Engineering Data

6201

Petrarca Series 2 Wire Tone Ring Apartment Handset

The Elvox Model 6200 is a Petrarca Style apartment handset for

use with the 2 Wire (1+1) Tone Ring Audio entry systems. The 6200

can be use standalone as an audio only station or combined with a

6000 using a 6145 wall pate or 6142 desk kit for a complete audio-

video station.The 6201 provides full duplex conversation with the

calling entry panel, concierge call/door release control and signal to

activate the 6000 monitor when both are mounted together for

audio-video operation. Optional restricted lock feature allows only

the station in conversation with door to release lock.

General information Specifications

Architects and Engineers Specifications

Lee Dan Communications, Inc. www.leedan.com info@leedan.com 800-231-1414

Low Profile Design

Elegant Design

Duplex Voice Operation

Electret Microphone

Surface Wall Installation

Desk Mounted with Optional Kit

Clear Voice Fidelity

Rugged and Reliable

Pleasant Electronic Call Tone Signal

Modular design allows combination

with Petrarca monitors

Screw Terminal Connections

System: 2 (1+1) wire Tone Ring/Modular

Videointercom

Controls: Door Release

Optionally up to 8 additional buttons

Handset: Duplex Handset with electret Mic and

heavy duty coiled cord

Construction: Molded High Impact Plastic

Finish: Soft White/Anthracite Grey

Wiring Terminations: Screw Terminal

Dimensions: 3.5”w x 8.75”h x 3.5”d

Net Weight: 1 lb (.5 Kg)

The Residence Station shall be a Petrarca Handset Station. The Station shall provide a

private duplex conversation with the Entry Panel. Handset shall utilize an electret micro-

phone. Signal shall be a pleasant tone from a dedicated speaker. A handset utilizing the

earpiece for tone will not be accepted. The Residence Station shall have a pushbutton for

concierge call/remote activation of the door release. Optional restricted lock feature shall

allow only the station in conversation with door to release lock. Up to 8 additional

pushbuttons or other accessories shall be available. The residence station shall be wall

mounted, desk mounted with a special desk kit or combined with a 6000 Galileo Video

Monitor on a 6145 wall plate or 6142 Video Desk Kit.

6201

Petrarca Series 2 Wire Tone

Ring Apartment Handset

© copyright Paso Sound Products, Inc. 2003 Specifications are subject to change without notice
