simple

|video door entry system

Kit RANGE

CAtAloGuE

The Basic kit consists of a single and/or two-family door-entry and

video entry phone system set featuring an innovative and elegant design.

The Basic range is easy to install and use, and is perfect for all residential

solutions.

Comelit has designed two solutions capable of fulﬁlling all

user requirements.

The Evolution kit retains the elegance and excellence of a Comelit product,

but is enhanced with performance features allowing system expansion for

up to 10 users, with the intercom function provided as standard.

KIT BASIC

KIT EVOLUTION

From a single/two-family setup... ... to a medium-size system (10 users)

Door opening

1207

2+2

1214KC 6101W+

6114KC

6101W+

6114KC

6101W+

6114KC

1214KC

1216

Composition

of the kit

Expandable

up to 10 users!

Scheme of expandable equipment up to 10 users

Example of installation with two-family PLANUXKIT

KIT BASIC

art. 8220S

The kit includes:

N°1 art. 2602

N°1 art. 1538

N°1 art. 3160/1

N°1 art. 3161/1

N°1 art. 3262/1

N°1 art. 1600

art. 8230S

The kit includes:

N°1 art. 2602

N°1 art. 1538

N°1 art. 3160/1

N°1 art. 3161/2

N°1 art. 3262/1

N°1 art. 1600

N°1 art. 3188

VANDALCOM

IKALL

8241I

The kit includes:

N°1 art. 31162

N°1 art. 33401

N°1 art. 3311/2S

N°1 art. 3348

N°1 art. 1610

N°1 art. 1538

N°1 art. 2602

STYLE2STYLE5

4 5

ACCESSORIES

Description

Spare parts and/or accessories are standard products of the

traditional cabling system

Single-Family

Kit

with IDEA

art. 8270

The kit includes

N°1 art. 2612

N°1 art. 1200

N°1 art. 3554

N°1 art. 3561

Stylekit 2 is a single-family door-entry phone kit created

by Comelit; it is extremely easy to install as it uses just 2

wires. Stylekit 2 features an original and innovative design,

characterised by unmistakable and exclusive blue LEDs,

large nameplates and high audio quality. An elegant desk

base guarantees ﬂexibility, to suit all requirements.

ACCESSORIES

Code Description

2612

Style series basic intercom for 2-wire system

3560

Flush-mounted external unit 2 wires

3561

Surface-mounted external unit 2 wires

3554

Spare ﬂush mounted box

4887

Waterproof housing for Idea surface-mounted entrance panel

4889

Waterproof shield for Idea ﬂush-mounted entrance panel

1200

12Vac transformer with 230vac input

1229

Accessory - additional ringtone

Single-Family

Kit

with IDEA

art. 8271

The kit includes

N°1 art. 2602

N°1 art. 1200

N°1 art. 3554

N°1 art. 3551

Stylekit 5 is a 5-wire door-entry phone kit created by

Comelit. Stylekit 5 features an original and innovative design,

characterised by unmistakable and exclusive blue LEDs, large

nameplates and high audio quality. The simple inclusion of

an additional door-entry phone offers easy expansion and an

elegant desk base guarantees ﬂexibility, to suit all requirements.

The external unit is wall-mounted, but the box art. 3554 used

to install it as a ﬂush-mounted product is also supplied as

part of the package.

Two-Family

Kit

with IDEA

art. 8272

The kit includes

N°2 art. 2602

N°1 art. 1200

N°1 art. 3554

N°1 art. 3553

ACCESSORIES

Code Description

3550

Flush-mounted external unit

3551

Surface-mounted external unit

3552

Flush-mounted external unit

3553

Surface-mounted external unit

3573

3-Button external unit for 5-wire Stylekit

3574

4-Button external unit for 5-wire Stylekit

3554

Spare ﬂush mounted box

4887

Waterproof housing for Idea surface-mounted entrance panel

4889

Waterproof shield for Idea ﬂush-mounted entrance panel

1200

12Vac transformer with 230Vac input

2602

Style series 4 +1 traditional system basic intercom

1122/A

12-24Vdc-ac general purpose relay

1229

Accessory - additional ringtone

Three-Family

Kit

with IDEA

art. 8273

The kit includes

N°3 art. 2602

N°1 art. 1200

N°1 art. 3573

Four-Family

Kit

with IDEA

art. 8274

The kit includes

N°4 art. 2602

N°1 art. 1200

N°1 art. 3574

KIT BASIC

ACCESSORIES

Cod. Description

4880

1 user external panel for B/W

4881

2 users external panel for B/W

4882

1 user entrance panel for colour

4883

2 User entrance panel for colour kit

3554

Spare ﬂush mounted box

4887

Waterproof housing for Idea surface-mounted entrance panel

4889

Waterproof shield for Idea ﬂush-mounted entrance panel

5801

Monitor Genius series B/W handset

5802

Monitor Genius series colour handset

5814K

Geniuskit B/W additional bracket

5814KC

Geniuskit colour additional bracket

5712

Desk base with bushing for Bravo/Genius monitor

2608

Style series Simplebus system basic intercom

2628

Style series Simplebus 2 system elegance intercom - white

2610

Style series Simplebus top/kit system elegance intercom

1229

Accessory - additional ringtone

1224A

Simplebus system digital switching device

4833/A

Line ampliﬁer for simplebus video systems

4833C

Line ampliﬁer for Simplebus color video systems

Single-Family B/W Kit

with IDEA

art. 8471

The kit includes

N° 1 art. 5801

N° 1 art. 5814K

N° 1 art. 4880

N° 1 art. 1205/B

N° 1 art. 1216

N° 1 art. 1214/2

Two-Family B/W Kit

with IDEA

art. 8472

The kit includes

N° 2 art. 5801

N° 2 art. 5814K

N° 1 art. 4881

N° 1 art. 1205/B

N° 1 art. 1216

N° 2 art. 1214/2

Single-Family Colour Kit

with IDEA

art. 8481

The kit includes

N° 1 art. 5802

N° 1 art. 5814KC

N° 1 art. 4882

N° 1 art. 1205/B

N° 1 art. 1216

N° 1 art. 1214KC

Two-Family Colour Kit

with IDEA

art. 8482

The kit includes

N° 2 art. 5802

N° 2 art. 5814KC

N° 1 art. 4883

N° 1 art. 1205/B

N° 1 art. 1216

N° 2 art. 1214KC

1122/A

12-24Vdc-ac general purpose relay

1256

Simplebus system digital relay actuator

1259/A

Switcher for remote cameras

1259C

Simplebus/colour kit for separate video cameras

1214/2

Simplebus 2 connection terminal

1214KC

Connecting terminal for color kit

1216

Simplebus/kit system terminal

1205/B

12Vac - 20vdc dual output power supply with 230vac input

1212/B

20Vdc 14va power supply with 230vac input

4576/100

Simplebus system Comelit cable 2x0.5 MM2 + 2x1.5 MM2 - 100 m

4576/500

Simplebus system Comelit cable 2x0.5 MM2 + 2x1.5 MM2 - 500 m

4578/100

Simplebus external Comelit 100 m cable 2x0.5 MM2 + 2x1.5 MM2

4578/500

Simplebus external Comelit 500 m cable 2x0.5 MM2 + 2x1.5 MM2

GENIUS

Particularly simple, versatile video intercom system, comprising

a ﬂush or surface mounted entrance panel. The b/w and

colour monitor features an elegant gloss outer case with silk

screen printing, and has 3 pushbuttons: door open, actuator

(or free C/N.O.) and staircase lighting (or video request).

