CONTREX, INC.
8900 Zachary Lane North
Maple Grove, MN 55369 USA
Tel: 763.424.7800 800.342.4411
Fax: 763.424.8734
EFFECTIVE August 1, 2005
FORM DS114X
PRI CE SUBJECT TO CHANGE
WITHOUT NOTICE
PRI CES ARE U .S. D O LLARS
PRI CE LI ST
LI ST
PART NO . D ESCRIPTIO N PRICE
CX-1102
3200-2040 CX-1102 2 AXIS CO N TRO L $ 1,795
UNWIND/DANCER/WIND CONTROLLER
3200-2041 CX-1102 2 AXIS CO N TRO L $ 2,190
WITH DEVICENET® BOARD INSTALLED
CX-1010
3200-1944 CX-1010 U N I VERSAL D I GI TAL CO N TRO L $ 1,295
FOR SPEED AND SPEED RATIO OPERATIONS
3200-1945 CX-1010 W I TH AN ALO G BO ARD I N STALLED $ 1,610
3200-1946 CX-1010 WITH DEVICENET® BOARD INSTALLED $ 1,690
3200-1947 CX-1010 WITH ANALOG AND DEVICENET® BOARDS INSTALLED $ 2,005
3200-1991 CX-1010 DEVICENET® OPTION BOARD ONLY $ 395
(requires external 5vdc)
3200-1992 CX-1010 AN ALO G O PTI O N BO ARD $ 315
2-Channel Standard
3200-1993 CX-1010 AN ALO G O PTI O N BO ARD $ 315
2-Channel Load Cell
3200-1994 CX-1010 ANALOG OPTION BOARD, $ 315
1-Channel Load Cell, 1-Channel Standard
3200-2021 CX-1010 TECHNICAL MANUAL (CD ROM - EXTRA COPIES) $ 15
0001-0131 CX-1010 TECHNICAL MANUAL (HARD COPY) $ 75
-2-
LI ST
PART N O . DESCRIPTION PRICE
M -SERI ES
3200-1602 M -TRIM U N I VERSAL D I GI TAL CO N TRO L $ 900
Precision "Front End" for any AC or DC drive. Isolated input/
output. Master or Follower mode with 4 presets, 6 limits/alarms,
3 frequency inputs, and RS422/RS485 computer link.
3200-1603 M -TRIM WITH ANALOG IN/OUT OPTION INSTALLED $ 1,050
3200-1607 M -TRI M WITH INVERSE SET-POINT FUNCTION $ 900
3200-1676 M-DRIVE DC MOTOR CONTROL/DRIVE $ 925
Rated for up to 2HP, 180V Armature, 200V Field. (Stock
configuration 1HP, 90V/100V with 120VAC supply . . . switch
selectable for 2HP, 230VAC supply.) Control features similar
to M-Trim.
3200-1677 M-DRIVE WITH ANALOG IN/OUT OPTION INSTALLED $ 1075
3200-1678 M-DRIVE WITH INVERSE SET-POINT FUNCTION $ 925
3200-1680 ANALOG I/O OPTION CARD - M -SERI ES $ 150
Retrofit M-Drive #3200-1676 or M-Trim #3200-1602 with this
plug-in accessory board. Analog is assignable to 1 of 7 input
variables; Analog out assignable to any (1) variable code.
Signals can be jumper selected as 4-20 ma or 0-10VDC.
3200-1682 CO M PLEM EN TARY AN ALO G I /O CARD - M -SERI ES $ 150
Same as 3200-1680 but an i ncreasi ng si gnal input causes a
decreasing motor speed.
3200-1931 M L-TRI M UNIVERSAL D IGITAL CON TRO LLER (115VAC) $ 565
Precision “Front End” for any AC or DC drive. Isolated Drive signal
and optionally isolated signal I/O. Master or Follower mode with
2 presets each. RS485 Link.
3200-1932 M L-TRI M UNIVERSAL D IGITAL CON TRO LLER (230VAC) $ 565
3200-1933 ML-DRIVE DC CONTROLLER/DRIVE (115VAC) $ 640
Rated for 1HP 90V Arm.
