The G700 has a large 3.0-inch 920,000-dot high-definition
picture display. The wide angle and high contrast give high
visibility even outdoors.
Date information is indispensible when creating photographic
records. By displaying the date
from the time the camera is
turned on until the shutter
release button is pressed, this
function helps prevent time
data errors caused by incorrect
date/time settings.
For level shooting, an
electronic level is
provided as a standard
feature. It enables you
to hold the camera in an
accurate level position
when shooting subjects
such as buildings and
interiors.
Boasting a wide viewing angle, the 3.0-inch
920,000-dot picture display is easy-to-see
and easy-to-use even outdoors
Electronic level enables
level photography
■Date display when camera is turned on
*Simulated image.
*Simulated image.
*Simulated image.
NEW
NEW
Even in confined space,
take photographs with wide
coverage of the subject
Zoom in to capture the subject from far away
The G700 uses a 28-140 mm 5x optical zoom lens. With the
ability to take photographs across a wide range impossible
for a standard 35 mm lens, the G700 is convenient for
shooting indoors and at other sites where it is not practical to
back up. It also easily
handles telephoto
shooting.
Now it is possible to shoot at an even
wider 22 mm equivalent. With the slim
design, you can shoot without being
bothered by lens bulk even when the
conversion lens is attached.
Wide conversion lens (DW-5) ＜Option＞
With 1 cm wide-angle macro photography*
you can capture small screws and scratches
and even vividly reproduce material
textures. In addition, the flash can be used
to illuminate subjects as close as 20 cm.
*The macro shooting wide-angle setting is f=5.9mm at a 33 mm focal length
(35 mm equivalent). At maximum telephoto you can shoot as close as 15 cm.
*When the flash is used with the wide conversion lens attached, parts of the image
may be dark because the light does not reach the edge of the frame.
Even surface texture is visible:
1 cm macro shooting
28-140 mm non-extending optical 5x
zoom captures each subject as intended
High-performance lens handles various situation
J<78
@46EB
HF89H?
Operation controls offer outstanding ease of use
28mm
22
mm
28
mm
140
mm
35mm
*All lens focal lengths in this catalog are converted into 35 mm camera equivalents.
The water, dust, and shock resistant digital camera
28
mm
22
mm
(option)
10
m
140
mm
Water, dust,
and shock
resistance
Chemical
resistance
Electronic
level
Password
lock
SD WORM
Internal
flash
1. DL-10
2. MediaBrowser
3. Adobe Reader
®
4. ListEditor
5. ME1
6. EC1
7. EX1
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
×
○
○
○
○
○
Windows
®
7 Windows Vista
®
Windows
®
2000
○
○
○
○
○
○
○
Windows
®
XP
■G700 Software
■G700 System Requirements
Windows
®
Windows
®
2000 Professional Service Pack 4,
Windows
®
XP Home Edition Service Pack 3/Professional Service Pack 3,
Windows Vista
®
Service Pack 2,
Windows
®
7 (32- and 64-bit)
Pentium
®
IV: 1.6 GHz or faster,
Pentium
®
M: 1.4 GHz or faster,
Core
TM
2 Duo: 1.5 GHz or faster
Windows
®
2000/Windows
®
XP: 512 MB or more,
Windows Vista
®
/Windows
®
7: 1 GB or more
300 MB or more
1024 × 768 pixels or greater
65,000 colors or greater
A CD-ROM drive compatible with the above-mentioned computer
A USB port compatible with the above-mentioned computer
Operating Systems Supported
CPU
Memory
Hard drive space required for installation
Display Resolution
Display Colors
CD-ROM Drive
USB Port
*The CD-ROM supports Japanese, English, French and German. Operations are
not guaranteed on operating systems with other languages.
*64-bit Windows Vista is not supported.
*If your computer has an upgraded OS, the USB function may not work normally, so it cannot be supported.
*The provided software may not operate properly if changes are made to the
operating system, such as with patches and service package releases.
*The camera does not support connection to a USB port added by using an
extension function (PCI bus or other).
*If used in conjunction with a hub or other USB devices, the software may not work properly.
*When dealing with movies and other large files, a larger memory environment is recommended.
*MediaBrowser is not supported under Windows 2000.
＜Optional Accessories ＞
Accessories included＜ ＞
■G700 Major Specifications
Item Specificatations
※ 1：The macro shooting wide-angle setting is f=5.9mm at a 33 mm focal length (35 mm equivalent).
※ 2：Image size is VGA.
※ 3：The upper and lower limits differ for each shooting mode and flash mode.
※ 4：The picture quality mode that can be set varies depending on the image size.
※ 5：SD WORM cards can be purchased from SanDisk Corporation agents that supply corporate customers.
※ 6：The estimated number of pictures that can be recorded or the estimated recording time.
※ 7：The maximum movie length that can be recorded at one time is either 90 minutes or 4 GB. When shooting movies of 1280 × 720 size,
the use of an SD/SDHC memory card with an SD speed class of Class 6 or higher is recommended.
※ 8：Compatible with DCF and DPOF. DCF is the abbreviation for “Design rule for Camera File system,” a JEITA standard
(Full compatibility with other devices is not guaranteed).
※ 9：When the flash is set to [Flash Off ].
※10：Mass storage mode is supported by Windows 2000, Windows XP, Windows Vista, Windows 7, Mac OS 9.0‒9.2.2, and Mac OS X 10.1.2‒10.6.3.
※11：The number of remaining shots is based on the CIPA standard and may vary depending on usage conditions. This is for reference only.
※12：When using the AAA Alkaline batteries manufactured by Panasonic.
※13：At a water depth of up to 5 m, a maximum of approximately two hours of shooting is possible. Optimal shooting may not be possible depending on the water environment.
DW-5
DB-65
BJ-6
SC-700
Product Name Model Name
■G700 Optional Accessories
Wide Conversion Lens
Rechargeable Battery
Battery Charger
Soft Case
Mode Image Size 1GB
210
365
238
433
683
1,102
1,337
2,514
4,834
183”
534”
1,294”
2GB
404
701
457
826
1,311
2,080
2,514
4,641
8,620
373”
1,087”
2,633”
4GB
810
1,403
914
1,653
2,623
4,162
5,029
9,284
17,243
734”
2,135”
5,170”
8GB
1,630
2,824
1,840
3,327
5,281
8,377
10,122
18,687
34,705
1,494”
4,344”
10,522”
16GB
3,283
5,688
3,706
6,701
10,635
16,869
20,383
37,631
69,887
3,006”
8,742”
21,170”
32GB
6,534
11,320
7,375
13,336
21,164
33,571
40,565
74,890
152,941
6,031”
17,536”
42,467”
Still
Movie
Internal Memory
(103MB)
22
38
25
45
72
116
141
265
509
20”
58”
142”
4000×3000（F）
4000×3000（N）
3984×2656（F）
2592×1944（F）
2048×1536（F）
1600×1200（F）
1280×960（F）
1280×960（N）
640×480（F）
1280×720 30fps
640×480 30fps
320×240 30fps
■SD Memory Card Storage Capacity (Number of Images and Time)
*The figures for storage capacity assume that no camera memo lists, voice
memos, or other camera system files are stored in the internal memory or on an SD memory card.
*The maximum recording time is the estimated total recording time.