GeniusKit allows call repetition by means of special terminals

and duplication of the door open pushbutton even in the

vicinity of the external unit. The standard conﬁguration can

be varied easily, by ﬁtting additional monitors or telephones,

or a second external video entry panel. Geniuskit can

also provide for additional cameras and locks. The basic kit can

be expanded to include up to 2 or more external units and 3

monitors per residential unit. Exapandable up to 16 internal

units with art.1252.

SMART

A single and two-family colour video entry phone system kit.

This consists of the new IDEA entrance panel and the new

Smart monitor, which helps to minimise the overall dimensions.

The privacy and intercom functions are standard features

of the Smartkit. In order to use the intercom function, the

single-family kit must be expanded with one or more additional

door-entry phones/monitors. The kit can be used as a system

base. The kits can be expanded to create solutions with 2

or more external units and 3 monitors per residential unit;

this can be expanded to a maximum of 16 units through the

addition of art. 1252.

Single-Family Colour Kit

with IDEA

art. 8471S

The kit includes

N°1 art. 6302

N°1 art. 4882

N°1 art. 1205/B

N°1 art. 1215

N°1 art. 1216

N°1 art. 6117

N°1 art. 6320

Two-Family Colour Kit

with IDEA

art. 8472S

The kit includes

N°2 art. 6302

N°1 art. 4883

N°1 art. 1205/B

N°2 art. 1215

N°1 art. 1216

N°2 art. 6117

N°2 art. 6320

ACCESSORIES

Code Description

4882 1 User entrance panel for colour kit

4883 2 User entrance panel for colour kit

3554 Spare ﬂush mounted box

4887 Waterproof housing for Idea surface-mounted entrance panel

4889 Waterproof shield for Idea ﬂush-mounted entrance panel

6302 Smart series sbc/kit system hands-free colour monitor

6312 Desk base with bushing for Smart monitor

6320 Surface-mounted support for Smart monitor

6333 Accessory - additional 5 buttons for Smart monitor

6117 Flush-mounted box for Planux and Smart monitor

6118 Plasterboard ﬁxing kit for Planux and Smart monitors

2608 Style series Simplebus system basic intercom

2628 Style series Simplebus 2 system elegance intercom - white

2610 Style series Simplebus top/kit system elegance intercom

1229 Accessory - additional ringtone

1224A Simplebus system digital switching device

4833C Line ampliﬁer for Simplebus color video systems

1122/A 12-24Vdc-ac general purpose relay

1256 Accessory - Simplebus system digital relay actuator

1259C Accessory - Simplebus/colour kit for separate video cameras

1215 Connection terminal

1216 Simplebus/kit system terminal

1205/B 12Vac - 20vdc dual output power supply with 230vac input

1212/B 20Vdc 14va power supply with 230vac input

4576/100 Simplebus system Comelit cable 2x0.5 MM2 + 2x1.5 MM2 - 100 m

4576/500 Simplebus system Comelit cable 2x0.5 MM2 + 2x1.5 MM2 - 500 m

4578/100 Simplebus external Comelit 100 m cable 2x0.5 MM2 + 2x1.5 MM2

4578/500 Simplebus external Comelit 500 m cable 2x0.5 MM2 + 2x1.5 MM2

KIT EVOLUTION

BRAVO

Bravokit - the new video door entry system from Comelit

Based on technology exclusive to Comelit, Simplebus is the

last word in simplicity. It comprises IKALL entrance panel,

with clean and attractive lines and Bravo, the elegant video

door entry monitor suitable for all types of residence.The kits

are available in both colour and black and white versions.

Both types are available in surface-mounted, single-fa-mily

or two-family versions. The Bravokit includes the “privacy”

function and the intercom function. In order to use the intercom

function, the singlefamily kit must be expanded with one or

more additional door entry telephones/ monitors. The basic

kit can be expanded to include up to 2 or more external units

and 3 monitors per residential unit. Exapandable up to 16

internal units with art.1252.

Single-Family B/W Kit

with IkAll

art. 8171I

The kit includes

N° 1 art. 5701

N° 1 art. 5714/K

N° 1 art. 4878K

N° 1 art. 1214/2

N° 1 art. 1207

N° 1 art. 1216

Two-Family B/W Kit

with IkAll

art. 8173I

The kit includes

N° 2 art. 5701

N° 2 art. 5714/K

N° 1 art. 4879K

N° 2 art. 1214/2

N° 1 art. 1207

N° 1 art. 1216

Single-Family Colour Kit

with IkAll

art. 8184I

The kit includes

N° 1 art. 5702

N° 1 art. 5714KC

N° 1 art. 4878KC

N° 1 art. 1214KC

N° 1 art. 1207

N° 1 art. 1216

Two-Family Colour Kit

with IkAll

art. 8185I

The kit includes

N° 2 art. 5702

N° 2 art. 5714KC

N° 1 art. 4879KC

N° 2 art. 1214KC

N° 1 art. 1207

N° 1 art. 1216

A single and two-family colour video entry phone system kit.

This consists of the new IKALL entrance panel, with clean

and attractive lines, and the new Smart monitor, which helps

to minimise the overall dimensions. The privacy and intercom

functions are standard features of the Smartkit. In order to use

the intercom function, the single-family kit must be expanded

with one or more additional door-entry phones/monitors. The

kit can be used as a system base, to create systems to which

a maximum of 10 residences are connected. The kits can be

expanded to create solutions with 2 or more external units

and 3 monitors per residential unit; this can be expanded

to a maximum of 16 units through the addition of art. 1252.

