INTRODUCTION Eco Force Flueing Specification

3

The EcoForce™ range

High Efficiency Gas Fired Condensing Water Heaters

Flueing Specifications

Models:

EF+ 35/150

EF+ 35/230

EF+ 55/230

EF80

EF100

EF120

EF150

EF180

2 May 2010

2

3

INDEX

Horizontal Concentric Balanced Flue

Models EF+35/150, EF+35/230, EF+55/230 (80/125 System) 4

Models EF80 (80/125 System) 5

Models EF80 (100/150 System) 6

Models EF100, EF120(100/150 System) 7

Models EF150, EF180 (100/150 System) 8

Vertical Concentric Balanced Flue

Models EF+35/150, EF+35/230, EF+55/230 (80/125 System) 9

Models EF80 (80/125 System) 10

Models EF80 (100/150 System) 11

Models EF100, EF120 (100/150 System) 12

Models EF150, EF180 (100/150 System) 13

Notes 14

4

FLUE SPECIFICATION

HORIZONTAL CONCENTRIC BALANCED FLUE

ECOFORCE™ MODELS

EF+35/150, EF+35/230, EF+55/230

PART NO: EFHF001 - HORIZONTAL FLUE KIT

EF+35/150 and EF+35/230 Maximum Equivalent Flue Length = 44 Metres

EF+55/230 Maximum Equivalent Flue Length = 21 Metres

Deduct 1.0 metre for each 90° Bend

Deduct 0.5 metre for each 45° Bend

Each Horizontal Flue Kit Includes all items marked as Std Spec

Part No

Description

Std Spec

M84460

Elbow PP 80/125 90°

1

M86934

Wall Terminal 80/125

1

M84455

Extension – 80/125 x 500mm

1

M84452

Extension – 80/125 x 1000mm

M84461

Elbow PP 80/125 45°

M84481

Wall Clamp 125mm

M84472

Condensate Drain PP 80/125

5

FLUE SPECIFICATION

HORIZONTAL CONCENTRIC BALANCED FLUE

ECOFORCE™ MODELS

EF80 (80/125 Flue System)

PART NO: EFHF002 - HORIZONTAL FLUE KIT

Maximum Equivalent Flue Length = 17 Metres

Deduct 1.0 metre for each 90° Bend

Deduct 0.5 metre for each 45° Bend

Each Horizontal Flue Kit Includes all items marked as Std Spec

Part No

Description

Std Spec

M84460

Elbow PP 80/125 90°

1

M86934

Wall Terminal 80/125

1

M84452

Extension – 80/125 x 1000mm

M84455

Extension – 80/125 x 500mm

M84461

Elbow PP 80/125 45°

M84481

Wall Clamp 125mm

M84472

Condensate Drain PP 80/125

6

FLUE SPECIFICATION

HORIZONTAL CONCENTRIC BALANCED FLUE

ECOFORCE™ MODELS

EF80 (100/150 Flue System)

PART NO: EFHF003 - HORIZONTAL FLUE KIT

Maximum Equivalent Flue Length = 53 Metres

Deduct 1.0 metre for each 90° Bend

Deduct 0.5 metre for each 45° Bend

Each Horizontal Flue Kit Includes all items marked as Std Spec

Part No

Description

Std Spec

M86996

Wall Terminal 100/150

1

M84475

Expander 80/125 – 100/150

1

M84412

Elbow PP 100/150 90°

1

M84402

Extension – 100/150 x 1000mm

M84405

Extension – 100/150 x 500mm

M84413

Elbow PP 100/150 45°

M84331

Wall Clamp 150mm

M84422

Condensate Drain PP 100/150

7

FLUE SPECIFICATION

HORIZONTAL CONCENTRIC BALANCED FLUE

ECOFORCE™ MODELS

EF100, EF120, (100/150 Flue System)

PART NO: EFHF004 - HORIZONTAL FLUE KIT

EF100 Maximum Equivalent Flue Length = 47 Metres

EF120 Maximum Equivalent Flue Length = 28 Metres

Deduct 1.0 metre for each 90° Bend

Deduct 0.5 metre for each 45° Bend

Each Horizontal Flue Kit Includes all items marked as Std Spec

Part No

Description

Std Spec

M86996

Wall Terminal 100/150

1

M84412

Elbow PP 100/150 90°

1

M84402

Extension – 100/150 x 1000mm

M84405

Extension – 100/150 x 500mm

M84413

Elbow PP 100/150 45°

M84331

Wall Clamp 150mm

M84422

Condensate Drain PP 100/150

8

FLUE SPECIFICATION

HORIZONTAL CONCENTRIC BALANCED FLUE

ECOFORCE™ MODELS

EF150, EF180 (100/150 Flue System)

