IBM Global Security Kit
GSKCapiCmd User’s Guide
GSKit Version 7
2
Edition 12 March 2007
(C) Copyright International Business Machines Corporation 2005-2007. All
rights reserved.
U.S. Government Users Restricted Rights -- Use, duplication or disclosure restricted
by GSA ADP Schedule Contract with IBM Corp.
Note: Before using this information and the product it supports, read the
information in Appendix 3. Notices.
3
Contents
Preface............................................................................................................................4
Chapter 1. Using The GSKCapiCmd Program........................................................7
GSKCapiCmd command line syntax.........................................................................8
Chapter 2. Key Database Commands......................................................................9
Create Key Database..................................................................................................9
Delete Key Database................................................................................................11
Change Password for Key Database........................................................................12
Stash the Password for Key Database......................................................................14
List Supported Key Databases.................................................................................15
Convert Key Database .............................................................................................15
Display Key Database Password Expiry..................................................................17
Chapter 3. Certificate Commands .........................................................................19
Create a Self-Signed Certificate...............................................................................19
Add a Certificate......................................................................................................22
Delete a Certificate ..................................................................................................23
Display Details of a Certificate................................................................................25
Export a Certificate..................................................................................................26
Receive a Certificate................................................................................................28
Import a Certificate..................................................................................................29
Extract a Certificate .................................................................................................31
List Details of Default Certificate............................................................................33
Set Default Certificate..............................................................................................34
List Certificates........................................................................................................35
Modify Certificate....................................................................................................37
Sign a Certificate......................................................................................................38
Chapter 4. Certificate Request Commands............................................................41
Create a Certificate Request.....................................................................................41
Delete Certificate Request .......................................................................................43
List Certificate Request Details...............................................................................44
Extract Certificate Request ......................................................................................46
List all Certificate Requests.....................................................................................47
Re-create Certificates Requests ...............................................................................48
Chapter 5. Random Password Generation.............................................................51
Create a Random Password .....................................................................................51
Chapter 6. Help Commands...................................................................................53
Chapter 7. Version Commands..............................................................................54
Chapter 8. Error Codes and Messages...................................................................55
Appendix 1. CMS Key Database..............................................................................61
Appendix 2. A Simple Example...............................................................................64
Appendix 3. Notices .................................................................................................70
4
Preface
This manual is intended for network or system security administrators who have installed
GSKit and want to use the GSKCapiCmd program to modify CMS or PKCS11 key databases.
This manual assumes the reader is familiar with the GSKit product range and the functionality
of the CMS key database.
Before continuing to read this manual ensure you have read and understood the following
prerequisite readings. This will ensure that you understand the required concepts and terms
used throughout the manual:
• Appendix 1 of this manual, “CMS Key Databases”.
• Appendix 2 of this manual, “A Simple Example”.
Please ensure that you read all of the identified readings before you continue with this
manual.
How this book is organized
This manual contains the following sections:
• Chapter 1, “Using the GSKCapiCmd Program”, on page 6. This chapter contains general
information about the GSKCapiCmd program.
• Chapter 2, “Key Database Commands”, on page 8. This chapter looks at the different
commands that are available to the GSKCapiCmd program for CMS key databases.
• Chapter 3, “Certificate Commands”, on page 17. This chapter looks at the different
commands that are available to the GSKCapiCmd program for managing certificates.
• Chapter 4, “Certificate Request Commands” on page 38. This chapter looks at the different
commands that are available to the GSKCapiCmd program for managing certificate requests.
• Chapter 5, “Random Commands”, on page 48.
• Chapter 6 “Help Command”, on page 50.
• Chapter 7 “Version Command”, on page 51.
• Chapter 8 “Error Codes and messages”, on page 52.
• Appendix 1, “CMS Key Databases”, on page 58.
• Appendix 2, “A Simple Example”, on page 61
• Appendix 3, “Notices”, on page 67
Contacting software support
Before contacting IBM Tivoli Software Support with a problem, refer to the IBM Tivoli Software
Support site by clicking the Tivoli support link at the following Web site:
http://www.ibm.com/software/support/ If you need additional help, contact software support by using
the methods described in the IBM Software Support Guide at the following Web site:
http://techsupport.services.ibm.com/guides/handbook.html The guide provides the following
information: Registration and eligibility requirements for receiving support v Telephone numbers,
depending on the country in which you are located v A list of information you should gather before
contacting customer support
Conventions used in this book
The following typeface conventions are used through out this manual:
Bold: Draws emphasis to a key word, indicating that the user needs to take note as the word will be
used at a later stage. In relation to the options of each command a bolded value indicates the default
value for that option.
5
Italic: Non-specific command line options or identifiers.
Symbol conventions
[ ] - Identifies an option that is optional, if an option is not surrounded by this style of brackets the
option is required.
| - Indicates an “OR” relationship between the options on either side of it.
{} – Identifies mutually exclusive set of options.
Operating system differences
This book uses the UNIX convention for specifying environment variables and for directory notation.
When using the Windows command line, replace $variable with %variable% for environment
variables and replace each forward slash (/) with a backslash (\) in directory paths. If you are using the
bash shell on a Windows system, you can use the UNIX conventions.
Acronyms
The following is a list of acronyms that are used throughout this manual.
CA - Certificate Authority
CMS - Certificate Management System
FIPS - Federal Information Processing Standards
GSKit - Global Security Kit
ICC - IBM Crypto for C
IE - Internet Explorer
Revision History
Revision Description On Date Refer to...
First draft of document 11/08/2004 Anthony Ferguson
Updating document with
additional information 24/08/2004 Anthony Ferguson
Updating the document with
additional information. 3/11/2004 Anthony Ferguson
Corrected a number of error
in the document after a
review.
2/12/2004 Anthony Ferguson
Updated a number of errors
after an @sec review 21/12/2004 Anthony Ferguson
Adding the random
password generation
information
7/1/2005 Anthony Ferguson
Correcting some minor
errors. 24/01/2005 Anthony Ferguson
Adding important warning to
ensure quotes are used for all
commands
14/02/2005 Anthony Ferguson
Addressing atsec comments 28/02/2005 Alex Hennekam
Adding the email and dc 11/08/2005 Anthony Ferguson
6
attributes to the DN tags
Adding the –sernum tag to
the certificate sign command 25/08/2005 Anthony Ferguson
Adding the –expiry action 16/02/2006 Anthony Ferguson
Adding pfx documentation
for certificate import and
export commands
10/04/2006 Anthony Ferguson
Adding additional error
codes to Chapter 8 27/04/2006 Anthony Ferguson
Adding newly supported
SHA algorithms 29/06/2006 Anthony Ferguson
Updating required fields for
DN tags 10/07/2006 Kai Gorman
Adding error codes 232 and
233 24/07/2006 Kai Gorman
Some corrections to
argument lists 12/March/2007 Simon McMahon
7
Chapter 1. Using The GSKCapiCmd Program
GSKCapiCmd is a tool that can be used to manage keys, certificates and certificate
requests within a CMS key database. The tool has all of the functionality that GSKit’s
existing java command line tool has except that GSKCapiCmd supports CMS and
PKCS11 key databases. If you are intending to manage key databases other than CMS
or PKCS11 you will need to use the existing java tool.
GSKCapiCmd can be used to manage all aspects of a CMS key database. The
following chapters go into detail for each of the functions supported by
GSKCapiCmd.
The advantage of using this tool over the existing one is that GSKCapiCmd does not
require java to be installed on the system.
GSKCapiCmd uses some encoding rules, and implements aspects of certain RFC’s
and standards. While it is not strictly necessary for users to have a full understanding
of these items in order to use this utility, those wishing to learn more should examine
the following resources:
http://asn1.elibel.tm.fr/en/standards/index.htm
Basic Encoding Rules (BER)
BER encoding is defined in the specification ITU-T Rec. X.690 (2002).
Distinguished Encoding Rules (DER)
DER encoding is defined in the specification ITU-T Rec. X.690 (2002).
http://www.faqs.org/rfcs
PKCS#10
RFC 2986: PKCS #10: Certification Request Syntax Specification, Version 1.7,
November 2000
X.509
RFC 3280: Internet X.509 Public Key Infrastructure - Certificate and Certificate
Revocation List (CRL), obsoletes RFC 2459, April 2002.
http://www.rsasecurity.com/rsalabs/
PKCS#11
Cryptographic Token Interface Standard
8
PKCS#12
PKCS 12 v1.0: Personal Information Exchange Syntax, RSA Laboratories, June 24,
1999
PKCS#7
PKCS 7 v1.5: Cryptographic Message Syntax, RSA Laboratories, March 1998
CMS
Appendix 1 offers some additional information concerning the format and use of a
CMS keystore, while appendix 2 takes the reader though a simple example of how
CMS keystores can be used to enable SSL communication between a server and client
application.
GSKCapiCmd command line syntax
The syntax for the GSKCapiCmd program is as follows:
gsk7capicmd <object> <action> <options>
where:
object Is one of the one of the following:
-keydb
Actions acted on a key database.
-cert
Actions acted on a certificate stored within an identified key database.
-certreq
Actions acted on a certificate request stored within an identified key database.
-random
Generates a random string of characters that can be used as a password for other
commands.
-version
Displays version information for GSKCapiCmd
-help Displays help for the GSKCapiCmd commands.
action Is the specific action to be taken on the object.
options Are the options associated with the specified object and task
This manual will go into detail for each particular object, its associated actions, and
what options are available in the following chapters.
9
Chapter 2. Key Database Commands
The key database commands are associated with the -keydb object. This object
supports the following actions:
• Create a Key Database (-create)
• Delete a Key Database (-delete)
• Change the Password of an existing Key Database (-changepw)
• Stash the Password of an existing Key Database (-stashpw)
• List the Supported Key Databases (-list)
• Convert an old style CMS Key Database to the updated style of CMS Key
Database (-convert)
• Display the expiry date associated with a CMS key databases password
(-expiry)
Each of the following sections goes into detail on how to use each of the key database
commands and what options are available for each command.
Create Key Database
The create command creates a new CMS key database. During the creation process
three files are created. The first file is the certificate key database itself. By standard it
is a good idea to name this file with a .kdb extension (key.kdb). This is not required,
but it is a good idea, it makes easy to identify the file as a key database.
The second file created is used to store certificate requests associated with the key
database. This file is created with the same name as given to the key database but with
a .rdb extension. The third file is used to hold the certificate revocation list used by
the key database; this file has become obsolete and is no longer used. This file is
created with the same name as the key database but this time with a .crl extension.
Once the key database has been created it is populated with a number of pre-defined
trusted certificate authority (CA) certificates. There is no way of preventing this from
occurring. The trusted CA certificates are as follows:
Entrust.net Global Secure Server Certification Authority
Entrust.net Global Client Certification Authority
Entrust.net Client Certification Authority
Entrust.net Certification Authority (2048)
Entrust.net Secure Server Certification Authority
VeriSign Class 3 Public Primary Certification Authority
VeriSign Class 2 Public Primary Certification Authority
VeriSign Class 1 Public Primary Certification Authority
VeriSign Class 4 Public Primary Certification Authority - G2
VeriSign Class 3 Public Primary Certification Authority - G2
VeriSign Class 2 Public Primary Certification Authority - G2
VeriSign Class 1 Public Primary Certification Authority - G2
VeriSign Class 4 Public Primary Certification Authority - G3
VeriSign Class 3 Public Primary Certification Authority - G3
VeriSign Class 2 Public Primary Certification Authority - G3
VeriSign Class 1 Public Primary Certification Authority - G3
Thawte Personal Premium CA
Thawte Personal Freemail CA
Thawte Personal Basic CA
10
Thawte Premium Server CA
Thawte Server CA
RSA Secure Server Certification Authority
Any or all of these CA certificates can be removed from the key database. If you want
to remove any of the certificates look at the delete certificate command in this
manual.
The syntax for creating a CMS key database with GSKCapiCmd is as follows:
gsk7capicmd -keydb -create -db <name> [-pw <passwd>] [-type <cms>] [-expire
<days>] [-stash] [-fips] [-strong]
Where:
object -keydb
action -create
options
IMPORTANT: On Unix type operating systems it is recommended to always
encapsulate string values associated with all tags in double quotes (“”). You
will also need to escape, using a ‘\’ character, the following characters if they
appear in the string values: ‘!’, ‘\’, ‘”’, ‘`’. This will prevent some command
line shells from interpreting specific characters within these values. (e.g.
gsk7capicmd –keydb –create –db “/tmp/key.kdb” –pw “j\!jj”). Note however
when prompted by gsk7capicmd for a value (for example a password) quoting
the string and adding the escape characters should not be done. This is because
the shell is no longer influencing this input.
-db <filename>
Fully qualified path name of a key database. A good example of a key
database filename might be /home/<user name>/keydb.db.
-pw <passwd>
The password for the key database identified by the –db tag above. If
you want to create a key store without a password simply leave the
-pw tag out of the above command.
-type <cms>
The type of the key database to be created. At this stage this tool only
supports the creation of CMS key database. If the tag is left off the tool
will assume that a CMS key database is to be created.
-expire <days>
The number of days before the password for the key database is to
expire. If the tag is left off, the key database password will never
expire. If specified the duration must be from 1 to 7300 days (20
years).
-stash
11
Stash the password for the key database after creation. A stash file is
used as an automatic way of providing a password. When accessing a
key database the system will first check for the existence of a stash file.
If one exists the contents of the file will be decrypted and used as input
for the password. When the -stash option is specified during the create
action, the password is stashed into a file with the name as follows:
<key database name>.sth.
-fips
This disables the use of the BSafe cryptographic library. Only the ICC
component which must be successfully intialized in FIPS* mode will
be used. If the ICC component does not intialize in FIPS mode then the
gsk7capicmd operation will fail.
