Copyright 2004 Carrier Corporation Form 48H,T-6PD
Standard-Efficiency (TM) units
meet minimum ASHRAE 90.1 ener-
gy efficiency requirements. High-
Efficiency (HJ) units well exceed
ASHRAE 90.1 energy efficiency
requirements. Gas heating with
electric cooling rooftop units offer:
• Pre-painted galvanized steel cabinet
for long life and quality appearance
• Commercial strength base rails with
built-in rigging capability
• Convertible design for vertical or hori-
zontal supply/return (004-014 only)
• Non-corrosive, sloped condensate
drain pan, meets ASHRAE 62 (IAQ)
• Two-inch return-air filters
• A wide assortment of factory-installed
options available, including high-static
drives that provide additional
performance range
• Optional factory-installed COBRA™
energy recovery unit (option on
48HJ004-014 units only)
• Factory-installed PremierLink™
digital communicating controls
• Factory-installed optional gear driven
EconoMi$er IV (vertical return for
sizes 004-012 only) for use with
standard rooftop unit controls
(includes CO2sensor control
capability)
• Factory-installed optional gear driven
EconoMi$er2 (vertical return only) for
use with PremierLink DDC controls
(includes 4 to 20 mA actuator for
demand control ventilation)
• Humidi-MiZer™ adaptive dehumidi-
fication system (48HJ004-014)
• MoistureMi$er™ dehumidification
package
Heat Options
• Exclusive integrated gas control
board with diagnostics
• Alumagard™ heat exchanger coating
• Induced-draft fan for gas combustion
• Tubular, dimpled heat exchangers
• Natural gas
•LPconversionkits
•LowNO
X(size 004-006 only)
• Optional stainless steel heat
exchangers.
WEATHERMAKER® 48TM004-028
WEATHERMASTER® 48HJ004-028
Single-Package Rooftop Units
Gas Heating/Electric Cooling
3 to 25 Nominal Tons
Product
Data
48HJ004-014
48TM004-014
48HJ015,017
48TM016-025
48TM028
905
→
2
Features/Benefits
Every compact one-piece
unit arrives fully assembled,
charged, tested, and ready to
run.
48 Series — gas heat models
All ignition components are contained
in the compact IGC (integrated gas
controller) which is easily accessible for
servicing. The IGC control board, de-
signed and manufactured exclusively
for Carrier rooftop units, provides
built-in diagnostic capability. An LED
(light-emitting diode) simplifies trouble-
shooting by providing visual fault notifi-
cation and system status confirmation.
The IGC also contains an exclusive
anti-cycle protection for gas heat oper-
ation. After 4 continuous cycles on the
unit high-temperature limit switch, the
gas heat operation is disabled, and an
error code is issued. This feature great-
ly improves reliability of the rooftop
unit.
The IGC also contains burner con-
trol logic for accurate and dependable
gas ignition. The LED is visible without
removing the unit control box access
panel. This LED fault-notification sys-
tem reduces service person trouble-
shooting time and minimizes service
costs. The IGC also maximizes heating
efficiency by controlling evaporator-fan
on and off delays.
Tubular, dimpled gas heat exchang-
ers optimize heat transfer for improved
efficiency. The tubular design permits
hot gases to make multiple passes
across the path of the supply air. The
dimpled design creates a turbulent gas
flow to maximize heating efficiency.
The efficient in-shot burners and
all ignition components are contained
in an easily removable, compact
assembly.
The California Air Quality Manage-
ment Districts NOx requirement of
40 nanograms/joule or less is met on
004-006 size Low NOx models.
The extra thick Alumagard™ heat
exchanger coating provides corrosion
resistance and ensures long life
(optional stainless steel heat exchang-
ers are available).
The unsightly appearance of flue
stacks is eliminated and the effects of
wind on heating operations are dimin-
ished by the induced draft combustion
Table of contents
Page
Features/Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Model Number Nomenclature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-10
ARI Capacity Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-17
Options and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-27
48TM
Physical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-33
Base Unit Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34-39
Accessory Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40-45
Selection Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46,47
Performance Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48-93
Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94-98
Typical Wiring Schematics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99-104
Typical Piping and Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105,106
Guide Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107-118
48HJ
Physical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119-127
Base Unit Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128-135
Accessory Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136-143
Selection Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144-146
Performance Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147-219
Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 220-230
Typical Wiring Schematics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 231-241
Typical Piping and Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 242,243
Guide Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 244-267
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268-279
Application Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 280-284
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 285
3
system. The inducer fan draws hot
combustion gas through the heat
exchanger at the optimum rate for the
most effective heat transfer. The heat
exchanger operates under negative
pressure, preventing flue gas leakage
into the indoor supply air.
During the Heating mode, the
evaporator-fan relay automatically
starts the evaporator fan after the heat
exchanger warms up to a suitable
temperature. The 30-second fan delay
prevents cold air from entering the
supply duct system when the condi-
tioned space is calling for heat to
maximize efficiency.
The direct-spark ignition system
saves operating expense when com-
pared to pilot ignition systems. No
crossover tube is required, therefore no
sooting or pilot fouling problems can
occur.
All standard units are designed for
natural gas, but an accessory LP (liquid
propane) conversion kit is available.