❶Soft Case(SC-700)
❷Wide Conversion Lens(DW-5)
①AV Cable
②USB Cable (Mini B Cable)
③CD-ROM
④Recageable Battery
⑤Battery Charger
⑥Neck Strap
❶ ❷
●Instruction Manual(Camera User Guide)*Warranty Card
*Softweare manual spplied on CD-ROM
Approx. 12.10 million effective pixels
1/2.3 CCD (Approx. 12.40 total million pixels)
5.0 mm to 25 mm (equivalent to 28 mm to 140 mm on a 35-mm camera)
F3.5 to F5.5
Normal shooting: Approx. 30 cm to ∞ (Wide-angle) or 50 cm to ∞ (Telephoto) (from the front of the lens)
Macro shooting: Approx. 1 cm to ∞ (Wide-angle※1), 15 cm to ∞ (Telephoto) or 1 cm to ∞ (Zoom macro mode) (from the front of the lens)
11 elements in 9 groups plus 1 prism
37mm
Optical zoom at 5.0× (focal length equivalent to 28 mm to 140 mm on a 35 mm camera)
Digital zoom at 4.0×, up to 20.0x (560 mm equivalent) in combination with optical zoom
Auto resize zoom at approx. 6.3× (VGA image)
※2
, up to 31.5x (882 mm equivalent) in combination with optical zoom
Multi AF (CCD method)/Spot AF (CCD method)/MF/Snap/∞ (with AF Auxiliary Light)
Digital image stabilizer
8, 4, 2, 1 to 1/1500 seconds
1/30 to 1/10000 seconds
Multi Light Metering (256 segments)/Center-weighted Light Metering/Spot Metering (TTL-CCD Metering and AE lock possible)
Program AE
Manual exposure compensation (+2.0 to ‒2.0 EV in 1/3 EV Steps), Auto bracket function (‒0.5 EV, ±0, +0.5 EV)
AUTO、ISO64／ISO100／ISO200／ISO400／ISO800／ISO1600／ISO3200
Auto/Outdoors/Cloudy/Incandescent 1/Incandescent 2/Fluorescent/Manual/Ring Light, White balance bracket function
Auto flash (fires automatically in low-light conditions and when the subject is backlit)/Anti Red-eye/
Flash On/FLASH ON (10M)/Flash Synchro./Flash Off
Approx. 20 cm to 10.0 m (Wide-angle), approx. 40 cm to 6.2 m (Telephoto) (ISO AUTO/ISO 1600, from the front of the lens)
3.0 Transmissive LCD, approx. 920,000 dots
Auto shooting mode/Scene mode (High Sens/Firefighting/Skew Correct Mode/Text Mode/Zoom Macro/
Movie)/My settings mode/CALS mode
F (Fine), N (Normal)
[4 : 3] 4000 × 3000, 2592 × 1944, 2048 × 1536, 1600 × 1200, 1280 × 960, 640 × 480
[3 : 2] 3984 × 2656
1280 × 720, 640 × 480, 320 × 240
4000 × 3000, 2048 × 1536
SD memory card (3.3Ｖ 256MB, 512ＭＢ, 1GB, 2ＧＢ), SDHC memory card (up to 32 GB),
SD WORM card※5
（128MB, 1GB）, Internal Memory (approx. 103 MB)
4000 x 3000 F: 22 pictures N: 38 pictures, 3984 x 2656 F: 25, 2592 x 1944 F: 45,
2048 x 1536 N: 72, 1600 x 1200 F: 116, 1280 x 960 F: 141 N: 265,
640 x 480 F: 509
1280 x 720 20 seconds, 640 x 480 58 seconds, 320 x 240 2 minutes 22 seconds
JPEG (Exif Ver. 2.21)※8
JPEG (Exif Ver. 2.21)※8
AVI (Open DML Motion JPEG Format Compliant)
EAN-13/8 (JAN-13/8), UPC-A/E, UPC/EAN (with add-ons), Interleaved 2 of 5, CODEBAR (NW-7),
CODE 39, CODE 93, CODE 128 TYPE C, GS1-128 (EAN-128), and RSS (GS1 DataBar)
QR Code, Micro QR Code, DataMatrix(ECC200), PDF417, Micro PDF417, MaxiCode,
EAN・UCC Composite(GS1 DataBar Composite)
Continuous mode, Self-timer (operation time: approx. 10 seconds, approx. 2 seconds), Interval shooting
(shooting interval: 5 seconds to 3 hours, in increments of 5 seconds)※9, Histogram display, Grid guide display
Thumbnail view, Enlarged view (maximum 16×), Resize, Contrast Correction
USB2.0 (High-Speed USB) Mini-B, AV output, Mass storage-compatible※10
Rechargeable Battery (DB-65) x１, AC adapter （AC-5c option）,
AAA Alkaline Battery x 2, AAA Nickel-Hydrogen Battery x 2
Based on CIPA standard, DB-65: approx. 360 shots AAA alkaline: 40 shots※12
118.8 mm × 71.0 mm × 41.0 mm, 32.0 mm (D) at thinnest, excluding projections
Approx. 280 g (excluding battery, SD memory card, and strap), Approx. 310 g (including memory card and supplied battery)
JIS/IEC waterproof grade 8, shooting to a water depth of approx. 5 m※13
JIS/IEC dustproof grade 6
External cleaning possible with ethanol and hypochlorous acid disinfectants
‒10 °C to 40 °C
No. of effective pixels (camera)
Image Sensor
Lens
Zoom Magnification
Focus Modes
Blur Reduction
Shutter
Speed※3
Exposure
Control
ISO Sensitivity
(Standard Output Sensitivity）
White Balance Mode
Flash
Picture Display
Shooting Mode
Picture Quality Mode※4
Number of
Recorded
Pixels
Recording Media
Recording
File
Format
Bar Codes
Supported
Other Major Shooting Functions
Other Major Playback Functions
Interface
Power Supply
Battery life※11
Dimensions (W × H × D)
Weight
Water Resistance/
Dust Resistance/
Chemical Resistance
Operating Temperature 
 
 
Picture/
Time Storage
Capacity
※6
(Internal: approx.
103MB）
Focal Length
F-aperture
Shooting
Distance 
Lens Construction
Filter size
Still Image
Movie
Exposure Metering Mode
Exposure Mode
Exposure Compensation
Flash Mode
Built-in flash Range
Still Image
Movie
Text
Still image
 
Movie※7
Still Image
Text
Movie
Linear
Matrix
http:// www.ricoh.com /r_dc
RICOH ASIA PACIFIC OPER AT IONS LIMI TED
• Windows® and Windows Vista® are registered trademarks or trademarks of Microsoft Corporation in the U.S. and/or other countries. • Mac OS is registered trademark of Apple Inc. in the U.S. and/or other countries.
• Adobe and Adobe Reader are trademarks or registered trademarks of Adobe Systems Incorporated in the U.S. and/or other countries. • The SD logo is a trademark. • Compatible with EPSON PRINT Image Matching III.
• All other company names and product names mentioned herein are trademarks or registered trademarks of their respective companies.
Sharply reproduce worksite conditions and even words written on
a blackboard. Even after cropping, images remain crisp and vivid.
For reliable photography even in dark sites such as tunnel
interiors, the G700 has a built-in flash with a range of 10 m
for wide-angle and 6.2 m for telephoto. With high-sensitivity
ISO 3200, the G700 can also shoot in situations where flash
cannot be used.
The accessory shoe (conforms to JIS B7101) makes it possible
to shoot with commercially available flash units*. This further
expands the scenes which can be photographed.
The focal length is fixed to 2.5 m and ISO sensitivity is raised
to enable shooting of clear photographs in the difficult
conditions for autofocus at the scene of a fire. Sharpness
processing is also done to give the still images a sharper feel.
By just pressing the ADJ. (adjust)
button, you can easily specify exposure
compensation, ISO sensitivity, and
other settings.
With the mode dial you can easily
switch between CALS mode, auto
shooting mode, My Settings mode (for
registration of frequently used
shooting settings), and scene mode (firefighting, skew
correction, etc.). In CALS mode, you can select from six
picture size and quality settings ranging from “5M 4：3 F” to
“VGA 4：3 F”.
The G700 supports the SanDisk Corporation SD WORM (write
once read many) card. Since deletes, changes, and card
initialization cannot be done, these cards can be used in place of
film for original documents when recording
police, fire department, and defense-related
scenes where data reliability might be questioned.
When stored under suitable conditions, the data
can be preserved for about 100 years.
By defining a password, you can lock the camera. In addition to
locking the camera as a whole or internal memory playback,
you can also limit use to SD WORM cards or just restrict
setting changes. The locks and restrictions can be removed
through password entry with a software keyboard or bar code.
When an image is not enough, up to 20 text or voice
information fields can be recorded as memos together with the
photograph. Selection from multiple memos (up to 99 files) is
possible, and memos can also be recorded in internal memory.
The reading of one and two dimensional bar codes is
supported. The saving of bar codes as camera memos can be
useful for freight management in logistics, prevention of
patient data mix-ups in medical facilities, etc.