* When in FIPS mode the ICC component uses algorithms that have been FIPS 140-2
validated.
-strong
Check that the password entered satisfies the minimum requirements
for the passwords strength. The minimum requirements for a password
are as follows:
• The minimum password length is 14 characters.
• A password needs to have at least one lower case character, one upper case
character, and one digit or special character ( eg. *$#% etc, a space is
classified as special characters).
• Each character should not occur more than three times in a password.
• No more than two consecutive characters of the password should be
identical.
• All characters mentioned above are in the standard ASCII printable character
set within the range from 0x20 to 0x7E inclusive.
Delete Key Database
The delete key database command simply deletes the identified key database. When
identifying the key database you simply need to specify the file name of the key
database. The request database (.rdb) and certificate revocation list (.crl) files are
removed automatically during the process. If a stash file was created it is not
removed.
If a password was provided for this command it is used to ensure that the user is
actually allowed to delete the key database. If the password is not correct the key
database is not deleted.
The syntax for deleting a key database with GSKCapiCmd is as follows:
gsk7capicmd -keydb -delete -db <name> [-pw <passwd>]
Where:
object -keydb
12
action -delete
options
IMPORTANT: On Unix type operating systems it is recommended to always
encapsulate string values associated with all tags in double quotes (“”). You
will also need to escape, using a ‘\’ character, the following characters if they
appear in the string values: ‘!’, ‘\’, ‘”’, ‘`’. This will prevent some command
line shells from interpreting specific characters within these values. (e.g.
gsk7capicmd –keydb –create –db “/tmp/key.kdb” –pw “j\!jj”). Note however
when prompted by gsk7capicmd for a value (for example a password) quoting
the string and adding the escape characters should not be done. This is because
the shell is no longer influencing this input.
-db <filename>
The fully qualified path name of a key database.
-pw <passwd>
The password for the key database identified by the –db tag above. The
–pw tag is required if the key database was created with a password. It
is an additional check to ensure that the user deleting the key database
is authorized to do so. If the key database does not have a password the
–pw tag is not required.
If a password is provided and it does not patch the password for the
identified key database the key database is not deleted.
Change Password for Key Database
The change password command allows the user to change the password associated
with the specified key database. When changing the password for a key database, all
key records containing encrypted private key information have the private key data re-
encrypted. The new password is used as input to create the new encryption key used
during the encryption process.
The syntax for changing the password of an existing key database with GSKCapiCmd
is as follows:
gsk7capicmd -keydb -changepw {-db <name> | -crypto <module name> -tokenlabel
<token label>} [-pw <passwd>] -new_pw <new passwd> [-expire <days>] [-stash]
[-fips] [-strong]
Where:
object -keydb
action -changepw
options
13
IMPORTANT: On Unix type operating systems it is recommended to always
encapsulate string values associated with all tags in double quotes (“”). You
will also need to escape, using a ‘\’ character, the following characters if they
appear in the string values: ‘!’, ‘\’, ‘”’, ‘`’. This will prevent some command
line shells from interpreting specific characters within these values. (e.g.
gsk7capicmd –keydb –create –db “/tmp/key.kdb” –pw “j\!jj”). Note however
when prompted by gsk7capicmd for a value (for example a password) quoting
the string and adding the escape characters should not be done. This is because
the shell is no longer influencing this input.
-db <filename>
The fully qualified path name of a key database.
-crypto <module name>
Indicates a PKCS11 cryptographic device operation, where <module
name> is the path to the module to manage the crypto device.
-tokenlabel <token label>
The PKCS11 cryptographic device token label.
-pw <passwd>
The password for the key database identified by the –db tag above. If
you want to create a key store without a password simply leave the
-pw tag out of the above command.
-new_pw <new passwd>
The new password for the key database.
-expire <days>
The number of days before the new password is to expire. If the tag is
not specified the key databases password never expires. If specified the
duration must be within the range of 1 to 7300 days (20 years).
-stash
Stash the password for the key database. When the –stash the new
password will be stashed in a file with the filename built as follows:
<filename of key database>.sth.
-fips This disables the use of the BSafe cryptographic library. Only the ICC
component which must be successfully intialized in FIPS* mode will
be used. If the ICC component does not intialize in FIPS mode then the
gsk7capicmd operation will fail.
* When in FIPS mode the ICC component uses algorithms that have been FIPS 140-2
validated
-strong Check that the password entered satisfies the minimum requirements
for the passwords strength. The minimum requirements for a password
are as follows:
14
• The minimum password length is 14 characters.
• A password needs to have at least one lower case character, one upper case
character, and one digit or special character (eg. *$#% etc, a space is
classified as special characters).
• Each character should not occur more than three times in a password.
• No more than two consecutive characters of the password should be
identical.
• All characters mentioned above are in the standard ASCII printable character
set within the range from 0x20 to 0x7E inclusive.
Stash the Password for Key Database
The stash password command takes an existing key databases password and stashes it
to a specified file. The reason that a user would want to stash a password for a key
database is to allow the password to be recovered from the file when automatic login
is required. The output of the command is a single file with the name of the key
database with a “.sth” extension.
The syntax for stashing the password of an existing key database with GSKCapiCmd
is as follows:
gsk7capicmd -keydb -stashpw -db <name> [-pw <passwd>] [-fips]
Where:
object -keydb
action -stashpw
options
IMPORTANT: On Unix type operating systems it is recommended to always
encapsulate string values associated with all tags in double quotes (“”). You
will also need to escape, using a ‘\’ character, the following characters if they
appear in the string values: ‘!’, ‘\’, ‘”’, ‘`’. This will prevent some command
line shells from interpreting specific characters within these values. (e.g.
gsk7capicmd –keydb –create –db “/tmp/key.kdb” –pw “j\!jj”). Note however
when prompted by gsk7capicmd for a value (for example a password) quoting
the string and adding the escape characters should not be done. This is because
the shell is no longer influencing this input.
-db <filename>
The fully qualified path name of a key database.
-pw <passwd>
The password for the key database identified by the –db tag above.
-fips This disables the use of the BSafe cryptographic library. Only the ICC
component which must be successfully intialized in FIPS* mode will
15
be used. If the ICC component does not intialize in FIPS mode then the
gsk7capicmd operation will fail.
* When in FIPS mode the ICC component uses algorithms that have been FIPS 140-2
validated
List Supported Key Databases
The list supported key databases simply lists all of the key database types that the
GSKCapiCmd supports.
The syntax for listing the key databases supported by GSKCapiCmd is as follows:
gsk7capicmd -keydb –list
Where:
object -keydb
action -list
Convert Key Database
The convert key database command converts an old version CMS key database to the
new version of CMS key database. The latest version of CMS is more secure because
it uses more secure algorithms to secure the contents of the key databases during
creation.
This command requires that you assign a name to the new key database that is
different to the existing old key database. This name cannot be the same as the
existing one. This is to ensure that the old key database is not destroyed until the user
destroys it. Once all testing of the new version key database has been completed the
user can remove the old key database and rename the new key database to the old key
databases name if required.
The syntax for converting a key database to the latest CMS version by GSKCapiCmd
is as follows:
gsk7capicmd -keydb –convert –db <name> [-pw <passwd>] –new_db <name>
[-new_pw <passwd>] [-preserve] [-strong] [-fips]
Where:
object -keydb
action -list
options
Deleted: . At this stage this command
will only indicate that CMS and PKCS11
key databases are supported.
Deleted: [-fips]
Deleted: ¶
options¶
¶
-fips¶
This disables the use of the BSafe
cryptographic library. Only the ICC
component which must be successfully
intialized in FIPS* mode will be used. If
the ICC component does not intialize in
FIPS mode then the gsk7capicmd
operation will fail. ¶
¶
* When in FIPS mode the ICC
component uses algorithms that have
been FIPS 140-2 validated¶
16
IMPORTANT: On Unix type operating systems it is recommended to always
encapsulate string values associated with all tags in double quotes (“”). You
will also need to escape, using a ‘\’ character, the following characters if they
appear in the string values: ‘!’, ‘\’, ‘”’, ‘`’. This will prevent some command
line shells from interpreting specific characters within these values. (e.g.
gsk7capicmd –keydb –create –db “/tmp/key.kdb” –pw “j\!jj”). Note however
when prompted by gsk7capicmd for a value (for example a password) quoting
the string and adding the escape characters should not be done. This is because
the shell is no longer influencing this input.
-db <filename>
The fully qualified path name of a key database.
-pw <passwd>
The password for the key database identified by the –db tag above.
-new_db <filename>
Fully qualified path name of a new key database to be created during
the conversion.
-new_pw <passwd>
The password for the key database identified by the –new_db tag
above.
-preserve
When this option is specified during the convert command the newly
created key database will not include any new trusted CA certificates,
it will be identical to the old key database.
If you chose not to include this option the following CA certificates
will be added to the newly created key database:
Entrust.net Global Secure Server Certification Authority
Entrust.net Global Client Certification Authority
Entrust.net Client Certification Authority
Entrust.net Certification Authority (2048)
Entrust.net Secure Server Certification Authority
VeriSign Class 3 Public Primary Certification Authority
VeriSign Class 2 Public Primary Certification Authority
VeriSign Class 1 Public Primary Certification Authority
VeriSign Class 4 Public Primary Certification Authority - G2
VeriSign Class 3 Public Primary Certification Authority - G2
VeriSign Class 2 Public Primary Certification Authority - G2
VeriSign Class 1 Public Primary Certification Authority - G2
VeriSign Class 4 Public Primary Certification Authority - G3
VeriSign Class 3 Public Primary Certification Authority - G3
VeriSign Class 2 Public Primary Certification Authority - G3
VeriSign Class 1 Public Primary Certification Authority - G3
Thawte Personal Premium CA
Thawte Personal Freemail CA
Thawte Personal Basic CA
Thawte Premium Server CA
Thawte Server CA
RSA Secure Server Certification Authority
There is no way of adding just a couple of the CA certificates it is all
or none, but you are able to remove any of them at a later stage.
17
-strong
Check that the password entered satisfies the minimum requirements
for the passwords strength. The minimum requirements for a password
are as follows:
• The minimum password length is 14 characters.
• A password needs to have at least one lower case character, one upper case
character, and one digit or special character (eg. *$#% etc, a space is
classified as special characters).
• Each character should not occur more than three times in a password.
• No more than two consecutive characters of the password should be
identical.
• All characters mentioned above are in the standard ASCII printable character
set within the range from 0x20 to 0x7E inclusive.
-fips This disables the use of the BSafe cryptographic library. Only the ICC
component which must be successfully intialized in FIPS* mode will
be used. If the ICC component does not intialize in FIPS mode then the
gsk7capicmd operation will fail.
* When in FIPS mode the ICC component uses algorithms that have been FIPS 140-2
validated
Display Key Database Password Expiry
The expiry key database command simply displays the date that the password
associated with the identified key database will expire. When identifying the key
database you simply need to specify the file name of the key database.
The syntax for displaying the expiry of the password associated with a key database
with GSKCapiCmd is as follows:
gsk7capicmd -keydb -expiry -db <name> [-pw <passwd>]
Where:
object -keydb
action -expiry
options
IMPORTANT: On Unix type operating systems it is recommended to always
encapsulate string values associated with all tags in double quotes (“”). You
will also need to escape, using a ‘\’ character, the following characters if they
appear in the string values: ‘!’, ‘\’, ‘”’, ‘`’. This will prevent some command
line shells from interpreting specific characters within these values. (e.g.
gsk7capicmd –keydb –expiry –db “/tmp/key.kdb” –pw “j\!jj”). Note however
when prompted by gsk7capicmd for a value (for example a password) quoting
18
the string and adding the escape characters should not be done. This is because
the shell is no longer influencing this input.
-db <filename>
The fully qualified path name of a key database.
-pw <passwd>
The password for the key database identified by the –db tag above. The
–pw tag is required if the key database was created with a password. If
the key database does not have a password the –pw tag is not required.
-fips This disables the use of the BSafe cryptographic library. Only the ICC
component which must be successfully intialized in FIPS* mode will
be used. If the ICC component does not intialize in FIPS mode then the
gsk7capicmd operation will fail.
* When in FIPS mode the ICC component uses algorithms that have been FIPS 140-2
validated
IMPORTANT: An expiry of 0 means that the password associated with the key
database does not expire.
19
Chapter 3. Certificate Commands
The certificate commands are associated with the -cert object. This object supports the
following actions:
• Create a self signed certificate in a key store (-create)
• Add a certificate to a key store (-add)
• Delete a certificate from a key store (-delete)
• Display the details of a certificate in a key store (-details)
• Export a certificate from a key store to another key store (-export)
• Receive a certificate into a key store (-receive)
• Import a certificate from a key store to another key store (-import)
• Extract a certificate from a key store (-extract)
• List the details of the default certificate in a key store (-getdefault)
• Set the default certificate in a key store (-setdefault)
• List the certificates stored in a key store (-list)
• Modify a certificate in a key store (-modify)
• Sign a certificate (-sign)
Each of the following sections goes into detail on how to use and what options are
available for each of the identified certificate actions.
Create a Self-Signed Certificate
A self-signed certificate provides a certificate that can be used for testing while
waiting for the officially signed certificate to be returned from the CA. Both a private
and public key are created during this process.
The create self-signed certificate command creates a self-signed X509 certificate in
the identified key database. A self-signed certificate has the same issuer name as its
subject name.
