EYE, EAR, NOSE & THROAT
Digital MacroView™ Otoscope
See it. Share it. Save it. Offering you clear, live and still images of the
ear canal and tympanic membrane, the Digital MacroView Otoscope
is a valuable tool in support of the treatment and management of
your patient’s ears. Requiring no additional purchase of software,
the Digital MacroView Otoscope is easy to learn and use.
■Insufflation port for pneumatic otoscopy
■Compatible with the range of Welch Allyn 3.5 V power sources
■Zoom feature for enhanced viewing
■Improves communication, which can lead to better patient compliance
■Allows you to store digital images in patient records
for enhanced documentation of exam findings
■Provides you the ability to share images with other
providers as visual descriptive reference
■Gives you an excellent training aid for educational purposes
■Offers you the ability to view small details of tubes and hearing aids
23920 Digital MacroView Otoscope, 10 ft USB Cable, and set of
four reusable ear specula
OTOSCOPES
5
EYE, EAR, NOSE & THROAT
OTOSCOPES
23804 Insufflator Bulb
24400-U Additional Set of 4 reusable tips (2.5, 3, 4 and 5 mm)
24302-U Universal Poly Reusable Speculum 2.5 mm
24303-U Universal Poly Reusable Speculum 3.0 mm
24304-U Universal Poly Reusable Speculum 4.0 mm
24305-U Universal Poly Reusable Speculum 5.0 mm
24320 SofSeal Small, Disposable Sealing Tip
24330 SofSeal Medium, Disposable Sealing Tip
52432-U 2.75 mm Universal KleenSpec® Pediatric Disposable Ear Specula
52434-U 4.25 mm Universal KleenSpec Disposable Ear Specula
23900-10 Replacement 10 ft USB Cable
71000-A NiCad Rechargeable Plug in Handle
71000-C NiCad/Convertible Rechargeable Plug in Handle
71670 NiCad Rechargeable Desk Charger Handle
71900 Lithium Ion Rechargeable Handle with AC Charging Module
06500-U 3.5 V Halogen Lamp for MacroView Otoscope
06500-LED LED Upgrade Kit
Digital MacroView Otoscope: Accessories
23804
MacroView Insufflator Bulb
with tube and tip
24330
SofSeal Medium, Disposable Sealing Tip
(Specula sold separately)
52432-U
2.75 mm Single Use Ear Specula
06500-U
Lamp
06500-LED
LED Light
6
EYE, EAR, NOSE & THROAT
MacroView™ Otoscope
Delivers almost twice the field of view at higher magnification
compared to standard otoscopes, making it easier to visualize
the auditory canal and tympanic membrane. This instrument is a
significant advance in hand-held otoscopy, providing an improved
view for enhanced learning and decision making.
■A nearly complete view of the tympanic membrane with approximately twice
the field of view and 30% greater magnification than a traditional otoscope
■Better clarity and definition of landmarks
■The ability to adjust focus for variable ear canal length or farsighted eyes
■Tip grip for secure fastening and ejection of ear specula
■Fiber optics produce cool light with no reflections, no obstruction
23810 MacroView Otoscope
23814 MacroView Otoscope with Insufflation Bulb
23820 MacroView Otoscope with Throat Illuminator
23824 MacroView Otoscope with Throat Illuminator and Insufflator Bulb
OTOSCOPES
23820
MacroView™ Otoscope
23820
MacroView™ Otoscope with Throat Illuminator
(Shown with 3.5 V lithium ion handle)
Tip Grip: Ensures ear
specula are fastened
securely and easily
Adjustable Focus:
Ability to zoom in
or out to fine tune
the view
Default Focus: Optimal
setting for most ear
examinations
Insufflation Port for
Pneumatic Otoscopy
Insufflation Port
Accepts disposable or
reusable ear specula
Throat Illuminator:
Provides light with
a handy built-in
penlight
Standard Otoscope MacroView™ Otoscope
Field of View
2X
Larger View
Convert the Otoscope into a
Throat or Nasal Illuminator
Hold the throat illuminator’s collar stationary
(the black portion below the silver ring) and
twist the otoscope section loose until it is
removed. The throat illuminator is now
ready for use.
Optional Nasal Illuminator
Attachment
Optional fiber optic nasal illuminator
attachment with 9 mm distal opening
quickly twists onto the throat illuminator
base for full view of nasal passages.
7
EYE, EAR, NOSE & THROAT
OTOSCOPES
MacroView™ Otoscope: Accessories
52700 Slotted Specula Instrumentation Tip (compatible with 23810 and 23820
MacroView Otoscopes), (case of 4 boxes, 48/box)
24320 SofSeal, Small (recommended for 2-4.25 mm ear specula),
(case of 6 boxes, 80/box)
24330 SofSeal, Medium (recommended for 3-5 mm ear specula),
(case of 6 boxes, 80/box)
24400-U Set of Four Reusable Ear Specula for Diagnostic and MacroView
Otoscopes—2.5, 3, 4 and 5 mm
52434-U 4.25 mm KleenSpec® Disposable Ear Specula for Diagnostic Otoscopes
(case of 10 bags, 850/bag)
52432-U 2.75 mm Universal KleenSpec® Pediatric Disposable Ear Specula for
Diagnostic Otoscopes (case of 10 bags, 850/bag)
06500-U 3.5 V Halogen Lamp for MacroView Otoscope
23804 Otoscope Insufflation Bulb and Tube with Tip for the
MacroView Otoscope
23857 3.5 V Throat Illuminator Section Only for 23820, 26035, 26535
52700
Slotted Specula
Instrumentation Tip
24330
SofSeal, Medium
(Specula sold separately)
23804
Otoscope Insufflation Bulb and Tube
4 mm 2.5 mm3 mm5 mm
24400-U Set of Four Reusable Ear Specula
4.25 mm
2.75 mm
52432-U
2.75 mm Universal
KleenSpec Pediatric
Disposable Ear Specula
KleenSpec Disposable Ear Specula
52434-U
4.25 mm KleenSpec
Disposable Ear Specula
8
EYE, EAR, NOSE & THROAT
3.5 V Diagnostic Otoscopes
Halogen HPX® illumination and fiber optics to the distal tip for easy
examinations.
■Halogen HPX lamp provides light output for true
tissue color and long-lasting performance
■Fiber optics project cool light to the distal tip with no reflections
or obstructions for superior views of the tympanic membrane
■Wide-angle viewing lens allows for instrumentation under magnification
■Sealed system for pneumatic otoscopy and accurate diagnosis of otitis
media
25020 Diagnostic Otoscope with Specula
25021 Diagnostic Otoscope with Insufflator Bulb
24330 SofSeal™, Medium (recommended for 3-5 mm ear specula),
(case of 6 boxes, 80/box)
24320 SofSeal, Small (recommended for 2-4.25 mm ear specula),
(case of 6 boxes, 80/box)
23557 3.5 V Throat Illuminator Section Only (thread on)
03100-U 3.5 V Halogen Lamp for Diagnostic Otoscopes
21504 Insufflator Bulb with Tip for Diagnostic Otoscope
52434-U 4.25 mm KleenSpec® Disposable Ear Specula for Diagnostic Otoscopes
(case of 10 bags, 850/bag)
52432-U 2.75 mm Universal KleenSpec® Pediatric Disposable Ear Specula for
Diagnostic Otoscopes (case of 10 bags, 850/bag)
24400-U Set of Four Reusable Ear Specula for Diagnostic and MacroView™
Otoscopes—2.5, 3, 4 and 5 mm
03100-LED LED Upgrade kit
OTOSCOPES
24330
SofSeal, Medium
21504
Insufflator Bulb
25020
Diagnostic Otoscope
3.5 V Diagnostic Otoscopes: Accessories
Insufflation Port
2.5 mm 3 mm 5 mm
24400-U Set of Four Reusable Ear Specula
2.75 mm 4.25 mm
52432-U
2.75 mm Universal
KleenSpec Pediatric
Disposable Ear Specula
KleenSpec Disposable Ear Specula
52434-U
4.25 mm KleenSpec
Disposable Ear Specula
4 mm
9
EYE, EAR, NOSE & THROAT
Operating Otoscope
Open system with rotatable lens and optional speculum for
convenient procedures, plus bright light output.
■Halogen HPX® lamp produces light for true tissue
color and long-lasting performance
■Open system makes use during procedures more convenient
■Rotatable lens and speculum for ease of use
■Fiber optic illumination produces cool light
21700 3.5 V Operating Otoscope with Specula
21701 3.5 V Operating Otoscope without Specula
209026-501 Replacement Lens Assembly (black)
03100-U 3.5 V Halogen Lamp
OTOSCOPES
Pneumatic Otoscope
Provides bright, white light output and a rotating lens with ultraseal
for pneumatic otoscopy.
■Halogen HPX® lamp provides light output for true tissue
color and consistent, long-lasting illumination
■Rotating lens with ultraseal enables easy pneumatic otoscopy
■Fiber optic illumination produces cool light
20200 3.5 V Pneumatic Otoscope with Specula
20201 3.5 V Pneumatic Otoscope without Specula
20250 3.5 V Pneumatic Otoscope with 12-Diopter Lens and Specula
20251 3.5 V Pneumatic Otoscope with 12-Diopter Lens
03100-U 3.5 V Halogen Lamp
21501 Insufflation Bulb without Tip
Pneumatic Otoscope: Accessories
Operating Otoscope: Accessories
20200
Pneumatic Otoscope
21501
Insufflation Bulb
21700
Operating Otoscope
10
EYE, EAR, NOSE & THROAT
PocketScope™ Otoscope with Throat Illuminator
Small, convenient, and easy to use with bright, white halogen light
and a built-in throat illuminator.
■Halogen light for true tissue color and consistent, long-lasting illumination
■Simply detach the otoscope head to use the throat
illuminator or all-purpose penlight
■Fiber optics provide cool light with no reflections or obstructions
■Wide-angle viewing lens allows for instrumentation under magnification
■Sealed system for pneumatic otoscopy
22820 PocketScope Otoscope with “AA” Handle
22821 PocketScope Otoscope with “AA” Handle and Soft Case
22822 PocketScope Otoscope with “AA” Handle and Hard Case
22800 PocketScope Otoscope with Rechargeable Handle
22811 PocketScope Otoscope with Rechargeable Handle and Soft Case
22812 PocketScope Otoscope with Rechargeable Handle and hard Case
22801 Pocket Otoscope with Throat Illuminator, Convertible Handle, Batteries
and Desk Charger with Soft Case
22802 Pocket Otoscope with Throat Illuminator, Convertible Handle, Batteries
and Desk Charger with Hard Case
21111 PocketScope Otoscope (head only)
21504 Insufflation Bulb with Tip for Diagnostic Otoscope
72600 2.5 V Rechargeable Battery for PocketScope
03400-U 2.5 V Halogen Lamp for PocketScope Instruments
211026-502 Otoscope Illuminator Assembly
72830 AA Handle with Batteries
72800 Convertible Handle with Rechargeable Battery
OTOSCOPES
22820
PocketScope™ Otoscope
with “AA” Handle
21504
Insufflation Bulb
PocketScope™ Otoscope with Throat Illuminator: Accessories
11
EYE, EAR, NOSE & THROAT
OTOSCOPES
22002
Reusable Otoscope Specula
22023
SofSpec™ Extra Comfort
Reusable Otoscope Specula
24323
SofSpec™ Extra Comfort
Reusable Ear Specula
Reusable Otoscope Specula
Economical and reliable.
