Designed to mount on any MIL-STD-1913 rail interface forward of an existing
scope, the FLIR Thermosight® T75 offers mission exibility as a long range thermal
weapon sight and hand-held as an observation device. The T75 is designed to
interface with a wide range of day scopes and weapon platforms.
The T75 is highly portable, runs on common AA Li batteries and is equipped
with large, rugged controls for image adjustment. FLIR is committed to providing
Imaging solutions that are mission ready and world class in their performance. The
Thermosight® T75 is no exception.
www.flir.com
Long-Range Thermal Weapons Sight
Thermosight® T75
Thermosight® T75 in the eld
APPLICATIONS
• Target Acquisition
• Reconnaissance
• Covert Operations
• Surveillance
• Speciality Law Enforcement
KEY FEATURES BENEFITS
Multi-use design Optimized as a clip-on thermal sight. Use in front of a day
optics as a clip-on, rail mounted thermal weapon sight.
Is compatible with all combat optics and is rapidly
adaptable to most weapons platforms.
Longwave thermal imaging sensor Provides crisp imagery daylight through total darkness,
fog, smoke, dust, and most obscurants
In-line conguration Low prole minimizes height above rail reducing
interference with other devices and snag hazards
Ergonomic user-interfaces Allows operators to keep positive control of the weapon’s
aimpoint while adjusting the sight
Quick detach locking throw lever Compatible with any MIL-STD-1913 Picatinny rail system
Multiple Control Options On sight joystick controls and optional remote control
pendant maintains shooter cheek weld
E-Zoom Unity mag and 2x, 4x E-Zoom
Rugged, small, and lightweight Minimizes impact on host weapon and reduces
operator fatigue. Designed for extreme operating
environments and tested to withstand thousands of
rounds of gun shock
All FLIR Inside FLIR controls the entire supply chain of the critical
technology inside the T75 ensuring fast service and
long term support.
FLIRTHERMOSIGHT
T75
®
System Characteristics
www.flir.com
Thermal Imaging Performance
Sensor type 640 x 512 Long Wave IR Sensor
Wide FOV 9.4° h x 7.5° v
E-zoom 1X, 2X, 4x
Spectral band 8-12 μm
System Features
Silent operation Inaudible beyond 1m
Long Range Detection Detect targets >800 meters (with day optic)
Boresight retention Maintains boresight after weapons ring
Video Output Standard NTSC or PAL video output (factory congured)
Controls and Display
Mini Joystick Control Color palettes, Polarity, Zoom, Digital Detail Enhancement,
Brightness/ Contrast, Windage/ Elevation, Menu
Menu Function Calibration, Display Mode, External Video,
Weapon Select, Reticle Alignment, POA/POI
Display Color OLED
Power
Power requirements Internal Replaceable Primary Batteries
Battery Types 3 EA. AA Lithium (L91)
Battery Run Time Minimum 5 hours at 23°C
Environmental
Waterproof MIL-STD-810G Blowing Rain
Water Immersion MIL-STD 810G Immersion, 1 meter for 30 minutes
Temperature Operating: -30°C to +50°C (-22°F to +122°F)
Storage: -40°C to +71°C (-40°F to +160°F)
Weapon Shock Compatible with 5.56, 7.62 NATO, .338 Lapua
EMI MIL-STD-461F RS103
Dimensions, Weight and Mounting
Weight 1 kg (2.2 lb.), with batteries and throw lever mount
Mounting Detachable Throw Lever Mount, Compatible with Picatinny Rail System
Dimensions 7.5” L x 3” W x 3.5” H (190mm L X 76.2mm W X 90mm H)
Available Accessories
Soft Carry Case Lightweight with padded zippered compartments
Lens Cap Molded lens cap, attached to unit
Light Shroud Molded Light Shroud, ts between unit and customer’s day scope
Lens cleaning kit Complete Cleaning Kit in Nylon Pouch
Operators Manual Written Instruction on Unit Operation (English)
Quick Reference Card Laminated Graphical Training Aid (English)
Batteries 6 ea. L91 AA Lithium
Remote Control Remote control pendant for camera operation
Video Cable Cable for video output to standard display
Equipment described herein is subject to US export regulations and may
require a license prior to export. Diversion contrary to US law is prohibited.
Imagery for illustration purposes only. Specications are subject to change
without notice. ©2017 FLIR Systems, Inc. All rights reserved. 08/18/2017