All units have a flame rectification
sensor to quickly sense the burner
flame and ignite burners almost imme-
diately. Fast shutdown is a certainty
since the sensor reacts quickly to any
flame outage or system failure. In the
event of a shutdown, an error code is
issued at the IGC board.
Safety is also assured due to the
heating safety controls which will shut
down the unit if there is a problem. If
excessive temperatures develop, limit
switches shut off the gas valve. After
4 continuous short cycles of the high-
temperature limit switch, the IGC
board locks out the gas heat cycle to
prevent any further short cycles. This
safety feature is provided exclusively on
Carrier rooftop units. The rollout
switch also deenergizes the gas valve in
the event of a flame rollout.
Quiet, efficient operation and
dependable performance
Compressors have vibration isolators
for quiet operation. Efficient fan and
motor design permits operation at low
sound levels.
Unit sizes 008-028 offer lower utility
costs through part-load operation us-
ing 2 or 3 stages of cooling.
Quiet and efficient operation is pro-
vided by belt-driven evaporator fans
(standard on all units over 5 tons). The
belt-driven evaporator-fan is equipped
with variable-pitch pulleys which allow
adjustment within the rpm ranges of
the factory-supplied pulleys.
Increased operating efficiency is
achieved through computer-designed
coils featuring staggered internally
enhanced copper tubes. Fins are
ripple-edged for strength, lanced, and
double waved for higher heat transfer.
Durable, dependable
construction
Designed for durability in any climate,
the weather-resistant cabinets are con-
structed of galvanized steel and bond-
erized, and all exterior panels are coat-
ed with a prepainted baked enamel fin-
ish. The paint finish is non-chalking,
and is capable of withstanding ASTM
(American Society for Testing and Ma-
terials) B117 500-hour Salt Spray
Test. All internal cabinet panels are
primed, permitting longer life and a
more attractive appearance for the
entire unit.
In addition, all size 004-014 units
are designed with a single, continuous
top piece to eliminate any possible
leaks at seams or gasketing. Totally en-
closed condenser-fan motors and per-
manently lubricated bearings provide
additional unit dependability.
Easy installation and
conversion
All units are shipped in the verti-
cal duct configuration for fit-up to
standard roof curbs. The contractor
can order and install the roof curb early
in the construction stage, before deci-
sions on size requirements are made.
All units feature a base rail design
with forklift slots and rigging holes for
easier maneuvering. Durable packag-
ing protects all units during shipment
and storage.
The units can be easily converted
from a vertical to a horizontal duct con-
figuration by relocating the panels sup-
plied with the unit (size 004-014 only).
To convert 004-014 units from
vertical to horizontal discharge, simply
relocate 2 panels. The same basic unit
can be used for a variety of applica-
tions and can be quickly modified at
the jobsite.
To convert 015-028 units from
vertical to horizontal discharge, use the
optional horizontal supply/return
adapter roof curb (48HJ015,017 and
48TM016-028) or accessory conver-
sion kit (48HJ020-028).
Convenient duct openings in the
unit basepans permit side-by-side or
concentric duct connections (see
Application data section) without re-
quiring internal unit modification.
NOTE: On units using horizontal sup-
ply and return, the accessory baromet-
ric relief or power exhaust MUST be
installed on the return ductwork.
Thru-the-bottom service connec-
tion capability comes standard with
the rooftop unit to allow power and
control wiring and gas connections to
be routed through the unit’s basepan,
thereby minimizing roof penetrations
(to prevent water leaks). (Thru-the-
bottom gas connection requires thru-
the-bottom accessory kit.) Power, gas
and control connections are made on
the same side of the unit to simplify
installation.
The non-corrosive sloped conden-
sate drain pan (size 004-014)
permits either an external horizontal
side condensate drain (outside the roof
curb) or an internal vertical bottom
drain (inside the roof curb). Both
options require an external, field-
supplied P-trap.
Standard 2-in. throwaway filters
are easily accessed through a remov-
able panel located above the air intake
hood. No tools are required to change
unit filters.
Belt-driven evaporator-fan motors
(optional on TM units under 6 tons)
allow maximum on-site flexibility with-
out changing motors or drives.
Low voltage wiring connections
are easily made thanks to the large ter-
minal board which is located for quick,
convenient access.
In addition, color-coded wires permit
easy tracing and diagnostics.
Proven compressor reliability
Design techniques feature computer-
programmed balance between com-
pressor, condenser, and evaporator.
Carrier-specified hermetic compres-
sors are equipped with compressor
overcurrent and overtemperature pro-
tection to ensure dependability.
4
All units have Carrier’s exclusive
Acutrol™ (004-014) or TXV (thermo-
static expansion valve) metering device
(015-028) which precisely controls re-
frigerant flow, preventing
slugging and flood-back, while main-
taining optimum unit performance. Re-
frigerant filter driers are standard.
Integrated economizers and
outdoor-air dampers
Available as options or accessories,
economizers and manual outdoor-air
dampers introduce outdoor air which
mixes with the conditioned air, improv-
ing indoor-air quality and often reduc-
ing energy consumption.
During a first stage call for cooling, if
the outdoor-air temperature is below
the economizer control changeover
set point, the mixed-air sensor modu-
lates the economizer outdoor-air damp-
er open to take advantage of free cool-
ing provided by the outside air. When
second-stage cooling is called for, the
compressor is energized in
addition to the economizer. If the
outdoor-air temperature is above the
changeover set point, the first stage
of compression is activated and the
economizer damper stays at minimum
position.