PART NO: EFHF005 - HORIZONTAL FLUE KIT

EF150 Maximum Equivalent Flue Length = 20 Metres

EF180 Maximum Equivalent Flue Length = 13 Metres

Deduct 1.0 metre for each 90° Bend

Deduct 0.5 metre for each 45° Bend

Each Horizontal Flue Kit Includes all items marked as Std Spec

Part No

Description

Std Spec

E61-001-172

Concentric Conversion Kit

1

M86996

Wall Terminal 100/150

1

M84412

Elbow PP 100/150 90°

1

M84402

Extension – 100/150 x 1000mm

M84405

Extension – 100/150 x 500mm

M84413

Elbow PP 100/150 45°

M84331

Wall Clamp 150mm

M84422

Condensate Drain PP 100/150

9

FLUE SPECIFICATION

VERTICAL CONCENTRIC BALANCED FLUE

ECOFORCE™ MODELS

EF+35/150, EF+35/230, EF+55/230

PART NO: EFVF001 - VERTICAL FLUE KIT

EF+35/150 and EF+35/230 Maximum Equivalent Flue Length = 44 Metres

EF+55/230 Maximum Equivalent Flue Length = 21 Metres

Deduct 1.0 metre for each 90° Bend

Deduct 0.5 metre for each 45° Bend

Each Vertical Flue Kit Includes all items marked as Std Spec

Part No

Description

Std Spec

M86864

Roof Terminal 80/125

1

M84455

Extension – 80/125 x 500mm

2

M84452

Extension – 80/125 x 1000mm

M84460

Elbow PP 80/125 90°

M84461

Elbow PP 80/125 45°

M84481

Wall Clamp 125mm

M84472

Condensate Drain PP 80/125

M87376

80/125 Flat Roof Flashing

M87909

80/125 Universal Roof Tile

10

FLUE SPECIFICATION

VERTICAL CONCENTRIC BALANCED FLUE

ECOFORCE™ MODELS

EF80 (80/125 Flue System)

PART NO: EFVF002 - VERTICAL FLUE KIT

Maximum Equivalent Flue Length = 17 Metres

Deduct 1.0 metre for each 90° Bend

Deduct 0.5 metre for each 45° Bend

Each Vertical Flue Kit Includes all items marked as Std Spec

Part No

Description

Std Spec

M86864

Roof Terminal 80/125

1

M84455

Extension – 80/125 x 500mm

1

M84452

Extension – 80/125 x 1000mm

M84460

Elbow PP 80/125 90°

M84461

Elbow PP 80/125 45°

M84481

Wall Clamp 125mm

M84472

Condensate Drain PP 80/125

M87376

80/125 Flat Roof Flashing

M87909

80/125 Universal Roof Tile

11

FLUE SPECIFICATION

VERTICAL CONCENTRIC BALANCED FLUE

ECOFORCE™ MODELS

EF80 (100/150 Flue System)

PART NO: EFVF003 - VERTICAL FLUE KIT

Maximum Equivalent Flue Length = 53 Metres

Deduct 1.0 metre for each 90° Bend

Deduct 0.5 metre for each 45° Bend

Each Vertical Flue Kit Includes all items marked as Std Spec

Part No

Description

Std Spec

M84862

Roof Terminal 100/150

1

M84475

Expander 80/125 – 100/150

1

M84405

Extension – 100/150 x 500mm

1

M84402

Extension – 100/150 x 1000mm

M84412

Elbow PP 100/150 90°

M84413

Elbow PP 100/150 45°

M84331

Wall Clamp 150mm

M84422

Condensate Drain PP 100/150

M87376

80/125 Flat Roof Flashing

M87909

80/125 Universal Roof Tile

12

FLUE SPECIFICATION

VERTICAL CONCENTRIC BALANCED FLUE

ECOFORCE™ MODELS

EF100, EF120, (100/150 Flue System)

PART NO: EFVF004 - VERTICAL FLUE KIT

EF100 Maximum Equivalent Flue Length = 47 Metres

EF120 Maximum Equivalent Flue Length = 28 Metres

Deduct 1.0 metre for each 90° Bend

Deduct 0.5 metre for each 45° Bend

Each Vertical Flue Kit Includes all items marked as Std Spec

Part No

Description

Std Spec

M84862

Roof Terminal 100/150

1

M84405

Extension – 100/150 x 500mm

1

M84402

Extension – 100/150 x 1000mm

M84412

Elbow PP 100/150 90°

M84413

Elbow PP 100/150 45°

M84331

Wall Clamp 150mm

M84422

Condensate Drain PP 100/150

M87376

80/125 Flat Roof Flashing

M87909

80/125 Universal Roof Tile

13

FLUE SPECIFICATION

VERTICAL CONCENTRIC BALANCED FLUE

ECOFORCE™ MODELS

EF150, EF180, (100/150 Flue System)

PART NO: EFVF005 - VERTICAL FLUE KIT

EF100 Maximum Equivalent Flue Length = 20 Metres

EF120 Maximum Equivalent Flue Length = 13 Metres

Deduct 1.0 metre for each 90° Bend

Deduct 0.5 metre for each 45° Bend

Each Vertical Flue Kit Includes all items marked as Std Spec

Part No

Description

Std Spec

E61-001-172

Concentric Conversion Kit

1

M84862

Roof Terminal 100/150

1

M84405

Extension – 100/150 x 500mm

1

M84402

Extension – 100/150 x 1000mm

M84412

Elbow PP 100/150 90°

M84413

Elbow PP 100/150 45°

M84331

Wall Clamp 150mm

M84422

Condensate Drain PP 100/150

M87376

80/125 Flat Roof Flashing

M87909

80/125 Universal Roof Tile

14
