A Start-Guide On Unity’s Entity Component System
Contents
• Foreword
• Content Of This Guide
• A Basic Game The “Normal“ Way
• Rewriting The Killerbird Game In ECS Style
o 1. “Bootstrapping“
▪ 1.1 Initialization
▪ 1.2 “Bridging“
▪ 1.3 Bootstrap Class
o 2. The First ComponentSystem - KillerbirdSpawnSystem
▪ 2.1 Dependencies & The Inject Attribute
▪ 2.2 Adding Behaviour
▪ 2.3 KillerbirdSpawnSystem Class
o 3. KillerbirdMoveSystem
▪ 3.1 Combining Data & Behaviour
▪ 3.2 KillerbirdMoveSystem Class
o 4. KillerbirdRemoveSystem
▪ 4.1 EntityCommandBuffers
▪ 4.2 KillerbirdRemoveSystem Class
o 5. Side Notes
▪ 5.1 Transforming Entities Without TransformSystem
o Conclusion
Foreword
First off, we’re going to see that it is perfectly fine to write parts of your project with the
ECS, and parts of it in the old fashion. The ECS is not superior to the EC Model in every
aspect. (more on that later)
For this simple guide, I have oriented myself at the TwoStickShooter (Pure) sample Unity
provides. However, I have changed quite a bit to demonstrate, that I don’t fully agree with
the application of the socalled “pure ECS“ approach. The hybrid solution is pretty much just
wrapping IComponentData types into classic MonoBehaviours, so that Unity can actually
serialize that data.
Apart from that, I have added comments all over the code. I found that the documentation
on the samples Unity provided wasn’t doing too good of a job to explain what is going on
and especially how it is happening. So, I’ve went through the decompiled assemblies and
tried to add a little description of how things like the Inject attribute work instead of just
stating what they do.
Content Of This Guide
Therefore (and maybe because I’m a bit lazy), we’re going to leave the player as it is. It works
perfectly fine and is definitely not going to be our bottleneck.
However, we will rewrite the SpawnManager to actually be a Spawn System, rewrite the
Killerbird MonoBehaviour to be a system that handles movement & rotation and write a new
system to handle the destruction of killerbirds.
Unity has added a bunch of stuff in their samples, that show how debug information can be
injected into the ECS. (E.g. in the pure EnemySpawnSystem the seed for the random number
generator & stuff like that is recorded). I’ve left this out on purpose.
If you are interested in that nethertheless, you should be able to very well understand
what’s going on in Unity’s samples after this guide.
If something is unclear, have a look at the documentation file in this
repository (The Core Of Unity’s ECS)
Alright, let’s get started.
A Basic Game The “Normal“ Way
Let’s have a look at a really basic game I’ve created for the purpose of this article.
Later, we’re going to rewrite this game in ECS style. Feel free to skip to the A Start Guide On
Unity’s ECS section, if you like.
I am using 3 free asset packages from the Asset Store for the visuals.
Those are the packages
• https://assetstore.unity.com/packages/2d/characters/birds-pack-4-in-1-27774
• https://assetstore.unity.com/packages/2d/characters/tasty-characters-free-forest-
pack-108878
• https://assetstore.unity.com/packages/2d/environments/2d-jungle-side-scrolling-
platformer-pack-78506
The game principle is really simple. You will be able to control a player, that can move left
and right. There are going to be a bunch of killer birds spawning in the Sky, trying to hit the
player. Birds die (i.e. they simply get destroyed) when colliding with something.
The player controller. Nothing special. We’re just reading input and moving the player
accordingly.
Player.cs
Furthermore, we have a Bird component that controls data (movement sped, rotation
speed etc.) & behaviour (rotating, flying towards the player, diying on collision)
Bird.cs
Lastly, we have a simple Manager class that is responsible for spawning our killer birds in
the sky.
BirdManager.cs
Note that this is just basic code for showcasing. I do not care about best practices etc. here.
That is, we’re just doing basic stuff in Update, you won’t see stuff like [SerializeField] etc. just
for the sake of having a light example.
