PRODUCT CATALOG
Concord™ Family
Product Catalog
December 1999
Interactive Technologies, Inc. •2266 Second Street North, North Saint Paul, MN 55109 • 800/777-5484 • www.itii.com
CONTROL PANELS
Concord Express
Concord Express System Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Concord System Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Concord Commercial System Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Sirens and Speakers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Hardwire Speakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
SAW Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Crystal Intrusion Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Crystal Fire and Smoke Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Crystal Environmental Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
X-10 Lighting and Appliance Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Central Station Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Hardwire Intrusion Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Hardwire Miscellaneous Detectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Sales, Print, and Video Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
CONTROL PANELS
Concord Express
INNOVATIVE TECHNOLOGY
Concord Family Line
1
Learn Mode™ Technology
ITI patented Learn Mode technology
increases the ease and reliability of
installations. Each sensor in a system
has its own factory-programmed
identity. ITI control panels “learn” the
identity of each sensor in the system
which eliminates programming
errors in the field and other problems
associated with the wireless systems
of other manufacturers.
Installation Time
ITI Learn Mode systems are easy to
install. Once the sensors are installed,
they are added to the control panel
memory; no sensor programming is
required. Large residential systems
can be installed in a single day by a
relatively inexperienced installer.
Smaller installations, such as
apartments, can be completed in less
than four hours.
Applications
ITI systems are used around the world
to protect people and property. ITI
systems are installed in museums for
collection security, military
installations for equipment security,
utility companies for usage
monitoring, nursing homes for
resident monitoring, and universities
for computer equipment security.
Home Automation
ITI systems go beyond burglar and
fire protection. The home automation
features available with some ITI
systems allow the user to turn lights
on and off at the touch of a button
and control their heating and cooling
system to save energy.
Two-Way Voice
ITI has responded to the growing
concern over false alarm prevention
and violent crime by developing its
two-way voice technology. Two-way
voice allows the central station
operator to hear what is happening
during an alarm and speak directly to
the people on the premises.
Reporting and Off-site
Programming Capabilities
ITI systems can report in SIA 2 and
Contact ID formats and can report to
most receivers. With many ITI
systems, system programming
changes can be made over the phone
using ITI ToolBox™ upload/download
software.
Ratings
The newest ITI products meet the
following ratings:
UL 985 (Household fire)
UL 1023 (Household burglary
CSFM (California State Fire Marshall)
ULC pending (UL of Canada)
The Concord Security System allows the greatest flexibility of any system in the industry.
ITI Technology
INNOVATIVE TECHNOLOGY
Concord Family Line
2
Sensors
The flexible design of the Concord
Family makes it compatible with
most hardwire sensors and the ITI
patented Learn Mode™ sensors. Each
Learn Mode sensor has its own
factory-programmed identification
code that is “learned" by the control
panel, which eliminates
programming errors in the field.
SAW sensors are distinguished from
ITI’s Crystal line by their use of
Surface Acoustical Wave (SAW) radio
technology and consumer-
replaceable alkaline batteries. The
SAW sensor offering includes a
door/window sensor, PIR motion
sensors, a water sensor, a freeze
sensor, and a keychain touchpad.
BURGLARY
To protect against intrusion, theft
and violence, hardwire sensors and
all ITI Learn Mode wireless sensors
can be added to the Concord Security
Systems.
LIFE SAFETY
Sensors can also protect against the
dangers of fire and carbon monoxide.
Help is summoned in the event of a
medical emergency.
ENVIRONMENTAL
Your customers can be warned of
flooding basements and furnace
failures before costly damage is done.
HOME AUTOMATION
Home Automation Modules,
exclusive to the Hybrid, Integrated,
and Commercial panels, provide
added security and convenience.
Lights can cone on automatically at
scheduled times during the day, the
system can be controlled from any
touchtone phone, and heating and air
conditioning can be managed while
your customer is away from home.
Concord Family Line
The Concord™ family of products is a
complete source for all your security
needs. From entry-level to high-end
residential and new construction
markets to commercial application,
the Concord product line has the
right solution for the job. It includes
four product versions: Concord
Express, Concord Hybrid, Concord
Integrated, and Concord Commercial.
Concord is a hardwire hybrid family
that provides reliable burglary
detection, life safety protection, and
home automation. Modular design
gives Concord the flexibility you
need to create system solutions your
customers want.
The flexible design of Concord is
your key to satisfied customers and
profitable upsell opportunities.
Within the Concord product line,
choose the panel that matches each
customer’s individual budget and
system requirements. From there,
tailor the panel by selecting from its
list of compatible options.
Residential, New
Construction, and
Commercial
Security Solutions
CONCORD EXPRESS
An integrated hardwire/wireless
security system that provides
burglary and fire detection. Offering
up to 24 zones, Concord Express
gives small- to mid-sized residential
customers an affordable, dependable
security choice.
CONCORD HYBRID
With 2 partitions and up to 76
zones, the Concord Hybrid panel is
designed for mid to large residential
and commercial security and home
automation needs. The hybrid panel
comes standard with 8 hardwire
zones and can be expanded with
additional hardwire inputs and
outputs and RF receivers.
CONCORD INTEGRATED
The Concord Integrated includes 16
or 32 wireless zones built-in.
Featuring 8 standard hardwire
zones, 2 partitions and the ability to
expand to 76 total zones, the
integrated panel is an excellent
offering for your high-end
residential and commercial
customers. The Integrated panel
provides comprehensive hardwire
and wireless security, life safety, and
home automation solutions.
CONCORD COMMERCIAL
For commercial locations requiring
UL listed burglary panels, Concord
Commercial is the correct security
choice. The commercial panel has
the UL 1610 approval for
commercial burglary. With 2
partitions and up to 76 zones,
Concord Commercial provides
complete intrusion protection for
your commercial customers.
EXPRESS
Concord Family
Interactive Technologies, Inc. 3
Concord Express System Configuration
To configure a Concord Express Security System, start by selecting the control panel components listed on pages 1 thought 3.
Control Panel Description/Features Specifications Accessories
60-806-95R
Concord Express Control Panel
Provides commercial and residential
security
6 built-in hardwire zones
(24 total zones with optional expansion
cards)
16 user-access codes with user-program
able authority
2-wire smoke detector compatibility
8 built-in wireless zones
16.5 VAC, 25 VA, 60 Hz transformer
12 VDC, 4 Ah sealed, lead-acid backup
battery
Regulated, current limited, fused 12 VDC
output
15-minute battery test under load every
24 hours
Gray, wall mount, steel enclosure
40 to 100 °F operating temperature
9.0” wide x 11.0” high x 3.0” deep
60-763 Lock and keys for Concord
Express enclosure
60-791 Installation Programming
Cable (connects LCD touchpad to panel
for on-site programming)
60-793 Concord Expansion Module
(holds up to six single-sized SuperBus
modules)
Power
60-822
16.5 VAC, 25 VA Class II Transformer
Provides primary power to the control
panel 16.5 VAC power supply
120 VAC @ 60 Hz power requirement
Beige
32 to 110 °F operating temperature
60-681
12 VDC, 4.0 Ah Lead Acid Battery
Provides backup power to the control panel
and hardwired devices when fully charged
and AC power is out
Backup battery provides up to 24 hours
backup power
1-year battery life
EXPRESS
Concord Family
4Interactive Technologies, Inc.
CPU Expansion Cards Description/Features Specifications Accessories
60-756
4-Zone Input/2 Form-C Relay Output
SnapCard
60-757
8-Zone Input SnapCard
Attaches to the CPU circuit board Snapcard
connection port
Includes one 12V two-wire smoke detector
loop (provides 100 mA of power to Style B
smoke detectors)
Provides three supervised UL Fire-rated
hardwire loops
Includes two "Form C" contact relays
controlled by a touchpad or a combination
of states and system events
End-of-line supervision with 2K ohm
resistor
60-757:
Includes two 12V two-wire smoke detector
loop (provides 100 mA of power to Style B
smoke detectors)
Provides six supervised UL Fire-rated
hardwire loops
Power source 12 VDC at 185 mA
maximum
40 to 120 °F operating temperature
70% maximum relative humidity,
non-condensing
5.25" wide x 2" high x 0.75" deep
60-757:
Power source 12 VDC at 120 mA
maximum
Hardwire Touchpads
60-820
SuperBus 2000 Fixed English LCD
Touchpad
27 defined English text status messages
1 line, 11 character LCD
Time displayed during idle periods
Keypad door with user-help label
Built-in speaker sounds alarm, status
sounds, and button-press beeps
Variable pitch sounder for the hearing
impaired.
3 panic buttons
Auto learning
Only compatible with Express
2 VDC nominal (8 - 15.4 VDC),
65 mA (maximum)
40 to 100 °F operating temperature
Maximum Humidity: 70% relative,
noncondensing
White
5.55” wide x 4.5” high x 1.1” deep
60-746
SuperBus 2000 2x16 LCD Touchpad
Provides complete on-site programming
and operational control of the system
2 line, 16 character back-lit LCD
Built-in speaker sounds alarm, status
sounds, and button-press beeps
Panic buttons for police, fire, and auxiliary
emergencies
Quick Guide slides out of touchpad to
provide basic system instructions
Auto Learning (Express Only)
12 VDC nominal (8 - 15.4 VDC),
90 mA (maximum)
40° to 100 °F operating temperature
Maximum Humidity: 70% relative,
noncondensing
White
Wall mounting
4.5" wide x 5.0" high x .92" deep
60-803-04
SuperBus 2000 2-line 2x20 LCD
Touchpad
60-804-04
SuperBus 2000 2-line 2x20 VFD
Touchpad
Provides complete on-site programming
and operational control of the system
2 line, 20 character LCD
Built-in speaker sounds alarm, status
sounds, and button-press beeps
Panic buttons for police, fire, and auxiliary
emergencies
60-804-04:
2 line, 20 character VFD
Backlit Display
12 VDC nominal (8 - 15.4 VDC),
115 mA (maximum)
40 to 100 °F operating temperature
Maximum Humidity: 70% relative,
noncondensing
Belgian Grey
8.44” wide x 5.0” high x 1.25” deep.
