Dual Monitors Wide View
DS-1900WA
DUAL WIDE LCD SOLUTION
DS-1900WA
Dual Monitors Wide View
LCD
Panel Type
Visible Screen Area
Pixel Pitch
Max. Visible Angle
Displayed Color
Response Time
Brightness
Aspect Ratio
Contrast Ratio
Recommended Resolution
SS-TN
29.5(H) x 11.75(V)
0.2835(H) x 0.2835(W)
80˚(T)/ 80˚(B)/ 80˚(L)/ 80˚(R)
16.7M(True 8-bit Colors)
5ms
300 cd/㎡
4 : 3
1000:1
1440 x 900
MONITOR STAND
Adjustable Monitor Stand
Adjustable Height, Tilt,
Swivel and Pivot
VIDEO SIGNAL
Horizontal Frequency
Vertical Frequency
30KHZ ~ 80KHZ
56Hz ~ 75Hz
CHARACTERISTICS
Controls
Color
Audio
Speakers
Dimension ( W x H x D）
Weight
Certication
Warranty
Graphic OSD, Auto Adjustment
Black
2W per Channel
Built-in
38"(W) x 18"(H) x 14"(D)
32 lbs
FCC,UL
3 year limited warranty
INTERFACE
Interface
Interface Type
Analog, Digital
D-sub, DVI-D, Audio-Line In
POWER
AC
Power Consumption
100V ~ 240V, 50Hz~60Hz
80W max, 3W Power Save Mode
19” Wide Monitor 2Set, Dual Stand 1Set, Audio Cable 2EA,
Cable Tie 6 EA, Cable Velcro 2EA, 4MM Wrench 1EA,
Power Cable 2EA, VGA Cable 2EA, DVI Cable 2EA,
Quick Installation Guide, Install CD
PACKAGE CONTENTS
A Clear View to Productivity
The DoubleSight DS-1900WA 19" Dual Monitor Flex Solution is a uniquely designed multiple LCD display
solution which can increase user productivity as much as 50% by allowing the user to view and manage
several sources of information or programs simultaneously without switching between windows.
The DS-190WA features DoubleSight's new Flex Stand which is adjustable for Height, Tilt, Swivel and Pivot.
Each Monitor adjusts independently of the other Monitor for a truly custom view. The unique 180° Arm
Rotation Feature allows users to share their screen with someone sitting to their right or across the desk making
this perfect for selling and training environments. The DS-1900WA Dual Monitor is an All-in-One complete turnkey
solution providing 2 High Resolution Monitors, 1 Adjustable Desktop Stand and all of the cabling needed.
All required components are preassembled and ship in one box which saves time and money.