The syntax for creating a certificate in an existing key database with GSKCapiCmd is
as follows:
gsk7capicmd -cert -create {-db <name> | -crypto <module name> -tokenlabel <token
label>} [-pw <passwd>] -label <label> -dn <dist name> [-size <key size>] [-
x509version <1 | 2 | 3>] [-default_cert <yes | no>] [-expire <days>] [-secondaryDB
<filename> -secondaryDBpw <password>] [-ca <true | false>] [-fips] [-sigalg<md5 |
sha1 | sha224 | sha256 | sha384 | sha512>]
Where:
object -cert
action -create
options
20
IMPORTANT: On Unix type operating systems it is recommended to always
encapsulate string values associated with all tags in double quotes (“”). You
will also need to escape, using a ‘\’ character, the following characters if they
appear in the string values: ‘!’, ‘\’, ‘”’, ‘`’. This will prevent some command
line shells from interpreting specific characters within these values. (e.g.
gsk7capicmd –keydb –create –db “/tmp/key.kdb” –pw “j\!jj”). Note however
when prompted by gsk7capicmd for a value (for example a password) quoting
the string and adding the escape characters should not be done. This is because
the shell is no longer influencing this input.
-db <filename>
Fully qualified path name of a key database to store the self-signed
certificate.
-crypto <module name>
Indicates a PKCS11 cryptographic device operation, where <module
name> is the path to the module to manage the crypto device.
-tokenlabel <token label>
The PKCS11 cryptographic device token label.
-pw <passwd>
The password for the key database identified by the –db or –tokenlabel
tags above.
-label <label>
Label attached to the certificate. The label is used to uniquely identify
the certificate by a human user.
-dn <distinct name>
The X.500 distinguished name that will uniquely identify the
certificate. The input needs to be a quoted string of the following
format (only CN is required):
CN=common name
O=organization
OU=organization unit
L=location
ST=state, province
C=country
DC=domain component
EMAIL=email address
For Example: “CN=weblinux.Raleigh.ibm.com,O=ibm,OU=IBM
HTTP Server,L=RTP,ST=NC,C=US”
Multiple OU are now supported. Simply add additional OU key\value
pairs to the specified distinguished name. If the OU value requires a
comma (‘,’) it will need to escape it with ‘\\’.
21
For Example: “CN=weblinux.Raleigh.ibm.com,O=ibm,OU=IBM
HTTP Server,OU=GSKit\\, Gold Coast,L=RTP,ST=NC,C=US”
-size <key size>
The size of the new key pair to be created. Key size from 512 to 4096,
default 1024.
-x509version <1 | 2 | 3>
The version of X.509 certificate to create, default is 3.
-default_cert <yes | no>
Sets the newly created certificate as the default certificate for the key
database. By default the newly created self-signed certificate is not set
as the default (no). A default certificate in a key database is used when
a specific certificate is not specified during the use of the key database.
-expire <days1>
Expiration time of the certificate in days, default 365 days. The
duration is 1 to 7300 days (20 years)
-secondaryDB <filename>
A CMS key database used to support the PKCS11 device. A PKCS11
device does not normally have a large amount of space available to
store a lot of signer certificates. The signer certificates are used for the
validation of certificates when they are added to the PCKS11 device.
-secondaryDBpw <password>
Password for the secondary CMS key database supporting the PKCS11
device.
-ca <true | false>
This tag adds the Basic Constraint extension to the self-signed
certificate. The Basic Constraint extension value will be set to true or
false depending on what value is associated with the tag.
-fips This disables the use of the BSafe cryptographic library. Only the ICC
component which must be successfully intialized in FIPS* mode will
be used. If the ICC component does not intialize in FIPS mode then the
gsk7capicmd operation will fail.
* When in FIPS mode the ICC component uses algorithms that have been FIPS 140-2
validated
-sigalg<md5 | sha1 | sha224 | sha256 | sha384 | sha512>
The hashing algorithm to be used during the creation of the self signed
certificate. This hashing algorithm is used to create the signature
associated with the newly created self-signed certificate.
1 To avoid possible timezone issues the actual valid-from time for the certificate will be set one day in
the past.
22
Add a Certificate
The add certificate command stores a CA certificate into the identified key database.
The CA certificate is received as a file with the data encoded as either Base64 (ascii)
or binary. It is important to identify the correct format of the file otherwise the
operation will fail.
The syntax for adding a certificate in an existing key database with GSKCapiCmd is
as follows:
gsk7capicmd -cert -add {-db <name> | -crypto <module name>
-tokenlabel <token label>} [-pw <passwd>] -label <label> -file <name> [-format
<ascii | binary>] [-trust <enable | disable>] [-secondaryDB <filename>
-secondaryDBpw <password>] [-fips]
Where:
object -cert
action -add
options
IMPORTANT: On Unix type operating systems it is recommended to always
encapsulate string values associated with all tags in double quotes (“”). You
will also need to escape, using a ‘\’ character, the following characters if they
appear in the string values: ‘!’, ‘\’, ‘”’, ‘`’. This will prevent some command
line shells from interpreting specific characters within these values. (e.g.
gsk7capicmd –keydb –create –db “/tmp/key.kdb” –pw “j\!jj”). Note however
when prompted by gsk7capicmd for a value (for example a password) quoting
the string and adding the escape characters should not be done. This is because
the shell is no longer influencing this input.
-db <filename>
The fully qualified path name of a key database.
-crypto <module name>
Indicates a PKCS11 cryptographic device operation, where <module
name> is the path to the module to manage the crypto device.
-tokenlabel <token label>
The PKCS11 cryptographic device token label.
-pw <passwd>
The password for the key database identified by the –db or –tokenlabel
tags above.
-label <label>
Label attached to the certificate.
-file <name>
23
Filename of the certificate to add. If it is “.p7”, “.smime” or “.eml”
then it is assumed to be a pkcs7 encoding. The first cert will take the
‘label’ given, all other certs, if present, will be labelled with their
subject name.
-format <ascii | binary>
Format of a certificate The default is Base64 encoded ascii, additional
information about base64 encoding can be found in rfc2045 and
rfc3548. The binary format is a binary dump of the DER encoded
certificate structure. For additional information refer to ITU-T Rec.
X.690 (2002) | ISO/IEC 8825-1:2002
-trust <enable | disable>
Trust status of a CA certificate, where the default is ‘enable’. When a
CA’s certificate trust status is enabled then that CA certificate is
permitted to be involved in a certificate chain validation. If the CA’s
certificate trust status is disabled then it cannot be used to validate any
certificates. For example if certificate “ABC” is signed by the CA
certificate “VeriSign CA” and “VeriSign CA” is not marked as trusted
the validation of “ABC” will fail.
-secondaryDB <filename>
A CMS key database used to support the PKCS11 device. A PKCS11
device does not normally have a large amount of space available to
store a lot of signer certificates. The signer certificates are used for the
validation of certificates when they are added to the PCKS11 device.
-secondaryDBpw <password>
Password for the secondary CMS key database supporting the PKCS11
device.
-fips This disables the use of the BSafe cryptographic library. Only the ICC
component which must be successfully intialized in FIPS* mode will
be used. If the ICC component does not intialize in FIPS mode then the
gsk7capicmd operation will fail.
* When in FIPS mode the ICC component uses algorithms that have been FIPS 140-2
validated
Delete a Certificate
The delete command simply removes the certificate with the identified label. Once the
delete operation is complete, there is no way of recovering the certificate unless you
add the certificate back into the key database.
The syntax for deleting a certificate in an existing key database with GSKCapiCmd is
as follows:
24
gsk7capicmd -cert -delete {-db <name> | -crypto <module name> -tokenlabel <token
label>} [-pw <passwd>] -label <label> [-secondaryDB <filename> -secondaryDBpw
<password>] [-fips]
Where:
object -cert
action -delete
options
IMPORTANT: On Unix type operating systems it is recommended to always
encapsulate string values associated with all tags in double quotes (“”). You
will also need to escape, using a ‘\’ character, the following characters if they
appear in the string values: ‘!’, ‘\’, ‘”’, ‘`’. This will prevent some command
line shells from interpreting specific characters within these values. (e.g.
gsk7capicmd –keydb –create –db “/tmp/key.kdb” –pw “j\!jj”). Note however
when prompted by gsk7capicmd for a value (for example a password) quoting
the string and adding the escape characters should not be done. This is because
the shell is no longer influencing this input.
-db <filename>
The fully qualified path name of a key database.
-crypto <module name>
Indicates a PKCS11 cryptographic device operation, where <module
name> is the path to the module to manage the crypto device.
-tokenlabel <token label>
The PKCS11 cryptographic device token label.
-pw <passwd>
The password for the key database identified by the –db or –tokenlabel
tags above.
-label <label>
Label attached to the certificate that is to be deleted.
-secondaryDB <filename>
A CMS key database used to support the PKCS11 device. A PKCS11
device does not normally have a large amount of space available to
store a lot of signer certificates. The signer certificates are used for the
validation of certificates when they are added to the PCKS11 device.
-secondaryDBpw <password>
Password for the secondary CMS key database supporting the PKCS11
device.
-fips
25
This disables the use of the BSafe cryptographic library. Only the ICC
component which must be successfully intialized in FIPS* mode will
be used. If the ICC component does not intialize in FIPS mode then the
gsk7capicmd operation will fail.
* When in FIPS mode the ICC component uses algorithms that have been FIPS 140-2
validated
Display Details of a Certificate
The display certificate details command displays the different details associated with
the identified certificate. The details displayed include:
• The label of the certificate.
• The size of the key associated with the certificate.
• The X509 version that the certificate was created.
• The serial number for the certificate.
• The issuer and subject distinguished names.
• The certificate’s validity period.
• The fingerprint of the certificate.
• The signature of the algorithm used during creation of the certificate.
• An indication of the certificates trust status.
If more details for the certificate are required use the –showOID option. This option
displays a more detailed listing of the certificates details.
The syntax for displaying the details for a certificate in an existing key database with
GSKCapiCmd is as follows:
gsk7capicmd -cert -details [-showOID] {-db <name> | -crypto <module name> -
tokenlabel <token label>} [-pw <passwd>] -label <label> [-secondaryDB <filename>
-secondaryDBpw <password>] [-fips]
Where:
object -cert
action -details
options
IMPORTANT: On Unix type operating systems it is recommended to always
encapsulate string values associated with all tags in double quotes (“”). You
will also need to escape, using a ‘\’ character, the following characters if they
appear in the string values: ‘!’, ‘\’, ‘”’, ‘`’. This will prevent some command
line shells from interpreting specific characters within these values. (e.g.
gsk7capicmd –keydb –create –db “/tmp/key.kdb” –pw “j\!jj”). Note however
when prompted by gsk7capicmd for a value (for example a password) quoting
the string and adding the escape characters should not be done. This is because
the shell is no longer influencing this input.
26
-showOID
Display a more in depth listing of the certificate.
-db <filename>
The fully qualified path name of a key database.
-crypto <module name>
Indicates a PKCS11 cryptographic device operation, where <module
name> is the path to the module to manage the crypto device.
-tokenlabel <token label>
The PKCS11 cryptographic device token label.
-pw <passwd>
The password for the key database identified by the –db or –tokenlabel
tags above.
-label <label>
Label attached to the certificate that is to be displayed.
-secondaryDB <filename>
A CMS key database used to support the PKCS11 device. A PKCS11
device does not normally have a large amount of space available to
store a lot of signer certificates. The signer certificates are used for the
validation of certificates when they are added to the PCKS11 device.
-secondaryDBpw <password>
Password for the secondary CMS key database supporting the PKCS11
device.
-fips This disables the use of the BSafe cryptographic library. Only the ICC
component which must be successfully intialized in FIPS* mode will
be used. If the ICC component does not intialize in FIPS mode then the
gsk7capicmd operation will fail.
* When in FIPS mode the ICC component uses algorithms that have been FIPS 140-2
validated
Export a Certificate
The export command exports a single certificate specified by its label from either a
CMS or PKCS12 key database to another CMS or PKCS12 key database. During this
process no key generation occurs. On successful completion the identified certificate
will be in both the source and destination key databases.
The syntax to export a certificate from an existing key database to another key
database with GSKCapiCmd is as follows:
27
gsk7capicmd -cert -export -db <name> [-pw <passwd>] -label <label> [-type <cms |
pkcs12 >] -target <name> [-target_pw <passwd>] [-target_type <cms | pkcs12>] [-
encryption <strong | weak>] [-fips]
Where:
object -cert
action -export
options
IMPORTANT: On Unix type operating systems it is recommended to always
encapsulate string values associated with all tags in double quotes (“”). You
will also need to escape, using a ‘\’ character, the following characters if they
appear in the string values: ‘!’, ‘\’, ‘”’, ‘`’. This will prevent some command
line shells from interpreting specific characters within these values. (e.g.
gsk7capicmd –keydb –create –db “/tmp/key.kdb” –pw “j\!jj”). Note however
when prompted by gsk7capicmd for a value (for example a password) quoting
the string and adding the escape characters should not be done. This is because
the shell is no longer influencing this input.
-db <filename>
The fully qualified filename of a key database containing the certificate
to exported from. If the supplied filename has an extension of either
“.p12” or .pfx” then it is assumed that it is in PKCS12 format. If it is
“.p7”, “.smime” or “.eml” then it is assumed to be a pkcs7 encoding.
-pw <passwd>
The password for the key database identified by the –db or –tokenlabel
tags above.
-label <label>
Label attached to the certificate that is to be exported.
-type <cms | pkcs12>
The type of the key database to be exported from, default cms.
-target <name>
Destination key database or file that the certificate is to be exported to.
If the supplied filename has an extension of either “.p12” or .pfx” then
it is assumed that it is in PKCS12 format. If the target keystore does
not already exist it will be created.
-target_pw <passwd>
The password of the destination key database or file.
-target_type <cms | pkcs12>
The type of the destination key database or file to be exported to,
default cms.
-encryption <strong | weak>
28
The strength of encryption used during the export, default strong. This
tag is no longer used as the export restrictions in the USA have been
eased. This tag is simply added to this command line tool for backward
compatibility reasons; it has no effect on the operation, strong is
always used.
