf ca init
> cp_conf ca fqdn <name>
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 28
Parameter
Description
init Initializes the internal CA
fqdn <name> Sets the FQDN of the internal CA to <name>
cp_conf finger
Description Displays the fingerprint which will be used on first-time launch to verify the identity
of the Security Management server being accessed by the SmartConsole. This fingerprint is a text
string derived from the Security Management server's certificate
Syntax
> cp_conf finger get
cp_conf lic
Description Shows the installed licenses and lets you manually add new ones.
Syntax
> cp_conf lic get
> cp_conf lic add -f <file>
> cp_conf lic add -m <Host> <Date> <Key> <SKU>
> cp_conf lic del <Signature Key>
Parameter
Description
get Shows the installed licenses
add -f <file> Adds the license from <file>
add -m Manually adds a license with these parameters:
<host> - name of the Security Management Server
<Date> - Date of the license
<Key> - License key
<SKU> - License SKU
del <Key> Deletes license <key>
cp_conf client
Description Manage the GUI clients that can use SmartConsoles to connect to the Security
Management Server.
Syntax
> cp_conf client get # Get the GUI clients list
> cp_conf client add <GUI client> # Add one GUI Client
> cp_conf client del < GUI client 1> < GUI client 2>... # Delete GUI Clients
> cp_conf client createlist < GUI client 1> < GUI client 2>... # Create new
list.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 29
Parameter
Description
get Shows the IP addresses of the allowed GUI clients.
add <GUI client> Adds the <GUI client> IP address to the list of allowed GUI
clients.
del <GUI client1> <GUI
client 2> Deletes one or more IP addresses from the list of allowed GUI
clients.
createlist <GUI
client1> <GUI client
2>
Deletes allowed GUI clients and creates a new list. The new list
allows <GUI client 1>, <GUI client 2>, and so on.
cp_conf ha
Description Enable or disable High Availability.
Syntax
> cp_conf ha {enable|disable} [norestart]
cp_conf snmp
Description Activate or deactivate SNMP.
Syntax
> cp_conf snmp get # Get SNMP Extension status.
> cp_conf snmp {activate|deactivate} [norestart] # Deactivate SNMP
Extension.
Parameter Description
get Shows the SNMP status.
{activate|deactivate
} Enables or disables SNMP.
[no restart] By default, the Security Gateway runs cpstop and cpstart when
you enable or disable SNMP. Use the norestart parameter to
configure SNMP and to not run cpstop and cpstart.
cp_conf auto
Description Configure the Security Gateway and Security Management Server products that
start automatically when the appliance or server reboots.
Syntax
> cp_conf auto get [fw1] [fg1] [rm] [all]
> cp_conf auto {enable|disable} <product1> <product2>...
Parameter
Description
get Shows which products start automatically
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 30
Parameter
Description
{enable|disable}
<product1> <product2>
Enables or disables the one or more products that start
automatically
cp_conf sxl
Description Enable or disable SecureXL acceleration.
Syntax
> cp_conf sxl {enable|disable}
cpconfig
Description Run a command line version of the Check Point Configuration Tool. This tool is
used to configure an installed Check Point product. The options shown depend on the installed
configuration and products. Amongst others, these options include:
• Licenses and contracts - Modify the necessary Check Point licenses and contracts.
• Administrator - Modify the administrator authorized to connect to the Security Management
server.
• GUI Clients - Modify the list of SmartConsole Client machines from which the administrators
are authorized to connect to a Security Management server.
• SNMP Extension - Configure the SNMP daemon. The SNMP daemon enables SecurePlatform
to export its status to external network management tools.
• PKCS #11 Token - Register a cryptographic token, for use by SecurePlatform; see details of
the token, and test its functionality.
• Random Pool - Configure the RSA keys, to be used by SecurePlatform.
• Certificate Authority - Install the Certificate Authority on the Security Management server in a
first-time installation.
• Secure Internal Communication - Set up trust between the gateway on which this command is
being run and the Security Management server.
• Certificate's Fingerprint - Display the fingerprint which will be used on first-time launch to
verify the identity of the Security Management server being accessed by the SmartConsole.
This fingerprint is a text string derived from the Security Management server's certificate.
• Automatic Start of Check Point Products - Specify whether Check Point Security Gateways will
start automatically at boot time.
Syntax `
> cpconfig
Further Info. See the
R77 Installation and Upgrade Guide
http://supportcontent.checkpoint.com/documentation_download?ID=24831
.
cpinfo
Description - CPinfo is a utility that collects data on a machine at the time of execution. The CPinfo
output file enables Check Point's support engineers to analyze setups from a remote location.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 31
Engineers can open the CPinfo file in demo mode, while viewing real Security Policies and objects.
This allows for in-depth analysis of all of configuration options and environment settings.
Syntax
> cpinfo [-v] [-l] [-n] [-o ] [-r | -t [tablename]] [-c <domain> ... | -x
<vs>]
Parameter Description
-z Output gzipped (effective with -o option)
-r Includes the registry (for Windows servers - shows a large output)
-v Prints version information
-l Embeds log records (very large output)
-n Does not resolve network addresses (faster)
-o Output to a file and to the screen
-t Output consists of tables only (SR only)
-c <domain> Get information about the specified <domain> Domain Management Server
(Multi-Domain Security Management)
-x <vs> Get information about the specified <vs> Virtual System (VSX)
Further Info: SecureKnowledge solution sk30567
http://supportcontent.checkpoint.com/solutions?id=sk30567.
cplic
The cplic command and all its derivatives relate to Check Point license management.
Note - SmartUpdate GUI is the recommended way of managing licenses.
All cplic commands are located in $CPDIR/bin. License Management is divided into three
types of commands:
•
Local licensing commands
are executed on local machines.
•
Remote licensing commands
are commands which affect remote machines are executed on
the Security Management Server.
•
License repository commands
are executed on the Security Management Server.
cplic check
Description Makes sure that the license includes the feature on the local gateway or Security
Management Server.
Syntax
gw> cplic check [-p <product>] [-v <version>] [-c|-count] [-t <date>]
[-r|-routers] [-S|-SRusers] <feature>
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 32
Parameter Description
-p <product> Product for which license information is requested. For example
fw1, netso
-v <version> Product version for which license information is requested
-c|-count Output the number of licenses connected to this feature
-t <date> Check license status on future date. Use the format ddmmmyyyy. A
feature may be valid on a given date on one license, but invalid in
another
-r|-routers Check how many routers are allowed. The feature option is not
needed
-S|-SRusers Check how many SecuRemote users are allowed.
<feature> <feature> for which license information is requested
cplic db_add
Description Used to add one or more licenses to the license repository on the Security
Management server. When local license are added to the license repository, they are
automatically attached to its intended Check Point gateway, central licenses need to undergo the
attachment process.
This command is a license repository command, and can only be executed on the Security
Management server.
Syntax
> cplic db_add -l <license-file> [<host>] [<expiration-date>] [<signature>]
[<SKU/features >]
Parameter Description
-l
<license-file> Name of the file that contains the license
<host> Security Management Server hostname or IP address
<expiration-date
> The license expiration date
<signature> The License signature string. For example:
aa6uwknDc-CE6CRtjhv-zipoVWSnm-z98N7Ck3m (The string is case
sensitive and the hyphens are optional)
<SKU/features > The SKU of the license summarizes the features included in the license.
For example: CPSUITE-EVAL-3DES-vNG
Example If the file 192.0.2.11.lic contains one or more licenses, the command: cplic
db_add -l 192.0.2.11.lic will produce output similar to the following:
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 33
Adding license to database ...
Operation Done
cplic db_print
Description Displays the details of Check Point licenses stored in the license repository on the
Security Management Server.
Syntax
> cplic db_print <object name | -all> [-n noheader] [-x print signatures]
[-t type] [-a attached]
Parameter Description
Object name Print only the licenses attached to Object name. Object name is the
name of the Check Point Security Gateway object, as defined in
SmartDashboard.
-all Print all the licenses in the license repository
-noheader
(or -n)
Print licenses with no header.
-x Print licenses with their signature
-t
(or -type)
Print licenses with their type: Central or Local.
-a
(or -attached)
Show which object the license is attached to. Useful if the -all option is
specified.
Comments This command is a license repository command, and can only be executed on the
Security Management server.
cplic db_rm
Description The cplic db_rm command removes a license from the license repository on the
Security Management server. It can be executed ONLY after the license was detached using the
cplic del command. Once the license has been removed from the repository, it can no longer be
used.
Syntax
> cplic db_rm <signature>
Parameter Description
Signature The signature string within the license.
Example cplic db_rm 2f540abb-d3bcb001-7e54513e-kfyigpwn
Comments This command is a license repository command, and can only be executed on the
Security Management server.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 34
cplic del
Description Delete a single Check Point license on a host, including unwanted evaluation,
expired, and other licenses. Used for both local and remote machines
Syntax
> cplic del [-F <output file>] <signature> <object name>
Parameter Description
-F <output file> Send the output to <output file> instead of the screen.
<signature> The signature string within the license.
cplic del <object name>
Description Detach a Central license from a Check Point Security Gateway. When this command
is executed, the license repository is automatically updated. The Central license remains in the
repository as an unattached license. This command can be executed only on a Security
Management server.
Syntax
> cplic del <object name> [-F <outputfile>] [-ip <dynamic ip>] <signature>
Parameter Description
<object name> The name of the Check Point Security Gateway object, as defined in
SmartDashboard.
-F <outputfile> Divert the output to outputfile rather than to the screen.
-ip <dynamic ip> Delete the license on the Check Point Security Gateway with the specified
IP address. This parameter is used for deleting a license on a DAIP Check
Point Security Gateway.
Note - If this parameter is used, then object name must be a DAIP
gateway.
<signature> The signature string within the license.
Comments This is a
Remote Licensing command
which affects remote machines that is
executed on the Security Management server.
cplic get
Description The cplic get command retrieves all licenses from a Security Gateway (or from
all Security Gateways) into the license repository on the Security Management Server. This
command helps you to synchronize the repository with the Check Point Security Gateways. When
the command is run, all local changes are updated.
Syntax
> cplic get {<ipaddr>|<hostname>|-all} [-v41]
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 35
Parameter Description
<ipaddr> The IP address of the Check Point Security Gateway from which licenses are to
be retrieved.
<hostname> The name of the Check Point Security Gateway object (as defined in
SmartDashboard) from which licenses are to be retrieved.
-all Retrieve licenses from all Check Point gateways in the managed network.
-v41 Retrieve version
4.1 licenses from the NF Check Point gateway. Used to upgrade
version 4.1 licenses.
Example If the Check Point Security Gateway with the object name caruso contains four
Local licenses, and the license repository contains two other Local licenses, the command: cplic
get caruso produces output similar to the following:
Get retrieved 4 licenses.
Get removed 2 licenses.
Comments This is a
Remote Licensing Command
which affects remote machines that is
executed on the Security Management Server.
cplic put
Description Install one or more Local licenses on a local machine.
Syntax
> cplic put [-o|-overwrite] [-c|-check-only] [-s|-select] [-F <output file>]
[-P|-Pre-boot] [-k|-kernel-only] -l <license-file> [<host>] [<expiration
date>] [<signature>] [<SKU/feature>]
Parameter Description
-o|-overwrite On a Security Management server this will erase all existing licenses and
replace them with the new license(s). On a Check Point Security Gateway this
will erase only Local licenses but not Central licenses, that are installed
remotely.
-c|-check-only Verify the license. Checks if the IP of the license matches the machine, and if
the signature is valid
-s|-select Select only the Local licenses whose IP address matches the IP address of
the machine.
-F
<outputfile> Outputs the result of the command to the designated file rather than to the
screen.
-P|-Pre-boot
Use this option after upgrading and before rebooting the machine. Use of this
option will prevent certain error messages.
-K|-kernel-onl
y
Push the current valid licenses to the kernel. For Support use only.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 36
Parameter Description
-l
<license-file> Name of the file that contains the license
<host> Security Management Server hostname or IP address
<expiration-da
te> The license expiration date
<signature> The License signature string. For example:
aa6uwknDc-CE6CRtjhv-zipoVWSnm-z98N7Ck3m (The string is case
sensitive and the hyphens are optional)
<SKU/features
> The SKU of the license summarizes the features included in the license. For
example: CPSUITE-EVAL-3DES-vNG
Comments Copy and paste the following parameters from the license received from the User
Center.
• host - One of the following:
All platforms - The IP address of the external interface (in dot notation); last part cannot be 0 or
255.
Solaris2 - The response to the hostid command (beginning with 0x).
• expiration date - The license expiration date. Can be never.
• signature -The License signature string. For example:
aa6uwknDc-CE6CRtjhv-zipoVWSnm-z98N7Ck3m (Case sensitive. The hyphens are
optional.)
• SKU/features - A string listing the SKU and the Certificate Key of the license. The SKU of
the license summarizes the features included in the license. For example:
CPMP-EVAL-1-3DES-NG CK0123456789ab
Example cplic put -l 215.153.142.130.lic produces output similar to the following:
Host Expiration SKU
215.153.142.130 26Dec2001 CPMP-EVAL-1-3DES-NG CK0123456789ab
cplic put <object name> ...
Description Use the cplic put command to attach one or more central or local license
remotely. When this command is executed, the license repository is also updated.
Syntax
> cplic put <object name> [-ip dynamic ip] [-F <output file>]
-l <license-file> [<host>] [<expiration date>] [<signature>] [<SKU/feature>
Parameter Description
object name The name of the Check Point Security Gateway object, as defined in
SmartDashboard.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 37
Parameter Description
-ip dynamic ip Install the license on the Check Point Security Gateway with the specified
IP address. This parameter is used for installing a license on a DAIP
Check Point gateway.
NOTE: If this parameter is used, then object name must be a DAIP Check
Point gateway.
-F <outputfile> Divert the output to <outputfile> rather than to the screen.
-l
<license-file> Installs the license(s) from <license-file>.
-l
<license-file> Name of the file that contains the license
<host> Security Management Server hostname or IP address
<expiration-date
> The license expiration date
<signature> The License signature string. For example:
aa6uwknDc-CE6CRtjhv-zipoVWSnm-z98N7Ck3m (The string is case
sensitive and the hyphens are optional)
<SKU/features > The SKU of the license summarizes the features included in the license.
For example: CPSUITE-EVAL-3DES-vNG
Comments This is a
Remote Licensing Command
which affects remote machines that is
executed on the Security Management server.
Copy and paste the following parameters from the license received from the User Center. More
than one license can be attached.
• host - the target hostname or IP address.
• expiration date - The license expiration date. Can be never.
• signature -The License signature string. For example:
aa6uwknDc-CE6CRtjhv-zipoVWSnm-z98N7Ck3m (Case sensitive. The hyphens are
optional)
• SKU/features - A string listing the SKU and the Certificate Key of the license. The SKU of
the license summarizes the features included in the license. For example:
CPMP-EVAL-1-3DES-NG CK0123456789ab
cplic print
Description The cplic print command (located in $CPDIR/bin) prints details of Check Point
licenses on the local machine.
Syntax
> cplic print [-n|-noheader][-x prints signatures][-t type][-F <outputfile>]
[-p preatures]
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 38
Parameter Description
-n|-noheader Print licenses with no header.
-x Print licenses with their signature
-t|-type Prints licenses showing their type: Central or Local.
-F
<outputfile> Divert the output to outputfile.
-p|-preatures Print licenses resolved to primitive features.
Comments On a Check Point gateway, this command will print all licenses that are installed on
the local machine — both Local and Central licenses.
cplic upgrade
Description Use the cplic upgrade command to upgrade licenses in the license repository
using licenses in a license file obtained from the User Center.
Syntax
> cplic upgrade –l <inputfile>
Parameter Description
–l <inputfile> Upgrades the licenses in the license repository and Check Point gateways
to match the licenses in <inputfile>
Example The following example explains the procedure which needs to take place in order to
upgrade the licenses in the license repository.
• Upgrade the Security Management Server to the latest version.
Ensure that there is connectivity between the Security Management Server and the
Security Gateways with the previous version products.
• Import all licenses into the license repository. This can also be done
after
upgrading the
products on the remote gateways.
• Run the command: cplic get –all. For example:
Getting licenses from all modules ...
count:root(su) [~] # cplic get -all
golda:
Retrieved 1 licenses.
Detached 0 licenses.
Removed 0 licenses.
count:
Retrieved 1 licenses.
Detached 0 licenses.
Removed 0 licenses.
• To see all the licenses in the repository, run the command cplic db_print -all –a
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 39
count:root(su) [~] # cplic db_print -all -a
Retrieving license information from database ...
The following licenses appear in the database:
==================================================
Host Expiration Features
192.0.2.11 Never CPFW-FIG-25-53 CK-49C3A3CC7121 golda
192.0.2.11 26Nov2012 CPSUITE-EVAL-3DES-NGX CK-1234567890 count
• In the
User Center
http://usercenter.checkpoint.com, view the licenses for the products that
were upgraded from version NGX to a Software Blades license and create new upgraded
licenses.
• Download a file containing the upgraded licenses. Only download licenses for the products that
were upgraded from version NGX to Software Blades.
• If you did not import the version NGX licenses into the repository, import the version NGX
licenses now using the command cplic get -all
• Run the license upgrade command: cplic upgrade –l <inputfile>
- The licenses in the downloaded license file and in the license repository are compared.
- If the certificate keys and features match, the old licenses in the repository and in the
remote Security Gateways are updated with the new licenses.
- A report of the results of the license upgrade is printed.
• In the example, there are two Software Blades licenses in the file. One does not match any
license on a remote Security Gateway, the other matches a version NGX license on a Security
Gateway that should be upgraded:
Comments This is a
Remote Licensing Command
which affects remote Security Gateways, that
is executed on the Security Management Server.
Further Info. For more about managing licenses, see the
R77 Installation and Upgrade Guide
http://supportcontent.checkpoint.com/documentation_download?ID=24831.
cp_merge
Description The cp_merge utility has two main functionalities
• Export and import of policy packages.
• Merge of objects from a given file into the Security Management server database.
Syntax
> cp_merge help
Parameter Description
help Displays the usage for cp_merge.
cp_merge delete_policy
Description Provides the options of deleting an existing policy package. Note that the default
policy can be deleted by delete action.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 40
Syntax
> cp_merge delete_policy [-s <db server>] [-u <user> | -c <certificate file>]
[-p <password>] -n <package name>
Parameter Description
-s <db server> Specify the database server IP Address or DNS name.2
-u <user> The administrator's name.1,2
-c <certificate file>
The path to the certificate file.1
-p <password> The administrator's password.1
-n <policy package
name> The policy package to export.2,3
Comments Further considerations:
1.
Either use certificate file or user and password
2.
Optional
Example Delete the policy package called standard.
> cp_merge delete_policy -n Standard
cp_merge export_policy
Description Provides the options of leaving the policy package in the active repository, or
deleting it as part of the export process. The default policy cannot be deleted during the export
action.
Syntax
> cp_merge export_policy [-s <db server>] [-u <user> | -c <certificate file>]
[-p <password>] [-n <policy package name> | -l <policy name>] [-d <output
directory>] [-f <outputfile>] [-r]
Parameter Description
-s <db server>
Specify the database server IP Address or DNS name.2
-u <user>
The database administrator's name.1
-c <certificate file>
The path to the certificate file.1
-p <password>
The administrator's password.1
-n <policy package name>
The policy package to export.2,3
-l <policy name>
Export the policy package which encloses the policy name.2,3,4
-d <output directory>
Specify the output directory.2
-f <outputfile>
Specify the output file name (where the default file name is
<policy name>.pol).2
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 41
Parameter Description
-r
Remove the original policy from the repository.2
Comments Further considerations:
1. Either use certificate file or user and password.
2. Optional.
3. If both -n and -l are omitted all policy packages are exported.
4. If both -n and -l are present -l is ignored.
Example Export policy package Standard to file:
> cp_merge export_policy -n Standard -f
StandardPolicyPackageBackup.pol -d C:\bak
cp_merge import_policy and cp_merge restore_policy
Description Provides the options to overwrite an existing policy package with the same name,
or preventing overwriting when the same policy name already exists.
Syntax
> cp_merge import_policy|restore_policy [-s <db server>] [-u <user> | -c
<certificate file>] [-p <password>] [-n <package name>] [-d <input
directory>] -f <input file> [-v]
Parameter Description
-s <db server> Specify the database server IP address or DNS name.2
-u <user> The administrator's name.1,2
-c <certificate file>
The path to the certificate file.1
-p <password> The administrator's password.1,2
-n <package name> Rename the policy package to <package name> when importing.2
-d <input directory> Specify the input directory.2
-f <inputfile> Specify the input file name.
-v Override an existing policy if found.2
Comments Further considerations
1. Either use certificate file or user and password
2. Optional
The cp_mergerestore_policy works only locally on the Security Management server and it
will not work from remote machines.
Caution: A Security policy from <policy>.W file can be restored using this utility; however,
important information may be lost when the policy is translated into .W format. This restoration
should be used only if there is no other backup of the policy.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 42
Example Import the policy package saved in file Standard.pol into the repository and
rename it to StandardCopy.
> cp_merge import_policy -f Standard.pol -n StandardCopy
cp_merge list_policy
Syntax
cp_merge list_policy [-s <db server>] [-u <user> | -c <certificate file>]
[-p <password>]
Parameter Description
-s <db server> Specify the database server IP Address or DNS name.2
-u <user> The administrator's name.1,2
-c <certificate file>
The path to the certificate file.1,2
-p <password> The administrator's password.1,2
Comments Further considerations:
1.
Either use certificate file or user and password.
2.
Optional.
Example: List all policy packages which reside in the specified repository:
> cp_merge list_policy -s localhost
cppkg
Description Manage the product repository. It is always executed on the Security Management
server.
cppkg add
Description Add a product package to the product repository. Only SmartUpdate packages can
be added to the product repository.
Products can be added to the Repository as described in the following procedures, by importing a
file downloaded from the Download Center. The package file can be added to the Repository
directly from the DVD or from a local or network drive.
