ChatScript Fact Manual
©
Bruce Wilcox, gowilcox@gmail.com www.brilligunderstanding.com Revision
6/9/2018 cs8.3
•Simple Facts
•Advanced Facts
•Esoteric Facts
SIMPLE FACTS
Facts are triples of subject,verb,object – though those are just the names of the
fields and may or may not be their content. Facts look like this:
(Bob eat fish )
The system has a number of facts it comes bundled with and others can be
created and stored either from compiling scripts, or from interactions with the
user.
Facts can use words, numbers, or other facts as field values, representing anything.
You can build records, arbitrary graphs, treat them as arrays of data, etc.
Simple Creating Facts
ˆcreatefact( subject verb object )
this creates a fact triple. The system will not create duplicate facts. If you have
a fact (Bob eat fish) then executing
^createfact(Bob eat fish)
will do nothing further (but it will return the found fact). One way to create a
fact of a fact is as follows:
^createfact( (Bob eat fish) how slowly )
The other way is to assign the value of fact creation to a variable and then use
that variable. You need to pass in a flag at creation, to tell the system the value
is a factid.
$fact = ^createfact( Bob own fish)
^createfact ($fact Bob pet FACTSUBJECT)
$fact = ^createfact( Bob own dog)
^createfact ($fact Bob pet FACTSUBJECT)
1
The above creates facts which are findable by querying for pets Bob has. You
can have any number of flags at the end. Flags include:
flag description
FACTSUBJECT apply to storing fact ids in the subject field
FACTVERB apply to storing fact ids in the verb field.
FACTOBJECT apply to storing fact ids in the object field.
FACTTRANSIENT the fact will disappear at the end of this volley
FACTDUPLICATE allow this fact to be a duplicate of an existing
fact.This is particularly important if you go
around deleting facts that might be referred to
by other facts. Those other facts will also get
deleted.So if you want complete isolation from
facts that look the same in some subfact but
shouldn’t be shared, you’ll want that subfact
declared FACTDUPLICATE.
AUTODELETE on a normal fact means that when that fact is
destroyed, if it refers to other facts
(FACTSUBJECT, FACTVERB, FACTOBJECT)
then those referred facts will also get destroyed.
AUTODELETE on a json fact tells the system that
the value stored as the object field is actually a
normal fact id value and that fact should be
destroyed when the json fact is destroyed.
Accessing Facts
To find facts, you need to make a query. There can be many different kinds of
queries.
ˆfindfact( subject verb object )
The simplest fact find involves knowing all the components (meanings) and
asking if the fact already exists. If it does, it returns the index of the fact. If it
doesn’t it returns FAILRULE_BIT.
ˆquery( kind subject verb object )
The simplest query names the kind of query and gives some or all of the field
values that you want to find. Any field value can be replaced with
?
which
means either you don’t care or you don’t know and want to find it.
2
The kinds of queries are programmable and are defined in
LIVEDATA/queries.txt
(but you need to be really advanced to add to it). The simplest query kinds are:
query flag description
direct_s find all facts with the given subject
direct_v find all facts with the given verb
direct_o find all facts with the given object
direct_sv find all facts with the given subject and verb
direct_so find all facts with the given subject and object
direct_vo find all facts with the given object and verb
direct_svo find all facts given all fields (prove that this fact exists)
If no matching facts are found, the query function returns the RULE fail code.
?: (do you have a dog) ^query( direct_svo I own dog) Yes.
If the above query finds a fact
(I own dog)
then the rule says yes. If not, the
rule fails during output. This query could have been put inside the pattern
instead.
ˆquery(kind subject verb object count fromset toset propagate match)
Query can actually take up to 9 arguments. Default values are
?
. The count
argument defaults to
-1
and indicates how many answers to limit to. When you
just want or expect a single one, use 1as the value.
fromset
specifies that the set of initial values should come from the designated
factset. Special values of fromset are
user
and
system
which do not name where
the facts come from but specify that matching facts should only come from the
named domain of facts.
toset names where to store the answers.
Commonly you don’t name it because you did an assignment like
@3 =
ˆquery(...) and if you didn’t do that, toset defaults to @0 so
if ( ^query(direct_s you ? ?) )
puts its answers in @0. It is equivalent to:
if ( ^query(direct_s you ? ? -1 ? @0) )
The final two arguments only make sense with specific query types that use
those arguments. A query can also be part of an assignment statement, in which
case the destination set argument (if supplied) is ignored in favor of the left side
of the assignment, and the query doesn’t fail even if it finds no values. E.g.
