INTRODUCTION

This Refcard is intended as a practical introduction to DNS, and assumes

you are familiar only with networking basics. After a brief explanation

of how DNS works, the bulk of this card will explain DNS configuration,

security, and common problems, in order to get you up and running

quickly, safely, and reliably.

WHAT IS DNS?

Invented in 1982, the Domain Name System is a replacement for a

centralized "hostname to numerical address database" (in reality it was

a simple text file) that was used in the days of ARPANET, the precursor to

what is known today as the Internet.

The purpose of the original database was to provide an easy way to

identify a network connected computer, instead of the unfriendly

numerical addresses.

It is much easier to remember "google.com" instead of

"74.125.237.130".

As the number of interconnected machines grew, maintaining this

information in a central database, as well as ensuring that all clients on

the network had an identical copy of this database at all times, became

increasingly difficult. The modern DNS addressed this issue by replacing

the previous central database with a distributed network of systems.

By design, the DNS is more than a simple name-to-IP address mapping

database. It allows for many additional properties to be assigned to

a domain name, including associated email addresses, anti-spam

information, and much more.

DOMAIN NAME HIERARCHY

Domain names are the most common method used for accessing

websites or any other host on the Internet. Each domain name is made

up of a number of elements (called "labels") separated by a dot.

For example: www.google.com

The domain name system works in a hierarchical model, with the right-

most elements classed as the "Top Level Domain" or TLD, followed by

the second element, which is classed as the "Second Level Domain."

This structure continues from right to left with each element being

classed as a subdomain of the element to its right.

BROUGHT TO YOU IN PARTNERSHIP WITH

CONTENTS

öINTRODUCTION

öHOW DNS WORKS

öCONFIGURING DNS

öRECORD TYPES

öSECURITY ISSUES

öDNSSEC

öCOMMON DNS PROBLEMS

WRITTEN BY MICHAEL HUGHES, LEAD SECURITY SPECIALIST, NATIONAL AUSTRALIA BANK

Practical DNS

Because DNS is a critical part of your

network infrastructure, it pays to become

familiar with the process of debugging DNS.

Download this e-book to learn a number of

approaches and techniques to debug DNS

issues, and new concepts, tools, and a basic

process to follow.

Visit our Debugging DNS Resource Center for more

https://ns1.com/debugging-dns

DZONE.COM/REFCARDZ

PRACTICAL DNS

BROUGHT TO YOU IN PARTNERSHIP WITH

In addition to the structure above, any element may be classed as a

hostname should it be associated with one or more IP addresses, and

provided it meets the following basic rules as stated in the DoD Host

Table Specification as well as RFC1123:

• A hostname must be a text string consisting of only the letters A

through Z (upper or lower case), digits 0 through 9, the minus

sign (-), and the period (.)

• A hostname cannot contain any spaces

• The first character must be an alphabetic character or a digit

• The last character cannot be a minus sign or a period

• The recommended length for a hostname is up to 24 characters

HOW DNS WORKS

DNS REQUEST PROCESS

When a user attempts to load a website by entering the site's URL into

their browser (or any URI with a hostname), a series of requests take

place in the background. The illustration below outlines the structure

and sequence of these events, and demonstrates how entering a domain

name into a browser eventually results in the browser knowing exactly

what IP address to connect to at the network layer.

1. The user queries their Internet Service Provider's (ISP) DNS

resolver asking for the IP address for "www.google.com."

2. The DNS resolver asks the root nameserver where it can

find details for "www.google.com," unless it already has the

information cached.

3. If it is asked, the root nameserver responds that this information

is handled by the .com nameserver.

4. The DNS resolver asks the .com nameserver where it can

find details for "www.google.com," unless it already has the

information cached.

5. If it is asked, the .com nameserver responds that this information

can be found at the nameservers of google.com.

6. The DNS resolver asks the google.com nameservers where it

can find details for "www.google.com," unless it already has the

information cached.

7. If it is asked, the google.com nameservers have this information

and respond with a DNS record containing the IP address for

"www.google.com."

8. The ISP's DNS resolver then sends this information back to the

user. The user then knows what IP address to connect to in order

to access "www.google.com."