Camera lock functions for a variety of
operation controls
SD WORM (write once read many)
memory card supported
The G700 has a high-accuracy image edit detection function
to increase data reliability when digital photographs are
submitted as evidence. The RSA encryption method is used
to make it possible to detect editing with respect to the
entire image. By loading the image onto a PC using the EC1
software provided, it is possible to make highly accurate
judgments on image edition.
The G700 is compliant with the PictBridge
industry standard for printing by connecting
camera and printer. If you connect the G700
to a compatible printer, you can print
directly without using a personal computer.
If you connect the G700 to a Ricoh-compatible printer, it is
possible to print out images in easy-to-use form layouts. For
details, please see the Ricoh website.
■Image edit detection function increases photo credibility
■PictBridge supported for direct printing
■Form print function for easy printing in easy-to-use layouts
NEW
NEW
Built-in flash reaches up to 10 m
Accessory shoe
12.1 million effective pixels for more
precise photo reproduction
Camera memo functions make image
management much easier
Bar code reader function useful for
camera memo and password input
NEW
NEW
NEW
NEW
Flash range of
5 m
Manual flash in
10 m
mode
ISO
3200
Smart functions support shooting and post-shooting operations
F@4EG
Security and PC-linkage functions for safe and certain photo management
■Firefighting mode
■Mode dial for quick mode changes
The G700 utilizes the new electronic vibration correction
function that takes two exposures at high speed with the
differences being calculated. It is a powerful tool when
shooting in low light and when shooting telephoto.
■Electronic vibration correction function
Rectangular objects photographed at an angle are corrected
so they appear to have been shot squarely. The
before-correction image is also recorded.
■Skew correction function
■Adjust button
*Taken with
Caplio 400G wide
*Taken with G700
*Taken with G700
with flash off
F86HE8
* SD WORM cards can be purchased from SanDisk Corporation
agents that supply corporate customers.
*A flash with both a slave flash function
and a pre-flash support function should
be used. It is not possible to use units
without a spring or lock mechanism or
units on which synchronization with the
pre-flash cannot be cancelled.
Furthermore, the accessory shoe does
not support a synchronizer contact.
You can also view in
the camera
reference images
(diagrams, etc.) that
correspond to
camera memos
Bar code read with
lens and data recorded
in camera memo
Data
written to
Photo and
bar code
managed
together
Before correction After correction
Lock all camera operations
Lock internal memory playback
Restrict use to SD WORM cards
Restrict camera setting changes
4961311010101
Despite its small size and light weight, the G700 has strengthened
glass at the lens front surface and body protectors added at
strategic points. This toughness enabled it to withstand 2.0 m
drops in 26 positions (6 surfaces, 8 corners, and 12 edges) in
testing conforming to US Department of Defense “MIL Standard
810F.” Furthermore, it also passes this test with the power on.
Toughness for the most
demanding sites
Approximately 360 pictures* can be taken with
the rechargeable battery provided. The
dissipation of battery power can be reduced by
specifying synchro monitor mode, which turns
the picture display off when the camera is not being operated.
With the wide, durable neck strap, you
can suspend the camera diagonally,
and it can also be suspended vertically
from the neck to allow for easy storage
in a breast pocket.
Dust resistance, at JIS/IEC dustproof protection grade 6,
guards against infiltration by dust and sand. The G700 can
also shoot in cold environments, with cold resistance able to
handle temperatures down to -10°C.
You can also attach commercially available 37 mm diameter filters,
which are effective for preventing lens scratching and condensation.
Water resistance is rated at JIS/IEC waterproof protection
grade 8 so the G700 can handle two hours of underwater
photography at a depth of 5 m. In addition to use at wet
sites, the G700 can also be used for shooting in the rain, and
it can be washed in water if it gets dirty.
The G700 can be disinfected with ethanol or sodium
hypochlorite, which has been approved as a food additive
disinfectant. So it can be safely used in medical facilities
and production facilities.
In addition to the high-capacity rechargeable
battery included, the G700 can also be powered
with readily available AAA-size alkaline
batteries. With these batteries, approximately 40
shots* can be taken. So you can quickly recover from the
battery depletion that can occur in periods of long use.
Sodium hypochlorite and
ethanol disinfection OK
■Wide and long neck strap
■Filter use possible
Featuring relatively large
buttons, the operation controls
are arranged in a simple design
that enables easy operation even
with gloves on.
■Operation controls easy to use even wearing gloves
Enhanced shock resistance tough
enough to pass a 2.0 m drop test
IPX8 equivalent water resistance
enables two hours of use at 5 m depth
＊Shooting capacity was measured using CIPA-standard parameters.
This is only an estimate and performance may vary depending on usage conditions.
＊Shooting capacity was measured using CIPA-standard parameters.
This is only an estimate and performance may vary depending on usage conditions.
■AAA Alkaline batteries can also be used
■
Extended operation time for up to about 360 pictures
NEW
NEW
NEW
NEW
NEW
Shock
resistance
Dust and
cold
resistance
Chemical
resistance
The toughness critical for difficult work sites
GBH:;
The G700 was created for
the demanding professional.
To the water, dust, and shock resistance
necessary for hard work-site use,
chemical resistance has now been added.
The wide range of functions
includes a CALS mode useful for
electronic data submission and
a password camera lock capability.
Attaining new levels of reliability,
this true tool represents
the crystallization of Ricoh technology.
B
a
!
g[
X
!
]bU
fcXVf!
*Simulated image.
118.8mm（W） × 71.0mm（H） × 41.0mm（D）
Water
resistance
*Simulated image.
two dimensional bar codeOne dimensional bar code
Sharply reproduce worksite conditions and even words written on
a blackboard. Even after cropping, images remain crisp and vivid.
For reliable photography even in dark sites such as tunnel
interiors, the G700 has a built-in flash with a range of 10 m
for wide-angle and 6.2 m for telephoto. With high-sensitivity
ISO 3200, the G700 can also shoot in situations where flash
cannot be used.
The accessory shoe (conforms to JIS B7101) makes it possible
to shoot with commercially available flash units*. This further
expands the scenes which can be photographed.
The focal length is fixed to 2.5 m and ISO sensitivity is raised
to enable shooting of clear photographs in the difficult
conditions for autofocus at the scene of a fire. Sharpness
processing is also done to give the still images a sharper feel.
By just pressing the ADJ. (adjust)
button, you can easily specify exposure
compensation, ISO sensitivity, and
other settings.
With the mode dial you can easily
switch between CALS mode, auto
shooting mode, My Settings mode (for
registration of frequently used
shooting settings), and scene mode (firefighting, skew
correction, etc.). In CALS mode, you can select from six
picture size and quality settings ranging from “5M 4：3 F” to
“VGA 4：3 F”.
The G700 supports the SanDisk Corporation SD WORM (write
once read many) card. Since deletes, changes, and card
initialization cannot be done, these cards can be used in place of
film for original documents when recording
police, fire department, and defense-related
scenes where data reliability might be questioned.
When stored under suitable conditions, the data
can be preserved for about 100 years.
By defining a password, you can lock the camera. In addition to
locking the camera as a whole or internal memory playback,
you can also limit use to SD WORM cards or just restrict
setting changes. The locks and restrictions can be removed
through password entry with a software keyboard or bar code.
When an image is not enough, up to 20 text or voice
information fields can be recorded as memos together with the
photograph. Selection from multiple memos (up to 99 files) is
possible, and memos can also be recorded in internal memory.
The reading of one and two dimensional bar codes is
supported. The saving of bar codes as camera memos can be
useful for freight management in logistics, prevention of
patient data mix-ups in medical facilities, etc.
Camera lock functions for a variety of
operation controls
SD WORM (write once read many)
memory card supported
The G700 has a high-accuracy image edit detection function
to increase data reliability when digital photographs are
submitted as evidence. The RSA encryption method is used
to make it possible to detect editing with respect to the
entire image. By loading the image onto a PC using the EC1
software provided, it is possible to make highly accurate
judgments on image edition.
The G700 is compliant with the PictBridge
industry standard for printing by connecting
camera and printer. If you connect the G700
to a compatible printer, you can print
directly without using a personal computer.
If you connect the G700 to a Ricoh-compatible printer, it is
possible to print out images in easy-to-use form layouts. For
details, please see the Ricoh website.