60-804-04:
12 VDC nominal (8 - 15.4 VDC),
120 mA (maximum)
EXPRESS
Concord Family
Interactive Technologies, Inc. 5
Wireless
Touchpads Description/Features Specifications Accessories
60-694-95R
5-Button SAW Keychain Touchpad
60-659-95R
4-Button SAW Keychain Touchpad
60-832-95
2-Button Encrypted Keychain
Touchpad
Recessed buttons help prevent false alarms
LED confirms RF transmissions
60-694-95R:
Single button panic control
Provides convenient operational control of
the system
Recessed buttons help prevent false alarms
Green LED confirms button presses
Light control capability (60-606-319.5
only)
60-832-95:
Each transmission to the panel is unique to
provide added resistance to code grabbers.
12 VDC, 33 mAh alkaline battery
included
5-8 year battery life
10 to 120 °F operating temperature
Black
Keychain mounting (keychain ring
included)
1.4" wide x 2.25" high x 0.38" deep
60-711 12V 33 mAh Alkaline Battery
60-606-319.5
4-Button Keychain Touchpad
60-607-319.5
2-Button Keychain Touchpad
Provides convenient operational control of
the system
Recessed buttons help prevent false alarms
Green LED confirms RF transmissions
Light control capability (60-606-319.5
only)
12 VDC, 33 mAh alkaline battery
included
5-8 year battery life
10 to 120 °F operating temperature
Black
Keychain mounting (keychain ring
included)
1.4" wide x 2.25" high x 0.38" deep
34-034 12V 33 mAh Alkaline Battery
466-1050 4-Button Keychain
Touchpad Specification Sheet 50/pk
466-1072 2-Button Keychain
Touchpad Specification Sheet 50/pk
60-597-95
HiTech Hand Held Wireless Touchpad
Provides portable operational control of the
system
Includes police, fire, and auxiliary panic
buttons
Light control capability
Bypass capability
Optional supervision reporting
Can be wall mounted
Quick arm
Red/Green key press indicator light
Convenient size and attractive styling
3 VDC LMN02 2/3 A button top battery
(included)
5-8 year battery life
Supervisory report every 64 minutes
10 to 120 °F operating temperature
Belgian gray
Portable or wall mounting (bracket
included)
2.1" wide x 6.1" high x .86" deep
60-733 3 VDC LMN02 2/3 A Button Top
Battery
444-1252 HiTech Hand Held Wireless
Touchpad Mounting Bracket
60-348-10-95
Hand Held Wireless Touchpad
Provides portable operational control of the
system
Includes police panic button
Light control capability
Bypass capability
Optional supervision reporting
Can be wall mounted
Quick arm
3.5 VDC ½ AA lithium battery (included)
5-8 year battery life
Supervisory report every 64 minutes
10 to 120 °F operating temperature
Belgian gray
Portable or wall mounting (bracket
included)
2.56" wide x 2" high x .94" deep
34-026 3.5 VDC 1/2 AA Lithium Battery
CONCORD
Concord Family
6Interactive Technologies, Inc.
Concord System Configuration
To configure a Concord Security System, start by selecting the control panel components listed on pages 4 through 9.
Control Panels Description/Features Specifications Accessories
60-734
Concord Hybrid Control Panel
60-792-95R-16Z
Concord RF16 Integrated Panel
60-792-95R-32Z
Concord RF32 Integrated Panel
Provides commercial and residential
security and home automation system
control
8 built-in hardwire zones (76 total zones
with optional expansion cards)
2 partitions
60 user access codes
Controls lights and appliances on a time
schedule, individually, or in groups (using
optional Line Carrier Card)
2-wire smoke detector compatibility
60-792-95R-16Z:
16 built-in wireless zones (76 total zones
with optional expansion cards)
60-792-95R-32Z:
32 built-in wireless zones (72 total zones
with optional expansion cards)
24 VAC, 30 or 50 VA, 60 Hz transformer
12 VDC, 4 Ah, or 7 Ah rechargeable,
sealed, lead-acid backup battery
Regulated, current limited, fused 12 VDC
output
15-minute battery test under load every
24 hours
Belgian gray, wall-mount, steel
enclosure
40 to 100 °F operating temperature
12.25" wide x 12.25" high x 3" deep
60-763 Lock and keys for Concord
enclosure
60-791 Installation Programming
Cable (connects LCD touchpad to panel
for on-site programming)
60-793 Concord Expansion Module
(holds up to six single-sized SuperBus
modules)
Power
60-761
24 VAC, 25 VA Class II Transformer
60-762
24 VAC, 25 VA Class II Line Carrier
Transformer - 1 Amp
60-778
24 VAC, 50 VA Class II Transformer
60-779
24 VAC, 50 VA Class II Line Carrier
Transformer - 2.5 Amp
Provides primary power to the control
panel
60-762, 60-778, 60-779:
60-762:
Required for X-10 devices and supervised
wireless siren (SWIS)
Must add 60-755 Power Line Carrier Card
60-762 and 779 required for X-10
24 VAC power supply
120 VAC @ 60 Hz power requirement
32 to 110 °F operating temperature
Black
2.25" wide x 3.5" high x 1.75" deep
60-755 Power Line Carrier Card
60-681
12 VDC, 4.0 Ah Lead Acid Battery
60-680
12 VDC, 7.0 Ah Lead Acid Battery
Provides backup power to the control panel
and hardwired devices when fully charged
and AC power is out
Backup battery provides up to 24 hours
backup power
1 year battery life None
CONCORD
Concord Family
Interactive Technologies, Inc. 7
SuperBus Radio
Receivers Description/Features Specifications Accessories
60-764-95R-16Z
16-zone SuperBus Radio Receiver
60-764-95R-32Z
32-zone SuperBus Radio Receiver
60-764-95R-MAX
76-zone SuperBus Radio Receiver
Mounts in Concord panel or can be located
up to 2,800 feet away
Receives signals from wireless sensors and
touchpads then to the panel through the
SuperBus digital data bus
Spacial diversity
Built-in tamper protection sounds an alarm
if tampered with
Compatible with all ITI 319.5 MHz (crystal
or SAW Learn Mode wireless sensors and
touchpads
Adds or extends Concord wireless
capabilities by up to 16 zones
60-764-95R-32Z:
Adds or extends Concord wireless
capabilities by up to 32 zones
60-764-95R-76Z:
Adds or extends Concord wireless
capabilities by up to 76 zones
8-15 VDC at 30 mA maximum power
required
32 to 120 °F operating temperature
Belgian gray
5.25" wide x 4.125" high x 1" deep,
excluding antennas
60-793 Concord Expansion Module
(holds up to six single-sized SuperBus
modules)
CPU Expansion Cards
60-755
Power Line Carrier (X-10) Card Allows use of Supervised Wireless Sirens
(SWIS)
Allows use of X-10 Modules for light
control and light activation during alarms
Attaches directly to the CPU circuit board
5 and 12 VDC input @ 110 mA nominal
current
10 to 120 °F operating temperature
2.95" wide x 1.95" high x 0.875" deep
See sensors for X-10 devices and SWIS.
60-756
4-Zone Input/2 Form-C Relay Output
SnapCard
60-757
8-Zone Input SnapCard
Attaches to the CPU circuit board Snapcard
connection port
Includes one 12V two-wire smoke detector
loop (provides 100 mA of power to Style B
smoke detectors)
Provides three supervised UL Fire-rated
hardwire loops
Includes two "Form C" contact relays
controlled by a touchpad or a combination
of states and system events
End-of-line supervision with 2K ohm
resistor
60-757:
Includes two 12V two-wire smoke detector
loop (provides 100 mA of power to Style B
smoke detectors)
Provides six supervised UL Fire-rated
hardwire loops
Power source 12 VDC @ 185 mA
maximum
40 to 120 °F operating temperature
70% maximum relative humidity,
noncondensing
5.25" wide x 2" high x 0.75" deep
60-757:
Power source 12 VDC at 120 mA
maximum
CONCORD
Concord Family
8Interactive Technologies, Inc.
SuperBus Expansion
Modules Description/Features Specifications Accessories
60-777
Phone Control and Voice Module
Attaches to the CPU circuit board using the
four-wire Superbus connection terminals
Adds on-site and remote system control
and from any touchtone phone
An on-board digital-voice chip delivers
system status messages over external
speakers
Voice chip includes more than 220-word
vocabulary
One module may be used to control a single
or multiple partition Concord system
In a multiple-partition system, each
partition may use its own module
connected to a separate phone line
User-adjustable status speaker volume
control
On/off hook status sensing
Ring detection
DTMF decoding
Local telephone power supply provides
phone power during line-seize mode of
operation
Mounts on wall or in panel enclosure
Power source 10-12 VDC at 600 mA
maximum
40 to 100 °F operating temperature
70% maximum relative humidity,
non-condensing
Belgian gray
8" wide x 5.5" high x 1.25" deep
Phone Line REN: 0.4 Ringer Equivalence
One module/panel communications LED
FCC Parts 15 and 68 Certified
UL985 for Household Fire warnings
(pending)
UL 1023 for Household Burglar Alarms
NFPA 72 for National Fire Alarm Code
60-584
SuperBus Hardwire Input Module
Provides up to eight additional hardwire
zones
Hardwire sensors can be configured N/O or
N/C
All zones supervised for open/short using
4.7K Ohm EOL resistor
Module cover tamper protection option
Built-in LED indicates proper
communication to control panel
Up to 8 modules per panel
12 VDC @ 18 mA max current draw
8 inputs configure N/O or N/C
EOL supervision on each zone with 4.7K
Ohm resistor
200 mA, 250 VAC fuse
32 to 120 °F operating temperature
Belgian gray
Tamper protection option
Wall mounting
4.125" wide x 5.25" high x 1.0" deep
33-017 200 mA, 250 VAC Fuse 5/pk
60-585
SuperBus Hardwire Output Module
Provides up to four additional hardwire
outputs for home automation and security
applications
"Form C" relays can be configured N/O or
N/C
Module cover tamper protection option
Built-in LED indicates proper
communication to control panel
Up to 8 modules per panel
12 VDC @ 11 mA typical (idle) or
91 mA max (all relays energized)
current draw
4 outputs configure N/O or N/C
32 to 120 °F operating temperature
Belgian gray
Tamper protection option
Wall mounting
4.125" wide x 5.25" high x 1.0" deep
33-017 200 mA, 250 VAC Fuse 5/pk
CONCORD
Concord Family
Interactive Technologies, Inc. 9
SuperBus Expansion
Modules—Continued Description/Features Specifications Accessories
60-620
SuperBus Energy Saver Module
Provides a money-saving and convenient
way to monitor and control the premises
heating and cooling temperature
Saves energy by overriding HVAC
thermostat when user is gone
User controls temperature limits for day
and nighttime HVAC thermostat control
Calibrates to premises thermostat
Built-in freeze sensor activates furnace and
alarm signal when the air temperature falls
to 45 °F or to the programmed temperature
Built-in LED indicates proper
communication to control panel
12 VDC @ 20 mA max current draw
Built-in freeze sensor activates at 45 °F
(±6 °F)