Alright cool. Everything works. The game is not interesting at all, but it works fine as a little
example. Now ask yourself, what could we do better ?
1. All of our birds move & rotate with the same speed. They have the same goal & the
same behaviour. The only difference is going to be their position, and therefore their
directional vector. So, with all that stuff in common, why would we let each bird
operate on it’s own ? This is a perfect example of a situation, that we can handle in a
batch.
2. Instantiate as well as Destroy are slow functions, you can read up why that is all over
the internet. But to give a quick explanation:
They operate on random memory, may perform deep copying ((de)serializing
objects) & let’s not forget, they work on GameObjects. A pretty heavy identificator.
The new ECS provides us with a lot faster methods for instantiating & destroying
entities.
3. We can do a better job with alining memory for the CPU (i.e. laying out our memory
more cache coherent)
Now that we have identified what we can do better, let’s get started. From scratch.
Rewriting The KillerBird Game In ECS Style
Alright. Time to put our knowledge about Unity’s ECS into action. Don’t worry if you don’t
have a clear picture of the ECS yet. We are going to work through this game step by step.
Also, I have left out comments in the code to not bloat up this article even more. There are
loads of comments in the complete files, which you can find on GitHub (I’m going to link
them here from time to time)
1. Bootstrapping
Before we actually run our systems, the very first thing we might want to do is to perform
some initialization, preparation and, what I call, “bridging“. For this, we might want to create
a class that’s often called “Bootstrap“, which is going to handle this kind of stuff for us.
public class Bootstrap {}
Nothing special here at all. You can mark that class as sealed, if you’re really fancy.
1.1 Initialization
Depending on the scale of our game, there’s going to be more or less stuff we need and / or
want to initialize and prepare for our systems. For example, we might want to create a
bunch of EntityArchetypes or fill data for our systems. A lot of this is going to be a one-time
operation, so it’s natural to keep this out of our systems.
Of course, no MonoBehaviour’s (our Bootstrap class is usually not deriving from any Unity
class) also means that we don’t have events like Awake, Start etc. that are being fired for us
to initialize our data. Instead, for this case, we can use the new
[RuntimeInitializeOnLoadMethod]
Attribute.
In this case, we want our Init method to be called before the scene is loaded.
public class Bootstrap
{
[RuntimeInitializeOnLoadMethod(RuntimeInitializeLoadType.Before
SceneLoad)]
public static void Init() { }
}
For our KillerbirdSpawnSystem, we’re going to prepare an EntityArchetype and we will grab
the MeshInstanceRenderer component (the ECS version of the MeshRenderer), which we
have wrapped in a MonoBehaviour, so we can alter the look of our Killerbird in the Editor.
(Note: Right now, there’s no SpriteInstanceRenderer component. That’s the reason why we
are using a mesh.)
We will also grab another MonoBehaviour from the scene called “GameSettings“, which we
can use to expose common data such as spawn cooldown to the Unity editor.
Before we can create the EntityArchetype, we will have to get access to the EntityManager.
We can do this by calling World.Active.GetOrCreateManager<EntityManager>()
This is what our Archetype is going to look like
entityManager.CreateArchetype(typeof(Position), typeof(Rotation),
typeof(TransformMatrix), typeof(MoveSpeed), typeof(KillerBird),
typeof(MeshInstanceRenderer));
all we have to do, is pass in all the components we want this entity to have. The
MeshInstanceRenderer relies on a TransformMatrix component (this is where the renderer
get’s position, rotation & scale of the mesh from). We won’t have to perform any operations
with that component.
With a call to GetLookFromPrototype<T>() we grab the
MeshInstanceRendererComponent from our our Wrapper, that we have placed in our scene.
(more on that in the next section)
Lastly, we will setup some data for our KillerbirdSpawnSystem by calling
KillerbirdSpawnSystem.SetupComponentData(entityManager);
More on that later.
1.2 Bridging
“Bridging“ is what I call the interaction between MonoBehaviour’s and the ECS.