■Image edit detection function increases photo credibility
■PictBridge supported for direct printing
■Form print function for easy printing in easy-to-use layouts
NEW
NEW
Built-in flash reaches up to 10 m
Accessory shoe
12.1 million effective pixels for more
precise photo reproduction
Camera memo functions make image
management much easier
Bar code reader function useful for
camera memo and password input
NEW
NEW
NEW
NEW
Flash range of
5 m
Manual flash in
10 m
mode
ISO
3200
Smart functions support shooting and post-shooting operations
F@4EG
Security and PC-linkage functions for safe and certain photo management
■Firefighting mode
■Mode dial for quick mode changes
The G700 utilizes the new electronic vibration correction
function that takes two exposures at high speed with the
differences being calculated. It is a powerful tool when
shooting in low light and when shooting telephoto.
■Electronic vibration correction function
Rectangular objects photographed at an angle are corrected
so they appear to have been shot squarely. The
before-correction image is also recorded.
■Skew correction function
■Adjust button
*Taken with
Caplio 400G wide
*Taken with G700
*Taken with G700
with flash off
F86HE8
* SD WORM cards can be purchased from SanDisk Corporation
agents that supply corporate customers.
*A flash with both a slave flash function
and a pre-flash support function should
be used. It is not possible to use units
without a spring or lock mechanism or
units on which synchronization with the
pre-flash cannot be cancelled.
Furthermore, the accessory shoe does
not support a synchronizer contact.
You can also view in
the camera
reference images
(diagrams, etc.) that
correspond to
camera memos
Bar code read with
lens and data recorded
in camera memo
Data
written to
Photo and
bar code
managed
together
Before correction After correction
Lock all camera operations
Lock internal memory playback
Restrict use to SD WORM cards
Restrict camera setting changes
4961311010101
Despite its small size and light weight, the G700 has strengthened
glass at the lens front surface and body protectors added at
strategic points. This toughness enabled it to withstand 2.0 m
drops in 26 positions (6 surfaces, 8 corners, and 12 edges) in
testing conforming to US Department of Defense “MIL Standard
810F.” Furthermore, it also passes this test with the power on.
Toughness for the most
demanding sites
Approximately 360 pictures* can be taken with
the rechargeable battery provided. The
dissipation of battery power can be reduced by
specifying synchro monitor mode, which turns
the picture display off when the camera is not being operated.
With the wide, durable neck strap, you
can suspend the camera diagonally,
and it can also be suspended vertically
from the neck to allow for easy storage
in a breast pocket.
Dust resistance, at JIS/IEC dustproof protection grade 6,
guards against infiltration by dust and sand. The G700 can
also shoot in cold environments, with cold resistance able to
handle temperatures down to -10°C.
You can also attach commercially available 37 mm diameter filters,
which are effective for preventing lens scratching and condensation.
Water resistance is rated at JIS/IEC waterproof protection
grade 8 so the G700 can handle two hours of underwater
photography at a depth of 5 m. In addition to use at wet
sites, the G700 can also be used for shooting in the rain, and
it can be washed in water if it gets dirty.
The G700 can be disinfected with ethanol or sodium
hypochlorite, which has been approved as a food additive
disinfectant. So it can be safely used in medical facilities
and production facilities.
In addition to the high-capacity rechargeable
battery included, the G700 can also be powered
with readily available AAA-size alkaline
batteries. With these batteries, approximately 40
shots* can be taken. So you can quickly recover from the
battery depletion that can occur in periods of long use.
Sodium hypochlorite and
ethanol disinfection OK
■Wide and long neck strap
■Filter use possible
Featuring relatively large
buttons, the operation controls
are arranged in a simple design
that enables easy operation even
with gloves on.
■Operation controls easy to use even wearing gloves
Enhanced shock resistance tough
enough to pass a 2.0 m drop test
IPX8 equivalent water resistance
enables two hours of use at 5 m depth
＊Shooting capacity was measured using CIPA-standard parameters.
This is only an estimate and performance may vary depending on usage conditions.
＊Shooting capacity was measured using CIPA-standard parameters.
This is only an estimate and performance may vary depending on usage conditions.
■AAA Alkaline batteries can also be used
■
Extended operation time for up to about 360 pictures
NEW
NEW
NEW
NEW
NEW
Shock
resistance
Dust and
cold
resistance
Chemical
resistance
The toughness critical for difficult work sites
GBH:;
The G700 was created for
the demanding professional.
To the water, dust, and shock resistance
necessary for hard work-site use,
chemical resistance has now been added.
The wide range of functions
includes a CALS mode useful for
electronic data submission and
a password camera lock capability.
Attaining new levels of reliability,
this true tool represents
the crystallization of Ricoh technology.
*Simulated image.
118.8mm（W） × 71.0mm（H） × 41.0mm（D）
Water
resistance
*Simulated image.
two dimensional bar codeOne dimensional bar code
Sharply reproduce worksite conditions and even words written on
a blackboard. Even after cropping, images remain crisp and vivid.
For reliable photography even in dark sites such as tunnel
interiors, the G700 has a built-in flash with a range of 10 m
for wide-angle and 6.2 m for telephoto. With high-sensitivity
ISO 3200, the G700 can also shoot in situations where flash
cannot be used.
The accessory shoe (conforms to JIS B7101) makes it possible
to shoot with commercially available flash units*. This further
expands the scenes which can be photographed.
The focal length is fixed to 2.5 m and ISO sensitivity is raised
to enable shooting of clear photographs in the difficult
conditions for autofocus at the scene of a fire. Sharpness
processing is also done to give the still images a sharper feel.
By just pressing the ADJ. (adjust)
button, you can easily specify exposure
compensation, ISO sensitivity, and
other settings.
With the mode dial you can easily
switch between CALS mode, auto
shooting mode, My Settings mode (for
registration of frequently used
shooting settings), and scene mode (firefighting, skew
correction, etc.). In CALS mode, you can select from six
picture size and quality settings ranging from “5M 4：3 F” to
“VGA 4：3 F”.
The G700 supports the SanDisk Corporation SD WORM (write
once read many) card. Since deletes, changes, and card
initialization cannot be done, these cards can be used in place of
film for original documents when recording
police, fire department, and defense-related
scenes where data reliability might be questioned.
When stored under suitable conditions, the data
can be preserved for about 100 years.
By defining a password, you can lock the camera. In addition to
locking the camera as a whole or internal memory playback,
you can also limit use to SD WORM cards or just restrict
setting changes. The locks and restrictions can be removed
through password entry with a software keyboard or bar code.
When an image is not enough, up to 20 text or voice
information fields can be recorded as memos together with the
photograph. Selection from multiple memos (up to 99 files) is
possible, and memos can also be recorded in internal memory.
The reading of one and two dimensional bar codes is
supported. The saving of bar codes as camera memos can be
useful for freight management in logistics, prevention of
patient data mix-ups in medical facilities, etc.
Camera lock functions for a variety of
operation controls
SD WORM (write once read many)
memory card supported
The G700 has a high-accuracy image edit detection function
to increase data reliability when digital photographs are
submitted as evidence. The RSA encryption method is used
to make it possible to detect editing with respect to the
entire image. By loading the image onto a PC using the EC1
software provided, it is possible to make highly accurate
judgments on image edition.
The G700 is compliant with the PictBridge
industry standard for printing by connecting
camera and printer. If you connect the G700
to a compatible printer, you can print
directly without using a personal computer.
If you connect the G700 to a Ricoh-compatible printer, it is
possible to print out images in easy-to-use form layouts. For
details, please see the Ricoh website.
■Image edit detection function increases photo credibility
■PictBridge supported for direct printing
■Form print function for easy printing in easy-to-use layouts
NEW
NEW
Built-in flash reaches up to 10 m
Accessory shoe
12.1 million effective pixels for more
precise photo reproduction
Camera memo functions make image
management much easier
Bar code reader function useful for
camera memo and password input
NEW
NEW
NEW
NEW
Flash range of
5 m
Manual flash in
10 m
mode
ISO
3200
Smart functions support shooting and post-shooting operations
F@4EG
Security and PC-linkage functions for safe and certain photo management
■Firefighting mode
■Mode dial for quick mode changes
The G700 utilizes the new electronic vibration correction
function that takes two exposures at high speed with the
differences being calculated. It is a powerful tool when
shooting in low light and when shooting telephoto.