Syntax
> cppkg add {<package-full-path>|<CD drive> [product]}
Parameter Description
package-full-pat
h If the package to be added to the repository is on a local disk or network
drive, type the full path to the package.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 43
Parameter Description
CD drive If the package to be added to the repository is on a DVD:
• For Windows machines type the DVD drive letter, e.g. d:\
• For UNIX machines, type the DVD root path, e.g.
/caruso/image/CPsuite-R77
You are asked to specify the product and appropriate operating system
(OS).
Comments cppkg add does not overwrite existing packages. To overwrite existing packages,
you must first delete existing packages.
Example
[d:\winnt\fw1\ng\bin]cppkg add l:\CPsuite-R77\
Enter package name:
----------------------
(1) SVNfoundation
(2) firewall
(3) floodgate
(4) rtm
(e) Exit
Enter your choice : 1
Enter package OS :
----------------------
(1) win32
(2) linux
(3) ipso
(e) Exit
Enter your choice : 1
You choose to add 'SVNfoundation' for 'win32' OS. Is this correct? [y/n] : y
cppkg delete
Description Delete a product package from the repository. To delete a product package you
must specify a number of options. To see the format of the options and to view the contents of the
product repository, use the cppkg print command.
Syntax
> cppkg delete <vendor> <product> <version> <os> [sp]
Parameter Description
vendor Package vendor (for example, checkpoint)
product Package name
version Package version
os Package Operating System. Options are:
win32, solaris, ipso, linux
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 44
Parameter Description
sp Package minor version
Comments It is not possible to undo the cppkg del command.
cppkg get
Description Synchronizes the Package Repository database with the content of the actual
package repository under $SUROOT.
Syntax
> cppkg get
cppkg getroot
Description Find out the location of the product repository. The default product repository
location on Windows machines is C:\SUroot. On UNIX it is /var/SUroot.
Syntax
> cppkg getroot
Example
> cppkg getroot
Current repository root is set to : /var/suroot/
cppkg print
Description List the contents of the product repository.
Use cppkg print to see the product and OS strings required to install a product package using
the cprinstall command, or to delete a package using the cppkg delete command.
Syntax
> cppkg print
cppkg setroot
Description Create a new repository root directory location, and to move existing product
packages into the new repository.
The default product repository location is created when the Security Management server is
installed. On Windows machines the default location is C:\SUroot and on UNIX it is
/var/SUroot. Use this command to change the default location.
When changing repository root directory:
• The content of the old repository is copied into the new repository.
• The $SUROOT environment variable gets the value of the new root path.
• A product package in the new location will be overwritten by a package in the old location, if
the packages are the same (that is, they have the same ID strings).
The repository root directory should have at least 200 Mbyte of free disk space.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 45
Syntax
> cppkg setroot <repository>
Parameter Description
<repository> The full path for the desired location for the
product repository.
Comments It is important to reboot the Security Management server after performing this
command, in order to set the new $SUROOT environment variable.
Example
cppkg setroot /var/new_suroot
Repository root is set to : /var/new_suroot/
Note: When changing repository root directory :
1. Old repository content will be copied into the new repository.
2. A package in the new location will be overwritten by a package in the old
location, if the packages have the same name.
Change the current repository root ? [y/n] : y
The new repository directory does not exist. Create it ? [y/n] : y
Repository root was set to : /var/new_suroot
Notice : To complete the setting of your directory, reboot the machine!
cpridrestart
Description Stops and starts the Check Point Remote Installation Daemon (cprid). This is the
daemon that is used for remote upgrade and installation of products. In Windows it is a service.
cpridstart
Description Start the Check Point Remote Installation Daemon (cprid). This is the service that
allows for the remote upgrade and installation of products. In Windows it is a service.
Syntax
> cpridstart
cpridstop
Description Stop the Check Point Remote installation Daemon (cprid). This is the service that
allows for the remote upgrade and installation of products. In Windows it is a service.
Syntax
> cpridstop
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 46
cprinstall
Description Use cprinstall commands to perform remote installation of product packages,
and associated operations.
On the Security Management server, cprinstall commands require licenses for SmartUpdate
On the remote Check Point gateways the following are required:
• Trust must be established between the Security Management server and the Check Point
gateway.
• cpd must run.
• cprid remote installation daemon must run.
cprinstall boot
Description Boot the remote computer.
Syntax
> cprinstall boot <object name>
Parameter Description
<object
name> Object name of the Check Point Security Gateway defined in SmartDashboard
Example > cprinstall boot harlin
cprinstall cpstart
Description Enable cpstart to be run remotely.
All products on the Check Point Security Gateway must be of the same version.
Syntax
> cprinstall cpstart <object name>
Parameter Description
Object name Object name of the Check Point Security Gateway defined in SmartDashboard.
cprinstall cpstop
Description Enables cpstop to be run remotely.
All products on the Check Point Security Gateway must be of the same version.
Syntax
> cprinstall cpstop {-proc|-nopolicy} <object name>
Parameter Description
-proc Kills Check Point daemons and Security servers while maintaining the active
Security Policy running in the kernel. Rules with generic allow/reject/drop
rules, based on services continue to work.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 47
Parameter Description
-nopolicy
Object name Object name of the Check Point Security Gateway defined in SmartDashboard.
cprinstall get
Description Obtain details of the products and the operating system installed on the specified
Check Point Security Gateway, and to update the database.
Syntax
> cprinstall get <object name>
Parameter Description
<object name> The name of the Check Point Security Gateway object defined in
SmartDashboard.
Example
cprinstall get gw1
Checking cprid connection...
Verified
Operation completed successfully
Updating machine information...
Update successfully completed
'Get Gateway Data' completed successfully
Operating system Major Version Minor Version
------------------------------------------------------------------------
SecurePlatform R75.20 R75.20
Vendor Product Major Version Minor Version
------------------------------------------------------------------------
Check Point VPN-1 Power/UTM R75.20 R75.20
Check Point SecurePlatform R75.20 R75.20
Check Point SmartPortal R75.20 R75.20
cprinstall install
Description Install Check Point products on remote Check Point Security Gateways. To install a
product package you must specify a number of options. Use the cppkg print command and copy
the required options.
Syntax
> cprinstall install [-boot] <Object name> <vendor> <product> <version> [sp]
Parameter Description
-boot Boot the remote computer after installing the package.
Only boot after ALL products have the same version. Boot will be canceled in
certain scenarios.
Object name Object name of the Check Point Security Gateway defined in SmartDashboard.
vendor Package vendor (e.g. checkpoint)
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 48
Parameter Description
product Package name
version Package version
sp Package minor version
Comments Before transferring any files, this command runs the cprinstall verify
command to verify that the Operating System is appropriate and that the product is compatible
with previously installed products.
Example
# cprinstall install -boot fred checkpoint firewall R70
Installing firewall R75.20 on fred...
Info : Testing Check Point Gateway
Info : Test completed successfully.
Info : Transferring Package to Check Point Gateway
Info : Extracting package on Check Point Gateway
Info : Installing package on Check Point Gateway
Info : Product was successfully applied.
Info : Rebooting the Check Point Gateway
Info : Checking boot status
Info : Reboot completed successfully.
Info : Checking Check Point Gateway
Info : Operation completed successfully.
cprinstall uninstall
Description Uninstall products on remote Check Point Security Gateways. To uninstall a
product package you must specify a number of options. Use the cppkg print command and copy
the required options.
Syntax
> cprinstall uninstall [-boot] <Object name> <vendor> <product> <version>
[sp]
Parameter Description
-boot Boot the remote computer after installing the package.
Only boot after ALL products have the same version. Boot will be canceled in
certain scenarios. See the Release Notes for details.
Object name Object name of the Check Point Security Gateway defined in SmartDashboard.
vendor Package vendor (e.g. checkpoint)
product Package name
version Package version
sp Package minor version.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 49
Comments
Before
uninstalling any files, this command runs the cprinstall verify command
to verify that the Operating System is appropriate and that the product is installed.
After
uninstalling, retrieve the Check Point Security Gateway data by running cprinstall get.
Example
# cprinstall uninstall fred checkpoint firewall R75.20
Uninstalling firewall R75.20 from fred...
Info : Removing package from Check Point Gateway
Info : Product was successfully applied.
Operation Success. Please get network object data to complete the operation.
cprinstall verify
Description Makes sure these operations were successful:
• If a specific product can be installed on the remote Check Point Security Gateway
• That the operating system and currently installed products are appropriate for the package
• That there is enough disk space to install the product
• That there is a CPRID connection
Syntax
> cprinstall verify <Object name> <vendor> <product> <version> [sp]
Parameter Description
Object name Object name of the Check Point Security Gateway defined in SmartDashboard.
vendor Package vendor (for example checkpoint).
product Package name
Options are: SVNfoundation, firewall, floodgate
version Package version.
sp Package minor version. This parameter is optional.
Example The following examples show a successful and a failed verify operation:
Verify succeeds:
cprinstall verify harlin checkpoint SVNfoundation R75.20
Verifying installation of SVNfoundation R75.20 on jimmy...
Info : Testing Check Point Gateway.
Info : Test completed successfully.
Info : Installation Verified, The product can be installed.
Verify fails:
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 50
cprinstall verify harlin checkpoint SVNfoundation R75.20
Verifying installation of SVNfoundation R75.20 on jimmy...
Info : Testing Check Point Gateway
Info : SVN Foundation R70 is already installed on 192.0.2.134
Operation Success. Product cannot be installed, did not pass dependency check.
cprinstall snapshot
Description Creates a snapshot <filename> on the Check Point Security Gateway.
Syntax
> cprinstall snapshot <object name> <filename>
Parameter Description
Object name Object name of the Check Point Security Gateway defined in SmartDashboard
filename Name of the snapshot file
Comments Supported on SecurePlatform only
cprinstall show
Description Displays all snapshot (backup) files on the Check Point Security Gateway.
Syntax
> cprinstall show <object name>
Parameter Description
Object name Object name of the Check Point Security Gateway defined in SmartDashboard.
Comments Supported on SecurePlatform only
Example
# cprinstall show GW1
SU_backup.tzg
cprinstall revert
Description Restores the Check Point Security Gateway from a snapshot.
Syntax
> cprinstall revert <object name> <filename>
Parameter Description
<object
name> Object name of the Check Point Security Gateway defined in SmartDashboard.
<filename> Name of the snapshot file.
Comments Supported on SecurePlatform only.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 51
cprinstall transfer
Description Transfers a package from the repository to a Check Point Security Gateway without
installing the package.
Syntax
> cprinstall transfer <object name> <vendor> <product> <version> [sp]
Parameter Description
Object name Object name of the Check Point Security Gateway defined in SmartDashboard.
vendor Package vendor (for example, checkpoint)
product Package name
version Package version.
sp Package minor version. This parameter is optional.
cpstart
Description Start all Check Point processes and applications running on an appliance or server.
Syntax
> cpstart
Comments This command cannot be used to start cprid. cprid is invoked when the machine
is booted and it runs independently.
cpstat
Description cpstat displays the status of Check Point applications, either on the local or on
another appliance or server, in various formats.
Syntax
> cpstat [-h <host>][-p <port>][-s <SICname>][-f <flavor>][-o <polling>][-c
<count>][-e <period>][-d] <application_flag>
Parameter Description
-h <host> A resolvable hostname, a dot-notation address (for example: 192.0.2.23), or a
DAIP object name. The default is localhost.
-p <port> Port number of the AMON server. The default is the standard AMON port
(18192).
-s <SICname>
Secure Internal Communication (SIC) name of the AMON server.
-f <flavor> The flavor of the output (as it appears in the configuration file). The default is the
first flavor found in the configuration file.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 52
Parameter Description
-o <polling>
Polling interval (seconds) specifies the pace of the results.
The default is 0, meaning the results are shown only once.
-c <count> Specifies how many times the results are shown. The default is 0, meaning the
results are repeatedly shown.
-e <period> Specifies the interval (seconds) over which 'statistical' olds are computed.
Ignored for regular olds.
-d Debug mode.
<applicatio
n_flag> One of the following:
• fw — Firewall component of the Security Gateway
• vpn — VPN component of the Security Gateway
• fg — QoS (formerly FloodGate-1)
• ha — ClusterXL (High Availability)
• os — OS Status
• mg — for the Security Management server
• persistency - for historical status values
• polsrv
• uas
• svr
• cpsemd
• cpsead
• asm
• ls
• ca
The following parameters can be added to the application flags:
• fw — "default", "interfaces", "all", "policy", "perf", "hmem", "kmem",
"inspect",
"cookies", "chains", "fragments", "totals", "ufp", "http", "ftp",
"telnet", "rlogin",
"smtp", "pop3", "sync"
• vpn — "default", "product", "IKE", "ipsec", "traffic", "compression",
"accelerator",
"nic", "statistics", "watermarks", "all"
• fg — "all"
• ha — "default", "all"
• os — "default", "ifconfig", "routing", "memory", "old_memory", "cpu",
"disk", "perf",
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 53
"multi_cpu", "multi_disk", "all", "average_cpu", "average_memory",
"statistics"
• mg — "default"
• persistency — "product", "Tableconfig", "SourceConfig"
• polsrv — "default", "all"
• uas — "default"
• svr — "default"
• cpsemd — "default"
• cpsead — "default"
• asm — "default", "WS"
• ls — "default"
• ca — "default", "crl", "cert", user", "all"
Example
> cpstat fw
Policy name: Standard
Install time: Wed Nov 1 15:25:03 2000
Interface table
-----------------------------------------------------------------
|Name|Dir|Total *|Accept**|Deny|Log|
-----------------------------------------------------------------
|hme0|in |739041*|738990**|51 *|7**|
-----------------------------------------------------------------
|hme0|out|463525*|463525**| 0 *|0**|
-----------------------------------------------------------------
*********|1202566|1202515*|51**|7**|
cpstop
Description Terminate all Check Point processes and applications, running on an appliance or
server.
Syntax
> cpstop
> cpstop -fwflag {-proc|-default}
Parameter Description
-fwflag -proc Kills Check Point daemons and Security servers while maintaining the
active Security Policy running in the kernel. Rules with generic
allow/reject/drop rules, based on services continue to work.
-fwflag -default Kills Check Point daemons and Security servers. The active Security
Policy running in the kernel is replaced with the default filter.
Comments This command cannot be used to terminate cprid. cprid is invoked when the
appliance or server is booted and it runs independently.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 54
cpwd_admin
Description cpwd (also known as WatchDog) is a process that invokes and monitors critical
processes such as Check Point daemons on the local machine, and attempts to restart them if
they fail. Among the processes monitored by Watchdog are cpd, fwd, fwm.
fwd does not work in a Security Management Only machine. To work with fwd in a Security
Management Only machine add -n (for example, fwd -n).
cpwd writes monitoring information to the $CPDIR/log/cpwd.elg log file. In addition,
monitoring information is written to the console on UNIX platforms, and to the Windows Event
Viewer.
The cpwd_admin utility is used to show the status of processes, and to configure cpwd.
Syntax
> cpwd_admin
cpwd_admin start
Description Start a new process by cpwd.
Syntax
> cpwd_admin start -name <process name> -path "<full path>" -command
"<executable name>"
Parameter Description
-name <process name> A name for the process to be watched by WatchDog.
-path "<full path>" The full path to the executable including the executable name
-
command "<executable
name>" The name of the executable file.
Example To start and monitor the fwm process.
> cpwd_admin start -name FWM -path "$FWDIR/bin/fwm" -command "fwm"
cpwd_admin stop
Description Stop a process which is being monitored by cpwd.
Syntax
> cpwd_admin stop -name <process name> [-path <"full path">] [-command
<"executable name">]
Parameter Description
-name <process name> A name for the process to be watched by WatchDog.
-path <"full path"> The full path to the executable (including the executable name) that
is used to stop the process.
-
command <"executable
name"> The name of the executable file mentioned in -path
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 55
Comments If -path and -command are not stipulated, cpwd will abruptly terminate the
process.
Example Stops the FWM process using fw kill
> cpwd_admin stop -name FWM -path "$FWDIR/bin/fw" -command "fw kill fwm"
cpwd_admin list
Description Print a status of the selected processes being monitored by cpwd.
Syntax
> cpwd_admin list
Output The status report output includes the following information:
• APP — Application. The name of the process.
• PID — Process Identification Number.
• STAT — Whether the process Exists (E) or has been Terminated (T).
• #START —How many times the process has been started since cpwd took control of the
process.
• START TIME — The last time the process was run.
• COMMAND — The command that cpwd used to start the process.
For example:
#cpwd_admin list
APP PID STAT #START START_TIME COMMAND
CPD 463 E 1 [20:56:10] 21/5/2001 cpd
FWD 440 E 1 [20:56:24] 21/5/2001 fwd
FWM 467 E 1 [20:56:25] 21/5/2001 fwm
cpwd_admin exist
Description Check whether cpwd is alive.
Syntax
> cpwd_admin exist
cpwd_admin kill
Description Terminate cpwd.
Syntax
> cpwd_admin kill
cpwd_admin config
Description Set cpwd configuration parameters. When parameters are changed, these changes
do not take effect until cpwd has been stopped and restarted.
Syntax
> cpwd_admin config {-p|-a <value=data value=data...>|-d <value
value...>|-r}
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 56
Parameter Description
-p Shows the cpwd parameters added using the config -a option.
-a Add one or more monitoring parameters to the cpwd configuration.
-d Delete one or more parameters from the cpwd configuration
-r Restore the default cpwd parameters.
These are the descriptions of the <value> parameters:
Value Description
timeout
(any value in seconds)
If rerun_mode=1, how much time passes from process failure to rerun.
The default is 60 seconds.
no_limit
(any value in seconds)
Maximum number of times that cpwd will try to restart a process. The
default is 5.
zero_timeout
(any value in seconds)
After failing no_limit times to restart a process, cpwd will wait
zero_timeout seconds before retrying. The default is 7200 seconds.
Should be greater than timeout.
sleep_mode • 1 - wait timeout
• 0 - ignore timeout. Rerun the process immediately
dbg_mode • 1 - Accept pop-up error messages (with exit-code#0) displayed when a
process terminates abruptly (Windows NT only).
• 0 -Do not receive pop-up error messages. This is useful if pop-up
error messages freeze the machine. This is the default (Windows NT
only).
rerun_mode • 1 - Rerun a failed process. This is the default.
• 0 - Do not rerun a failed process. Perform only monitoring.
stop_timeout The time in seconds that the cpwd will wait for a stop command to be
completed. Default is 60 seconds.
reset_startups Indicates the time in seconds that the cpwd waits after the process begins
before it resets the startup_counter. Default value is 1 hour, meaning
that an hour after the process begins its startup counter is reset to 0.
Example The following example shows two configuration parameters being changed:
timeout to 120 seconds, and no_limit to 10.
C:\>cpwd_admin config -p
WD doesn't have configuration parameters
C:\>cpwd_admin config -a timeout=120 no_limit=12
C:\>cpwd_admin config -p
WD Configuration parameters are:
timeout : 120
no_limit : 12cpwd_admin config -a timeout=120 no_limit=10
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 57
config -a and cpwd_adminconfig -d have no effect if cpwd is running. They will affect cpwd
the next time it is run.
disconnect_client
SmartDashboard can connect to a Security Management Server using one of these modes:
• Read/Write - Administrators have full permissions to create or change all objects, settings
and policies.
• Read Only - Administrators can see all objects, settings and policies, but cannot add, change
or delete them.
Only one administrator can use SmartDashboard to connect to a Security Management Server in
the read/write mode at one time. When an administrator connects in the Read/Write mode, this
prevents other administrators from doing these actions:
• Connecting to the same management in the read/write mode
• Creating or changing objects, settings and policies
• Backing up the management server database
• Installing a Security Policy
You can use a special command line utility to disconnect a different SmartDashboard client that is
open in the Read/Write mode.
To remove the database lock, run disconnect_client from the Security Management Server
command line.
For more information, see sk65146 http://supportcontent.checkpoint.com/solutions?id=sk65146
dbedit
Description Edit the objects file on the Security Management server. Editing the objects.C
file on the gateway is not required or desirable, since it will be overwritten the next time a Policy is
installed.
Syntax
> dbedit [-s <server>] [- u <user>|-c <certificate>] [-p <password>] [-f
<filename>] [-r <db-open-reason>] [-help]
Parameter Description
-s server The Security Management server on which the objects_5_0.C file
to be edited is located. If this is not specified in the command line,
then the user will be prompted for it.
If the server is not localhost, the user will be required to
authenticate.
-u user |
-c certificate The user's name (the name used for the SmartConsole) or the full
path to the certificate file.
-p password The user's password (the password used for the SmartConsole).
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 58
Parameter Description
-f filename The name of the file containing the commands. If
filename
is not
given, then the user will be prompted for commands.
-r db-open-reason A non-mandatory flag used to open the database with a string that
states the reason. This reason will be attached to audit logs on
database operations.
-help Print usage and short explanation.
dbedit commands:
Parameter Description
create
[object_type]
[object_name]
Create an object with its default values.
The create command may use an extended (or "owned") object.
Changes are committed to the database only by an update or quit
command.
modify
[table_name]
[object_name]
[field_name] [value]
Modify fields of an object which is:
• stored in the database (the command will lock the object in such
case).
• newly created by dbedit
Extended Formats for owned objects can be used:
For example, [field_name] = Field_A:Field_B
update
[table_name]
[object_name]
Update the database with the object. This command will check the
object validity and will issue an error message if appropriate.
delete
[table_name]
[object_name]
Delete an object from the database and from the client implicit
database.
addelement
[table_name]
[object_name]
[field_name] [value]
Add an element (of type string) to a multiple field.
rmelement
[table_name]
[object_name]
[field_name] [value]
Remove an element (of type string) from a multiple field.
rename
[table_name][object_na
me]
[new_object_name]
Assign a new name for a given object. The operation also performs
an update.