Control features similar to ML-Trim.
3200-1934 ML-DRIVE DC CONTROLLER/DRIVE (230VAC) $ 640
Rated for 2HP 180V Arm.
-3-
LI ST
PART N O . DESCRIPTION PRICE
M-SERIES - Continued
3200-1936 M LP-TRI M UNIVERSAL DIGITAL/ANALOG CONTROLLER (115VAC) $ 660
Similar to ML-Trim but with 1 analog input useable for frequency,
set point, or dancer trim. Zero-error in freq. follower mode, and
other enhancements.
3200-1937 M LP-TRI M UNIVERSAL DIGITAL/ANALOG CONTROLLER (230VAC) $ 660
3200-1938 M LP-D RI VE DC CONTROLLER/DRIVE - DIGITAL/ANALOG (115VAC) $ 735
Rated for 1 HP - 90V Arm. Control features similar to MLP-Trim.
3200-1939 M LP-D RI VE DC CONTROLLER/DRIVE - DIGITAL/ANALOG (230VAC) $ 735
Rated for 2 HP 180V Arm.
3200-1740 M-TRACK FULL SYNCHRONIZING CONTROL $ 1,650
Controls any AC/DC or Servo Drive to synchronize a slave
machine in both speed and phase relative to the master.
3200-1820 M-RO TARY SYNCHRONIZING CONTROL FOR $ 1,650
RO TARY KN I FE/D RU M
Similar to M-TRACK but has engineering unit set points and
electronic cam profile feature.
3200-1831 M -CUT FEED -TO -LEN GTH CO N TRO L $ 1,250
Incremental and absolute motion control for precise repeat
lengths. Fast response for use with servo motors/amplifiers.
3200-1840 M-SHUTTLE FO R FLYI N G CU T-O FF $ 1,650
Synchronized back-and-forth action for cut-off carriage drive.
3200-1841 M-TRAVERSE LEVEL WIND OR WEB SCAN $ 1,650
Synchronized back-and-forth action with adjustable lay and
width settings. Edge or Center based.
3200-1855 O PEN-CHASSIS M -CUT CO NTROLLER (M B-CU T) $ 900
With isolated power supply. Also includes DB9 cable assy and
CONTREX-HOST Software with 1st unit ordered.
3200-185X OPEN-CHASSIS M-SERIES CONTROLLER $ 1,175
M-Rotary, M-Track, M-Traverse, M-Shuttle functions
in an open-chassis package. With isolated power supply. Also
incl udes D B9 cabl e assy and CONTREX-HOST Softw are w i th
1st unit ordered.
-4-
LI ST
PART N O . DESCRIPTION PRICE
3200-1860 PEN D AN T W /RI BBO N CABLE FO R M B-SERI ES $ 375
OPEN CHASSIS CONTROLS
Not required if laptop computer is available.
O PEN CH ASSI S M -SERI ES N O TE:
Custom software configuration possible. Contact factory with
specifications/custom requirements or for Special Volume Discount.
CO M PUTER/PH O N E LIN K ACCESSO RY ITEMS FO R M -SERIES PRO D U CTS
Built-in RS422/RS485 port. Instruction manual describes character
format and message protocol. More than 50 parameters can
be monitored or changed from host computer. Experienced
programmers can write their own routines.
3200-2022 Contrex H ost 3 CD - User Ready Software (Windows) $ 250
Program allows user to command, change parameter,
monitor, or save-to-fi le. W orks w ith CX-1010, M -Seri es,
M B-Seri es, M L-Seri es or M LP-Seri es.
NOTE: W indows DDE drivers are also available from
3rd party vendors.
MICRO-MODULES
3200-1800 MM100 COMMUNICATION CONVERSION DEVICE - RS232:RS422. $ 195
Module has standard female DB-25 pin, RS232 receptacle
and 4 screw terminals for RS422. Transmit/Receive LEDs
verify operation. Snap-Track package. Adapts M-Series
communication port to match host computer having RS232
port. Only one device required on multi-channel M-Series
systems. Requires + 12VDC from M-Series Control. Optional
isolation mode (isolation requires extra 5VDC source).