22-gauge stranded wire
42 to 95 °F operating temperature
Belgian gray
Wall mounting next to thermostat
2.60" wide x 2.60" high x .90” deep
60-677
Interrogator 200 Audio Verification
Module
Gives the central station operator the ability
to hear what is happening during an alarm
and speak directly to the people on the
premises
Auto Gain Control circuitry means
microphone requires no adjustments
Up to 2 modules per control panel
12 VDC @ 10 mA max current draw
18-gauge stranded wire between
speaker and control panel
22-gauge stranded wire for all other
wire runs
40 to 100 °F operating temperature
Belgian gray
Recessed or surface mounting
6.9" wide x 4.9" high x 2.5" deep
CONCORD
Concord Family
10 Interactive Technologies, Inc.
Hardwire Touchpads Description/Features Specifications Accessories
60-746-01
SuperBus 2000 2x16 LCD Touchpad
Provides complete on-site programming
and operational control of the system
2 line, 16 character LCD
Built-in speaker sounds alarm, status
sounds, and button-press beeps
Panic buttons for police, fire, and auxiliary
emergencies
Quick Guide slides out of touchpad to
provide basic system instructions
Auto learn
12 VDC nominal (8 - 15.4 VDC), 90 mA
(maximum)
40 to 100 °F operating temperature
Maximum Humidity: 70% relative,
noncondensing
White
Wall mounting
4.5" wide x 5.0" high x .92" deep
60-728
SuperBus LED Touchpad
Provides operational control of the system
15 LEDs for easy visual system status
8 individual zone LEDs
STAY, AWAY, and NO DELAY LEDS show
system status
Enter Code LED flashes to let user know
when to enter their access code
Quick Guide slides out of touchpad to
provide basic system instructions
12 VDC nominal (8 - 14 VDC), 65 mA
(maximum)
40 to 100 °F operating temperature
Maximum Humidity: 70% relative,
noncondensing
White
Wall mounting
4.5" wide x 5.0" high x .92" deep
60-803-04
SuperBus 2000 2-line 2x20 LCD
Touchpad
60-804-04
SuperBus 2000 2-line 2x20 VFD
Touchpad
Provides complete on-site programming
and operational control of the system
2 line, 20 character LCD
Built-in speaker sounds alarm, status
sounds, and button-press beeps
Panic buttons for police, fire, and auxiliary
emergencies
60-804-04:
2 line, 20 character VFD
12 VDC nominal (8 - 15.4 VDC),
115 mA (maximum)
40 to 100 °F operating temperature
Maximum Humidity: 70% relative,
noncondensing
Belgian Grey
8.44” wide x 5.0” high x 1.25” deep.
60-804-04:
12 VDC nominal (8 - 15.4 VDC),
120 mA (maximum)
CONCORD
Concord Family
Interactive Technologies, Inc. 11
Wireless
Touchpads Description/Features Specifications Accessories
60-694-95R
5-Button SAW Keychain Touchpad
60-659-95R
4-Button SAW Keychain Touchpad
Recessed buttons help prevent false alarms
LED confirms RF transmissions
60-694-95R:
Single button panic control
Provides convenient operational control of
the system
Recessed buttons help prevent false alarms
Green LED confirms button presses
Light control capability (60-606-319.5 only)
12 VDC, 33 mAh alkaline battery
included
5-8 year battery life
10 to 120 °F operating temperature
Black
Keychain mounting (keychain ring
included)
1.4" wide x 2.25" high x 0.38" deep
60-711 12V 33 mAh Alkaline Battery
60-606-319.5
4-Button Keychain Touchpad
60-607-319.5
2-Button Keychain Touchpad
Provides convenient operational control of
the system
Recessed buttons help prevent false alarms
Green LED confirms RF transmissions
Light control capability (60-606-319.5 only)
12 VDC, 33 mAh alkaline battery
included
5-8 year battery life
10 to 120 °F operating temperature
Black
Keychain mounting (keychain ring
included)
1.4" wide x 2.25" high x 0.38" deep
34-034 12V 33 mAh Alkaline Battery
466-1050 4-Button Keychain
Touchpad Specification Sheet 50/pk
466-1072 2-Button Keychain
Touchpad Specification Sheet 50/pk
60-597-95
HiTech Hand Held Wireless Touchpad
Provides portable operational control of the
system
Includes police, fire, and auxiliary panic
buttons
Light control capability
Bypass capability
Optional supervision reporting
Can be wall mounted
Quick arm
Red/Green key press indicator light
Convenient size and attractive styling
3 VDC LMN02 2/3 A button top battery
(included)
5-8 year battery life
Supervisory report every 64 minutes
10 to 120 °F operating temperature
Belgian gray
Portable or wall mounting (bracket
included)
2.1" wide x 6.1" high x .86" deep
60-733 3 VDC LMN02 2/3 A Button Top
Battery
444-1252 HiTech Hand Held Wireless
Touchpad Mounting Bracket
60-348-10-95
Hand Held Wireless Touchpad
Provides portable operational control of the
system
Includes police panic button
Light control capability
Bypass capability
Optional supervision reporting
Can be wall mounted
Quick arm
3.5 VDC ½ AA lithium battery (included)
5-8 year battery life
Supervisory report every 64 minutes
10 to 120 °F operating temperature
Belgian gray
Portable or wall mounting (bracket
included)
2.56" wide x 2" high x .94" deep
34-026 3.5 VDC 1/2 AA Lithium Battery
COMMERCIAL
Concord Family
12 Interactive Technologies, Inc.
Concord Commercial System Configuration
To configure a Concord Commercial Security System, start by selecting the control panel components listed on
pages 10 through 14.
Control Panel Description/Features Specifications Accessories
60-801
Concord Commercial Hybrid
Control Panel
Provides commercial security and business
automation system control
8 built-in hardwire zones (76 total zones
with optional expansion cards)
2 partitions
60 user access codes
Controls lights and appliances on a time
schedule, individually, or in groups (using
optional Line Carrier Card)
2-wire smoke detector compatibility
U.L. commercial listing UL 1610
Lock set included
Tamper resistant enclosure
24 VAC, 30 or 50 VA, 60 Hz transformer
12 VDC, 4 Ah, or 7 Ah rechargeable,
sealed, lead-acid backup battery
Regulated, current limited, fused 12 VDC
output
15-minute battery test under load every
24 hours
Belgian gray, wall-mount, steel
enclosure
40 to 100 °F operating temperature
12.25" wide x 12.25" high x 3" deep
60-791 Installation Programming
Cable (connects LCD touchpad to panel
for on-site programming)
60-793 Concord Expansion Module
(holds up to six single-sized SuperBus
modules)
60-817 Concord Commercial Bus
Module Mounting Kit
Power
60-761
24 VAC, 25 VA Class II Transformer
60-762
24 VAC, 25 VA Class II Line Carrier
Transformer - 1 Amp
60-778
24 VAC, 50 VA Class II Transformer
60-779
24 VAC, 50 VA Class II Line Carrier
Transformer - 2.0 Amp
Provides primary power to the control
panel
60-762, 60-778, 60-779:
60-762:
Required for X-10 devices and supervised
wireless siren (SWIS)
Must add 60-755 Power Line Carrier Card
60-762 and 779 for X-10
24 VAC power supply
120 VAC @ 60 Hz power requirement
32 to 110 °F operating temperature
Black
2.25" wide x 3.5" high x 1.75" deep
60-755 Power Line Carrier Card
COMMERCIAL
Concord Family
Interactive Technologies, Inc. 13
SuperBus Radio
Receivers Description/Features Specifications Accessories
60-764-95R-16Z
16-zone SuperBus Radio Receiver
60-764-95R-32Z
32-zone SuperBus Radio Receiver
60-764-95R-MAX
76-zone SuperBus Radio Receiver
Mounts in Concord panel or can be located
up to 2,800 feet away
Receives signals from wireless sensors and
touchpads then to the panel through the
SuperBus digital data bus
Spacial diversity
Built-in tamper protection sounds an alarm
if tampered with
Compatible with all ITI 319.5 MHz (crystal
or SAW Learn Mode wireless sensors and
touchpads
Adds or extends Concord wireless
capabilities by up to 16 zones
60-764-95R-32Z:
Adds or extends Concord wireless
capabilities by up to 32 zones
60-764-95R-76Z:
Adds or extends Concord wireless
capabilities by up to 76 zones
8-15 VDC at 30 ma maximum power
required
32° to 120 °F operating temperature
Belgian gray
5.25" wide x 4.125" high x 1" deep,
excluding antennas
60-793 Concord Expansion Module
(holds up to six single-sized SuperBus
modules)
CPU Expansion Cards
60-755
Power Line Carrier (X-10) Card Allows use of Supervised Wireless Sirens
(SWIS)
Allows use of X-10 Modules for light
control and light activation during alarms
Attaches directly to the CPU circuit board
5 and 12 VDC input @ 110 mA nominal
current
10 to 120 °F operating temperature
2.95" wide x 1.95" high x 0.875" deep
See sensors for X-10 devices and SWIS.