-fips This disables the use of the BSafe cryptographic library. Only the ICC
component which must be successfully intialized in FIPS* mode will
be used. If the ICC component does not intialize in FIPS mode then the
gsk7capicmd operation will fail.
* When in FIPS mode the ICC component uses algorithms that have been FIPS 140-2
validated
Receive a Certificate
The receive certificate command stores a certificate received from a CA that was
requested to sign a certificate request. The certificate being received can be in either
binary or Base64 encoded ascii. Additional information about base64 encoding can be
found in rfc2045 and rfc3548. The binary format is a binary dump of the DER
encoded certificate structure. For additional information refer to ITU-T Rec. X.690
(2002) | ISO/IEC 8825-1:2002. During the receiving of the certificate, the certificate
is matched to its corresponding certificate request. This certificate request is removed
from the key database as it is no longer needed.
If the certificate request is required after receiving the certificate, you will need to use
the recreate certificate request command that can be found in chapter four of this
manual.
The syntax for receiving a certificate to an existing key database with GSKCapiCmd
is as follows:
gsk7capicmd -cert -receive -file <name> [-format <ascii | binary>] { -db <name> | -
crypto <module name> -tokenlabel <token label>} [-pw <passwd>] [-default_cert
<yes | no>] [-fips]
Where:
object -cert
action -receive
options
IMPORTANT: On Unix type operating systems it is recommended to always
encapsulate string values associated with all tags in double quotes (“”). You
will also need to escape, using a ‘\’ character, the following characters if they
appear in the string values: ‘!’, ‘\’, ‘”’, ‘`’. This will prevent some command
line shells from interpreting specific characters within these values. (e.g.
gsk7capicmd –keydb –create –db “/tmp/key.kdb” –pw “j\!jj”). Note however
29
when prompted by gsk7capicmd for a value (for example a password) quoting
the string and adding the escape characters should not be done. This is because
the shell is no longer influencing this input.
-file <name>
The file name of the certificate that is to be received, this file can be
either binary or base64 encoded.
-db <filename>
The fully qualified path name of a key database.
-crypto <module name>
Indicates a PKCS11 cryptographic device operation, where <module
name> is the path to the module to manage the crypto device.
-tokenlabel <token label>
The PKCS11 cryptographic device token label.
-pw <passwd>
The password for the key database identified by the –db or –tokenlabel
tags above.
-default_cert <yes | no>
Sets the newly created certificate as the default certificate for the key
database. By default the newly created self-signed certificate is not set
as the default (no). A default certificate in a key database is used when
a specific certificate is not specified during the use of the key database.
-fips This disables the use of the BSafe cryptographic library. Only the ICC
component which must be successfully intialized in FIPS* mode will
be used. If the ICC component does not intialize in FIPS mode then the
gsk7capicmd operation will fail.
* When in FIPS mode the ICC component uses algorithms that have been FIPS 140-2
validated
Import a Certificate
The import command imports certificates from either a CMS or PKCS12 key database
to either a CMS, PCKS12 or PCKS11 key database. During this process no key
generation occurs. On successful completion the identified certificates will be in both
the source and destination key databases.
The syntax for importing a certificate from an existing key database to another key
database with GSKCapiCmd is as follows:
gsk7capicmd -cert -import -db <name> [-pw <passwd>] [-label <label>] [-type <cms
| pkcs12>] { -target <name> | -crypto <module name> -tokenlabel <token label>} [-
secondaryDB <filename> -secondaryDBpw <password>] [-target_pw <passwd>] [-
target_type <cms | pkcs11 | pkcs12>] [-new_label <label>] [-fips]
30
Where:
object -cert
action -import
options
IMPORTANT: On Unix type operating systems it is recommended to always
encapsulate string values associated with all tags in double quotes (“”). You
will also need to escape, using a ‘\’ character, the following characters if they
appear in the string values: ‘!’, ‘\’, ‘”’, ‘`’. This will prevent some command
line shells from interpreting specific characters within these values. (e.g.
gsk7capicmd –keydb –create –db “/tmp/key.kdb” –pw “j\!jj”). Note however
when prompted by gsk7capicmd for a value (for example a password) quoting
the string and adding the escape characters should not be done. This is because
the shell is no longer influencing this input.
-db <filename>
The fully qualified path name of a key database that contains the
certificate that is to be imported from. If the supplied filename has an
extension of either “.p12” or .pfx” then it is assumed that it is in
PKCS12 format. If it is “.p7”, “.smime” or “.eml” then it is assumed to
be a pkcs7 encoding.
-pw <passwd>
The password for the key database or PKCS11 cryptographic device
identified by either the -db or -crypto tags respectively.
-label <label>
Label attached to the certificate that is to be imported. If the label tag is
missing from the command line the operation will transfer all
certificates from the source key database to the target key database. If a
certificate in the source key database already exists in the target key
database that certificate is not imported.
-type <cms | pkcs11 | pkcs12>
The type of the key database to be imported from, default cms.
-target <name>
Destination key database to import the certificate into. If the supplied
filename has an extension of either “.p12” or .pfx” then it is assumed
that it is in PKCS12 format.
-crypto <module name>
Indicates a PKCS11 cryptographic device operation, where <module
name> is the path to the module to manage the crypto device.
-tokenlabel <token label>
The PKCS11 cryptographic device token label.
Deleted: OR¶
¶
gsk7capicmd -cert -import -file <name>
[-pw <passwd>] -label <label> [-type
<cms>] { -target <name> | -crypto
<module name> -tokenlabel <token
label>} [-secondaryDB <filename> -
secondaryDBpw <password>] [-
target_pw <passwd>] [-target_type <cms
| pkcs11 | pkcs12>] [-new_label <label>]
[-fips]¶
¶
Deleted: -file <filename>¶
The fully qualified path name of a
PKCS12 file that contains the certificate
that is to be imported from. ¶
¶
31
-secondaryDB <filename>
A CMS key database used to support the PKCS11 device. A PKCS11
device does not normally have a large amount of space available to
store a lot of signer certificates. The signer certificates are used for the
validation of certificates when they are added to the PCKS11 device.
-secondaryDBpw <password>
Password for the secondary CMS key database supporting the PKCS11
device.
-target_pw <passwd>
The password of the destination key database.
-target_type <cms | pkcs12>
The type of the destination key database to be imported to, default cms.
-new_label <label>
The label to be used in the destination key database to identify the
imported certificate.
-fips This disables the use of the BSafe cryptographic library. Only the ICC
component which must be successfully intialized in FIPS* mode will
be used. If the ICC component does not intialize in FIPS mode then the
gsk7capicmd operation will fail.
* When in FIPS mode the ICC component uses algorithms that have been FIPS 140-2
validated
Extract a Certificate
The extract certificate command simply extracts the certificate data from the key
database and places it into the identified file. If the file does not exist it will be
created. If the file already exists an error indicating this will be returned. The data will
be saved as either base64 encoding or binary.
The syntax to extract a certificate from an existing key database with GSKCapiCmd is
as follows:
gsk7capicmd -cert -extract {-db <name> | -crypto <module name> -tokenlabel <token
label>} -pw <passwd> -label <label> -target <name> [-format <ascii | binary>]
[-secondaryDB <filename> -secondaryDBpw <password>] [-fips]
Where:
object -cert
action -extract
options
32
IMPORTANT: On Unix type operating systems it is recommended to always
encapsulate string values associated with all tags in double quotes (“”). You
will also need to escape, using a ‘\’ character, the following characters if they
appear in the string values: ‘!’, ‘\’, ‘”’, ‘`’. This will prevent some command
line shells from interpreting specific characters within these values. (e.g.
gsk7capicmd –keydb –create –db “/tmp/key.kdb” –pw “j\!jj”). Note however
when prompted by gsk7capicmd for a value (for example a password) quoting
the string and adding the escape characters should not be done. This is because
the shell is no longer influencing this input.
-db <filename>
The fully qualified path name of a key database.
-crypto <module name>
Indicates a PKCS11 cryptographic device operation, where <module
name> is the path to the module to manage the crypto device.
-tokenlabel <token label>
The PKCS11 cryptographic device token label.
-pw <passwd>
The password for the key database identified by the –db or –tokenlabel
tags above.
-label <label>
Label attached to the certificate that is to be extracted.
-target <name>
Destination file that the certificate is to be extracted to.
-format <ascii | binary>
Format of a certificate. The default is Base64 encoded ascii, additional
information about base64 encoding can be found in rfc2045 and
rfc3548. The binary format is a binary dump of the DER encoded
certificate structure. For additional information refer to ITU-T Rec.
X.690 (2002) | ISO/IEC 8825-1:2002
-secondaryDB <filename>
A CMS key database used to support the PKCS11 device. A PKCS11
device does not normally have a large amount of space available to
store a lot of signer certificates. The signer certificates are used for the
validation of certificates when they are added to the PCKS11 device.
-secondaryDBpw <password>
Password for the secondary CMS key database supporting the PKCS11
device.
-fips This disables the use of the BSafe cryptographic library. Only the ICC
component which must be successfully intialized in FIPS* mode will
Deleted: key database or
Deleted: exported
33
be used. If the ICC component does not intialize in FIPS mode then the
gsk7capicmd operation will fail.
* When in FIPS mode the ICC component uses algorithms that have been FIPS 140-2
validated
List Details of Default Certificate
The list default certificate details simply lists the following details for the default
certificate of the identified key database:
• The label of the default certificate.
• The size of the key associated with the default certificate.
• The X509 version that the default certificate was created.
• The serial number for the default certificate.
• The issuer and subject distinguished names.
• The default certificates validity period.
• The fingerprint of the default certificate.
• The signature of the algorithm used during creation of the default
certificate.
• An indication of the default certificate’s trust status.
The syntax for listing the details for the default certificate in an existing key database
with GSKCapiCmd is as follows:
gsk7capicmd -cert -getdefault -db <name> [-pw <passwd>] [-fips]
Where:
object -cert
action -getdefault
options
IMPORTANT: On Unix type operating systems it is recommended to always
encapsulate string values associated with all tags in double quotes (“”). You
will also need to escape, using a ‘\’ character, the following characters if they
appear in the string values: ‘!’, ‘\’, ‘”’, ‘`’. This will prevent some command
line shells from interpreting specific characters within these values. (e.g.
gsk7capicmd –keydb –create –db “/tmp/key.kdb” –pw “j\!jj”). Note however
when prompted by gsk7capicmd for a value (for example a password) quoting
the string and adding the escape characters should not be done. This is because
the shell is no longer influencing this input.
-db <filename>
The fully qualified path name of a key database.
-pw <passwd>
34
The password for the key database identified by the –db tag above.
-fips This disables the use of the BSafe cryptographic library. Only the ICC
component which must be successfully intialized in FIPS* mode will
be used. If the ICC component does not intialize in FIPS mode then the
gsk7capicmd operation will fail.
* When in FIPS mode the ICC component uses algorithms that have been FIPS 140-2
validated
Set Default Certificate
The set default certificate command sets a certificate to be used as the default
certificate for the identified key database. During this command the current default
certificate, if there is one, has it’s default setting removed. The new certificate is then
set as the default certificate. There can only ever be one default certificate in a key
database.
The syntax for setting the default certificate in an existing key database with
GSKCapiCmd is as follows:
gsk7capicmd -cert -setdefault -db <name> [-pw <passwd>] -label <label> [-fips]
Where:
object -cert
action -setdefault
options
IMPORTANT: On Unix type operating systems it is recommended to always
encapsulate string values associated with all tags in double quotes (“”). You
will also need to escape, using a ‘\’ character, the following characters if they
appear in the string values: ‘!’, ‘\’, ‘”’, ‘`’. This will prevent some command
line shells from interpreting specific characters within these values. (e.g.
gsk7capicmd –keydb –create –db “/tmp/key.kdb” –pw “j\!jj”). Note however
when prompted by gsk7capicmd for a value (for example a password) quoting
the string and adding the escape characters should not be done. This is because
the shell is no longer influencing this input.
-db <filename>
The fully qualified path name of a key database.
-pw <passwd>
The password for the key database identified by the –db tag above.
-label <label>
35
Label that uniquely identifies the certificate that is to be set as the
default certificate in the identified key database.
-fips This disables the use of the BSafe cryptographic library. Only the ICC
component which must be successfully intialized in FIPS* mode will
be used. If the ICC component does not intialize in FIPS mode then the
gsk7capicmd operation will fail.
* When in FIPS mode the ICC component uses algorithms that have been FIPS 140-2
validated
List Certificates
The list certificate command lists all of the certificates store within the identified key
database. As an example the following certificate list is displayed for a new key
database created with the GSKCapiCmd program. The command used to create this
list is as follows: gsk7capicmd –cert –list –db <database name> [-pw <password>].
Certificates found:
* default, - has private key, ! trusted
Entrust.net Global Secure Server Certification Authority
Entrust.net Global Client Certification Authority
Entrust.net Client Certification Authority
Entrust.net Certification Authority (2048)
Entrust.net Secure Server Certification Authority
VeriSign Class 3 Public Primary Certification Authority
VeriSign Class 2 Public Primary Certification Authority
VeriSign Class 1 Public Primary Certification Authority
VeriSign Class 4 Public Primary Certification Authority - G2
VeriSign Class 3 Public Primary Certification Authority - G2
VeriSign Class 2 Public Primary Certification Authority - G2
VeriSign Class 1 Public Primary Certification Authority - G2
VeriSign Class 4 Public Primary Certification Authority - G3
VeriSign Class 3 Public Primary Certification Authority - G3
VeriSign Class 2 Public Primary Certification Authority - G3
VeriSign Class 1 Public Primary Certification Authority - G3
Thawte Personal Premium CA
Thawte Personal Freemail CA
Thawte Personal Basic CA
Thawte Premium Server CA
Thawte Server CA
RSA Secure Server Certification Authority
The default key is marked with the ‘*’ symbol and all trusted self-signed (root) certs
are listed with a ‘!’ symbol. The ‘-‘ symbol is used to show where a private key is
present.
