The FOS-120A Light Source and FLS-130A Laser Source deliver
excellent stability. They are compatible with the FOT-10A and
FOT-20A Power Meters, which are suitable for a variety of
testing applications including continuity and end-to-end testing.
Versatility
The FOS-120A Light Source and FLS-130A Laser Source feature
single- and dual-wavelength sources from single or double ports.
The units deliver continuous wave (CW) signals for power/loss
measurements and 2-kHz signal generation for fiber identification.
Certain FOS-120A models and all FLS-130A models are equipped with
EXFO's Universal Interface.
Unit Powering
Powering options include a 9 V battery and a standard AC adapter.
The battery life offers a minimum of seven hours of continuous operation.
An auto-off function with a 10-minute timer is included to preserve
battery life.
Accessories
Each unit comes complete with a rigid carrying case, a shockproof PVC
holster with strap, as well as SC, ST and FC connectors.
Delivering Optical Source Stability
Key Features
"Single- or dual-wavelength configuration
"2-kHz signal generation for fiber identification
"Dual powering: 9 V battery and AC adapter/charger
"Auto-off function
"Rigid carrying case and shockproof holster with strap
"Equipped with EXFO’s Universal Interface, except for certain FOS-120A models
FOS-120A/FLS-130A
Specifications
Specifications—FOS-120A Light Source (LED)
Models FOS-121A FOS-122A FOS-123A FOS-124A FOS-125A
Wavelength1(nm) 850 ± 30 1310 ± 40 1550 ± 30 850 ± 30 1310 ± 30
1310 ± 40 1550 ± 30
Spectral width2, 3 (nm) 50 145 70 50/145 70/70
Launch power3(dBm)
9/125 µm N/A N/A -25 N/A -20/-25
50/125 µm -17 -20 -25 -17/-20 -20/-25
62.5/125 µm -14 -16 -25 -14/-16 -20/-25
Power stability4(dB)
1 h ± 0.03 ± 0.06 ± 0.08 ± 0.03/± 0.06 ± 0.06/± 0.08
8 h ± 0.05 ± 0.10 ± 0.12 ± 0.05/± 0.10 ± 0.10/± 0.12
Output ports 1 1 1 2 2
Specifications—FLS-130A Laser Source (Laser)
Models FLS-132A FLS-133A FLS-135A FLS-136A
Wavelength1(nm) 1310 ± 20 1550 ± 20 1310 ± 20 1310 ± 20
1550 ± 20 1550 ± 20
Spectral width5(nm) ≤5≤5≤5/5 ≤5/5
Launch power3(dBm)
9/125 µm -7 -7 -7/-7 -8/-8
50/125 µm -7 -7 -7/-7 -8/-8
62.5/125 µm -7 -7 -7/-7 -8/-8
Power stability4(dB)
1 h ± 0.06 ± 0.08 ± 0.06/± 0.08 ± 0.06/± 0.08
8 h ± 0.10 ± 0.12 ± 0.10/± 0.12 ± 0.10/± 0.12
Output ports 1 1 2 1
General Specifications—FOS-120A and FLS-130A
Size (H ×W ×D) 22.2 cm ×10.3 cm ×5.9 cm (8 3/4in ×4 1/16 in ×2 1/4in)
Weight
unit 0.6 kg (1.4 lb)
shipping 1.8 kg (4 lb)
Temperature
operating -10 °C to 50 °C (14 °F to 122 °F)
Standard Accessories
User Guide, carrying case, 9 V battery, AC adapter, protective holster, shoulder strap and Certificate of Compliance.
Laser Safety
21 CFR 1040.10 and IEC-60825-1 CLASS 1 LASER PRODUCT
CLASS 1 LED PRODUCT
Notes
1. At 23 ˚C.
2. FWHM = Full width at half maximum.
3. Typical.
4. For a temperature stability of ± 1 ˚C.
5. rms = root mean square.