@2 = ^query(direct_sv I love you)
3
The above query will store its results (including no facts found) in @2.
Queries can also be used as test conditions in patterns and if constructs. A
query that finds nothing fails, so you can do:
u: ( dog ^query(direct_sv dog wants ?)) A dog wants @0object.
You can also do !ˆquery. Or
if (^query(direct_vo ? want toy)) {@0subject wants a toy.}
Private queries
You can define your own queries beyond the LIVEDATA ones. In a normal topic
file as a top level unit you can do:
query: name "value"
Name is the name to give your query and the query command string is placed
within double quotes.
System-reserved verbs
The system builds the Word-net hierarchy using the verb
isa
, with the lower-level
(more specific) word as subject and the upper-level word as object. E.g.
(dog~1 isa animal~4)
The system builds concept and topic sets using the verb
member
with the member
value as subject and the set name as object. E.g.
(run member ~movementverbs)
When you build a table and a data member has a short-form like Paris for
*Paris,_France*, the verb is also
member
with subject as short form and long
form as object. E.g.,
(Paris member Paris,_France)
@Fact-Sets
The results of queries are stored in a fact-set.
Fact-sets are labeled @0,@1, etc. through @20.
By default in the simplest queries, the system will find all facts that match and
store them in fact-set @0.
A fact set is a collection of facts, but since facts have fields (are like records),
it is also valid to say a factset is a collection of subjects, or verbs, or objects.
4
Therefore when you use a factset, you normally have to specify how you want it
used.
fields description
@1subject means use
the subject
field
@1verb means use
the verb
field
@1object means use
the object
field
@1fact means keep
the fact
intact (a
reference to
the fact) –
required if
assigning to
another set.
@1+ means
spread the
sub-
ject,verb,object
onto
successive
match
variables –
only valid
with match
variables
@1- means
spread the
ob-
ject,verb,subject
onto
successive
match
variables–
only valid
with match
variables
5
fields description
@1all means the
same as @1+,
spread sub-
ject,verb,object,flags
onto match
variables._6
=
ˆfirst(@1all)
- this puts
subject in
_6, verb in
_7, object in
_8
It is legal to store
null
into a factset, and it will generally return
null
for all
accesses of that fact.
?: (do you have a pet ^query( direct_sv I pet ?) ) I have a @0object.
If the chatbot has facts about what pets it has stored like
(I pet dog)
and
(I
pet cat)
, then the rule can find them and display one of them. Which one it
shows is arbitrary, it will be the first fact found.
You can transfer the contents of one fact-set to another with a simple assignment
statement like
@2 = @1
You can transfer fields of a fact from a fact-set using assignment, while simulta-
neously removing that fact from the set. The functions to do this are:
ˆfirst( fact-set ), ˆlast( fact-set ), ˆpick( fact-set )
ˆfirst
– retrieve the first fact,
ˆlast
– retrieve the last fact,
ˆpick
– retrieve a
random fact, e.g.
_1 = ^first(@1all)
Removing the fact is the default, but you can suppress it with the optional
second argument KEEP, e.g.
_1 = ^last(@1all)
gets the last value but leaves it in the set.
You can erase the contents of a fact-set merely by assigning null into it.
@1 = null
6
This does not destroy the facts; merely the collection of them. You can sort a
fact set which has number values as a field
ˆsort( fact-set {more fact-sets} )
the fact set is sorted from highest first. By default, the subject is treated as a
float for sorting. You can say something like
@2object
to sort on the object field.
You can add additional factsets after the first, which will move their contents
slaved to how the first one was rearranged. Eg.
^sort(@1subject @2 @3)
will perform the sort using the subject field of
@1
, and then rearrange
@2
and
@3
in the same way (assuming they have the same counts). If you actually want to
destroy facts, you can query them into a fact-set and then do this:
ˆdelete( fact-set )
^delete(@1)
all facts in
@1
will be deleted and the set erased. You can also delete an individual
fact who’s id is sitting on some variable
^delete($$f)
If you merely want to empty a factset, you do
@0 = null
which does not damage any facts. When you do
^delete(@0)
you delete all facts within that factset AND all facts which use those facts as
part of themselves. Deleted facts are never saved at the end of a volley.
