U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

ABS USA

PS-851 A 1 1.375 3/4 BCFJF 11107939

PS-446 C 1 2.500 1-3/4 BCFJF 11116013

PS-267 C 1 2.750 2 BCFJF 11116014

PS-1679 C 1 3.125 2-1/4 BCFJF 11116015

PS-2116 C 3 3.875 3 BCFJF 11116016

A-C PUMP (Div. of ITT INDUSTRIES)

PS-150 B — — 1/2 BMF-F

PS-200 A 1 1.250 5/8 BMFJF Model C1 Close Coupled Pumps 52-104-969-803

Types: CR, DDH, DG, DGH, HH, HHS 52-104-969-813

R, RH, RHS, RS, WH 52-104-969-823

PS-507V- A 3 1.250 5/8 VCFKF I 52-115-403-801

P66

PS-642 B — — 5/8 BMF-F 52-105-071-801

PS-447V- B 8 — 5/8 VCFJF A/I 52-114-660-803

P66

PS-118 C 1 1.187 5/8 BCFJF

PS-359 C 1 1.250 5/8 BCFJF 52-104-945-804

PS-7689 C 1 1.250 5/8 QCFKF I 52-126-378-801

PS-735 D 3 1.250 5/8 BCDJF 52-104-945-805

PS-647 B — — 3/4 BMF-F

PS-358 C 1 1.375 3/4 BCFJF

PS-750 D 1 1.375 3/4 BCDJF

PS-703 D 1 1.500 7/8 BCDJF

PS-360 A 1 1.625 1 BCFJF 52-104-969-806

52-104-969-816

PS-357 C 1 1.625 1 BCFKF 52-113-094-802

PS-460 D 1 1.625 1 BCFKF 52-104-945-804

PS-754 E 1 1.625 1 BCFJF

PS-937 E — — 1 BCF-F 52-110-870-809

PS-557 E 3 1.625 1 BCFJF 52-104-870-809

PS-754V E 3 1.625 1 VCFJF 52-116-831-801

52-116-831-804

PS-276 T 1 1.625 1 BCFJF 52-105-275-808

PS-277 T 1 1.625 1 BCFKF 52-105-275-858

T9-1000 WT — — 1 TCF-F 316SS 52-108-896-803

PS-355 C 1 1.750 1-1/8 BCFKF 52-104-946-803

PS-348 C — — 1-1/8 BCF-F

PS-605 D11.750 1-1/8 BCFKF 52-104-945-803

PS-204 E 1 1.750 1-1/8 BCFJF SJH, Size 3 x 2-1/2, 2-1/2 x 2 08-216-526-001

PS-867 E 3 1.750 1-1/8 BCFKF 52-104-870-806

PS-185 C11.875 1-1/4 BCFJF 52-113-592-801

PS-2122 C 1 1.875 1-1/4 BCFJF 52-114-901-807

PS-756 C 1 1.875 1-1/4 BCFKF

PS-598 C 3 1.875 1-1/4 BCFKF

PS-466 C 1 2.000 1-1/4 BCFJF

PS-2230 C 3 2.000 1-1/4 BCFJF Series 2000

PS-1018 C32.000 1-1/4 BCFKF Series 2000 52-118-510-801

PS-1018- C 3 2.000 1-1/4 QCFKF I 52-126-211-801

EPR-P66

PS-2200 C32.000 1-1/4 VCFKF I 52-114-659-808

PS-1015 E — — 1-1/4 BCF-F 52-110-870-807

PS-361 E 1 1.875 1-1/4 BCFJF Model C16 with 215T & 52-104-609-817

Smaller Frame Motors 52-105-609-813

F2L-1, F2L-3, F2L-5 and F2L-6 52-114-605-805

PS-137 E 1 1.875 1-1/4 BCFKF 52-106-609-813

52-106-609-817

PS-108 E 1 1.875 1-1/4 NCPKP 52-105-383-807

PS-546 E 31.875 1-1/4 BCFJF 52-104-870-807

52-114-890-807

PS-2211 T 3 1.875 1-1/4 BCFJF 52-105-275-801

PS-177 C 1 2.000 1-3/8 BCFJF MAXEAL®-V 52-115-605-801

Sizes 6x4x12, 8x5x12, 8x6x12

PS-2134 C 1 2.000 1-3/8 BCFJF 52-121-998-801

NOTE:

A. MOUNTS ON SHAFT

I. ABRASION RESISTANT CARBON (P66)

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

I. ABRASION RESISTANT CARBON (P66)

A-C PUMP (Div. of ITT INDUSTRIES) (continued)

PS-210 C 1 2.000 1-3/8 BCFKF Custom V 52-114-713-801

PS-1667 C 1 2.000 1-3/8 BCFKF Series 8000 52-117-036-801

PS-1667- C 1 2.000 1-3/8 QCFKF I 52-126-489-801

EPR-P66

PS-210V- C 3 2.000 1-3/8 VCFKF I 52-114-659-801

P66

PS-4087 E — — 1-3/8 VCF-F 316SS 52-118-671-802

52-118-671-803

PS-354 E 1 2.000 1-3/8 BCFJF SS-HH, SS-DH, SS-L, SS-CH 52-111-322-801

PS-677 E 1 2.000 1-3/8 BCFKF 52-105-382-801

PS-677V E 3 2.000 1-3/8 VCFKF 52-118-679-801

T9-1375 WT — — 1-3/8 TCF-F 316SS 52-118-672-802

PS-758 C 1 2.125 1-1/2 BCFJF 52-112-870-801

PS-553 C 3 2.125 1-1/2 BCFKF 52-118-591-001

PS-382 D 1 2.125 1-1/2 BCFJF 52-104-945-801

52-104-945-806

PS-371 D 1 2.125 1-1/2 BCFKF 52-101-848-082

52-104-946-801

PS-314 E 3 2.000 1-1/2 BCFJF Type-SH 4 x 3 08-301-766-066-04

PS-316 E 3 2.000 1-1/2 BCFKF 4 x 2-1/2 SKH 08-301-766-020-36

PS-4088 E Bal. 3 2.000 1-1/2 QCFJF I 52-161-209-801

PS-238 C 1 2.375 1-5/8 BCFJF 52-110-870-811

52-114-043-805

PS-239 C 1 2.375 1-5/8 BCFKF 52-118-511-002

52-118-512-002

PS-2202 C 3 2.625 1-5/8 BCFJF Series 2000 52-119-056-802

PS-1019 C 3 2.625 1-5/8 BCFKF Series 2000 52-118-510-802

PS-2201 C 3 2.625 1-5/8 QCFKF I 52-126-211-802

PS-4288 C 3 2.625 1-5/8 QCFZF 52-126-874-801

PS-609 E 1 2.312 1-5/8 BCDJF Type-KSH 08-303-611-07-001

08-306-539-015-03

52-115-315-801

PS-281 R 3 2.375 1-5/8 BCDKF

PS-446 C 1 2.500 1-3/4 BCFJF MAXEAL®-V Series 5000 52-115-605-802

PS-2135 C 1 2.500 1-3/4 BCFJF 52-121-998-802

PS-1674 C 1 2.500 1-3/4 BCFKF Series 8000 52-117-036-802

PS-1674- C 1 2.500 1-3/4 QCFKF I 52-126-489-802

EPR-P66

PS-436V- C 3 2.500 1-3/4 VCFKF I 52-114-659-802

P66

PS-2109 E — — 1-3/4 BCF-F 52-110-870-802

PS-317 E 1 2.487 1-3/4 BCFJF 5 x 5 KSG 08-303-611-07-004

PS-205 E12.500 1-3/4 BCFJF MAXEAL VII®C16, C17S,F2-2 08-212-616-001

F2-5, F2-8, F2L-2, and F2L-4

PS-366 E 1 2.500 1-3/4 BCFKF 52-110-871-802

PS-535 E 3 2.500 1-3/4 BCFJF 52-104-870-802

52-122-588-806

52-104-870-802

PS-262 E 3 2.500 1-3/4 BCFKF 52-114-890-802

PS-1197 K 1 2.500 1-3/4 BCFKF

PS-1608 C 1 2.625 1-7/8 BCFKF 52-114-713-805

PS-2114 C32.625 1-7/8 BCFJF 52-122-693-805

52-127-471-805

PS-312- C 3 2.625 1-7/8 QCFKF I 52-126-488-801

EPR-P66

PS-2069 E 1 2.625 1-7/8 BCFJF 3 x 2 MM-2

PS-2070 E 1 2.625 1-7/8 BCFKF 3 x 2 MM-2 08-301-766-02-065

PS-2071 E 3 2.625 1-7/8 BCFJF 52-122-588-814

PS-7884 E Bal. 3 2.500 1-7/8 BCFKF 52-121-754-802

PS-318 K 1 2.625 1-7/8 BCFJF Models: NSW, NSWV 52-110-280-03-801

PS-1693 K 1 2.625 1-7/8 BCFKF 52-110-280-801

PS-7352 K 1 2.625 1-7/8 BCFKF 52-110-280-807

PS-1105 V 25 2.640 1-7/8 BMFJF Model F7N-2, 4 x 4 x 11

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

NOTE:

I. ABRASION RESISTANT CARBON (P66)

A-C PUMP (Div. of ITT INDUSTRIES) (continued)

PS-2133 C 1 2.750 2 BCFJF 52-119-056-803

52-121-998-803

PS-267 C 1 2.750 2 BCFJF 52-122-693-807

PS-1017 C 1 2.750 2 BCFKF Series 8000 52-117-036-803

PS-1017- C 1 2.750 2 BCFZF 52-161-177-803

TC-SEAT

PS-3674 C 1 2.750 2 QCFKF I 52-126-489-803

PS-3580 C 1 2.750 2 QCFZF I 52-126-872-803

PS-1020 C 3 3.000 2 BCFKF Series 2000 52-118-510-803

PS-1020- C 3 3.000 2 QCFKF I Series 2000 52-126-211-803

EPR-P66

PS-2112 E — — 2 BCF-F 52-110-870-803

52-110-871-803

PS-2112V E — — 2 VCF-F 316SS 52-115-539-803

PS-319 E 1 2.687 2 BCFJF MAXEAL®VII Series 2000 52-115-315-803

08-212-617-001

PS-478 E 1 2.687 2 BCFKF MAXEAL®VII and KS

PS-530 E 3 2.750 2 BCFJF 52-104-870-803

52-116-823-810

PS-477 E 3 2.750 2 BCFKF 52-123-692-801

PS-477V E 3 2.750 2 VCFKF 52-115-946-803

PS-477V- E 3 2.750 2 VCFZF 52-115-720-807

TC-SEAT

PS-1040 K 3 2.750 2 BCFKF 52-237-862-801

PS-7196V K 3 2.750 2 VCFJF 52-237-862-802

PS-1687 D 1 3.000 2-1/8 BCFKF 52-104-945-802

FA-3502 E — — 2-1/8 BCF-F 316SS 52-129-173-802

PS-327 E 3 3.000 2-1/8 BCFJF 52-129-172-801

PS-1678 C 3 3.125 2-1/4 BCFJF 52-122-693-804

PS-323 E 1 3.125 2-1/4 BCDJF CUSTOM Vll, KS, C17, 8 x 8 SH 08-216-036-001

PS-351 E 1 3.125 2-1/4 BCDKF 08-630-132-009

PS-849 E 3 3.125 2-1/4 BCDKF 52-104-870-804

PS-1688 E 3 3.125 2-1/4 BCFJF 52-122-588-808

PS-351V E 3 3.125 2-1/4 VCDKF 52-114-660-804

PS-279 E 3 3.375 2-1/2 BCFJF Model F2-6

PS-349 E 3 3.375 2-1/2 BCFKF 52-104-870-805

PS-349V E 3 3.375 2-1/2 VCFKF 52-115-946-804

PS-836 C33.500 2-3/4 BCFJF 52-122-693-806

PS-483 C 3 3.500 2-3/4 BCFKF 52-114-713-804

PS-483- C 3 3.500 2-3/4 QCFKF I 52-126-488-803

EPR-P66

PS-838 E 3 3.500 2-3/4 V/BCFJF 08-210-902-045

52-114-890-810

52-115-315-805

PS-321 E 3 3.500 2-3/4 V/BCFKF CUSTOM Vll 08-216-035-001

52-104-870-808

PS-321V E33.500 2-3/4 VCFKF 52-114-660-805

PS-7936 E 3 3.500 2-3/4 VCFZF 316SS 52-121-756-805

PS-322 K 3 3.500 2-3/4 BCFKF NSWG, NSWV, Series 300 52-109-719-802

PS-324 E33.875 3 BCDJF 12 x 12 SD 08-210-902-04-037

PS-2141 K 3 3.875 3 BCFKF 52-237-805-801

PS-2141- K 3 3.875 3 BLFLF 52-237-805-808

SC-SC

PS-6228 K 3 3.875 3 VCFJF 52-237-805-803

PS-7244 K 3 4.125 3-1/4 BCFKF 52-237-806-801

PS-4113 T 3 4.375 3-1/2 BCFKF 52-115-082-801

PS-8028 X 3 4.750 3-7/8 VCFKF I 08-217-897-801

PS-2140 K 3 6.000 5 BCFKF 52-115-055-801

52-238-383-801

ACE ENGINEERING

PS-633 C 1 1.250 5/8 BCFKF 1743-2CS

PS-112 C 1 1.375 3/4 BCFKF 2043-3CS

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

ACE PUMP CORP.

PS-100 A 1 1.187 5/8 BMFJF ACH-25, 33, 50, 75, 100, ACL-75

ACO & BCH-25, 33, 50, 75

PS-953 A 1 1.187 5/8 BCFJF 30210F

PS-447V B 8 — 5/8 VCFJF A 80040F, ECL-7SG

PS-4114 B 8 1.109 5/8 Special Z-ECL-7V

PS-202 B 11 — 5/8 BMFJF A BAC-7B / 40110

PS-202V B 11 — 5/8 VCFJF A BAC-7V-40151F

BAC-7VC

BAC-7VT-40150

PS-800 C 1 1.156 5/8 BMFJF H

PS-1016 C 1 1.187 5/8 N/BCFJF B

PS-1091 C 1 1.187 5/8 VCFJF 30240F

PS-102 D 1 1.250 5/8 BCDKF

PS-851 A 1 1.375 3/4 BCFJF ACH-150,200,300 & 500, ACX-H150 30220F

BCH-100, 200, 300

PS-752 D 1 1.375 3/4 BCDKF

PS-360 A 1 1.625 1 BCFJF BCH-300, 500, 750, 1000

Models 100S,133S, 150S, 175S

PS-360V- A 1 1.625 1 VCFJF 42120F, GE-7-V

CMS

PS-185V- C 1 1.875 1-1/4 VCFJF 30265F

CMS

PS-185V- C 1 1.875 1-1/4 VLFLF 30266F

SC-SC

PS-185V C 3 1.875 1-1/4 VCFJF BAC-7-750V,BAC-7-850V

ACURA SPASYSTEMS, INC.

PS-601 B1 1.375 3/4 BMFJF

Aquaheat, Aquaheat Plus,Magnaflow,1090-A

Magnaflow 56, Maverick, Supercharger,

Supercharger II

ADAMATION, INC.

PS-3401 Q 9 — 1 NMDKF A 75-7050-020

PS-758 C 1 2.125 1-1/2 BCFJF 55-6301-364-6193

ADVANCED PROCESS TECHNOLOGY, INC.

PS-112V C 3 1.375 3/4 VCFKF 90551

PS-756V C 3 1.875 1-1/4 VCFKF 90119

ADVANTAGE ENGINEERING, INC.

PS-552 C 3 1.250 5/8 BCFJF 6480000

PS-552- C 3 1.250 5/8 QCFJF I 6491000

EPR-P66

PS-633V- C 3 1.250 5/8 VCFKF I 6490000, 6495301

P66

PS-598- C 3 1.875 1-1/4 QCFKF 6495612

EPR

PS-553 C 3 2.125 1-1/2 BCFKF 6480000

PS-4361 C 3 2.500 1-3/4 BCFKF 6480005

AERMOTOR PUMPS

PS-100 A 1 1.187 5/8 BMFJF 17038

PS-200 A1 1.250 5/8 BMFJF SJ-45

PS-274 E 1 1.250 5/8 BCDJF

PS-487 E 1 1.250 5/8 BCDKF

PS-201 A 1 1.375 3/4 BMFJF SJ-47

PS-275 C11.375 3/4 BCFJF

AGCHEMICAL EQUIPMENT

PS-202V B 11 — 7/8 VCFKF A 000015

PS-360V- A 1 1.625 1 VCFJF GL-7V

CMS

PS-235 C 1 1.625 1 BCFJF BM-7274

PS-235V C 3 1.625 1 VCFJF 9MFP, 16PK, CC1-1/2, CC 2-3 BM-7274X

PUMP MANUFACTURERS’ CROSS-REFERENCE

NOTE:

A. MOUNTS ON SHAFT

B.TAPERED SPRING

H. SPRING HOLDER NOT INCLUDED

I. ABRASION RESISTANT CARBON (P66)

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

AG CHEMICAL EQUIPMENT (continued)

PS-756V C 3 1.875 1-1/4 VCFKF 703225

PS-3940 C 3 1.875 1-1/4 VRFLF 513745, 513747

PS-466 C 1 2.000 1-1/4 BCFJF BM-7275

PS-466V C 1 2.000 1-1/4 VCFJF BM-7275X

AIR-O-LATOR CORP.

PS-618 C 3 1.875 1-1/4 BCFJF 37SM-125CC

PS-598- C 3 1.875 1-1/4 BLFLF 37SM-125SC

SC-SC

PS-816 C 3 2.125 1-1/2 BCFJF 37SM-150CC

PS-553- C 3 2.125 1-1/2 BLFLF 37SM-150SC

SC-SC

PS-2217 C 3 2.125 1-1/2 BZFZF 37SM-150TC

PS-550 C 3 2.500 1-3/4 BCFJF 37SM-175CC

PS-436- C 3 2.500 1-3/4 BLFLF 37SM-175SC

SC-SC

PS-436- C 3 2.500 1-3/4 BZFZF 37SM-175TC

TC-TC

PS-532 C 3 2.750 2 BCFJF 37SM-200CC

ALCO

PS-832 D 3 2.750 2 BCDKF Models 244D and 539 2250033-2, 5250013-3

ALLIED PUMP CORP.

PS-507 A 1 1.250 5/8 BMFKF

ALLIS CHALMERS (See A-C PUMP)

AMERICAN DISH SERVICE

PS-162 A 1 1.000 1/2 BMFJF

AMERICAN MACHINE AND TOOL CO. (AMT)

PS-200 A 1 1.250 5/8 BMFJF MS-626V

PS-200V- A 1 1.250 5/8 VCFJF 1640-161-91

CMS

PS-642 B — — 5/8 BMF-F

PS-933V C— — 5/8 VCF-F 1646-005-0

PS-201 A 1 1.375 3/4 BMFJF MS-756-B

PS-348V C — — 1-1/8 VCF-F 1645-000-00

PS-356 C 1 1.750 1-1/8 BCFJF 287-15A/B

AMERICAN-MARSH PUMPS

PS-633V C 3 1.250 5/8 VCFKF 890031

PS-112V C 3 1.375 3/4 VCFKF 890004

PS-687V C31.500 7/8 VCFKF 890036

PS-185 C 1 1.875 1-1/4 BCFJF 10-1400-02

PS-756 C 1 1.875 1-1/4 BCFKF 890003

PS-2208 C1 1.875 1-1/4 BZFZF 10-1400-02S4

PS-185V- C 1 1.875 1-1/4 VCFJF 800-011-869

CMS

PS-756V C 3 1.875 1-1/4 VCFKF 890044

PS-758 C 1 2.125 1-1/2 BCFJF 10-1401-01

PS-446 C 1 2.500 1-3/4 BCFJF 10-1402-00

PS-267 C12.750 2BCFJF 10-1403-09

PS-267V C 3 2.750 2 VCFJF 890023

AMERICAN PRODUCTS

PS-150 B — — 1/2 BMF-F

PS-1000 B 1 1.250 5/8 BMFJF Americana II®,Bronze-Bronze®397012

Eagle®Maxim, Power-Glass®,Ultra-Flo®397020

PS-201 A 1 1.375 3/4 BMFJF Americana®,Bronze-Noryl®395005

AMPCO PUMPS CO.

PS-359V- C 1 1.250 5/8 VCFJF GS625002

CMS

PS-633V- C 1 1.250 5/8 VCFKF GS625003

CMS

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

A. MOUNTS ON SHAFT

G. MOUNTS IN PLASTIC

I. ABRASION RESISTANT CARBON (P66)

AMPCO PUMPS CO. (continued)

PS-357 C 1 1.625 1 BCFKF GS5009976

PS-356V- C 1 1.750 1-1/8 VCFJF GS1125008

CMS

PS-7908 C 1 1.875 1-1/4 BCFJF 316SS/I GS4810341, GS5097400

PS-756 C 1 1.875 1-1/4 BCFKF GS5009974

PS-756- C 1 1.875 1-1/4 QCFKF GS8105960

EPR

PS-

2122V-

C 1 1.875 1-1/4 VCFJF GS8106850

CMS

PS-3543 C 1 2.375 1-5/8 VCFZF 316SS/I GS5098409

AMPRO-DIACLEAR

PS-163 B 1 1.000 1/2 BMFJF Dia Cast, Lexan®-200 Series AP-504D

PS-1000 B 1 1.250 5/8 BMFJF Dura-Flo®,Noryl®Turbo, XL 600 AP-304D

ANTHONY

PS-100 A 1 1.187 5/8 BMFJF 04547

PS-1000 B 1 1.250 5/8 BMFJF 04380

A.O. SMITH CORP.

PS-162 A 1 1.000 1/2 BMFJF 55831, 64135

PS-506 A 1 1.000 1/2 BMFKF 9708-1, 9708-4

PS-752 D 1 1.375 3/4 BCDKF

APOLLO DENTAL PRODUCTS, INC.

PS-218 A — — 5/8 BCF-F MMS71110

AQUA-CHEM

PS-358 C 1 1.375 3/4 BCFJF 925-7520

PS-235 C 1 1.625 1 BCFJF 925-7526

PS-251 E 3 1.625 1 BCFKF 925-7509

PS-618 C 3 1.875 1-1/4 BCFJF 925-7563

PS-177 C 1 2.000 1-3/8 BCFJF 925-7523

PS-2114 C 3 2.625 1-7/8 BCFJF 925-7562

AQUA-FLO

PS-2131 A 1 — 5/8 BMFJF G Flo-Master®,Tub-Master®91049000

PS-200 A 1 1.250 5/8 BMFJF Circ-Master®,Dominator®–High Head 92500150

Dominator®–Medium Head, Flo-Master®92500151

Pond-Flo, Tub-Master®

PS-200V- A 1 1.250 5/8 VCFJF 92500152

CMS

PS-642 B—— 5/8 BMF-F

PS-1021 B 8 — 5/8 BMFJF A K-81159 PU10

PS-1000 B 1 1.250 5/8 BMFJF A, B, and D-Series 92509040

A, C, and D-Series, Dominator®92500050

High and Medium head – pre 1995

PS-201 A 1 1.375 3/4 BMFJF

PS-309 C 1 1.500 7/8 BCFJF AC Series 92500000

PS-361 E 1 1.875 1-1/4 BCFJF

ARBEE CORP.

PS-235 C 1 1.625 1 BCFJF

PS-351 E 1 3.125 2-1/4 BCDKF

ARDE BARINCO, INC.

PS-3765 K13.000 2-1/8 VCFRF A63-18V

ARMSTRONG PUMPS, INC. (For Additional Listings - See Page 154)

PS-8066

XSpecial

1.864 1/4 QCFLF Gemini / 10 180200-277, 880200-277

PS-401A C 1.938 1/2 BCFJF 816549-091

PS-3844 C 1 .938 1/2 BCFJF 816706-001, 816706-002

816706-021, 916706-021

PS-392 C 1.938 1/2 B/QMFJF 816032-000

PS-3843 C 1 .938 1/2 VCFJF 116706-021,116706-023

816706-003, 816706-004

816706-023, 916706-023

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

ARMSTRONG PUMPS, INC. (continued) (For Additional Listings - See Page 154)

PS-359V- C 1 1.250 5/8 VCFJF 810134-000, 910134-000

CMS

PS-358V C 3 1.375 3/4 VCFJF 816707-001, 816707-002

PS-750- D 1 1.375 3/4 BCDJF I 116707-001

P66

PS-752 D 1 1.375 3/4 BCDKF

PS-750V- D 1 1.375 3/4 VCDJF I 116707-003, 116707-004

CMS-P66

PS-750V D 3 1.375 3/4 VCDJF 816707-003

PS-8006 XB2 27 2.375 1-1/8 VCFJF 316SS 975002-003

PS-3029 C 1 1.750 1-1/4 BCFJF B 975000-958

PS-979 C 1 1.750 1-1/4 BCFKF B

PS-185- C 1 1.875 1-1/4 QCFJF I 975000-991

EPR-P66

PS-618- C 3 1.875 1-1/4 QCFJF I 810150-125

EPR-P66

PS-2203 C 3 1.875 1-1/4 QCFKF I

PS-3023 D 1 1.875 1-1/4 QCFLF I 975000-981, 975000-982

9975000-981

PS-976 D 1 1.750 1-1/4 BCFJF 825458-001

PS-977 D 1 1.750 1-1/4 BCFKF

PS-517 D 3 1.875 1-1/4 BCFKF 810150-137

PS-517- D 3 1.875 1-1/4 BCFZF 810150-133

TC-SEAT

PS-383V D 3 1.875 1-1/4 VCFKF 810150-127

PS-3030 C 1 2.375 1-5/8 QCFJF I 975000-993

PS-7017 C 3 2.375 1-5/8 QCFKF I 975000-961

PS-514 D 1 2.375 1-5/8 BCDJF

PS-461 D 1 2.375 1-5/8 BCDKF

PS-3025 D 1 2.375 1-5/8 QCFLF I 975000-983, 975000-984

9975000-983

PS-8040 XB2 27 2.843 1-5/8 VCFJF 316SS 975000-956, 975002-033

PS-205 E 1 2.500 1-3/4 BCFJF 425920-001

PS-338- C 3 3.000 2-1/8 QCFJF 975000-997, 9975000-997

EPR

PS-543V C 3 3.000 2-1/8 VCFKF D101166-108

PS-3035 D 1 3.000 2-1/8 QCFLF I 975000-987, 975000-985

9975000-987

PS-8035 XB2 27 3.375 2-1/8 VCFJF 316SS 975000-957, 975002-073

PS-853 C 3 3.375 2-1/2 BCFKF E Model 4600 12x10x12.5 D101166-010

ARNESON PRODUCTS, INC.

PS-200 A 1 1.250 5/8 BMFJF Pool Sweep A-8

ASTRAL POOL

PS-200 A 1 1.250 5/8 BMFJF Sena Series 1800

PS-1000 B 1 1.250 5/8 BMFJF Sena Series 1600

ATLANTIC FLUIDICS (Div. of TUTHILL VACUUM SYSTEMS)

PS-1000 B 1 1.250 5/8 BMFJF

PS-601 B 1 1.375 3/4 BMFJF

PS-356 C 1 1.750 1-1/8 BCFJF

PS-185 C 1 1.875 1-1/4 BCFJF

PS-177 C 1 2.000 1-3/8 BCFJF

AURORA PUMP (For Replacement Seal Kits - See Page 144)

PS-7520 C 1 1.250

.590 (15MM)

VCFKF I 712-6444-749

PS-129 D 1 1.250

.590 (15MM)

BCFJF #4 Series Pump 712-0703-754

PS-1675 D 1 1.250

.590 (15MM)

BCFKF 14AS114ABF 712-0703-752

PS-100 A 11.187 5/8 BMFJF 712-7042-750

PS-2204 A 1 1.250 5/8 VCFZF 712-2042-767

PS-290 C 1 1.250 5/8 BCFJF BJ, BJH, BJV, 712-1003-753

BJF w/Motors thru 3/4 HP 1750 RPM

Thru 1-1/2 HP 3500 RPM

PS-633 C 1 1.250 5/8 BCFKF 712-1003-749

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

B.TAPERED SPRING

E. LOCK COLLAR SOLD SEPARATELY

I. ABRASION RESISTANT CARBON (P66)

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

AURORA PUMP (continued) (For Replacement Seal Kits - See Page 144)

PS-358 C 1 1.375 3/4 BCFJF BJ, BJH, BJV,

BJF W/Motors 1HP 1750 RPM Up

2HP 3500 RPM Up.

Types: GAPB, GAHA, GAFA, GAVA

Models: GA-4, 5, 6, 7 and 9.

PS-2229 C 1 1.375 3/4 BCFKF 712-1004-749

PS-7843 C 1 1.375 3/4 VCFJF 712-1004-764

712-1004-769A

PS-2229V- C 1 1.375 3/4 VCFKF I 712-1004-745

P66

PS-752 D 1 1.375 3/4 BCDKF 712-0705-755

PS-135 D 1 1.500

.787 (20MM)

BCDJF #5 Series Turbine Pump 712-0707-752

712-0707-754

PS-614 D 1 1.500

.787 (20MM)

BCDKF 712-0707-755

PS-3900 D 1 1.625 1 BCDKF I 712-6452-755

PS-380 D 1 1.625 1 BCFJF 712-0709-754

PS-460- D 1 1.625 1 BCFKF I 712-0709-755

P66

PS-356 C 1 1.750 1-1/8 BCFJF

BC, BCH, BCV, BCF

712-0907-753

and GBH w/Frames 56 thru 256U.

Type: GBHA & GBVAw/Mtr. Frs. 143T, 145T,

182T & 184T. Type: GBPA w/Power Frame 1.

Type OJ Power Series, 2 x 2 1/2 x 9-10-12

PS-355- C 1 1.750 1-1/8 BCFKF I 712-0907-749

P66

PS-7325

C 1 1.750 1-1/8 QCFZF 712-0907-769

PS-356V- C 1 1.750 1-1/8 VCFJF 712-0907-764

CMS

PS-355V- C 1 1.750 1-1/8 VCFKF 712-0907-745

CMS

PS-801 C 3 1.750 1-1/8 BCFJF 712-2732-753

PS-2226 C 3 1.750 1-1/8 QCFZF I 712-0937-769

PS-384 E 1 1.750 1-1/8 BCFKF 712-0454-749

PS-867 E 3 1.750 1-1/8 BCFKF 712-0354-756

PS-136 D 1 1.875

1.181 (30MM)

BCDJF #6 Series Turbine Pump 712-0713-754

PS-1179- D 1 1.875

1.181 (30MM)

BCDKF I 712-0713-755

P66

PS-1179V- D 1 1.875

1.181 (30MM)

VCDKF I 712-0713-774

P66

PS-3938 D 1 1.875

1.181 (30MM)

VCFZF I 712-0713-727

PS-306 E11.875 1-3/16 BCDJF GGU, KCM, KCMF, KGG, KU, KUF 712-0305-754

PS-185 C 1 1.875 1-1/4 BCFJF 712-0908-753

PS-137 E 1 1.875 1-1/4 BCFKF GMC & GAC 712-0306-755

PS-758 C 1 2.125 1-1/2 BCFJF BC,BCH,BCV &GBH W/Motor Frame 712-1010-753

284U & Up.GBHA & GBVAW/Motor Frame

213T & Up.OJ Power Series #2.

PS-2232 C1 2.125 1-1/2 BCFKF I 712-0910-759

PS-2209 C 1 2.125 1-1/2 BZFZF 712-0910-678

PS-7632 C 1 2.125 1-1/2 QCFZF I 712-0910-769

PS-659V- C 1 2.125 1-1/2 VCFKF I 712-0910-745

CMS-P66

PS-7747 C 1 2.125 1-1/2 VCFZF I 712-0910-767

PS-553 C32.125 1-1/2 BCFKF 712-0940-749

PS-758V C 3 2.125 1-1/2 VCFJF 712-0910-764

PS-382 D12.125 1-1/2 BCFJF 712-0718-754

PS-305 E 1 2.125 1-1/2 BCFJF

PS-7933 E 1 2.125 1-1/2 QCFZF I 712-0409-769

PS-395 E 3 2.125 1-1/2 BCFJF 712-0459-753

PS-258 E 3 2.125 1-1/2 BCFKF 712-0359-753

712-0359-764

PS-7562 E 3 2.125 1-1/2 QCFZF I 712-0359-769

PS-4368 E 52.125 1-1/2 QCFZF I 712-1432-769

PS-664 E 3 2.375 1-9/16 BCDJF 712-0310-754

PS-446 C 1 2.500 1-3/4 BCFJF Type OJ Power Series #3 712-1012-753

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

I. ABRASION RESISTANT CARBON (P66)

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

I. ABRASION RESISTANT CARBON (P66)

AURORA PUMP (continued) (For Replacement Seal Kits - See Page 144)

PS-448- C 1 2.500 1-3/4 BCFKF I 712-1012-749

P66

PS-446V- C 1 2.500 1-3/4 VCFJF 712-1012-764

CMS

PS-4153 C 1 2.500 1-3/4 VCFJF 316SS

PS-448V- C 1 2.500 1-3/4 VLFLF 712-1012-576

SC-SC

PS-436- C 3 2.500 1-3/4 BCFKF I 712-1042-749

P66

PS-7035 C 3 2.500 1-3/4 QCFZF I 712-1042-769

PS-366- E 1 2.500 1-3/4 BCFKF I 712-0412-749

P66

PS-7736 E 1 2.500 1-3/4 QCFZF I 712-0412-769

712-0462-769

PS-366V- E 1 2.500 1-3/4 VCFKF I 712-0412-745

CMS-P66

PS-535 E 3 2.500 1-3/4 BCFJF 712-0462-753

PS-4429 E 5 2.500 1-3/4 BCFZF I 712-1433-747

PS-4372 E 5 2.500 1-3/4 QCFZF I 712-1433-769

PS-267 C 1 2.750 2 BCFJF Type OJ Power Series #4 712-1014-753

PS-842- C 1 2.750 2 BCFKF I 712-1014-749

P66

PS-2219 C 1 2.750 2 BZFZF 712-1014-678

PS-267V- C 1 2.750 2 VCFJF 712-1014-764

CMS

PS-842V- C 1 2.750 2 VCFKF I 712-1014-745

P66-CMS

PS-332 C 3 2.750 2 BCFKF 712-1044-749

PS-3708 E 1 2.750 2 BCFZF I 712-1434-747

PS-479V E 3 2.750 2 VCFJF

PS-1678 C 3 3.125 2-1/4 BCFJF

PS-7766 K 3 3.125 2-1/4 BCFJF 712-6478-753

PS-7060 K 3 3.281 2-1/4 BCFKF I 712-6410-749

PS-268- C 1 3.250 2-3/8 BCFJF 712-1017-753

CMS

PS-492- C 1 3.250 2-3/8 BCFKF I 712-0917-749

CMS-P66 712-2717-749

PS-268 C 3 3.250 2-3/8 BCFJF Type OJ Power Series #5 712-1047-753

PS-492 C33.250 2-3/8 BCFKF 712-1047-749

PS-492- C 3 3.250 2-3/8 BCFKF I 712-1017-749

P66

PS-268V C 3 3.250 2-3/8 VCFJF I 712-1047-764

PS-4006 E 1 3.250 2-3/8 BCFZF I 712-1435-747

PS-278 E 3 3.250 2-3/8 BCFJF 712-0467-753

PS-350 E 3 3.250 2-3/8 BCFKF 712-0462-756

712-0467-756

PS-278V E 3 3.250 2-3/8 VCFJF 712-0467-764

PS-269 C 3 3.375 2-1/2 BCFJF SPHER-Flo Series 4A-4B 712-1012-739

712-1048-753

PS-3924 E33.250 2-1/2 BCFJF 712-6390-756

PS-279 E 3 3.375 2-1/2 BCFJF 712-0468-753

PS-349 E 3 3.375 2-1/2 BCFKF 712-0468-756

PS-349- E 3 3.375 2-1/2 BCFKF I 712-0468-755

P66

PS-2205- E 3 3.375 2-1/2 QCFKF I

EPR

PS-1695 K 33.375 2-1/2 BCFKF 712-2743-749

PS-270 C 33.750 2-7/8 BCFJF Type OJ Power Series #6

PS-841- E 3 3.750 2-7/8 BCFKF I 712-0471-755

P66

PS-2116 C 3 3.875 3 BCFJF 712-7010-739

PS-3836 U 3 3.875 3 BCFJF 712-7038-753

PS-3553 T 3 4.781 3-5/8 BCFKF I 712-6415-749

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

B.TAPERED SPRING

H. SPRING HOLDER NOTINCLUDED

I. ABRASION RESISTANT CARBON (P66)

AURORA PUMP (continued) (For Replacement Seal Kits - See Page 144)

PS-8054 V 3 4.781 3-5/8 BCFKF I 712-6416-749

PS-272 C 3 4.625 3-3/4 BCFJF 5C, 5D

PS-4414 V 3 6.781 5 BCFKF 712-6421-749

AUTOMATIC ICE & BEVERAGE

PS-6312 Q Special 1.625 1 BMD/PAP 9121026-91

BAKER-HYDRO (Div. of WATERCO USA)

PS-200 A 1 1.250 5/8 BMFJF 35B1178

PS-3985 B 1 1.375 3/4 BCFJF 634016

BAKER MFG. CO.

PS-1050 C — — 1/2 BCF-F E93B

PS-1050V C — — 1/2 VCF-F E93V

PS-933V C — — 5/8 VCF-F

PS-732 C 3 1.250 5/8 BCFKF F18AM, F18 AMP

PS-208 C — — 7/8 BCF-F H93B

PS-617 C 3 1.500 7/8 BCFKF H18AM, H18AMP

PS-309V C 3 1.500 7/8 VCFJF H18FMV

PS-687V C 3 1.500 7/8 VCFKF H18BMV, H18BMVF

H18BMVP

PS-4318 D 3 1.500 7/8 NCFLF H18MNN

BALDWIN-LIMA-HAMILTON (PATERSON PUMP CO.)

PS-371 D 1 2.125 1-1/2 BCFKF 600-28-267

PS-288 D 1 2.500 1-3/4 BCDKF 600-28-284

BALTIMORE AIRCOIL CO.

PS-299 A — — 5/8 BMF-F 300329

PS-974 A — — 3/4 BCF-F 300331

BALZER, INC.

PS-618 C 3 1.875 1-1/4 BCFJF 33013

PS-598- C 3 1.875 1-1/4 BLFLF 36755

SC-SC

BANJO CORP.

PS-3985 B 1 1.375 3/4 BCFJF 12713BN, 12733BN

PS-4056 B1 1.375 3/4 QCFJF 12713, 12733

PS-3986 B 1 1.375 3/4 VCFJF 12713V,12733V

PS-601V B 3 1.375 3/4 VCFJF 127135

PS-3785 C 1 1.625 1 VCFJF 17035, 17135

PS-3959 K 1 1.625 1 VCFJF 17235

PS-3813 C 1 2.125 1-1/2 VCFJF B/H 18025, 18125

BARNARD-LEAS MFG.

PS-200V A 3 1.250 5/8 VCFJF 5-0-17

BARNES, JOHN S.

