OPERATION MANUAL

1 - Golden Tee Golf ‘99

1 GETTING STARTED .................................................................. 2

GAME PACKAGE CONTENTS........................................................... 2

Non-Tournament Kit Version:.................................................. 2

ITS Tournament Version:......................................................... 2

RECOMMENDED TOOLS AND SUPPLIES........................................... 2

Non-Tournament Kit Version:.................................................. 2

ITS Tournament Version:......................................................... 2

2 INSTALLATION PREPARATION ............................................ 2

THE CABINET................................................................................. 3

Power Requirements ................................................................ 3

Monitor Requirements.............................................................. 3

Cabinet Selection ..................................................................... 3

CONTROL PANEL............................................................................ 4

Trackball Preparation ............................................................. 4

Button Preparation .................................................................. 6

GRAPHIC OVERLAYS...................................................................... 6

Control Panel Overlay Installation.......................................... 6

Function Labels Overlay Installation ...................................... 7

Marquee Installation................................................................ 7

WIRING AND HARDWARE ASSEMBLY............................................. 7

Control Panel Assembly........................................................... 7

Printed Circuit Board (PCB) ................................................... 7

Wire Harness............................................................................ 8

Power Wires............................................................................. 8

Monitor Wires .......................................................................... 8

Speaker Wires .......................................................................... 8

SYNC ........................................................................................ 8

Coin Doors, Test Switch, Service Button, and Volume Control

Panel ........................................................................................ 9

Mars Light Hookup (optional) ................................................. 9

Final Check.............................................................................. 9

LED SIGN (ITS ONLY)................................................................. 10

3 CONNECTING THE PHONE LINE (ITS ONLY) ........................ 10

Node Connections .................................................................. 11

Phone Connections ................................................................ 11

4 INITIAL POWER-UP.................................................................... 12

5 DIP SWITCH SETTINGS .............................................................. 12

6

OPERATOR MODE...................................................................... 13

VOLUME SETTINGS ...................................................................... 14

ITS COLLECTION REPORT AS DOLLARS (ITS ONLY) ................... 14

ITS COLLECTION REPORT AS COINS (ITS ONLY) ........................ 14

OPERATOR ADJUSTABLES ............................................................ 15

Game Mode Selection ............................................................ 15

Game Resets........................................................................... 15

Attract Mode Sounds.............................................................. 16

Credits and Coin Door Settings............................................. 16

Delay Time Adjustment .......................................................... 16

Coin Door Protection Menu .................................................. 17

Skill Level Adjustment (In Regular Play Only) ...................... 17

Hole In One Contest Mode (In Regular Play Only)............... 18

Three Hole Operator Event.................................................... 18

GAME AUDITS.............................................................................. 19

Display Coin Audits ............................................................... 19

Display Game Selection Audits.............................................. 19

Number of Golfers and Holes Played .................................... 19

ASPEN LAKE Audits.............................................................. 20

COCONUT COVE Audits ...................................................... 20

RANCHO SAGUARO Audits.................................................. 20

Reset Audits............................................................................ 20

TOURNAMENT MENU (ITS ONLY) ............................................... 21

Tournament Operator Adjustables......................................... 21

Display Tournament Audits....................................................22

Display Hardware Audits....................................................... 22

Display Timers ....................................................................... 22

LEADERBOARD MENU.................................................................. 23

Display Leaderboard Menu ................................................... 23

Clear Leaderboard Menu....................................................... 24

SYSTEM TESTS MENU .................................................................. 24

Video Screen Test................................................................... 24

Full GROM Checksum Test.................................................... 24

Fast GROM Checksum Test ................................................... 25

Video RAM Test ..................................................................... 25

Palette RAM Test ................................................................... 26

Board Test.............................................................................. 26

Sound Test.............................................................................. 26

Control Panel Test ................................................................. 27

Voltage Adjust Test ................................................................ 27

Sign Test (ITS Only)............................................................... 27

Serial Port Test (ITS Only).................................................... 27