5200-0045 COMMUNICATION CONVERSION DEVICE - RS232:RS485 $ 195
Module has standard female DB-25 pin RS232 receptacle
and screw terminals for either RS422 or RS485.
Transmission LED’s verify operation. Requires 5 to 12VDC
(availabl e from CONTREX control lers).
-5-
LI ST
PART N O . DESCRIPTION PRICE
MICRO-MODULES - Continued
5200-0042 CDE-2 CABLE ADAPTER - 9 PIN FEMALE TO 25 PIN MALE $ 40
Straight extension to match converters to computers having
a 9 pin male plug serial port.
5200-0041 CDE-3 CABLE ADAPTER - 9 PIN FEMALE TO 9 PIN MALE $ 40
To match MB-Series open chassis controller to computers
having 9 pin male plug serial port. (No converter required.)
3200-1803 MM500 8-CHANNEL OPTO-ISOLATION MODULE $ 160
For high-noise environments. Use for discrete inputs
on M-Series controllers. (Not for use on high-freq.
encoder inputs.)
SU PPRESSI O N
6003-5017 QUENCHARC $ 4
Snubber for AC Coils and Supply Line. 100 ohm - 0.1 mfd.
6003-5015 QUENCHARC $ 4
Snubber for low voltage Signal Lines. 22 ohm - 0.1 mfd.
6500-0020 CO RCOM LIN E FILTER $ 25
For AC Supply Line 10 Amps @ 120, 8 amps @ 250
6500-0073 CO RCOM LIN E FILTER $ 45
For AC Supply Line 20 Amps @ 120, 16 Amps @ 250
-6-
LI ST
PART NO. MODEL NO. DESCRIPTION PRICE
E-DRIVE DC MOTOR CONTROLLER/DRIVE
3200-1100 ED -O E-DRIVE D C CO N TRO LLER $ 495
Open chassis for up to 1 HP, (90V) or 2HP (180V)
3200-1110 ED -1 E-DRIVE D C CO N TRO LLER $ 745
with enclosure, 10T dial pot, no display.
3200-1120 ED -2 E-DRIVE D C CO N TRO LLER $ 900
with enclosure, 10T pot, 4-digit display.
3200-1130 ED -3 E-DRIVE D C CO N TRO LLER $ 1,040
with enclosure, man 10T pot, auto 10T pot, and
master/follower select switch.
5800-1500 TCD-10T TURN COUNT 10T DIAL for ED-2 $ 60
3200-1150 SR241-4 SPEED READ -O U T, $ 295
cable interconnect to ED-O Controllers.
M U LTI -M O TO R SYSTEM ACCESSO RI ES
3200-1330 RC272 MASTER RATIO OSCILLATOR AND FREQU ENCY SCALER $ 375
Auto: 500 Hz in = 500 HZ out
Manual: 0-500 Hz out (Specify other ranges)
3200-1200 VCO-1B M ASTER O SCI LLATO R O R $ 275
ANALOG-TO-FREQ UENCY CONVERTER
0-500 Hz. Field selectable other ranges.
Requi res _+12VDC.
Above oscillators do not include operators
potentiometers. O rder separately.
SPEED PO TS FO R RC272/V CO -1 O SCI LLATO RS
7120-1374 P10-10 POT, 10T w/dial & 10 ft. cable (0.50%) $ 170
7120-1390 P10A-10 PO T, 10T w/dial & 10 ft. cable (0.05%) $ 380
-7-
LI ST
PART NO. MODEL NO. DESCRIPTION PRICE
ACCESSO RY CIRCU ITS (Most require external _+12VDC to 15VDC power.)
3200-1170 PD C-1B PULSE-TO-D C CARD/CO NNECTOR $ 175
Specify sensor type, input frequency.
Output range is 4-20 ma.