60-756
4-Zone Input/2 Form-C Relay Output
SnapCard
60-757
8-Zone Input SnapCard
Attaches to the CPU circuit board Snapcard
connection port
Includes one 12V two-wire smoke detector
loop (provides 100 mA of power to Style B
smoke detectors)
Provides three supervised UL Fire-rated
hardwire loops
Provides false alarm prevention
Includes two "Form C" contact relays
controlled by a touchpad or a combination
of states and system events
End-of-line supervision with 2K ohm
resistor
60-757:
Includes two 12V two-wire smoke detector
loop (provides 100 mA of power to Style B
smoke detectors)
Provides six supervised UL Fire-rated
hardwire loops
Power source 12 VDC at 185 mA
maximum
40 to 120 °F operating temperature
70% maximum relative humidity,
non-condensing
5.25" wide x 2" high x 0.75" deep
60-757:
Power source 12 VDC at 120 mA
maximum
COMMERCIAL
Concord Family
14 Interactive Technologies, Inc.
SuperBus Expansion
Cards Description/Features Specifications Accessories
60-777
Phone Control and Voice Module
Attaches to the CPU circuit board using the
four-wire Superbus connection terminals
Adds on-site and remote system control
and from any touchtone phone
An on-board digital-voice ship delivers
system status messages over external
speakers
Voice chip includes more than 220
vocabulary
One module may be used to control a single
or multiple partition Concord system
In a multiple-partition system, each
partition may use its own module
connected to a separate phone line
User-adjustable status speaker volume
control
On/off hook status sensing
Ring detection
DTMF decoding
Local telephone power supply provides
phone power during line-seize mode of
operation
Mounts on wall or in panel enclosure
Power source 10-12 VDC at 600 mA
maximum
40 to 100 °F operating temperature
70% maximum relative humidity,
non-condensing
Belgian gray
8" wide x 5.5" high x 1.25" deep
Phone Line REN: 0.4 Ringer Equivalence
One module/panel communications LED
FCC Parts 15 and 68 Certified
UL985 for Household Fir warnings
(pending)
UL 1023 for Household Burglar Alarms
(pending)
NFPA 72 for National Fire Alarm Code
(pending)
60-584
SuperBus Hardwire Input Module
Provides up to eight additional hardwire
zones
Hardwire sensors can be configured N/O or
N/C
All zones supervised for open/short using
4.7K Ohm EOL resistor
Module cover tamper protection option
Built-in LED indicates proper
communication to control panel
Up to 8 modules per panel
12 VDC @ 18 mA max current draw
8 inputs configure N/O or N/C
EOL supervision on each zone with 4.7K
Ohm resistor
200 mA, 250 VAC fuse
32 to 120 °F operating temperature
Belgian gray
Tamper protection option
Wall mounting
4.125" wide x 5.25" high x 1.0" deep
33-017 200 mA, 250 VAC Fuse 5/pk
60-585
SuperBus Hardwire Output Module
Provides up to four additional hardwire
outputs for home automation and security
applications
"Form C" relays can be configured N/O or
N/C
Module cover tamper protection option
Built-in LED indicates proper
communication to control panel
Up to 8 modules per panel
12 VDC @ 11 mA typical (idle) or 91 mA
max (all relays energized) current draw
4 outputs configure N/O or N/C
32 to 120 °F operating temperature
Belgian gray
Tamper protection option
Wall mounting
4.125" wide x 5.25" high x 1.0" deep
33-017 200 mA, 250 VAC Fuse 5/pk
COMMERCIAL
Concord Family
Interactive Technologies, Inc. 15
SuperBus Expansion
Cards–Continued Description/Features Specifications Accessories
60-677
Interrogator 200 Audio Verification
Module
Gives the central station operator the ability
to hear what is happening during an alarm
and speak directly to the people on the
premises
Auto Gain Control circuitry means
microphone requires no adjustments
Up to 2 modules per control panel
12 VDC @ 10 mA max current draw
18-gauge stranded wire between
speaker and control panel
22-gauge stranded wire for all other
wire runs
40 to 100 °F operating temperature
Belgian gray
Recessed or surface mounting
6.9" wide x 4.9" high x 2.5" deep
Hardwire Touchpads Description/Features Specifications Accessories
60-746
SuperBus 2x16 LCD Touchpad
Provides complete on-site programming
and operational control of the system
2 line, 16 character LCD
Built-in speaker sounds alarm, status
sounds, and button-press beeps
Panic buttons for police, fire, and auxiliary
emergencies
Quick Guide slides out of touchpad to
provide basic system instructions
12 VDC nominal (8 - 15.4 VDC), 90 mA
(maximum)
40 to 100 °F operating temperature
Maximum Humidity: 70% relative,
noncondensing
Belgian gray
Wall mounting
4.5" wide x 5.0" high x .92" deep
60-728
SuperBus LED Touchpad
Provides operational control of the system
15 LEDs for easy visual system status
8 individual zone LEDs
STAY, AWAY, and NO DELAY LEDS show
system status
Enter Code LED flashes to let user know
when to enter their access code
Quick Guide slides out of touchpad to
provide basic system instructions
12 VDC nominal (8 - 14 VDC), 65 mA
(maximum)
40 to 100 °F operating temperature
Maximum Humidity: 70% relative,
noncondensing
Belgian gray
Wall mounting
4.5" wide x 5.0" high x .92" deep
60-803-04
SuperBus 2000 2-line 2x20 LCD
Touchpad
60-804-04
SuperBus 2000 2-line 2x20 VFD
Touchpad
Provides complete on-site programming
and operational control of the system
2 line, 20 character LCD
Built-in speaker sounds alarm, status
sounds, and button-press beeps
Panic buttons for police, fire, and auxiliary
emergencies
Quick Guide slides out of touchpad to
provide basic system instructions
60-804-04:
2 line, 20 character VFD
12 VDC nominal (8 - 15.4 VDC),
115 mA (maximum)
40 to 100 °F operating temperature
Maximum Humidity: 70% relative,
noncondensing
Belgian Grey
8.44” wide x 5.0” high x 1.25” deep.
60-804-04:
12 VDC nominal (8 - 15.4 VDC),
90 mA (maximum)
COMMERCIAL
Concord Family
16 Interactive Technologies, Inc.
Wireless
Touchpads Description/Features Specifications Accessories
60-694-95R
5-Button SAW Keychain Touchpad
60-659-95R
4-Button SAW Keychain Touchpad
Recessed buttons help prevent false alarms
LED confirms RF transmissions
60-694-95R:
Single button panic control
Provides convenient operational control of
the system
Recessed buttons help prevent false alarms
Green LED confirms button presses
Light control capability (60-606-319.5
only)1
12 VDC, 33 mAh alkaline battery
included
5-8 year battery life
10 to 120 °F operating temperature
Black
Keychain mounting (keychain ring
included)
1.4" wide x 2.25" high x 0.38" deep
60-711 12V 33 mAh Alkaline Battery
60-606-319.5
4-Button Keychain Touchpad
60-607-319.5
2-Button Keychain Touchpad
Provides convenient operational control of
the system
Recessed buttons help prevent false alarms
Green LED confirms button presses
Light control capability (60-606-319.5 only)
12 VDC, 33 mAh alkaline battery
included
5-8 year battery life
10 to 120 °F operating temperature
Black
Keychain mounting (keychain ring
included)
1.4" wide x 2.25" high x 0.38" deep
34-034 12V 33 mAh Alkaline Battery
466-1050 4-Button Keychain
Touchpad Specification Sheet 50/pk
466-1072 2-Button Keychain
Touchpad Specification Sheet 50/pk
60-597-95
HiTech Hand Held Wireless Touchpad
Provides portable operational control of the
system
Includes police, fire, and auxiliary panic
buttons
Light control capability
Status report control
Bypass capability
Optional supervision reporting
Can be wall mounted
Quick arm
Red/Green key press indicator light
Convenient size and attractive styling
3 VDC LMN02 2/3 A button top battery
(included)
5-8 year battery life
Supervisory report every 64 minutes
10 to 120 °F operating temperature
Belgian gray
Portable or wall mounting (bracket
included)
2.1" wide x 6.1" high x .86" deep
60-733 3 VDC LMN02 2/3 A Button Top
Battery
444-1252 HiTech Hand Held Wireless
Touchpad Mounting Bracket
60-348-10-95
Hand Held Wireless Touchpad
Provides portable operational control of the
system
Includes police panic button
Light control capability
Status report control
Bypass capability
Optional supervision reporting
Can be wall mounted
Quick arm
3.5 VDC ½ AA lithium battery (included)
5-8 year battery life
Supervisory report every 64 minutes
10 to 120 °F operating temperature
Belgian gray
Portable or wall mounting (bracket
included)
2.56" wide x 2" high x .94" deep
34-026 3.5 VDC 1/2 AA Lithium Battery
SIRENS AND SPEAKERS
Concord Family
Interactive Technologies, Inc. 17
Wireless Interior Sirens Description/Features Specifications Accessories
60-736-95
Supervised Wireless Interior Siren
(SWIS)