ECS components can’t be serialized at the moment (no worries, that’s going to change in the
future). That is, we can’t edit our component data in Unity’s editor (which is obviously one of
the greatest things about Unity)
What we can do, however, is wrap our components to old-fashioned MonoBehaviours.
(See ComponentWrapper) Unity has already done this for us with the
MeshInstanceRenderer component.
All we do in the before mentioned GetLookFromPrototype<T>() method, is to find our
GameObject in the scene (which holds our MeshInstanceRendererComponent, the wrapped
version of MeshInstanceRenderer) and grab the MeshInstanceRenderer component from it.
public static MeshInstanceRenderer GetLookFromPrototype<T>() where T
: MonoBehaviour
{
var prototype = Object.FindObjectOfType<T>();
var result =
prototype.GetComponent<MeshInstanceRendererComponent>();
return result.Value;
}
As mentioned before, I don’t believe that the ECS should replace the OOP model. Meaning,
our bootstrap class is also going to be great to function as the bridge between
MonoBehaviour‘s <-> Entities / Systems.
The player for example is an entity that you usually want to create once at the beginning of
the game. So, if your player actually is an entity (remember, in this guide our player is a
normal MonoBehaviour) you could very well do that in the Bootstrap class, instead of
creating a separate component system for that.
1.3 Bootstrap Class
So, here is what our bootstrap class is looking like by now.
Bootstrap.cs
In the Init function, which is being called by the[RuntimeInitializeOnLoadMethod]
attribute, we’re creating an EntityArchetype for our Killerbird entity.
Then, we call the
GetLookFromPrototype<T>()
method which grabs the MeshInstanceRenderer component from a GameObject living in our
scene. As you can see, there’s already a wrapper for the MeshInstanceRenderer, called
MeshInstanceRendererComponent, that’s simply exposing our component to the editor.
Lastly, we’re setting up some data for our first Component System, which we are going to
talk about later.
2. Our First ComponentSystem - KillerbirdSpawnSystem
Alright, now we’re ready to start our first ComponentSystem.
All we have to do, is to derive from ComponentSystem and implement the OnUpdate
method. (See ComponentSystem)
public class KillerbirdSpawnSystem : ComponentSystem
{
protected override void OnUpdate () { }
}
2.1 Dependencies & The Inject Attribute
The Inject attribute is one of those things Unity is always showing in their code, but not
really explaining.
A dependency in our component system means, that our system is not going to operate as
long as the dependency is not satisfied. This means, that e.g. OnUpdate is simply not being
called by Unity.
We will have a dependency on our KillerbirdSpawnSystem, let’s have a closer look at it.
struct Data
{
public ComponentDataArray<SpawnCooldown> spawnCooldown;
}
[Inject] private Data data;
This looks probably pretty familiar to you by now, from all the videos Unity has pushed out
so far. What’s actually happening here ?
We define a struct, that is simply going to hold some data for us, that we’re going to work
with. (The SpawnCooldown component in this case, which holds nothing but a float value
that represents our cooldown timer.)
When we now put the Inject attribute on our data field, it means that we do not want to
run our system until we have initialized our data (meaning we have actually data that we
can work with now.)
So, that’s what is happening in the SetupComponentData method, that we have called
earlier from within our Init method in the Bootstrap class.
public static void SetupComponentData(EntityManager entityManager)
{
var stateEntity =
entityManager.CreateEntity(typeof(SpawnCooldown));
entityManager.SetComponentData(stateEntity, new SpawnCooldown {
value = 0.0f });
}
We are creating a new entity with a SpawnCooldown component, and initialize that
component, fulfilling our dependency. The component is then being injected into our Data
struct. Now, after calling this method, Unity will actually start running the system.
(See Injection)
2.2 Adding Behaviour
Next step is to actually do something in our system. In this example, we’re going to use the
OnUpdate method, which works exactly the same as the Update method of a
MonoBehaviour.
All we do here, is to see if we’re ready to spawn a new killerbird (IsReady()) and then actually
spawn said bird (Spawn). Note, that we’re accessing our GameSettings MonoBehaviour to
grab common data we’ve exposed to the editor.
