Replacement Guidelines
Prestcold to DWM Copeland
D5.3.5/0104/E 1
R
RE
EP
PL
LA
AC
CE
EM
ME
EN
NT
T
G
GU
UI
ID
DE
EL
LI
IN
NE
ES
S:
:
F
FR
RO
OM
M
P
PR
RE
ES
ST
TC
CO
OL
LD
D
T
TO
O
D
DW
WM
M
C
CO
OP
PE
EL
LA
AN
ND
D
1Prestcold and DWM Copeland Models............................................................................................................2
2Prestcold to DWM Copeland Overview...........................................................................................................3
3Prestcold Cross Reference: PK to DK compressors.........................................................................................4
4Prestcold Cross Reference: PL to DL compressors..........................................................................................6
5Prestcold Cross Reference PR to D2 or D9R...................................................................................................8
6Prestcold Cross Reference PLG to DL or D2S............................................................................................... 10
D5.3.5/0104/E 2
1 Prestcold and DWM Copeland Models
HP 0.5 11.5 22.5 33.5 4 5 6 7 10 15 20 30 40 50 60 70
PK - Series
P2S
PL - Series
S-Series
P3S P4S P6S P8S
P6D P8D
DEMAND COOLING
P2D P3D P4D
HIGH EFFICIENCY 2D
DEMAND COOLING
8D
L - Series
2S 4S 6S 8S
DISCUS
DISCUS
Standard
S-Series
K - Series
3S
3D 4D 6D
D5.3.5/0104/E 3
2 Prestcold to DWM Copeland Overview
An overview of both brands is indicated below, this shows the alternatives between Prestcold and DWM Copeland.
The major differences between the two brands are the PK, PL, PLG and PR. Please refer to the enclosed cross
reference tables for alternatives.
All Discus compressors and the P4S, P6S, P8S and P6T compressors were derived from the DWM range.
Therefore all operating characteristics are the same.
HP
PK 0.5 DK
PL 3DL
PLG 4.5 D2S
PR 7.5 D3S
P4S 10 D4S
P6S 20 D6S
P8S 45 D8S
P6 D6T
P2D 6D2D
P3D 10 D3D
P4D 15 D4D
P6D 30 D6D
P8D 70 D8D
D5.3.5/0104/E 4
3 Prestcold Cross Reference: PK to DK compressors
Ident Numbers with Associated Motors
Prestcold
Description Prestcold Ident
Number DWM Copeland
Description DWM Copeland
Ident Number
PK5X/0011P-49 4630303 DKMP-5X EWK 4615204
PK5X/0011P-42T 4615737 DKMP-5X EWL 4615191
PK5X/0011P-08 4635171 DKMP-5X-CAG 4615180
PK50/0011-08 4635057 DKM5X-CAG 4615180
PK10X/0011P-42T 4617255 DKMP-7X-EWL 4615088
PK100/001-08 4635068 DKMP-7X-CAG 4623403
PK100/0011-49 4619422 DKM-75 EWK 4571933
PK10X/0011P-08 4635182 DKM-75-CAG 4582460
PK10X/0011P-09 4615000 DKMP-75X-EWL 4615088
PK7X/0014P-42T 4615760 DKJP-7X-EWL 4615259
PK7X/0014P-08 4635193 DKJP-7X-CAG 4615248
PK7X/0014P-49 4623016 DKJP-7X-EWK 4615260
PK7X/0014P-09 4615759 DKJP-7X-EWL 4615259
PK75/0014-42T 6704060 DKJ 75 EWN 4578309
DKJ 75 EWN 4588593
PK75/0014-49 4618690 DKJD-75-EWK 2479064
PK75/0014-09 6704026 DKJD-75-EWL 2479064
PK75/0014-08 4635080 DKJD-75-CAG 2416785
PK10X/0014P-42T 4619239 DKJP-10X-TWY 4615306
PK10X/0014P-08 4635206 DKJP-10X-EWL 4615099