SMART

Single-Family Colour Kit

with IkAll

art. 8171IS

The kit includes

N° 1 art. 6302

N° 1 art. 6117

N° 1 art. 6320

N° 1 art. 1207

N° 1 art. 1215

N° 1 art. 1216

N° 1 art. 4878KC

Two-Family Colour Kit

with IkAll

art. 8172IS

The kit includes

N° 2 art. 6302

N° 2 art. 6117

N° 2 art. 6320

N° 1 art. 1207

N° 2 art. 1215

N° 1 art. 1216

N° 1 art. 4879KC

ACCESSORIES

Code Description

4878KC

iKall simplebus kit single family colour external unit

4879KC

iKall simplebus kit two family colour external unit

31121

Natural anodised aluminium rain shield

31161

Natural anodised aluminium housing with rain shield

4680KC

iKall series simplebus kit colour audio/video unit

6302

Smart series sbc/kit system hands-free colour monitor

6312

Desk base with bushing for Smart monitor

6320

Surface-mounted support for Smart monitor

6333

Accessory - additional 5 buttons for Smart monitor

6117

Flush-mounted box for planux and Smart monitor

6118

Plasterboard ﬁxing kit for planux and Smart monitors

1207

Power supply for simplebus kit - iKall

2608

Style series Simplebus system basic intercom

2628

Style series Simplebus 2 system elegance intercom - white

2610

Style series Simplebus top/kit system elegance intercom

1229

Accessory - additional ringtone

1224A

Simplebus system digital switching device

4833C

Line ampliﬁer for Simplebus color video systems

1122/A

Simplebus system digital switching device

1256

Accessory - Simplebus system digital relay actuator

1259C

Accessory - Simplebus/colour kit for separate video cameras

1215

Connection terminal

1216

Simplebus/kit system terminal

1212/B

20Vdc 14va power supply with 230vac input

4576/100

Simplebus system Comelit cable 2x0.5 Mm2 + 2x1.5 Mm2 - 100 m

4576/500

Simplebus system Comelit cable 2x0.5 MM2 + 2x1.5 MM2 - 500 m

4578/100

Simplebus external Comelit 100 m cable 2x0.5 MM2 + 2x1.5 MM2

4578/500

Simplebus external Comelit 500 m cable 2x0.5 MM2 + 2x1.5 MM2

ACCESSORIES

Code Description

4878K

iKall Simplebus kit single family B/W external unit

4878KC

iKall Simplebus kit single family colour external unit

4879K

iKall Simplebus kit two family B/W external unit

4879KC

iKall Simplebus kit two family colour external unit

31121

Natural anodised aluminium rain shield

31161

Natural anodised aluminium housing with rain shield

4680K

iKall series Simplebus kit B/W audio/video unit

4680KC

iKall series Simplebus kit colour audio/video unit

5701

Monitor Bravo series B/W handset

5702

Monitor Bravo series colour handset

5714/K

Bravokit B/W additional bracket

5714KC

Bravokit colour additional bracket

5712

Desk base with bushing for Bravo/Genius monitor

5733

Bravo monitor additional 4 buttons

5734

Bravo monitor additional 2 buttons and 2 leds

1207

Power supply for simplebus kit - iKall

2608

Style series Simplebus system basic intercom

2610

Style series Simplebus top/kit system elegance intercom

1229

Accessory - additional ringtone

1224A

Simplebus system digital switching device

4833/A

Line ampliﬁer for Simplebus video systems

4833C

Line ampliﬁer for Simplebus color video systems

1122/A

Simplebus system digital switching device

1256

Accessory - Simplebus system digital relay actuator

1259/A

Switcher for remote cameras

1259C

Accessory - Simplebus/colour kit for separate video cameras

1214/2

Simplebus 2 connection terminal

1214KC

Connecting terminal for color kit

1216

Simplebus/kit system terminal

1212/B

Simplebus/kit system terminal

4576/100

Simplebus system Comelit cable 2x0.5 Mm2 + 2x1.5 Mm2 - 100 m

4576/500

Simplebus system Comelit cable 2x0.5 MM2 + 2x1.5 MM2 - 500 m

4578/100

Simplebus external Comelit 100 m cable 2x0.5 MM2 + 2x1.5 MM2

4578/500

Simplebus external Comelit 500 m cable 2x0.5 MM2 + 2x1.5 MM2

KIT EVOLUTION

PLANUXLUX

10 11

A single colour video entry phone system kit. It includes the

new IKALL entrance panel, with clean and attractive lines, and

the Planux Lux monitor with touch-sensitive technology. The

privacy and intercom functions are standard features of the

Planux Lux and Planux Lux kit. In order to use the intercom

function, the single-family kit must be expanded with one or

more additional door-entry phones/monitors.

The kit can be used as a system base, to create systems to

which a maximum of 10 residences are connected. The kits

can be expanded to create solutions with 2 or more external

units and 3 monitors per residential unit; this can be expanded

to a maximum of 16 units through the addition of art. 1252.

Single-Family Colour Kit

with IkAll

art. 8171IPlB

The kit includes

N° 1 art. 6101B/C

N° 1 art. 6114KC

N° 1 art. 6117

N° 1 art. 1207

N° 1 art. 1214KC

N° 1 art. 1216

N° 1 art. 4878KC

Single-Family Colour Kit

with IkAll

art. 8171IPlW

The kit includes

N° 1 art. 6101W/C

N° 1 art. 6114KC

N° 1 art. 6117

N° 1 art. 1207

N° 1 art. 1214KC

N° 1 art. 1216

N° 1 art. 4878KC

1122/A

12-24Vdc-ac general purpose relay

1256

Accessory - Simplebus system digital relay actuator

1259C

Accessory - Simplebus/colour kit for separate video cameras

1214KC

Connecting terminal for colour kit

1216

Simplebus/kit system terminal

1212/B

20Vdc 14va power supply with 230vac input

4576/100

Simplebus system Comelit cable 2x0.5 Mm2 + 2x1.5 Mm2 - 100 m

4576/500

Simplebus system Comelit cable 2x0.5 Mm2 + 2x1.5 Mm2 - 500 m

4578/100

Simplebus external Comelit 100 m cable 2x0.5 Mm2 + 2x1.5 Mm2

4578/500

Simplebus external Comelit 500 m cable 2x0.5 Mm2 + 2x1.5 Mm2

ACCESSORIES

Code Description

4878KC

iKall Simplebus kit single family colour external unit

4879KC

iKall Simplebus kit two family b/w external unit

31121

Natural anodised aluminium rain shield

31161

Natural anodised aluminium housing with rain shield

4680KC

IKall series Simplebus kit colour audio/video unit

6101B/C

Planux lux series hands-free colour monitor - black

6101W/C

Planux lux series hands-free colour monitor - white

6114KC

Planuxkit colour additional bracket

6117

Flush-mounted box for Planux and smart monitors

6118

Plasterboard ﬁxing kit for Planux and smart monitors

6101L/C

White colour template for video Planux lux

6101N/C

Black colour template for video Planux lux

1207

Power supply for Simplebus kit - iKall

2608

Style series Simplebus system basic intercom

2628

Style series Simplebus 2 system elegance intercom - white

2610

Style series simplebus top/kit system elegance intercom

1229

Accessory - additional ringtone

1224A

Simplebus system digital switching device

4833C

Line ampliﬁer for Simplebus color video systems

ACCESSORIES

Code Description

4878KC

iKall Simplebus kit single family colour external unit

4879KC

iKall Simplebus kit two family b/w external unit

31121

Natural anodised aluminium rain shield

31161

Natural anodised aluminium housing with rain shield

4680KC

IKall series Simplebus kit colour audio/video unit

6101B

Planux series hands-free colour monitor - absolute black

6101W

Planux series hands-free colour monitor - white

6114KC

Planuxkit colour additional bracket

6112

Desk base with junction box for Planux monitor

6117

Flush-mounted box for planux and Smart monitor

6118

Plasterboard ﬁxing kit for planux and Smart monitors

6120

Surface-mounted support for Planux monitor

6121

High surface-mounted support for Planux monitor

6122

Tilting accessory for Planux monitors

1207

Power supply for simplebus kit - iKall

2608

Style series Simplebus system basic intercom

2628

Style series Simplebus 2 system elegance intercom - white

2610

Style series Simplebus top/kit system elegance intercom

1229

Accessory - additional ringtone

1224A

Simplebus system digital switching device

4833C

Line ampliﬁer for Simplebus color video systems

1122/A

12-24Vdc-ac general purpose relay

1256

Accessory - Simplebus system digital relay actuator

1259C

Accessory - Simplebus/colour kit for separate video cameras

1214KC

Connecting terminal for colour kit

1216

Simplebus/kit system terminal

1212/B

20Vdc 14va power supply with 230vac input

4576/100

Simplebus system Comelit cable 2x0.5 Mm2 + 2x1.5 Mm2 - 100 m

4576/500

Simplebus system Comelit cable 2x0.5 Mm2 + 2x1.5 Mm2 - 500 m

4578/100

Simplebus external Comelit 100 m cable 2x0.5 Mm2 + 2x1.5 Mm2

4578/500

Simplebus external Comelit 500 m cable 2x0.5 Mm2 + 2x1.5 Mm2

PLANUX

A single and two-family colour video entry phone system kit.