APPENDIX A

GENERAL TROUBLESHOOTING ............................................ 28

PHONE LINE CONNECTION PROBLEMS (ITS ONLY) ..................... 28

VIDEO PROBLEMS................................................................... 30

SOUND PROBLEMS ................................................................. 31

CONTROL PROBLEMS ............................................................ 31

POWER-UP PROBLEMS........................................................... 32

LED SIGN PROBLEMS (ITS ONLY)............................................. 33

MISCELLANEOUS PROBLEMS .............................................. 33

APPENDIX B

JAMMA HARNESS CONNECTION AND

CABINET SCHEMATIC .............................................................. 34

JAMMA HARNESS CONNECTION................................................. 34

TRACKBALL HARNESS CONNECTION............................................ 34

CABINET SCHEMATIC................................................................... 35

APPENDIX C

ITS TOURNAMENT OVERVIEW.............................................. 36

Game Highlights .................................................................... 37

Tournament Highlights .......................................................... 37

Networking Highlights ........................................................... 37

Accounting Highlights ...........................................................37

ITS GAME INITIALIZATION FORM (ITS ONLY) ............................ 38

ITS DEBIT ACCOUNT FORM (ITS ONLY)..................................... 38

APPENDIX D

ITS TOURNAMENT PROCEDURES ......................................... 39

OFFICIAL TOURNAMENT RULES ................................................... 39

BEGINNING A TOURNAMENT........................................................ 40

COLLECTION PROCEDURE ............................................................ 40

ENDING A TOURNAMENT ............................................................. 41

PRIZE CLAIM PROCEDURE............................................................ 42

TOURNAMENT ICONS ................................................................... 43

APPENDIX E

FREQUENTLY ASKED QUESTIONS ABOUT THE ITS........ 44

APPENDIX F

WARRANTY INFORMATION.................................................... 48

Golden Tee Golf ’99 - 2

1Getting Started

Game Package Contents

Non-Tournament Kit Version:

(1) Printed Circuit Board (PCB) Assembly

(1) Connecting Wire Harness (JAMMA)

(1) Trackball Assembly w/Metal Plate

(1) Trackball Cable Assembly

(3) Button Assemblies

(1) Marquee Styrene

(1) Marquee Plexiglas

(1) Control Panel Overlay

(1) Set of Function Labels

(1) Manual

ITS Tournament Version:

(1) Golden Tee ‘99 Golf Tournament Cabinet

(1) Tournament Operation Manual

(1) Monitor Manual

(1) Bill Acceptor Manual

(1) 50 ft. Telephone Cable

(1) Telephone Line T-Splitter

(1) Envelope of important operator forms

Recommended Tools and Supplies

Non-Tournament Kit Version:

• Phillips and Slotted Screwdrivers

• Socket Set, Wire Cutters and Strippers

• Pliers or Channel Locks

• Electric Drill with 3/32", ¼", and 7/16" Bits

• Chassis or Sheet Metal Punch

• Razor Knife and Sharp Blades

• Soldering Iron and 60/40 Resin Core Solder

• Assorted Fastening Hardware

• Heat Shrink Tubing (3/32", 1/8", and 3/16")

• Masking Tape or 4" Wire Ties

IF YOU DO YOUR OWN PAINTING, YOU'LL

NEED THESE PAINT SUPPLIES:

• Air Brush or Paint Sprayer

• Paint Brush, Paint Roller and Pan

• Paint (and Primer)

• Sandpaper

ITS Tournament Version:

• Normal telephone outlet that connects to an

outside phone line.

• Inexpensive telephone, used to test the line

connection.

• Voltmeter - used to verify voltage on the PCB.

2 Installation Preparation

BEFORE YOU START.....

1. Check to see if all the needed parts have been

included in your kit or tournament cabinet (See

Game Package Contents)

2. Do you have the necessary tools? (See

Recommended Tools and Supplies)

3. Do not work with any part of the system plugged in

(lights, monitor, or power supply).

NOTE:

(FOR TOURNAMENT OWNERS ONLY)

Your Tournament cabinet has been checked at

the factory prior to shipping and should be

ready to plug-in and play. However,

connections or components often come loose

during shipping. Make sure you check all of

the connectors, wires and harnesses on your

cabinet before turning the game on. You may

skip to LED Sign on page 10.

