Ettus E3XX Getting Started Guide

Version 1.4

Figure 1: Top View (E310)

Ettus E3XX Getting Started Guide ANGRYVIPER Team

Revision History

Revision Description of Change Date

v1.3.1-E3XX Initial Release 3/2018

v1.4 Updated for Release 9/2018

Ettus E3XX Getting Started Guide ANGRYVIPER Team

Table of Contents

1 References 4

2 Overview 5

3 Prerequisites 5

3.1 Installation of provided projects: core,assets and bsp_e310 ........................ 5

3.2 Vendor Software Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

3.3 Building Required Projects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

3.4 Hardware Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

4 SD Card Setup 8

4.1 Make a backup image of factory SD card (assumes Linux host) . . . . . . . . . . . . . . . . . . . . . . 8

4.2 Format the SD card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

4.3 Copy OpenCPI ﬁles to SD card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

4.3.1 Copy Standalone Mode speciﬁc ﬁles to SD card . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

4.3.2 Copy Network Mode speciﬁc ﬁles to SD card . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

4.3.3 SD Card Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

5 Script Setup 9

5.1 Setting up the Network and Standalone Mode scripts . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

5.1.1 Network Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

5.1.2 Standalone Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

5.2 Setup system time reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

6 Development Host Setup - Network Mode ONLY 11

6.1 Network Mounting Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

6.1.1 CentOS 6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

6.1.2 CentOS 7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

7 Conﬁguring the runtime environment on the platform 13

7.1 Network Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

7.2 Standalone Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

8 Build an application 15

9 Run an Application 15

9.1 Network Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

9.2 Run an Application in Standalone Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

10 Running Reference Applications 18

Appendices 19

A Generating Boot Artifacts 19

A.1 BOOT.bin and u-boot.img . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

A.2 devicetree.dtb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

A.3 uImage and uramdisk.image.gz . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

B Copying only required ﬁles to SD card 20

B.1 Copy embedded OS and boot ﬁles to SD card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

B.2 Files needed for Standalone Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

B.3 Files needed for Network Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Ettus E3XX Getting Started Guide ANGRYVIPER Team

1 References

This document assumes a basic understanding of the Linux command line (or “shell”) environment. The reference(s)

in Table 1 can be used as an overview of OpenCPI and may prove useful.

Title Published By Link

Getting Started ANGRYVIPER Team Getting_Started.pdf

Installation Guide ANGRYVIPER Team RPM_Installation_Guide.pdf

Acronyms and Deﬁnitions ANGRYVIPER Team Acronyms_and_Definitions.pdf

Overview OpenCPI http://opencpi.github.io/

Overview.pdf

Table 1: References

Ettus E3XX Getting Started Guide ANGRYVIPER Team

2 Overview

This document provides steps for conﬁguring a factory provided Ettus USRP E310 with the OpenCPI runtime

environment for executing applications, conﬁguring a development system to build OpenCPI bitstreams targeting

the e3xx platform, and examples of executing applications on the OpenCPI conﬁgured E310.

3 Prerequisites

This guide assumes that, at a minimum, the following RPMs are installed:

RPM Name Description

All prerequisite RPMs These packages have OpenCPI-speciﬁc patches and are provided

as RPMs. This packaging ensures they will not conﬂict with

other installed copies by using a nonstandard installation loca-

tion of /opt/opencpi/prerequisites.

angryviper-ide-*.x86 64.rpm The ANGRYVIPER IDE (Eclipse with plugins). See RPM

Installation Guide.pdf, Appendix D for an alternative method

to set up the IDE using an existing Eclipse installation.

opencpi-*.x86_64.rpm Base installation RPM includes the runtime portion of the

Component Development Kit (CDK) and the source for the

ocpi.core and ocpi.assets Projects containing framework essen-

tial components, workers, platforms, etc.

opencpi-devel-*.x86_64.rpm Additional header ﬁles and scripts for developing new assets as

HDL and/or RCC.

opencpi-sw-platform-xilinx13_4-*.noarch.rpm Additional ﬁles necessary to build the framework targeting spe-

ciﬁc RCC/software platforms, independent of the ﬁnal deployed

hardware.

opencpi-hw-platform-e3xx-*.noarch.rpm Additional ﬁles necessary to build the framework targeting spe-

ciﬁc hard-ware platform "X" when running RCC platform "Y"

("Y" can be "no sw"). This RPM also includes hardware-speciﬁc

SD Card images when applicable.

3.1 Installation of provided projects: core,assets and bsp_e310

This guide assumes the user has executed ocpi-copy-projects, accepting the default settings, to copy and register the

core,assets, and bsp_e310 projects from the /opt/opencpi/projects for building bitstreams for the E310. Reference

the Getting Started Guide for details on ocpi-copy-projects. Although the projects are registered by

ocpi-copy-projects, changes to the registry can be made via ocpidev un/register project or the ANGRYVIPER

GUI.