It consists of the new IKALL entrance panel, with clean and

attractive lines, and the Planux monitor with touch-sensitive

technology. The privacy and intercom functions are standard

features of the Planux kit. In order to use the intercom function,

the single-family kit must be expanded with one or more

additional door-entry phones/monitors. The kit can be used

as a system base, to create systems to which a maximum of

10 residences are connected. The kits can be expanded to

create solutions with 2 or more external units and 3 monitors

per residential unit; this can be expanded to a maximum of

16 units through the addition of art. 1252.

Single-Family Colour Kit

with IkAll

art. 8171IP

The kit includes

N° 1 art. 6101W

N° 1 art. 6101N

N° 1 art. 6114KC

N° 1 art. 6117

N° 1 art. 6120

N° 1 art. 1207

N° 1 art. 1214KC

N° 1 art. 1216

N° 1 art. 4878KC

Two-Family Colour Kit

with IkAll

art. 8172IP

The kit includes

N° 2 art. 6101W

N° 2 art. 6101N

N° 2 art. 6114KC

N° 2 art. 6117

N° 2 art. 6120

N° 1 art. 1207

N° 2 art. 1214KC

N° 1 art. 1216

N° 1 art. 4878KC

NOTES

ACCESSORIES

Code Description

4878KC

iKall Simplebus kit single family colour external unit

31121

Natural anodised aluminium rain shield

31161

Natural anodised aluminium housing with rain shield

4680KC

IKall series Simplebus kit colour audio/video unit

6101WM

White Planux hands-free colour monitor with memovideo

6214C

Simplebus top bracket for Planux memo and Planux manager

6112

Desk base with junction box for Planux monitor

6117

Flush-mounted box for planux and Smart monitor

6118

Plasterboard ﬁxing kit for planux and Smart monitors

6120

Surface-mounted support for Planux monitor

6121

High surface-mounted support for Planux monitor

6122

Tilting accessory for Planux monitors

1207

Power supply for simplebus kit - iKall

2608

Style series Simplebus system basic intercom

2628

Style series Simplebus 2 system elegance intercom - white

2610

Style series Simplebus top/kit system elegance intercom

1229

Accessory - additional ringtone

1224A

Simplebus system digital switching device

4833C

Line ampliﬁer for Simplebus color video systems

4888C

Simplebus colour system power supply mixer

1122/A

12-24Vdc-ac general purpose relay

1256

Accessory - Simplebus system digital relay actuator

1259C

Switcher for remote cameras

1214/2C

Simplebus 2 and Simplebus colour connection terminal

1216

Simplebus/kit system terminal

1212/B

20Vdc 14va power supply with 230vac input

4576/100

Simplebus system Comelit cable 2x0.5 Mm2 + 2x1.5 Mm2 - 100 m

4576/500

Simplebus system Comelit cable 2x0.5 Mm2 + 2x1.5 Mm2 - 500 m

4578/100

Simplebus external Comelit 100 m cable 2x0.5 Mm2 + 2x1.5 Mm2

4578/500

Simplebus external Comelit 500 m cable 2x0.5 Mm2 + 2x1.5 Mm2

PLANUX

A single colour video entry phone system kit. It consists of

the new IKALL entrance panel, with clean and attractive lines,

and the PlanuxMemo monitor with touch-sensitive technology.

The privacy and intercom functions are standard features of

the PlanuxMemo kit. In order to use the intercom function,

the single-family kit must be expanded with one or more

additional door-entry phones/monitors. The kit can be used

as a system base, to create systems to which a maximum

of 10 residences are connected.

Single-Family Colour Kit

with IkAll

art. 8171IPM

The kit includes:

N° 1 art. 6101WM

N° 1 art. 6214C

N° 1 art. 6117

N° 1 art. 6120

N° 1 art. 1207

N° 1 art. 4888C

N° 1 art. 4878KC

MEMO

with TOUCH SCREEN

KIT VARIANT DIAGRAMS

For BRAVO monitor use

art. 5702+5714KC (COLOUR) or

art. 5701+5714/K (B/W)

12161214KC 1214KC

1214KC

6101W

+6114KC

6101W

+6114KC

6101B

+6114KC

6101B

+6114KC

6101W

+6114KC

6101B

+6114KC

6101W

+6114KC

6101B

+6114KC

2+2 2+2 2+2 2+2

2 2

1195

1207 1224A 1207 1224A 1207 1224A 1207 1224A

Variant diagrams

VARIANTS

4878KC 4878KC 4878KC 4878KC

6101W

+6114KC

6101B

+6114KC

1224A 1207

Door opening

4878KC 4878KC

Door opening

Variant with second entrance for single-family kit

Variant with second entrance for two-family kitVariant of expandable plant up to 10 users

2+2 2+2

2+2

2 2

* *

6101W

+6114KC

6101W

+6114KC

6101B

+6114KC

6101B

+6114KC

Door opening Door opening

4879KC 4879KC

2+2 2+2

2+2

2+2 2+2

1216

1214KC

1224A 1207

1214KC

1998/A - 1998VC

1195

1595

6101W+

6114KC

6101W+

6114KC

6101W+

6114KC

1216

1214KC

1207

2+2

Door opening

Variant with two additional entry phones

for single-family kit

Variant with two additional monitors for single-family kit

Variant with additional cameras

for single-family kit

Variant with additional lock

for single-family kit

Variant with two additional monitors

or entry phones for two-family kit

Variant with ﬂoor door call connection

and additional bell

for single and two-family kit

For SMART monitor use

art. 6302

For PLANUX LUX monitor use

art. 6101W/C + 6114KC

or art. 6101B/C + 6114KC

6101W

+6114KC

6101W

+6114KC

6101W

+6114KC

6101W

+6114KC

6101W

+6114KC

6101W

+6114KC

6101B

+6114KC

6101W

+6114KC

6101B

+6114KC

6101B

+6114KC

6101B

+6114KC

6101B

+6114KC

6101B

+6114KC

6101B

+6114KC

6101B

+6114KC

6101B

+6114KC

6101W

+6114KC

6101W

+6114KC

1212/B 1212/B

1216

1214KC

1207

Door opening

4878KC

2+2

2+2 2

230V 230V

4878KC

2+2

1216

1214/2C

1214KC

1207

Door opening Door opening

2+2

1256 1207

Door opening

2+2

1207

4878KC 4879KC

1229

4878KC

Door opening

2+2

COAX

12071259C

Door opening

1216

2610

1214/2C

1214KC

1205B

4879KC

2+2

230V

2+2

2610

KIT ACCESSORIES

ACCESSORIES

4878K B/W single-family external unit simplebus - IKALL kit

Audio/video external unit with black 1-button faceplate, tted with

4680K jack, die-cast aluminium module-holder frame and ushmounted

box. Dimensions: 125x125x45 mm.