Also, be sure to check the voltage level of the

power supply from the circuit board. For best

results, make sure the voltage reading is set to

5.2 volts on the circuit board, not on the power

supply or the JAMMA connector. See JAMMA

Harness Connection on page 34

3 - Golden Tee Golf ‘99

The Cabinet

Power Requirements

Make sure the game you have chosen

to convert is able to supply all the

required voltages for GOLDEN TEE

'98.

+5 VDC 5 amps

+12 VDC 2 amps

WARNING!!!

The output level of many "regulated" switching

power supplies actually vary with load. For

this reason, the power supply from an old

game may not be correctly adjusted for

GOLDEN TEE '98. This makes the existing

power supply inappropriate and hazardous to

your new game. Therefore, it is very important

to adjust the +5 VDC supply WITHOUT

connecting the PCB, then readjusting it later,

after the PCB has been installed. Measure

power on the PCB, on an IC. Damage will

occur if the power supply is outside the

acceptable limits (between 4.8 and 5.5 VDC.)

Monitor Requirements

GOLDEN TEE ‘99 requires a monitor

in a horizontal mount raster scan with

negative composite SYNC. It can be

difficult to change the monitor from

vertical to a horizontal unit, therefore,

installation will be easier if you choose a horizontal

mount cabinet.

Cabinet Selection

You can choose either a new cabinet or a

used cabinet for your GOLDEN TEE ‘99

game. Reusing a cabinet is by far the

most cost-effective way to maximize the

return of your initial investment. In either

case, all you need to provide is the cabinet

with a power supply and monitor. We

provide the rest. The end result is a new

game at a very low cost.

NOTE:

It is recommended that a large control panel

with a 25" monitor, like those on a 4-player

cabinet, be used for your GOLDEN TEE '99.

When selecting a cabinet, keep this in mind:

A cabinet with a 25" monitor and a large control panel

will allow you to mount the trackball farther from the

monitor. This prevents players hands from hitting the

monitor glass when rolling the trackball forward, and

will earn better than a smaller control panel with a

smaller monitor.

1. Remove the following from the cabinet:

• Main Logic Board(s)

• Control Panel

• Monitor Plexiglas

• Marquee

• Cabinet Graphics

2. Thoroughly clean out your cabinet. Remove all the

old buttons, joysticks and wires from the control

panel. DO NOT remove monitor and speaker wires.

3. Remove the old graphics and adhesive from the

control panel, and the side of the cabinet. Remove

adhesive with solvent.

4. For a fresh look, painting is highly recommended.

Spray painting gives a better finish, but if an air

brush or paint sprayer is unavailable, a roller is

second best. Remember to cover all exposed

surfaces not to be painted.

5. Remember, spending time on the cabinet's

appearance (i.e., marquee, control panel, and

cabinet graphics) will raise your profits with the

introduction of a new game package, especially if

the cabinet looks clean and new.

6. The "new game look" should always apply to the

inside of your game as well. A few wire ties and

shrink tubing on your harness, some fastening

hardware on your subassemblies, and a sweep with

the vacuum cleaner will ensure that glitches do not

occur.

Golden Tee Golf ’99 - 4

Control Panel

Mounting the trackball correctly and securely is very

important for the profitability of your new game.

Follow these instructions carefully for mounting the

trackball to: 1) a metal control panel; 2) a wooden

control with routing; 3) or a wooden control panel

without routing. (Refer to template inserts which came

with your new kit.)

CONTROL PANEL LAYOUT

(Trackball MUST be centered on the control panel)

NOTE:

Installing the trackball as far away from the

monitor as possible will prevent players hands

from hitting the monitor glass when rolling the

trackball forward.

NOTE:

The trackball mounting bolts may become

loose over time, which may present a danger

to your players. Make sure the bolt heads are

flat and secure on the control panel surface

and that the bolts are tightly secured. It is

highly recommended that a nylon-insert

locking nut be added and tightened against the

existing nut of each carriage bolt to ensure a

tight, secure fit.

Trackball Preparation

When making the hole for the

trackball, follow the instructions,

starting on the next page, for the type

of control panel you will be using.

NOTE:

When installing the trackball, make sure the

trackball is in the right orientation. (Refer to

picture below.)

