CATALOGUE
2013.2014
Video Intercoms
Home Automation
Access Control
The Best Way
to Communicate
Farfisa has been synonymous with Intercoms since 1967 when
it already represented the division devoted to the residential
communication of historical musical instruments company.
Just 20 years ago, in 1993, the company implemented a major
change and became autonomous and independent under the
name Aci Farfisa.
The History of Videointercom, Telephony and Security
is characterized by continuous economic growth and growth
in organizational structure, from conquering new market
segments and from the challenges in new sectors related to its
core manufacturing. So today it has an excellent sales and service
network in Italy and abroad, and is sure of its strengths: product
quality, listening to customers, internationalization.
In fact, the all-round qualities are the pride of Aci Farfisa: customer
service to ensure complete satisfaction involves careful design and
selection of materials. The entire production process is followed
step by step with the aim of best meeting the various demands
wherever they are found in the world of Electrical Material
and Security that even come from very different markets. The
company is in fact present and distributes its systems in at least
60 countries worldwide.
Videointercom, Security, Telephony today are integrated into
the sphere of Residential Home Automation for a modern,
complete and reliable range.
MADE IN ITALY
Made in Italy, high Quality
There should be some mention of a value that Aci Farfisa
holds particularly close to its heart: Made in Italy.
For Farfisa to be able to fully create its own projects and its
own productions as well as being a guarantee of success is
a fact that fills with pride and is unquestionably a tangible
sign of high quality, appreciated in Italy and highly sought
after by abroad customers.
The company has also obtained the ISO 9001 quality
certification to ensure the efficient methods and strict
control over the entire production cycle.
Aci Farfisa is associated to
4INTERNAL STATIONS
enter the smart house
With the development of myLogic we are proud to say that resi-
dential communication enters the field of home automation.
The heart of the innovative myLogic line is the advanced video
intercom station designed by Nico Smeenk. It is an elegant,
refined hands-free video intercom with a large 4.3” 16:9 touch
screen LCD-TFT. Clean, elegant design to enhance interior decora-
tion, ergonomic use with clear, intuitive icons, and user interface
with appealing graphics: this is myLogic, easy to install and simple
to use. Thanks to the consolidated Duo System technology, all
main functions - from heating/air conditioning to access control,
irrigation, shutters, etc. - are managed from the myLogic station
in a simple, intuitive way with customization options. Just touch
the screen with your finger or pen, or press the 4 function keys:
the personalized programs created by the user will activate the
connected devices upon occurrence of planned events. myLogic
makes communication easier also inside the home. In addition
to traditional video intercom features, it offers intercom/text
transmission, block notes, lost calls recording with photo from
camera and many other functions.
myLogic is provided with a memory card reader to import
users images (photo frames) that can be used for personalized
screen savers.
myLogic is anyway much more: it is a complete videointercom
range meeting any requirements, always on Duo System, by
offering mainly 3 versions: myLogic ONE with OSD technology,
myLogic Video with advanced videointercom functions up to
myLogic Home Automation. The series is complete with accessories
and installation elements for a customized offer in features,
installation and environment.
myLogic is the new solution by Aci Farfisa to open the doors to
home automation.
5
new
colour communication
style in technology
Extremely essential in the operation keys and into the simple and cured lines which
strongly characterize the look, the new ZHero colour hand free monitor is conceived to
be surface wall mounted.
It uses soft touch keys and it’s the ideal solution for functional and modern environ-
ments where its perfectly integrated thanks also to the optimised dimensions. It perfectly
works with Duo System.
Exhito is the name of the videointercom range that carries
with it all the functions you can expect from a monitor:
state-of-the-art technology and flexibility with a strongly-
characterised appealing design. Distinguished by a thin,
discreet footprint, strong personality and long-lasting
construction, Exhito guarantees numerous features with
7 buttons for automatic switch-on and door lock and 5
buttons for intercom calls and auxiliary services, such as
ring tone deactivation.
The monitor is white, and the grey frame around the 4” LCD
(b/w in the basic version) can be easily changed with green,
blue or metallized grey frames for better integration with
the interior decoration. Exhito is the solution to all system
requirements (also for intercom installations), from tradi-
tional or reduced wiring to the FN4000 and DF6000 digital
systems. But Exhito is much more than that, and can also
be used for Duo System, Aci Farfisa digital system with 2
non-polarised wires.
6
the antivandal door station
DOOR STATIONS
77
Agorà is the new elegant and robust video door station, with
slim and compact shape. Simply conceived, this modular
range uses a few elements to create flexible solutions.
Surface mounted - therefore extremely easy to install - this
modular range is characterized by the very thin profile, so
it slightly protrudes from the wall.
Even in width, Agorà module has reduced dimension,
colour camera is conceived with pin-hole lens while front
plate is made in anodised extruded aluminium. Name-holders
are back lit in original blue colour for easy identification
even in poor lighting conditions.
Agorà can be used with all Aci Farfisa internal stations for
the easiest and the most modern technologies, that means
Duo System, 2-wire digital technology and analogue reduced
wiring technology.
Recently a new proposal has been added to the Agorà line,
the Light one with clear grey plastic front different with
respect to the dark grey colour of the classic version.
It can simply work with all the indoor Farfisa stations, properly
exploiting the most modern and simple system, from Duo
System up to the analogue with reduced wiring.
the subtle art of communication
the best technology
in the smallest space
Digital Video Intercom
DUO SYSTEM
INTERNAL STATIONS
ZHero
myLogic
Echos
Exhito
DOOR STATIONS
Agorà Light
Ago
Profilo
Matrix Style
SYSTEM ELEMENTS
POWER SUPPLIES AND ACCESSORIES
VIDEO KITS
16
17
18
18
19
20
20
22
23
23
24
FN4000
INTERNAL STATIONS
Echos
Exhito
Compact
DOOR STATIONS
Profilo
Matrix Style
SYSTEM ELEMENTS
POWER SUPPLIES AND SERVICE MODULES
30
31
31
32
34
35
35
DF6000
INTERNAL STATIONS
Exhito
DOOR STATIONS
Profilo
Matrix Style
POWER SUPPLIES AND SERVICE MODULES
38
39
41
41
Analogue Video Intercom
Access Control
INTERNAL STATIONS
myLogic
DOOR STATIONS
SYSTEM ELEMENTS
POWER SUPPLIES AND SERVICE MODULES
VIDEO KITS
80
81
82
82
83
PROXIMITY READERS
AUDIO KITS
KEYPADS
86
86
87
DOOR STATION GSM MYCOM
ELECTRONIC PABX’s
INTERCOM - TELEPHONE INTERFACE
PROTECTION DEVICES
90
92
92
92
REDUCED WIRING,
ELECTRONIC CALL
INTERNAL STATIONS
Echos
Exhito
DOOR STATIONS
Agorà Light
Ago
Profilo
Matrix Style
Mody
POWER SUPPLIES AND SERVICE MODULES
VIDEO KITS AND AUDIO KITS
46
47
48
49
49
51
52
53
54
CONVENTIONAL WIRING,
ELECTRONIC CALL SYSTEM
INTERNAL STATIONS
Echos
Exhito
DOOR STATIONS
Profilo
Matrix Style
Mody
POWER SUPPLIES AND SERVICE MODULES
VIDEO KITS
AUDIO KITS
58
59
60
62
63
65
66
67
ALTERNATE CURRENT CALL SYSTEM
INTERNAL STATIONS
700
Project
DOOR STATIONS
Profilo
Matrix Style
Mody
POWER SUPPLIES AND SERVICE MODULES
AUDIO KITS
70
70
71
72
73
75
75
Home AutomationTelephony
16
19
17
20
17
21
26, 32
17
20
26, 32
39, 40 39, 40
18
22
30
26, 27,
32, 33
18 18
31
38
31
38
24 22
26, 32,
34
39, 41
10
DOOR
STATIONS
KITS
INTERNAL
STATIONS
PRODUCT \ TECHNOLOGY CROSS REFERENCE
This picture introduces the complete panorama of the Aci Farfisa products ranges and their
correspondence with the video intercom digital system.
The number of indicated pages allows, at a glance, view of the products available for each
system technology.
Agorà Prolo Prolo Matrix Style Matrix Style Video KitAgorà Light
myLogic
Home Automation
myLogic
video
myLogic
One
Echos Echos ExhitoZHero Exhito
basic
DUO SYSTEM
DUO SYSTEM
FN4000
FN4000
DF6000
DF6000
DUO SYSTEM
FN4000
DF6000
18 18
31
23
38 38
35
DOOR KEEPER
EXCHANGERS
DUO SYSTEM
FN4000
DF6000
13
27
37
Digital Video Intercom
PDX2000 PDX4000
Exhito
basic
Exhito
DUO SYSTEM
FN4000
DF6000
system
color
DUO SYSTEM
The Duo System digital system is characterized by extreme ease of
assembly because it is based on only 2 non-polarized wires. The result
is a clear and substantial saving of time and therefore cost, with the
possibility of wiring and installation errors practically reduced to zero.
The Duo System installation is designed for medium and large systems
and makes work easier even in restructuring situations because the
wiring is simplified and basic.
Another advantage of the system is the possibility of integrating video
surveillance cameras. Duo System is the technology which forms the
backbone of Home Automation, essentially represented by myLogic
and all its applications.
INTERNAL STATIONS
ZHero
myLogic
Echos
Exhito
DOOR STATIONS
Agorà Light
Ago
Prolo
Matrix Style
SYSTEM ELEMENTS
POWER SUPPLIES AND ACCESSORIES
VIDEO KITS
16
17
18
18
19
20
20
22
23
23
24
system
color
14 Digital Video Intercom
DUO SYSTEM
DUO SYSTEM
Duo System is the innovative 2-wire digital system that allows quick and easy assembly of
a Videointercom system, even if it is large in size and considerably complex. The 2 wires which
transmit video, audio, door lock and various controls signals are not polarized, so installation and
maintenance over the years are facilitated maximally, greatly reducing time, cost and wiring errors.
The Duo System technology is consolidated by various successful installations, but that does not
stop it from evolving by integrating new items or accessories to the range that make the system
even more powerful and competitive.
Today, added to the internal stations are the new ZHero line and new version of myLogic, which
today is even more exible, while added to the external stations is Agorà Light, the version with
light grey colour schemes. The range of products is completed with Echos and Exhito for internal
stations with Matrix Style and Prolo for external stations, with digital and traditional call
modules Another plus is PDX2000, the door-keeper exchanger that is exible and practical
which enriches the functionality of the Duo System. The best performance is guaranteed: 200
internal stations and multiple main and secondary external stations with a reduction of time,
cost and wiring errors. Duo System is also the carrier technology of Home Automation
myLogic systems. An interesting benet not to be underestimated: Integration with Video
surveillance systems is possible in the Duo installation.
myLogic
Several main and secondary outdoor stationsUp to 200 indoor stations
Agorà Light
PDX2000
Agorà
ZHero
Prolo
Exhito
Matrix Style
Echos
Surveillance cameras management
Digital door-keeper exchanger
Agorà Light Prolo
EX3262C
ML2002C
DV2421P
DV2421P
2221S
2220S2220S
DV2421P
EH9262CW
/
/
/
/
/
2
2
2
2
2
15
Digital Video Intercom
DUO SYSTEM
Reconstruction
Residential estates
Medium and large residential estates
Installation scheme example
OSD
www.acifarsa.it
new
16 Digital Video Intercom
DUO SYSTEM
INTERNAL STATIONS ZHERO
ZH1262W
Dim: mm 123x168x29
Colour: white
White coloured monitor to be surface wall mounted with 3,5”
LCD display. It’s with soft touch buttons either for functions
activation or to drive OSD system operations. It allows electric
lock release, bell sound exclusion, camera auto switching and
a second lock opening.
ZH1262B
Dim: mm 123x168x29
Colour: black
Black coloured monitor to be surface wall mounted with 3,5”
LCD display. It’s with soft touch buttons either for functions
activation or to drive the OSD system operations. It allows electric
lock release, bell sound exclusion, camera auto switching and
a second lock opening.
INSTALLATION ELEMENTS
ZH1083
Back box. To be used with the bracket and frame of the related colour.
ZH1084W
White coloured bracket and frame to be used with back box ZH1083.
ZH1084B
Black coloured bracket and frame to be used with back box ZH1083.
INTERNAL STATIONS
The series of internal stations available for the Duo System are the most innovative in the
videointercom panorama: ZHero, myLogic, Echos, Exhito. All oer the best performance for
colour Videointercom with design excellence. With dierent versions, installation components
and accessories, the range of choice is very wide and allows you to nd the best compromise for
the functionalities and economical optimisation demands with a view to achieving the greatest
result and thus satisfaction of requirements.
New monitor that fully exploits Duo System technology, the most advanced and versatile
amongst all the installation typologies, hence it nds natural application with ZHero.
It takes advantage of the OSD system to program and to organize details and operation
parameters of the 3,5” display. The soft touch keys allow to easily govern the menu
access and the driving of the functions more frequently used. Essential in the
lines, it’s conceived for being surface mounted with thin
prominence on the wall. It can also be recessed in the
wall using the appropriated mounting elements.
TOUCH
TOUCH
OSD
TOUCHOSD On Screen Display
TOUCH
SCREEN
17
Digital Video Intercom
DUO SYSTEM
INTERNAL STATIONS MYLOGIC
ML2002C
Dim: mm 154x154x30
Colour: white
Colour hands-free myLogic One videointercom for Duo System
Color with OSD technology. 4.3” LCD screen, 16:9 format. 4 function
buttons for the classic videointercom functions (door-lock,
intercommunication, auto switch-on etc..). Compatible with
the PDX2000 digital door-keeper exchanger.
ML2062C
Dim: mm 154x154x30
Colour: white
Colour hand-free videointercom for Duo System Color. 4.3” LCD-
TFT touch screen, 16:9 format. 4 function buttons and instructions
on the graphic interface (by nger touch or nib supplied) for the
classical videointercom functions (door-lock, intercommuni-
cation, auto switch-on etc). Further advanced features video
memory, block notes, memo, photo frame. Software updating and
imported personal pictures are possible through memory card.
ML2262C
Dim: mm 154x154x30
Colour: metal grey and dark anthracite colour
Colour hand-free videointercom with home automation functions
for Duo System Color. 4.3” LCD-TFT touch screen, 16:9 format.
4 function buttons and instructions on the graphic interface (by
nger touch or nib supplied) for the classical videointercom
functions and home automation features. In videointercom area
door-lock, intercommunication, auto switch-on, video memory,
block notes, memo. Home automation functions allow external
devices control through specic interfaces. Software updating and
imported personal pictures are possible through memory card.
INSTALLATION ELEMENTS
ML2083
Dim: mm 148x143x45
Back box for myLogic stations.
WA2160W
Dim: mm 155x150x35
White wall adaptor for surface mounting of myLogic monitors. Made in
plastic, it can be used in all the surface mounting installations of myLogic
monitors, instead of the ush mounting.
WA2160T
Dim: mm 155x150x35
Silver colour wall adaptor for surface mounting of myLogic monitors. Made
in plastic, it can be used in all the surface mounting installations of myLogic
monitors, instead of the ush mounting.
TA2160
Table adaptor for myLogic monitors, to be mounted with WA2160W or
WA2160T, supplied with connection cables.
ACCESSORIES
MC2000W
White plastic cover for myLogic monitors. It allows the personalization
of the videointercom, by changing the one supplied with the monitor.
MC2000T
Silver colour plastic cover for myLogic monitors. It allows the personaliza-
tion of the videointercom, by changing the one supplied with the monitor.
77 >
HOME AUTOMATION
Further info about myLogic
in HOME AUTOMATION section
The OSD (On Screen Display) technology allows to program the functions in a simple
way by the available keys, it allows the visualization of a menu overlapped to the
screen picture, for example it results extremely easy to use for brightness adjustment
while the image is displayed.
On the contrary by the Touch Screen system the commands are directly enabled by
nger touching the screen on the corresponding icons. Therefore immediateness is
the top of the practical operation for setting or planning.
18 Digital Video Intercom
DUO SYSTEM
INTERNAL STATIONS EXHITO
EX3262C
Dim: mm 211x218x62
Colour: white
Colour monitor LCD 4” screen for Duo System Color. Provided with
7 function buttons (auto switch-on, door-opening and further 5
for additional functions).
EX3262
Dim: mm 211x218x62
Colour: white
B/W monitor 4” screen for Duo System. Provided with 7 func-
tion buttons (auto switch-on, door-opening and further 5 for
additional functions).
EX352
Dim: mm 65x218x62
Colour: white
Intercom for Duo System basic version, provided of 3 function
buttons of which 1 lock release and further 2 for additional
functions.
EX362
Dim: mm 83x218x62
Colour: white
Intercom for Duo System, provided with 7 function buttons,
1 of which door-opening and further 6 for additional functions.
INSTALLATION ELEMENTS
WB3262
Wall bracket for EX3262C, EX3262.
TA3160
Table adaptor for Exhito videointercoms. Made in metal, it is provided
with 2.4 m cable with 20 conductors.
TA320
Table adaptor for Exhito intercoms. Made in metal, it is provided with
2.4 m cable with 20 conductors.
ACCESSORIES
MC3000B
Interchangeable cover blue “skycolour that replaces the one provided
for the screen of Exhito monitor.
MC3000G
Interchangeable cover green “spring” colour that replaces the one
provided for the screen of Exhito monitor.
MC3000T
Interchangeable cover silver “champagne” colour that replaces the one
provided for the screen of Exhito monitor.
INTERNAL STATIONS ECHOS
EH9262CW
Dim: mm 208x103x26
Colour: white and grey
Colour boom voice monitor for Duo System in white colour. LCD
3.5” screen, adjustable on horizontal axis. Function buttons for
door-opening, auto switch-on, bell exclusion (with LED indicating
the setting), volume and brightness adjustment and 6 further
buttons for intercommunicating and additional functions.
EH9262CT
Dim: mm 208x103x26
Colour: techno colour
Colour boom voice monitor for Duo System in techno colour. LCD
3.5” screen, adjustable on horizontal axis. Function buttons for
door-opening, auto switch-on, bell exclusion (with LED indicating
the setting), volume and brightness adjustment and 6 further
buttons for intercommunicating and additional functions.
INSTALLATION ELEMENTS
9083
Dim: mm 192x86x26
Back box for wall mounting of EH9262CW and EH9262CT monitors.
WA9100W
Dim: mm 192x86x26
Colour: white
Wall adaptor for surface mounting of EH9262CW monitor.
WA9100T
Dim: mm 192x86x26
Colour: techno grey
Wall adaptor for surface mounting of EH9262CT monitor.
TA9160
Dim: mm 135x240x75
Table adaptor for Echos monitors. For mounting it needs WA9100T or
WA9100W. Compatible with all the systems technologies.
19
Digital Video Intercom
DUO SYSTEM
DOOR STATIONS AGORÀ LIGHT
VD2121CAGL
Dim: mm 99x208x30
Composed by surface mounting box, front plate with frame, cover,
door speaker, colour camera and 1 button for door stations up
to 2 calls, Agorà Light version in light grey. Digital Duo System
technology.
AD2121CAGL
Dim: mm 99x208x30
Composed by surface mounting box, front plate with frame,
cover, door speaker and 1 button for door stations up to 2 calls,
Agorà Light version in light grey. Digital system Duo System.