PK10X/0014-49 4629649 DKJP-10X-CAG 4615282
PK10X/0014P-09 4614654 DKJP-10X-EWL 4615099
PK100/0014-49 4619499 DKJ-100-EWK 4573713
PK100/0014-42T 6704468 DKJD-100-EWL 2479906
PK100/0014-08 4635091 DKJD-100-CAG 4588480
PK100/0014-09 6704424 DKJD-100-EWL 2479906
PK150/0014-49 4619433 DKJD 150 EWK 4591913
PK150/0014-42T 6719180 DKJD-150-EWL 4583190
PK150/0014-08 4635104 DKJD-150-CAG 4635046
PK150/0014-09 6719157 DKJD 150 EWK 4591913
PK150/0014-09 6719146 DKJD 150 EWK 4591913
D5.3.5/0104/E 5
Prestcold Cross Reference: PK to DK compressors Continued
Ident Numbers with Associated Motors
Prestcold
Description Prestcold Ident
Number DWM Copeland
Description DWM Copeland
Ident Number
PK10X/0017P-42T 4615806 DKSJP-10X-EWL 4615328
PK10X/0017P-49 4620346 DKSJP-10X-EWK 4615339
PK10X/0017P-08 4635239 DKSJP-10X-CAG 4615317
PK10X/0017P-09 4615793 DKSJP-10X-EWL 4615328
PK15X/0017P-42T 4615022 DKSJP-15X-EWL 4615102
PK15X/0017P-49 4623936 DKSJP-15X-EWK 4615373
PK15X/0017P-08 4635240 DKSJ-15X-CAG 4615351
PK15X/0017P-09 4614676 DKSJP-15X-EWL 4615102
PK150/0017-49 4597193 DKSJ-150-EWK 4601450
PK100/0017-42T 6704684 DKSJ-100-EWN 4578310
PK100/0017-49 4618703 DKSJ-100-EWK 2479075
PK100/0017-09 6704640 DKSJ-10X-EWL 4595164
PK100/0017-08 4635126 DKSJ-10x-CAG 4595186
PK150/0017-42T 6705109 DKSJD-150-EWL 2480024
PK150/0017-08 4635137 DKSJD-150-CAG 4582517
PK150/0017-09 6705063 DKSJD-150-EWL 2480024
PK150/0020-42T 6705303 DKL-150-EWN 4578321
PK15X/0020P-42T 4615839 DKLP-15X-EWL 4615419
PK15X/0020P-08 4635251 DKLP-15X-CAG 4615395
PK20X/0020P-42T 4637359 DKLP-20X-EWL 4637224
PK15X/0025P-42T 4615862 DKSLP-15X-EWL 4615453
PK15X/0025P-49 4623947 DKSLP-15X-EWK 4615464
PK15X/0025P-08 4635262 DKSLP-15X-CAG 4615442
PK15X/0025P-09 4615851 DKSLP-15X-EWL 4615453
PK20X/0025P-49 4635455 DKSLP-20X-EWK 4635295
PK20X/0025P-42T 4635444 DKSLP 20X EWL 4627289
PK150/0025-49 4618714 DKSLP-15X-EWK 4615464
PK150/0025-42T 6705507 DKSL-150-EWN 4588560
D5.3.5/0104/E 6
4 Prestcold Cross Reference: PL to DL compressors
Ident Numbers with Associated Motors
Prestcold Description Prestcold Ident
Number DWM Copeland
Description DWM Copeland
Ident Number
PL20X/0027P-42T 4614701 DLEP-20X-EWL 4615044
PL20X/0027P-49 4620482 DLEP-20X-EWK 4615497
PL200/0027-42T 6710014 DLEE-201-EWL 2640308
PL200/0027-49 4590603 DLE-201-EWK 2641811
PL20X/0036P-49 4629990 DLFP-20X-EWK 4615522
PL20X/0036P-42T 4615895 DLFP-20X-EWL 4615055
PL20X/0036P-09 4615884 DLFP-20X-EWL 4615055
PL200/0036-42T 6710070 DLFE-201-EWL 2417039
PL200/0036-49 4594989 DLF-201-EWK 2501703
PL200/0036-09 6710047 DLF-201-EWL 4586451
PL30X/0036P-42T 4614712 DLFP-30X-EWL 4615055
PL30X/0036-49 4624382 DLFP-30X-EWK 4615555
PL300/0036-42T 6710401 DLFE-301-EWL 2479871
PL300/0036-49 4592289 DLFE-301-EWK 4572254
PL300/0036-09 6710376 DLFE-301-EWL 2479871
PL20X/0040P-49 4630290 DLJP-20X-EWK 4615599
PL20X/0040P-42T 4614994 DLJP-20X-EWL 4615577
PL200/0040-42T 6710183 DLJE-201-EWL 4571524
PL200/0040-49 4618725 DLJE-201-EWK 4576143
PL30X/0040P-49 4630234 DLJP-30X-EWK 4615624