ˆlength( fact-set )
If you want to know how many facts a fact-set has, you can do this:
^length(@1)
outputs the count of facts.
ˆnth(fact-set count)
If you want to retrieve a particular set fact w/o erasing it, you can use
^nth(@1 count)
7
where the first argument is like
ˆfirst
because you also specify how to interpret
the answer) and the second is the index you want to retrieve. An index out of
bounds will fail.
ˆunpackfactref
examines facts in a set and generates all fact references from it. That is, it lists
all the fields that are themselves facts.
@1 = ^unpackfactref( @2)
All facts which are field values in @2 go to @1. You can limit this:
@1 = ^unpackfactref(@2object)
only lists object field facts, etc. Unlike variables, which by default are saved
across inputs, fact sets are by default discarded across inputs. You can force a
set to be saved by saying:
^enable(write @9) # force set to save thereafter
^disable(write @9 ) # turn off saving thereafter
You can store a fact in a fact set easily.
$$tmp = createfact(I love you)
@0 = $$tmp
or
@0 += $$tmp
Fact Indexing
A fact like
(bird eat worm)
is indexed by the system so that bird can find facts
with bird as the subject or as the verb or as the object. Similarly eat can find
facts involving it in each position. As a new fact is added, like
(bird hate cat)
the word bird gets the new fact added to the front of its list of facts involving
bird in the subject field.
So if you search for just one fact where bird is the subject, you get the most
recent fact. If you search for all facts with bird as the subject, the facts will be
stored in a fact set most recent first (lowest/earliest element of the fact set).
You would use
ˆfirst(@2)
to get its most recent fact and
ˆlast(@2)
to get its
oldest fact.
8
Tables
With the ability to create and manipulate facts comes the need to create large
numbers of them conveniently. This is the top-level declaration of a table, a
combination of a transient output macro declaration and a bunch of data to
execute the macro on. Usually the macro creates facts.
The table has
•a name (ignored- just for your documentation convenience),
•a list of arguments,
•a bunch of script,
•aDATA: separator,
•and then the table data.
The data is line oriented.
Within a line there are no rules about whitespace; you can indent, tab, use lots of
spaces, etc. Each line should have as many elements as the table has arguments.
The table ends with the end of file or a new top-level declaration. E.g.,
Table: authors (^author ^work ^copyright)
^createfact(^author member ~author) # add to concept ~author
^createfact(^work member ~book) # add to concept ~book
^createfact(^work exemplar ^author) # author wrote this book
if (^copyright != *) { ^createfact(^copyright date ^work) }
Data:
"Mark Twain" "Huckleberry Finn" 1884
"Mark Twain" "Tom Sawyer" * # don't know the date
For tables with really short data, you can choose to cheat on the separate line
concept, and separate your entries with \n , which is the equivalent.
DATA:
a 1 \n b 2 \n c 3 \n d 4 \n e 5 # values assigned to letters.
f6g7
Tables of only single values do not need a line separator. E.g,
table: mine(^arg)
DATA:
value1 value2 value3
value4 value5 value6
A table allows you to automatically list shortened synonyms of proper names.
For example, Paris could be a shortened synonym for Paris, France.
In a table of capitals, you would normally make the fact on the full name, and
9
write the shortened synonyms in parens. You may have more than one: “Paris,
France” (Paris “City of Love”) France.
These synonyms are represented using the member verb, sort of like making a
concept set of the full name. The system detects this specially during inferencing,
and if an argument to ˆquery were Paris, it could automatically transfer across
and consider facts for *Paris,_France* as well.
It would not go the other way, however, so if the argument were Paris_France,
it would not move over to Paris.
You should store your facts on the full name. The mechanism allows user input
to use the short name.
Variable Argument Tables
While a line of table data must fill all fields of the table exactly (no more or less),
you can tell the system to fill in the remaining arguments with
*
by putting
...
as your last value. Eg.
table: test(^item1 ^item2 ^item3 ^item4)
# ...
Data:
lion 50 ...
This table will use *for item3 and item4 of lion.