■Reusable specula are lightweight yet durable, and may
be autoclaved, boiled, or sterilized in solution
■SofSpec™ reusable specula also have an elastomer tip
specially contoured for an ultrapneumatic seal
22002 2.0 mm Reusable Ear Speculum
22003 3.0 mm Reusable Ear Speculum
22004 4.0 mm Reusable Ear Speculum
22005 5.0 mm Reusable Ear Speculum
22009 9.0 mm Reusable Ear Speculum
22100 Set of Five Reusable Ear Specula for Pneumatic, Operating and Consulting
Otoscopes—2, 3, 4, 5 and 9 mm
22023 3.0 mm SofSpec Extra Comfort Reusable Ear Specula
22025 5.0 mm SofSpec Extra Comfort Reusable Ear Specula
22027 7.0 mm SofSpec Extra Comfort Reusable Ear Specula
22120 Set of 3 SofSpec Extra Comfort Reusable Ear Specula—3, 5 and 7 mm for
Pneumatic, Operating and Consulting Otoscopes
24302-U 2.5 mm Reusable Ear Speculum
24303-U 3.0 mm Reusable Ear Speculum
24304-U 4.0 mm Reusable Ear Speculum
24305-U 5.0 mm Reusable Ear Speculum
24400-U Set of Four Reusable Ear Specula for Diagnostic and MacroView
Otoscopes—2.5, 3, 4 and 5 mm
24323 3.0 mm SofSpec Extra Comfort Reusable Ear Specula
24325 5.0 mm SofSpec Extra Comfort Reusable Ear Specula
24327 7.0 mm SofSpec Extra Comfort Reusable Ear Specula
24420 Set of 3 SofSpec Extra Comfort Reusable Ear Specula—3, 5 and 7 mm for
Diagnostic Otoscopes
Pneumatic/Operating/Consulting Standard Reusable Specula
Pneumatic/Operating/Consulting SofSpec Reusable Specula
Diagnostic/MacroView/Standard Reusable Specula
Diagnostic SofSpec Reusable Specula
24302-U
2.5 mm Reusable Ear Speculum
12
EYE, EAR, NOSE & THROAT
OTOSCOPES
Disposable Specula and Dispensers
Safe, convenient, and affordable.
■KleenSpec® Disposable Specula are economical and convenient
■KleenSpec Disposable Specula are made from non-
toxic plastic and are available in a variety of sizes
■KleenScoop™ cerumen removal disposable specula are designed
for curettage of the outer ear canal and will reach just beyond the
anterior prominence of the ear canal in patients over 10 years old
■The dispenser holds all specula sizes within a series
■Dispenser is available with and without a storage compartment
52432-U 2.75 mm Universal KleenSpec Pediatric Disposable Ear Specula for
Diagnostic Otoscopes (case of 10 bags, 850/bag)
52434-U 4.25 mm KleenSpec Disposable Ear Specula for Diagnostic Otoscopes
(case of 10 bags, 850/bag)
52450 KleenScoop (case of 10 boxes, 100 pieces per box)
52400 Dispenser for Disposable Ear Specula without storage, 524 Series
(case of 10 Dispensers)
52401 Dispenser for Disposable Ear Specula with storage, 524 Series
(case of 10 Dispensers)
52133 3.0 mm KleenSpec Disposable Ear Specula for Pneumatic, Operating
and Consulting Otoscopes (case of 10 bags, 500/bag)
52134 4.0 mm KleenSpec Disposable Ear Specula for Pneumatic, Operating
and Consulting Otoscopes (case of 10 bags, 500/bag)
52135 5.0 mm KleenSpec Disposable Ear Specula for Pneumatic, Operating
and Consulting Otoscopes (case of 10 bags, 500/bag)
52101 Dispenser for Disposable Ear Specula with storage (521 Series)
(case of 10) Dispensers Disposable Otoscope Specula Dispensers
(Pneu, Oper, Cons)
52100 Dispenser for Disposable Ear Specula without storage (521 series)
(case of 10 Dispensers)
52401
Disposable Otoscope
Specula Dispenser for 524
Series Otoscope Specula
52100
Disposable Otoscope Specula
Dispenser for 521 Series
Otoscope Specula
KleenSpec Diagnostic and KleenScoop Cerumen Removal Disposable
Specula—524 Series
Disposable Otoscope Specula
KleenSpec Pneumatic, Operating and Consulting Disposable Specula—521 Series
Disposable Otoscope Specula
Disposable Otoscope Specula Dispenser
Disposable Otoscope Specula Dispenser
2.75 mm
4.25 mm
3.0 mm
4.0 mm
5.0 mm
13
EYE, EAR, NOSE & THROAT
PanOptic™ Ophthalmoscope
The revolutionary PanOptic provides easy entry into the eye, together
with a wider field of view to more easily observe conditions such as
hypertension, diabetic retinopathy, and papilledema.
■Fast, easy entry into undilated pupils
■5X larger view of the fundus vs. standard
ophthalmoscopes in an undilated eye
■25º field of view vs. the standard 5º field of view
■Greater working distance improves comfort for both practitioner and patient
■Helps detect corneal abrasions with cobalt blue filter
and corneal viewing lens (model 11820 only)
■Patented Glare Extinguishment System prevents
interference from unwanted glare and reflections
■Halogen HPX® lamp provides bright, white light
■Compatible with all existing Welch Allyn 3.5 V power sources
11810 PanOptic Ophthalmoscope (head only)
11820 PanOptic Ophthalmoscope with Cobalt Blue Filter and
Corneal Viewing Lens
11800-V Veterinary PanOptic Ophthalmoscope with 3 spot sizes: micro,
small and large; with add-on magnifying lens
03800-U Halogen HPX Lamp for PanOptic Ophthalmoscope
11870 Patient Eyecup (pkg of 5) for PanOptic Ophthalmoscope
11875 Corneal Viewing Lens for PanOptic Ophthalmoscope
05258-M PanOptic Diagnostic Set Carrying Case (rigid)
05815-M PanOptic Diagnostic Set Carrying Case (soft)
03800-LED LED Lamp Upgrade Kit
11820
PanOptic™ Ophthalmoscope Head
shown with Lithium Ion Handle
11820
PanOptic™
Ophthalmoscope
(head only)
11870
Patient Eyecup
for PanOptic
Ophthalmoscope
PanOptic™ Ophthalmoscope: Accessories
Patient Eye Cup
Soft Grip
Handle
Axial PointSourceTM Optics for
easy entry into undilated pupils
resulting in a 5X larger view of
the fundus
Patented Glare
Extinguishment
System
Dynamic
Focusing
Wheel
Easy-to-use
Aperture Dial
PanOptic
Ophthalmoscope
Standard
Arteries
Veins
Optic disc
Macula
11875
Corneal Viewing
Lens for PanOptic
Ophthalmoscope
Lenses
+20 to -20
Filters
Red-free
Cobalt Blue
(model 11820 only)
Optical System
Patented Axial
PointSourceTM Optics
Instrument HeadField of View (5X larger view of the fundus)
OPHTHALMOSCOPES
14
EYE, EAR, NOSE & THROAT
3.5 V Standard Ophthalmoscope
Uses halogen light for true tissue color and consistent, long-lasting
illumination. Versatile and reliable at an economical price.
■Halogen light for true tissue color and consistent, long-lasting illumination
■6 apertures for generalist use: micro, small, and large spot
sizes, fixation target, slit aperture, and red-free filter
■28 focusing lenses with a range of -25 to +40 diopters
■Rubber brow rest prevents scratching of eyeglasses
11710 Standard Ophthalmoscope (head only)
03000-U 3.5 V Halogen Lamp for 11710 Standard Ophthalmoscope
11710
3.5 V Standard Ophthalmoscope
(head only)
3.5 V Standard Ophthalmoscope: Accessories
Aperture
Select ion
Dial
Lens
Selection
Disc
APERTURES FOR: 3.5 V Standard Ophthalmoscope
Filters
Red-free
Lenses
28 Lenses
-25 to +40 Diopters
Slit
used to determine levels of lesions and tumors.
Large Aperture
standard aperture for a dilated pupil and
general examination of the eye.
Micro-Spot Aperture
allows quick entry into small, undiluted pupils.
Red-Free Filter
excludes red rays from examination field for easy
identification of veins, arteries and nerve fibers.
Fixation Aperture
has graduated crosshairs for measuring
eccentric fixation or locating lesions.
Small Aperture
provides excellent view of fundus through
an undilated pupil.
Optical System
Standard Optics
EYE, EAR, NOSE & THROAT
OPHTHALMOSCOPES
15
EYE, EAR, NOSE & THROAT
3.5 V Coaxial Ophthalmoscope
The patented Welch Allyn Coaxial Vision System facilitates
ophthalmoscopy by enabling easier entry into the eye, a larger field
of view, and reduced glare compared to standard ophthalmoscopes.
■Halogen HPX® lamp provides light for true tissue
color and long-lasting performance
■Coaxial optics produce a shadow-free spot, easier entry into undilated
pupils, and a larger field of view versus standard ophthalmoscopes
■Detect corneal abrasions with cobalt blue filter
■Polarizing filter virtually eliminates corneal reflection
■Sealed optics keep out dust and dirt
■18 unique aperture/filter combinations for greater versatility
■Red-free filter may be used with any aperture
■28 focusing lenses with a range of -25 to +40 diopters
11720 Coaxial Ophthalmoscope
04900-U 3.5 V Halogen Lamp for 11720 Ophthalmoscopes
04900-LED LED Upgrade Kit
11720
Coaxial Ophthalmoscope
(head only)
3.5 V Coaxial Ophthalmoscope: Accessories
Lenses
28 Lenses
-25 to +40 Diopters
Filters
Cross-linear Polarizing
Red-free
Cobalt Blue
Optical System
Coaxial Optics
Coaxial
Optical
System
Compact Head
Design
Triple-sealed
Ophthalmoscope
Cross-linear
Polarizing
Filter
Aperture
Select ion
Dial Lens
Selection
Disc
Slit
used to determine levels of lesions and tumors.
Large Aperture
standard aperture for a dilated pupil and
general examination of the eye.
Micro-Spot Aperture
allows quick entry into small, undiluted pupils.
Red-Free Filter
excludes red rays from examination field for easy
identification of veins, arteries and nerve fibers.
Fixation Aperture
has graduated crosshairs for measuring
eccentric fixation or locating lesions.
Small Aperture
provides excellent view of fundus through
an undilated pupil.
APERTURES FOR: 3.5 V Coaxial Ophthalmoscope, 3.5 V AutoStep® Coaxial Ophthalmoscope
and Prestige™ Coaxial-Plus Ophthalmoscope (models 11720, 11730 and 11735)
Cobalt Filter
used with fluorescein dye to view small lesions,
abrasions and foreign objects on the cornea.
OPHTHALMOSCOPES
16
EYE, EAR, NOSE & THROAT
11730
AutoStep® Coaxial Ophthalmoscope
3.5 V AutoStep® Coaxial Ophthalmoscope
Patented coaxial optics, Halogen HPX® illumination, and 68 focusing
lenses combine for premium quality.