TRACKBALL ORIENTATION

(NOT DRAWN TO SCALE)

IMPORTANT!:

The supplied trackball comes equipped with a

grounding cable. This cable must be

connected to field ground to protect the

trackball P.C. boards from becoming damaged

by electro-static discharge.

5 - Golden Tee Golf ‘99

To mount trackball to a metal control

panel use Trackball Mounting

Template #1

1. Fill any existing holes in the metal control panel.

2. Place and secure TEMPLATE #1 to your control

panel in the desired location.

NOTE: The trackball should be as far away

from the monitor as possible.

3. Carefully drill the holes for the ball and the

mounting bolts using the template as a guide.

4. Remove template and file down any rough edges.

5. See Graphic Overlays section on page 6 on how to

install the graphics.

6. Mount the trackball under the control panel using

the 4 carriage bolts. It is highly recommended that

a nylon-insert locking nut be added to the nut of

each carriage bolt to ensure a tight, secure fit.

Loose bolts can create unsafe conditions for

game play.

NOTE: Be sure the trackball is mounted as

shown in the diagram on page 4.

NOTE: Do not over-tighten the trackball. It will

warp and cause the trackball to not operate

correctly.

NOTE: The supplied metal plate is not needed

with metal control panels.

NOTE: Be sure to mount the trackball so as

much of the ball is exposed as possible.

7. Securely fasten the trackball grounding wires to

Field Ground in your cabinet. This step is

important in reducing static buildup and discharge

caused by the trackball.

8. If using Plexiglas on your control panel, it is highly

recommended that a 3-1/2" hole be cut in the

Plexiglas for the trackball. This allows for players

to use the full height of the trackball. Carefully file

and smooth the edges of the hole in the Plexiglas so

players do not cut their hands when playing.

To mount trackball to a wooden

control panel with routing capability

use Trackball Mounting Template #2

1. Fill any existing holes in the wooden control panel.

2. Place and secure Template #2 to your control panel

in the desired location.

NOTE: The trackball should be as far away

from the monitor as possible.

3. Carefully cut the hole for the trackball in the shape

indicated on the template.

4. Drill the mounting holes indicated.

5. Next route out the shaded area indicated on

TEMPLATE #2, 1/16" deep. Use a 1/2" Rabbiting

Bit for best results. This is so the supplied metal

plate will be flush with the control panel surface.

6. Remove template and file down any rough edges.

7. See Graphic Overlays section on page 6 on how to

install the graphics.

8. Mount the trackball to the metal plate using the 4

carriage bolts supplied. Then mount the metal

plate to the wooden control panel. It is highly

recommended that a nylon-insert locking nut be

added to the nut of each carriage bolt to ensure a

tight, secure fit. Loose bolts can create unsafe

conditions for game play.

NOTE: Be sure the trackball is mounted as

shown in the diagram on page 4.

NOTE: Do not over-tighten the trackball. It will

warp and cause the trackball to not operate

correctly.

NOTE: Be sure to mount the trackball so as

much of the ball is exposed as possible.

9. Securely fasten the trackball grounding wires to

Field Ground in your cabinet. This step is

important in reducing static buildup and discharge

caused by the trackball.

10. If using Plexiglas on your control panel, it is highly

recommended that a 3-1/2" hole be cut in the

Plexiglas for the trackball. This allows for players

to use the full height of the trackball. Carefully file

and smooth the edges of the hole in the Plexiglas so

players do not cut their hands when playing.

Golden Tee Golf ’99 - 6

To mount trackball to a wooden

control panel without routing capability

use Trackball Mounting Template #3

1. Fill any existing holes in the wooden control panel.

2. Place and secure Template #3 to your control panel

in the desired location.

NOTE: The trackball should be as far away

from the monitor as possible.

3. Carefully cut the hole for the trackball in the shape

indicated on the template. The trackball should fit

the hole shape exactly.

4. Drill the mounting holes as indicated.

5. Remove template and file down any rough edges.

6. Using the Trackball Orientation Template, cut a 3”

hole in the Plexigals overlay to fit over the

trackball. Be sure to include holes for the buttons

and all of the mounting bolts. Carefully file and

smooth the cut edges so players do not cut their

hands when playing.