$ ocpi-copy-projects

...

$ ls ~/ocpi_projects

assets bsp_e310 core

$ ocpidev show registry

Project registry is located at: /opt/opencpi/cdk/../project-registry

----------------------------------------------------------------------------------------

| Project Package-ID | Path to Project | Valid/Exists |

| ------------------ | --------------- | ------------ |

| ocpi.core | /home/<user>/ocpi_projects/core | True |

| ocpi.assets | /home/<user>/ocpi_projects/assets | True |

| ocpi.bsp.e310 | /home/<user>/ocpi_projects/bsp_e310 | True |

----------------------------------------------------------------------------------------

Ettus E3XX Getting Started Guide ANGRYVIPER Team

3.2 Vendor Software Setup

The platform that is expected to be used is the Ettus Research/National Instruments Universal Software Radio

Peripheral (USRP) E310 (or E3XX) SDR (e.g. e3xx). This OpenCPI-enabled platform provides the capability of

deploying hardware and software workers while using Xilinx’s 13.4 distribution of Linux.

The synthesizers and cross-compilers required to build HDL and RCC Workers for this Platform are installed by

following the instructions found in the OpenCPI FPGA Vendor Tools Installation Guide. This document assumes

that the user has installed the appropriate versions of Vivado and the Xilinx SDK.

3.3 Building Required Projects

The core,assets, and bsp_e310 projects must be built in a speciﬁc order for this platform. This section outlines

how to build the relevant projects and provides the commands to do so.

For this document, the projects should be built as follows:

1. Build core for the xilinx13_4 RCC Platform and the e3xx HDL Platform, but omit assemblies

2. Build assets for the xilinx13_4 RCC Platform and the e3xx HDL Platform, but omit assemblies

3. Build the bsp_e310 project for these same platforms

4. Build the testbias assembly from the assets project. This will be used later in this guide.

Once the HDL Platform is built in the BSP project, assemblies can be built for that HDL platform

$ cd /home/<user>/ocpi_projects/ && \

$ ocpidev build -d core --rcc-platform xilinx13_4 --hdl-platform e3xx --no-assemblies && \

$ ocpidev build -d assets --rcc-platform xilinx13_4 --hdl-platform e3xx --no-assemblies && \

$ ocpidev build -d bsp_e310 --rcc-platform xilinx13_4 --hdl-platform e3xx && \

$ ocpidev build -d assets hdl assembly testbias --hdl-platform e3xx;

Note: replace “<user>” with your username in the commands above.

Each of these build commands can also be performed via the ANGRYVIPER IDE as follows:

To perform this operation within the IDE:

1. Open the ANGRYVIPER Perspective

2. Select the asset from OpenCPI Project View

3. Import to AV Operations Panel using “>” button

4. Select the RCC and/or HDL platforms for the build (use Ctrl for multiple selection)

5. Click “Build”

See the ANGRYVIPER Team’s Getting Started Guide for additional information concerning the use of ocpidev

and the ANGRYVIPER IDE to build OpenCPI assets.

3.4 Hardware Setup

•Ettus USRP E3XX

It is expected that this SDR package includes a power supply, micro-USB to USB cable and standard SD card

(4GB or larger).

OpenCPI has been tested on the Ettus USRP E310.

The micro-USB serial port located on the back E310 labeled CONSOLE (Figure 2) can be used to access the

serial connection with the processor.

Ettus E3XX Getting Started Guide ANGRYVIPER Team

Figure 2: Back Panel

•Ethernet cable: An Ethernet port is available on the E310 (Figure 2) and is required when the Network

mode (discussed later) environment is used. The OpenCPI BSP for the E310 is conﬁgured for DHCP.

Figure 3: Front Panel

•Access to a network which supports DHCP. (Network Mode)

•SD card: As mentioned earlier, a 4GB or larger SD card should come with the SDR. The bootable SD card

slot is located on the front of the unit (Figure 3) and ejects by gently pushing it in and releasing.

•SD card reader

•Further information on front panel: Also found on the front panel of the SDR are six labeled SMB (50

Ohm) connectors: TRX-A, RX2-A, RX2-B, TRX-B, GPS, and SYNC (Figure 3). The upper connections are

Ettus E3XX Getting Started Guide ANGRYVIPER Team

split into two individual channels referred to as “Front End A” and “Front End B.” Speciﬁc details can be

found in the vendor manuals.

4 SD Card Setup

4.1 Make a backup image of factory SD card (assumes Linux host)

This section provides the steps for creating an SD card backup image. The subsequent subsections assume the SD

card is empty.

•Determine the device ﬁle name for the SD card by executing dmesg command below. It will likely be something

like /dev/sdb or /dev/mmcblk0.