4878KC Colour single-family external unit simplebus - IKALL kit

Audio/video external unit with black 1-button faceplate, tted with 4680KC jack,

die-cast aluminium module-holder frame and ushmounted box. Dimensions:

125x125x45 mm.

4879K B/W two-family external unit simplebus - IKALL kit

Audio/video external unit with black 2-button faceplate, tted with4680K jack,

die-cast aluminium module-holder frame and ushmounted box. Dimensions:

125x125x45 mm.

4879KC Colour two-family external unit simplebus - IKALL kit

Audio/video external unit with black 2-button faceplate, tted with 4680KC jack,

die-cast aluminium module-holder frame and ushmounted box. Dimensions:

125x125x45 mm.

31121 Natural anodised aluminium rain shield

Natural anodised aluminium rain shield. 1 module. Dimensions 154x152x44 mm.

31161 Natural anodised aluminium housing with rain shield

Natural anodised aluminium housing with rain shield. 1 module. Dimensions

154x152x85 mm.

4680K IKALL series simplebus kit b/w audio/video unit

Simplebus Color system audio/video unit with terminal block complete with

front-adjustable wide-angle 1/4” B/W camera and LED camera illumination.

Complete with terminal block and digital audio management system with

Eco-cancelling, watertight loudspeaker and electrets microphone; loudspeaker

volume can be adjusted from the front. Complete with microprocessor and DIP

SWITCH with 8 positions for programming calls to users. Audiovisual indications

for disabled individuals assistance request can be activated via programming.

33Vdc power supply via special power supply unit Art. 1595. On-board electronic

lock-release function (3A), plus C, NC, NO contacts for 10A relay. For use in modu-

les Art. 33410, 33411 and 33412. Dimensions: 102x55x38 mm.

4680KC IKALL series simplebus kit colour audio/video unit

Simplebus Color system audio/video unit with terminal block complete with

front-adjustable wide-angle 1/4” colour camera and LED camera illumination.

Complete with terminal block and digital audio management system with

Eco-cancelling, watertight loudspeaker and electrets microphone; loudspeaker

volume can be adjusted from the front. Complete with microprocessor and DIP

SWITCH with 8 positions for programming calls to users. Audiovisual indications

for disabled individuals assistance request can be activated via programming.

33Vdc power supply via special power supply unit Art. 1595. On-board electronic

lock-release function (3A), plus C, NC, NO contacts for 10A relay. For use in modu-

les Art. 33410, 33411 and 33412. Dimensions: 102x55x38 mm.

4880 1 user external panel for B/W kit

Flush/Surface-mounted external video entry phone (the external unit is surface

mounted but a box art. 3554 is also provided to allow ush mounted installation

of the external unit) with anodized aluminium facing and ample name holder

slots, with LED rear-lighting. 12V AC power supply. Dimensions of external unit:

95x176x15 mm. Dimensions of ush-mounted box: 95,5x176x5x35 mm.

4881 2 user entrance panel for B/W kit

Flush/Surface-mounted external video entry phone (the external unit is surface

mounted but a box art. 3554 is also provided to allow ush mounted installation of

the external unit) with anodized aluminium facing and ample name holder slots,

with LED rear-lighting. 12V AC power supply. Dimensions of external unit: 95x176x15

mm. Dimensions of ush-mounted box: 95,5x176x5x35 mm.

4882 2 user entrance panel for colour

Flush/Surface-mounted external video entry phone (the external unit is surface

mounted but a box art. 3554 is also provided to allow ush mounted installation of

the external unit) with anodized aluminium facing and ample name holder slots,

with LED rear-lighting. 12V AC power supply. Dimensions of external unit: 95x176x15

mm. Dimensions of ush-mounted box: 95,5x176x5x35 mm.

4883 2 user entrance panel for colour kit

Flush/surface-mounted external video entry phone (the external unit is surface

mounted but a box art. 3554 is also provided to allow ush mounted installation of

the external unit) with anodized aluminium facing and nameplate holder, with LED

rear-lighting. 12V AC power supply. Dimensions of external unit: 95x176x15 mm. Di-

mensions of ushmountedbox: 95,5x176x5x35 mm.

3550 Flush-mounted external unit

Flush-mounted door entry phone external unit with front in anodised aluminium and

large nameholder label lit from the rear with an LED. Complete with speaker unit,

adjustment of the 2 volumes, callgenerator, watertight loudspeaker and electret

micro-phone. 12V AC power supply. Dimensions of external unit:95x176x15 mm.

Dimensions of ushmounted box: 95,5x176,5x35 mm.

3551 Surface-mounted external unit

Surface-mounted door entry phone external unit with front in anodised aluminium

and large nameholder label lit from the rear with an LED. Complete with speaker unit,

adjustment of the 2 volumes, call generator, watertight loudspeaker and electret mi-

crophone. 12V AC power supply. Dimensions of external unit: 95x176x25mm.

3552 Flush-mounted external unit

Flush-mounted door entry phone external unit with front in anodised aluminium and

large nameholder label lit from the rear with an LED. Complete with speaker unit,

adjustment of the 2 volumes, callgenerator, watertight loudspeaker and electret

micro-phone. 12V AC power supply. Dimensions of external unit: 95x176x15 mm.

Dimensions of ush-mounted box: 95,5x176,5x35 mm.

3553 Surface-mounted external unit

Surface-mounted door entry phone external unit with front in anodised aluminium

and large nameholder label lit from the rear with an LED. Complete with speaker unit,

adjustment of the 2 volumes, call generator, watertight loudspeaker and electret

microphone.12V AC power supply. Dimensions of external unit: 95x176x25mm.

3560 Flush-mounted external unit 2 wire

Flush-mounted door entry external unit with front in anodised aluminium and 1 alu-

minium call push-button, large name holder lit from the rear with an LED. Complete

with speaker unit, adjustment of the 2 volumes, watertight loudspeaker and electret

microphone. Dimensions of external unit: 95x176x15 mm.

3561 Surface-mounted external unit

Flush-mounted door entry external unit with front in anodised aluminium and 2 alu-

minium call push-button, large name holder lit from the rear with an LED. Complete

with speaker unit, adjustment of the 2 volumes, watertight loudspeaker and electret

microphone. Dimensions of external unit: 95x176x15 mm.

3573 3-button external unit for 5-wire STYLE kit

Flush-mounted door entry phone external unit with the faceplate in anodised alumi-

nium and a single call pushbutton, large name holder backlit with the exclusive blue

LED. Complete with speaker unit, call volume adjustment, call generator, watertight

loudspeaker and electret microphone. 12V AC power supply. Dimensions of external

unit: 95x176x15 mm.

3574 4-button external unit for 5-wire STYLE kit

Flush-mounted door entry phone external unit with the faceplate in anodi-

sed aluminium and a single call pushbutton, large name holder backlit with

the exclusive blue LED. Complete with speaker unit, call volume adjustment,

call generator, watertight loudspeaker and electret microphone. 12V AC po-

wer supply. Dimensions of external unit: 95X176X15 mm.

3554 Spare ush mounted box for IDEA

Flush-mounting box. Dimensions: 95,5x176,5x35mm.

4887 Waterproof housing for idea surface-mounted entrance panel

Protection housing with rain shield for Idea wall-mounted keypad.

Dimensions: 119x196x76 mm.