7. See Graphic Overlays section on page 6 on how to

install the graphics.

8. Insert the trackball into the newly cut hole. Place

the Plexiglas overlay on top of the control panel.

Place the supplied metal plate under the trackball

and use the carraige bolts to secure it to the control

panel. The metal plate below and the Plexiglas

above will secure the trackball into position. It is

highly recommended that a nylon-insert locking nut

be added to the nut of each carriage bolt to ensure a

tight, secure fit. Loose bolts can create unsafe

conditions for game play.

NOTE: Be sure the trackball is mounted as

shown in the diagram on page 4.

NOTE: Do not over-tighten the trackball. It will

warp and cause the trackball to not operate

correctly.

NOTE: Be sure to mount the trackball so as

much of the ball is exposed as possible.

9. Securely fasten the trackball grounding wires to

Field Ground in your cabinet. This step is

important in reducing static buildup and discharge

caused by the trackball.

Button Preparation

1. When making the holes for the buttons,

DO NOT use the Function Labels to

outline any new holes. The Function

Labels are designed to fit right over the

buttons when installed on the control

panel. If the labels are used as a

template the holes will be too big, and the buttons

will fall through. Instead, use the labels as a guide

to where you want to drill your new holes, and then

cut a 1-1/8" hole in the center of where the labels

are to be placed. DO NOT stick the labels to the

panel at this time.

2. Drill or punch the holes marked for buttons or

bolts. Use a chassis or sheet metal punch for best

results on button holes.

3. Use a file to smooth any rough edges on the holes.

4. Fill any old and unused holes with wood, resin, or a

metal plate.

5. It is recommended that you cover your control

panel with Plexiglas. Now would be a good time to

cut it to fit while the dimensions and tools are at

hand.

Graphic Overlays

GOLDEN TEE ‘99 comes equipped with graphics that

will accommodate a variety of existing game cabinets.

Control Panel Overlay Installation

1. Make sure the control panel is clean and free from

dust, grease, metal filings, and sawdust. The

background overlay provided with the game is

oversized to accommodate most control panel

sizes. Center the background overlay on the

control panel surface. Be sure to leave enough

excess material above and below the control panel

in order to trim it evenly.

2. Remove the protective backing from the

background overlay. Center the background

overlay over the control panel and place down

gently, making sure to keep it square. Using your

hands, press down firmly, starting from the center

and smooth the background overlay outward,

making sure all bubbles have been pressed out for a

clean, flat surface.

7 - Golden Tee Golf ‘99

3. Using a sharp razor knife, trim any excess from the

background overlay. Carefully pierce through the

overlay above each control panel hole that you

have marked. Cut out material covering the pre-

drilled holes with the razor knife. Be sure to cut

the background overlay above each hole and trim

cleanly and evenly.

Function Labels Overlay Installation

Line up the supplied function labels with the

corresponding control panel holes. Remove the backing

and carefully press into place. Be sure they are straight.

Attach the HOOK/SWING reference diagram above

the trackball label. If your control panel is too narrow

to fit the reference diagram, mount the diagram under

the monitor glass on the bezel. Refer to the diagrams

below.

FUNCTION LABEL LAYOUT #1

or put the HOOK/SWING Reference diagram on the

monitor bezel.

FUNCTION LABEL LAYOUT #2

Marquee Installation

If your cabinet needs a new marquee glass, determine

the correct size and cut the Plexiglas (supplied) to fit.

Using the old marquee glass as a template, center the

Plexiglas on your new marquee graphics, making sure

that all the printed images will be visible. Using a razor

knife, score the new marquee deeply, following the

edges of the old glass. Carefully break off the styrene.

Be sure the light behind the marquee works and that the

glass is clean on both sides. Now install the marquee

graphics and glass securely.

Wiring and Hardware Assembly

REMEMBER! DO NOT WORK WITH ANY PART OF THIS

SYSTEM PLUGGED IN (Lights, Monitor, or Power Supply).

NOTE:

All switch wires used in this game need to be

wired to the normally open connection on the

switches. Each switch requires a ground wire

on the common connector and the appropriate

control or switch wire on the other normally

open connector of the switch.