Alternatively, you can declare the table variable via:
table: ^mytable variable ( ^arg1 ^arg2 ^arg3 ^arg4 )
which allows you to not supply all arguments and not use
...
, but it means you
get no error checking if you failed to supply enough arguments.
Note:If you create member facts to add something to a concept, the concept
must have been predeclared. You can declare an empty concept just before the
table like this:
concept: ~newconcept()
table: mytable( ^x )
createfact(^x member ~newconcept)
DATA:
# data here
TABLEMACRO
When you have tables you generate over and over again, you don’t want to repeat
all the script for it. Instead you want to declare a permanent table function
10
using a table macro.
It looks a lot like a table definition, except it has a different declaration header
and has no DATA: or data attached.
tablemacro: ^secondkeys(^topic ^key)
$$tmp = join(^topic . 1 )
CreateFact(^key member $$tmp)
The table macro can declares more arguments than the table will have. When
you invoke an actual table using it, you will be supplying some of the arguments
then, and the rest come from the table data. An invocation of this tablemacro
would look like this:
table: ^secondkeys(~accidents)
repair garage insurance injure injury
Note several things. This is declared as a table. The system can tell the difference
because the table name (ˆsecondkeys) will already have a definition.
The arguments you supply must be real arguments, not
ˆxxx
names of dummy
arguments). This table presupplies one argument (~accidents).
There is no need for a
DATA:
line because the table function has already been
defined- it knows all its code. So one proceeds directly to supplying table data. In
this instance, the code will be expecting each table entry is one value, because the
ˆsecondkeys
tablemacro said there are two arguments. Since one is presupplied,
the table data must supply the rest (1). So this will execute the table code on
each of the 5 table data entries.
Datum
You can use a tablemacro within a topic to declare a single table line.
It must be at the top level, like a t: or u: rule. E.g.
topic: ~mytopic []
t: this is a test
datum: ^secondkeys(~accidents) repair
Note that unlike tables that are allowed to run to many entries even on the same
line sometimes, a datum will only be allowed to run the tablemacro once.
String processing in Tables
It is common for a string to be a table argument. Any functional string
ˆ"xxx"
stores itself in an appropriate manner.
11
They are like regular output - they are literally output script. Formatting is
automatic and you get to make them do any kind of executable thing, as though
you were staring at actual output script.
There is no user context when compiling a table. As a consequence, if you have
table code that looks like this:
^createfact( x y ^" This is $var output")
the functional string does NOT evaluate itself before going to createfact. It gets
stored as its original self.
Regular strings, by default, remove their quotes and substitute underscores for
spaces. This is good when the intention is as a composite word, but if the string
is to be used as direct output, you may prefer to retain the quotes and spaces.
You can do this by declaring the argument name with .KEEP_QUOTES. E.g.
table: ^test( ^my1 ^my2.KEEP_QUOTES)
It is particularly important to use the quoted form when the contents includes a
concept or topic name that has underscores because the system cannot tell a
spacing underscore from a significant one.
Simple Fact Functions (more in system functions manual)
Various functions create, destroy and aggregate facts, as well as mark and unmark
them. For those routines that aggregate facts, the result is stored into a fact set.
Usually this is done by assignment, e.g.
@2 = gambitTopics()
Such assignments never fail, they just may assign a zero length to the result.
Often, however, you can use the function to simultaneously store and test. If
not in an assignment context, the function will store results into
@0
and fail if
the result is no facts. Eg.
if ( gambitTopics() ) { first(@0object)}
ˆaddproperty( set flag )
add this flag onto all facts in named set or onto words. If you just say
^addproperty(@9 USER_FLAG3)
then all facts get that flag on them. The predefined but meaningless to the
system fact flags are User_flag4,User_flag3,User_flag2,User_flag1.
If set has a field marker (like
@2subject
) then the property is added to all values
of that field of facts of that set, that is, a dictionary word. The flags must come
from dictionarysystem.h and the set of property flags or system flags.
12
ˆconceptlist( kind location )
Generates a list of transient facts for the designated word position in the sentence
of the concepts (or topics or both) referenced by that word, based on kind being
CONCEPT
or
TOPIC
or
BOTH
. Facts are
(~concept ˆconceptlist location)
where location is the location in the sentence.