PS-400 C — — 1/2 BMF-F PA-4947

PS-933 C——5/8 BCF-F PA-2408

PS-508 D 1 1.250 5/8 BCDJF 5080

PS-358 C 1 1.375 3/4 BCFJF 3SE2042L 67562

PS-578 D — — 7/8 BCD-F PA-2421

PS-397 C — — 1 BCF-F PA-1525

PS-348 C——1-1/8 BCF-F PA-4386

PS-383 D1 1.875 1-1/4 BCFKF Y-42

PS-461 D 1 2.375 1-5/8 BCDKF Y-45

PS-223 D — — 1-7/8 BCD-F PA-3684

BEACH RUSS

PS-400 C — — 1/2 BMF-F

PS-678 K — — 5/8 BCF-F

PS-564 C ——3/4 BCF-F

PS-145 K —— 3/4 BCF-F

PS-141 R — — 1 BCF-F

PS-185 C 1 1.875 1-1/4 BCFJF

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

B.TAPERED SPRING

I. ABRASION RESISTANT CARBON (P66)

BELL & GOSSETT (Div. of ITT CORP.) (For Additional Listings - See Page 154)

PS-8066 Special 1 .864 1/4 QCFLF 189144

PS-400A — 1 .938 1/2 B - - J - 118619

PS-401 C — — 1/2 BCF-F 118614

PS-400 C — — 1/2 BMF-F Cast Iron 3/4 thru 3 PZ-3118, 118680

Booster Pumps Type: E and H1 PZ-4118

Type: E1, 1-1/4, 1-1/2HV

PS-401A C 1 .938 1/2 BCFJF For PD-35, PD-37 Series 1522 Kit #3, 186681

PS-393 C 1 .938 1/2 BMFKF

PS-392 C 1 .938 1/2 B/QMFJF Bronze 3/4 thru 3 Boosters BPD 35, Kit #7,189102, 189182

BPD 37-Series 1522-PD 35 & PD 37 Kit 118681, 3TC29

-Series 60AA 1522 Cast Iron 200AB-F58

PS-7712 C 1 1.125 1/2 BMFJF Kit #20

PS-4349 G 1 .938 1/2 QLFLF P86261

PS-516 A 1 1.250 5/8 BCFJF DP0304

PS-200 A 1 1.250 5/8 BMFJF 180013

PS-118 C 1 1.187 5/8 BCFJF 186879

PS-359 C 1 1.250 5/8 BCFJF 180014

PS-2160 C 1 1.250 5/8 BCFJF DP0302

PS-399 D — — 3/4 BCD-F PW2Z-3188

P-18008-0601

PS-437 D 1 1.275 3/4 BCDJF 1512-PD-39, BPD-39 and 60A Kit #2, 172553, 185260

186433, 186499

PS-4024 G 1 1.275 3/4 QLFLF P86262

PS-309 C 1 1.500 7/8 BCFJF DP0294

PS-397 C — — 1 BCF-F

PS-235 C 1 1.625 1 BCFJF 180011, 650PF

PS-398 D — — 1 BCF-F PW1Z-4118

PS-348 C — — 1-1/8 BCF-F Universal Straight thru M Type PHD-118A

PS-356 C 1 1.750 1-1/8 BCFJF 180017

PS-3712 D 3 1.750 1-1/8 VCFZF I DP0-476

PS-384 E 1 1.750 1-1/8 BCFKF

PS-978 C 1 1.750 1-1/4 BCFJF B All Iron-Series 1510, 1515, 1531 Kit #4 & 10

(Small Frame) Types M1 and M2 186692,186860, 186862

PS-979 C 1 1.750 1-1/4 BCFKF B Kit #4 & 10

PS-978- C 1 1.750 1-1/4 QCFLF B P75423

EPR-SC

PS-978- C 1 1.750 1-1/4 QCFZF B 186861

EPR-TC

PS-4204 C 1 1.750 1-1/4 QRFLF

PS-978V C 1 1.750 1-1/4 VCFJF B 185060

PS-185- C 1 1.875 1-1/4 BCFJF I P70511

P66

PS-185V- C 1 1.875 1-1/4 VCFJF P70513, 186877

CMS

PS-416 D — — 1-1/4 BCF-F

PS-976 D 1 1.750 1-1/4 BCFJF Series 1510, 1515, 1531 Universal Kit #1, 186680, 185011

(Small Frame) Types M1 and M2

PS-977 D11.750 1-1/4 BCFKF

PS-6261 G 1 1.875 1-1/4 QCFJF 316SS/I P75221

PS-6260 G 1 1.875 1-1/4 QCFZF 316SS/I P75223

PS-6264 G 1 1.875 1-1/4 VCFJF 316SS/I P75225

PS-177 C12.000 1-3/8 BCFJF 52-115-605-801 / DP0298

PS-172 C — — 1-3/8 BCF-F AC5228

PS-172- C — — 1-3/8 BCF-F I P63336

P66

PS-376- D — — 1-3/8 QCD-F I P63316

EPR-P66

PS-491 D 1 2.000 1-3/8 BCDJF 186827

PS-186 D 1 2.000 1-3/8 BCDKF VSC 4 x 4x 9-3/4, 5 x 5 x 9-3/4, P77084

5 x 5 x 12, 6 x 6 x 9-3/4

PS-7803 D 12.000 1-3/8 QCDZF I 186834

PS-186V D 1 2.000 1-3/8 VCDKF

PS-224 E 3 2.125 1-1/2 NCFKF

PS-238 C 1 2.375 1-5/8 BCFJF 186544

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

A. MOUNTS ON SHAFT

I. ABRASION RESISTANT CARBON (P66)

*** COMPLETE WITH MATING RING ADAPTOR

BELL & GOSSETT (Div. of ITT CORP.) (continued) (For Additional Listings - See Page 154)

PS-238- C 1 2.375 1-5/8 QCFJF

EPR

PS-4288 C 3 2.625 1-5/8 QCFZF AC3048

PS-514 D 1 2.375 1-5/8 BCDJF Series 1531, 1510 Universal Kit #8

(Large Frame) M2 and C 186543

PS-461 D 1 2.375 1-5/8 BCDKF Kit #8

PS-514- D 1 2.375 1-5/8 QCDZF I 185225

EPR-P66

PS-6262 G 1 2.375 1-5/8 QCFJF 316SS/I P75222

PS-6263 G 1 2.375 1-5/8 QCFZF 316SS/I P75224

PS-2108 C — — 1-3/4 BCF-F AC5229

PS-2108- C — — 1-3/4 BCF-F I P63337

P66

PS-550 C 3 2.500 1-3/4 BCFJF 52-112-693-802

PS-446V C 3 2.500 1-3/4 VCFJF F4992S

PS-237 D 1 2.500 1-3/4 BCDJF 186826

PS-288 D 1 2.500 1-3/4 BCDKF VSC 6 x 6 x 12, 8 x 8 x 10-1/2 &13 P77033

PS-7652 D 1 2.500 1-3/4 QCDZF I 186835

PS-2111 C — — 2 BCF-F AC0642, AC5230

PS-4345 C 3 3.000 2 BCFJF I P70517

PS-3027 C 3 3.000 2 QCFZF AC3049

PS-4357 G 25 2.750 2 QCFLF VSX P5001889

PS-3019 G 25 2.750 2 QLFLF 316SS P5001028

PS-3020 G 3 3.000 2-1/8 QCFJF 316SS P75396

PS-1676 C 3 3.125 2-1/4 BCFKF 52-118-949-802

PS-594 D 3 3.250 2-3/8 BCDKF VSC 10 x 10 x 13, 12 x 12 x 13 P81905

PS-834 D 3 3.250 2-3/8 BCDJF VSC 10 x 10 x 13, 12 x 12 x 13 186828

PS-3804 G 25 3.375 2-1/2 QCFLF VSX P5001891

PS-7909 D 3 3.375 2-5/8 BCFJF I P75572, 185377

PS-328- E 3 3.375 2-5/8 BCFJF I

P66

PS-838 E 3 3.500 2-3/4 V/BCFJF 52-122-588-813

PS-3802 G 3 3.875 3 QCFLF VSX-VSH 18 x 10 x 22A P5001893

PS-3793 G 3 4.375 3-1/2 QCFLF VSX-VSC 14 x 16 x 17 P5001895

BEMATEK SYSTEMS, INC.

PS-2111V C — — 2 VCF-F 20178-P2347

BENNETT PUMPS

PS-400 C—— 1/2 BMF-F 541-M-1003 541-M-1003

PS-157 C — — 3/4 BCF-F 541-M-1001 541-M-1001

BERKELEY (See PENTAIR, INC. for Additional Part Numbers)

PS-516 A 1 1.250 5/8 BCFJF S-20788, S-20789

S-20994

PS-200 A11.250 5/8 BMFJF New Style Mid-Jet S4 Models: HS, S-08019, S-20790

CIMPS, CIMPHS, CIXPS, CIXPRS,

C1-1/4MPS,B1-1/2APKS,D1-1/2MPKS

PS-202 B 11 — 5/8 BMFJF A BM-3081 Mid-Jet 49-53 S-05053, S-05645

B1MRS, B1MRHS, B1XRHS S-16844, S-20900

B1- 1/4MRS, B1-1/2MRS S-20996

PS-202V B11 — 5/8 VCFJF A S-18150

PS-3960 G11.250 5/8 BCFJF S-08019

PS-851 A 1 1.375 3/4 BCFJF S-20794, S-21961

PS-973 A 1 1.375 3/4 BCFKF S-22380

PS-201 A1 1.375 3/4 BMFJF New Style: C1-1/2TPLS, C2TPMS, S-05646, S-20791

C2-1/2TPMS,B1-1/2MQKS S-20792, S-21962

C2TPMS, C2-1/2TPMS, B1XQHS

B1-1/4MQS, B1-1/2MQS

PS-921 A 1 1.375 3/4 BMFKF S-20793, S-32280

PS-201V- A 1 1.375 3/4 VCFJF S-18662

CMS

PS-440 B 11 — 3/4 BMFJF A S-20997

PS-7618 B 11 1.375 3/4 BCFJF *** S-06405

PS-750 D 1 1.375 3/4 BCDJF Model 142MPKS, 1-1/2MQKS S-05647

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

A. MOUNTS ON SHAFT

BERKELEY (continued) (See PENTAIR, INC. for Additional Part Numbers)

PS-752 D 1 1.375 3/4 BCDKF S-20780

PS-2008 D 1 1.375 3/4 BCFJF S-20779

PS-360 A 1 1.625 1 BCFJF S-08742, S-09583

S-20795, S-20796

PS-460 D 1 1.625 1 BCFKF S-20781

PS-754 E 1 1.625 1 BCFJF S-14867, S-20763

PS-236 E 1 1.625 1 BCFKF S-20764, S-20765

PS-356 C 1 1.750 1-1/8 BCFJF S-32690

PS-2227 C 1 1.750 1-1/8 BCFJF S-32689

PS-604 D 1 1.750 1-1/8 BCFJF S-16812

PS-605 D 1 1.750 1-1/8 BCFKF S-20783

PS-204 E 1 1.750 1-1/8 BCFJF BZR, BZQ S-07216, S-20766

PS-384 E 1 1.750 1-1/8 BCFKF BZR, BZQ

S-20767, S-20768, S-20995

PS-185 C 1 1.875 1-1/4 BCFJF S-32014

PS-2122 C 1 1.875 1-1/4 BCFJF S-32013

PS-381 D 1 1.875 1-1/4 BCFJF Model 2TPKHS, 3TQKHS, 2TQKIS, S-05649, S-20784

3TQKHS, 22TQKHS, 2TRKHS S-20785

PS-383 D 1 1.875 1-1/4 BCFKF S-20786

PS-361 E 1 1.875 1-1/4 BCFJF All Models A Line Pump except 6YPH, S-05648

4EPBL & 6YP S-20770

PS-137 E 1 1.875 1-1/4 BCFKF

S-15368, S-20769

PS-1185 E 1 1.875 1-1/4 NCPJP S-20771

PS-883 K 1 1.875 1-1/4 BCFJF S-39485

PS-305 E 1 2.125 1-1/2 BCFJF Models 6YPH, 4EPBL, B1-1/2TQLS,S-05650

B2TQMS, 2-1/2TQMS, B3TQMS S-20774

PS-374 E 1 2.125 1-1/2 BCFKF S-15385

PS-258 E 3 2.125 1-1/2 BCFKF S-20773, S-20775

PS-374V E 3 2.125 1-1/2 VCFKF S-15538

PS-821 D 3 2.375 1-5/8 BCDJF S-16656

PS-446 C 1 2.500 1-3/4 BCFJF S-32015

PS-2142 C 1 2.500 1-3/4 BCFJF S-32692

PS-237 D 1 2.500 1-3/4 BCDJF S-16768

PS-288 D 1 2.500 1-3/4 BCDKF

PS-205 E 1 2.500 1-3/4 BCFJF A Line Pump, Model B3TPMS S-07277, S-20776, S-20777

PS-366 E 1 2.500 1-3/4 BCFKF

PS-593 D 3 2.625 1-7/8 BCDKF S-20787, S-20993

PS-2069 E 1 2.625 1-7/8 BCFJF S-15213, S-20778

S-32693, S-32694

PS-2072 E32.625 1-7/8 BCFKF S-20884

PS-479 E 1 2.750 2 BCFJF S-13481

PS-338 C3 3.000 2-1/8 BCFJF S-32016

PS-537 E 1 3.000 2-1/8 BCFJF S-15894, S-15950

PS-353 E 1 3.000 2-1/8 BCFKF S-16076

PS-327 E 3 3.000 2-1/8 BCFJF S-17274

PS-835 D 3 3.375 2-1/2 BCDJF S-18337

PS-463 D 3 3.375 2-1/2 BCDKF S-30320

BLACKMER (DOVER CORP.)

PS-303 D1 1.500 7/8 BCDKF 333030

PS-9007 W Special 2.156 1 TCFJF 316SS 333102

PS-9338 W 27 1.812 1-1/16 TCFKF 331277

BLAKESLEE, INC.

PS-235V C 3 1.625 1 VCFJF PUMPAKS Models 30-010 thru 30-023 32-036

PS-3401 Q 9 — 1 NMDKF A 02255

BLUE, JOHN CO.

PS-879 K 1 1.625 1 BCFJF S-3565

BOWSER

PS-564 C — — 3/4 BCF-F 27A09

PS-466 C 12.000 1-1/4 BCFJF 28A09

BRADEN WINCH

PS-201 A 1 1.375 3/4 BMFJF

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

NOTE:

I. ABRASION RESISTANT CARBON (P66)

N. NON-STANDARD SPRING HOLDER

BSM PUMP CORP.

PS-181 C 20 Plate 5/8 NCPGP Models: 2S, 102 and 220, 225, 713-9020-270

240, 245 with 5/8" Shaft

PS-358 C 1 1.375 3/4 BCFJF 466-142-1

PS-182 C 20 Plate 3/4 NCPGP Models: 3S, 53, 55, 103 713-9030-270

PS-235 C 1 1.625 1 BCFJF 466-137-1

PS-185 C 1 1.875 1-1/4 BCFJF 213-744-274

PS-185- C 1 1.875 1-1/4 BCFJF I 466-292, 713-9245-270

P66

PS-185V- C 1 1.875 1-1/4 VCFJF 466-292-1

CMS

PS-186 D 1 2.000 1-3/8 BCDKF 466-143-1

PS-237 D 1 2.500 1-3/4 BCDJF 213-752-274

BUFFALO PUMPS

PS-290 C 1 1.250 5/8 BCFJF Models: BPL, BPM, BPO CC-10900

PS-235 C 1 1.625 1 BCFJF Models: BPL, BPM, BPO CC-10901

PS-384 E 1 1.750 1-1/8 BCFKF Model 1-1/2, 2 & 3SL,

1-1/2 & 2SA W/ Solid Shafts, 2-1/2SW

PS-137 E 1 1.875 1-1/4 BCFKF 1-1/2, 2 & 3SL, SA Sleeved 231-31-330

PS-354 E 1 2.000 1-3/8 BCFJF

PS-677 E 1 2.000 1-3/8 BCFKF

PS-2104 E — — 1-3/8 BCF-F 231-31-412

231-31-1012, 231-31-1573

PS-374 E 1 2.125 1-1/2 BCFKF 4SL, 3SA, 2RR, 284 Stage,

6SLH & 4HSM

PS-744 E 1 2.375 1-5/8 BCDKF 5SL, 4S, Large Frame 13564-6

PS-2070 E 1 2.625 1-7/8 BCFKF 6SL, 4RR, 6HSM, 2 Stage 13564-8

D1 Dbl. Suction, 4SL ExtraHeavy

PS-7869 E 1 2.625 1-7/8 QCFZF I 231-31-1150

231-31-1620

PS-279 E 3 3.375 2-1/2 BCFJF 231-31-1724

PS-349 E 3 3.375 2-1/2 BCFKF Model 8SL

PS-350 E 3 3.250 2-3/8 BCFKF D2 Dbl. Suction Pumps, 6S & 6SU

BURKS PUMPS (Div. of CRANE PUMPS & SYSTEMS)

PS-1002 C 1 1.000 1/2 BCFJF N 21727

PS-200 A 1 1.250 5/8 BMFJF 17038

PS-290 C11.250 5/8 BCFJF 8514 ,23846

PS-290V C 1 1.250 5/8 VCFJF 9652, 9676, 9762, 3CJSM

PS-2206 C 3 1.250 5/8 QCFKF 20764-C

PS-1156V C 1 1.250 5/8 VCFKF 20498-C

PS-201 A 1 1.375 3/4 BMFJF 17039

PS-358 C 1 1.375 3/4 BCFJF Series CS-Turbine Pump

PS-358V C 3 1.375 3/4 VCFJF 9813

PS-185 C 1 1.875 1-1/4 BCFJF 9917

PS-756- C 1 1.875 1-1/4 QCFKF 21271

EPR

PS-185V- C 1 1.875 1-1/4 VCFJF 9926

CMS

PS-598- C 3 1.875 1-1/4 QCFKF 23559

EPR

PS-381 D 1 1.875 1-1/4 BCFJF 33066-1-1/2

PS-4044 C 1 2.125 1-3/8 BCFJF

PS-238 C 1 2.375 1-5/8 BCFJF 21136

PS-238V-C1 2.375 1-5/8 VCFJF 21189

CMS

PS-1068 C 12.500 1-3/4 BCFKF M3842-C

BYRON JACKSON - (Div. of FLOWSERVE)

PS-775 D 3 1.500 7/8 BCDJF Series 400 D-30903

PS-428 R 1 1.500 7/8 BCDJF Series 400 D-30904

PS-2033 D 3 1.625 1 BCFJF Series 513 D-30433

PS-382 D 12.125 1-1/2 BCFJF

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

CAMAC INDUSTRIES

PS-358V- C 1 1.375 3/4 VCFJF Series 50

CMS

PS-883V- K 1 1.875 1-1/4 VCFJF 254

CMS

CAMERON COMPRESSION SYSTEMS

PS-185 C 1 1.875 1-1/4 BCFJF 2-01S-073-003

PS-805- C 3 2.000 1-3/8 BCFJF I Z109-500

P66

PS-239 C 1 2.375 1-5/8 BCFKF 2-01S-077-001

CARTER PUMPS, INC.

PS-100 A 1 1.187 5/8 BMFJF 1S-5010

PS-200 A 1 1.250 5/8 BMFJF 1S-5005A, 1S-5054

PS-290 C 1 1.250 5/8 BCFJF Humdinger Pump 1S-5023, 1S-5035

PS-201 A 1 1.375 3/4 BMFJF 1S-5039

PS-360 A 1 1.625 1 BCFJF 2S-5050, 2S-5089

2S-5054, 2S-5112

PS-383 D 1 1.875 1-1/4 BCFKF 2S-5116, 2S-5119

3S-5239

PS-186 D 1 2.000 1-3/8 BCDKF 4S-5106, 4S-5151

PS-553 C 3 2.125 1-1/2 BCFKF

PS-446 C 1 2.500 1-3/4 BCFJF 4S-5052

PS-147 D — — 1-3/4 BCD-F 4S-5052

PS-237 D 1 2.500 1-3/4 BCDJF 6S-5202

PS-288 D 1 2.500 1-3/4 BCDKF 5S-5029

CARVER PUMP CO.

PS-200 A 1 1.250 5/8 BMFJF B20-1, B1-2-1-1/4

PS-359 C 1 1.250 5/8 BCFJF BB20-1

PS-201 A 1 1.375 3/4 BMFJF K1/2, L20-11

PS-358 C 1 1.375 3/4 BCFJF Model T14C6

PS-188 E 1 1.500 7/8 BCFJF

PS-229 E 3 1.500 7/8 BCFKF 091-087-02-0212

PS-360 A 1 1.625 1 BCFJF KN-3LC

PS-356 C 1 1.750 1-1/8 BCFJF A300-810

PS-627 C 1 1.750 1-1/8 BCFJF B 26C6, 2-1/2YC7, 2YC7, 3YC9

PS-185 C 1 1.875 1-1/4 BCFJF K2L-20-9

PS-525 C 3 1.875 1-1/4 BCFKF B

PS-466 C 1 2.000 1-1/4 BCFJF 090-125-01-0101

PS-466V C1 2.000 1-1/4 VCFJF 090-125-01-0103

PS-4131 C 1 2.000 1-1/4 VCFJF 316SS 090-125-01-0114

PS-466V- C 1 2.000 1-1/4 VCFLF 090-125-01-0166

SC-SEAT

PS-381 D 1 1.875 1-1/4 BCFJF KN-2H-2L-3N

PS-264- E31.875 1-1/4 BCFKF I 090-125-02-0236

P66

PS-4049 E 3 1.875 1-1/4 VCFLF 316SS 090-125-02-1269

PS-681 U 1 1.875 1-1/4 BCD/FJF 1, 1-1/4, 1-1/2, 2, 3, 4L, 1-1/4,1-1/2, 2,

2-1/2, 3, 4LA,1LB, 1-1/4, 2, 2-1/2,

3,4H,1-1/4, 1-1/2, 2, 2-1/2, 3, 4HA

PS-186 D 1 2.000 1-3/8 BCDKF 4B, 4BB, 4GHB, 4GHC

PS-745 E 1 2.375 1-5/8 BCDJF 090-162-02-4608

PS-822 E 3 2.375 1-5/8 BCDKF

PS-1699- E3 2.375 1-5/8 BCFKF I 090-162-02-0236

P66

PS-1683V E 3 2.375 1-5/8 VCFJF 090-162-02-0203

PS-262- E 3 2.500 1-3/4 QCFKF I 090-175-02-0246

EPR-P66

PS-7252 E 1 2.625 1-3/4 BCFJF 090-175-01-0110

PS-2130 E 32.625 1-3/4 BCFJF

PS-4141 E 32.625 1-3/4 QCFZF I 090-175-01-0137

PS-4261 E 3 2.625 1-3/4 VCFJF 090-175-01-0114

PS-4228 E 3 2.625 1-3/4 VCFZF 316SS/I 090-175-01-0105

PS-8059 XBT 3 2.375 1-7/8 QCFZF 316SS/I 090-187-02-99AZ

PUMP MANUFACTURERS’ CROSS-REFERENCE

20 NOTE:

B.TAPERED SPRING

I. ABRASION RESISTANT CARBON (P66)

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

NOTE:

A. MOUNTS ON SHAFT

I. ABRASION RESISTANT CARBON (P66)

CARVER PUMP CO. (continued)

PS-8010 X Bal. 3 2.375 1-7/8 VCFZF 316SS/I 090-187-02-9958

PS-3522 E 3 2.750 2 BCFKF 316SS/I 090-200-02-0236

PS-477 E 3 2.750 2 BCFKF

PS-3999 E 3 2.750 2 VCFZF 316SS 091-200-02-1678

PS-353V E 3 3.000 2-1/8 VCFKF 090-212-02-0204

PS-3576 E 3 3.125 2-1/4 VCFJF 316SS/I 090-225-02-02EG

PS-2098V E 3 3.250 2-3/8 VCFKF 090-237-02-0204

CATERPILLAR

PS-642 B — — 5/8 BMF-F 4S-7805

PS-647 B — — 3/4 BMF-F 1N-9177

PS-235 C 1 1.625 1 BCFJF 6N-4743, 6N-9313

C-B TOOL CO. (LANCASTER PUMP DIVISION)

PS-150 B — — 1/2 BMF-F 4761

PS-200 A 1 1.250 5/8 BMFJF 2661

PS-201 A 1 1.375 3/4 BMFJF 1661

PS-357 C 1 1.625 1 BCFKF 4400 Series

CENTRAL SCIENTIFIC (CENCO) (HYVAC PRODS.)

PS-452 B 9 — 5/8 BMFJF A P-35332

PS-441 B 9 — 3/4 BMFKF A P-35334

PS-112 C 1 1.375 3/4 BCFKF

PS-1026 D 1 1.437 3/4 BCDKF P-35219

PS-547 C 3 2.000 1-3/8 BCFKF P-29538

CENTREX

PS-299 A — — 5/8 BMF-F

PS-360 A 1 1.625 1 BCFJF 201-491,201-493

CH&E MFG CO.

PS-516 A 1 1.250 5/8 BCFJF W105-7A

PS-200 A 1 1.250 5/8 BMFJF W105-7

PS-200V- A 1 1.250 5/8 VLFLF W105-7C

SC-SC

PS-851 A 1 1.375 3/4 BCFJF W105-1

PS-201V- A 1 1.375 3/4 VCFJF W105-1V

CMS

PS-1125- C 1 1.375 3/4 BLFLF W105-1D

SC-SC

PS-145 K — — 3/4 BCF-F W105-8

PS-7434 C 1 1.625 1 BCFJF W105-2

PS-380 D 1 1.625 1 BCFJF W105-10

PS-185- C 1 1.875 1-1/4 BLFLF W105-15A

SC-SC

PS-758 C 1 2.125 1-1/2 BCFJF W105-4

PS-758- C 1 2.125 1-1/2 BLFLF W105-4C

SC-SC

PS-541 K 1 2.125 1-1/2 BCFJF W105-6A

PS-541V- K 1 2.125 1-1/2 VCFJF W105-6AV

CMS

PS-432 R12.125 1-1/2 BCFKF W105-6

PS-449 K 1 2.500 1-3/4 BCFJF W105-11A

CHALLENGE MFG.

PS-642 B — — 5/8 BMF-F

PS-647 B——3/4 BMF-F

PS-235 C 1 1.625 1 BCFJF D-97

PS-357V C31.625 1 VCFKF D-98

PS-355 C 1 1.750 1-1/8 BCFKF E-97

PS-659 C 1 2.125 1-1/2 BCFKF H-97

PS-659V C 3 2.125 1-1/2 VCFKF H-98

CHAMPION INDUSTRIES

PS-200 A 1 1.250 5/8 BMFJF 106467

PS-447- B 8 — 5/8 QCFJF A/I 108426

EPR

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

22 NOTE:

H. SPRING HOLDER NOTINCLUDED

CHAMPION INDUSTRIES (continued)

PS-3100 Q — — 1 NMDKF Unitized 110276

PS-758 C 1 2.125 1-1/2 BCFJF 110611

CHEMINEER, INC. (Unit of ROBBINS & MYERS)

PS-238V C 3 2.375 1-5/8 VCFJF 472-00082

CHICAGO PUMP (Div. of YEOMANS CHICAGO CORP.)

PS-100 A 1 1.187 5/8 BMFJF 2665171

PS-200 A 1 1.250 5/8 BMFJF 2658090

PS-263 D 1 1.187 5/8 BCDKF 266910

PS-750 D 1 1.375 3/4 BCDJF 2655888, 2663071

PS-265 D 3 1.375 3/4 BCDKF 2675337

PS-250 D 3 1.500 7/8 BCDKF 2675339

PS-188 E 1 1.500 7/8 BCFJF 2657110, 2663072

PS-229 E 3 1.500 7/8 BCFKF 267338

PS-380 D 1 1.625 1 BCFJF 2613940, 2663369

PS-252 D 3 1.625 1 BCFKF 2675341

PS-754 E 1 1.625 1 BCFJF 2655887

PS-251 E 3 1.625 1 BCFKF 2675340

PS-604 D 1 1.750 1-1/8 BCFJF 2658071

PS-605 D 1 1.750 1-1/8 BCFKF 2655131

PS-254 D 3 1.750 1-1/8 BCFKF 2675344

PS-253 E 3 1.750 1-1/8 BCFKF 2675343

PS-306 E 1 1.875 1-3/16 BCDJF 2655886

PS-255 E 3 1.875 1-3/16 BCDKF 2675345

PS-361 E 1 1.875 1-1/4 BCFJF 2657093, 2663048

PS-256 E 3 1.875 1-1/4 BCFKF 2675347

PS-264 E 3 1.875 1-1/4 BCFKF 2675318

PS-354 E 1 2.000 1-3/8 BCFJF 2655089

PS-257 E 3 2.000 1-3/8 BCFKF 2675350 000

PS-258 E 3 2.125 1-1/2 BCFKF 2675351

PS-259 E 3 2.125 1-1/2 BCFKF 2675352 000

PS-868 T 1 2.125 1-1/2 BCFJF VPM-LLC4

PS-446 C 1 2.500 1-3/4 BCFJF 117185

PS-262 E 3 2.500 1-3/4 BCFKF VPM-LMC4 2675354

CLAYEQUIPMENT

PS-185 C 1 1.875 1-1/4 BCFJF 0-902718-0

PS-758 C 1 2.125 1-1/2 BCFJF 0-902719-0

CLAYTON MARK

PS-501 A 1 1.250 5/8 BMFJF 29304B

CLEARWATER INDUSTRIES

PS-163 B 1 1.000 1/2 BMFJF 516069

CLEAVER-BROOKS, INC.

PS-358 C 1 1.375 3/4 BCFJF 925-65

CLEVELAND GEAR CO.

PS-5082 C 1 1.750 1 BCFKF H Z1032N

PS-254 D31.750 1-1/8 BCFKF Z1028C

PS-326V D 3 1.937 1-1/4 VCFKF Reducer 70 Z1028D

PS-4363 D32.187 1-1/2 BCFGF Z1028E

PS-3026 D 3 2.437 1-5/8 BCDGF Z1028F

PS-333 D32.812 2 NCPGP Reducer 400 Z1028G

PS-335V D33.375 2-1/2 VCPGP Z1028H

PS-3713 D 3 4.000 3 NCPGP Z1028J

CLIMAX ENGINE

PS-299 A — — 5/8 BMF-F 125-101

PS-380 D 1 1.625 1 BCFJF

CLOW CORP. (YEOMANS CHICAGO CORP.)

PS-185 C 1 1.875 1-1/4 BCFJF C3-2-57

PS-2208 C 1 1.875 1-1/4 BZFZF C3-2-72

PS-756V- C 1 1.875 1-1/4 VCFKF C3-2-142

CMS

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

CLOW CORP. (YEOMANS CHICAGO CORP.) (continued)

PS-383V D 3 1.875 1-1/4 VCFKF C3-2-12

PS-883 K 1 1.875 1-1/4 BCFJF C3-2-82

PS-210V C 3 2.000 1-3/8 VCFKF C3-2-51

PS-758 C 1 2.125 1-1/2 BCFJF C3-2-73

PS-2209 C 1 2.125 1-1/2 BZFZF C3-2-58

PS-446 C 1 2.500 1-3/4 BCFJF C3-2-59

PS-2210 C 1 2.500 1-3/4 BCFZF C3-2-93

PS-436V C 3 2.500 1-3/4 VCFKF C3-2-100

PS-449 K 1 2.500 1-3/4 BCFJF C3-2-43

PS-267 C 1 2.750 2 BCFJF C3-2-60

PS-842- C 1 2.750 2 BCFZF C3-2-94

TC-SEAT

PS-1145 C 1 2.750 2 VCFKF C3-2-98

PS-2143 K 1 2.750 2 BCFJF C3-2-47

PS-7196 K 3 2.750 3 BCFJF

PS-3562 T 3 2.937 2-1/16 BCFKF C3-2-153

PS-844 C 1 3.000 2-1/8 BCFJF C3-2-83

PS-887 K 1 3.000 2-1/8 BCFJF C3-2-44

PS-1679 C 1 3.125 2-1/4 BCFJF C3-2-61

PS-1676V C 3 3.125 2-1/4 VCFKF C3-2-99

PS-2158 K 1 3.375 2-1/2 BCFJF C3-2-53

PS-3518 K 1 3.875 3 BCFJF C3-2-45

COLT-AUTOSAN

PS-754 E 1 1.625 1 BCFJF 97049

COLUMBIA

PS-142 B 1 1.000 1/2 BMFJF

COMPAIR LeROI

PS-299 A — — 5/8 BMF-F 125-101

PS-687V C 3 1.500 7/8 VCFKF 125-907

PS-598 C 3 1.875 1-1/4 BCFKF

PS-210V C 3 2.000 1-3/8 VCFKF Model No A204-1455 125-940

PS-467 C 1 2.125 1-3/8 BCFKF

PS-1062 C 3 2.125 1-3/8 VCFKF 125-188-2

PS-6002 D 3 3.375 2-5/8 VCFKF 125-848

PS-6155 C 2 3.500 2-3/4 VCFKF 125-711

CONSOLIDATED DIESEL ELECTRIC

PS-758 C 1 2.125 1-1/2 BCFJF 0338-0275

CONSTRUCTION MACHINE (See CRANE PUMPS & SYSTEMS)

CONTINENTAL PUMP

PS-290 C 1 1.250 5/8 BCFJF V8-15Q

PS-359 C 1 1.250 5/8 BCFJF V8-15A, U8-15Q

PS-359- C 1 1.250 5/8 QCFJF

EPR-CMS

PS-358 C 1 1.375 3/4 BCFJF U8-56QA/R

PS-358V- C 1 1.375 3/4 VCFJF U8-56F

CMS

COOPER ENERGY SERVICES (See CAMERON COMPRESSION SYSTEMS)

CORCORAN CO.

PS-358V C 3 1.375 3/4 VCFJF

CORKEN, INC.

PS-756V C 3 1.875 1-1/4 VCFKF 2994-XD

CORNELL PUMP CO.

PS-618 C 3 1.875 1-1/4 BCFJF A17161J-40, A17161P-40

PS-546 E 31.875 1-1/4 BCFJF A15002C-40, A15002E-40

A17161X-40

PS-264 E 3 1.875 1-1/4 BCFKF A15002B-40

PS-137V E 31.875 1-1/4 VCFKF A15002D-40

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

CORNELL PUMP CO. (continued)

PS-2211 T 3 1.875 1-1/4 BCFJF A15002H-40

PS-3607 T 3 1.875 1-1/4 NAFGF A15002I-40

PS-864 E 3 2.000 1-3/8 BCFJF A15003J-40

PS-821 D 3 2.375 1-5/8 BCDJF A15005H-40

PS-1697 D 3 2.375 1-5/8 BCFKF A17064M-40

PS-3772 D 3 2.375 1-5/8 VZFLF A17064X-40

PS-595 E 3 2.375 1-5/8 BCDJF A15005D-40

PS-822 E 3 2.375 1-5/8 BCDKF A15005C-40

PS-1683 E 3 2.375 1-5/8 BCFJF A15005A-40

PS-1699 E 3 2.375 1-5/8 BCFKF A15005Y-40

PS-1699V E 3 2.375 1-5/8 VCFKF A15005X-40

PS-550 C 3 2.500 1-3/4 BCFJF A15006F-40, A15006M-40

PS-436- C 3 2.500 1-3/4 BZFLF A15006J-40

TC-VS-SC

PS-532 C 3 2.750 2 BCFJF A15007J-40, A20777G-40

PS-833 D 3 2.750 2 BCDJF A15007D-40, A17264P-40

PS-2075 D 3 2.750 2 BCFJF A15007M-40

PS-530 E 3 2.750 2 BCFJF A15007B-40

PS-2143 K 1 2.750 2 BCFJF A15007J-40

PS-468 D 3 3.250 2-1/2 BCDJF A15008E-40

PS-463- D 3 3.375 2-1/2 BZFLF A17258W-40

TC-SC A205226U-40

PS-3888 D 3 3.375 2-1/2 VZFLF A16421D-40, A20526R-40

PS-279 E 3 3.375 2-1/2 BCFJF A15008A-40

PS-349V- E 3 3.375 2-1/2 VZFLF A20526F-40

TC-SC

PS-2158 K 1 3.375 2-1/2 BCFJF A15008R-40

PS-1613 K 3 3.375 2-1/2 BCFJF A15008R-40

PS-6219 D 3 3.875 3 BZFLF A169721-40

PS-4033 D 3 3.875 3 VZFLF A169720-40, A20564P-40

PS-324 E 3 3.875 3 BCDJF A15009A-40

PS-7873 K 3 3.875 3 BCFJF A15009G-40

CRANE-DEMING (Div. of CRANE PUMPS & SYSTEMS)

PS-1002 C 1 1.000 1/2 BCFJF N 58125

PS-106 C 1 1.000 1/2 BCFKF N 58216

PS-1002V C 1 1.000 1/2 VCFJF N 55716

PS-200 A 1 1.250 5/8 BMFJF Fig. 4910-63, 4357, 4358

PS-501 A 1 1.250 5/8 BMFJF Fig. 4910, 11, 12, 13 / 4963, 4966, 4967

PS-507 A 1 1.250 5/8 BMFKF

PS-200V- A 1 1.250 5/8 VCFJF 40861

CMS

PS-507V- A 1 1.250 5/8 VCFKF 8009530

CMS

PS-493 C 1 1.187 5/8 BCFKF 0006841, 0006876

PS-359 C11.250 5/8 BCFJF 34427

PS-633 C 1 1.250 5/8 BCFKF 0115515

PS-359V- C 1 1.250 5/8 VCFJF 0115835

CMS

PS-226 D 1 1.187 5/8 BCDKF 0006875, 0020444

PS-201 A 1 1.375 3/4 BMFJF Fig. 4910, 4911, 3305, 3352, 4352

PS-750 D 1 1.375 3/4 BCDJF

PS-208 C — — 7/8 BCF-F 6880

PS-687 C 1 1.500 7/8 BCFKF Fig. 4001 30877

PS-309V C31.500 7/8 VCFJF 84876

PS-687V C 3 1.500 7/8 VCFKF 84877

PS-790 D 1 1.437 7/8 BCDJF Fig. 4001, Dwg. 112-041

PS-703 D 1 1.500 7/8 BCDJF Fig. 4001, Dwg. 116-386 30876

PS-892 K 1 1.500 7/8 BCFJF Fig. 4001 0030894

PS-878 K 1 1.500 7/8 BCFKF Fig. 4001 30895

PS-428 R 1 1.500 7/8 BCDJF Fig. 4001, Dwg. 113-068

PS-2145 C 3 1.437 1 BCFJF 65187

PS-3755 C 3 1.437 1 VCFJF 75513

PS-235 C 1 1.625 1 BCFJF 30878

NOTE:

N. NON-STANDARD SPRING HOLDER

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

CRANE-DEMING (Div. of CRANE PUMPS & SYSTEMS) (continued)

PS-357 C 1 1.625 1 BCFKF Fig. 4011, Dwg. 115-313 30879

PS-460 D 1 1.625 1 BCFKF Fig. 4011

PS-879 K 1 1.625 1 BCFJF 30896

PS-891 K 1 1.625 1 BCFKF 30897

PS-141 R — — 1 BCF-F Fig. 3302-04 #2

PS-429 R 1 1.625 1 BCFJF 30896

PS-430 R 1 1.625 1 BCFKF 30897

PS-608 E 1 1.687 1-1/8 BCFKF Fig. 4012, Size 1A

PS-384 E 1 1.750 1-1/8 BCFKF 29177

PS-185 C 1 1.875 1-1/4 BCFJF 0030880, 0070713

PS-756 C 1 1.875 1-1/4 BCFKF 30881

PS-185V- C 1 1.875 1-1/4 VCFJF 0088458, 0088459

CMS

PS-598- C 3 1.875 1-1/4 BCFZF 8030880

TC SEAT

PS-756V C 3 1.875 1-1/4 VCFKF 84881

PS-381 D 1 1.875 1-1/4 BCFJF

PS-383 D 1 1.875 1-1/4 BCFKF 7180

PS-546 E 3 1.875 1-1/4 BCFJF Model: AVS 0078876, 0078879

PS-883 K 1 1.875 1-1/4 BCFJF 30898

PS-890 K 1 1.875 1-1/4 BCFKF 30899

PS-1187 T 1 1.875 1-1/4 BCFJF 45935

PS-186 D 1 2.000 1-3/8 BCDKF 30882

PS-209 K — — 1-3/8 BCF-F

PS-2234 E 3 2.062 1-7/16 BCFKF Models: 1523, 1535 36636

PS-758 C 1 2.125 1-1/2 BCFJF 30884

PS-659 C 1 2.125 1-1/2 BCFKF Fig. 4021HD 30885

PS-2209 C 1 2.125 1-1/2 BZFZF 8030885

PS-659V- C 1 2.125 1-1/2 VCFKF 84885

CMS

PS-382 D 1 2.125 1-1/2 BCFJF Fig. 4021HD

PS-541 K 1 2.125 1-1/2 BCFJF 0030900

PS-884 K 1 2.125 1-1/2 BCFKF 0030901

PS-431 R 1 2.125 1-1/2 BCFJF

PS-432 R 1 2.125 1-1/2 BCFKF

PS-238 C 1 2.375 1-5/8 BCFJF 0030886

PS-239 C 1 2.375 1-5/8 BCFKF 0030887

PS-238V- C1 2.375 1-5/8 VCFJF 106330

CMS

PS-239V- C 1 2.375 1-5/8 VCFKF 106331

CMS

PS-446 C 1 2.500 1-3/4 BCFJF Model 7360 0030888

PS-448 C 1 2.500 1-3/4 BCFKF 0030889

PS-2207 C 3 2.500 1-3/4 VCFZF 117779

PS-237 D 1 2.500 1-3/4 BCDJF

PS-535 E32.500 1-3/4 BCFJF Model 3065 0078882

PS-2109 E — — 1-3/4 BCF-F 0078877

PS-449 K12.500 1-3/4 BCFJF Fig.7182- Fig.4031 0030904

PS-213 R— — 1-3/4 BCD-F

PS-2144 T 3 2.500 1-3/4 BCFJF 45936

PS-340 C 1 2.625 1-7/8 BCFJF 46389

PS-1608 C 1 2.625 1-7/8 BCFKF 0046390

PS-312 C 3 2.625 1-7/8 BCFKF

PS-543 C 1 3.000 2-1/8 BCFKF 0030891, 425650999

PS-543V C33.000 2-1/8 VCFKF 119412

PS-353 E 1 3.000 2-1/8 BCFKF

PS-2086 E3 3.000 2-1/8 BCFKF

PS-2126 T 3 3.000 2-1/8 BCFJF 45937

PS-1679 C 1 3.125 2-1/4 BCFJF 0030892

PS-1676 C 3 3.125 2-1/4 BCFKF 0030893

PS-1676V C 3 3.125 2-1/4 VCFKF 75520

CRANE PUMPS & SYSTEMS

PS-3000 G 1 26MM 12MM BLFLF 112566B

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

CRANE PUMPS & SYSTEMS (continued)

PS-633- C 1 1.250 5/8 QCFKF 124476

EPR-CMS

PS-7547 C 1 1.250 5/8 VLFLF 005080SK

PS-732 C 3 1.250 5/8 BCFKF 21752

PS-5625 Special 1 1.250 5/8 QC-J- 23568

PS-3916 C 3 1.375 3/4 BCFJF 110395

PS-767 C 3 1.375 3/4 BCFJF 63599

PS-9339 W 2 1.375 3/4 TCFJF 316SS 21741

PS-8064 X 3 1.375 3/4 BLFLF 316SS 083459-A

PS-309 C 1 1.500 7/8 BCFJF M-3824-B, 30876

PS-687V- C 1 1.500 7/8 VCFKF 120941

CMS

PS-774 C 3 1.500 7/8 BCFJF 111131

PS-197 K — — 7/8 BCF-F M-3046

PS-8065 X 3 1.500 7/8 BLFLF 316SS 082827-A

PS-235 C 1 1.625 1 BCFJF M-4292-B

PS-357 C 1 1.625 1 BCFKF 5MPK, 6MFP, 9MFP, 16PK, M-4292-C

CC1-1/2-1-1/2, CC1-1/2-2

PS-2145 C 3 1.437 1 BCFJF 68157

PS-235V C 3 1.625 1 VCFJF M-4292-G, 7841-0

PS-604 D 1 1.750 1-1/8 BCFJF M-4274-C

PS-521 D 1 1.875 1-1/8 BCFKF

PS-4302 C 1 1.750 1-3/16 BCFJF 21942-P

PS-756 C 1 1.875 1-1/4 BCFKF 19146, 110697

PS-185V- C 1 1.875 1-1/4 VCFJF 23109

CMS

PS-185V- C 1 1.875 1-1/4 VCFZF 118359

TC-SEAT

PS-466 C 1 2.000 1-1/4 BCFJF M-3957-C

PS-598- C 3 1.875 1-1/4 BCFZF 121918

TC-SEAT

PS-756V C 3 1.875 1-1/4 VCFKF 20500-C, 84881

PS-1015 E — — 1-1/4 BCF-F 78876

PS-7323 K 1 1.875 1-1/4

BZ/CFZ/JF

60817

PS-467 C 1 2.125 1-3/8 BCFKF M-3983-C

PS-177V C 3 2.000 1-3/8 VCFJF 7842-0

PS-758 C 1 2.125 1-1/2 BCFJF 0030884, 070713

PS-2209 C 12.125 1-1/2 BZFZF 0030885A

PS-238 C 1 2.375 1-5/8 BCFJF 0030886

PS-7806 C 1 2.375 1-5/8 VLFLF 125579

PS-239V C 3 2.375 1-5/8 VCFKF 23150

PS-2212 C 1 2.500 1-3/4 BCFJF M-3842-F

PS-1068 C 1 2.500 1-3/4 BCFKF M-3842-C

PS-446- C 1 2.500 1-3/4 BZFZF 71559

TC-TC

PS-550 C32.500 1-3/4 BCFJF 125852

PS-4035

C/X Special

1 2.500 1-3/4 BCFJF M-9262

PS-213 R—— 1-3/4 BCD-F M-2653

PS-340 C1 2.625 1-7/8 BCFJF 46389

PS-1028 C 1 2.750 2 BCFKF M-4414-C

PS-2219 C 1 2.750 2 BZFZF 71560

PS-1145 C 3 2.750 2 VCFKF 0-536026-E

PS-7892 E Bal. 3 2.625 2 BCFKF 9054995

PS-7196 K 3 2.750 2 BCFJF 00103045

PS-543 C13.000 2-1/8 BCFKF 0030891

PS-1679 C 1 3.125 2-1/4 BCFJF 0030892

PS-468 D3 3.250 2-1/2 BCDJF M-4272-B

PS-6205 C 1 3.500 2-3/4 BCFJF 85980

PS-6908 C 1 3.500 2-3/4 BZFZF 85981

PS-2153- C 1 3.875 3 BCFJF 085983

CMS

CREPACO

PS-397 C — — 1 BCF-F 549S6407F

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

A. MOUNTS ON SHAFT

I. ABRASION RESISTANT CARBON (P66)

CREPACO (continued)

PS-397V C — — 1 VCF-F 549S6408F

PS-154 C — — 1-1/4 BCF-F 549S6407

PS-3730 C — — 1-3/8 NCF-F 549P122960

CUMMINS WAGNER

PS-1619 B 1 1.625 1 BCDJF 3089056

CURTIS

PS-605 D 1 1.750 1-1/8 BCFKF

PS-288 D 1 2.500 1-3/4 BCDKF RMB-414

DAKON

PS-150 B — — 1/2 BMF-F Seat is Impeller

DARLEY, W.S. & CO.