AGL100TS
Dim: mm 99x208x30
Composed by surface mounting box, front plate with frame for
combination with audio-video or just audio door station up to 8
additional buttons, complete with appropriate connection cables,
Agorà Light version in light grey. Digital system Duo System.
Nearby photo with puch buttons conguration at maximum
extension.
INSTALLATION ELEMENTS
WA01AG
Aluminium wall adaptor that easily allows the replacement of a Mody
external door station ush mounted into a Agorà surface mounted one.
ACCESSORIES
AGL21
Single call button module.
AGL20
Blank button module.
DOOR STATIONS
All ranges of Farsa external stations can be suitably exploited in the Duo System. In this case, it is
Agorà (including the Agorà Light, the new variation with light grey colour with ABS components),
Prolo and Matrix Style anti-vandal protection.
All are modular and with integrated electrical door speaker units, while the Prolo and Matrix
Style oer the possibility of calling with traditional buttons or via digital modules.
20 Digital Video Intercom
DUO SYSTEM
PROFILO AUDIO AND VIDEO MODULES
VD2120CPL
Dim: mm 99x110x17
Audio-video door station for Duo System Color without call
buttons. Colour camera with xed 3.6 mm lens. To be installed
joint with CD213…PL module with conventional buttons or with
digital TD2100PL module.
AD2120CPL
Dim: mm 99x110x17
Audio external door station for Duo System without call buttons.
To be installed joint with CD213…PL module with conventional
buttons or with digital TD2100PL module.
DOOR STATIONS AGORÀ
VD2121CAG
Dim: mm 99x208x30
Composed by surface mounting box, front plate with frame, cover,
door speaker, colour camera and 1 button for door stations up
to 2 calls. Digital Duo System technology.
AD2121CAG
Dim: mm 99x208x30
Composed by surface mounting box, front plate with frame,
cover, door speaker and 1 button for door stations up to 2 calls.
Digital system Duo System.
AG100TS
Dim: mm 99x208x30
Composed by surface mounting box, front plate with frame for
combination with audio-video or just audio door station up to
8 additional buttons, complete with appropriate connection
cables. Digital system Duo System.
Nearby photo with puch buttons conguration at maximum
extension.
INSTALLATION ELEMENTS
WA01AG
Aluminium wall adaptor that easily allows the replacement of a Mody
external door station ush mounted into a Agorà surface mounted one.
ACCESSORIES
AG21
Single call button module.
AG20
Blank button module.
PROFILO DIGITAL DOOR STATIONS
TD2100PL
Dim: mm 99x110x17
Digital door station for Duo System, with aluminium front plate
and 14 steel buttons. Equipped with LCD graphic display. It allows
the call to the user by dialling the corresponding number and
electric lock release by entering the private code. The electronic
index is also integrated, which gives the possibility to scroll the
names in alphabetical order and select the desired one. It can
store up to 200 user names.
21
Digital Video Intercom
DUO SYSTEM
PROFILO
CONVENTIONAL DOOR STATIONS
CD2131PL
Dim: mm 99x110x17
Digital decoder for Duo System with 1 button for conventional
external station, it can code up to 128 users.
CD2132PL
Dim: mm 99x110x17
Digital decoder for Duo System with 2 buttons for conventional
external station, it can code up to 128 users.
CD2134PL
Dim: mm 99x110x17
Digital decoder for Duo System with 4 buttons for conventional
external station, it can code up to 128 users.
CD2138PL
Dim: mm 99x110x17
Digital decoder for Duo System with 8 buttons for conventional
external station, it can code up to 128 users.
PL24S
Dim: mm 99x110x17
Additional module with integrated decoder for external stations
with 4 buttons for Duo System installations.
PL228S
Dim: mm 99x110x17
Additional module with integrated decoder for external stations
with 8 buttons on 2 rows for Duo System installations.
INSTALLATION ELEMENTS PROFILO
PL71
Dim: mm 91x133x47
Back box for 1 module.
PL72
Dim: mm 91x244.5x47
Back box for 2 modules.
PL73
Dim: mm 91x356x47
Back box for 3 modules.
PL81
Dim: mm 118x153x41
Hood cover for 1 module.
PL82
Dim: mm 118x264x41
Hood cover for 2 modules.
PL83
Dim: mm 118x376x41
Hood cover for 3 modules.
PL84
Dim: mm 217x264x41
Hood cover for 4 modules on 2 vertical rows.
PL86
Dim: mm 217x376x41
Hood cover for 6 modules on 2 vertical rows.
PL89
Dim: mm 316x376x41
Hood cover for 9 modules on 3 vertical rows.
PL91
Dim: mm 118x154x80
Surface mounting rain shelter for 1 module.
PL92
Dim: mm 118x265x80
Surface mounting rain shelter for 2 modules.
PL93
Dim: mm 118x377x80
Surface mounting rain shelter for 3 modules.
PL94
Dim: mm 217x264x80
Surface mounting rain shelter for 4 modules on 2 vertical rows.
PL96
Dim: mm 217x376x80
Surface mounting rain shelter for 6 modules on 2 vertical rows.
PL99
Dim: mm 316x376x80
Surface mounting rain shelter for 9 modules on 3 vertical rows.
22 Digital Video Intercom
DUO SYSTEM
AUDIO AND VIDEO MODULES
MATRIX STYLE
VD2120CMAS
Dim: mm 115x115
Colour audio-video external station for Duo System Color without
call buttons. The camera has a xed 3.6 mm lens.
AD2110MAS
Dim: mm 115x115
Audio external door station for Duo System, without call buttons.
DIGITAL DOOR STATION
MATRIX STYLE
TD2100MAS
Dim: mm 115x115
Digital door station for Duo System, with stainless steel front
plate and 14 buttons. Equipped with 16-digit display on 2 lines.
It allows the call from the user by dialling the corresponding
number and electric lock release by entering the private code. The
electronic index is also integrated, which gives the possibility
to scroll the names in alphabetical order and select the desired
one. It can store up to 250 user names.
INSTALLATION ELEMENTS MATRIX STYLE
MAS61
Dim: mm 140x140
Front frame matt titanium grey colour for 1 module.
MAS62
Dim: mm 140x257
Front frame matt titanium grey colour for 2 modules.
MAS63
Dim: mm 140x374
Front frame matt titanium grey colour for 3 modules.
MA71
Dim: mm 128x128x65
Back box for 1 module.
MA72
Dim: mm 128x245x65
Back box for 2 modules.
MA73
Dim: mm 128x362x65
Back box for 3 modules.
MA91
Dim: mm 146x145x92
Surface mounting rain shelter for 1 module.
MA92
Dim: mm 146x262x92
Surface mounting rain shelter for 2 modules.
MA93
Dim: mm 146x379x92
Surface mounting rain shelter for 3 modules.
CONVENTIONAL DOOR STATIONS
MATRIX STYLE
CD2131MAS
Dim: mm 115x115
Digitiser for Duo System with 1 call button for conventional
external door station. It can code up to 128 users.
CD2132MAS
Dim: mm 115x115
Digitiser for Duo System with 2 call buttons for conventional
door station. It can code up to 128 users.
CD2134MAS
Dim: mm 115x115
Digitiser for Duo System with 4 call buttons for conventional
door station. It can code up to 128 users.
MAS24S
Dim: mm 115x115
Module for additional call buttons for Duo System, with 4
call buttons to be connected to CD2131MAS, CD2132MAS or
CD2134MAS. Encoding board for 4 buttons integrated
2221ML
23
Digital Video Intercom
DUO SYSTEM
SYSTEM
ELEMENTS
PDX2000
Dim: mm 209x186x67
Colour: white
Digital door-keeper exchanger. Available functions: internal
station-internal station and external station-internal station
communication, auto-insertion on external door station, day/
night shunted switching, gestione lost calls, guarantee of system
working even with problems with the door-keeper exchanger.
Further features: classication users groups, insertion on a busy
user, opening of many doors even on non-specic demand, memo/
agenda, servant function, dierent colour for display lighting.
Multiple door-keepers exchanger system allowed. Updating
or data import through memory card. Call queuing and call
booking not available.
ST7100CW
Dim: mm 156x224x61
Colour: white
Colour monitor 4” LCD screen, adjustable in inclination, auto
switch-on button and an additional one.
INSTALLATION ELEMENTS
TA7100W
White table adaptor, for ST7100CW monitors. Complete with cable clamp,
junction box and 2.4 m connection cable with 20 wires. To be used with
WB7260 wall bracket.
WB7260
Wall bracket for ST7100CW monitors for connection to PDX2000 door-keep-
er exchanger.
POWER SUPPLIES
AND ACCESSORIES
2220S
Power supply for Duo System for conventional and digital external
door stations. Output 13 Vac/1 A protected against overloading
and shortcircuits. Dim: 3 DIN modules.
2221ML
Flat power supply for myLogic in multi-way installations.
It powers all devices with a proper audio, video and data
impedance.
2221S
Line driver 6 DIN modules. Directly connected to the mains, it
allows power to Duo System riser.
2223
Video amplier for b/w Duo System installations.
2223C
Video amplier for Duo System colour installations.
2230
Flat separator in home automation installations with Duo System
with myLogic.
2273
Digital exchanger for Duo System.
2281
Actuator for Duo System, used to activate auxiliary services, such
as additional door lock, lights, and chimes.
2302
Twisted pair wire for Duo System with single section 1 sq. mm.,
100 m coil.
DV2424P
Video distributor 4 output for Duo System. It is very flexible
and it allows very wide installations. It is used to withdraw the
signal from the riser.
DV2420
Line distributor for Duo System.
DV2421P
Video distributor for Duo System.
DV2422A
Active video line distributor, 2 outputs, specific for myLogic
monitor, it also can be connected to all the other Duo System
devices.
DM2444
Concentrator module that allow to selectively centralize more
door stations and morerisers.
PRS210
15 VA transformer. 127-230 V. 13 Vac. VDE certication. 3 DIN
modules in DIN bar, or it can be mounted on the wall. Can be
used to power art. 2223, 2223C and 2281.
2287
Selector for 4 or 7 exchanges for Duo System. It allows the se-
lection of maximum 4 or 7 surveillance cameras and\or other
services activation.
24 Digital Video Intercom
DUO SYSTEM
MYLOGIC-AGORÀ LIGHT SERIES
ML2002AGLC
One-way colour videokit with myLogic One monitor and Agorà
Light external station.
ML2062AGLC
One-way colour videokit with myLogic videointercom and Agorà
Light external station.
ML2262AGLC
One-way colour videokit with home-automation myLogic monitor
and Agorà Light external station.
VIDEO KITS
One or two family solutions in a practical videokits are available. Easy to install as it is on Duo
System wiring are ready and complete with all components to make up the system.
They are all packed in elegant cases.
MYLOGIC-PROFILO SERIES
ML2002PLC
One-way colour videokit with myLogic One monitor and Prolo
external station.
ML2062PLC
One-way colour videokit with myLogic videointercom and Prolo
external station.
ML2262PLC
One-way colour videokit with home-automation myLogic monitor
and Prolo external station.
MYLOGIC-AGORÀ SERIES
ML2002AGC
One-way colour videokit with myLogic One monitor and Agorà
external station.
ML2062AGC
One-way colour videokit with myLogic videointercom and Agorà
external station.
ML2262AGC
One-way colour videokit with home-automation myLogic monitor
and Agorà external station.
ML2002AGLC MYLOGIC ML2002C+ML2083 AGORÀ LIGHT VD2121CAGL 2220S+2221ML
ML2062AGLC MYLOGIC ML2062C+ML2083 AGORÀ LIGHT VD2121CAGL 2220S+2221S
ML2002AGC MYLOGIC ML2002C+ML2083 AGORÀ VD2121CAG 2220S+2221ML
ML2062AGC MYLOGIC ML2062C+ML2083 AGOVD2121CAG 2220S+2221S
ML2002PLC MYLOGIC ML2002C+ML2083 PROFILO VD2120CPL+CD2131PL+PL72 2220S+2221ML
ML2062PLC MYLOGIC ML2062C+ML2083 PROFILO VD2120CPL+CD2131PL+PL72 2220S+2221S
EH9262AGCW ECHOS EH9262CW+9083+WA9100W+DV2421P AGORÀ VD2121CAG 2220S+2221S+DV2420
EH9262AGCT ECHOS EH9262CT+9083+WA9100T+DV2421P AGORÀ VD2121CAG 2220S+2221S+DV2420
EH9262PLCW ECHOS EH9262CW+9083+ WA9100W+DV2421P PROFILO VD2120CPL+CD2131PL+PL72 2220S+2221S+DV2420
EH9262PLCT ECHOS EH9262CT+9083+WA9100T+DV2421P PROFILO VD2120CPL+CD2131PL+PL72 2220S+2221S+DV2420
EX3262AGC EXHITO EX3262C+WB3262+DV2421P AGORÀ VD2121CAG 2220S+2221S+DV2420
EX3262PLC EXHITO EX3262C+WB3262+DV2421P PROFILO VD2120CPL+CD2131PL+PL72 2220S+2221S+DV2420
ML2262AGLC MYLOGIC ML2262C+ML2083 AGORÀ LIGHT VD2121CAGL 2220S+2221S
ML2262AGC MYLOGIC ML2262C+ML2083 AGORÀ VD2121CAG 2220S+2221S
ML2262PLC MYLOGIC ML2262C+ML2083 PROFILO VD2120CPL+CD2131PL+PL72 2220S+2221S
EX3262AG EXHITO EX3262+WB3262+DV2421P AGORÀ VD2121CAG 2220S+2221S+DV2420
EX3262PL EXHITO EX3262+WB3262+DV2421P PROFILO VD2120CPL+CD2131PL+PL72 2220S+2221S+DV2420
EH9262PLCW/2 ECHOS 2xEH9262CW+9083+DV2421P PROFILO VD2120CPL+CD2132PL+PL72 2220S+2221S+DV2420
EH9262PLCT/2 ECHOS 2xEH9262CT+9083+DV2421P PROFILO VD2120CPL+CD2132PL+PL72 2220S+2221S+DV2420
EX3262PLC/2 EXHITO 2xEX3262C+WB3262+DV2421P PROFILO VD2120CPL+CD2132PL+PL72 2220S+2221S+DV2420
EX3262PL/2 EXHITO 2xEX3262+WB3262+DV2421P PROFILO VD2120CPL+CD2132PL+PL72 2220S+2221S+DV2420
25
Digital Video Intercom
DUO SYSTEM
ECHOS-AGORÀ SERIES
EH9262AGCW
One-way colour videokit with white Echos monitor and Ago
external station.
EH9262AGCT
One-way colour videokit with metal grey colour Echos monitor
and Agorà external station.
EXHITO-AGORÀ SERIES
EX3262AGC
One-way colour videokit with Exhito monitor and Agorà external
station.
EX3262AG
One-way b/w videokit with Exhito monitor and Agorà external
station.
ECHOS-PROFILO SERIES
EH9262PLCW
One-way colour video kit with white Echos monitor and Prolo
external station.
EH9262PLCT
One-way colour video kit with metal grey colour Echos monitor
and Prolo external station.
EH9262PLCW/2
Two-way colour video kit with white Echos monitors and Prolo
external station.
EH9262PLCT/2
Two-way colour video kit with metal grey colour Echos monitors
and Prolo external station.
EXHITO-PROFILO SERIES
EX3262PLC
One-way colour video kit with Exhito monitor and Prolo external
station.
EX3262PL
One-way b/w video kit with Exhito monitor and Prolo external
station.
EX3262PLC/2.
Two-way colour video kit with Exhito monitor and Prolo external
station.
EX3262PL/2
Two-way b/w with Exhito monitor and Prolo external station.
KIT INTERNAL STATIONS DOOR STATIONS POWER SUPPLY
VIDEO KIT COMPOSITION
One-way colour
Two-way colour
One-way b/w
Two-way b/w
One-way colour
home automation
FN4000
The FN4000 digital system based on Farnet technology is especially
designed and manufactured for large and considerably complex
installations.
Thanks to the high quality performance and excellent range of choice
in terms of product range and proven technology guarantee, FN4000
provides the ideal solution in almost all extended system situations,
offering good overall savings in economical terms.
In fact, compared to an analogue system for the same system extension,
FN4000 benefits the installer thanks to simplified wiring, which
obviously means cost savings and reduction of the possibility of errors.
INTERNAL STATIONS
Echos
Exhito
Compact
DOOR STATIONS
Prolo
Matrix Style
SYSTEM ELEMENTS
POWER SUPPLIES AND SERVICE MODULES
30
31
31
32
34
35
35
ProloMatrix Style
Exhito Echos
PDX4000
28 Digital Video Intercom
FN4000
Door Stations
FN4000
The FN4000 digital system is a solution developed on Farnet technology for advanced
Videointercom systems. Farnet includes a series of physical and protocol specifications
according to which they develop digital technology for integrated and flexible systems
for services in residential areas. FN4000 is the alternative proposed to the traditional
analogue method that allows several advantages and features:
simplified wiring with 5 wires per audio system and 5 wires (more coaxial or twisted
pair) per video system, regardless of the number of users, the number of parallel entrances
and the number of staircases
guaranteed solution, even in heavily extended systems
integration of the audio-video secret with electronic calling
• ease of installation thanks to the few conductors and self-diagnosis for digital modules
possibility of integrating PDX4000 door keeper exchanger
use of internal stations on the line Echos and Exhito and Compact audio-only
use of internal stations on the line Profilo and Matrix Style with digital or traditional
calling modules
advantageous quality/price ratio, taking performance and installation factors into
consideration
Internal Stations Digital door-keeper exchanger
EX3160C
+WB3160DG
DV
/
/
/
/ /
5+video line
5+video line
6+video line
7+video line
6+video line
DV
4220
EH9160CWDG
Matrix Style
29
Digital Video Intercom
FN4000
Large residential estates
Medium and large residential estates
Oce block
Installation scheme example
30 Digital Video Intercom
FN4000
ECHOS INTERNAL STATIONS
EH9160CWDG
Dim: mm 208x103x26
Colour: white and grey
Colour hand-free monitor for FN4000 digital system. LCD 3.5”
screen, adjustable on horizontal axis. Function buttons for door-
opening, auto-switch-on, bell exclusion (with LED indicating the
setting), volume and brightness adjustment and further 6 buttons
for intercommunicating and additional functions.
INTERNAL STATIONS
With FN4000, the possible Videointercoms are the series Echos and Exhito, both in colour, exible
and with integrated decoding. Exhito also oers solutions in b/w or in a new colour version that
is more essential in its features, or if demanded audio-only.
Thanks to the proper installation items, for internal stations you can decide on recessed or surface
or table-top mounting with specic solutions for each set.
INSTALLATION ELEMENTS
9083
Dim: mm 192x86x26
Built-in back box for Echos monitor.
WA9100W
Dim: mm 192x86x26
Colour: white
Wall adaptor for surface mounting of white Echos monitor.
TA9160
Dim: mm 240x135x75
Table adaptor for Echos monitor to be mounted with wall adaptor
WA9100W.
31
Digital Video Intercom
FN4000
EXHITO INTERNAL STATIONS
EX3160C
Dim: mm 211x218x62
Colour: white
Colour monitor with LCD 4” screen supplied with 7 function
buttons (auto switch-on, door lock and further 5 for additional
functions). It can be installed in FN4000 digital system if combined
with specic WB3160DG wall bracket.