■Electronic vibration correction function
Rectangular objects photographed at an angle are corrected
so they appear to have been shot squarely. The
before-correction image is also recorded.
■Skew correction function
■Adjust button
*Taken with
Caplio 400G wide
*Taken with G700
*Taken with G700
with flash off
F86HE8
* SD WORM cards can be purchased from SanDisk Corporation
agents that supply corporate customers.
*A flash with both a slave flash function
and a pre-flash support function should
be used. It is not possible to use units
without a spring or lock mechanism or
units on which synchronization with the
pre-flash cannot be cancelled.
Furthermore, the accessory shoe does
not support a synchronizer contact.
You can also view in
the camera
reference images
(diagrams, etc.) that
correspond to
camera memos
Bar code read with
lens and data recorded
in camera memo
Data
written to
Photo and
bar code
managed
together
Before correction After correction
Lock all camera operations
Lock internal memory playback
Restrict use to SD WORM cards
Restrict camera setting changes
4961311010101
Despite its small size and light weight, the G700 has strengthened
glass at the lens front surface and body protectors added at
strategic points. This toughness enabled it to withstand 2.0 m
drops in 26 positions (6 surfaces, 8 corners, and 12 edges) in
testing conforming to US Department of Defense “MIL Standard
810F.” Furthermore, it also passes this test with the power on.
Toughness for the most
demanding sites
Approximately 360 pictures* can be taken with
the rechargeable battery provided. The
dissipation of battery power can be reduced by
specifying synchro monitor mode, which turns
the picture display off when the camera is not being operated.
With the wide, durable neck strap, you
can suspend the camera diagonally,
and it can also be suspended vertically
from the neck to allow for easy storage
in a breast pocket.
Dust resistance, at JIS/IEC dustproof protection grade 6,
guards against infiltration by dust and sand. The G700 can
also shoot in cold environments, with cold resistance able to
handle temperatures down to -10°C.
You can also attach commercially available 37 mm diameter filters,
which are effective for preventing lens scratching and condensation.
Water resistance is rated at JIS/IEC waterproof protection
grade 8 so the G700 can handle two hours of underwater
photography at a depth of 5 m. In addition to use at wet
sites, the G700 can also be used for shooting in the rain, and
it can be washed in water if it gets dirty.
The G700 can be disinfected with ethanol or sodium
hypochlorite, which has been approved as a food additive
disinfectant. So it can be safely used in medical facilities
and production facilities.
In addition to the high-capacity rechargeable
battery included, the G700 can also be powered
with readily available AAA-size alkaline
batteries. With these batteries, approximately 40
shots* can be taken. So you can quickly recover from the
battery depletion that can occur in periods of long use.
Sodium hypochlorite and
ethanol disinfection OK
■Wide and long neck strap
■Filter use possible
Featuring relatively large
buttons, the operation controls
are arranged in a simple design
that enables easy operation even
with gloves on.
■Operation controls easy to use even wearing gloves
Enhanced shock resistance tough
enough to pass a 2.0 m drop test
IPX8 equivalent water resistance
enables two hours of use at 5 m depth
＊Shooting capacity was measured using CIPA-standard parameters.
This is only an estimate and performance may vary depending on usage conditions.
＊Shooting capacity was measured using CIPA-standard parameters.
This is only an estimate and performance may vary depending on usage conditions.
■AAA Alkaline batteries can also be used
■
Extended operation time for up to about 360 pictures
NEW
NEW
NEW
NEW
NEW
Shock
resistance
Dust and
cold
resistance
Chemical
resistance
The toughness critical for difficult work sites
GBH:;
The G700 was created for
the demanding professional.
To the water, dust, and shock resistance
necessary for hard work-site use,
chemical resistance has now been added.
The wide range of functions
includes a CALS mode useful for
electronic data submission and
a password camera lock capability.
Attaining new levels of reliability,
this true tool represents
the crystallization of Ricoh technology.
*Simulated image.
118.8mm（W） × 71.0mm（H） × 41.0mm（D）
Water
resistance
*Simulated image.
two dimensional bar codeOne dimensional bar code
The G700 has a large 3.0-inch 920,000-dot high-definition
picture display. The wide angle and high contrast give high
visibility even outdoors.
Date information is indispensible when creating photographic
records. By displaying the date
from the time the camera is
turned on until the shutter
release button is pressed, this
function helps prevent time
data errors caused by incorrect
date/time settings.
For level shooting, an
electronic level is
provided as a standard
feature. It enables you
to hold the camera in an
accurate level position
when shooting subjects
such as buildings and
interiors.
Boasting a wide viewing angle, the 3.0-inch
920,000-dot picture display is easy-to-see
and easy-to-use even outdoors
Electronic level enables
level photography
■Date display when camera is turned on
*Simulated image.
*Simulated image.
*Simulated image.
NEW
NEW
Even in confined space,
take photographs with wide
coverage of the subject
Zoom in to capture the subject from far away
The G700 uses a 28-140 mm 5x optical zoom lens. With the
ability to take photographs across a wide range impossible
for a standard 35 mm lens, the G700 is convenient for
shooting indoors and at other sites where it is not practical to
back up. It also easily
handles telephoto
shooting.
Now it is possible to shoot at an even
wider 22 mm equivalent. With the slim
design, you can shoot without being
bothered by lens bulk even when the
conversion lens is attached.
Wide conversion lens (DW-5) ＜Option＞
With 1 cm wide-angle macro photography*
you can capture small screws and scratches
and even vividly reproduce material
textures. In addition, the flash can be used
to illuminate subjects as close as 20 cm.
*The macro shooting wide-angle setting is f=5.9mm at a 33 mm focal length
(35 mm equivalent). At maximum telephoto you can shoot as close as 15 cm.
*When the flash is used with the wide conversion lens attached, parts of the image
may be dark because the light does not reach the edge of the frame.
Even surface texture is visible:
1 cm macro shooting
28-140 mm non-extending optical 5x
zoom captures each subject as intended
High-performance lens handles various situation
J<78
@46EB
HF89H?
Operation controls offer outstanding ease of use
28mm
22
mm
28
mm
140
mm
35mm
*All lens focal lengths in this catalog are converted into 35 mm camera equivalents.
The water, dust, and shock resistant digital camera
28
mm
22
mm
(option)
10
m
140
mm
Water, dust,
and shock
resistance
Chemical
resistance
Electronic
level
Password
lock
SD WORM
Internal
flash
1. DL-10
2. MediaBrowser
3. Adobe Reader
®
4. ListEditor
5. ME1
6. EC1
7. EX1
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
×
○
○
○
○
○
Windows
®
7 Windows Vista
®
Windows
®
2000
○
○
○
○
○
○
○
Windows
®
XP
■G700 Software
■G700 System Requirements
Windows
®
Windows
®
2000 Professional Service Pack 4,
Windows
®
XP Home Edition Service Pack 3/Professional Service Pack 3,
Windows Vista
®
Service Pack 2,
Windows
®
7 (32- and 64-bit)
Pentium
®
IV: 1.6 GHz or faster,
Pentium
®
M: 1.4 GHz or faster,
Core
TM
2 Duo: 1.5 GHz or faster
Windows
®
2000/Windows
®
XP: 512 MB or more,
Windows Vista
®
/Windows
®
7: 1 GB or more
300 MB or more
1024 × 768 pixels or greater
65,000 colors or greater
A CD-ROM drive compatible with the above-mentioned computer
A USB port compatible with the above-mentioned computer
Operating Systems Supported
CPU
Memory
Hard drive space required for installation
Display Resolution
Display Colors
CD-ROM Drive
USB Port
*The CD-ROM supports Japanese, English, French and German. Operations are
not guaranteed on operating systems with other languages.
*64-bit Windows Vista is not supported.
*If your computer has an upgraded OS, the USB function may not work normally, so it cannot be supported.
*The provided software may not operate properly if changes are made to the
operating system, such as with patches and service package releases.
*The camera does not support connection to a USB port added by using an
extension function (PCI bus or other).
*If used in conjunction with a hub or other USB devices, the software may not work properly.