PS-4246 D 3 1.675 1-1/4 BCDLF 1841203

PS-448 C 1 2.500 1-3/4 BCFKF 1842300

DAYTON (See TEEL PUMP)

DEAN PUMP (Div. of MET-PRO CORP.)

PS-3589 E 5 1.625 1 VCFZF

DECATUR PUMP

PS-501 A 1 1.250 5/8 BMFJF 20888

PS-359 C 1 1.250 5/8 BCFJF

PS-290 C 1 1.250 5/8 BCFJF 8514

PS-290V C 1 1.250 5/8 VCFJF 9762

PS-750 D 1 1.375 3/4 BCDJF

PS-358 C 1 1.375 3/4 BCFJF 8991

PS-185 C 1 1.875 1-1/4 BCFJF 9917

PS-598- C 3 1.875 1-1/4 QCFKF 21271

EPR

PS-185V C 3 1.875 1-1/4 VCFJF 9926

DEFCO, INC.

PS-359V- C 1 1.250 5/8 VCFJF A2518

CMS

PS-360V- A 1 1.625 1 VCFJF

CMS

DeLAVAL (See IMO INDUSTRIES, INC.)

DELAVAN MFG. & CO.

PS-1061 A 1 1.250 9/16 VCFJF 34943

DELTA T SYSTEMS, INC.

PS-732- C 3 1.250 5/8 QCFKF I 108-00001-00

EPR-P66

PS-2167- C 1 1.437 7/8 QCFJF I 108-00006-00

EPR-P66

PS-2224 C 3 1.437 7/8 QCFKF I 108-00002-00

DEMING (See CRANE PUMPS & SYSTEMS)

DEMPSTER INDUSTRIES, LLC

PS-162 A 1 1.000 1/2 BMFJF

PS-200 A11.250 5/8 BMFJF 907-06030

PS-202 B11 — 5/8 BMFJF A

PS-441 B 9 — 3/4 BMFKF A Utility Pump 907-06001

PS-440 B 11 —3/4 BMFJF APrimo Jet®and Converto Jet 907-06006

PS-358 C 1 1.375 3/4 BCFJF 907-06043

PS-309 C 1 1.500 7/8 BCFJF 907-06033

PS-309V C 3 1.500 7/8 VCFJF 907-06034

PS-598 C 3 1.875 1-1/4 BCFKF 907-06035

PS-756V C 3 1.875 1-1/4 VCFKF 907-06046

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

A. MOUNTS ON SHAFT

DENISON HYDRAULICS (Parker Hannifin HPD)

PS-5108 C 2 1.562 3/4 VCFKF

PS-5138 C Plate 2.875 1-1/8 BCFGF 623-11278-0

PS-5676 C 2 2.187 1-3/8 B/VCFJF 316SS Old Design 623-00006-0

PS-5711 C 2 2.187 1-3/8 B/VCFKF 316SS New Design 623-00006-0

PS-5676V C 2 2.187 1-3/8 VCFJF 623-00006-5

PS-5074 C 3 2.000 1-3/8 BCFKF

PS-5720 C 2 2.125 1-1/2 BCFKF 623-00012-0

PS-5002 D 2 2.500 1-11/16 BCFKF 623-12260-0

PS-5194 D 2 2.500 1-11/16 VCFKF 623-12263-0

PS-5342 C 2 3.000 1-7/8 BCFJF Old Design 623-00016-0

PS-5712 C 2 3.000 1-7/8 B/VCFKF New Design 623-00016-0

PS-5679 C 2 3.000 1-7/8 QCFJF 623-00016-4

PS-5717 C 2 3.000 1-7/8 VCFJF 623-00016-5

PS-5011 C Plate 3.528 1-7/8 BCFGF 623-00002-0

PS-5721 C Plate Plate 1-7/8 VCFGF 623-00002-5

PS-5706 C 2 3.000 2-1/8 VCFKF 316SS 623-00015-5

PS-5005 D 2 3.000 2-3/16 BCFKF 623-12322-0

PS-5719 D 2 3.000 2-3/16 QCFKF 623-12330-0

PS-5024 D 2 3.000 2-3/16 VCFKF 623-12331-0

DETROIT HARVESTER HOWELL

PS-298 A — — 1/2 BMF-F 3-6

PS-299 A — — 5/8 BMF-F H,SM-F,PM,1/4HP,-New style replaces 4-6

old style eared carbon. Seat is Impeller

PS-100 A 1 1.187 5/8 BMFJF

DEUBLIN CO.

PS-397 C — — 1 BCF-F 954-211

DeVILBISS

PS-508 D 1 1.250 5/8 BCDJF QM-4507

PS-358 C 1 1.375 3/4 BCFJF QM-4509

PS-752 D 1 1.375 3/4 BCDKF QMW-4509

DIACLEAR

PS-142 B 1 1.000 1/2 BMFJF 36100

DISCFLO CORP.

PS-338V- C 3 3.000 2-1/8 VLFLF P-170-1000036

SC-SC

PS-3877 C 3 3.375 2-1/2 VLFLF P-170-1000035

DIXIE PUMP

PS-200 A 1 1.250 5/8 BMFJF

PS-201 A1 1.375 3/4 BMFJF

DOERR

PS-359 C 1 1.250 5/8 BCFJF

DOMESTIC PUMP (Div. of ITT CORP.)

PS-200 A 1 1.250 5/8 BMFJF 180013

PS-359 C 1 1.250 5/8 BCFJF 180014

PS-201 A 1 1.375 3/4 BMFJF

PS-358 C 1 1.375 3/4 BCFJF 180010

PS-360 A 1 1.625 1 BCFJF

PS-235 C 1 1.625 1 BCFJF 180011

PS-177 C 1 2.000 1-3/8 BCFJF 180015

DOUGHBOY INDUSTRIES (Div. of HOFFINGER INDUSTRIES)

PS-671 B 1 .875 3/8 BMFJF 306-1003

PS-200 A 1 1.250 5/8 BMFJF 306-1006

PS-1000 B 1 1.250 5/8 BMFJF 306-1002

PS-642 B — — 5/8 BMF-F 308-1264

PS-202 B 11 — 5/8 BMFJF A 306-1001

DOUGLAS MOTOR CORP.

PS-201 A 1 1.375 3/4 BMFJF 47406

PS-210 C 1 2.000 1-3/8 BCFKF 46154

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

A. MOUNTS ON SHAFT

I. ABRASION RESISTANT CARBON (P66)

N. NON-STANDARD SPRING HOLDER

DOWDELL CO., J.L. (DOWCO PUMP)

PS-202 B 11 — 5/8 BMFJF A D1101S-5/8

PS-440 B 11 — 3/4 BMFJF A D1101S-3/4

DRESSER INDUSTRIES (See COMPAIR LeROI)

PS-200 A 1 1.250 5/8 BMFJF 125-101/113-1

PS-618 C 3 1.875 1-1/4 BCFJF

PS-1062 C 3 2.125 1-3/8 VCFKF

PS-436V C 3 2.500 1-3/4 VCFKF 125-693-2

DRESSER RAND

PS-768 C 3 1.375 3/4 BCFKF SEL 244

PS-553 C 3 2.125 1-1/2 BCFKF W27658P2

PS-3931 E 2 2.312 1-5/8 BCDKF W35548P1

PS-3952

ESpecial

3 3.031 2 NCDKF 000-049-082

PS-611 E 3 2.812 2-1/8 BCFJF

PS-556 U 1 3.000 2-1/8 BCFKF 720025J1

PS-4172 E 3 3.875 3-7/8 VCFKF 316SS 050-825-201

DUFF-NORTON

PS-933 C — — 5/8 BCF-F 732015C

PS-185 C 1 1.875 1-1/4 BCFJF 464901C

DUNHAM, C.A.

PS-508 D 1 1.250 5/8 BCDJF Model D 614

DUNHAM-BUSH (MEPCO: Marshall Engineered Products Co.)

PS-1002 C 1 1.000 1/2 BCFJF N S-996

PS-106 C 1 1.000 1/2 BCFKF N S-996 New

PS-118 C 1 1.187 5/8 BCFJF

PS-359 C 1 1.250 5/8 BCFJF S-472

PS-552- C 1 1.250 5/8 BLFLF S-5099

SC-SC

PS-633V- C 1 1.250 5/8 VCFKF S-2143, S-5549

CMS

PS-552- C 3 1.250 5/8 QCFJF S-5011

EPR

PS-552- C 3 1.250 5/8 QCFJF I S-4940

EPR-P66

PS-732- C 3 1.250 5/8 QCFKF I S-4981

EPR-P66

PS-633V- C 3 1.250 5/8 VCFZF S-472-TC-V

TC SEAT

PS-750 D 1 1.375 3/4 BCDJF 40088878W

PS-2027- D 3 1.500 3/4 QCFZF S-5579

EPR-TC-

SEAT

PS-188 E11.500 7/8 BCFJF 40090790W

PS-982 C 1 1.625 1 BCFKF 860

PS-499 C 3 1.625 1 BCFKF GA-1781-4

PS-983 C 1 1.750 1-1/8 BCFKF 861, ML-8702

PS-185 C1 1.875 1-1/4 BCFJF S-4998

PS-756 C 1 1.875 1-1/4 BCFKF S-3179

PS-756V- C 1 1.875 1-1/4 VCFKF S-5548

CMS

PS-618- C 3 1.875 1-1/4 QCFJF I S-4982, S-5085

EPR-P66

PS-239 C1 2.375 1-5/8 BCFKF S-3291

PS-3616 C 1 2.375 1-5/8 QCFKF S-4932

DURIRON (See FLOWSERVE CORP.)

PS-866 E 31.750 1-1/8 BCFJF

PS-867 E 3 1.750 1-1/8 BCFKF

PS-886 T 3 1.750 1-1/8 BCFJF

PS-918 T 3 1.750 1-1/8 BCFKF

PS-2069 E 1 2.625 1-7/8 BCFJF

PS-2072 E 3 2.625 1-7/8 BCFKF

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

A. MOUNTS ON SHAFT

C.COMPLETE WITH COLLAR

N. NON-STANDARD SPRING HOLDER

DURIRON (continued) (See FLOWSERVE CORP.)

PS-742 T 1 2.625 1-7/8 BCFJF

PS-743 T 1 2.625 1-7/8 BCFKF

PS-4392 E 3 3.625 2-5/8 QCFLF C

DURO

PS-452 B 9 — 5/8 BMFJF A 5486

PS-508 D 1 1.250 5/8 BCDJF 5485

PS-102 D 1 1.250 5/8 BCDKF Models: DV-30, 50, 70, 100, B-170

VX-30, 50, 70, 100 DJ-70, 100, SJ70, 100

EAST SIDE MFG.

PS-100 A 1 1.187 5/8 BMFJF P-28322

PS-200 A 1 1.250 5/8 BMFJF

PS-1000 B 1 1.250 5/8 BMFJF Model BTH

PS-359 C1 1.250 5/8 BCFJF

PS-201 A 1 1.375 3/4 BMFJF

PS-358 C 1 1.375 3/4 BCFJF

PS-750 D 1 1.375 3/4 BCDJF MF-1

PS-360 A 1 1.625 1 BCFJF Series C, CM and CH P-28175

EASTERN ENGINEERING (See PULSAFEEDER)

ECONOMY PUMP (PATERSON PUMP CO.)

PS-100 A 1 1.187 5/8 BMFJF

PS-360 A 1 1.625 1 BCFJF

PS-1067 E 1 1.875 1-1/8 BCFKF 2x2MD

EDWARDS ENGINEERING

PS-3578V C 1 1.175 7/16 VCFJF C-316

PS-867V E 3 1.750 1-1/8 VCFKF 220000

ELECTROMOTIVE DIV.

PS-632 C 1 1.000 1/2 BCFKF N 822832

PS-602 D 1 1.562 7/8 BCDJF 5876888

ELKINGTON DISHWASHER

PS-3440 C 1 1.750 1 BCFJF DT Series

ENPO-CORNELL PUMP CO.

PS-961 B 1 1.250 5/8 BCFJF

PS-452 B 9 — 5/8 BMFJF A

PS-201 A1 1.375 3/4 BMFJF

PS-360 A 1 1.625 1 BCFJF

PS-466 C 1 2.000 1-1/4 BCFJF M-3957-F

PS-466V C 1 2.000 1-1/4 VCFJF M-3957-G

PS-546 E 3 1.875 1-1/4 BCFJF

PS-467 C12.125 1-3/8 BCFKF M-3983-C

PS-1683 E 3 2.375 1-5/8 BCFJF

PS-2212 C 1 2.500 1-3/4 BCFJF M-3842-F

PS-1068 C 1 2.500 1-3/4 BCFKF M-3842-C

PS-449 K12.500 1-3/4 BCFJF

PS-2139 C1 2.750 2 BCFJF M 4414-F

PS-842 C 1 2.750 2 BCFKF M-4414-C

PS-1040 K 3 2.750 2 BCFKF

PS-1041 K 3 3.250 2-3/8 BCFKF

PS-1613 K3 3.375 2-1/2 BCFJF

ENVIRONMENT ONE CORP.

PS-2033 D 3 1.625 1 BCFJF A-2021B110

ESSICK

PS-358 C 1 1.375 3/4 BCFJF 9014009

PS-175 K 1

1.375/1.500

3/4 BCFJF 9014225

PS-185 C 1 1.875 1-1/4 BCFJF 9014025

PS-177 C 1 2.000 1-3/8 BCFJF 9014027

PS-495 K 12.000 1-3/8 BCFJF 9014140

EUROPLAST LTD.

PS-201 A 11.375 3/4 BMFJF 60985AA

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

EVERITE

PS-150 B — — 1/2 BMF-F Seat Is Impeller 1205

PS-200 A 1 1.250 5/8 BMFJF 2544

PS-501 A 1 1.250 5/8 BMFJF

PS-359 C 1 1.250 5/8 BCFJF 2584

FAIRBANKS MORSE (See PENTAIR, INC. for Additional Part Numbers)

PS-506 A 1 1.000 1/2 BMFKF Models: 49 and 59 Circulating Pumps 91325

PS-200 A 1 1.250 5/8 BMFJF Models: H, HC, HV 82723, 82470-75

PS-501 A 1 1.250 5/8 BMFJF H500, 649, 650 Shallow Well and 82635-60, 82702-75

All Model 49 Ejectors to 1 HP.

Models 300, 500 and 750 VS-VD

PS-507 A 1 1.250 5/8 BMFKF For UL 25 Westco Shallow Well 82480-60

PS-359 C 1 1.250 5/8 BCFJF Submersible Motor

PS-508 D 1 1.250 5/8 BCDJF Model 49 82480-75

PS-102 D 1 1.250 5/8 BCDKF 82698

PS-201 A 1 1.375 3/4 BMFJF Models: AC, AEC, AS, AES

PS-877 C 1 1.375 3/4 BCFJF Model 5553B-Build Together Pump HYDE2, 82738-60

PS-750 D 1 1.375 3/4 BCDJF 40088878

PS-188 E 1 1.500 7/8 BCFJF 1-1/4 Fig. 5553E, Mtr Frm. up to 184 HYD1Q1

PS-229 E 3 1.500 7/8 BCFKF Westco BR545

PS-235 C 1 1.625 1 BCFJF CND-1726D-1726C

LV411900X01

PS-356 C 1 1.750 1-1/8 BCFJF 1-1/2, 2, 3, 4 Fig.5553N, Frm. 213 & Up HYD1AC

PS-204 E 1 1.750 1-1/8 BCFJF 1-1/4 Fig. 5553E, Mtr. Frm. 213 & Up HYD1Q2

PS-6812 C 1 1.875 1-3/16 BCFJF LV7140047753

PS-8074 X Bal. 3 1.687 1-3/16 Special HYD1BT3

PS-185 C 1 1.875 1-1/4 BCFJF HYD1AC2

PS-756 C 1 1.875 1-1/4 BCFKF HYD1BX8

PS-381 D 1 1.875 1-1/4 BCFJF Westco 2G

PS-510 D 1 2.000 1-1/4 BCFJF Models: 5554, 5554A HYD1E2

PS-883 K 1 1.875 1-1/4 BCFJF HYD1AD2

PS-865 E 3 2.000 1-3/8 BCFKF HYD1Q3

PS-1104 V 25 2.140 1-3/8 BMFJF Frame 25

PS-8079 XB5 3 1.937 1-7/16 Special 316SS HYD1BT6

PS-758 C 1 2.125 1-1/2 BCFJF LV740048753

PS-305 E 1 2.125 1-1/2 BCFJF ND2502-A1

PS-395 E 3 2.125 1-1/2 BCFJF 3˝ & 4˝ Fig. 5821, 2˝ & 3˝ Fig. 5822, HYD1AA1, HYD1X3

2˝ & 2-1/2˝ Fig. 5823, 3˝ Fig. 5874A

PS-395- E 3 2.125 1-1/2 QCFJF FMB088775CO1

EPR

PS-515 E 3 2.250 1-1/2 BCFJF 2˝ Fig. 5812, 3˝, 4˝ Fig. 5811 HYD1A2

PS-514 D 1 2.375 1-5/8 BCDJF ND1246-A4

PS-1683 E32.375 1-5/8 BCFJF HYD1BG1

PS-446 C1 2.500 1-3/4 BCFJF HYD1AC3, HYD1AD1

PS-550 C 3 2.500 1-3/4 BCFJF HYD1CB2

PS-6241 C 3 2.500 1-3/4 BLFLF HYD1EH2

PS-3963 C 3 2.500 1-3/4 BLFZF HYD1CM2

PS-3719 C 3 2.500 1-3/4 B/VLFZF HYD1DJ2

PS-3687 C 3 2.500 1-3/4 BZFZF HYD1CD2

PS-3718V C32.500 1-3/4 VCFJF HYD1CR2

PS-449 K 1 2.500 1-3/4 BCFJF Models: 5421 BP, KTPA-10031 HYD1AD1

PS-6246 K 1 2.500 1-3/4 BCFJF HYD1AD7

PS-6242 T32.500 1-3/4 VCFJF 316SS HYD1EN2

PS-1070 U 3 2.375 1-3/4 BCFJF 5˝ Fig. 5821, 6˝ Fig. 5821, 4˝ Fig. 5822 HYD1AA3

3˝ Fig. 5823, 4˝ Fig. 5874A, 3˝ Fig. 5876A

2˝ Fig. 5972A, 2-1/2˝ Fig. 5972A

PS-519 U 3 2.500 1-3/4 BCFJF Fig. 5822A, Size 4 HYD1T2

PS-2069 E 12.625 1-7/8 BCFJF HYD1E4

PS-2070 E 12.625 1-7/8 BCFKF HYD1Q4

PS-3964 T 32.625 1-7/8 BCFJF HYD1CW1

PS-898 U 3 2.500 1-7/8 BCFJF 8˝ Fig. 5821, 5˝ & 6˝ Fig. 5822 HYD1AA4

4˝ & 5˝ Fig. 5823, 5˝ Fig. 5874A

PS-2146 V 3 2.625 1-7/8 BMFJF HYD1S16

PS-1105 V 25 2.640 1-7/8 BMFJF Frame 28

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

FAIRBANKS MORSE (continued) (See PENTAIR, INC. for Additional Part Numbers)

PS-8077

XSpecial

3 2.500 1-7/8 VCFJF 316SS HYD1BT10

PS-7781 C 1 2.750 2 BCFJF HYD1CB1

PS-7781- C 1 2.750 2 BLFZF HYD1CK2, HYD1CN2

SC-TC

PS-4015 C 3 2.750 2 BCFKF HYD1CE2

PS-332 C 3 2.750 2 BCFKF HYD1BX1

PS-6238 C 3 2.750 2 BLFLF HYD1EH1

PS-3721 C 3 2.750 2 BLFZF HYD1CM1, HYD1DJ1

PS-6247V C 3 2.750 2 VCFKF HYD1CS2

PS-4178 C 3 2.750 2 VLFLF HYD151

PS-530 E 3 2.750 2 BCFJF HYD1BG2

PS-2143 K 1 2.750 2 BCFJF

PS-338 C 3 3.000 2-1/8 BCFJF Frame 30 Model 5500 HYD1AC4

PS-327 E 3 3.000 2-1/8 BCFJF HYD1Q5

PS-887 K 1 3.000 2-1/8 BCFJF HYD1AD3

PS-1107- V 1 3.187 2-1/8 BCFJF Frame 32 HYD1S

CMS

PS-1102 V 3 3.140 2-1/8 BCFJF Frame 32 HYD1S5

PS-7782 C 1 3.125 2-1/4 BCFKF HYD1CE1

PS-1676 C 3 3.125 2-1/4 BCFKF HYD1BX10

PS-3966 C 3 3.125 2-1/4 BLFZF HYD1CN1

PS-6248 C 3 3.125 2-1/4 VCFKF HYD1CS1

PS-7431 K 1 3.125 2-1/4 BCFJF HYD1AD9

PS-269 C 3 3.375 2-1/2 BCFJF

HYD1AD4, FMB027764A01

PS-853 C 3 3.375 2-1/2 BCFKF HYD1BX3

PS-6254 E 3 3.500 2-1/2 BCFJF HYD1CX2

PS-279 E 3 3.375 2-1/2 BCFJF 8˝ Fig. 5822, 6˝ & 8˝ Fig. 5823, HYD1AA6, HYD1BG3

5˝ & 6˝ Fig. 5824, 5˝ Fig. 5972

PS-1613 K 3 3.375 2-1/2 BCFJF HYD1AD10

PS-4072 T 3 3.500 2-1/2 BCFJF HYD1CW2

PS-6244 T 3 3.500 2-1/2 VCFJF HYD1EN4

PS-6243 T 3 3.500 2-1/2 VLFZF HYD1ES4, FMB1403087

PS-2147 V 3 3.500 2-1/2 BCFJF HYD1S17

PS-3994 C 3 3.500 2-3/4 BCFJF HYD1CB3

PS-6239 C 3 3.500 2-3/4 BLFLF HYD1EH3

PS-4366 C 3 3.500 2-3/4 BLFZF HYD1CM3

PS-2154- C 3 3.500 2-3/4 B/VCFZF FMB060882X01

TC-SEAT

PS-3661 C33.500 2-3/4 VLFZF HYD1DJ3

PS-2148 K 3 3.500 2-3/4 BCFJF HYD1AD11

PS-328 E3 3.375 2-5/8 BCFJF HYD1AA8, HYD1Q6

PS-542 E 3 3.375 2-5/8 BCFKF HYD1Q6

PS-329 E 3 3.750 2-7/8 BCFJF HYD1Q7

PS-2153 C 3 3.875 3 BCFJF HYD1EF3

PS-2115 C 3 3.875 3 BCFKF HYD1BX4

PS-3600 C 3 3.875 3 BCFKF HYD1CE3

PS-2115- C 3 3.875 3 BCFZF FMB060882X02

TC-SEAT

PS-6240 C3 3.875 3 BLFLF HYD1EH4

PS-3701 C33.875 3 BLFZF HYD1CM4

PS-6249- C 3 3.875 3 BLFZF HYD1CN3

SC-TC

PS-2153- C 3 3.875 3 BZFZF HYD1CD4

TC-TC

PS-6249 C 3 3.875 3 BZFZF HYD1CK3

PS-6250 C 3 3.875 3 VCFKF HYD1CS3

PS-475 E 33.875 3 BCDKF HYD1BE4

PS-324SS E 33.875 3 BCFJF HYD1BG4

PS-3969 E 3 4.000 3 BCFJF HYD1CX3

PS-7993 T 3 4.000 3 BCFJF HYD1CW3

PS-3836 U 3 3.875 3 BCFJF HYD1AA7

PS-7215 V 3 4.000 3 BCFJF 316SS HYD1S18

PS-4069 V 3 4.000 3 BCFZF FMB061419X01

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

A. MOUNTS ON SHAFT

B.TAPERED SPRING

H. SPRING HOLDER NOT INCLUDED

I. ABRASION RESISTANT CARBON (P66)

FAIRBANKS MORSE (continued) (See PENTAIR, INC. for Additional Part Numbers)

PS-1069 V 3 4.750 3-1/8 BCFJF HYD1S8

PS-4127 C 3 4.125 3-1/4 BCFJF HYD1EF4

PS-6258 C 3 4.125 3-1/4 BCFKF HYD1CE4

PS-3702 C 3 4.125 3-1/4 BLFZF HYD1CN4

PS-6251 C 3 4.125 3-1/4 BZFZF HYD1CK4

PS-6253 C 3 4.125 3-1/4 VCFJF HYD1CR4

PS-6252 C 3 4.125 3-1/4 VCFKF HYD1CS4

PS-330 E 3 4.125 3-1/4 BCDJF HYD1Q8

PS-6245 C 3 4.375 3-1/2 BCFKF HYD1BX6

PS-6256 D 3 4.375 3-1/2 BLFZF HYD1DC3

PS-4019 E 3 4.375 3-1/2 BCFJF I HYD1BG5

PS-4101 E 3 4.375 3-1/2 BCFKF HYD1BE5

PS-3499 E 3 4.625 3-5/8 BCFJF HYD1CX4

PS-3684 T 3 4.625 3-5/8 BCFJF HYD1CW4

PS-6237 T 3 4.625 3-5/8 BCFZF FMB213293X01

PS-3779 V 3 4.625 3-5/8 BCFJF HYD1S19

PS-4014 D 3 4.625 3-3/4 BLFZF HYD1DB3, HYD1DC1

FEDERAL PUMP

PS-293 A 14 .815 5/8 BMFKF Seat is Metal to Metal Press Fit

PS-245 C 1 1.625 1 BCFJF B/H

PS-248 C 1 1.625 1 BCFKF B/H

PS-380 D 1 1.625 1 BCFJF

PS-246 C 1 1.875 1-1/4 BCFJF B/H

PS-249 C 1 1.875 1-1/4 BCFKF B/H

PS-381 D 1 1.875 1-1/4 BCFJF

PS-547 C 3 2.000 1-3/8 BCFKF

PS-682 C 1 2.156 1-1/2 BCFJF B/H

PS-247 C 1 2.156 1-1/2 BCFKF B/H

PS-382 D 1 2.125 1-1/2 BCFJF

PS-446 C 1 2.500 1-3/4 BCFJF

PS-205 E 1 2.500 1-3/4 BCFJF

FINISH THOMPSON, INC.

PS-359- C 1 1.250 5/8 QCFJF J101256

EPR-CMS

FINN CORP.

PS-185 C 1 1.875 1-1/4 BCFJF 080485

FLINT & WALLING (Div. of ZOELLER PUMP CO.)

PS-165 B 9 .906 1/2 BMFJF A 132891/92

PS-800 C 1 1.156 5/8 BMFJF H Models:BPA, C, C6267,CA AC-16,131100, 132377

PS-201 A 1 1.375 3/4 BMFJF 81, 82, 83, 605, 607, 609 Shallow Well 126544, 126545

64, 65, 66, 67, 68 Deep Well

PS-687 C 1 1.500 7/8 BCFKF 121224

PS-357 C11.625 1 BCFKF Series C211 129868

PS-204 E 1 1.750 1-1/8 BCFJF

PS-185 C 1 1.875 1-1/4 BCFJF 136557

FLOWSERVE CORP. (See DURIRON, IDP and WORTHINGTON)

PS-928 C — — 9/16 BCF-F 05595400, 27337583

PS-3542 C 3 1.031 9/16 VCFKF 74744277

PS-516 A 1 1.250 5/8 BCFJF 74297284

PS-528 A 1 1.375 5/8 BMFJF 28518652

PS-637 A 3 1.250 5/8 BMFJF 60311669

PS-933 C — — 5/8 BCF-F 055955-00, 27337591

PS-359V- C 1 1.250 5/8 VCFJF 74315409

CMS

PS-626 C 1 1.375 5/8 VCFJF PO2099-00,28518660

PS-7635 C 3 1.062 5/8 VCFKF 74744285

PS-951- C 3 1.375 5/8 QCFKF 74264060

EPR

PS-951 C 3 1.375 5/8 VCFKF PO2752-00, 74262767

PS-564 C — — 3/4 BCF-F 024439-00, 27197623

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

I. ABRASION RESISTANT CARBON (P66)

FLOWSERVE CORP. (continued) (See DURIRON, IDP and WORTHINGTON)

PS-2236 C 3 1.375 3/4 BCFJF 60721792, 60980901

PS-2235 C 3 1.375 3/4 VCFJF 60724572

PS-4229- C 3 1.375 3/4 QCFZF 68865831

TC-SEAT

PS-7994 E 3 1.187 3/4 VCFKF 1802AJCTYPIR075XP171

PS-602 D 1 1.562 7/8 BCDJF 60110418

PS-936 E — — 7/8 BCF-F 024440-00, 27197631

PS-7859V E 3 1.312 7/8 VCFKF 316SS 74744301

PS-7896 E 3 1.500 7/8 VCEZE 60311578

PS-845 U 3 1.562 15/16 BCFGF 27252691

PS-560V U 3 1.562 15/16 VCFKF 031446-01, 74744319

PS-252 D 3 1.625 1 BCFKF 82230962

PS-348 C — — 1-1/8 BCF-F PO2885-00, 28518934

68885854

PS-348V C — — 1-1/8 VCF-F PO2889-00, 74262874

PS-356 C 1 1.750 1-1/8 BCFJF 74908260

PS-801 C 3 1.750 1-1/8 BCFJF 60954526

PS-355V C 3 1.750 1-1/8 VCFKF 39633201

PS-605 D 1 1.750 1-1/8 BCFKF CPM-10055, 60110442

PS-604 D 1 1.750 1-1/8 BCFJF 60110434

PS-607 E 1 1.687 1-1/8 BCFJF 60110327, 60110335

PS-384 E 1 1.750 1-1/8 BCFKF 60110616

PS-867 E 3 1.750 1-1/8 BCFKF 69237592

PS-204V E 3 1.750 1-1/8 VCFJF 60954682

PS-867V- E 3 1.750 1-1/8 VCFZF 60954716

TC-SEAT

FA-607 E — — 1-1/8 BCF-F 053129-00, 68885870

68885896,74308461

FA-608V E — — 1-1/8 VCF-F 60954690

PS-1637 E 3 1.812 1-1/8 B/VCFKF 60514254

T9-1125 WT — — 1-1/8 TCF-F 316SS PO2877-00, 25818801

60954914

PS-723 T 1 1.875 1-3/16 BCDJF 60111267

PS-618 C 3 1.875 1-1/4 BCFJF 60721800, 60980918

60980919

PS-618- C 3 1.875 1-1/4 QCFJF I 74737990

EPR-P66

PS-2203 C31.875 1-1/4 QCFKF I 68867910

PS-7436 C 3 1.875 1-1/4 QCFZF I 60671328

PS-756V C 3 1.875 1-1/4 VCFKF 74898800

PS-618V- C 3 1.875 1-1/4 VCFZF 60727401

TC-SEAT

PS-7972 G11.875 1-1/4 BLFLF

Model 4MSX7 - See PS-7971 for Upper Seal

81955064 - Lower Seal

PS-394 U 3 1.875 1-1/4 BCF/DKF 031448-00

PS-172 C — — 1-3/8 BCF-F PO2886-00, 28518868

PS-172- C — — 1-3/8 QCF-F I 74332321, 80631400

EPR-P66

PS-172V C——1-3/8 VCF-F PO2890-00, 28518884

PS-4163 E — — 1-3/8 QCF-F 316SS 74712241

PS-2104V E — — 1-3/8 VCF-F 74816034

PS-4087 E — — 1-3/8 VCF-F 316SS PO2874-00

PS-3925 E32.125 1-3/8 VCFJF 74816117

PS-7971 G 1 2.000 1-3/8 BCFJF See PS-7972 for Lower Seal 81955072 - Upper Seal

PS-3014 G 1 2.000 1-3/8 BLFZF 316SS 81981193

PS-725 T 1 2.000 1-3/8 BCFJF 60111275

PS-561SS U 1 2.000 1-3/8 BCFKF 05049800, 02645700

27215094

PS-2106 E — — 1-1/2 BCF-F 05484500, 27335819

68886167, 68886175

69170181

PS-2106V E — — 1-1/2 VCF-F 60506169, 60549581

74332164, 80612400

PS-258 E 3 2.125 1-1/2 BCFKF 68886100, 68886118

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

C.COMPLETE WITH COLLAR

I. ABRASION RESISTANT CARBON (P66)

FLOWSERVE CORP. (continued) (See DURIRON, IDP and WORTHINGTON)

PS-305V E 3 2.125 1-1/2 VCFJF 68886068

PS-4034 E 3 2.312 1-1/2 BCFZF 60514148

PS-1648 E 3 2.312 1-1/2 B/VCFKF 60514130, 60514288

PS-1651 E 3 2.312 1-1/2 VCFJF H/HC 60514122

PS-1652 E 3 2.312 1-1/2 VCFKF 60514726

PS-239- C 3 2.375 1-5/8 QCFKF 60727328

EPR

PS-609 E 1 2.312 1-5/8 BCDJF 60110343

PS-610 E 1 2.312 1-5/8 BCFKF 60110350

PS-2108 C — — 1-3/4 BCF-F 28518876

PS-2108- C — — 1-3/4 BRF-F 80996900

P90

PS-2108V C — — 1-3/4 VCF-F 74262882, PO2891-00

PS-2109 E — — 1-3/4 BCF-F 28518785

PS-7950 E 3 2.500 1-3/4 QCFZF I 74840992

PS-366V E 3 2.500 1-3/4 VCFKF 74780065

PS-3016 G 1 2.500 1-3/4 BLFLF 81974883

PS-4216 G 1 2.500 1-3/4 BLFZF 81974917

PS-4263 T 3 2.500 1-3/4 VCFJF 316SS 68885862

PS-3884 U 1 2.500 1-3/4 VCFZF

PS-2072 E 3 2.625 1-7/8 BCFKF 60433083, 60434321

68885987

PS-1659 E 3 2.625 1-7/8 VCFJF 60954757

PS-1660 E 3 2.625 1-7/8 VCFKF 60954807

PS-4193 E 3 2.625 1-7/8 VCFZF 316SS

FA-513V E — — 1-7/8 VCF-F 60954765

PS-3648 EBal. Special 2.687 1-7/8 VCFZF 60502697

PS-3017 G 1 2.625 1-7/8 BCFJF 81974875

PS-3018 G 1 2.625 1-7/8 BLFLF 81974909

FA-8094V X — — 1-7/8 VCF-F 60954542

PS-530 E 3 2.750 2 BCFJF 60110780

PS-477 E 3 2.750 2 BCFKF 60110756, 69261352

PS-456- U 3 2.750 2 QCFKF 753294-41

EPR

PS-3591 U 3 2.750 2 QCFZF I 753294-90

PS-456V U 3 2.750 2 VCFKF 753295-40

FA-2120 C — — 2-1/8 BCF-F PO2888-00

PS-1612 E 3 2.812 2-1/8 BCFKF 601103-76

PS-278V E 3 3.250 2-3/8 VCFJF 609697-97

FA-2098 E — — 2-3/8 BCF-F 605283-61

FA-350V E — — 2-3/8 VCF-F 609698-05

PS-3936V- E Bal. 3 3.125 2-3/8 VCFZF 801909-54

TC-SEAT

PS-3008 G 1 3.250 2-3/8 BCFJF 81974891

PS-3022 G 1 3.250 2-3/8 BLFZF 81974941

PS-2205- E 3 3.375 2-1/2 QCFKF I 60647260

EPR

PS-349V E 3 3.375 2-1/2 VCFKF 75514554

PS-4392 E33.625 2-5/8 QCFLF C

PS-8102 X Bal. 3 3.375 2-3/4 VCFZF 316SS

PS-475 E33.875 3 BCDKF 60434883

PS-5252 E 3 3.875 3 BCFKF 74841065

PS-325SS U 3 4.125 3-1/4 BCFKF 69261378

PS-7986 U 3 4.625 3-3/4 BCDKF 60311578

FLOWAY (Div. of WEIR SPECIALTY PUMPS)

PS-252 D 3 1.625 1 BCFKF 542949-2010

PS-264 E 3 1.875 1-1/4 BCFKF 545305-1010, 231-31-413

FLYGT (Div. of ITT CORP.) (See Pages 168-171)

FMC FOODTECH

PS-397 C — — 1 BCF-F 401-50-0001

PS-2105 C — — 1-1/2 BCF-F 401-50-0006

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

36 NOTE:

A. MOUNTS ON SHAFT

I. ABRASION RESISTANT CARBON (P66)

FOOTE BROTHERS

PS-383 D 1 1.875 1-1/4 BCFKF

PS-186 D 1 2.000 1-3/8 BCDKF

PS-371 D 1 2.125 1-1/2 BCFKF

PS-462 D 1 2.750 2 BCDKF

FRANKLIN ELECTRIC CO., INC. (LITTLE GIANT PUMP CO., MONARCH PUMPS)

PS-200 A 1 1.250 5/8 BMFJF 106196105

PS-200V- A 1 1.250 5/8 VCFJF 240316

CMS

PS-452 B 8 — 5/8 BMFJF A

PS-1021 B 8 — 5/8 BMFJF A 292456101

PS-877 C 1 1.375 3/4 BCFJF 106196102

PS-360 A 1 1.625 1 BCFJF 240180

PS-360V- A 1 1.625 1 VCFJF 240369

CMS

PS-2122 C 1 1.875 1-1/4 BCFJF 106196101

PS-185V- C 1 1.875 1-1/4 VCFJF 240359

CMS

FRANKLIN PUMP SYSTEMS (Div. of JACUZZI)

PS-200 A 1 1.250 5/8 BMFJF 10000206

PS-201 A 1 1.375 3/4 BMFJF 10150209

PS-877 C 1 1.375 3/4 BCFJF 10120301

PS-235 C 1 1.625 1 BCFJF 10129906

PS-2122 C 1 1.875 1-1/4 BCFJF 10036903

PS-2142 C 1 2.500 1-3/4 BCFJF 10037000

FREDERICK PUMP & ENGINE

PS-952 A 1 1.250 5/8 BCFJF

PS-360 A 1 1.625 1 BCFJF

PS-185 C 1 1.875 1-1/4 BCFJF

PS-756V C 3 1.875 1-1/4 VCFKF 80912

PS-1042 U 1 2.500 1-3/4 BCFJF

FRICK CO.