Once the user knows which IP address to connect to in order to retrieve

the content of "www.google.com" the DNS job is complete.

DNS ROOT SERVERS

As demonstrated in the previous diagram, DNS infrastructure is designed

in a distributed manner, with different servers responsible for different

sections of the DNS namespace.

At the top of the hierarchical structure are the DNS "root" servers. These

servers are responsible for the initial delegation of requests received

from DNS resolvers to the correct top level domain nameservers.

At the time of writing of this guide, there are 13 root servers defined in

the DNS root zone. The hostnames of these servers are in the following

format:

.ROOT-SERVERS.NET

. The letter values are A-M and each of

these root server hostnames is managed by a different organization

(with the exception of A and J, which are both currently managed by

Verisign). The following table represents the current details of the DNS

root servers:

LETTER IPV4 ADDRESS IPV6 ADDRESS OPERATOR

A 198.41.0.4 2001:503:ba3e::2:30 Verisign

B 192.228.79.201 N/A USC-ISI

C 192.33.4.12 N/A Cogent

Communications

D 199.7.91.13 2001:500:2d::d University of

Maryland

E 192.203.230.10 N/A NASA

F 192.5.5.241 2001:500:2f::f Internet Systems

Consortium

G 192.112.36.4 N/A

Defense

Information

Systems Agency

DZONE.COM/REFCARDZ

PRACTICAL DNS

BROUGHT TO YOU IN PARTNERSHIP WITH

LETTER IPV4 ADDRESS IPV6 ADDRESS OPERATOR

H 128.63.2.53 2001:500:1::803f:235 U.S. Army

Research Lab

I 192.36.148.17 2001:7fe::53 Netnod

J 192.58.128.30 2001:503:c27::2:30 Verisign

K 193.0.14.129 2001:7fd::1 RIPE NCC

L 199.7.83.42 2001:500:3::42 ICANN

M 202.12.27.33 2001:dc3::35 WIDE Project

The reason the number 13 was chosen as the number of root server

hostnames is primarily the desire for the details of all root servers to fit

in one DNS packet. DNS messages were originally limited to 512 bytes of

data, and each IPv4 address is exactly 32 bytes long, so the number 13

was chosen. This requires 416 bytes of space, leaving 96 bytes for future

use or other supporting information.

While there are only 13 root server names, in reality there are many

more DNS root servers than this. A majority of the IP addresses assigned

to the root server hostnames (as seen in the above table) are actually

"anycast" addresses.

Anycast is a technique that uses the same address at multiple (physical)

servers at the same time. For example, the root server "L.ROOT-SERVERS.

NET" which is managed by ICANN is actually a cluster of over 130

physical servers distributed around the globe. This type of redundancy

serves two main purposes:

1. To ensure speedy responses to DNS queries (by providing

network-topologically short distances to the root servers); and

2. To minimize the likelihood of an outage of the entire DNS system.

Management of the DNS root zone itself is actually controlled by the

United States Government"s Department of Commerce. The zone is

managed by the Internet Assigned Numbers Authority (IANA); the IANA

contract is currently held by the Internet Corporation for Assigned

Names and Numbers (ICANN). Any changes proposed for the DNS root

zone must be approved by the US Department of Commerce before they

can be implemented.

CONFIGURING DNS

NAMESERVERS

In the example given above, we can see that nameservers play a key

role in the DNS request process. When you register a new domain name,

the nameservers for that domain are one of the first items you may

configure. This is normally done through the same company with which

you registered your domain name.

Nameserver configuration page at Godaddy.com

Configuring the nameservers provides the parent domains (e.g. .com) with

an address at which the rest of the records for that domain name can be

found. As was seen in step 5 above, these details are given by the top level

domain nameservers whenever they are queried by a DNS resolver.

DNS ZONES

All DNS information regarding a domain name (IP addresses, mail

server details, etc.) are stored on the configured nameservers in what

is known as a DNS Zone. These zones are generally bundled into a

zone file, which contains details of all domains for which the given

nameserver is authoritative.

As there are a large number of different DNS server software packages,

the format of these zone files can vary slightly between different

implementations. The most widely-used DNS software on the Internet

today is the Berkeley Internet Name Domain (BIND) DNS server.