4889 Waterproof shield for idea ush-mounted entrance panel

Protection visor with rain shield for Idea ush-mounted button pad.

Dimensions: 115x195x52 mm.

5801 Monitor GENIUS series B/W handset

Genius monitor with 4’ B/W screen, white matt nish. Fitted as standard

with blue door-open pushbutton and two grey pushbuttons for various fun-

ctions. It has brightness control and a selector for the call volume, adjustable

to three dierent positions (high, medium and low). It can be converted into

a desk version using art. 5712. Dimensions: 204x225x63 mm.

5802 Monitor GENIUS series colour handset

Genius monitor with 3,5’ colour screen, white matt nish. Fitted as standard

with blue door-open pushbutton and two grey pushbuttons for various fun-

ctions. the brightness control and a selector for the call volume, adjustable

to three dierent positions (high, medium and low). It can be converted into

the desk version using art. 5712. Dimensions: 204x225x63 mm.

5814K Geniuskit B/W additional bracket

Completion bracket for monitor art. 5801. Fitted with branch terminal art.

1214/2.

5814KC Geniuskit colour additional bracket

Completion bracket for Genius monitor art. 5802. Provided with branch ter-

minal 1214KC.

5701 Monitor BRAVO series B/N handset

Handset version Bravo monitor with 4’ B/W screen, The chrome keys, the bril-

liant white gloss nish combined with the silver colour base combined with

the etched glass eect facia. It is tted as standard with door open pushbut-

tons and two pushbuttons for various functions, signalling LED, brightness

adjustment, contrast adjustment, and slide call volume adjustment. The

Call tone function, which allows the call tone to be temporarily excluded,

is standard and is obtained by positioning the call volume on zero. It can be

converted into a desk version with art. 5712. Dimensions: 212x225x55 mm.

5702 Monitor BRAVO series colour handset

Handset version Bravo monitor with 3.5’ colour screen. The chrome keys,

the brilliant white gloss nish combined with the silver colour base com-

bined with the etched glass eect facia. It is tted as standard with door

open pushbuttons and two pushbuttons for various functions, signalling

LED, brightness adjustment, contrast adjustment, and slide call volume

adjustment. The “Call tone’ function, which allows the call tone to be tem-

porarily excluded, is standard and is obtained by positioning the call volume

on zero. It can be converted into a desk version with art. 5712. Dimensions:

212x225x55 mm.

5714/K Bravokit B/W additional bracket

Completion bracket for Bravo monitor art. 5701. Fitted with branch terminal

art. 1214/2.

5714KC Bravokit colour additional bracket

Completion bracket for Bravo monitor with colour Bravokit. Fitted with

branch terminal art. 1214KC.

5712 Desk base with bushing for Bravo/Genius monitor

Desk base. Allows conversion into desk version of all the GENIUS/BRAVO mo-

nitors both in the handset and hands-free versions. Complete with 2 mt of

cable and connection box. Dimensions: 173x186.5x174 mm.

5733 Bravo monitor additional 4 buttons

Card with 4 additional pushbuttons (N/O or for digital services), provided

with screws. Can be inserted inside all the BRAVO series monitors rapidly

without having to open the monitor.

5734 Bravo monitor additional 2 buttons and 2 leds

Card with 2 additional pushbuttons (N/O or for digital services) and 2 ad-

ditional LEDs, provided with screws. Can be inserted inside all the BRAVO

series monitors rapidly without having to open the monitor.

6302 Smart series SBC/kit system hands-free colour monitor

Flush-mounted (on box Art. 6117) or Surface Mounted (with bracket Art.

6320) colour monitor with 3.5” screen and Full-Duplex hands-free audio.

Allows audio volume adjustment, ringtone volume adjustment with priva-

cy activation indicator light and brightness control. Fitted as standard with

key button, audio enabling/disabling button with corresponding indication

LEDs and 2 other buttons pre-set for self-ignition and switchboard call (the-

se can, however, be programmed for various uses). It is normally used for

local oor call management and call repetition, and comes complete with

an 8-position DIP SWITCH for user code programming, as well as a second

8-position DIP SWITCH for programming management. Inclusion of the

button card Art. 6333 allows a further 5 additional programmable buttons

to be made available. The monitor can be used in SBC Simplebus TOP co-

lour systems, or as an additional monitor for Simplebus KITS. Dimensions

138x138x24 mm.

6312 Desk base with bushing for Smart monitor

Adjustable tilt desk base converts the Smart monitor into a desktop version.

Complete with 1 x 2 m labelled RJ45 cable for connecting the monitor ter-

minals to the clasp or to a civil series jack. Dimensions: 145x190x120 mm.

6320 Supporto da parete per monitor Smart

Adjustable tilt desk base converts the Smart monitor into a desktop version.

Complete with 1 x 2 m labelled RJ45 cable for connecting the monitor termi-

nals to the Junction box or to a civil series jack. Dimensions:

145x190x120 mm.

6333 Accessory for 5 additional buttons on the Smart monitor

Accessory for Smart monitor which allows the addition of 5 extra program-

mable buttons for digital services. Can be installed quickly, without opening

up the monitor.

6101B PLANUX series hands-free colour monitor - absolute black

Colour monitor with 3.5” On-Screen Display. With touch-sensitive techno-

logy and full-duplex hands-free function. Audio volume, call volume,

colour, brightness and contrast adjustment. Ringtones can be customised,

selecting from the 7 melodies provided. Backlit control panel consisting of:

1 key button, 1 enable/disable audio button, 1 privacy or doctor function

button which can be selected via the menu (with red LED to indicate privacy

enabled), 1 self-ignition button, 2 buttons for various uses and 4 buttons for

entry, conrmation and navigation within the menus. The monitor, used in

conjunction with art. 6112, can be converted into the desk version. Dimen-

sions 145x145x33 mm.

KIT ACCESSORIES

6101W PLANUX hands-free colour monitor - white

Colour monitor with 3.5” On-Screen Display. With touch-sensitive technology

and full-duplex hands-free function. Audio volume, call volume, colour, bright-

ness and contrast adjustment. Ringtones can be customised, selecting from the

7 melodies provided. Backlit control panel consisting of: 1 key button, 1 enable/

disable audio button, 1 privacy or doctor function button which can be selected

via the menu (with red LED to indicate privacy enabled), 1 self-ignition button,

2 buttons for various uses and 4 buttons for entry, conrmation and navigation

within the menus. The monitor, used in conjunction with art. 6112, can be con-

verted into the desk version. Dimensions 145x145x33 mm.

6101B/C PLANUX LUX series hands-free colour monitor - black

Colour monitor with 3.5” On-Screen Display and glass cover. With touchsensi-

tive technology and full-duplex hands-free function. Audio volume, call volu-

me, colour, brightness and contrast adjustment. Ringtones can be customised,

selecting from the 7 melodies provided. Backlit control panel consisting of: 1

key button, 1 enable/disable audio button, 1 pri vacy or doctor function button

which can be selected via the menu (with red LED to indicate privacy enabled),

1 self-ignition button, 2 buttons for various uses and 4 buttons for entry, conr-

mation and navigation within the menus. Dimensions 160x167x4 mm.