Accessory upgrade kits allow for
control by differential dry-bulb temper-
ature (outdoor vs return), outdoor air
enthalpy changeover, or more precise
differential enthalpy control.
Units can be equipped with different
economizer options to meet specific
controls applications. The factory-
installed or field-installed EconoMi$er IV
and EconoMi$er2 are available. The
EconoMi$er IV is used with the stan-
dard rooftop unit controls and includes
an industry standard, stand-alone,
solid-state controller. The control can be
used with a CO2 sensor for DCV (de-
mand control ventilation) operation. For
direct digital control (DDC) applications,
the EconoMi$er2 can be operated using
PremierLink controls or a third party
controller. The EconoMi$er2 includes
4 to 20 mA actuator capability for de-
mand control ventilation applications.
All economizers incorporate a paral-
lel blade, gear-driven damper system
for efficient air mixing and reliable con-
trol. In addition, the standard damper
actuator includes a spring return to
provide reliable closure on power loss.
The economizers for sizes 004-014 are
equipped with up to 100% barometric
relief capability for high outdoor air-
flow operations. Economizers for unit
sizes 004-014 are available, factory-
installed, for vertical return only. Econ-
omizers for unit sizes 015-028 are
compatible for vertical or horizontal re-
turn. An optional field-installed baro-
metric relief package is available for
size 015-028 units.
In addition, single-stage power
exhaust is available as a field-installed
accessory for EconoMi$er IV to help
maintain proper building pressure.
For units without economizer, year-
round ventilation is enhanced by an op-
tional manual outdoor-air damper. On
004-014 units, a 25% or 50% manual
damper is available as a field-installed
accessory. Unit sizes 015-028 are
equipped with a manual 25% damper.
Service options (48HJ004-
017 and 48TM004-028 units
only)
Servicing a rooftop unit has never been
easier with the factory-installed service
options for these rooftop units. These
options include the following:
• Hinged access panels are provided
for the filter/indoor-fan motor,
compressors, evaporator fan, and
control box areas. Quick access to
major components is accomplished
by simply unlatching and swinging
open the various panels. Each
hinged panel is permanently
mounted to the unit, thereby elimi-
nating the concern of a dropped or
wind-blown panel puncturing deli-
cate roof materials. The 4 extended
access panels are also equipped with
‘‘tie back’’ retaining devices to hold
the door in the open position while
servicing the unit.
• An external, covered, 115-v Ground
Fault Interrupt (GFI) receptacle is
provided as a convenient power
source for drills, lights, refrigerant
recovery units, or other electrical
service tools. A factory-supplied step
down transformer is connected to
the “load” side of the unit main
power connection (size 004-014).
For sizes 015-028, connect the out-
let to a field-supplied and properly
fused branch circuit power supply.
• Slide out “motor-drive-blower”
reduces service time (only on
48HJ017).
• An integral non-fused disconnect
switch within the rooftop unit
reduces installation time, labor and
material costs. Safety is assured by
an interlock which prevents access
to the control box unless the switch
is in the OFF position. In addition,
the externally mounted handle
incorporates power lockout capabil-
ity to further protect service
personnel.
Carrier PremierLink™ controls
add reliability, efficiency, and
simplification (48HJ004-017
and 48TM004-028 units only)
The PremierLink direct digital controls
can be ordered as a factory-installed
option or as a field-installed accessory.
Designed and manufactured exclusively
by Carrier, the controls can be used to
actively monitor and control all modes
of operations, as well as monitor the
following diagnostics and features: unit
number, zone temperature, zone set
point, zone humidity set point, dis-
charge air temperatures, fan status,
stages of heating, stages of cooling,
damper position, outdoor-air tempera-
ture, outdoor humidity level, filter
status, fire shutdown status, IAQ (in-
door air quality) set point, enthalpy sta-
tus, differential enthalpy status, heat/
cool lockout, cfm set point, pre-
occupancy purge, economizer controls
and early morning warm-up.
This controller has a 38.4K baud
communications capability and is com-
patible with ComfortLink™ controls,
CCN (Carrier Comfort Network®) and
ComfortVIEW™ software. The Scroll-
ing Marquee and Navigator™ display
are optional tools that can be used for
programming and monitoring the unit
for optimal performance. The addition
of the Carrier CO2 sensor in the condi-
tioned space provides ASHRAE
(American Society of Heating, Refrig-
eration, and Air Conditioning Engi-
neers) 62-99 compliance and Demand
Control Ventilation.
The PremierLink peer-to-peer, Inter-
net ready communicating control is de-
signed specifically for Constant Volume
(CV) and Variable Volume and Temper-
ature (VVT®) applications. This com-
prehensive controls system allows all
Carrier 3 to 25 ton rooftops with a
3-wire communications bus to be daisy
chained together on a roof to create a
fully functional HVAC (heating,
Features/Benefits (cont)
→
905
5
ventilation, and air conditioning) auto-
mation system.
Indoor-air quality (IAQ) begins
with Carrier rooftops
Sloped condensate pans minimize
biological growth in rooftop units in
accordance with ASHRAE Standard
62. Two-inch filters with optional dirty
filter indicator switch provide for
greater particle reduction in the return
air. The face-split evaporator coils
improve the dehumidification capabili-
ty of standard units, maximize building
humidity control.