■Halogen HPX lamp provides light output for true tissue
color and consistent, long-lasting illumination
■Coaxial optics produce a shadow-free spot, easier entry
into undilated pupils, and a larger field of view
■18 aperture/filter combinations for greater versatility: micro,
small, and large spot sizes, cobalt blue filter for corneal exams,
fixation target, or slit aperture can be combined with red-free
filter, polarizing filter, or unfiltered Halogen HPX illumination
■68 lenses in single-diopter steps for precise resolution (+38 to -30)
■Sealed optics keep out dust and dirt for years of maintenance-free operation
■Rubber brow rest prevents scratching of eyeglasses
11730 AutoStep Coaxial Ophthalmoscope (head only)
04900-U 3.5 V Halogen Lamp
04900-LED LED Upgrade Kit
Lens
Selection Disc
Aperture
Selection Dial
Filters
Cobalt Blue
Cross-linear Polarizing
Red-free
Optical System
Coaxial Optics
Lenses
68 Lenses
-30 to +38 Diopters
3.5 V AutoStep Coaxial Ophthalmoscope: Accessories
16
EYE, EAR, NOSE & THROATEYE, EAR, NOSE & THROAT
OPHTHALMOSCOPES
17
EYE, EAR, NOSE & THROAT
11735
Prestige™ Coaxial-Plus
Ophthalmoscope shown
with Lithium Ion Handle
Easy Entry into
Undilated Pupils
Neutral Density Filter
Opacity
Setting
68 Lenses
Prestige™ Coaxial-Plus Ophthalmoscope
Patented Coaxial-Plus optics enable easy entry into undilated pupils
for more accurate diagnoses, while two filter selections provide
optimum light levels for entering healthy eyes and those with
cataracts.
■Enables easy entry into undilated pupils through
precise lamp filament and optical alignment
■The neutral filter provides the ideal amount of color-accurate Halogen
HPX® light for entering healthy eyes without unwanted reflex
■The opacity setting provides the brightest Halogen HPX light for
easy entry into eyes with cataract or other media opacity
■68 lenses provide extensive range of focus for optimum resolution
(+38 to -30)
11735 Prestige Coaxial-Plus Ophthalmoscope (head only)
04900-U 3.5 V Halogen Lamp
04900-LED LED Upgrade Kit
Lenses
68 Lenses
-30 to +38 Diopters
Filters
Neutral Density
Opacity Setting
Red-free
Cobalt Blue
Optical System
Coaxial-Plus Optics
Prestige Coaxial-Plus Ophthalmoscope: Accessories
OPHTHALMOSCOPES
18
EYE, EAR, NOSE & THROAT
PocketScope™ Ophthalmoscope
Lightweight, compact diagnostic instruments deliver high
performance in a slightly smaller package.
■Halogen light for true tissue color and consistent, long-lasting illumination
■12 aperture/filter combinations for greater versatility: micro, small,
and large spot sizes, cobalt blue filter for corneal exams, fixation
target, and slit aperture, plus red-free filter and unfiltered halogen
■48 focusing lenses for better resolution
12800 PocketScope Ophthalmoscope with Rechargeable Handle
13000 PocketScope Ophthalmoscope (head only)
12811 PocketScope Ophthalmoscope with Rechargeable Handle and Soft Case
12820 PocketScope Ophthalmoscope with “AA” Handle
12821 PocketScope Ophthalmoscope with “AA” Handle and Soft Case
03900-U 2.5 V Halogen Lamp for PocketScope Ophthalmoscope
05280-1 Hard Case for PocketScope Sets and Instruments
72600 2.5 V Rechargeable Battery for PocketScope Ophthalmoscope
05928-U Soft Zipper Case for PocketScope Set
12800
PocketScope™
Ophthalmoscope with
Rechargeable Handle
Prestige™ Coaxial-Plus Ophthalmoscope: Accessories
EYE, EAR, NOSE & THROAT
18
OPHTHALMOSCOPES
19
EYE, EAR, NOSE & THROAT
767 Integrated Diagnostic Systems and
Wall Transformer Sets
A convenient, modular package that puts everything needed for fast,
accurate diagnoses at arm's length. By combining a wall aneroid,
ophthalmoscope, otoscope, specula dispenser, and thermometer
(optional), Welch Allyn puts all the basic diagnostic tools within easy
reach. These systems are attractive, modular, and easy to order and
install. Customize your Wall Set to match your individual needs.
■All the instruments you'll need to perform a complete diagnostic examination
■Comfortable, contoured handles are easy to hold and maneuver
■Durable, easy-to-clean, high-impact ABS housing
■OptiSense™ sensor automatically turns handles on when they are
removed from the cradles and off when they are replaced
■Optional KleenSpec® Diagnostic or Pneumatic Specula Dispenser
■Optional digital clock with pulse timer
■Choose either PanOptic model 11810 or model 11820 with cobalt
blue filter and corneal viewing lens, or the other sealed
(dust-free) Coaxial Ophthalmoscope (11720)
■Otoscope options include the MacroView™ Otoscope, which
provides 30% more magnification and nearly twice the field of
view of traditional otoscopes, or Pneumatic Otoscope
■Optional 767 Wall Aneroid with easy-to-read dial face,
certified accuracy and lifetime calibration program
■Sturdy, predrilled mounting board mounts easily
to any wall, preventing loss or theft
■Optional SureTemp® Plus Electronic Thermometer for
accurate oral readings in approximately 4- to 6-seconds,
rectal readings in approximately 15 seconds
76791-2MPX
767 Wall Transformer with 11820 PanOptic™
Ophthalmoscope , MacroView™ Otoscope,
767 Tycos® Wall Aneroid, SureTemp®
Plus Thermometer, KleenSpec® Specula
Dispenser and Wall Board
767 INTEGRATED WALL SYSTEMS
EYE, EAR, NOSE & THROAT
1
EYE, EAR, NOSE & THROATEYE, EAR, NOSE & THROAT
767 INTEGRATED WALL SYSTEMS
20
Welch Allyn Integrated Diagnostic System and Wall Transformer Sets—Components Chart
Part Number
Wall
Board
767
Transformer
Coaxial
Ophthalmoscopes
PanOptic™
Ophthalmoscopes
Diagnostic
MacroView™
Otoscopes
Pneumatic
Otoscope
767
Aneroid
KleenSpec®
Dispenser
Small
KleenSpec
Dispenser
Large
SureTemp® Plus
Thermometers
76710
76720
(clock) 11720 11810 11820 23810 23820 20200 7670-01 52401 52101 01690-300
Integrated Wall Systems
76798 • • • • • •
76791-1MPX • • • • • • •
76791-21MPX • • • • • • •
76791-22MPX • • • • • • •
76791-2MPX • • • • • • •
76791-MX • • • • • • •
76792-1MP • • • • • •
76792-2MP • • • • • •
76792-M • • • • • •
76793-MX • • • • • • •
76794-M • • • • • •
76795-1MPX • • • • • • •
76795-2MPX • • • • • • •
76795-MX • • • • • • •
76796-1MP • • • • • •
76796-2MP • • • • • •
76796-M • • • • • •
76797-2PX • • • • • • •
76797-X • • • • • • •
76798-2P • • • • • •
Integrated Wall Systems for Spot or Spot LXi (includes wall mounting bracket for Spot/Spot LXi) —Spot/Spot LXi Models Ordered Separately
76791-1MPSNOBPX • • • • • •
76791-2MPSNBPX • • • • • •
76791-MXNOBP • • • • • •
76792-MNOBP • • • • •
* Order with part number 34XFWT-B Connex ProBP with SureBP and Wall Mount or part number 34XXWT-B Connex ProBP with Standard BP and Wall Mount
Integrated Wall Systems for Spot or Spot LXi (includes wall mounting bracket for Spot/Spot LXi) —Spot/Spot LXi Models Ordered Separately
76794-MSPOT • • • • •
76794-MLXI • • • • •
76794-2MPSPOT • • • • •
76794-2MPLXI • • • • •
21
EYE, EAR, NOSE & THROAT
767 INTEGRATED WALL SYSTEMS
Welch Allyn Integrated Diagnostic System and Wall Transformer Sets—Components Chart Continued
Part Number
Wall
Board
767
Transformer
Coaxial
Ophthalmoscopes
PanOptic™
Ophthalmoscopes
Diagnostic
MacroView™
Otoscopes
Pneumatic
Otoscope
767
Aneroid
KleenSpec®
Dispenser
Small
KleenSpec
Dispenser
Large
SureTemp® Plus
Thermometers
76710
76720
(clock) 11720 11810 11820 23810 23820 20200 7670-01 52401 52101 01690-300
2011 Wall Transformer Sets
76510 • •
76520 • •
76910 • •
76920 • •
79510 • • •
79520 • • •
76710-71M • • •
76710-72M • • •
76710-81M • • •
76710-82M • • •
76710-TAKX • • • •
76710-TAPX • • • •
76710-TAX • • •
76710-TKX • • •
76710-TPX • • •
76710-TX • •
76720-TAKX • • • •
76720-TAPX • • • •
76720-TAX • • •
76720-TKX • • •
76720-TPX • • •
76720-TX • •
EYE, EAR, NOSE & THROAT
76791-1MPX 767 Wall Transformer with PanOptic Ophthalmoscope, MacroView™
Otoscope, 767 Wall Aneroid, KleenSpec® Specula Dispenser for Diagnostic
Otoscopes and SureTemp® Plus
76791-2MPX 767 Wall Transformer with 11820 PanOptic™, Ophthalmoscope, MacroView
Otoscope, 767 Tycos® Wall Aneroid, SureTemp Plus Thermometer,
KleenSpec Specula Dispenser and Wall Board
76791-22MPX 767 Wall Transformer with Clock, 11820 PanOptic Ophthalmoscope,
MacroView Otoscope, 767 Wall Aneroid, SureTemp Plus Thermometer,
KleenSpec Specula Dispenser and Wall Board
76792-M 767 Wall Transformer with Coaxial Ophthalmoscope, MacroView Otoscope,
767 Wall Aneroid and KleenSpec Specula Dispenser for Diagnostic
Otoscopes and Wall Board
76792-MNOBP Wall Transformer with Coaxial Ophthalmoscope, MacroView Otoscope,
and KleenSpec Specula Dispenser for Diagnostic Otoscopes and
Wall Board
76792-1MP Wall Transformer with PanOptic Ophthalmoscope, MacroView Otoscope,
767 Wall Aneroid and KleenSpec Specula Dispenser for Diagnostic
Otoscopes and Wall Board