Control Panel Assembly

1. Install the trackball and buttons on the control

panel by following the detailed instructions

beginning on page 4. The two red buttons are used

for FACE LEFT and FACE RIGHT. The white

button is used as the START button.

NOTE:

If you want your new game to earn money, you

must install the trackball correctly.

2. If you are using Plexiglas for added protection,

don't forget to place it on the panel before inserting

the buttons.

3. Wire the trackball and buttons using the JAMMA

Harness Connection and Cabinet Schematic table on

page 34. Connect the trackball using the supplied

trackball cable into PLAYER 1 on the PCs.

IMPORTANT!:

The supplied trackball comes equipped with a

grounding cable. This cable must be

connected to field ground to protect the

trackball P.C. boards from becoming damaged

by electro-static discharge.

Printed Circuit Board (PCB)

Mount the PCB to the side of the cabinet with the

connector toward the top of the drawer. This will keep

the wire harness from slipping off due to vibration.

Mark and drill pilot holes (3/32") onto the cabinet side,

being careful not to drill through to the outside. Attach

the PCB standoffs to the cabinet using wood screws and

spacers, snug but not too tight or the board may warp

or crack. Be sure the board is not being flexed in any

way.

Golden Tee Golf ’99 - 8

Wire Harness

WARNING!

Be sure that all power is

OFF before connecting

power supply.

1. If you are installing GOLDEN TEE ‘99 into a

Dynamo cabinet with a pre-installed JAMMA

harness, you will notice that it does not have a wire

for the test switch. You will have to add a contact

to the edge connector at the proper position

(position 15). Some cabinets (Dynamo included)

have only one coin switch input and the coin

switches are wired together. Connect the

designated wires to the coin switches separately.

2. Attach the wire harness connector to the PCB. Be

sure it is mounted correctly.

WARNING!!!

Make sure you have identified PIN 1 on the

connector before powering up. Plugging the

JAMMA connector in backwards will cause

damage to the PCB.

3. It is best to use connectors (not supplied) whenever

joining a set of harness wires to a subassembly. If

you choose to solder wires together, follow this

procedure:

• Strip off about ½" of insulation from the wire.

• Slide a piece of heat-shrink tubing over the

end.

• Do not leave a lot of excess wire spooled up in

your cabinet. Cut the wires to the length you

need plus a few extra inches. Leave enough

for proper cable dressing. Do not make it

stretch across the inside of the cabinet.

4. Solder the new wire to the original wire. Use a

straight in-line splice.

Power Wires

1. Connect the wires that are designated for your

power supply. You will need a supply of +5 vdc,

and +12 vdc. The +5 vdc must be regulated to

within 5% (+ or - 0.25) . The +12 vdc may be

unregulated but should not stray too far or the

sound may be affected. If the cabinet's supply does

not provide these voltages, it will have to be

replaced. A switching-type supply is

recommended.

2. You will notice that you have more than one wire

for each voltage. Use all wires supplied on the

harness. This will ensure better power transmission

and prevent overloading of the edge connector

pads.

3. Tin all power supply wires before connecting them

to the power supply. Loose strands may short out

the supply. For best results, connect spade lugs to

the ends of the power wires and attach to the screw

terminals of the power supply.

Monitor Wires

You will be connecting the RED, GREEN, and BLUE

video drives along with the composite SYNC and video

GROUND wires.

Speaker Wires

Connect the speaker wires paying attention to

their polarity.

NOTE:

If your cabinet has two speakers, connect

both. If they are 8 or 16 ohm speakers,

connect them in parallel, if they are 4 ohm,

connect them in series.

Position speakers as far from the monitor as possible. If

placed too close, the speaker's magnet may deflect the

monitor and cause strange coloration, which can usually

be corrected by degaussing the monitor. Make sure

everything else in the cabinet is attached securely for

the same reason.

SYNC

This is the recommended approach for a Wells-

Gardener monitor and should work with some others as

well.

9 - Golden Tee Golf ‘99

If your monitor does not have a composite SYNC input

but has separate horizontal and vertical SYNC inputs,

try connecting the composite SYNC signal from the

PCB to the negative horizontal SYNC signal on the

monitor. This should produce a satisfactory result,

although some adjustment of the monitor's SYNC

controls may be necessary.

