Lawn & Garden Product Brochure

Lawn & Garden Product Brochure

TABLE OF CONTENTS

4

6

7

8

12

13

14

15

Tractors

ZTRS

Tillers

Lawn Mowers

Blowers

& Hedge Trimmers

Chain Saws

Trimmers

Attachments

Tractors

McCulloch

M22-46T

960420146

McCulloch

M24-54T

960420151

McCulloch

M23-48T

960420150

Model M24-54T M23-48T M22-46T

Model Number 960420151 960420150 960420146

Engine 24 HP* Twin

Briggs & Stratton 23 HP* Twin

Briggs & Stratton 22 HP* Twin

Briggs & Stratton

Deck Width 54" 48" 46"

Transmission Hydro Foot Pedal Hydro Foot Pedal Hydro Foot Pedal

Blade Engagement Electric Electric Manual

Deck Wheels 444

Tires 15" / 20" 15" / 20" 15" / 20"

Front Axle Cast Iron Cast Iron Cast Iron

Seat High Back High Back High Back

Fuel Tank 3 Gallons 3 Gallons 3 Gallons

Cup Holder Yes Yes Yes

Warranty 333

*Engine power values are as rated by the engine manufacturer.

4

Model M20-42T M195-42T PB14538

Model Number 960420145 960420144 960120124

Engine 20 HP* Twin

Briggs & Stratton 19.5 HP* Twin

Briggs & Stratton 14.5 HP*

Briggs & Stratton

Deck Width 42" 42" 38"

Transmission Hydro Foot Pedal Hydro Foot Pedal 6 Speed

Blade Engagement Manual Manual Manual

Deck Wheels 420

Tires 15" / 20" 15" / 20" 15" / 20"

Front Axle Cast Iron Steel Steel

Seat Mid Back Low-Back Low-Back

Fuel Tank 3 Gallons 1.5 Gallons 1.5 Gallons

Cup Holder Yes Yes Yes

Warranty 3 3 2

*Engine power values are as rated by the engine manufacturer.

McCulloch

M20-42T

960420145

McCulloch

M195-42T

960420144

Poulan Pro

PB14538

960120124

5

Model 541ZX 461ZX

Model Number 966681901 966681801

Engine 22 HP*

Briggs & Stratton Professional Series 19.5 HP*

Briggs & Stratton Professional Series

Deck Width 54" 46"

Transmission Hydro Gear, EZT Hydro Gear, EZT

Blade Engagement Electric Electric

Deck Wheels 4 3

Hour Meter Digital Digital

Tires 11x4-5" / 18 x 9.5-8" 11x4-5" / 18 x 8.5-8"

Seat High Back High Back

Fuel Tank 3.5 Gallons 3.5 Gallons

Cup Holder Yes Yes

Warranty 2 2

Poulan Pro

541ZX

966681901

ZTR

*Engine power values are as rated by the engine manufacturer.

Poulan Pro

461ZX

966681801

6

Model PRRT900 RT900 HDF900 VF550

Model Number 960920030** 960920029** 960820032 960820015

Engine 900 LCT / 208cc* 900 LCT / 208cc* 900 LCT / 208cc* 550 Series / 140cc*

Till Width 17" Rear Tine 14" Rear Tine 12" / 24" / 26" Front Tine 12" / 22" / 24" Front Tine

Rotation Counter Counter Single Single

Transmission Forward & Reverse Forward & Reverse Forward Front

Wheels / Tires 16" Lug Tread Pneumatic Tire 13" Lug Tread Pneumatic Tire 8" Poly Rubber 7" Poly Rubber

Depth Stake 7 Position, Spring Loaded 7 Position, Spring Loaded 6 Position 5 Position

Tillers

*Engine power values and displacements are as rated by the engine manufacturer.

Poulan Pro

PRRT900

960920030

Poulan Pro

RT900

960920029

Poulan Pro

HDF900

960820032

Poulan Pro

VF550

960820015

7

Model PR625Y22RKP PR675Y22RHP PR675Y22RP PR625Y22SHP PR625N21RH

Model Number 961420113 961420112 961420111 961220033 961320082

Engine 625 E Series / 190cc*

Briggs & Stratton

675 EX Series / 190cc*

Briggs & Stratton

675 EX Series / 190cc*

Briggs & Stratton

625 E Series / 190cc*

Briggs & Stratton

625 E Series / 190cc*

Briggs & Stratton

Drive Front Wheel Drive

Single Speed

Front Wheel Drive

Single Speed

Front Wheel Drive

Single Speed

Front Wheel Drive

Single Speed

Front Wheel Drive

Single Speed

Cut Width 22" 22" 22" 22" 21"

Mulch / Bag

/ Discharge

2-in-1: Mulch,

Side Discharge

3-in-1: Mulch, Bag,

Side Discharge

3-in-1: Mulch, Bag,

Side Discharge

2-in-1: Mulch,

Side Discharge

3-in-1: Mulch, Bag,

Side Discharge

Front / Rear Wheels 8" / 12" 8”/ 12” 8”/ 12” 8”/ 12” 8”/ 12”

Height Adjustment 55555

Lawn Mowers

*Engine power values and displacements are as rated by the engine manufacturer.

