HD-series
Products in this category are certified to the highest level of useful life
(professional use and not occasional use) to ensure maximum value
from your investment.
All are made of the best materials available and constructed in
accordance with the latest and most advanced techniques.
Reaching new heights in professional shop equipment
HD-series
Makes Wheel Positioning Easy
VIEW ONLINE
DEMO VIDEO
trans-
trans-
The Winntec Wheel Assist brings speed
and precision to wheel removal and fitting
through its innovative, intuitive and highly
portable design.
Operating as a standalone piece of workshop
equipment, that doesn’t require charging or linking
up to a power source, the Winntec Wheel Assist has
powerful gas springs that will enable workshop
technicians to quickly and easily remove and or replace
wheels.
Developed in partnership with tire specialists, this
unique, patent pending product, intuitively supports
the technician, enabling them to precisely position
the height of the wheel, whilst guarding against injury
during the numerous lifts required in the wheel fitting
process. Its durable yet lightweight construction means
it’s easy to move around the workshop too.
HD-series
Wheel Assist
HDY472260 (N.W. 34 kg / 75 lbs)
Max. capacity : 60 kg / 132 lbs
Working range : 0 - 710mm / 28 in
Certified by SGS : EN ISO 12100:2010 - 2006/42/EC
Makes Wheel Positioning Easy
HD-series
Makes
Wheel
Positioning
Easy
Wheel Assist
www.winntec.net
“For those removing wheels unassisted there is an
increased risk of personal injury, and if a costly wheel
lifter is being used there are frustrations relating to
the frequency and length of time that they have to be
charged, lack of manoeuvrability within the workshop
and the speed of operation. Precise positioning is also
difficult leading to a risk of damage to the wheel or
ceramic brake systems.”
Shortlisted as a finalist in the Automechanika award
for innovation in workshop products (2014), the Winntec
Wheel Assist combats all of these challenges in a
simple to use, cost effective way.
Designed for those heavier 25 kg (55 lbs) plus wheels,
the Winntec Wheel Assist will prove to be an essential
piece of workshop equipment.
700
792 689
337
1590
1022
218
216
192 480
28
670
1590
1352
852
672
337
670
Dimensions shown in mm - 1 mm equals 0.039 in
Max. capacity : 60 kg / 132 lbs
Working range : 0 - 710mm / 28 in
Certified by SGS : EN ISO 12100:2010 - 2006/42/EC
VIEW ONLINE
DEMO VIDEO
Advanced quality and service!
VIEW ONLINE
DEMO VIDEO