^conceptlist( CONCEPT 3 ) # absolute sentence word index
^conceptlist( TOPIC _3 ) # whereever _3 is bound
Otherwise, if you don’t use an assignment, it stores into set 0 and fails if no facts
are found. Any set already marked
ˆAddproperty(~setname NOCONCEPTLIST)
will not be returned from
ˆconceptlist
. Special preexisting lists you might use
the members of to exclude include:
~pos
(all bits of word properties)
~sys
(all
bits of system proerties) and ~role (all role bits from pos-tagging).
If you omit the 2nd argument (location), then it generates the set of all such in
the sentence, iterating over every one but only doing the first found reference of
some kind.
If you use
ˆmark
to mark a position, both the word and all triggered concepts
will be reported via
ˆconceptlist
. But if the mark is a non-canonical word,
mark does not do anything about the canonical form, and so there may be no
triggered concepts as well. (Best to use a canonical word as mark).
ˆcreatefact( subject verb object flags )
the arguments are a stream, so flags is optional. Creates a fact of the listed data
if it doesn’t exist (unless flags allows duplicates). See system functions manual
for a bit more on how createfact can process data.
ˆdelete( set )
erase all facts in this set. This is the same as
ˆaddfactproperty(set
FACTDEAD).
ˆfield(fact fieldname)
given a reference to a fact, pull out a named field. If the fieldname is in lower
case and the field is a fact reference, you get that number. If the fieldname starts
uppercase, the system gives you the printout of that fact. Eg for a fact:
$$f = createfact (I eat (he eats beer))
^field( $$f object) # returns a number (the fact index)
and
13
^field($$f object) # returns (he eats beer)`
fieldname include:
subject
,
verb
,
object
,
flags
,
all
(spread onto 3 match
variables, raw (spread onto 3 match variables).
all
just displays a human normal dictionary word, so if the value were actually
plants~1
you’d get just plants whereas raw would return what was actually
there plants~1.
You can also retrieve a field via $$f.subject or $$f.verb or $$f.object.
ˆfind( setname itemname )
given a concept set, find the ordered position of the 2nd argument within it.
ˆOutput that index (0-based). Used, for example, to compare two poker hands.
ˆfirst( fact-set-annotated )
retrieve the first fact. You must qualify with what you want from it. Retrieve
means the fact is removed from the set.
ˆfirst(@0subject)
retrieves the subject
field of the first fact.
Other obvious qualifications are
verb
,
object
,
fact
(return the index of the
fact itself),
all
(spread all 3 fields onto a match variable triple,
raw
(like all but
all displays just a normal human-readable word like plant whereas raw displays
what was actually there, which might have been plant~1).
ˆlast( fact-set-annotated )
retrieve the last fact – see ˆfirst for a more complete explanation.
ˆlength( word )
puts the length of the word into the output stream. If word is actually a fact set
reference (e.g., @2 ), it returns the count of facts in the set.
ˆnext( FACT fact-set-annotated )
Allows you to walk a set w/o erasing anything. See
ˆfirst
for more complete
description of annotation, the distinction between next and
ˆfirst
is that next
does NOT remove the fact from the set, but moves on to each fact in turn. You
can reset a set with
^reset(@1)
14
then loop thru it looking at the subject field with
loop() { _0 = next(FACT @1subject) }
ˆpick(~concept )
Retrieve a random member of the concept. Pick is also used with factsets to
pick a random fact (analogous to ˆfirst with its more complete description).
ˆreset( fact-set )
Reset a fact set for browsing using ˆnext.
ˆquery( kind subject verb object )
See writeup earlier.
ˆsort( set )
sort the set.
ˆunduplicate( set )
Remove duplicate facts from this set. The destination set will be named in an
assignment statement like:
@1 = ^unduplicate(@0)
Facts vs Variables
How are facts and variables different? Which should you use?
Facts are persistent.
If you don’t create them explicitly as transient, they stay with the user forever.
Variables that don’t begin with
$$
are also persistent and stay with the user
forever.
There are no limits on the number of variables you can have (none that you need
be aware of) and variable names can be up to 999 characters long.
15
The limits on user facts that can be saved are defined as a parameter when CS
is started up (default 100). You can create more facts, but it will only save the
most recent limit.
Facts are indexed by subject, verb, object, so you can query to find one.