Example:
Rename network object London to Chicago.
rename network_objects london chicago
quit
Quit dbedit and update the database with modified objects not yet
committed.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 59
Example Replace the owned object with a new null object, where NULL is a reserved word
specifying a null object:
modify network_objects my_obj firewall_setting NULL
Example Extended Format
firewall_properties owns the object floodgate_preferences.
floodgate_preferences has a Boolean attribute turn_on_logging, which will be set to
true.
modify properties firewall_properties
floodgate_preferences:turn_on_logging true
comments is a field of the owned object contained in the ordered container. The 0 value indicates
the first element in the container (zero based index).
modify network_objects my_networkObj interfaces:0:comments my_comment
Replace the owned object with a new one with its default values.
modify network_objects my_net_obj interfaces:0:security interface_security
dbver
Description The dbver utility is used to export and import different revisions of the database.
The properties of the revisions (last time created, administrator responsible for, etc) can be
reviewed. The utility can be found in $FWDIR/bin. Run these commands from Expert mode.
Syntax
dbver> export <version_numbers> <delete|keep>
dbver> import <exported_version_in_server>
dbver> create <version_name> <version_comment>
dbver> delete <version_numbers>
dbver> print <version_file_path>
dbver> print_all
dbver create
Description Create a revision from the current state of $fwdir/conf, including current
objects, rule bases, and so on.
Syntax
dbver> create <version_name> <version_comment>
Parameter Description
version_name the name of the revision
version_comment append a comment to the revision
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 60
dbver export
Description Archive the revision as an archive file in the revisions repository:
$fwdir/conf/db_versions/export.
Syntax
dbver> export <version_numbers> <delete|keep>
Parameter Description
<version_numbers>
The file name of the exported version.
<delete|keep>
• delete removes the revision from the revisions repository
•
keep
maintains the revision in the revisions repository
dbver import
Description Add an exported revision to the repository a version from
$fwdir/conf/db_versions/export. Give filename of revision as input.
Syntax
dbver> import <exported_version_in_server>
Parameter Description
<exported_version_in_
server> The file name of the exported version.
dbver print
Description Print the properties of the revision.
Syntax
dbver> print <version_file_path>
Parameter Description
<version_file_
path> The full name and path on the local machine of the revision.
Output
dbver> print c:\rwright_2002-04-01_160810.tar.gz
Version Id: 1
Version Date: Mon Apr 1 16:08:10 2009
Version Name: save
Created by Administrator: jbrown
Major Version: R75.20
Minor Version: R75.20
dbver print_all
Description Print the properties of all revisions to be found on the server side:
$fwdir/conf/db_versions
Syntax
dbver> print_all
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 61
dynamic_objects
Description dynamic_objects specifies an IP address to which the dynamic object will be
resolved on this machine. First, define the dynamic object in the SmartDashboard. Then create the
same object with the CLI (-n parameter). After the new object is created on the gateway with the
CLI, you can use the dynamic_objects command to specify an IP address for the object.
Syntax
# dynamic_objects -o <object_name> [-r <fromIP> <toIP> ...] [-a <fromIP>
<toIP> ...] [-d <fromIP> <toIP> ...] [-l] [-n <object_name>] [-c]
Parameter Description
-o <object_name> The name of the object, as defined in SmartDashboard and the
dynamic_objects -n <name> command.
-r <fromIP> <toIP> ...
Address ranges — one or more "from IP address to IP address"
pairs
-a <fromIP> <toIP> ...
Add ranges to object
-d <fromIP> <toIP> ...
Delete range from object
-l List dynamic objects
-n <object_name> Create new object (if Security Gateway is not running)
-c Compare the objects in the dynamic objects file and in objects.C.
-do object_name Delete object
Example Create a new dynamic object named "bigserver" and add to it the IP address range
192.0.2.1-192.0.2.40: dynamic_objects -n bigserver -r 192.0.2.1 192.0.2.40 -a
fw
Description The fw commands are used for working with various aspects of the firewall. All fw
commands are executed on the Check Point Security Gateway.
Typing fw at the command prompt sends a list of available fw commands to the standard output.
Syntax
> fw
fw -i
Description Generally, when Check Point Security gateway commands are executed on a
Security gateway they will relate to the gateway as a whole, rather than to an individual kernel
instance. For example, the fw tab command will enable viewing or editing of a single table of
information aggregated for all kernel instances.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 62
This command specifies that certain commands apply to an individual kernel instance. By adding
-i <kern> after fw in the command, where <kern> is the kernel instance's number.
Syntax
> fw -i applies to the following commands:
> fw ctl debug (when used without the -buf parameter)
> fw ctl get
> fw ctl set
> fw ctl leak
> fw ctl pstat
> fw monitor
> fw tab
For details and additional parameters for any of these commands, refer to the command's entry.
Example To view the connections table for kernel instance #1 use the following command:
> fw -i 1 tab -t connections
fw ctl
Description The fw ctl command controls the Firewall kernel module.
Syntax
fw ctl {install|uninstall}
fw ctl debug [-m <module>] [+|-] {options | all | 0}
fw ctl debug -buf [buffer size]
fw ctl kdebug
fw ctl pstat [-h][-k][-s][-n][-l]
fw ctl iflist
fw ctl arp [-n]
fw ctl block {on|off}
fw ctl chain
fw ctl conn
Parameter Description
{Install|
Uninstall}
• Uninstall — tells the operating system to stop passing packets to the
Security Gateway, and unloads the Security Policy. The networks behind it
become unprotected.
• Install — tells the operating system to start passing packets to the
Security Gateway. The command fw ctl install runs automatically when
cpstart is performed.
Note - If you run fw ctl uninstall followed by fw ctl install, the
Security Policy is not restored.
debug Generate debug messages to a buffer. See fw ctl debug (on page 63).
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 63
Parameter Description
kdebug Reads the debug buffer and obtains the debug messages. If there is no debug
buffer, the command will fail.
• [-f] read the buffer every second and print the messages, until Ctrl-C is
pressed. Otherwise, read the current buffer contents and end.
• [-t/-T] print the time field (seconds/microseconds)
• [-p] to print specific fields
all|proc|pid|date|mid|type|freq|topic|time|ticks|tid|tex
t|err|host|vsid|cpu
•
[
-m
] - number of cyclic files, [
-s
] - size of each
pstat [-h]
[-k][-s]
[-n][-l]
Displays Security Gateway internal statistics:
-h — Generates additional hmem details.
-k — Generates additional kmem details.
-s — Generates additional smem details.
-n — Generates NDIS information (Windows only).
-l — Generates general Security Gateway statistics.
iflist Displays the IP interfaces known to the kernel, by name and internal number.
arp [-n] Displays ARP proxy table.
-n — Do not perform name resolution.
block
{on|off} on — Blocks all traffic.
off — Restores traffic and the Security Policy.
chain Prints the names of internal Security Gateways that deal with packets. Use to
ensure that a gateway is loaded. The names of these gateways can be used in
the fw monitor -p command.
conn Prints the names of the connection modules.
fw ctl debug
Description Generate debug messages to a buffer.
Syntax A number of debug options are available:
fw ctl debug -buf [buffer size]
fw ctl debug [-m <module>] [+ | -] {options|all|0}
fw ctl debug 0
fw ctl debug [-d <comma separated list of strings>]
fw ctl debug [-d <comma separated list of ^strings>]
fw ctl debug [-s <string>]
fw ctl debug -h
fw ctl debug -x
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 64
Parameter Description
-buf [buffer size]
Allocates a buffer of size kilobytes (default 128) and starts collecting
messages there. If the -buf argument is not set, the debug
messages are printed to the console.
-m <module> Specify the Security Gateway module you wish to debug. The default
module is fw.
For example: fw ctl debug –m VPN all
[+ | -]
<options|all|0> Sets or resets debug flags for the requested gateway).
• If + is used, the specified flags are set, and the rest remain as
they were.
• If - is used, the specified flags are reset, and the rest remain as
they were.
• If neither + nor - are used, the specified flags are set and the
rest are reset.
-h Print a list of debug modules and flags.
0
Returns all flags in all gateways to their default values, releases the
debug buffer (if there was one).
-d <comma separated
list of strings> Only lines containing these strings are included in the output.
(Available in R70 or higher)
-d <comma separated
list of ^strings> Lines containing these strings are omitted from the output
(Available in R70 or higher)
For example:
fw ctl debug –d error,failed,^packet
Output shows only lines containing the words "error" or "failed" and
not the word "packet"
-s <string> Stop debug messages when a certain string is issues (Available in
R70 or higher)
For example: fw ctl debug –s error
-x Shuts down the debug.
fw ctl affinity
fw ctl affinity -s
Description Sets CoreXL affinities when using multiple processors. For an explanation of
kernel, daemon and interface affinities, see the
R77 Performance Tuning Administration Guide
http://supportcontent.checkpoint.com/documentation_download?ID=24808.
fw ctl affinity -s settings are not persistent through a restart of the Security Gateway. If you
want the settings to be persistent, either use:
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 65
• sim affinity (a Performance Pack command)
• Or edit the fwaffinity.conf configuration file
To set interface affinities, you should use fw ctl affinity only if Performance Pack is not
running. If Performance Pack is running, you should set affinities by using the Performance Pack
sim affinity command. These settings will be persistent. If Performance Pack's sim
affinity is set to Automatic mode (even if Performance Pack was subsequently disabled), you
will not be able to set interface affinities by using fw ctl affinity -s.
Note - The fw ctl affinity command is different for a VSX Gateway and a
Security Gateway:
VSX Gateway - Use the -d parameter to save the CoreXL affinity settings after
you reboot it
• Security Gateway -
The CoreXL affinity settings are not saved after you reboot
it
Syntax
> fw ctl affinity -s <proc_selection> <cpuid>
<proc_selection> is one of the following parameters:
Parameter
Description
-p <pid> Sets affinity for a particular process, where <pid> is the process ID#.
-n <cpdname> Sets affinity for a Check Point daemon, where <cpdname> is the Check
Point daemon name (for example: fwd).
-k <instance> Sets affinity for a kernel instance, where <instance> is the instance's
number.
-i
<interfacename> Sets affinity for an interface, where <interfacename> is the interface
name (for example: eth0).
<cpuid> should be a processing core number or a list of processing core numbers. To have no
affinity to any specific processing core, <cpuid> should be: all.
Note - Setting an Interface Affinity will set the affinities of all interfaces sharing the
same IRQ to the same processing core. To view the IRQs of all interfaces, run:
fw ctl
affinity -l -v -a .
Example To set kernel instance #3 to run on processing core #5, run:
> fw ctl affinity -s -k 3 5
fw ctl affinity -l
Description Lists existing CoreXL affinities when using multiple processors. For an explanation
of kernel, daemon and interface affinities, see the
R77 Performance Tuning Administration Guide
http://supportcontent.checkpoint.com/documentation_download?ID=24808.
Syntax
> fw ctl affinity -l [<proc_selection>] [<listtype>]
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 66
If <proc_selection> is omitted, fw ctl affinity -l lists affinities of all Check Point
daemons, kernel instances and interfaces. Otherwise, <proc_selection> is one of the
following parameters:
Parameter
Description
-p <pid> Displays the affinity of a particular process, where <pid> is the
process ID#.
-n <cpdname> Displays the affinity of a Check Point daemon, where <cpdname> is the
Check Point daemon name (for example: fwd).
-k <instance> Displays the affinity of a kernel instance, where <instance> is the
instance's number.
-i <interfacename> Displays the affinity of an interface, where <interfacename> is the
interface name (for example: eth0).
If <listtype> is omitted, fw ctl affinity -l lists items with specific affinities, and their
affinities. Otherwise, <listtype> is one or more of the following parameters:
Parameter
Description
-a All: includes items without specific affinities.
-r Reverse: lists each processing core and the items that have it as their
affinity.
-v Verbose: list includes additional information.
Example To list complete affinity information for all Check Point daemons, kernel instances
and interfaces, including items without specific affinities, and with additional information, run:
> fw ctl affinity -l -a -v
fw ctl engine
Description Enables the INSPECT2C engine, which dynamically converts INSPECT code to C
code.
Run the command on the Check Point Security Gateway.
Syntax
> fw ctl engine {on|off|stat|setdefault}
Parameter Description
on Compile the engine if necessary, and activate it.
Because the engine may not have been previously compiled, turning the engine
ON may not activate it immediately. Instead, the engine is activated in the
background after the compilation.
After turning the engine ON, the engine recompiles and reactivates itself every
policy installation regardless of the values of inspect2c_compile and
inspect2c_activate.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 67
Parameter Description
off Deactivates the engine if active. Subsequent policy installation on the gateway
does NOT auto-activate the engine unless the command is used again.
stat Print the status of the engine. For example: "During compilation", "Before
auto-activation", "Deactivated".
setdefault Restore control to database settings. Security Management server settings are
ignored.
At the next policy installation, return the control of the engine to the values of
the following gateway database attributes:
• inspect2c_compile (true/false) - controls whether or not the engine is
compiled on the gateway during policy installation. Compilation is performed
in the background and may take a few minutes.
• inspect2c_activate (true/false) - controls whether the engine is
automatically activated after it is compiled. When set to true, the engine is
compiled regardless of the value of inspect2c_compile.
Use GuiDBEdit to change the values of the attributes.
fw ctl multik stat
Description Displays multi-kernel statistics for each kernel instance. The state and processing
core number of each instance is displayed, along with:
• The number of connections currently being handled
• The peak number of concurrent connections the instance has handled since its inception
fw ctl sdstat
Description The IPS performance counters measure the percentage of CPU consumed by each
IPS protection. The measurement itself is divided according to the type of protection: Pattern
based protections or INSPECT based protections. In addition, the IPS counters measure the
percentage of CPU used by each section ("context") of the protocol, and each protocol parser.
Syntax
> fw ctl zdebug >& outputfile
> fw ctl sdstat start
> fw ctl sdstat stop
Parameter Description
fw ctl zdebug >&
outputfile Turn on debug mode and specify an output file.
fw ctl sdstat start Activate the IPS counters
fw ctl sdstat stop Print a report and stop the counters.
Example The workflow is as follows:
Run the following commands on the Check Point Security Gateway (version R70 or higher):
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 68
On the Check Point Security Gateway:
• Run fw ctl zdebug >& outputfile
• Run fw ctl sdstat start
Let the counters run. However- do not leave the counters on for more than 10 minutes.
• Run fw ctl sdstat stop
It is important to stop the counters explicitly, otherwise there may be performance penalty
This generates the output file outputfile that must be processed on the (SecurePlatform only)
Security Management Server.
On the Security Management Server:
• From $FWDIR/script, run the script
./sdstat_analyse.csh outputfile
The output of the script is a report in csv format that can be viewed in Microsoft Excel.
If there is a problem in the report, or if more details are needed, a debug flag is available which
prints extra information to outputfile.
• Run fw ctl zdebug + spii >& outputfile
Example Debug Message Explanation
sdstat_get_stats_all_ins
tances : Smart Defense
report objects are not
initalized, hence no
report can be done.
User tried to create a report without initializing the counters,
or an error occurred during initialization and the user then
tried to print a report.
FW-1 -
sdstats_print_report:
Failed to calculate Smart
Defense
(total_smart_defense is
0)
The measurement process failed and the total time units for
IPS is zero.
Comments
1.
A value in the report of "< 1" means that the percentage of CPU used by a protection is less
than 1%.
2.
The report generated by the sdstat_analyse script may contain a number instead of a
protection name. This is because the original output contains a signature id, but the id is
missing from the Security Policy on the Gateway.
fw fetch
Description Fetches the Inspection Code from the specified host and installs it to the kernel.
Syntax
> fw fetch [-n] [-f <filename>] [-c] [-i] master1 [master2] ...
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 69
Parameter Description
-n Fetch the Security Policy from the Security Management server to the
local state directory, and install the Policy only if the fetched Policy is
different from the Policy already installed.
-f <filename> Fetch the Security Policy from the Security Management server listed in
<filename>. If filename is not specified, the list in
conf/masters is used.
-c Cluster mode, get policy from one of the cluster members, from the
Check Point High Availability (CPHA) kernel list.
-i Ignore SIC information (for example, SIC name) in the database and use
the information in conf/masters. This option is used when a Security
Policy is fetched for the first time by a DAIP gateway from a Security
Management server with a changed SIC name.
master1 Execute command on the designated master.
The IP address of the Security Management Server from which to fetch
the Policy. You can specify one or more servers, which will be searched in
the order listed.
If no targets is not specified, or if targets is inaccessible, the Policy is
fetched from localhost.
fw fetchlogs
Description fw fetchlogs fetches Log Files from a remote machine. You can use the fw
fetchlogs command to transfer Log Files to the machine on which the fw fetchlogs
command is executed. The Log Files are read from and written to the directory $FWDIR/log.
Syntax
> fw fetchlogs [[-f <file name>] ... ] <module>
Parameter Description
-f
<filename> The Log Files to be transferred. The file name can include wildcards. In
Solaris, any file containing wildcards should be enclosed in quotes.
The default parameter is *.log.
Related pointer files will automatically be fetched.
<module> The name of the remote machine from where you transfer the Log Files.
Comments The files transferred by the fw fetchlogs command are MOVED from the source
machine to the target machine. This means that they are deleted from the source machine once
they have been successfully copied.
Fetching Current Log Data
The active Log File (fw.log) cannot be fetched. If you want to fetch the most recent log data,
proceed as follows:
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 70
• Run
\
to close the currently active Log File and open a new one.
• Run fw lslogs to see the newly-generated file name.
• Run fw fetchlogs -f
filename
to transfer the file to the machine on which the fw
fetchlogs command is executed. The file is now available for viewing in the SmartView
Tracker.
After a file has been fetched, it is renamed. The gateway name and the original Log File name are
concatenated to create a new file name. The new file name consists of the gateway name and the
original file name separated by two (underscore) _ _ characters.
Example The following command:
> fw fetchlogs -f 2001-12-31_123414.log module3
fetches the Log File 2001-12-31_123414.log from Module3.
After the file has been fetched, the Log File is renamed:
module3_ _2001-12-31_123414.log
fw hastat
Description The fw hastat command displays information about High Availability machines
and their states.
Syntax
> fw hastat [<target>]
Parameter Description
<target> A list of machines whose status will be displayed. If target is not specified, the
status of the local machine will be displayed.
fw isp_link
Description Takes down (or up) a redundant ISP link.
Syntax
> fw isp_link [<target>] <link-name> {up|down}
Parameter Description
target The name of the Check Point Security Gateway.
link-name The name of the ISP link as defined in the ISP-redundancy tab.
Comments This command can be executed locally on the Check Point Security Gateway or
remotely from the Security Management server. In the latter case, the target argument must be
supplied. For this command to work, the Check Point Security Gateway should be using the ISP
redundancy feature.
fw kill
Description Prompts the kernel to shut down all firewall daemon processes. The command is
located in the $FWDIR/bin directory on the Security Management server or gateway machine.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 71
The firewall daemons and Security servers write their pids to files in the $FWDIR/tmp
directory upon startup. These files are named $FWDIR/tmp/daemon_name.pid. For
example, the file containing the pid of the firewall snmp daemon is: $FWDIR/tmp/snmpd.pid.
Syntax
> fw kill [-t <sig_no>] <proc-name>
Parameter Description
-t <sig_no> This Unix only command specifies that if the file
$FWDIR/tmp/proc-name.pid exists, send signal sig_no to the pid given
in the file.
If no signal is specified, signal 15 (sigterm or the terminate command) is sent.
<proc-name> Prompt the kernel to shut down specified firewall daemon processes.
Comments In Windows, only the default syntax is supported: fw kill proc_name. If the -t
option is used it is ignored.
fw lea_notify
Description Send a LEA_COL_LOGS event to all connected lea clients, see the
LEA Specification
documentation. It should be used after new log files have been imported (manually or
automatically) to the $FWDIR/log directory in order to avoid the scheduled update which takes 30
minutes.
This command should be run from the Security Management server.
Syntax
> fw lea_notify
fw lichosts
Description Print a list of hosts protected by Security Gateway products. The list of hosts is in
the file $fwdir/database/fwd.h
Syntax
> fw lichosts [-x] [-l]
Parameter Description
-x Use hexadecimal format
-l Use long format
fw log
Description fw log displays the content of Log files.
Syntax
> fw log [-f [-t]] [-n] [-l] [-o] [-c <action>] [-h <host>] [-s <starttime>]
[-e <endtime>] [-b <starttime> <endtime>] [-u <unification_scheme_file>] [-m
{initial|semi|raw}] [-a] [-k {alert_name|all}] [-g] [logfile]
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 72
Parameter Description
-f [-t]
After reaching the end of the currently displayed file, do not exit (the
default behavior), but continue to monitor the Log file indefinitely
and display it while it is being written.
The -t parameter indicates that the display is to begin at the end of
the file, in other words, the display will initially be empty and only
new records added later will be displayed.
-t must come with a -f
flag. These flags are relevant only for active
files.
-n Do not perform DNS resolution of the IP addresses in the Log file
(the default behavior). This option significantly speeds up the
processing.
-l
Display both the date and the time for each log record (the default is
to show the date only once above the relevant records, and then
specify the time per log record).
-o Show detailed log chains (all the log segments a log record consists
of).
-c <action> Display only events whose action is action, that is, accept, drop,
reject, authorize, deauthorize, encrypt and decrypt.
Control actions are always displayed.
-h <host> Display only log whose origin is the specified IP address or name.
-s <starttime> Display only events that were logged after the specified time (see
time format below). starttime may be a date, a time, or both. If
date is omitted, then today's date is assumed.
-e <endtime> Display only events that were logged before the specified time (see
time format below). endtime may be a date, a time, or both.
-b <starttime>
<endtime>
Display only events that were logged between the specified start and
end times (see time format below), each of which may be a date, a
time, or both. If date is omitted, then today's date is assumed. The
start and end times are expected after the flag.
-u
<unification_scheme
_file>
Unification scheme file name.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 73
Parameter Description
-m This flag specifies the unification mode.
• initial - the default mode, specifying complete unification of
log records; that is, output one unified record for each id. This is
the default.