Optional proportional reacting CO2
sensor is available with the Econo-
Mi$er IV outdoor air damper option/
accessory to aid the IAQ benefits.
Humidi-MiZer™ adaptive
dehumidification system
(48HJ004-014)
Carrier’s Humidi-MiZer adaptive dehu-
midification system is an all-inclusive
factory-installed option that can be
ordered with any Weathermaster®
48HJ004-014 rooftop unit to meet
the demand for providing a flexible and
high performing solution to accommo-
date all of these design related issues.
This system expands the envelope of
operation of Carrier’s Weathermaster
48HJ004-014 rooftop products to
provide unprecedented flexibility to
meet year-round comfort conditions.
The Humidi-MiZer adaptive dehumidi-
fication system has the industry’s only
dual dehumidification mode setting.
The Humidi-MiZer system includes two
new modes of operation. The Weath-
ermaster 48HJ004-014 rooftop cou-
pled with the Humidi-MiZer system is
capable of operating in normal design
cooling mode, subcooling mode, and
hot gas reheat mode. Normal Design
Cooling mode is when the unit will
operate under its normal sequence of
operation by cycling compressors to
maintain comfort conditions. Subcool-
ing mode will operate to satisfy part
load type conditions when the space
requires combined sensible and a
higher proportion of latent load con-
trol. Hot Gas Reheat mode will oper-
ate when outdoor temperatures
diminish and the need for latent capac-
ity is required for sole humidity control.
Hot Gas Reheat mode will provide
neutral air for maximum dehumidifica-
tion operation.
Exclusive MoistureMi$er™
dehumidification package
(48HJ015,017 and 48TM016-
028 only)
The MoistureMi$er dehumidification
package is a result of recent advances
by Carrier in controlling comfort levels.
This factory-installed option significant-
ly improves the dehumidification capa-
bility of the rooftop unit and helps con-
trol humidity levels in the building.
This option provides increased dehu-
midification by cooling the hot liquid re-
frigerant leaving the condenser coil. The
MoistureMi$er package consists of a
subcooling coil located on the leaving-air
side of the evaporator coil. The location
of this coil in the indoor airstream en-
hances the latent capacity of the
48HJ015 and 017 and 48TM016-028
units by as much as 40%. Many build-
ings suffer from humidity damage or
poor indoor air quality due to humid
conditions. The improved latent capacity
provided by the MoistureMi$er option
reduces the building’s humidity, eliminat-
ing potential property damage and mak-
ing the space more comfortable.
The MoistureMi$er option is the
ideal IAQ option for hot and humid
regions. The operation of the
MoistureMi$er package can be con-
trolled by a field-installed, wall mount-
ed humidistat or Thermidistat™ device.
The circuit activates only when needed
(using the accessory humidistat) as op-
posed to some dehumidification sys-
tems that operate continuously. The
humidistat can be set for any humidity
level between 20% and 80% relative
humidity.The Thermidistat device can
be set for any humidity level between
50% and 90% relative humidity.
COBRA™ energy recovery
units (sizes 004-014 only)
Carrier’s factory-installed optional
COBRA units recover energy from the
building exhaust air and pre-condition
ventilation air for the rooftop unit dur-
ing winter and summer operation.
These units are designed to satisfy the
higher ventilation requirements and
other building codes while minimizing
energy costs.
Factory installation of the 62AQ
section provides the benefit of reduced
field-installation time, single point
power connections, and the assurance
of a factory test for the complete
COBRA unit. The COBRA energy
recovery section requires less mainte-
nance than other energy recovery
systems and can be serviced by any
qualified refrigeration technician.
The COBRA energy recovery units
utilize Carrier’s high-efficiency
48HJ004-014 rooftop units and pro-
vide 3 to 121/2 tons of cooling capaci-
ty with the capability to pre-condition
600 to 3000 cfm of outdoor air.
Indoor-air quality (IAQ) generally re-
fers to the level of pollutants inside a
building. These pollutants include ciga-
rette smoke, carbon dioxide exhaled by
occupants, radon gas, car exhaust,
paint fumes, and odors.
Concern over increased indoor air
pollutants has been spurred by several
issues: 1) changes in new building
construction methods and retrofit of
older buildings have reduced air
infiltration rates; 2) Synthetic materials
release airborne particles, odors,
and chemicals; and 3) HVAC systems
that bring in minimal fresh air.
In 1989, IAQ concerns caused
ASHRAE to recommend increased
ventilation for all public buildings.
Simply introducing fresh air into a
building, however, is not always
practical or cost effective. Additional
ventilation can overload HVAC
systems and increase energy costs.
Carrier’s COBRA energy recovery
unit solves this dilemma by providing
increased fresh air while keeping
increased costs to a minimum. In
addition, the COBRA energy recovery
unit helps reduce humidity levels,
which helps to prevent deterioration of
building materials and retards the
growth of mold and mildew.
The COBRA energy recovery unit
provides the best solution to retaining
the energy-conserving benefits of to-
day’s tighter building construction
while improving indoor-air quality.