Produces low volume status beeps and full
volume alarm sounds without any wiring
Plugs into any 120 VAC wall outlet
Receives signals from the control panel over
AC power lines
3 status sound settings
Low-battery warning
Status sounds can be turned off
U.L. approved
Rechargeable backup battery included
85 dB siren output at 10 feet
120V AC powered
3.6 VDC NiCd battery pack included
Belgian Grey
4.3" wide x 3.4" high x 1.5" deep
Hardwire Sirens
60-278
Hardwire Interior Siren and Piezo
Produces both low volume status sounds
and high volume siren sounds with voice
alarm messages, using PIU
Includes a speaker and piezo
Interior voice speaker annunciates all voice
messages and alarms
Piezo activates for status and alarm sounds
Good for areas where system status and
siren sounds need to be heard
20W speaker output
12 VDC @ 5 mA max current draw
6-12 VDC @ 120 mA operating voltage
10 to 120 °F operating temperature
Belgian gray
Recessed or surface mounting
6 11/16" wide x 4 3/4" high x 2 3/8" deep
13-374
LD 105 Hardwire Interior Piezo Siren
Produces low volume status beeps and full
volume alarm sounds
Small size with maximum output of 85 dB
85 dB max siren output
12 VDC @ 150 mA max current draw
4.5-15 VDC @ 75 mA operating voltage
42 to 95 °F operating temperature
Belgian gray
Wall mounting
2.8" wide x 4.8" high x 1.25" deep
60-483-01
Interior Slim Line Piezo Siren
Produces low volume status beeps and full
volume alarm sounds
Small size provides clean installations
85 dB alarm siren output
Separate piezo annunciator for low volume
status beeps and alarm sounds
85 dB max siren output
12 VDC @ 30 mA max current draw
6-12 VDC @ 60 mA operating voltage
10 to 120 °F operating temperature
Belgian gray
Recessed mounting
2.5" wide x 6" high x 1.25" deep
60-683
Phone Jack Siren
Produces low volume status beeps and full
volume alarm sounds without running any
wires
Uses existing phone line wiring
Replaces an existing phone jack and
provides a jack for a phone
Can be used with any wireless or hardwire
system supplying 6-12 VDC
Status sounds can be turned off
85 dB max siren output
30 mA max current draw
6-12 VDC @ 60 mA operating voltage
10 to 120 °F operating temperature
Belgian gray
Wall mounting with back box or flush
mounting with a single gang box
2.88" wide x 6" high x 1.83" deep
SIRENS AND SPEAKERS
Concord Family
18 Interactive Technologies, Inc.
Hardwire Sirens–
Continued Description/Features Specifications Accessories
13-046
Hardwire Exterior Piezo Siren
Produces full volume alarm sounds for large
indoor and outdoor areas
Weatherproof housing
115 dB alarm siren output
Only 145 mA max current draw
115 dB max siren output
12 VDC @ 145 mA max current draw
6-12 VDC @ 98 mA operating voltage
22-gauge stranded wire
10 to 120 °F operating temperature
White
Wall mounting
3.56" diameter x 3.25" deep
Hardwire Speakers
13-453
Surface Mount Interior Speaker
Produces both low volume status sounds
and high volume siren sounds with voice
alarm messages, using phone interface and
voice module
Interior voice speaker annunciates all voice
messages and alarms
Good for areas where system status and
siren sounds need to be heard
15 W RMS
20 W peak
8 ohm
Not investigated by UL
Surface mounting
13-454
Recessed Mount Interior Speaker
Produces both low volume status sounds
and high volume siren sounds with voice
alarm messages, using phone interface and
voice module
Interior voice speaker annunciates all voice
messages and alarms
Good for areas where system status and
siren sounds need to be heard.
15 W RMS
20 W peak
8 ohm
Not investigated by UL
Recessed mounting
60-252
Interior Speaker and Piezo
Produces both low volume status sounds
and high volume siren sounds with voice
alarm messages, using phone interface and
voice module
Includes a speaker and piezo
Interior voice speaker annunciates all voice
messages and alarms
Good for areas where system status and
siren sounds need to be heard
20 W speaker output
12 VDC @ 5 mA max current draw
6-12 VDC @ 120 mA operating voltage
10 to 120 °F operating temperature
Belgian gray
Recessed or surface mounting
6 11/16" wide x 4 3/4" high x 2 3/8" deep
13-060
RMS Exterior Horn, 15 Watt Speaker
Produces alarm and status voice messages
or alarm messages only
Good for large indoor and outdoor areas
where voice feedback is needed
Status and alarm messages
UL approved, 85 dBA
22-gauge stranded wire
10 to 120 °F operating temperature
White
Wall mounting
13-060:
15 W, 8 Ohm speaker output
5 1/8” diameter x 5 7/8” deep
13-061:
30 W, 8 Ohm speaker output
8” diameter x 9 1/8” deep
SAW SENSORS
Concord Family
Interactive Technologies, Inc. 19
SAW Sensors Description/Features Specifications Accessories
60-670-95R
Belgian Gray Door/Window Sensor
60-670-11-95R
Brown Door/Window Sensor
Protects anything that opens and closes,
such as doors, windows, jewelry cases, and
gun cabinets
For low and average traffic areas
Terminal block for hardwire contacts can be
added to the built-in terminal post
Two 1.5 VDC AAA alkaline batteries
4-6 year battery life
1 internal reed switch
1 built-in terminal post
10 to 120 °F operating temperature
Supervisory report every 64 minutes
Belgian gray
Flat surface mounting
1.13" wide x 4.25" high x .88" deep
60-710 1.5 VDC AAA Alkaline Battery
6/pk
60-714 SAW Door/Window Sensor
Terminal Block 10/pk
60-715 Belgian Gray Door/Window
Sensor Spacer 25/pk
60-715-11 Brown Door/Window
Sensor Spacer 25/pk
60-716 Belgian Gray Door/Window
Sensor
60-716-11 Brown Door/Window
Sensor Magnet Spacer 20/pk
60-639-95R
Indoor PIR Motion Sensor
60-807-95R
Indoor PIR Pet Immune Motion
Sensor
Passive infrared detection
Detects movement inside an enclosed
structure
Use in large rooms, narrow corridors, and
stairwells
3-minute motion lockout to conserve
battery life
Two sensitivity settings
Small and unobtrusive
60-639-95R:
Provides the best overall human detection
Optional Animal Alley Lens
Mounting kit included to adjust coverage
pattern
60-807-95R:
Pet Immunity up to 40 pounds
Excellent vertical vs. horizontal pattern
recognition
Two 1.5 VDC AA alkaline batteries
3-4 year battery life
32 to 120 °F operating temperature
Tamper switch
Supervisory report every 64 minutes
Belgian gray
Wall mounting
2.5" wide x 3" high x 2" deep
60-807-95R:
Use with pets up to 40 pounds
60-600 1.5 VDC AA alkaline battery
60-639-95R:
13-381 Fresnel Animal Alley Lens
60-737 Swivel mount
60-639-95R-OD
Outdoor PIR Motion Sensor
Use for chime notification of movement
outside the premises or to turn on an
exterior light upon approach*
Use in driveways, walkways, etc.
Passive infrared detection
3-minute motion lockout to conserve
battery life
* This sensor is not intended for intrusion
detection. Do not use this sensor in a police,
panic, or fire sensor group.
Two 1.5 VDC AA alkaline batteries
3-4 year battery life
10 to 120 °F operating temperature
Tamper switch
Supervisory report every 64 minutes
Belgian gray
Wall mounting
3" wide x 3" high x 3" deep (+1.25" with
mounting bracket)
60-600 1.5 VDC AA Alkaline Battery
60-744-95R
Water Sensor
Detects water leaks in home or business
Uses two parts: a detector wired to the
transmitter
Two 1.5 VDC AAA alkaline batteries
3-5 year battery life
10 to 120 °F operating temperature
Belgian gray
Flat surface mounting
Detector: 0.94" wide x 1.80" high x 0.50"
deep
1.13" wide x 4.25" high x 0.94" deep
60-710 1.5 VDC AAA Alkaline Battery
CRYSTAL INTRUSION SENSORS
Concord Family
20 Interactive Technologies, Inc.
Crystal Intrusion Sensors Description/Features Specifications Accessories
60-362-10-319.5
Belgian Gray Door/Window Sensor
60-362-11-319.5
Brown Door/Window Sensor
Protects anything that opens and closes,
such as doors, windows, jewelry cases, and
gun cabinets
Installs on anything that opens or closes
For low and average traffic areas
Built-in terminal strip for connecting
hardwire contacts
2 internal reed switches allow for vertical
or horizontal mounting
3.5 VDC ½ AA lithium battery
5-8 year battery life
2 internal reed switches
1.56" wide x 3.25" high x .88" deep
10 to 120 °F operating temperature
Tamper switch
Supervisory report every 64 minutes
Belgian gray or brown
Flat surface mounting
34-026 3.5 VDC ½ AA Lithium Battery
60-189 Belgian Gray Sensor Spacers
20/pk
60-191 Brown Sensor Spacers 20/pk
60-188 Belgian Gray Magnet Spacers
25/pk
60-190 Brown Magnet Spacers 25/pk
60-260, 261 Sensor Cases 5/pk
60-555-10, 11 Magnets (includes
plastic) 10/pk
466-1045 Door/Window Sensor
Specification Sheet 50/pk
60-741-95
Micro Recessed Belgian Gray
Door/Window Sensor
60-741-11-95
Micro Recessed Brown D/W Sensor
Protects doors and windows where the
sensor should be concealed
Sensors are completely concealed when
installed
Lithium battery
3.5 VDC ½ AA lithium battery
12-16 year battery life
Recessed mount in 5/8” hole
Magnet can be mounted using 5/8”
sleeve, or 1/2” hole
Supervisory report every 64 minutes
10 to 120 °F operating temperature
60-499-10-319.5
Slim Line Belgian Gray
Door/Window Sensor
60-499-11-319.5
Slim Line Brown D/W Sensor
Protects anything that opens
and closes where the sensor mounting area
is limited, such as narrow casements and
window frames
Slim design fits on most windows.