76792-2MP Wall Transformer with 11820 PanOptic Ophthalmoscope, MacroView
Otoscope, 767 Wall Aneroid and KleenSpec Specula Dispenser and
Wall Board
76793-MX Wall Transformer with Coaxial Ophthalmoscope, MacroView Otoscope,
SureTemp Plus Thermometer, 767 Wall Aneroid and KleenSpec Specula
Dispenser for Diagnostic Otoscope and Wall Board
76794-M Wall Transformer with Coaxial Ophthalmoscope, MacroView Otoscope, 767
Wall Aneroid, KleenSpec Specula Dispenser for Diagnostic Otoscope and
Wall Board
76795-1MPX Wall Transformer with PanOptic Ophthalmoscope, 23820 MacroView
Otoscope, 767 Wall Aneroid, 52401 KleenSpec Specula Dispenser,
SureTemp Plus Thermometer and Wall Board
76795-2MPX Wall Transformer with 11820 PanOptic Ophthalmoscope, 23820 MacroView
Otoscope, 767 Wall Aneroid, 52401 KleenSpec Specula Dispenser,
SureTemp Plus Thermometer and Wall Board
76796-M Wall Transformer with Coaxial Ophthalmoscope, MacroView Otoscope
with Throat Illuminator, 767 Wall Aneroid and KleenSpec Specula
Dispenser for Diagnostic Otoscope and Wall Board
76796-1MP Wall Transformer with PanOptic Ophthalmoscope, MacroView Otoscope
with Throat Illuminator, 767 Wall Aneroid and 52401 KleenSpec Specula
Dispenser and Wall Board
76796-2MP Wall Transformer with 11820 PanOptic, MacroView Otoscope with Throat
Illuminator, 767 Wall Aneroid and KleenSpec Specula Dispenser for
Diagnostic Otoscope and Wall Board
76797-X 767 Wall Transformer with Coaxial Ophthalmoscope, Pneumatic Otoscope,
767 Wall Aneroid, 52101 KleenSpec Specula Dispenser, SureTemp Plus
Thermometer and Wall Board
767 Integrated Diagnostic Systems and Wall Transformer Sets
2222
767 INTEGRATED WALL SYSTEMS
EYE, EAR, NOSE & THROAT
76797-2PX Wall Transformer with 11820 PanOptic Ophthalmoscope, Pneumatic
Otoscope, 767 Wall Aneroid, 52101 KleenSpec Specula Dispenser,
SureTemp Plus Thermometer and Wall Board
76798-2P 767 Wall Transformer with 11820 PanOptic Ophthalmoscope,
Pneumatic Otoscope, 767 Wall Aneroid, KleenSpec Specula
Dispenser for Pneumatic Otoscopes and Wall Board
76710-71M 767 Wall Transformer with Coaxial Ophthalmoscope and
MacroView Otoscope
76710-72M 767 Wall Transformer with Coaxial Ophthalmoscope and
MacroView Otoscope
76710-81M 767 Wall Transformer with PanOptic Ophthalmoscope and
MacroView Otoscope
76710-82M 767 Wall Transformer with PanOptic Ophthalmoscope with Cobalt
Blue Filter and Corneal Viewing Lens and MacroView Otoscope
76710-TX 767 Wall Transformer with SureTemp Plus Wall Thermometer
76710-TAX 767 Wall Transformer with SureTemp Plus Thermometer
and 767 Wall Aneroid
76710-TAKX 767 Wall Transformer with SureTemp Plus Wall Thermometer, Wall
Aneroid, and KleenSpec Specula Dispenser for Diagnostic Otoscopes
76710-TAPX 767 Wall Transformer with SureTemp Plus Wall Thermometer, Wall
Aneroid, and KleenSpec Pneumatic, Operating, and Consulting
Otoscope Specula Dispenser
76710-TKX 767 Wall Transformer with SureTemp Plus Wall Thermometer and
KleenSpec Specula Dispenser for Diagnostic Otoscopes
76710-TPX 767 Wall Transformer with SureTemp Plus Wall Thermometer and
KleenSpec Pneumatic, Operating, and Consulting Otoscope
Specula Dispenser
76794-MSPOT 767 Wall Transformer with Coaxial Ophthalmoscope, MacroView
Otoscope, 52401 KleenSpec Specula Dispenser, mounting screws only
for Spot Vital Signs® and Wall Board*
76794-MLXI 767 Wall Transformer with Coaxial Ophthalmoscope, MacroView
Otoscope, 52401 KleenSpec Specula Dispenser, mounting screws
and 4701-62 Wall Mount with Basket for Spot Vital Signs LXi and
Wall Board*
76794-2MPSPOT 767 Wall Transformer with 11820 PanOptic Ophthalmoscope,
MacroView Otoscope, 52401 KleenSpec Specula Dispenser, mounting
screws and 4701-62 Wall Mount with Basket for Spot Vital Signs and
Wall Board*
76794-2MPLXI 767 Wall Transformer with 11820 PanOptic Ophthalmoscope,
MacroView Otoscope, 52401 KleenSpec Specula Dispenser, mounting
screws only for Spot Vital Signs LXi and Wall Board*
* Spot Vital Signs® or Spot Vital Signs® LXi monitor ordered separately.
23
767 INTEGRATED WALL SYSTEMS
767 Wall Transformer
Accurate diagnosis within easy reach.
■Offers the flexibility to add on as you grow
■Handle-based rheostats for quick light intensity adjustments
■Modular design provides the ability to add a third
handle or SureTemp® thermometer
■OptiSense™ sensor automatically turns handles on and off when removed
and replaced from cradle
76710 767 Wall Transformer
76720 767 Wall Transformer with Digital Clock
76730 767 Third Handle Module
76790-3 Wall Board for mounting instruments
76790-4 Wall Board for mounting instruments and Spot Vital Signs® Monitor
76790-5 Wall Board for mounting instruments and Spot Vital Signs LXi Monitor
01690-300 SureTemp® Plus 690 Electronic Thermometer, One Room, Wall Mount,
9 ft Cord and Oral Probe with Oral Probe Well
7670-01 767 Wall Aneroid with Durable FlexiPort Adult Cuff
52101 KleenSpec® Pneumatic, Operating, and Consulting Otoscope Disposable
Specula Dispenser with Storage Compartment (10 sold per case)
52401 Universal KleenSpec MacroView™ Otoscope Disposable Specula
Dispenser with Storage Compartment (10 sold per case)
76700 Locking Collar for theft protection (Set of 2)
52100 KleenSpec Disposable Specula Dispenser (521 series)
52401 KleenSpec Disposable Specula Dispenser (524 series)
76400 8 ft power cord
761076-10 16 inch power cord—this will come standard with any wall transformer
ending in “-16” (76710-16)
761069 6 ft cord - right angle power cord goes to the desk charger
76501 15 ft power cord has ferrite bead and is compatible with the 76710
76720
767 Wall Transformer
with clock
7670-01
767 Tycos® Wall Aneroid
with Durable One-Piece
Adult Cuff
52100
Specula Dispenser
52401
Specula Dispenser
767 Integrated Diagnostic Systems and Wall Transformer Sets:
Accessories
Power Cords
2424
EYE, EAR, NOSE & THROAT
POWER HANDLES, SOURCES AND WALL UNITS
71900
3.5 V Lithium Ion
Rechargeable Handle
3.5 V Lithium Ion Rechargeable Handle: Accessories
Low-battery
Indicator Light
Textured
Handle
Soft Grip
Rheostat
71980 71950
25
EYE, EAR, NOSE & THROAT
POWER HANDLES, SOURCES, AND WALL UNITS
3.5 V Lithium Ion Rechargeable Handle
Twice the on-time, half the weight, and fits more comfortably
in your hand.
■Half the weight of traditional 3.5 V handles
■Fits all Welch Allyn 3.5 V instrument heads
■120 minutes of on-time (compared to 60 minutes for standard NiCad handles)
■Made of sturdy CYCOLOY engineering resin
■Low-battery indicator
■Lithium ion battery technology that has no "memory" effect
■AC charging module is easily removable from the handle and has
retractable AC prongs (model 71900 only)
71900 Lithium Ion Handle with AC Charging Module—3.5 V Lithium Ion
Rechargeable Handle Model Configuration
71930 Lithium Ion Handle with Well Adapter (for use with 71110 Charger Only)
71910 Lithium Ion Handle only for use in Universal Desk Charger
71960 Replacement Lithium Ion Battery
71950 Lithium Ion Power Handle AC Charging Module
71980 Lithium Ion Power Handle Well Adapter Module Only
(for use with 71110 Desk Charger)
71990 Lithium Ion Power Handle Well Adapter Module Only
(for use with select stand console chargers)
26
EYE, EAR, NOSE & THROAT
71000-A
Rechargeable
Handle
7100-C
Rechargeable/
Convertible Handle
3.5 V Nickel-Cadmium Rechargeable Handles
A choice of convenient rechargeable power sources that fit all our
3.5 V instrument heads.
■Rechargeable nickel-cadmium battery included
■Smooth, nonabrasive knurled finish ensures a no-slip grip
■Chrome-plated brass construction for durability and reliable long life
■Rechargeable and can also be converted for use with
standard C-cell batteries (model 71000-C only)
■Recharges in the Welch Allyn desk charger and numerous stand consoles
and well chargers (model 71670)
71000-A Rechargeable Handle
71000-C Rechargeable/Convertible (to C-cell Batteries) Handle
71670 Rechargeable NiCad Handle for Desk/Well Chargers
72300 Replacement NiCad Rechargeable Battery (orange)
for 71000-A/71000-C
710171-501 Battery charger module (section only) for 71000-A/71000-C
72200 Replacement NiCad Rechargeable Battery (black) for 71000 and 71670
710168-501 Battery Converter
3.5 V Nickel-Cadmium Rechargeable Handles: Accessories
Transformer
ETL/UL
Recognized
Transformer
ETL/UL
Recognized
NiCad
Battery
C-cell
Battery
C-cell
Converter
POWER HANDLES, SOURCES, AND WALL UNITS
27
EYE, EAR, NOSE & THROAT
71821-MP
Desk Charger with
2 NiCad Handles
(Showing 11820, 23810)
71140
Universal Desk Charger for
Lithium Ion and NiCad Handles
71249
PocketScope Adapter Sleeve
for Universal Desk Charger
Universal Charger and Desk Sets
Compact, portable unit provides convenient drop-in recharging of
desk/well-charger instrument handles.