6
48TM004-014
Model number nomenclature
Coil Protection Options (fin/tube)
–– Al/Cu Cond & Evap (Standard Unit)
B– Cu/Cu Cond & Evap
C–Cu/Cu Cond & Al/Cu Evap
F–E-Coat Al/Cu Cond & Al/Cu Evap
G–E-Coat Cu/Cu Cond & Al/Cu Evap
V–Al/Cu Pre-Coat Cond Fin & Al/Cu Evap
Capacity Nominal-Tons
004 –3 Tons
005 –4 Tons
006 –5 Tons
007 –6 Tons
008 –7-1/2 Tons
009 –8-1/2 Tons
012 –10 Tons
014 –12-1/2 Tons
Factory-Installed Options
48 TM D 006 P M F 6 - - HA
48 –Packaged Rooftop
Electric Cooling/
Natural Gas Heat
TM–Constant Volume, Standard Efficiency Voltage
1–575-3-60
3–208/230-1-60
5–208/230-3-60
6–460-3-60
Controls and Sensors
––None
N–Novar ETM3051 Control*
P–PremierLink™ DDC Control
Example:
Indoor Motor Options
––Standard Motor & Drive
A–Alternate Motor
M–High-Static Indoor Motor
Heat Options:
49 States
D– Low Heat
E–Medium Heat
F–High Heat
California Compliant
L–Low NOx Low Heat
M–Low NOx Medium Heat
N–Low NOx High Heat
LEGEND
*Contact factory for availability and application information.
†Refer to 48TM Price Pages, Quote Builder, or contact your local Carrier repre-
sentative for FIOP code table.
Al — Aluminum
Cu — Copper
DDC — Direct Digital Controls
FIOP — Factory-Installed Option
Quality Assurance
Certified to ISO 9001:2000
†
11
ARI* CAPACITY RATINGS — 48TM004-014
LEGEND
*Air Conditioning and Refrigeration Institute.
†The SEER values shown for sizes 004, 005, and 006 are for units with the
optional belt drive motors;SEER rating for these units with the standard direct
drive motor is 9.7.
**ARI does not require EER ratings for units with capacity below 65,000 Btuh.
For these units, the EER rating at ARI standard conditions is provided for infor-
mation only.
††The IPLV applies only to two-stage cooling units.
NOTES:
1. Rated in accordance with ARI Standards 210-94 or 360-93.
2. ARI ratings are net values, reflecting the effects of circulating fan heat.
3. Ratings are based on:
Cooling Standard: 80 F db, 67F wb indoor entering-air temperature and
95 F db air entering outdoor unit.
IPLV Standard: 80 F db, 67F wb indoor entering-air temperature and 80 F
db outdoor entering-air temperature.
4. All 48TM004-014 units are in compliance with ASHRAE 90.1 2001 Energy
Standard for minimum SEER and EER requirements. Refer to state and
local codes or visit the following website:http://solstice.crest.org/efficiency/
bcap to determine if compliance with this standard pertains to a given geo-
graphical area of the United States.
HEATING CAPACITIES AND EFFICIENCIES — 48TM004-014
208/230-1-60 — SINGLE-STAGE GAS HEAT
208/230-1-60 — SINGLE-STAGE GAS HEAT — LOW NOx
208/230/460-3-60 — SINGLE-STAGE GAS HEAT — LOW NOx
AFUE — Annual Fuel Utilization Efficiency
UNIT
48TM
NOMINAL
TONS
NET COOLING
CAPACITY(Btuh)
TOTAL
kW SEER† EER** SOUNDRATING
(decibels) IPLV ††
004 3 35,000 4.0 10.0 8.781 N/A
005447,000 5.3 10.0 8.8 81 N/A
006557,000 6.710.0 8.5 81 N/A
007671,000 7.0 — 10.1 80 N/A
008 71/288,000 8.7— 10.1 82 10.5
009 81/2100,000 9.9 — 10.1 82 10.4
012 10 114,000 11.3 — 10.1 84 11.0
014 121/2136,000 14.3 — 9.5 86 9.7
db — Dry Bulb
EER — Energy Efficiency Ratio
IPLV —Integrated Part-Load Values
SEER — Seasonal Energy Efficiency Ratio
wb — Wet Bulb
UNIT
48TM
INPUT CAPACITYOUTPUT CAPACITYTEMPERATURE
RISE (°F)
MINIMUM HEATING
AIRFLOW (CFM)
EFFICIENCY
1st Stage 2nd Stage 1st Stage 2nd Stage AFUE (%) Steady State (%)
E004 74,000 — 57,000 — 25-35 1004 80 80
F004 115,000 — 89,000 — 55-85 1002 80 80
D00574,000 — 57,000 — 25-55 1004 80 80
E005115,000 — 91,000 — 35-65 132780 80
F005150,000 — 118,000 — 50-80 1396 80 80
D00674,000 — 57,000 — 25-55 1004 80 80
E006115,000 — 91,000 — 35-65 132780 80
F006150,000 — 118,000 — 50-80 1314 80 80
UNIT
48TM
INPUT CAPACITYOUTPUT CAPACITYTEMPERATURE
RISE (°F)
MINIMUM HEATING