When used together with -f, no updates will be displayed, but
only entries relating to the start of new connections. To display
updates, use the semi parameter.
• semi - step-by-step unification, that is, for each log record,
output a record that unifies this record with all
previously-encountered records with the same id.
•
raw
- output all records, with no unification.
-a Output account log records only.
-k {<alert_name>|all}
Display only events that match a specific alert type. The default is
all, for any alert type.
-g Do not use a delimited style. The default is:
• : after field name
•
;
after field value
logfile Use logfile instead of the default Log file. The default Log File is
$FWDIR/log/fw.log.
Where the full date and time format is: MMM DD, YYYY HH:MM:SS. For example: May 26, 1999
14:20:00
It is possible to specify date only in the format MMM DD, YYYY, or time only, in the format:
HH:MM:SS, where time only is specified, the current date is assumed.
Example
> fw log
> fw log | more
> fw log -c reject
> fw log -s "May 26, 1999"
> fw log -f -s 16:00:00
Output [<date>] <time> <action> <origin> <interface dir and name> [alert]
[field name: field value;] ...
Each output line consists of a single log record, whose fields appear in the format shown above.
Example Output
14:56:39 reject jam.checkpoint.com >daemon alert src: veredr.checkpoint.com;
dst: jam.checkpoint.com; user: a; rule: 0; reason: Client Encryption: Access
denied - wrong user name or password ; scheme: IKE; reject_category:
Authentication error; product: Security Gateway
14:57:49 authcrypt jam.checkpoint.com >daemon src: veredr.checkpoint.com;
user: a; rule: 0; reason: Client Encryption: Authenticated by Internal
Password; scheme: IKE; methods: AES-256,IKE,SHA1; product: Security Gateway;
14:57:49 keyinst jam.checkpoint.com >daemon src: veredr.checkpoint.com;
peer gateway: veredr.checkpoint.com; scheme: IKE; IKE: Main Mode completion.;
CookieI: 32f09ca38aeaf4a3; CookieR: 73b91d59b378958c; msgid: 47ad4a8d; methods:
AES-256 + SHA1, Internal Password; user: a; product: Security Gateway;
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 74
fw logswitch
Description fw logswitch creates a new active Log File. The current active Log File is closed
and renamed by default $FWDIR/log/<current_time_stamp>.log unless you define an
alternative name that is unique. The format of the default name <current_time_stamp>.log
is YYYY-MM-DD_HHMMSS.log. For example: 2003-03-26_041200.log
Warning:
• The Logswitch operation fails if a log file is given a pre-existing file name.
• The rename operation fails on Windows if the active log that is being renamed, is open at the
same time that the rename operation is taking place; however; the Logswitch will succeed and
the file will be given the default name $FWDIR/log/current_time_stamp.log.
The new Log File that is created is given the default name $FWDIR/log/fw.log. Old Log Files
are located in the same directory.
A Security Management server can use fw logswitch to change a Log File on a remote machine
and transfer the Log File to the Security Management server. This same operation can be
performed for a remote machine using fw lslogs (on page 75) and fw fetchlogs (on page 69).
When a log file is sent to the Security Management server, the data is compressed.
Syntax
> fw logswitch [-audit] [<filename>]
> fw logswitch -h <hostage> [+|-][<filename>]
Parameter Description
-audit Does logswitch for the Security Management server audit file. This is relevant
for local activation.
<filename> The name of the file to which the log is saved. If no name is specified, a default
name is provided.
-h <hostage>
The resolvable name or IP address of the remote machine (running either a
Security Gateway or a Security Management server) on which the Log File is
located. The Security Management server (on which the fw logswitch
command is executed) must be defined as one of host's Security Management
servers. In addition, you must initialize SIC between the Security Management
server and the host.
+ Change a remote log and copy it to the local machine.
- Change a remote log and move it to the local machine thereby deleting the log
from the remote machine.
Comments Files are created in the $FWDIR/log directory on both host and the Security
Management server when the + or - parameters are specified. Note that if - is specified, the Log
File on the host is deleted rather than renamed.
hostage specified:
• filename specified - On hostage, the old Log File is renamed to old_log. On the Security
Management Server, the copied file will have the same name, prefixed by hostages name.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 75
For example, the command fw logswitch -h venus +xyz creates a file named
venus_xyz.log on the Security Management Server.
• filename not specified - On hostage, the new name is
the current date, for example: 2003-03-26_041200.log.
On the Security Management Server, the copied file will have the same name, but prefixed by
hostage_. For example, target_2003-03-26_041200.log.
hostage not specified:
• filename specified - On the Security Management Server, the old Log File is renamed to
old_log.
• filename not specified - On the Security Management Server, the old Log File is renamed to
the current date.
Compression
When log files are transmitted from one machine to another, they are compressed using the zlib
package, a standard package used in the Unix gzip command (see RFC 1950 to RFC 1952 for
details). The algorithm is a variation of LZ77 method.
The compression ratio varies with the content of the log records and is difficult to predict. Binary
data are not compressed, but string data such as user names and URLs are compressed.
fw lslogs
Description Display a list of Log Files residing on a remote or local machine. You must initialize
SIC between the Security Management server and the remote machine.
Syntax
> fw lslogs [[-f <filename>] ...] [-e] [-s {<name>|<size>|<stime>|<etime>}]
[-r] [<machine>]
Parameter Description
-f <filename> The list of files to be displayed. The file name can include wildcards. In
Unix, any file containing wildcards should be enclosed in quotes.
The default parameter is *.log.
-e Display an extended file list. It includes the following data:
• Size - The size of the file and its related pointer files together.
• Creation Time - The time the Log File was created.
• Closing Time - The time the Log File was closed.
•
Log File Name
- The file name.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 76
Parameter Description
-s Specify the sort order of the Log Files using one of the following sort
options:
• name - The file name.
• size - The file size.
• stime - The time the Log File was created.
• etime - The time the Log File was closed.
The default is stime.
-r Reverse the sort order (descending order).
<machine> The name of the machine on which the files are located. It can be a
gateway or a Log Server. The default is localhost.
Example This example shows the extended file list you see when you use the fw lslogs -e
command:
> fw lslogs -e module3
Size Creation Time Closing Time Log file name
99KB 10Jan2002 16:46:27 10Jan2002 18:36:05 2002-01-10_183752.log
16KB 10Jan2002 18:36:05 -- fw.log
fw mergefiles
Description Merge several Log Files into a single Log File. The merged file can be sorted
according to the creation time of the Log entries, and the times can be "fixed" according to the
time zones of the origin Log servers.
Logs entries with the same Unique-ID are unified. If a Log switch was performed before all the
segments of a specific log were received, this command will merge the records with the same
Unique-ID from two different files, into one fully detailed record.
Syntax
> fw mergefiles [-s] [-t <time_conversion_file>] <log_file_name_1> [...
<log_file_name_n>] <output_file>
Parameter Description
-s Sort merged file by log records time field.
-t
<time_conversion_fil
e>
Fix different GMT zone log records time in
the event that the log files
originated from Log Servers in different time zone.
The time_conversion_file format is as follows:
ip-address signed_date_time_in_seconds
ip-address signed_date_time_in_seconds
<log_file_name_n>
Full pathnames
of the Log File(s).
<output_file> Full pathname of the output Log File.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 77
Comments It is not recommended to merge the current active fw.log file with other Log
Files. Instead, run the fw logswitch command and then run fw mergefiles.
fw monitor
Description Inspecting network traffic is an essential part of troubleshooting network
deployments. fw monitor is a powerful built-in tool to simplify the task of capturing network
packets at multiple capture points within the firewall chain. These packets can be inspected using
industry-standard tools later on.
In many deployment and support scenarios capturing network packets is an essential
functionality. tcpdump or snoop are tools normally used for this task. fw monitor provides an
even better functionality but omits many requirements and risks of these tools.
•
No Security Flaws
— tcpdump and snoop are normally used with network interface cards in
promiscuous mode. Unfortunately the promiscuous mode allows remote attacks against these
tools. fw monitor does not use the promiscuous mode to capture packets. In addition most
firewall operating systems are hardened. In most cases this hardening includes the removal of
tools like tcpdump or snoop because of their security risk.
•
Available on all Security Gateway installations
— fw monitor is a built-in firewall tool which
needs no separate installation in case capturing packets is needed. It is a functionality
provided with the installation of the Firewall package.
•
Multiple capture positions within the firewall kernel module chain
— fw monitor allows you
to capture packets at multiple capture positions within the firewall kernel module chain; both
for inbound and outbound packets. This enables you to trace a packet through the different
functionalities of the Firewall.
•
Same tool and syntax on all platforms
— Another important fact is the availability of fw
monitor on different platforms. Tools like snoop or tcpdump are often platform dependent or
have specific "enhancements" on certain platforms. fw monitor and all its related
functionality and syntax is absolutely identical across all platforms. There is no need to learn
any new "tricks" on an unknown platform.
Normally the Check Point kernel modules are used to perform several functions on packets (like
filtering, encrypting and decrypting, QoS …). fw monitor adds its own modules to capture
packets. Therefore fw monitor can capture all packets which are seen and/or forwarded by the
Firewall.
Only one instance of fw monitor can be run at a time.
Use ^C (that is Control + C) to stop fw monitor from capturing packets.
Syntax
> fw monitor [-u|s] [-i] [-d] [-D] [{-e <expr>|{-f <filter-file>|-}}] [-l
<len>] [-m <mask>]
[-x <offset>[,<len>]] [-o <file>] [[-pi <pos>] [-pI <pos>] [-po <pos>] [-pO
<pos>] | -p all]] [-a]
[-ci <count>] [-co <count>] [-h] -T
Parameter Description
-u|s Printing the UUID or the SUUID: The option –u or –s is used to print
UUIDs or SUUIDs for every packet. Please note that it is only
possible to print the UUID or the SUUID – not both.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 78
Parameter Description
-i Flushing the standard output: Use to make sure that captured data
for each packet is at once written to standard output. This is
especially useful if you want to kill a running fw monitor process and
want to be sure that all data is written to a file.
[-d] [-D] Debugging fw monitor: The -d option is used to start fw monitor in
debug mode. This will give you an insight into fw monitor's inner
workings. This option is only rarely used outside Check Point. It is
also possible to use –D to create an even more verbose output.
{-e <expr>|{-f
<filter-file>|-}} Filtering fw monitor packets: fw monitor
has the ability to capture
only packets in which you are interested. fw monitor filters use a
subset of INSPECT to specify the packets to be captured. Set the
filter expression:
• on the command line using the –e switch.
• by reading it from a file using the -f switch.
•
by reading it from standard input using the -f - switch.
-l <len> Limiting the packet length: fw monitor lets you limit the packet
data which will be read from the kernel with -l. This is especially
useful if you have to debug high sensitive communication. It lets you
to capture only the headers of a packet (e.g. IP and TCP header)
while omitting the actual payload. Therefore you can debug the
communication without seeing the actual data transmitted. Another
possibility is to keep the amount of data low. If you don't need the
actual payload for debugging you can decrease the file site by
omitting the payload. It's also very useful to reduce packet loss on
high-loaded machines. fw monitor uses a buffer to transfer the
packets from kernel to user space. If you reduce the size of a single
packet this buffer won't fill up so fast.
-m <mask> Setting capture masks: By default fw monitor captures packets
before and after the virtual machine in both directions. These
positions can be changed. This option allows you to specify in which
of the four positions you are interested.
-x <offset>[,<len>] Printing packet/payload data: In addition to the IP and Transport
header fw monitor can also print the packets' raw data using the –
x option. Optionally it is also possible to send all data that is written
only to the screen the data written.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 79
Parameter Description
-o <file> Write output to file: Save the raw packet data to a file in a standard
(RFC 1761) format. The file can be examined using by tools like
snoop, tcpdump or Ethereal.
Note - The snoop file format is normally used to store Layer 2
frames. For "normal" capture files this means that the frame
includes data like a source and a destination MAC address. fw
monitor operates in the firewall kernel and therefore has no
access to Layer
2 information like MAC addresses. Instead of writing
random MAC addresses, fw monitor includes information like
interface name, direction and chain position as "MAC addresses".
-T Print time stamp in microseconds. -T is needed only when -o is not
used. When -o is used the exact time is written to the snoop file by
default as of Corsica.
[[-pi <pos>] [-pI
<pos>] [-po <pos>]
[-pO <pos>] | -p all]]
Insert fw monitor chain module at a specific position: In addition to
capture masks (which give the ability to look at packets in a specific
position) fw monitor has the ability to define where exactly in the
firewall chain the packets should be captured. This can be defined
using these options.
-a Use absolute chain positions: If you use fw monitor to output the
capture into a file (option –o), one of the fields written down to the
capture file is the chain position of the fw monitor chain module.
Together with a simultaneous execution of fw ctl chain you can
determine where the packet was captured. Especially when using –
p all you will find the same packet captured multiples times at
different chain positions. The option –a
changes the chain ID from a
relative value (which only makes sense with the matching fw ctl
chain output) to an absolute value. These absolute values are known
to CPEthereal and can be displayed by it.
[-ci <count>]
[-co <count>] Capture a specific number of packets: fw monitor enables you to
limit the number of packets being captured. This is especially useful
in situations where the firewall is filtering high amounts of traffic. In
such situations fw monitor may bind so many resources (for
writing to the console or to a file) that recognizing the break
sequence (Control-C) might take very long.
-h Displays the usage.
Example The easiest way to use fw monitor is to invoke it without any parameter. This will
output every packet from every interface that passes (or at least reaches) the Check Point Security
Gateway. The same packet appears several times (two times in the example below). This is caused
by fw monitor capturing the packets at different capture points.
Output
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 80
cpmodule> fw monitor
monitor: getting filter (from command line)
monitor: compiling
monitorfilter:
Compiled OK.
monitor: loading
monitor: monitoring (control-C to stop)
eth0:i[285]: 192.0.2.133 -> 192.0.2.2 (TCP) len=285 id=1075
TCP: 1050 -> 18190 ...PA. seq=bf8bc98e ack=941b05bc
eth0:I[285]: 192.0.2.133 -> 192.0.2.2 (TCP) len=285 id=1075
TCP: 1050 -> 18190 ...PA. seq=bf8bc98e ack=941b05bc
eth0:o[197]: 192.0.2.2 -> 192.0.2.133 (TCP) len=197 id=44599
TCP: 18190 -> 1050 ...PA. seq=941b05bc ack=bf8bca83
eth0:O[197]: 192.0.2.2 -> 192.0.2.133 (TCP) len=197 id=44599
TCP: 18190 -> 1050 ...PA. seq=941b05bc ack=bf8bca83
eth0:o[1500]: 192.0.2.2 -> 192.0.2.133 (TCP) len=1500 id=44600
TCP
^C
: 18190 -> 1050 ....A. seq=941b0659 ack=bf8bca83
monitor: caught sig 2
monitor: unloading
The first line of the fw monitor output is
eth0:i[285]: 192.0.2.133 -> 192.0.2.2 (TCP) len=285 id=1075
This packet was captured on the first network interface (eth0) in inbound direction before the
virtual machine (lowercase i). The packet length is 285 bytes (in square parenthesis; repeated at
the end of the line. Note that these two values may be different. The packets ID is 1075. The packet
was sent from 192.0.2.133 to 192.0.2.2 and carries a TCP header/payload.
The second line of the fw monitor output is
TCP: 1050 -> 18190 ...PA. seq=bf8bc98e ack=941b05bc
The second line tells us that this is a TCP payload inside the IP packet which was sent from port
1050 to port 18190. The following element displays the TCP flags set (in this case PUSH and ACK).
The last two elements are showing the sequence number (seq=bf8bc98e) of the TCP packet and
the acknowledged sequence number (ack=941b05bc). You will see similar information for UDP
packets.
You will only see a second line if the transport protocol used is known to fw monitor. Known
protocols are for example TCP, UDP and ICMP. If the transport protocol is unknown or cannot be
analyzed because it is encrypted (e.g. ESP or encapsulated (e.g. GRE) the second line is missing.
Further Info. See SecureKnowledge solution sk30583
http://supportcontent.checkpoint.com/solutions?id=sk30583.
fw monitor Filters
Description Use these expressions to help when you are filtering fw monitor.
Syntax > fw monitor -e "accept <expression>;"
Expressions for Protocols
Expression Description
tcp TCP
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 81
Expression Description
udp UDP
icmp4 ICMP v4
icmp6 ICMP v6
esp ESP
Expressions for Services
Expression Description
http HTTP (TCP port 80)
https HTTPS (TCP port 443)
ftp FTP (TCP port 20 or 21)
ssh SSH (TCP port 22)
telnet TELNET (TCP port 23)
smtp SMTP (TCP Port 25)
pop3 POP3 (TCP port 110)
dns DNS (TCP / UDP port 53
proxy HTTP (TCP port 8080)
Expressions for VPN
For more information, see sk52421 http://supportcontent.checkpoint.com/solutions?id=sk52421.
Expression Description Check Point Description
ike IKE (UDP port 500)
natt NAT-T (UDP port 4500)
uenc UDP encapsulation (UDP port
2746)
Check Point SecuRemote IPsec
Transport Encapsulation Protocol
rdp Check Point RDP (UDP port 259) Proprietary Check Point "Reliable Data
Protocol" (does not comply with RDP as
specified in RFC 908/RFC 1151)
topo Check Point Security Gateway
SecuRemote Topology Requests
(TCP port 264)
Topology Download from Security
Gateway (by FWD daemon) to
SecuRemote (build 4100 and higher) and
SecureClient
l2tp L2TP (TCP port 1701)
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 82
Expression Description Check Point Description
test Check Point Tunnel Testing (UDP
port 18234)
Check Point tunnel testing application -
Testing ICA through VPN by SecuRemote
/ SecureClient
Expressions for ICA (Internal Certificate Authority)
For more information, see sk52421 http://supportcontent.checkpoint.com/solutions?id=sk52421.
Expression Description Check Point Description
pull Check Point Internal CA Pull
Certificate Service (TCP port 18210)
Pulling certificates by Security Gateway
from Security Management Server (by
CPCA daemon)
push Check Point Internal CA Push
Certificate Service (TCP port 18211)
Pushing certificates from the Internal
Certificate Authority (ICA) on Security
Management Server (by CPD daemon)
to Security Gateway
crl Check Point Internal CA Fetch CRL
and User Registration Services
(TCP port 18264)
Protocol for Certificate Revocation Lists
and registering users when using the
Policy Server (needed when, e.g.,
Security Gateway is starting).
See sk35292
http://supportcontent.checkpoint.com/s
olutions?id=sk35292.
ica Check Point Internal CA
Management Tools (TCP port
18265)
• Managing the ICA and central administration
of Internal Certificate Authority (ICA) on the
Security Management Server
• Needs to be started separately with the
Security Management Server and
cpca_client
Expressions for Security Management Server
Expression Description
smc Port 18190 (SmartConsole)
policy Port 18191 (Install policy)
amon Port 18192 (AMON server)
pslog Port 18231
scv Port 18233 (Client SCV)
Expressions for Common Tasks
Expression Description
cpca Uses these expressions: camgmt, pull, crl, and ica
sic Uses these expressions: cpca, push, and policy
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 83
Expression Description
vpnd Uses these expressions:
ike, natt, uenc, rdp, topo, l2tp, test,
pslog and scv
vpn Uses expressions for standard site to site: esp, and ike
vvpn Uses expressions for remote access: natt, and https
multi Uses expressions for multi-portal: https, and port 444
vpnall Uses expressions for all VPN services: esp, vpnd, crl, and multi
vpn1 Uses expressions for VPN and common test services: vpn, vvpn, ftp, and
ping
Expressions to Exclude Background Traffic
Expression Description
no_term Uses expressions to exclude remote terminal: not ssh and not telnet
no_mgmt Uses expressions to exclude Check Point management services: not smc and
not policy and not amon
Example: > fwmonitor -e "accept https;"
fw putkey
Description Install a Check Point authentication password on a host. This password is used to
authenticate internal communications between Security Gateways and between a Check Point
Security Gateway and its Security Management server. A password is used to authenticate the
control channel the first time communication is established. This command is required for
backward compatibility scenarios.
Syntax
> fw putkey [-opsec] [-no_opsec] [-ssl] [-no_ssl] [-k <num>] [-n <myname>]
[-p <pswd>] <host>...
Parameter Description
-opsec Only control connections are enabled.
-no_opsec Only OPSEC control connections are enabled.
-ssl The key is used for an SSL connection.
-no_ssl The key is not used for an SSL connection.
-k <num> The length of the first S/Key password chain for fwa1 authentication (Check
Point's proprietary authentication protocol). The default is 7. When fewer than 5
passwords remain, the hosts renegotiate a chain of length 100, based on a long
random secret key. The relatively small default value ensures that the first
chain, based on a short password entered by the user, is quickly exhausted.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 84
Parameter Description
-n <myname> The IP address (in dot notation) to be used by the Check Point Security Gateway
when identifying this host to all other hosts, instead of, for example, the
resolution of the hostname command.
-p <psw> The key (password). If you do not enter the password on the command line, you
will be prompted for it.
<host> The IP address(es) or the resolvable name(s) of the other host(s) on which you
are installing the key (password). This should be the IP address of the interface
"closest" to the host on which the command is run. If it is not, you will get error
messages such as the following:
"./fwd: Authentication with hostname for command sync failed"
Comments This command is never used in a script.
fw repairlog
Description fw repairlog rebuilds a Log file's pointer files. The three files:
name
.logptr,
name
.loginitial_ptr and
name
.logaccount_ptr are recreated from data in the specified
Log file. The Log file itself is modified only if the -u flag is specified.
Syntax
fw repairlog [-u] <logfile>
Parameter Description
-u Indicates that the unification chains in the Log file should be rebuilt.
<logfile> The name of the Log file to repair.
fw sam
Description Manage the Suspicious Activity Monitoring (SAM) server. Use the SAM server to
block connections to and from IP addresses without the need to change the Security Policy.
