QuickSpecs
Compaq P1210 CRT Monitor
DA-10707 World Wide — Version 2 — May 21, 2001
1
M
ODELS
Compaq P1210 CRT Monitor
210290-xxx
Note: AssetControl monitor. AssetControl features are accessible with Compaq desktops featuring Intelligent Manageability.
S
PECIFICATIONS
Type Color auto- scanning with Digital Control
Picture Tube (diagonal) 22 in/56 cm Diamondtron NF CRT
Viewable (diagonal) 20 in/51 cm
Pitch 0.24 mm Aperture Grill Pitch
Graphic Preset Modes 1920 x 1440 1792 x 1344 1600 x 1200 1280 x 1024
80 Hz/60 Hz, 75 Hz
85 Hz/60 Hz, 75 Hz 95 Hz/75 Hz, 85 Hz 110 Hz/60 Hz,
75 Hz, 85 Hz
1024 x 768 800 x 600 640 x 480
145 Hz/75 Hz, 85 Hz 160 Hz/75 Hz, 85 Hz 160 Hz/60 Hz, 85 Hz
Note: All modes are non-interlaced unless specified otherwise. V Frequency shown Maximum/Presets.
Text Mode 720 x 400
70 Hz
Mac Compatible Modes 1152 x 870
75 Hz
Note: Adapter required.
User-Programmable Modes 18 (9 Preset Modes and 9 Pre-loads)
Anti-Glare/Anti-Reflection/Anti-Static Yes/Yes/Yes
Plug and Play Yes
Plug and Play Protocol DDC1/2B
Dual Video Inputs Yes
Approvals/Certifications MPR-II (Low Emissions) Yes
TCO-99 Yes
Energy Star Compliant Yes
UL Listing Yes
ISO9241-3 VOT Guidelines Approval Yes
FCC Approval Yes
CE Mark (including PFC) Yes
GS Mark Yes
Analog Controls No
Brightness, Contrast Yes
On-Screen Controls Yes
QuickSpecs
Compaq P1210 CRT Monitor
DA-10707 World Wide — Version 2 — May 21, 2001
2
S
PECIFICATIONS
(continued)
Language Selection English Yes
Spanish Yes
French Yes
German Yes
Dutch No
Italian Yes
Japanese Yes
User Controls Sizing and Positioning Yes
Pincushion Yes
Pincushion Balance Yes
Trapezoid Yes
Tilt (rotation) Yes
Color temperature Yes
Degauss Yes
Parallelogram Yes
Individual color control Yes
Zoom Yes
Moiré Cancellation Yes
Convergence Yes
Factory Reset Yes
Corner Purity Adjustment Yes
AssetControl Yes
Note: When used with Compaq Intelligent Manageability CPUs and appropriate network software.
Pixel Clock Frequency (maximum) 340 MHz (2048 x 1536, 75 Hz, 120 kHz)
Input Impedance 75 ohms
Horizontal Frequency 30 to 121 kHz
Vertical Frequency 50 to 160 Hz
Power Supply 90 to 260 VAC
Maximum Power Rating 155 W
USB Capabilities Built-in; 1 upstream, 3 downstream
Synchronized Input Separate H, V synchronized
Signal Cable Detachable 15-in D-sub to 15-pin D-sub cable. Two D-sub connectors on monitor
Maximum Phosphorus Size 16 x 12 in/406.1 x 304.6 mm (20 in/507.6 mm diagonal)
Dimensions (HxWxD) 19.7 x 19.7 x 19 in/500 x 500 x 482 mm
Weight 66 lbs/30 kg
Temperature Operating 50° to 95° F/10° to 35° C
Non-operating –4° to 140° F/–20° to 60° C
QuickSpecs
Compaq P1210 CRT Monitor
DA-10707 World Wide — Version 2 — May 21, 2001
3
S
PECIFICATIONS
(continued)
Humidity Operating 20% to 80%
Non-operating 10% to 95%
Warranty Three-year parts, three-year on-site labor, or next business day direct replacement
Note: Certain restrictions apply. Consult the Compaq Customer Service Support Center for details.
QuickSpecs
Compaq P1210 CRT Monitor
DA-10707 World Wide — Version 2 — May 21, 2001
4
C
OMPATIBILITY
Graphics Controllers 3Dlabs Oxygen GVX1
3Dlabs OXYGEN VX1-16 (PCI)
3Dlabs OXYGEN VX1-32 (AGP)
ATI Mobility P
ATI RAGE PRO TURBO 2X
Compaq Powerstorm 300 (PCI)
Compaq Powerstorm 350 (PCI)
Diamond Viper V730
Diamond Viper V770 Ultra
ELSA GLoria II
ELSA GLoria Synergy (PCI)
ELSA Synergy II
Intense3D Wildcat 4110
Matrox Millennium II
Matrox Millennium G100 (AGP)
Matrox Millennium G200 (PCI)
Matrox Millennium G400
Matrox Millennium G450 (AGP and PCI)
NVIDIA GeForce 2 GTS
NVIDIA GeForce 256
NVIDIA TNT2 M64
NVIDIA TNT2 Pro
NVIDIA Vanta
RAGE ATI Iic
S3 VIRGE/MX (AGP)
Velocity 4000
Chipsets Intel 810e
Intel 815
Intel 815e