AIRFLOW (CFM)
EFFICIENCY
1st Stage 2nd Stage 1st Stage 2nd Stage AFUE (%) Steady State (%)
M004 60,000 — 49,000 — 20-50 910 80 80
N004 90,000 — 73,000 — 30-60 1130 80 80
L00560,000 — 49,000 — 20-50 910 80 80
M00590,000 — 73,000 — 30-60 1130 80 80
N005120,000 — 98,000 — 40-70 1300 80 80
L00660,000 — 49,000 — 20-50 910 80 80
M00690,000 — 73,000 — 30-60 1130 80 80
N006120,000 — 98,000 — 40-70 1300 80 80
UNIT
48TM
INPUT CAPACITYOUTPUT CAPACITYTEMPERATURE
RISE (°F)
MINIMUM HEATING
AIRFLOW (CFM)
EFFICIENCY
1st Stage 2nd Stage 1st Stage 2nd Stage AFUE (%) Steady State (%)
M004 60,000 — 49,000 — 20-50 910 80 80
N004 90,000 — 73,000 — 30-60 1130 80 80
L00560,000 — 49,000 — 20-50 910 80 80
M00590,000 — 73,000 — 30-60 1130 80 80
N005120,000 — 98,000 — 40-70 1300 80 80
L00660,000 — 49,000 — 20-50 910 80 80
M00690,000 — 73,000 — 30-60 1130 80 80
N006120,000 — 98,000 — 40-70 1300 80 80
ARI*capacity ratings
12
HEATING CAPACITIES AND EFFICIENCIES — 48TM004-014 (cont)
208/230/460/575-3-60 — SINGLE-STAGE GAS HEAT
208/230/460/575-3-60 — 2-STAGE GAS HEAT
AFUE — Annual Fuel Utilization Efficiency
UNIT
48TM
INPUT CAPACITYOUTPUT CAPACITYTEMPERATURE
RISE (°F)
MINIMUM HEATING
AIRFLOW (CFM)
EFFICIENCY
1st Stage 2nd Stage 1st Stage 2nd Stage AFUE (%) Steady State (%)
E004 74,000 — 59,200 — 15-45 1220 80 80
D00574,000 — 59,200 — 15-45 1220 80 80
E005115,000 — 92,000 — 35-65 1320 80 80
D00674,000 — 59,200 — 15-45 1220 80 80
E006115,000 — 92,000 — 35-65 1320 80 80
D00774,000 — 59,200 — 15-45 1220 80 80
E007115,000 — 92,000 — 35-65 1320 80 80
D008 125,000 — 100,000 — 20-50 1860 80 80
D009 125,000 — 100,000 — 20-50 1860 80 80
UNIT
48TM
INPUT CAPACITYOUTPUT CAPACITYTEMPERATURE
RISE (°F)
MINIMUM HEATING
AIRFLOW (CFM)
EFFICIENCY
1st Stage 2nd Stage 1st Stage 2nd Stage AFUE (%) Steady State (%)
F004 82,000 115,000 65,600 92,000 55-85 1004 80 80
F005120,000 150,000 96,000 120,000 50-80 1396 80 80
F006120,000 150,000 96,000 120,000 50-80 1314 80 80
F007120,000 150,000 96,000 120,000 50-80 1390 80 80
E008 120,000 180,000 96,000 144,000 35-65 2060 80 80
F008 180,000 224,000 144,000 179,200 45-75 2230 80 80
E009 120,000 180,000 96,000 144,000 35-65 2060 80 80
F009 180,000 224,000 144,000 179,200 45-75 2180 80 80
D012 120,000 180,000 90,000 144,000 35-65 2060 80 80
E012 180,000 224,000 144,000 179,200 35-65 2510 80 80
F012 200,000 250,000 160,000 200,000 40-70 2650 80 80
D014 180,000 224,000 144,000 179,200 35-65 2510 80 80
E014 200,000 250,000 160,000 200,000 40-70 2650 80 80
ARI*capacity ratings (cont)
13
ARI* CAPACITY RATINGS — 48TM016-028
LEGEND
*Air Conditioning and Refrigeration Institute.
NOTES:
1. Rated in accordance with ARI Standards 360-93 and 270-95.
2. ARI ratings are net values, reflecting the effects of circulating fan
heat.
3. Ratings are based on:
Cooling Standard: 80 F db, 67F wb indoor entering-air tempera-
ture and 95 F db air entering outdoor unit.
IPLV Standard: 80 F db, 67F wb indoor entering-air temperature
and 80 F db outdoor entering-air temperature.
4. All 48TM016-028 units are in compliance with ASHRAE 90.1 2001
Energy Standard for minimum EER requirements. Refer to
state and local codes or visit the following website:
http://solstice.crest.org/efficiency/bcap to determine if compliance
with this standard pertains to a given geographical area of the
United States.
HEATING CAPACITIES AND EFFICIENCIES — 48TM016-028
*All units are 2-stage heat.
NOTE:Minimum allowable temperature of mixed-air entering the heat exchanger during first-stage
heating is 45 F. There is no minimum mixed-air temperature limitation during second-stage heating.
For entering-air temperatures below 45 F both stages of heat must be energized together to minimize
condensation issues and ensure proper unit operation.