3200-1175 PDC-3B PULSE-TO-D C CARD/CO NNECTOR $ 225
Zero based or groundable output 0-5VDC or 4-20 ma.
Specify sensor type and input frequency.
7300-0841 ADR-1 ACCEL-DECEL RAMP CARD /CONNECTOR $ 195
5-30 SECOND S.
3200-1180 DSS-1 DELTA-SPEED SW ITCH $ 295
Specify sensor type, frequency and trip range.
3200-1440 PDB-1 PRE-AM P/ D I VI D E CARD $ 195
For mag. pickups. Jumper Select divide
by 1, 2, 4, 8, or 16.
5210-0013 PO W ER SU PPLY +_15VDC $ 130
Open Chassis - 80 milliamps.
QUADRATURE RING KITS II N EW - 60T GEAR, 5-24VD C - OPEN CO LLECTO R
7300-1600 QRK56C, 5/8" Bore w/Pull-up Resistor $ 165
7300-1601 QRK143TC, 7/8" Bore w/Pull-up Resistor $ 178
7300-1602 QRK182TC, 1-1/8" Bore w/Pull-up Resistor $ 255
7300-1603 QRK213TC, 1-3/8" Bore w/Pull-up Resistor $ 255
7300-1604 QRK254TC, 1-5/8" Bore w/Pull-up Resistor $ 255
7300-1605 Q RK71D Metric Face, 14mm Bore w/Pull-up Resistor $ 260
7300-1610 QRK56C, 5/8" Bore w/o Pull-up Resistor $ 165
7300-1611 QRK143TC, 7/8" Bore w/o Pull-up Resistor $ 178
7300-1612 QRK182TC, 1-1/8" Bore w/o Pull-up Resistor $ 255
7300-1613 QRK213TC, 1-3/8" Bore w/o Pull-up Resistor $ 255
7300-1614 QRK254TC, 1-5/8" Bore w/o Pull-up Resistor $ 255
7300-1615 Q RK71D Metric Face, 14mm Bore w/o Pull-up Resistor $ 260
QUAD RATU RE RIN G KITS II N ew- 60T GEAR, 5-24VD C - DIFFERENTIAL
7300-1620 QRK56C, 5/8" Bore Line Driver Output $ 175
7300-1621 QRK143TC, 7/8" Bore Line Driver Output $ 188
7300-1622 QRK182TC, 1-1/8" Line Driver Output $ 265
7300-1623 QRK213TC, 1-3/8" Line Driver Output $ 265
7300-1624 QRK254TC, 1-5/8" Line Driver Output $ 265
7300-1625 Q RK71D Metric Face, 14mm Bore Line D river O utput $ 270
-8-
CONVERSION TABLE NEW PRODUCT
NUMBERS VS OLD PRODUCT NUMBERS
Quadrature Sensor Ring
Kits - 60 Tooth Gear - 5 to 15 VDC - Open Collector
7300-1310 56C, 5/8" Bore, with Pull-up Resistor Replaced by QRK II 7300-1600
7300-1311 143TC, 7/8" Bore, with Pull-up Resistor Replaced by QRK II 7300-1601
7300-1312 182TC, 1-1/8" Bore, with Pull-up Resistor Replaced by QRK II 7300-1602
7300-1313 213TC, 1-3/8" Bore, with Pull-up Resistor Replaced by QRK II 7300-1603
7300-1314 254TC, 1-5/8" Bore, with Pull-up Resistor Replaced by QRK II 7300-1604
7300-1355 71D Metric, 14mm Bore, with Pull-up Resistor Replaced by QRK II 7300-1605
7300-1315 56C, 5/8" Bore, without Pull-up Resistor Replaced by QRK II 7300-1610
7300-1316 143TC, 7/8" Bore, without Pull-up Resistor Replaced by QRK II 7300-1611
7300-1317 182TC, 1-1/8" Bore, without Pull-up Resistor Replaced by QRK II 7300-1612
7300-1318 213TC, 1-3/8" Bore, without Pull-up Resistor Replaced by QRK II 7300-1613
7300-1319 254TC, 1-5/8" Bore, without Pull-up Resistor Replaced by QRK II 7300-1614
7300-1357 71D Metric, 14mm Bore, without Pull-up Resistor Replaced by QRK II 7300-1615