The syntax to list the certificates in an existing key database with GSKCapiCmd is as
follows:
gsk7capicmd -cert -list [<all | personal | CA | site>] [-expiry [<number of days>] {-db
<name> | -crypto <module name> -tokenlabel <token label>}[-pw <passwd>]
[-type <cms | pkcs11>] [-secondaryDB <filename> -secondaryDBpw <password>]
[-fips]
Where:
36
object -cert
action -list
The list command has four special tags that can be associated with it. These
tags are used to identify what type of certificates you are requesting to be
displayed. The tags are not required, by default all certificate stored within the
key database will be displayed. The below lists all of the tags that can be
associated with the list command:
all - List the labels of all certificates in the identified key database, this is the
default for the list command.
personal - List all personal certificates in the identified key database.
CA – List all of the certificate authority (CA) certificates in the identified key
Database.
site – This tag will return error 228 as it is only added for backward
compatibility and potential future enhancements. It is not recommended
to use this tag.
options
IMPORTANT: On Unix type operating systems it is recommended to always
encapsulate string values associated with all tags in double quotes (“”). You
will also need to escape, using a ‘\’ character, the following characters if they
appear in the string values: ‘!’, ‘\’, ‘”’, ‘`’. This will prevent some command
line shells from interpreting specific characters within these values. (e.g.
gsk7capicmd –keydb –create –db “/tmp/key.kdb” –pw “j\!jj”). Note however
when prompted by gsk7capicmd for a value (for example a password) quoting
the string and adding the escape characters should not be done. This is because
the shell is no longer influencing this input.
-expiry <number of days>
The expiry tag identifies the number of days from today that a
certificate is valid for. If the certificates validity falls within this time it
is displayed. To list certificates that have already expired, enter the
value 0. If you do not specify this tag it is not applied during the
execution of the command.
-db <filename>
The fully qualified path name of a key database. If the supplied
filename has an extension of either “.p12” or .pfx” then it is assumed
that it is in PKCS12 format. If it is “.p7”, “.smime” or “.eml” then it is
assumed to be a pkcs7 encoding.
-crypto <module name>
Indicates a PKCS11 cryptographic device operation, where <module
name> is the path to the module to manage the crypto device.
37
-tokenlabel <token label>
The PKCS11 cryptographic device token label.
-pw <passwd>
The password for the key database identified by the –db or –tokenlabel
tags above.
-type <cms | pkcs11>
The type of the key database to be exported from, default cms.
-secondaryDB <filename>
A CMS key database used to support the PKCS11 device. A PKCS11
device does not normally have a large amount of space available to
store a lot of signer certificates. The signer certificates are used for the
validation of certificates when they are added to the PCKS11 device.
-secondaryDBpw <password>
Password for the secondary CMS key database supporting the PKCS11
device.
-fips This disables the use of the BSafe cryptographic library. Only the ICC
component which must be successfully intialized in FIPS* mode will
be used. If the ICC component does not intialize in FIPS mode then the
gsk7capicmd operation will fail.
* When in FIPS mode the ICC component uses algorithms that have been FIPS 140-2
validated
Modify Certificate
The modify certificate command allows a CA’s certificate trust status to be enabled or
disabled. When a CA’s certificate trust status is enabled then that CA certificate is
permitted to be involved in a certificate chain validation. If the CA’s certificate trust
status is disabled then it cannot be used to validate any certificates. For example if
certificate “ABC” is signed by the CA certificate “VeriSign CA” and “VeriSign CA”
is not marked as trusted the validation of “ABC” will fail. You are able to have any
number of trusted CA certificates in the single key database.
The syntax for modifying the trust status of a certificate in an existing key database
with GSKCapiCmd is as follows:
gsk7capicmd -cert -modify -db <name> [-pw <passwd>] -label <label> -trust <enable
| disable> [-fips]
Where:
object -cert
action -modify
38
options
IMPORTANT: On Unix type operating systems it is recommended to always
encapsulate string values associated with all tags in double quotes (“”). You
will also need to escape, using a ‘\’ character, the following characters if they
appear in the string values: ‘!’, ‘\’, ‘”’, ‘`’. This will prevent some command
line shells from interpreting specific characters within these values. (e.g.
gsk7capicmd –keydb –create –db “/tmp/key.kdb” –pw “j\!jj”). Note however
when prompted by gsk7capicmd for a value (for example a password) quoting
the string and adding the escape characters should not be done. This is because
the shell is no longer influencing this input.
-db <filename>
The fully qualified path name of a key database.
-pw <passwd>
The password for the key database identified by the –db tag above.
-label <label>
Label attached to the certificate.
-trust <enable | disable>
Trust status of a CA certificate, default is enabled. Trust status of a CA
certificate, default is enable. When a CA’s certificate trust status is
enabled then that CA certificate is permitted to be involved in a
certificate chain validation. If the CA’s certificate trust status is
disabled then it cannot be used to validate any certificates. For example
if certificate “ABC” is signed by the CA certificate “VeriSign CA” and
“VeriSign CA” is not marked as trusted the validation of “ABC” will
fail.
-fips This disables the use of the BSafe cryptographic library. Only the ICC
component which must be successfully intialized in FIPS* mode will
be used. If the ICC component does not intialize in FIPS mode then the
gsk7capicmd operation will fail.
* When in FIPS mode the ICC component uses algorithms that have been FIPS 140-2
validated
Sign a Certificate
The sign certificate command allows the signing of a certificate request by an existing
certificate stored within a key database. The command accepts a certificate request in
its file format and a label of a certificate stored within the key database that contains
the private key to be used during the signing process. If a certificate is not identified,
the private key of the default certificate in the key database is used during the signing
process.
The syntax for signing a certificate with GSKCapiCmd is as follows:
39
gsk7capicmd -cert -sign {-db <name> | -crypto <module name> -tokenlabel <label>}
[-pw <passwd>] -label <label> -target <name> [-format <ascii | binary>] [-expire
<number of days>] -file <name> [-secondaryDB <filename> -secondaryDBpw
<password>] [-fips] [-sigalg<md5 | sha1 | sha224 | sha256 | sha384 | sha512>] [-
sernum <serial number>]
Where:
object -cert
action -sign
options
IMPORTANT: On Unix type operating systems it is recommended to always
encapsulate string values associated with all tags in double quotes (“”). You
will also need to escape, using a ‘\’ character, the following characters if they
appear in the string values: ‘!’, ‘\’, ‘”’, ‘`’. This will prevent some command
line shells from interpreting specific characters within these values. (e.g.
gsk7capicmd –keydb –create –db “/tmp/key.kdb” –pw “j\!jj”). Note however
when prompted by gsk7capicmd for a value (for example a password) quoting
the string and adding the escape characters should not be done. This is because
the shell is no longer influencing this input.
-db <filename>
The fully qualified path name of a key database..
-crypto <module name>
Indicates a PKCS11 cryptographic device operation, where <module
name> is the path to the module to manage the crypto device.
-tokenlabel <token label>
The PKCS11 cryptographic device token label.
-pw <passwd>
The password for the key database identified by the –db tag above.
-label <label>
Label of the certificate that has the private key that should be used for
the signing operation.
-target <name>
The name of the file that will contain the signed certificate.
-format <acsii | binary>
The format of the signed certificate. The default is Base64 encoded
ascii, additional information about base64 encoding can be found in
rfc2045 and rfc3548. The binary format is a binary dump of the DER
encoded certificate structure. For additional information refer to ITU-T
Rec. X.690 (2002) | ISO/IEC 8825-1:2002
40
-expire <number of days2>
The expiry tag identifies the number of days from today that a
certificate is valid for, default is 365 days.
-file <name>
The name and location of the certificate request to be signed.
-secondaryDB <filename>
A CMS key database used to support the PKCS11 device. A PKCS11
device does not normally have a large amount of space available to
store a lot of signer certificates. The signer certificates are used for the
validation of certificates when they are added to the PCKS11 device.
-secondaryDBpw <password>
Password for the secondary CMS key database supporting the PKCS11
device.
-fips This disables the use of the BSafe cryptographic library. Only the ICC
component which must be successfully intialized in FIPS* mode will
be used. If the ICC component does not intialize in FIPS mode then the
gsk7capicmd operation will fail.
* When in FIPS mode the ICC component uses algorithms that have been FIPS 140-
2 validated
-sigalg<md5 | sha1 | sha224 | sha256 | sha384 | sha512>
The hashing algorithm to be used during the signing of the certificate.
This hashing algorithm is used to create the signature associated with
the newly created signed certificate.
-sernum
The serial number in conjunction with the issuers name uniquely
identifies a certificate. A serial number is normally assigned to a
certificate by the certificate authority (CA) that signed the certificate
request. This tag has been included to allow the emulation of this
process. The -sernum tag accepts two types of values:
1.) Hexidecimal - A hexadecimal value can be passed as the -sernum
tags value by perpending a “0x” to the front of the serial number.
2.) String - A string representation of the serial number. The string
representation of the serial number is normally displayed in ACSII
format.
If the –sernum tag is not passed a random serial number is assigned to
the signed certificate.
2 To avoid possible timezone issues the actual valid-from time for the certificate will be set one day in
the past.
41
Chapter 4. Certificate Request Commands
The certificate request commands are associated with the -certreq object. This object
supports the following actions:
• Create a certificate request in an existing key database (-create)
• Delete a certificate request from an existing key database (-delete)
• List the details of a certificate request in an existing key database (-details)
• Extract a certificate request from an existing key database (-extract)
• List the certificates requests stored in an existing key database (-list)
• Re-create the certificate request stored in an existing key database
(-recreate)
Each of the following sections goes into detail on how to use and what options are
available for each of the identified certificate request actions.
Create a Certificate Request
The create certificate request command creates a new RSA private-public key pair
and a PKCS10 certificate request in the specified key database. For CMS key
databases, the certificate request information is stored in the file with the “.rdb”
extension that is associated with the key database. During the creation process the
certificate request is also extract to a file that can be used to send the certificate
request to a CA for signing.
The syntax for creating a certificate request in an existing key database with
GSKCapiCmd is as follows:
gsk7capicmd -certreq -create {-db <name> | -crypto <module name> -tokenlabel
<token label>} [-pw <passwd>] -label <label> -dn <dist name> [-size <key size>] -
file <name> [-secondaryDB <filename> -secondaryDBpw <password>] [-fips] [-
sigalg<md5 | sha1 | sha224 | sha256 | sha384 | sha512>]
Where:
object -certreq
action -create
options
IMPORTANT: On Unix type operating systems it is recommended to always
encapsulate string values associated with all tags in double quotes (“”). You
will also need to escape, using a ‘\’ character, the following characters if they
appear in the string values: ‘!’, ‘\’, ‘”’, ‘`’. This will prevent some command
line shells from interpreting specific characters within these values. (e.g.
gsk7capicmd –keydb –create –db “/tmp/key.kdb” –pw “j\!jj”). Note however
when prompted by gsk7capicmd for a value (for example a password) quoting
42
the string and adding the escape characters should not be done. This is because
the shell is no longer influencing this input.
-db <filename>
The fully qualified path name of a key database.
-crypto <module name>
Indicates a PKCS11 cryptographic device operation, where <module
name> is the path to the module to manage the crypto device.
-tokenlabel <token label>
The PKCS11 cryptographic device token label.
-pw <passwd>
The password for the key database identified by the –db or –tokenlabel
tags above.
-label <label>
Label to be attached to the certificate request on creation. The user
uses this label to uniquely identify the certificate request.
-dn <distinct name>
The X.500 distinguished name that will uniquely identify the
certificate. The input needed to be a quoted string of the following
format (only CN is required):
CN=common name
O=organization
OU=organization unit
L=location
ST=state, province
C=country
DC=domain component
EMAIL=email address
For Example: “CN=weblinux.Raleigh.ibm.com,O=ibm,OU=IBM
HTTP Server,L=RTP,ST=NC,C=US”
Multiple OU are now supported. Simply add additional OU key\value
pairs to the specified distinguished name. If the OU value requires a
comma (‘,’) it will need to escape it with ‘\\’.
For Example: “CN=weblinux.Raleigh.ibm.com,O=ibm,OU=IBM
HTTP Server,OU=GSKit\\, Gold Coast,L=RTP,ST=NC,C=US”
-size <key size>
The size of the new key pair to be created. Key size from 512 to 4096,
default 1024.
-file <name>
The file name that the certificate request will be extracted to during the
certificate request creation process.
43
-secondaryDB <filename>
A CMS key database used to support the PKCS11 device. A PKCS11
device does not normally have a large amount of space available to
store a lot of signer certificates. The signer certificates are used for the
validation of certificates when they are added to the PCKS11 device.
-secondaryDBpw <password>
Password for the secondary CMS key database supporting the PKCS11
device.
-fips This disables the use of the BSafe cryptographic library. Only the ICC
component which must be successfully intialized in FIPS* mode will
be used. If the ICC component does not intialize in FIPS mode then the
gsk7capicmd operation will fail.
* When in FIPS mode the ICC component uses algorithms that have been FIPS 140-2
validated
-sigalg<md5 | sha1 | sha224 | sha256 | sha384 | sha512>
The hashing algorithm to be used during the creation of the certificate
request. This hashing algorithm is used to create the signature
associated with the newly created certificate request.
Delete Certificate Request
The delete certificate request removes the certificate request from the identified key
database. This means that the entry in the “.rdb” associated with the certificate request
is deleted.