UNIT SIZE
48TMD
NOMINAL
TONS
NET COOLING
CAPACITY(Btuh)
TOTAL
WATTS EER
SOUND
RATING
(decibels)
IPLV
01615 176,000 17,064 9.5 88 9.5
020 18 202,000 21,166 9.788 10.2
02520 236,000 24,832 9.5 94 10.1
028 25 278,000 28,535 9.794 10.4
UNIT SIZE
48TMF
NOMINAL
TONS
NET COOLING
CAPACITY(Btuh)
TOTAL
WATTS EER
SOUND
RATING
(decibels)
IPLV
01615 176,000 17,1799.5 88 9.5
020 18 202,000 21,301 9.788 10.1
02520 236,000 24,832 9.5 94 10.0
028 25 277,000 29,0679.5 94 10.0
db — Dry Bulb
EER — Energy Efficiency Ratio
IPLV —Integrated Part-Load Values
wb — Wet Bulb
UNIT
48TM
HEATINGINPUT
(Btuh)
Stage 2/Stage 1*
OUTPUT CAPACITY
(Btuh)
TEMPERATURE
RISE (F)
STEADY-STATE
EFFICIENCY (%)
MINIMUM
HEATINGCFM
D,M016275,000/206,000 223,000 15-45 81.0 3750
F,N016360,000/270,000 292,000 20-50 81.0 3830
D,M020 275,000/206,000 223,000 15-45 81.0 4580
F,N020 360,000/270,000 292,000 20-50 81.0 5400
D,M025275,000/206,000 223,000 15-45 81.0 4580
F,N025360,000/270,000 292,000 20-50 81.0 5400
D,M028 275,000/206,000 223,000 15-45 81.0 4580
F,N028 360,000/270,000 292,000 20-50 81.0 5400
28
LEGEND
*Evaporator coil fin material/condenser coil fin material. Contact your local repre-
sentative for details about coated fins.
†Weight of 14-in. roof curb.
**Single phase/three-phase.
††Rollout switch lockout is manually reset by interrupting power to unit or resetting
thermostat.
***Three-phase standard high heat models have heating input values as shown.
Single-phase standard high heat models have one-stage heating with heating
input values as follows:
48TMF004 — 115,000 Btuh
48TMF005,006 — 150,000 Btuh
†††California SCAQMD compliant Low NOxmodels have combustion products
that are controlled to 40 nanograms per joule or less.
NOTES:
1. High-static motor not available on single-phase units.
2. An LP kit is available as an accessory. Kit may be used at elevations as high
as 2000 ft. LP kit is not used with Low NOx units.
UNIT SIZE48TM E/F/M/N004 D/E/F/L/M/N005D/E/F/L/M/N006D/E/F007
NOMINALCAPACITY(tons) 3456
OPERATING WEIGHT (lb)
Unit
Al/Al*460 470 490 615
Al/Cu*465 476497626
Cu/Cu*468 482 505 637
EconoMi$er IV50 50 50 50
EconoMi$er2 46 46 46 46
Roof Curb† 115 115 115 115
COMPRESSOR Reciprocating Scroll
Quantity 1111
No. Cylinders (per Circuit) 2222
Oil (oz)50 50 50 60
REFRIGERANTTYPE R-22
Expansion Device Acutrol™ Metering Device
Operating Charge (lb-oz)
Circuit 1 4-5 6-6 7-14 11-0
Circuit 2 ————
CONDENSER FANPropeller Type
Nominal Cfm 3500 4000 4000 4100
Quantity...Diameter (in.) 1...22.0 1...22.0 1...22.0 1...22.0
Motor Hp...Rpm 1/4...1100 1/4...1100 1/4...1100 1/4...1100
Watts Input (Total) 325 325 325 320
CONDENSER COILEnhanced Copper Tubes, Aluminum Lanced Fins
Rows...Fins/in. 1...172...172...172...17
Total Face Area (sq ft) 8.36 8.36 10.42 16.5
EVAPORATOR FANCentrifugal Type
Quantity...Size (in.) Std 1...10 x 10 1...10 x 10 1...11 x 10 1...10 x 10
Alt 1...10 x 10 1...10 x 10 1...10 x 10 —
High-Static 1...10 x 10 1...10 x 10 1...10 x 10 1...10 x 10
Type Drive Std Direct Direct Direct Belt
Alt Belt Belt Belt —
High-Static Belt Belt Belt Belt
Nominal Cfm 1200 1600 2000 2100
Maximum Continuous Bhp Std .34 .75 1.20 2.40
Alt 1.20 1.20 1.30/2.40** —
High-Static 2.40 2.40 2.90 2.90
Motor Frame SizeStd48 48 48 56
Alt 48 48 56 —
High-Static 56 56 56 56
Nominal Rpm High/Low Std 860/800 1075/9701075/1040 —
Alt 1620 1620 1725 —
High-Static 1725 1725 1725 1725
Fan Rpm Range Std —— —1070-1460
Alt 685-1045 770-1175 900-1300 —
High-Static 1075-1455 1075-1455 1300-1685 1300-1685
Motor Bearing Type Ball Ball Ball Ball
Maximum Allowable Rpm 2100 2100 2100 2100
Motor Pulley Pitch Diameter Min/Max (in.) Std — — — 2.8/3.8
Alt 1.9/2.9 1.9/2.9 2.8/3.8 —
High-Static 2.8/3.8 2.8/3.8 3.4/4.4 3.4/4.4
Nominal Motor Shaft Diameter (in.) Std 1/21/21/25/8
Alt 1/21/25/8—
High-Static 5/85/87/87/8
Fan Pulley Pitch Diameter (in.) Std ———4.5
Alt 4.5 4.0 5.5 —
High-Static 4.5 4.5 4.5 4.5
Belt, Quantity...Type...Length (in.) Std — — — 1...A...39
Alt 1...A...36 1...A...36 1...A...40 —
High-Static 1...A...39 1...A...39 1...A...40 1...A...40
Pulley Center Line Distance (in.) Std ———14.7-15.5
Alt 10.0-12.4 10.0-12.4 14.7-15.5 —
High-Static 10.0-12.4 10.0-12.4 14.7-15.5 14.7-15.5
Speed Change per Full Turn of Std ———80
Movable Pulley Flange (rpm) Alt 48 7080—
High-Static 65 65 60 60
Movable Pulley Maximum Full Turns Std ——— 5
From Closed Position Alt 555—
High-Static 6655
Factory Setting Std ——— 3
Alt 333—
High-Static 31/231/231/231/2
Factory Speed Setting (rpm) Std ———1226
Alt 829 932 1100 —
High-Static 1233 1233 1416 1416
Fan Shaft Diameter at Pulley (in.) 5/85/85/85/8
EVAPORATOR COILEnhanced Copper Tubes, Aluminum Double-Wavy Fins
Rows...Fins/in. 2...15 2...15 3...15 4...15
Total Face Area (sq ft) 4.175.5 5.5 5.5
Al — Aluminum
Bhp — Brake Horsepower
Cu — Copper
Physical data — 48TM004-007
48TM
29
LEGEND
*Evaporator coil fin material/condenser coil fin material. Contact your local repre-
sentative for details about coated fins.