SAM commands are logged. Use this command to (also) monitor active SAM requests (see -M
option).
To configure the SAM server on the Security Management server or Security Gateway, use
SmartDashboard to edit the Advanced > SAM page of the Check Point Security Gateway object.
Syntax
Add/Cancel SAM rule according to criteria:
> fw sam [-v][-s <sam server>][-S <server sic name>][-f <fw host>][-t
<timeout>][-l <log>][-C] -{n|i|I|j|J} <Criteria>
Delete all SAM rules:
> fw sam [-v][-s <sam server>][-S <server sic name>][-f <fw host>] -D
Monitor all SAM rules:
> fw sam [-v][-s <sam server>][-S <server sic name>][-f <fw host>] -M
-{i|j|n} all
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 85
Monitor SAM rules according to criteria:
> fw sam [-v][-s <sam server>][-S <server sic name>][-f <fw host>] -M
-{i|j|n} <Criteria>
Syntax
Parameter Description
-v Verbose mode. Writes one message (describing whether the command
was successful or not) to stderr for each Security Gateway machine on
which the command is enforced.
-s <sam_server> The IP address (in dot format) or the resolvable name of the FireWalled
host that will enforce the command. The default is localhost.
-S
<server_sic_name
>
The SIC name for the SAM server to be contacted. It is expected that the
SAM server will have this SIC name, otherwise the connection will fail. If
no server SIC name is supplied the connection will proceed without SIC
names comparison. For more information about enabling SIC refer to the
OPSEC API Specification.
-f <fw host> Specify the host, the Security Gateway machine on which to enforce the
action.
host can be one of the following (default is All):
• localhost—
Specify the computer running the SAM server to enforce
the action on it.
• The name of the object or group—the action is enforced on this object;
if this object is a group, on every object in the group.
• Gateways—Action enforced on FireWalls defined as gateways and
managed by Security Management server where the SAM server runs.
• All—Enforced on FireWalls managed by Smart- Center server where
SAM server runs.
-D Cancel all inhibit (-i, -j,-I,-J) and notify (-n) commands.
To "uninhibit" inhibited connections, execute fw sam with the -C or -D
parameters. It is also possible to use this command for active SAM
requests.
-C Cancel the command to inhib
it connections with the specified parameters.
These connections will no longer be inhibited (rejected or dropped). The
command parameters must match the ones in the original command,
except for the -t (timeout) parameter.
-t <timeout> The time period (in seconds) for which the action will be enforced. The
default is forever or until cancelled.
-l <log> The type of the log for enforced actions can be one of the following:
nolog, long_noalert, long_alert. The default is long_alert.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 86
Parameter Description
-n Notify, or generate, a long-format log entry. Generates an alert when
connections that match the specified services or IP addresses pass
through the FireWall. This action does not inhibit or close connections.
-i Inhibit (do not allow) new connections with the specified parameters. Each
inhibited connection is logged according to log type. Matching connections
will be
rejected
.
-I Inhibit new connections with the specified parameters, and close all
existing connections with the specified parameters. Each inhibited
connection is logged according to the log type. Matching connections will
be
rejected
.
-j Inhibit new connections with the specified parameters. Each inhibited
connection is logged according to the log type. Connections will be
dropped
.
-J Inhibit new connections with the specified parameters, and close all
existing connections with the specified parameters. Each inhibited
connection is logged according to the log type. Connections will be
dropped
.
-M Monitor the active SAM requests with the specified actions and criteria.
all Get all active requests. For monitoring purposes only.
Usage Criteria are used to match connections, and are composed of various combinations of the
following parameters:
<source ip><source netmask><destination ip><destination netmask>
<service><protocol>
Possible combinations are:
src <ip>
dst <ip>
any <<ip>
subsrc <ip><netmask>
subdst <ip><netmask>
subany <ip><netmask>
srv <src ip><dest ip><service><protocol>
subsrv <src ip><src netmask><dest ip><dest netmask><service> <protocol>
subsrvs <src ip><src netmask><dest ip><service><protocol>
subsrvd <src ip><dest ip><dest netmask><service><protocol>
dstsrv <dest ip><service><protocol>
subdstsrv <dest ip><dest netmask><service><protocol>
srcpr <ip><protocol>
dstpr <ip><protocol>
subsrcpr <ip><netmask><protocol>
subdstpr <ip><netmask><protocol>
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 87
Syntax
Criteria Parameters Description
src <ip> Match the source IP address of the connection.
dst <ip> Match the destination IP address of the connection.
any <ip> Match either the source IP address or the destination IP
address of the connection.
subsrc <ip> <netmask> Match the source IP address of the connections according to
the netmask.
subdst <ip> <netmask> Match the destination IP address of the connections according
to the netmask.
subany <ip> <netmask> Match either the source IP address or destination IP address
of connections according to the netmask.
srv <src ip> <dst ip>
<service> <protocol> Match the specific source IP address, destination IP address,
service and protocol.
subsrv <src ip> <netmask>
<dst ip> <netmask>
<service> <protocol>
Match the specific source IP address, destination IP address,
service and protocol. Source and destination IP addresses are
assigned according to the netmask.
subsrvs <src ip> <src
netmask> <dest ip>
<service> <protocol>
Match the specific source IP address, source netmask,
destination netmask, service and protocol.
subsrvd <src ip> <dest ip>
<dest netmask> <service>
<protocol>
Match specific source IP address, destination IP, destination
netmask, service and protocol.
dstsrv <dst ip> <service>
<protocol> Match specific destination IP address, service and protocol.
subdstsrv <dst ip>
<netmask> <service>
<protocol>
Match specific destination IP address, service and protocol.
Destination IP address is assigned according to the netmask.
srcpr <ip> <protocol> Match the source IP address and protocol.
dstpr <ip> <protocol> Match the destination IP address and protocol.
subsrcpr <ip> <netmask>
<protocol> Match the source IP address and protocol of connections.
Source IP address is assigned according to the netmask.
subdstpr <ip> <netmask>
<protocol> Match the destination IP address and protocol of connections.
Destination IP address is assigned according to the netmask.
Example This command inhibits all connections originating on louvre for 10 minutes.
Connections made during this time will be rejected:
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 88
> fw sam -t 600 -i src louvre
This command inhibits all FTP connections from the louvre subnet to the eifel subnet. All
existing open connections will be closed. New connection will be dropped, a log is kept and an
alert is sent:
> fw sam -l long_alert -J subsrvs louvre 255.255.255.0 eifel 21 6
The previous command will be enforced forever - or until canceled by the following command:
> fw sam -C -l long_alert -J subsrvs louvre 255.255.255.0 eifel 21 6
This command monitors all active "inhibit" or "notify SAM" requests for which lourve is the
source or destination address:
> fw sam -M -nij any lourve
This command cancels the command in the first example:
> fw sam -C -i src louvre
fw stat
Description Use fw stat to view the policy installed on the gateway, and which interfaces are
being protected.
Note - The cpstat command is an enhanced version of fw stat
Syntax
> fw stat -l
> fw stat -s
Parameter Description
-l Show a long, detailed listing of the installed policies.
-s Shows a short summary of the installed policies.
Examples
> fw stat
HOST POLICY DATE
localhost Standard 18Apr2012 15:01:51 : [>eth0] [<eth0]
Two interfaces are being protected. The arrows show the direction of the packets.
After the policy is uninstalled, the output becomes:
> fw stat
HOST POLICY DATE
localhost - - : >eth0 <eth0
This shows that there is no policy installed, and the interfaces are not protected.
fw tab
Description The fw tab command shows data from the kernel tables, and lets you change the
content of dynamic kernel tables. You cannot change the content of static kernel tables.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 89
Kernel tables (also known as State tables) store data that the Firewall and other modules in the
Security Gateway use to inspect packets. These kernel tables are the "memory" of the virtual
computer in the kernel and are a critical component of Stateful Inspection. The kernel tables are
dynamic hash tables in the kernel memories.
Syntax
fw tab [-t <table>] [-s] [-c] [-f] [-o <filename>] [-r] [-u | -m <maxval>]
[{-a|-x} -e <entry>] [-y] [<hostname>]
Parameter Description
- t <table> Specifies a table for the command.
-s Shows a short summary of the table (s) data.
-c Shows formatted table information in common format.
-f
Shows a formatted version of the table data. Each table can use a different style.
-o
<filename> Outputs CL formatted file called <filename>.You can open the file with fw log
and other commands or processes that can read FW log formats.
-r Resolves IP addresses in formatted output.
-u Show unlimited table entries.
-m <maxval> Sets the maximum table entries that are shown to <maxval>.
-a|-x Adds (-a) or removes (-x) an entry from the specified table.
Include the -t <table> parameter when you run the fw tab command with
the -a and -x parameters. You cannot run these parameters on remote
appliances or servers.
Caution - If you use the -a and -x parameters incorrectly, you can cause the
appliance or server to become unstable.
-e <entry> One or more entries that you add or remove from the table.
-y Do not show a prompt to users before they run commands.
[<hostname>
] One or more target appliances or servers for the fw tab command. If you do not
use this parameter, the default setting is localhost.
Example > fw tab -t arp_table -a -e "1,2,3,4,5"
Adds an entry: <00000001,00000002,00000003,00000004,00000005,> to arp_table
fw tab - m 100 -r sample-gw
Comments If a table has the expire attribute, when you use the -a parameter to add entries,
the default table timeout is added.
This feature only works on local machine kernel tables and does not work on a remote machine's
tables like additional fw tab commands.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 90
The -x flag can be used independently of the -e flag in which case the entire table content is
deleted.
This feature should only be used for debug purposes. It is not advisable to arbitrarily change the
content of any kernel table since doing so may have unexpected results including unexpected
security and connectivity impacts.
fw ver
Description Display the Security Gateway major and minor version number and build number.
Syntax
> fw ver [-k][-f <filename>]
Parameter Description
-k Print the version name and build number of the Kernel module.
-f <filename> Print the version name and build number to the specified file.
fwm
Description Perform management operations on the Security Gateway. It controls fwd and all
Check Point daemons.
Syntax
> fwm
fwm dbimport
Description Imports users into the Check Point User Database from an external file. You can
create this file yourself, or use a file generated by fwm dbexport.
Syntax
> fwm dbimport [-m] [-s] [-v] [-r] [-k <errors>] [-f <file>] [-d <delim>]
Parameter Description
-m If an existing user is encountered in the import file, the user's default values
will be replaced by the values in the template (the default template or the one
given in the attribute list for that user in the import file), and the original values
will be ignored.
-s Suppress the warning messages issued when an existing user's values are
changed by values in the import file.
-v verbose mode
-r fwm dbimport will delete all existing users in the database.
-k <errors> Continue processing until nerror errors are encountered.
The line count in the error messages starts from 1 including the attributes line
and counting empty or commented out lines.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 91
Parameter Description
-f <file> The name of the import file. The default import file is
$FWDIR/conf/user_def_file.
-d <delim> Specifies a delimiter different from the default value (;).
Comments The IKE pre shared secret does not work when exporting from one machine and
importing to another.
To ensure that there is no dependency on the previous database values, use the-r flag together
with the -m flag.
File Format
The import file must conform to the following Usage:
• The first line in the file is an attribute list.
• The attribute list can be any partial set of the following attribute set, as long as name is
included:
{name; groups; destinations; sources; auth_method; fromhour; tohour;
expiration_date; color;
days; internal_password; SKEY_seed; SKEY_passwd;
SKEY_gateway; template; comments; userc}
• The attributes must be separated by a delimiter character.
• The default delimiter is the ; character. However, you can use a different character by
specifying the -d option in the command line.
• The rest of the file contains lines specifying the values of the attributes per user. The values
are separated by the same delimiter character used for the attribute list. An empty value for an
attribute means use the default value.
• For attributes that contain a list of values (for example, days), enclose the values in curly
braces, that is,{}. Values in a list must be separated by commas. If there is only one value in a
list, the braces may be omitted. A + or - character appended to a value list means to add or
delete the values in the list from the current default user values. Otherwise the default action
is to replace the existing values.
• Legal values for the days attribute are: MON, TUE, WED, THU, FRI, SAT, SUN.
• Legal values for the authentication method are: Undefined, S/Key, SecurID, Unix
Password, VPN-1 & FireWall-1 Password, RADIUS, Defender.
• Time format is hh:mm.
• Date format is dd-mmm-yy, where mmm is one of {Jan, Feb, Mar, Apr, May, Jun, Jul, Aug,
Sep, Oct, Nov, Dec}.
• If the S/Key authentication method is used, all the other attributes regarding this method must
be provided.
• If the Check Point password authentication method is used, a valid Check Point password
should be given as well. The password should be encrypted with the C language encrypt
function.
• Values regarding authentication methods other than the one specified are ignored.
• The userc field specifies the parameters of the user's SecuRemote connections, and has
three parameters, as follows:
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 92
• key encryption method - DES, CLEAR, Any
• data encryption method - DES, CLEAR, Any
• integrity method - MD5,[blank] = no data integrity.
• "Any" means the best method available for the connection. This depends on the encryption
methods available to both sides of the connection. For example,
{DES,CLEAR,} means: key encryption method is DES; no data encryption; no data
integrity.
• A line beginning with the ! character is considered a comment.
fwm expdate
Description Modify the expiration date of all users and administrators.
Syntax
> fw expdate dd-mmm-1976
Comments The date can be modified using a filter.
Example fw expdate 02-mar-2003 -f 01-mar-2003
fwm dbexport
Description Export the Check Point User Database to a file. The file may be in one of the
following formats:
• The same syntax as the import file for fwm dbimport
• LDIF format, which can be imported into an LDAP server using ldapmodify
Syntax
To export the User Database to a file that can be used with fwm dbimport:
> fwm dbexport [ [-g group | -u user] [-d delim] [-a {attrib1, attrib2, ...}
] [-f file] ]
To export the User Database as an LDIF file:
> fwm dbexport -l -p [-d] -s subtree [-f file] [-k IKE-shared-secret]
Parameter Description
-g group Specifies a group (group) to be exported. The users in the group are not
exported.
-u user Specifies that only one user (user) is to be exported.
-d Debug flag
-a {attrib1,
attrib2, ...} Specifies the attributes to export, in the form of a comma-separated list,
between {} characters, for example,
-a {name,days}. If there is only one attribute, the {} may be omitted.
-f file
file specifies the name of the output file. The default output file is
$FWDIR/conf/user_def_file.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 93
Parameter Description
-l Create an LDIF format file for importation by an LDAP server.
-p The profile name.
-s The branch under which the users are to be added.
-k This is the Account Unit's IKE shared secret (IKE Key in the Encryption
tab of the Account Unit Properties window.)
Comments Note:
• The IKE pre shared secret does not work when exporting from one machine and importing to
another.
• If you use the -a parameter to specify a list of attributes, and then import the created file using
fwm dbimport, the attributes not exported will be deleted from the user database.
• fwm dbexport and fwm dbimport (non-LDIF Usage) cannot export and import user groups.
To export and import a user database, including groups, proceed as follows:
* Run fwm dbexport on the source Security Management server.
* On the destination Security Management server, create the groups manually.
* Run fwm dbimport on the destination Security Management server.
The users will be added to the groups to which they belonged on the source Security Management
server.
• If you wish to import different groups of users into different branches, run fwm dbexport
once for each subtree, for example:
fwm dbexport -f f1 -l -s ou=marketing,o=WidgetCorp,c=us
fwm dbexport -f f2 -l -s ou=rnd,o=WidgetCorp,c=uk
Next, import the individual files into the LDAP server one after the other. For information
on how to do this, refer to the documentation for your LDAP server.
• The LDIF file is a text file which you may wish to edit before importing it into an LDAP server.
For example, in the Check Point user database, user names may be what are in effect login
names (such as "maryj") while in the LDAP server, the DN should be the user's full name
("Mary Jones") and "maryj" should be the login name.
Example Suppose the User Database contains two users, "maryj" and "ben".
fwm dbexport -l -s o=WidgetCorp,c=us
creates a LDIF file consisting of two entries with the following DNs:
cn=ben,o=WidgetCorp,c=us
cn=maryj,o=WidgetCorp,c=us
fwm dbload
Description Download the user database and network objects information to selected targets. If
no target is specified, then the database is downloaded to localhost.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 94
Syntax
gw> fwm dbload [-a|-c <conffile>] [<targets>]
Parameter Description
-a <conffile> Execute command on all targets specified in the default system
configuration file ($FWDIR/conf/sys.conf). This file must be manually
created.
-c <conffile> Only OPSEC control connections in the file are enabled.
<targets> Execute command on the designated targets.
fwm ikecrypt
Description fwm ikecrypt command line encrypts the password of a SecuRemote user using
IKE. The resulting string must then be stored in the LDAP database.
Syntax
> fwm ikecrypt <shared-secret> <user-password>
Parameter Description
<shared-secret> The IKE Key defined in the Encryption tab of the LDAP Account Unit
Properties window.
<user-password> The SecuRemote user's password.
Comments An internal CA must be created before implementing IKE encryption. An Internal
CA is created during the initial configuration of the Security Management server, following
installation.
fwm getpcap
Description fwm getpcap command line fetches the packet capture.
Syntax > fwm getpcap -g <gw> -u <cap id> [-p <path>] [-c <domain>]
Parameter Description
-g <gw> Host name of the gateway
-u <cap id> Capture UID
-p <path> Output pathname
-c <domain> Host name of the Domain Management Server
Note - This command only works with IPS packet captures stored on the Gateway in
$FWDIR//opt/CPsuite-R77/fw1/log/captures_repository. It does not work with other blades such
as Anti-Bot and Anti-Virus that store packet captures in $FWDIR/log/blob.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 95
fwm load
Description Compile and install a Security Policy or a specific version of the Security Policy on
the target's Security Gateways. This is done in one of two ways:
• fwm load compiles and installs an Inspection Script (*.pf) file on the designated Security
Gateways.
• fwm load converts a Rule Base (*.W) file created by the GUI into an Inspection Script (*.pf)
file then installs it to the designated Security Gateways.
Versions of the Security Policy and databases are maintained in a version repository on the
Security Management server. Using this command, specific versions of the Security Policy can be
installed on a gateway (local or remote) without changing the definition of the current active
database version on the Security Management server.
To protect a target, you must load a Policy that contains rules whose scope matches the target. If
none of the rules are enforced on the target, then all traffic through the target is blocked.
Syntax > fwm load [-p <plug-in>] [-S] <rulebase> <targets>
Parameter Description
-S The targets are UTM-1 Edge gateways.
-p <plug-in> Specifies the product name <plug-in> if applicable.
rulebase
A Rule Base created by the GUI. Specify the name of the rulebase, such as
Standard (case sensitive).
<targets> Execute command on the designated target.
Example The following command installs the Security Policy standard in the target
gateway johnny.
fwm load Standard johnny
fwm lock_admin
Description View and unlock locked administrators.
Syntax >fwm lock_admin [-v][-u <administrator>][-ua]
Parameter Description
-v View the names of all locked administrators.
-u
<administrator> Unlock a single administrator.
-ua Unlock all locked administrators.
fwm logexport
Description fwm logexport exports the Log file to an ASCII file.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 96
Syntax > fwm logexport [-d <delimiter>] [-i <filename>] [-o <outputfile>] [-n]
[-p]
[-f] [-m {initial|semi|raw}] [-a]
Parameter Description
-d <delimiter> Set the output delimiter. The default is a semicolon (;).
-i <filename> The name of the input Log file. The default is the active Log file, fw.log
-o <outputfile> The name of the output file. The default is printing to the screen.
-n Do not perform DNS resolution of the IP addresses in the Log file (this
option significantly speeds the processing).
-p Do not perform service resolution. A service port number is displayed.
-f If this is the active Log file (fw.log), wait for new records and export
them to the ASCII output file as they occur.
-m
{initial|semi|ra
w}
This flag specifies the unification mode.
• initial - the default mode. Complete the unification of log records;
that is, output one unified record for each id.
• semi - step-by-step unification, that is, for each log record, output a
record that unifies this record with all previously-encountered records
with the same id.
•
raw
- output all records, with no unification.
-a Show account records only (the default is to show all records).
Comments Controlling the Output of fwm logexport using logexport.ini
The output of fwm logexport can be controlled by creating a file called logexport.ini and
placing it in the conf directory: $FWDIR/conf. The logexport.ini file should be in the
following format:
[Fields_Info]
included_fields = field1,field2,field3,<REST_OF_FIELDS>,field100
excluded_fields = field10,field11
note that:
• the num field will always appear first, and cannot be manipulated using logexport.ini
• <REST_OF_FIELDS> is a reserved token that refers to a list of fields. It is optional. If -f
option is set, <REST_OF_FIELDS> is based on a list of fields taken from the file
logexport_default.C.
• If -f is not set, <REST_OF_FIELDS> will be based on the given input log file.
• It is not mandatory to specify
both
included_fields and excluded_fields.
Format:
The fwm logexport output appears in tabular format. The first row lists the names of all fields
included in the subsequent records. Each of the subsequent rows consists of a single log record,
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 97
whose fields are sorted in the same order as the first row. If a record has no information on a
specific field, this field remains empty (as indicated by two successive semi-colons).
Example
num;date;time;orig;type;action;alert;i/f_name;i/f_dir;product;sys_messag
e:;service;s_port;src;dst;
0; 5Dec2002;9:08:44;jam.checkpoint.com;control; ;;daemon;inbound;VPN-
1 &
FireWall-1;The hme0 interface
is not protected by the anti-spoofing feature. Your network may be at
risk;;;;;
1; 5Dec2002;9:08:44;jam.checkpoint.com;control; ;;daemon;inbound;VPN-1 &
FireWall-1;;
ftp;23456;1.2.3.4;3.4.5.6;
fwm sic_reset
Description Reset the Internal CA and delete all the certificates from the Internal CA and the
Internal CA itself. After running sic_reset, the ICA should be initialized through the cpconfig
command. If this command is run all the certified IKE from the Internal CA should be removed
(using the SmartConsole).