$ dmesg | tail -n 15

•Run the following dd command to make a backup image, where DEVICENAME was determined above. This

step should take ∼15 minutes depending on the card size.

$ dd if=DEVICENAME of=backup.image

To restore the card back to the original contents, run the command “dd of=DEVICENAME if=backup.image” (Do

not do this step unless you want the original contents back on the SD card.)

4.2 Format the SD card

•Format the SD card with a single FAT32 partition.

4.3 Copy OpenCPI ﬁles to SD card

This section provides the simplest instructions for copying ﬁles over to the SD card. Appendix B contains more

involved instructions for copying only the necessary ﬁles to the SD card for each mode.

WARNING: The user must ensure that the contents of the SD, match the version of the OpenCPI release that the

artifacts were built against.

When using the factory SD card, all ﬁles can be ignored or deleted. Any ﬁles/directories copied to SD card will

appear at /mnt/card on the E310.

Copy the following directory onto the SD card:

$ cp -r /opt/opencpi/cdk/e3xx/sdcard-xilinx13_4/* /run/media/<user>/<partition>/

4.3.1 Copy Standalone Mode speciﬁc ﬁles to SD card

Copy the testbias bitstream into the artifacts directory:

$ cp /home/ocpi_projects/assets/hdl/assemblies/testbias/container-testbias_e3xx/\

target-zynq/testbias_e3xx_base.bit.gz /run/media/<user>/<partition>/opencpi/xilinx13_4/artifacts

4.3.2 Copy Network Mode speciﬁc ﬁles to SD card

No additional ﬁles required for Network Mode.

4.3.3 SD Card Source

The ﬁnal SD Card artifacts are distributed in /opt/opencpi/cdk/e3xx/ via RPM as noted previously. The end user

is not required nor expected to generate the ﬁles, but the process is documented below in Appendix A.

Ettus E3XX Getting Started Guide ANGRYVIPER Team

5 Script Setup

There are two type of setups or modes for running applications on any embedded radio: Network and Standalone.

In Network mode, a development system hosts the OpenCPI tree as an NFS server to the E310 which is an NFS

client. This conﬁguration provides quick and dynamic access to all of OpenCPI, and presumably any applications,

components and bitstreams. In Standalone mode, all the artifacts are located on the SDR’s local storage (e.g. SD

card) and no network connection is required. This may be more suited for deployment scenarios in which network

connection is not possible or practical. Network mode is generally preferred during the development process.

For both Network and Standalone mode, the following step is necessary:

1) Enter the mounted SD card’s opencpi directory

$ cd /run/media/<user>/<partition>/opencpi/

5.1 Setting up the Network and Standalone Mode scripts

For each mode, a startup script is used to conﬁgure the environment of the embedded system. The OpenCPI

framework provides a default script for each mode. The default scripts are to be copied, modiﬁed per the user’s

requirements.

5.1.1 Network Mode

1) Make a copy of the default script for editing

$ cp /run/media/<user>/<partition>/opencpi/default_mynetsetup.sh \

/run/media/<user>/<partition>/opencpi/mynetsetup.sh

2) Edit the copy

1. In mynetsetup.sh, uncomment the following lines which are necessary for mounting core,assets, and bsp_

e310 projects:

mkdir -p /mnt/ocpi_core

mount -t nfs -o udp,nolock,soft,intr $1:/home/<user>/ocpi_projects/core /mnt/ocpi_core

mkdir -p /mnt/ocpi_assets

mount -t nfs -o udp,nolock,soft,intr $1:/home/<user>/ocpi_projects/assets /mnt/ocpi_assets

mkdir -p /mnt/bsp_e310

mount -t nfs -o udp,nolock,soft,intr $1:/home/<user>/ocpi_projects/assets /mnt/bsp_e310

2. Edit /home/<user>/ocpi_projects/core and /home/<user>/ocpi_projects/assets to reﬂect the paths to

the core,assets, and bsp_e310 projects on the host, for example:

mkdir -p /mnt/ocpi_core

mount -t nfs -o udp,nolock,soft,intr $1:/home/johndoe/ocpi_projects/core /mnt/ocpi_core

mkdir -p /mnt/ocpi_assets

mount -t nfs -o udp,nolock,soft,intr $1:/home/johndoe/ocpi_projects/assets /mnt/ocpi_assets

mkdir -p /mnt/bsp_e310

mount -t nfs -o udp,nolock,soft,intr $1:/home/johndoe/ocpi_projects/assets /mnt/bsp_e310

5.1.2 Standalone Mode

In this mode, all OpenCPI artifacts that are required to run any application on the E310 must be copied onto the

SD card. Building the provided projects to obtain such artifacts is discussed in Section 3.3. Once the artifacts have

been created, they must be copied to the SD card in Section 4. In general, any required .so (RCC workers),

.bit.gz (hdl assemblies), and application XMLs or executables must be copied to the SD card.