PS-492- C 1 3.250 2-3/8 BCFKF 80BA2-47 P-81905

CMS

PS-4028

3Special

4.500 2-7/8 NCFGF Model No MRI-90

FYBROC (Div. of MET-PRO CORP.)

PS-8057 XB2 27 3.562 2-1/8 VCFJF 316SS 0895C010

G.E. OSMONICS

PS-4272 C 1 1.250 5/8 BCFJF 316SS 1113515

PS-552- C 3 1.250 5/8 QCFJF I 1114630

EPR-P66

PS-2016 E 1 1.250 5/8 BCFJF 1113517

PS-548 C 3 1.625 1 BCFJF 1121167

PS-235V C 3 1.625 1 VCFJF

PS-791 E 3 1.625 1 BCFKF 1114326

-791-EPR-

E 3 1.625 1 QCFZF 1201945

TC-SEAT

PS-791V- E 3 1.625 1 VCFZF 1201946

TC-SEAT

PS-2047V D 3 2.000 1-3/8 VCFJF 3011311

GALION

PS-157 C——3/4 BCF-F

PS-397 C — — 1 BCF-F

GARDNER DENVER

PS-441 B 9—3/4 BMFKF A 60BN-1

PS-373 C 11.375 3/4 BCFKF 60AY-10

PS-360 A 1 1.625 1 BCFJF 60BT-11

PS-370 A 1 1.625 1 BCFKF 60BT-1

PS-357V C 3 1.625 1 VCFKF 60DD-799

PS-236 E 1 1.625 1 BCFKF 60AY-2,16 &18

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

B.TAPERED SPRING

GARDNER DENVER (continued)

PS-605 D 1 1.750 1-1/8 BCFKF 60BC-10

PS-384 E 1 1.750 1-1/8 BCFKF 60AY-11 &13

PS-383 D 1 1.875 1-1/4 BCFKF 60BC-3

PS-6036 D 2 1.875 1-1/4 VCPFP 60DD-597

PS-186 D 1 2.000 1-3/8 BCDKF 60BC-14

PS-6048 D 3 2.000 1-3/8 VCPSP 60DD-594

PS-354 E 1 2.000 1-3/8 BCFJF

PS-7367 C Special 2.718 1-7/16 VCFGF 60DD-52

PS-6055 E 28 2.718 1-7/16 VCPGP 60DD-105

PS-382 D 1 2.125 1-1/2 BCFJF

PS-371 D 1 2.125 1-1/2 BCFKF

PS-374 E 1 2.125 1-1/2 BCFKF 60AY-21

PS-239V C 3 2.375 1-5/8 VCFKF 60BC-2-5

PS-6005 C 3 2.375 1-5/8 VCFKF 60DD-86

PS-6075 D 3 2.375 1-5/8 VCPSP 60DD-592

PS-436V C 3 2.500 1-3/4 VCFKF 60DD-596

PS-312V C 3 2.625 1-7/8 VCFKF 60DD-98

PS-593 D 3 2.625 1-7/8 BCDKF 60BC-9,12

PS-6094 D 3 2.625 1-7/8 VCPSF 60DD-599

PS-2070 E 1 2.625 1-7/8 BCFKF 60AY-20

PS-543V C 3 3.000 2-1/8 VCFKF 60DD-600

PS-1676V C 3 3.125 2-1/4 VCFKF 60DD-104

PS-5358 D 3 3.125 2-1/4 Special 60DD-595

PS-351 E 1 3.125 2-1/4 BCDKF 60AY-15

PS-463 D 3 3.375 2-1/2 BCDKF 60BC-8

PS-6154 C 27 4.406 2-3/4 VCFGF 60DD54

GARWOOD INDUSTRIES

PS-303 D 1 1.500 7/8 BCDKF 206556

PS-227 D 1 1.750 1 BCFKF

PS-210 C 1 2.000 1-3/8 BCFKF 2016264

PS-376 D — — 1-3/8 BCD-F 2039056

GEARMASTER

PS-1043 C 1 1.000 1/2 BMFJF A34-3970

GECO SALES

PS-1000 B 1 1.250 5/8 BMFJF

GENERAL MOTORS CORP. (GMC)

PS-642 B — — 5/8 BMF-F 5121751

PS-933 C——5/8 BCF-F 5186571

PS-752 D 1 1.375 3/4 BCDKF 5186113

PS-192 C3 2.125 1-1/2 NCFGF

GENERAL PUMP

PS-200 A11.250 5/8 BMFJF

PS-810 C 1 1.250 5/8 N/BCFJF B 1-1/2 HP to 2 HP

GEORGIA PACIFIC PUMP

PS-200 A 1 1.250 5/8 BMFJF

GG INDUSTRIES

PS-200 A 1 1.250 5/8 BMFJF P-M03885

PS-642 B — — 5/8 BMF-F P-M03857, P-M07909

PS-1000 B 1 1.250 5/8 BMFJF P-Seal 4 / P-Seal 5 Mark III

GILBERT BARKER (GILBARCO, INC.)

PS-1000 B 1 1.250 5/8 BMFJF K81159X

PS-756 C11.875 1-1/4 BCFKF K74050X

PS-514 D 1 2.375 1-5/8 BCDJF

PS-461 D 12.375 1-5/8 BCDKF

GLT, INC.

PS-6313 Q 1 1.019 1/2 BCFJF 185694-1

PS-1085V C 11.250 5/8 VCFJF B 114696

PS-6318 Q 9 1.578 1-1/8 VMFAF 117071

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

38 NOTE:

N. NON-STANDARD SPRING HOLDER

GORMAN-RUPP CO. (For Additional Listings - See Page 155)

PS-150 B — — 1/2 BMF-F Seat is Impeller S8243-4

PS-788 B 1 1.000 1/2 BMFKF

PS-106 C 1 1.000 1/2 BCFKF N 25271-801

PS-106V C 1 1.000 1/2 VCFKF N 25271-802

PS-218 A — — 5/8 BCF-F 12873-002

PS-200 A 1 1.250 5/8 BMFJF S756, S1531

PS-507 A 1 1.250 5/8 BMFKF

PS-882 B — — 5/8 BCF-F 8243-12

PS-118 C 1 1.187 5/8 BCFJF S809

PS-359 C 1 1.250 5/8 BCFJF S765, 25271-824

PS-1080 C 1 1.250 5/8 NCFKF 25270-113

PS-1045 C 3 1.250 5/8 VCFJF

PS-102 D 1 1.250 5/8 BCDKF S217

PS-795 S 8 1.187 5/8 NAPSP GS-625

PS-851 A 1 1.375 3/4 BCFJF S1190

PS-601 B 1 1.375 3/4 BMFJF Model: 83E-F13 26822-008

PS-564 C — — 3/4 BCF-F S32

PS-112 C 1 1.375 3/4 BCFKF S1679

PS-358 C 1 1.375 3/4 BCFJF S936, S1575

PS-358V- C 1 1.375 3/4 VCFJF 25271-850

CMS

PS-373V C 1 1.375 3/4 VCFKF 25271-021

PS-750 D 1 1.375 3/4 BCDJF S383

PS-752 D 1 1.375 3/4 BCDKF

PS-792 S Special 1.500 3/4 NAPSP GS-750

PS-617 C 3 1.500 7/8 BCFKF 25271-159

PS-2027V D 3 1.500 7/8 VCFKF 25271-855

PS-360 A 1 1.625 1 BCFJF S2147

PS-397 C — — 1 BCF-F S237

PS-235 C 1 1.625 1 BCFJF S1906, S1832

PS-357 C 1 1.625 1 BCFKF

PS-499 C 3 1.625 1 BCFKF 25271-869

PS-357V C 3 1.625 1 VCFKF 25271-870

PS-380 D 1 1.625 1 BCFJF S1415

PS-460 D 1 1.625 1 BCFKF S363, S364

PS-4253 DBal. 3 1.500 1 VCFKF 316SS 25276-251

PS-236 E 1 1.625 1 BCFKF

PS-557 E 3 1.625 1 BCFJF 25271-032

PS-791 E 3 1.625 1 BCFKF S388

PS-793 S 8 1.750 1 NAPSP Model: 13A2-B GS-1000

PS-9018 W 27 2.156 1 TCFJF 316SS S1212

PS-348 C — — 1-1/8 BCF-F 92055-1112

PS-867 E 3 1.750 1-1/8 BCFKF 25271-039

PS-867V E 3 1.750 1-1/8 VCFKF 25271-037

PS-756 C 1 1.875 1-1/4 BCFKF S1621

PS-185- C 1 1.875 1-1/4 QCFJF 25271-893

EPR

PS-598 C 3 1.875 1-1/4 BCFKF 25271-889

PS-185V C 3 1.875 1-1/4 VCFJF 25271-888

PS-756V C 3 1.875 1-1/4 VCFKF 25271-836, 25271-886

PS-381 D 1 1.875 1-1/4 BCFJF S321

PS-383 D 1 1.875 1-1/4 BCFKF S37, S493

PS-517 D 3 1.875 1-1/4 BCFKF S493C

PS-981 D 3 1.875 1-1/4 BCFKF S321A

PS-383V D 3 1.875 1-1/4 VCFKF 25271-192

PS-361 E11.875 1-1/4 BCFJF S335

PS-137 E 1 1.875 1-1/4 BCFKF S350

PS-546 E 3 1.875 1-1/4 BCFJF 42029, 25271-044

PS-137V E 3 1.875 1-1/4 VCFKF 25271-043

PS-6259 G 1 1.875 1-1/4 VCFJF 316SS 25276-633

PS-794 S 8 2.125 1-1/4 NAPSP Model: 14C2B GS-1250

PS-2234 E 3 2.062 1-7/16 BCFKF 25271-051

PS-2234V E 3 2.062 1-7/16 VCFKF 25271-056

PS-758 C 1 2.125 1-1/2 BCFJF S1150

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

NOTE:

A. MOUNTS ON SHAFT

H. SPRING HOLDER NOTINCLUDED

N. NON-STANDARD SPRING HOLDER

GORMAN-RUPP CO. (continued) (For Additional Listings - See Page 155)

PS-553 C 3 2.125 1-1/2 BCFKF 25271-907

PS-659V C 3 2.125 1-1/2 VCFKF

PS-371 D 1 2.125 1-1/2 BCFKF S283, S317, S774

PS-534 D 3 2.125 1-1/2 BCFKF S1934

PS-371V D 3 2.125 1-1/2 VCFKF 25271-207

PS-7079 D 28 2.375 1-1/2 VZFZF 12364A

PS-374 E 1 2.125 1-1/2 BCFKF S239

PS-8002 X 3 2.125 1-1/2 BCFJF 25271-554

PS-382 D 1 2.125 1-1/2 BCFJF Models S4A1, S4B1, S6A1, S6B1, S1934

S6C1, S8A1, S8B1

PS-239V C 3 2.375 1-5/8 VCFKF 25271-921

PS-544 C 3 2.375 1-5/8 BCFKF 25271-922

PS-2058 E 1 2.375 1-5/8 BCFKF 25271-061

PS-1683 E 3 2.375 1-5/8 BCFJF 25271-064

PS-446 C 1 2.500 1-3/4 BCFJF S1822

PS-2212 C 1 2.500 1-3/4 BCFJF Model S8C1 25271-947

PS-446V- C 1 2.500 1-3/4 VCFJF 25271-942

CMS

PS-436 C 3 2.500 1-3/4 BCFKF 25271-943

PS-267 C 1 2.750 2 BCFJF 25271-971

PS-267V- C 1 2.750 2 VCFJF

CMS

PS-1145 C 3 2.750 2 VCFKF 25271-983

PS-332 C 3 2.750 2 BCFKF S1929

PS-1688 E 3 3.125 2-1/4 BCFJF 25271-095

PS-463 D 3 3.375 2-1/2 BCDKF

PS-3888 D 3 3.375 2-1/2 VZFLF 26835-541

PS-349V- E 3 3.375 2-1/2 VZFLF 26835-544, 26835-546

TC-SC

PS-6219 D 3 3.875 3 BZFLF 26835-548

PS-4033 D 3 3.875 3 VZFLF 26835-542

PS-7835V C 3 4.125 3-1/4 VCFJF 25271-994

GOULDS PUMPS (Div. of ITT INDUSTRIES)

PS-631 C 1 1.000 1/2 BCFJF N

PS-1002 C 1 1.000 1/2 BCFJF N Fig . 3604 74207-0050

PS-1002V C 1 1.000 1/2 VCFJF N 74208-0050, 74209-0050

PS-702 A 1 1.187 5/8 BMFJF Balanced Flow BF-03, 10K1, 10K6, 70470-5062

Series: LS, LD, G, O, M, XS05, 15, 20, 72598-1062, 20-83-1100

30, 50, Jetomatic,

Fig. 3642, 3742, Fig 3672

PS-701 A11.187 5/8 BMFKF Balanced Flow BF-03, Figs.: 3648, 3628, 10K2, 72598-3062

3728, 3748, 3642, 3742, 3638, 3738,

3788, and 3811

PS-518- A 1 1.187 5/8 BLFLF 10K63

SC-SC

PS-702- A 1 1.187 5/8 QCFJF 10K110, 72598-8082

EPR

PS-3977 A 1 1.187 5/8 VLFLF 10K105, 3481008,

72598 7062

PS-702V A 1 1.187 5/8 VCFJF 10K24

PS-4240 A 1 1.187 5/8 BCFJF 10K10

PS-200V- A 1 1.250 5/8 VLFLF 10K120

SC-SC

PS-600 B 1 1.187 5/8 BMFJF Fig. 3231

PS-700 B 1 1.187 5/8 BMFJF Cellar Drainer Fig. 3631 10K7

PS-1000V B 3 1.250 5/8 VCFJF 696-0442

PS-3926 B91.062 5/8 VCFKF 316SS 10K127

PS-411V B 11 — 5/8 VCFJF A 15K20

PS-1155 C 11.187 5/8 BCFJF

PS-493 C 1 1.187 5/8 BCFKF Fig. 3377 and 3371 Multi Stage 10K3

PS-4222 C 11.187 5/8 QCFLF 316SS/H 10K18

PS-3707 C 1 1.187 5/8 QLFLF 316SS/H Does Not Require Springholder 10K81

PS-4226 C 11.187 5/8 VLFLF 316SS/H

PS-1155V C 11.187 5/8 VCFJF 10K24

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

B.TAPERED SPRING

C.COMPLETE WITH COLLAR

H. SPRING HOLDER NOT INCLUDED

I. ABRASION RESISTANT CARBON (P66)

GOULDS PUMPS (Div. of ITT INDUSTRIES) (continued)

PS-4031 C 1 1.187 5/8 VCFLF 10K46, 10K55

PS-3613 C 1 1.187 5/8 VLFLF

PS-6267 G 1 1.187 5/8 QLFLF 10K167, A00576C 1

PS-8104 XA 9 1.062 5/8 YCFKF 10K109

PS-1522 A — — 3/4 BMF-F 7501000

PS-750 D 1 1.375 3/4 BCDJF 10K4

PS-3996 C 1 1.500 7/8 VCFLF 10K40

PS-303 D 1 1.500 7/8 BCDKF 70470-4087

PS-703 D 1 1.500 7/8 BCDJF XS15, 20, 50 Aqua Lawn Jetomatic, 10K8

Fig. 3629, 3649, 3729,3749, 3639, 3739,

3678 and 3789

PS-397V C — — 1 VCF-F 41355000000

PS-235 C 1 1.625 1 BCFJF 10K12, 84001-2

PS-754 E 1 1.625 1 BCFJF Fig. 3169M, 3750S, 3655, 3450, 3650, 70783-1100

3750 & 3755

PS-236 E 1 1.625 1 BCFKF 69127-2100

PS-557 E 3 1.625 1 BCFJF 91666-1000

91670-1000

PS-3976 E 3 1.625 1 VCFJF 316SS Model 3655 / 3755 S

PS-8020 XB2

3Special

1.750 1 VCFJF 316SS

PS-710 E 1 1.750 1-1/16 BCFJF Fig. 3405, 3305S 70783-3106

PS-356 C 1 1.750 1-1/8 BCFJF Fig. 3643 10K21

PS-355- C 1 1.750 1-1/8 BLFLF 10K28

SC-SC

PS-356- C 1 1.750 1-1/8 BLFZF 10K22

SC-TC

PS-588 C 3 1.750 1-1/8 BCFKF B Fig. 3643 10K9, 76407-1112

PS-185 C 1 1.875 1-1/4 BCFJF Fig. 3656 9152071001

PS-2208 C 1 1.875 1-1/4 BZFZF 9152071002

PS-185V- C 1 1.875 1-1/4 VCFJF 10K25

CMS

PS-3886 C 1 1.875 1-1/4 VCFJF 316SS A06101A02

PS-3538 C 1 1.875 1-1/4 VCFLF 316SS 10K27, 76407 8125

PS-4176 C 1 1.875 1-1/4 VCFZF 316SS A06101A07

PS-4150 C 1 1.875 1-1/4 VLFLF 316SS 10K64, 10K188

PS-510 D 1 2.000 1-1/4 BCFJF 51010

PS-361 E 1 1.875 1-1/4 BCFJF 2” Fig. 3460

PS-2128 E 3 1.875 1-1/4 BCFJF

PS-2129 E 3 1.875 1-1/4 BCFKF

PS-177 C 1 2.000 1-3/8 BCFJF

PS-7919 C 3 2.000 1-3/8 B/VLFLF

PS-4194 D 1 2.000 1-3/8 VLFLF A015616E000

PS-354 E 1 2.000 1-3/8 BCFJF Fig. 3345, 3320

PS-677 E 1 2.000 1-3/8 BCFKF

PS-864 E 3 2.000 1-3/8 BCFJF 3196ST

PS-865 E 3 2.000 1-3/8 BCFKF 3196ST

PS-3901 E3 2.000 1-3/8 VCFJF

316SS/C/H

A04710A01

T9-1375 WT —— 1-3/8 TCF-F 316SS 90432001

PS-705 E 3 2.062 1-7/16 BCFJF Fig. 3405M, 3305M 70783-3143

PS-2106- E — — 1-1/2 BCF-F I 91671-0001

P66

PS-305 E12.125 1-1/2 BCFJF Fig. 3169, 3650, 3655, 3750 70783-1150

For Group M and K, 2-1/2” Fig. 3430

PS-374 E 1 2.125 1-1/2 BCFKF

PS-395 E 3 2.125 1-1/2 BCFJF 776A908-2

PS-238- C 1 2.375 1-5/8 QCFLF 10K20

EPR-SC

PS-238V- C 1 2.375 1-5/8 VCFJF 10K26

CMS

PS-238V- C 1 2.375 1-5/8 VCFLF 10K45

SC-CMS

PS-7806 C 1 2.375 1-5/8 VLFLF 10K65, 10K189

PS-818 C 3 2.375 1-5/8 BCFJF 45162000000

46983000000

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

NOTE:

B.TAPERED SPRING

C.COMPLETE WITH COLLAR

I. ABRASION RESISTANT CARBON (P66)

GOULDS PUMPS (Div. of ITT INDUSTRIES) (continued)

PS-238V C 3 2.375 1-5/8 VCFJF 46983000000

46984000000

PS-238V- C 3 2.375 1-5/8 VCFLF A05632E000

SC-SEAT

PS-544V- C 3 2.375 1-5/8 VLFLF 10K186

SC-SC

PS-7497 C 25 2.500 1-5/8 B/VCFJF A05669E000

PS-7497V C 25 2.500 1-5/8 VCFJF A05670E000

PS-446 C 1 2.500 1-3/4 BCFJF 10K181-Lower Seal 10K157, 9152091001

See PS-267 for Upper Seal

PS-446- C 1 2.500 1-3/4 BLFLF 10K31

SC-SC

PS-446V- C 1 2.500 1-3/4 VCFJF 9152091003

CMS

PS-3719 C 3 2.500 1-3/4 B/VLFZF 10K83

PS-2108 C — — 1-3/4 BCF-F 92055 1175

PS-7867 E — — 1-3/4 BCF-F 316SS/C/I

PS-1684 E 3 2.312 1-3/4 BCFJF 3316, 3405 Group M

PS-4326 E 3 2.312 1-3/4 VCFJF 316SS/C

PS-535 E 3 2.500 1-3/4 BCFJF 3196MT - 3735/36M

PS-262 E 3 2.500 1-3/4 BCFKF

PS-3902 E 3 2.500 1-3/4 VCFJF 316SS/C 3196MT A04754A01

PS-1078 E 27 3.000 1-3/4 BCFJF 3316-3405M

PS-3754 V 3 2.750 1-3/4 BCFJF 43424000000

PS-267 C 1 2.750 2 BCFJF 10K181-Upper Seal, 10K182-Lower Seal 9152101002

See PS-446 for Lower Seal

PS-2219 C 1 2.750 2 BZFZF 9152101001

PS-3993 C 3 2.750 2 BCFJF 10K142

PS-3721 C 3 2.750 2 BLFZF 10K85, 76407 9200

PS-267V- C 3 2.750 2 VLFLF 43434000000

SC-SC

PS-707 E 3 2.875 2-1/16 BCDKF Fig. 3305, 3405, 3306, 3406 Group L

PS-1679 C 1 3.125 2-1/4 BCFJF 10K182-Upper Seal 9152111001

PS-848 E 3 3.125 2-1/4 BCDJF

PS-849 E 3 3.125 2-1/4 BCDKF

PS-3951 E 27 3.906 2-1/4 VCFKF 3405 L 10x12-14

PS-4089 E 3 3.500 2-3/4 VCFLF 316SS 3410 L Pump

PS-2153- C 1 3.875 3 BCFJF 9152141005

CMS

PS-8060 X3 5.375 4-3/8 VCFKF 316SS Fig. 3415 Group M

GRAHAM ENGINEERING CORP.

PS-1688 E3 3.125 2-1/4 BCFJF 65100021

GRAINGER (See TEEL PUMP)

GRISWOLD PUMP CO.

PS-2122 C11.875 1-1/4 BCFJF 10036903

PS-758 C 1 2.125 1-1/2 BCFKF

PS-446 C12.500 1-3/4 BCFJF 10037002

PS-2142 C 1 2.500 1-3/4 BCFJF 10037000

PS-448V-C12.500 1-3/4 VCFKF 10037002CNV

CMS

PS-448V- C 1 2.500 1-3/4 VLFLF 10037002SSV

SC-SC

GRUNDFOS CBS, INC. (For Additional Listings - See Pages 166-167)

PS-1618 C 1 1.250 5/8 BCFJF B 14032695, 91868262

PS-974 A — — 3/4 BCF-F 91867994

PS-768 C 3 1.375 3/4 BCFKF 91868257

PS-112V C 3 1.375 3/4 VCFKF 91868215

PS-154 C — — 1-1/4 BCF-F 91868171

PS-185 C 11.875 1-1/4 BCFJF 91868317

PS-1109V C 3 1.875 1-1/4 VCFKF 91868217

PS-361- E 11.875 1-1/4 BCFJF I 91867954

P66

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

A. MOUNTS ON SHAFT

I. ABRASION RESISTANT CARBON (P66)

N. NON-STANDARD SPRING HOLDER

GRUNDFOS CBS, INC. (continued) (For Additional Listings - See Pages 166-167)

PS-264- E 3 1.875 1-1/4 BCFKF I 91867962

P66

PS-137V- E 3 1.875 1-1/4 VCFKF I 91867976

P66

PS-3974 D Bal. 1 1.875 1-3/8 BCFJF 91867955

PS-2105 C — — 1-1/2 BCF-F 91868172

PS-2106 E — — 1-1/2 BCF-F 91868014

PS-2108 C — — 1-3/4 BCF-F 91868173

PS-2108V C — — 1-3/4 VCF-F 91868252

PS-2142 C 1 2.500 1-3/4 BCFJF 91868269

PS-2151 C 3 2.500 1-3/4 BCFKF 91868260

PS-2151- C 3 2.500 1-3/4 BCFZF 91868230

TC-SEAT

PS-2151V C 3 2.500 1-3/4 VCFKF 91868219

PS-2109 E — — 1-3/4 BCF-F 91868003, 91868293

PS-2109- E — — 1-3/4 QCF-F 91868466

EPR

PS-205 E 1 2.500 1-3/4 BCFJF 91867956

PS-205V- E 1 2.500 1-3/4 VCFJF 96702875

CMS

PS-262 E 3 2.500 1-3/4 BCFKF 91867963

PS-449 K 1 2.500 1-3/4 BCFJF 91868291

PS-674 T 1 2.500 1-3/4 BCFJF 91868024

PS-477- E 3 2.750 2 BCFKF I 91868207

P66

PS-2111 C — — 2 BCF-F 91868174

PS-3537 C 1 3.125 2-1/4 BCFJF 91868272

FA-2098 E — — 2-3/8 BCF-F 91868099

GUSHER PUMPS

PS-164 B 9 — 1/2 BMFKF A

PS-1002 C 1 1.000 1/2 BCFJF N 84076-3

PS-701V A 1 1.187 5/8 VCFKF 84090

PS-957 A 1 1.187 5/8 BCFJF 84081

PS-359 C 1 1.250 5/8 BCFJF 84000-2, 84000-30

PS-1079 C 1 1.250 5/8 NCFJF

PS-1080 C 1 1.250 5/8 NCFKF

PS-359V- C 1 1.250 5/8 VCFJF 84000-24

CMS

PS-359V- C 1 1.250 5/8 VCFLF 84000-38

SC-CMS

PS-441 B 9 — 3/4 BMFKF A 84082

PS-358V- C 1 1.375 3/4 VZFZF 84064-6

TC-TC

PS-309 C 1 1.500 7/8 BCFJF 84079-2

PS-3941 C 1 1.500 7/8 VLFLF 84079-9

PS-2026 D3 1.500 7/8 BCFJF 84138-1

PS-370 A 1 1.625 1 BCFKF 84089

PS-235 C11.625 1 BCFJF 84001-2, 84001-12

PS-235V- C 1 1.625 1 VCFJF 84001-10

CMS

PS-235V- C 1 1.625 1 VLFLF 84001-14

SC-SC

PS-2216V- C 1 1.625 1 VZFZF 84176-2

CMS

PS-2122 C11.875 1-1/4 BCFJF 84002-31

PS-2123 C 1 1.875 1-1/4 BCFKF 84002-17

PS-1081 C 1 1.875 1-1/4 NCFJF

PS-1083 C 1 1.875 1-1/4 NCFJF

PS-1082 C 1 1.875 1-1/4 NCFKF

PS-1084 C 1 1.875 1-1/4 NCFKF

PS-1084- C 1 1.875 1-1/4 NCFZF 84002-27, 84008-27

TC-SEAT

PS-2215 C 1 1.875 1-1/4 QCFJF I 84002-18, 84002-3

84002-55

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

NOTE:

C.COMPLETE WITH COLLAR

I. ABRASION RESISTANT CARBON (P66)

GUSHER PUMPS (continued)

PS-4053 C 1 1.875 1-1/4 QLFLF 84002-57

PS-185V- C 1 1.875 1-1/4 VCFJF 84217-3

CMS

PS-2123V- C 1 1.875 1-1/4 VCFKF 84002-12

CMS

PS-2123V- C 1 1.875 1-1/4 VCFZF 84002-34

TC-CMS

PS-185V- C 1 1.875 1-1/4 VLFLF 84217-1

SC-SC

PS-7805 C 1 1.875 1-1/4 VLFLF 84002-22, 84002-50

PS-2122V- C 1 1.875 1-1/4 VZFLF 84002-41, 84002-58

TC-SC-CMS

84002-59

PS-210- C 1 2.000 1-3/8 BCFZF 84105-14

TC-SEAT

PS-177V- C 1 2.000 1-3/8 VCFJF 84144-2

CMS

PS-210V- C 1 2.000 1-3/8 VCFKF 84105-7

CMS

PS-177V- C 1 2.000 1-3/8 VLFLF 84015-18

SC-SC

PS-210V- C 3 2.000 1-3/8 VZFLF 84105-5

TC-SC

PS-758 C 1 2.125 1-1/2 BCFJF 84109-1

PS-758V- C 1 2.125 1-1/2 VLFLF 84109-2

SC-SC

PS-2107 C — — 1-5/8 BCF-F 84004-55

PS-238 C 1 2.375 1-5/8 BCFJF 84004-28

PS-239 C 1 2.375 1-5/8 BCFKF 84004-18

PS-238- C 1 2.375 1-5/8 BZFLF 84002-40

TC-SC

PS-3664 C 1 2.375 1-5/8 BZFZF 84004-30

PS-238- C 1 2.375 1-5/8 QCFJF 84004-34

EPR

PS-7902 C 1 2.375 1-5/8 VCFJF 84004-46

PS-238V- C 1 2.375 1-5/8 VCFJF 84004-26

CMS

PS-239V- C 1 2.375 1-5/8 VCFKF 84004-7

CMS

PS-238V- C 1 2.375 1-5/8 VCFZF I 84004-20

P66-TC

PS-7806 C 1 2.375 1-5/8 VLFLF 84004-23, 84004-39

PS-238V- C 1 2.375 1-5/8 VZFLF 84004-42, 84004-48

TC-SC-CMS

84004-49, 84004-55

PS-2057 E 1 2.375 1-5/8 BCFJF 84005-2, 84005-15

PS-2058V- E 1 2.375 1-5/8 VCFZF 84005-28

TC-SEAT

PS-1699E- E 3 2.375 1-5/8 QCFZF I 84005-27

TC-P66

PS-446V- C 1 2.500 1-3/4 VCFJF 84006-11

CMS

PS-7561 E 3 2.500 1-3/4 VCFZF C/I 84007-15

PS-7901 E Bal. 1 2.375 1-3/4 BCFJF 84004-46

PS-9106 W 2 2.500 1-3/4 TCFJF 316SS 84010-01

PS-267 C 1 2.750 2 BCFJF 84176-1

PS-267V- C 1 2.750 2 VCFJF 84176-2

CMS

PS-6224 C 1 2.750 2 VLFLF 84176-4

PS-1613 K 3 3.375 2-1/2 BCFJF 84059-5

HAIGHT PUMP

PS-825 D 3 2.500 1-3/4 BCDKF AP13.518X

PS-237V D 3 2.500 1-3/4 VCDJF AP13.518Y

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

44 NOTE:

B.TAPERED SPRING

G. MOUNTS IN PLASTIC

H. SPRING HOLDER NOT INCLUDED

N. NON-STANDARD SPRING HOLDER

HALE PRODUCTS, INC.

PS-201 A 1 1.375 3/4 BMFJF 292-5040-00-3

PS-851 A 1 1.375 3/4 BCFJF 296-5040-00

PS-360 A 1 1.625 1 BCFJF 296-5010-00

PS-235 C 1 1.625 1 BCFJF Model: 20FD 106434 25D-G444, 1001-02-20-00

PS-1048 C 1 1.625 1 BCFJF H 296-5060-00-0

PS-548 C 3 1.625 1 BCFJF 296-5060-06-0

PS-1049 C 3 1.625 1 BCFJF H

PS-356 C 1 1.750 1-1/8 BCFJF 296-5220-00

PS-177 C 1 2.000 1-3/8 BCFJF 296-5250-99

PS-495 K 1 2.000 1-3/8 BCFJF 296-5070-00

PS-347 C 1 2.125 1-1/2 BCFJF B/H

PS-758 C 1 2.125 1-1/2 BCFJF 296-5021-03

PS-378 C 1 2.125 1-1/2 BCFKF B/H 296-5020-06

PS-659 C 1 2.125 1-1/2 BCFKF 296-5021-01

PS-2209 C 1 2.125 1-1/2 BZFZF 296-5021-06-0

PS-267 C 1 2.750 2 BCFJF 296-5210-00

HALL SCOTT

PS-200 A 1 1.250 5/8 BMFJF

PS-750 D 1 1.375 3/4 BCDJF Pump 390

HAYWARD GORDON

PS-436- C 3 2.500 1-3/4 BZFZF 54099158

TC-TC

HAYWARD INDUSTRIES, INC.

PS-2131 A 1 — 5/8 BMFJF G Power-Flo LX, Power-Flo®Matrix, SPX1500KA

Power-Flo II®,Turbo Flo®

PS-200 A 1 1.250 5/8 BMFJF Cast Iron SPX1250XZ2C

PS-3960 G 1 1.250 5/8 BCFJF SPX1250XZ2

SPX-2700SA

PS-3890 G 1 1.381 5/8 BCFJF NorthStar, Tri-Star SPX-3200SA, SPX-4000,

SPX4000SA, SPX4000SA2

PS-201 A 1 1.375 3/4 BMFJF Max-Flo®,Super Pump®,Super Pump II®

SPX1600Z2, SPX1600Z2G

PS-370 A 1 1.625 1 BCFKF

HOBARTCORP.

PS-631 C 1 1.000 1/2 BCFJF N R23682

PS-663 Q 1 1.000 1/2 BMFJF C115710

PS-6313 Q 1 1.019 1/2 BCFJF 185694-4

PS-1085V C 1 1.250 5/8 VCFJF B A104329, 00-114696

PS-235 C 1 1.625 1 BCFJF R79205

PS-539 C 1 1.625 1 BCFJF H R87809

PS-754 E11.625 1 BCFJF

PS-754V E 3 1.625 1 VCFJF A104330

PS-6318 Q91.578 1-1/8 VMFAF 00-117071

PS-6317 Q 9 2.000 1-3/8 VMPSP 00-114144

PS-3854 Q25 2.000 1-3/8 BMPAP C114144

PS-4041 Q 1 3.375 2-1/4 VMPSP 00-117072

HOLLAND PUMP MFG.

PS-2209 C 1 2.125 1-1/2 BZFZF

PS-2060- D 1 2.500 1-3/4 BZFZF 6TP

TC-TC

PS-340 C 1 2.625 1-7/8 BCFJF

PS-340- C 1 2.625 1-7/8 BZFZF 8TP

TC-TC

HOMART-SEARS

PS-162 A 1 1.000 1/2 BMFJF 259-043, W6476

PS-100 A 1 1.187 5/8 BMFJF 42G2377W

PS-508 D 1 1.250 5/8 BCDJF 759-31

HOMELITE

PS-200 A 1 1.250 5/8 BMFJF 62729

PS-711 A 31.187 5/8 BMFJF A-62861-2

PS-201 A 1 1.375 3/4 BMFJF A-75911

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

A. MOUNTS ON SHAFT

B.TAPERED SPRING

H. SPRING HOLDER NOT INCLUDED

HOMELITE (continued)

PS-601 B 1 1.375 3/4 BMFJF 43271

PS-601V- B 1 1.375 3/4 VCFJF Models AP302,AP502

CMS

PS-360 A 1 1.625 1 BCFJF A-62403

PS-1086 A 3 2.000 1 BCFJF A-62713, A-62713-1

PS-235 C 1 1.625 1 BCFJF 47046

PS-466 C 1 2.000 1-1/4 BCFJF 46150

HOYT CORP.