■Colored LEDs indicate power to the unit and that handles are charging
■Advanced circuitry for constant automatic safe charging
and optimum lamp performance and life
■Compact for convenience and mobility
■Optional wall mount kit for permanently mounting to wall or cabinet
■Optional specula tray conveniently stores swabs,
otoscope specula, and curettes
■Accepts 3.5 V or 2.5 V well-rechargeable NiCad handles, Lithium Ion
Handle and PocketScope™ handles (only PocketScope™ handles
require an adapter)
71140 Universal Desk Charger for Lithium Ion and NiCad Handles
71630 Desk Charger with 2 NiCad Handles
71640 Desk Charger with 2 Lithium Ion Handles
79290 Universal Desk Charger with Two Adapter Sleeves (for PocketScope)
71510-PSM Desk Set with PanOptic™ Ophthalmoscope, Pneumatic Otoscope
and two Lithium Ion Handles
71641-M Desk Set with Coaxial Ophthalmoscope, MacroView™ Otoscope
and NiCad Handles
71641-MS Desk Set with Coaxial Ophthalmoscope, MacroView Otoscope
and Lithium Ion Handle
71811-MP Desk Set with PanOptic Ophthalmoscope, MacroView Otoscope
and NiCad Handles
71811-MPS Desk Set with PanOptic Ophthalmoscope, MacroView Otoscope
and Lithium Ion Handles
71821-MP Desk Set with PanOptic Ophthalmoscope with Corneal Viewing Lens,
MacroView Otoscope and two NiCad Handles
92850 2.5 V Desk Set with Pocket Ophthalmoscope/Otoscope, Handles
and Adapter Sleeve and Hard Case
92851 2.5 V Desk Set with Pocket Ophthalmoscope/Otoscope, Handles
and Adapter Sleeve and Soft Case
71420 Wall Mount Kit for Desk Charger
71310 Specula Tray
71249 PocketScope Adapter Sleeve
Universal Charger and Desk Sets: Accessories
Universal Charger and Desk Sets
Universal Desk Charger Sets
POWER HANDLES, SOURCES, AND WALL UNITS
28
EYE, EAR, NOSE & THROAT
Part Number
Ophthalmoscopes Otoscopes Handles Desk
Charger Cases
11810 11820 11720 13000 20200 23810 21111 71670*71910*
72800/71249
Pocket 71140 Hard Soft
71510-PSM • • • •
71630 • •
71640 • •
71641-M • • • •
71641-MS • • • •
71811-MP • • • •
71811-MPS • • • •
71821-MP • • • •
92850 • • • • •
92851 • • • • •
Desk Charger Set Components Chart
* All desk sets come with two handles
2828
EYE, EAR, NOSE & THROAT
POWER HANDLES, SOURCES, AND WALL UNITS
Part Number
Ophthalmoscopes Otoscopes Handles Nasal
Illuminators Cases
11810 11820 11710 11720 23810 23820 20200 21700 71000-A 71000-C 71900 26535 Hard Soft
97100-M • • • •
97100-MC • • • •
97100-MPC • • • •
97100-MPS • • • •
97100-MS • • • •
97101-M • • • •
97101-MC • • • •
97101-MPC • • • •
97101-MPS • • • •
97110-M • • • • •
97110-MC • • • • •
97110-MPC • • • • •
97110-MPS • • • • •
97110-MS • • • • •
97111-M • • • •
97111-MC • • • • •
97120 • • • •
97120-C • • • •
97121 • • • •
97121-C • • • •
97150-M • • • •
97150-MC • • • •
97150-MPC • • • •
97150-MPS • • • •
97150-MS • • • •
97151-M • • • •
97151-MC • • • •
97151-MS • • • •
97170 • • • •
97171 • • • •
97171-C • • • •
97200-M • • • •
97200-MC • • • •
Diagnostic Sets–Components Chart
29
EYE, EAR, NOSE & THROAT
DIAGNOSTIC SETS
30
EYE, EAR, NOSE & THROAT
Part Number
Ophthalmoscopes Otoscopes Handles Nasal
Illuminators Cases
11810 11820 11710 11720 23810 23820 20200 21700 71000-A 71000-C 71900 26535 Hard Soft
97200-MPC • • • •
97200-MPS • • • •
97200-MS • • • •
97210-M • • • •
97210-MC • • • •
97210-MPS • • • •
97201-MS • • • •
97210-M • • • • •
97201-MC • • • • •
97210-MPC • • • • •
97201-MPS • • • • •
97210-MS • • • • •
97211-M • • • • •
97211-MC • • • • •
97211-MPS • • • • •
97211-MS • • • • •
97250-M • • • •
97250-MC • • • •
97250-MPC • • • •
97250-MPS • • • •
97250-MS • • • •
97251-M • • • •
97251-MPS • • • •
97251-MS • • • •
97220 • • • •
97220-C • • • •
97220-SM • • • •
97221 • • • •
97221-C • • • •
97270 • • • •
97270-C • • • •
97271 • • • •
97271-C • • • •
Diagnostic Sets–Components Chart
3030
EYE, EAR, NOSE & THROAT
DIAGNOSTIC SETS
Part Number
Ophthalmoscopes Retinoscopes Fixation
Cards Handles Case
11820 11735 11730 11720 18245 18300 18250 71000-A*71900 Hard**
18335 • • • • •
18335-SM • • • • •
18330 • • • • •
18330-SM • • • • •
18430 • • • • •
18320 • • • • •
18320-PC • • • • •
18320-PSM • • • • •
18420 • • • • •
11790 • • •
11770 • • •
Ophthalmic Set Components Chart
*Available with Convertible Handle; add ”-C” to set number when ordering (e.g., 71000 to 71000-C)
**All sets available in Soft Case by changing last numeric digit of set to 1 (e.g., 18335 to 18331)
31
EYE, EAR, NOSE & THROAT
DIAGNOSTIC SETS
32
EYE, EAR, NOSE & THROAT
Part Number
Otoscopes Handles Cases
23810 23820 20200 21700 71000-A*Hard Soft
20270 • • •
20271 • • •
21770 • • •
21771 • • •
25070-M • • •
25270-M • • •
Otoscope Components Chart
*Note: Add ”C” to the end of the item numbers above for a set with the 71000-C Convertible handle in place of the
71000-A (e.g., 25070-MC to receive the to 7100-C handle)
DIAGNOSTIC SETS
33
EYE, EAR, NOSE & THROAT
2.5 V CompacSet™
The perfect “second set” for a fast paced environment.
■Full-featured ophthalmoscope and fiber-optic otoscope
integrated into one, easy-to-use instrument
■Fold-away design keeps instruments protected on the go
■Halogen illumination gives bright, white, long-lasting light
■Instrument heads swivel for easy access from any position
■Powered by AA or rechargeable batteries
92000 CompacSet with AA batteries
92100 CompacSetand#8482; with NiCad rechargeable batteries
92000
2.5 V CompacSet™
DIAGNOSTIC SETS
2.5 V PocketScope™ Set
Have all the accuracy of Welch Allyn diagnostics right in your
lab coat pocket.
■2.5 V PocketScope Ophthalmoscope with consistent,
long-lasting halogen illumination for true tissue color
■2.5 V PocketScope Otoscope with built-in throat illuminator gives you two
instruments in one, with halogen illumination and fiber optics for cool light
■Adjustable rheostat to control light intensity
■Powered by AA batteries
■Available in either hard or soft case
92820 PocketScope Set with Hard Case
92821 PocketScope Set with Soft Case
92100 CompacSetand#8482; with NiCad rechargeable batteries
92821
2.5 V PocketScope
with Soft Case
34
Elite™ Retinoscope
Makes refractions easier than ever by producing one of the brightest,
sharpest, and cleanest streaks available.
■Provides 2.8X the brightness of our standard retinoscopes
■Superior streak quality enables easier and quicker
refractions—even in patients with small pupils
■Crossed linear polarizing filter eliminates bothersome glare from
trial lenses, helping you perform a more precise exam
■External focusing sleeve improves comfort and maneuverability
■Sealed optics keep the lenses cleaner for more effective exams
■Fits all Welch Allyn 3.5 V power sources
■For those preferring a spot retinoscope, the streak retinoscope converts to
a spot retinoscope by simply replacing the streak lamp with a spot lamp
18245 Elite Streak Retinoscope
18300 Elite Spot Retinoscope
08200-U Halogen HPX® Streak Replacement Lamp
08300-U Halogen HPX Spot Replacement Lamp
18250 Fixation Cards for dynamic retinoscopy (set of four)
18245
Elite™ Retinoscope
Shown with 719
Lithium Ion Handle
Superior Streak/
Spot Quality
Crossed
Linear
Polarizing
Filter
External Focusing
Sleeve
Dust-Free
Design
Elite Retinoscope: Accessories
18250
Fixation Cards
Set of four fixation cards quickly
and easily attach to magnetic
logo on instrument head for
dynamic retinoscopy.
EYE, EAR, NOSE & THROAT
RETINOSCOPE
35
SureSight® Vision Screener
Test for the primary vision disorder in children, refractive error, with
this child-friendly unit that engages youngsters, puts them at ease,
and requires minimal cooperation.
■Five-second, automatic test makes patient compliance easier
■Lights and sounds engage child's attention
■Measures and indicates abnormal readings automatically—
no provider interpretation required
■Operates at a nonthreatening 14 inches (35 cm) distance
■Minimal cooperation is necessary, making it equally effective for
children, disabled patients and those with a language barrier
■Screens for common vision problems, including near- and farsightedness
(myopia/hyperopia), astigmatism (asymmetrical focus) and anisometropia
(unequal power between eyes)
14000 SureSight Vision Screener (English)
14042 Martel Thermal Printer
05140-U Carrying Case
53600 Printer Paper (5 rolls)
72420 Lithium Ion Battery
71040 Charging Transformer only
14000
SureSight®
Vision Screener
14042
Martel Thermal Printer
SureSight Vision Screener: Accessories
EYE, EAR, NOSE & THROAT
VISION SCREENERS
36
StrabismoScope™ Unidirectional Occluder
Makes diagnosing strabismus easier than ever. Ideal for visualizing
dissociated vertical deviation.
■Efficient testing for strabismus, both latent
(heterophorias) and manifest (heterotropias)
■Simultaneously view the movement of covered and uncovered eyes
■Halogen light increases the ambient light on the patient's
side and aids visualization by the practitioner
■Durable—rugged ABS housing resists damage from drops
■Fits all Welch Allyn 3.5 V power sources
■Laminated wall chart for patient education
12400 3.5 V StrabismoScope Unidirectional Occluder
03000-U 3.5 V Halogen Lamp
71000-A 3.5 V Direct Plug-in Rechargeable Handle
71000-C 3.5 V Convertible Rechargeable Handle
71900 3.5 V Lithium Ion Smart Handle with Removable AC Adapter
StrabismoScope Unidirectional Occluder: Accessories
12400
3.5 V StrabismoScope™
Unidirectional Occluder
EYE, EAR, NOSE & THROAT
VISION SCREENERS
37
14010
SureSight® Autorefractor
14042
Martel Thermal Printer
SureSight® Autorefractor
SureSight Autorefractor is a portable, fast and affordable device that
makes testing even your toughest patients quick and painless— for
both you and your patients.
■Five-second, automatic testing is both fast and efficient
■SureSight's lights and sounds engage the patient's attention
■Minimal cooperation is required, making it ideal for use on young
children, the disabled, and when there is a language barrier
■The hand-held, 2-pound (0.9 kg) SureSight unit and
printer can be carried easily from room to room, to your
waiting area, off-site—wherever you need it
■SureSight is so easy to learn and use, your staff
can readily use it to refract patients
■SureSight refracts babies, children, and adults. You can even test
patients while they're wearing glasses or contact lenses
14010 SureSight Autorefractor Set (includes 110-130 V charging transformer,
stand, thermal printer, and carrying case)
53600 Printer Paper (5 rolls)
14042 Martel Thermal Printer
05140-U Carrying Case
72420 Lithium Ion Battery
71040 Charging Transformer Only
SureSight Autorefractor: Accessories
EYE, EAR, NOSE & THROAT
AUTOREFRACTOR
38
74350
Wall/Desk Power
Source for BIO
74360
Portable Power
Source for BIO
05120-U
Soft Carrying Case
for BIO (large)
Binocular Indirect Ophthalmoscope
One of the most advanced BIOs available, with state-of-the-art,
convenient features plus lightweight, comfortable fit and
increased stability.