1) Make a copy of the default script for editing

Ettus E3XX Getting Started Guide ANGRYVIPER Team

$ cp /run/media/<user>/<partition>/opencpi/default_mysetup.sh \

/run/media/<user>/<partition>/opencpi/mysetup.sh

2) Edit the copy

Unlike Network mode, there is no required modiﬁcations to this script.

3) Copy any additional artifacts to SD card’s opencpi/artifacts/ directory

5.2 Setup system time reference

If Linux system time is not required to be accurate, this step may be skipped.

For either Network or Standalone mode, the following settings that are passed by mynetsetup.sh/mysetup.sh to

the zynq_net_setup.sh/zynq_setup.sh scripts may require modiﬁcation:

•Identify the system that is to be used as a time server, where the default is “time.nist.gov”. A valid time

server must support RFC-868.

•Identify the current timezone description, where the default is “EST5EDT,M3.2.0,M11.1.0”. Change this if

required for the local timezone. See man tzset on the host PC for more information.

•If a time server is not required, or cannot connect to a time server, the user is required to manually set the

time at start up. Use the date command to manually set the Linux system time. See man date on the host

PC for more information.

Ettus E3XX Getting Started Guide ANGRYVIPER Team

6 Development Host Setup - Network Mode ONLY

6.1 Network Mounting Mode

The NFS server needs to be enabled on the host in order to run the SDR in Network Mode. The following sections

are directions on how to do this for both CentOS 6 and CentOS 7 host operating systems.

6.1.1 CentOS 6

From the host, install the necessary tools using yum:

% sudo yum install nfs-utils nfs-utils-lib

% sudo chkconfig nfs on

% sudo service rpcbind start

% sudo service nfs start

From the host, add the following lines to the bottom of /etc/exports and change “XX.XX.XX.XX/MM” to a valid

netmask for the DHCP range that the SDR will be set to for your network (e.g. 192.168.0.0/16).

% sudo vi /etc/exports

/opt/opencpi XX.XX.XX.XX/MM(rw,sync,no_root_squash,no_subtree_check)

<host core project location> XX.XX.XX.XX/MM(rw,sync,no_root_squash,no_subtree_check)

<host assets project location> XX.XX.XX.XX/MM(rw,sync,no_root_squash,no_subtree_check)

% sudo exportfs -av

From the host, restart the services that have modiﬁed for the changes to take eﬀect:

% sudo service nfs start

6.1.2 CentOS 7

From the host, install the necessary tools using yum:

% sudo yum install nfs-utils 1

From the host, allow NFS past SELinux2:

% sudo setsebool -P nfs_export_all_rw 1

% sudo setsebool -P use_nfs_home_dirs 1

From the host, allow NFS past the ﬁrewall:

% sudo firewall-cmd --permanent --zone=public --add-service=nfs

% sudo firewall-cmd --permanent --zone=public --add-port=2049/udp

% sudo firewall-cmd --permanent --zone=public --add-service=mountd

% sudo firewall-cmd --permanent --zone=public --add-service=rpc-bind

% sudo firewall-cmd --reload

Deﬁne the export by creating a new ﬁle that has the extension “exports”. If it does not have that extension, it

will be ignored. Add the following lines to that ﬁle and replace “XX.XX.XX.XX/MM” with a valid netmask for the

DHCP range that the SDR will be set to for your network (e.g. 192.168.0.0/16).

% sudo vi /etc/exports.d/user_ocpi.exports

/opt/opencpi XX.XX.XX.XX/MM(rw,sync,no_root_squash,crossmnt)

/home/user/ocpi_projects/core XX.XX.XX.XX/MM(rw,sync,no_root_squash,crossmnt)

/home/user/ocpi_projects/assets XX.XX.XX.XX/MM(rw,sync,no_root_squash,crossmnt)

1nfs-utils-lib was rolled into nfs-utils starting with CentOS 7.2, if using eariler versions of CentOS 7, nfs-utils-lib will need

to be explicitly installed

2You can use getsebool to see if these values are already set before attempting to set them. Some security tools may interpret the

change attempt as a system attack.

Ettus E3XX Getting Started Guide ANGRYVIPER Team

If the ﬁle system that you are mounting is XFS, then each mount needs to have a unique fsid deﬁned. Instead, use:

% sudo vi /etc/exports.d/user_ocpi.exports

/opt/opencpi XX.XX.XX.XX/MM(rw,sync,no_root_squash,crossmnt,fsid=33)

/home/user/ocpi_projects/core XX.XX.XX.XX/MM(rw,sync,no_root_squash,crossmnt,fsid=34)

/home/user/ocpi_projects/assets XX.XX.XX.XX/MM(rw,sync,no_root_squash,crossmnt,fsid=35)

Restart the services that have modiﬁed for the changes to take eﬀect:

% sudo systemctl enable rpcbind

% sudo systemctl enable nfs-server

% sudo systemctl enable nfs-lock

% sudo systemctl enable nfs-idmap

% sudo systemctl restart rpcbind

% sudo systemctl restart nfs-server

% sudo systemctl restart nfs-lock

% sudo systemctl restart nfs-idmap

* Note: Some of the “enable” commands may fail based on your package selection, but should not cause any problems.