EX3160
Dim: mm 211x218x62
Colour: white
B/w monitor with LCD 4” provided with 7 function buttons (2
for auto switch-on and door opening and further 5 for additional
functions). For FN4000 digital system if combined with specic
WB3160DG wall bracket.
EX3100C
Dim: mm 211x218x62
Colour: white
Colour monitor LCD 4” screen, basic version, provided with
3 function buttons for auto switch-on, door-opening and
additional functions. For FN4000 systems if connected with
WB3160DG wall brackets.
EX320DG
Dim: mm 83x218x62
Colour: white
Wall bracket to mount on the wall EX3160C or EX3160 monitors
in FN4000 digital systems.
INSTALLATION ELEMENTS
WB3160DG
Wall bracket to mount on the wall EX3160C, EX3160 or EX3100C monitors
in FN4000 digital systems.
TA3160
Table adaptor for Exhito videointercoms. Made in metal, it is provided
with 2.4 m cable with 20 conductors.
TA320
Table adaptor for Exhito intercoms. Made in metal, it is provided with
2.4 m cable with 20 conductors.
ACCESSORIES
MC3000B
Interchangeable cover blue “sky colour that replaces the one provided
for the screen of Exhito monitor.
MC3000G
Interchangeable cover green “spring” colour that replaces the one
provided for the screen of Exhito monitor.
MC3000T
Interchangeable cover silver “champagne” colour that replaces the one
provided for the screen of Exhito monitor.
COMPACT INTERNAL STATION
KM810WDG
Dim: mm 86x211x65
Colour: white
Intercom for FN4000 digital system with integrated decoding.
Provided with 1 button for door-opening and one further for
additional functions
32 Digital Video Intercom
FN4000
PROFILO AUDIO AND VIDEO MODULES
PL40PCDG
Dim: mm 99x110x17
Colour camera module with door speaker integrated without call
buttons. To be joint to TD4100PL or to CD4134PL or CD4138PL
modules with traditional call buttons.
PL42PCDG
Dim: mm 99x110x17
Colour camera module with door speaker integrated with two
call buttons. To be joint to TD4100PL or to CD4134PL or CD4138PL
modules with traditional call buttons.
PL10P
Dim: mm 99x110x17
Audio module with integrated door speaker without call buttons
for conventional wiring systems.
PL11P
Dim: mm 99x110x17
Audio module with integrated door speaker with 1 call button
for 1 conventional wiring systems.
PL12P
Dim: mm 99x110x17
Audio module with integrated door speaker with 2 call buttons
for conventional wiring systems.
PROFILO DIGITAL DOOR STATION
TD4100PL
Dim: mm 99x110x17
Digital door station for FN4000, with aluminium front plate and
14 steel buttons. Equipped with LCD-graphic display. It allows the
call from the user by dialling the corresponding number and
electric lock release by entering the private code. The electronic
index is also integrated, which gives the possibility to scroll the
names in alphabetical order and select the desired one. It can
store up to 200 user names. This integration allows to save further
space considering other modular compositions.
DOOR STATIONS
The Prolo and Matrix Style external stations lines oer various solutions for the FN4000 system.
They are both modular and allow calling with traditional buttons or digital calling components
guided by the display. Prolo in particular will be chosen for space optimization of the module, for
its reduced size in width and for the possibility of a double button. Matrix Style gives guaranted
against vandalism thanks to the IP45 and IK09 degrees of protection while also oering elegant
nishing.
33
Digital Video Intercom
FN4000
CONVENTIONAL DOOR STATIONS
PROFILO
CD4134PL
Dim: mm 99x110x17
Digitizer with 4 buttons for composition with conventional
external stations for digital FN4000 systems. It allows for coding
up to 63 users.
CD4138PL
Dim: mm 99x110x17
Digitizer with 8 buttons for composition with conventional
external stations for digital FN4000 systems. It allows for coding
up to 63 users.
PL24S
Dim: mm 99x110x17
Additional module with integrated decoder for external stations
with 4 buttons for Duo System installations.
PL228S
Dim: mm 99x110x17
Additional module with integrated decoder for external stations
with 8 buttons on 2 rows for Duo System installations.
PL50
Dim: mm 99x110x17
Street number module.
PL20
Dim: mm 99x110x17
Blank module.
PROFILO INSTALLATION ELEMENTS
PL71
Dim: mm 91x133x47
Back box for 1 module.
PL72
Dim: mm 91x244.5x47
Back box for 2 modules.
PL73
Dim: mm 91x356x47
Back box for 3 modules.
PL81
Dim: mm 118x153x41
Hood cover for 1 module.
PL82
Dim: mm 118x264x41
Hood cover for 2 modules.
PL83
Dim: mm 118x376x41
Hood cover for 3 modules.
PL84
Dim: mm 217x264x41
Hood cover for 4 modules on 2 vertical rows.
PL86
Dim: mm 217x376x41
Hood cover for 6 modules on 2 vertical rows.
PL89
Dim: mm 316x376x41
Hood cover for 9 modules on 3 vertical rows.
PL91
Dim: mm 118x154x80
Surface mounting rain shelter for 1 module.
PL92
Dim: mm 118x265x80
Surface mounting rain shelter for 2 modules.
PL93
Dim: mm 118x377x80
Surface mounting rain shelter for 3 modules.
PL94
Dim: mm 217x264x80
Surface mounting rain shelter for 4 modules on 2 vertical rows.
PL96
Dim: mm 217x376x80
Surface mounting rain shelter for 6 modules on 2 vertical rows.
PL99
Dim: mm 316x376x80
Surface mounting rain shelter for 9 modules on 3 vertical rows.
34 Digital Video Intercom
FN4000
MATRIX STYLE
AUDIO AND VIDEO MODULES
MAS42CDG
Dim: mm 115x115
Colour camera and audio module without call buttons with
6 white LED. Autoiris 3.6 mm lens. If equipped with CV01 video
signal is converted in balanced.
MAS43CDG
Dim: mm 115x115
Colour camera and audio module with 1 call button with 6
white LED. Autoiris 3.6 mm lens. If equipped with CV01 video
signal is converted in balanced.
MAS10P
Dim: mm 115x115
Audio module with door speaker, without call button.
MAS11P
Dim: mm 115x115
Audio module with door speaker, with 1 call button.
MAS12P
Dim: mm 115x115
Audio module with door speaker, with 2 call buttons.
CONVENTIONAL DOOR STATIONS
MATRIX STYLE
CD4130MAS
Dim: mm 115x115
Digitizer for conventional push button pannels, it is contained
in a Matrix single module and allows for coding up to 63 users.
MAS24S
Dim: mm 115x115
Module for additional call buttons for FN4000, with 4 call
buttons to be connected to CD4130MAS. Encoding board for
4 buttons integrated.
INSTALLATION ELEMENTS MATRIX STYLE
MAS61
Dim: mm 140x140
Front frame matt titanium grey colour for 1 module.
MAS62
Dim: mm 140x257
Front frame matt titanium grey colour for 2 modules.
MAS63
Dim: mm 140x374
Front frame matt titanium grey colour for 3 modules.
MA71
Dim: mm 128x128x65
Back box for 1 module.
MA72
Dim: mm 245x128x65
Back box for 2 modules.
MA73
Dim: mm 362x128x65
Back box for 3 modules.
MA91
Dim: mm 145x146x92
Surface mounting rain shelter for 1 module.
MA92
Dim: mm 262x146x92
Surface mounting rain shelter for 2 modules.
MA93
Dim: mm 379x146x92
Surface mounting rain shelter for 3 modules.
MATRIX STYLE
DIGITAL EXTERNAL STATION
TD4100MAS
Dim: mm 115x115
Digital door station of Matrix series with front plate and 14 Key
in stainless steel. It is equipped with 16 characters on 2 lines
display. It allows the user chime by dialling the corresponding
number and electric locks release by entering the private code.
The electronic index is also integrated. Scrolling function allows
to display the tenant names in alphabetical sequence and the
call is activated pressing the chime button. It contains up 250
name users.
35
Digital Video Intercom
FN4000
SYSTEM
ELEMENTS
PDX4000
Dim: mm 215x215x89
Colour: white
Digital door-keeper exchanger. Available functions: call
booking, call queuing, internal station-internal station and
external station-internal station communication, door-open,
day/night/night shunted switching.
POWER SUPPLIES
AND SERVICE MODULES
PRS4220
Stabilised power supply, 230 V/127 V. 60 VA. 12 Vdc/13 Vac. Outputs
protected against overloading and short circuits. Dim: 8 DIN modules.
4273P
Digital exchanger, 4 switching exchanges for systems with sec-
ondary door stations and 1 or more main common door stations.
Base: 84x120 mm.
4230
One-way module for intercommunicating and secondary call.
Assembled in container like 8 A DIN module.
4235TVP
Floor decoder that connects 4 monitors (or intercoms) to the
digital line of FN4000 system. Moreover it allows the interface
of a non-digital push button panel to the internal stations con-
nected to the module for example for secondary door stations.
4236
Back box for 4235TVP.
1471
Two command input relay unit (12 Vac; 12/24 Vdc). 3 A modules
in DIN bar.
1472
Exchange exchanger (1 A, 24 V) 3 command input: 12 Vdc/Vac, 24
Vdc and electronic note. Mountable on 3 A DIN module.
DV2
2-output video distributor for coaxial connection. Power supply: 12 Vdc.
DV4
4-output video distributor for coaxial connec tion. Power supply: 12 Vdc.
DV2D
2-output oor distributor for pair cable connection. Power supply:
12/21 Vdc.
DV4D
4-output oor distributor for pair cable connection. Power supply:
12/21 Vdc.
PRS210
Stabilised power supply for assembly on DIN bar. Mains supply
at 230V and 127V. Protected against overloading or overvoltage
by thermoprotectors. It complies with the European safety
standard EN 60065.
476
Video amplier-distributor with 1 input and 5 outputs. Power
supply: 21-24 Vdc. 8 A modules on DIN bar.
CV01
It can be inserted inside Mody and Matrix Style push button
panels, it allows to convert from video signal by non-balanced
line to video signal by balanced line.
CV03
Video signal converter from twisted pair to coaxial cable.
1281
Stabilised power supply 230-127 Vac, 48VA, outputs protected
against overloading and short circuits. Output voltages: 13 Vac
and 21 Vdc. Certication: VDE. 8 A modules on DIN bar.
DF6000
DF6000 is a digital system characterized by flexible solutions and
ease of installation, thanks to a support with just 2 conductors for
audio applications, plus 3 for video. In systems of medium complexity
ease of installation and cost-effectiveness and the typical features
of a Videointercom system are guaranteed.
The system can reach up to 8 inputs in parallel and can be used with
external stations with digital or traditional calling. The DF6000
installation can be in the extended or plus version, which differ in
the number of users, the first extending up to 255, the second up to
110 with doorbell, bell exclusion and volume control. Both versions
can be integrated into the same system.
The proven DF6000 solution offers Exhito internal stations that allow
audio-visual systems, both in colour and in black and white, while the
outer modular stations are on Matrix style or Profilo.
INTERNAL STATIONS
Exhito
DOOR STATIONS
Prolo
Matrix Style
POWER SUPPLIES AND SERVICE MODULES
38
39
41
41
38 Digital Video Intercom
DF6000
EXHITO INTERNAL STATIONS
EX3160C
Dim: mm 211x218x62
Colour: white
Colour monitor with LCD 4” monitor supplied with 7 function
buttons (auto switch-on, door lock and further 5 for additional
functions). It can be installed in DF6000 digital system if combined
with specic WB3162 wall bracket.
EX3160
Dim: mm 211x218x62
Colour: white
B/w monitor with 4” screen equipped with door opener button
and additional further buttons. It can be installed in DF6000
digital systems if joint to WB3162 wall bracket.
EX3100C
Dim: mm 211x218x62
Colour: white
Colour monitor LCD 4” screen for Duo System, basic version, pro-
vided with 3 function buttons for auto switch-on, door-opening
and additional functions. For DF6000 systems if connected with
WB3162 wall brackets.
EX312
Dim: mm 65x218x62
Colour: white
Intercom for DF6000 system, basic version. With integrated
decoding and address selection by shunting. Provided with 1 lock
release button and 2 further ones for extra functions.
EX322
Dim: mm 83x218x62
Colour: white
Intercom for DF6000 digital systems with integrated decode
module and jumper address selection. Supplied with 1 button
for door lock and an additional one. Arranged for oor chime
through buzzer.
INSTALLATION ELEMENTS
WB3162
Wall bracket with terminals for electrical connection and wall mounting
of EX3160, EX3160C or EX3100C in digital DF6000 systems.
TA3160
Table adaptor for Exhito videointercoms. Made in metal, it is provided
with 2.4 m cable with 20 conductors.
TA320
Table adaptor for Exhito intercoms. Made in metal, it is provided with
2.4 m cable with 20 conductors.
ACCESSORIES
MC3000B
Interchangeable cover blue “sky” colour that replaces the one provided
for the screen of Exhito monitor
MC3000G
Interchangeable cover green “spring” colour that replaces the one
provided for the screen of Exhito monitor.
MC3000T
Interchangeable cover silver “champagne” colour that replaces the one
provided for the screen of Exhito monitor.
INTERNAL STATIONS
The DF6000 digital system oers the most versatile among those presented in the catalogue as
a series of Exhito internal stations. In fact, with Exhito you may decide to have colour, black and
white or basic version video screens, or the audio-only solution, whether basic or advanced.
The line is completed with installation components and accessories to nd the perfect answer
for each specic requirement.
39
Digital Video Intercom
DF6000
DOOR STATIONS
Prolo and Matrix Style are the door stations for the DF6000 digital, both of which modular. In
particular, Prolo oers video colour or black and white compositions with conventional or digital
module buttons, to be preferred in cases where there is little available space, then the reduced size
module also with double button becomes the ideal solution. Instead the Matrix Style anti-vandal
protection range is audio or colour video; it is exible for any horizontal compositions and guarantees
maximum strength because of the IP45 and IK09 degrees of protection, not to mention that it is a
sign of particular elegance due to the detailed nishing.
PROFILO AUDIO AND VIDEO MODULES
PL40PCED
Dim: mm 99x110x17
Video colour module with xed optics 3.6 mms with integrated
speaker module withoutcall buttons, for DF6000 digital systems.
PL41PCED
Dim: mm 99x110x17
Colour camera module with 3.6 mm fixed lens with inte-
grated door speaker with 1 call button for DF6000 digital
systems.
PL42PCED
Dim: mm 99x110x17
Colour camera module with 3.6 mm fixed lens with inte-
grated door speaker with 2 call buttons for DF6000 digital
systems.
PL40PED
Dim: mm 99x110x17
B/w camera module with 3.6 mm fixed lens with integrat-
ed door speaker without call buttons for DF6000 digital
systems.
PL41PED
Dim: mm 99x110x17
B/w camera module with 3.6 mm fixed lens with integrated
door speaker with 1 call button for DF6000 digital systems.
PL10PED
Dim: mm 99x110x17
Audio module with integrated door speaker without call but-
tons for DF6000 digital systems.
PL11PED
Dim: mm 99x110x17
Audio module with integrated door speaker with 1 call button
for DF6000 digital systems.
PL12PED
Dim: mm 99x110x17
Audio module with integrated door speaker with 2 call buttons
for DF6000 digital systems.
40 Digital Video Intercom
DF6000
PROFILO DIGITAL DOOR STATIONS
TD6100PL
Dim: mm 99x110x17
Digital keyboard for digital systems DF6000 with front plate and
14 buttons in stainless steel. Provided with LCD graphic display, it
allows the call of the indoor stations through typing the corre-
sponding number and the door opening by a reserved code. It
integrates electronic index allowing consultation, visualization
and the single users calling. They are displayed in alphabetical
order. It can contain up to 250 users names.
CONVENTIONAL DOOR STATIONS
PROFILO
CD6134PL
Dim: mm 99x110x17
Digitalizer for conventional push button panel of 4 buttons, it
allows to codify up to 128 buttons of a conventional door station.
CD6138PL
Dim: mm 99x110x17
Digitalizer for conventional push button panel with 8 buttons
on 2 rows, it allows to codify up to 128 buttons of a conventional
door station.
PL24S
Dim: mm 99x110x17
Additional module with integrated decoder for external stations
with 4 buttons for DF6000 digital systems.
PL228S
Dim: mm 99x110x17
Additional module with integrated decoder for external stations
with 8 buttons on 2 rows for Duo System installations.
PL50
Dim: mm 99x110x17
Street number module.
PL20
Dim: mm 99x110x17
Blank module.
PROFILO INSTALLATION ELEMENTS
PL71
Dim: mm 91x133x47
Back box for 1 module.
PL72
Dim: mm 91x244.5x47
Back box for 2 modules.
PL73
Dim: mm 91x356x47
Back box for 3 modules.
PL81
Dim: mm 118x153x41
Hood cover for 1 module.
PL82
Dim: mm 118x264x41
Hood cover for 2 modules.
PL83
Dim: mm 118x376x41
Hood cover for 3 modules.
PL84
Dim: mm 217x264x41
Hood cover for 4 modules on 2 vertical rows.
PL86
Dim: mm 217x376x41
Hood cover for 6 modules on 2 vertical rows.
PL89
Dim: mm 316x376x41
Hood cover for 9 modules on 3 vertical rows.
PL91
Dim: mm 118x154x80
Surface mounting rain shelter for 1 module.
PL92
Dim: mm 118x265x80
Surface mounting rain shelter for 2 modules.
PL93
Dim: mm 118x377x80
Surface mounting rain shelter for 3 modules.
PL94
Dim: mm 217x264x80
Surface mounting rain shelter for 4 modules on 2 vertical rows.
PL96
Dim: mm 217x376x80
Surface mounting rain shelter for 6 modules on 2 vertical rows.
PL99
Dim: mm 316x376x80
Surface mounting rain shelter for 9 modules on 3 vertical rows.
41
Digital Video Intercom
DF6000
POWER SUPPLIES
AND SERVICE MODULES
PRS6220
Power supply, 230 V/127 V. 45V A. 15 Vdc/13 Vac. Outputs protected
against overloading and short circuits. Dim: 8 DIN modules.
6273
Digital exchanger for DF6000 system, it can be used in installation
with secondary entrances or several common main entrances.
PRS210
Stabilised power supplies for assembly on DIN bar. Mains supply
at 230V and 127V. Protected against overloading or overvoltage
by thermoprotectors. All the power supplies comply with the
European safety standard EN 60065.
DV2D
2-output floor distributor for pair cable connection. Power
supply: 12/21 Vdc.
DV4D
4-output floor distributor for pair cable connection. Power
supply: 12/21 Vdc.
1471
2 command input relay unit (12 Vac; 12/24 Vdc). 3 A modules
in DIN bar.
1472
Exchange exchanger (1A, 24 V) 3 command input: 12 Vdc/Vac, 24
Vdc and electronic note. Mountable on 3 A DIN module.
MATRIX STYLE
AUDIO AND VIDEO MODULES
TD6100MAS
Dim: mm 115x115
Digital keypad made by front plate and 14 steel buttons. It
is equipped with 16 characters on 2 lines display. It allows
the user chime by dialling the corresponding number and
electric lock release by entering the 4-digit private code. The
electronic index is also integrated. Scrolling function allows
to display the tenant names in alphabetical sequence and user
chime. It contains up to 250 name users. This integration allow
to reduce further space compared to dierent corresponding
modular compositions.