■Video-aligned optical system ensures precise
positioning of components for easy viewing
■Well-padded leather headband and swooped design combined
with ergonomic controls provide comfort and simple operation
■Illumination and visual pathways can be converged for
excellent visualization and true small-pupil capability
■Adjusts to handle interpupillary distances of 49 mm to 75 mm
■SoftTilt™ park/rest feature allows optics to be moved to
a stationary position out of your line of vision
■Halogen light source is one of the brightest, longest-lasting BIO lamps
■Vital optics and mirror assemblies are sealed against dirt
and dust for long-term clear viewing and durability
■Diffuser filter broadens the illumination beam for
enhanced viewing of the peripheral retina
■Choose portable power source or versatile wall/desk power source
12500 Binocular Indirect Ophthalmoscope
12500-D Binocular Indirect Ophthalmoscope with Diffuser Filter
12500-Y Binocular Indirect Ophthalmoscope with Yellow Filter
12500-DY Binocular Indirect Ophthalmoscope with Diffuser and Yellow Filter
74350 Wall/Desk Power Source for BIO
74360 Portable Power Source for BIO
05120-U Soft Carrying Case for BIO (large)
05122-U Soft Carrying Case for BIO (small)
12550 Teaching Mirror
12551 Voltage Adapter (4.5 V- 6 V)
12060 Scleral Depressor
73300 Extension Cord, 8 ft
01200-U BIO Halogen Lamp
72240 BIO Portable Power Supply Replacement Battery
74390 Direct Power Supply
Binocular Indirect Ophthalmoscope: Accessories
12500
Binocular Indirect
Ophthalmoscope
Full-time Safety Filter:
Protects against UV and IR hazards
Mirror Tilt Control:
Optimally synchronizes
illumination and viewing paths
Sealed Optics:
Protect against dirt and
dust for enhanced viewing
and durability
IPD Control:
Adjusts interpupillary
distances from 48 mm
to 75 mm
Halogen Light
Source
Optional
Diffuser Filter:
Broadens the
illumination
beam
Padded
Headband
3838
EYE, EAR, NOSE & THROAT
BINOCULAR INDIRECT OPHTHALMOSCOPE
Oto Acoustic Emission (OAE) Hearing Screener
Precisely and objectively screen for hearing loss in newborns,
infants, toddlers, preschool and school-age children in just seconds.
■Requires minimal patient cooperation
■Fast, accurate results—about 10 seconds per ear;
objective testing—no patient response required
■Clear results that don't require caregiver interpretation—
pass/refer result provided by instrument
■Portable design
■10-test memory storage in device
■Simple printer interface for easy patient data documentation
■Patient information can be downloaded into a PC ASCII file
■Optional power supply: rechargeable lithium battery or AC power
■One-year warranty, extended warranty available
■Can be fitted with a variety of ear tip sizes
29400 OAE Hearing Screener Set, including Printer
29421 OAE Tree Ear Tips, Newborn (20/bag), sample pack consist of 4 each
ofTree Ear Tips/Blue Infant, Pediatric, and Adolescent Ear Tips
29422 OAE Tree Ear Tips, Newborn (100/bag)
29423 OAE Blue Infant Ear Tips (20/bag)
29424 OAE Blue Infant Ear Tips (100/bag)
29425 OAE Pediatric Foam Ear Tips (20/bag)
29426 OAE Pediatric Foam Ear Tips (100/bag)
29427 OAE Adolescent Foam Ear Tips (20/bag)
29428 OAE Adolescent Foam Ear Tips, (100/bag)
29420 OAE Ear Tip Sampler Pack (Newborn, Infant, Pediatric, Adolescent)
29450 OAE Label Printer
29451 OAE Label Roll Replacement, Self-adhesive, (220/roll)
29440 OAE Carrying Case (Optional case for Screener Set Only, No Printer)
29402 OAE Ear Probe, Nozzle and Quick Guide
29410 OAE Test Cavity (5/bag)
29411 Ear Probe Body Nozzle, OAE (5/bag)
520-PS6VDC OAE Power Supply w/Cord, 6 VDC, 4.0 amp
541-USB001 OAE USB 6' Cable
541-SEKBLE OAE Printer Cable OAE to printer
29400
OAE Hearing Screener Set,
including Printer
29421
OAE Tree Ear Tip,
Newborn
29425
OAE Pediatric
Foam Ear Tips
29427
OAE Adolescent Foam
Ear Tips
29423
OAE Blue
Infant Ear Tips
29420
OAE Ear Tip
Sampler Pack
OAE Hearing Screener: Accessories
39
EYE, EAR, NOSE & THROAT
HEARING SCREENER
Ear Wash System
Turn cerumen removal into a clean, quick, safe procedure with the
first system to simultaneously irrigate and suction discharge using
Hydrovac Action.
■Eliminates messy outflow by automatically dislodging,
removing and disposing of cerumen
■Transparent tip seals tightly and directs outflow back
to sink and away from you and your patient
■You control and monitor suction, water temperature and pressure
■Designed to reduce typical side effects like vertigo, nausea, and
tympanic membrane damage
29350 Ear Wash System
29360 Ear Tips for Ear Wash System (case of 4 boxes or 100 ear tips)
29373 Domestic Aerator Adapter Kit
29330 Hose Assembly (10 ft)
Ear Wash System: Accessories
29350
Earwash System
Water Chamber with
Hydrovac Action
4040
EYE, EAR, NOSE & THROAT
EAR WASH SYSTEM
MicroTymp® 3 Portable Tympanometric Instrument
Portable, reliable, cost-effective tympanometry for patients
of all ages.
■1000 Hz Quick Interpretation Mode for Testing of Infants less than 6 Months
■Enhanced, Field Upgradeable Software
■Welch Allyn Quality and Enhanced Serviceability
93650 MicroTymp3 Set with Charging Stand and Printer
23650 MicroTymp3 Handle Only (includes handle, battery and tip box with
2 tips of each size)
24620 MicroTymp3 Tip Box with (2) tips of each size
24621 4 Extra Small MicroTymp3 Tips, 7 mm (Black)
24622 4 Small MicroTymp3 Tips, 9 mm (Gray)
24623 4 Medium MicroTymp3 Tips, 12 mm (Blue)
24624 4 Large MicroTymp3 Tips, 16 mm (Green)
24625 4 Extra Large MicroTymp3 Tips, 20 mm (White)
72910 MicroTymp3 Replacement Battery
71170 MicroTymp3 Portable Tympanometric Instrument Printer/Charger
55260 MicroTymp3 Card Holder (included in set #93650)
55270 MicroTymp3 1000 Hz Documentation Card, 100 each
(starter pack included in set)
56100 Thermal Paper (5 rolls/box)
23650
MicroTymp3 Handle Only
with two sets of Probe Tips
93650
MicroTymp®3 Set with
Charging Stand and Printer
24620
MicroTymp3 Tip Box
MicroTymp3 Portable Tympanometric Instrument: Accessories
Large MicroTymp
Probe Tip (Gray)
Thermal
Printer
Paper
Charging Stand
41
EYE, EAR, NOSE & THROAT
TYMPANOMETRIC SYSTEMS
TM 286™ AutoTymp®
■Tympanometry, ipsilateral acoustic reflex testing, and manual or
automated audiometry packaged in a single, user-friendly device
■Multifunction capability enables management of ear health through
detection and documentation of otitis media, perforated tympanic
membrane, patent tympanostomy tube, ossicular disruption, and tympanos
28600 TM 286 Auto Tymp
05260-U TM 286 Carrying Case
23220 Audiometry Patient Response Switch
23221 Audiometry Single Patch Cord, 2-Conductor
23222 Audiometry AudioCups
26008 TM 286 Ear Tips 8 mm (box of 25)
26011 TM 286 Ear Tips 11 mm (box of 25)
26013 TM 286 Ear Tips 13 mm (box of 25)
26015 TM 286 Ear Tips 15 mm (box of 25)
26017 TM 286 Ear Tips 17 mm (box of 25)
26019 TM 286 Ear Tips 19 mm (box of 25)
26100 TM 286 Ear Tips (6 sizes, 2 each)
26241 TM 286 Test Cavity
28206 Threshold Audiometry Card
28203 Audiometry Headset External—DD45
28601 TM 286 Power Brick
28602 TM 286 Cord, Power, Hosp Grade
52600 TM 286 Printer Paper, 4" Thermal, 5 rolls
28604 TM 286 Quick Reference Guide
28210 Audiometry Y-cord Headset, 2-Plug Shielded
TM 286 AutoTymp: Accessories
4242
EYE, EAR, NOSE & THROAT
TYMPANOMETRIC SYSTEMS
28600
TM 286 Auto Tymp®
AM 282™ Manual Audiometer
■Quantifies specific dB and frequency hearing loss with precision testing
■Offers a full range of frequencies and intensity levels
■Frequency-modulated stimulus mode for reliable
results with children and elderly patients
28200 AM 282 Manual Audiometer with Case
28201 AM 282 Power Supply
28202 AM 282 Carry Case
28206 Threshold Audiometry Card
28207 AM 282 Power Plug
28208 AM 282 Audiogram Forms (1 pad of 50)
28203 Audiometry Headset External-DD45
28210 Audiometry Y-Cord Headset 2-Plug Shielded
23220 Audiometry Patient Response Switch
23221 Audiometry Single Patch Cord, 2-Conductor 23222
Audiometry Audio Cups
AM 282 Manual Audiometer: Accessories
43
EYE, EAR, NOSE & THROAT
AUDIOMETERS
28200
AM 282 Manual Audiometer
28202
AM 282 Carry Case
44
AudioScope® 3 Screening Audiometer
View the tympanic membrane and ear canal while screening for
hearing loss, quickly and accurately.
■Halogen light and fiber optics enable brilliant view of tympanic
membrane and ear canal before and during screening
■Choice of three screening levels—20 dB HL, 25 dB HL and
40 dB HL—at 500, 1000, 2000 and 4000 Hz for all ages
■Built-in 1000 Hz pretone lets patients "practice" listening first
92680 AudioScope 3 Set (AudioScope 3, set of AudioSpec® Specula, 110-130 V
Charging Transformer, Recording Forms)
92600 AudioScope 3, Complete (AudioScope 3, set of AudioSpec Specula,
110-130 V Charging Transformer, Charging Stand, Recording Forms)
23300 AudioScope 3 with AudioSpec® Specula (Handle Only)
71123 3.5 V AudioScope 3 Charging Stand only (without transformer)
71040 Charging Transformer only
05232-U Soft Carrying Case for AudioScope 3
23303 Small AudioSpec Speculum for AudioScope 3
23305 Medium AudioSpec Speculum for AudioScope 3
23307 Large AudioSpec Speculum for AudioScope 3
23400 Set of 3 AudioSpec Specula for AudioScope (Small, Medium, Large)
72300 Replacement NiCad Rechargeable Battery (Orange)
55230 AudioScope 3 Recording Forms (100/pkg, 10 pkg/box),
(Reference number on product is not order number)
06200-U 3.5 V Halogen Lamp
92680
AudioScope® 3 Complete
23300
AudioScope® 3 Handle only shown with
Replacement NiCad Rechargeable
Battery 72300
AudioScope® 3 Screening Audiometer: Accessories
23400
Set of three AudioSpec® Specula
EYE, EAR, NOSE & THROAT
AUDIOMETERS
45
LumiView™ Portable Binocular Microscope
Unique 3-D optics for viewing into small cavities.