PS-6301 Q 3 3.000 2-1/4 NMPAP 28-488

HYDROMATIC PUMP CO. (See PENTAIR, INC. for Additional Part Numbers)

PS-1621 Q 9 — 1/2 BMFJF A 05484-000-1

PS-299 A — — 5/8 BMF-F

00083-002-1, 00083-007-1

PS-200 A 1 1.250 5/8 BMFJF

00083-000, 00083-001

14525A010

PS-200V- A 1 1.250 5/8 VCFJF 00083-010-1

CMS

PS-447 B 8 — 5/8 BCFJF A 07548-000-1

PS-359 C 1 1.250 5/8 BCFJF 01556-000-1

PS-6216 C 1 1.250 5/8 VZFZF 11397-001-1

PS-851 A 1 1.375 3/4 BCFJF 17048-000-1

PS-201V- A 1 1.375 3/4 VCFJF 17048-001-1

CMS

PS-1622 B 9 — 3/4 BMFJF A 04917-000-1

PS-358 C 1 1.375 3/4 BCFJF 00100-000-1

PS-703 D 1 1.500 7/8 BCDJF 11716A011

PS-235 C 1 1.625 1 BCFJF HPLX200 00300-000-1

PS-235- C 1 1.625 1 BLFLF 00300-004-1

SC-SC

PS-2216 C 1 1.625 1 BZFZF 00696-000-1

PS-235V- C 1 1.625 1 VCFJF 00300-001-1

CMS

PS-2216V- C 1 1.625 1 VZFZF 00300-003-1

CMS

PS-185 C 1 1.875 1-1/4 BCFJF 04916-000-1

PS-185- C 1 1.875 1-1/4 BLFLF 04916-003-1

SC-SC

PS-2208 C1 1.875 1-1/4 BZFZF 04916-001-1

PS-185E- C 1 1.875 1-1/4 QCFLF 04916-005-1

SC-CMS

PS-185V- C 1 1.875 1-1/4 VCFJF 04916-002-1

CMS

PS-185V- C 1 1.875 1-1/4 VZFLF 04916-006-1

TC-SC

PS-185V- C 1 1.875 1-1/4 VZFZF 04916-004-1

TC-TC

PS-347 C12.125 1-1/2 BCFJF B/H 08100-000-5

PS-758 C 1 2.125 1-1/2 BCFJF 00920-001-1

PS-758- C 1 2.125 1-1/2 BLFLF 00920-013-1

SC-SC

PS-758-SC- C 1 2.125 1-1/2 BLFZF 00920-011-1

TC-CMS

PS-2209 C 1 2.125 1-1/2 BZFZF 00920-004-1

PS-7409 C 1 2.125 1-1/2 VCFJF 316SS 00920-003-1, 00920-005-1

00920-007-1

PS-659V- C 1 2.125 1-1/2 VZFZF 00920-009-1, 00920-014-1

TC-VS-TC

PS-446 C 12.500 1-3/4 BCFJF 11049-001-1

PS-446- C 1 2.500 1-3/4 BZFZF 11049-002-1

TC-TC

PS-2212- C 1 2.500 1-3/4 BZFZF 21181A015

TC-TC

PS-340 C 1 2.625 1-7/8 BCFJF 14859-000-1

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

B.TAPERED SPRING

HYDROMATIC PUMP CO. (continued) (See PENTAIR, INC. for Additional Part Numbers)

PS-340- C 1 2.625 1-7/8 BZFLF 14859-003-1

TC-SC

PS-340- C 1 2.625 1-7/8 BZFZF 14859-001-1

TC-TC

PS-267 C 1 2.750 2 BCFJF 01957-000-1

PS-267-SC- C 1 2.750 2 BLFLF 01957-005-1

SC-CMS

PS-2219 C 1 2.750 2 BZFZF 01957-002-1

PS-3810V- C 1 2.750 2 VCFJF 01957-010-1

CMS

PS-267V- C 1 2.750 2 VCFJF 01957-001-1

CMS

PS-6218 C 1 2.750 2 VZFZF 01957-004-1

PS-1087 C 1 3.125 2-1/4 BCFJF 08073-000-1

PS-7064 C 1 3.125 2-1/4 BZFZF 08073-001-1

PS-1679V- C 1 3.125 2-1/4 VCFJF 08073-003-1

CMS

PS-3530 E 3 3.125 2-1/4 B/VZFZF 1100148SC2

PS-1088 C 3 3.875 3 BCFJF B 03718-000-1

PS-761 D 3 3.875 3 BCDJF 43421-001-1

HYPRO CORP. (See PENTAIR, INC. for Additional Part Numbers)

PS-1050 C — — 1/2 BCF-F 10522C

PS-3001 G 3 1.000 1/2 VCFJF 24608

PS-3002 G 3 1.000 1/2 VCFJF 316SS 24766

PS-516 A 1 1.250 5/8 BCFJF 9501-3, 2120-0008

PS-200V- A 1 1.250 5/8 VCFJF Model Nos. 9203, 9401C, 9300C-HM 2120-0009

CMS

PS-200V A 3 1.250 5/8 VCFJF 9501-4, 9202-C

PS-3741 B 1 1.250 5/8 VLFLF 24466

PS-359V C 3 1.250 5/8 VCFJF

PS-4442 C 3 1.250 5/8 VCFKF 2120-0003

PS-3006 G 1 1.250 5/8 BCFJF 316SS 24275

PS-4220 G 1 1.250 5/8 VCFJF 24609

PS-3005 G 3 1.250 5/8 VLFLF 316SS 2120-0039

PS-851 A 1 1.375 3/4 BCFJF 2120-0010

PS-201V- A 1 1.375 3/4 VCFJF 9000 Series 2120-0011

CMS

PS-201V A 3 1.375 3/4 VCFJF 9501-50

PS-3009 G1 1.500 7/8 BCFJF 316SS 24458

PS-360 A 1 1.625 1 BCFJF 24607, 2120-0054

PS-360V-A11.625 1VCFJF 2120-0034, 24611

CMS

PS-397 C — — 1 BCF-F 21399

PS-3012 G11.750 1-1/8 BLFLF 316SS 23906

PS-3015 G 25 2.000 1-3/8 VLFLF 316SS 2120-0043

ICEE DISTRIBUTORS

PS-6234 C 1 1.250 5/8 BCFJF 0-ID1339

IMO INDUSTRIES, INC.

PS-2138 C

Special

1.360 1/2 BCFGF PP046JCE

PS-3729 X 3 1.000 1/2 BCFKF PP046JRF

PS-7727

XSpecial

3 1.000 1/2 VCFGF PP046JRH

PS-4313 C

3Special

1.500 5/8 VCFGF PP046JC/C

PS-752 D 1 1.375 3/4 BCDKF PP046DP

PS-687 C 1 1.500 7/8 BCFKF PP046H

PS-3824 C 28 2.438 1 VCFKF PP046JM

PS-1034V C 28 2.438 1 VCFKF PP046JCH

PS-7991 D 25 1.625 1 BCPGP PP046DF

PS-4255 DBal. 31.500 1VCFZF PP046KDA

PS-8091 X 31.625 1 VCFRF 316SS PP046JZC

PS-1044 C 28 2.834 1-3/16 BCFKF PP046JL

PS-1044V C 28 2.834 1-3/16 VCFKF PP046JHG

PS-4152 C 3 1.875 1-1/4 BCFGF PP046JLC/C

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

A. MOUNTS ON SHAFT

I. ABRASION RESISTANT CARBON (P66)

IMO INDUSTRIES, INC. (continued)

PS-598- C 3 1.875 1-1/4 BCFLF PP046JFF

SC-SEAT

PS-1036 C 28 2.835 1-1/4 BCFKF PP046JH, PP046JH/C

PS-1036V C 28 2.835 1-1/4 VCFKF PP046JN

PS-4431 D 3 1.875 1-1/4 VLFLF

PS-8073 X 28 2.832 1-1/4 VCFKF 316SS PP046JBS, PP046JBS/CR

PS-3979 C

Special

2.740 1-1/2 BCFKF PP046JAH

PS-371 D 1 2.125 1-1/2 BCFKF PP046DAA

PS-1035 C 28 3.544 1-5/8 BCFKF PP046JK

PS-1039 C 28 3.544 1-5/8 VCFKF PP046JR, PP046JRC

PS-436- C 3 2.500 1-3/4 BCFLF PP046JDT

SC-SEAT

PS-1038 C 28 3.544 1-3/4 BCFKF PP046JG

PS-1038V C 28 3.544 1-3/4 VCFKF PP046JGJ

PS-8058 X 3 2.500 1-3/4 VCFLF 316SS PP046JWF

PS-462 D 1 2.750 2 BCDKF PP046BP

PS-1676 C 3 3.125 2-1/4 BCFKF PP046JCD

PS-1677 C 28 5.118 2-3/8 BCFKF PP046FBY

PS-8003 X 3 3.250 2-3/8 VCFLF 316SS PP046JTT

PS-3862 X 3 4.375 3.500 VCFKF 316SS PP046JZM

INGERSOLL-DRESSER PUMPS AND COMPRESSORS (See FLOWSERVE CORP.)

PS-164 B 9 — 1/2 BMFKF A

PS-200 A 1 1.250 5/8 BMFJF CPM-6252C1, CPM-

6258C1

PS-507V A 3 1.250 5/8 VCFKF CPM-625271, CPM-625871

PS-600 B 1 1.187 5/8 BMFJF Bronze Fitted KRVSA-3/4, 1-1/4, CPM-10015

Model B 1/4 to 1-1/2 HP Motors

PS-616 B 1 1.187 5/8 BMFKF Iron Fitted KRVSA-3/4, 1-1/4, CPM-10029, 60110269

Model B 1/4 to 1-1/2 HP Motors

PS-359 C 1 1.250 5/8 BCFJF 1x 4, -3/4,1,1-1/4, 2 x 5 HK & HOK CPM-6251C1

PS-633 C 1 1.250 5/8 BCFKF 1x 4, 3/4, 1, 1-1/4, 1-1/2, 2 x 5 HK CPM-625171

PS-760 A 3 1.375 3/4 BMFJF SMP 1000 & SMP 2000 CPM-10600A

PS-601 B 1 1.375 3/4 BMFJF CPM-10034, 60116225

PS-606 B 1 1.375 3/4 BMFKF CPM-10035, 60110301

PS-564 C — — 3/4 BCF-F 02443900

PS-3654 C 1 1.375 3/4 BCFKF SMP2000

PS-2236 C 3 1.375 3/4 BCFJF SMP2000 1802ATY210RM075BF1C1

60721792, 60980901

PS-2235 C 3 1.375 3/4 VCFJF CPM-10606A, 60724572

PS-7994 E 3 1.187 3/4 VCFKF 1802AJCTYPIR075XP171

PS-303 D 1 1.500 7/8 BCDKF SMP2000 W-11448, W-20168

PS-602 D11.562 7/8 BCDJF KRVS-1-1/2, 2, 3 1/4 to 1-1/2 HP CPM-10052

PS-603 D 1 1.562 7/8 BCDKF KRVS CPM-10053

PS-7859V E 3 1.312 7/8 VCFKF 316SS 1802AJCTYP1R088BF171

PS-560V U 3 1.562 15/16 VCFKF 7GA 1802AJCTYP1R094

03144601, 74744319

PS-801 C 3 1.750 1-1/8 BCFJF 3 x 5 HK, 3 x 6 HK & HOK CPM-1121C1, 60487089

PS-2226 C31.750 1-1/8 QCFZF I 3 x 5 HK, 3 x 6 HK, HOK CPM-112171

PS-355V C 3 1.750 1-1/8 VCFKF 39633201, 39757141

PS-604 D 1 1.750 1-1/8 BCFJF Bronze Fitted KRVS-1, 1-1/2, CPM-10054

2.3 2 to 25 HP Motors CPM-10026, 60110434

PS-605 D 1 1.750 1-1/8 BCFKF Iron Fitted KRVS-1, 1-1/2, CPM-10055, 60110442

2.3 2 to 25 HP Motors

PS-521 D 1 1.875 1-1/8 BCFKF W-31826

PS-607 E1 1.687 1-1/8 BCFJF Bronze Fitted 1, 2 RVN-1 1-1/2, 2, 3 RVNL CPM-10043, 60110327

1-1/2, 2 RV and RVH-3RVS ,1-1/2 RVL

PS-608 E 1 1.687 1-1/8 BCFKF Iron Fitted 1, 2 RVN-1 1-1/2, 2, 3 RVNL CPM-10044, CPM-10087

1-1/2, 2 RVand RVH-3RVS,1-1/2 RVL 60110335

PS-867 E 3 1.750 1-1/8 BCFKF 68885865, 69237592

PS-4421 E 3 1.750 1-1/8 QCFJF 316SS

PS-204V E 3 1.750 1-1/8 VCFJF CPM-10715A, 60954682

PS-867V E 3 1.750 1-1/8 VCFKF CPM-10715B, 68885847

PS-867V- E 31.750 1-1/8 VCFZF 1802AJCTYP1A112XF1D1

TC-SEAT 60954716

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

I. ABRASION RESISTANT CARBON (P66)

INGERSOLL-DRESSER PUMPS AND COMPRESSORS

(continued) (See FLOWSERVE CORP.)

PS-1636 E 3 1.812 1-1/8 B/VCFJF H/HC/VOC/HOC CPM-10465A, CPM-10470A

PS-1637 E 3 1.812 1-1/8 B/VCFKF H/HC/VOC/HOC CPM-10406B, CPM-10465B

CPM-10470B

PS-619 E 3 1.812 1-1/8 BCFJF Long Nose Carbon CPM-10217A, CPM-10220A

PS-948 E 3 1.812 1-1/8 BCFKF Long Nose Carbon CPM-10220B, CPM-10217B

PS-1668 E 3 1.812 1-1/8 BCFZF CPM-10465C, CPM-10470C

PS-1639V E 3 1.812 1-1/8 VCFKF CPM-10406B

PS-1172V E 3 1.812 1-1/8 VCFJF 6 VOC 7 HOC CPM-10406A

PS-3511 T 3 1.750 1-1/8 VCFJF HOC2 & VOC 2 1802AJCTYP1DBLXF1C1

PS-343 E 1 1.875 1-3/16 BCDKF CPM-118S429X2

PS-310 E 1 1.875 1-3/16 BCDJF CPM-118S429X5

PS-723 T 1 1.875 1-3/16 BCDJF Models DHV and DMV CPM-118S429X4, 60111267

PS-724 T 1 1.875 1-3/16 BCDKF Models DHV and DMV CPM-118S429X3

PS-185 C 1 1.875 1-1/4 BCFJF CPM-10601A

PS-756 C 1 1.875 1-1/4 BCFKF W-44104

PS-618 C 3 1.875 1-1/4 BCFJF SMP 3000 & SMP 2000 1802ATY210RM125BF1C1

60721800, 60980918

609809-19, CPM-10601A

PS-185V C 3 1.875 1-1/4 VCFJF CPM-10613A

PS-598- C 3 1.875 1-1/4 QCFKF CPM-10604A

EPR 1802TY210RM028F171

PS-756V C 3 1.875 1-1/4 VCFKF 74898800

PS-618V- C 3 1.875 1-1/4 VCFZF CPM-10709, 60727401

TC-SEAT

PS-2203 C 3 1.875 1-1/4 QCFKF I

1802ATY210RM125028F171

68867910

PS-416 D — — 1-1/4 BCF-F 74898800, W-32652

PS-3973 U 2 1.875 1-1/4 BCPKF

PS-467 C 1 2.125 1-3/8 BCFKF W-28861, W-21642

PS-354 E 1 2.000 1-3/8 BCFJF CPM-137S429X5

PS-677 E 1 2.000 1-3/8 BCFKF CPM-137S429X2

PS-3925 E 3 2.125 1-3/8 VCFJF 1802AJCTYPEA138XF1C1

74816117

PS-725 T 1 2.000 1-3/8 BCFJF CPM-137S429X4

60111275

PS-726 T 1 2.000 1-3/8 BCFKF CPM-137S429X3

PS-371 D 1 2.125 1-1/2 BCFKF W-27658

PS-2106 E — — 1-1/2 BCF-F 3879AJCTYP1A150BF1-1

68886183, 68886175

PS-2106V E — — 1-1/2 VCF-F CPM-10369ABC

CPM-10407ABC

3879AJCTYPA150XF-I

80612400

PS-305 E 1 2.125 1-1/2 BCFJF GTB CPM-10367A

CPM-10368B

PS-395 E 3 2.125 1-1/2 BCFJF CPM-10132

PS-258 E 3 2.125 1-1/2 BCFKF GTB CPM-10129, CPM-10367B

CPM-10368B,6886100

PS-305V E 3 2.125 1-1/2 VCFJF GTB CPM-10369A, 68886068

1802AJCTYP1A150XF1C1

PS-374V E32.125 1-1/2 VCFKF GTB CPM-10369B

1802AJCTYPIRXP171

1802AJCTYP1A150XF171

PS-620 E 3 2.312 1-1/2 BCFJF Long Nose Carbon CPM-10218A

CPM-10221A

PS-629 E 3 2.312 1-1/2 BCFKF Long Nose Carbon CPM-10218B

CPM-10221B

PS-4034 E 3 2.312 1-1/2 BCFZF CPM-10466C, 60514148

PS-1647 E 3 2.312 1-1/2 B/VCFJF H/HC CPM-10466A

CPM-10471A

PS-1648 E 3 2.312 1-1/2 B/VCFKF H/HC CPM-10466B, CPM-10471B

60514288

PS-1651 E 32.312 1-1/2 VCFJF H/HC CPM-10473A, 60514122

PS-620V E 32.312 1-1/2 VCFJF Long Nose Carbon CPM-10224A

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

I. ABRASION RESISTANT CARBON (P66)

INGERSOLL-DRESSER PUMPS AND COMPRESSORS

(continued) (See FLOWSERVE CORP.)

PS-1652 E 3 2.312 1-1/2 VCFKF H/HC CPM-10473B, 60514726

PS-1691 E 3 2.312 1-1/2 VCFKF Long Nose Carbon CPM-10224B

PS-1692 E 3 2.312 1-1/2 VCFZF Long Nose Carbon CPM-10224C

PS-818 C 3 2.375 1-5/8 BCFJF SMP 3000 CPM-10602A, 60721818

PS-609 E 1 2.312 1-5/8 BCDJF 2, 3, 4 and 5RVL-3 RVH-1-1/2 ORVL CPM-10045, 60110343

PS-484 E 1 2.312 1-5/8 BCDKF X33548P1

PS-346 E 1 2.312 1-5/8 BCFJF 3 RVL CPM-10028

PS-610 E 1 2.312 1-5/8 BCFKF 2, 3, 4 and 5RVL-3 RVH-1-1/2 ORVL CPM-10046, 60110350

PS-859-TC- E 3 2.500 1-3/4 BCFZF S-Line Series 100 CPM-10347

SEAT

PS-7950 E 3 2.500 1-3/4 QCFZF I 748409-92

PS-4139 E 3 2.625 1-3/4 VCFKF 1802ATCTYP1R175XF171

PS-674 T 1 2.500 1-3/4 BCFJF 3, 4, 5 RVL and CRVL CPM-10024

PS-722 E 1 2.625 1.771 BCFJF CPM-177S429X5

PS-719 E 1 2.625 1.771 BCFKF CPM-177S429X2

PS-727 T 1 2.625 1.771 BCFJF CPM-177S429X4

PS-728 T 1 2.625 1.771 BCFKF CPM-177S429X3

PS-340- C 1 2.625 1-7/8 QCFJF CPM-10656

EPR-CMS

PS-2069 E 1 2.625 1-7/8 BCFJF CPM-10370A

PS-2071 E 3 2.625 1-7/8 BCFJF CPM-10371A

PS-2072 E 3 2.625 1-7/8 BCFKF 3GT CPM-10158, CPM-10370B

CPM-10371B

1802AJCTYP1A188B/XF171

6043421,68885987

PS-1659 E 3 2.625 1-7/8 VCFJF GTB CPM-10372A

1802AJCTYPA188XF1C1

60954757

PS-1660 E 3 2.625 1-7/8 VCFKF GTB CPM-10372B, 60954807

68859601

PS-1661 E 3 2.625 1-7/8 VCFZF CPM-10716C

1802AJCTYP1A188-XF1D1

PS-949 E 3 2.687 1-7/8 BCFKF Long Nose Carbon CPM-10219B

CPM-10222B

PS-1662 E 3 2.687 1-7/8 B/VCDJF VOC/HOC CPM-10467A

PS-1664 E 3 2.687 1-7/8 B/VCFJF VOC/HOC Long Nose Carbon

CPM-10219A, CPM-10222A

CPM-10461A, CPM-10467B

CPM 10472B

PS-1663 E 3 2.687 1-7/8 B/VCDJF H/HC/VOC/HOC

PS-7020 E 3 2.687 1-7/8 VCFJF

CPM-10225A, CPM-10408A

PS-1653 T 3 2.687 1-7/8 VCFJF HOC 6 x 4 x 13 CPM-10278

PS-530 E 3 2.750 2 BCFJF

PS-477 E 3 2.750 2 BCFKF S Line Item 206 CPM-200S429X2

CPM-200S429X7

PS-342 E 3 2.750 2 NCPKP 1-1/2, 2 and 3 VM-1-1/2 and 3 VL CPM-10130

3VLA Vertical Pumps and S Line CPM-200S429X1

PS-611 E 3 2.812 2-1/8 BCFJF All Bronze Fitted Pumps

1-1/2, 2 MRV-5 RVH, 6 RVL, 50RVL D CPM-10047

PS-1612 E 3 2.812 2-1/8 BCFKF All Iron Fitted Pumps CPM-10048, 60110376

1-1/2, 2 MRV-5 RVH, 6 RVL, 50RVL D

PS-2086 E 3 3.000 2-1/8 BCFKF Series 100S CPM-10351

PS-278 E 3 3.250 2-3/8 BCFJF HOC CPM-10469A

PS-350 E 3 3.250 2-3/8 BCFKF 4GT/S/HOC CPM-10159, CPM-10469B

PS-278V E 3 3.250 2-3/8 VCFJF HOC 1802AJCTYP1A238-XF1C1

6003427, 60969797

PS-2098V E 3 3.250 2-3/8 VCFKF CPM

-10718B, CPM-10251B

PS-279 E 3 3.375 2-1/2 BCFJF CPM-10134

PS-349 E 3 3.375 2-1/2 BCFKF S Line Item 208 CPM-250S429X2

CPM-250S429X7

69261360

PS-321 E 3 3.500 2-3/4 V/BCFKF S Line Series 100 CPM-10355

PS-475 E 3 3.875 3 BCDKF 6GT

PS-325SS U 3 4.125 3-1/4 BCFKF S Line 211, 8 x 14SD,10 x 14SD CPM-325S429X2

69261378

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

I. ABRASION RESISTANT CARBON (P66)

N. NON-STANDARD SPRING HOLDER

INSINGER MACHINE CO.

PS-204 E 1 1.750 1-1/8 BCFJF B15

ITT INDUSTRIES (See A-C Pump, Bell & Gossett, Domestic Pump, Jabsco, Marlow)

ITT R&CW (ITT RESIDENTIAL & COMMERCIAL WATER PUMPS)

PS-3926 B 9 1.062 5/8 VCFKF 316SS A00202C 1

PS-544V- C 3 2.375 1-5/8 VLFLF 76407 3625

SC-SC

PS-3993 C 3 2.750 2 BCFJF 76407 1200

JABSCO (Div. of ITT INDUSTRIES)

PS-642 B — — 5/8 BMF-F Seat is Impeller 1/2” Motor Pump

PS-382 D 1 2.125 1-1/2 BCFJF

3200 and 3200-01, 3200-21

JACUZZI (Div. of STA-RITE INDUSTRIES)

PS-162 A 1 1.000 1/2 BMFJF 10-563

PS-631 C 1 1.000 1/2 BCFJF N Model 5AM 10-564

PS-200 A 1 1.250 5/8 BMFJF Cygnet K,KM, Vector LVLA, J, JCM, 10-467, 10-1436-00

LCM, LCU and LR Series 10-0002-06

PS-290 C 1 1.250 5/8 BCFJF 10-1202, 10-1203

7524000

PS-359 C 1 1.250 5/8 BCFJF 10-478, 10-506

PS-102 D 1 1.250 5/8 BCDKF 10-502

PS-201 A 1 1.375 3/4 BMFJF Model 5RP, SF, Magnum, RC-Series 10-477,10-486, 10-120

10-1390-04,10-1502-09

PS-358 C 1 1.375 3/4 BCFJF 10-479

PS-877 C 1 1.375 3/4 BCFJF 8M 10-1203-01, 10-1203-19

PS-683 C 1 1.500 3/4 BCFJF 10-100

PS-750 D 1 1.375 3/4 BCDJF 10-503

PS-235 C 1 1.625 1 BCFJF 10M 10-504, 10-1299-06

PS-204 E 1 1.750 1-1/8 BCFJF 10-505

PS-185 C 1 1.875 1-1/4 BCFJF 10-0369-29, 10-1400-02

PS-2122 C 1 1.875 1-1/4 BCFJF 10-0369-03

PS-209 K — — 1-3/8 BCF-F 10-315, 10-328

PS-758 C 1 2.125 1-1/2 BCFJF 10-1348-07

PS-2142 C 1 2.500 1-3/4 BCFJF 10-0307-00

PS-205 E 1 2.500 1-3/4 BCFJF 10-330

PS-213 R — — 1-3/4 BCD-F 10-323

PS-874 D 1 3.125 2-1/4 BCDJF 10-365

JAEGER

PS-201 A11.375 3/4 BMFJF

PS-360 A 1 1.625 1 BCFJF

PS-356 C 1 1.750 1-1/8 BCFJF 80237

PS-177 C 1 2.000 1-3/8 BCFJF 81031-1

PS-461 D 1 2.375 1-5/8 BCDKF 66319-1

PS-876 D 1 2.625 2 BCDKF 66435-1

JANDY

PS-1000 B 1 1.250 5/8 BMFJF P84-60 P55

PS-3890 G1 1.381 5/8 BCFJF PB-460Q P84-3

PS-4280 G 1 1.381 5/8 VCFJF FHP, JEP, MHP, PHP, SHP, SWF, WFTR R00479400

PS-4231 G 1

1.250/1.381

5/8 3/4 BCFJF R0445500

PS-601 B11.375 3/4 BMFJF HHP, HHPU R0338200

JOHNSON CONTROLS

PS-4026 D 3 2.500 1-3/4 NCFKF 029 22359 001

PS-6147 C — — 2-1/2 NCF-F 522M0007H01

PS-6151 D — — 2-5/8 NCP-P I 02913450 000

PS-4028 K

3Special

4.500 2-7/8 NCFGF 523B0201G01

JOY MFG. (See SULLIVAN PALATEK)

KADY INTERNATIONAL

PS-687 C 1 1.500 7/8 BCFKF 91381

PS-210 C 1 2.000 1-3/8 BCFKF 91379

PS-3541 T 3 2.000 1-3/8 VZFZF 316SS 118563

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

NOTE:

A. MOUNTS ON SHAFT

N. NON-STANDARD SPRING HOLDER

KENCO

PS-162 A 1 1.000 1/2 BMFJF Type 62, 63, 64, 65

PS-163 B 1 1.000 1/2 BMFJF AE001A1

PS-165 B 9 .906 1/2 BMFJF A 59A,140A

PS-200 A 1 1.250 5/8 BMFJF Model 139A New Style

PS-452 B 9 — 5/8 BMFJF A Model 109A New Style

PS-762 A 3 1.375 3/4 BMFKF Model 114 6A001A1

KINNEY VACUUM PUMP (Div. of TUTHILL VACUUM SYSTEMS)

PS-358 C 1 1.375 3/4 BCFJF KC2.5-15, KS-13

KC-5, KC-8(491)

PS-358V C 3 1.375 3/4 VCFJF 65046

PS-197 K — — 7/8 BCF-F SK-549

PS-357 C 1 1.625 1 BCFKF KS-27-47

PS-159 D 3 1.625 1 NCPGP VSM-778-8811 65024

PS-355 C 1 1.750 1-1/8 BCFKF KC-46

PS-177V C 3 2.000 1-3/8 VCFJF 065046-A-000

PS-659 C 1 2.125 1-1/2 BCFKF KD-110, KDH-130

PS-238V- C 1 2.375 1-5/8 VCFJF 065241-A000

CMS

PS-366 E 1 2.500 1-3/4 BCFKF KD-220, KDH-220

PS-462 D 1 2.750 2 BCDKF

PS-658 R 1 2.750 2 BCDKF KBM-1200, MB-17

KLEIN PRODUCTS OF KANSAS, INC.

PS-547 C 3 2.000 1-3/8 BCFKF 33011197

KRAISSL CO.

PS-150 B — — 1/2 BMF-F Seat is Impeller

LABCONCO CORP.

PS-6308 Q 9 1.250 .687 Special A 4485800

LANCASTER PUMP CO.

PS-150 B — — 1/2 BMF-F Laundro Pak Seat is Impeller 376 4761

PS-1002 C 1 1.000 1/2 BCFJF N Converto, Supreme Jet, MTR Jet, 1061

Type M 901 thru 906, Type P, all models

PS-200 A 1 1.250 5/8 BMFJF 2661

PS-1000 B 1 1.250 5/8 BMFJF 5236

PS-151 B 1 1.375 5/8 BMFJF Types S & SD Lancaster

Dutchman-1182, 1183, 1192, 1193 2461

PS-1005A B 1 1.375 5/8 BMFKF 2561

PS-447 B 8 — 5/8 BCFJF A Model 570, 575, 1775

PS-493 C 1 1.187 5/8 BCFKF 5256

PS-201 A 1 1.375 3/4 BMFJF Types S & SD Lancaster Dutchman-

1182, 1183, 1192, 1193 1661

PS-358 C 1 1.375 3/4 BCFJF Self Priming Pump Model 673 1361

PS-703 D11.500 7/8 BCDJF Turbo Pak Model 523BF- 524 BG 429 7/8

PS-360 A 1 1.625 1 BCFJF Type M-907 and M-908 7561

PS-381 D 1 1.875 1-1/4 BCFJF Type M-909 and M-910 909-61

LEAR SIEGLER (See SHERWOOD BRASS)

LECOURTENAY

WHEN SEAL IS MOUNTED ON A SHAFT,USE THE FOLLOWING

PS-866 E 3 1.750 1-1/8 BCFJF Models 3BA2, 2-1/2 -BA8

PS-546 E3 1.875 1-1/4 BCFJF Model 3BA7 11481

PS-864 E 3 2.000 1-3/8 BCFJF Models 4BA7, 3BA8, 4BA6, 6B3

PS-595 E 3 2.375 1-5/8 BCDJF Models 5BA6, 2-1/2 M7A 11485-8

PS-2069 E 1 2.625 1-7/8 BCFJF Models 4BA8, 5BA7

PS-530 E 3 2.750 2 BCFJF Model 8BA5 11393

PS-327 E 3 3.000 2-1/8 BCFJF Model 5MB7 15168-9, 23305

PS-848 E 3 3.125 2-1/4 BCDJF Models 6BA8, 8BA6, 10BA4/5 11479-80, 23300, 23304

PS-328 E 33.375 2-5/8 BCFJF Models 6B8, 10BA6, 10BA7 15165-7, 23301

PS-329 E 33.750 2-7/8 BCFJF Model 8BA8

WHEN SEAL IS MOUNTED ON A SLEEVE, USE THE FOLLOWING

PS-546 E 3 1.875 1-1/4 BCFJF Model 3B4 11481

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

52 NOTE:

A. MOUNTS ON SHAFT

H. SPRING HOLDER NOTINCLUDED

I. ABRASION RESISTANT CARBON (P66)

N. NON-STANDARD SPRING HOLDER

LECOURTENAY (continued)

PS-864 E 3 2.000 1-3/8 BCFJF Model 6B3

PS-595 E 3 2.375 1-5/8 BCDJF Model 4B6 11485-8

PS-530 E 3 2.750 2 BCFJF Model 5BA6 11393

PS-327 E 3 3.000 2-1/8 BCFJF Models 6BA5, 6BA6 15168-9, 23305

PS-848 E 3 3.125 2-1/4 BCDJF Models 4BA8, 5BA7, 8B5 11479-80, 23300, 23304

PS-278 E 3 3.250 2-3/8 BCFJF Model 8BA5 15170-1

PS-328 E 3 3.375 2-5/8 BCFJF Models 8BA6, 6BA8, 10BA4/5 15170-7, 23301

PS-324 E 3 3.875 3 BCDJF Models 6B8,10BA6,10BA7 11489-93

NOTE: Lecourtenay seals are also available with Ni-Resist mating rings.

LEHIGH

PS-752 D 1 1.375 3/4 BCDKF D-811

PS-108 E 1 1.875 1-1/4 NCPKP D-845

LELAND FARADAY

PS-142 B 1 1.000 1/2 BMFJF

PS-163 B 1 1.000 1/2 BMFJF Model LFP-43000

PS-1000 B 1 1.250 5/8 BMFJF Models LFP-2075, 2100, 2150, 2200

PS-800 C 1 1.156 5/8 BMFJF H

Models LFP-333-615, 14107-14120, 34105-34320

PS-877 C 1 1.375 3/4 BCFJF Models LFP-533-1100, 5050, 5075, 5100

LEROYSOMER NORTH AMERICA

PS-3893 C

3Special

1.500 7/8 VCFGF 90243401

PS-3943 C

3Special

2.125 1-1/2 VCFGF 90348301

PS-3945 C

3Special

1.875 1-1/4 VCFGF 90311601

PS-3584 C

3Special

2.000 1-3/8 VCFGF 90300001

PS-3939 C

3Special

2.375 1-5/8 VCFKF 90352401

LEWIS, CHARLES S. &CO. (Div. of WEIR GROUP)

PS-381 D 1 1.875 1-1/4 BCFJF

PS-381- D 1 1.875 1-1/4 NCFJF 1732

NEO

PS-3555 D 1 1.875 1-1/4 QLFLF 10282

PS-205 E 1 2.500 1-3/4 BCFJF

PS-205- E 1 2.500 1-3/4 BCFJF I 21353

P66

PS-366 E 1 2.500 1-3/4 BCFKF 10283

LIBERTY PUMPS

PS-4064 Special Special .950 1/2 BMFJF Unitized 50980A0

PS-4065 Special Special 1.110 5/8 BMFJF Unitized 5120000

PS-4066 Special Special 1.334 3/4 BLFLF Unitized 5633000

LINK BELT

PS-357 C 1 1.625 1 BCFKF WB-35

PS-355 C11.750 1-1/8 BCFKF WB-40

PS-461 D 1 2.375 1-5/8 BCDKF WB-60

PS-288 D 1 2.500 1-3/4 BCDKF WB-70

LITTLE GIANT PUMP CO. (Div. of FRANKLIN ELECTRIC CO., INC.)

PS-150 B — — 1/2 BMF-F Seat is Impeller 926030

PS-163 B 1 1.000 1/2 BMFJF 926024, 926029

PS-165 B 9 .906 1/2 BMFJF A 108112, 926031

PS-961 B 1 1.250 5/8 BCFJF 926034

PS-1000 B 1 1.250 5/8 BMFJF Pump 10 &12

PS-933 C — — 5/8 BCF-F 926052

PS-552 C 3 1.250 5/8 BCFJF 926053

PS-356V C 3 1.750 1-1/8 VCFJF 926042, 926043

LOCKWOOD PUMP

PS-301 A 1 1.375 3/4 BMFJF

PS-360 A 11.625 1 BCFJF CM Pump

LOGANSPORT

PS-400 C ——1/2 BMF-F P-9509

PS-106 C 11.000 1/2 BCFKF N P-17251

PS-109 D — — 5/8 BCD-F SF-4, SF-10 P-14883

PS-564 C — — 3/4 BCF-F SF-80, 100, 125, 150 P-9518

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

NOTE:

A. MOUNTS ON SHAFT

B.TAPERED SPRING

LOMART

PS-150 B — — 1/2 BMF-F Seat is Impeller

PS-142 B 1 1.000 1/2 BMFJF

PS-163 B 1 1.000 1/2 BMFJF 40-027, 40-029

PS-1000 B 1 1.250 5/8 BMFJF

LOUIS PUMP

PS-370 A 1 1.625 1 BCFKF

LOU-RICH, INC.

PS-6305 Q 2 1.625 1 BMDAF 13417

LUITWEILER PUMP

PS-201 A 1 1.375 3/4 BMFJF

PS-361 E 1 1.875 1-1/4 BCFJF

LYCO WAUSAU, INC.

PS-446 C 1 2.500 1-3/4 BCFJF 1100-17

McDONALD A-Y

PS-166 A 1 1.187 5/8 BMFJF 5MCD1

PS-501 A 1 1.250 5/8 BMFJF 3000, 4000 and 4100 Jet Well 5MCD4

PS-201 A 1 1.375 3/4 BMFJF 5MCD5

PS-521 D 1 1.875 1-1/8 BCFKF 5MCD2

MAGNETROL (See SCHAUB ENGINEERING CO.)

MAGNUM PRODUCTS, LLC.

PS-516 A 1 1.250 5/8 BCFJF 48273

PS-185- C 1 1.875 1-1/4 BLFLF 48253

SC-SC

MANITOWOC CO., INC.

PS-360 A 1 1.625 1 BCFJF 003705011

MARLOW(Div. of ITT INDUSTRIES)

PS-151 B 1 1.375 5/8 BMFJF 42513-00

PS-2161 B 1 1.375 5/8 BMFJF SCT Series, Stainless Steel 46328-00

PS-411 B 11 — 5/8 BMFJF A Model H23EC-A 1-1/2 HP, 2AF Series 25353-00, 25353-20

26467-00, 23736-00

PS-411V B 11 — 5/8 VCFJF A 27678-00, 29163-00

29163Z

PS-201 A 1 1.375 3/4 BMFJF Argonaut®,Mardur®38592-00

PS-405 A27 1.625 1 B/VCFJF 26473-00

PS-413 C27 1.625 1 BCFJF 20760-00, 25355-00

PS-978 C 1 1.750 1-1/4 BCFJF B L Series 45672-20

PS-979 C 1 1.750 1-1/4 BCFKF B

PS-923 C 25 2.250 1-1/4 BCFJF B 27452-00, 27233-20

PS-416 D— — 1-1/4 BCF-F 27453-00

PS-416A D25 2.250 1-1/4 BCFJF 3B Series 27223-00, 27224-00

27225-00, 3B28EC-C2

PS-7919 C32.000 1-3/8 B/VLFLF 43350-00

PS-929 C25 2.000 1-3/8 BCFJF 25481-00

PS-404 D 25 2.000 1-3/8 BCDJF 25356-00, 26477-00

25356-20

PS-8048 XT 3 2.125 1-3/8 VCFJF 316SS 45184000000

PS-818 C 3 2.375 1-5/8 BCFJF 46983-00

PS-544V-C32.375 1-5/8 VLFLF 43435-00

SC-SC

PS-7497 C 25 2.500 1-5/8 B/VCFJF 28146-00

PS-514 D 12.375 1-5/8 BCDJF L Series 45673-20

PS-446 C 1 2.500 1-3/4 BCFJF 25357-00

PS-550 C 3 2.500 1-3/4 BCFJF Model 6 EL 47182-00

PS-267 C 1 2.750 2 BCFJF 25358-00

PS-478 E 1 2.687 2 BCFKF

PS-7963 K 33.000 2BCFJF 43426000000

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

MASSEY FERGUSON

PS-642 B — — 5/8 BMF-F 892-563M1

PS-647 B — — 3/4 BMF-F 1019-293M1

MEGATOR CORP.

PS-359V- C 1 1.250 5/8 VCFJF 5079V

CMS

PS-359 C 1 1.250 5/8 BCFJF 5079

PS-358 C 1 1.375 3/4 BCFJF 5479

PS-309 C 1 1.500 7/8 BCFJF 5679

PS-309V C 3 1.500 7/8 VCFJF 5679V

PS-356 C 1 1.750 1-1/8 BCFJF 5879

PS-357V- C 1 1.750 1-1/8 VCFJF 5879V

CMS

PS-185 C 1 1.875 1-1/4 BCFJF 5779

PS-758 C 1 2.125 1-1/2 BCFJF 5979

PS-758V- C 1 2.125 1-1/2 VCFJF 5979V

CMS

MEMPHIS PUMP & MFG. CO., INC.

PS-100 A 1 1.187 5/8 BMFJF 0625-6BC

PS-118 C 1 1.187 5/8 BCFJF

PS-1091 C 1 1.187 5/8 VCFJF

PS-508 D 1 1.250 5/8 BCDJF

PS-201 A 1 1.375 3/4 BMFJF

PS-1093 C 1 1.375 3/4 VCFJF

PS-1092 C 1 1.375 3/4 VCFKF

PS-1094 C 1 1.625 1 VCFJF

MEPCO: (Marshall Engineered Products Co.) (See DUNHAM-BUSH)

METAL MASTER

PS-150 B — — 1/2 BMF-F Seat is Impeller 12515

PS-680 A 1 1.187 5/8 BCFJF 19023

PS-702 A 1 1.187 5/8 BMFJF Close Coupled Circulator 15110

PS-200 A 1 1.250 5/8 BMFJF

PS-153 A 1 1.250 5/8 BMFKF Swim Pool Pump

PS-151 B 1 1.375 5/8 BMFJF Circulator Hi Lift

MET-PRO CORP.

PS-1000V B 3 1.250 5/8 VCFJF 6960440

PS-3962

WSpecial

2 1.250 5/8 TCFJF 6960444

PS-397V C — — 1 VCF-F 6765570

PS-937V E——1VCF-F 6765583

PS-236V E 3 1.625 1 VCFKF 6764554

T9-1000 WT — — 1 TCF-F 316SS 6765575

PS-9349 WT 27 2.000 1 TCFZF 316SS

PS-2104V E — — 1-3/8 VCF-F 6767102

PS-1056V C 3 2.500 1-3/4 VCFKF 6765941

PS-1056V- C 3 2.500 1-3/4 VCFLF 6765942

SC-SEAT

PS-366V E 3 2.500 1-3/4 VCFKF 6764540, 6765965

MEYER-MOJONNIER

PS-227 D 1 1.750 1 BCFKF 750062149

MIDCO MFG.

PS-600 B 1 1.187 5/8 BMFJF

PS-601 B 1 1.375 3/4 BMFJF

MIDLAND PRODUCTS (Div. of CRANE PUMPS & SYSTEMS)

PS-201 A 11.375 3/4 BMFJF 6070-0

PS-360 A 1 1.625 1 BCFJF Models 5M, 7M and 18M 6007-0

PS-177 C 1 2.000 1-3/8 BCFJF Models 40M and 40W

PS-805 C 32.000 1-3/8 BCFJF 6368-0

PS-550 C 3 2.500 1-3/4 BCFJF 6412-0

PS-532 C 3 2.750 2 BCFJF 6428-0

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

NOTE:

A. MOUNTS ON SHAFT

B.TAPERED SPRING

N. NON-STANDARD SPRING HOLDER

MILE HIGH EQUIPMENT CO.