MAS43CED
Dim: mm 115x115
Colour camera and audio module with 1 call button. Autoiris
3.6 mm lens. For 4+1 reduced wiring systems and for DF6000
digital systems.
MAS11PED
Dim: mm 115x115
Audio module with door speaker and 1 call button for 1+1
intercom systems electronic call and for DF6000 digital systems.
46
48
47
49
47
49, 50
60, 61
71, 72
47
51
62, 63
72, 73 73, 74
47
52, 53
59
63, 64
70 70
58 59 59 59
70
42
Exhito Exhito
basic
Exhito
basic
Exhito 724N Project
basic
Echos Project
extendable
DOOR
STATIONS
Agorà Prolo Matrix Style ModyAgorà Light
INTERNAL
STATIONS
This picture introduces the complete panorama of the Aci Farfisa products ranges and their
correspondence with the analogue video intercom system.
The number of indicated pages allows, at a glance, view of the products available for each
system technology.
Reduced wiring
electronic call
Reduced wiring
electronic call
Conventional wiring
electronic call
Conventional wiring
electronic call
Alternate current call
Alternate current call
PRODUCT \ TECHNOLOGY CROSS REFERENCE
54 55
66
75
67
KIT
Video Kit Audio Kit
Analogue Video Intercom
REDUCED WIRING,
ELECTRONIC CALL
CONVENTIONAL WIRING,
ELECTRONIC CALL SYSTEM
ALTERNATE CURRENT CALL SYSTEM
45
57
69
Reduced wiring
electronic call
Conventional wiring
electronic call
Alternate
current call
REDUCED WIRING,
ELECTRONIC CALL
If the traditional analogue technology is preferred to the digital, the
reduced wiring solution is often the most suitable.
Reduced wiring means a Videointercom system or electronic call
intercom with reduced number of cables referred to as 4+1 and 1+1
respectively which can seamlessly integrate with each other.
The advantage is a notable simplification of the installation, with the
assurance of basic traditional functionality of the equipment and an
improved quality/price ratio.
The reduced wiring systems have more flexible internal station aesthetic
ranges available like Echos and Exhito, while for external stations you
can choose between Agorà and Agorà Light, Profilo, Matrix Style and
Mody, a wide variety of aesthetic choices
INTERNAL STATIONS
Echos
Exhito
DOOR STATIONS
Agorà Light
Ago
Prolo
Matrix Style
Mody
POWER SUPPLIES AND SERVICE MODULES
VIDEO KITS AND AUDIO KITS
46
47
48
49
49
51
52
53
54
46 Analogue Video Intercom
REDUCED WIRING, ELECTRONIC CALL
INTERNAL STATIONS
The Farsa reduced wiring video or audio system with electronic calling oers dierent aesthetic
ranges for internal stations: Echos and Exhito - Echos, with open voice functionning in colour has
a modern design, while Exhito is more exible in the solutions, even allowing the video to be in
b/w version or audio-only.
INTERNAL STATIONS ECHOS
EH9161CW
Dim: mm 208x103x26
Colour: white
White hand-free monitor for conventional wiring. LCD 3.5’’ screen
adjustable on horizontal axis. Function buttons for door opening,
auto switch-on, bell exclusion (with LED indicating the setting),
volume and brightness adjustment and 6 further buttons for
intercommunicating and additional functions.
EH9161CT
Dim: mm 208x103x26
Colour: techno grey
Techno grey hand-free monitor for conventional wiring.
LCD 3.5’’ screen adjustable on horizontal axis. Function
buttons for door opening, auto switch-on, bell exclusion
(with LED indicating the setting), volume and brightness
adjustment and 6 further buttons for intercommunicating
and additional functions.
INSTALLATION ELEMENTS
9083
Dim: mm 192x86x26
Back box for monitor Echos.
WA9100W
Dim: mm 192x86x26
Colour: white
Wall adaptor for surface mounting of white Echos monitors EH9161CW.
WA9100T
Dim: mm 192x86x26
Colour: techno
Wall adaptor for surface mounting of metal grey colour Echos monitors
EH9161CT.
TA9160
Dim: mm 240x135x75
Table adaptor for Echos monitors to be mounted with WA9100W
or WA9100T.
47
Analogue Video Intercom
REDUCED WIRING, ELECTRONIC CALL
INSTALLATION ELEMENTS
WB3161
Wall bracket to mount on the wall EX3160C, EX3160 and EX3100C monitors
in 4+1 reduced wiring.
TA3160
Table adaptor for Exhito videointercoms. Made in metal, it is provided
with 2.4 m cable with 20 conductors.
TA320
Table adaptor for Exhito intercoms. Made in metal, it is provided with
2.4 m cable with 20 conductors.
ACCESSORIES
MC3000B
Interchangeable frame blue “sky” colour that replaces the 1 provided
for the screen of Exhito monitor.
MC3000G
Interchangeable frame green “spring” colour that replaces the 1 provided
for the screen of Exhito monitor.
MC3000T
Interchangeable frame silver “champagne” colour that replaces the 1
provided for the screen of Exhito monitor.
EX301
Additional button module for EX321 and EX311 intercoms.
EX304
Additional loudspeaker module to be inserted into EX321 and EX311
intercoms.
EX332
3 LED module to be inserted into EX321 to indicate auxilliary services.
INTERNAL STATIONS EXHITO
EX3160C
Dim: mm 211x218x62
Colour: white
Colour monitor LCD 4” provided with 7 function buttons (2 for
auto switch-on and door opening and further 5 for additional
functions). It can be installed in conventional wiring system if
mounted with WB3160.
EX3160
Dim: mm 211x218x62
Colour: white
B/w at 4” monitor provided with 7 function buttons (2 for
auto switch-on and door opening and further 5 for additional
functions). It can be installed in conventional wiring system if
mounted with WB3160.
EX3100C
Dim: mm 211x218x62
Colour: white
Colour monitor LCD 4” screen, basic version, provided with 3
function buttons for auto switch-on, door-opening and ad-
ditional functions. For conventional wiring systems, electronic
call if connected with WB3160 wall brackets.
EX311
Dim: mm 65x218x62
Colour: white
Basic intercom for 1+1 reduced wiring audio systems, supplied
with 1 button for door-lock release and further 2 buttons for
additional functions.
EX321
Dim: mm 83x218x62
Colour: white
Intercom for reduced wiring, provided with 8 function buttons of
which 1 for door-opening and further 7 for additional functions.
48 Analogue Video Intercom
REDUCED WIRING, ELECTRONIC CALL
DOOR STATIONS AGORÀ LIGHT
AGL100V
Dim: mm 99x208x30
Composed by surface mounting box, front plate with frame,
cover ready for door speaker, camera and up to 2 buttons
call, diodes included, Agorà Light version in light grey. Reduced
wiring technology.
AGL100A
Dim: mm 99x208x30
Composed by surface mounting box, front plate with frame,
cover ready for door speaker and up to 4 buttons call, diodes
included, Agorà Light version in light grey. Reduced wiring
technology.
AGL100T
Dim: mm 99x208x30
Composed by surface mounting box and front plate with frame.
Ready for installation of 8 single call button modules, for combi-
nation with audio-video or only audio door station.
Nearby photo with puch buttons conguration at maximum
extension.
DOOR STATIONS
The Farsa 4 +1 video or 1 +1 audio reduced wiring system uses dierent aesthetic ranges for
external stations: Agorà and Agorà Light, Prolo, Matrix Style or Mody. Specically, Agorà and
Agorà Light can be surface mounted into the wall, protruding very little from the wall because
of the shallow depth of the base module. Prolo particularly stands out from the other modular
stations thanks to its optimized dimensions, even in compositions where space is limited in width.
Matrix Style - elegant and rened - oers anti-vandal resistance guaranted by IP45 and IK09.
ACCESSORIES
AGL21
Single call button module.
AGL20
Blank button module.
49
Analogue Video Intercom
REDUCED WIRING, ELECTRONIC CALL
DOOR STATIONS PROFILO
PL40PCED
Dim: mm 99x110x17
Colour camera module with 3.6 mm xed lens with integrated
door speaker without call buttons for 4+1 reduced wiring
systems.
PL41PCED
Dim: mm 99x110x17
Colour camera module with 3.6 mm fixed lens with inte-
grated door speaker with 1 call button for 4+1 reduced
wiring systems.
PL42PCED
Dim: mm 99x110x17
Colour camera module with 3.6 mm xed lens with integrated
door speaker with 2 call buttons for 4+1 reduced wiring
systems.
PL40PED
Dim: mm 99x110x17
B/w camera module with 3.6 mm fixed lens with integrated
door speaker without call buttons for 4+1 reduced wiring
systems.
PL41PED
Dim: mm 99x110x17
B/w camera module with 3.6 mm fixed lens with integrated
door speaker with 1 call button for 4+1 reduced wiring
systems.
PL10PED
Dim: mm 99x110x17
Audio module with integrated door speaker without call but-
tons for 1+1 reduced wiring systems.
PL11PED
Dim: mm 99x110x17
Audio module with integrated door speaker with 1 call button
for 1+1 reduced wiring systems.
PL12PED
Dim: mm 99x110x17
Audio module with integrated door speaker with 2 call buttons
for 1+1 reduced wiring systems.
DOOR STATIONS AGORÀ
AG100V
Dim: mm 99x208x30
Composed by surface mounting box, front plate with frame,
cover ready for door speaker, camera and up to 2 buttons.
Diodes included. Reduced wiring technology.
AG100A
Dim: mm 99x208x30
Composed by surface mounting box, front plate with frame, cover
ready for door speaker and up to 4 buttons. Diodes included.
Reduced wiring technology.
AG100T
Dim: mm 99x208x30
Composed by surface mounting box and front plate with frame.
Ready for installation of 8 single call button modules, for combi-
nation with audio-video or only audio door station.
Nearby photo with puch buttons conguration at maximum
extension.
ACCESSORIES
AG21
Single call button module.
AG20
Blank button module.
AGOAND AGORÀ LIGHT
AUDIO AND VIDEO MODULES
AG40CED
Colour camera and door speaker module for audio-video door
station, reduced wiring technology.
AG30ED
Door speaker module for audio door station, reduced wiring
technology.
INSTALLATION ELEMENTS
WA01AG
Aluminium wall adaptor that easily allows the replacement of a Mody
external door station ush mounted into a Agorà surface mounted one.
50 Analogue Video Intercom
REDUCED WIRING, ELECTRONIC CALL
INSTALLATION ELEMENTS PROFILO
PL71
Dim: mm 91x133x47
Back box for 1 module.
PL72
Dim: mm 91x244.5x47
Back box for 2 modules.
PL73
Dim: mm 91x356x47
Back box for 3 modules.
PL81
Dim: mm 118x153x41
Hood cover for 1 module.
PL82
Dim: mm 118x264x41
Hood cover for 2 modules.
PL83
Dim: mm 118x376x41
Hood cover for 3 modules.
PL84
Dim: mm 217x264x41
Hood cover for 4 modules on 2 vertical rows.
PL86
Dim: mm 217x376x41
Hood cover for 6 modules on 2 vertical rows.
PL89
Dim: mm 316x376x41
Hood cover for 9 modules on 3 vertical rows.
PL91
Dim: mm 118x154x80
Surface mounting rain shelter for 1 module.
PL92
Dim: mm 118x265x80
Surface mounting rain shelter for 2 modules.
PL93
Dim: mm 118x377x80
Surface mounting rain shelter for 3 modules.
PL94
Dim: mm 217x264x80
Surface mounting rain shelter for 4 modules on 2 vertical rows.
PL96
Dim: mm 217x376x80
Surface mounting rain shelter for 6 modules on 2 vertical rows.
PL99
Dim: mm 316x376x80
Surface mounting rain shelter for 9 modules on 3 vertical rows.
Additional modules
PL21
Dim: mm 99x110x17
Module with 1 additional call button.
PL22
Dim: mm 99x110x17
Module with 2 additional call buttons.
PL23
Dim: mm 99x110x17
Module with 3 additional call buttons.
PL24
Dim: mm 99x110x17
Module with 4 additional call buttons.
PL226
Dim: mm 99x110x17
Module with 6 additional call buttons on 2 rows.
PL228
Dim: mm 99x110x17
Module with 8 additional call buttons on 2 rows.
PL50
Dim: mm 99x110x17
Street number module.
PL20
Dim: mm 99x110x17
Blank module.
241DMA
4-diode module to be inserted in button modules PL21, PL22,
PL23, PL24, PL226 and PL228 for audio 1+1 and video 4+1 systems.
51
Analogue Video Intercom
REDUCED WIRING, ELECTRONIC CALL
DOOR STATIONS MATRIX STYLE
MAS43CED
Dim: mm 115x115
Colour camera and audio module with 1 call button. Autoiris
3.6 mm lens. For 4+1 reduced wiring systems and for DF6000
digital systems.
MAS11PED
Dim: mm 115x115
Audio module with door speaker and 1 call button for 1+1
intercom systems electronic call.
Additional modules
MAS22
Dim: mm 115x115
Additional module with 2 call buttons.
MAS24
Dim: mm 115x115
Additional module with 4 call buttons.
MAS20
Dim: mm 115x115
Blank module.
241DMA
4-diode module to be inserted in button modules MAS22, MAS24
for reduced wire technology.
INSTALLATION ELEMENTS MATRIX STYLE
MAS61
Dim: mm 140x140
Front frame in matt titanium grey colour for 1 module.
MAS62
Dim: mm 140x257
Front frame in matt titanium grey colour for 2 modules.
MAS63
Dim: mm 140x374
Front frame in matt titanium grey colour for 3 modules.
MA71
Dim: mm 128x128x65
Back box for 1 module.
MA72
Dim: mm 128x245x65
Back box for 2 modules.
MA73
Dim: mm 128x362x65
Back box for 3 modules.
MA91
Dim: mm 146x145x92
Surface mounting rain shelter for 1 module.
MA92
Dim: mm 146x262x92
Surface mounting rain shelter for 2 modules.
MA93
Dim: mm 146x379x92
Surface mounting rain shelter for 3 modules.
52 Analogue Video Intercom
REDUCED WIRING, ELECTRONIC CALL
Additional modules
MD21
Dim: mm 124x90x18
Module with 1 additional call button.
MD22
Dim: mm 124x90x18
Module with 2 additional call buttons.
MD23
Dim: mm 124x90x18
Module with 3 additional call buttons.
MD24
Dim: mm 124x90x18
Module with 4 additional call buttons.
MD222
Dim: mm 124x90x18
Module with 2 additional call buttons on 2 rows.
MD224
Dim: mm 124x90x18
Module with 4 additional call buttons on 2 rows.
MD226
Dim: mm 124x90x18
Module with 6 additional call buttons on 2 rows.
MD228
Dim: mm 124x90x18
Module with 8 additional call buttons on 2 rows.
MD20
Dim: mm 124x90x18
Blank module.
MD50
Dim: mm 124x90x18
Street number module.
241D
2-diode module to be inserted in button modules MD21, MD22,
MD23, MD24, MD222, MD224, MD226 and MD228.
DOOR STATIONS MODY
MD41D
Dim: mm 124x90x18
B/w video module with 3.6 mm fixed lens for 4+1 reduced
wiring systems.
MD10ED
Dim: mm 124x90x18
Audio module with integrated door speaker for 1+1 reduced
wiring systems.
MD11ED
Dim: mm 124x90x18
Audio module with integrated door speaker with 1 call button
for 1+1 reduced wiring systems.
MD12ED
Dim: mm 124x90x18
Audio module with integrated door speaker with 2 call buttons
for 1+1 reduced wiring systems.
53
Analogue Video Intercom
REDUCED WIRING, ELECTRONIC CALL
INSTALLATION ELEMENTS MODY
MD71
Dim: mm 124x121.5x64
Back box complete with module frame for 1 module
MD72
Dim: mm 124x213x64
Back box complete with module frame for 2 modules.
MD73
Dim: mm 124x304.5x64
Back box complete with module frame for 3 modules.
MD74
Dim: mm 124x395x64
Back box complete with module frame for 4 modules.
MD81
Dim: mm 151x140x40
Hood cover for 1 module.
MD82
Dim: mm 151x231.5x40
Hood cover for 2 modules.
MD83
Dim: mm 151x323x40
Hood cover for 3 modules.
MD804
Dim: mm 151x414.5x40
Hood cover for 4 modules.
MD84
Dim: mm 276x231.5x40
Hood cover for 4 modules on 2 rows.
MD86
Dim: mm 276x323x40
Hood cover for 6 modules on 2 rows.
MD91
Dim: mm 151x140x80
Surface mounting rain shelter for 1 module.
MD92
Dim: mm 151x231.5x80
Surface mounting rain shelter for 2 modules.
MD93
Dim: mm 151x323x80
Surface mounting rain shelter for 3 modules.
MD94
Dim: mm 276x231.5x80
Surface mounting rain shelter for 4 modules on 2 rows.
MD96
Dim: mm 276x323x80
Surface mounting rain shelter for 6 modules on 2 rows.
POWER SUPPLIES
AND SERVICE MODULES
1181E
Timed power supply - 127-230 Vac. 48VA outputs protected
against overloading and short circuits. Output voltages: 13 Vac
and 21 Vdc. Certication: VDE. 8 A modules in DIN bar.
PRS210
15VA transformer. 127-230V. 13 Vac. VDE certication. 3 DIN
modules in DIN bar, or it can be mounted on the wall.
PRS210ED
15VA transformer with electronic ringer for 1+1 audio installa-
tions. 127-230V. 13 Vac. 4 A modules in DIN bar.
1443ED
System module for intercommunication service in reduced wiring.
6 A modules in DIN bar.
DV2D
2-output oor distributor. Power supply: 12/21 Vdc.
DV4D
4-output oor distributor. Power supply: 12/21 Vdc.
1473
4-exchange switcher for automatic switching of 2 inputs. 8 A
modules in DIN bar.
1471
2 command input relay unit (12 Vac; 12/24 Vdc). 3 A modules
in DIN bar.
1471E
3 command input relay unit (12 Vac; 12/24 Vdc and electronic).
Provided with timed output for systems with electronic call and
private conversation. 4 A modules in DIN bar.
1472
2-way exchanger (1A, 24V) 3 command input: 12 Vdc/Vac, 24 Vdc
and electronic note. Mountable in 3 A DIN module.
RL36
Relay module with one exchange (1A, 24V) to be integrated
inside intercoms, it permits to drive 12 Vdc/Vac signal, electronic
note and EC ground.
RL37D
It can drive the chime for intercoms and video intercoms, mounta-
ble on 4 A DIN module. 1 free supplementary contact is available,
with electronic note.
1281
Stabilised power supply 230-127 Vac, 48VA, outputs protected
against overloading and short circuits. Output voltages: 13 Vac
and 21 Vdc. Certication: VDE. 8 A modules on DIN bar.
54 Analogue Video Intercom
REDUCED WIRING, ELECTRONIC CALL
ECHOS-AGORÀ LIGHT SERIES
EH9161AGLCW
Colour one-way video kit with white Echos internal station and
Agorà Light door station.
EH9161AGLCT
Colour one-way video kit with metal grey colour Echos internal
station and Agorà Light door station.
ECHOS-AGORÀ SERIES
EH9161AGCW
Colour one-way video kit with white Echos internal station and
Agorà door station.