■Adapts optical properties of binocular microscope to converge user's
vision into a magnified, stereoscopic three-dimensional view
■Directs cool halogen light to the spot for clear 3-D
image and accurate depth perception
■Simple to use, easy to carry and very affordable
20500H LumiView Portable Binocular Microscope, Head Mount with Portable
Battery Pack
20510H LumiView Portable Binocular Microscope, Head Mount with
Direct Power Source
20520H LumiView Portable Binocular Microscope, Headband Flat-Surface
Magnifier with Portable Battery Pack
20530H LumiView Portable Binocular Microscope, Head Mount Only
20530S LumiView Portable Binocular Microscope, Spectacle Mount Only
20520S LumiView Portable Binocular Microscope, Spectacle Flat-Surface
Magnifier with Portable Battery Pack
20500S LumiView Portable Binocular Microscope, Spectacle Mount with
Portable Battery Pack
08500-U LumiView Replacement Lamp
72250 Rechargeable Battery
05374-U Carrying Case for Spectacle LumiView
75260 Portable Power Source with Charger
75210 Direct Power Supply
21502 Spectacle Holder
74180 Charger Only for Portable Power Source
75200 Portable Power Source only
20500H
LumiView™ Portable
Binocular Microscope
72250
Rechargeable Battery
75200
Portable Power Source only
74180
Charger Only for Portable
Power Source
LumiView Portable Binocular Microscope: Accessories
Halogen Light
Easy Adjustable
Head Band
EYE, EAR, NOSE & THROAT
ILLUMINATORS
46
EYE, EAR, NOSE & THROAT
3.5 V Fiber Optic Transilluminators
General fiber optic examination light for checking pupil reflex.
Transillumination of frontal and maxillary sinuses.
■Fiber optic light transmission for cool distal light
■Fully sterilizable with steam, water, gas or solutions
■Optional cobalt blue filter
41100 3.5 V Finnoff Ocular Transilluminator
41101 3.5 V Finnoff Ocular Transilluminator with Cobalt Blue Filter
43300 3.5 V Curved All-Purpose Transilluminator
03100-U 3.5 V Halogen Lamp
03100-LED LED Upgrade Kit
41102 Cobalt Blue Filter only
41100
3.5 V Finnoff Ocular
Transilluminator
26535
3.5 V Nasal Illuminator
3.5 V Halogen Fiber Optic Transilluminators: Accessories
3.5 V Nasal Illuminators
Halogen HPX® illumination and reusable tip for easy
nasal examinations.
■Fiber optics project cool distal light
■Simply detach the head to use as a throat illuminator/penlight
26535 3.5 V Nasal Illuminator section only
26538 3.5 V Complete Nasal Illuminator
03100-U 3.5 V Halogen Lamp
22009 9 mm Speculum
03100-U 3.5 V Halogen Lamp
22009 9mm Speculum
3.5 V Nasal Illuminators: Accessories
9 mm
43300
3.5 V Curved All-Purpose
Transilluminator
EYE, EAR, NOSE & THROAT
ILLUMINATORS
46
3.5 V Bivalve Nasal Speculum
Halogen HPX® illumination, fiber optics, and adjustable speculum
facilitate easy removal of foreign bodies.
■Fiber Optic light transmission produces cool distal light
■Adjustable speculum facilitates removal of foreign bodies
■Autoclavable for complete sterilization
26038 3.5 V Bivalve Nasal Speculum complete with Illuminator
26035 3.5 V Bivalve Nasal Speculum Section Only
03100-U 3.5 V Halogen Lamp
26330 Magnifying Lens
23857 3.5 V Throat Illuminator Section Only for 23820, 26035, 26535
03100-LED LED Upgrade Kit
3.5 V Bivalve Nasal Speculum: Accessories
3.5 V Nasal Illuminators: Accessories
3.5 V Larynx / Nasopharynx Illuminators
Halogen HPX® illumination and fiber optic light transmission
for easy exams.
■Fiber optic light transmission produces cool distal light
■Wide-angle rotatable mirror with pilot aperture
■Illuminators withstand sterilization with steam, water, gas or solutions
27000 3.5 V Complete Larynx Illuminator
27050 3.5 V Complete Nasopharynx Illuminator
03100-U 3.5 V Halogen Lamp
27010 3.5 V Larynx Mirror Section Only
27070 3.5 V Fiber Optic Illuminator Only
03100-LED LED Upgrade Kit
27000
Larynx Illuminator
EYE, EAR, NOSE & THROAT
ILLUMINATORS
47
26038
3.5 V Bivalve Nasal
Speculum
Fiber Optic Laryngoscope Blades
Removable, repolishable light pipes make these an affordable choice
in fiber optic laryngoscope blades.
■Single-piece stainless steel construction ensures blade integrity
■Damaged light pathways can be repaired at a
fraction of the cost of replacement blades
■Free repolishing service extends product life
69061 #1 MacIntosh Fiber Optic Laryngoscope Blade
69062 #2 MacIntosh Fiber Optic Laryngoscope Blade
69063 #3 MacIntosh Fiber Optic Laryngoscope Blade
69064 #4 MacIntosh Fiber Optic Laryngoscope Blade
69211 #1 E-MacIntosh Fiber Optic Laryngoscope Blade
69212 #2 E-MacIntosh Fiber Optic Laryngoscope Blade
69213 #3 E-MacIntosh Fiber Optic Laryngoscope Blade
69214 #4 E-MacIntosh Fiber Optic Laryngoscope Blade
68065 #00 Miller Halogen Fiber Optic Laryngoscope Blade
68060 #0 Miller Halogen Fiber Optic Laryngoscope Blade
68061 #1 Miller Halogen Fiber Optic Laryngoscope Blade
68062 #2 Miller Halogen Fiber Optic Laryngoscope Blade
68063 #3 Miller Halogen Fiber Optic Laryngoscope Blade
68064 #4 Miller Halogen Fiber Optic Laryngoscope Blade
MacIntosh Fiber Optic
Laryngoscope Blades
E-MacIntosh Fiber Optic
Laryngoscope Blades
Miller Halogen Fiber Optic
Laryngoscope Blades
EYE, EAR, NOSE & THROAT
LARYNGOSCOPES
48
MacIntosh Standard (Lamp) Blades
Part Number Blade Size Overall Length Inside Length (Base to Tip)
69061 #189 mm 63 mm
69062 #2108 mm 82 mm
69063 #3126 mm 101 mm
69064 #4160 mm 135 mm
English MacIntosh Fiber Optic Blades*
69211 #195 mm 70 mm
69212 #2116 mm 90 mm
69213 #3135 mm 110 mm
69214 #4156 mm 130 mm
Miller Halogen Fiber Optic Blades*
68065 #00 8 mm 36 mm
68060 #08 mm 53 mm
68061 #18 mm 79 mm
68062 #210 mm 132 mm
68063 #311 mm 172 mm
68064 #413 mm 182 mm
*Dimensions are approximate
Fiber Optic Laryngoscope Handles
Bright, white HPX® illumination offers a clear color-corrected view.
■Patented HPX technology blends halogen and xenon gases
under pressure to produce a bright, white light for true
tissue color and consistent, long-lasting illumination
■Up to 40% lighter than our previous design, for increased
responsiveness and maneuverability
■Knurled finish ensures secure grip
■Single HPX lamp cartridge design used across all sizes of 2.5 V handles
60813 2.5 V Medium, uses two C-size batteries
60814 2.5 V Penlight, uses two AA-size batteries
60815 2.5 V Stubby, uses two AA-size batteries
60713 2.5 V Handle only
60835 3.5 V Handle only
60813
2.5 V Medium
Handle
60814
2.5 V Penlight
Handle
60815
2.5 V Stubby
Handle
60713
2.5 V Handle only
60835
3.5 V Handle only
Lightweight Fiber Optic HPX Handles
2.5 V Rechargeable Fiber Optic HPX Handle
3.5 V Rechargeable Fiber Optic HPX Handle
EYE, EAR, NOSE & THROAT
LARYNGOSCOPES
49
Lightweight Fiber Optic HPX Handles
Part Number Description
60813 2.5 V Medium, uses two C-size batteries
60814 2.5 V Penlight, uses two AA-size batteries
60815 2.5 V Stubby, uses two AA-size batteries
608125-501 2.5 V Halogen HPX Gold Lamp Cartridge Assembly
608107 Switch Plunger/Lamp Shield
0600-U 2.5 V Halogen HPX Replacement Lamp
2.5 V Rechargeable Fiber Optic HPX Handle
60713 2.5 V Handle only
71140 Charger only, 110-130 V, 50/60 Hz
72000 2.5 V NiCad Rechargeable Battery
608125-501 2.5 V Halogen HPX Gold Lamp Cartridge Assembly
06000-U 2.5 V Halogen HPX Replacement Lamp
3.5 V Rechargable Fiber Optic HPX Handle
60835 3.5 V Handle only
71140 Charger only, 110-130 V, 50/60 Hz
72200 3.5 V NiCad Rechargeable Battery
608351-501 3.5 V Halogen HPX Gold Lamp Cartridge Assembly
608107 Switch Plunger/Lamp Shield
00300-U 3.5 V Halogen HPX Replacement Lamp
50
EYE, EAR, NOSE & THROAT
608107 Switch Plunger/Lamp Shield (for use with Lightweight, 2.5 V and 3.5 V
Rechargeable Fiber Optic Laryngoscope Handles)
608125-501 2.5 V Halogen HPX Silver Lamp Cartridge Assembly (for use with
Lightweight and 2.5 V Rechargeable Fiber Optic Laryngoscope Handles)
06000-U 2.5 V Halogen HPX Replacement Lamp (for use with Lightweight and 2.5 V
Rechargeable Fiber Optic Laryngoscope Handles)
72000 2.5 V NiCad Rechargeable Battery
72200 3.5 V NiCad Rechargeable Battery
00300-U 3.5 V Halogen HPX Replacement Lamp
71140 Charger only, 110-130 V, 50/60 Hz
608351-501 3.5 V Halogen HPX Gold Lamp Cartridge Assembly
LARYNGOSCOPES
Fiber Optic Laryngoscope Handles: Accessories
51
EYE, EAR, NOSE & THROAT
LARYNGOSCOPES
Fiber Optic Laryngoscope Sets
A unique design that's stronger, safer, upgradeable and lower cost
over the life of the instrument.