Syntax > fwm sic_reset
fwm unload <targets>
Description Uninstall the currently loaded Inspection Code from selected targets.
Syntax > fwm unload <targets> [-all|-c <conffile>]
Parameter Description
<targets> Execute command on the designated targets.
-all Execute command on all targets specified in the default system
configuration file ($FWDIR/conf/sys.conf). This file must be manually
created.
-c conffile Execute command on targets specified in the conffile.
fwm ver
Description fwm ver shows the build number.
Syntax > fwm ver [-f <filename>]
Parameter Description
-f <filename> Exports the build number data to a file
fwm verify
Description The fwm verify command verifies the specified policy package without installing
it.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 98
Syntax > fwm verify <policy>
Parameter Description
<policy> The name of an available policy package.
GeneratorApp
Description Generate a report for SmartReporter. Both command line parameters are
required. Run this command from Expert mode.
Syntax # GeneratorApp <Directory> <ReportID>
Parameter Description
<Directory> The result directory (that is, the location at which the result is placed).
<ReportID> The report ID required for command line generations.
The Report ID must be enclosed within curly braces.
For a list of all Report IDs see "Predefined Reports" in the
R77 SmartReporter
Administration Guide
http://supportcontent.checkpoint.com/documentation_download?ID=24813.
Example For automatic directory computation use "". In such a case, the directory should be
as follows:
<Result location>/<Report Name>/<Generation Date and Time>
inet_alert
Description Notify a company's Internet Service Provider (ISP) when the company's corporate
network is under attack. The inet_alert utility forwards log messages generated by the alert
daemon to an external Management Station, typically located at the ISP site. The ISP can then
analyze the alert and decide how to react.
inet_alert uses the ELA Protocol to send the alert. The Management Station receiving the alert
must be running the ELA Proxy.
If communication with the ELA Proxy is to be authenticated or encrypted, a key exchange must be
performed between the Management Station running the ELA Proxy and the Security Gateway
generating the alert.
To use this utility, enter it into a script. From Global Properties > Logs and alert > alert
commands > early versions compatibility > run 4.x alert script, and enter the name of the script.
Syntax
# inet_alert -s <ipaddr> [-o] [-a <auth_type>] [-p <port>] [-f <token value>]
[-m <alerttype>]
Parameter Description
-s <ipaddr> The IP address (in dot format) of the ELA Proxy to be contacted.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 99
Parameter Description
-o Print the alert log received by inet_alert to stdout. Use this option
when inet_alert is part of a pipe.
-a <auth_type> The type of connection to the ELA Proxy. One of the following values:
• ssl_opsec. Means the connection is authenticated and
encrypted, (Default)
• auth_opsec. Means the connection is authenticated.
• clear. Means the
connection is neither authenticated nor
encrypted.
-p <port> The ELA proxy's port number. Default is 18187.
-f <token value> A field to be added to the log, represented by a token-value pair as
follows:
• token is the name of the field to be added to the log. token may not
contain spaces.
• value is the field's value. value may not contain spaces.
This option may be used multiple times to add multiple token-value
pairs to the log.
If token is a reserved log field name, the specified field's value will
appear in the corresponding column in SmartView Tracker. Otherwise, the
token-value pair will be displayed in the Info. column in SmartView
Tracker.
-m <alerttype> The alert to be triggered at the ISP site. This alert overrides the alert
specified in the log message generated by the alert daemon.
The response to the alert is handled according to the actions specified in
the ISP's Security Policy:
The following alerts execute the OS commands defined in the
corresponding fields of the Log and Alert tab of the Properties Setup
window in Global Properties:
• alert. Popup alert command.
• mail. Mail alert command.
• snmptrap. SNMP trap alert command.
• spoofalert. Anti-spoof alert command.
The following NetQuota and ServerQuota alerts execute the OS commands
specified in: $FWDIR/conf/objects.C:
value=clientquotaalert. Parameter=clientquotaalertcmd
Return Value
Exit status Description
0 Execution was successful.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 100
Exit status Description
102 Undetermined error.
103 Unable to allocate memory.
104 Unable to obtain log information from stdin.
106 Invalid command line arguments.
107 Failed to invoke the OPSEC API.
Example
# inet_alert -s 10.0.2.4 -a clear -f product cads -m alert
This command specifies that in the event of an attack, inet_alert should take the following
actions:
• Establish a clear connection with the ELA Proxy located at IP address 10.0.2.4.
• Send a log message to the specified ELA Proxy. The product field of this log message should
be set to "cads". This means that "cads" will be displayed in the product column of
SmartView Tracker.
• Trigger the OS command specified in the Popup Alert Command field of the Log and Alert tab
of the Properties Setup window in the SmartDashboard.
ldapcmd
Description ldapcmd is used to manage processes running on the Security Gateway
collectively or individually. It includes:
Cache
Cache operations, such as emptying the cache, as well as providing debug information.
Statistics
Lookup statistics such as:
• All user search
• Pending lookups (when two or more lookups are identical)
• Total lookup time (the total search time for a specific lookup)
• Cache statistics such as hits and misses
Logging
View the alert and warning log regarding debug.
Syntax
# ldapcmd -p {<process_name>|all} <command> [-d debug_level] [command_arg]
Parameter Description
-p Run a specified process or run all processes.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 101
Parameter Description
<command> These are the valid values for the command parameter:
• cacheclear
{all|UserCacheObject|TemplateCacheObject|TemplateExtGrpC
acheObject}
• cachetrace
{all|UserCacheObject|TemplateCacheObject|TemplateExtGrpCa
cheObject}
• stat {
print_interval {<reset interval time in secs>|0} [stop
statistics]}
•
log
{on|off}
log Specify whether or not to create LDAP logs.
ldapcompare
Description ldapcompare is used to perform compare queries that prints a message whether
the result returned a match or not. ldapcompare opens a connection to an LDAP directory
server, binds, and performs the comparison specified on the command line or from a specified
file.
Syntax
# ldapcompare -d [<options>] dn <attribute> <value>
Parameter Description
-d Debug flag
<options> See below
dn The DN object
attribute The attribute of the DN object
value The value of the attribute of the DN object
The ldapcompare options are as follows:
• -u - Include user-friendly entry names in the output.
• -d <level> - Set LDAP debugging level to "level".
• -F sep -Print "sep" instead of "=" between attribute names and values.
• -f <file> - Perform sequence of compares listed in "file".
• -D <binddn> - Bind DN.
• -w <passwd> - Bind password (for simple authentication).
• -h <host> - LDAP server.
• -p <port> - Port on the LDAP server.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 102
• -T <timeout> - Client side timeout for all operations (in milliseconds).
• -l <time limit> - Server Side time limit (in seconds) for compare.
• -z <size limit> - Server Side size limit (in entries) for compare.
ldapconvert
Description ldapconvert is a utility program to port from Member mode to MemberOf mode.
This is done by searching all specified group/template entries and fetching their Member attribute
values.
Each value is the DN of a member entry. The entry identified by this DN will be added the
MemberOf attribute value of the group/template DN at hand. In addition, those Member attribute
values will be deleted from the group/template unless Both mode is specified.
While running the program, a log file, named ldapconvert.log, is generated in the current
directory, logging all modifications done and errors encountered.
Syntax
> ldapconvert -d -h <host> -p <port> -D user_DN -w <secret> [-g group_DN |
-f <file>]
-m mem_attr -o memberof_attr –c memberobjectclass[<extra options>]
Parameter Description
-d Debug flag.
-h <host> LDAP server IP address.
-p <port> LDAP server port number.
-D user_DN LDAP bind DN.
-w <secret> LDAP bind password.
-g group_DN Group or template DN to perform the conversion on. May appear
multiple times for multiple entries.
-f <file> File containing a list of group DNs each separated by a new line.
-m mem_attr LDAP attribute name when fetching and (possibly) deleting a
Member attribute value.
-o memberof_attr LDAP attribute name when adding a "MemberOf" attribute value.
–c memberobjectclass
LDAP objectclass attribute value that filters which type of member
entries to modify. May appear multiple times creating a compound
filter.
<extra options> See below
The ldapcomvert extra options are as follows:
• -M -Maximum number of member LDAP updated simultaneously (default is 20).
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 103
• -B -Convert to Both mode.
• -p <port> -LDAP port (default is 389).
• -T <timeout> -Client side timeout for LDAP operations, in milliseconds: default is "never".
• -l <time limit> -Server side time limit for LDAP operations, in seconds: default is "never".
• -s -Server side size limit for LDAP operations (in entries) (default is "none").
• -z -Use SSL.
Comments It is recommended to make a backup of the LDAP server before running the
conversion program in case unrecoverable errors are encountered.
There are two GroupMembership modes: template-to-groups and user-to-groups. It is
imperative to keep these modes consistent. For instance, if you apply conversion on LDAP users to
include 'MemberOf' attributes for their groups, then this conversion should also be applied on
LDAP defined templates for their groups.
Why does a command run with the option –M fail?
The program terminates with an error message stating the connection terminated unexpectedly.
This means that the LDAP server could not handle so many LDAP requests simultaneously and
closed the connection. The solution is to run the program again with a lower value for the –M
option (the default value should be adequate but could also cause a connection failure in extreme
situation). Continue to reduce the value until the program exits normally. Each time you run the
program with the same set of groups the program will pick up where it left off.
Example A group is defined with the DN: cn=cpGroup,ou=groups, ou=cp, c=il and the
following attributes:
...
cn=cpGroup
uniquemember="cn=member1,ou=people, ou=cp,c=il"
uniquemember=" cn=member2, ou=people, ou=cp,c=il"
...
For the 2 member entries:
...
cn=member1
objectclass=fw1Person
...
and:
...
cn=member2
objectclass=fw1Person
...
Run ldapconvert with the following arguments:
ldapconvert -g cn=cpGroup,ou=groups, ou=cp, c=il -h myhost -d cn=admin -
w secret
\ –m uniquemember -o memberof -c fw1Person
The result for the group DN will be as follows:
...
cn=cpGroup
...
The result for the 2 member entries will be as follows:
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 104
...
cn=member1
objectclass=fw1Person
memberof="cn=cpGroup,ou=groups, ou=cp, c=il"
...
and
...
cn=member2
objectclass=fw1Person
memberof=" cn=cpGroup,ou=groups, ou=cp, c=il"
...
Running the same command with the –B options, will produce the same result but the group entry
will not be modified.
If there is another member attribute value for the same group entry:
uniquemember="cn=template1,ou=people, ou=cp,c=il"
and the template is:
cn=member1
objectclass=fw1Template
After running the same command line the template entry will stay intact because the command
line specified the option –c fw1Person but the object class of template1 is fw1Template.
ldapmodify
Description ldapmodify imports users to an LDAP server. The input file must be in the LDIF
format.
Syntax
# ldapmodify -a -c -d -h <host> -p <port> -D <LDAPadminDN> -p
<LDAPadminPassword>
-f <exportfilename>.ldif -d
Parameter Description
-a Add users.
-c Continue on errors.
-h <host> LDAP server IP address.
-d Debug flag.
-p <port> LDAP server port number.
-D <LDAPadminDN> LDAP Administrator DN.
-p <LDAPadminPassword> LDAP Administrator password.
-f
<exportfilename>.ldif Specifies the name of the input file. This file must be in the LDIF
format.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 105
Comments You can import the Security Management User Database to an LDAP server by first
generating an LDIF file using fwm dbexport, and then using ldapmodify.
Before importing, prepare the LDAP directory as follows:
• Make sure the root branch is defined as an allowed branch on your LDAP server.
• Restart the LDAP server.
• Create the branch into which the users will be imported, either by using Create Tree Object in
the Account Management Client or with the ldapmodify command:
ldapmodify -a -h <host> -p <port> -D <LDAPadminDN> -w <LDAPadminPassword>
dn: o=myOrg,c=US
objectclass: organization
o:myOrg
Example Importing Users using ldapmodify:
1.
Export the users using fwm dbexport using hello1234 as the pre-shared secret.
fwm dbexport -l -f ./o_file.ldif -s "o=bigcorp,c=uk" -k hello1234
2.
Create the "o=bigcorp,c=uk" branch.
3.
Import the users:
ldapmodify -a -c -h <host> -p <port> -D bindDN -w bindPas -f ./o_file.ldif
4.
Define an Account Unit with these parameters.
ldapsearch
Description ldapsearch queries an LDAP directory and returns the results.
Syntax
ldapsearch [options] filter [attributes] -d
Parameter Description
options See the options attributes below.
filter RFC-1558 compliant LDAP search filter. For example,
objectclass=fw1host.
attributes The list of attributes to be retrieved. If no attributes are given, all attributes are
retrieved.
-d Debug flag.
The following are the attributes for options:
• -A -Retrieve attribute names only (without values).
• -B -Do not suppress printing of non-ASCII values.
• -D bindDN -The DN to be used for binding to the LDAP server.
• -F separator -Print separator between attribute name and value instead of "=".
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 106
• -h host -The LDAP server identified by IP address or resolvable name.
• -l timelimit -The server side time limit for search, in seconds.
• -p portnum -The port number. The default is standard LDAP port 389.
• -S attribute -Sort the results by the values of attribute.
• -s scope -One of the following: "base", "one", "sub".
• -b -Base distinguished name (DN) for search.
• -t -Write values to files in /tmp. Each attribute-value pair is written to a separate file,
named: /tmp/ldapsearch-<attribute>-<value>.
• For example, for the fw1color attribute, the file written is named.
• /tmp/ldapsearch-fw1color-a00188.
• -T timeout - Client-side timeout (in milliseconds) for all operations.
• -u - Show "user friendly" entry names in the output. For example, show "cn=Babs Jensen,
users, omi" instead of "cn=Babs Jensen, cn=users,cn=omi"
• -w password - The password.
• -Z - Encrypt using SSL.
• -z sizelimit -Server-side size limit for search, in entries.
Example ldapsearch -p 18185 -b cn=omi objectclass=fw1host objectclass
This means that the LDAP directory will be queried for fw1host objects using port number 18185
with DN common name "omi". For each object found, the value of its objectclass attribute will
be printed.
log_export
Description log_export is a utility that allows you to transfer Log data to an external
database. This utility behaves as a LEA client. LEA (Log Export API) enables Security Gateway Log
data to be exported to third-party applications. log_export receives the Logs from the Security
Management server via LEA so it can be run from any host that has a SIC connection with the
Security Management server and is defined as an OPSEC host. To run log_export, you need a
basic understanding and a working knowledge of:
• Oracle database administration
• LEA
Syntax
# log_export [-f <conf_file>] [-l <lea_server_ip_address>] [-g
<log_file_name>,<log_file_name>,...]
[-t <database_table_name>] [-p <database_password>][-h] [-d]
Parameter Description
-f <conf_file> The Configuration File from which log_export reads the Log
file parameters. If conf_file is not specified, the default
Configuration File log_export.conf, located in the current
working directory.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 107
Parameter Description
-l
<lea_server_ip_address> The IP address of the LEA server.
-g <log_file_name>,
<log_file_name>,... A comma separated list of log file names from where the logs
will be taken.
-t <database_table_name>
The name of the table in the database to which the logs will be
added.
p <database_password> The database login password. If you do not want to specify the
password in the Configuration File for security reasons, you
can enter the password using the command line where it will
not be saved anywhere.
-h Display log_export help.
-d Display debugging information.
Further Info. For more information about LEA, see
Check Point LEA (Log Export API)
Specification
Comments Only Oracle database is currently supported.
Before you can run log_export, the Oracle client must be installed and configured. Make sure
that:
• the ORACLE_HOME environment variable is set correctly.
• $ORACLE_HOME/lib is located in the PATH environment variable on the Windows platform or
LD_LIBRARY_PATH on Solaris and Linux platforms.
• If log_export is running from another machine, you must install and configure at least
SmartReporter.
The log_export Configuration File
log_export has a Configuration File. The Configuration File is a Check Point Set file and should
be configured according to Set file conventions. The Configuration File contains the default
parameters for log_export. log_export reads all parameters from the Configuration File that
is specified in the command line.
Modifying the Configuration File
log_export parameters are defined in the Configuration File. To change the parameters, you
can either modify the Configuration File or use the command line. Any parameter entered using
the command line will override the parameters in the Configuration File.
Modify the Configuration File according to the following parameters:
• db_connection_string - The string that defines the Oracle database server. For example,
the name of the server.
• db_table_name - The name of the table in the database to which the logs will be added.
• create_db_table - Following are the available options:
• 1 - create a new table in the database
• 0 - use the existing table.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 108
• If there is an existing table, the logs will be added to that table. This requires that the
existing table have the same format as the logs you are adding. If you enter 0 and there is
no existing table, you will get an error message. The default is 1.
• db_user_name - The database login user name.
• db_password - The database login password.
• log_server_ip_address - The IP address of the LEA server.
• log_server_port - Port number of the LEA server. The default LEA port is 18184.
• log_file_name - A list of log file names from where the logs will be taken.
• log_fields - The name of the Log file as known by LEA.
• db_field_name - The Log field name as represented in the database table.
• db_field_type - The Log field type in the database table. This parameter can be one of the
following:
• STRING
• NUMBER
• DATE
• db_field_size - The size of the field in the database table. This parameter is required only
if the db_field_type is either STRING or NUMBER.
Example Configuration File Example
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 109
:db_table_name (fw_log)
:db_connection_string (database_service_name)
:db_user_name (scott)
:db_password (tiger)
:log_server_ip_address (127.0.0.1)
:log_server_port (18184)
:create_db_table (1)
:log_file_name (fw.log)
:log_fields (
: (time
:db_field_name (log_time)
:db_field_type (DATE)
)
: (product
:db_field_name (product)
:db_field_type (STRING)
:db_field_size (25)
)
: (i/f_name
:db_field_name (interface)
:db_field_type (STRING)
:db_field_size (100)
)
: (orig
:db_field_name (origin)
:db_field_type (STRING)
:db_field_size (16)
)
: (action
:db_field_name (action)
:db_field_type (STRING)
:db_field_size (16)
)
: (service
:db_field_name (service)
:db_field_type (STRING)
:db_field_size (40)
)
queryDB_util
Description queryDB_util enables searching the object database according to search
parameters.
Syntax
# queryDB_util [-t <table_name>] [-o <object_name>] [-a]
[-mu <modified_by>] [-mh <modified_from>]
[-ma <modified_after>] [-mb <modified_before>] [-p{m|u|h|t|f}]
[-f <filename>] [-h] [-q]
Parameter Description
-t <table_name> The name of the table.
-o <object_name> The name of the object.
[-a] All objects.
-mu <modified_by> The name of the administrator who last modified the object.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 110
Parameter Description
-mh
<modified_from> The host from which the object was last modified.
-ma
<modified_after> The date after which the object was modified
<[hh:mm:ss][ddmmmyyyy]>. Either or both options may be used.
Omitting hh:mm:ss defaults to today at midnight, omitting
ddmmmyyyyy defaults to today's date on the client.
-mb
<modified_before> The date before which the object was modified
<[hh:mm:ss][ddmmmyyyy]>. Either or both options may be used.
Omitting hh:mm:ss defaults to today at midnight, omitting
ddmmmyyyyy defaults to today's date on the client.
-p{m|u|h|t|f} Short print options:
• c - creation details.
• m - last_modification details.
• u - administrator name (create/modify).
• h - host name (create/modify).
• t - time (create/modify).
• f - field details.
-f <filename> The name of the output file
-h Display command help
-q Quit.
Example Print modification details of all objects modified by administrator "aa":
query> -a -mu Bob -pm
Object Name:my_object
Last Modified by:Bob
Last Modified from:london
Last Modification time:Mon Jun 19 11:44:27 2000
Object Name:internal_ca
Last Modified by:Bob
Last Modified from:london
Last Modification time:Tue Jun 20 11:32:58 2000
A total of 2 objects match the query.
rs_db_tool
Description rs_db_tool is used to manage DAIP gateways in a DAIP database.
Syntax
# rs_db_tool [-d] <-operation <add <-name object_name> <-ip module_ip>
<-TTL Time-To-Live> >
# rs_db_tool [-d] <-operation fetch <-name object_name> >
# rs_db_tool [-d] <-operation <delete <-name object_name> >
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 111
# rs_db_tool [-d] <-operation <list> >
# rs_db_tool [-d] <-operation <sync> >
Parameter Description
-d debug file.
-operation add Add entry to database.
<-name object_name> Enter the name of the gateway object.
<-ip module_ip> Enter the IP Address of the gateway
<-TTL Time-To-Live> The relative time interval (in seconds) during which the entry is
valid.
A value of zero specifies "unlimited".
- operation fetch Get entry from database.
- operation delete Delete entry from database.
- operation list List all the database entries.
- operation sync Synchronize the database.
sam_alert
Description This tool executes FW-1 SAM (Suspicious Activity Monitoring) actions according to
information received through Standard input. This tool is for executing FW-1 SAM actions with the
FW-1 User Defined alerts mechanism.
Syntax
sam_alert [-o] [-v] [-s <sam_server>] [-t <timeout>] [-f <fw_host1>
<fw_host2>...]
[-C] [-n|-i|-I -src|-dst|-any|-srv]
Parameter Description
-o Prints the input of this tool to the standard output (for pipes).
-v Turns on verbose mode (of the fw sam command).
-s <sam_server> The sam server to be contacted. Localhost is the default.
-t <timeout> The time period, in seconds, for which the action will be enforced. The
default is forever.
-f <fw_host> Identifies the FireWalls to run the operation on. Default is "all FireWalls."
-C Cancels the specified operation.
Security Management Server and Firewall Commands
Command Line Interface Reference Guide R77 | 112
Parameter Description
-n Notify every time a connection that matches the specified criteria passes
the Firewall.
-i Inhibit connections that match the specified criteria.
-I Inhibit connections that match the specified criteria and close all existing
connections that match the criteria.
-src Match the source address of connections.
-dst Match the destination address of connections.
-any Match either the source or destination address of the connection.