3.5 VDC ½ AA lithium battery (send to
ITI to replace)
5-8 year battery life
10 to 120 °F operating temperature
Tamper switch
Supervisory report every 64 minutes
Belgian gray or brown
Flat surface mounting
.31" wide x 4.94" high x
.88" deep
80-089-10 Belgian Gray Sensor
Case 5/pk
80-089-11 Brown Sensor Case
5/pk
60-511-01-95
DS924i PIR Motion Sensor
60-511-02-95
DS924i Pet Immune PIR Motion
Sensor
Detects movement inside an enclosed
structure
Use in large rooms, narrow corridors, and
stairwells
Passive infrared detection
3 sensitivity settings
Includes masking kit to adjust coverage
pattern
3-minute motion lockout to conserve
battery life
Optional lenses to suit various installation
needs
60-511-02-95:
Adds pet immunity up to 40 pounds
3.5 VDC ½ AA lithium battery
3-5 year battery life
Standard 70° lens coverage is 35' x 40'
10 to 120 °F operating temperature
Tamper switch
Supervisory report every 64 minutes
Belgian gray
Wall mounting
2.75" wide x 4.38" high x 1.75" deep
34-026 3.5 VDC ½ AA Lithium Battery
13-286 DS924 70' Long Range Lens
3/pk
13-287 DS924 78° x 35' Pet Lens 3/pk
13-288 DS924 110° x 35' Wide Angle
Lens 3/pk
13-318 DS924 35' Barrier Lens 3/pk
13-319 DS924 85° x 70' Dual Corridor
Lens 3/pk
13-320 DS924 10° x 70' Long Range
Pet Lens 3/pk
13-359 DS924 Mounting Bracket
466-1145 DS924i PIR Specification
Sheet 50/pk
CRYSTAL INTRUSION SENSORS
Concord Family
Interactive Technologies, Inc. 21
Crystal Intrusion
Sensors–Continued Description/Features Specifications Accessories
60-703-95
ITI Crystal PIR Motion Sensor
Detects movement inside an enclosed
structure
Use in large rooms, narrow corridors, and
stairwells
Passive infrared detection
3-minute motion lockout to conserve
battery life
Optional pet lens
Two sensitivity settings
Mounting kit included to adjust coverage
pattern
Small and unobtrusive
Two 1.5 VDC AA alkaline batteries
3-4 year battery life
10 to 120 °F operating temperature
Tamper switch
Supervisory report every 64 minutes
Belgian gray
Wall mounting
2.5" wide x 3" high x 2" deep
60-600 1.5 VDC AA Alkaline Battery
13-381 Fresnel Animal Alley Lens
60-459-319.5
Sound Sensor
Responds to frequencies generated by
breaking glass
Installs in rooms with many windows or a
large picture window
Detection coverage of 360° up to 15' away
Detects sound of breaking glass (including
tempered glass) .06" - .25" thick
Sensitivity preset by manufacturer
3.5 VDC ½ AA lithium battery
5-8 year battery life
Audio microphone
10 to 120 °F operating temperature
Supervisory report every 64 minutes
Belgian gray
Wall or ceiling mounting
4.38" diameter x 2" deep
34-026 3.5 VDC ½ AA Lithium Battery
13-332 IntelliSense Sound Sensor
Tester
60-834
FlexGuard® Dual Disturbance Sound
Sensor
Responds to frequencies generated by
breaking glass
Installs in rooms with many windows or a
large picture window
Detection coverage up to 25' away in any
direction
Includes a flex and audio microphone
Adjustable flex sensitivity
Test LEDs for flex sensitivity and audio
range settings
Uses two 3.5 VDC AA batteries or one
9 VDC battery
Replaces the Intellisense Sound Sensor
(part number 60-582-10-319.5)
Two 3.5 VDC AA lithium batteries
(included) or one 9 VDC alkaline or
lithium battery
5-8 year battery life
10 to 120 °F operating temperature
Tamper switch
Supervisory report every 64 minutes
Belgian gray
Wall or ceiling mounting
4.13" wide x 4.75" high x 1.25" deep
34-002 9 VDC Eveready® Energizer®
Alkaline Battery - UL listed
34-011 9 VDC, 550 mAh, Duracell®
Alkaline Battery - UL listed
34-037 9 VDC, 1.2 Ah, UltraLife®
Lithium Battery - UL listed
60-619 3.5 VDC AA Lithium Battery
6/pk
13-332 IntelliSense Sound Sensor
Tester
60-461-10-319.5
Belgian Gray Shock Sensor
60-461-10-319.5
Brown Shock Sensor
Installs on windows to detect
openings/closings and breaking glass or
splintering wood
Detects breaking glass or splintering wood
up to 5' away
Shock detector can be mounted inside or
outside sensor case
2 built-in reed switches allow for vertical
or horizontal mounting to detect window
openings/closings
Adjustable sensitivity
3.5 VDC ½ AA lithium battery
5-8 year battery life
10 to 120 °F operating temperature
Tamper switch
Supervisory report every 64 minutes
Belgian gray or brown
Window frame mounting
1.56" wide x 4.88" high x .94" deep
34-026 3.5 VDC ½ AA Lithium Battery
60-267 Belgian Gray Sensor Case 5/pk
80-006-10, 11 Belgian Gray, Brown
Sensor Spacer 20/pk
13-005, 011 Belgian Gray, Brown
Surface Mount Litton® Shock Detector
SP3237
60-268 Brown Sensor Case 5/pk
13-214 Litton Shock Detector (fits
inside case)
13-215 Belgian Gray Litton Recessed
Mount Shock Detector
CRYSTAL INTRUSION SENSORS
Concord Family
22 Interactive Technologies, Inc.
Crystal Intrusion
Sensors–Continued Description/Features Specifications Accessories
60-462-10-319.5
Belgian Gray Glass Break Sensor
60-462-11-319.5
Brown Glass Break Sensor
Mounts directly onto glass in doors and
windows, gun cabinets, etc., to detect
breaking glass
5' sensitivity radius
Adheres to glass being protected
Can be mounted anywhere on glass, at
least 1" from glass frame
Built-in terminal strip for connecting
hardwire contacts
3.5 VDC 1/2 AA lithium battery
5-8 year battery life
10 to 120 °F operating temperature
Tamper switch
Supervisory report every 64 minutes
Belgian gray or brown
Glass mounting with adhesive pads
(included)
1.5" wide x 3.25" high x .88" deep
34-026 3.5 VDC ½ AA Lithium Battery
13-067 Glass Guard Adhesive Pad
50/pk
60-615-10-319.5
Quik Bridge™ Learn Mode Repeater
Receives and retransmits signals from
Learn Mode sensors, touchpads, and other
Repeaters to increase the distance a sensor
can be mounted from the control panel
Ideal for large installations where:
- distant sensors perform poorly on the
sensor test;
- distant sensors cause supervisory
problems; or
- control panel antennas are shielded by
metal
Dual-antenna receiver for improved sensor
data reception
24-hour backup battery option
On board backup battery charging circuit
Low backup battery report option
AC power failure option
Supervisory reports every 64 minutes
Tamper switch
600’ typical open-air range
Main power supplied by:
15-16.5 VAC, 2 VA transformer (required
if backup battery is used), or
9-16.5 VAC, 2 VA transformer, or
12 VDC power supply
50 mA max current draw
24-hour backup with 12 VDC, 1.3 Ah
lead-acid battery
319.5 MHz radio receiver and sensor
Crystal-controlled superheterodyne
radio receiver
40 to 120 °F operating temperature
Tamper switch
AC power failure report
Supervisory report every 64 minutes
Belgian gray
ABS Plastic
Flat surface mounting
4.125" wide x 5.25" high (+8.75" with
antennas) x 1" deep
5.1 oz.
Note:
A weatherproof case is available from
Rose Enclosures (301-696-9800).
Order part number 09122008-00.
CRYSTAL FIRE AND SMOKE
Concord Family
Interactive Technologies, Inc. 23
Crystal Fire and Smoke
Sensors Description/Features Specifications Accessories
60-506-319.5
System Sensor™ Smoke
Sensor 2100 RF
60-645-95
System Sensor™ Smoke
Sensor 2300 RF
Produces an alarm and sends an alarm
signal to the control panel when smoke is
detected
Use in bedrooms, hallways, stairwells, etc.
Most suitable for detecting slow
smoldering fires
Photoelectric smoke detector
Built-in siren
Built-in low battery annunciator
60-645:
Low battery signal sent to control panel 7
days prior to low battery chirp
Notifies user when sensor needs to be
cleaned
Installer-serviceable chamber cleaning
32 to 100 °F operating temperature
Tamper switch
Supervisory report every 64 minutes
White
Wall or ceiling mounting
5.5" diameter x 2.5" deep
60-506:
Two 9 VDC alkaline or lithium batteries
1 year alkaline battery life
2 year lithium battery life
60-645:
Two 3V 2/3 A lithium batteries
5 year battery life
34-002 9 VDC Eveready Energizer
Alkaline Battery - UL listed
34-011 9 VDC, 550 mAh, Duracell
Alkaline Battery - UL listed
34-037 9 VDC, 1.2 Ah, UltraLife
Lithium Battery - UL listed
34-030 3 VDC 2/3 A Lithium Battery
60-460-319.5
Rate-of-Rise Heat Sensor
60-460-319.5-LB
Rate-of-Rise Heat Sensor w/Lithium
Battery
Responds to high temperatures or rapid
temperature changes
Use in kitchens, bathrooms, garages, etc.
Provides detection in spaces up to
2,500 sq. ft.
Activates when temperature increases
15 °F/minute or greater
Fixed temperature sensor activates at
135 °F
One 9 VDC alkaline or lithium battery
1 year alkaline battery life
2 year lithium battery life
40 to 100 °F operating temperature
Tamper switch
Supervisory report every 64 minutes
Belgian gray
Wall or ceiling mounting
4.5" diameter x 2.25" deep
34-002 9 VDC Eveready Energizer
Alkaline Battery - UL listed
34-011 9 VDC, 550 mAh, Duracell
Alkaline Battery - UL listed
34-037 9 VDC, 1.2 Ah, UltraLife
Lithium Battery - UL listed
60-589-319.5
Fire Pull Station Sensor
Allows a person to activate a fire alarm in
the event of a fire
Use in residential or commercial sites
Manually activated
Built-in transmitter
Clear shield protects activation switch
Easily resets with key
3.5 VDC ½ AA lithium battery
5-8 year battery life
Manually activated
Reset with key (included)
40 to 100 °F operating temperature
Supervisory report every 64 minutes
Red case
Wall mounting
3.38" wide x 3.38" high x 1.88" deep
34-026 3.5 VDC ½ AA Lithium Battery
CRYSTAL ENVIRONMENTAL SENSORS
Concord Family
24 Interactive Technologies, Inc.
Crystal Environmental
Sensors Description/Features Specifications Accessories
60-504-10-319.5
Freeze Sensor
Detects furnace failure in residential or
commercial sites by detecting when the air
temperature falls below 45 °F
Use in climates where temperatures can
drop below 32 °F
Monitors the temperature in an open area
up to 900 sq. ft.