NOTE: You will need to add the ocpi.bsp.e310 project to your list of exports (in /etc/exports.d/user_ocpi.

exports).

Ettus E3XX Getting Started Guide ANGRYVIPER Team

7 Conﬁguring the runtime environment on the platform

7.1 Network Mode

1. Plug in an Ethernet cable to a network conﬁgured for DHCP

2. Ensure a micro-USB to USB cable is connected between the E310’s serial port and development host

3. Apply power to the E310

4. Use a serial terminal application to establish a serial connection, for example:

$ sudo screen /dev/ttyUSB0 115200

5. After a successful boot to PetaLinux, login to the system, using “root” for user name and password

6. Setup the OpenCPI environment on remote system

Each time the SDR is booted, the OpenCPI environment must be setup. By sourcing the mynetsetup.sh

script, the remote system’s environment is conﬁgured for OpenCPI and NFS directories are mounted for

Network mode.3. The user must provide the network address of the development system to the script as its

only argument:

$ . /mnt/card/opencpi/mynetsetup.sh XX.XX.XX.XX

where XX.XX.XX.XX is the IP address of the NFS host (i.e. that development host, e.g. 192.168.1.10). A

successful run should output the following:

An IP address was detected.

Setting the time from time server: time.nist.gov

My IP address is: XX.XX.XX.XX, and my hostname is: zynq

Running login script. OCPI_CDK_DIR is now /mnt/net/cdk.

Executing /home/root/.profile

No reserved DMA memory found on the linux boot command line.

The mdev config has no OpenCPI rules. We will add them to /etc/mdev.conf

NET: Registered protocol family 12

Driver loaded successfully.

OpenCPI ready for zynq.

Discovering available containers...

Available containers:

# Model Platform OS OS-Version Arch Name

0 hdl e3xx PL:0

1 rcc xilinx13_4 linux x13_4 arm rcc0

Note: If the output includes “rdate: bad address ‘time.nist.gov’”, comment out the rdate command in

zynq_net_setup.sh, reboot the radio, and start back at step 1 of this section.

3This script calls the zynq_net_setup.sh script, which should not be modiﬁable by the user.

Ettus E3XX Getting Started Guide ANGRYVIPER Team

7.2 Standalone Mode

1. (Not required for OpenCPI in this mode) Plug in an Ethernet cable to a network conﬁgured for DHCP

2. Ensure a micro-USB to USB cable is connected between the E310’s serial port and development host

3. Apply power to the E310

4. Use a serial terminal application to establish a serial connection, for example:

$ sudo screen /dev/ttyUSB0 115200

5. After a successful boot to PetaLinux, login to the system, using “root” for user name and password

6. WARNING: Applications (including XML-only ones) fail if there is not an IP address assigned to the platform,

even when in “standalone mode.” When the Ethernet port is not connected to a network conﬁgured with

DHCP, a temporary IP address must be set:

$ ifconfig eth0 192.168.244.244

7. Setup the OpenCPI environment on remote system

Each time the SDR is booted, the OpenCPI environment must be setup. By sourcing the mysetup.sh script,

the remote system’s environment is conﬁgured for OpenCPI 4. There are no arguments for this script.

$ . /mnt/card/opencpi/mysetup.sh

A successful run should output the following:

Attempting to set the time from time server: time.nist.gov

Setting the time from time server: time.nist.gov

Running login script. OCPI_CDK_DIR is now /mnt/card/opencpi.

Executing /home/root/.profile

No reserved DMA memory found on the linux boot command line.

The mdev config has no OpenCPI rules. We will add them to /etc/mdev.conf

NET: Registered protocol family 12

Driver loaded successfully.

OpenCPI ready for zynq.

Discovering available containers...

Available containers:

# Model Platform OS OS-Version Arch Name

0 hdl e3xx PL:0

1 rcc xilinx13_4 linux x13_4 arm rcc0

Note: If the output includes “rdate: bad address ‘time.nist.gov’”, comment out the rdate command in

zynq_setup.sh, reboot the radio, and start back at step 1 of this section.

4This script calls the zynq_setup.sh script, which should not be modiﬁable by the user.