-srv Match specific source, destination, protocol and service.
svr_webupload_config
This utility is used to configure the SmartReporter web upload script. For the complete upload
procedure and additional information refer to the section
How to Upload Reports to a Web Server
in the
R77 SmartReporter Administration Guide
http://supportcontent.checkpoint.com/documentation_download?ID=24813.
Syntax
# svr_webupload_config [-i <perl_int_loc>]
[-p <rep_dir_root>]
Parameter Description
-i Specifies the Perl interpreter location.
-p Specifies the path for the reports virtual directory.
Command Line Interface Reference Guide R77 | 113
CHAPT ER 4
VPN Commands
In This Section:
Overview ...................................................................................................................... 113
vpn crl_zap .................................................................................................................. 113
vpn crlview .................................................................................................................. 113
vpn debug .................................................................................................................... 114
vpn drv ......................................................................................................................... 115
vpn export_p12............................................................................................................ 115
vpn macutil .................................................................................................................. 116
vpn nssm_toplogy ....................................................................................................... 116
vpn overlap_encdom .................................................................................................. 117
vpn sw_topology ......................................................................................................... 118
vpn tu ........................................................................................................................... 118
vpn ver ......................................................................................................................... 119
Overview
Description VPN commands generate status information regarding VPN processes, or are used
to stop and start specific VPN services. All VPN commands are executed on the Security Gateway.
The vpn command sends to the standard output a list of available commands.
Usage vpn
Comments Sends to the standard output a list of available commands.
vpn crl_zap
Description Erase all Certificate Revocation Lists (CRLs) from the cache.
Syntax
> vpn crl_zap
Return Value 0 for success; any other value equals failure.
vpn crlview
Description Retrieve the Certificate Revocation List (CRL) from various distribution points and
displays it for the user. The command comes in three flavors:
• vpn crlview -obj <MyCA> -cert <MyCert>. The VPN daemon contacts the Certificate
Authority called MyCA and locates the certificate called MyCert. The VPN daemon extracts the
certificate distribution point from the certificate then goes to the distribution point, which
might be an LDAP or HTTP server. From the distribution point, the VPN daemon retrieves the
CRL and displays it to the standard output.
VPN Commands
Command Line Interface Reference Guide R77 | 114
• vpn crlview -f d:\temp\MyCert. The VPN daemon extracts the certificate distribution
point from the certificate, goes to the distribution point, retrieves the CRL, and displays the
CRL to the standard output.
• vpn crlview -view <lastest_CRL>. If the CRL has already been retrieved, this command
instructs the VPN daemon to display the contents to the standard output.
Syntax
> vpn crlview -obj <object name> -cert <certificate name>
> vpn crlview -f <filename>
> vpn crlview -view
Parameter Description
-obj -cert • -obj refers to the name of the CA network object
•
-cert
refers to the name of the certificate
-f Refers to the filename of the certificate
-view Views the CRL
-d Debug option
Return Value 0 for success; any other value equals failure.
vpn debug
Description Instruct the VPN daemon to write debug messages to the VPN log file: in
$FWDIR/log/vpnd.elg. Debugging of the VPN daemon takes place according to topics and
levels. A topic is a specific area on which to perform debugging, for example if the topic is LDAP,
all traffic between the VPN daemon and the LDAP server are written to the log file. Levels range
from 1-5, where 5 means "write all debug messages".
This command makes use of TdError, a Check Point infrastructure for reporting messages and
debug information. There is no legal list of topics. It depends on the application or module being
debugged.
To debug all available topics, use: ALL for the debug topic.
IKE traffic can also be logged. IKE traffic is logged to $FWDIR/log/IKE.elg
Syntax
> vpn debug < on [ DEBUG_TOPIC=level ] | off | ikeon | ikeoff | trunc | timeon
<SECONDS>|
timeoff
> vpn debug on DEBUG_TOPIC=level |off timeon<SECONDS>]|timeoff
> vpn debug ikeon | ikeoff timeon|timeoff
> vpn debug trunc
Syntax
Parameter Description
on Turns on high level VPN debugging.
VPN Commands
Command Line Interface Reference Guide R77 | 115
Parameter Description
on topic=level Turns on the specified debug topic on the specified level. Log messages
associated with this topic at the specified level (or higher) are sent to
$FWDIR/log/vpnd.elg
off Turns off all VPN debugging.
timeon/timeoff Number of seconds to run the debug command
ikeon Turns on IKE packet logging to: $FWDIR/log/IKE.elg
ikeoff Turns of IKE logging
trunc Truncates the $FWDIR/log/IKE.elg file, switches the cyclic vpnd.elg
(changes the current vpnd.elg file to vpnd0.elg and creates a new
vpnd.elg), enables VPND and IKE debugging and adds a timestamp to
the vpnd.elg file.
Return Value 0= success, failure is some other value, typically -1 or 1.
Example vpn debug on all=5 timeon 5.
This writes all debugging information for all topics to the vpnd.elg file for five seconds.
Comments IKE logs are analyzed using the support utility IKEView.exe.
vpn drv
Description Install the VPN kernel (vpnk) and connects to the firewall kernel (fwk), attaching
the VPN driver to the Firewall driver.
Syntax
> vpn drv on|off
> vpn drv stat
Parameter Description
on/off Starts/stops the VPN kernel
stat Returns the status of the VPN kernel, whether the kernel is on or off
vpn export_p12
Description Export information contained in the network objects database and writes it in the
PKCS#12 format to a file with the p12 extension.
Syntax
> vpn export_12 -obj <network object> -cert <certificate object> -file <filename>
-passwd <password>
VPN Commands
Command Line Interface Reference Guide R77 | 116
Parameter Description
-obj Name of the gateway network object
-cert Name of the certificate
-file What the file with the p12 should be called
-passwd Password required to open the encrypted p12 file
Return Value 0 for success; any other value equals failure.
Example vpn export_p12 -obj Gateway1 -cert MyCert -file mycert.p12
-passwd kdd432
vpn macutil
This command is related to Remote Access VPN, specifically Office mode, generating a MAC
address per remote user. This command is relevant only when allocating IP addresses via DHCP.
Remote access users in Office mode receive an IP address which is mapped to a hardware or MAC
address. This command displays a generated hardware or MAC address for each name you enter.
Syntax
> vpn macutil <username>
Example vpn macutil John
Output
20-0C-EB-26-80-7D, "John"
vpn nssm_toplogy
Description Generate and upload a topology (in NSSM format) to NSSM server for use by
clients.
Syntax
> vpn nssm_topology -url <"url"> -dn <"dn"> -name <"name"> -pass <"password">
[-action <bypass|drop>][-print_xml]
Parameter Description
-url URL of the NSSM server
-dn Distinguished name of the NSSM server needed to establish an SSL connection
-name Valid Login name for NSSM server
-pass Valid password for NSSM server
VPN Commands
Command Line Interface Reference Guide R77 | 117
Parameter Description
-action Specifies the action the Symbian client should take if the packet is not destined
for an IP address in the VPN domain. Legal options are Bypass (default) or Drop
-print_xml The topology is in XML format. This flag writes that topology to a file in XML
format.
vpn overlap_encdom
Description Display all overlapping VPN domains. Some IP addresses might belong to two or
more VPN domains. The command alerts for overlapping encryption domains if one or both of the
following conditions exist:
• The same VPN domain is defined for both gateway
• If the gateway has multiple interfaces, and one or more of the interfaces has the same IP
address and netmask.
If the gateway has multiple interfaces, and one or more of the interfaces have the same IP address
and netmask
Syntax
> vpn overlap_encdom [communities | traditional]
Parameter Description
Communities With this flag, all pairs of objects with overlapping VPN domains are
displayed -- but only if the objects (that represent VPN sites) are included
in the same VPN community. This flag is also used if the same destination
IP can be reached via more than one community.
Traditional Default flag. All pairs of objects with overlapping VPN domains are
displayed.
Example vpn overlap_encdom communities
VPN Commands
Command Line Interface Reference Guide R77 | 118
Output
c:\> vpn overlap_encdom communitie
The objects Paris and London have overlapping encryption domains.
The overlapping domain is:
10.8.8.1 - 10.8.8.1
10.10.8.0 - 10.10.9.255
- This overlapping encryption domain generates a multiple entry p
oints configuration
in
MyIntranet and RemoteAccess communities.
-
Same destination address can be reached in more than one community (Meshed, Star).
This configuration is not supported.
The objects Paris and Chicago have overlapping encryption domains.
The overlapping
domain is:
10.8.8.1 - 10.8.8.1
-
Same destination address can be reached in more than one community (MyIntranet,
NewStar).
This configuration is not supported.
The objects Washington and Tokyo have overlapping encryption domains.
The overlapping domain is:
10.12.10.68 - 10.12.10.68
10.12.12.0 - 10.12.12.127
10.12.14.0 - 10.12.14.255
- This overlapping encryption domain generates a multiple entry points configuration
in
Meshed, Star and NewStar communities.
vpn sw_topology
Description Download the topology for a Safe@ or Edge gateway.
Syntax
> vpn [-d] sw_toplogy -dir <directory> -name <name> -profile <profile> [-filename
<filename>]
Parameter Description
-d Debug flag
-dir Output directory for file
-name Nickname of site which appears in remote client
-profile Name of the Safe@ or Edge profile for which the topology is created
-filename Name of the output file
vpn tu
Description Launch the TunnelUtil tool which is used to control VPN tunnels.
Syntax
> vpn tu
> vpn tunnelutil
VPN Commands
Command Line Interface Reference Guide R77 | 119
Example vpn tu
Output
********** Select Option **********
(1) List all IKE SAs
(2) List all IPsec SAs
(3) List all IKE SAs for a given peer (GW) or user (Client)
(4) List all IPsec SAs for a given peer (GW) or user (Client)
(5) Delete all IPsec SAs for a given peer (GW)
(6) Delete all IPsec SAs for a given User (Client)
(7) Delete all IPsec+IKE SAs for a given peer (GW)
(8) Delete all IPsec+IKE SAs for a given User (Client)
(9) Delete all IPsec SAs for ALL peers and users
(0) Delete all IPsec+IKE SAs for ALL peers and users
(Q) Quit
*******************************************
Further Info. When viewing Security Associations for a specific peer, the IP address must be
given in dotted decimal notation.
vpn ver
Description Display the VPN major version number and build number.
Syntax
> vpn ver [-k] -f <filename>
Parameter Description
ver Displays the version name and version build number
-k Displays the version name and build number and the kernel build number
-f Prints the version number and build number to a text file.
Command Line Interface Reference Guide R77 | 120
CHAPT ER 5
SmartView Monitor Commands
In This Section:
Overview ...................................................................................................................... 120
rtm debug .................................................................................................................... 120
rtm drv ......................................................................................................................... 120
rtm monitor ................................................................................................................. 121
rtm rtmd ...................................................................................................................... 123
rtm stat ........................................................................................................................ 123
rtm ver ......................................................................................................................... 123
rtmstart ....................................................................................................................... 124
rtmstop ........................................................................................................................ 124
Overview
Description The rtm command and all its derivatives are used to execute SmartView Monitor
operations.
rtm debug
Description Send debug printouts to the $FWDIR/log/rtmd.elg file.
Usage rtm debug <on | off> [OPSEC_DEBUG_LEVEL |
TDERROR_<AppName>_<Topic>=<ErrLevel>]
Syntax
Parameter Description
on Start debug mode
off Stop debug mode
OPSEC_DEBUG_LEVE
L Turn on OPSEC debug printouts
TDERROR_RTM_ALL Turn on SmartView Monitor debug printouts
rtm drv
Description Start, stop or check the status of the SmartView Monitor kernel driver.
Usage rtm drv <on | off | stat>
SmartView Monitor Commands
Command Line Interface Reference Guide R77 | 121
Syntax
Parameter Description
on Start the SmartView Monitor kernel driver
off Stop the SmartView Monitor kernel driver
stat SmartView Monitor kernel driver status
rtm monitor
Description
Starts the monitoring process for an interface or a virtual link.
If options and grouping are not used, this command monitors all traffic, on all interfaces, in both
directions.
Syntax
rtm monitor {<
module_name
> [<
interface_name
>] | <
module_name
>-filter ["<
complex
filter>
"] | -v <
virtual_link_name
>} [
<options>
] [-g <
grouping
> <
entity-1
>...<
entity-n
>]
Parameter Description
module-name The name of the SmartView Monitor module.
interface-name The name of the monitored interface.
"<
complex filter
>"
Boolean regular expression to match traffic to be monitored.
virtual_link_name The name of the monitored Virtual Link.
grouping svc | src | dst | ip | fgrule | topsvc | topsrc | topdst | topip |
topfw | topfgrule
svc Monitors according to a service.
src Monitors according to a network object (source only).
dst Monitors according to a network object (destination only).
ip Monitors according to a network object (source and destination).
fgrule Monitors according to a QoS Policy rule.
topsvc Monitors the traffic of the top 50 services.
topsrc Monitors the traffic of the top 50 sources.
SmartView Monitor Commands
Command Line Interface Reference Guide R77 | 122
Parameter Description
topdst Monitors the traffic of the top 50 destinations.
topdst Monitors traffic to and from the top 50 IP addresses (source of
destination).
topfwn Monitors according to the top 50 Firewall rules.
topfgrule Monitors according to the top 50 QoS Policy rules.
Options Description
-a aggregate (default) - Shows connections as a group.
individual - Shows individual connections.
-w bandwidth (default) - Shows effective bandwidth.
loss - Shows the difference between the transmission rate and the receiving rate.
rtt - Shows the time required to travel between two endpoints.
-t wire - Shows the data on the wire after compression or encryption.
application - Shows the data as the application sees it (not compressed and not
encrypted).
-i <
number of seconds
>
Default: 2
@@ Specifies a sub-rule (for example, 'rule@@subrule')
-d Specifies the monitor direction.
Valid values for an interface:
- inbound
- outbound
- eitherbound
Valid values for a virtual link:
- a2b - endpoint A to endpoint B
- b2a - endpoint B to endpoint A
- a2b_b2a - both directions
-y Specifies the units of bandwidth (when -w = bandwidth)
- bytes (default)
- pkts
- line
c Indicates the number of new connections opened per second.
C Average concurrent connections (use with a
grouping
value).
SmartView Monitor Commands
Command Line Interface Reference Guide R77 | 123
Options Description
-p Specifies whether or not thousands will be separated by commas.
Examples
This command shows monitoring data in bytes-per-second for the top 50 services passed on all
interfaces in both directions: rtm monitor localhost -filter -g topsvc
This command shows monitoring data in concurrent connections for the top 50 sources inbound to
interface eth0: rtm monitor localhost -filter "[and[[interface 0
[[eth0in]]][svc 1 [telnet http]]]" -y C -g topsrc
This command shows monitoring data in bytes-per-sec for the top 50 services passed on interface
hme1: rtm monitor localhost hme1 -g topsvc -y b
Comments
The specified entities correspond to the specified grouping option. For example, if the monitoring
process works according to a service (svc), add all the monitored services, separated by a space.
To monitor for the QoS Policy, use rule@@fgrule
rtm rtmd
Description Start the SmartView Monitor daemon manually. This also occurs manually when
rtmstart is run.
Usage rtm rtmd
rtm stat
Description Display the general SmartView Monitor status. In addition, it displays the status of
the daemon, driver, opened views and active virtual links.
Usage rtm stat [flavor(s)] [-h] [-v[v][v]]
Syntax
Parameter Description
-h Help
-v Verbose
vl Current virtual links
view Current views
rtm ver
Description Display the SmartView Monitor version.
Usage rtm ver [-k]
SmartView Monitor Commands
Command Line Interface Reference Guide R77 | 124
Syntax
Parameter Description
-k Displays the SmartView Monitor kernel version.
rtmstart
Description Load the SmartView Monitor kernel module and starts the SmartView Monitor
daemon.
Usage rtmstart
rtmstop
Description Kill the SmartView Monitor daemon and unloads the SmartView Monitor kernel
module.
Usage rtmstop
Command Line Interface Reference Guide R77 | 125
CHAPT ER 6
ClusterXL Commands
In This Section:
cphaconf ...................................................................................................................... 125
cphaprob ..................................................................................................................... 126
cphastart ..................................................................................................................... 126
cphastop ...................................................................................................................... 127
cphaconf
Description The cphaconf command configures ClusterXL.
Important - Running this command is not recommended. It should be run
automatically, only by the Security Gateway or by Check Point support. The only
exception to this rule is running this command with set_cpp option, as described
below.
Usage
cphaconf [-i <computer id>] [-p <policy id>] [-b <db_id>] [-n <ClusterXL num>]
[-c <ClusterXL size>] [-m <service >] [-t <secured IF 1>...] start
cphaconf [-t <secured IF 1>...] [-d <disconnected IF 1>...] add
cphaconf clear-secured
cphaconf clear-disconnected
cphaconf stop
cphaconf init
cphaconf forward <on/off>
cphaconf debug <on/off>
cphaconf set_ccp <broadcast/multicast>
cphaconf mc_reload
cphaconf debug_data
cphaconf stop_all_vs
Syntax
Parameter
Description
set_ccp
<broadcast/multicast
>
Sets whether ClusterXL Control Protocol (CCP) packets should be
sent with a broadcast or multicast destination MAC address. The
default behavior is multicast. The setting created using this
command will survive reboot.
Note: The same value (either broadcast or multicast) should be set
on all ClusterXL members.
stop_all_vs Stops the ClusterXL product on all Virtual Systems on a VSX
Gateway.
ClusterXL Commands
Command Line Interface Reference Guide R77 | 126
cphaprob
Description The cphaprob command verifies that the cluster and the cluster members are
working properly.
Usage
cphaprob -d <device> -t <timeout(sec)> -s <ok|init|problem> [-p] register
cphaprob -f <file> register
cphaprob -d <device> [-p] unregister
cphaprob -a unregister
cphaprob -d <device> -s <ok|init|problem> report
cphaprob [-i[a]] [-e] list
cphaprob state
cphaprob [-a] if
Syntax
Parameter Description
cphaprob -d <device> -t
<timeout(sec)> -s
<ok|init|problem> [-p]
register
Register <device> as a critical process, and add it to the list of
devices that must be running for the cluster member to be
considered active.
cphaprob -f <file>
register Register all the user defined critical devices listed in <file>.
cphaprob -d <device> [-
p]
unregister Unregister a user defined <device> as a critical process. This
means that this device is no longer considered critical.
cphaprob -a unregister Unregister all the user defined <device>.
cphaprob -d <device> -s
<ok|init|problem> report Report the status of a user defined critical device to ClusterXL.
cphaprob [-i[a]] [-e] list
View the list of critical devices on a cluster member, and of all
the other machines in the cluster.
cphaprob state View the status of a cluster member, and of all the other
members of the cluster.
cphaprob [-a] if
View the state of the cluster member interfaces and the virtual
cluster interfaces.
cphastart
Description Running cphastart on a cluster member activates ClusterXL on the member. It
does not initiate full synchronization. cpstart is the recommended way to start a cluster
member.
ClusterXL Commands
Command Line Interface Reference Guide R77 | 127
cphastop
Description Running cphastop on a cluster member stops the cluster member from passing
traffic. State synchronization also stops. It is still possible to open connections directly to the
cluster member. In High Availability Legacy mode, running cphastop may cause the entire
cluster to stop functioning.
Command Line Interface Reference Guide R77 | 128
CHAPT ER 7
Identity Awareness Commands
In This Section:
Introduction ................................................................................................................. 128
pdp ............................................................................................................................... 128
pep ............................................................................................................................... 133
adlog ............................................................................................................................ 135
test_ad_connectivity ................................................................................................... 137
Introduction
These terms are used in the CLI commands:
• PDP - The process on the Security Gateway responsible for collecting and sharing identities.
• PEP - The process on the Security Gateway responsible for enforcing network access
restrictions. Decisions are made according to identity data collected from the PDP.
• AD Query - AD Query is the module responsible for acquiring identities of entities (users or
computers) from the AD (Active Directory). AD Query was called Identity Logging in previous
versions and in some cases is also referenced as AD Log. The adlog is the command line
process used to control and monitor the AD Query feature.
• test_ad_connectivity - A utility that runs connectivity tests from the Security Gateway to
an AD domain controller.
The PEP and PDP processes are key components of the system. Through them, administrators
control user access and network protection.
AD Query can run either on a Security Gateway that has been enabled with Identity Awareness or
on a Log Server. When it runs on a Security Gateway, AD Query serves the Identity Awareness
feature, and gives logging and policy enforcement. When it runs on a Log Server, AD Query gives
identity logging. The command line tool helps control users’ statuses as well as troubleshoot and
monitor the system.
The test_ad_connectivity utility runs over both the LDAP and WMI protocols. It is usually
used by the SmartDashboard Identity Awareness first time wizard, but you can run it manually on
the Security Gateway when needed.
pdp
Description These commands control and monitor the PDP process.
Syntax # pdp [command]... <parameter>
Parameter
Description
<none> Display available options for this command and exit
debug Control debug messages
Identity Awareness Commands
Command Line Interface Reference Guide R77 | 129
Parameter
Description
tracker Tracker options
connections pdp connections information
network pdp network information
status pdp status information
control pdp control commands
monitor Display monitoring data
update Recalculate users and computers group membership (deleted accounts will
not be updated)
ad Operations related to AD Query
timers Show pdp timers information
pdp monitor
Description Lets you monitor the status of connected sessions. You may perform varied queries
according to the usage below to get the output you are interested in.
Syntax # pdp monitor <parameter> <option>
Parameter
Description
all Display information for all connected sessions
user <user name> Display session information for the given user name
ip <IP address> Display session information for the given IP address
machine <computer
name> Display session information for the given computer name
mad Display all sessions that relate to a managed asset (i.e. all
sessions that successfully performed computer authentication)
client_type
[unknown|portal|"Ide
ntity Agent"|"AD
Query"]
Display all sessions connecting via the given client type
Possible client types are:
• Unknown - User was identified by an unknown source
• Portal - User was identified by the Captive Portal
• Identity Agent - User/computer was identified by an Identity
Awareness Agent
•
AD Query - User was identified by AD Query
groups <group name> Display all sessions of users / computers that are members of
the given group name
Identity Awareness Commands
Command Line Interface Reference Guide R77 | 130
Parameter
Description
cv_ge <version>
Display all sessions that are connected with a client version that
is higher than (or equal to) the given version
cv_le <version> Display all sessions that are connected via a client version that
is lower than (or equal to) the given version.