Originally written in 1984 by four Berkeley College students as a

graduate project, the BIND DNS server was eventually rewritten in

2000 with contributions coming from a number of large organizations

including IBM, Hewlett Packard, Compaq, and Sun Microsystems.

This rewrite was labeled version 9 and is currently still the supported

version of the BIND DNS server in use on systems around the world (and

also used by the majority of DNS root servers themselves). Below is an

example of a zone file for the BIND 9 DNS server: ~

$TTL 14400

$ORIGIN example.com.

@ 14400 IN SOA ns1.example.com. admin.example.com. (

2012121902 ;

3600; refresh seconds

600; retry

86400; expire

3600; minimum

);

IN A 12.34.56.78

IN NS ns1.example.com.

IN NS ns2.example.com.

ns1 IN A 11.11.11.11

ns2 IN A 22.22.22.22

www IN CNAME example.com.

ftp IN CNAME example.com.

mail IN MX 10 example.com.

DNS zone file example (BIND DNS Server)

DZONE.COM/REFCARDZ

PRACTICAL DNS

BROUGHT TO YOU IN PARTNERSHIP WITH

RECORD TYPES

Each piece of data stored within a zone file is called a resource record.

There are a large number of different record types that can exist for a

domain. The most common record types are as follows:

"SOA" RECORDS

The DNS "SOA" record is a mandatory entry for any DNS zone. It is the

"Start of Authority" record; its purpose is to inform DNS resolvers that this

server is the authoritative server for the requested domain name.

The structure of an SOA record is as follows:

@ 14400 IN SOA ns1.example.com. admin.example.com. (

2012121902 ; serial number

3600; refresh seconds

600; retry seconds

86400; expire seconds

3600; minimum TTL seconds );

The first entry in the "SOA" record contains the name of the host

where the zone file is located (ns1.example.com above) as well as the

administrative email contact for the DNS zone (admin.example.com

above — the "@" symbol is replaced with a "." within DNS zone files).

The "serial number" value is used as a type of version control on the DNS

records. Where multiple nameservers are configured, ensuring that each

server"s SOA serial number value is the same is a good indication that

DNS changes have been replicated on all nameservers.

The "refresh" value is how long a secondary nameserver will wait before

checking whether updates have been made on the primary server. When

checking, the secondary server will check the serial number of the zone

on the master server, and if different will request a zone transfer to

update its local copy.

The "retry" value is how long a secondary nameserver will wait to retry a

zone transfer in the event the initial attempt fails.

The "expire" value is how long a secondary nameserver will continue to

attempt a zone transfer before giving up. If this value is reached before a

successful zone transfer is made, the secondary nameserver will expire

its local zone file and stop responding to user queries.

The "minimum TTL" value is an indication of how long a DNS cache

may hold a negative value (e.g. an error message) before requesting

fresh copies.

"A" RECORDS

"A" records are one of the key record types within the DNS. Their purpose

is to define a relationship between a human-friendly name and an IPv4

address. These records are useful for pointing different portions of your

domain to different IP addresses (e.g. pointing "www.example.com" to

your web server).

Each DNS "A" record consists of both a host name and IP address. The

format of these records is as follows:

The "node name" value above will be the portion of the address that

precedes ".example.com" (for example "www"). The IP address is the

location that the resulting hostname ("www.example.com") will point to.

"AAAA" RECORDS

"AAAA" records are similar to DNS "A" records.The only difference is

that "AAAA" records point to IPv6 addresses instead of IPv4 addresses.

Configuration of the record and layout is the same: simply replace "A"

with "AAAA" and use an IPv6 address.

"NS" RECORDS

"NS" records are used to specify what the nameservers for the domain

name are. These should ideally match the values set at the domain

name registrar.

Each DNS "NS" record consists of both the domain name and

nameserver hostname and is formatted as follows:

example.com. IN NS <HOSTNAME OF NAMESERVER>

The hostname will generally be a value such as "ns1.yourdomain.

com" or "ns1.yourwebhost.com". If these values do not match those

configured with the domain name registrar, it can lead to problems

accessing your website in certain circumstances.