Sends alarm signal to control panel when
air temperature falls below 45 °F
Sends restore signal to control panel when
temperature increases to 55 to 60 °F
3.5 VDC ½ AA lithium battery
5-8 year battery life
10 to 120 °F operating temperature
Tamper switch
Supervisory report every 64 minutes
Belgian gray
Flat surface mounting
1.56" wide x 4.88" high x .94" deep
34-026 3.5 VDC ½ AA Lithium Battery
80-006-10 Belgian Gray Sensor
Spacer 20/pk
80-006-11 Brown Sensor Spacer
20/pk
60-652-95
Carbon Monoxide Sensor
Detects hazardous levels of carbon
monoxide gas
Internal siren sounds and red light comes
on when dangerous levels of gas are
present
Transmits alarm signal to control panel
when dangerous levels of gas are present
Sensor adjusts response time to carbon
monoxide levels present
Green light indicates detector is
functioning properly
Plugs into standard outlet
Note:
Gases NOT detected: methane, butane,
heptane, ethyl alcohol, isopropyl alcohol,
carbon dioxide, and propane.
110 VAC @ 60 Hz, 7W power
requirement
102-132 VAC operating voltage
2.5W average standby power
3.5 VDC ½ AA lithium battery for
transmitter
5-8 year sensor battery life
85 dB @ 10' for 4 minutes minimum
internal siren output
Time and CO PPM present for alarm to
sound:
<15 minutes @ 400 PPM
<35 minutes @ 200 PPM
<90 minutes @ 100 PPM
40 to 100 °F operating temperature
Supervisory report every 64 minutes
White case, green label
110 VAC grounded non-switched outlet
mounting
6.5" wide x 3.5" high x 2.25" deep
34-026 3.5 VDC ½ AA Lithium Battery
X-10 MODULES AND CENTRAL STATION MONITORING
Concord Family
Interactive Technologies, Inc. 25
X-10 Lighting and
Appliance Control Description/Features Specifications Accessories
13-079
X-10 Appliance Module
15 Amps, 1500W
Communicates through existing AC wiring;
no additional wiring needed
Controls appliances such as fans,
dehumidifiers, and stereos, using Concord
scheduling capabilities
Not for use with Concord Express
500W appliances
120 VAC @ 60 Hz power requirement
13-204
X-10 Powerhouse Series
Lamp Module
13-403
X-10 Pro Series Lamp Module
Provides system and user control of lamps
(up to 300W)
Communicates through existing AC wiring;
no additional wiring needed
Turns lights on during a fire or auxiliary
alarm
Blinks lights during police alarm
Blinks lights to indicate arming level
Turns lights on for 5 minutes when system
is armed/disarmed
13-403:
Automatic gain control—more reliable.
For use with 300W max incandescent
lights only
120 VAC @ 60 Hz power requirement
White
2.25" wide x 2.75" high x 1.25" deep
13-399
Universal Relay Module
Activates a relay for devices such as garage
door openers, sprinklers, and curtains with
a 4-Button Keychain Touchpad
Built-in low volume siren
Open/close command can be set for
momentary or continuous open/close
120 VAC @ 60 Hz power requirement
Provides isolated relay contacts to
control devices rated up to 5A @ 24
VDC (100 VA @ 30 VAC)
Rated for devices up to 30 VDC
White
2.25" wide x 3.5" high x 1.75" deep
13-397
2-Way Wall Switch Module
Automates indoor or outdoor lights,
including: porch, patio, hallway, and
stairway lights.
500W appliances
120 VAC @ 60 Hz power requirement
X-10 MODULES AND CENTRAL STATION MONITORING
Concord Family
26 Interactive Technologies, Inc.
Central Station
Monitoring Description/Features Specifications Accessories
60-766
CS-5000 Central Station Receiver
Provides control panel monitoring
Monitors all ITI systems
Monitors most communications formats
Provides ITI and SIA (Security Industry
Association) standard format
Communication outputs for computer
automation applications
Built-in CRT
4 telephone line connections
3 RS-232 outputs
Backup batteries
110 VAC @ 60 Hz or 220 VAC @ 50 Hz
operating voltage
12 VDC, 6.5 Ah lead acid backup battery
(not included)
Chassis: Rack mountable, anodized
aluminum desktop chassis; "tool-less"
front p anel access to all changea ble
cards; holds up to 12 line cards
19" wide, 5.75" high, 11.5" deep
Continuous call throughput from 12 line
cards simultaneously receiving SIA DCS
events at 300 baud
Automatic line card interpretations of
Modem, FSK/BFSK, Tone Burst, and
DTMF formats
500 call minimum call history memory.
Built-in test and diagnostics
Includes one line card
13-352 Okidata® Printer
13-227 Proxima® Surge Suppressor
13-248 12V, 6.5 Ah Backup Battery
60-417 Phone Line and Power Fault
Annunciator Module
46-056 Installation and Operator’s
Guide
46-081 CS-5000 Full Color Brochure
Remote Programming
Software
60-675-WIN
ITI ToolBox 4.3 for Windows
Software application that allows control
panels to be programmed from a PC
Uploads control panel information for new
accounts
Downloads control panel information for
new installations
Updates existing control panel
programming
Easy, menu-driven interface
On-line help
Stores database of control panel accounts
on a PC hard disk
Y2K Compliant
Package includes:
Up to two 3.5" high density disks
User’s Guide
On-line help
Minimum system required:
Windows 3.1 or later
386/25 MHz IBM® or compatible PC
Hayes™ or compatible modem
8 MB free hard disk space
60-719 ToolBox Modem Kit
HARDWIRE SENSORS
Concord Family
Interactive Technologies, Inc. 27
Hardwire Intrusion
Contacts Description/Features
13-430
Surface Mount 2” Gap, White
13-431
Surface Mount 2” Gap, Brown
Tane Model Number: SW-35WG
2-inch gap
10/pk
Surface mount
13-432
Surface Mount 1” Gap, White
13-433
Surface Mount 1” Gap, Brown
Tane Model Number: SW-32G
1-inch gap
10/pk
Surface mount
13-434
Rollerball Switch Contact, White
13-435
Rollerball Switch Contact, Brown
Tane Model Number: RG-32
¾-inch gap
10/pk
13-428
Mini Surface Contact w/Terminal
and Adhesive Strip, White
13-429
Mini Surface Contact w/Terminal
and Adhesive Strip, Brown
Tane Model Number: FM-106
1-inch gap minimum
10/pk
13-436
Magnetic Recessed Contact, White
13-437
Rollerball Recessed Contact, Brown
Tane Model Number: STB-10
.7-inch gap minimum
10/pk
HARDWIRE SENSORS
Concord Family
28 Interactive Technologies, Inc.
Hardwire Miscellaneous
Detectors Description/Features Specifications Accessories
13-438
Overhead Garage Door Switch Tane Model Number: Met-44
Quantity of 1
13-075
Call Switch N/O 8-ft. Reed Switch
13-076
Double Holdup Button N/O Reed
Switch, White
13-066
Sentrol 1005 Mini-Magna Pull N/C
Reed Switch 10/pk, White
13-065
Sentrol 1005 Mini-Magna Pull N/C
Reed Switch 10/pk, Brown
13-062
Sentrol 5150 Glass Break Detector,
White
13-063
Sentrol 5150 Glass Break Detector,
Brown
10-foot protection on a single pane
Easy to use, field proven 3M adhesion
Detects all types of glass without
adjustment
Ideal for 24-hour loop protection
13-468
Optex Pet Immune PIR
Detects movement inside an enclosed
structure
Use in large rooms, narrow corridors, and
stairwells
Passive infrared detection
Wide angle coverage (40 x 40 feet).
Long range coverage (10 x 67 feet)
9-16 VDC input power
17 mA @ 12 VDC current draw
-4 to 120 °F operating temperature
13-464
DS-940 Hardwire PIR
13-465
DS-940P Pet Immune Hardwire PIR
Detects movement inside an enclosed
structure
Use in large rooms, narrow corridors, and
stairwells
Passive infrared detection
Optional pet lens
Two sensitivity settings
Mounting kit included to adjust coverage
pattern
Small and unobtrusive
9-15 VDC input power
17 mA @ 12 VDC current draw
-20 to 122 °F operating temperature
Tamper switch
Supervisory report every 64 minutes
Belgian gray
Wall mounting
2.25" wide x 3" high x 1.5" deep
13-440
DS-835 Tri-Tech PIR/Microwave
Motion Detector - Hardware
Tri-Tech Model Number: DS835
Microwave motion detector
Quantity of 1
Uses microwave passive infrared and
built-in artificial intelligence for maximum
pattern recognition
SALES, PRINT, AND VIDEO MATERIALS
Concord Family
Interactive Technologies, Inc. 29
Sales, Print, and Video
Materials Description/Features Specifications Accessories
80-347
Concord Express Demonstration Kit
80-332
Concord Demonstration Kit
Provides an effective way to demonstrate
Express to business and residential
customers.
Kit Includes:
Operational control panel
Fixed English LCD Touchpad
(2) 2-button keychain touchpads
Hardwire interior siren
SAW door/window sensor
ITI PIR motion detector housing
Water-resistant panic housing
Active hardwire contacts configured
into the panel
80-332:
Operational control panel
Alphanumeric touchpad.
2 door/window sensors.
Interrogator 200 Audio Verification
Module.
4-button keychain touchpad.
System Sensor Smoke Sensor.
Pendant Panic Sensor.
Plastic door/window sensors cases .
Black carrying case (19” wide x 14” high)
466-1731
Concord Product Line Overview
Specification
Provides a easy-to-understand overview of
the Concord Express, Concord, and Concord
Commercial systems.