Example
pdp monitor ip 192.0.2.1
Shows the connected user behind the given IP address (192.0.2.1).
Note - The last field "Published " indicates whether the session information was
already published to the Gateway PEPs whose IP addresses are listed.
pdp connections
Description These commands assist in monitoring and synchronizing the communication
between the PDP and the PEP.
Syntax pdp connections <argument>
Argument
Description
pep Shows the connection status of all the PEPs that should be updated by the
current PDP
ts Shows a list of terminal servers that are connected
ifmap Shows a list of the active IFMAP sessions
pdp control
Description Provides commands to control the PDP process.
Syntax # pdp control <parameter> <option>
Parameter
Description
revoke_ip <IP
address> Log out the session that is related to the given IP.
revoke_pt_key
<session id.> Revoke the packet tagging key if one exists.
sync Force an initiated synchronization operation between the PDPs and the
PEPs. When running this command, the PDP will inform its related PEPs
the up-to-date information of all connected sessions. At the end of this
operation, the PDP and the PEPs will contain the same and latest session
information.
pdp network
Description Shows information about network related features.
Identity Awareness Commands
Command Line Interface Reference Guide R77 | 131
Syntax # pdp network <parameter>
Parameter
Description
info Display a list of networks known by the PDP.
registered
Display the mapping of a network address to registered gateways (PEP module).
pdp debug
Description Activates and deactivates the debug logs of the PDP daemon.
Syntax # pdp debug <parameter> <option>
Parameter
Description
on Turn on the debug logs (should be followed by the command "set" to
determine the required filter).
off Turn off the debug logs.
set <topic name>
[critical|surprise
|
important|events|
all]…
Filter the debug logs that would be written to the debug file according
to the given topic and severity
For debug it is recommended to run:
pdp debug set all all
Note that you can place a number of topics and severity pairs.
For example: topicA severityA topicB severityB ...
unset <topic name>…
Unset a specific topic or topics.
stat Show the status of the debug option.
reset Reset the debug options of severity and topic. The debug is still
activated after running this command.
rotate Rotate the log files (increase the index of each log file) so that the
current log file that will be written is the PDP log. For example,
pdpd.elg becomes pdpd.elg.0 and so on.
ccc [on|off]
Allows enabling or disabling writing of the CCC debug logs into the PDP
log file.
Important - Activating the debug logs affects the performance of the daemon.
Make sure to turn off the debug after you complete troubleshooting.
pdp tracker
Description Adds the TRACKER topic to the PDP logs (on by default). This is very useful when
monitoring the PDP-PEP identity sharing and other communication on distributed environments.
This can be set manually by adding the TRACKER topic to the debug logs.
Syntax # pdp tracker <parameter>
Identity Awareness Commands
Command Line Interface Reference Guide R77 | 132
Parameter
Description
on Turns on logging of TRACKER events in the PDP log.
off Turns off the logging of TRACKER events in the PDP log.
pdp status
Description Displays PDP status information such as start time or configuration time.
Syntax # pdp status <parameter>
Parameter
Description
show Display PDP information.
pdp update
Description Initiates a recalculation of group membership for all users and computers. Note
that deleted accounts will not be updated.
Syntax # pdp update <parameter>
Parameter
Description
all Recalculate group membership for all users and computers.
pdp ad associate
Description For AD Query, adds an identity to the Identity Awareness database on the Security
Gateway. The group data must be in the AD.
Syntax # pdp ad associate ip <ip> u <username> d <domain> [m <machine>] [t
<timeout>] [s]
Parameter
Description
ip <ip> IP address for the identity.
u <username> Username for the identity.
m <machine> Computer that is defined for the identity.
d <domain> Domain of the ID server.
t <timeout> Timeout setting for the AD Query (default is 5 hours).
s Associates u <username> and m <machine>
parameters sequentially.
First the <machine> is added to the database and then the <username>
.
pdp ad disassociate
Description Removes the identity from the Identity Awareness database on the Security
Gateway. Identity Awareness does not authenticate a user that is removed.
Syntax # pdp ad disassociate ip <ip> {u <username>|m <machine>} [r
{probed|override|timeout}]
Identity Awareness Commands
Command Line Interface Reference Guide R77 | 133
Parameter
Description
ip <ip> IP address for the identity
u <username> Username for the identity
m <machine> Computer that is defined for the identity
t <timeout> Timeout setting for the AD Query (default is 5 hours)
r
{probed|override
|timeout}
Reason that is shown in the SmartView Tracker logs
pep
Description Provides commands to control and monitor the PEP process.
Syntax # pep [command]... <argument>
Parameter
Description
tracker Tracker options.
show Display PEP information.
pep show
Description Displays information regarding pep status.
Syntax # pep show <parameter> <option>
pep show user
Description Enables monitoring the status of sessions that are known to the PEP. You can
perform varied queries according to the usage below to get the output you are interested in.
Syntax # pep show user all
Parameter
Description
all Display all sessions with information summary.
Query Syntax # pep show user query <parameter>
Parameter
Description
usr <username> Display session information for the given user name.
mchn <computer
name> Display session information for the given computer name.
cid <IP> Display session information for the given IP.
uid <uidString> Display session information for the given session ID.
Identity Awareness Commands
Command Line Interface Reference Guide R77 | 134
Parameter
Description
pdp <IP> Display all session information that was published from the given PDP IP.
ugrp <group> Display all sessions of users that are members of the given user group
name.
mgrp <group> Display all sessions of computers that are members of the given
computer group name.
Note - You can use multiple query tokens (parameters) at once to create a
logical "AND" correlation between them. For example, to display all users that
have a sub string of "jo" AND are part of the user group "Employees" then you
can use:
# pep show user query usr jo ugrp Employees
pep show pdp
Description Enables monitoring the communication channel between the PEP and the PDP. The
output displays the connect time and the number of users that were shared through the
connection.
Syntax # pep show pdp <parameter>
Parameter
Description
all List all the PDPs that are connected to the current PEP with the relevant
information.
id <IP> Display connection information of the given PDP IP.
pep show stat
Description Shows the last time the daemon was started and the last time a policy was
received.
Important - Each time the daemon starts, it loads the policy and the two timers
(Daemon start time and Policy fetched at) will be very close.
Syntax # pep show stat
pep show network
Description Shows network related information.
Syntax # pep show network <parameter>
Parameter Description
pdp Shows information about mapping between the network and PDPs.
registratio
n Shows which networks this PEP is registered to.
Identity Awareness Commands
Command Line Interface Reference Guide R77 | 135
pep debug
Description See pdp debug (on page 131).
adlog
Description Provides commands to control and monitor the AD Query process.
When AD Query runs on a Security Gateway, AD Query serves the Identity Awareness feature that
gives logging and policy-enforcement. In this case the command line is: adlog a <argument>
(see below for options)
When it runs on a Log Server, AD Query gives identity logging. In this case, the command line is:
adlog l <argument>. Note: the l in adlog l is a lowercase L.
Options for adlog a and adlog l are identical.
Syntax # adlog {a|l} <command>… <argument>
Parameter
Description
<none> Display available options for this command and exit.
{a|l} Set the working mode:
adlog a - if you are using AD Query for Identity Awareness.
adlog l - if you are using a Log Server (identity logging)
query
See sections below.
debug
dc
statistics
control
control muh
control
srv_account
adlog query
Description Shows the database of identities acquired by AD Query, according to the given filter.
Usage adlog [a|l] query <argument>
Syntax
Parameter
Description
ip <IP address> Filters identities relating to the given IP.
Identity Awareness Commands
Command Line Interface Reference Guide R77 | 136
Parameter
Description
string <string> Filters identity mappings according to the given string.
user <user name> Filters identity mappings according to a specific user.
machine
<computer name> Filters identity mappings according to a specific computer.
all No filtering, shows the entire identity database.
Example
adlog a query user jo
Shows the entry that contains the string "jo" in the user name.
adlog dc
Description Shows status of connection to the AD domain controller.
Usage adlog [a|l] dc
Syntax None
adlog statistics
Description Displays statistics regarding NT Event Logs received by adlog, per IP and by total. It
also shows the number of identified IPs.
Usage adlog [a|l] statistics
Syntax None
adlog debug
Description Turns on/off debug flags for controlling the debug file. The debug file is located at
$FWDIR/log/pdpd.elg (for Identity Awareness on a Security Gateway) or $FWDIR/log/fwd.elg (for
identity logging on a log server).
Usage adlog [a|l] debug <parameter>
Syntax
Parameter
Description
on Turn on debug.
off Turn off debug.
mode Show debug status (on/off).
extended Turn on debug and add extended debug topics.
adlog control
Description Sends control commands to AD Query.
Identity Awareness Commands
Command Line Interface Reference Guide R77 | 137
Usage adlog {a|l} control <parameter>
Syntax
Parameter
Description
stop Stop AD Query. New identities are not acquired via AD Query.
reconf Send a reconfiguration command to AD Query, which means it resets to policy
configuration as was set in SmartDashboard.
adlog service_accounts
Description Shows accounts that are suspected to be "service accounts". Service accounts are
accounts that don’t belong to actual users, rather they belong to services running on a computer.
They are suspected as such if they are logged in more than a certain number of times.
Usage adlog [a|l] service_accounts
Syntax None
test_ad_connectivity
Description Runs connectivity tests from the Security Gateway to an AD domain controller.
Syntax $FWDIR/bin/test_ad_connectivity <parameter_1 value_1> <parameter
value_2> … <parameter_n value_n>
Parameters can be set in the command line as specified below, or set in a text file located at
$FWDIR/conf/test_ad_connectivity.conf . Parameters set in the
test_ad_connectivity.conf file are overridden by ones provided in the command line.
Important - Parameters set in $FWDIR/conf/test_ad_connectivity cannot
contain whitespaces and cannot be within quotation marks.
Output of the utility is provided in a file (not to STDOUT). The path of the file is specified by the –o
parameter (see below).
Syntax
Parameter
Mandatory?
Description
-d <domain name> Mandatory Domain name of the AD, for example
ad.checkpoint.com
-i <DC IP> Mandatory IP of the domain controller that is being tested.
-u <user name> Mandatory Administrator user name on the AD.
-o <filename> Mandatory Output filename relative to $FWDIR/tmp. For example,
if you specify -o myfile, the output will be in
$FWDIR/tmp/myfile
Identity Awareness Commands
Command Line Interface Reference Guide R77 | 138
Parameter
Mandatory?
Description
-c <password
clear> Either this or -a
should be
specified
User’s password.
-a Either this or -c
should be
specified
For entering password via stdin.
-t <timeout> Mandatory Total timeout in milliseconds.
-D <user DN> Optional Use this for LDAP user DN override (the utility won’t try
to figure out the DN automatically).
-l Optional Run LDAP connectivity test only (no WMI test).
-w Optional Run WMI connectivity test only (no LDAP test).
-s Optional SSL Parameters file path.
-L Optional Timeout for the LDAP test only. If this timeout expires
and the LDAP test doesn’t finish, both tests fail.
-h Optional Show help.
Command Line Interface Reference Guide R77 | 139
CHAPT ER 8
IPS Commands
In This Section:
Overview ...................................................................................................................... 139
ips bypass stat ............................................................................................................ 139
ips bypass on|off ......................................................................................................... 139
ips bypass set .............................................................................................................. 140
ips debug ..................................................................................................................... 140
ips pmstats .................................................................................................................. 141
ips pmstats reset ........................................................................................................ 141
ips refreshcap ............................................................................................................. 141
ips stat ......................................................................................................................... 141
ips stats ....................................................................................................................... 142
Overview
Description - IPS commands let you configure and show the IPS on the Security Gateway without
installing a new policy.
Comments - Changes in the IPS configuration are not persistent. If you install a policy or restart
the computer, the changes are deleted.
ips bypass stat
Description - Shows the status of the bypass mode.
Usage- ips bypass stat
Comments - Shows this information:
• IPS bypass mode - on or off
• CPU thresholds
• Memory thresholds
ips bypass on|off
Description - Manages IPS bypass. When IPS bypass is enabled:
• If the CPU or memory goes above the high threshold, IPS enters bypass mode and is
automatically disabled.
• When the CPU or memory goes below the low threshold, IPS exits bypass mode and is
automatically enabled.
Usage - ips bypass {on|off}
IPS Commands
Command Line Interface Reference Guide R77 | 140
Syntax
Parameter Description
on
IPS bypass is enabled.
off
IPS bypass is disabled.
Example- ips bypass on
ips bypass set
Description - Configures the thresholds for the ips bypass command.
Usage - ips bypass set {cpu|mem} {low|high} <th>
Syntax
Parameter
Description
cpu
Configure the CPU threshold
mem
Configure the memory threshold.
low
Configure the lower threshold to exit bypass mode.
high
Configure the higher threshold to enter bypass mode.
<th>
The CPU or memory threshold value.
Example - ips bypass set cpu low 80
ips debug
Description - Shows the IPS debug information.
Usage - ips debug [-e <filter>] -o <outfile>
Syntax
Parameter
Description
-e
Filters which packets are captured.
<filter>
Uses a subset of INSPECT to specify which packets are captured.
-o <outfile>
Outputs the debug information to the file <outfile>.
Example - ips debug -o sampledebug
IPS Commands
Command Line Interface Reference Guide R77 | 141
ips pmstats
Description - Shows statistics about the pattern matcher. These statistics are shown for each
pattern:
• Memory
• CPU usage
• Compilation time
Usage - ips pmstats -o <outfile>
Syntax
Parameter
Description
-o <outfile>
Outputs the debug information to the file <outfile>.
Example - ips pmstats -o samplefile
ips pmstats reset
Description - Resets the data that is collected to calculate the pmstat statistics.
Usage - ips pmstats reset
ips refreshcap
After installing a new policy, IPS captures the first packet for each protection and saves it in the
packet capture repository.
Description - Refreshes the packet capture repository. IPS designates the next packet of each
protection as the first packet. The new first packet replaces the previous one in the packet capture
repository.
Usage - ips refreshcap
ips stat
Description - Shows the IPS status of these items:
• IPS enabled or disabled
• Active profile
• Update version
• Global detect mode - on or off
• Bypass mode - on or off
Syntax - ips stat
IPS Commands
Command Line Interface Reference Guide R77 | 142
ips stats
Description - Print IPS and Pattern Matcher performance statistics. Without arguments, runs on
current gateway for 20 seconds. This is a resource intensive command and should not be run on a
system experiencing a high load.
Usage - ips stats [<ip_address> -m] [-g <seconds>] [<ip_address> <seconds>]
Syntax
Parameter
Description
-m Analyzes input statistics file from gateway. Give IP address of the gateway. Run
from the Security Management Server.
-g Collect statistics for current gateway.
seconds Period in which statistics are gathered
Examples
ips_stats 192.0.2.14 40
Run statistics on gateway with address 192.0.2.14 for 40 seconds
ips_stats –g 30
Run the statistics on the current gateway for 30 seconds
ips_stats 192.0.2.14 –m
Analyze the statistics taken from the gateway with address 192.0.2.14
Index
A
Adding a Rule • 17
Adding a Rule - Middle of Rule Base • 18
adlog • 135
adlog control • 136
adlog dc • 136
adlog debug • 136
adlog query • 135
adlog service_accounts • 137
adlog statistics • 136
C
Changing a Rule • 17
Changing a Rule Base • 17
CLI Commands for Software Blades • 9
CLI Commands in Other Guides • 9
ClusterXL Commands • 125
comp_init_policy • 22
Configuring and Deleting a Network Group • 15
Configuring and Deleting a Service Group • 16
Configuring Automatic NAT • 14
cp_admin_convert • 22
cp_conf • 26
cp_conf admin • 27
cp_conf auto • 29
cp_conf ca • 27
cp_conf client • 28
cp_conf finger • 28
cp_conf ha • 29
cp_conf lic • 28
cp_conf sic • 27
cp_conf snmp • 29
cp_conf sxl • 30
cp_merge • 39
cp_merge delete_policy • 39
cp_merge export_policy • 40
cp_merge import_policy and cp_merge
restore_policy • 41
cp_merge list_policy • 42
cpca_client • 22
cpca_client create_cert • 22
cpca_client double_sign • 26
cpca_client get_crldp • 26
cpca_client get_pubkey • 26
cpca_client init_certs • 24
cpca_client lscert • 23
cpca_client revoke_cert • 23
cpca_client search • 25
cpca_client set_mgmt_tool • 24
cpca_client set_sign_hash • 25
cpconfig • 30
cphaconf • 125
cphaprob • 126
cphastart • 126
cphastop • 127
cpinfo • 30
cplic • 31
cplic check • 31
cplic db_add • 32
cplic db_print • 33
cplic db_rm • 33
cplic del • 34
cplic del <object name> • 34
cplic get • 34
cplic print • 37
cplic put • 35
cplic put <object name> ... • 36
cplic upgrade • 38
cppkg • 42
cppkg add • 42
cppkg delete • 43
cppkg get • 44
cppkg getroot • 44
cppkg print • 44
cppkg setroot • 44
cpridrestart • 45
cpridstart • 45
cpridstop • 45
cprinstall • 46
cprinstall boot • 46
cprinstall cpstart • 46
cprinstall cpstop • 46
cprinstall get • 47
cprinstall install • 47
cprinstall revert • 50
cprinstall show • 50
cprinstall snapshot • 50
cprinstall transfer • 51
cprinstall uninstall • 48
cprinstall verify • 49
cpstart • 51
cpstat • 51
cpstop • 53
cpwd_admin • 54
cpwd_admin config • 55
cpwd_admin exist • 55
cpwd_admin kill • 55
cpwd_admin list • 55
cpwd_admin start • 54
cpwd_admin stop • 54
Create or Modify Policy Objects (Hosts,
Networks) • 13
Creating a Domain Management Server • 10
Creating a Host • 14
Creating a Network • 13
Creating a Network Group • 15
Creating a Service • 15
Creating a Service Group • 16
Creating an Address Range • 14
D
dbedit • 57
Page 144
dbver • 59
dbver create • 59
dbver export • 60
dbver import • 60
dbver print • 60
dbver print_all • 60
disconnect_client • 57
dynamic_objects • 61
E
Error Codes in dbedit • 20
F
fw • 61
fw ctl • 62
fw ctl affinity • 64
fw ctl affinity -l • 65
fw ctl affinity -s • 64
fw ctl debug • 63
fw ctl engine • 66
fw ctl multik stat • 67
fw ctl sdstat • 67
fw fetch • 68
fw fetchlogs • 69
fw hastat • 70
fw -i • 61
fw isp_link • 70
fw kill • 70
fw lea_notify • 71
fw lichosts • 71
fw log • 71
fw logswitch • 74
fw lslogs • 75
fw mergefiles • 76
fw monitor • 77
fw monitor Filters • 80
fw putkey • 83
fw repairlog • 84
fw sam • 84
fw stat • 88
fw tab • 88
fw ver • 90
fwm • 90
fwm dbexport • 92
fwm dbimport • 90
fwm dbload • 93
fwm expdate • 92
fwm getpcap • 94
fwm ikecrypt • 94
fwm load • 95
fwm lock_admin • 95
fwm logexport • 95
fwm sic_reset • 97
fwm unload <targets> • 97
fwm ver • 97
fwm verify • 97
G
GeneratorApp • 98
I
Identity Awareness Commands • 128
Important Information • 3
inet_alert • 98
Installing Policy with a Multi-Domain Server •
20
Introduction • 128
Introduction to Automation Scripts • 10
Introduction to dbedit • 11
ips bypass on|off • 139
ips bypass set • 140
ips bypass stat • 139
IPS Commands • 139
ips debug • 140
ips pmstats • 141
ips pmstats reset • 141
ips refreshcap • 141
ips stat • 141
ips stats • 142
L
Launching the dbedit Utility • 11
ldapcmd • 100
ldapcompare • 101
ldapconvert • 102
ldapmodify • 104
ldapsearch • 105
Locking the Database • 12
log_export • 106
N
Network Groups • 15
Networks • 13
O
Object Naming Restrictions • 16
Overview • 113, 120, 139
P
pdp • 128
pdp ad associate • 132
pdp ad disassociate • 132
pdp connections • 130
pdp control • 130
pdp debug • 131
pdp monitor • 129
pdp network • 130
pdp status • 132
pdp tracker • 131
pdp update • 132
pep • 133
pep debug • 135
pep show • 133
Page 145
pep show network • 134
pep show pdp • 134
pep show stat • 134
pep show user • 133
Pushing the Security Policy to Security
Gateways • 19
Q
queryDB_util • 109
R
Renaming and Deleting a Service • 16
Renaming and Deleting Objects • 14
rs_db_tool • 110
rtm debug • 120
rtm drv • 120
rtm monitor • 121
rtm rtmd • 123
rtm stat • 123
rtm ver • 123
rtmstart • 124
rtmstop • 124
Running CLI Commands in Automation Scripts
• 10
S
sam_alert • 111
Security Management Server and Firewall
Commands • 21
Service Groups • 16
Services • 15
Showing Parameters for a Sample Object • 12
SmartView Monitor Commands • 120
svr_webupload_config • 112
T
test_ad_connectivity • 137
U
Using Automation Scripts • 12
Using dbedit Commands in a Script • 11
Using XML to Export Settings for a Domain
Management Server • 20
V
VPN Commands • 113
vpn crl_zap • 113
vpn crlview • 113
vpn debug • 114
vpn drv • 115
vpn export_p12 • 115
vpn macutil • 116
vpn nssm_toplogy • 116
vpn overlap_encdom • 117
vpn sw_topology • 118
vpn tu • 118
vpn ver • 119
W
Working with dbedit • 11