The syntax for deleting a certificate request in an existing key database with
GSKCapiCmd is as follows:
gsk7capicmd -certreq -delete {-db <name> | -crypto <module name> -tokenlabel
<token label>} [-pw <passwd>] -label <label> [-secondaryDB <filename>
-secondaryDBpw <password>] [-fips]
Where:
object -certreq
action -delete
options
IMPORTANT: On Unix type operating systems it is recommended to always
encapsulate string values associated with all tags in double quotes (“”). You
will also need to escape, using a ‘\’ character, the following characters if they
appear in the string values: ‘!’, ‘\’, ‘”’, ‘`’. This will prevent some command
line shells from interpreting specific characters within these values. (e.g.
44
gsk7capicmd –keydb –create –db “/tmp/key.kdb” –pw “j\!jj”). Note however
when prompted by gsk7capicmd for a value (for example a password) quoting
the string and adding the escape characters should not be done. This is because
the shell is no longer influencing this input.
-db <filename>
The fully qualified path name of a key database.
-crypto <module name>
Indicates a PKCS11 cryptographic device operation, where <module
name> is the path to the module to manage the crypto device.
-tokenlabel <token label>
The PKCS11 cryptographic device token label.
-pw <passwd>
The password for the key database identified by the –db or –tokenlabel
tags above.
-label <label>
Label attached to the certificate request that is to be deleted.
-secondaryDB <filename>
A CMS key database used to support the PKCS11 device. A PKCS11
device does not normally have a large amount of space available to
store a lot of signer certificates. The signer certificates are used for the
validation of certificates when they are added to the PCKS11 device.
-secondaryDBpw <password>
Password for the secondary CMS key database supporting the PKCS11
device.
-fips This disables the use of the BSafe cryptographic library. Only the ICC
component which must be successfully intialized in FIPS* mode will
be used. If the ICC component does not intialize in FIPS mode then the
gsk7capicmd operation will fail.
* When in FIPS mode the ICC component uses algorithms that have been FIPS 140-2
validated
List Certificate Request Details
The list certificate request details command simple lists the identified certificate
requests details. These details include:
• The label of the certificate request.
• The size of the key associated with the certificate request.
• The subject distinguished name.
• The fingerprint of the certificate.
• The signature of the algorithm used during creation of the certificate.
45
For a more detailed listing of the certificate requests details please us the -showOID
option in the command.
The syntax for listing a certificate requests details in an existing key database with
GSKCapiCmd is as follows:
gsk7capicmd -certreq -details [-showOID] {-db <name> | -crypto <module name> -
tokenlabel <token label>} [-pw <passwd] -label <label> [-secondaryDB <filename> -
secondaryDBpw <password>] [-fips]
Where:
object -certreq
action -details
options
IMPORTANT: On Unix type operating systems it is recommended to always
encapsulate string values associated with all tags in double quotes (“”). You
will also need to escape, using a ‘\’ character, the following characters if they
appear in the string values: ‘!’, ‘\’, ‘”’, ‘`’. This will prevent some command
line shells from interpreting specific characters within these values. (e.g.
gsk7capicmd –keydb –create –db “/tmp/key.kdb” –pw “j\!jj”). Note however
when prompted by gsk7capicmd for a value (for example a password) quoting
the string and adding the escape characters should not be done. This is because
the shell is no longer influencing this input.
-showOID
Display a more in depth listing of the certificate.
-db <filename>
The fully qualified path name of a key database.
-crypto <module name>
Indicates a PKCS11 cryptographic device operation, where <module
name> is the path to the module to manage the crypto device.
-tokenlabel <token label>
The PKCS11 cryptographic device token label.
-pw <passwd>
The password for the key database identified by the –db or –tokenlabel
tags above.
-label <label>
Label attached to the certificate request that is to be displayed.
-secondaryDB <filename>
A CMS key database used to support the PKCS11 device. A PKCS11
device does not normally have a large amount of space available to
46
store a lot of signer certificates. The signer certificates are used for the
validation of certificates when they are added to the PCKS11 device.
-secondaryDBpw <password>
Password for the secondary CMS key database supporting the PKCS11
device.
-fips This disables the use of the BSafe cryptographic library. Only the ICC
component which must be successfully intialized in FIPS* mode will
be used. If the ICC component does not intialize in FIPS mode then the
gsk7capicmd operation will fail.
* When in FIPS mode the ICC component uses algorithms that have been FIPS 140-2
validated
Extract Certificate Request
The extract certificate request command extracts an existing certificate request stored
in the specified key database to the identified file in base64 format. The certificate
request will still exist within the key database so you are able to extract it as many
times as needed. The file that is extracted is the file that is dispatched to a CA for
signing.
The syntax for extracting a certificate request from an existing key database with
GSKCapiCmd is as follows:
gsk7capicmd -certreq -extract {-db <name> | -crypto <module name> -tokenlabel
<token label>} [-pw <passwd>] -label <label> -target <name> [-secondaryDB
<filename> -secondaryDBpw <password>] [-fips]
Where:
object -certreq
action -extract
options
IMPORTANT: On Unix type operating systems it is recommended to always
encapsulate string values associated with all tags in double quotes (“”). You
will also need to escape, using a ‘\’ character, the following characters if they
appear in the string values: ‘!’, ‘\’, ‘”’, ‘`’. This will prevent some command
line shells from interpreting specific characters within these values. (e.g.
gsk7capicmd –keydb –create –db “/tmp/key.kdb” –pw “j\!jj”). Note however
when prompted by gsk7capicmd for a value (for example a password) quoting
the string and adding the escape characters should not be done. This is because
the shell is no longer influencing this input.
-db <filename>
The fully qualified path name of a key database.
47
-crypto <module name>
Indicates a PKCS11 cryptographic device operation, where <module
name> is the path to the module to manage the crypto device.
-tokenlabel <token label>
The PKCS11 cryptographic device token label.
-pw <passwd>
The password for the key database identified by the –db or –tokenlabel
tags above.
-label <label>
Label attached to the certificate request that is to be extracted.
-target <name>
Destination file that the certificate request is to be extracted to.
-secondaryDB <filename>
A CMS key database used to support the PKCS11 device. A PKCS11
device does not normally have a large amount of space available to
store a lot of signer certificates. The signer certificates are used for the
validation of certificates when they are added to the PCKS11 device.
-secondaryDBpw <password>
Password for the secondary CMS key database supporting the PKCS11
device.
-fips This disables the use of the BSafe cryptographic library. Only the ICC
component which must be successfully intialized in FIPS* mode will
be used. If the ICC component does not intialize in FIPS mode then the
gsk7capicmd operation will fail.
* When in FIPS mode the ICC component uses algorithms that have been FIPS 140-2
validated
List all Certificate Requests
The list certificate request command lists all of the certificate request labels stored
within the identified key database.
The syntax for listing the certificate requests stored within an existing key database
with GSKCapiCmd is as follows:
gsk7capicmd -certreq -list { -db <name> | -crypto <module name> -tokenlabel
<token label>} [-pw <passwd>] [-secondaryDB <filename> -secondaryDBpw
<password>] [-fips]
Where:
48
object -certreq
action -list
options
IMPORTANT: On Unix type operating systems it is recommended to always
encapsulate string values associated with all tags in double quotes (“”). You
will also need to escape, using a ‘\’ character, the following characters if they
appear in the string values: ‘!’, ‘\’, ‘”’, ‘`’. This will prevent some command
line shells from interpreting specific characters within these values. (e.g.
gsk7capicmd –keydb –create –db “/tmp/key.kdb” –pw “j\!jj”). Note however
when prompted by gsk7capicmd for a value (for example a password) quoting
the string and adding the escape characters should not be done. This is because
the shell is no longer influencing this input.
-db <filename>
The fully qualified path name of a key database.
-crypto <module name>
Indicates a PKCS11 cryptographic device operation, where <module
name> is the path to the module to manage the crypto device.
-tokenlabel <token label>
The PKCS11 cryptographic device token label.
-pw <passwd>
The password for the key database identified by the –db tag or the
-crypto tag above.
-secondaryDB <filename>
A CMS key database used to support the PKCS11 device. A PKCS11
device does not normally have a large amount of space available to
store a lot of signer certificates. The signer certificates are used for the
validation of certificates when they are added to the PCKS11 device.
-secondaryDBpw <password>
Password for the secondary CMS key database supporting the PKCS11
device.
-fips This disables the use of the BSafe cryptographic library. Only the ICC
component which must be successfully intialized in FIPS* mode will
be used. If the ICC component does not intialize in FIPS mode then the
gsk7capicmd operation will fail.
* When in FIPS mode the ICC component uses algorithms that have been FIPS 140-2
validated
Re-create Certificates Requests
49
The re-create certificate request command recreates a certificate request from an
existing certificate stored within the specified key database. The recreation of a
certificate may be required to allow a certificate to be signed by another CA in case
there was a problem with the CA that originally signed it.
The syntax to recreate a certificate request in an existing key database with
GSKCapiCmd is as follows:
gsk7capicmd -certreq -recreate { -db <name> | -crypto <module name> -tokenlabel
<token label>} [-pw <passwd>] -label <label> -target <name> [-secondaryDB
<filename> -secondaryDBpw <password>] [-fips]
Where:
object -certreq
action -recreate
options
IMPORTANT: On Unix type operating systems it is recommended to always
encapsulate string values associated with all tags in double quotes (“”). You
will also need to escape, using a ‘\’ character, the following characters if they
appear in the string values: ‘!’, ‘\’, ‘”’, ‘`’. This will prevent some command
line shells from interpreting specific characters within these values. (e.g.
gsk7capicmd –keydb –create –db “/tmp/key.kdb” –pw “j\!jj”). Note however
when prompted by gsk7capicmd for a value (for example a password) quoting
the string and adding the escape characters should not be done. This is because
the shell is no longer influencing this input.
-db <filename>
The fully qualified path name of a key database.
-crypto <module name>
Indicates a PKCS11 cryptographic device operation, where <module
name> is the path to the module to manage the crypto device.
-tokenlabel <token label>
The PKCS11 cryptographic device token label.
-pw <passwd>
The password for the key database identified by the –db tag or the
-crypto tag above.
-label <label>
Label attached to the certificate request that is to be recreated.
-target <name>
Destination file that the certificate request is to be recreated to.
-secondaryDB <filename>
50
A CMS key database used to support the PKCS11 device. A PKCS11
device does not normally have a large amount of space available to
store a lot of signer certificates. The signer certificates are used for the
validation of certificates when they are added to the PCKS11 device.
-secondaryDBpw <password>
Password for the secondary CMS key database supporting the PKCS11
device.
-fips This disables the use of the BSafe cryptographic library. Only the ICC
component which must be successfully intialized in FIPS* mode will
be used. If the ICC component does not intialize in FIPS mode then the
gsk7capicmd operation will fail.
* When in FIPS mode the ICC component uses algorithms that have been FIPS 140-2
validated
51
Chapter 5. Random Password Generation
The GSKCapiCmd program provides its users with the ability to generate random
passwords. Users are able to specify the password length and if the generated
password is required to conform to GSKit’s minimum password requirements.
The random commands are associated with the -random object. This object supports
the following actions:
• Create a random password of a specified length. (-create)
The following section goes into detail on how to use and what options are available
for each of the identified random actions.
Create a Random Password
The create random password command creates a random string of characters that can
be used with other GSKCapiCmd commands that require a password. This command
should be used if the user is looking for a truly random password.
The syntax for creating a random password with GSKCapiCmd is as follows:
gsk7capicmd -random -create -length <password length> -strong -fips
Where:
object -random
action -create
options
-length <password length>
The length of the random password. There is a maximum length when
the -strong tag is used for this command. The maximum length is 125
character.
-strong Check that the password entered satisfies the minimum requirements
for the passwords strength. The minimum requirements for a password
are as follows:
• The minimum password length is 14 characters.
• A password needs to have at least one lower case character, one upper case
character, and one digit or special character ( eg. *$#% etc, a space is
classified as special characters).
• Each character should not occur more than three times in a password.
• No more than two consecutive characters of the password should be
identical.
52
• All characters mentioned above are in the standard ASCII printable character
set within the range from 0x20 to 0x7E inclusive.
-fips This disables the use of the BSafe cryptographic library. Only the ICC
component which must be successfully intialized in FIPS* mode will
be used. If the ICC component does not intialize in FIPS mode then the
gsk7capicmd operation will fail.
* When in FIPS mode the ICC component uses algorithms that have been FIPS 140-2
validated
53
Chapter 6. Help Commands
GSKCapiCmd has an extensive help command system. You are able to get help on
what objects are available, what actions are associated with a particular object, and
help on how to use each of the actions.
The help commands are associated with the -help object. The syntax for the help
commands is as follows:
gsk7capicmd -help <object> <action>
Where:
<object> The object you want to find out information on.
<action> The action you are wanting to find out information on. This action
must be associated with the identified object. If it is not the system will
display the help associated with the requested object.
Examples:
Listing all of the objects and their associated actions.
gsk7capicmd -help
Listing the actions for the -keybd object:
gsk7capicmd -help -keydb
Listing the specific help for the -create action associated with the -keydb object.
gsk7capicmd -help -keydb -create
To find out the different objects and their associated actions please refer to chapters 2,
3 and 4 of this manual.
54
Chapter 7. Version Commands
The version command simply displays version information associated with the
currently installed GSKCapiCmd program.
The version command is associated with the -version object. The syntax is as follows:
gsk7capicmd -version
The version command has no associated actions or objects.
55
Chapter 8. Error Codes and Messages
GSKCapiCmd, returns GSKKM_OK (0) on success or a positive number indicting
the error that has occurred. The following table lists all of the error codes and their
associated error messages.