Keep in mind, that we’re now working with value types most of the time, let’s have a quick
look at the IsReady method
private bool IsReady ()
{
var time = data.spawnCooldown[0].value -Time.deltaTime;
var ready = time <= 0.0f;
if (ready)
time = Bootstrap.gameSettings.spawnCooldown;
data.spawnCooldown[0] = new SpawnCooldown { value = time};
return ready;
}
Nothing exiting going on here, except of how we work with our SpawnCooldown
component. Unity hasn’t yet implemented ref return, meaning that at the end, when
altering a value type, we will have to reassign the new value to our component.
In our Spawn method, we’re finally creating our Killerbird entity and setting a bunch of
component data for it. (see Entities & EntityManager)
Note how we literally compose our entity with giving it a position, rotation, look (renderer)
etc. step after step.
2.3 KillerbirdSpawnSystem Class
That’s all there is to the KillerbirdSpawnSystem. If you run the project now, it’s going to
work. There’s nothing happening apart from Birds being instantiated, but it’s working.
Here’s the complete class
KillerbirdSpawnSystem.cs
3. KillerbirdMoveSystem
By now, we already know quite a bit about component systems. I assume you have
understood the concepts so far, so I’m not going to explain the whole system again.
This system is going to handle the movement and rotation for all of our killerbirds. In The EC
version of this game, we’re moving every bird independently (which is pretty common in
OOP)
We will access the Position, Rotation, MoveSpeed as well as the RotationSpeed component.
Let’s create a structure to hold that data and inject it into our system.
struct Data
{
public readonly int Length;
public ComponentDataArray<Position> positions;
public ComponentDataArray<Rotation> rotations;
public readonly ComponentDataArray<MoveSpeed> moveSpeeds;
public readonly ComponentDataArray<RotationSpeed> rotSpeeds;
}
[Inject] private Data data;
The Length integer is also being auto populated for us (it’s simply going to hold the size of
our ComponentDataArrays, which are all of the same size)
Note, that we won’t need an Init method this time, to initialize our components. That’s
because our Spawn method is already doing that for us. It’s initializing every new spawned
killerbird with a position, rotation etc.
In the OnUpdate method, we’re going to iterate over all of our killerbird entities, and calling
the Move method for each one of those.
protected override void OnUpdate()
{
var deltaTime = Time.deltaTime;
for (int i = 0; i < data.Length; i++)
{
Move(i, deltaTime);
}
}
3.1 Combining Data & Behaviour
So far, we haven’t worked much with our components. Now, we will actually interact with
those and alter the behaviour of our killerbird entities by doing so.
All we have to do, is to read our data (position, rotation, …), change that and write it back
into our ComponentDataArray’s. Simple as that.
private void Move (int idx, float deltaTime)
{
var resultRot = quaternion.identity;
var targetPos = (float3)Bootstrap.player.position;
var pos = data.positions[idx].Value;
var dir = targetPos - pos;
if (!dir.Equals(Vector3.zero))
{
var angle = math.atan2(dir.y, dir.x);
var targetRot = quaternion.axisAngle(Vector3.forward,
angle);
resultRot = math.slerp(data.rotations[idx].Value, targetRot,
deltaTime * data.rotSpeeds[idx].value);
}
pos += math.normalize(dir) * data.moveSpeeds[idx].speed *
deltaTime;
data.rotations[idx] = new Rotation(resultRot);
data.positions[idx] = new Position(pos);
}
Couple of things here.
• First of all, behind the scenes, Unity is already doing some work for us when using the
Position & Rotation components. Changing position and rotation isn’t enough, Unity
is going to „translate“ this data into a transform matrix (which is happening in the
TransformSystem the ECS already ships with) and throws this into different systems
such as a rendering system (MeshInstanceRendererSystem) and later physics,
collision systems etc.
So, Unity is not only pushing components for us, but it is also providing
ComponentSystems that directly work with those components. All we have to do, is
to read and write to those components, as done above.
