Exploded View BLBD02LA Rev. 002 BLBD02LARev001

User Manual: BLBD02LA

Open the PDF directly: View PDF .
Page Count: 1

ITEM Part no. Part Nam e Qty U M

1282100-00 B L T M easu rin g C u p / Viso r BL T 1 pz

28210 0-00M BLT M easuring Cup / Vis or BLT (m aquila) 1 pz

50804119-01 KIBISAN PN 127L-150 // Grade PN 127 C olor :150 0.01246 kg

2282101-00 B L T Jar Li d / Tap a Jarra B L T 1 pz

28210 1-00M BLT J ar Lid / Tapa J arra BLT (m aquila) 1 pz

50804715-00 Polietileno Baja Desindad PEM E X PX 20020X/ LDP E 0.06071 kg

923324-00 Piigm ento negro / Black m as ter bac h 0.00253 kg

3271102-01 B L T/ BL B Glass Jar / Jar ra Vid rio BL B /BL T 1 pz

4383961-00 C u ch ill a Su p erio r IB /B LM / U p per B lade IB /B L M 1 pz

5383961-01 C u chilla In ferior IB /BL M /BL H / L ower B lade IB/ B L M /B LH 1 pz

6153106-00 SS W asher for cu tter blad e /R o ldan a I no x. C uch illas 1 pz

7172270-01 "V" seal blend ers / V seal 1 pz

8155490-09 B lad e Sh aft BL M / Flecha cuchi llas B L M/I B/B L H 1 pz

9381227-01 R u b ber Gasket Glass B LM ´s / Sello Jarra Vidr io B L M ´s 381227-01 1 pz

10 178970-00 B ase C u chillas Vidrio B LM / Glass Cu tter Base B L M 1 pz

178970-00. Bas e C uchillas Vidrio B LM / Glass C utter Bas e BLM (m aquila) 1 pz

50801449-00 N y lon 6/6 N atural Vy dy ne 21SPF 0.01576 kg

1000000578-00 Pigm ento Light Pearl Gray Pantone 402c 0.00065 kg

178795-00 Ins erto de Alum inio / Aluminum Ins ert 1 pz

11 179165-01 B u je Sinter izado B LT / Sinter iz ed B u sh ing B LT 1 p z

12 184783-01 SS W ash e r fo r cutter b ase / R o ld ana Ino x. Base C u chillas 1 pz

13 163995-15 W ash er Phen o lic / R old ana F eno lica 1 pz

14 282310-00 C o p le Hu le B L T / B L T Ru bb er C ou p li ng with m etal plati n g C R 3-R OH S 1 pz

15 282102-00 B LT Jar N ut / B ase Jarr a B L T 1 pz

28210 2-00M BLT J ar Nut / Base J arra BLT (m aquila) 1 pz

922174-16 ABS PA 757 J O1 Black 0.04321 kg

31

32

33 Exploded View BLBD02LA 01/03/10

282421-00 B L T C ou p ling N ylo n / Polyam id e 66 M F G6N 1 pz

17 155430-00 Tapita / Screw C ap 4 pz

15543 0-00M T apita / Sc rew C ap (m aquila) 4 pz

50804 309-00 U niprene 7100-50D Negro Tapita 0.00050 k g

18 175505-01 Scr ew Pan Head Platin g C R 3-R OH S/ To rn illo Pan H ead 4 pz

19 152263-03 Grom m et / Grom m et 4 pz

20 281430-00 R o tar y Switch Bu tton / Perilla B LB 1 pz

28143 0-00M R otary Sw itch Button / Boton de Velocidades (m aquila) 1 pz

922174-14 ABS PA757 N atural 0.019 kg

50807669-00 Pigm ento for ABS / M aster Bach ( C OLOR PE N D IN G FR OM ID ) 0.00038 kg

21 281432-00 A lum inu m B L T Up p er H ou sin g An o d iz i ng Plating / H o using Sup erio r A lum ino B LT 1 pz

22 281431-00 Switch Ro tatorio / R otar y Sw i tch J3400-405 1 pz

23 281434-00 D i od e IN4001 / D io do IN 4 001 1 p z

24 886001-80 Sold er Paste / So ld adu r a de Estaño 0.0005 kg

25 281420-00 B L T M o to r Sp acer / Gasket Separad or BL T 281420-00 1 pz

26 271413-00 B L B 550W M o to r / M o to r 550W B L T 1 pz

27 271414-00 B L T/B L B M o to R ub ber Su pp o rt / So p o rte M o tor B LB /B L T 2 pz

28 921310-11 Power C o rd B lend ers Bl ack SP T-2 60°C 18AW G / C ab le To m acor r iente L icu ad o ras N eg ro 1 pz

29 281427-00 C ri m p Co n ecto r 30-649 2 p z

30 282408-02 B LT Lo w er H o u sin g / H o usin g In ferio r B LT Rev. 02 1 pz

282408-02M B LT Low er Hous ing / Housing Inferior B LT (m aquila) R ev . 02 1 pz

922105-02 Polipropileno Natural 0.14590 k g

923324-00 Piigm ento negro / Black m as ter bac h 0.00608 kg

31 281409-00 F o o t B LT Blen ders/ Patas B L T licuado ras 4 pz

32 281414-00 Pan H ead M ach ine Screw M 3.5 x12 Plarin g C R 3-R O H S 3 p z

33 281415-00 T10 Tam per To r x Screw Plati n g CR 3-R OH S 1 pz