Error Code Error Message
1 Unknown error occurred
2 An asn.1 encoding/decoding error occurred.
3 An error occurred while initializing asn.1 encoder/decoder.
4 An asn.1 encoding/decoding error occurred because of an out-of-
range index or non-existent optional field.
5 A database error occurred.
6 An error occurred while opening the database file, check for file
existence and permission.
7 An error occurred while re-opening the database file.
8 Database creation failed.
9 The database already exists.
10 An error occurred while deleting the database file.
11 The database could not be opened.
12 An error occurred while reading the database file.
13 An error occurred while writing data to the database file.
14 A database validation error occurred.
15 An invalid database version was encountered.
16 An invalid database password was encountered.
17 An invalid database file type was encountered.
18 The specified database has been corrupted.
19 An invalid password was provided or the key database has been
tampered or corrupted.
20 A database key entry integrity error occurred.
21 A duplicate certificate already exists in the database.
22 A duplicate key already exists in the database (Record ID).
23 A certificate with the same label already existed in the key database.
24 A duplicate key already exists in the database (Signature).
25 A duplicate key already exists in the database (Unsigned Certificate).
26 A duplicate key already exists in the database (Issuer and Serial
Number).
27 A duplicate key already exists in the database (Subject Public Key
Info).
28 A duplicate key already exists in the database (Unsigned CRL).
29 The label has been used in the database.
30 A password encryption error occurred.
56
31 A LDAP related error occurred. (LDAP is not supported by this
program)
32 A cryptographic error occurred.
33 An encryption/decryption error occurred.
34 An invalid cryptographic algorithm was found.
35 An error occurred while signing data.
36 An error occurred while verifying data.
37 An error occurred while computing digest of data.
38 An invalid cryptographic parameter was found.
39 An unsupported cryptographic algorithm was encountered.
40 The specified input size is greater than the supported modulus size.
41 An unsupported modulus size was found.
42 A database validation error occurred.
43 Key entry validation failed.
44 A duplicate extension field exists.
45 The version of the key is wrong.
46 A required extension field does not exist.
47 The validity period does not include today or does not fall within its
issuer's validity period.
48 The validity period does not include today or does not fall within its
issuer's validity period.
49 An error occurred while validating validity private key usage
extension.
50 The issuer of the key was not found.
51 A required certificate extension is missing.
52 An invalid basic constraint extension was found.
53 The key signature validation failed.
54 The root key of the key is not trusted.
55 The key has been revoked.
56 An error occurred while validating authority key identifier extension.
57 An error occurred while validating private key usage extension.
58 An error occurred while validating subject alternative name extension.
59 An error occurred while validating issuer alternative name extension.
60 An error occurred while validating key usage extension.
61 An unknown critical extension was found.
62 An error occurred while validating key pair entries.
63 An error occurred while validating CRL.
64 A mutex error occurred.
65 An invalid parameter was found.
66 A null parameter or memory allocation error was encountered.
67 Number or size is too large or too small.
68 The old password is invalid.
57
69 The new password is invalid.
70 The password has expired.
71 A thread related error occurred.
72 An error occurred while creating threads.
73 An error occurred while a thread was waiting to exit.
74 An I/O error occurred.
75 An error occurred while loading CMS.
76 A cryptography hardware related error occurred.
77 The library initialization routine was not successfully called.
78 The internal database handle table is corrupted.
79 A memory allocation error occurred.
80 An unrecognized option was found.
81 An error occurred while getting time information.
82 Mutex creation error occurred.
83 An error occurred while opening message catalog.
84 An error occurred while opening error message catalog.
85 An null file name was found.
86 An error occurred while opening files, check for file existence and
permissions.
87 An error occurred while opening files to read.
88 An error occurred while opening files to write.
89 There is no such file.
90 The file cannot be opened because of its permission setting.
91 An error occurred while writing data to files.
92 An error occurred while deleting files.
93 Invalid Base64-encoded data was found.
94 An invalid Base64 message type was found.
95 An error occurred while encoding data with Base64 encoding rule.
96 An error occurred while decoding Base64-encoded data.
97 An error occurred while getting a distinguished name tag.
98 The required common name field is empty.
99 The required country or region name field is empty.
100 An invalid database handle was found.
101 The key database does not exist.
102 The request key pair database does not exist.
103 The password file does not exist.
104 The new password is identical to the old one.
105 No key was found in the key database.
106 No request key was found.
107 No trusted CA was found
108 No request key was found for the certificate.
109 There is no private key in the key database
58
110 There is no default key in the key database.
111 There is no private key in the key record.
112 There is no certificate in the key record.
113 There is no CRL entry.
114 An invalid key database file name was found.
115 An unrecognized private key type was found.
116 An invalid distinguished name input was found.
117 No key entry was found that has the specified key label.
118 The key label list has been corrupted.
119 The input data is not valid PKCS12 data.
120 The password is invalid or the PKCS12 data has been corrupted or
been created with later version of PKCS12.
121 An unrecognized key export type was found.
122 An unsupported password-based encryption algorithm was found.
123 An error occurred while converting the key ring file to a CMS key
database.
124 An error occurred while converting the CMS key database to a key
ring file.
125 An error occurred while creating a certificate for the certificate
request.
126 A complete issuer chain cannot be built.
127 Invalid WEBDB data was found.
128 There is no data to be written to the key ring file.
129 The number of days that you entered extends beyond the permitted
validity period.
130 The password is too short; it must consist of at least {0} characters.
131 A password must contain at least one numeric digit.
132 All characters in the password are either alphabetic or numeric
characters.
133 An unrecognized or unsupported signature algorithm was specified.
134 An invalid database type was encountered.
135 The specified secondary key database is in use by another PKCS#11
device.
136 No secondary key database was specified.
137 The label does not exist on the PKCS#11 device.
138 Password required to access the PKCS#11 device.
139 Password not required to access the PKCS#11 device.
140 Unable to load the cryptographic library.
141 PKCS#11 is not supported for this operation.
142 An operation on a PKCS#11 device has failed.
143 The LDAP user is not a valid user. (LDAP is not supported by this
program)
144 The LDAP user is not a valid user. (LDAP is not supported by this
59
program)
145 The LDAP query failed. (LDAP is not supported by this program)
146 An invalid certificate chain was found.
147 The root certificate is not trusted.
148 A revoked certificate was encountered.
149 A cryptographic object function failed.
150 There is no certificate revocation list data source available.
151 There is no cryptographic token available.
152 FIPS mode is not available.
153 There is a conflict with the FIPS mode settings.
154 The password entered does not meet the minimum required strength.
200 There was a failure during initialization of the program.
201 Tokenization of the arguments passed to the GSKCapiCmd Program
failed.
202 The object identified in the command is not a recognised object.
203 The action passed is not a known -keydb action.
204 The action passed is not a known -cert action.
205 The action passed is not a known -certreq action.
206 There is a tag missing for the requested command.
207 The value passed with the –version tag is not a recognised value.
208 The value passed with the –size tag is nota recognised value.
209 The value passed in with the –dn tag is not in the correct format.
210 The value passed in with the –format tag is not a recognised value.
211 There was an error associated with opening the file.
212 PKCS12 is not supported at this stage.
213 The cryptographic token you are trying to change the password for is
not password protected.
214 PKCS12 is not supported at this stage.
215 The password entered does not meet the minimum required strength.
216 FIPS mode is not available.
217 The number of days you have entered as the expiry date is out of the
allowed range.
218 Password strength failed the minimum requirements.
219 No Default certificate was found in the requested key database.
220 An invalid trust status was encountered.
221 An unsupported signature algorithm was encountered. At this stage
only MD5 and SHA1 are supported.
222 PCKS11 not supported for that particular operation.
223 The action passed is not a known –random action.
224 A length than less than zero is not allowed.
225 When using the –strong tag the minimum length password is 14
characters.
226 When using the –strong tag the maximum length password is 300
60
characters.
227 The MD5 algorithm is not supported when in FIPS mode.
228 The site tag is not supported for the –cert –list command. This
attribute is simply added for backward compatibility and potential
future enhancement.
229 The value associated with the -ca tag is not recognised. The value
must be either ‘true’ or ‘false’.
230 The value passed in with the –type tag is not valid.
231 The value passed in with the –expire tag is below the allowed range.
232 The encryption algorithm used or requested is not supported.
233 The target already exists.
61
Appendix 1. CMS Key Database
What is a CMS Key Database?
CMS is the native GSKit key database (keystore) containing X.509 certificates,
certificate requests (ones pending signing by an authority), and private keys for those
certificates should they have them. Typically only personal certificates contain private
keys. Should a certificate have an associated private key it is stored encrypted in the
keystore with its associated certificate. Private keys cannot be stored without an
associated certificate.
How is one organized?
A cms keystore consists of a file with extension .kdb and possibly two other files with
extension .rdb and .crl respectively.
A key record in a .kdb file is either a certificate or a certificate along with its
encrypted private key information. Private keys cannot be stored in a CMS keystore
without a corresponding certificate.
When a certificate request is created, a .rdb file with the same file stem as the key
database file is created to store the requested key pair along with the PKCS#10
certificate request data. Only when a signed certificate is obtained from a signing
authority and received into the key database (the signed certificate is matched up with
the private key in the .rdb file and together they are added to the .kdb file as a
certificate and its private key information), the request entry is deleted from the
request key database.
A .crl file is created for legacy reasons (in the past it contained CRLs) and is no
longer used. This file is always empty.
How is it protected?
GSKit implements password protection for access control, confidentiality, and
integrity of the CMS key database; the password must be provided prior to any access
to the keystore database.
The access control does not limit unauthorized users from reading and writing the file,
GSKit relies on the OS for these protections, but because all sensitive data in the
keystore is encrypted, all records hashed and the index to all records hashed, access to
sensitive data is effectively controlled and any modification to the file is detectable.
Should tampering be detected GSKit will not allow access to the keystore similarly as
if the incorrect password had been given.
What can I put in a cms key database?
The CMS keystore contains X.509 certificates along with their private key
information should they have any. For example when using the GSKCapiCmd tool to
62
maintain a cms keystore the following items may typically end up in the cms
keystore:
CA Certificates. Each valid X.509 certificate needs to be signed. Typically this
is done by a trusted Certificate Authority (CA). In order to validate a
certificate signed by a CA that CA’s public certificate must be in the cms
keystore. The GSKCapiCmd tool automatically populates a new cms keystore
with a number of CA certificates. Should the cms keystore not already contain
a required CA certificate an administrator would typically use GSKCapiCmd
to add it . Any valid X.509 certificate can be imported into a cms keystore. In
order for the import or add operation to succeed the incoming certificate will
be validated. For this reason the certificate needed for the validation chain
must be in the keystore already.
Intermediate Certificates. A valid certificate does not necessarily need to be
signed by a CA. Instead it can be signed by what is known as an intermediate
certificate that has itself be signed by a CA. If this is the case then both the CA
certificate and the intermediate certificate must be in the cms keystore in order
to validate that certificate. This is known as a certificate validation chain. An
administrator would typically use GSKCapiCmd to add their intermediate
certificate. Intermediate certificates are treated the same as a CA certificate by
the keystore.
Personal Certificates: In a client-server relationship the server may ask the
client for its certificate. When acting as a client GSKit will attempt to use a
personal certificate from the keystore to present to the server. Typically GSKit
will pick the certificate that is marked as the default or the one otherwise
indicated by the client application. Another use of a personal certificate is for
signing other certificates. For example an Intermediate certificate together
with its private key may be in a cms keystore and used to sign other
certificates. An extracted version (without the private key) of the intermediate
certificate would then be added to other cms keystores to be used in a
validation chain. An administrator would typically use GSKCapiCmd to add
and extract their personal certificate(s). The final use for a personal certificate
is for a server application. A personal certificate may be presented to the client
by the server duing a SSL handshake.
GSKCapiCmd supports two certificate transfer formats (eg. for add, import, extract,
etc). These are refered to as ascii and binary thougout this document. The default is
Base64 encoded ascii. Additional information about base64 encoding can be found in
rfc2045 and rfc3548. The binary format is a binary dump of the DER encoded
certificate structure. For additional information refer to ITU-T Rec. X.690 (2002) |
ISO/IEC 8825-1:2002
What is a label?
A label is a friendly name that an administrator can attached to a certificate contained
in a CMS keystore. It is simply a convenient human readable way to reference a
certificate.
63
How can I manipulate certificates in a cms keystore?
Certificates in a CMS keystore are standard X.509 certificates. X.509 entities can be
imported (for personal certificates), added (for a certificate needed in a validation
chain such as a CA or intermediate certificate), exported (from one CMS keystore to
another. This takes the private key with it if one exists), and extracted (extract the
public certificate – the private key is not extracted). Note that as GSKCapiCmd does
not support PKCS#12 the private key component of a certificate cannot be extracted,
only exported into another CMS keystore (along with the certificate itself).
An administrator can also change trust status of a certificate. When a certificate’s trust
status is enabled that certificate is permitted to be involved in a certificate chain
validation. If the certificate’s trust status is disabled then it cannot be used to validate
any other certificates. For example if certificate “ABC” is signed by the CA certificate
“VeriSign CA” and “VeriSign CA” is not marked as trusted the validation of “ABC”
will fail.
64
Appendix 2. A Simple Example
The example below offers an example scenario for a company setting up a website for
its employees to access business sensitive information. It is assumed that the web
server chosen by the company uses GSKit as it’s SSL provider. The example does not
cover all issues for such a scenario but instead concentrates on what an administrator
would typically need to do to set up a cms keystore in such an environment.
The requirement
The ACME company wishes to set up a website for it’s employees to access certain
sensitive business information across a wide geographical area. Some employees are
more senior than others and therefore will be allowed access to more resources on the
server than the more junior employees. It is expected that employees can be assured
they are connecting to their company website and not some fraudulent site pretending
to be their company site. Employees use a customized web browser that can read
CMS keystores to access certificates contained in them.