Find out more about EXFO’s extensive line of high-performance portable instruments by visiting our Web site at www.exfo.com
Rugged Handheld Solutions
• OLTS
• Power Meter
• Light Source
• Talk Set
• OSA
• PMD
• Chromatic Dispersion Analyzer
• Multiwavelength Meter
DWDM Test Systems
Optical FiberUNIVERSAL TEST SYSTEM
• OTDR
• OLTS
• ORL
• Switch
Protocol
• 10/100 and Gigabit Ethernet
• SONET/SDH (DS0 to OC-192c)
• SDH/PDH (64Kb/s to STM-64c)
Ordering Information
SPFOS120AFLS130A.1AN © 2003 EXFO Electro-Optical Engineering Inc. All rights reserved. Printed in Canada 03/04
EXFO has made every effort to ensure that the information contained in this specification sheet is accurate. However, we accept no
responsibility for any errors or omissions, and we reserve the right to modify design, characteristics and products at any time without obligation.
Units of measurement in this document conform to SI standards and practices.
Contact EXFO for prices and availability or to obtain the phone number of your local EXFO distributor.
For the most recent version of this spec sheet, please go to the EXFO website at http://www.exfo.com/support/techdocs.asp
In case of discrepancy, the Web version takes precedence over any printed literature.
All names, trademarks, products and services mentioned are registered or unregistered trademarks of their respective owners.
CORPORATE HEADQUARTERS 465 Godin Avenue Vanier (Quebec) G1M 3G7 CANADA Tel.: 1 418 683-0211 ·Fax: 1 418 683-2170
EXFO AMERICA 1201 Richardson Drive, Suite 260 Richardson TX 75080 USA Tel.: 1 800 663-3936 ·Fax: 1 972 907-2297
EXFO EUROPE Le Dynasteur, 10/12 rue Andras Beck 92366 Meudon la Forêt Cedex FRANCE Tel.: +33.1.40.83.85.85 ·Fax: +33.1.40.83.04.42
EXFO ASIA-PACIFIC 151 Chin Swee Road, #03-29 Manhattan House SINGAPORE 169876 Tel.: +65 6333 8241 ·Fax: +65 6333 8242
EXFO CHINA Beijing New Century Hotel Office Tower, Room 1754-1755 Beijing 100044 P. R. China Tel.: +86 (10) 6849 2738 · Fax: +86 (10) 6849 2662
No. 6 Southern Capital Gym Road
TOLL-FREE (USA and Canada) Tel.: 1 800 663-3936 www.exfo.com • info@exfo.com
FOS-12XA-XX
Light Source
Model
FOS-121A = 850 nm
FOS-122A = 1300 nm
FOS-123A = 1550 nm
FOS-124A = 850/1300 nm (2 ports)
FOS-125A = 1310/1550 nm (2 ports)
Connector
50 = FC/PC
54 = SC/PC
74 = ST/PC
EI-EUI-28 = UPC/DIN 47256*
EI-EUI-76 = UPC/HMS-10/AG*
EI-EUI-89 = UPC/FC narrow key*
EI-EUI-90 = UPC/ST*
EI-EUI-91 = UPC/SC*
EI-EUI-95 = UPC/E-2000*
* for models FOS-123A and FOS-125A only
Example: FOS-123A-EI-EUI-89
FLS-13XA-XX
Laser Source
Model
FLS-132A = 1310 nm
FLS-133A = 1550 nm
FLS-135A = 1310/1550 nm (2 ports)
FLS-136A = 1310/1550 nm (1 port)
Connector
50 = FC/PC
54 = SC/PC
74 = ST/PC
EI-EUI-28 = UPC/DIN 47256
EI-EUI-76 = UPC/HMS-10/AG
EI-EUI-89 = UPC/FC narrow key
EI-EUI-90 = UPC/ST
EI-EUI-91 = UPC/SC
EI-EUI-95 = UPC/E-2000
Example: FLS-135A-EI-EUI-89