Coin Doors, Test Switch, Service Button,

and Volume Control Panel

1. Wire the coin doors and the test / service switch(es)

as per the JAMMA Harness Connection and

Cabinet Schematic table on page 34.

2. Connect the door lamps to the +12 vdc supply.

Some games have separate power supply outputs

for the lamps.

3. Install a test switch somewhere convenient inside

the coin door area. This switch allows you to enter

adjustables, run diagnostics, and see or clear audits.

Make it readily accessible through the coin door.

Wire it to the Test wire on the JAMMA Harness.

4. Install a service switch (not included) somewhere

convenient inside the coin door area. This switch

allows you to give credits to players without

affecting the game's credit audits or coin meters.

Example: A player puts in a coin and gets no credit,

the operator can then push the service button and a

credit is given to the player without affecting the

game's audits and coin meter.

5. GOLDEN TEE ‘99 has the ability to adjust volume

at any time during a game. Install two push button

switches (not included) inside the coin door for

easy access. Connect the switches to the JAMMA

harness. Refer to the JAMMA Harness Connection

and Cabinet Schematic table on page 34.

6. GOLDEN TEE ‘99 is also capable of running a

Mars Light or other external signal, which will be

activated if the game is running a special Hole-In-

One contest.

Mars Light Hookup (optional)

Equipment required

A MARS light police beacon and a 3 amp 120 volt AC

solid state relay with a 2.5 to 8 volt control line.

1. Connect a wire from PIN 2 of the PCB’s ticket

connector to the positive control line of the relay.

2. Connect a wire from PIN 3 of the PCB’s ticket

connector to the negative control line of the relay.

WARNING!

Make sure all power is OFF before installation

3. The hot AC line in should connect to one side of

the light and the return should connect to the AC

input of the relay.

4. From the AC output of the relay, connect a wire to

the other side of the light.

WARNING!

Make sure all wires and connections are

securely fastened, with no loose strands of

wire. Improper or sloppy connections can

cause serious injury or fire.

5. The Hole-In-One contest is turned ON in the

Operator Adjustables in order for the light to

activate when a hole-in-one is made.

NOTE:

Mars Light will only work for sound PROMS

1.0 and above.

Final Check

1. Check the game inside and out for any

imperfections. Secure any loose wiring or

fastening hardware.

2. Make sure the coin door is tight and the coin mechs

are well adjusted.

3. Make sure all assemblies are firmly attached.

Anything that is not mounted securely will rattle

when the game is played. This game makes use of

low-frequency sounds which can cause any loose

joints to rattle.

Golden Tee Golf ’99 - 10

LED Sign (Tournament Version Only)

The LED message sign is folded back for safe shipping

purposes. Before you start your game, lift the LED sign

forward until it is in an upright position. Make sure the

cables connecting the sign to the cabinet do not get

caught or pinched in the access hole. Attach the metal

support brackets, found inside the cash box, to the back

of the sign and cabinet. This bracket will prohibit the

sign from falling backward. Make sure to orient the

bracket so the V-shaped notch lines up with the hinge

on the bottom of the sign box. Use the supplied short

screws to attach the top of the bracket to the sign box.

Use the longer screws to attach the bracket to the

cabinet .

NOTE:

Make sure the brackets are oriented correctly.

Mounting the brackets backwards or using the

wrong screws will allow the mounting screws

to drive too far into the sign box and may

damage the sign's electronics.

3 Connecting The Phone Line

(Tournament Version Only)

In order for your game to join the tournament, you must

connect the game to a regular telephone line. The ITS

requires a regular phone line that gives a dial tone.

Phone systems that are not direct outside lines may not

work.

1. Set up your ITS-compatible Golden Tee ‘99 Golf

cabinet as you would any other video game. Be

sure the LED sign and modem are properly

connected to the PCB and the modem is on. Use

the illustrations on the next page to verify proper

connections.

2. Make sure the supplied, long, round telephone

cable is plugged into the phone jack marked LINE

on the modem. Thread the other end of the cable

through the mouse hole below the back door. Be

sure to loop the cable through the cable clip for

extra strain relief.