6101W/C PLANUX LUX series hands-free colour monitor - white

Colour monitor with 3.5” On-Screen Display and glass cover. With touch-sensi-

tive technology and full-duplex hands-free function. Audio volume, call volu-

me, colour, brightness and contrast adjustment. Ringtones can be customised,

selecting from the 7 melodies provided. Backlit control panel consisting of: 1

key button, 1 enable/disable audio button, 1 privacy or doctor function button

which can be selected via the menu (with red LED to indicate privacy enabled),

1 self-ignition button, 2 buttons for various uses and 4 buttons for entry, conr-

mation and navigation within the menus. Dimensions 160x167x4 mm.

6114KC PLANUX kit colour additional bracket

The video door entry system is complete conversation privacy as standard.

Handles local oor calls and call repetition as standard. Dimensions: 96x106x17

mm.

6101L/C Template PLANUX LUX MONITOR White

6101N/C Template PLANUX LUX MONITOR Black

6112 Desk base with junction box for PLANUX monitor

Desk base allowing the Planux monitor to be converted for desk use, complete

with two 2 m RJ45 headed cables: one for connection to the VIP network, the

other to connect the extra terminals to the junction box. Dimensions: 145x190

x120 mm.

6117 Flush-mounted box for PLANUX and SMART monitors

Flush-mounted box for Planux and Smart monitors. Accessory art. 6122 can be

used for tilting the Planux monitor. Dimensions: 132x132x50 mm.

6118 Plasterboard installation kit for Planux and Smart monitors

Accessory allowing installation of Planux monitors on plasterboard walls, wi-

thout the application of box art. 6117. Installation kit for plasterboard walls.

6120 Surface-mounted support for PLANUX monitor

Short surface support for Planux monitor for use with tilt facility art 6122 Ac-

cessory art. 6122 cannot be used for tilting. Dimensions: 145x145x26 mm.

6121 High surface-mounted support for PLANUX monitor

Long support for Planux monitor wall mounting Accessory art. 6122 can be

used for tilting. Dimensions: 145x145x45 mm.

6122 Tilting accessory for planux monitors

Accessory for tilting Planux monitors to be used in combination with the

long support art.6121 and the ush-mounted box art. 6117. Dimensions:

136x136x40 mm.

2602 STYLE series 4 +1 traditional system BASIC intercom

Telephone with electronic call, conversation button on the base, call tonevo-

lume adjustment and privacy, door opener pushbutton and supplementary

isolated pushbutton for additional services with independent common. With

this model, addition of pushbuttons or supplementary LEDs is not possible.

Dimensions: 95x215x58 mm.

2608 STYLE series simplebus system BASIC intercom

Telephone with electronic call call tone adjustment, privacy of speech, call

tone privacy, door open pushbutton and supplementary pushbutton for porter

switchboard call or free (C/N.O.). By means of selection jumper, the second pu-

shbutton can be used to control actuator art. 1256. Allows management of the

local oor call and call repetition. Complete with dip-switch with 8 positions

for selection of the desired user code. With this model, addition of pushbuttons

or supplementary LEDs is not possible. Dimensions: 95x215x58 mm. From the

RI006 it is compatible with all SBTOP functions and products.

2610 STYLE series Simplebus top/kit system ELEGANCE intercom

Telephone with electronic call, call volume adjustment, privacy of speech, call

tone privacy. Fitted as standard with door open pushbuttons, porter switchbo-

ard call, actuator control Art. 1256 and LED for various functions (engaged and

doctor function). Up to 6 supplementary pushbuttons can be added, of which a

maximum of 3 LEDs. Allows management of the oor door call and call repeti-

tion. Complete with dip-switch with 8 positions for selection of the desired user

code. Telephone to be used in mixed audio/video Simplebus 1, Simplebus 2 sy-

stems. Fitted with branch terminal art. 1214/2C. With this model, the facia can

be replaced. From the RI010 it is compatible with all SBTOP functions and pro-

ducts. Allows direct intercommunication between users with the same address

(without the aid of an interface or porter switchboard), transmission of alarm

signals to the porter switchboard, separate call to main switchboard, secondary

switchboard and guardian door-entry phone. Dimensions: 95x215x58 mm.

2612 STYLE series BASIC intercom for 2-wire

Additional entry phone for kit 8270, with electronic call, call button on the

base, call volume adjustment, privacy, door open pushbutton and free (C/N.O.)

pushbutton. Dimensions: 95x215x58 mm.

2628 STYLE series Simplebus2 system ELEGANCE intercom - white

Telephone with electronic call call volume adjustment, privacy call tone, pri-

vacy of speech. Fitted with door open pushbutton, switchboard call, actuator

control art. 1256 and free (C/N.O.). Up to 6 supplementary pushbuttons can be

added, of which a maximum of 3 LEDs. Allows management of the local oor

call and call repetition. Complete with dip-switch with 8 positions for selection

of the desired user code. Telephone to be used in mixed audio/video systems

(Simplebus 1 and Simplebus 2) or in audio systems when the call repetition

function is required. Fitted with terminal 1214/2. With this model, the can facia

can be replaced. Dimensions: 95x215x58 mm. From the RI005 it is compatible

with all SBTOP functions and products.

1229 Accessory - additional ringtone

Additional bell for call repetition can be controlled directly from terminals S-

and S+ of the brackets and/or from the telephones. Surfacemounted or on civil

series 503 box. Dimensions: 110x75x29 mm.

1224A Simplebus system digital switching device

Switching device for audio or audio-video systems with 2 or more entrances.

Complete with 2 DIP SWITCHES with 8 positions for dening the user range

of the riser. 12V AC power supply (use transformer Art. 1200/U). Dimensions:

60x85x35 mm (4 DIN modules).

4833/A Line amplier for SIMPLEBUS video systems

Video amplier to be used in the following cases: 1. After the 50th mo nitor in

systems with more than 50 monitors. 2. Each 150 m. (if twisted pair is used)

or 100 m. (if normal cable is used) or 80 m. (if twisted and shielded pair is

used). 3. At the base of each riser in systems with video main panel and audio

or video secondary panels. 4. At the base of each riser in systems with main pa-

nel and star-connected risers (max 10). Power supplied at 12 VAC. Dimensions

66x85x35 mm (4 DIN modules).

4833C Line amplier for SIMPLEBUS color video systems

Amplier for Simplebus Color video systems. Regenerates the riser signal re-

garding the video component. Complete with microcontroller for optimum

operation management. For its use, follow the indications given in the tech-

nical documentation. Power supply: 12V AC or 20V DC. Only to be mounted on

the part of the system on input into the mixers art. 4888CU (Simplebus 1 part).

Dimensions: 66x85x35 mm (4 DIN modules).

1122/A 12-24 Vdc-Ac general purpose relay

All systems. 12-24 V DC-AC 10 A relay for general uses. Can be controlled di-

rectly, for call repetition, from terminals S+ and S of the brackets and/or from

the digital telephones Dimensions:68x85x35 mm (4 DIN modules).

1256 Simplebus system digital relay actuor

Intelligent Simplebus device for controlling a 10 A (12-24 V relay contact) on

board. It can be used in Simplebus 1 and Simplebus 2 systems. For use and

programming of the function required, follow the indications given in the tech-

nical documentation. If used in mixed audio/video systems, the actuator relay

needs terminal art. 1214/2 to be purchased separately. Power supply: 12V AC

or 20V DC. Dimensions: 66x85x35 (4 DIN modules).