*When dealing with movies and other large files, a larger memory environment is recommended.
*MediaBrowser is not supported under Windows 2000.
＜Optional Accessories ＞
Accessories included＜ ＞
■G700 Major Specifications
Item Specificatations
※ 1：The macro shooting wide-angle setting is f=5.9mm at a 33 mm focal length (35 mm equivalent).
※ 2：Image size is VGA.
※ 3：The upper and lower limits differ for each shooting mode and flash mode.
※ 4：The picture quality mode that can be set varies depending on the image size.
※ 5：SD WORM cards can be purchased from SanDisk Corporation agents that supply corporate customers.
※ 6：The estimated number of pictures that can be recorded or the estimated recording time.
※ 7：The maximum movie length that can be recorded at one time is either 90 minutes or 4 GB. When shooting movies of 1280 × 720 size,
the use of an SD/SDHC memory card with an SD speed class of Class 6 or higher is recommended.
※ 8：Compatible with DCF and DPOF. DCF is the abbreviation for “Design rule for Camera File system,” a JEITA standard
(Full compatibility with other devices is not guaranteed).
※ 9：When the flash is set to [Flash Off ].
※10：Mass storage mode is supported by Windows 2000, Windows XP, Windows Vista, Windows 7, Mac OS 9.0‒9.2.2, and Mac OS X 10.1.2‒10.6.3.
※11：The number of remaining shots is based on the CIPA standard and may vary depending on usage conditions. This is for reference only.
※12：When using the AAA Alkaline batteries manufactured by Panasonic.
※13：At a water depth of up to 5 m, a maximum of approximately two hours of shooting is possible. Optimal shooting may not be possible depending on the water environment.
DW-5
DB-65
BJ-6
SC-700
Product Name Model Name
■G700 Optional Accessories
Wide Conversion Lens
Rechargeable Battery
Battery Charger
Soft Case
Mode Image Size 1GB
210
365
238
433
683
1,102
1,337
2,514
4,834
183”
534”
1,294”
2GB
404
701
457
826
1,311
2,080
2,514
4,641
8,620
373”
1,087”
2,633”
4GB
810
1,403
914
1,653
2,623
4,162
5,029
9,284
17,243
734”
2,135”
5,170”
8GB
1,630
2,824
1,840
3,327
5,281
8,377
10,122
18,687
34,705
1,494”
4,344”
10,522”
16GB
3,283
5,688
3,706
6,701
10,635
16,869
20,383
37,631
69,887
3,006”
8,742”
21,170”
32GB
6,534
11,320
7,375
13,336
21,164
33,571
40,565
74,890
152,941
6,031”
17,536”
42,467”
Still
Movie
Internal Memory
(103MB)
22
38
25
45
72
116
141
265
509
20”
58”
142”
4000×3000（F）
4000×3000（N）
3984×2656（F）
2592×1944（F）
2048×1536（F）
1600×1200（F）
1280×960（F）
1280×960（N）
640×480（F）
1280×720 30fps
640×480 30fps
320×240 30fps
■SD Memory Card Storage Capacity (Number of Images and Time)
*The figures for storage capacity assume that no camera memo lists, voice
memos, or other camera system files are stored in the internal memory or on an SD memory card.
*The maximum recording time is the estimated total recording time.
❶Soft Case(SC-700)
❷Wide Conversion Lens(DW-5)
①AV Cable
②USB Cable (Mini B Cable)
③CD-ROM
④Recageable Battery
⑤Battery Charger
⑥Neck Strap
❶ ❷
●Instruction Manual(Camera User Guide)*Warranty Card
*Softweare manual spplied on CD-ROM
Approx. 12.10 million effective pixels
1/2.3 CCD (Approx. 12.40 total million pixels)
5.0 mm to 25 mm (equivalent to 28 mm to 140 mm on a 35-mm camera)
F3.5 to F5.5
Normal shooting: Approx. 30 cm to ∞ (Wide-angle) or 50 cm to ∞ (Telephoto) (from the front of the lens)
Macro shooting: Approx. 1 cm to ∞ (Wide-angle※1), 15 cm to ∞ (Telephoto) or 1 cm to ∞ (Zoom macro mode) (from the front of the lens)
11 elements in 9 groups plus 1 prism
37mm
Optical zoom at 5.0× (focal length equivalent to 28 mm to 140 mm on a 35 mm camera)
Digital zoom at 4.0×, up to 20.0x (560 mm equivalent) in combination with optical zoom
Auto resize zoom at approx. 6.3× (VGA image)
※2
, up to 31.5x (882 mm equivalent) in combination with optical zoom
Multi AF (CCD method)/Spot AF (CCD method)/MF/Snap/∞ (with AF Auxiliary Light)
Digital image stabilizer
8, 4, 2, 1 to 1/1500 seconds
1/30 to 1/10000 seconds
Multi Light Metering (256 segments)/Center-weighted Light Metering/Spot Metering (TTL-CCD Metering and AE lock possible)
Program AE
Manual exposure compensation (+2.0 to ‒2.0 EV in 1/3 EV Steps), Auto bracket function (‒0.5 EV, ±0, +0.5 EV)
AUTO、ISO64／ISO100／ISO200／ISO400／ISO800／ISO1600／ISO3200
Auto/Outdoors/Cloudy/Incandescent 1/Incandescent 2/Fluorescent/Manual/Ring Light, White balance bracket function
Auto flash (fires automatically in low-light conditions and when the subject is backlit)/Anti Red-eye/
Flash On/FLASH ON (10M)/Flash Synchro./Flash Off
Approx. 20 cm to 10.0 m (Wide-angle), approx. 40 cm to 6.2 m (Telephoto) (ISO AUTO/ISO 1600, from the front of the lens)
3.0 Transmissive LCD, approx. 920,000 dots
Auto shooting mode/Scene mode (High Sens/Firefighting/Skew Correct Mode/Text Mode/Zoom Macro/
Movie)/My settings mode/CALS mode
F (Fine), N (Normal)
[4 : 3] 4000 × 3000, 2592 × 1944, 2048 × 1536, 1600 × 1200, 1280 × 960, 640 × 480
[3 : 2] 3984 × 2656
1280 × 720, 640 × 480, 320 × 240
4000 × 3000, 2048 × 1536
SD memory card (3.3Ｖ 256MB, 512ＭＢ, 1GB, 2ＧＢ), SDHC memory card (up to 32 GB),
SD WORM card※5
（128MB, 1GB）, Internal Memory (approx. 103 MB)
4000 x 3000 F: 22 pictures N: 38 pictures, 3984 x 2656 F: 25, 2592 x 1944 F: 45,
2048 x 1536 N: 72, 1600 x 1200 F: 116, 1280 x 960 F: 141 N: 265,
640 x 480 F: 509
1280 x 720 20 seconds, 640 x 480 58 seconds, 320 x 240 2 minutes 22 seconds
JPEG (Exif Ver. 2.21)※8
JPEG (Exif Ver. 2.21)※8
AVI (Open DML Motion JPEG Format Compliant)
EAN-13/8 (JAN-13/8), UPC-A/E, UPC/EAN (with add-ons), Interleaved 2 of 5, CODEBAR (NW-7),
CODE 39, CODE 93, CODE 128 TYPE C, GS1-128 (EAN-128), and RSS (GS1 DataBar)
QR Code, Micro QR Code, DataMatrix(ECC200), PDF417, Micro PDF417, MaxiCode,
EAN・UCC Composite(GS1 DataBar Composite)
Continuous mode, Self-timer (operation time: approx. 10 seconds, approx. 2 seconds), Interval shooting
(shooting interval: 5 seconds to 3 hours, in increments of 5 seconds)※9, Histogram display, Grid guide display
Thumbnail view, Enlarged view (maximum 16×), Resize, Contrast Correction
USB2.0 (High-Speed USB) Mini-B, AV output, Mass storage-compatible※10
Rechargeable Battery (DB-65) x１, AC adapter （AC-5c option）,
AAA Alkaline Battery x 2, AAA Nickel-Hydrogen Battery x 2
Based on CIPA standard, DB-65: approx. 360 shots AAA alkaline: 40 shots※12
118.8 mm × 71.0 mm × 41.0 mm, 32.0 mm (D) at thinnest, excluding projections
Approx. 280 g (excluding battery, SD memory card, and strap), Approx. 310 g (including memory card and supplied battery)
JIS/IEC waterproof grade 8, shooting to a water depth of approx. 5 m※13
JIS/IEC dustproof grade 6
External cleaning possible with ethanol and hypochlorous acid disinfectants
‒10 °C to 40 °C
No. of effective pixels (camera)
Image Sensor
Lens
Zoom Magnification
Focus Modes
Blur Reduction
Shutter
Speed※3
Exposure
Control
ISO Sensitivity
(Standard Output Sensitivity）
White Balance Mode
Flash
Picture Display
Shooting Mode
Picture Quality Mode※4
Number of
Recorded
Pixels
Recording Media
Recording
File
Format
Bar Codes
Supported
Other Major Shooting Functions
Other Major Playback Functions
Interface
Power Supply
Battery life※11
Dimensions (W × H × D)
Weight
Water Resistance/
Dust Resistance/
Chemical Resistance
Operating Temperature 
 
 
Picture/
Time Storage
Capacity
※6
(Internal: approx.