PS-6312 Q Special 1.625 1 BMD/PAP 9121026-91

PS-6311 Q Special 2.375 1-5/8 N/BMDAF 9121025-91

MILRECO

PS-448 C 1 2.500 1-3/4 BCFKF RMB-414

MONARCH PUMPS (Div. of FRANKLIN ELECTRIC CO., INC.)

PS-200 A 1 1.250 5/8 BMFJF 240160

PS-200V- A 1 1.250 5/8 VCFJF ATH, AT600 240136

CMS

PS-851 A 1 1.375 3/4 BCFJF 240260

PS-201 A 1 1.375 3/4 BMFJF 240170, MS17

PS-201V- A 1 1.375 3/4 VCFJF BSGF 6&8, B2U 240344, MS44

CMS

PS-460 D 1 1.625 1 BCFKF 240060

PS-185 C 1 1.875 1-1/4 BCFJF 240070

PS-185V- C 1 1.875 1-1/4 VCFJF 8BSGF 240359

CMS

PS-756V- C 1 1.875 1-1/4 VCFKF 240362

CMS

PS-186 D 1 2.000 1-3/8 BCDKF 240367

PS-3972 K 3

2.500/2.125

1-1/2 VLFLF

PS-448 C 1 2.500 1-3/4 BCFKF 240120

PS-835 D 3 3.375 2-1/2 BCDJF 240363

PS-838 E 3 3.500 2-3/4 V/BCFJF 240290

MONTGOMERY WARD

PS-358 C 1 1.375 3/4 BCFJF 24181

MORETRENCH

PS-7766 K 3 3.125 2-1/4 BCFJF

MOYNO, INC.

PS-631 C 1 1.000 1/2 BCFJF N

PS-1002 C 1 1.000 1/2 BCFJF N 3204215000

PS-4214 C 1 1.000 1/2 BCFJF 3206480000

PS-1002- C 1 1.000 1/2 QCFJF N 3206497000

EPR

PS-1002V C 1 1.000 1/2 VCFJF N 3206037000

PS-200 A 1 1.250 5/8 BMFJF

PS-359 C 1 1.250 5/8 BCFJF 3202424000

PS-1119 C 1 1.250 5/8 BCFJF EM & EC Pumps 3202423000

PS-359- C 1 1.250 5/8 QCFJF 3206379000

EPR-CMS

PS-359V- C 1 1.250 5/8 VCFJF 3206501000

CMS

PS-633V-C31.250 5/8 VZFLF

TC-SC

PS-851 A 1 1.375 3/4 BCFJF 8-65C 3201625000

PS-358 C 1 1.375 3/4 BCFJF 3203945000

PS-360 A1 1.625 1 BCFJF EC-67

PS-548 C 3 1.625 1 BCFJF 3201750000

PS-380 D 1 1.625 1 BCFJF

PS-262 E 3 2.500 1-3/4 BCFKF

MP PUMPS, INC.

PS-4055 A1 1.000 5/16 BCFJF 33976

PS-114 A 1 1.000 5/16 BMDJF

PS-162 A 1 1.000 1/2 BMFJF 21609

PS-165 B 9 .906 1/2 BMFJF A

PS-113 B 1 1.093 5/8 BMFJF 13385

PS-447V B 8 — 5/8 VCFJF A Model 2430 21580

PS-358 C 1 1.375 3/4 BCFJF 15151

PS-112 C 1 1.375 3/4 BCFKF 15112

PS-128V C 3 1.375 3/4 VCFJF B 15110, 15150, 15131, 15200, 15241 26640

PS-3788 G 3 1.375 3/4 VCFJF 30061

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

56 NOTE:

A. MOUNTS ON SHAFT

B.TAPERED SPRING

H. SPRING HOLDER NOT INCLUDED

I. ABRASION RESISTANT CARBON (P66)

MP PUMPS, INC. (continued)

PS-9339 W 2 1.375 3/4 TCFJF 316SS 30054

PS-703 D 1 1.500 7/8 BCDJF 9524

PS-245V- C 1 1.625 1 VCFJF B/H 22272 - Old Style

CMS

PS-248V- C 1 1.625 1 VCFKF B/H 22274

CMS

PS-380 D 1 1.625 1 BCFJF 14233

PS-4195 G 1 1.625 1 VCFJF 316SS 22272 - New Style

PS-604 D 1 1.750 1-1/8 BCFJF

PS-347 C 1 2.125 1-1/2 BCFJF B/H 14421, 14424

PS-347V- C 1 2.125 1-1/2 VCFJF B/H 22361

CMS

PS-382 D 1 2.125 1-1/2 BCFJF

PS-3992 G 1 2.125 1-1/2 VCFJF 31374

PS-7587 W 2 2.125 1-1/2 TCFJF 316SS 26565

PS-446V- C 1 2.500 1-3/4 VCFJF 26685

CMS

PS-7959 D 3 2.500 1-3/4 VRFZF 26752

MTH TOOL CO., INC.

PS-933- C — — 5/8 BCF-F I 12-2739-01-457

P66

PS-208V- C — — 7/8 VCF-F I 12-1068-01-494

P66

MURPHY DIESEL

PS-358 C 1 1.375 3/4 BCFJF MD-4090

PS-1095 C — — 1 BCF-F MD-7980B1

MUSKIN

PS-163 B 1 1.000 1/2 BMFJF 09-2001

PS-142 B 1 1.000 1/2 BMFJF 09-2013

MYERS, F.E. (See PENTAIR, INC. for Additional Part Numbers)

PS-1621 Q 9 — 1/2 BMFJF A 21607A001

PS-162 A 1 1.000 1/2 BMFJF 21607A015

PS-200 A 1 1.250 5/8 BMFJF 10840A1, A2, A3 14525A000, 1425A010

16275A

PS-200V- A 1 1.250 5/8 VCFJF 21181A044

CMS

PS-3845 B 8 1.299 5/8 BMFJF 25053A000

PS-359 C 1 1.250 5/8 BCFJF 22447A

PS-359V- C 1 1.250 5/8 VCFJF 21181A021

CMS

PS-508 D 1 1.250 5/8 BCDJF 10840A1

PS-968 A 1 1.437 3/4 BCFJF 11416A000

PS-101 A 1 1.437 3/4 BMFJF Models H, HN, K, MHN 11416A, A2, A3

PS-902 B 9 — 3/4 BMFKF A 21579A

PS-1125 C 1 1.375 3/4 BCFJF 25370A000

PS-7277 C 1 1.437 3/4 BCFJF 21181A17

PS-7514 C 1 1.437 3/4 BCFJF

PS-309 C 1 1.500 7/8 BCFJF 21576A000

PS-3907 C 1 1.500 7/8 BCFJF 21576A010

PS-3749 C 1 1.500 7/8 BCFJF 21576A011

PS-7130 C 1 1.500 7/8 BCFJF WG-20-21-15

PS-703 D 1 1.500 7/8 BCDJF Model 125 Centro-Thrift 11716A1

PS-983V C 3 1.750 1-1/8 VCFKF 21181A6

PS-204 E1 1.750 1-1/8 BCFJF 8824A1

PS-185 C 1 1.875 1-1/4 BCFJF 22577A000

PS-185- C 1 1.875 1-1/4 BLFLF 21181A062

SC-SC

PS-2208 C 1 1.875 1-1/4 BZFZF 21181A019

PS-381 D 1 1.875 1-1/4 BCFJF Model 2695 21181A016, 15218A

PS-758 C 1 2.125 1-1/2 BCFJF 22922A000

PS-2209 C 1 2.125 1-1/2 BZFZF 21181A013

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

NOTE:

A. MOUNTS ON SHAFT

B.TAPERED SPRING

I. ABRASION RESISTANT CARBON (P66)

MYERS, F.E. (continued) (See PENTAIR, INC. for Additional Part Numbers)

PS-758V- C 1 2.125 1-1/2 VCFJF 21181A002

CMS

PS-659V- C 1 2.125 1-1/2 VZFZF 21181A064

TC-VS-TC

PS-238 C 1 2.375 1-5/8 BCFJF 21181A032

PS-2212 C 1 2.500 1-3/4 BCFJF 22883A000

PS-446 C 1 2.500 1-3/4 BCFJF 11049-001-1

PS-237 D 1 2.500 1-3/4 BCDJF 300 FS-VG4D

PS-7138 C 1 3.125 2-1/4 BCFJF 23605A000

PS-7138- C 1 3.125 2-1/4 BZFZF 21181A020

TC-TC

PS-7936 E 3 3.500 2-3/4 VCFZF 316SS 21576A011

PS-1088 C 3 3.875 3 BCFJF B 25449A000

NASH_ELMO (Div. of GARDNER DENVER NASH)

PS-100 A 1 1.187 5/8 BMFJF HTG Pump

PS-100V- A 1 1.187 5/8 VCFJF PK-0389

CMS

PS-452 B 9 — 5/8 BMFJF A S1-1/4C

PS-600 B 1 1.187 5/8 BMFJF PK-0339

PS-600V- B 1 1.187 5/8 VCFJF PK-0654

CMS

PS-764 A 1 1.375 3/4 BCFJF PK-0482

PS-204 E 1 1.750 1-1/8 BCFJF 11 Vertical PK-0295

PS-866 E 3 1.750 1-1/8 BCFJF PK-0754

PS-282 U 3 1.750 1-1/8 BCFKF PK-0334

PS-177 C 1 2.000 1-3/8 BCFJF MH-50, MH-80 PK-0874

PS-177V C 3 2.000 1-3/8 VCFJF PK-2044

PS-354 E 1 2.000 1-3/8 BCFJF AL 621 PK-0475

PS-864 E 3 2.000 1-3/8 BCFJF PK-0873

PS-758 C 1 2.125 1-1/2 BCFJF PK-0791

PS-2223 C 3 2.125 1-1/2 VCFZF PK-0959

PS-382 D 1 2.125 1-1/2 BCFJF MPS-673 PK-0624

PS-817 D 3 2.125 1-1/2 BCFJF PK-0302, PK-0306

PS-305 E 1 2.125 1-1/2 BCFJF MP-40 PK-0678

PS-884 K 1 2.125 1-1/2 BCFKF MPS-40

PS-238V C 3 2.375 1-5/8 VCFJF PK-3437

PS-550 C 3 2.500 1-3/4 BCFJF AT-94 PK-0900

PS-446V- C 3 2.500 1-3/4 VCFJF I PK-1531

P66

PS-340 C 1 2.625 1-7/8 BCFJF PK-0893

PS-4436 C 1 3.000 2-1/8 VCFJF PK-3438

PS-9122 W 2 3.000 2-1/8 TCFJF 316SS PK-2510

PS-874 D 1 3.125 2-1/4 BCDJF 1-1/2 H-6 PK-0341

PS-2089 D33.125 2-1/4 BCFJF PK-0479

PS-268V C 3 3.250 2-3/8 VCFJF PK-3439

PS-269V C 3 3.375 2-1/2 VCFJF PK-1772

PS-838 E33.500 2-3/4 V/BCFJF PK-0523

PS-9314 W 2 1.687 2-3/4 TCFJF 316SS PK-3368

PS-2116 C 3 3.875 3 BCFJF AD-303 PK-0937

PS-9140 W23.875 3TCFJF 316SS PK-2522

PS-9351 W 2 4.875 4 TCFJF 316SS PK-2549

NEPTUNE

PS-150 B — — 1/2 BMF-F Seat is Impeller

OBERDORFER PUMPS

PS-671 B 1 .875 3/8 BMFJF IGCC Pump 32373

PS-671V- B 1 .875 3/8 VCFJF

CMS

PS-1098 B 1 .875 1/2 BMFJF Model 142 32482

PS-3003 G 3 1.000 1/2 BCFJF 32592

PS-642 B — — 5/8 BMF-F 4GP, 9GP, RA-TV, RB-TB A-5377, A-6019

PS-600 B 1 1.187 5/8 BMFJF 4GP, 9GP, RA-TV, RB-TB

PS-933V C — — 5/8 VCF-F 9798A

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

B.TAPERED SPRING

I. ABRASION RESISTANT CARBON (P66)

OBERDORFER PUMPS (continued)

PS-359 C 1 1.250 5/8 BCFJF A-5935

PS-4346 C 3 1.187 5/8 VCFJF 316SS 33109

PS-235 C 1 1.625 1 BCFJF 32315

PS-235V- C 1 1.625 1 VCFJF 32372

CMS

OHLER PUMP

PS-141 R — — 1 BCF-F

PS-235 C 1 1.625 1 BCFJF

PS-357 C 1 1.625 1 BCFKF

PS-185 C 1 1.875 1-1/4 BCFJF

PS-186 D 1 2.000 1-3/8 BCDKF

PS-209 K — — 1-3/8 BCF-F

PACER PUMPS

PS-601 B 1 1.375 3/4 BMFJF 714-11

PS-601V B 3 1.375 3/4 VCFJF 714-14

PAC-FAB (PENTAIR POOL PRODUCTS, INC.)

PS-952 A 1 1.250 5/8 BCFJF AV-7 Pump 23822

PS-200 A 1 1.250 5/8 BMFJF Challenger®,Dynamite, Dynamo®,354545

Dynatron®,Pinnacle®

PS-201 A 1 1.375 3/4 BMFJF Hydropump®354001

PACIFIC PUMPING CO. (PACO) (For Replacement Seal Kits - See Pages 145-146)

PS-516 A 1 1.250 5/8 BCFJF 14010242

PS-200 A 1 1.250 5/8 BMFJF SL-7101, SL-7741

K102-1, 91909744

PS-628 A 3 1.250 5/8 BMFKF K100-7, 14008630

K102-7, 91909687

91909747

PS-1618 C 1 1.250 5/8 BCFJF B 14032695

PS-2149 C 3 1.250 5/8 BCFKF B 14032688

PS-508 D 1 1.250 5/8 BCDJF SL-7100

PS-973 A 1 1.375 3/4 BCFKF K101-7, 91909722

PS-201 A 1 1.375 3/4 BMFJF K101-1, 91909719

PS-768 C 3 1.375 3/4 BCFKF 14032689

PS-112V C 3 1.375 3/4 VCFKF 14032363

PS-750 D 1 1.375 3/4 BCDJF Model 1-1/2LRV, 1-1/4JS

PS-752 D 1 1.375 3/4 BCDKF SL-7104

PS-703 D 1 1.500 7/8 BCDJF SL-7098

PS-235 C 1 1.625 1 BCFJF SL-7735

PS-380 D 1 1.625 1 BCFJF SL-7087

PS-460 D 1 1.625 1 BCFKF SL-7106

PS-754 E11.625 1 BCFJF 14007521

PS-204 E 1 1.750 1-1/8 BCFJF SL-7770

PS-2122 C 1 1.875 1-1/4 BCFJF K105-1, 14032698

K107-1, 91909832

91909909

PS-185 C 1 1.875 1-1/4 BCFJF 14033710

PS-756 C 1 1.875 1-1/4 BCFKF SL-7094

PS-1109 C 3 1.875 1-1/4 BCFKF K105-7, 14032691

91909838

PS-756V C 3 1.875 1-1/4 VCFKF K107-6, 91909912

PS-1109V C 3 1.875 1-1/4 VCFKF K105-6, 14032365

91909837

PS-154 C—— 1-1/4 BCF-F 14032143

PS-361 E 1 1.875 1-1/4 BCFJF Model 2CLSU-3ALR 14007099

PS-361- E 11.875 1-1/4 BCFJF I 14007083

P66

PS-137 E 1 1.875 1-1/4 BCFKF SL-8102

PS-264- E 3 1.875 1-1/4 BCFKF I 14008102

P66

PS-137V- E 31.875 1-1/4 VCFKF IK600-6, 91911824

P66

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

A. MOUNTS ON SHAFT

N. NON-STANDARD SPRING HOLDER

PACIFIC PUMPING CO. (PACO) (continued) (For Replacement Seal Kits - See Pages 145-146)

PS-3974 D Bal. 1 1.875 1-3/8 BCFJF 14007089

PS-758 C 1 2.125 1-1/2 BCFJF

PS-371 D 1 2.125 1-1/2 BCFKF

PS-2106 E — — 1-1/2 BCF-F 14010219

PS-305 E 1 2.125 1-1/2 BCFJF SL-8223

PS-374 E 1 2.125 1-1/2 BCFKF

PS-2108 C — — 1-3/4 BCF-F 14032145, 14032355

PS-446 C 1 2.500 1-3/4 BCFJF K104-1, 91909802

PS-2142 C 1 2.500 1-3/4 BCFJF 14032700

PS-2150 C 3 2.500 1-3/4 BCFJF K106-1, 91909874

K108-1, 91909944

PS-2151 C 3 2.500 1-3/4 BCFKF 14032693, K303-7

PS-2151V C 3 2.500 1-3/4 VCFKF K106-6, 91909878

K108-6, 91909947

PS-2151V- C 3 2.500 1-3/4 VCFZF 14032384

TC-SEAT

PS-205 E 1 2.500 1-3/4 BCFJF Model 3CLSU SL-7090, 14007090

PS-366 E 1 2.500 1-3/4 BCFKF SL-8398

PS-262 E 3 2.500 1-3/4 BCFKF KP3014-516 14008148,14008650

14009965, 29-5015-47001

K307-71

PS-449 K 1 2.500 1-3/4 BCFJF 14033023

FA-1875 C — — 1-7/8 BCF-F 14033944

FA-513V E — — 1-7/8 VCF-F 14034032

PS-2111 C — — 2 BCF-F 14032146

PS-479 E 1 2.750 2 BCFJF K602-1, 91911836

PS-843 E 1 2.750 2 BCFKF K602-7, 91911839

PS-530 E 3 2.750 2 BCFJF K602-6, 91911838

PS-477 E 3 2.750 2 BCFKF

PS-3537 C 1 3.125 2-1/4 BCFJF 14032701

PS-323 E 1 3.125 2-1/4 BCDJF 14001709, 14007709

PS-351 E 1 3.125 2-1/4 BCDKF 14017123, 29-60122-47001

K308-71

PS-1688 E 3 3.125 2-1/4 BCFJF K111-1, 91910192

PS-2094V E 3 3.125 2-1/4 VCFKF K111-6, 91910195

PAUL MUELLER CO.

PS-1002 C 1 1.000 1/2 BCFJF N 9841604

PS-356 C 1 1.750 1-1/8 BCFJF 9840339

PEABODY-BARNES MFG.

PS-163 B 1 1.000 1/2 BMFJF 18189

PS-165 B 9 .906 1/2 BMFJF A 29726

PS-200 A11.250 5/8 BMFJF For Comet, Rocket Econo, 25,31,33,

35,48,49,50,52,102DM and 740DM 11397-12839, 12703

PS-359 C11.250 5/8 BCFJF 18873A

PS-552 C 3 1.250 5/8 BCFJF 23701

PS-508 D11.250 5/8 BCDJF 5080

PS-201 A 1 1.375 3/4 BMFJF Vertical Single and Multi Stage 152,152DM,

202D,202DM, 302D 302DM and 502DM 13110, 14017122

PS-358 C 1 1.375 3/4 BCFJF 15344, 67562

PS-235 C11.625 1 BCFJF 18004-30090

PS-236 E 1 1.625 1 BCFKF 8022

PS-879 K 1 1.625 1 BCFJF 64434

PS-185 C 1 1.875 1-1/4 BCFJF Models: 18ACG, 18, 19, 23 & 26 CCG 70713

PS-598 C 3 1.875 1-1/4 BCFKF 3TACG Int 1020 33289

PS-383 D 1 1.875 1-1/4 BCFKF 12074

PS-1118 K 1 1.875 1-1/4 BH/CFJF 39485

PS-7323 K 1 1.875 1-1/4

BZ/CFZJF

60817

PS-228 K 3 1.875 1-1/4 BCFKF Model 3TCCG 25328A

PS-177 C 1 2.000 1-3/8 BCFJF 52601

PS-547 C 3 2.000 1-3/8 BCFKF 39463

PS-758 C 1 2.125 1-1/2 BCFJF 24998

PS-553 C 3 2.125 1-1/2 BCFKF 31000

PS-237 D 1 2.500 1-3/4 BCDJF 13301

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

NOTE:

I. ABRASION RESISTANT CARBON (P66)

PUMP MANUFACTURERS’ CROSS-REFERENCE

PEABODY-BARNES MFG. (continued)

PS-2237 K 1 2.625 1-7/8 BCFJF 51938

PS-332 C 3 2.750 2 BCFKF 53626

PEERLESS (For Replacement Seal Kits - See Page 147)

PS-162 A 1 1.000 1/2 BMFJF 2665554

PS-100 A 1 1.187 5/8 BMFJF 2665171

PS-200 A 1 1.250 5/8 BMFJF 2658090

PS-300 A 1 1.250 5/8 BMFJF Convertible & Single Stage Jet Water King 2655294-V12271

1181377-2665624

PS-637 A 3 1.250 5/8 BMFJF 2692269 000

PS-263 D 1 1.187 5/8 BCDKF 2675336

PS-508 D 1 1.250 5/8 BCDJF 2666910

PS-301 A 1 1.375 3/4 BMFJF Single Stage Jet: J2G, J3G 1J, 2655293, 26650131

2J, 3J, 15J, 75J,1GJ

PS-750 D1 1.375 3/4 BCDJF 2655888, 2663071

PS-265 D 3 1.375 3/4 BCDKF 2675337

PS-303 D 1 1.500 7/8 BCDKF 2655239, 2664873

PS-250 D 3 1.500 7/8 BCDKF 2675339, 269042101

PS-188 E 1 1.500 7/8 BCFJF 2663072, 2657110

PS-229 E 3 1.500 7/8 BCFKF 2675338

PS-778 A 3 1.625 1 BCFKF 2692914

PS-380 D 1 1.625 1 BCFJF PE-200, PE-300, PE-500 Fluidyne 2613940, 2663369

PS-252 D 3 1.625 1 BCFKF 2664873, 269042102

PS-252- D 3 1.625 1 QCFKF 2675341 000

EPR

PS-754 E 1 1.625 1 BCFJF 2655887

PS-251 E 3 1.625 1 BCFKF 2675340, 2656324

PS-801 C 3 1.750 1-1/8 BCFJF 269987501000

PS-529 C 3 1.750 1-1/8 BCFKF 269794701000

PS-604 D 1 1.750 1-1/8 BCFJF 2658071

PS-605 D 1 1.750 1-1/8 BCFKF TVB-58, Turbine Vane Pump 2655131

PS-254 D 3 1.750 1-1/8 BCFKF 2675344, 2655131

PS-204 E 1 1.750 1-1/8 BCFJF 2663077

PS-253 E 3 1.750 1-1/8 BCFKF Model 300-90

2675343, 2664886, 2675317

PS-306 E 1 1.875 1-3/16 BCDJF 2655886

PS-255 E 3 1.875 1-3/16 BCDKF 2675345, 269042103

PS-1109- C3 1.875 1-1/4 BCFJF 269986601 000

CER

PS-1109 C 3 1.875 1-1/4 BCFKF 2687165 000

PS-1109- C 3 1.875 1-1/4 QCFKF 2687626 000, 2687926 000

EPR

PS-2122V C 3 1.875 1-1/4 VCFJF 269986602 000

PS-1109V C 3 1.875 1-1/4 VCFKF 268716501

PS-361 E 1 1.875 1-1/4 BCFJF PB-3, 3 x 4 x 10 2657093, 2663048

PS-256 E31.875 1-1/4 BCFKF 2664893, 2675347

PS-264 E 3 1.875 1-1/4 BCFKF 2675318, 2687266

PS-547 C 3 2.000 1-3/8 BCFKF 269794702

PS-354 E 1 2.000 1-3/8 BCFJF 2655089, 2663075

PS-677 E 1 2.000 1-3/8 BCFKF 2663368, 2675349

PS-257 E 3 2.000 1-3/8 BCFKF 2675350

PS-1110 C 3 2.125 1-1/2 BCFKF F2-1044AM,1230AM, 1240AM, 3AE14 2687166 000

PS-2221 C 3 2.125 1-1/2 QCFKF 2691073

PS-1110V C 3 2.125 1-1/2 VCFKF 2687166 007

PS-2223- C 3 2.125 1-1/2 VCFLF

SC-SEAT

PS-382 D 1 2.125 1-1/2 BCFJF 2656981, 2675353

PS-2106- E——1-1/2 BCF-F I 2689751 000

P66

PS-305 E 1 2.125 1-1/2 BCFJF 2663008, 2675108

PS-258 E 3 2.125 1-1/2 BCFKF 2675351, 2691073

PS-259 E 3 2.125 1-1/2 BCFKF 2675352

PS-550 C 3 2.500 1-3/4 BCFJF 269359803 000

PS-436 C 3 2.500 1-3/4 BCFKF AD IV-V 2693598 000

PS-436- C 32.500 1-3/4 QCFKF 2675319 000

EPR

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

NOTE:

A. MOUNTS ON SHAFT

B.TAPERED SPRING

I. ABRASION RESISTANT CARBON (P66)

PEERLESS (continued) (For Replacement Seal Kits - See Page 147)

PS-825 D 3 2.500 1-3/4 BCDKF PE-Pumps 2675356

PS-2109 E — — 1-3/4 BCF-F 2689752 000

PS-205 E 1 2.500 1-3/4 BCFJF 2663044

PS-262 E 3 2.500 1-3/4 BCFKF 2675355

PS-535 E 3 2.500 1-3/4 BCFJF MTP Frame

PS-262- E 3 2.500 1-3/4 QCFKF I 2675354 000

EPR-P66

PS-2114 C 3 2.625 1-7/8 BCFJF 269987701000

PS-312 C 3 2.625 1-7/8 BCFKF 269794703

PS-2072 E 3 2.625 1-7/8 BCFKF Type AD Fig. 5130 2676205

PS-332 C 3 2.750 2 BCFKF Type AD Group IV, 8AE-12 2693599000, 504293

PS-477- E 3 2.750 2 QCFKF 2675320 000

EPR

PS-353 E 1 3.000 2-1/8 BCFKF Model 6A-16

PS-327 E 3 3.000 2-1/8 BCFJF Model 6A-16

PS-1676 C 3 3.125 2-1/4 BCFKF 2692217000

PS-492 C 3 3.250 2-3/8 BCFKF 2693666000

PS-483 C 3 3.500 2-3/4 BCFKF 2693601000

PS-475 E 3 3.875 3 BCDKF 6˝ 6TU16

PELLERIN MILNOR CORP.

PS-750 D 1 1.375 3/4 BCDJF 24S020

PENBERTHY INJECTOR

PS-162 A 1 1.000 1/2 BMFJF D-1104

PS-165 B 9 .906 1/2 BMFJF A

PS-1112 Q 9 — 1/2 BMFJF A 14036

PENTAIR, INC.

(See AURORA, BERKELEY, FAIRBANKS MORSE, HYDROMATIC, HYPRO, MYERS, F.E., STA-RITE)

PS-359 C 1 1.250 5/8 BCFJF 01556-000-1

PS-633- C 1 1.250 5/8 BZFZF 21181A024

TC-TC

PS-2216V- C 1 1.625 1 VZFZF 00300-002-1

CMS

PS-185 C 1 1.875 1-1/4 BCFJF 22577A000

PS-2208 C 1 1.875 1-1/4 BZFZF 21181A019

PS-758-SC- C 1 2.125 1-1/2 BLFZF 00920-011-1

TC-CMS

PS-2209 C 1 2.125 1-1/2 BZFZF 00920-004-1

PS-7409 C 1 2.125 1-1/2 VCFJF 316SS 00920-005-1, 00920-007-1

-1088-TC-

C1 3.875 3 BZFZF B 25449A001

TC-CMS

PS-1088V- C 1 3.875 3 VZFZF B 37180021

TC-TC-CMS

PENTAIR POOL PRODUCTS

PS-961 B1 1.250 5/8 BCFJF 071734S, 071734-SP

PS-4352 C 3 3.875 3 BLFZF B 60 MPH & 60 MMPH 037180041

PERFECTING (Div. of DUFF-NORTON)

PS-359 C11.250 5/8 BCFJF 732015

PS-356 C11.750 1-1/8 BCFJF 732049

PS-177 C 1 2.000 1-3/8 BCFJF 732057

PESCO

PS-507 A 1 1.250 5/8 BMFKF

PFAUDLER, INC.

PS-359 C11.250 5/8 BCFJF 1621350

PS-3893 C

3Special

1.500 7/8 VCFGF 3515444

PS-356 C 1 1.750 1-1/8 BCFJF 1621492

PS-3943 C

3Special

2.125 1-1/2 VCFGF 3512911

PS-3584 C

3Special

2.000 1-3/8 VCFGF 3512910

PHILLIPS GASKET (See CATERPILLAR)

PIONEER (See DETROIT HARVESTER HOWELL)

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

A. MOUNTS ON SHAFT

N. NON-STANDARD SPRING HOLDER

PIQUA MACHINE (See ENPO-CORNELL PUMP CO.)

POWER PRODUCTS (See TECUMSEH PRODUCTS CO.)

PRECISION SCIENTIFIC

PS-1043 C 1 1.000 1/2 BMFJF 342005

PS-732 C 3 1.250 5/8 BCFKF 342003

PS-1113 C 1 1.375 3/4 BCFKF 342027

PS-499 C 3 1.625 1 BCFKF 342012

PREMIER

PS-201 A 1 1.375 3/4 BMFJF

Series 120T, MKII 225/255, 300, 325/355, 725/756

31-812

PS-1000 B 1 1.250 5/8 BMFJF

Series 220/225 ( Pre 1988 ), 455/456, 500, 600

31-813

PRICE PUMP CO.

PS-1002V C 1 1.000 1/2 VCFJF N Model S95M

PS-516 A 1 1.250 5/8 BCFJF 0118

PS-447 B 8 — 5/8 BCFJF A Model SE100, E100B, PRYCO-50, 75, 95 0538

PS-447V B 8 — 5/8 VCFJF A 0539

PS-359 C 1 1.250 5/8 BCFJF 0841

PS-359V C 3 1.250 5/8 VCFJF Model “S” Motor Pumps 0553

PS-4155 G 1 1.250 5/8 VLFLF 0541

PS-3885 K 1 1.178 5/8 VCFJF 0985

PS-9155 W 2 1.250 5/8 TLFLF 316SS Model LT-25

PS-201 A 1 1.375 3/4 BMFJF Model SP-15

PS-601 B 1 1.375 3/4 BMFJF PRYCO-100, 125, 150

PS-358 C 1 1.375 3/4 BCFJF 1112

PS-358V- C 1 1.375 3/4 VCFJF 0549

CMS

PS-1094 C 1 1.625 1 VCFJF 8304-211

PS-758 C 1 2.125 1-1/2 BCFJF Models E150, E200

PS-7409 C 1 2.125 1-1/2 VCFJF 316SS 0122

PS-7587 W 2 2.125 1-1/2 TCFJF 316SS 0123

PS-446- C 1 2.500 1-3/4 QCFJF 3724

EPR

PS-446V- C 1 2.500 1-3/4 VCFJF 3516

CMS

PROCON PRODUCTS

PS-4060 G 1 1.181 7/16 BCFJF 1034-A7

PS-4061 G11.181 7/16 QCFJF For Home Water Systems 1034-A4W

PS-4062 G 1 1.181 7/16 QCFJF 1034-A4

PS-4063 G11.181 7/16 VCFJF 1034-A2

PROSSER PUMP (Div. of CRANE PUMPS & SYSTEMS)

PS-1002 C 1 1.000 1/2 BCFJF N 558312-2, 558312-21

PS-359 C 1 1.250 5/8 BCFJF 5 HP 2-31001

PS-687 C 1 1.500 7/8 BCFKF 15 HP Mod # 9-16034-1 2-31006

PS-756 C 1 1.875 1-1/4 BCFKF 25 and 40 HP Mod # 9-26032-3

PULSAFEEDER (Div. of IDEX CORP.)

PS-1065 C 3 .875 3/8 BCFJF 307328

PS-1050V C — — 1/2 VCF-F Y0900121-316

PS-933V C — — 5/8 VCF-F Y0900421-316

PS-552 C 3 1.250 5/8 BCFJF Model 2-17 Type 107 307414

PUREX/HYDROTECH (See PAC-FAB)

PS-100 A11.187 5/8 BMFJF LSeries™ P28280

PS-952 A 1 1.250 5/8 BCFJF AV-7 Pump P23822

PS-501 A 1 1.250 5/8 BMFJF Aquatron®P28322/071733

PS-1000 B 1 1.250 5/8 BMFJF Whisperflo®P28323/071734

PS-201 A 1 1.375 3/4 BMFJF AH Series™, L Series™ P28300/071728

PS-360 A 1 1.625 1 BCFJF C Series P28175/071725

QUINCY COMPRESSOR

PS-6090 E 3 2.500 1-3/4 B/VCFKF 22578-1

PS-2152V C 3 3.500 2-3/4 VCFKF 22592-1

PS-6177 C 3 4.250 3-3/8 VCFKF 22593-1

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

NOTE:

PUMP MANUFACTURERS’ CROSS-REFERENCE

A. MOUNTS ON SHAFT

N. NON-STANDARD SPRING HOLDER

RAINBOW IRRIGATION PUMPS

PS-185 C 1 1.875 1-1/4 BCFJF 14821

PS-446 C 1 2.500 1-3/4 BCFJF 13470

RAPID DAYTON (See TAIT)

RED JACKET (VEEDER- ROOT CO.)

PS-106 C 1 1.000 1/2 BCFKF N Deep and Shallow Well Type A & B Multi-Stage

Pumps Models 25A, 33A, 50A, 75A, 100A 540

PS-518 A 1 1.187 5/8 BCFKF 076-183

PS-100 A 1 1.187 5/8 BMFJF SW-DW Jet Pump

C76-78A, C76-98A, C176-037

PS-701 A 1 1.187 5/8 BMFKF C76-134

PS-711 A 3 1.187 5/8 BMFJF 076-182

PS-493 C 1 1.187 5/8 BCFKF For Centri-Jet “R” and Centri-Jet V 25R, 500

33R, 50R, 75R, 100, 101,150, 151

PS-102 D 1 1.250 5/8 BCDKF Deep Well & Shallow Well Type H, 530

Models 25H, 33H, 50H, 75H, 100H

PS-201 A 1 1.375 3/4 BMFJF 76-129, 76-189

PS-902 B 9 — 3/4 BMFKF A Centri Jet X Pumps 33X and 50X C76-99A, 555

“CJ”, “CJM” and “SJ” Pumps

PS-750 D 1 1.375 3/4 BCDJF All Types HB Centrifugal Jet Pumps 560

PS-370 A 1 1.625 1 BCFKF 76-132

PS-460 D 1 1.625 1 BCFKF 545

REDA PUMP

PS-508 D 1 1.250 5/8 BCDJF 17197A

PS-188 E 1 1.500 7/8 BCFJF 13131A

PS-703 D 1 1.500 7/8 BCDJF 14011A

PS-380 D 1 1.625 1 BCFJF 13977A

PS-382 D 1 2.125 1-1/2 BCFJF 15114A

RELIANCE ELECTRIC (Div. of BALDOR ELECTRIC CO.)

PS-356 C 1 1.750 1-1/8 BCFJF 64262-12L

PS-185 C 1 1.875 1-1/4 BCFJF Motor Frame 140 64262-12A

PS-2208 C 1 1.875 1-1/4 BZFZF Motor Frame 140 64262-20A

PS-185V- C 1 1.875 1-1/4 VCFJF Motor Frame 140 64262-13A

CMS

PS-185V- C 1 1.875 1-1/4 VZFZF Motor Frame 140 64262-20AA

TC-TC

PS-618- C3 1.875 1-1/4 BZFZF Motor Frame 140 64262-15E

TC-TC

PS-381 D 1 1.875 1-1/4 BCFJF Motor Frame 140 64262-8A

PS-381- D 1 1.875 1-1/4 BLFLF 64262-39A

SC-SC

PS-6229 K 3 1.875 1-1/4 BCFJF 316SS 64262-41D

PS-4134

XSpecial

Special 1.875 1-3/8 B/NCPGF 64147-24R

PS-758 C12.125 1-1/2 BCFJF Motor Frame 140 or 180 64262-12B

PS-758- C 1 2.125 1-1/2 BLFLF Motor Frame 140 or 180 64262-39B

SC-SC

PS-2209 C 1 2.125 1-1/2 BZFZF Motor Frame 140 or 180 64262-20B

PS-7409 C 1 2.125 1-1/2 VCFJF 316SS Motor Frame 140 or 180 64262-13B

PS-758V- C 1 2.125 1-1/2 VLFLF Motor Frame 140 or 180 64262-39BB

SC-SC

PS-659V- C 1 2.125 1-1/2 VZFZF Motor Frame 140 or 180 64262-20BB

TC-VS-TC

PS-382 D12.125 1-1/2 BCFJF Motor Frame 140 or 180 64262-8B

PS-446 C 1 2.500 1-3/4 BCFJF Motor Frame 180 or 210 64262-12C

PS-446- C 1 2.500 1-3/4 BZFZF Motor Frame 180 or 210 64262-20C

TC-TC

PS-446V- C 1 2.500 1-3/4 VCFJF Motor Frame 180 or 210 64262-13C

CMS

PS-448V- C 1 2.500 1-3/4 VLFLF Motor Frame 180 or 210 64262-39CC

SC-SC

PS-446V- C 1 2.500 1-3/4 VZFZF Motor Frame 180 or 210 64262-20CC

TC-TC

PS-436- C 3 2.500 1-3/4 BLFLF Motor Frame 180 or 210 64262-39C

SC-SC

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

RELIANCE ELECTRIC (continued) (Div. of BALDOR ELECTRIC CO.)

PS-436- C 3 2.500 1-3/4 BZFZF Motor Frame 140 or 180 64262-15C

TC-TC

PS-2207 C 3 2.500 1-3/4 VCFZF Motor Frame 180 or 210 64262-23C

PS-237 D 1 2.500 1-3/4 BCDJF Motor Frame 180 or 210 64262-8C

PS-6217 D 1 2.500 1-3/4 VZFLF 316SS Motor Frame 180 or 210 64262-25CC

PS-267 C 1 2.750 2 BCFJF Motor Frame 210 or 250 64262-12D

PS-267- C 1 2.750 2 BLFLF Motor Frame 210 or 250 64262-39D

SC-SC-CMS

PS-2219 C 1 2.750 2 BZFZF Motor Frame 210 or 250 64262-20D

PS-267V- C 1 2.750 2 VCFJF Motor Frame 210 or 250 64262-13D

CMS

PS-6224 C 1 2.750 2 VLFLF Motor Frame 210 or 250 64262-39DD

PS-6218 C 1 2.750 2 VZFZF Motor Frame 210 or 250 64262-25DD

PS-6213 C 1 2.750 2 VZFZF 316SS Motor Frame 210 or 250 64262-20DD

PS-267V- C 3 2.750 2 VCFZF Motor Frame 210 or 250 64262-23D

TC-SEAT

PS-7196 K 3 2.750 2 BCFJF 64262-41E

PS-1057 C 3 3.000 2-1/8 B/VCFKF 611725-5B

PS-1679 C 1 3.125 2-1/4 BCFJF Motor Frame 250 64262-12E

PS-1680- C 1 3.125 2-1/4 BLFLF Motor Frame 250 64262-39E

SC-SC

PS-7064 C 1 3.125 2-1/4 BZFZF Motor Frame 250 64262-20E

PS-1678V C 3 3.125 2-1/4 VCFJF Motor Frame 250 64262-13E

PS-6233 C 3 3.125 2-1/4 VCFLF 64262-67A

PS-7766 K 3 3.125 2-1/4 BCFJF 64262-41C

PS-6205 C 1 3.500 2-3/4 BCFJF Motor Frame 320 64262-18F

PS-2154- C 1 3.500 2-3/4 BLFLF Motor Frame 320 64262-39N

SC-SC-CMS

PS-6220 C 1 3.500 2-3/4 BZFLF Motor Frame 320 64262-25N

PS-6908 C 1 3.500 2-3/4 BZFZF Motor Frame 320 64262-20N

PS-483V- C 3 3.500 2-3/4 VCFZF 64262-23G

TC-SEAT

PS-6207 C 3 3.500 2-3/4 VCFJF Motor Frame 320 64262-18N

PS-2154V- C 3 3.500 2-3/4 VLFLF Motor Frame 320 64262-39NN

SC-SC

PS-2154V- C 3 3.500 2-3/4 VZFZF Motor Frame 320 64262-20NN

TC-TC

PS-2153- C13.875 3 BLFLF Motor Frame 320 64262-39M

SC-SC-CMS

PS-7875 C 1 3.875 3 BZFZF Motor Frame 360 64262-20H

PS-7998 C 1 3.875 3 BZFZF Motor Frame 360 64262-20M

PS-2153V- C 1 3.875 3 VLFLF Motor Frame 320 64262-39MM

SC-SC-CMS

PS-3539 C 1 3.875 3 VZFZF Motor Frame 360 64262-20MM

PS-6214 C 1 3.875 3 VZFZF Motor Frame 320 64262-20HH

PS-2116 C 3 3.875 3 BCFJF Motor Frame 360 64262-12G

PS-2153 C 3 3.875 3 BCFJF Motor Frame 320 64262-18G

PS-6206V C 3 3.875 3 VCFJF Motor Frame 320 64262-18L

PS-6225 C 3 3.875 3 VLFLF Motor Frame 360 64262-39HH

PS-6202 D 1 3.875 3 BZFZF Motor Frame 360 64262-8H, 64262-62HH

PS-6219 D 3 3.875 3 BZFLF Motor Frame 360 64262-25H

PS-6232 D 3 3.875 3 VZFLF Motor Frame 360 64262-62AA

PS-6228 K 3 3.875 3 VCFJF 64262-41B

PS-6226 C 3 4.125 3-1/4 VLFLF Motor Frame 360 64262-39KK

PS-7172 D 3 4.125 3-1/4 BCFJF Motor Frame 360 64262-8J, 64262-63C

PS-3827 D 3 4.125 3-1/4 BZFZF Motor Frame 360 64262-8K and 20K

PS-6201 D 3 4.125 3-1/4 VCFJF Motor Frame 360 64262-8F and 36KK

PS-6227 K 3 4.125 3-1/4 VCFJF 64262-41A

PS-6204 C 3 4.375 3-1/2 BCFJF 64262-12K

PS-6221 D 3 4.375 3-1/2 V/BZFZF 64262-33A

PS-3745 D 3 4.375 3-1/2 VZFZF 64262-37PP

PS-6203 D 3 4.625 3-3/4 VCFJF 64262-8M

PS-6230 D 3 6.625 5-5/8 VCFJF 64262-42D

PS-6231 D 3 6.375 5-3/8 VZFLF 64262-43F

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

REXNORD INDUSTRIES, LLC.

