W ER350

User Manual: ER350

Open the PDF directly: View PDF PDF.
Page Count: 2

Power Input: 12 V DC (24V DC available by special order)
Voltage Tolerance: 15%
Current Draw: 0.25 A@12 VDC; 0.15 A@24 VDC
at temperature 20
Sensor Switch monitored output (GK-350M), Rating 2A@
125V, indicates the lockset locked or unlocked status.
Operating Temperature: -10~45
Humidity: 0~95% non-condensing.
Lock's surface Temperature (when the power is on):
current temperature +20
2000 LBS jaw strength pull testing.
Tested to 1,000,000 cycles.
Weight Approx. : 330 g
Hollow F rames S urfac e Mount Ins tallation
Wood F rames S urfac e Mount Ins tallation
Vers ion C hangeable
E R 350
S urfac e Mount E lec tric S trike
S tainles s
s teel plate ens ures s trength and long life.
The E R 350 s eries s urface mount electric
s trikes are des igned for us e with night latch
locks (without deadbolt) having up to 12 mm
throw latc hbolt.
The E R -350 s eries is available in two
models , E R 350 Unmonitored or the G K -350M
with s ens or s witch output. T he units are
des ign for us e with mos t hollow metal frames ,
aluminum frames and wood frames .
Field-reversible ( on site
for Fail-safe (Power to Lock) or Fail-secure (Power to Open)
in 10 seconds.
by changing position of screws)
1
2
1
2
"Fail-Secure"
(Power to Open)
"Fail-Safe"
(Power to Lock)
L ong life s olenoids
Strikes are powered by a solenoid, not a buzzer coil.
Special designed solenoid for strength and long life
operating lifetime with guaranteed 1,000,000 operations.
In-swinging
In-swinging
Night Latch
NightLatch
ER 350 ER 350M
GEM are warranted against defects in
material and workmanship while used in normal service for a
period of 1 years from the date of sale to the original
customer.
Electric Strikes
The information and specifications printed in this manual are
current at the time of publication. The GEM policy is one of
continual development and improvement; therefore GEM
reserves the right to change specifications without notice.
Warranty:
S ens or S witc h Monitoring Output
Dis claimer:
Unit :mm
Dimens ions :
The models with "Sensor Switch monitoring output" function
is GK-350M , indicates the lockset locked or unlocked status.
The Sensor Switch monitoring as
N.C. (Normal Close) output for
dooropened.
The Sensor Switch monitoring as
N.O. (Normal Open) output for
doorclosed.
E R -350
S urfac e Mount E lec tric S trike
28 . 5
4
40
DEEP:12
62
86