Variables you have to know the name of it (but it can be composed on the
fly). Facts use up more memory, but can be exported to arbitrary files (and
imported).
Facts can represent an array of values, with a field as index. But so can variables
with omposited naming.
So mostly it depends on whether you want to find information by querying. You
have implicit associations of facts by the values of the subject, verb, and object
fields. But you could create a variable name of two of the fields of the fact, if
the third field was really the fact’s “value”.
WARNING When you get a reference to a fact, like:
$$tmp = ^first(@1fact)
that value is a numeric index into fact space. It is ONLY valid during the current
volley. You cannot insure that it will remain valid across volleys. The valid ways
to access facts across volleys are:
1. rerun ˆquery(...) to get a set of factsubject
2.
get your fact reference into an @factset and have the set marked to save
across volleys via ˆenable(write @4)
3. save the fact as text to a permanet variable, e.g.,
$fact = ^WriteFact(^first(@1fact)
You can later reaccess (or recreate) this fact via ˆcreatefact($fact).
ADVANCED FACTS
Facts of Facts
Suppose you do something like
^createfact( john eat (wet food peanuts))
What happens when you retrieve it into a fact set and then do
_1 = ^last(@1+)
16
and get the fact disassembled onto _1,_2,_3, and _4?
What you get for _3 is a reference to a fact, that is, a number.
You can decode that by using
ˆfield( _3 subject)
or
ˆfield(_3 verb)
or
ˆfact(_3 object)
to get wet or food or peanuts. The first argument to
ˆfield
is a fact number.
You get a fact number if you do
_3 = createfact(...)
and can decode
_3
the
same way. Naturally this function fails if you give it something that cannot be a
fact reference.
Flags
Facts may have flags on them. You can create them with flags (see
ˆcreatefact
)
and you can get them using ˆfield or when you spread out a fact onto a collection
of match variables.
System-defined flags (which should not be set or erased by user scripts) are:
flag description
FACTSUBJECTFACTVERBFACTOBJECTdescribe that a field is a fact
FACTDEAD indicates the fact has been killed
and will go away at the end of
volley
Flags you can use to define facts that have system meaning but may or may not
stay on them are:
flag description
FACTDUPLICATE
allow multiple versions of the same
fact
FACTTRANSIENT the fact should die at the end of
the volley if not in a fact set
ORIGINAL_ONLY
a “member” fact defining a concept
only uses the raw word
Flags you can set for yourself include:
flag description
USER_FLAG1USER_FLAG2USER_FLAG3USER_FLAG4USER_FLAG5USER_FLAG6USER_FLAG1USER_FLAG8user defined
17
Facts created by JSON code have user markings also, renamed as
flag description
JSON_PRIMITIVE_VALUEJSON_STRING_VALUEJSON_ARRAY_VALUEJSON_OBJECT_VALUEwhich indicate what kind of value
the object of the fact is.
JSON_ARRAY_FACTJSON_OBJECT_FACTwhich indicate what kind of value
the subect of the fact is.
JSON
Json is a great representation for creating and accessing complex fact structures.
See the ChatScript JSON manual for more details.
ESOTERIC FACTS
Compiled Script Table Arguments
You can specify that a table argument string is to be compiled as output script.
Normally it’s standard word processing like all English phrases. To compile it,
you prefix the doublequoted string with the function designator ˆ. E.g.,
DATA:
~books "this is normal" ^"[script a][script b] ^fail(TOPIC)"
This acts like a typical string. You pass it around, store it as value of variables
or as a field of a fact. Like all other strings, it remains itself whenever it is put
into the output stream, EXCEPT if you pass it into the
ˆeval
function. Then
it will actual get executed So.
To use that argument effectively, you would get it out of the fact you built
and store it onto some variable (like
_5
or
$value
) , and then
ˆeval(_5)
or
ˆeval($value).