The CEO of ACME has asked the system administrator to implement this system in a
manner that is secure and cost conscious.
Considerations for the administrator
The administrator makes some decisions based on the requirements:
• As the employees are located at different geographical locations a secure
channel for the web traffic must be used. The administrator decides that this
should be SSL.
• As employees will have different levels of access to web content the
administrator decides that the server will operate in client authentication mode
where each connecting client must present a valid certificate in order to gain
access. Information from this presented certificate will be used to limit access
to authorized areas of the web server only (this is outside the scope of this
scenario)
• As cost is an issue the administrator decides that it is too costly to have every
employee certificate signed by a CA. The administrator decides to make use of
a company wide intermediate certificate that will then be used to sign all
employee certificates.
• Employees must be able to validate the server’s certificate thereby proving the
authenticity of the web server.
• The administrator notes that it is bad practice to use a certificate for more than
one purpose so decides that another certificate must be produced and signed
by the CA. This certificate will be the server certificate used for the website.
Using the Intermediate Certificate for this purpose would be poor practice.
Step 1 – Obtain a company wide Intermediate Certificate
The administrator needs to create a certificate that can be used to sign each
employee’s certificate. This intermediate certificate itself may be publically published
65
so it needs to be signed by a trusted CA. To achieve this, the administrator performs
the following actions:
1. The administrator creates a new cms keystore using the “Create a Key Database”
command:
gsk7capicmd -keydb -create -db acme.kdb -pw offs64b -expire 365 -fips
2. The administrator notices that the new keystore, while containing a number of CA
certificates, does not contain the certificate of the CA he would like to use to sign
his Intermediate Certificate. He obtains the CA certificate (this is usually done by
visiting a well know site that publishes these) and adds it to his cms keystore via
the “Add a Certificate” command:
gsk7capicmd -cert -add -db acme.kdb -pw offs64b -label OurCA -file CACert.arm
-format ascii -fips
3. The administrator then creates a new certificate request to be sent to the CA that
he has chosen to sign our Intermediate Certificate using the “Create a Certificate
Request” command:
gsk7capicmd -certreq -create -db acme.kdb –pw offs64b -label OurIntermediate -
dn “CN=acme.com,O=acme,C=US” -file certreq.arm -fips -sigalg sha1
4. The administrator takes the request file (certreq.arm in this case) and sends it to
the CA for signing. Sometime later the signed certificate is returned by the CA.
The administrator then receives the certificate into the cms keystore using the
“Receive a Certificate” command:
gsk7capicmd -cert -receive -file signedCert.arm -db acme.kdb -pw offs64b -fips
5. Make the new certificate the default one. This means that it will be used by default
to sign other certificate request if no other certificate lable is given. The
administrator makes it the default certificate using the following command:
gsk7capicmd -cert -setdefault -db acme.kdb -pw offs64b -label OurIntermediate -
fips
Step 2 – Sign all employee certificates using the ACME Intermediate
The administrator now has a cms keystore containing ACME’s intermediate
certificate and the CA certificate that signed that intermediate certificate. The
administrator now needs to use ACME’s intermediate certificate to sign all the
employee certificates. To achieve this, the administrator performs the following
actions:
1. The administrator asks each employee to obtain the CA certificate and add it to
their respective cms keystores. Note that employees may first need to create their
66
own cms keystore in the same manner as the administrator did in item 1 of step 1.
The employee adds the CA certificate using the “Add a Certificate” command:
gsk7capicmd -cert -add -db Dave.kdb -pw Davepwd -label OurCA -file
CACert.arm -format ascii -fips
2. The administrator extracts the Intermediate Certificate (note that this does not
extract the private key of the certificate) using the “Extract a Certificate”
command:
gsk7capicmd -cert -extract -db acme.kdb -pw offs64b -label acmeCert -target
acmeCert.arm -fips
3. The administrator sends the ACME intermediate certificate to each employee
asking them to add it to their keystore. Employees do this via the “Add a
Certificate” command:
gsk7capicmd -cert -add -db Dave.kdb -pw Davepwd -label acmeCert -file
acmeCert.arm –format ascii –fips
4. The administrator asks each employee to create a certificate request putting their
employee email address in the CN field. The employees use the “Create a
Certificate Request” command:
gsk7capicmd -certreq -create -db Dave.kdb –pw Davepwd -label myCert -dn
“CN=dave@acme.com,O=acme,C=US” -file DavesCertReq.arm -fips -sigalg
sha1
5. Upon receipt of each employee’s certificate request the administrator signs it and
returns the signed certificate to the employee. The administrator uses the “Sign a
Certificate” command to achieve this:
gsk7capicmd -cert -sign -db acme.kdb -pw offs64b -label acmeCert -target
DavesCertReq.arm -expire 365 -file DavesSignedCert.arm -fips -sigalg sha1
6. As each employee obtains their signed certificate they receive it into their cms
keystore. Employees use the “Receive a Certificate” command:
gsk7capicmd -cert -receive -file DavesSignedCert.arm -db Dave.kdb -pw
Davepwd -fips
7. Make the new certificate the default one. This means that it will be the certificate
sent to the web server when it requests one via SSL for client authentication
purposes. The employee makes it the default certificate using the following
command:
gsk7capicmd -cert -setdefault -db Dave.kdb -pw Davepwd -label myCert -fips
Step 3. Create the web Server certificate
At this stage the administrator has a cms database containing the CA certificate and
the ACME Intermediate certificate (with it’s corresponding private key). The
67
administrator puts this cms keystore in a safe place using it only to sign new
employee certificates.
Each employee has a cms keystore containing the CA certificate, the ACME
Intermediate Certificate (minus the corresponding private key), and their own
certificate that has been signed by the ACME Intermediate Certificate.
The remaining task for the administrator is to create a cms keystore with a certificate
to be used by the web server. Although the administrator could have used the ACME
Intermediate Certificate for this purpose as stated previously it is considered bad
practice to use a certificate for more than one purpose. The intermediate certificate is
already being used to sign employees certificates. To create a keystore and server
certificate the administrator performs the following actions:
1. The administrator creates a new cms keystore using the “Create a Key Database”
command:
gsk7capicmd -keydb -create -db acmeWebServer.kdb -pw ejed43dA -expire 365 -
fips
2. The administrator adds the CA certificate to the keystore using the “Add a
Certificate command:
gsk7capicmd -cert -add -db acmeWebServer.kdb -pw ejed43dA -label OurCA -
file CACert.arm –format ascii -fips
3. The administrator creates a new certificate request to be sent to the CA that he has
chosen to sign our web server certificate using the “Create a Certificate Request”
command:
gsk7capicmd -certreq -create -db acmeWebServer.kdb –pw ejed43dA -label
OurServerCert -dn “CN=web.acme.com,O=acme,C=US” -file serverCertReq.arm
-fips -sigalg sha1
4. The administrator takes the request file (serverCertReq.arm in this case) and sends
it to the CA for signing. Sometime later the signed certificate is returned by the
CA. The administrator then receives the certificate into the cms keystore using the
“Receive a Certificate command:
gsk7capicmd -cert -receive -file signedServerCert.arm -db acmeWebServer.kdb -
pw ejed43dA -fips
5. Make the new certificate the default one. This means that when a client connects
to the web server the server will offer this certificate to the client. The
administrator makes it the default certificate using the following command:
gsk7capicmd -cert -setdefault -db acmeWebServer.kdb -pw ejed43dA -label
OurServerCert -fips
6. The administrator now has a cms keystore with a server certificate ready for use
by the web server application.
68
So do we meet the requirements?
Let’s look at each requirement in turn:
• As the employees are located at different geographical locations a secure
channel for the web traffic must be used. The administrator decides that this
should be SSL.
For a web server to make use of SSL it must have a server side
certificate to offer to clients during the SSL handshake. The certificate
labelled “OurServerCert “ in the keystore acmeWebServer.kdb may be
used for this purpose.
• As employees will have different levels of access to web content the
administrator decides that the server will operate in client authentication mode
where each connecting client must present a valid certificate in order to gain
access. Information from this presented certificate will be used to limit access
to authorized areas of the web server only (this is outside the scope of this
scenario)
Each employee has their own certificate to offer to the server when it
requests one during the SSL handshake. The server can first validate
the client certificate as it has the signer chain, that is, the client
certificate is signed by the ACME Intermediate Certificate, and the
ACME intermediate certificate is in turn signed by the CA certificate.
The server keystore (acmeWebServer.kdb) has both of these. Once the
client certificate has been validated the application can inspect the CN
of the certificate and extract the employee email address from it. The
application can then use the employee email address to determine the
level of access allowed for the connection.
• As cost is an issue the administrator decides that it so too costly to have every
employee certificate signed by a CA. The administrator decides to make use of
a company wide intermediate certificate that will then be used to sign all
employee certificates.
The administrator only incurred the expense of two CA signing
operations. One for the Intermediate Certificate and one for the signer
certificate.
• Employees must be able to validate the server’s certificate thereby proving the
authenticity of the web server.
When the client application receives (as part of the SSL handshake) the
server certificate it can verify the validity of that certificate as it has the
CA certificate that signed it.
• The administrator notes that it is bad practice to use a certificate for more than
one purpose so decides that another certificate must be produced and signed
69
by the CA. This certificate will be the server certificate used for the website.
Using the Intermediate Certificate for this purpose would be poor practice.
Two certificates have been created. “OurServerCert” for use of the
ACME web server and “OurIntermediate” for the administrator to use
to sign employee certificates.
70
Appendix 3. Notices
This information was developed for products and services offered in the U.S.A. IBM
may not offer the products, services, or features discussed in this document in other
countries. Consult your local IBM representative for information on the products and
services currently available in your area. Any reference to an IBM product, program,
or service is not intended to state or imply that only that IBM product, program, or
service may be used. Any functionally equivalent product, program, or service that
does not infringe any IBM intellectual property right may be used instead. However,
it is the user's responsibility to evaluate and verify the operation of any non-IBM
product, program, or service.
IBM may have patents or pending patent applications covering subject matter
described in this document. The furnishing of this document does not give you any
license to these patents. You can send license inquiries, in writing, to:
IBM Director of Licensing
IBM Corporation
North Castle Drive
Armonk, NY 10504-1785
U.S.A.
For license inquiries regarding double-byte (DBCS) information, contact the IBM
Intellectual Property Department in your country or send inquiries, in writing, to:
IBM World Trade Asia Corporation
Licensing
2-31 Roppongi 3-chome, Minato-ku
Tokyo 106-0032, Japan
The following paragraph does not apply to the United Kingdom or any other
country where such provisions are inconsistent with local law:
INTERNATIONAL BUSINESS MACHINES CORPORATION PROVIDES THIS
PUBLICATION "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF NON-INFRINGEMENT, MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE. Some states do not allow disclaimer of express or
implied warranties in certain transactions, therefore, this statement may not apply to
you.
This information could include technical inaccuracies or typographical errors.
Changes are periodically made to the information herein; these changes will be
incorporated in new editions of the publication. IBM may make improvements and/or
changes in the product(s) and/or the program(s) described in this publication at any
time without notice.
Any references in this information to non-IBM Web sites are provided for
convenience only and do not in any manner serve as an endorsement of those Web
sites. The materials at those Web sites are not part of the materials for this IBM
product and use of those Web sites is at your own risk.
71
IBM may use or distribute any of the information you supply in any way it believes appropriate without
incurring any obligation to you.
Licensees of this program who wish to have information about it for the purpose of
enabling: (i) the exchange of information between independently created programs
and other programs (including this one) and (ii) the mutual use of the information
which has been exchanged should contact:
IBM Corporation
2ZA4/101
11400 Burnet Road
Austin, TX 78758
U.S.A.
Such information may be available, subject to appropriate terms and conditions,
including in some cases, payment of a fee.
The licensed program described in this information and all licensed material available
for it are provided by IBM under terms of the IBM Customer Agreement, IBM
International Program License Agreement, or any equivalent agreement between us.
Any performance data contained herein was determined in a controlled environment.
Therefore, the results obtained in other operating environments may vary
significantly. Some measurements may have been made on development-level
systems and there is no guarantee that these measurements will be the same on
generally available systems. Furthermore, some measurements may have been
estimated through extrapolation. Actual results may vary. Users of this document
should verify the applicable data for their specific environment.
Information concerning non-IBM products was obtained from the suppliers of those
products, their published announcements or other publicly available sources. IBM has
not tested those products and cannot confirm the accuracy of performance,
compatibility or any other claims related to non-IBM products. Questions on the
capabilities of non-IBM products should be addressed to the suppliers of those
products.
Trademarks
The following terms are trademarks or registered trademarks of International Business
Machines Corporation in the United States, other countries, or both:
IBM
IBM logo
AIX
DB2
Novell
SecureWay
Tivoli
Tivoli logo
Universal Database
WebSphere
Lotus is a registered trademark of Lotus Development Corporation and/or IBM
Corporation.
72
Domino is a trademark of International Business Machines Corporation and Lotus
Development Corporation in the United States, other countries, or both.
Microsoft, Windows, Windows NT, and the Windows logo are trademarks of
Microsoft Corporation in the United States, other countries, or both.
Intel, Intel Inside (logos), MMX and Pentium are trademarks of Intel Corporation in
the United States, other countries, or both.
UNIX is a registered trademark of The Open Group in the United States and other
countries.
Linux is a trademark of Linus Torvalds in the U.S., other countries, or both.
Java and all Java-based trademarks are
trademarks of Sun Microsystems, Inc.
in the United States, other countries, or
both.
Other company, product, and service names may be trademarks or service marks of
others.