■Single-piece stainless steel construction ensures blade integrity
■Removable light pipe and smooth surface design
■Free fiber optic repolishing service extends product life
■Blades are upgradeable and repairable at a fraction of the cost of
replacement blades
69696 MacIntosh #1, 2, 3, 4 Fiber Optic Laryngoscope Set with Case
69697 E-MacIntosh #1, 2, 3, 4 Fiber Optic Laryngoscope Set with Case
68696 Miller #0, 1, 2, 3, 4 Fiber Optic Laryngoscope Set with Case
65121 Miller #0 and 2 and MacIntosh #3 and 4 Popular Mixed-Blade Fiber Optic
Laryngoscope Set with Case
65122 Miller #0 and 2, MacIntosh #3 and 4 Popular Mixed-Blade Fiber Optic
Laryngoscope Set with Case
65123 Miller #0 and 2, MacIntosh #3 and 4 Popular Mixed-Blade Fiber Optic
Laryngoscope Set with Case
65124 Miller #0 and 2, E-MacIntosh #3 and 4 Popular Mixed-Blade Fiber Optic
Laryngoscope Set with Case
65125 Miller #0 and 2, E-MacIntosh #3 and 4 Popular Mixed-Blade Fiber Optic
Laryngoscope Set with Case
65126 Miller #0 and 2, E-MacIntosh #3 and 4 Portable Fiber Optic Laryngoscope
Set with Case
Fiber Optic Sets with Case
Popular Mixed-Blade Style Fiber Optic Sets with Case
68696
Miller #0, 1, 2, 3, 4
65122
Miller #0 and 2, MacIntosh #3
and 4, with Medium (60813) and
Stubby Battery Handles (60815)
and Case (05700)
52
65103
MacIntosh #3 and 4 with
Medium Handle
EYE, EAR, NOSE & THROAT
LARYNGOSCOPES
Fiber Optic Sets with Case
Part Number Blades Handles Case
69696 MacIntosh #1, 2, 3, 4 Medium and Penlight 05691-U
69697 English MacIntosh #1, 2, 3, 4 Medium and Penlight 05791-U
68696 Miller #0, 1, 2, 3, 4 Medium and Penlight 05681-U
Popular Mixed Blade Style Fiber Optic Sets with Case
65121 Miller #0 and 2 and MacIntosh #3 and 4 Medium (60813) and
Penlight (60814) 05700
65122 Miller #0 and 2 and MacIntosh #3 and 4 Medium (60813) and
Stubby (60815) 05700
65123 Miller #0 and 2 and MacIntosh #3 and 4 Stubby (60815) and
Penlight (60814) 05700
65124 Miller #0 and 2 and E-MacIntosh #3 and 4 Medium (60813) and
Penlight (60814) 05701
65125 Miller #0 and 2 and E-MacIntosh #3 and 4 Medium (60813) and
Stubby (60815) 05701
65126 Miller #0 and 2 and E-MacIntosh #3 and 4 Stubby (60815) and
Penlight (60814) 05701
Portable Fiber Optic Sets
Sets Include a choice of two blade options, two handle options and a soft vinyl case. The blade options
are for small to medium and medium to large size patients.
65101 MacIntosh #3, Miller #0, Miller #2 Medium (60813)
65102 MacIntosh #3, Miller #0, Miller #2 Penlight (60814)
65103 MacIntosh #3, MacIntosh #4 Medium (60813)
65104 MacIntosh #3, MacIntosh #4 Penlight (60814)
05620-U Portable Case Only, Soft Vinyl Zippered
65101 MacIntosh #3, Miller #0, Miller #2 Portable Fiber Optic Laryngoscope Set
65102 MacIntosh #3, Miller #0, Miller #2 Portable Fiber Optic Laryngoscope Set
65103 MacIntosh #3, MacIntosh #4 Portable Fiber Optic Laryngoscope Set
65104 MacIntosh #3, MacIntosh #4 Portable Fiber Optic Laryngoscope Set
05620-U Portable Case Only, Soft Vinyl Zippered
Portable Fiber Optic Sets
53
Standard (Lamp) Laryngoscope Blades
Reduced blade weight improves balance and maneuverability
for even the toughest intubations.
■Single-piece stainless steel construction ensures blade integrity
■Removable light pipe and smooth surface design
■Blades can be economically upgraded from lamp to fiber optic illumination
■Repairable at a fraction of the cost of a replacement blade
69041 #1 MacIntosh Standard (Lamp) Laryngoscope Blade
69042 #2 MacIntosh Standard (Lamp) Laryngoscope Blade
69043 #3 MacIntosh Standard (Lamp) Laryngoscope Blade
69044 #4 MacIntosh Standard (Lamp) Laryngoscope Blade
69241 #1 E-MacIntosh Standard (Lamp) Laryngoscope Blade
69242 #2 E-MacIntosh Standard (Lamp) Laryngoscope Blade
69243 #3 E-MacIntosh Standard (Lamp) Laryngoscope Blade
69244 #4 E-MacIntosh Standard (Lamp) Laryngoscope Blade
MacIntosh Standard
(Lamp) Blades
E-MacIntosh Standard
(Lamp) Blades
E-MacIntosh Standard (Lamp) Blades
MacIntosh Standard (Lamp) Blades
EYE, EAR, NOSE & THROAT
LARYNGOSCOPES
54
EYE, EAR, NOSE & THROAT
68045 #00 Miller Standard (Lamp) Laryngoscope Blade
68040 #0 Miller Standard (Lamp) Laryngoscope Blade
68041 #1 Miller Standard (Lamp) Laryngoscope Blade
68042 #2 Miller Standard (Lamp) Laryngoscope Blade
68043 #3 Miller Standard (Lamp) Laryngoscope Blade
68044 #4 Miller Standard (Lamp) Laryngoscope Blade
LARYNGOSCOPES
Miller Standard (Lamp) Blades
Miller Standard (Lamp)
Blades
MacIntosh Standard (Lamp) Blades
Part Number Blade Size Overall Length Inside (Base to Tip) Replacment Lamp
69041 #189 mm 63 mm 04700-U
69042 #2108 mm 82 mm 04700-U
69043 #3126 mm 101 mm 04800-U
69044 #4160 mm 135 mm 04800-U
English MacIntosh Fiber Optic Blades
69241 #195 mm 70 mm 04700-U
69242 #2116 mm 90 mm 04700-U
69243 #3135 mm 110 mm 04800-U
69244 #4156 mm 130 mm 04800-U
Miller Standard (Lamp) Blades
68045 #00 8 mm 36 mm 04700-U
68040 #08 mm 53 mm 04700-U
68041 #18 mm 79 mm 04700-U
68042 #210 mm 132 mm 04800-U
68043 #311 mm 172 mm 04800-U
68044 #413 mm 182 mm 04800-U
55
EYE, EAR, NOSE & THROAT
LARYNGOSCOPES
60715
Rechargeable Handle
and Transformer
60200
Large
60300
Medium
60400
Penlight
60305
Stubby
Standard Handles
Part Number Description
60200 Large (uses two “D” batteries)
60300 Medium (uses two “C” batteries)
60400 Penlight (uses two “AA” batteries)
60305 Stubby (uses two “A” batteries)
Rechargeable Standard Handles
60715 Rechargeable Handle and Transformer 110-130 V, 50/60 Hz
60710 Handle only, 2.5 V
71040 Transformer only, 110-130 V, 50/60 Hz
72000 NiCad Rechargeable Battery
Standard Laryngoscope Handles
Built to last. Comfortable grip and finish enhance laryngoscope use.
■Crafted from durable chrome-plated brass with knurled finish for sure grip
60200 Large (uses two “D” batteries)
60300 Medium (uses two “C” batteries)
60400 Penlight (uses two “AA”batteries)
60305 Stubby (uses two “AA” batteries)
60715 Rechargeable Handle and Transformer 110-130 V, 50/60 Hz
60710 Handle only, 2.5 V
71040 Transformer only, 110-130 V, 50/60 Hz
72000 NiCad Rechargeable Battery
Standard Handles
Rechargeable Standard Handles
56
Standard Laryngoscope Sets
A unique design that‘s stronger, safer, upgradeable and lower cost
over the life of the instrument.
■Single-piece stainless steel construction ensures blade integrity
■Removable light pipe and smooth surface design
■Blades are upgradeable to fiber optic and repairable at a fraction of the
cost of replacement blades
69096 MacIntosh Laryngoscope Set # 1, 2, 3 and 4 Standard Laryngoscope Set
69097 E-MacIntosh Laryngoscope Set # 1, 2, 3 and 4 Standard Laryngoscope Set
68096 Miller Laryngoscope Set # 0, 1, 2, 3 and 4 Standard Laryngoscope Set
65221 Miller Set #0 and 2, Universal MacIntosh #3 and 4 Mixed-Blade Standard
Laryngoscope Set
65222 Miller Set #0 and 2, Universal MacIntosh #3 and 4 Mixed-Blade Standard
Laryngoscope Set
65223 Miller Set #0 and 2, Universal MacIntosh #3 and 4 Mixed-Blade Standard
Laryngoscope Set
65224 Universal Miller #0 and 2, E-MacIntosh Set #3 and 4 Mixed-Blade Standard
Laryngoscope Set
65225 Universal Miller #0 and 2, E-MacIntosh Set #3 and 4 Mixed-Blade Standard
Laryngoscope Set
65226 Universal Miller #0 and 2, E-MacIntosh Set #3 and 4 Mixed-Blade Standard
Laryngoscope Set
Specific Blade Style Standard Sets (Lamp)
Popular Mixed-Blade Style Standard Sets (Lamp)
69096
MacIntosh Laryngoscope Set #1, 2, 3
and 4 with Medium (60813) and Penlight
(60814) Handles with Case
65202
MacIntosh # 3, Miller # 0,
Miller # 2 and Penlight Handle
(60814) with Case
EYE, EAR, NOSE & THROAT
LARYNGOSCOPES
65201 MacIntosh # 3, Miller # 0, Miller # 2 Portable Standard Laryngoscope Set
65202 MacIntosh # 3, Miller # 0, Miller # 2 Portable Standard Laryngoscope Set
65203 MacIntosh # 3, MacIntosh # 4 Portable Standard Laryngoscope Set
65204 MacIntosh # 3, MacIntosh # 4 Portable Standard Laryngoscope Set
57
Portable Standard Sets
EYE, EAR, NOSE & THROAT
LARYNGOSCOPES
Specific Blade Style Standard Sets (Lamp)
Part Number Blades Handles Case
69096 MacIntosh #1, 2, 3, 4 Medium and Penlight 05691-U
69097 English MacIntosh #1, 2, 3, 4 Medium and Penlight 05791-U
68096 Miller #1, 2, 3, 4 Medium and Penlight 05681-U
Popular Mixed Blade Style Standard Sets (Lamp)
Sets includes four blades, two handles and a case. Two blades are Miller blades sizes #0 and 2.
The other two blades are sizes #3 and 4 either MacIntosh or English MacIntosh style. The models
also vary by handle configuration.
65221 Miller #0 and 2, Universal MacIntosh #3 and 4 Medium and Penlight
65222 Miller #0 and 2, Universal MacIntosh #3 and 4 Medium and Stubby
65223 Miller #0 and 2, Universal MacIntosh #3 and 4 Stubby and Penlight
65224 Universal Miller #0 and 2, and Engligh MacIntosh
Set #3 and 4 Medium and Penlight
65225 Universal Miller #0 and 2, and Engligh MacIntosh
Set #3 and 4 Medium and Stubby
65226 Universal Miller #0 and 2, and Engligh MacIntosh
Set #3 and 4 Stubby and Penlight
Portable Fiber Optic Sets
Sets include a choice of two blade options, two handle options and a soft vinyl case.
The blade options are for small to medium and medium to large size patients.
65201 MacIntosh #3, Miller #0, Miller #2 Medium
65202 MacIntosh #3, Miller #0, Miller #2 Penlight
65203 MacIntosh #3, MacIntosh #4 Medium
65204 MacIntosh #3, MacIntosh #4 Penlight