"CNAME" RECORDS

"CNAME" is short for canonical name. These records are used to define

an alias for another domain or hostname. These records are particularly

useful when you have multiple hostnames that are located on the same

IP address.

Each "CNAME" record needs to point to another valid hostname, either

for the same domain or even a completely different domain. Generally

"CNAME" records point to a hostname that is configured in a DNS "A"

record. The format of these records is as follows:

<HOST NAME> IN CNAME <EXISTING HOSTNAME>

The hostname is the value preceding the ".example.com" as in the "A"

record example and is typically something like "www." The existing

hostname could be another hostname for the current domain, for

example "blog.example.com." In this case, when a user attempts to visit

"www.example.com" they will see the content associated with "blog.

example.com."

If the existing hostname value is set to a hostname on a different domain

— for example "www.domain2.com" — when a user visits "www.example.

com" they will see the same content as a user visiting "www.example.com."

DZONE.COM/REFCARDZ

PRACTICAL DNS

BROUGHT TO YOU IN PARTNERSHIP WITH

"MX" RECORDS

"MX" is short for Mail Exchanger. These records are used to identify the

server that handles email address for your domain name.

Each "MX" record contains three pieces of information: the hostname,

the priority and the mail server"s hostname. The format of an "MX"

record is as follows:

The hostname value is the domain for which the MX record exists. This is

generally set to the value of your domain name (e.g. "example.com.").

The priority value is a numerical value that signifies the priority of this

particular MX record — and hence the mail server. The values used for

this are only important if you have more than one mail server. The lower

the value of the priority field, the higher the priority of the mail server.

The mail server hostname is then the hostname that handles email for

this domain. It could be a google.com address if the domain uses Google

Apps for email hosting, but the simplest setup is to have the hostname set

to "mail.example.com". If this is the case, it is important to ensure that a

valid DNS "A" record exists for the "mail" hostname. If this isn"t configured

properly, you may experience issues receiving email at your domain.

"TXT" RECORDS

"TXT" (or text) records serve multiple purposes. They allow for virtually

any free text to be stored and can be assigned to specific hostnames.

The typical format for a TXT record is as follows:

"TXT" records often store sender policy framework (SPF) data . SPF data

is used to inform email servers which actual systems are authorized

to send mail on behalf of the given hostname. This is useful in the

prevention of spam emails being sent with a forged sender address

originating from your domain. (RFC 4408 discourages this practice

as "not optimal," however, because SPF now has its own DNS resource

record type (code 99).)

Another common use of the "TXT" records is for DomainKeys Identified

Mail (DKIM) data. These records allow a receiving mail server to

authenticate entities that have signed a specific email message. DKIM

is similar to SPF in that it can help reduce spam email from containing

forged email addresses originating from your domain, but it also

contains a large amount of additional functionality.

"PTR" RECORDS

The "PTR" record type is used to perform the exact opposite

functionality of the DNS "A" record. Where the "A" record allows for the

translation of a domain name or hostname into an IP address, the "PTR"

record allows for an IP address to be translated into a domain name.

The format of a "PTR" record is as follows:

The first field is the IP address in reverse format, with the "in-addr.arpa"

value appended to the end, for example "1.0.168.192.in-addr.arpa". The

domain value would then be the domain name you want the IP address

(192.168.0.1 in this example) to resolve to.

Ensuring that both forward lookups (using "A" records) and reverse lookups

(using "PTR" records) match is important: in some instances, applications

will not work correctly if this is not configured correctly. For example, some

mail servers will not accept mail from a mail server if the reverse lookup

does not match the domain name the email is originating from.

SECURITY ISSUES

As DNS is one of the core technologies used in the delivery of the

modern Internet, coupled with the high percentage of DNS servers using

the same DNS server software (BIND), the DNS protocol and servers

implementing it are under constant scrutiny from hackers. The following

are two common DNS related attacks:

DNS CACHE POISONING

One of the more common attacks against the DNS protocol is the DNS

cache poisoning attack. In order to reduce unnecessary Internet traffic,

most Internet Service Providers (ISP) configure their DNS servers to

cache DNS responses for the period defined in the TTL value of the

requested record set.

