RecoveryPOD – Backup, storage and archiving solution, powered by CommVault,

Fujitsu and NetApp

RecoveryPOD solving business challenges effectively

and efficiently.

Businesses today are challenged with high cost resource costs,

are constrained with how to manage, protect their data and

most importantly what to do in an event of a natural disaster.

Managing data is the lifeblood of every organisation, but

before it can become an asset, it must be efficiently protected

and archived. RecoveryPOD provides a blend of advanced

technologies like snapshots, de-duplication, converged backup,

archiving and enterprise grade storage through one single

solution stack from CommVault, Fujitsu and NetApp.

RecoveryPOD integrates the best-of-breed enterprise scale

backup, storage and archiving solutions of CommVault

integrated data and information management software.

RecoveryPOD integrates the technologies of:

• CommVault Simpana 10

• Fujitsu Primergy Servers

• NetApp Storage Systems

RecoveryPOD is available as the following solutions

Application Data Management One and three-year support options are available for 2, 5, 10, 15 TB offerings.

Core Archiving Provide full rights to use all Archive and Content Store agents supported by the limits of the

Data Archive Core feature pack, based on 1TB of archived data capacity.

Enterprise Archiving Provide full rights to use all archive and content store agents supported by the Data Archive

Enterprise feature pack, based on 1TB of archived data capacity.

Dedicated Desktop Protection Provide protection for desktop and laptops that are often neglected in current enterprise

backup solutions available in 5, 10 and 15TB bundles.

Optional:

Cloud Backup – provided by AWS For additional protection with Cloud based offsite backup and archiving

Optional:

Cloud Optimisation – provided by Riverbed

Eliminate tape, improve disaster recovery, and reduce costs, leverage the cloud as a secure,

durable storage location accessible from anywhere.

Configuration RecoveryPOD 2TB RecoveryPOD 5TB RecoveryPOD 10TB RecoveryPOD 15TB

CPU 1x Intel XEON E5-2620v2 1x Intel XEON E5-2620v2 1x Intel XEON E5-2620v2 1x Intel XEON E5-2620v2

RAM 32GB RAM 32GB RAM 32GB RAM 64GB RAM

Network 4x 1GbE NIC 2x 1GbE + 2x 10GbE NIC 2x 1GbE + 2x 10GbE NIC 2x 1GbE + 2x 10GbE NIC

Internal Drives 2x 300K SAS for Boot Drive

6x 1TB SATA for Backup target

2x 300K SAS for De-dupe DB

4x 1TB SATA for Boot

2x 600 10K SAS for Boot

10x 300GB SAS for De-dupe

2x 600 10K SAS for Boot Drive

10x 300GB SATA for Backup

target

External Controller —LSI SAS HBA LSI SAS HBA LSI SAS HBA

RAID Config RAID 1 + 5 RAID 1 + 5 RAID 1 + 5 RAID 1 + 5

Capacity 4.7TB Usable 20.5TB Usable 30.7TB Usable 42.8TB Usable

OS Windows Server Standard

2012 OEM

Windows Server Standard

2012 OEM

Windows Server Standard

2012 OEM

Windows Server Standard

2012 OEM

CommVault 2TB Application Data

Management Bundle

5TB Application Data

Management Bundle

10TB Application Data

Management Bundle

15TB Application Data

Management Bundle

Expansion slots Tower: 10x PCIe slots (2 CPU is

required), 24x HDD maximum

Rack: 7x PCIe slots (2 CPU is

required), 12x HDD maximum

7x PCIe slots

(Two CPU is required),

12x HDD maximum

7x PCIe slots

(Two CPU is required),

12x HDD maximum

7x PCIe slots

(Two CPU is required),

12x HDD maximum

NetApp

E2700 Storage —12x 2TB SATA Drives 12x 3TB SATA Drives 24x 2TB SATA Drives