1259/A Switcher for remote cameras

Module which allows modulation and transmission of the video signal coming

from 3 B/W cameras visible sequentially together with the image coming from

the external unit.Sequential switching of the cameras is possible by using the

Bravo or Videocom monitor actuator pushbutton. Possibility of managing pri-

vate cameras. Power supply: 12 V AC or 20 V DC. Dimensions: 60x85x35 mm (4

DIN modules).

1259C Simplebus colour kit for separate video cameras

Module which allows modulation and transmission of the video signal coming

from 3 colour cameras visible sequentially together with the image coming

from the external unit. Sequential switching of the cameras is possible by using

the Diva, Bravo or Genius actuator pushbutton. Possibility of managing private

cameras. Power supply: 12 V AC or 20 V DC. Dimensions: 60x85x35 mm (4 DIN

modules).

1214/2 Simplebus 2 connection terminal

Line branch terminal. The terminal is to be mounted on the riser to branch to-

wardsbrackets or telephones. It is provided as standard with the bracket art.

4714W/2.use. Dimensions: 53x95x65 mm (3 DIN modules).

1214/2C Simplebus 2 and Simplebus colour connection terminal

Line branch terminal for GENIUS monitor. The terminal must be connected on

the riser to be branched towards brackets or telephones.

1215 Simplebus2/colour/kit connection terminal

Terminal required when expanding the system with an additional SMART

door entry monitor. Dimensions 20x20x25 mm.

1216 Simplebus/kit system terminal

Line termination terminal. To be mounted at the end of the riser, according

to the indications given in the technical documentation, to optimise distri-

bution of the signals.

1200 12Vac transformer with 230Vac input

Transformer with 230V primary winding, 12V AC / 900 mA secondary win-

ding for continuous use.Dimensions: 53x95x65 mm (3 DIN modules).

1205/B 12Vac - 20Vdc dual output power supply with 230Vac input

Technical characteristics: The transformer has 2 outputs: one to supply

the external unit and the electric lock, and one to supply the monitor.

Dimensions: 105x85x85.mm 500mA delayed protection fuse.Terminal

board:AC230V input mains voltage ~~ AC output for external unit and elec-

tric lock+ - 20V DC output for the monitor power supply.

1207 Dual power supply unit, output 33Vdc-20 Vdc, input 230 Vac

Power supply unit with overload and short circuit protection devices. It has

two separate continuous outputs: one to power the external unit and elec-

tric lock, and the other to power the monitor. Input voltage 120-230 VAC.

Dimensions: 105x85x85 mm (6 DIN modules).

1212/B 20Vdc 14Va power supply with 230Vac input

Power supply with 230V AC input, 0-20V DC / 15VA output. The transformer

is tted with PTC internal protection. Dimensions:71.5x90x62 mm (4 DIN

modules).

4576/100 SIMPLEBUS system Comelit cable 2x0.5 mm2 + 2x1.5

mm2 - 100 m

Specic cable for Simplebus 1 systems consisting of two power supply

conductors (1.5 mm2) and a small telephone braid for the signals.

100 mt coil.

4576/500 SIMPLEBUS system Comelit cable 2x0.5 mm2 + 2x1.5

mm2 - 500 m

Specic cable for Simplebus 1 systems consisting of two power supply con-

ductors (1.5 mm2) and a small telephone braid for the signals. 500 mt coil.

4578/100 SIMPLEBUS external Comelit 100 m cable 2x0.5 mm2 +

2x1.5 mm2

Specic cable for outdoors for Simplebus systems 2 consisting of two power

supply conductors (1.5 mm2) and a small telephone braid for the signals.

100 mt coil.

4578/500 SIMPLEBUS external Comelit 500 m cable 2x0.5 mm2 +

2x1.5 mm2

Specic cable for outdoors for Simplebus systems 2 consisting of two power

supply conductors (1.5 mm2) and a small telephone braid for the signals.

500 mt coil.

cod.

2G31000210

Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo - Bergamo [Italy]

Ph. +39 (0) 346 750011 - Fax +39 (0) 34671436 - www.comelitgroup.com - info@comelit.it

Comelit Group Spa

Via Don Arrigoni 5

24020 Rovetta S. Lorenzo

Bergamo Italy

Tel. +39 (0) 346 750011

Fax +39 (0) 346 71436

www.comelitgroup.com - info@comelit.it

Comelit Group Belgium

Doornveld 170

1731 Zellik (Asse)

Tel. +32 24115099

Fax +32 24115097

www.comelit.be - info@comelit.be

Comelit Group Germany GmbH

Brusseler Allee 23 - 41812 Erkelenz

Tel. +49 243190151-23 - 49 243190151-24

Fax +49 24319015125

www.comelit.de

info@comelit.de

Comelit Group Spa- Sucursal en España

Calle Pintor Roig i Soler 28

08916 Badalona, Barcelona Spain

+34 932430376

+34 934084683

www.comelit.es

info@comelit.es

[ F ]

[ B ]

[ E ]

[ D ]

[ NL ]

Comelit (Shanghai)

Electronics Co.,Ltd

5 Floor No. 4 Building No.30,

Hongcao Road, Hi-Tech Park

Caohejing,

Shanghai, China

Tel. +86-21-64519192/9737/3527

Fax +86-21-64517710

www.comelit.com.cn

comelit@comelit.com.cn

Comelit Far East

Block 1002, Nr.06-1407

Toa Payoh Industrial Park

Singapore 319074

Tel. +65 6352 3456

Fax. +65 6352 8557

oce@comelit.sg

Comelit Group U.A.E.

Middle East Oﬃce

P.O. Box 54433

Dubai U.A.E.

Tel. +971 4 299 7533

Fax +971 4 299 7534

www.comelit.ae

info@comelit.ae

[ PRC ]

[ SG ]

Comelit Immotec

Siège: 18, rue Séjourné

94000 CRETEIL CEDEX

Tél. +33 (0) 1 43 53 97 97

Fax +33 (0) 1 43 53 97 87

www.comelit.fr

contact@comelit-immotec.fr

Comelit Hellas

9 Epiru str. - 16452 Argiroupolis

Athens Greece

Tel. +30 210 99 68 605-6

Fax +30 210 99 45 560

www.comelit.gr - telergo@otenet.gr

Comelit Ireland

Ground Floor

14 Herbert Street - Dublin 2

Tel. +353 (0) 1 619 0204

Fax +353 (0) 1 619 0298

www.comelit.ie - info@comelit.ie

Comelit Nederland BV

Buitendijks 1 - 3356 Lx Papendrecht

Tel. +31 786511201

Fax +31 786170955

www.comelit.nl

info@comelit.nl

[ IRL ]

[ GR ]

[ I ] Comelit Group UK Ltd

Unit 4 Mallow Park - Watchmead

Welwyn Garden City Herts

AL7 1GX

Tel: +44 (0)1707377203

Fax: +44 (0)1707377204

www.comelitgroup.co.uk

info@comelitgroup.co.uk

Comelit Usa

2021 S. Myrtle Avenue

Monrovia, CA 91016

Tel. +1 626 930 0388

Fax +1 626 930 0488

www.comelitusa.com

sales@comelitusa.com

[ UK ]

[ UAE ]

[ USA ]

Catalogue_123_EN Catalogue 123 EN

Navigation menu

Versions of this User Manual:

Views

Navigation