Two color
8.5” high x 11” wide
8 pages
50/pk
466-1593
Concord End-User Brochure Provides an overview of Concord for
business and residential customers.
Four color
Glossy
8.5” high x 11” wide
8 pages
50/pk
466-1593
Concord End-User Feature/Benefit
Sheet
466-1611
Concord Express End-User
Feature/Benefit Sheet
466-1641
Concord Commercial End-User
Feature/Benefit Sheet
Provides an overview of Concord for
business and residential customers.
Four color
Glossy
8.5” high x 11” wide
8 pages
50/pk
Sales, Print, and Video
Materials Description/Features Specifications Accessories
SALES, PRINT, AND VIDEO MATERIALS
Concord Family
30 Interactive Technologies, Inc.
466-1504-SAW
SAW Wireless Sensor Brochure
466-1504-CRY
Crystal Wireless Sensor Brochure
Provides an overview of some wireless SAW
sensors available and their applications
Four color
Glossy
4” wide x 9” high (folded)
16 pages
25/pk
466-1513
Concord User’s Guide
466-1594
Concord Owners Video
466-1667
Concord Express User’s Guide
466-1743
Concord Express Owners Video
User’s Guides:
Provides complete operating instructions
for the security system.
3-hole punched
8.5” wide x 11” high
One included with each panel.
User’s Videos:
Provides an overview and basic instructions
for operating. One video is included with
each panel.
15 minutes
Full color
8.5” wide x 11” high
3-hole drilled
Black and white
466-1512
Concord Installation Guide
466-1665
Concord Express Installation Guide
Provides installation, setup, and
programming procedures.
3-hole punched
8.5” wide x 11” high
Available upon request
INDEX
by Product Part Number
Interactive Technologies, Inc.
13-046
Hardwire Exterior Piezo Siren 18
13-060
RMS Exterior Horn, 15 Watt Speaker 18
13-062
Sentrol 5150 Glass Break Detector, White 28
13-063
Sentrol 5150 Glass Break Detector, Brown 28
13-065
Sentrol 1005 Mini-Magna Pull N/C Reed Switch 10/pk,
Brown 28
13-066
Sentrol 1005 Mini-Magna Pull N/C Reed Switch 10/pk,
White 28
13-075
Call Switch N/O 8-ft. Reed Switch 28
13-076
Double Holdup Button N/O Reed Switch, White 28
13-079
X-10 Appliance Module 25
13-204
X-10 Powerhouse Series Lamp Module 25
13-374
LD 105 Hardwire Interior Piezo Siren 17
13-397
2-Way Wall Switch Module 25
13-399
Universal Relay Module 25
13-403
X-10 Pro Series Lamp Module 25
13-428
Mini Surface Contact w/Terminal and Adhesive Strip,
White 27
13-429
Mini Surface Contact w/Terminal and Adhesive Strip,
Brown 27
13-430
Surface Mount 2” Gap, White 27
13-431
Surface Mount 2” Gap, Brown 27
13-432
Surface Mount 1” Gap, White 27
13-433
Surface Mount 1” Gap, Brown 27
13-434
Rollerball Switch Contact, White 27
13-435
Rollerball Switch Contact, Brown 27
13-436
Magnetic Recessed Contact, White 27
13-437
Rollerball Recessed Contact, Brown 27
13-438
Overhead Garage Door Switch 28
13-440
DS-835 Tri-Tech PIR/Microwave Motion Detector -
Hardware 28
13-453
Surface Mount Interior Speaker 18
13-454
Recessed Mount Interior Speaker 18
13-464
DS-940 Hardwire PIR 28
13-465
DS-940P Pet Immune Hardwire PIR 28
13-468
Optex Pet Immune PIR 28
466-1504-CRY
Crystal Wireless Sensor Brochure 30
466-1504-SAW
SAW Wireless Sensor Brochure 30
466-1512
Concord Installation Guide 30
466-1513
Concord User’s Guide 30
466-1593
Concord End-User Brochure 29
466-1593
Concord End-User Feature/Benefit Sheet 29
466-1594
Concord Owners Video 30
466-1611
Concord Express End-User Feature/Benefit Sheet 29
466-1641
Concord Commercial End-User Feature/Benefit Sheet 29
466-1665
Concord Express Installation Guide 30
466-1667
Concord Express User’s Guide 30
466-1731
Concord Product Line Overview Specification 29
466-1743
Concord Express Owners Video 30
60-252
Interior Speaker and Piezo 18
60-278
Hardwire Interior Siren and Piezo 17
60-348-10-95
Hand Held Wireless Touchpad 5, 11, 16
60-362-10-319.5
Belgian Gray Door/Window Sensor 20
60-362-11-319.5
Brown Door/Window Sensor 20
60-459-319.5
Sound Sensor 21
60-460-319.5
Rate-of-Rise Heat Sensor 23
60-460-319.5-LB
Rate-of-Rise Heat Sensor w/Lithium Battery 23
60-461-10-319.5
Belgian Gray Shock Sensor 21
60-461-10-319.5
Brown Shock Sensor 21
60-462-10-319.5
Belgian Gray Glass Break Sensor 22
60-462-11-319.5
Brown Glass Break Sensor 22
60-483-01
Interior Slim Line Piezo Siren 17
60-499-10-319.5
Slim Line Belgian Gray Door/Window Sensor 20
60-499-11-319.5
Slim Line Brown D/W Sensor 20
60-504-10-319.5
Freeze Sensor 24
60-506-319.5
System Sensor™ Smoke Sensor 2100 RF 23
60-511-01-95
DS924i PIR Motion Sensor 20
60-511-02-95
DS924i Pet Immune PIR Motion Sensor 20
60-584
SuperBus Hardwire Input Module 8, 14
60-585
SuperBus Hardwire Output Module 8, 14
60-589-319.5
Fire Pull Station Sensor 23
60-597-95
HiTech Hand Held Wireless Touchpad 5, 11, 16
60-606-319.5
4-Button Keychain Touchpad 11, 16
60-607-319.5
2-Button Keychain Touchpad 5, 11, 16
60-607-319.5
4-Button Keychain Touchpad 5
60-615-10-319.5
Quik Bridge™ Learn Mode Repeater 22
60-620
SuperBus Energy Saver Module 9
60-639-95R
Indoor PIR Motion Sensor 19
60-639-95R-OD
Outdoor PIR Motion Sensor 19
60-645-95
System Sensor™ Smoke Sensor 2300 RF 23
60-652-95
Carbon Monoxide Sensor 24
60-659-319.5
4-Button SAW Keychain Touchpad 16
60-659-95R
4-Button SAW Keychain Touchpad 5, 11
60-670-1195R
Brown Door/Window Sensor 19
60-670-95R
Belgian Gray Door/Window Sensor 19
60-675-WIN
ITI ToolBox 4.3 for Windows 26
60-677
Interrogator 200 Audio Verification Module 9, 15
60-680
12 VDC, 7.0 Ah Lead Acid Battery 6
60-681
12 VDC, 4.0 Ah Lead Acid Battery 3, 6
60-683
Phone Jack Siren 17
60-694-95R
5-Button SAW Keychain Touchpad 5, 11, 16
60-703-95
ITI Crystal PIR Motion Sensor 21
60-728
SuperBus LED Touchpad 10, 15
60-734
Concord Hybrid Control Panel 6
60-736-95
Supervised Wireless Interior Siren (SWIS) 17
60-741-11-95
Micro Recessed Brown D/W Sensor 20
60-741-95
Micro Recessed Begian Gray Door/Window Sensor 20
60-744-95R
Water Sensor 19
60-746
SuperBus 2000 2x16 LCD Touchpad 4
60-746
SuperBus 2x16 LCD Touchpad 15
60-746-01
SuperBus 2000 2x16 LCD Touchpad 10
60-755
Power Line Carrier (X-10) Card 7, 13
60-756
4-Zone Input/2 Form-C Relay Output SnapCard 4, 7, 13
60-757
8-Zone Input SnapCard 4, 7, 13
60-761
24 VAC, 25 VA Class II Transformer 6, 12
60-762
24 VAC, 25 VA Class II Line Carrier Transformer -
1 Amp 6, 12
60-764-95R-16Z
16-zone SuperBus Radio Receiver 7, 13
60-764-95R-32Z
32-zone SuperBus Radio Receiver 7, 13
60-764-95R-MAX
76-zone SuperBus Radio Receiver 7, 13
INDEX
by Product Part Number
Interactive Technologies, Inc.
60-766
CS-5000 Central Station Receiver 26
60-777
Phone Control and Voice Module 8, 14
60-778
24 VAC, 50 VA Class II Transformer 6, 12
60-779
24 VAC, 50 VA Class II Line Carrier Transformer - 2.0 Amp 12
60-779
24 VAC, 50 VA Class II Line Carrier Transformer - 2.5 Amp 6
60-792-95R-16Z
Concord RF16 Integrated Panel 6
60-792-95R-32Z
Concord RF32 Integrated Panel 6
60-801
Concord Commercial Hybrid Control Panel 12
60-803-04
SuperBus 2000 2-line 2x20 LCD Touchpad 4, 10, 15
60-804-04
SuperBus 2000 2-line 2x20 VFD Touchpad 4, 10, 15
60-806-95R
Concord Express Control Panel 3
60-807-95R
Indoor PIR Pet Immune Motion Sensor 19
60-820
SuperBus 2000 Fixed English LCD Touchpad 4
60-822
16.5 VAC, 25 VA Class II Transformer 3
60-832-95
2-Button Encrypted Keychain Touchpad 5
60-834
FlexGuard® Dual Disturbance Sound Sensor 21
80-332
Concord Demonstration Kit 29
80-347
Concord Express Demonstration Kit 29
©Interactive Technologies, Inc. December 1999
Specifications subject to change.
Some features are optional.
Document Number: 466-1242-CON
T: 800/777-1415
F: 651/779-4890
I
nteractive
T
echnologies,
I
nc.
2266 Second Street North
North Saint Paul, MN 55109-2900
WebSite:
www.ititechnologies.com
Security
Automation
Fire Protection
Access Control WIRELESS

Navigation menu