FactSet Remaps
Factset names like @1 are not mnemonic. You can “rename” them as follows:
rename: @bettername @12
in a script before any uses of
@bettername
, which now mean
@12
. Then you can
do:
$$tmp = @betternamesubject
18
Predefined queries
exact_
- use the given arguments without expanding beyond them. Most efficient
when you know exactly what you want.
exact_svrange
- find facts given subject and verb, where object is a number
and must be in range (>= propogate <= match)
exact_vrange
find facts given
verb, where object must be number in range (>= propogate <= match)
e.g. @0 = ^query(exact_vrange ? myverb ? -1 ? ? $_lowvalue $_highvalue)
direct_ and direct_flag
up2set
- propogate upwards from subject to find the fact that leads to object of
which is a given concept
given: (soap member ~hygiene_items) and (~hygiene_item member ~personal_items) and (~personal_items member ~drugstore) and (~drugstore member ~storetypes)
given ^query(up2set soap ? '~store_type 10 ) - ie, what kind of store sells soap
yields (~drugstore member ~storetypes)
up2seta
- similar to up2set but you name the verb instead of assuming member/is
Defining your own queries
The query code wanders around facts to find those you want. But since facts
can represent anything, you may need to custom tailor the query system, which
itself is a mini-programming language. The full query function is takes nine
arguments and any arguments at the end you omit default themselves.
All query kinds are defined in
LIVEDATA/queries.txt
and you can add entries
to that (or revise existing ones). The essential things a query needs to be able
to do is:
1. Start with existing words or facts
2. Find related words or facts
3.
Mark newly found words or facts so you don’t trip over them multiple
times
4.
Mark words or facts that you want to ignore or be treated as a successful
find
5. Store found facts
A query specification provides a name for the query and specifies what operations
to do with what arguments, in what order.
An essential notion is the “tag”. As the system examines facts, it is not going
to compare the text strings of words with some goal. That would be inefficient.
Instead it looks to see if a word or a fact has a particular “tag” on it.
Each word/fact can have a single tag id, drawn from a set of nine. The tags ids
are labeled 1thru 9.
19
Another essential notion is the field/value. One refers to fields of facts or values
of the incoming arguments, or direct values in the query script.
Here are the codes involved:
code meaning
srefers to the subject argument or the subject field of a fact
vrefers to the verb argument or the verb field of a fact
orefers to the object argument or the object field of a fact
prefers to the propagate argument
mrefers to the match argument
~set use the explicitly named concept set
'word use the explicitly named word
@n use the named fact set
Each query has is composed of four segments. Each segment is separated using a
colon. Each segment is a series of actions, which typically involve naming a tag,
a field, and then the operation, and possibly special arguments to the operation.
You can separate things in a segment with a period or an underscore, to assist
in visual clarity. Those characters are ignored. I always separate actions by
underscores. The period I use to mark the end of literal values (
~sets
and
'words).
EXAMPLE 1 – PARIS as subject
Consider this example: we want to find facts about Paris. The system has these
facts:
(Paris exemplar France)
and
(Paris member ~capital)
Our query will be
^query(direct_s Paris ? ?)
which request all facts about a subject named Paris (to be stored in the default
output factset @0).
Segment one handles marking and/or storing initial values. You always start by
naming the tag you want to use, then naming the field/value and the operation.
The operations are:
20
operation meaning
ttag the item
qtag and queue the item
<> scan from the item, tagging things found (more explanation shortly)
The query
direct_s
, which finds facts that have a given subject, is defined as
1sq:s::
This says segment 1 is
1sq
and segment 2 is
s
and segments 3 and 4 have no
data.
Segment 1 says to start with a tag of
1
, use the subject argument and tag and
queue it.
Segment two says how to use the queue. The queue is a list of words or facts
that will be used to find facts. In our example, having stored the word Paris
onto the queue, we now get all facts in which Paris participates as the subject (
the s: segment )
Segment three tells how to disqualify facts that are found (deciding not to return
them). There is no code here, so all facts found will be acceptable.
Segment four tells how to take disqualified facts as a source of further navigation
around the fact space. There is nothing here either. Therefore the system returns
the two facts with Paris as the subject
Example 2 – Finding facts up in the hierarchy
Assume you have this fact
( 23 doyou ~like)
and what you actually have is a
specific verb like which is a member of ~like. You want to find facts using doyou
and like and find facts where doyou matches and some set that contains like
matches.
The query for this is
direct_v<o
, which means you have a verb and you have
an object but you want the object to match anywhere up in the hierarchy.
<
,
which means the start of the sentence in patterns, really means the left side
of something. And in the case of facts and concepts, the left side is the more
specific (lower in the hierarchy) and the right side is most general (higher in the
higherarchy) when the verb is member.
21

Navigation menu