EH9161AGCT
Colour one-way video kit with metal grey colour Echos internal
station and Agorà door station.
ECHOS-PROFILO SERIES
EH9161PLCW
Colour one-way video kit with white Echos internal station and
Prolo door station.
EH9161PLCT
Colour one-way video kit with metal grey colour Echos internal
station and Prolo door station.
EH9161PLCW/2
Colour two-way video kit with white Echos internal station and
Prolo door station.
EH9161PLCT/2
Colour two-way video kit with metal grey colour Echos internal
station and Prolo door station.
EXHITO-AGORÀ LIGHT SERIES
EX3161AGLC
Colour one-way video kit with Exhito internal station and Ago
Light door station.
EX3161AGL
B/w one-way video kit with Exhito internal station and Agorà
Light door station.
EX3111AGLC
Colour one-way video kit with Exhito internal station basic model
and Agorà Light door station.
EXHITO-AGORÀ SERIES
EX3161AGC
Colour one-way video kit with Exhito internal station and Ago
door station.
EX3161AG
B/w one-way video kit with Exhito internal station and Agorà
door station.
EX3111AGC
Colour one-way video kit with Exhito internal station basic model
and Agorà door station.
EXHITO-PROFILO SERIES
EX3161PLC
Colour one-way video kit with Exhito internal station and Prolo
door station.
EX3161PL
B/w one-way video kit with Exhito internal station and Prolo
door station.
EX3111PLC
Colour one-way video kit with Exhito internal station basic model
and Prolo door station.
EX3161PLC/2
Two way colour video kit with Exhito internal station and Prolo
door station
EX3161PL/2
Two way b/w video kit with Exhito internal station and Prolo
door station.
EX3111PLC/2
Two way colour video kit with Exhito internal station basic model
and Prolo door station.
VIDEO KITS AND AUDIO KITS
The one or two way solutions kits are very popular and they are easy to install because
of the simple and intuitive wiring as the box contains all the material needed for
installation but the cables.
EX3161AGL EXHITO EX3160+WB3161 AGORÀ LIGHT AG40CED+AGL100V+AGL21+AGL20 1181E
EX3161AG EXHITO EX3160+WB3161 AGORÀ AG40CED+AG100V+AG21+AG20 1181E
EX3161PL EXHITO EX3160+WB3161 PROFILO PL41PED+PL71 1181E
EH9161AGLCW ECHOS EH9161CW+9083+WA9100W AGORÀ LIGHT AG40CED+AGL100V+AGL21+AGL20 1181E
EH9161AGLCT ECHOS EH9161CT+9083+WA9100T AGORÀ LIGHT AG40CED+AGL100V+AGL21+AGL20 1181E
EH9161AGCW ECHOS EH9161CW+9083+WA9100W AGO AG40CED+AG100V+AG21+AG20 1181E
EH9161AGCT ECHOS EH9161CT+9083+WA9100T AGORÀ AG40CED+AG100V+AG21+AG20 1181E
EH9161PLCW ECHOS EH9161CW+9083+WA9100W PROFILO PL41PCED+PL71 1181E
EH9161PLCT ECHOS EH9161CT+9083+WA9100T PROFILO PL41PCED+PL71 1181E
EX3161AGLC EXHITO EX3160C+WB3161 AGORÀ LIGHT AG40CED+AGL100V+AGL21+AGL20 1181E
EX3111AGLC EXHITO EX3100C+WB3161 AGORÀ LIGHT AG40CED+AGL100V+AGL21+AGL20 1181E
EX3161AGC EXHITO EX3160C+WB3161 AGORÀ AG40CED+AG100V+AG21+AG20 1181E
EX3111AGC EXHITO EX3100C+WB3161 AGORÀ AG40CED+AG100V+AG21+AG20 1181E
EX3161PLC EXHITO EX3160C+WB3161 PROFILO PL41PCED+PL71 1181E
EX3111PLC EXHITO EX3100C+WB3161 PROFILO PL41PCED+PL71 1181E
EX3161PL/2 EXHITO 2xEX3160+WB3161 PROFILO PL42PCED+PL71 1181E
EH9161PLCW/2 ECHOS 2xEH9161CW+9083+WA9100W PROFILO PL42PCED+PL71 1181E
EH9161PLCT/2 ECHOS 2xEH9161CT+9083+WA9100T PROFILO PL42PCED+PL71 1181E
EX3161PLC/2 EXHITO 2xEX3160C+WB3161 PROFILO PL42PCED+PL71 1181E
EX3111PLC/2 EXHITO 2xEX3100C+WB3161 PROFILO PL42PCED+PL71 1181E
1AEXD EXHITO EX321 AGORÀ AG100A+AG30ED+AG21+AG20 PRS210ED
1PEXD EXHITO EX321 PROFILO PL11PED+PL71 PRS210ED
1PEXFD EXHITO EX321 PROFILO PL11PED+FC52PL+PL92 PRS210ED
1CKD EXHITO EX311 PRS210
1CKSD EXHITO EX311 PRS210
2PEXD EXHITO 2xEX321 PROFILO PL12PED+PL71 PRS210ED
2CKD EXHITO 2xEX311 PRS210
2CKSD EXHITO 2xEX311 PRS210
55
Analogue Video Intercom
REDUCED WIRING, ELECTRONIC CALL
1AEXD
Audio one-way with Exhito internal station and Agorà door station.
1PEXD
Audio one-way with Exhito internal station and Prolo door
station.
2PEXD
Audio two-way with Exhito internal station and Prolo door
station.
1PEXFD
One way audio kit with Exhito indoor station and Prolo external
station equipped with access control keypad (for more details
on FC52PL refer to page 87).
1CKD
Audio one-way with Exhito internal station and door station
ush mounted Click series.
1CKSD
Audio one-way with Exhito internal station and door station
surface mounted Click series.
2CKD
Audio two-way with Exhito internal station and door station
ush mounted Click series.
2CKSD
Audio two-way with Exhito internal station and door station
surface mounted Click series.
KITS INTERNAL STATIONS DOOR STATIONS POWER SUPPLY
VIDEO KIT / AUDIO KIT COMPOSITION
One-way colour
One-way audio
Two-way colour
Two-way b/w
One-way b/w
Two-way audio
86 >
ush mounted Click series
surface mounted Click series
ush mounted Click series
surface mounted Click series
CONVENTIONAL
WIRING,
ELECTRONIC
CALL SYSTEM
Some situations require the installation of a video or audio intercom
using analogue technology with electronic calling and traditional
wiring, so we refer to systems with coaxial or twisted pair video
7+1 or audio 4+1 cables.
On these occasions Farfisa offers various aesthetic ranges to choose
the most suitable for the the installation and aesthetic needs. For
internal stations, the Echos and Exhito lines are available, while
external stations have the choice between the all the different modular
options: Profilo, Matrix Style and Mody.
INTERNAL STATIONS
Echos
Exhito
DOOR STATIONS
Prolo
Matrix Style
Mody
POWER SUPPLIES AND SERVICE MODULES
VIDEO KITS
AUDIO KITS
58
59
60
62
63
65
66
67
58 Analogue Video Intercom
CONVENTIONAL WIRING, ELECTRONIC CALL
INTERNAL STATIONS ECHOS
EH9160CW
Dim: mm 208x103x26
Colour: white and grey
Colour hand-free white monitor for conventional wiring. LCD
3.5’’ screen adjustable on horizontal axis. Function buttons for
door opening, auto switch-on, bell exclusion (with LED indicating
the setting), volume and brightness adjustment and 6 further
buttons for intercommunicating and additional functions.
EH9160CT
Dim: mm 208x103x26
Colour: metal grey colour
Colour hand-free “techno” grey monitor for conventional wiring.
LCD 3.5’’ screen adjustable on horizontal axis. Function buttons for
door opening, auto switch-on, bell exclusion (with LED indicating
the setting), volume and brightness adjustment and 6 further
buttons for intercommunicating and additional functions.
EH9100CW
Dim: mm 208x103x26
Colour: white and grey
Colour hand-free white monitor for conventional wiring. LCD
3.5’’ screen adjustable on horizontal axis. Function buttons for
door opening, auto switch-on, bell exclusion (with LED indicating
the setting), volume and brightness adjustment.
INTERNAL STATIONS
The Echos and Exhito internal stations are ranges available for conventional wiring with electronic
calling, guaranteeing all the typical features required by basic service systems. The units on oer
are in colour or b/w video or audio-only and are compatible with each other allowing mixed
systems to meet the individual needs of users.
INSTALLATION ELEMENTS
9083
Dim: mm 192x86x26
Back box for monitor Echos.
WA9100W
Dim: mm 192x86x26
Colour: white
Wall adaptor for surface mounting of white Echos monitors.
WA9100T
Dim: mm 192x86x26
Colour: metal grey colour
Wall adaptor for surface mounting of metal grey colour Echos monitors.
TA9160
Dim: mm 240x135x75
Table adaptor for Echos monitors to be mounted with WA9100W
or WA9100T.
59
Analogue Video Intercom
CONVENTIONAL WIRING, ELECTRONIC CALL
INTERNAL STATIONS EXHITO
EX3160C
Dim: mm 211x218x62
Colour: white
Colour LCD 4” monitor provided with 7 function buttons (2 for
auto switch-on and door opening and further 5 for additional
functions). It can be installed in conventional wiring system if
mounted with WB3160.
EX3160
Dim: mm 211x218x62
Colour: white
B/w at 4” monitor provided with 7 function buttons (2 for
auto switch-on and door opening and further 5 for additional
functions). It can be installed in conventional wiring system if
mounted with WB3160.
EX3100C
Dim: mm 211x218x62
Colour: white
Colour monitor LCD 4” screen, basic version, provided with 3
function buttons for auto switch-on, door-opening and ad-
ditional functions. For conventional wiring systems, electronic
call if connected with WB3160 wall brackets.
EX310
Dim: mm 65x218x62
Colour: white
Intercom basic version for conventional wiring, electronic call,
supplied with 1 push button for door-opening and additional
functions.
EX320
Dim: mm 83x218x62
Colour: white
Intercom plus version for conventional wiring, provided with
2 function buttons of which 1 for door-opening and further 6
for additional functions.
INSTALLATION ELEMENTS
WB3160
Staa con morsetti per collegamento e ssaggio a muro del monitor
EX3160C, EX3160 e EX3100C in installazioni con tecnologia convenzionale
(con cavo coassiale).
TA3160
Table adaptor for Exhito videointercoms. Made in metal, it is provided
with 2.4 m cable with 20 conductors.
TA320
Table adaptor for Exhito intercoms. Made in metal, it is provided with
2.4 m cable with 20 conductors.
ACCESSORIES
MC3000B
Interchangeable frame blue “sky” colour that replaces the 1 provided
for the screen of Exhito monitor.
MC3000G
Interchangeable frame green “spring” colour that replaces the 1 provided
for the screen of Exhito monitor.
MC3000T
Interchangeable frame silver “champagne” colour that replaces the 1
provided for the screen of Exhito monitor.
EX301
Additional button module for EX320 and EX310 intercom.
EX304
Additional loudspeaker module for EX320 and EX310 intercom.
EX332
3 LED module for EX320 intercom to indicate auxilliary services.
60 Analogue Video Intercom
CONVENTIONAL WIRING, ELECTRONIC CALL
DOOR STATIONS PROFILO
PL40PC
Dim: mm 99x110x17
Colour camera module with 3.6 mm xed lens with integrated
door speaker without call buttons for conventional systems.
PL41PC
Dim: mm 99x110x17
Colour camera module with 3.6 mm xed lens with integrated
door speaker with 1 call button for conventional systems.
PL42PC
Dim: mm 99x110x17
Colour camera module with 3.6 mm xed lens with integrated
door speaker with 2 call buttons for conventional systems.
DOOR STATIONS
The external stations that can be used for conventional wiring systems with electronic calling
belong to the Prolo, Matrix Style and Mody ranges, all of which are modular with maximum space
optimization. The use in an analogue technology accentuates the modular ability, emphasizing
its versatility.
PL422PC
Dim: mm 99x110x17
Colour camera module with 3.6 mm xed lens with integrated
door speaker with 2 call buttons on 2 rows for conventional
systems.
PL424PC
Dim: mm 99x110x17
Colour camera module with 3.6 mm xed lens with integrated
door speaker with 4 call buttons on 2 rows for conventional
systems.
61
Analogue Video Intercom
CONVENTIONAL WIRING, ELECTRONIC CALL
PL40P
Dim: mm 99x110x17
B/w camera module with 3.6 mm xed lens with integrated
door speaker without call buttons for conventional systems.
PL41P
Dim: mm 99x110x17
B/w camera module with 3.6 mm xed lens with integrated door
speaker with 1 call button for conventional systems.
PL42P
Dim: mm 99x110x17
B/w camera module with 3.6 mm xed lens with integrated door
speaker with 2 call buttons for conventional systems.
PL422P
Dim: mm 99x110x17
B/w camera module with 3.6 mm xed lens with integrated door
speaker with 2 call buttons on 2 rows for conventional systems.
PL424P
Dim: mm 99x110x17
B/w camera module with 3.6 mm xed lens with integrated door
speaker with 4 call buttons on 2 rows for conventional systems.
PL10P
Dim: mm 99x110x17
Audio module with integrated door speaker without call buttons
for conventional wiring systems.
PL11P
Dim: mm 99x110x17
Audio module with integrated door speaker with 1 call button
for 1 conventional wiring systems.
PL12P
Dim: mm 99x110x17
Audio module with integrated door speaker with 2 call buttons
for conventional wiring systems.
PL122P
Dim: mm 99x110x17
Audio module with integrated door speaker with 2 call buttons
on 2 rows for conventional wiring systems.
PL124P
Dim: mm 99x110x17
Audio module with integrated door speaker with 4 call buttons
on 2 rows for conventional wiring systems.
Additional module
PL21
Dim: mm 99x110x17
Module with 1 additional call button.
PL22
Dim: mm 99x110x17
Module with 2 additional call buttons.
PL23
Dim: mm 99x110x17
Module with 3 additional call buttons.
PL24
Dim: mm 99x110x17
Module with 4 additional call buttons.
PL226
Dim: mm 99x110x17
Module with 6 additional call buttons on 2 rows.
PL228
Dim: mm 99x110x17
Module with 8 additional call buttons on 2 rows.
PL50
Dim: mm 99x110x17
Street number module.
PL20
Dim: mm 99x110x17
Blank module.
62 Analogue Video Intercom
CONVENTIONAL WIRING, ELECTRONIC CALL
DOOR STATIONS MATRIX STYLE
MAS10P
Dim: mm 115x115
Audio module with door speaker integrated for conventional
wiring systems without call buttons.
MAS11P
Dim: mm 115x115
Audio module with door speaker integrated for conventional
wiring systems with 1 call button.
MAS12P
Dim: mm 115x115
Audio module with door speaker integrated for conventional
wiring systems with 2 call buttons.
ADDITIONAL BUTTONS MODULE
MAS22
Dim: mm 115x115
Additional module with 2 call buttons.
MAS24
Dim: mm 115x115
Additional module with 4 call buttons.
INSTALLATION ELEMENTS PROFILO
PL71
Dim: mm 91x133x47
Back box for 1 module.
PL72
Dim: mm 91x244.5x47
Back box for 2 modules.
PL73
Dim: mm 91x356x47
Back box for 3 modules.
PL81
Dim: mm 118x153x41
Hood cover for 1 module.
PL82
Dim: mm 118x264x41
Hood cover for 2 modules.
PL83
Dim: mm 118x376x41
Hood cover for 3 modules.
PL84
Dim: mm 217x264x41
Hood cover for 4 modules on 2 vertical rows.
PL86
Dim: mm 217x376x41
Hood cover for 6 modules on 2 vertical rows.
PL89
Dim: mm 316x376x41
Hood cover for 9 modules on 3 vertical rows.
PL91
Dim: mm 118x154x80
Surface mounting rain shelter for 1 module.
PL92
Dim: mm 118x265x80
Surface mounting rain shelter for 2 modules.
PL93
Dim: mm 118x377x80
Surface mounting rain shelter for 3 modules.
PL94
Dim: mm 217x264x80
Surface mounting rain shelter for 4 modules on 2 vertical rows.
PL96
Dim: mm 217x376x80
Surface mounting rain shelter for 6 modules on 2 vertical rows.
PL99
Dim: mm 316x376x80
Surface mounting rain shelter for 9 modules on 3 vertical rows.
63
Analogue Video Intercom
CONVENTIONAL WIRING, ELECTRONIC CALL
INSTALLATION ELEMENTS MATRIX STYLE
MAS61
Dim: mm 140x140
Front frame in matt titanium grey colour for 1 module.
MAS62
Dim: mm 140x257
Front frame in matt titanium grey colour for 2 modules.
MAS63
Dim: mm 140x374
Front frame in matt titanium grey colour for 3 modules.
MA71
Dim: mm 128x128x65
Back box for 1 module.
MA72
Dim: mm 128x245x65
Back box for 2 modules.
MA73
Dim: mm 128x362x65
Back box for 3 modules.
MA91
Dim: mm 146x145x92
Surface mounting rain shelter for 1 module.
MA92
Dim: mm 146x262x92
Surface mounting rain shelter for 2 modules.
MA93
Dim: mm 146x379x92
Surface mounting rain shelter for 3 modules.
DOOR STATIONS MODY
MD100
Dim: mm 124x90x18
Audio module with integrated door speaker for conventional
wiring systems with 1 call button.
MD200
Dim: mm 124x90x18
Audio module with integrated door speaker for conventional
wiring systems with 2 call buttons.
MD10
Dim: mm 124x90x18
Audio module ready for door speaker for conventional wiring
systems without call buttons.
MD11
Dim: mm 124x90x18
Audio module ready for door speaker for conventional wiring
systems with 1 call button.
MD12
Dim: mm 124x90x18
Audio module ready for door speaker for conventional wiring
systems with 2 call buttons.
MD122
Dim: mm 124x90x18
Audio module ready for door speaker for conventional wiring
systems with 2 call buttons on 2 rows.
MD124
Dim: mm 124x90x18
Audio module ready for door speaker for conventional wiring
systems with 4 call buttons on 2 rows.
MD30
Speaker unit for 4+1 audio systems to be placed on the MD10,
MD11, MD12, MD122, MD124 modules.
64 Analogue Video Intercom
CONVENTIONAL WIRING, ELECTRONIC CALL
Additional buttons module
MD21
Dim: mm 124x90x18
Module with 1 additional call button.
MD22
Dim: mm 124x90x18
Module with 2 additional call buttons.
MD23
Dim: mm 124x90x18
Module with 3 additional call buttons.
MD24
Dim: mm 124x90x18
Module with 4 additional call buttons.
MD222
Dim: mm 124x90x18
Module with 2 additional call buttons on 2 rows.
MD224
Dim: mm 124x90x18
Module with 4 additional call buttons on 2 rows.
MD226
Dim: mm 124x90x18
Module with 6 additional call buttons on 2 rows.
MD228
Dim: mm 124x90x18
Module with 8 additional call buttons on 2 rows.
INSTALLATION ELEMENTS MODY
MD71
Dim: mm 124x121.5x64
Back box complete with module frame for 1 module.
MD72
Dim: mm 124x213x64
Back box complete with module frame for 2 modules.