PS-201 A 1 1.375 3/4 BMFJF X7718

PS-578 D — — 7/8 BCD-F X203565

PS-188 E 1 1.500 7/8 BCFJF X203224

PS-141 R — — 1 BCF-F X6185

PS-154 C — — 1-1/4 BCF-F X7387

PS-185 C 1 1.875 1-1/4 BCFJF X8023

PS-137 E 1 1.875 1-1/4 BCFKF X203691

PS-169 K — — 1-1/4 BCF-F X6186

PS-172 C — — 1-3/8 BCF-F X7389

PS-177 C 1 2.000 1-3/8 BCFJF X2U59-1

PS-209 K — — 1-3/8 BCF-F X6187

PS-223 D — — 1-7/8 BCD-F X7235

PS-593 D 3 2.625 1-7/8 BCDKF 2U59-6

PS-196 D — — 2 BCD-F X7380

RICE

PS-200 A 1 1.250 5/8 BMFJF 21-024

PS-201 A 1 1.375 3/4 BMFJF 12-023

PS-750 D 1 1.375 3/4 BCDJF 0330-9-6

ROBBINS & MYERS (See MOYNO, INC.)

ROMAR FILTER

PS-200 A 1 1.250 5/8 BMFJF 618-001

ROPER PUMP CO.

PS-1050 C — — 1/2 BCF-F G3-29, G14-263

PS-1050- C — — 1/2 QCF-F G3-65

EPR

PS-400 C — — 1/2 BMF-F G14-222-403, G14-263X

PS-1050V C — — 1/2 VCF-F G14-32

PS-933 C — — 5/8 BCF-F G14-116

PS-933V C — — 5/8 VCF-F G14-13

PS-633 C 1 1.250 5/8 BCFKF G14-225

PS-564 C — — 3/4 BCF-F G14-117

PS-768 C 3 1.375 3/4 BCFKF G14-226

PS-112V C 3 1.375 3/4 VCFKF G14-471

PS-752 D 1 1.375 3/4 BCDKF G14-261, G14-266

PS-208 C — — 7/8 BCF-F G14-324

PS-617 C 3 1.500 7/8 BCFKF G14-227

PS-687V C31.500 7/8 VCFKF G14-477

PS-703 D 1 1.500 7/8 BCDJF

PS-935 E 1 1.500 7/8 BCFKF 316SS

PS-397 C — — 1 BCF-F G14-320

PS-397V C — — 1 VCF-F G14-51

PS-235 C 1 1.625 1 BCFJF G14-338X

PS-499 C 3 1.625 1 BCFKF 1AM-27 G14-338

PS-499- C31.625 1 QCFKF G14-312

EPR

PS-357V C 3 1.625 1 VCFKF

PS-7207 C 3 1.750 1 VCFKF Model No: P2-C1219

PS-3619 C 3 1.750 1 VCFKF G4-398

PS-937 E — — 1 BCF-F G14-120, G14-250

PS-236 E11.625 1BCFKF G14-343

PS-891 K 1 1.625 1 BCFKF G4-94

PS-2155 C 3 1.750 1-1/16 BCFKF G14-489

PS-127 D11.750 1-1/16 BCDKF G14-288

PS-348 C — — 1-1/8 BCF-F G14-278, G4-334

PS-529 C 3 1.750 1-1/8 BCFKF G4-313

PS-355V C 3 1.750 1-1/8 VCFKF G4-15, G4-375

PS-154 C — — 1-1/4 BCF-F G14-429

PS-154V C — — 1-1/4 VCF-F G3-10, G3-36

PS-756 C 11.875 1-1/4 BCFKF

PS-598 C 3 1.875 1-1/4 BCFKF

PS-416 D — — 1-1/4 BCF-F G14-121, G14-122

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

NOTE:

A. MOUNTS ON SHAFT

I. ABRASION RESISTANT CARBON (P66)

ROPER PUMP CO. (continued)

PS-172 C — — 1-3/8 BCF-F G14-512

PS-172V C — — 1-3/8 VCF-F G14-510

PS-467 C 1 2.125 1-3/8 BCFKF G14-579

PS-186 D 1 2.000 1-3/8 BCDKF G14-248

PS-2156 C 3 2.250 1-7/16 BCFKF G4-112

PS-2156V C 3 2.250 1-7/16 VCFKF G4-142

PS-2105 C — — 1-1/2 BCF-F G14-430

PS-2105V C — — 1-1/2 VCF-F G3-35

PS-553 C 3 2.125 1-1/2 BCFKF G4-267, G14-230

PS-7975 C

3Special

2.125 1-1/2 VCFKF G4-75, G14-475

PS-939 D — — 1-1/2 BCF-F G14-123, G14-124

PS-371 D 1 2.125 1-1/2 BCFKF

PS-1145 C 3 2.750 2 VCFKF G4-46

PS-543V C 3 3.000 2-1/8 VCFKF G4-41

PS-1676V C 3 3.125 2-1/4 VCFKF

PS-942 D — — 2-1/4 BCD-F G14-125

PS-941 D 1 3.125 2-1/4 BCDKF G14-223

ROTH PUMP CO.

PS-1120 C 1 1.062 1/2 BCFJF Size 00-100 F8A030VF

PS-118 C 1 1.187 5/8 BCFJF Size 0 and 10 F8B015VF / 086VL

PS-348V C — — 1-1/8 VCF-F F8E011UF

PS-7884V EBal. 3 2.500 1-7/8 VCFKF F7J2002FS

FA-10047 C — — 2 VCF-F F8H056UF

RUTH BERRY

PS-102 D 1 1.250 5/8 BCDKF 610

PS-201 A 1 1.375 3/4 BMFJF 601, 601A

PS-750 D 1 1.375 3/4 BCDJF 620

RUTHMAN COMPANIES

PS-164 B 9 — 1/2 BMFKF A Model 55-4520 906

PS-165 B 9 .906 1/2 BMFJF A

PS-452 B 9 — 5/8 BMFJF A

PS-633 C 1 1.250 5/8 BCFKF

PS-902 B 9 — 3/4 BMFKF A

PS-360 A 1 1.625 1 BCFJF

PS-235 C 1 1.625 1 BCFJF

SCHAUB ENGINEERING CO.

PS-493 C 1 1.187 5/8 BCFKF 12-3113-001

PS-1123 C 1 1.625 1 BCFKF 12-3113-002

PS-598 C 3 1.875 1-1/4 BCFKF 12-3113-003

SCOT PUMP (Div. of ARDOX CORP.)

PS-516 A 1 1.250 5/8 BCFJF

101.000.110C, 118.000.102

118.000.110

PS-952 A 1 1.250 5/8 BCFJF 118.000.340

PS-200 A 1 1.250 5/8 BMFJF 101.000.340

PS-501 A11.250 5/8 BMFJF 118.000.340D

PS-200V- A 1 1.250 5/8 VCFJF

CMS

PS-359V- C 1 1.250 5/8 VCFJF 101.000.103

CMS

PS-3550 C 1 1.250 5/8 VRFRF 101.000.239

PS-732- C 3 1.250 5/8 QCFKF 101.000.173

EPR

PS-633V C 3 1.250 5/8 VCFKF 101.000.120, 101.000.316

PS-633V- C 3 1.250 5/8 VCFKF I 101.000.225X

P66

PS-9309 W 3 1.187 5/8 QRFRF 101.000.242

PS-201 A 1 1.375 3/4 BMFJF 101.000.102

PS-201V- A 1 1.375 3/4 VCFJF FPK, FG-FKG 3 & 5 HP 101.000.115

CMS

PS-112V C 3 1.375 3/4 VCFKF 101.003.171

PS-360 A 11.625 1BCFJF 101.000.159

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

NOTE:

A. MOUNTS ON SHAFT

I. ABRASION RESISTANT CARBON (P66)

N. NON-STANDARD SPRING HOLDER

SCOT PUMP (Div. of ARDOX CORP.) (continued)

PS-185 C 1 1.875 1-1/4 BCFJF 101.000.104

101.000.104A

PS-185- C 1 1.875 1-1/4 BCFJF I 101.000.294

P66

PS-756- C 1 1.875 1-1/4 QCFKF

101.000.124C, 101.000.203

EPR

PS-185V- C 1 1.875 1-1/4 VCFJF FP-FPD, FG-FKG 8 & 16 101.000.194

CMS

PS-756V- C 1 1.875 1-1/4 VCFKF 101.000.124

CMS

PS-2203 C 3 1.875 1-1/4 QCFKF I 101.000.124A

PS-185V C 3 1.875 1-1/4 VCFJF

PS-756V C 3 1.875 1-1/4 VCFKF

PS-3872 E 1 1.875 1-1/4 QCFKF

PS-883V- K 1 1.875 1-1/4 VCFJF 101.000.210

CMS

PS-228V- K 1 1.875 1-1/4 VCFKF 101.000.164

CMS

PS-758 C 1 2.125 1-1/2 BCFJF

101.000.168, 118.000.343

118.000.344

PS-758V C 3 2.125 1-1/2 VCFJF HYD 556 101.000.175

PS-659V C 3 2.125 1-1/2 VCFKF 101.000.182

PS-446 C 1 2.500 1-3/4 BCFJF 101.000.196

PS-446- C 1 2.500 1-3/4 BCFJF I 118.000.388

P66

PS-436V C 3 2.500 1-3/4 VCFKF 101.000.221

PS-836- C 1 3.500 2-3/4 BCFJF 137.001.692

CMS

SCOTSMAN ICE SYSTEMS

PS-380 D 1 1.625 1 BCFJF

PS-6305 Q 2 1.625 1 BMDAF 02-1300-01

PS-4133 Q Special 2.500 1-3/4 Special 02-0929-02

SERFILCO

PS-1002 C 1 1.000 1/2 BCFJF N 55-434

PS-358 C 1 1.375 3/4 BCFJF 55-407

PS-309 C 1 1.500 7/8 BCFJF 55-488

PS-758V- C 1 2.125 1-1/2 VCFJF 55-481

CMS

SETHCO (Div. of MET-PRO CORP.)

PS-1002V C 1 1.000 1/2 VCFJF N

PS-1050 C—— 1/2 BCF-F 760P04-320

PS-359 C 1 1.250 5/8 BCFJF

SHERWOOD BRASS

PS-631 C 1 1.000 1/2 BCFJF N 5789

PS-1002 C 1 1.000 1/2 BCFJF N 10522

PS-200 A 1 1.250 5/8 BMFJF 10159

PS-447 B 8 — 5/8 BCFJF A 12859

PS-452 B 9 — 5/8 BMFJF A 8388

PS-508 D11.250 5/8 BCDJF 10523

PS-578 D——7/8 BCD-F 8570

PS-703 D 1 1.500 7/8 BCDJF 8578

PS-188 E 1 1.500 7/8 BCFJF 9791

SHETLER PUMP

PS-200 A 1 1.250 5/8 BMFJF

PS-201 A 11.375 3/4 BMFJF

SHIPPENSBURG (SHIPCO)

PS-356- C 1 1.750 1-1/8 QCFJF SDPS-00155

EPR

SID HARVEY INDUSTRIES, INC.

PS-1050

——

1/2 BCF-F

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

68 NOTE:

B.TAPERED SPRING

H. SPRING HOLDER NOTINCLUDED

SIEMENS WATER TECHNOLOGIES

PS-4437

D 2 2.000 2-1/8 BCDKF WTU18080

SIGMUND PUMP

PS-356 C 1 1.750 1-1/8 BCFJF

PS-355V C 3 1.750 1-1/8 VCFKF

PS-758 C 1 2.125 1-1/2 BCFJF

PS-659V C 3 2.125 1-1/2 VCFKF

PS-267 C 1 2.750 2 BCFJF

SIHI PUMPS AMERICAS

PS-544 C 3 2.375 1-5/8 BCFKF 501 483

PS-1057 C 3 3.000 2-1/8 B/VCFKF 501 90

PS-3606 C 3 3.000 2-1/8 VCFLF 43092920

SIMFLO PUMPS, INC.

PS-618 C 3 1.875 1-1/4 BCFJF 059-0220MA

PS-7702 EBal. 3 1.875 1-3/8 BCFJF 059-0180MA

PS-4159 E Bal. 3 2.125 1-5/8 VCFJF 059-0200MA

PS-2114 C 3 2.625 1-7/8 BCFJF 059-0270MA

PS-532 C 3 2.750 2 BCFJF 059-0280MA

PS-1678 C 3 3.125 2-1/4 BCFJF 059-0290MA

PS-269 C 3 3.375 2-1/2 BCFJF 059-0300MA

PS-7703 EBal. 3 3.375 2-5/8 BCFJF 059-0201MA

SIMMONS PUMP CORP.

PS-200 A 1 1.250 5/8 BMFJF Model 6

SKIDMORE PUMP

PS-663 Q 1 1.000 1/2 BMFJF 50648

PS-100 A 1 1.187 5/8 BMFJF 142-54049

PS-536 C 3 1.187 5/8 BCFJF 53497

PS-290 C 1 1.250 5/8 BCFJF 142-54099

PS-359 C 1 1.250 5/8 BCFJF 50625-1

PS-508 D 1 1.250 5/8 BCDJF Condensate Pump 142-54052, P15, P15A

PS-309 C 1 1.500 7/8 BCFJF 142-54055, 50625-2

PS-356 C 1 1.750 1-1/8 BCFJF 142-54058, 50625-3

SMITH & LOVELESS, INC. (For Additional Listings - See Page 174)

PS-1104 V 25 2.140 1-3/8 BMFJF Frame 25

PS-1105 V25 2.640 1-7/8 BMFJF Frame 28

PS-1102 V 3 3.140 2-1/8 BCFJF Frame 32

PS-1107- V 1 3.187 2-1/8 BCFJF

CMS

SOMAT CO.

PS-359 C 1 1.250 5/8 BCFJF 54300

PS-309 C 1 1.500 7/8 BCFJF 54302

PS-801 C31.750 1-1/8 BCFJF 54310

PS-529 C 3 1.750 1-1/8 BCFKF 54311

PS-544 C 3 2.375 1-5/8 BCFKF 54325

PS-332 C3 2.750 2 BCFKF 54326

PS-6302 Q 1 3.375 2-1/4 BMPAP 54306

SPECIALTY PACKAGING

PS-1085V C 1 1.250 5/8 VCFJF B 00-114696

PS-539 C 1 1.625 1 BCFJF H 00-104330

PS-6318 Q 9 1.578 1-1/8 VMFAF 00-117071

PS-6317 Q 9 2.000 1-3/8 VMPSP 00-114144

PS-758V- C 1 2.125 1-1/2 VCFJF 00-223422

CMS

PS-4041 Q 1 3.375 2-1/4 VMPSP 00-117072

SPP PUMPS

PS-359 C 11.250 5/8 BCFJF

PS-633 C 1 1.250 5/8 BCFKF

PS-355 C 1 1.750 1-1/8 BCFKF

PS-356 C 1 1.750 1-1/8 BCFJF

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

NOTE:

A. MOUNTS ON SHAFT

B.TAPERED SPRING

H. SPRING HOLDER NOT INCLUDED

SPP PUMPS (continued)

PS-758 C 1 2.125 1-1/2 BCFJF

PS-659 C 1 2.125 1-1/2 BCFKF

PS-267 C 1 2.750 2 BCFJF

PS-842 C 1 2.750 2 BCFKF

STA-RITE INDUSTRIES (See PENTAIR, INC. for Additional Part Numbers)

PS-4225 G 1 23MM 12MM QCFLF

PS-1615 B 1 1.000 3/8 BMFJF Model 297A U109-173

PS-162 A 1 1.000 1/2 BMFJF U109-103

PS-142 B 1 1.000 1/2 BMFJF

PS-163 B 1 1.000 1/2 BMFJF LT Series

U109-68 SS, U109-321SS

PS-663 Q 1 1.000 1/2 BMFJF U109-100

PS-100 A 1 1.187 5/8 BMFJF AJ Series, Dura-Glas Pre 1998, U9-469, U109-6

Dyna-Glas and Dyna-Max, Max-E-Glass U109-6A, U109-93SS

pre 1998, PLBC Series Pre 1995 17351-0102S

PLBC Series

PS-200 A 1 1.250 5/8 BMFJF Dura-Glas®,Max-E-Glas®17304-0100

Series PE, PEA, P2R and P2RA

PS-501 A 1 1.250 5/8 BMFJF

PS-1000 B 1 1.250 5/8 BMFJF CF/CFA Series, HP Series U109-136SS

PS-118 C 1 1.187 5/8 BCFJF

U109-87, U9-102, U109-118

PS-493 C 1 1.187 5/8 BCFKF U9-1

PS-1618 C 1 1.250 5/8 BCFJF B

PS-4267 G 1 1.187 5/8 BCFJF U9-6

PS-4165 G 1 1.187 5/8 VLFLF 316SS U9-437

PS-4390 G 1 1.250 5/8 VLFLF 17304-0102

PS-851 A 1 1.375 3/4 BCFJF 37400-0027S

PS-201 A 1 1.375 3/4 BMFJF DJ/JS/JT Series Pre 01/01, Dura-Glas II U9-122, U109-358SS

Pre 1998, Dura-Jet, Dyna-Glas/Dyna-Max,

U109-372SS

Dyna-Jet, JW/JWPA Series, 17351-0101

Max-E-Glas II Pre 1998

PS-201V- A 1 1.375 3/4 VCFJF 37400-0028S

CMS

PS-1622 B 9 — 3/4 BMFJF A

PS-4048 B 9 1.312 3/4 BLFLF U9-394SS

PS-128 C 1 1.375 3/4 BCFJF B U9-99

PS-358 C 1 1.375 3/4 BCFJF U109-99

PS-877 C 1 1.375 3/4 BCFJF U109-267

PS-750 D 1 1.375 3/4 BCDJF U9-43

PS-4265 G1 1.375 3/4 BCFJF DJ/JS/JT Series,

Dyna-Glass/Dyna Max

after 6/00 JW/JWPA Series after 1/01

Dura-Glass II and Max-E

Glas II

(Series P4E, P4EA, P4R, P4RA)

PS-3868 G 1 1.375 3/4 VCFJF Dura-Glass II and Max-E Glas II

(Series P4E, P4EA, P4R, P4RA)

Max-E-Pro (Series P6E & P6RA)

PS-687 C 1 1.500 7/8 BCFKF U9-18, 20, 22, 25, 29, 32

U109-21, U109-30

PS-774 C 3 1.500 7/8 BCFJF U109-170

PS-235 C 1 1.625 1 BCFJF 16504

PS-380 D11.625 1BCFJF Model-AS-H-3U9-39, U109-47

PS-127 D 1 1.750 1-1/16 BCDKF U109-31

PS-204 E 1 1.750 1-1/8 BCFJF U109-96

PS-866 E3 1.750 1-1/8 BCFJF U109-96SS

PS-867 E 3 1.750 1-1/8 QCFKF U9-307

EPR

PS-185 C 1 1.875 1-1/4 BCFJF CC/C Series, D Series CC/C Series, U109-200

DSeries pre 8/00 CSPH/CCSPH Series U109-433SS, 32014

PS-246 C 1 1.875 1-1/4 BCFJF B/H CC/C Series, D Series U109-220

PS-804 D 31.875 1-1/4 BCFJF CC/C Series, D Series

PS-3883 G 1 1.875 1-1/4 BCFJF U9-433SS

PS-6265 G 11.875 1-1/4 VLFLF U9-451SS

PS-758 C 1 2.125 1-1/2 BCFJF 16554

PS-446 C 1 2.500 1-3/4 BCFJF CCPH/CCSPH Series S-32015

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

70 NOTE:

A. MOUNTS ON SHAFT

I. ABRASION RESISTANT CARBON (P66)

PUMP MANUFACTURERS’ CROSS-REFERENCE

STA-RITE INDUSTRIES (continued) (See PENTAIR, INC. for Additional Part Numbers)

PS-2142 C 1 2.500 1-3/4 BCFJF S-32692

PS-535 E 3 2.500 1-3/4 BCFJF U109-251

PS-340 C 1 2.625 1-7/8 BCFJF S-32694

PS-327 E 3 3.000 2-1/8 BCFJF U109-252

STEIN SAM ASSOC.

PS-397 C — — 1 BCF-F 401-50-0001

PS-2105 C — — 1-1/2 BCF-F 401-50-0006

STERLING FLUID SYSTEMS

PS-200 A 1 1.250 5/8 BMFJF 1181377 000

PS-529 C 3 1.750 1-1/8 BCFKF 269794701 0000

PS-816 C 3 2.125 1-1/2 BCFJF 504290

PS-1057 C 3 3.000 2-1/8 B/VCFKF 501908

PS-483 C 3 3.500 2-3/4 BCFKF 502365

STERLING, INC.

PS-3723 C 3 1.437 5/8 QCFJF I 081.00036.00

081.00036.01

PS-3981 C 3 1.437 5/8 QCFKF I 081.00037.00

PS-7872 C 3 1.437 5/8 VCFKF I 081.00039.00

PS-3826 C 1 1.437 7/8 QCFJF I 081.00034-00

PS-2224 C 3 1.437 7/8 QCFKF I 081.00024.00

081.00024.02

PS-3678 C 3 1.437 7/8 QCFLF I 081.00035.00

PS-4017 C 3 1.437 7/8 VCFKF I 081.00027.00

PS-758 C 1 2.125 1-1/2 BCFJF 081.00017.00

STERLING MACHINERY

PS-201 A 1 1.375 3/4 BMFJF

PS-564 C — — 3/4 BCF-F

PS-358 C 1 1.375 3/4 BCFJF 1616

PS-145 K — — 3/4 BCF-F

PS-175 K 1

1.375/1.500

3/4 BCFJF

PS-303 D 1 1.500 7/8 BCDKF J81-E

PS-1681 D 3 1.437 7/8 BCDKF

PS-185 C 1 1.875 1-1/4 BCFJF 1636

PS-177 C 1 2.000 1-3/8 BCFJF 1706

PS-178 R 1 2.000 1-3/8 BCDJF

PS-209 K — — 1-3/8 BCF-F

PS-629 E 3 2.312 1-1/2 BCFKF 133861

PS-216 K — — 1-1/2 BCF-F

PS-213 R — — 1-3/4 BCD-F

PS-217 R 1 2.500 1-3/4 BCDKF

PS-853 C 3 3.375 2-1/2 BCFKF 13498, 20125-H

STERO CORP.

PS-447 B 8 —- 5/8 BCFJF A

PS-3440 C11.750 1BCFJF P571697

STEVENS PUMP CO.

PS-200 A 1 1.250 5/8 BMFJF 16-062-03

STONE BENNETT

PS-499 C31.625 1 BCFKF 30016

STONE CONST.

PS-851 A11.375 3/4 BCFJF 32223, 322231H

PS-185 C 1 1.875 1-1/4 BCFJF 37692

PS-758 C12.125 1-1/2 BCFJF 37691, 376911H

PS-446 C 1 2.500 1-3/4 BCFJF 377281H

PS-360 A 1 1.625 1 BCFJF 32224, 322241H

SULLAIR CORP.

PS-6120 K

3Special

3.000 2-1/8 VCFZF 250038-066

PS-6121 K

3Special

3.000 2-1/8 VCFZ/KF I 250038-068

PS-6138 C

3Special

3.375 2-1/2 VCFKF 250038-093

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

NOTE:

H. SPRING HOLDER NOTINCLUDED

I. ABRASION RESISTANT CARBON (P66)

N. NON-STANDARD SPRING HOLDER

PUMP MANUFACTURERS’ CROSS-REFERENCE

SULLAIR CORP. (continued)

PS-6141 K

3Special

3.375 2-1/2 VCFKF 250038-080

PS-6140 K

3Special

3.375 2-1/2 VCFZF 250038-079

PS-6173 C

3Special

3.875 3 VCFKF 250035-751

PS-6172 C

3Special

3.875 3 VCFKF H 250035-750

PS-6169 K

3Special

3.875 3 NCFKF 250035-734

PS-6171 K

3Special

3.875 3 VCFKF 250035-736

PS-3961 K — — 3-3/8 VCF-F 250014-770

SULLIVAN-PALATEK, INC.

PS-1053 C 3 1.875 1-1/4 B/VCFKF 519056-08

PS-6180 C 3 2.000 1-3/8 VCFGF 519056-25

PS-210V C 3 2.000 1-3/8 VCFKF

PS-534 D 3 2.125 1-1/2 BCFKF RP-250, RP-365A-222599

PS-1055 C — — 1-3/4 BCF-F RPV-125

PS-1056V C 3 2.500 1-3/4 VCFKF 519056-6

PS-4276 C 3 3.000 2-1/8 B/VCFKF 519056-13

PS-853 C 3 3.375 2-1/2 BCFKF Model 600

PS-6174 E 3 3.875 3 VCDGP 519056-15

SUPERIOR EQUIPMENT SOLUTIONS

PS-3100 Q — — 1 NMDKF 75-7050-020

SWABY MFG. CO.

PS-359 C 1 1.250 5/8 BCFJF

PS-758 C 1 2.125 1-1/2 BCFJF

PS-446 C 1 2.500 1-3/4 BCFJF

PS-2120 C 1 3.375 2-1/2 BCFJF

SWIMQUIP

PS-201 A 1 1.375 3/4 BMFJF XL VI/XL VII Series 37407-0009

SYNCROFLO, INC.

PS-921 A 1 1.375 3/4 BMFKF 13-690-0600

PS-360 A 1 1.625 1 BCFJF 13-650-0610

PS-370 A 1 1.625 1 BCFKF 13-690-0610

PS-235 C 1 1.625 1 BCFJF 13-690-0710

PS-185 C 1 1.875 1-1/4 BCFJF 13-950-0880

PS-756 C 1 1.875 1-1/4 BCFKF 13-690-2112

PS-1109 C3 1.875 1-1/4 BCFKF 13-690-0611

PS-361 E 1 1.875 1-1/4 BCFJF 13-650-1010

PS-137 E 1 1.875 1-1/4 BCFKF 13-690-0650

PS-3991 E Bal. 3 1.875 1-3/8 BCFKF 13-690-0612

PS-238 C 1 2.375 1-5/8 BCFJF 13-950-0886

PS-1019 C 3 2.625 1-5/8 BCFKF 13-690-2515

PS-205 E12.500 1-3/4 BCFJF 13-650-3011

TACO, INC. (For Replacement Seal Kits - See Page 147)

PS-8100

XSpecial

1.875 1/4 QCFLF 185-026

PS-163 B 1 1.000 1/2 BMFJF 106-031

PS-3561 C1.938 1/2 BCFJF 180-097, 180-108

PS-3563 C 1 .938 1/2 QCFLF 180-240

PS-1002 C 1 1.000 1/2 BCFJF N Series 1616 121-008

PS-106 C 1 1.000 1/2 BCFKF N 131-031

PS-3583 C11.000 1/2 BCFKF 121-136

PS-3004 G 1 1.000 1/2 QCFLF 185-135

PS-3568 G 1 1.000 1/2 QLFLF 185-151

PS-200 A11.250 5/8 BMFJF 172-009, 172-017

PS-200V A 3 1.250 5/8 VCFJF 172-006

PS-1000V B3 1.250 5/8 VCFJF 1600-305

PS-359 C 1 1.250 5/8 BCFJF 121-009, 122-009

PS-633 C 1 1.250 5/8 BCFKF

Series 131-9, 132-9, 133-9, 138-9, 1600-9

170-102RP, 1600-170RP

PS-3525 C 3 1.250 5/8 QCFKF I 1600-170

PS-3586 G 11.250 5/8 QCFJF 1600-846C

PS-358 C 1 1.375 3/4 BCFJF 180-206

PS-752 D 1 1.375 3/4 BCDKF 142-043

PS-360 A 11.625 1 BCFJF 170-021, 170-095

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

NOTE:

I. ABRASION RESISTANT CARBON (P66)

N. NON-STANDARD SPRING HOLDER

TACO, INC. (continued) (For Replacement Seal Kits - See Page 147)

PS-754 E 1 1.625 1 BCFJF 900-012

PS-356 C 1 1.750 1-1/8 BCFJF 950-670RP, 951-3161BRP

PS-355 C 1 1.750 1-1/8 BCFKF 950-664RP

PS-529- C 3 1.750 1-1/8 QCFKF 950-664BRP

EPR

PS-355V C 3 1.750 1-1/8 VCFKF 950-667RP

PS-204 E 1 1.750 1-1/8 BCFJF 900-024

PS-384 E 1 1.750 1-1/8 BCFKF 840-128

PS-867 E 3 1.750 1-1/8 BCFKF 840-128BRP

PS-264 E 3 1.875 1-1/4 BCFKF 840-011

PS-758 C 1 2.125 1-1/2 BCFJF 950-671RP

PS-758- C 1 2.125 1-1/2 QCFJF 951-3162BRP

EPR

PS-659V C 3 2.125 1-1/2 VCFKF 950-668RP

PS-305 E 1 2.125 1-1/2 BCFJF 862-029

PS-374 E 1 2.125 1-1/2 BCFKF 862-172

PS-544 C 3 2.375 1-5/8 BCFKF 950-673RP

PS-4068 C 3 2.375 1-5/8 QCFZF I 950-676RP

PS-340- C 1 2.625 1-7/8 QCFJF 951-2968RP

EPR-CMS

PS-267 C 1 2.750 2 BCFJF 950-672RP

PS-842 C 1 2.750 2 BCFKF 950-666RP

PS-1145 C 3 2.750 2 VCFKF 950-669RP

PS-479 E 1 2.750 2 BCFJF Model 6012

PS-1676 C 3 3.125 2-1/4 BCFKF 950-674RP

PS-1676- C 3 3.125 2-1/4 QCFKF I 950-674

EPR

PS-1676V- C 3 3.125 2-1/4 VCFZF 950-677RP

TC-SEAT

PS-483 C 3 3.500 2-3/4 BCFKF 950-675RP

TAIT

PS-162 A 1 1.000 1/2 BMFJF W-6476

PS-201 A 1 1.375 3/4 BMFJF 25062

PS-921 A 1 1.375 3/4 BMFKF 24820

PS-1125 C 1 1.375 3/4 BCFJF 16519

PS-703 D 1 1.500 7/8 BCDJF 24584

PS-360 A 1 1.625 1 BCFJF

PS-380 D 1 1.625 1 BCFJF 24963

PS-598 C 3 1.875 1-1/4 BCFKF W-16524

PS-805 C 3 2.000 1-3/8 BCFJF 16538

PS-267 C12.750 2BCFJF

TECUMSEH PRODUCTS CO.

PS-350 E 3 3.250 2-3/8 BCFKF K-509-9

TEEL PUMP

PS-392 C 1 .938 1/2 B/QMFJF 5NC03

PS-631 C 1 1.000 1/2 BCFJF N 5P380, 5P418

PS-1002 C 1 1.000 1/2 BCFJF N 1P609, IP610 1R305

PS-3542 C 3 1.031 9/16 VCFKF 5P419

PS-100 A 1 1.187 5/8 BMFJF 2P141, 2P894-2P899, 3P683-684-685 1R311, 5P403, 5P404

3P-686-687-690-692-715-716

PS-516 A 1 1.250 5/8 BCFJF 1P746-851-860-896-897-952-955-996 1R303, 5P407

1P998, 2P004-006-390,2P091, 2P092

3P551-3P553 3P577

PS-200 A 1 1.250 5/8 BMFJF 1R312, 5P405, 5P406

PS-501 A 1 1.250 5/8 BMFJF 1R315, 5P409, 5P410

PS-200V A 3 1.250 5/8 VCFJF 1P862, 2P486 opt. for 1P746-851 1R300, 5P408

1P854-856-860-884-896-897-952-955

1P996-998-2P004-006-290 3P551-553 3P577

PS-113 B 11.093 5/8 BMFJF 1P795 1R302, 5P366

PS-600 B 1 1.187 5/8 BMFJF 5P367

PS-1000 B 1 1.250 5/8 BMFJF 2P356, 2P360, 2P363, 2P366 1R317, 1R318

5P368, 5P369

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

NOTE:

A. MOUNTS ON SHAFT

B.TAPERED SPRING

H. SPRING HOLDER NOT INCLUDED

TEEL PUMP (continued)

PS-1152 B 1 1.250 5/8 BMFKF 1R318

PS-447 B 8 — 5/8 BCFJF A

1P787-793-796-798-831-837, 2P498-503-852

1R306, 1P831, 5P402

3P736

PS-447V B 8 — 5/8 VCFJF A

Optional for 1P787-793-796-798-831-1P837

1R324, 5P365

2P498-503

PS-800 C 1 1.156 5/8 BMFJF H

1P-849-850-879, 3P547-550- 571-599-648

1R307, 5P387, 5P421

1P979-984, 2P019-280, PC-18-2PC56

PS-359 C 1 1.250 5/8 BCFJF 1P898, 3P569A, 3P570A 1P557, 1R310, 5P386

PS-2160 C 1 1.250 5/8 BCFJF 3P511, 3P512, 3P579, 1P861 1R298, 5P420

PS-359V C 3 1.250 5/8 VCFJF 1P555, 1P804, 3P569, 3P570 5NC07, 5P385

PS-508 D 1 1.250 5/8 BCDJF 1R316, 5P382, 5P384

PS-851 A 1 1.375 3/4 BCFJF 1P855-868-869-895, 1P913,

1P950

5P414, 1R299

2P007-008, 2P333, 3P525 3P526, 3P600

PS-201 A 1 1.375 3/4 BMFJF 5P411, 5P412, 1R313

PS-101 A 1 1.437 3/4 BMFJF 5P416, 1R319

PS-201V A 3 1.375 3/4 VCFJF 1P946;Optional for 1P855-868-869 5P413, 1R245

1P895-913-950-979-984,

2P007-008,3P525-526-600

PS-877 C 1 1.375 3/4 BCFJF Optional for 1P700-702-799-803-947 5P389, 1R308

1P949, 2P391, 2P392, 2P393, 2P394

PS-877V C 1 1.375 3/4 VCFJF

1P700-702-799-803-947-949, 2P391 2P392,

5P388, 1R309

2P393, 2P394

PS-750 D 1 1.375 3/4 BCDJF 5P383

PS-188V E 3 1.500 7/8 VCFJF 5NC27

PS-360 A 1 1.625 1 BCFJF 5NC01, 5P417

PS-235 C 1 1.625 1 BCFJF 5P390

PS-380 D 1 1.625 1 BCFJF 5P423

PS-754 E 1 1.625 1 BCFJF 5P370

PS-356 C 1 1.750 1-1/8 BCFJF 2P015, 2P141, 3P582-601-604-609,

3P653-656-663, 3P664, 3P703-704-705-706

3P707, 3P7371R301, 3P-608, 5P391

PS-355 C 1 1.750 1-1/8 BCFKF 5P392

PS-529 C 3 1.750 1-1/8 BCFKF 5P393

PS-204 E 1 1.750 1-1/8 BCFJF 5P373

PS-253 E 3 1.750 1-1/8 BCFKF 5P372

PS-204V E 3 1.750 1-1/8 VCFJF 5NC29

PS-185 C 1 1.875 1-1/4 BCFJF 2P142, 3P660, 3P661, 3P662 5P394, IR439

PS-246 C 1 1.875 1-1/4 BCFJF B/H 5P395

PS-756 C 1 1.875 1-1/4 BCFKF 5P396

PS-361 E 1 1.875 1-1/4 BCFJF 5P374

PS-177 C 1 2.000 1-3/8 BCFJF 5P397

PS-705 E 3 2.062 1-7/16 BCFJF 5P375

PS-758 C 1 2.125 1-1/2 BCFJF 5P398

PS-609 E 1 2.312 1-5/8 BCDJF 5P377

PS-484 E 1 2.312 1-5/8 BCDKF 5P376

PS-448 C 1 2.500 1-3/4 BCFKF 5P399

PS-205 E 1 2.500 1-3/4 BCFJF 5P378

PS-1659 E 3 2.625 1-7/8 VCFJF 5NC35

PS-479V E 3 2.750 2 VCFJF 5NC36

PS-322 K 3 3.500 2-3/4 BCFKF 5P401

TERRA PRODUCTS

PS-601V B 3 1.375 3/4 VCFJF 127135

PS-245V C 3 1.625 1 VCFJF B/H 17035

THELCO CORP.

PS-348 C — — 1-1/8 BCF-F SU1774

PS-348V C——1-1/8 VCF-F SU1778

T9-1125 WT — — 1-1/8 TCF-F 316SS SU1766

PS-172 C — — 1-3/8 BCF-F SU1775

PS-172V C — — 1-3/8 VCF-F SU1789

PS-2108 C — — 1-3/4 BCF-F SU1776

PS-2108V C ——1-3/4 VCF-F SU1780

THERMO KING

PS-159 D 3 1.625 1 NCPGP 220203, 220378

PS-1128 D 3 1.875 1-1/4 NCPKF 1210A02G01

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

NOTE:

A. MOUNTS ON SHAFT

N. NON-STANDARD SPRING HOLDER

THERMOTRON INDUSTRIES

PS-3833 C 2 1.750 1-1/8 BCFKF 555824

PS-239 C 1 2.375 1-5/8 BCFKF 1246366

THOMSEN®GROUP, LLC.