PL30X/0040P-42T 4614585 DLJP-30X-EWL 4615066
PL300/0040-42T 6710514 DLJE-301-EWL 4580931
PL300/0040-49 4618736 DLJE-301-EWK 4586268
PL300/0040-09 6710489 DLJE-301-EWL 4580931
PL30X/0050P-49 4626924 DLLP-30X-EWK 4615657
PL30X/0050P-42T 4614574 DLLP-30X-EWL 4616252
PL30X/0050P-09 4615942 DLL-301-EWL 4586440
PL300/0050-42T 6710627 DLL-301-EWL 4586440
PL300/0050-09 6710592 DLL-301-EWL 4586440
D5.3.5/0104/E 7
Prestcold Cross Reference: PL to PK compressors Continued
Ident Numbers with Associated Motors
Prestcold Description Prestcold Ident
Number DWM Copeland
Description DWM Copeland
Ident Number
PL40X/0050P-12 4615964 DLLP-40X-EWM 4615679
PL40X/0050P-33 4614563 DLLP-40X-EWL 4615077
PL400/0050-12 6710796 DLLE-401-EWM 2417153
PL40X/0062P-12 4615986 DLSGP-40X-EWM 4615691
PL40X/0062P-33 4614552 DLSGP-40X-EWL 4616263
PL400/0062-12 6710810 DLSG-401-EWM 2417017
PL400/0062-33 6710821 DLSGE-401-EWL 4587125
PLH50X/0074-12/27 4619171 DLHA1-50X-EWM/D 4619035
PLH50X/0074-33 4619160 DLHA1-50X-EWL 4619024
PLH50X/0074-49 4619182 DLHA1-50X-EWK 4619046
D5.3.5/0104/E 8
5 Prestcold Cross Reference PR to D2 or D9R
Ident Numbers with Associated Motors
Prestcold Description Prestcold Ident
Number DWM Copeland
Description DWM Copeland
Ident Number
PR50X/A0089-33 4614927 D2SC-55X-EWL/D 4627336
PR50X/0089-12 4596601 D2SC-55X-EWM/D 4637677
PR500/0089-45 6717526 D9RA-500L-AWM/D 2827470
PR500/0089-33 6700057 D9RA4-500L-EWL 2825792
PR500/0089-12 6700013 D9RA-500L-EWM 2855535
PR500/0105-45 6717606 D9RA-500L-AWM/D 2827470
PR500/0105-33 6700331 D9RA-500L-EWL 2825792
PR500/0105-12 6700295 D9RA-500L-EWM 2855535
PR750/A0089-45 6717560 D9RA4-750-AWM/D 4574192
PR750/A0089-15 6701447 D9RA4-750-TWY Ident. N° on request
PR750/0089-33 6700193 D9RA4-750-EWL 2825792
PR750/0089-12 6700159 D9RA 750 EWM 4570587
PR750/0105L-33 6700615 D9RC-750L-EWL 4615691
PR750/0105L-12 6700579 D9RC-750L-EWL 4615691
PR750/0105-45 6717640 D9RC-750-AWM/D 4627405
PR750/0105-33 6700477 D9RC-750-EWL 2295775
PR750/0105-12 6700433 D9RC-750-EWM 2295786
PR1000/0105-33 6700751 D9RC4-1000-EWL 2295877
PR1000/0105-27 6700795 D9RC4-1000-EWM/D 2295888
PR1000/0105-12 6700717 D9RC4-1000-EWM/D Same motor as
EWM/D
PR1000/A0105-49 6700773 D9RC4-1000-EWK 2507198
PR1000/A0105-45/55 6717720 D9RC4-1000-AWM/D 2641889
PR1000/A0105-40 6701527 D9RC 1000 EWY 2295866
PR750/0138-33 6700977 D9RS-750-EWL Ident. N° on request
PR750/0138-12 6700933 D9RS-750-EWM Ident. N° on request
PR750/A0138-45 6717764 D9RS-750-AWM/D Ident. N° on request
D5.3.5/0104/E 9
Prestcold Cross Reference PR to D2 or D9R Continued
Ident Numbers with Associated Motors
Prestcold
Description Prestcold Ident
Number DWM Copeland
Description DWM Copeland
Ident Number
PR1000/A0138-45/55 6717800 D9RS-1000-AWM 2641914
PR1000/0138-33 6701118 D9RS-1000-EWL 2295924
PR1000/0138-12 6701072 DRRS1000-EWM 2295935
PR1500/A0138-45/55 6717844 D9RS4-1500-AWM/D 2641903
PR1500/A0138-40 6701583 D9RS4-1500-EWY 2296018
PR1500/A0138-49 4618907 D9RS4-1500-EWK 2507201
