Ditec Sprint
Simply, all the comfort
that you have ever wanted
2 | Ditec Sprint
3 GOOD
REASONS
REASONS
Beautiful
Lovely appearance, also
ideal for more sophisti-
cated environments.
Available in the plastic version,
black or light grey, or in the Alu
version, for high-class internal
spaces, either in residential or office,
studio, and hotel settings.
Modular
The modular line, for
your every requirement.
You can choose the Alu
cover or the plastic one. And not
only: 24 V DC power supply (without
transformer) and 230 V AC versions
are available and the battery is
always optional.
Simple
Easy to install,
easy to use.
The reduced weight,
optional battery and arrange-
ment of the components enable a
quick mechanical and electrical
installation.
24 V motor with encoder
Base plate
Battery kit
Electronic panel
Function-selector button
Arm support
Turn on and turn off button
Cover in plastic
Aluminium cover
1
,
0
0
0
,
0
0
0
C
Y
C
L
E
S
Ditec Sprint | 3
Ditec Sprint
Automation for swing doors
Facilitates movement and improves quality of life
SPRINTV - SPRINTLV SPRINTP - SPRINTL SPRINTPN - SPRINTLN
Characteristics
Maximum capacity 80 kg x 1.0 m
Automation for swing doors
opening and closing by motor,
with encoder
Service index 5 – heavy duty
Lifecycle 1,000,000 cycles
Protection rating
IP30, Class II
(plastic version)
Temperature -20 °C + 55 °C
Opening time 3 ÷ 6 s/90° (adjustable)
Closing time 4 ÷ 7 s/90° (adjustable)
Hold open time 30 s
Product dimensions (mm) 79x93x450
Beautiful. The new Ditec Spring automation, thanks to its
neutral and elegant appearance is the ideal solution for both
residential and high-class environments, such as professional
studios, shops, offices and hotels.
Available in light grey, black or satin aluminium, it is suitable
for internal swing doors up to 80 kg of weight.
Simple to assemble and install thanks to the lower weight
fastening plate and the adjustments which can be set on the
electronic card.
Simple to configure according to the choices and needs of its
user thanks to the PUSH AND GO and LOW ENERGY modes.
Modular. It is possible to select the 24 V DC or 230 V AC power
supply operator with the desired cover, the most suitable arm
and add batteries, if required: the installers just have to select
what they really need and if they wish they can integrate the
selectors, the sensors and the other Ditec Entrematic acces-
sories for a more complete installation. Main components
Product range
230 V AC power supply
Description Cover Transformer
SPRINTV aluminium
SPRINTP light grey plastic
SPRINTPN black plastic
24 V DC power supply
Description Cover
SPRINTLV aluminium
SPRINTL light grey plastic
SPRINTLN black plastic
When building the system, only use Ditec accessories and safety devices.
Every Ditec automation features CE marking and is designed and built in compliance with the safety requirements of the Machinery Directive
(2006/42/EC), of the Electromagnetic Compatibility Directive (2004/108/EC) and of the Low Voltage Directive (2006/95/EC) and of other Directives,
laws, specific standards for special products and situations.
The Company reserves the right to make changes which may improve the products.
For this reason, the technical details featured in this catalogue are not binding.
The pictures shown in this leaflet were taken with the consent of those concerned or in public locations.
Further information can be found in the Technical Manuals available at the website: www.ditecentrematic.com
Entrematic
Via Mons. Banfi , 3 · 21042 Caronno P.lla (VA) · Italy
Tel +39 02 963911 · Fax: +39 02 9650314
ditec@entrematic.com
www.ditecentrematic.com · www.entrematic.com
Ditec Entrematic branches are in: Belgium, France, Germany, Portugal, Spain, Sweden, Switzerland,
Turkey, Latin America, USA, Canada and China.
For addresses and contacts visit our website www.ditecentrematic.com
Cod. P202B - 11/2013
Ditec Sprint
gdp milano 147965
Movement arms
Specific accessories
SPRINTBAT: battery kit
SPRINTSET: memory card to rapidly set the automation
Control accessories and sensors
The automation can be completed with Ditec command, control
and safety devices.
To select please refer to the PM general price list.
Accessories
Certifications
MD
Machine Directive
EMCD
Compatibility Directive
Electromagnetic
LVD
Low Voltage Directive
EN 16005
User Safety Standard
SBA
Arm with articulated
motion.
SBS
Arm with sliding motion.
min. 550
SPRINT BRAS
Arm with three-sections
articulated motion for
doors that open inward;
automation seen from the side.
min. 650 min. 650
Articulated - SBA Sliding - SBSArticulated in three sections - BRAS