PS-9700 C 1 1.625 .970 VCFJF 9122-VL

PS-185V- C 1 1.875 1-1/4 VCFJF 9123-VL

CMS

THRUSH PUMPS

PS-163 B 1 1.000 1/2 BMFJF

PS-106 C 1 1.000 1/2 BCFKF N GT, GTB, GTN Series Circulators 1/3

PS-600 B 1 1.187 5/8 BMFJF AA-190, AA-199

PS-290 C 1 1.250 5/8 BCFJF 1-1/2TV3/4, 2TV3/4, J #s 1, 2, 3, 4

PS-633V- C 1 1.250 5/8 VCFKF TX-022/024

CMS

PS-208 C — — 7/8 BCF-F 9765-0260

PS-687 C 1 1.500 7/8 BCFKF 1-1/2ATV1, 1-1/2TVI, 2TVB1-1/2, 2VTB1,

2TV1, 2TV1-1/2, 2TV2, 3TV1, 3TV1-1/2,

3TV2, N#’s1, 2, 3, 4

PS-687V C 3 1.500 7/8 VCFKF TX-026/028

PS-348 C — — 1-1/8 BCF-F 9765-0300

PS-355 C 1 1.750 1-1/8 BCFKF

2TV3, 2-1/2TV3, 2-1/2TV5, 3TV3, 3TV5, 5ATV3,

5ATV5, 5TV3, 5TV5, Series R #s 1, 2, 3, 4

PS-154 C — — 1-1/4 BCF-F 9765-0520

PS-598- C 3 1.875 1-1/4 QCFKF 7307-000-1

EPR

PS-756V C 3 1.875 1-1/4 VCFKF TX-052/054

PS-172 C — — 1-3/8 BCF-F 9765-0340

PS-210 C 1 2.000 1-3/8 BCFKF 2-1/2TV7-1/2, 3TV7-1/2, 3TV1,

5ATV7-1/2, 2-1/2TV10, 4TV10

5TV15, Series V#’s3, 4

PS-210V C 3 2.000 1-3/8 VCFKF TX-035/036

PS-2107 C — — 1-5/8 BCF-F 9765-0560

PS-239V C 3 2.375 1-5/8 VCFKF TX-056/058

TOLEDO

PS-501 A 1 1.250 5/8 BMFJF A14067

TONKAFLOW (See G.E. OSMONICS)

TORO CO.

PS-200V- A 1 1.250 5/8 VCFJF 42088

CMS

PS-200V- A 3 1.250 5/8 VCFLF 99-0582

SC-SEAT

TRANE, INC.

PS-192 C3 2.125 1-1/2 NCFGF X10063400000

TRIPLEX HEATING

PS-165 B 9 .906 1/2 BMFJF A

PS-452 B 9 — 5/8 BMFJF A

PS-202 B11 —5/8 BMFJF A

TRUPAR

PS-507 A 1 1.250 5/8 BMFKF P-1190

PS-102 D 1 1.250 5/8 BCDKF P-11048

PS-201 A1 1.375 3/4 BMFJF P-11201

TRW(See REDAPUMP)

TUTHILL PUMP CO.

PS-633 C 11.250 5/8 BCFKF 2C1B9

PS-768 C 3 1.375 3/4 BCFKF 3C1B9

PS-499 C 3 1.625 1 BCFKF 5C1B9

PS-4189 E 3 2.250 1 BCPKF CC0919-1A

NOTE:

I. ABRASION RESISTANT CARBON (P66)

N. NON-STANDARD SPRING HOLDER

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

TUTHILL VACUUM SYSTEMS

PS-358V- C 1 1.375 3/4 VCFJF 065046 A000

CMS

PS-768 C 3 1.375 3/4 BCFKF 065238 A000

PS-252 D 3 1.625 1 BCFKF 065024 A00

PS-529- C 3 1.750 1-1/8 QCFKF I 065277 00EP

EPR-P66

PS-355V C 3 1.750 1-1/8 VCFKF 065049 A000

PS-154V C — — 1-1/4 VCF-F 065220 0000

PS-185V- C 1 1.875 1-1/4 VCFJF 065239 A001

CMS

PS-4123 D 3 2.000 1-3/8 VCFKF 005019-2-B

PS-758V- C 1 2.125 1-1/2 VCFJF 065240 A000

CMS

PS-534 D 3 2.125 1-1/2 BCFKF

PS-4408 D 3 2.125 1-1/2 B/VCPKP 065018 A000

PS-238V- C 1 2.375 1-5/8 VCFJF 065241 A000

CMS

PS-446V C 3 2.500 1-3/4 VCFJF 065289 A000

FA-1875 C — — 1-7/8 BCF-F 065215 0000

FA-1875V C — — 1-7/8 VCF-F 065219 0000

FA-2120 C — — 2-1/8 BCF-F 065214 0000

PS-1678V C 3 3.125 2-1/4 VCFJF 065242 A00

UNITED SERVICE EQUIPMENT

PS-1133 C 1 1.181 7/16 BCFJF 1034A7

U.S. ELECTRICAL MOTOR

PS-358 C 1 1.375 3/4 BCFJF PUL-2112

PS-356 C 1 1.750 1-1/8 BCFJF

PS-320 C 1 2.250 1-1/2 BCFJF Frame 213

U.S. FILTER

PS-1002V C 1 1.000 1/2 VCFJF N 7802910

PS-290V C 1 1.250 5/8 VCFJF 7802918

PS-1687 D 1 3.000 2-1/8 BCFKF U18080

VERTIFLO PUMP CO.

PS-358 C 1 1.375 3/4 BCFJF SJ-2112-C1-00

PS-358V- C 1 1.375 3/4 VCFJF SJ-2112-C1-X2

CMS

PS-112V- C 1 1.375 3/4 VCFKF SJ-2112-71-X0

CMS

PS-7305 C 1 1.375 3/4 VLFLF 316SS SJ-2112-S1-X2

PS-756 C 1 1.875 1-1/4 BCFKF SJ-2120-71-00

PS-3886 C 1 1.875 1-1/4 VCFJF 316SS SJ-2120-C1-X2

PS-185V- C 1 1.875 1-1/4 VCFJF SJ-2120-C1-X0

CMS

PS-758 C 1 2.125 1-1/2 BCFJF SJ-2124-C1-02

PS-659 C 1 2.125 1-1/2 BCFKF SJ-2124-71-00

PS-758V- C 1 2.125 1-1/2 VCFJF SJ-2124-C1-X0

CMS

PS-7409 C 1 2.125 1-1/2 VCFJF 316SS SJ-2124-C1-X2

PS-659V- C 1 2.125 1-1/2 VCFKF SJ-2124-71-X0

CMS

PS-238 C1 2.375 1-5/8 BCFJF SJ-2126-C1-00

PS-239 C1 2.375 1-5/8 BCFKF SJ-2126-71-00

PS-238V-C1 2.375 1-5/8 VCFJF SJ-2126-C1-X0

CMS

PS-239V- C 1 2.375 1-5/8 VCFKF SJ-2126-71-X0

CMS

PS-844 C 1 3.000 2-1/8 BCFJF SJ-2134-C1-00

VIC CLEANING MACHINE

PS-162 A 1 1.000 1/2 BMFJF 22-907

PS-701 A 11.187 5/8 BMFKF 42-607

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

VICO (BALBOA WATER GROUP)

PS-2136 A 1

1.375/ 1.750

3/4 BCFJF SuperFlo, UltraFlo, Ultima PPSFSeal

VIKING INSTRUMENT

PS-162 A 1 1.000 1/2 BMFJF 1-3438-3

VIKING PUMP, INC. (Div. of IDEX CORP.)

PS-6321 C 3 1.125 1/2 BCFKF 2-471-051-999-00

PS-3735 C 3 1.125 1/2 VCFKF 2-471-052-999-00

PS-7948 E Special 1.193 1/2 BCPKF 2-471-003-999-00

PS-7948N E Special 1.193 1/2 NCPKF 2-471-019-999-00

PS-7948V E Special 1.193 1/2 VCPKF 2-471-017-999-00

PS-9320

WSpecial

Special 1.193 1/2 TCPKF 316SS 2-471-004-999-00

PS-1625 C 3 1.250 5/8 BCFKF 2-472-014-999-00

PS-1625- C 3 1.250 5/8 QCFKF 2-472-016-999-00

EPR

PS-1626 C 3 1.250 5/8 VCFKF 2-472-015-999-00

PS-9321 W 2 1.250 5/8 TCFKF 316SS 2-472-006-999-00

PS-9322 WT 28 1.490 5/8 TCFOF 316SS 2-472-012-990-00

PS-7087 D 3 1.375 3/4 BCPKF 2-473-003-999-00

PS-7613 D 3 1.375 3/4 NCPKF 2-473-009-999-00

PS-7613V D 3 1.375 3/4 VCPKF 2-473-018-999-00

PS-3935 W 2 1.375 3/4 TCFKF 316SS 2-473-038-999-00

PS-9324 W 2 1.375 3/4 TCFKF 316SS 2-473-006-999-00

PS-9323

WSpecial

2 1.375 3/4 TCFKF 316SS 2-473-001-999-00

PS-9325

WSpecial

2 1.375 3/4 TCFOF 316SS 2-473-034-999-00

PS-460 D 1 1.625 1 BCFKF 2-475-002-999-00

PS-6328 D 3 1.625 1 BCPKF 2-475-001-999-00

PS-6329 D 3 1.625 1 NCPKF 2-475-005-999-00

PS-1630V D 3 1.625 1 VCPKF 2-475-010-999-00

PS-6331 E 3 1.625 1 BCPKF 2-475-115-999-00

PS-3803 E 3 1.625 1 VCFKF 2-475-012-999-00

PS-1631 T 3 1.625 1 NCPKF 2-475-004-999-00

PS-9313 W 2 1.625 1 TCFKF 316SS 2-475-019-999-00

PS-9334 W 2 1.625 1 TCFOF 316SS 2-475-025-999-00

PS-7967 E 3 2.000 1-1/8 BCPKF 2-476-001-999-00

PS-3653 E 3 2.000 1-1/8 NCPGF 2-476-006-999-00

PS-6334 E 3 2.000 1-1/8 VCPKF 2-476-012-999-00

PS-7232 W 2 2.000 1-1/8 TCFKF 316SS 2-476-003-999-00

PS-9327 W2 2.000 1-1/8 TCFOF 316SS 2-476-005-999-00

PS-9328 W 28 2.354 1-1/8 TCFKF 316SS 2-476-123-999-00

PS-9329 W 28 2.354 1-1/8 Special 316SS 2-476-133-999-00

PS-3731 Special 3 1.625 1-1/8 BCPKP 2-476-018-999-00

PS-6339 D 3 1.875 1-1/4 BCPKF 2-477-100-999-00

PS-3934 D 3 1.875 1-1/4 NCPKF 2-477-019-999-00

PS-1632V D 3 1.875 1-1/4 VCPKF 2-477-020-999-00

PS-3611 WT 2 1.875 1-1/4 TCFOF 316SS 2-477-140-999-06

PS-9003 WT 2 2.343 1-1/4 TCFKF 316SS 2-477-018-999-00

PS-7105 C32.250 1-7/16 BCFKF 2-477-288-999-00

335-00-180-243

PS-4067 E3 2.125 1-7/16 VCFKF 2-477-042-999-00

PS-6340 E 3 2.171 1-7/16 BCPKF 2-477-173-999-00

PS-6342 E 3 2.171 1-7/16 VCPKF 2-477-180-999-00

PS-4189 E32.250 1-7/16 BCPKF

PS-1634 E 3 2.250 1-7/16 BCPKP 2-477-008-999-00

PS-3848 E 3 2.312 1-7/16 BCPKF 2-477-001-999-00

PS-6344 E 3 2.312 1-7/16 NCPKF 2-477-429-999-00

PS-6338 E 3 2.312 1-7/16 VCPKF 2-477-038-999-00

335-00-210-024

PS-4140 E 32.375 1-7/16 VCFLF 2-477-669-999-00

PS-1633 T 3 2.187 1-7/16 NCPKF 2-477-006-999-00

PS-9227 W 2 2.312 1-7/16 TCFKF 316SS 2-477-003-999-00

PS-9307 W 2 2.312 1-7/16 TCFOF 316SS 2-477-005-999-00

PS-9304 W 22.687 1-7/16 TCFKF 316SS 2-477-116-999-00

PS-9330 W Special 2.484 1-7/16 TCFKF 316SS 2-477-179-999-00

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

NOTE:

B.TAPERED SPRING

VIKING PUMP, INC. (Div. of IDEX CORP.) (continued)

PS-9331 W 28 2.687 1-7/16 Special 316SS 2-477-346-999-00

PS-819 D 3 2.375 1-5/8 BCDKF 2-478-011-999-00

PS-6348 E 3 2.375 1-5/8 BCPKF 2-478-041-999-00

PS-6349 E 3 2.375 1-5/8 VCPKF 2-478-046-999-00

PS-9017 WT 28 2.875 1-5/8 TCFKF 316SS 2-478-040-999-00

PS-9332 WT 28 2.875 1-5/8 TCFOF 316SS 2-478-026-999-00

PS-7580 E 3 3.437 2-7/16 BCPKP 2-480-001-999-00

PS-3751 E 3 3.437 2-7/16 VCPKF 2-480-004-999-00

PS-9333 W 28 4.000 2-7/16 TCFKF 316SS 2-480-051-999-00

PS-3505 U 3 4.375 3-7/16 VCPKF 2-481-006-999-00

VILTER MFG., INC.

PS-6175 R 3 3.875 3 NCPGP A-33489-A

VULCAN-HART

PS-1618 C 1 1.250 5/8 BCFJF B

PS-508 D 1 1.250 5/8 BCDJF

PS-360 A 1 1.625 1 BCFJF 97505

PS-236 E 1 1.625 1 BCFKF 97049

PS-1167 C 1 1.750 1-1/8 BCFKF B

PS-604 D 1 1.750 1-1/8 BCFJF

WATER ACE PUMP CO. (Part of Pentair Pump Group)

PS-3845 B 8 1.299 5/8 BMFJF Models RSP-7,10,15 25053A000

WATERCO USA

PS-3985 B 1 1.375 3/4 BCFJF Supatuf 634016

PS-185 C 1 1.875 1-1/4 BCFJF 19B5032

PS-446 C 1 2.500 1-3/4 BCFJF 19B5033

WATEROUS CO.

PS-499 C 3 1.625 1 BCFKF

PS-3010 G 3 1.625 1 BCFLF V-3386

PS-605 D 1 1.750 1-1/8 BCFKF V-1467

PS-3013 G 25 1.750 1-1/8 VCFLF 316SS V-3505

PS-598 C 3 1.875 1-1/4 BCFKF V-2145

PS-383V D 3 1.875 1-1/4 VCFKF V-1150

PS-6266 G 3 1.875 1-1/4 BCFLF 316SS V-3218

PS-659V C 3 2.125 1-1/2 VCFKF

WATERWAY PLASTICS

PS-671 B1 .875 3/8 BMFJF Tiny Mite 811-4000A

PS-1000 B11.250 5/8 BMFJF 319-3100B

WATTS

PS-680 A 1 1.187 5/8 BCFJF Close Coupled Circulator

PS-1000 B11.250 5/8 BMFJF

WAUKESHA CHERRY-BURRELL

PS-239V C32.375 1-5/8 VCFKF PG4-45, 5164130809

PS-267V C3 2.750 2 VCFJF PG4-46

PS-1145 C 1 2.750 2 VCFKF PG4-46, 5065080809

PS-1676 C 3 3.125 2-1/4 BCFKF 5065711207

WAUKESHA MOTORS

PS-642 B — — 5/8 BMF-F 102320 & 20B

PS-1522 A — — 3/4 BMF-F 810350

PS-201 A11.375 3/4 BMFJF 152243-B

PS-647 B — — 3/4 BMF-F 120828

PS-752 D11.375 3/4 BCDKF

PS-685 R 1 1.500 7/8 BCDKF 108025

PS-1619 B 11.625 1 BCDJF 117177G-J

PS-380 D 1 1.625 1 BCFJF

PS-604 D11.750 1-1/8 BCFJF

157475, 157475E, 157475K

PS-185 C 1 1.875 1-1/4 BCFJF 178033

WAYNE COMBUSTION SYSTEMS

PS-162 A 1 1.000 1/2 BMFJF 15717 / 56106

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

NOTE:

B.TAPERED SPRING

I. ABRASION RESISTANT CARBON (P66)

WAYNE COMBUSTION SYSTEMS (continued)

PS-163 B 1 1.000 1/2 BMFJF 15863 / 56108

PS-400 C — — 1/2 BMF-F 15189

PS-1137 Q 1 1.000 1/2 BMFJF 15780 / 56107

PS-200 A 1 1.250 5/8 BMFJF Series SJ-CJX 15559 / 56104

PS-642 B — — 5/8 BMF-F

PS-1000 B 1 1.250 5/8 BMFJF 15996 / 56109

PS-1155 C 1 1.187 5/8 BCFJF Series J and S 15529

PS-201 A 1 1.375 3/4 BMFJF 15693 / 56105

PS-201V A 3 1.375 3/4 VCFJF 16229

WAYNE PUMPS

PS-974 A — — 3/4 BCF-F 16829

PS-1522 A — — 3/4 BMF-F 16725

PS-150 B — — 1/2 BMF-F 16722

WDM PUMPS

PS-864V E 3 2.000 1-3/8 VCFJF MSIXFCEA138

PS-436V C 3 2.500 1-3/4 VCFKF MS21XFNRAC134

WEBER INDUSTRIES, INC.

PS-359V- C 1 1.250 5/8 VCFJF 70X120-M

CMS

PS-851 A 1 1.375 3/4 BCFJF 70X107-M

PS-358V- C 1 1.375 3/4 VCFJF 70X121-M

CMS

PS-356V- C 1 1.750 1-1/8 VCFJF 70X118-M

CMS

PS-185V- C 1 1.875 1-1/4 VCFJF 70X123-M

CMS

PS-446V- C 1 2.500 1-3/4 VCFJF 70X125-M

CMS

WEBSTER ELECTRIC

PS-218 A — — 5/8 BCF-F

PS-467 C 1 2.125 1-3/8 BCFKF 151-26815

WEIL PUMP CO., INC.

PS-100 A 1 1.187 5/8 BMFJF 1-1/4" Submersible 17-30009-005

PS-600 B 1 1.187 5/8 BMFJF

PS-1000 B 1 1.250 5/8 BMFJF

PS-933- C — — 5/8 BCF-F I 330.016.000

P66

PS-989 C 1 1.187 5/8 N/BCFJF B

PS-851 A11.375 3/4 BCFJF 17-62372-008

PS-358 C 1 1.375 3/4 BCFJF 205.016.101

PS-358V- C 1 1.375 3/4 VCFJF 205.093.101

CMS

PS-750 D 1 1.375 3/4 BCDJF X1397, X2372

PS-617 C 3 1.500 7/8 BCFKF X3452

PS-380 D 1 1.625 1 BCFJF X992

PS-2033 D 3 1.625 1 BCFJF 17-62427-000

PS-754 E 1 1.625 1 BCFJF X993

PS-356 C 1 1.750 1-1/8 BCFJF 137-000-129

PS-604 D11.750 1-1/8 BCFJF X2428

PS-802 D 3 1.750 1-1/8 BCFJF 17-62428-008

PS-204 E1 1.750 1-1/8 BCFJF

PS-384 E 1 1.750 1-1/8 BCFKF X-217UKY

PS-866 E31.750 1-1/8 BCFJF 17-61117-008

PS-381 D11.875 1-1/4 BCFJF X2174, X-2429UKY

PS-804 D 3 1.875 1-1/4 BCFJF 17-62429-006

PS-1623 K 3 2.125 1-1/4 BCFJ/KF 17-05511-001

PS-210 C 1 2.000 1-3/8 BCFKF Model AS

PS-758 C 12.125 1-1/2 BCFJF 205.228.001

PS-758- C 1 2.125 1-1/2 BLFLF 205.229.001

SC-SC

PS-758V- C 1 2.125 1-1/2 VCFJF 205.228.002

CMS

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

NOTE:

B.TAPERED SPRING

H. SPRING HOLDER NOTINCLUDED

I. ABRASION RESISTANT CARBON (P66)

WEIL PUMP CO., INC.

PS-758V- C 1 2.125 1-1/2 VLFLF 205.229.002

SC-SC

PS-926 C 3 2.312 1-1/2 BCFJF

PS-514 D 1 2.375 1-5/8 BCDJF Model AYM-2-1/2x3

PS-1142 K 3 2.500 1-3/4 BCFJ/KF 17-05514-005

PS-2069 E 1 2.625 1-7/8 BCFJF Model AYM-4x5

PS-267 C 1 2.750 2 BCFJF 205.258.001

PS-847 D 3 3.125 2-1/4 BCDKF Model AYM 5 & 6 17-62550-009

WEINMAN (Div. of CRANE PUMPS & SYSTEMS)

PS-501 A 1 1.250 5/8 BMFJF Types- 4, 5, 6 & 8ACK, 4&6AEK

PS-4371 A 1 1.250 5/8 VCFJF I Q26-77-Y25

PS-3816 A 1 1.250 5/8 VCFKF I Q26-77-Y6

PS-309 C 1 1.500 7/8 BCFJF Q26-394-Y2

PS-188 E 1 1.500 7/8 BCFJF Type 2SB Q26-177-Y3

PS-245 C 1 1.625 1 BCFJF B/H Types- 4AE, 6AC, 6AE, & 6AC Q26-201-Y2

PS-248 C 1 1.625 1 BCFKF B/H Types- 4AE, 6AC, 6AE, & 6AC Q26-143-Y34

PS-380 D 1 1.625 1 BCFJF Q26-78-Y3

PS-204 E 1 1.750 1-1/8 BCFJF Q26-184-Y3

PS-384 E 1 1.750 1-1/8 BCFKF Q26-102-Y35

PS-546 E 3 1.875 1-1/4 BCFJF Q26-243-Y2

PS-228 K 3 1.875 1-1/4 BCFKF FR#11, 3UE-B11, 4UD-B11, 4UE-B11 Q26-190-Y34

PS-185 C 1 1.875 1-1/4 BCFJF Q26-166-Y2

Q26-395-Y2

Q26-395-Y21

PS-246 C 1 1.875 1-1/4 BCFJF B/H Group A-Type 1G, 1-1/4G, 1-1/2G, 1-1/2K, Q26-166-Y2

1-1/2KH, 2G, GB,and KB. Grp. B-7-1/2.

HP & Less at 1750: 20 HP & less at

3500 RPM Types. 1-1/2KH, 2K, 2-1/2G,

2-1/2K, 3G, 3K, 4GL, and 4G

PS-2122 C 1 1.875 1-1/4 BCFJF Q26-243-Y2

PS-185- C 1 1.875 1-1/4 BCFJF I Q26-395-Y21

P66

PS-249 C 1 1.875 1-1/4 BCFKF B/H Q26-276-Y34

PS-2123 C 1 1.875 1-1/4 BCFKF Q26-102-Y34

PS-756 C 1 1.875 1-1/4 BCFKF 1G2A30P12G-D Q26-395-Y34

PS-185- C 1 1.875 1-1/4 BLFLF Q26-395-Y39

SC-SC

PS-1082 C 1 1.875 1-1/4 NCFKF Q26-395-Y24

PS-185V- C 1 1.875 1-1/4 VCFJF I Q26-395-Y25

CMS-P66

PS-756V C31.875 1-1/4 VCFKF Q26-395-Y6

PS-381 D 1 1.875 1-1/4 BCFJF Q26-79-Y3

PS-383 D 1 1.875 1-1/4 BCFKF Q26-5-Y35

PS-361 E 1 1.875 1-1/4 BCFJF When Seal is Mounted on Shaft: Q26-243-Y3

2L-4, 5, 6, 3L-6, 4L3, 5L3

PS-137 E 1 1.875 1-1/4 BCFKF Q26-102-Y35

PS-264 E 3 1.875 1-1/4 BCFKF Q26-243-Y34, Q26-243-Y35

PS-7702 E Bal. 3 1.875 1-3/8 BCFJF Q26-415-Y34

PS-4145 E Bal. 3 1.875 1-3/8 BCFZF Q26-318-Y10

PS-3769 EBal. 31.875 1-3/8 VCZFZ I Q26-318-Y17

PS-347 C 1 2.125 1-1/2 BCFJF B/H Group B-10 HP, Over at 1750; 25 HP Q26-167-Y2

Over at 3500 RPM 1-1/2KH, 2K, 2-1/2G,

2-1/2K, 3G, 3K, 4GL, 4G.

Group C TYP.- 2-1/2KH.

PS-378 C 1 2.125 1-1/2 BCFKF B/H Q26-175-Y34

PS-382 D 1 2.125 1-1/2 BCFJF Q26-167-Y3

PS-305 E 1 2.125 1-1/2 BCFJF When Seal is Mounted on Sleeve: Q26-264-Y3

2L-4, 2L-5, 3L-6, 4L-2, 4L-3, 5L-3.

When Seal is Mounted on Shaft:

2-1/2JC,3L-4, 3L-5, 4L-1, 5L-2, 6L-2, 6L03.

PS-374 E 1 2.125 1-1/2 BCFKF Q26-265-Y35

PS-395 E 3 2.125 1-1/2 BCFJF Q26-178-Y2, Q26-178-Y3

PS-258 E 32.125 1-1/2 BCFKF Q26-178-Y35

80 NOTE:

I. ABRASION RESISTANT CARBON (P66)

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

WEINMAN (Div. of CRANE PUMPS & SYSTEMS) (continued)

PS-305V- E 3 2.125 1-1/2 VCFJF I Q26-178-Y25

P66

PS-374V E 3 2.125 1-1/2 VCFKF Q26-178-Y16

PS-818 C 3 2.375 1-5/8 BCFJF Q26-373-Y12

PS-544 C 3 2.375 1-5/8 BCFKF Q26-373-Y34

PS-238V C 3 2.375 1-5/8 VCFJF Q26-373-Y25

PS-239V C 3 2.375 1-5/8 VCFKF Q26-373-Y16

PS-745 E 1 2.375 1-5/8 BCDJF When Seal is Mounted on Shaft: Q26-240-Y13

Type 3JC, 4L-4, 5L-1, 8L-3

PS-744 E 1 2.375 1-5/8 BCDKF Q26-241-Y35

PS-822 E 3 2.375 1-5/8 BCDKF Q26-240-Y35

PS-1699 E 3 2.375 1-5/8 BCFKF Q26-240-Y34

PS-7787 E 3 2.375 1-5/8 QCDZF I Q26-240-Y30

PS-1699V- E 3 2.375 1-5/8 VCFKF I Q26-240-Y6

P66

PS-205 E 1 2.500 1-3/4 BCFJF When Seal is Mounted on Sleeve: Q26-222-Y13

Type 3L-4, 3L-5, 4L-1, 5L-2, 6L-2, 6L-3. Q26-217-Y13

When Seal is Mounted on Shaft: 2-1/2JC.

PS-205- E 1 2.500 1-3/4 BCFJF I Q26-179-Y21

P66

PS-366 E 1 2.500 1-3/4 BCFKF Q26-223-Y35

PS-205V- E 1 2.500 1-3/4 VCFJF Q26-179-Y25

CMS

PS-535 E 3 2.500 1-3/4 BCFJF Q26-217-Y2, Q26-217-Y25

PS-262 E 3 2.500 1-3/4 BCFKF

Q26-217-Y35, Q26-217-Y34

PS-3540 E 3 2.500 1-3/4 QZFZF

PS-7774 E Bal. 3 2.375 1-3/4 BCFJF Q26-319-Y10

PS-2231 E Bal. 3 2.375 1-3/4 BCFKF Q26-304-Y2

PS-7821

EBal.

32.375 1-3/4

BCFZF

PS-449 K 1 2.500 1-3/4 BCFJF Frame #12-3UE, 4UD, 4UE-B12

Frame #13: 4UF, 5UF, 6UG-B13 Q26-191-Y12

PS-2170 U 3 2.500 1-3/4 BCFJF Q26-179-Y13

PS-479 E 1 2.750 2 BCFJF When Seal is Mounted on Shaft: Q26-267-Y13

Type 6L-1, 8L-2, 10L-2,10L-3. When Seal

Mounted on Sleeve: 4L-4, 5L-1 and 8L-3

PS-477 E 3 2.750 2 BCFKF Q26-268-Y35

PS-7892 EBal. 3 2.625 2 BCFKF Q26-305-Y34

PS-385A U 3 2.750 2 BCFKF 3JC and 5LI Split Case Q26-180-Y35

PS-4391 U32.750 2VLFLF 8L2

PS-3784 E Bal. 3 3.000 2-1/4 BCFJF Q26-306-Y12

PS-3643 E Bal. 3 3.000 2-1/4 BCFKF Q26-306-Y34

PS-7749 E Bal. 3 3.000 2-1/4 BCFKF Q26-306-Y10

PS-3656 E Bal. 3 3.000 2-1/4 VCFZF I Q26-306-Y17

PS-2097- E 1 3.250 2-3/8 BCFJF Q26-181-Y12

CMS

PS-350 E33.250 2-3/8 BCFKF Q26-181-Y34, Q26-181-Y35

Q26-275-Y35

PS-278 E3 3.250 2-3/8 BCFJF

When Seal is Mounted on Shaft: 8L-1, 12L-2 Q26-273-Y03

When Seal is Mounted on Sleeve:

6L-1, 8L-2, 10L-3

PS-350V- E 3 3.250 2-3/8 VCFZF I Q26-181-Y17

P66-TC

PS-2158 K 1 3.375 2-1/2 BCFJF Q26-406-Y12

PS-279 E 3 3.375 2-1/2 BCFJF Pump Type 10L-2, Seal is Mtd. on Sleeve Q26-182-Y13

PS-349 E33.375 2-1/2 BCFKF Q26-198-Y35

PS-7927 E Bal. 3 3.375 2-5/8 BCFKF Q26-340-Y34

PS-324 E 3 3.875 3 BCDJF Type 8L-1, 12L-2 Seal is Mtd. on Sleeve Q26-199-Y13

PS-475 E 3 3.875 3 BCDKF Q26-183-Y35

PS-5252 E 3 3.875 3 BCFKF Q26-183-Y34

WEIR SPECIALTY PUMPS

PS-758 C 1 2.125 1-1/2 BCFJF 157258

PS-7409 C 1 2.125 1-1/2 VCFJF 316SS 157256

PS-2209 C 12.125 1-1/2 BZFZF 52597

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

WEIR SPECIALTY PUMPS (continued)

PS-3558 K 3 2.375 1-1/2 BCFJF 157319

PS-4304 K 1 2.500 1-3/4 VZFZF 157472

PS-267 C 1 2.750 2 BCFJF 157259

PS-267V- C 1 2.750 2 VCFJF 157554

CMS

PS-4343 K 3 2.750 2 BZ/CFZ/JF 804820

PS-1679 C 1 3.125 2-1/4 BCFJF 52600

PS-2120 C 1 3.375 2-1/2 BCFJF 157599

PS-324SS E 3 3.875 3 BCFJF 157474

WELLS BLOOMFIELD

PS-359 C 1 1.250 5/8 BCFJF 35902

WEMCO (Div. of WEIR SPECIALTY PUMPS)

PS-541 K 1 2.125 1-1/2 BCFJF 157174

WESTINGHOUSE

PS-663 Q 1 1.000 1/2 BMFJF 69782

WHEELER, C.H.

PS-218 A — — 5/8 BCF-F

PS-702 A 1 1.187 5/8 BMFJF Reuse Brass Seat Housing

WHITE

PS-701 A 1 1.187 5/8 BMFKF

PS-200 A 1 1.250 5/8 BMFJF

WORTHINGTON (See FLOWSERVE CORP.)

PS-928 C — — 9/16 BCF-F 1 GA 055954-00, 74744277

PS-200 A 1 1.250 5/8 BMFJF Model 1-1/40CS-5, 1-1/4OM-5 043008-00

PS-507 A 1 1.250 5/8 BMFKF 1-1/2PM3

PS-528 A 1 1.375 5/8 BMFJF Delta 512 and 520 PO2098-00, 285186052

PS-200V A 3 1.250 5/8 VCFJF

PS-933 C — — 5/8 BCF-F 2GAR, 2GA 055955-00

PS-359 C 1 1.250 5/8 BCFJF 050675-00

PS-359V- C 1 1.250 5/8 VCFJF 74315409

CMS

PS-626 C 1 1.375 5/8 VCFJF Delta 520 PO2099-00

PS-951 C 3 1.375 5/8 VCFKF Delta 512 and 520 PO2752-00, 7426767

PS-201 A 1 1.375 3/4 BMFJF 1-1/2PE, 3 & 4

PS-564 C — — 3/4 BCF-F 3 & 4 GA Pumps 024439-00

PS-373 C 1 1.375 3/4 BCFKF Frame 1A,DN2 026493-00, 026492-00

PS-768 C 3 1.375 3/4 BCFKF SEL 244

PS-578 D—— 7/8 BCD-F 5 & 6 AUM

PS-936 E— — 7/8 BCF-F 5 & 6 GAUM 024440-00, 27197631

PS-560SS U 2 1.562 15/16 BCFKF Frame 1 026456-00, 031446-00

PS-370 A 1 1.625 1 BCFKF

PS-348 C — — 1-1/8 BCF-F PO2885-00, 28518934

68885854

PS-801 C 3 1.750 1-1/8 BCFJF Frame 1 D-812, 820, 1012, 1020 PO2885-00 w/ PO2897-00

PS-529 C31.750 1-1/8 BCFKF Frame 1 D-812, 820, 1012, 1020 PO2885-00 w/ PO2893-00

PS-356V C 3 1.750 1-1/8 VCFJF Frame 1 D-812, 820, 1012, 1020 PO2889-00 w/ PO2897-00

PS-355V C31.750 1-1/8 VCFKF Frame 1 D-812, 820, 1012, 1020 PO2889-00 w/ PO2893-00

PS-866 E 3 1.750 1-1/8 BCFJF Frame 1 D-1011, 1021 PO2869-00 w/ PO2897-00

PS-867 E 3 1.750 1-1/8 BCFKF Frame 1 D-1011, 1021 PO2869-00 w/ PO2893-00

PS-282 U 3 1.750 1-1/8 BCFKF 2-1/2 LR10 051610-00, 053129-00

PS-394 U31.875 1-1/4 BCF/DKF 2, 2-1/2 GRM1, 3GRWMCI 03144800, 74295924

PS-805 C 3 2.000 1-3/8 BCFJF Frame 2 D-812, 820, 1012, 1020 PO2886-00 w/ PO2898-00

PS-547 C 3 2.000 1-3/8 BCFKF Frame 2 D-812, 820, 1012, 1020 PO2886-00 w/ PO2894-00

PS-177V C 32.000 1-3/8 VCFJF Frame 2 D-812, 820, 1012, 1020 PO2890-00 w/ PO2898-00

PS-210V C 3 2.000 1-3/8 VCFKF Frame 2 D-812, 820, 1012, 1020 PO2890-00 w/ PO2894-00

PS-864 E 3 2.000 1-3/8 BCFJF Frame 2 D-811, 821, 1011, 1021 PO2870-00 w/ PO2898-00

PS-865 E 3 2.000 1-3/8 BCFKF Frame 2 D-811, 821, 1011, 1021 PO2870-00 w/ PO2894-00

PS-561SS U 1 2.000 1-3/8 BCFKF Frame 2 2-1/2 LR-13 050498-00, 026457-00

272150-94

PS-2106V E ——1-1/2 VCF-F 605061-69

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

NOTE:

A. MOUNTS ON SHAFT

WORTHINGTON (continued) (See FLOWSERVE CORP.)

PS-258 E 3 2.125 1-1/2 BCFKF 3LR-9, 4,5,& 6LR-10, 3LR-12, 4LR-12, 051612-00 w/ 053130-00

1-1/2LLR-7, 1-1/2LLR-10, 2LLR-9

PS-395 E 3 2.125 1-1/2 BCFJF 3LR-9, 4,5 & 6LR-10, 3LR-12, 051708-00 w/ 053130-00

4LR-121-1/2LLR-7, 1-1/2LLR-10, 2LLR-9

PS-458 U 3 2.375 1-5/8 BCDKF 4LR-14, 5LR-13, 4LR-11 051613-00 w/ 053132-00

PS-2108 C — — 1-3/4 BCF-F PO2887-00, 28518876

PS-2108V C — — 1-3/4 VCF-F PO2891-00

PS-550 C 3 2.500 1-3/4 BCFJF Frame 3 D-812, 820, 1012, 1020 PO2887-00 w/ PO2899-00

PS-436 C 3 2.500 1-3/4 BCFKF Frame 3 D-812, 820, 1012, 1020 PO2887-00 w/ PO2895-00

PS-7679 C 3 2.500 1-3/4 VLFLF

PS-535 E 3 2.500 1-3/4 BCFJF Frame 3 D-811, 821, 1011, 1021 PO2871-00 w/ PO2899-00

PS-262 E 3 2.500 1-3/4 BCFKF Frame 3 D-811, 821, 1011, 1021 PO2871-00 w/ PO2895-00

PS-555 U 1 2.500 1-3/4 BCFD/KF Frame 3 026458-00

PS-555SS U 1 2.500 1-3/4 BCFKF Frame 3 050499-00

PS-2070 E 1 2.625 1-7/8 BCFKF 4GRWM 031449-00

PS-1108 V 1 2.625 1-7/8 BMFJF 4FNC-10

PS-477 E 3 2.750 2 BCFKF 2˝ HBL, 4GRM, 5GRWM 031450-00

PS-456 U 3 2.750 2 BCFKF 5LR-15, 6LR-13, 6LR-16, 8LR-13 051614-00 w/ 053133-00

PS-385A U 3 2.750 2 BCFKF 8LR-14

PS-854 C 3 2.875 2-1/8 BCFJF Frame 4 D-1012, 1020 PO2888-00 w/ PO2900-00

PS-855 C 3 2.875 2-1/8 BCFKF Frame 4 D-1012, 1020 PO2888-00 w/ PO2896-00

PS-856 E 3 2.875 2-1/8 BCFJF Frame 4 D-1011, 1021 PO2872-00 w/ PO2900-00

PS-857 E 3 2.875 2-1/8 BCFKF Frame 4 D-1011, 1021 PO2872-00 w/ PO2896-00

PS-556 U 2 3.000 2-1/8 BCFKF Frame 4 026459-00, 050500-00

PS-475 E 3 3.875 3 BCDKF 6LR-18, 10LR-15 055426-00 w/ 055425-00

PS-330 E 3 4.125 3-1/4 BCDJF 6 UZD-1

YOEMANS CHICAGO CORP. (See CLOW CORP.)

YORK (See JOHNSON CONTROLS)

ZODIAC POOL SYSTEMS, INC. (See JANDY)

ZOELLER PUMP CO.

PS-4218 B — — 1/2 BCF-F 009567

PS-3033 Q 8 .906 1/2 BCFKF 005095

PS-7929 B 1 1.250 5/8 VLFLF 012240

PS-447 B 8 — 5/8 BCFJF A 001016, 001017

PS-397 C — — 1 BCF-F 007767

PS-356 C 1 1.750 1-1/8 BCFJF 006510

PS-4443 C 1 1.750 1-1/8 BCFLF 011125

PS-355- C 1 1.750 1-1/8 BLFLF 011124

SC-SC

PS-356V- C 1 1.750 1-1/8 VLFLF 011126

SC-SC

PS-185 C11.875 1-1/4 BCFJF 008165

PS-185- C11.875 1-1/4 BLFLF 011128

SC-SC

PS-2208 C 1 1.875 1-1/4 BZFZF 008166

PS-185V- C 1 1.875 1-1/4 VCFJF 008177

CMS

PS-185V- C 1 1.875 1-1/4 VCFLF 011131

SC-SEAT

PS-4150 C11.875 1-1/4 VLFLF 316SS 011130

PS-758 C 1 2.125 1-1/2 BCFJF 006500

PS-758- C 1 2.125 1-1/2 BCFLF 007024

SC-SEAT

PS-629-TC C 1 2.125 1-1/2 BCFZF 007024

PS-758- C 1 2.125 1-1/2 BLFLF 007023

SC-SC

PS-2209 C 1 2.125 1-1/2 BZFZF 007011

PS-758V- C 12.125 1-1/2 VCFJF 007027

CMS

U.S. Seal Mating Mating Shaft Material

Part No. Head Ring Ring OD Dia. Code Notes Pump Nameplate Data Mfg. Part No.

PUMP MANUFACTURERS’ CROSS-REFERENCE

ZOELLER PUMP CO. (continued)

PS-758V- C 1 2.125 1-1/2 VCFLF 011133

SC-SEAT

PS-758V- C 1 2.125 1-1/2 VLFLF 011134

SC-SC

PS-659V- C 1 2.125 1-1/2 VZFZF 007026, 008180

TC-VS-TC

PS-446 C 1 2.500 1-3/4 BCFJF 008168

PS-446- C 1 2.500 1-3/4 BZFZF 008169

TC-TC

PS-340 C 1 2.625 1-7/8 BCFJF 007131

PS-340- C 1 2.625 1-7/8 BZFLF 011139

TC-SC

PS-340- C 1 2.625 1-7/8 BZFZF 007440

TC-TC

U.S. SEAL MFG. recommends using U.S. SEALUBE

as a lubricant when installing our seals.

Please call us for information on our

LUBE-PP (1cc Pillow Pak), LUBE-10ML (10ml Tube),

LUBE-4OZ (4 oz. Bottle), and LUBE-8OZ (8 oz. Bottle).

Us_seal_catalog_99 V 25 Cross Reference By Manufacturer 2010

Navigation menu

Versions of this User Manual:

Views

Navigation