Poulan Pro

PR625Y22RKP

961420113

Poulan Pro

PR675Y22RHP

961420112

Poulan Pro

PR675Y22RP

961420111

Poulan Pro

PR625N21RH

961320082

Poulan Pro

PR625Y22SHP

961220033

8

Model PR625Y22RKP PR675Y22RHP PR675Y22RP PR625Y22SHP PR625N21RH

Model Number 961420113 961420112 961420111 961220033 961320082

Engine 625 E Series / 190cc*

Briggs & Stratton

675 EX Series / 190cc*

Briggs & Stratton

675 EX Series / 190cc*

Briggs & Stratton

625 E Series / 190cc*

Briggs & Stratton

625 E Series / 190cc*

Briggs & Stratton

Drive Front Wheel Drive

Single Speed

Front Wheel Drive

Single Speed

Front Wheel Drive

Single Speed

Front Wheel Drive

Single Speed

Front Wheel Drive

Single Speed

Cut Width 22" 22" 22" 22" 21"

Mulch / Bag

/ Discharge

2-in-1: Mulch,

Side Discharge

3-in-1: Mulch, Bag,

Side Discharge

3-in-1: Mulch, Bag,

Side Discharge

2-in-1: Mulch,

Side Discharge

3-in-1: Mulch, Bag,

Side Discharge

Front / Rear Wheels 8" / 12" 8”/ 12” 8”/ 12” 8”/ 12” 8”/ 12”

Height Adjustment 55555

Model PR550N21 PR500N21SH PR500N21S PR450N20S PR22WT

Model Number 961320078 961120124 961120123 961120122 961720009

Engine 550 E Series / 140cc*

Briggs & Stratton

500 E Series / 140cc*

Briggs & Stratton

500 E Series / 140cc*

Briggs & Stratton

450 Series *

Briggs & Stratton

550 E Series / 140cc*

Briggs & Stratton

Drive Push Push Push Push Push

Cut Width 21" 21" 21" 20" 22"

Mulch / Bag

/ Discharge

3-in-1: Mulch, Bag,

Side Discharge

2-in-1: Mulch,

Side Discharge

2-in-1: Mulch,

Side Discharge Side Discharge N/A

Front / Rear Wheels 7” / 7” 7" / 12" 7" / 7" 7" / 7" N/A / 12"

Height Adjustment 5 5 5 5 N/A

*Engine power values and displacements are as rated by the engine manufacturer.

Poulan Pro

PR550N21

961320078

Poulan Pro

PR500N21S

961120123

Poulan Pro

PR450N20S

961120122

Poulan Pro

PR22WT

961720009

Poulan Pro

PR500N21SH

961120124

9

Model M22-170F M21-170 M21-140

Model Number 961420110 961320085 961320084

Engine 170cc* Engine 170cc* Engine 550 E Series / 140cc*

Briggs & Stratton

Drive Variable Speed

Front Drive Self-Propelled Push Push

Cut Width 22" 21" 21"

Mulch / Bag

/ Discharge

3-in-1: Mulch, Bag,

Side Discharge

3-in-1: Mulch, Bag,

Side Discharge

3-in-1: Mulch, Bag,

Side Discharge

Front / Rear Wheels 8" / 12" 8" / 12" 8" / 8"

Height Adjustment 555

Lawn Mowers

*Engine power values and displacements are as rated by the engine manufacturer.

McCulloch

M22-170F

961420110

McCulloch

M21-140

961320084

McCulloch

M21-170

961320085

10

Model M22-170F M21-170 M21-140

Model Number 961420110 961320085 961320084

Engine 170cc* Engine 170cc* Engine 550 E Series / 140cc*

Briggs & Stratton

Drive Variable Speed

Front Drive Self-Propelled Push Push

Cut Width 22" 21" 21"

Mulch / Bag

/ Discharge

3-in-1: Mulch, Bag,

Side Discharge

3-in-1: Mulch, Bag,

Side Discharge

3-in-1: Mulch, Bag,

Side Discharge

Front / Rear Wheels 8" / 12" 8" / 12" 8" / 8"

Height Adjustment 555

Model WE18XP WE20X WE20C WE16R

Model Number 961420088 961320058 961320063 961540001

Engine Cordless Electric /

24V DC

Cordless Electric /

24V DC

Corded Electric /

12V AC N/A

Drive Rear Wheel Drive

Variable Speed Push Push Push

Cut Width 18" 20" 20" 16"

Mulch / Bag

/ Discharge

2-in-1: Mulch,

Bag

3-in-1: Mulch, Bag,

Side Discharge

3-in-1: Mulch, Bag,

Side Discharge N/A

Front / Rear Wheels 7” / 8” 7" / 10" 7" / 10" N/A / 12"

Height Adjustment 5 5 5 N/A

*Engine power values and displacements are as rated by the engine manufacturer.