• As you can see, Quaternion, Vector3 etc now have ECS counterparts (quaternion,
float3, …). We can use those interchangeably though, as they contain explicit as well
as implicit conversion operators to each other.
• There’s a new math class to work with those new types. You won’t find methods such
as quaternion.axisAngle in the quaternion structure. You’ll have to look into the math
class.
• There’s no physics component / system yet. That is, we can’t move our entities by a
rigidbody. For the moment, we’ll have to alter the position directly. But since there’s
no collision system yet, that’s not too big of a deal.
• We’re working with value types, so we’ll have to write our changed position &
rotation back into our components.
3.2 KillerbirdMoveSystem Class
That’s all we need to move and rotate our killerbirds. Inject our data into the system, iterate
over aour entities, manipulate position and rotation, write back into components.
The code of the complete system
KillerbirdMoveSystem.cs
4. KillerbirdRemoveSystem
All there is left to do, is to destroy our killerbirds when they are “dead“. In this “game“, dead
means they collided with something. Since there’s no physics / collision system, we need to
get a bit more creative right now. For this, we’ll be doing a very basic bounds check. For each
bird, we’ll simply check if it’s y position is close enough to the player’s y position. Meaning,
we’re pretty much colliding with the player. If it is, the bird is dead and we can remove it.
As always, starting with the data that our system depends on
struct Data
{
public readonly int Length;
public EntityArray killerbirds;
public ComponentDataArray<Position> positions;
}
[Inject] private Data data;
We will only need the position for the bounds check. Then all there is left, is to gain access to
the entity, so that we can actually destroy it.
EntityArray is a NativeArray wrapped for us to work specifically with entities.
When adding a readonly integer called Length to our data structure, Unity will assume that
this is the length of our array(s), so this is also being auto populated for us. Have a readonly
integer that’s not named Length in that strucutre and Unity is going to throw a bunch of
exceptions at you.
Again, in the OnUpdate method, our actual logic is happening. We’ll iterate over all our birds
and see if they are out of bounds (= collide with the player, technically), which is happening
in the IsReadyForRemoval method.
protected override void OnUpdate()
{
for (int i = 0; i < data.Length; i++)
{
var ready = IsReadyForRemoval(i);
if (ready)
Remove(i);
}
}
private bool IsReadyForRemoval (int idx)
{
var height = math.abs(Bootstrap.player.position.y -
data.positions[idx].Value.y);
return height <= Bootstrap.gameSettings.boundsThreshold;
}
If it is, we’ll destroy it in the Remove method.
4.1 EntityCommandBuffers
However, since we’re possibly altering our NativeArray’s (removing entities) as well as
accessing them in the very same frame, Unity is again going to throw an exception at us.
InvalidOperationException: The NativeArray has been deallocated, it is not
allowed to access it.
When removing an element, memory has to be de- and reallocated. So, accessing it when
that is happening is a pretty bad idea. Unity’s solution to problems like this are command
buffers.
Command buffers are especially common in graphics programming, and they do what the
name tells you, they record commands. Those commands can then be executed later.
The ComponentSystem class already contains a EntityCommandBuffer called
PostUpdateCommands, that we can directly access. It is called, as the name suggests, as
soon as OnUpdate finished. We can do pretty much the same stuff with it, as we can with
the EntityManager. Create entities, destroy entities, add components, whatever.
In fact, we’re using the EntityManager. It’s simply all being delayed for us.
So, let’s record a DestroyEntity command, to remove an entity after we have iterated over
all of our entities (Post OnUpdate)
private void Remove (int idx)
{
PostUpdateCommands.DestroyEntity(data.killerbirds[idx]);
}
4.2 KillerbirdRemoveSystem Class
To recap the system: We grab our entities and position components, we iterate over said
entities, do a bounds check using the position of each entity and if the bounds check returns
that the bird is technically dead, we record a command to destroy this entity.
The complete system
KillerbirdRemoveSystem.cs
And that’s all there is to do, to realize this little, not so funny game using the ECS.