MD73
Dim: mm 124x304.5x64
Back box complete with module frame for 3 modules.
MD74
Dim: mm 124x395x64
Back box complete with module frame for 3 modules.
MD81
Dim: mm 151x140x40
Hood cover for 1 module.
MD82
Dim: mm 151x231.5x40
Hood cover for 2 modules.
MD83
Dim: mm 151x232x40
Hood cover for 3 modules.
MD804
Dim: mm 151x414.5x40
Hood cover for 4 modules.
MD84
Dim: mm 276x231.5x40
Hood cover for 4 modules on 2 rows.
MD86
Dim: mm 276x323x40
Hood cover for 6 modules on 2 rows.
MD91
Dim: mm 151x140x80
Surface mounting rain shelter for 1 module.
MD92
Dim: mm 151x231.5x80
Surface mounting rain shelter for 2 modules.
MD93
Dim: mm 151x323x80
Surface mounting rain shelter for 3 modules.
MD94
Dim: mm 276x231.5x80
Surface mounting rain shelter for 4 modules on 2 rows.
MD96
Dim: mm 276x323x80
Surface mounting rain shelter for 6 modules on 2 rows.
65
Analogue Video Intercom
CONVENTIONAL WIRING, ELECTRONIC CALL
POWER SUPPLIES
AND SERVICE MODULES
1281
Stabilised power supply 230-127 Vac, 48VA, outputs protected
against overloading and short circuits. Output voltages: 13 Vac
and 21 Vdc. Certication: VDE. 8 A modules on DIN bar.
1281E
Power supply with timer integrated 230-127 Vac/48 VA outputs
protected against overloading and short circuits. Provided with
note generator for videointercom systems with electronic call.
Output voltages: 13 Vac and 21 Vdc. Certication: VDE. 8 A mo-
dules on DIN bar.
1282E
Audio-video timer. Allows operation in timer mode of a video
system with electronic call, automatic deletion at the end of
the conversation and the switching on of one video intercom at
a time. Mountable on 6 A DIN module. Art. 1281 and 1282E can
be used instead of 1281E in case of intercommunicating service
or automatic switch-o of conversation are required.
PRS210
15VA transformer. 127-230V. 13 Vac. VDE certication. 3 DIN
modules in DIN bar, or it can be mounted on the wall. Can be
used to power art. 2223, 2223C, 2273 and 2281.
PRS240
18 VA power supply with 2 modulated electronic ringers module.
8 Vdc-13 Vac. VDE certication. 6 A modules in DIN bar.
PRS226E
18VA power supply-commutator with 2 electronic ringers. 8
Vdc-13 Vac. 6 A modules in DIN bar. For intercoms connected to
external door station.
476
Video amplier-distributor with 1 input and 5 outputs. Power
supply: 21-24 Vdc. 8 A modules on DIN bar.
1273TV
7-exchange exchanger for automatic switching of 2 audio-video
inputs. 8 A modules in DIN bar.
1304
Multipolar cable for video intercom systems with a maximum
extension of 100m. Made up of 10 wires of dierent sections
and 75Ω coaxial cable.
CV02
Placed inside the external door station, it sounds in case of
eected calling.
1443E
Intercommunication service module to be inserted inside the 1282E
timer. It can be used when there is only one intercommunication
service in the system.
DV2
2-output video distributor coax video system. Power supply: 12 Vdc.
DV4
4-output video distributor coax video system. Power supply: 12 Vdc.
DV2D
2-output oor distributor pair cable connection. Power supply:
12/21 Vdc.
DV4D
4-output oor distributor pair cable connection. Power supply:
12/21 Vdc.
CV01
Converter of video signal by non-balanced line to balanced line.
1473
4-exchange switcher for automatic switching of 2 inputs. 8 A
modules in DIN bar.
1471
2-command input relay unit (12 Vac; 12/24 Vdc). 3 A modules
in DIN bar.
1471E
3-command input relay unit (12 Vac; 12/24 Vdc and electronic).
Provided with timed output for systems with electronic call and
private conversation. 4 A modules in DIN bar.
1472
2-exchange exchanger (1A, 24V) 3 command input: 12 Vdc/
Vac, 24 Vdc and electronic note. Mountable on 3 A DIN module.
GN30
Generator of 3 electronic ringers. For dierentiated calls from
landings or various external door stations.
RL36
Relay module with one exchange (1A, 24V) to be integrated
inside intercoms, it permits to drive 12 Vdc/Vac signal, electronic
note and EC ground.
RL37
It can drive the chime for intercoms and video intercoms, mounta-
ble on 4 A DIN module. 1 free supplementary contact is available,
with electronic note.
SR41
Electronic buzzer module for parallel call of various intercoms
in systems with electronic call.
CV03
Video signal converter from twisted pair to coaxial cable.
EX3160PL EXHITO EX3160+WB3160 PROFILO PL41P+PL71 1281E
EH9160PLCW ECHOS EH9160CW+9083+WA9100W PROFILO PL41PC+PL71 1282E+1281
EH9160PLCT ECHOS EH9160CT+9083+WA9100T PROFILO PL41PC+PL71 1282E+1281
EX3160PLC EXHITO EX3160C+WB3160 PROFILO PL41PC+PL71 1281E
66 Analogue Video Intercom
CONVENTIONAL WIRING, ELECTRONIC CALL
ECHOS-PROFILO SERIES
EH9160PLCW
Colour one-way video kit with white Echos internal station and
Prolo door station.
EH9160PLCT
Colour one-way video kit with metal grey colour Echos internal
station and Prolo door station.
EXHITO-PROFILO SERIES
EX3160PLC
Colour one-way video kit with Exhito internal station and Prolo
door station.
EX3160PL
B/w one-way video kit with Exhito internal station and Prolo
door station.
VIDEO KITS
The video kit is an excellent solution for one family installations. By adopting
the single module of the Prolo series, the choice is between Echos or Exhito
monitors. Ready and complete with all the components for mounting, you can
choose between b/w or colour picture. Packed in carton case.
KITS INTERNAL STATIONS DOOR STATIONS POWER SUPPLY
KITS COMPOSITION
One-way b/w
One-way colour
1CK EXHITO EX310 PRS210
1CKS EXHITO EX310 PRS210
2CK EXHITO 2xEX310 PRS210
2CKS EXHITO 2xEX310 PRS210
67
Analogue Video Intercom
CONVENTIONAL WIRING, ELECTRONIC CALL
1CK
Audio one-way with Exhito internal station and door station
ush mounted Click series.
2CK
Audio two-way with Exhito internal station and door station
ush mounted Click series.
1CKS
Audio one-way with Exhito internal station and door station
surface mounted Click series.
2CKS
Audio two-way with Exhito internal station and door station
surface mounted Click series.
AUDIO KITS
For one or two family Intercom systems, audio kits are available with Exhito
internal station and the new Click series small and elegant external station. The
choice varies not only by the number of users, but also by the wall mounting
option: ush mounted or recessed according to needs.
KITS INTERNAL STATIONS DOOR STATIONS POWER SUPPLY
KITS COMPOSITION
One-way audio
One-way audio
ush mounted Click series
surface mounted Click series
ush mounted Click series
surface mounted Click series
ALTERNATE CURRENT
CALL SYSTEM
In the catalogue there is also some unmissable intercom equipment
that uses the analogue system for alternate current call system
as points of reference for many existing systems or specific requests.
The selection of this technology only provides the audio solution
for which there are no internal stations for video, among the other
options the Project Line and 724N continue to deliver quality and
reliability. Matrix Style, Profilo and Mody are possible alternatives
for the outdoor stations.
There is no rigidity in designing Farfisa systems, which by using the
appropriate system components means that the installation of these
components can also exploit of the electronic call system technology.
INTERNAL STATIONS
700
Project
DOOR STATIONS
Prolo
Matrix Style
Mody
POWER SUPPLIES AND SERVICE MODULES
AUDIO KITS
70
70
71
72
73
75
75
70 Analogue Video Intercom
ALTERNATE CURRENT CALL
INTERNAL STATIONS 700
724N
Dim: mm 215x75x88
Colour: beige
Intercom for alternate current call 4+1 systems. Complete with
carbon microphone, buzzer, door opener button and spiral cord.
INTERNAL STATIONS
For analogue alternate current call systems, the internal intercom stations available with this
technology are the 724N and various versions of the Project range; these are exible and modern
with some accessories that complete the line. They undoubtedly provide maximum robustness
and a more consolidated design.
INTERNAL STATIONS PROJECT
PT510W
Dim: mm 214x77x72
Colour: white
Basic intercoms with door-opener button, spiral cord, electro-
nic microphone, wall mounting and buzzer for 4+1 intercom
systems with alternate current call. Also suitable for systems
with electronic call.
PT520W
Dim: mm 214x86x72
Colour: white
Extendable intercom, for additional or intercommunication
functions, for 4+1 systems with alternate current call. Compatible
with 3+1 systems. Complete with electronic microphone, buzzer,
spiral cord and 2 buttons extendable to 10 for door-opener,
intercom calls and various services.
PT524W
Dim: mm 77x214x72
Colour: white
Basic intercom, for 4+1 systems with alternate current call.
Complete with door-opener, carbon microphone, buzzer, spiral
cord. It can be used also in systems with electronic call.
ACCESSORIES PROJECT
PT501
Single button unit.
PT502
LED module for door open indication and other functions.
PT515
Switch module to cut out ringer (privacy) or other functions.
TA320
Table adaptor compatible with Project series. Made in metal, it is supplied
with 2.4 m cable with 20 conductors.
SM50
Private conversation module for systems with alternate current call.
When installed inside the intercom, it allows only the called user to be
put in communication with the external door station.
71
Analogue Video Intercom
ALTERNATE CURRENT CALL
DOOR STATIONS PROFILO
PL10P
Dim: mm 99x110x17
Audio module with integrated door speaker without call buttons
for conventional wiring systems.
PL11P
Dim: mm 99x110x17
Audio module with integrated door speaker with 1 call button
for 1 conventional wiring systems.
PL12P
Dim: mm 99x110x17
Audio module with integrated door speaker with 2 call buttons
for conventional wiring systems.
PL122P
Dim: mm 99x110x17
Audio module with integrated door speaker with 2 call buttons
on 2 rows for conventional wiring systems.
PL124P
Dim: mm 99x110x17
Audio module with integrated door speaker with 4 call buttons
on 2 rows for conventional wiring systems.
DOOR STATIONS
External station ranges for analogue alternate current call systems are the Prolo, Matrix Style
and Mody ranges. Prolo is the most suitable for situations where there is limited space available,
thanks to the reduced size of the basic module in width and the possibility of a double button
that allows further space saving. You may decide on the Matrix Style whenever an anti-vandal
protection handset is required (IP45 and IK09 degrees of protection) but that does not leave out
its special elegance. Mody is an evergreen solution for large numbers of users that allows space
saving also because of the double button module facility.
Additional modules
PL21
Dim: mm 99x110x17
Module with 1 additional call button.
PL22
Dim: mm 99x110x17
Module with 2 additional call buttons.
PL23
Dim: mm 99x110x17
Module with 3 additional call buttons.
PL24
Dim: mm 99x110x17
Module with 4 additional call buttons.
PL226
Dim: mm 99x110x17
Module with 6 additional call buttons on 2 rows.
PL228
Dim: mm 99x110x17
Module with 8 additional call buttons on 2 rows.
PL50
Dim: mm 99x110x17
Street number module.
PL20
Dim: mm 99x110x17
Blank module.
72 Analogue Video Intercom
ALTERNATE CURRENT CALL
INSTALLATION ELEMENTS PROFILO
PL71
Dim: mm 91x133x47
Back box for 1 module.
PL72
Dim: mm 91x244.5x47
Back box for 2 modules.
PL73
Dim: mm 91x356x47
Back box for 3 modules.
PL81
Dim: mm 118x153x41
Hood cover for 1 module.
PL82
Dim: mm 118x264x41
Hood cover for 2 modules.
PL83
Dim: mm 118x376x41
Hood cover for 3 modules.
PL84
Dim: mm 217x264x41
Hood cover for 4 modules on 2 vertical rows.
PL86
Dim: mm 217x376x41
Hood cover for 6 modules on 2 vertical rows.
PL89
Dim: mm 316x376x41
Hood cover for 9 modules on 3 vertical rows.
PL91
Dim: mm 118x154x80
Surface mounting rain shelter for 1 module.
PL92
Dim: mm 118x265x80
Surface mounting rain shelter for 2 modules.
PL93
Dim: mm 118x377x80
Surface mounting rain shelter for 3 modules.
PL94
Dim: mm 217x264x80
Surface mounting rain shelter for 4 modules on 2 vertical rows.
PL96
Dim: mm 217x376x80
Surface mounting rain shelter for 6 modules on 2 vertical rows.
PL99
Dim: mm 316x376x80
Surface mounting rain shelter for 9 modules on 3 vertical rows.
DOOR STATIONS MATRIX STYLE
MAS10P
Dim: mm 115x115
Audio module with door speaker integrated for conventional
wiring system without call buttons.
MAS11P
Dim: mm 115x115
Audio module with door speaker integrated for conventional
wiring system with 1 call button.
MAS12P
Dim: mm 115x115
Audio module with door speaker integrated for conventional
wiring system with 2 call buttons.
Additional buttons module
MAS22
Dim: mm 115x115
Additional module with 2 call buttons.
MAS24
Dim: mm 115x115
Additional module with 4 call buttons.
73
Analogue Video Intercom
ALTERNATE CURRENT CALL
INSTALLATION ELEMENTS MATRIX STYLE
MAS61
Dim: mm 140x140
Front frame matt titanium grey colour for 1 module.
MAS62
Dim: mm 140x257
Front frame matt titanium grey colour for 2 modules.
MAS63
Dim: mm 140x374
Front frame matt titanium grey colour for 3 modules.
MA71
Dim: mm 128x128x65
Back box for 1 module.
MA72
Dim: mm 128x245x65
Back box for 2 modules.
MA73
Dim: mm 128x362x65
Back box for 3 modules.
MA91
Dim: mm 146x145x92
Surface mounting rain shelter for 1 module.
MA92
Dim: mm 146x262x92
Surface mounting rain shelter for 2 modules.
MA93
Dim: mm 146x379x92
Surface mounting rain shelter for 3 modules.
DOOR STATIONS MODY
MD100
Dim: mm 124x90x18
Audio module with integrated door speaker for conventional
wiring systems with 1 call button.
MD200
Dim: mm 124x90x18
Audio module with integrated door speaker for conventional
wiring systems with 2 call buttons.
MD10
Dim: mm 124x90x18
Audio module ready for door speaker for conventional wiring
systems without call buttons.
MD11
Dim: mm 124x90x18
Audio module ready for door speaker for conventional wiring
systems with 1 call button.
MD12
Dim: mm 124x90x18
Audio module ready for door speaker for conventional wiring
systems with 2 call buttons.
MD122
Dim: mm 124x90x18
Audio module ready for door speaker for conventional wiring
systems with 2 call buttons on 2 rows.
MD124
Dim: mm 124x90x18
Audio module ready for door speaker for conventional wiring
systems with 4 call buttons on 2 rows.
MD30
Speaker unit for 4+1 audio systems to be placed on the MD10,
MD11, MD12, MD122, MD124 modules.
74 Analogue Video Intercom
ALTERNATE CURRENT CALL
Additional buttons module
MD21
Dim: mm 124x90x18
Module with 1 additional call button.
MD22
Dim: mm 124x90x18
Module with 2 additional call buttons.
MD23
Dim: mm 124x90x18
Module with 3 additional call buttons.
MD24
Dim: mm 124x90x18
Module with 4 additional call buttons.
MD222
Dim: mm 124x90x18
Module with 2 additional call buttons in 2 rows.
MD224
Dim: mm 124x90x18
Module with 4 additional call buttons in 2 rows.
MD226
Dim: mm 124x90x18
Module with 6 additional call buttons in 2 rows.
MD228
Dim: mm 124x90x18
Module with 8 additional call buttons in 2 rows.
INSTALLATION ELEMENTS MODY
MD71
Dim: mm 124x121.5x64
Back box for 1 module.
MD72
Dim: mm 124x213x64
Back box for 2 modules.
MD73
Dim: mm 124x304.5x64
Back box for 3 modules.
MD74
Dim: mm 124x395x64
Back box for 4 modules.
MD81
Dim: mm 151x140x40
Hood cover for 1 module.
MD82
Dim: mm 151x231.5x40
Hood cover for 2 modules.
MD83
Dim: mm 151x323x40
Hood cover for 3 modules.
MD804
Dim: mm 151x414.5x40
Hood cover for 4 modules.
MD84
Dim: mm 276x231.5x40
Hood cover for 4 modules on 2 vertical rows.
MD86
Dim: mm 276x323x40
Hood cover for 6 modules on 2 vertical rows.
MD91
Dim: mm 151x140x80
Surface mounting rain shelter for 1 module.
MD92
Dim: mm 151x231.5x80
Surface mounting rain shelter for 2 modules.
MD93
Dim: mm 151x323x80
Surface mounting rain shelter for 3 modules.
MD94
Dim: mm 276x231.5x80
Surface mounting rain shelter for 4 modules on 2 vertical rows.
MD96
Dim: mm 276x323x80
Surface mounting rain shelter for 6 modules on 2 vertical rows.
1PTMW PROJECT PT510W MODY MD71+MD100 PRS210
1MPW PROJECT PT510W MODY MD71+MD11+MD30 PRS220
2PTMW PROJECT 2x PT510W MODY MD71+MD200 PRS210
2MPW PROJECT 2x PT510W MODY MD71+MD12+MD30 PRS220
1V/12V PROJECT 1/12xPT524SW ERREP/R RP1/RP12+MD30 PRS220
75
Analogue Video Intercom
ALTERNATE CURRENT CALL
POWER SUPPLIES
AND SERVICE MODULES
SR40
Electronic ringer module for systems with alternate current
call. When installed inside the intercom, it allows the buzzer
call to be replaced by the electronic call or a call to be added,
e.g. a call from landing.
SR41
Electronic buzzer module.
1473
4-exchange exchanger for automatic switching of 2 inputs. 8 A
modules in DIN bar.
1471
2 command input relay unit (12 Vac; 12/24 Vdc). 3 A modules
in DIN bar.
1472
2-exchange exchanger (1A, 24V) 3 command input: 12 Vdc/
Vac, 24 Vdc and electronic note. Mountable on 3 A DIN module.
GN30
Generator of 3 electronic ringers. For dierentiated calls from
landings or various external door stations.
RL36
Relay module with one exchange (1A, 24V) to be integrated
inside intercoms, it permits to drive 12 Vdc/Vac signal, electronic
note and EC ground.
PRS210
15VA transformer. 127-230V. 13 Vac. VDE certication. 3 DIN
modules in DIN bar, or it can be mounted on the wall. Can be
used to power art. 2223, 2223C, 2273 and 2281.
PRS220
15VA power supply. 6 Vdc-13 Vac. VDESASO certications. 4 A
modules in DIN bar.
PRS226
18VA power supply-commutator.
8 Vdc-13 Vac. VDE certication. 6 A modules in DIN bar. For in-
tercoms connected to external door station.
PRS231
Power supply 8 Vdc-13 VAC. 6 A DIN module. It is able to supply
intercommunicating intercom systems without door station.
PRS235
18VA power supply with call reset.