Weed Eater

WE18XP

961420088

Weed Eater

WE20C

961320063

Weed Eater

WE20X

961320058

Weed Eater

WE16R

961540001

11

Blowers

Hedge Trimmers

Model PPBP30 MC200VS BVM200VS FB25

Model Number 966720201 966625101 966781501 952711937

Engine 30cc, 2-Cycle Gas 25cc, 2-Cycle Gas 25cc, 2-Cycle Gas 25cc, 2-Cycle Gas

Air Speed / Volume 180 MPH / 485 CFM 200 MPH / 430 CFM 200 MPH / 430 CFM 170 MPH / 290 CFM

Mulch Ratio N/A 10:1 10:1 N/A

Vacuum N/A Yes Yes No

Model PP2822 GHT225 HT1700

Model Number 966513101 952711803 952711897

Engine / Motor 28cc 25cc 2.4 Amp Electric Motor

Starting Type Spring Assist Standard N/A

Blades Dual Sided/Serrated Stainless Steel Double Edged Double Edged Blades

Cut Width 22" 22" 17"

Handle Type Swivel Reduced Vibration Standard

Poulan Pro

PPBP30

966720201

McCulloch

MC200VS

966625101

Poulan Pro

BVM200VS

966781501

Weed Eater

FB25

952711937

Poulan Pro

PP2822

966513101

Weed Eater

GHT225

952711803

Weed Eater

HT1700

952711897

12

Chain Saws

Model PP5020AV PP4218A PP3816A PP338PT CS380 CS340 P4018WT P3314

Model Number 966807601 967185102 967196401 966423701 967027501 967027401 952802036 952802026

Engine 50cc, 2-Cycle 42cc, 2-Cycle 38cc, 2-Cycle 38cc, 2-Cycle 38cc 34cc 40cc 2-Cycle 33cc 2-Cycle

Bar 20" 18" 16" 12" 16" 14" 18" 14"

Oiler Automatic Automatic Automatic Automatic Automatic Automatic Automatic Automatic

Chain Tensioning Screw Type Screw Type Screw Type Screw Type Screw Type Screw Type Screw Type Screw Type

Other Carry Case

Included

Carry Case

Included

Carry Case

Included N/A N/A N/A Carry Case

Included N/A

Poulan Pro

PP5020AV

966807601

Poulan Pro

PP4218A

967185102

Poulan Pro

PP3816A

967196401

Poulan Pro

PP338PT

966423701

McCulloch

CS380

967027501

McCulloch

CS340

967027401

Poulan

PP4018WT

952802036

Poulan

P3314

952802026

13

Model PP333 PP133 PP25SFA PP25CFA T22LS T22LCS W25SF W25CF WE-15TNE

Model Number 952711951 952711962 967185701 967185601 966631902 966631802 967184301 967184201 966048001

Engine Full Crank

33cc Gas

Full Crank

33cc Gas

Full Crank

25cc Gas

Full Crank

25cc Gas

22cc 2-Cycle

Gas

22cc 2-Cycle

Gas

25cc 2-Cycle

Gas

25cc 2-Cycle

Gas

5.0 Amp

Electric

Starting Type Spring Assist Sure Fire Spring Assist Spring Assist SoftStart™SoftStart™Simple 2 Start™Simple 2 Start™N/A

Shaft Pro-Link

Straight Shaft

Pro-Link

Straight Shaft

Pro-Link

Straight Shaft

Pro-Link

Straight Shaft

Straight Shaft

Split Boom

Curved Shaft

Split Bloom Straight Curved Adjustable

Length

Cut Width

17" Trim Head /

8" Brushcutter

17" 17" 17" 17" 16" 15" 15" 15"

Head Type Fixed Head /

Dual Exit

Fixed Head /

Dual Exit

Fixed Head /

Dual Exit

Fixed Head /

Dual Exit

Tap ‘N Go

Dual Exit

Tap ‘N Go

Dual Exit

Fixed Head /

Dual Exit

Fixed Head /

Dual Exit Auto Feed

Trimmers

McCulloch

T22LS

966631902

McCulloch

T22LCS

966631802

Weed Eater

W25SF

967184301

Weed Eater

W25CF

967184201

Weed Eater

WE EL-15TNE

966048001

Poulan Pro

PP333

952711951

Poulan Pro

PP133

952711962

Poulan Pro

PP25SFA

967185701

Poulan Pro

PP25CFA

967185601

14

Trimmer Attachments

Our split-shaft trimmers allow you to quickly & easily convert your trimmer with

any of the six convenient optional attachments.

Just a click and you’re ready to go. No tools required!

Attachments

Poulan Pro

PP1000E

952711607

Poulan Pro

PP4000C

952711610

Poulan Pro

PP2000T

952711608

Poulan Pro

PP5500P

952711672

Poulan Pro

PP300B

952711609

Poulan Pro

PP6000H

952711674

15

For more information including product reviews and support go to:

mcculloch.com, poulanpro.com, poulan.com or weedeater.com

Copyright © 2013 McCulloch, Poulan Pro, Poulan, Weed Eater and other product and feature names are trademarks of the Poulan Division. All rights reserved.

Poulan claims no right the following trademarks: Briggs & Stratton, Intek (owned by Briggs & Stratton Corp.), Hydro-Gear, EZT (owned by Hydro-Gear, Inc.) and Kohler (owned by Kohler Co.).