Quadrature Sensor Ring Kits - 60 Tooth Gear - 5 to 15 VD C - Differential
7300-1370 56C, 5/8" Bore, Line Driver Output Replaced by QRK II 7300-1620
7300-1371 143TC, 7/8" Bore, Line Driver Output Replaced by QRK II 7300-1621
7300-1372 182TC, 1-1/8" Bore, Line Driver Output Replaced by QRK II 7300-1622
7300-1373 213TC, 1-3/8" Bore, Line Driver Output Replaced by QRK II 7300-1623
7300-1374 254TC, 1-5/8" Bore, Line Driver Output Replaced by QRK II 7300-1624
7300-1375 71D Metric, 14mm Bore, Line Driver Output Replaced by QRK II 7300-1625
Quadrature Sensor Ring Kits - 60 Tooth Gear - 15 to 24 VD C - Open Collector
7300-1410 56C, 5/8" Bore, with Pull-up Resistor Replaced by QRK II 7300-1600
7300-1411 143TC, 7/8" Bore, with Pull-up Resistor Replaced by QRK II 7300-1601
7300-1412 182TC, 1-1/8" Bore, with Pull-up Resistor Replaced by QRK II 7300-1602
7300-1413 213TC, 1-3/8" Bore, with Pull-up Resistor Replaced by QRK II 7300-1603
7300-1414 254TC, 1-5/8" Bore, with Pull-up Resistor Replaced by QRK II 7300-1604
7300-1415 71D Metric, 14mm Bore, with Pull-up Resistor Replaced by QRK II 7300-1605
7300-1420 56C, 5/8" Bore, without Pull-up Resistor Replaced by QRK II 7300-1610
7300-1421 143TC, 7/8" Bore, without Pull-up Resistor Replaced by QRK II 7300-1611
7300-1422 182TC, 1-1/8" Bore, without Pull-up Resistor Replaced by QRK II 7300-1612
7300-1423 213TC, 1-3/8" Bore, without Pull-up Resistor Replaced by QRK II 7300-1613
7300-1424 254TC, 1-5/8" Bore, with out Pull-up Resistor Replaced by QRK II 7300-1614
7300-1425 71D Metric, 14mm Bore, without Pull-up Resistor Replaced by QRK II 7300-1615
Product Number Change: Quadrature Speed Sensors
7200-0940, 7200-0942, 7200-0970, 7200-0972 Replaced with 7200-0990
7200-0941, 7200-0971, 7200-0945, 7200-0973 Replaced with 7200-0991
7200-0943, 7200-0946 Replaced with 7200-0992
-9-
LI ST
PART NO. MODEL NO. DESCRIPTION PRICE
M AGN ETIC PICK-U P KITS
Note: Only M-Trim, M-Drive, and E-Drive controls can use
magnetic pick-ups. O ther m odels require Q uad Kits, Single
Channel Kits, other Encoders, or Converter Kit 3200-1980.
7300-0980 RK56C SENSOR KIT w/60T GEAR - 5/8 inch $ 99
7300-0982 RK143TC SEN SO R KI T w/60T GEAR - 7/8 inch $ 112
7300-0934 RK182TC SEN SO R KI T w/60T GEAR - 1-1/8 inch $ 175
7300-0936 RK213TC SEN SO R KI T w/60T GEAR - 1-3/8 inch $ 175
7300-0987 RK254TC SEN SO R KI T w/60T GEAR - 1-5/8 inch $ 175
7300-0981 RK56C-30 SEN SO R KI T w/30T GEAR - 5/8 inch $ 117
7300-0983 RK143TC-30 SEN SO R KI T w/30T GEAR - 7/8 inch $ 139
7300-0984 RK182TC-30 SEN SO R KI T w/30T GEAR - 1-1/8 inch $ 195
7300-0985 RK213TC-30 SEN SO R KI T w/30T GEAR - 1-3/8 inch $ 367
3200-1980 DUAL CHANN EL M AG PICK-UP CON VERTER $ 85
Converts 2 magnetic pick-up signals into amplified square
wave. Requi res 5-12VDC (availabl e from CONTREX controll ers).