103MB）
Focal Length
F-aperture
Shooting
Distance 
Lens Construction
Filter size
Still Image
Movie
Exposure Metering Mode
Exposure Mode
Exposure Compensation
Flash Mode
Built-in flash Range
Still Image
Movie
Text
Still image
 
Movie※7
Still Image
Text
Movie
Linear
Matrix
http:// www.ricoh.com /r_dc
RICOH ASIA PACIFIC OPER AT IONS LIMI TED
• Windows® and Windows Vista® are registered trademarks or trademarks of Microsoft Corporation in the U.S. and/or other countries. • Mac OS is registered trademark of Apple Inc. in the U.S. and/or other countries.
• Adobe and Adobe Reader are trademarks or registered trademarks of Adobe Systems Incorporated in the U.S. and/or other countries. • The SD logo is a trademark. • Compatible with EPSON PRINT Image Matching III.
• All other company names and product names mentioned herein are trademarks or registered trademarks of their respective companies.
The G700 has a large 3.0-inch 920,000-dot high-definition
picture display. The wide angle and high contrast give high
visibility even outdoors.
Date information is indispensible when creating photographic
records. By displaying the date
from the time the camera is
turned on until the shutter
release button is pressed, this
function helps prevent time
data errors caused by incorrect
date/time settings.
For level shooting, an
electronic level is
provided as a standard
feature. It enables you
to hold the camera in an
accurate level position
when shooting subjects
such as buildings and
interiors.
Boasting a wide viewing angle, the 3.0-inch
920,000-dot picture display is easy-to-see
and easy-to-use even outdoors
Electronic level enables
level photography
■Date display when camera is turned on
*Simulated image.
*Simulated image.
*Simulated image.
NEW
NEW
Even in confined space,
take photographs with wide
coverage of the subject
Zoom in to capture the subject from far away
The G700 uses a 28-140 mm 5x optical zoom lens. With the
ability to take photographs across a wide range impossible
for a standard 35 mm lens, the G700 is convenient for
shooting indoors and at other sites where it is not practical to
back up. It also easily
handles telephoto
shooting.
Now it is possible to shoot at an even
wider 22 mm equivalent. With the slim
design, you can shoot without being
bothered by lens bulk even when the
conversion lens is attached.
Wide conversion lens (DW-5) ＜Option＞
With 1 cm wide-angle macro photography*
you can capture small screws and scratches
and even vividly reproduce material
textures. In addition, the flash can be used
to illuminate subjects as close as 20 cm.
*The macro shooting wide-angle setting is f=5.9mm at a 33 mm focal length
(35 mm equivalent). At maximum telephoto you can shoot as close as 15 cm.
*When the flash is used with the wide conversion lens attached, parts of the image
may be dark because the light does not reach the edge of the frame.
Even surface texture is visible:
1 cm macro shooting
28-140 mm non-extending optical 5x
zoom captures each subject as intended
High-performance lens handles various situation
J<78
@46EB
HF89H?
Operation controls offer outstanding ease of use
28mm
22
mm
28
mm
140
mm
35mm
*All lens focal lengths in this catalog are converted into 35 mm camera equivalents.
The water, dust, and shock resistant digital camera
28
mm
22
mm
(option)
10
m
140
mm
Water, dust,
and shock
resistance
Chemical
resistance
Electronic
level
Password
lock
SD WORM
Internal
flash
1. DL-10
2. MediaBrowser
3. Adobe Reader
®
4. ListEditor
5. ME1
6. EC1
7. EX1
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
×
○
○
○
○
○
Windows
®
7 Windows Vista
®
Windows
®
2000
○
○
○
○
○
○
○
Windows
®
XP
■G700 Software
■G700 System Requirements
Windows
®
Windows
®
2000 Professional Service Pack 4,
Windows
®
XP Home Edition Service Pack 3/Professional Service Pack 3,
Windows Vista
®
Service Pack 2,
Windows
®
7 (32- and 64-bit)
Pentium
®
IV: 1.6 GHz or faster,
Pentium
®
M: 1.4 GHz or faster,
Core
TM
2 Duo: 1.5 GHz or faster
Windows
®
2000/Windows
®
XP: 512 MB or more,
Windows Vista
®
/Windows
®
7: 1 GB or more
300 MB or more
1024 × 768 pixels or greater
65,000 colors or greater
A CD-ROM drive compatible with the above-mentioned computer
A USB port compatible with the above-mentioned computer
Operating Systems Supported
CPU
Memory
Hard drive space required for installation
Display Resolution
Display Colors
CD-ROM Drive
USB Port
*The CD-ROM supports Japanese, English, French and German. Operations are
not guaranteed on operating systems with other languages.
*64-bit Windows Vista is not supported.
*If your computer has an upgraded OS, the USB function may not work normally, so it cannot be supported.
*The provided software may not operate properly if changes are made to the
operating system, such as with patches and service package releases.
*The camera does not support connection to a USB port added by using an
extension function (PCI bus or other).
*If used in conjunction with a hub or other USB devices, the software may not work properly.
*When dealing with movies and other large files, a larger memory environment is recommended.
*MediaBrowser is not supported under Windows 2000.
＜Optional Accessories ＞
Accessories included＜ ＞
■G700 Major Specifications
Item Specificatations
※ 1：The macro shooting wide-angle setting is f=5.9mm at a 33 mm focal length (35 mm equivalent).
※ 2：Image size is VGA.
※ 3：The upper and lower limits differ for each shooting mode and flash mode.
※ 4：The picture quality mode that can be set varies depending on the image size.
※ 5：SD WORM cards can be purchased from SanDisk Corporation agents that supply corporate customers.
※ 6：The estimated number of pictures that can be recorded or the estimated recording time.
※ 7：The maximum movie length that can be recorded at one time is either 90 minutes or 4 GB. When shooting movies of 1280 × 720 size,
the use of an SD/SDHC memory card with an SD speed class of Class 6 or higher is recommended.
※ 8：Compatible with DCF and DPOF. DCF is the abbreviation for “Design rule for Camera File system,” a JEITA standard
(Full compatibility with other devices is not guaranteed).
※ 9：When the flash is set to [Flash Off ].
※10：Mass storage mode is supported by Windows 2000, Windows XP, Windows Vista, Windows 7, Mac OS 9.0‒9.2.2, and Mac OS X 10.1.2‒10.6.3.
※11：The number of remaining shots is based on the CIPA standard and may vary depending on usage conditions. This is for reference only.
※12：When using the AAA Alkaline batteries manufactured by Panasonic.
※13：At a water depth of up to 5 m, a maximum of approximately two hours of shooting is possible. Optimal shooting may not be possible depending on the water environment.