This allows for all concurrent requests to be served from the local cache

at the ISP and not require the series of lookups normally required. This

results in faster DNS responses for the end user, as well as a decrease in

data costs for the ISP.

This mechanism, however, is the target for the DNS cache poisoning

attack. In this attack, the hacker aims to have their IP address cached by

the ISP"s DNS resolvers for a record of their choosing.

For example, the attacker would seek to have the IP address of the

hostname "login.example.com" be cached with their own IP address

instead of the legitimate IP address. The result of this attack is that anyone

using that DNS resolver (typically most of that ISP's customers) would be

loading the site "login.example.com" from the hacker's server rather than

the legitimate server. Once this is achieved, the hacker could potentially

display a fake login page and harvest users" logins and passwords.

DNS REFLECTION ATTACKS

DNS reflection attacks differ from DNS cache poisoning attacks in that

their primary goal is not to compromise the integrity of a DNS resolver"s

data, but rather to completely flood a system with DNS responses,

rendering it unable to respond to legitimate queries. This type of attack

is known as a Denial of Service (DoS) attack.

DZONE.COM/REFCARDZ

PRACTICAL DNS

BROUGHT TO YOU IN PARTNERSHIP WITH

This attack is conducted by a hacker spoofing the sender IP address of a

DNS query to mimic that of the victim"s server. When the DNS resolver

then replies to the query, the response will go to the victim"s server

rather than the hackers. This attack works due to the fact that a small

DNS query can actually return a response that is many times larger than

the query itself.

Hackers leverage this in order to direct a large amount of network (DNS)

traffic at the victim"s machine. This results in the victim machine being

unable to accept or respond to legitimate traffic.

DNSSEC

The original DNS protocol was never designed with security in mind; user

access to the nascent Internet was tightly controlled and not open to

public access.

The Domain Name System Security Extensions (DNSSEC) are an

expansion of the DNS protocol aimed at mitigating a number of security

issues that have been identified within the DNS since this time. The

DNSSEC provide the ability for DNS clients to determine that the DNS

response they are receiving actually comes from the server authoritative

for the given domain name. This feature is a direct response to the DNS

cache poising attacks described above.

HOW DNSSEC WORKS

DNSSEC is implemented by adding a number of additional records to the

DNS zone of a domain. These records are as follows:

RECORD NAME FUNCTION

RRSIG

The signature of the DNS resource record set. This

record is returned in the response to any DNS

query and can be verified by checking against the

public key for the domain.

DNSKEY Contains the public key for the domain.

DS The "Delegation Signer" record, used in

authenticating the DNSKEY for a domain.

NSEC Used to prove a name does not exist.

NSEC3

An alternative version of the traditional NSEC

record also provides proof a name doesn"t exist

but prevents zonewalking.

NSEC3PARAM Parameter record for use with NSEC3.

In order for DNSSEC to be functional in any given DNS query, every

authoritative server from the trust anchor (generally the TLD

nameservers) all the way down to the domain"s nameservers must

support DNSSEC and offer signing of record sets. If any of these do not

support the extensions, then it is not possible to utilize the benefits of

DNSSEC for that query.

In order to sign a DNS zone with DNSSEC, a private and public key pair

is generated by the owner. The public key is listed in the DNS zone in

the "DNSKEY" record whilst the private key is stored securely on the

authoritative nameserver. Once this is done, the parent domain server is

informed that this zone has been signed.

Each record in the zone is now digitally signed with the signature of the

record set stored in the "RRSIG" record. This record is the encrypted

hash of the original records value. Sent with the response to every DNS

query, this "RRSIG" records allows the client to determine if the value

received is the same as the one sent by the server.

When the client receives the DNS response, it takes the "RRSIG" value,

decrypts it with the public key (retrieved from the "DNSKEY" record) and

then compares the result with the hash of the record value received. If

these values match, then the record received is identical to the one sent.

The next feature of DNSSEC is the ability to ensure that the server that sent

the record and public key is actually the legitimate authoritative domain

server for that domain. This is achieved using the "DS" record. This "DS"

record stores a digest of the domain"s DNS key in the domain"s parent

zone that is protected by the parent zones "DNSKEY." This configuration

then continues in a hierarchical structure up to the DNS root zone. The

data for the DNS root zone is treated as a "Trust Anchor."