Ettus E3XX Getting Started Guide ANGRYVIPER Team

8 Build an application

The setup of the platform can be veriﬁed by running an application that uses both RCC and HDL workers. A

simple application that requires two RCC and one HDL worker is located in assets/applications/bias.xml, but

only the RCC artifacts are provided with the installation of RPMs, and are availble on the SD card (Standard

Mode) or mounted CDK directory (Network Mode). The remaining task is to build an assembly, or bitstream for

loading the FPGA, which contains the HDL worker.

9 Run an Application

9.1 Network Mode

The default setup script sets the OCPI_LIBRARY_PATH variable to include the RCC workers that are required to

execute the application, but it must be updated to include to the assembly bitstream that was built. After running

the mynetsetup.sh script, navigate to /mnt/ocpi_assets/applications, then update the OCPI_LIBRARY_PATH

variable using the following command:

$ export OCPI_LIBRARY_PATH=/mnt/ocpi_assets/artifacts:/mnt/ocpi_core/artifacts

Run the application using the following command:

$ ocpirun -v -t 1 -d -m bias=hdl bias.xml

The output should be similar to:

Available containers are: 0: PL:0 [model: hdl os: platform: e3xx], 1: rcc0 [model: rcc os: linux

֒→platform: xilinx13_4]

Actual deployment is:

Instance 0 file_read (spec ocpi.core.file_read) on rcc container 1: rcc0, using file_read in /

֒→mnt/ocpi_core/artifacts/ocpi.core.file_read.rcc.0.xilinx13_4.so dated Fri Sep 28

֒→18:18:26 2018

Instance 1 bias (spec ocpi.core.bias) on hdl container 0: PL:0, using bias_vhdl/a/bias_vhdl in

֒→/mnt/ocpi_assets/artifacts/ocpi.assets.testbias_e3xx_base.hdl.0.e3xx.gz dated Tue Oct

֒→2 11:59:53 2018

Instance 2 file_write (spec ocpi.core.file_write) on rcc container 1: rcc0, using file_write

֒→in /mnt/ocpi_core/artifacts/ocpi.core.file_write.rcc.0.xilinx13_4.so dated Fri Sep 28

֒→18:18:31 2018

Application XML parsed and deployments (containers and artifacts) chosen

Application established: containers, workers, connections all created

Communication with the application established

Dump of all initial property values:

Property 0: file_read.fileName = "test.input" (cached)

Property 1: file_read.messagesInFile = "false" (cached)

Property 2: file_read.opcode = "0" (cached)

Property 3: file_read.messageSize = "16"

Property 4: file_read.granularity = "4" (cached)

Property 5: file_read.repeat = "<unreadable>"

Property 6: file_read.bytesRead = "0"

Property 7: file_read.messagesWritten = "0"

Property 8: file_read.suppressEOF = "false"

Property 9: file_read.badMessage = "false"

Property 10: file_read.ocpi_debug = "false" (parameter)

Property 11: file_read.ocpi_endian = "little" (parameter)

Property 12: bias.biasValue = "16909060" (cached)

Property 13: bias.ocpi_debug = "false" (parameter)

Property 14: bias.ocpi_endian = "little" (parameter)

Property 15: bias.test64 = "0"

Property 16: file_write.fileName = "test.output" (cached)

Property 17: file_write.messagesInFile = "false" (cached)

Ettus E3XX Getting Started Guide ANGRYVIPER Team

Property 18: file_write.bytesWritten = "0"

Property 19: file_write.messagesWritten = "0"

Property 20: file_write.stopOnEOF = "true" (cached)

Property 21: file_write.ocpi_debug = "false" (parameter)

Property 22: file_write.ocpi_endian = "little" (parameter)

Application started/running

Waiting up to 1 seconds for application to finish

Application finished

Dump of all final property values:

Property 3: file_read.messageSize = "16"

Property 5: file_read.repeat = "<unreadable>"

Property 6: file_read.bytesRead = "4000"

Property 7: file_read.messagesWritten = "251"

Property 8: file_read.suppressEOF = "false"

Property 9: file_read.badMessage = "false"

Property 15: bias.test64 = "0"

Property 18: file_write.bytesWritten = "4000"

Property 19: file_write.messagesWritten = "250"

Run the following command to view the input:

$ hexdump test.input | less

The output should look like the following:

0000000 0000 0000 0001 0000 0002 0000 0003 0000

0000010 0004 0000 0005 0000 0006 0000 0007 0000

0000020 0008 0000 0009 0000 000a 0000 000b 0000

0000030 000c 0000 000d 0000 000e 0000 000f 0000

0000040 0010 0000 0011 0000 0012 0000 0013 0000

0000050 0014 0000 0015 0000 0016 0000 0017 0000

0000060 0018 0000 0019 0000 001a 0000 001b 0000

0000070 001c 0000 001d 0000 001e 0000 001f 0000

0000080 0020 0000 0021 0000 0022 0000 0023 0000

0000090 0024 0000 0025 0000 0026 0000 0027 0000

00000a0 0028 0000 0029 0000 002a 0000 002b 0000

00000b0 002c 0000 002d 0000 002e 0000 002f 0000

00000c0 0030 0000 0031 0000 0032 0000 0033 0000

00000d0 0034 0000 0035 0000 0036 0000 0037 0000

00000e0 0038 0000 0039 0000 003a 0000 003b 0000

00000f0 003c 0000 003d 0000 003e 0000 003f 0000

0000100 0040 0000 0041 0000 0042 0000 0043 0000

0000110 0044 0000 0045 0000 0046 0000 0047 0000

0000120 0048 0000 0049 0000 004a 0000 004b 0000

0000130 004c 0000 004d 0000 004e 0000 004f 0000

0000140 0050 0000 0051 0000 0052 0000 0053 0000

0000150 0054 0000 0055 0000 0056 0000 0057 0000

0000160 0058 0000 0059 0000 005a 0000 005b 0000

Run the following command to view the output:

$ hexdump test.output | less

The output should look like the following:

0000000 0304 0102 0305 0102 0306 0102 0307 0102

0000010 0308 0102 0309 0102 030a 0102 030b 0102

0000020 030c 0102 030d 0102 030e 0102 030f 0102

0000030 0310 0102 0311 0102 0312 0102 0313 0102

Ettus E3XX Getting Started Guide ANGRYVIPER Team

0000040 0314 0102 0315 0102 0316 0102 0317 0102

0000050 0318 0102 0319 0102 031a 0102 031b 0102

0000060 031c 0102 031d 0102 031e 0102 031f 0102

0000070 0320 0102 0321 0102 0322 0102 0323 0102

0000080 0324 0102 0325 0102 0326 0102 0327 0102

0000090 0328 0102 0329 0102 032a 0102 032b 0102

00000a0 032c 0102 032d 0102 032e 0102 032f 0102

00000b0 0330 0102 0331 0102 0332 0102 0333 0102

00000c0 0334 0102 0335 0102 0336 0102 0337 0102

00000d0 0338 0102 0339 0102 033a 0102 033b 0102

00000e0 033c 0102 033d 0102 033e 0102 033f 0102

00000f0 0340 0102 0341 0102 0342 0102 0343 0102

0000100 0344 0102 0345 0102 0346 0102 0347 0102

0000110 0348 0102 0349 0102 034a 0102 034b 0102

0000120 034c 0102 034d 0102 034e 0102 034f 0102

0000130 0350 0102 0351 0102 0352 0102 0353 0102

0000140 0354 0102 0355 0102 0356 0102 0357 0102

0000150 0358 0102 0359 0102 035a 0102 035b 0102

0000160 035c 0102 035d 0102 035e 0102 035f 0102

Ettus E3XX Getting Started Guide ANGRYVIPER Team

9.2 Run an Application in Standalone Mode

The default setup script sets the OCPI_LIBRARY_PATH variable to include the all of the artifacts that are required to

execute the application. Speciﬁcally, all three of the artifacts that are located on the SD card are mounted at

/mnt/card/opencpi/xilinx13_4/artifacts. After running mysetup.sh, navigate to /mnt/card/opencpi/xml.

Run the application using the following command:

$ ocpirun -v -t 1 -d -m bias=hdl bias.xml

The output should be similar to the output shown in Section 9.1.

Run the following commands to view the input and output, and reference Section 9.1 for the expected results:

$ hexdump test.input | less

$ hexdump test.output | less

10 Running Reference Applications

Now that you have set up OpenCPI and the E310 radio, you can run one of the reference applications. Navigate to

bsp_e310/applications/FSK or bsp_e310/applications/rx_app and follow the instructions in the corresponding

documents (FSK_App_Getting_Started_Guide_E3XX.pdf and FSK_app_e3xx.pdf, or RX_app_e3xx.pdf ).

Ettus E3XX Getting Started Guide ANGRYVIPER Team

Appendices

A Generating Boot Artifacts

In normal use cases, the SD card should be createdable and usable via the simple steps in Section 4. This section

outlines the steps required to regenerate the artifacts used in previous sections for solely informational purposes and

is not expected for users to have to complete these steps.

A.1 BOOT.bin and u-boot.img

The original ﬁrst and second stage bootloader artifacts that come installed on the E310 SD card are not suitable

for the Petalinux build OpenCPI uses for its software platform as those artifacts are expecting a uImage kernel with

a separate ﬁlesystem partition, while the Petalinux build uses a separate ramdisk image ﬁle. The BOOT.bin and

u-boot.img ﬁles were rebuilt in order to support booting into this style of Linux images from Ettus’s and Xilinx’s

repositories. In summary, the repositories were cloned and checked out to the proper branch, according to the release

for the e310 and the bitbake recipe, and subsequently cross-compiled for ARM using the Xilinx toolchain. The steps

are shown below.