SPEED SEN SO RS Note: See page 8 for Product N umber Cross Reference
7200-0990 QUADRATURE SENSOR 5-24VDC $ 100
w/Pull-up Resistor - open collector
7200-0991 QUADRATURE SENSOR 5-24VDC $ 100
w/o Pull-up Resistor - open collector
7200-0992 QUADRATURE SENSOR 5-24VDC $ 110
Differential
7200-0940 Q UADRATURE SENSOR 5-15VD C $ 120
w/Pull-up Resistor - open collector
(Obsolete Available only while existing stock lasts.)
5800-1410 SM 3 N MAGN ETIC PICKUP, Threaded $ 25
5800-1412 SM 3N-A MAGNETIC PICKUP, Smooth $ 25
6500-0038 SM5XP M AGN ETIC PICKUP, Explosion Proof1 $ 595
5800-1413 SP8 N 3 PROX SENSOR, 3-wire1&2 $ 160
3200-1340 ENCDR-600 ENCODER, 10V, 600 PPR $ 295
3200-1350 ENCDR-1200 ENCODER, 10V, 1200 PPR $ 295
3200-1341 QENCDR-600 ENCODER, 5V, 600 PPR, Quadrature, NPN $ 525
7000-0450 R56CXP FLANGE RING ONLY, 56C, for SM5XP sensor $ 125
1NOTE:These sensors require larger size targets . . . use with 30T gears only.
2NOTE:These sensors will fit in Flange Ring Sensor Kits (RK Kits). Order
Sensor Kit "less sensor" and add special sensor/price as additional
order line item.
-10-
LI ST
PART NO. MODEL NO. DESCRIPTION PRICE
GEARS
5800-1700 G60T5 GEAR, 60T, 5/8 inch $ 25
5800-1701 G60T7 GEAR, 60T, 7/8 inch $ 38
5800-1702 G60T9 GEAR, 60T, 1 1/8 inch $ 45
5800-1703 G60T11 GEAR, 60T, 1 3/8 inch $ 45
5800-1704 G60T13 GEAR, 60T, 1 5/8 inch $ 45
7000-0376 G20T2 SPRO CKET, 20T, 1/4 inch $ 60
5800-0382 G30T5 GEAR, 30T, 5/8 inch $ 40
5800-0383 G30T7 GEAR, 30T, 7/8 inch $ 65
5800-0347 G30T9 GEAR, 30T, 1 1/8 inch $ 68
5800-0348 G30T11 GEAR, 30T, 1 3/8 inch $ 240
DC DRIVES, REGEN, SINGLE PHASE
D C CO N TRO LLER for 1/8 - 5 HP, Regen, chassis only. Chassis is
drive module only. Subplate, Armature Contactors, Pot, and Operator
Devi ces are NOT included. Convertible unit is shipped in 230V
configuration. (5 HP version is slightly larger chassis.)
HP AMP VO LTS PRICE
3200-1264 DF9P-10C 1 10 115 $ 600
3200-1264 DF9P-10C 2 10 230 $ 600
3200-1782 D F9P-15C 3 15 230 $ 680
3200-1792 DF9P-25C 5 25 230 $ 1,150
-11-
OTHER CONTREX PRODUCT LINES:
REFLEX PRODUCTS
Reflex model accessory and signal conditioning cards are
available. Consult Price Sheet D S456 or contact factory.
SERVO MOTORS/AMPLIFIERS
Complete line of Brushless DC servo motors and amplifiers
available as modules or as complete kits. Consult Price Sheet DS410
or contact factory.
ADDITIONAL INFORMATION:
Check our W eb Site for Technical and Application Information for our
most popular controller models.
W eb Site: www.contrexinc.com
E-M ail: info@contrexinc.com