8 Vdc-13 Vac. VDE certication. 6 A modules in DIN bar. For private
conversation systems.
AUDIO KITS
The kits are very appreciated because easy to be used. They
are organised ready for installation: in the box you will nd all
components for assembly, namely the internal station, external
station and power supply, accompanied by an instruction
manual. All models are one or two family, except for the
Victory family that oers solutions from 1 to 12 users.
1PTMW
Audio one-way kit with Project internal station and Mody door station with integrated door speaker.
2PTMW
Audio two-way kit with Project internal station and Mody door station with integrated door speaker.
1MPW
Audio one-way kit with Project internal station and Mody door station with separate door speaker.
2MPW
Audio two-way kit with Project internal station and Mody door station with separate door speaker.
1V/12V
Audio one-way Victory series (or multi-way up to 12) kit with Project internal station and ErreP/R
door station.
KITS INTERNAL STATIONS DOOR STATIONS POWER SUPPLY
KITS COMPOSITION
One-way audio
One/Two-way audio
Two-way audio
HOME AUTOMATION
With myLogic, the range developed and designed for home automation,
the Farfisa selection enters the world of home automation.
It is a result of constant research and is undoubtedly at the cutting
edge in various respects: concept, technology, power, design and
usability. MyLogic incorporates advanced Videointercom features
with many possibilities for home automation, it is easy to install and
simple to use. Based on Duo System digital technology, it allows you to
control and manage all the main functions from a single point in your
home: from access control to the heating system, to air conditioning
units, up to the events programming, everything tailored to the user.
INTERNAL STATIONS
myLogic
DOOR STATIONS
SYSTEM ELEMENTS
POWER SUPPLIES AND SERVICE MODULES
VIDEO KITS
80
81
82
82
83
www.mylogic.it
system
color
78 Home automation
Door stations
Surveillance cameras management
Digital door-keeper exchanger
MYLOGIC HOME AUTOMATION
The myLogic terminal is at the heart of an integrated home automation-Videointercom system
that uses Duo System digital technology. Consequently myLogic makes all the characteristics and
the advantages that characterize the Duo System valid, rst and foremost the extreme simplicity
of installation thanks to the 2 non-polarized wires. The Duo System system oers a wide variety
of operation and installation options, allowing even complex systems with a large number of
users. Therefore the broadest performance is assured: up to 200 internal stations with the ability
to integrate other monitor ranges alongside myLogic and multiple main and secondary external
stations. myLogic is therefore able to eectively manage the dierent home automations within
a complex and multi-user system.
In the detail of the operation, the myLogic terminal manages the connected devices through
the actuator to run the commands set. The main areas of work manage Video intercom,
Thermoregulation and the Actuators/Events section, i.e. the possibility of tripping the
device in certain situations.
All functions are managed with simple gestures like touching your nger or the supplied stylus
directly on the screen or by using the 4 function keys at the bottom of the device. MyLogic is also
equipped with a memory card reader to import your photos (photo frame) that can also be used
for creating custom screen savers and technology upgrades or for the particular needs of the user.
ACI Farfisa also dedicates a
website to myLogic, www.mylogic.it
where you can find all the information,
details and documentation
for a detailed view of the range
Duo System
Agorà Light
PDX2000
Agorà
ProloMatrix Style
10
myLogic
79Home automation
CONTROL BOARD
Simple interface for easy access to myLogic functions
and settings.
ACTIONS
Home automation functions such as lighting, window
shutters and garden watering...
EVENTS
Home automation control of dynamic functions such as
door opening/closing, gas detection, lighting settings.
SETTINGS
Simple and practical myLogic settings (audio, display,
etc.).
CLIMATE CONTROL
Automatic or manual control of central heating and
air conditioning.
VIDEO INTERCOM
Control of received, dialled or missed calls from the
door station. Stored images of callers.
PICTURES
Personalization of the home page screen by using
standard pictures or user imported images.
BLOCK NOTES
Memo text with acoustic warning activated at a set
time.
INTERCOM/TEXTING
Intercom function to connect all house sectors and
messaging service.
FAVOURITES
Personalization and optimisation of the access to
myLogic functions according to demand.
Functions
to manage your home
Home Page
Video Intercom
Smart home
Notes
Images
Climate control
80 Home automation
INTERNAL STATIONS MYLOGIC
ML2262C
Dim: mm 154x154x30
Colour: metal grey and dark anthracite
Colour hand-free videointercom with home automation functions
for Duo System. 4.3” LCD-TFT touch screen, 16:9 format. 4 function
buttons and instructions on the graphic interface (by nger touch
or stylus supplied) for the classical videointercom functions and
home automation features. In videointercom area door-lock,
intercommunication, auto switch-on, missed chimes with visitor
photo, block notes, memo. Home automation functions allow
external devices control through specic interfaces. Software
updating and imported personal pictures are possible through
memory card.
INSTALLATION ELEMENTS
ML2083
Back box for myLogic monitors.
WA2160W
White wall adaptor for surface mounting of myLogic monitors. Made
in plastic, it can be used in all the surface mounting installations of my-
Logic monitors, instead of the ush mounting.
WA2160T
Silver colour wall adaptor for surface mounting of myLogic monitors.
Made in plastic, it can be used in all the surface mounting installations
of myLogic monitors, instead of the ush mounting.
TA2160
Table adaptor for myLogic monitors, to be mounted with WA2160W or
WA2160T, supplied with connection cables.
ACCESSORIES
MC2000W
White plastic cover for myLogic monitors. It allows the personalization
of the videointercom, by changing the one supplied with the monitor.
MC2000T
Silver colour plastic cover for myLogic monitors. It allows the person-
alization of the videointercom, by changing the one supplied with the
monitor.
INTERNAL STATIONS
Aci Farsa Home automation conceives myLogic at the system centre of the system as a Video
intercom-home automation internal terminal. The line includes in addition to the basic
component, covers that can be interchanged to suit the look the internal enviroment, completed
with some installation components to give a choice of either surface or recessed mounting,
as an alternative to the table support. All details and proportions are treated in full respect of
a product which makes prestige combined with practicality its strong point.
myLogic with built-in back box myLogic with wall adaptor
for surface mounting
system
color
81Home automation
Discover all the details of the Duo system
with all the available External Stations
in the Digital Video intercom chapter.
Page 19
19
>
EXTERNAL STATIONS
MyLogic works with Duo System digital technology, and so takes advantage of all the system
components such as external stations, any door keeper exchanger, power supplies and modules
for complete installation and maximum performance.
The external stations designed for Duo System are Agorà Light and Agorà, Prolo and Matrix Style,
all modular and of high quality. In particular Agorà Light or Agorà are preferred in situations
where reduced size in width is important. A further advantage is the fact that the module is
already complete and ready for installation and comes ush mounted into the wall, so there is
no need to break the wall. Prolo instead is the most exible and compact range with digital
calling modules or with traditional button modules, even for large numbers of users with multiple
possibilities thanks to the double button that allows further space savings and various accessories
in the range. Matrix Style anti-vandal designed, thanks to the IP45 and IK09 degrees, ensures
maximum protection at the same time as oering elegance and exibility.
82 Home automation
POWER SUPPLIES
AND SERVICE MODULES
2220S
Power supply for Duo System for conventional and digital door
stations. Output 13 Vac/1A protected against overloading and
shortcircuits. Dim: 3 DIN modules.
2221S
Line driver 6 DIN modules. Directly connected to the mains, it
allows power to Duo System riser.
2223C
Video amplier for Duo System colour installations.
2273
Digital exchanger for Duo System.
2302
Twisted pair wire for Duo System with single section 1 sq. mm.,
100 m coil.
2281
Actuator for Duo System, used to activate auxiliary services, such
as additional door lock, lights, and chimes.
DV2420
Line distributor for Duo System.
DV2421P
Video distributor for Duo System. It allows very wide installations.
It is used to with draw the signal from the riser.
PRS210
15VA transformer. 127-230V. 13 Vac. VDE certication. 3 DIN
modules in DIN bar, or it can be mounted on the wall. Can be
used to power art. 2223, 2223C and 2281.
2230
Appartment separator in home automation installations with
Duo System with myLogic.
DV2424P
Video distributor 4 output for Duo System. It is very flexible
and it allows very wide installations. It is used to withdraw the
signal from the riser.
2221ML
Appartment power supply for myLogic in multi-way instal-
lations. It powers all devices with a proper audio, video and
data impedance.
DV2422A
Active video line distributor, 2 outputs, specic for myLogic mon-
itor, it also can be connected to all the other Duo System devices.
DM2444
Concentrator module that allows to selectively centralize more
door stations and more risers.
2287
Selector for 4 or 7 exchanges for Duo System. It allows the se-
lection of maximum 4 or 7 surveillance cameras and\or other
services activation.
SYSTEM
ELEMENTS
PDX2000
Dim: mm 209x186x67
Colour: white
Digital door-keeper exchanger. Available functions: internal
station-internal station and external station-internal station
communication, auto-insertion on external door station, day/
night shunted switching, lost calls management, guarantee of
system working even with the door-keeper exchanger badly
working. Further features: classication users groups, insertion
on a busy user, opening of many doors even on non-specific
demand, memo/ agenda, servant function, different colour
for display lighting. Multiple door-keepers exchanger system
allowed. Updating or data import through memory card. Call
queuing and call booking not available.
ST7100CW
Dim: mm 156x224x61
Colour: white
Colour monitor 4” LCD screen, adjustable in inclination, auto
switch-on button and an additional one.
INSTALLATION ELEMENTS AND ACCESSORIES
TA7100W
White table adaptor, for ST7100CW monitors. Complete with
cable clamp, junction box and 2.4 m connection cable with 20
wires. To be used with WB7260 wall bracket.
WB7260
Wall bracket for ST7100CW monitors for connection to PDX2000
door-keeper exchanger.
ML2262AGLC MYLOGIC ML2262C+ML2083 AGORÀ LIGHT VD2121CAGL 2220S+2221S
ML2262AGC MYLOGIC ML2262C+ML2083 AGORÀ VD2121CAG 2220S+2221S
ML2262PLC MYLOGIC ML2262C+ML2083 PROFILO VD2120CPL+CD2131PL+PL72 2220S+2221S
83Home automation
MYLOGIC-AGORÀ LIGHT SERIES
ML2262AGLC
One-way colour videokit with home-automation myLogic monitor
and Agorà Light door station.
MYLOGIC-AGORÀ SERIES
ML2262AGC
One-way colour videokit with home-automation myLogic monitor
and Agorà door station.
VIDEO KITS
These are very much demanded and widely appreciated videokits, complete with all the components
for easy installation of a myLogic home automation system for one or two way Duo System.
The packaging is particulary good looking and they also contain the user manual for the end user
very important for correct home automation functions management.
MYLOGIC-PROFILO SERIES
ML2262PLC
One-way colour videokit with home-automation myLogic monitor
and Prolo door station.
VIDEO KIT INTERNAL STATION DOOR STATION POWER SUPPLY
VIDEO KIT COMPOSITION
One-way colour
ACCESS CONTROL
The selection of Access Control includes a complete line of access control
proximity readers and keypads that Standing Alone or together with
Video intercom systems offer various security solutions.
Aci Farfisa also offers products for stand-alone use with look of the
most flexible external station ranges of the catalogue. We refer to
Profilo and Mody for proximity readers, and the available ranges for
keypads are Profilo, Matrix Style and Mody or other items not related
to an existing range of push button panels that vary in features and
specifications.
The 1PEXFD kit represents a new and practical solution; it is an audio
kit consisting of the external station with access control module and
intercom.
PROXIMITY READERS
AUDIO KIT
KEYPADS
86
86
87
8686 Access Control
PROXIMITY READERS
FP52
Dim: mm 124x90x18
Stand Alone Proximity Reader to be inserted in the Mody door
station composition, in anodised aluminium. Ideal for access
control situations, it uses all the accessories of Mody push button
panels for surface or ush mounting, it is possible to combine it
in Videointercom in Videointercom installations. It is provided
with two mono stable relays which timing is adjustable according
to the features of the connected device. The programming is
made through master card managed by a display and a LED on
the front of the reader that indicates also the operation status
and data insertion of the enabled cards. Thanks to the 500 unit
memory capacity, it is particularly indicated for the management
of the access in big buildings or communities. It is provided with
4 cards + 1 Master Card.
FP52PL
Dim: mm 99x110x17
Aluminium stand alone proximity reader into a Prolo door
station model. Designed for access control, it exploits Prolo
accessories for ush or surface mounting, so even compositions for
videointercom system are possible. Supplied with two relays with
programmable timer according to the features of the connected
device. The programming is made through a master card managed
by a display and front LED’s that indicate also data insertion of
the enabled cards. Memory capacity is 500 cards, therefore ideal
use is access control of complex buildings or communities. It is
provided with 4 cards + 1 master card. Power supply 12 Vac/Vdc.
FP11/10
Set containing 10 cards in white plastic for FP52 and FP52PL
proximity reader. ISO standard format.
FP12/10
Set composed by 10 transponder units for activation of FP52 and
FP52PL. Together with the actual transponder, which is circular
shaped joint to an useful metal key-holder with closing. Material
is plastic in blue and white colour.
TRANSFORMER
PRS210
15VA transformer. 127-230V. 13 Vac. VDE certication. 3 A modules
on DIN bar. Ideal to power with alternate current Farcode Proximity
Readers and Access Control Keypads elements.
PROXIMITY READERS
The selection of proximity readers is up-to-date and adapts harmoniously to the more versatile
ranges of modular external stations in the catalogue: Prolo and Mody.
The system allows the opening of doors or gates to be activated so as to allow exclusive access
to the card holder or the transponder once the element is simply approached to the reader.
Among the range for access control, this choice is particularly suitable for communities or large
residential complexes.
1PEXFD
Complete one way audio kit that consists of Exhito EX321 inter-
com + external station with modules PL11PED and FC52PL access
control keypad with PL92 for surface mounting + PRS210ED
power supply. Reduced wiring.
55
>
AUDIO KIT
8787
Access Control
KEYPADS
FC52PL
Dim: mm 99x110x17
Stand alone keypad with aluminium front plate and stainless
steel buttons, that can be installed singularly or in composi-
tion with Profilo door stations for surface or flush mounting.
Keypad for programming and setting relay enable codes of
the two relays for door opening or access control etc. Keypad
deactivation with increasing time intervals (max 25 sec), and,
in case of wrong combination, deactivation is automatic.
12 programmable codes from 1 to 8 digits for each relay,
programmable timer from 1 to 99 sec. or bistable working of
relays. Two LED’s and sound signals indicate correct or wrong
combination and programming. Relay can be activated by
pressing additional button. Power supply 12 Vac/Vdc. Flush
mounted version.
FC52MAS
Dim: mm 115x115x57
Anti-vandal stand alone keypad (IP45, with stainless steel front
plate and buttons ) that can be installed singularly or combining
it with conventional or digital audio or video Matrix Style com-
position. It works with 2 relays for lock opening, access control
etc. with 12 programmable codes from 1 to 8 digits for each
relay. Possibility to activate relays with additional buttons (exit
button). Programmable timer from 1 to 99 seconds in monostable
working, or bistable operation. Flush mounting with Matrix
or Matrix Style accessories (for the installation elements, see
Door Stations on previous chapters). Power Supply: 12 Vac/Vdc.
FC52P
Dim: mm 124x90x18
Access Control keypad with aluminium front plate and buttons
in stainless steel Mody series. 2 relays for lock opening, access
control, etc. Keypad for programming and setting relay enable
codes. Keypad deactivation with increasing time intervals (max
25 sec.) in case of wrong combination. 4 programmable codes
from 2 to 6 digits for each relay. Possibility to activate relay 2
with a single button. Programmable timer from 1 to 99 sec-
onds or bistable operation of relay 1. 2 LED’s and sound signals
indicating correct or incorrect combination and programming.
Relay 1 can be activated by pressing an additional Exit button.
Power supply 12 Vac/Vdc.
FC32P
Dim: mm 85x110x54
Access Control keypad with aluminium front plate and buttons
in stainless steel. 2 relays for lock opening, access control, etc.
Keypad for programming and setting relay enable codes. Keypad
deactivation with increasing time intervals (max 25 sec.) in case
of wrong combination. 4 programmable codes from 2 to 6 digits
for each relay. Possibility to activate relay 2 with a single button.
Programmable timer from 1 to 99 seconds or bistable operation
of relay 1. 2 LEDs and sound signals indicating correct or incorrect
combination and programming. Relay 1 can be activated by
pressing an additional Exit button. Power supply 12 Vac/Vdc.
Wall back boxed version.
FC42
Dim: mm 80x125x33
Access Control keypad IP45 surface mounted with stainless
steel front plate and buttons. 2 relays for lock opening, access
control, etc. Keypad for programming and setting relay enable
codes. Keypad deactivation with increasing time intervals (max
25 sec.) in case of wrong combination. 12 programmable codes
up to 8 digits for each relay. Programmable timer from 1 to 99
seconds or bistable operation of relay 1. 2 LED’s and sound signals
indicating correct or incorrect combination and programming.
Relays can be activated by pressing an additional Exit buttons.
Power supply 12 Vac/Vdc. Wall surfaced mounted version.
FC21E
Dim: mm 77x106x42
Access control keypad with front plate, buttons and box in
plastic. One lock-opening relay, access control, etc. Keypad
for programming and setting relay enabling codes. Keypad
deactivation with increasing time intervals (max 25 sec.) in
case of wrong combination. 8 programmable codes from 2 to
6 digits. Programmable timer from 1 to 99 seconds or bistable
operation. 2 LED’s indicating correct or incorrect combination
and programming. Power supply 12 Vac/Vdc. Wall mounted
and without back box.
TRANSFORMER
PRS210
15VA transformer. 127-230V. 13 Vac. VDE certication. 3 A modules
on DIN bar. Ideal to power with alternate current Farcode Proximity
Readers and Access Control Keypads elements.
KEYPADS
There is a wide range of devices for access control, with dierent models that respond to dierent
needs, starting from the basic product up to keypads that, while always stand alone in function,
guarantee greater security once combined with a Video intercom system by using the modules
with Prolo, Matrix Style or Mody lines.
TELEPHONY
The telecommunication applications in residential are organised by
Aci Farfisa by several solutions.
One of the news is myCom system using Profilo door stations where
calls to the tenants happen directly exploiting the GSM technology
to fixed or mobile telephones, therefore with no conventional audio
systems and related cabling, the communication and the access control
are guaranteed by a remarkable installation simplicity.
Within the telephone communications range solutions, telephone
PABX’s are available, with extra and further accessories. These
complete the offer.
DOOR STATION GSM MYCOM
ELECTRONIC PABX’s
INTERCOM - TELEPHONE INTERFACE
PROTECTION DEVICES
90
92
92
92
9090 TELEPHONY
DOOR STATION GSM MYCOM
The door station “myCom” uses GSM technology; therefore few elements and
just a power supply are requested: this allows to have a complete a reliable
communication system.
The call is made by the Profilo door station by a conventional button module
or by digital keyboard and it’s transmitted to a fixed or mobile telephone
number properly programmed in a planned sequence. Several external stations
are allowed and multiple lock openings are separately managed, for instance
door and gate.
Therefore it’s a substantial alternative for an audio installation even pretty
large (without limits of distance amongst outside station and inside received)
with no wiring at all.
