AB
AB
AA
MARK
Form No. C-1150:144-ENG
Family code = M260
CoroPak 15.2 15.10.01 Revised 15.10.01
Even more possibilities thanks to tailored design!
If you do not find what you need in our comprehensive standard
programme, choose the tool shape you require and we will tailor it
for you to your dimensions.
– Quick quotation
– Easy to order
– Competitive delivery
Type of milling tool
ISO application area
Carbide grade
Center cutting
DC
TCDC
DCON
DN
APMX
LU
LF
RE
CHW
KCH
ZEFP
FHA
Mounting type
A, B
P, M, K, N, S, H
H10F, GC1620, GC1630
Y = Yes
Cutting diameter — 2–20 mm (.079–.787 inch)
Cutting diameter tolerance — ≥IT8 ≤IT11
Shank diameter — 2–20 mm (.079–.787 inch)
Neck diameter — Depending on tool design
Maximum cutting length — 0.5–5.0 × DC
Usable length — Depending on tool design
Overall length — 38–200 mm (1.496–7.874 inch)
Corner radius — ≤0.4 × DC
Chamfer width — ≤0.3 mm (.012 inch)
Chamfer angle — 40–50 degrees
Number of cutting edges — 2–4
Helix angle — 30º–45º
Cylindrical shank — CYL
Weldon — WEL
Main milling applications
Full slot
Options
Note For specific details regarding the options, contact your
Sandvik Coromant sales representative.
CoroMill® Plura Flexible: Multi-material
Intermediate Finishing/super finishing Profiling
Type of milling tool
Type of
milling tool
A, B
Ð
≥IT8 ≤IT11
H10F, GC1620, GC1630, GC1640, GC1720, GC1730, GC1740
2–4
30º
–
45º
P, M, K, N, S, H
0.5–5.0
×
DC
≤0.4 × DC
≤0.3 mm (.012 Zoll)
Form No. C-1150:144-ENG
Family code = M260
CoroPak 15.2 15.10.01 Revised 15.10.01
The value/choice must be given
If no value/choice is specified, it will be
recommended by the system
ISO application area
Type of milling tool
Reference standard product
Maximum cutting length APMX
Cutting diameter DC
Chamfer angle
State only your options
Number of cutting edges ZEFP
Helix angle FHA
Cutting diameter tolerance TCDC
Shank diameter DCON
Neck diameter DN
Carbide grade
Chamfer width CHW
Center cutting
Y = Yes
Usable length LU
Overall length LF
Corner radius RE
Mounting type
Cylindrical shank = CYL, Weldon = WEL
Customer Customer No. (Coromant internal) Date
Street
Post Code/City/State
Quantity
Telephone
Telefax
Customer attention
Issuer
CoroMill® Plura
Flexible: Multi-material
Inquiry/ordering No.
Customer denomination
Your value/
Your choice
Depends on the tool design
Depends on the tool design
40–50 degrees
2-20 mm (.079–.787 inch)
38–200 mm (1.496–7.874 inch)
2-20 mm (.079–.787 inch)
AB
DC
DN
DCON
APMX
LU
LF
FHA
RE/CHWxKCH DN
DCON
DC
APMX
LU
LF
FHA
AB
AA
Even more possibilities thanks to tailored design!
If you do not find what you need in our comprehensive standard
programme, choose the tool shape you require and we will tailor it
for you to your dimensions.
– Quick quotation
– Easy to order
– Competitive delivery
Form No. C-1050:114-ENG
Family code = M249, M261
CoroPak 15.2 15.10.01 Revised 15.10.01
Type of milling tool
ISO application area
Carbide grade
Center cutting
DC
TCDC
DCON
DN
APMX
LU
LF
RE
CHW
KCH
ZEFP
FHA
Mounting type
CBMD
A, B
P, M, K, N, S, H
H10F, GC1620, GC1630, GC1640, GC1720,
GC1730, GC1740
Y = Yes, N = No
Cutting diameter — 2–25 mm (.079–.984 inch)
Cutting diameter tolerance — ≥IT8 ≤IT11
Shank diameter — 3–25 mm (.118–.984 inch)
Neck diameter — Depending on tool design
Maximum cutting length — 0.5–6.0 × DC
Usable length — Depending on tool design
Overall length — 38–200 mm (1.496–7.874 inch)
Corner radius — ≤0.4 × DC
Chamfer width — ≤0.2 × DC
Chamfer angle — 15–60 degrees
Number of cutting edges — 2–10
Helix angle — 0º–60º
Cylindrical shank — CYL
Weldon — WEL
iLock — iLock
Chip breaker - "None", "HF"
Main milling applications
Full slot
Options
Note For specific details regarding the options, contact your
Sandvik Coromant sales representative.
CoroMill® Plura Optimized: Material specific
Intermediate Finishing/super finishing Profiling
Type of milling tool
Type of
milling tool
A, B
Ð
≥IT8 ≤IT11
H10F, GC1620, GC1630, GC1640, GC1720, GC1730, GC1740
2–10
0º
–
60º
P, M, K, N, S, H
0.5–6.0
×
DC
≤0.4 × DC
≤0.2 × DC
ISO application area
Type of milling tool
Reference standard product
Maximum cutting length APMX
Cutting diameter DC
Chamfer angle
State only your options
Number of cutting edges ZEFP
Helix angle FHA
Cutting diameter tolerance TCDC
Shank diameter DCON
Neck diameter DN
Carbide grade
Chamfer width CHW
Center cutting
Y = Yes, N = No
Usable length LU
Overall length LF
Corner radius RE
Mounting type
CBMD
Cylindrical shank = CYL, Weldon = WEL, iLock = iLock
(Chip breaker manufacturers designation) - "None", "HF"
Form No. C-1050:114-ENG
Family code = M249, M261
CoroPak 15.2 15.10.01 Revised 15.10.01
The value/choice must be given
If no value/choice is specified, it will be
recommended by the system
Customer Customer No. (Coromant internal) Date
Street
Post Code/City/State
Quantity
Telephone
Telefax
Customer attention
Issuer
CoroMill® Plura
Optimized: Material specific
Inquiry/ordering No.
Customer denomination
Your value/
Your choice
Depends on the tool design
Depends on the tool design
15–60 degrees
3–25 mm (.118–.984 inch)
38–200 mm (1.496–7.874 inch)
2–25 mm (.079–.984 inch)