5. Side Notes
A bunch of good-to-know things, that you don’t really need but I still want to include in this
start guide. ( I probably have already forgotten a lot of those side notes, so this section might
get updated over time as well)
5.1 Transforming Entities Without TransformSystem
At the moment there’s no scale component available. This is about to change with the new
preview version though.
However, if for some reason you don’t want to work with the transform components
(Position, Rotation, Scale), you can directly manipulate the transform matrix via the
TransformMatrix component.
As mentioned before, under the hood, there’s a ComponentSystem called TransformSystem
operating on the Position, Rotation & Scale component. It’s pretty much just grabbing those
components and throwing them together into a 4x4 matrix.
You can avoid the TransformSystem by leaving out all 3 of those components. You will, of
course, still need a TransformMatrix component though.
Here’s our Spawn method rewritten to directly use the transform matrix
private void Spawn ()
{
var spawnCenter = new float3(0, 14, 0);
var x = Random.Range(-15, 15);
var pos = new float3(spawnCenter.x + x, spawnCenter.y,
spawnCenter.z);
var entity =
EntityManager.CreateEntity(Bootstrap.killerbirdArchetype);
EntityManager.SetComponentData(entity, new MoveSpeed { speed =
Bootstrap.gameSettings.moveSpeed });
EntityManager.SetComponentData(entity, new RotationSpeed { value
= Bootstrap.gameSettings.rotationSpeed });
EntityManager.SetSharedComponentData(entity,
Bootstrap.killerbirdRenderer);
// Create a new matrix with a rotation and position
var transform = new float4x4(quaternion.identity, pos);
// Create a scale matrix with the factor of 100
var scale = float4x4.scale(100);
// Multiply both matrices
var result = Unity.Mathematics.math.mul(transform, scale);
// Write our transform matrix into our component
EntityManager.SetComponentData(entity, new TransformMatrix {
Value = result });
}
• At first we create a 4x4 matrix (float4x4) with a position and rotation (there will
probably be a constructor overload for the scale soon.)
• Then, we create a scale matrix. Note, that this is not scaling your matrix, it creates
an empty matrix that has the passed in scale!
• Next, we multiply both matrices. There’s no multiplication operator, so we will have
to use the mul function, that you can find in the new math class.
• Lastly, write our matrix into the TransformMatrix component, that e.g. the
MeshInstanceRendererSystem is going to work on.
Conclusion
If we ignore all the comments in the code, and the fact that we are confronted with many
new principles as well as a whole new framework, it really isn’t that much more code. Unity
is doing a lot of work for us in the background.
So, what benefits did we now get from rewriting our game to be a mix of OOP (Player) and
ECS (Killerbird- Spawn, Move, RemoveSystem) ?
• Multithreading is easy. We barely have any dependencies on our entities. The only
thing a killerbird depends on, is it’s own position, rotation & the player’s position.
Especially when using the new Job System, we can easily put all of that stuff onto
different threads.
• We have a clear separation of data & logic. You want to know what data we are
working with ? Look at the components. You want to know how this data flows ?
Look at the systems. That’s it.
• We have arranged our memory way more efficient for the CPU. When Moving &
rotating a killerbird, all we throw in is the position, rotation & speed.
When we use MonoBehaviours & their Transform component, we have to load in the
whole object. We can’t just take the position separately & work with that. The whole
object is going to be loaded into memory.
• We are relying heavily on value types, instead of reference types. Meaning, we avoid
Garbage Collector (GC) allocations and deallocations.
• As a result of all of the above, performance improved significantly! Just by arranging
our code & memory differently.
On my machine (Intel i5-6600) those are my results
o Classic scene: 2.3 – 3.0 milliseconds per frame (330-430 fps)
o ECS scene: 1.6 – 1.9 milliseconds per frame (625-525 fps)
In this really basic game, performance improved for us by about 200 fps (or better, about 0.7
– 1.1 milliseconds per frame).
Of course, the jump in performance will depend on your specific game and how you apply
the principles we have talked about in this article.