PR1500/0138-33 6701254 D9RS4-1500-EWL 2296029
PR1500/0138-12/27 6701210 D9RS4-1500-EWM/D 2296030
D5.3.5/0104/E 10
6 Prestcold Cross Reference PLG to DL or D2S
Ident Numbers with Associated Motors
Prestcold Description Prestcold Ident
Number DWM Copeland
Description DWM Copeland
Ident Number
PLG200/0036-42T 6710854 DLF-301-EWM Ident. N° on request
PLG200/0040-42T 6710923 DLF-301-EWM Ident. N° on request
PLG200/0040-12 6710912 DLF-30X 4597524
PLG300/0036-12 4617346 DLFP-30X-EWM/D 4615055
PLG300/0036-42T 6710990 DLJP-30X-EWL 4615066
PLG300/0040-42T 6711062 DLJP-30X-EWL 4615066
PLG400/0050-33 6711200 DLLP-40X-EWL 4615077
PLG400/0050-12 6711197 DLLP-40X-EWM 4615679
PLG300/0050-42T 6711131 DLLP-401-EWL 4576881
PLG400/0062-33 6711277 D2SA-450-EWL 4637439
PLG400/0062-12 6711266 D2SA-450--EWM 4637644
PLG500/0062-33 6711346 D2SA-450-EWL 4637439
PLG500/0062-12 6711335 D2SA-450--EWM 4637644
PLG65X/0074-33 4631033 D2SC-65X-EWL/N 4638103
PLG65X/ 0074-12 4631022 D2SC-65X-EWM/D 4637677
PLG650/0074-33 6711482 D2SC-650-EWM/D Ident. N° on request
PLG650/0074-12 6711471 D2SC-650-EWM/D Ident. N° on request
D 5.3.5 / 0104/E
Copeland Marketing & Sales - 27, Rue des Trois Bourdons - B 4840 Welkenraedt, Belgium
Tel. +32 (0) 87 305411 - Fax +32 (0) 87 305506 - internet: www.ecopeland.com - email: eCommerce@eCopeland.com
The Emerson logo is a trademark and service mark of Emerson Electric Co. Copeland Corporation is a division of Emerson Electric Co. Copeland is a registered trademark.
Information contained in this brochure is subject to change without notification.
© 2004 Copeland
Benelux Eastern Europe, Turkey & Iran
Deltakade 7 27, Rue des Trois Bourdons
NL-5928 PX Venlo B-4840 Welkenraedt
Tel. +31 (0) 77 324 0234 Tel. +32 (0) 87 305 061
Fax +31 (0) 77 324 0235 Fax +32 (0) 87 305 506
Deutschland/Österreich & Schweiz Poland
Senefelder Straße 3 11A, Konstruktorska
D-63477 Maintal P-02-673 Warszawa
Tel. +49 (0)6109 6059 0 Tel. +48 225 458 9205
Fax +49 (0)6109 6059 40 Fax +48 225 458 9255
France/Greece & Maghreb Russia & CIS
8, Allee Du Moulin Berger Malaya Trubetskaya, 8-11th Floor
F-69130 Ecully RUS-119881 Moscow
Tel. +33 (0)4 78668570 Tel. +7 095 232 94 72
Fax +33 (0)4 78668571 Fax +7 095 232 03 56
Italia Middle East & Africa
Via Ramazzotti, 26 PO Box 26382, R/A 8, FD-2
I-21047 Saronno (va) Jebel Ali, Dubai - UAE
Tel. +39 02 961781 Tel. +9714 883 2828
Fax +39 02 96178888 Fax +9714 883 2848
España & Portugal
Sweden/Denmark/Norway & Finland
Diputacion, 238 AT.8
Östbergavägen 4, P.O.Box 10
E-08007 Barcelona
S-59021 Väderstad
Tel. +34 93 4123752
Tel. +46 (0) 142 70520
Fax +34 93 4124215
Fax +46 (0) 142 70521
UK & Ireland
Colthrop Way
GB- Thatcham, Berkshire - RG19 4 NQ
Tel. +44 (0)1635 87 6161
Fax +44 (0)1635 877111
Asia/Pacific
10/F, Pioneer Building, 213 Wai Yip Street,
Kwun Tong, Kowloon - Hong Kong
Tel. +852 28 66 31 08
Fax +852 25 20 62 27
Latin America
7975 North West 154Th Street - Suite 300
Miami Lakes, FL, 33016 - USA
Tel. +1 305 818 8880
Fax +1 305 818 8888
