FortiGate®-310B ASIC-Powered Security
at Switching Speeds Datasheet
Distributed Perimeters Require Security at Switching Speeds
Traditional perimeter security technologies have become obsolete in defending against today’s blended security threats. Using multiple attack vectors, these
threats are increasing in volume and sophistication, leveraging every available network connection point to proliferate. Organizations with mobile or remote users
are causing centralized security perimeters to transform into a “distributed perimeter,” enabling new entry points for security threats. With so many network
access points, it has become impossible to deploy a single point of network protection within an enterprise infrastructure.
Internal Segmentation Restraints
As networks grow, administrators aspire to segregate user-groups and applications such as VoIP into smaller security zones for improved security. Dividing the
network with security segmentation points isolates security events, increases policy granularity, and protects sensitive information. Unfortunately most mid-range
security devices lack the interface count or the raw throughput to facilitate extensive internal network security segmentation.
ASIC-Accelerated Multi-Threat Security Solution
The FortiGate-310B answers the call of growing mid-sized networks by integrating a purpose-built security processing ASIC, known as the FortiASIC Network
Processor, designed to deliver security throughput at switching speeds. Eight hardware accelerated interfaces (expandable to 12) allow networks to enforce
firewall policy between network segmentation points for layered security with switch-like performance. An additional purpose-built ASIC, known as the FortiASIC
Content Processor, provides additional acceleration for content intensive security technologies such as intrusion prevention and antivirus scanning for dangerous
traffic streams. The inclusion of an Advanced Mezzanine Card (AMC) expansion slot allows for even more flexibility, offering additional ASIC-accelerated ports for
additional throughput or disk-based storage for local logging and content archiving. With numerous accelerated multi-threat security interfaces, organizations can
create multiple security zones for various departments, users, access methods, and even devices to enforce network security at accelerated speeds.
Fortigate-310B
Base Unit
Fortigate-310B
with Optional 4-Port AMC Module (ASM-FB4)
Feature Benefit
Hardware Acceleration Up to 12Gbps FW & 9Gbps VPN combined
with 800Mbps IPS and AV acceleration
ensures security is never a bottleneck
Ten 10/100/1000 interfaces
(expandable to 14)
Facilitates numerous internal segmentation
points throughout the network
Modular Expansion Flexible expansion options for four
additional NP-accelerated ports or HDD for
local logging and archiving
Unified Security Architecture Multi-threat protection from a single device
increases security and lowers costs
Fortinet’s Multi-Layered Security Solution
Fortinet’s multi-layered security solutions efficiently and economically provide an integrated set of
security services in a single, easy-to-manage high-performance appliance that is capable of
supporting a wide range of deployment scenarios. In addition, FortiGuard Subscription Services
include everything from technical support, antivirus updates, antispyware, antispam, and Web
content filtering to ensure that your security environment remains current and your corporate
resources are protected against the latest blended threats. FortiGate systems come with a one-year
limited hardware warranty and 90-day limited software warranty.
Multi-Layered Security Services
Hardware Accelerated
Network / Content Processing
Firewall
IDS / IPS
Antivirus / Antispyware
Web Filtering
Antispam
Traffic Shaping
IPsec / SSL VPN
Complete Content
Protection
Multi-Layered Security
Integrated
Management, Logging & Reporting
FortiGate
310B
Base Unit
310B with
Optional
ASM-FB4
Hardware Specifications
Total 10/100/1000 Interfaces 10 14
Configurable Ports 10 14
AMC Expansion Slot 1 Single
Width
N/A
System Performance
Firewall Throughput – Avg Size Packets (512 byte) 8 Gbps 12 Gbps
Firewall Throughput – Small Size Packets (64 byte) 8 Gbps 12 Gbps
IPSec VPN Throughput 6 Gbps 9 Gbps
Antivirus Throughput* 160 Mbps
IPS Throughput* 800 Mbps
Dedicated IPSec VPN Tunnels 3,000
Concurrent Sessions 500,000
New Sessions/Sec 20,000
Policies 8,000
Unlimited User Licenses Yes
Dimensions
Height 1.75 inches (4.45 cm)
Width 17 inches (43.18 cm)
Length 12.6 inches (32 cm)
Weight 14 lbs (6.35 kg)
Rack Mountable Yes
AC Power Required 100 - 240 VAC, 60 - 50
Hz, 5 - 3 Amp (Max)
Power Consumption (AVG) 120W
Environment
Operating temperature 32 to 104 deg F (0 - 40
deg C)
Storage temperature -13 to 158 deg F (-25 to
70 deg C)
Humidity 5 to 95% non-condensing
Compliance FCC Class A Part 15,
UL/CUL, C Tick, VCCI
Certifications ICSA Labs: Firewall, IPSec,
Antivirus, IPS, Antispyware
* Antivirus performance is measured based on HTTP traffic with 32Kbyte file
attachments and IPS performance is measured based on UDP traffic with 512byte
packet size. Actual performance may vary depending on the network traffic and
environment.
The FortiGate-310B Offers:
• ASIC-Powered firewall security at switching speeds
• Leading price/performance ratio
• Customizable expansion options
• Highest port density of any product in its class
• Multi-threat security from a single device
Fortinet Advanced Mezzanine Card (AMC)
Expansion Modules
The AMC standard, also known as AdvancedMC™, was developed by the
PCI Industrial Computers Manufacturers Group (PICMG), which has over 100
companies building to the specification. AdvancedMC has been developed to
meet the requirements for the next generation of carrier grade
communications equipment.
4-Port Gigabit Ethernet Module
ASM-FB4
• 4-Port FortiASIC hardware
accelerated Gigabit SFP module
• (Includes 4x SX SFP transceivers)
• 4 Gbps Firewall performance
• 3 Gbps IPsec (3DES) VPN
performance
80 GB AMC Storage Module
ASM-S08
• 80 Gigabyte hard disk drive storage
module
• High duty cycle hard drive design
FortiGuard Security Subscription Services
With FortiGuard® Security Subscription services enabled, customers can rest assured that their Fortinet security platforms are performing optimally and protecting their corporate assets with the latest security
intelligence. FortiGuard services deliver the latest security content directly to Fortinet products. Fortinet offers four standard subscription services: Antivirus, Intrusion Prevention, Web Filtering and Antispam
services to protect against multiple types of new and emerging threats. FortiGuard services are updated by the Fortinet Global Threat Research Team, a team of experts working around the clock and around
the world to keep Fortinet customers secure. The Fortinet Global Threat Research Team enables Fortinet to deliver comprehensive multi-threat protection, including zero-day protection from new and emerging
threats. The FortiGuard Network is a network of global data centers that automatically deliver updates quickly and reliably to Fortinet products.
For customers requiring guaranteed response time to suspicious malware threats, Fortinet offers a premier version of the FortiGuard Antivirus Security Subscription service. Along with Service Level
Agreements (SLAs), the premier service provides the customer with a direct conduit to the Fortinet Global Threat Research Team.
Fortinet also offers a premier version of the FortiGuard Web Filtering Security Subscription service. This higher-tier service offering includes guaranteed SLAs and a larger quota for rating URLs submitted to
the Fortinet Global Threat Research Team.
FortiCare Support Services
Includes:
• 24/7/365 FortiCare Web-based support • 8x5 telephone-based technical support (24x7 - optional) • 1-Year limited hardware warranty
• Technical account management service available • Professional services available
®