Using this record, and hierarchical authentication method, it is possible

to ensure that the "DNSKEY" received for a domain has not been

spoofed by an attacker.

DNS REQUEST PROCESS WITH DNSSEC

The DNS request process remains quite similar to the standard process

of requesting DNS data, albeit with a few more pieces of data added in

order to verify the responses received.

The following is an example workflow and description of a typical DNS

request with DNSSEC enabled. Changes from a normal (non DNSSEC

enabled) DNS request are in italics.

1. The user queries their Internet Service Provider"s (ISP) DNS

resolver asking for the IP address for "www.google.com."

2. The DNS resolver asks the root nameserver where it can

find details for "www.google.com," unless it already has the

information cached. It also sets the "DNSSEC OK" (DO) bit to

signify that it is requesting the DNSSEC records be returned also.

3. If it is asked, the root nameserver responds that this information

is handled by the .com nameserver. It also sends the DS record for

the .com zone and RRSIG records for any records returned with

the result. The resolver would then validate that the DS record

value received from the root nameserver matches the digest of

the DNSKEY record value for the .com zone.

DZONE.COM/REFCARDZ

PRACTICAL DNS

BROUGHT TO YOU IN PARTNERSHIP WITH

4. The DNS resolver asks the .com nameserver where it can

find details for "www.google.com," unless it already has the

information cached.

5. If it is asked, the .com nameserver responds that this information

can be found at the nameservers of google.com. It also sends the DS

record for the google.com zone and RRSIG records for any records

returned with the result. The resolver would then validate that the

DS record value received from the .com nameserver matches the

digest of the DNSKEY record value for the google.com zone.

6. The DNS resolver asks the google.com nameservers where it

can find details for "www.google.com," unless it already has the

information cached.

7. If it is asked, the google.com nameservers have this information

and respond with a DNS record set (RRSET) of all "A" records

configured for "www.google.com." It also sends the RRSIG value

for the RRSET that was returned. The ISP"s DNS resolver can then

validate that the RRSIG value is indeed the signature of the RRSET

that is returned by checking it against the DNSKEY record in the

google.com zone. The resolver has now validated that the records

themselves have not been tampered with, and also previously

validated that the servers that have been involved in receiving

the data are trusted by validating the DS records against the

associated parent"s DNSKEY record.

8. The ISP"s DNS resolver then sends the "A" record for "www.

google.com" back to the user. The user then knows what IP

address to connect to in order to access "www.google.com."

DNSSEC AVAILABILITY

Unfortunately, not all top level domains currently support DNSSEC.

As was previously mentioned, each server in the chain needs to both

support DNSSEC as well as have the appropriate records configured in

order for DNSSEC to have any effect.

As of April 2013, less than a third of all top level domain servers

(including ccTLD's) are configured with the appropriate settings to

support DNSSEC.

Of the 19 globally assigned top level domains, the following do not

currently support DNSSEC:

• .aero,

• .coop

• .int

• .jobs

• .mobi

• .name

• .pro

• .tel

• .travel

• .xxx

COMMON DNS PROBLEMS

DNS PROPAGATION

The most common problem encountered with the DNS protocol is the

situation known as "DNS Propagation." When a change is made to a DNS

zone, this change is not immediately seen by the rest of the world.

The name itself (specifically the "propagation" component) suggests

that changes propagate outwards across the Internet away from the

server on which the change was made. This is a common misconception:

DNS changes do not propagate outwards like ripples. Instead, when a

change is made on a DNS zone, the only real automated propagation of

that change is to secondary or child nameservers. Due to the nature of

DNS, all DNS queries for a particular domain will follow the hierarchical

approach to determining which server has the data for that domain,

eventually arriving at the nameserver for the domain.

As the change to the DNS zone has already occurred on the primary

server, the updated values are immediately available and are included in

all DNS responses made by that server after the change has been made.

Once the change has been made on the primary server, each additional

authoritative nameserver will update its stored values the next time it

attempts a zone transfer.