†Weight of 14-in. roof curb.
**Single phase/three-phase.
††Rollout switch lockout is manually reset by interrupting power to unit or resetting
thermostat.
***Three-phase standard high heat models have heating input values as shown.
Single-phase standard high heat models have one-stage heating with heating
input values as follows:
48TMF004 — 115,000 Btuh
48TMF005,006 — 150,000 Btuh
†††California SCAQMD compliant Low NOxmodels have combustion products
that are controlled to 40 nanograms per joule or less.
NOTES:
1. High-static motor not available on single-phase units.
2. An LP kit is available as an accessory. Kit may be used at elevations as high
as 2000 ft. LP kit is not used with Low NOx units.
UNIT SIZE48TM E/F/M/N004 D/E/F/L/M/N005D/E/F/L/M/N006D/E/F007
FURNACE SECTION
Rollout Switch Cutout
Temp (F)†† 195 195 195 195
Burner Orifice Diameter
(in. ...drill size)
Natural Gas Std TMD — .113...33 .113...33 .113...33
TME .113...33 .113...33 .113...33 .113...33
TMF .113...33 .129...30 .129...30 .129...30
TML— .102...38 .102...38 —
TMM .102...38 .102...38 .102...38 —
TMN.102...38 .116...32 .116...32 —
Liquid Propane Alt TMD — .089...43 .089...43 .089...43
TME .089...43 .089...43 .089...43 .089...43
TMF .089...43 .104...37.104...37.104...37
Thermostat Heat Anticipator
Setting (amps)
208/230vand575 Stage 1 .14 .14 .14 .14
Stage 2 .14 .14 .14 .14
460v Stage1 .14 .14 .14 .14
Stage 2 .14 .14 .14 .14
Gas Input (Btuh) Standard Units TMD ——/74,000 —/74,000 —/74,000
(Stage 1/Stage 2) TME —/74,000 —/115,000 —/115,000 —/115,000
TMF*** 82,000/115,000 120,000/150,000 120,000/150,000 120,000/150,000
Low NOx Units TML††† — 60,000 60,000 —
TMM††† 60,000 90,000 90,000 —
TMN††† 90,000 120,000 120,000 —
Efficiency (Steady
State) (%)80 80 80 80
Temperature Rise Range TMD — 15-45 15-45 15-45
TME 15-45 35-65 35-65 35-65
TMF 55-85 50-80 50-80 50-80
TML— 20-50 20-50 —
TMM 20-50 30-60 30-60 —
TMN30-60 40-7040-70—
Manifold Pressure (in. wg)
Natural Gas Std 3.5 3.5 3.5 3.5
Liquid Propane Alt 3.5 3.5 3.5 3.5
Gas Valve Quantity 11 11
Gas Valve Pressure Range
Psig 0.180-0.4870.180-0.4870.180-0.4870.180-0.487
in. wg 5.0-13.5 5.0-13.5 5.0-13.5 5.0-13.5
Field Gas Connection
Size(in.) 1/21/21/21/2
HIGH-PRESSURE SWITCH (psig)
Standard Compressor 450 ±50 500 ±50
Internal Relief (Differential)
Cutout 428 428
Reset (Auto.) 320 320
LOW-PRESSURE SWITCH (psig)
7±3Cutout
Reset (Auto.) 22 ±7
FREEZEPROTECTION
THERMOSTAT (F)
Opens 30 ±5
Closes 45 ±5
OUTDOOR-AIR INLET SCREENSCleanable
Quantity...Size (in.) Varies by Option Selected
RETURN-AIR FILTERS Throwaway
Quantity...Size (in.) 2...16 x 25 x 2
Al — Aluminum
Bhp — Brake Horsepower
Cu — Copper
48TM

Navigation menu