DW-5
DB-65
BJ-6
SC-700
Product Name Model Name
■G700 Optional Accessories
Wide Conversion Lens
Rechargeable Battery
Battery Charger
Soft Case
Mode Image Size 1GB
210
365
238
433
683
1,102
1,337
2,514
4,834
183”
534”
1,294”
2GB
404
701
457
826
1,311
2,080
2,514
4,641
8,620
373”
1,087”
2,633”
4GB
810
1,403
914
1,653
2,623
4,162
5,029
9,284
17,243
734”
2,135”
5,170”
8GB
1,630
2,824
1,840
3,327
5,281
8,377
10,122
18,687
34,705
1,494”
4,344”
10,522”
16GB
3,283
5,688
3,706
6,701
10,635
16,869
20,383
37,631
69,887
3,006”
8,742”
21,170”
32GB
6,534
11,320
7,375
13,336
21,164
33,571
40,565
74,890
152,941
6,031”
17,536”
42,467”
Still
Movie
Internal Memory
(103MB)
22
38
25
45
72
116
141
265
509
20”
58”
142”
4000×3000（F）
4000×3000（N）
3984×2656（F）
2592×1944（F）
2048×1536（F）
1600×1200（F）
1280×960（F）
1280×960（N）
640×480（F）
1280×720 30fps
640×480 30fps
320×240 30fps
■SD Memory Card Storage Capacity (Number of Images and Time)
*The figures for storage capacity assume that no camera memo lists, voice
memos, or other camera system files are stored in the internal memory or on an SD memory card.
*The maximum recording time is the estimated total recording time.
❶Soft Case(SC-700)
❷Wide Conversion Lens(DW-5)
①AV Cable
②USB Cable (Mini B Cable)
③CD-ROM
④Recageable Battery
⑤Battery Charger
⑥Neck Strap
❶ ❷
●Instruction Manual(Camera User Guide)*Warranty Card
*Softweare manual spplied on CD-ROM
Approx. 12.10 million effective pixels
1/2.3 CCD (Approx. 12.40 total million pixels)
5.0 mm to 25 mm (equivalent to 28 mm to 140 mm on a 35-mm camera)
F3.5 to F5.5
Normal shooting: Approx. 30 cm to ∞ (Wide-angle) or 50 cm to ∞ (Telephoto) (from the front of the lens)
Macro shooting: Approx. 1 cm to ∞ (Wide-angle※1), 15 cm to ∞ (Telephoto) or 1 cm to ∞ (Zoom macro mode) (from the front of the lens)
11 elements in 9 groups plus 1 prism
37mm
Optical zoom at 5.0× (focal length equivalent to 28 mm to 140 mm on a 35 mm camera)
Digital zoom at 4.0×, up to 20.0x (560 mm equivalent) in combination with optical zoom
Auto resize zoom at approx. 6.3× (VGA image)
※2
, up to 31.5x (882 mm equivalent) in combination with optical zoom
Multi AF (CCD method)/Spot AF (CCD method)/MF/Snap/∞ (with AF Auxiliary Light)
Digital image stabilizer
8, 4, 2, 1 to 1/1500 seconds
1/30 to 1/10000 seconds
Multi Light Metering (256 segments)/Center-weighted Light Metering/Spot Metering (TTL-CCD Metering and AE lock possible)
Program AE
Manual exposure compensation (+2.0 to ‒2.0 EV in 1/3 EV Steps), Auto bracket function (‒0.5 EV, ±0, +0.5 EV)
AUTO、ISO64／ISO100／ISO200／ISO400／ISO800／ISO1600／ISO3200
Auto/Outdoors/Cloudy/Incandescent 1/Incandescent 2/Fluorescent/Manual/Ring Light, White balance bracket function
Auto flash (fires automatically in low-light conditions and when the subject is backlit)/Anti Red-eye/
Flash On/FLASH ON (10M)/Flash Synchro./Flash Off
Approx. 20 cm to 10.0 m (Wide-angle), approx. 40 cm to 6.2 m (Telephoto) (ISO AUTO/ISO 1600, from the front of the lens)
3.0 Transmissive LCD, approx. 920,000 dots
Auto shooting mode/Scene mode (High Sens/Firefighting/Skew Correct Mode/Text Mode/Zoom Macro/
Movie)/My settings mode/CALS mode
F (Fine), N (Normal)
[4 : 3] 4000 × 3000, 2592 × 1944, 2048 × 1536, 1600 × 1200, 1280 × 960, 640 × 480
[3 : 2] 3984 × 2656
1280 × 720, 640 × 480, 320 × 240
4000 × 3000, 2048 × 1536
SD memory card (3.3Ｖ 256MB, 512ＭＢ, 1GB, 2ＧＢ), SDHC memory card (up to 32 GB),
SD WORM card※5
（128MB, 1GB）, Internal Memory (approx. 103 MB)
4000 x 3000 F: 22 pictures N: 38 pictures, 3984 x 2656 F: 25, 2592 x 1944 F: 45,
2048 x 1536 N: 72, 1600 x 1200 F: 116, 1280 x 960 F: 141 N: 265,
640 x 480 F: 509
1280 x 720 20 seconds, 640 x 480 58 seconds, 320 x 240 2 minutes 22 seconds
JPEG (Exif Ver. 2.21)※8
JPEG (Exif Ver. 2.21)※8
AVI (Open DML Motion JPEG Format Compliant)
EAN-13/8 (JAN-13/8), UPC-A/E, UPC/EAN (with add-ons), Interleaved 2 of 5, CODEBAR (NW-7),
CODE 39, CODE 93, CODE 128 TYPE C, GS1-128 (EAN-128), and RSS (GS1 DataBar)
QR Code, Micro QR Code, DataMatrix(ECC200), PDF417, Micro PDF417, MaxiCode,
EAN・UCC Composite(GS1 DataBar Composite)
Continuous mode, Self-timer (operation time: approx. 10 seconds, approx. 2 seconds), Interval shooting
(shooting interval: 5 seconds to 3 hours, in increments of 5 seconds)※9, Histogram display, Grid guide display
Thumbnail view, Enlarged view (maximum 16×), Resize, Contrast Correction
USB2.0 (High-Speed USB) Mini-B, AV output, Mass storage-compatible※10
Rechargeable Battery (DB-65) x１, AC adapter （AC-5c option）,
AAA Alkaline Battery x 2, AAA Nickel-Hydrogen Battery x 2
Based on CIPA standard, DB-65: approx. 360 shots AAA alkaline: 40 shots※12
118.8 mm × 71.0 mm × 41.0 mm, 32.0 mm (D) at thinnest, excluding projections
Approx. 280 g (excluding battery, SD memory card, and strap), Approx. 310 g (including memory card and supplied battery)
JIS/IEC waterproof grade 8, shooting to a water depth of approx. 5 m※13
JIS/IEC dustproof grade 6
External cleaning possible with ethanol and hypochlorous acid disinfectants
‒10 °C to 40 °C
No. of effective pixels (camera)
Image Sensor
Lens
Zoom Magnification
Focus Modes
Blur Reduction
Shutter
Speed※3
Exposure
Control
ISO Sensitivity
(Standard Output Sensitivity）
White Balance Mode
Flash
Picture Display
Shooting Mode
Picture Quality Mode※4
Number of
Recorded
Pixels
Recording Media
Recording
File
Format
Bar Codes
Supported
Other Major Shooting Functions
Other Major Playback Functions
Interface
Power Supply
Battery life※11
Dimensions (W × H × D)
Weight
Water Resistance/
Dust Resistance/
Chemical Resistance
Operating Temperature 
 
 
Picture/
Time Storage
Capacity
※6
(Internal: approx.
103MB）
Focal Length
F-aperture
Shooting
Distance 
Lens Construction
Filter size
Still Image
Movie
Exposure Metering Mode
Exposure Mode
Exposure Compensation
Flash Mode
Built-in flash Range
Still Image
Movie
Text
Still image
 
Movie※7
Still Image
Text
Movie
Linear
Matrix
http:// www.ricoh.com /r_dc
RICOH ASIA PACIFIC OPER AT IONS LIMI TED
• Windows® and Windows Vista® are registered trademarks or trademarks of Microsoft Corporation in the U.S. and/or other countries. • Mac OS is registered trademark of Apple Inc. in the U.S. and/or other countries.
• Adobe and Adobe Reader are trademarks or registered trademarks of Adobe Systems Incorporated in the U.S. and/or other countries. • The SD logo is a trademark. • Compatible with EPSON PRINT Image Matching III.
• All other company names and product names mentioned herein are trademarks or registered trademarks of their respective companies.

Navigation menu