Technical features
• Programming by USB, SMS (texting) or directly on SIM card
• Powering 12 Vdc\ac
• A SIM card is required
• Pre paid SIM card can be managed
Functions
Land phone number or mobile phone number (3 numbers in cascade in case of
no answer)
• CLIP function available. It allows caller identication for lock releasing
• 2 electric lock releases are permitted
• The max number of users is 50
• Alarm activation managing
GSM AUDIO CALL MODULES
PL10G
Dim: mm 99x110x17
Audio module with integrated door speaker, with no button
for myCom system.
PL11G
Dim: mm 99x110x17
Audio module with integrated door speaker, 1 call button for
myCom system.
PL12G
Dim: mm 99x110x17
Audio module with integrated door speaker, 2 call buttons
for myCom system.
PL124G
Dim: mm 99x110x17
Audio module with integrated door speaker, 4 call buttons on
two rows for myCom system.
OTHER SYSTEM ELEMENTS
PRS210
15VA transformer. 127-230V. 13 Vac. VDE certication. 3 A modules
on DIN bar. Ideal to power with alternate current Farcode Proximity
Readers and Access Control Keypads elements.
AN01
Antenna to be used any time the signal is not appropriated. It’s
supplied with coaxial cable and connector, a bracket is not supplied.
9191
TELEPHONY
PROFILO INSTALLATION ELEMENTS
PL71
Dim: mm 91x133x47
Back box for 1 module.
PL72
Dim: mm 91x244.5x47
Back box for 2 modules.
PL73
Dim: mm 91x356x47
Back box for 3 modules.
PL81
Dim: mm 118x153x41
Hood cover for 1 module.
PL82
Dim: mm 118x264x41
Hood cover for 2 modules.
PL83
Dim: mm 118x376x41
Hood cover for 3 modules.
PL84
Dim: mm 217x264x41
Hood cover for 4 modules on 2 vertical rows.
PL86
Dim: mm 217x376x41
Hood cover for 6 modules on 2 vertical rows.
PL89
Dim: mm 316x376x41
Hood cover for 9 modules on 3 vertical rows.
PL91
Dim: mm 118x154x80
Surface mounting rain shelter for 1 module.
PL92
Dim: mm 118x265x80
Surface mounting rain shelter for 2 modules.
PL93
Dim: mm 118x377x80
Surface mounting rain shelter for 3 modules.
PL94
Dim: mm 217x264x80
Surface mounting rain shelter for 4 modules on 2 vertical rows.
PL96
Dim: mm 217x376x80
Surface mounting rain shelter for 6 modules on 2 vertical rows.
PL99
Dim: mm 316x376x80
Surface mounting rain shelter for 9 modules on 3 vertical rows.
Additional modules
PL24S
Dim: mm 99x110x17
Additional module with integrated decoder for external
stations with 4 buttons.
PL228S
Dim: mm 99x110x17
Additional module with integrated decoder for external
stations with 8 buttons on 2 rows.
PL50
Dim: mm 99x110x17
Street number module.
PL20
Dim: mm 99x110x17
Blank module.
MYCOM DIGITAL DOOR STATIONS
TD10PLG
Dim: mm 99x110x17
Digital door station for myCom, with aluminium front plate and
14 steel buttons. Equipped with LCD graphic display. It allows the
call from the user by dialling the corresponding number and
electric lock release by entering the private code. The electronic
index is also integrated, which gives the possibility to scroll
the names in alphabetical order and select the desired one. It
can store up to 200 user names. It must be connected to PL10G,
PL11G, PL12G or PL124G.
FC52PL
Dim: mm 99x110x17
Stand alone keypad with aluminium front plate and stainless
steel buttons, that can be installed singularly or in composition
with Prolo door stations for surface or ush mounting. Keypad
for programming and setting relay enable codes of the two relays
for door opening or access control etc. Keypad deactivation with
increasing time intervals (max 25 sec), and, in case of wrong
combination, deactivation is automatic. 12 programmable codes
from 1 to 8 digits for each relay, programmable timer from 1 to
99 sec. or bistable working of relays. Two LED’s and sound signals
indicate correct or wrong combination and programming. Relay
can be activated by pressing additional button. Power supply 12
Vac/Vdc. Flush mounted version.
FP52PL
Dim: mm 99x110x17
Aluminium stand alone proximity reader into a Prolo door
station model. Designed for access control, it exploits Prolo
accessories for ush or surface mounting, so even compositions for
videointercom system are possible. Supplied with two relays with
programmable timer according to the features of the connected
device. The programming is made through a master card managed
by a display and front LED’s that indicate also data insertion of
the enabled cards. Memory capacity is 500 cards, therefore ideal
use is access control of complex buildings or communities. It is
provided with 4 cards + 1 master card. Power supply 12 Vac/Vdc.
KIT 1MCFCPL
Composed by door station PL11G, transformer PRS210, FC52PL
keypad and rain shelter PL92.
KIT 1MCPL
Composed by door station PL11G, transformer PRS210 and back
box PL71.
9292 TELEPHONY
ELECTRONIC PABX’s
FT105P
Telephone PABX with 1 trunk line and 5 internal lines.
FT208P
Telephone PABX with 2 external lines/8 internal lines, respec-
tively. The intercom double call, together with the possibility to
divide the external lines on to 2 dierent bands of internal stations,
make the FT208 mode the ideal solution for two-way or home/
oce applications in which the PABX is shared.
ADDITIONAL BOARDS
ES60
Intercom interface with double call and 2 relays for door-opener.
ES65
Same as ES60, with 2 additional relays for the activation of
electrical equipment, also from remote telephone.
ES70
Board which allows to identify the calling number providing that
this service is required to the local telephone provider.
INTERCOM - TELEPHONE INTERFACE
FT11D
An intercom-telephone interface that allows a normal telephone
to be connected to the telephone trunk line and the home in-
tercom system.
FT11D does not require any programming and telephone com-
munication is direct. Intercom communication can take place
after an external call has been received or by pressing the R
key or Flash twice.
Operation: during conversation, a background sound signal
indicates the arrival of an intercom or telephone call to the user.
The telephone conversation under way can be put on hold, with
background music, in order to answer the intercom call. The
intercom interface has a terminal board with the same numbering
as a Aci Farsa intercom and can form part of a 4+1 intercom or
traditional video intercom system.
Power supply: 127/230V.
Maximum power consumption: 7W.
DIN housing: DIN, 8 A modules.
FT105P FT208P
Power supply 230V 230V
Maximum power consumption 16W 18W
Power consumption in stand-by 10W 10W
Temperature and humidity ÷40° C - 85%RH ÷40°C- 85%RH
Dimensions 226 x 254 x 66 226 x 254 x 66
Weight 1,3 kg 1,4 kg
No. of external lines 1 2
No. of internal lines 5 8
Italian approval 1998BXSP191 1998BXSP032
ELECTRONIC PABXs
The Fartel PABX’s represent the heart of Aci Farfisa integrated communication.
They increase the uses and capabilities of the telephone: the ideal answer to the
ever-increasing communication needs of the home and the office. The range
includes PABX and additional boards.
The PABX’s of the connected terminals: programming the telephones in different
telephone features and intercom services (e.g.: only certain local areas, only
some telecommunication operators), setting distinctive ringing, associating
a direct internal number with each telephone set (DISA function), defining
a terminal as “fax”, follow me, call capture, 3-party conference. 2 different
general modes can be programmed (e.g.: day and night). Programming is
carried out from a master telephone via a security code. Other features of
the PABX: electrical power failure running (each external line is guaranteed
a direct connection with an internal station and a permanent memory keeps
the programming data), room monitor (continuous listening from one room
to another), amplified speaker output for paging application, activation of
electrical equipment from remote telephone.
PROTECTION DEVICES
PR1
Protection device for 1 telephone line on DIN 2.5 module bar.
PR2
Protection device for 2 telephone lines on DIN 2.5 module bar.
PRAL
Protection device for power supply line on DIN 2.5 module bar.
ITEMS INDEX
1AEXD 55
1CK 67
1CKD 55
1CKS 67
1CKSD 55
1MPW 75
1PEXD 55
1PEXFD 55, 86
1PTMW 75
1V/12V 75
2CK 67
2CKD 55
2CKS 67
2CKSD 55
2MPW 75
2PEXD 55
2PTMW 75
241D 52
241DMA 50, 51
476 35, 65
724N 70
1181E 53
1273TV 65
1281 35, 53, 65
1281E 65
1282E 65
1304 65
1443E 65
1443ED 53
1471 35, 41, 53, 65, 75
1471E 53, 65
1472 35, 41, 53, 65, 75
1473 53, 65, 75
2220S 23, 82
2221ML 23, 82
2221S 23, 82
2223 23
2223C 23, 82
2230 23, 82
2273 23, 82
2281 23, 82
2287 23, 82
2302 23, 82
4230 35
4235TVP 35
4236 35
4273P 35
6273 41
9083 18, 30, 46, 58
A
AD2110MAS 22
AD2120CPL 20
AD2121CAG 20
AD2121CAGL 19
AG20 20, 49
AG21 20, 49
AG30ED 49
AG40CED 49
AG100A 49
AG100T 49
AG100TS 20
AG100V 49
AGL20 19, 48
AGL21 19, 48
AGL100A 48
AGL100T 48
AGL100TS 19
AGL100V 48
AN01 90
C
CD2131MAS 22
CD2131PL 21
CD2132MAS 22
CD2132PL 21
CD2134MAS 22
CD2134PL 21
CD2138PL 21
CD4130MAS 34
CD4134PL 33
CD4138PL 33
CD6134PL 40
CD6138PL 40
CV01 35, 65
CV02 65
CV03 35, 65
D
DM2444 23, 82
DV2 35, 65
DV2D 35, 41, 53, 65
DV4 35, 65
DV4D 35, 41, 53, 65
DV2420 23, 82
DV2421P 23, 82
DV2422A 23, 82
DV2424P 23, 82
E
EH9100CW 58
EH9160CT 58
EH9160CW 58
EH9160CWDG 30
EH9160PLCT 66
EH9160PLCW 66
EH9161AGCT 54
EH9161AGCW 54
EH9161AGLCT 54
EH9161AGLCW 54
EH9161CT 46
EH9161CW 46
EH9161PLCT 54
EH9161PLCT/2 54
EH9161PLCW 54
EH9161PLCW/2 54
EH9262AGCT 25
EH9262AGCW 25
EH9262CT 18
EH9262CW 18
EH9262PLCT 25
EH9262PLCT/2 25
EH9262PLCW 25
EH9262PLCW/2 25
ES60 92
ES65 92
ES70 92
EX301 47, 59
EX304 47, 59
EX310 59
EX311 47
EX312 38
EX320 59
EX320DG 31
EX321 47
EX322 38
EX332 47, 59
EX352 18
EX362 18
EX3100C 31, 38, 47, 59
EX3111AGC 54
EX3111AGLC 54
EX3111PLC 54
EX3111PLC/2 54
EX3160 31, 38, 47, 59
EX3160C 31, 38, 47, 59
EX3160PL 66
EX3160PLC 66
EX3161AG 54
EX3161AGC 54
EX3161AGLC 54
EX3161AGL 54
EX3161PL 54
EX3161PL/2 54
EX3161PLC 54
EX3161PLC/2 54
EX3262 18
EX3262AG 25
EX3262AGC 25
EX3262C 18
EX3262PL 25
EX3262PL/2 25
EX3262PLC 25
EX3262PLC/2 25
F
FC21E 87
FC32P 87
FC42 87
FC52MAS 87
FC52P 87
FC52PL 87, 91
FP11/10 86
FP12/10 86
FP52 86
FP52PL 86, 91
FT11D 92
FT105P 92
FT208P 92
G
GN30 65, 75
K
KIT 1MCFCPL 91
KIT 1MCPL 91
KM810WDG 31
M
MA71 22, 34, 51, 63, 73
MA72 22, 34, 51, 63, 73
MA73 22, 34, 51, 63, 73
MA91 22, 34, 51, 63, 73
MA92 22, 34, 51, 63, 73
MA93 22, 34, 51, 63, 73
MAS10P 34, 62, 72
MAS11P 34, 62, 72
Art. Page Art. Page Art. Page
MAS11PED 41, 51
MAS12P 34, 62, 72
MAS20 51
MAS22 51, 62, 72
MAS24 51, 62, 72
MAS24S 22, 34
MAS42CDG 34
MAS43CDG 34
MAS43CED 41, 51
MAS61 22, 34, 51, 63, 73
MAS62 22, 34, 51, 63, 73
MAS63 22, 34, 51, 63, 73
MC2000T 17, 80
MC2000W 17, 80
MC3000B 18, 31, 38, 47, 59
MC3000G 18, 31, 38, 47, 59
MC3000T 18, 31, 38, 47, 59
MD10 63, 73
MD10ED 52
MD11 63, 73
MD11ED 52
MD12 63, 73
MD12ED 52
MD20 52
MD21 52, 64, 74
MD22 52, 64, 74
MD23 52, 64, 74
MD24 52, 64, 74
MD30 63, 73
MD41D 52
MD50 52
MD71 53, 64, 74
MD72 53, 64, 74
MD73 53, 64, 74
MD74 53, 64, 74
MD81 53, 64, 74
MD82 53, 64, 74
MD83 53, 64, 74
MD84 53, 64, 74
MD86 53, 64, 74
MD91 53, 64, 74
MD92 53, 64, 74
MD93 53, 64, 74
MD94 53, 64, 74
MD96 53, 64, 74
MD100 63, 73
MD122 63, 73
MD124 63, 73
MD200 63, 73
MD222 52, 64, 74
MD224 52, 64, 74
MD226 52, 64, 74
MD228 52, 64, 74
MD804 53, 64, 74
ML2002AGC 24
ML2002AGLC 24
ML2002C 17
ML2002PLC 24
ML2062AGC 24
ML2062AGLC 24
ML2062C 17
ML2062PLC 24
ML2083 17, 80
ML2262AGC 24, 83
ML2262AGLC 24, 83
ML2262C 17, 80
ML2262PLC 24, 83
P
PDX2000 23, 82
PDX4000 35
PL10G 90
PL10P 32, 61, 71
PL10PED 39, 49
PL11G 90
PL11P 32, 61, 71
PL11PED 39, 49
PL12G 90
PL12P 32, 61, 71
PL12PED 39, 49
PL20 33, 40, 50, 61, 71, 91
PL21 50, 61, 71
PL22 50, 61, 71
PL23 50, 61, 71
PL24 50, 61, 71
PL24S 21, 33, 40, 91
PL40P 61
PL40PC 60
PL40PCDG 32
PL40PCED 39, 49
PL40PED 39, 49
PL41P 61
PL41PC 60
PL41PCED 39, 49
PL41PED 39, 49
PL42P 61
PL42PC 60
PL42PCDG 32
PL42PCED 39, 49
PL50 33, 40, 50, 61, 71, 91
PL71 21, 33, 40, 50, 62, 72, 91
PL72 21, 33, 40, 50, 62, 72, 91
PL73 21, 33, 40, 50, 62, 72, 91
PL81 21, 33, 40, 50, 62, 72, 91
PL82 21, 33, 40, 50, 62, 72, 91
PL83 21, 33, 40, 50, 62, 72, 91
PL84 21, 33, 40, 50, 62, 72, 91
PL86 21, 33, 40, 50, 62, 72, 91
PL89 21, 33, 40, 50, 62, 72, 91
PL91 21, 33, 40, 50, 62, 72, 91
PL92 21, 33, 40, 50, 62, 72, 91
PL93 21, 33, 40, 50, 62, 72, 91
PL94 21, 33, 40, 50, 62, 72, 91
PL96 21, 33, 40, 50, 62, 72, 91
PL99 21, 33, 40, 50, 62, 72, 91
PL122P 61, 71
PL124G 90
PL124P 61, 71
PL226 50, 61, 71
PL228 50, 61, 71
PL228S 21, 33, 40, 91
PL422P 61
PL422PC 60
PL424P 61
PL424PC 60
PR1 92
PR2 92
PRAL 92
PRS210 23, 35, 41, 53, 65, 75, 82, 86, 87, 90
PRS210ED 53
PRS220 75
PRS226 75
PRS226E 65
PRS231 75
PRS235 75
PRS240 65
PRS4220 35
PRS6220 41
PT501 70
PT502 70
PT510W 70
PT515 70
PT520W 70
PT524W 70
R
RL36 53, 65, 75
RL37 65
RL37D 53
S
SM50 70
SR40 75
SR41 65, 75
ST7100CW 23, 82
T
TA320 18, 31, 38, 47, 59, 70
TA2160 17, 80
TA3160 18, 31, 38, 47, 59
TA7100W 23, 82
TA9160 18, 30, 46, 58
TD10PLG 91
TD2100MAS 22
TD2100PL 20
TD4100MAS 34
TD4100PL 32
TD6100MAS 41
TD6100PL 40
V
VD2120CMAS 22
VD2120CPL 20
VD2121CAG 20
VD2121CAGL 19
W
WA01AG 19, 20, 49
WA2160T 17, 80
WA2160W 17, 80
WA9100T 18, 46, 58
WA9100W 18, 30, 46, 58
WB3160 59
WB3160DG 31
WB3161 47
WB3162 38
WB3262 18
WB7260 23, 82
Z
ZH1083 16
ZH1084W 16
ZH1084B 16
ZH1262W 16
ZH1262B 16
Art. Page Art. Page Art. Page
10
12 13
11
MANUALI
HANDBOOKS
MANUELS
MANUALES
MANUAIS
2 013
10
12 13
11
MANUALI
HANDBOOKS
MANUELS
MANUALES
MANUAIS
2 013
2013.2014
CATALOGO
CATALOGUE
CATALOGUE
CATÁLOGO
CATÁLOGO
KATALOG
2013.2014
CATALOGO
CATALOGUE
CATALOGUE
CATÁLOGO
CATÁLOGO
KATALOG
www.acifarsa.it
www.mylogic.it
Aci Farsa
on line
Go to the site www.acifarsa.it designed with the
most advanced computer technologies for detailed
information on all Aci Farsa products and on all the
types of systems with the system manuals.
Discover also www.mylogic.it, the site completely
reserved for the home automation.
Aci Farsa
social network
Aci Farfisa goes social! Discover Aci Farfisa’s social
world on the major social networks: Facebook, Youtube
and Flickr.
Aci Farsa
multimedia
Request a copy of the CD containing the whole Aci Farsa
Video intercom catalogue in Italian, English, French,
Spanish, Portuguese and German and a copy of the CD
containing all complete and updated technical manuals.
Cod: GB 05/13
design:
capolinea.it
print:
Bieffe
www.bieffesrl.com
photos:
Paolo Zitti
www.paolozitti.it
Maurizio Paradisi
www.maurizioparadisi.it
Copyright © 2013:
ACI srl
Via E. Vanoni, 3
60027 Osimo AN Italy
Tel. (+39) 071.7202038
Fax (+39) 071.7202037
info@acifarsa.it
www.acifarsa.it
Diagrams in this catalogue are a simple reference.
For detailed installation schematics, please see the specic technical manual.
Due to the continuous technological evolution, Aci Farsa reserves the right to change
the specications of any item and range composition without prior notice.
As for CCTV sector, please refer to the specic Catalogue.
Further info
about myLogic
in HOME
AUTOMATION
chapter
77
>
www.acifarsa.it

Navigation menu
