Liebherr

02/24/2007

Item Reference no. Number Description Price

10 7042971 2 ADJUSTING SCREW 009

11 7790791 1 CASTOR BASE

12 7790789 1 CASTOR BASE

13 4082795 8 OVAL-HEAD SELF-TAPPING SCREW 002

20 7113073 1 BOLT 004

21 2884989 1 SLEEVE

30 7424295 1 VARIOUS HOUSINGS 012

31 4082704 2 OVAL-HEAD SELF-TAPPING SCREW 002

32 4098779 1 PT SCREW 001

35 6021021 1 DISTRIBUTOR STRIP 012

40 7424293 1 ELECTRONICS COVER 012

41 4098026 2 SCREW IN ACC. WITH DRAWING

50 7422558 2 VARIOUS INJECTION-MOULDED ITEMS 009

51 4098196 4 OVAL-HEAD SELF-TAPPING SCREW 003

60 6118781 1 COMPACT FAN 022

61 6118779 1 COMPACT FAN 022

70 7424773 2 VARIOUS RETAINING FIXTURES 001

80 7266079 4 BUFFER 006

90 7743601 2 REFLECTOR 010

100 6072799 2 LAMPHOLDER 013

110 7402675 2 SEALING RINGS 006

120 6070797 2 INCANDESCENT BULB 012

130 4082915 8 COUNTERSUNK SELF-TAPPING SCREW 002

140 5940957 1 REFRIGERATOR EVAPORATOR, SPEC. DESIGN 023

150 7744087 1 SPECIAL SECURING HARDWARE 009

160 4098789 2 SCREW IN ACC. WITH DRAWING 001

170 7412220 2 COVER CAP 001

180 7422032 4 EVAPORATOR FIXTURE 003

190 7640528 2 COVER PROFILE TRIM 008

200 7424655 1 FAN COVER PRE-ASSEMBLED 019

210 4082807 2 OVAL-HEAD SELF-TAPPING SCREW 003

220 7402624 2 PLUG 005

230 7271513 1 TOUGHENED SAFETY-GLASS PLATE 013

240 7424881 1 COVERS, VARIOUS 012

250 4098196 2 OVAL-HEAD SELF-TAPPING SCREW 003

280 7424653 1 OPERATING PANEL HOUSING 012

290 7424960 9 BUTTON 005

300 7428761 1 OPERATING UNIT TRIM 015

310 6113775 1 OPERATING UNIT BOARD 022

320 6113425 1 POWER BOARD 034

330 6942042 1 AIR SENSOR FOR REFRIGERATOR COMPARTMENT 014

340 6942100 1 EVAPORATOR SENSOR FOR REFRIGERATOR

350 6942108 1 AIR SENSOR FOR FREEZER COMPARTMENT

360 6942799 1 SENSOR FOR FREEZER COMPARTMENT CONDENSER 013

362 5940799 1 REFRIGERATOR EVAPORATOR, SPEC. DESIGN 027

364 8003791 1 MOULDING 009

366 8003086 2 MOULDING 008

368 7640611 1 VARIOUS RETAINING FIXTURES 016

370 6152010 1 TEMPERATURE LIMITER

371 7640613 1 VARIOUS RETAINING FIXTURES 017

373 7424649 1 DIVIDING WALL 022

374 4098100 4 PT SCREW 003

375 7271529 1 TOUGHENED SAFETY-GLASS PLATE 012

376 6113616 1 REED BOARD 010

377 7424719 1 COVERS, VARIOUS 012

378 4082807 2 OVAL-HEAD SELF-TAPPING SCREW 003

379 9873683 1 FIN-TYPE EVAPORATOR 030

380 6119747 1 COMPRESSOR R 134 a 043

390 6133074 2 INTEGRAL BOARD 027

400 4098044 2 OVAL-HEAD SELF-TAPPING SCREW 004

410 7426680 2 EVAPORATOR TRAYS 007

420 6119745 1 COMPRESSOR R 134 a 043

Liebherr

02/24/2007

450 7266797 8 SPECIAL SECURING HARDWARE 002

451 4229503 6 WASHER 003

452 7203799 6 VARIOUS RETAINING FIXTURES 003

460 7700001 2 PIPE 007

470 6009795 1 SUPPLY LINE 013

480 9941799 1 HOSE 010

490 7412634 1 VARIOUS RETAINING FIXTURES 006

500 5941717 1 CONDENSER FIN 023

501 7427453 1 VARIOUS RETAINING FIXTURES 004

510 4098124 6 SCREW IN ACC.WITH DRAWING 003

520 5942034 1 DRYER