$ git clone https://github.com/EttusResearch/meta-ettus.git

$ cd meta-ettus && git checkout e300-daisy && cd ..

$ git clone https://github.com/Xilinx/u-boot-xlnx.git

$ cd u-boot-xlnx && git checkout 664820b231b129552e963e1a96b45ac7196ccc81 && cd ..

$ cp meta-ettus/e300-bsp/recipes-bsp/u-boot/ettus-e300/* u-boot-xlnx/

$ cd u-boot-xlnx

$ mv ps7_init.{c,h} board/xilinx/zynq/

$ git apply 0001-E300-Uses-UART0-for-console.patch

$ git apply 0002-E300-Disable-QSPI.patch

$ git apply 0003-Read-mac-address-from-i2c-EEPROM.patch

$ git apply 0001-e300-Added-memory-test.patch

$ source {xilinx-install-dir}/Xilinx/SDK/2013.4/settings64.sh

$ make zynq_zc70x_config CROSS_COMPILE=arm-xilinx-linux-gnueabi-

$ make CROSS_COMPILE=arm-xilinx-linux-gnueabi-

A.2 devicetree.dtb

The device tree needed to be modiﬁed in order to register the hardware devices with the correct hardware device

driver in the Petalinux kernel. In summary, the device tree provided by Ettus was decompiled to a device tree source

(dts) ﬁle using the device tree compiler (dtc), modiﬁed the text ﬁle by adding the proper "compatible" strings to

the devices, and subsequently compiled back into a device tree blob (dtb). The steps shown below assume dtc is in

your $PATH and the original device tree blob is in the current working directory.

$ dtc -I dtb -O dts -o devicetree.dts uImage-zynq-e31x-3.dtb

$ vim devicetree.dts

$ dtc -I dts -O dtb -o devicetree.dtb devicetree.dts

Note: The full source for the modiﬁed devicetree.dts can be found at <BSPproject>/hdl/platforms/e3xx/sd_

card_source/devicetree.dts

A.3 uImage and uramdisk.image.gz

The uImage and uramdisk.image.gz image ﬁles come directly from the default 13_4 OpenCPI software platform.

The 13_3 software platform could not be used due to the SD card driver in 13_3 not supporting the E310’s SD card

device.

Ettus E3XX Getting Started Guide ANGRYVIPER Team

B Copying only required ﬁles to SD card

B.1 Copy embedded OS and boot ﬁles to SD card

Copy the following ﬁles/directories onto the SD card:

$ cp /opt/opencpi/cdk/e3xx/sdcard-xilinx13_4/boot.bin /run/media/<user>/<partition>/

$ cp /opt/opencpi/cdk/e3xx/sdcard-xilinx13_4/devicetree.dtb /run/media/<user>/<partition>/

$ cp /opt/opencpi/cdk/e3xx/sdcard-xilinx13_4/u-boot.img /run/media/<user>/<partition>/

$ cp /opt/opencpi/cdk/e3xx/sdcard-xilinx13_4/uImage /run/media/<user>/<partition>/

$ cp /opt/opencpi/cdk/e3xx/sdcard-xilinx13_4/uramdisk.image.gz /run/media/<user>/<partition>/

B.2 Files needed for Standalone Mode

After performing the steps from B.1, copy the entire opencpi directory to the SD card, then copy the relevant

bitstreams, artifacts into the artifacts directory and application XMLs into the applications directory. For this

getting started guide, only one bitstream is required to be copied onto the SD cards, where as the required artifacts

and application XML where copied to the SD along with the entire opencpi directory.

$ cp -r /opt/opencpi/cdk/e3xx/sdcard-xilinx13_4/opencpi /run/media/<user>/<partition>/

$ cp /home/<user>/ocpi_projects/assets/hdl/assemblies/testbias/container-testbias_e3xx_base/\

target-zynq/testbias_e3xx_base.bit.gz /run/media/<user>/<partition>/opencpi/xilinx13_4/artifacts

B.3 Files needed for Network Mode

After performing the steps from B.1, create a directory on the partition named "opencpi" and copy the following

ﬁles into the this directory:

$ mkdir /run/media/<user>/<partition>/opencpi

$ cp /opt/opencpi/cdk/e3xx/sdcard-xilinx13_4/opencpi/default_mynetsetup.sh \

/run/media/<user>/<partition>/opencpi/

$ cp /opt/opencpi/cdk/e3xx/sdcard-xilinx13_4/opencpi/zynq_net_setup.sh \

/run/media/<user>/<partition>/opencpi/

Ettus E3xx Getting Started Guide

Navigation menu

Versions of this User Manual:

Views

Navigation
