HARDWARE SPEC SHEET
The Synergis™ system supports HID’s open
field hardware enabling organizations to
deploy industry-standard access control
modules and protect their investments for
years to come. The HID VertX† V100 reader
interface module connects up to two access
control card readers, controlling either one
or two doors. The V100 is controlled by the
Synergis Cloud Link intelligent appliance or
the HID VertX V1000 controller through a
high-speed RS-485 network.
Seamlessly integrated with the Genetec
Synergis IP Access Control Solution
HID VertX
V100 Dual-Reader
Module
Reader and IO interface module
for up to 2 doors
Overview
Connects to Synergis Cloud Link or HID VertX
V1000 controller via RS-485
Reports all activity in real-time to Synergis Cloud
Link or the V1000
Controls up to 2 readers or 2 doors
Reports supervised inputs
Some inputs can be configured as general
purpose inputs
UL 294, ULC-S319 (See Synergis Cloud Link
Hardware Installation Guide)
UL 1076 recognized component
Available Interfaces
Readers: Up to 2 readers (Wiegand or Clock-and-
Data interface)
Inputs: Up to 7 inputs (2 door monitor switches,
2 Request-to-Exit switches, AC Fail Monitor*,
Battery Fail Monitor*, Enclosure Tamper*)
Outputs: Up to 4 non-latching relay outputs (2
door strikes, 2 auxiliary devices
*Can be configured as a general purpose input)
Synergis Cloud Link
e Synergis Cloud Link appliance
is an intelligent and PoE-enabled
micro-server that supports a mix
of non-proprietary access control
modules like the HID VertX V100.
Modernize your access control
environment by deploying Synergis Cloud
Link over your network and establishing real-time
connectivity to your doors.
Innovative Solutions
HID VertX V100 Dual-Reader Interface Module
HARDWARE SPEC SHEET
Genetec Inc.
2280 Alfred-Nobel Blvd., Suite 400,
Montreal, QC, Canada H4S 2A4
T 514.332.4000
genetec.com
info@genetec.com
© Genetec Inc., 2016. TM trademark of Genetec Inc.
† HID, EDGE and VertX are the trademarks and registered trademarks of HID Global
Corporation in the United States and other countries.
e V100 two-reader interface module connects to and reports all activities to the Synergis Cloud Link
appliance or the V1000 via RS-485.
Architecture
VertX V100
Dual-Reader
Module
HID VertX V100 Dual-Reader Interface Module
Choose the Synergis IP access control solution to
protect your people and assets with your choice
of widely-deployed, non-proprietary, and secure
access control hardware.
Specifications
Dimensions 5.8” W x 4.825” H x 1.275” D (147.32 mm x
122.55 mm x 32.38 mm)
Weight 12.4 oz (.35 kg)
Power Supply
Requirements
60 mA @ 9-18 VDC (with no readers
connected). When the V100 is supplying power
to readers, the requirements are 600 mA @
9-18VDC. e V100 can supply 500 mA to two
readers
Operating
Environment:
Indoors, or customer-supplied NEMA-4 rated
enclosure
Operating
Temperature:
32° to 122° F (0° to 50° C)
Communications
Ports
RS-485 — two wire. Two SIA standard
Wiegand/Clock-and-Data ports
Certications UL294, UL 1076 (US) | CSA 205 (Canada) |
FCC Class A | CE Mark, EN 50130-4 (EU) |
EMC for Canada, EU (CE Mark), Australia
(C-Tick Mark), New Zealand, Japan.
ULC-S319 (See Synergis Cloud Link Hardware
Installation Guide)
Warranty 24-month warranty. Please refer to the
Genetec Sales Policy for more information
▶
▶