530 7271907 1 GLASS PLATE - COMPLETE 016

540 7271905 1 GLASS PLATE - COMPLETE 015

550 7271903 2 GLASS PLATE - COMPLETE 018

560 7271595 1 GLASS PLATE - COMPLETE 018

570 7271783 1 GLASS PLATE - COMPLETE 019

580 7640659 5 TRIM STRIP PROFILE 010

590 7422015 5 RETAINING STRIP FOR GLASS PLATES 009

600 7426440 8 PLUG

610 7112615 1 GRID SHELF 019

640 9790121 1 DRAWER, NON-PRINTED 018

650 9790135 1 DRAWER-COMPLETE 018

660 9790137 1 DRAWER-COMPLETE 018

670 7402463 3 DRAWER TRIM, NON-PRINTED 013

680 7430212 1 DRAWER TRIM, PRINTED 008

690 7430214 1 DRAWER TRIM, PRINTED 008

700 7430216 1 DRAWER TRIM, PRINTED 008

710 7402565 2 DRAWER BODY 016

720 7402563 1 DRAWER BODY 015

721 7271505 2 TOUGHENED SAFETY-GLASS PLATE 013

730 9012469 1 DOOR, CAVITY-FOAMED 033

740 7424665 8 BUSHING 002

750 7108501 1 GASKET EXCHANABLE

760 7424619 4 COVERS, VARIOUS 016

770 7042459 1 ZINC DIE-CAST BEARING BLOCK 010

780 7113144 1 BOLT 006

790 7424613 1 BUSHING 002

800 4082716 2 OVAL-HEAD SELF-TAPPING SCREW 003

821 7402016 1 WASHER 001

830 9012129 1 DOOR, MOUNTED 040

840 7108499 1 GASKET EXCHANABLE

860 9101027 1 VARIOUS INJECTION-MOULDED ITEMS 013

870 7426768 1 FASTENING 008

880 7426770 1 FASTENING 008

890 7112665 1 WIRE BRACKET/GLASS-LINE DOOR 010

900 7426772 1 FASTENING 008

910 7426774 1 FASTENING 008

920 7112667 2 WIRE BRACKET/GLASS-LINE DOOR 010

930 7426776 2 FASTENING 008

940 7426778 2 FASTENING 008

950 7112669 1 WIRE BRACKET/GLASS-LINE DOOR 010

960 7426198 1 VARIOUS RETAINING FIXTURES 009

970 7112573 1 WIRE BRACKET/GLASS-LINE DOOR 012

980 7112571 1 WIRE BRACKET/GLASS-LINE DOOR 012

990 7426202 1 VARIOUS RETAINING FIXTURES 009

1000 7271745 4 GLASS PLATE - COMPLETE 013

1010 7640549 4 TRIM STRIP PROFILE 010

1020 9450793 1 HINGE, COMPLETE 016

1030 7113077 1 BOLT 004

1040 4084011 4 OVAL-HEAD SCREW 001

1041 7422157 1 WASHER 001

1050 7430150 1 MOULDED HANDLE 017

1060 7430142 1 MOULDED HANDLE

Liebherr

02/24/2007

1070 4098136 8 SCREW IN ACC.WITH DRAWING 001

1071 7426630 4 VARIOUS INJECTION-MOULDED ITEMS 008

1080 7402612 8 PLUG 001

1100 7042519 1 HINGE PLATE 013

1110 4084404 2 COUNTERSUNK SCREW 001

1120 9292799 1 KEY 006

1140 9041793 1 PRESSURE COMPENSATION VALVE 010

1150 7424565 2 VARIOUS INJECTION-MOULDED ITEMS 007

1160 7424567 1 VARIOUS INJECTION-MOULDED ITEMS 006

1170 7424569 1 VARIOUS INJECTION-MOULDED ITEMS 006

1180 7890048 2 DRAWER RAIL 013

1190 4098188 4 OVAL-HEAD WOOD SCREW 004

1210 7424611 1 DRAWER, NON-PRINTED 020

1220 7424607 1 DIVIDING WALL 012

1230 7743123 2 011

1231 4098124 4 SCREW IN ACC.WITH DRAWING 003

1232 4082791 2 OVAL-HEAD SELF-TAPPING SCREW 001

9899 ------- 0

9901 9900813 1 VENTILATION TRIM 021

9910 7080361 1 OPERATING INSTRUCTIONS 098

9911 7080009 1 OPERATING INSTRUCTIONS 098

9920 9880643 1 PACKAGING, COMPLETELY 026

9930 8041625 1 FOLDING CARDBOARD BOX 018

9950 8409989 1 STAINLESS STEEL CLEANER CHROMOL 50ML
