Parts Information
Service air filters will now be distributed as a kit. The kit will contain the air filter, the new clamp
[92173-1001], and an instruction card. When ordering a new air filter you will receive a kit as shown as the
table below.
Eligibility
See the “Engine Information Table” below for information on the correct kit.
Engine Information Table
Model Mounted Air Filter Kit
FR541V 11013-7050 or 11013-0727 99999-0383
FR600V
FS481V
11013-7049 or 11013-0726 99999-0384
FS541V
FS600V
FR651V
FR691V
FR730V
FS651V
FS691V
FS730V
The “Kit Contents Table” shows the parts included in each kit.
Kit Contents Table
Kit Air Filter Clamp Card
99999-0383 11013-0727 92173-1001 49007-0735
99999-0384 11013-0726 92173-1001 49007-0738
SERVICE
©2012, Kawasaki Motors Corp., U.S.A.
ENG 12-06
National
December 21, 2012
MODEL: FR651V, FR691V, FR730V, FS651V, FS691V, FS730V FR541V,
FR600V, FS481V, FS541V, FS600V
TITLE: NEW FR & FS AIR FILTER CLAMP (P/N 92173-1001)
See reverse side for additional information
Details
As a product improvement, the original air filter clamp (92173-7007) now supersedes to a new clamp
(92173-1001) with a redesigned band. When changing the air filter, replace the original air filter clamp
(92173-7007) with the new clamp (92713-1001).
REF:
CODE:
DATE:
Replacement Procedure
1. Remove the original air filter and clamp.
2. Install the new air filter and new clamp as
shown on the kit instruction card. Tighten the
clamp.
3. To ensure a proper seal when installing the
new clamp, attempt to rotate the air filter in
the intake tube. If the air filter rotates, tighten
the clamp further and re-test. The clamp
is tight enough when the air filter does not
rotate.
Warranty Information
This is Service Information only, not warranty
authorization.
KAWASAKI MOTORS CORP., U.S.A.
Page 2
ENG 12-06