The "propagation" effect is actually caused by ISP"s DNS resolvers

caching the original, now outdated, DNS records and returning that

to the end user, rather than the updated value that could be retrieved

directly from the domain"s nameservers.

The TTL value assigned to each record indicates to DNS resolvers how

long they should cache the values of the retrieved DNS records.

Ideally, if a change were made to a DNS record immediately after it was

cached by a DNS resolver, the delay before that resolver retrieved the

updated record would be at most the value of that record sets TTL.

While not as common in recent times, not all DNS resolvers adhere

to the values contained in the TTL values, with many choosing to

implement their own TTL values for cached records (in order to reduce

bandwidth use). This is where the "propagation" effect comes from.

In order to reduce the likelihood of a long DNS propagation time, try this:

1. Ensure that the TTL values of all records are set to a low value

(e.g. 300).

2. Ensure that when changing nameservers both the old and the

new nameservers are configured with the same DNS records.

This will ensure that regardless of what nameserver the user is

directed to, the results they receive will be consistent.

DZONE.COM/REFCARDZ

PRACTICAL DNS

BROUGHT TO YOU IN PARTNERSHIP WITH

WEBSITE NOT AVAILABLE ON "WWW." HOSTNAME

Another common issue with DNS configuration is users' experiencing

difficulties accessing their website using "www.example.com" rather

than just "example.com."

The cause of this issue is actually quite simple to diagnose as well as

resolve. The ideal configuration of the DNS zone to allow the "www."

hostname to work is as follows:

1. Ensure that there is an "A" record for the domain itself. example.

com. IN A 192.168.0.1

2. Next, create a CNAME record for the "www." hostname. www.

example.com. IN CNAME example.com

The above steps will (as far as DNS is concerned) ensure that the website

is visible on both "www.example.com" as well as "example.com." It is

then the responsibility of the web server to determine whether to force

redirect the user to one or the other.

There are other methods to solve this issue, including adding an A record

for both the domain itself as well as the "www." hostname (instead of a

CNAME record); however for ease of maintenance, the use of a CNAME

record is recommended as if the IP address needs to be changed in

future, it only needs to be changed once.

NAMESERVER REDUNDANCY

For most domain name owners, configuring a domain's nameservers is as

simple as entering the values given to them by their web hosting company.

For example: ns1.webhost.com and ns2.webhost.com

It is important to check, however, that your provider"s nameservers are:

a. Not located on the same server as the website itself; and

b. Located in geographically diverse locations.

A large number of providers use the web hosting control panel "cPanel"

which by default allows the provider to configure the nameservers, web

server and mail server to be located on the same physical server. This

means that should the server itself go offline for whatever reason, your

website and email are completely offline.

Ideally, you should ensure that your web host has at least its DNS servers

located on separate physical servers as well as networks to your web

server and mail server. This provides a layer of defense in that if the DNS

service fails to work on one of your nameservers due to a network or

hardware issue, the other nameserver is still able to respond, and the

website and mail server will remain unaffected.

DZone, Inc.

150 Preston Executive Dr. Cary, NC 27513

888.678.0399 919.678.0300

may be reproduced, stored in a retrieval system, or transmitted, in any form

or by means electronic, mechanical, photocopying, or otherwise, without

prior written permission of the publisher.

DZone communities deliver over 6 million pages each month

to more than 3.3 million soware developers, architects

and decision makers. DZone oers something for everyone,

including news, tutorials, cheat sheets, research guides, feature

articles, source code and more. "DZone is a developer’s dream,"

says PC Magazine.

Written by Michael Hughes, Lead Security Specialist, National Australia Bank

Michael Hughes has worked for energy companies, web hosting companies and large financial institutions as a technical

specialist and, more recently, a security specialist. Michael has a Bachelors Degree in Telecommunications Engineering,

and has developed a deep knowledge of many technologies over his career. While working for one of the larger web

hosting companies in Australia, Michael developed ViewDNS.info with the aim of providing a free and simple interface to a

large number of DNS tools.

Dzone Refcard Practical DNS Guide

Navigation menu

Versions of this User Manual:

Views

Navigation
