JV535H – GE Profile™ Series 30" High Performance Range Hood
Specification Revised 3/13
220972
Installation Information: Before installing, consult installation
instructions packed with product for current dimensional data.
Light bulb(s) not included.
Dimensions (in inches)
Exhaust outlet connects to 3-1/4" x 10" duct (vertically or horizontally) and 7" round
(vertically). Includes rectangular damper and 7" round damper adapter.
Round damper accessory, JXDA22 available at additional cost.
JXHC1 Cord Kit – Allows a receptacle in the cabinet over the range to accommodate
either an over-the-range microwave oven or a standard hood.
For answers to your Monogram® or GE® appliance
questions, visit our website atGEAppliances.com or
call GE Answer Center® service, 800.626.2000.
Listed by
Underwriters
Laboratories
Model A B C D
JV535 4-3/4 29-7/8 20 12
A
B
C
D
hood_a_b_c_new.eps
9
12
1-1/4
4-3/4
12-9/16
1-9/16
5
1-1/2
3/8
JV666.eps
Amp Rating
120V 1.4
JV535H – GE Profile™ Series 30" High Performance Range Hood
Specification Revised 3/13
220972
Features and Benefits
• Convertible venting – Hood configuration can be changed to fit the needs of various
installation requirements.
• Vertical and rear exhaust – Provides the option of connecting duct work to either the
rear or the top of the hood.
• Variable 2-speed fan control – Powerful variable speed exhaust system effectively
pulls smoke and vapors out of the kitchen.
• Halogen light – Provides bright light that illuminates the cooking surface below hood.
• Removable grease filter – Durable filters can be removed for easy cleaning
and maintenance.
• Round and rectangular ducting – Hood is designed to fit either standard round or
rectangular duct work.
• Damper included.
• Model JV536HSS – Stainless Steel
• Model JV535HWW – White on white
• Model JV535HCC – Bisque on bisque
• Model JV535HBB – Black on black
JV535/565HWW/CC/BB