3. Connect the end of the long cable into any existing

telephone jack. Use the included splitter if you are

connecting to a jack already in use. If no jack is

available, you will need to install a phone jack,

preferably near the cabinet.

4. Turn on the game cabinet and watch the Attract

mode. The game will automatically attempt an

initialization call. Pay attention to the various

screen messages. and listen carefully to the modem

for a dial tone, dialing sounds and the modem

connect sound as the game makes its call.

5. Automatic installation is complete when the screen

displays a SUCCESSFUL message. If an

unsuccessful message appears, enter Test Mode by

pressing the button inside the coin door. A second

attempt to call will begin when you exit Test Mode

by pressing the START button. If your first few

attempts to call are unsuccessful, check the

Troubleshooting section in this manual.

NOTE:

If you are unable to get your game to complete

a successful call, contact your distributor or

the Incredible Technologies Technical

Department.

6. After your successful phone call, the game is now

connected to the Tournament System and ready for

public play! Tournament information will appear

on the LED sign and promotional materials will be

sent from the ITS, for display at each location.

IMPORTANT:

Fill out the ITS Game Initialization Forms for

each cabinet and location. Fax or mail the

Initialization Forms to I.T. to validate your

game. Your game will NOT access the

tournament if these forms are not received.

11 - Golden Tee Golf ‘99

Node Connections

If you are planning to place more than one tournament

game in a location, you may want to connect them

together so all of the ITS machines share the same

phone line. Follow the directions below to correctly

daisy-chain your tournament cabinets together.

ITS games can be connected together and share one

phone line. All of your game cabinets will require

operating modems. Connect the first game cabinet up to

the phone line following the directions listed under

Connecting The Phone Line on page 10.

From the first cabinet, connect the long round telephone

cable, supplied with the game, to the jack on the modem

marked PHONE. Connect the other end of this cable

into the modem of the next cabinet in line. The cable

connects to the jack marked LINE on the modem. If a

third cabinet is to be connected, attach another

telephone cable to the PHONE jack from the second

machine and connect the other end to the LINE jack on

the third machine. Repeat this sequence until all of

your tournament machines are daisy-chained together.

All ITS-compatible games will have the ability to be

connected together in a location. Even if each machine

is a different game running a different tournament, only

one phone line will be necessary for all of the data to be

transferred.

NOTE:

Because the node connection is a daisy chain,

it is very important that all connected units be

in operation. If one of the nodes is turned off

or out of service, the nodes connected after

that machine will not transfer their data.

Phone Connections

Connecting to the PCB

Connecting to the Modem

Connecting to the Wall

Golden Tee Golf ’99 - 12

4 Initial Power-Up

1. Connect the JAMMA Harness.

WARNING!!!

Make sure the harness is plugged in correctly.

Damage to the PCB will occur if the JAMMA

connector is plugged in wrong.

2. Connect the supplied phone cable to a phone jack.

(Tournament Version Only)

3. Plug in the game and turn it ON.

4. Look and smell for smoke (TURN IT OFF

IMMEDIATELY IF ANY IS NOTICED).

NOTE:

Use the Voltage Adjust Test on page 27 to

adjust your power supply. The ideal reading

should be 5.2 volts on the circuit board. This

is very important for your game to perform

correctly. The voltage should be checked and

adjusted regularly for best game performance.

5. Make sure the LED's on the PCB are flashing. If

not, something is wrong, turn off the game.

6. Listen for sound. Sounds should be heard in the

attract mode.

7. How is the picture? Is it centered? Is it too bright?

Is it in focus? Adjust your monitor to get the best

picture possible.

NOTE:

Check your monitor manual to make

adjustments. Some test patterns are available

through the game's system tests by pressing

the Test switch. Use them when making any

adjustments. (See System Tests Menu on

page 24. Proper monitor adjustment is very

important.)

8. Try all coin switches. Drop quarters or tokens

through to check the coin mechs. Insert a dollar

bill into the bill validator and listen for the credits

to ring up. Make sure the game is adding credits.

You can use the PLAYER CONTROL TEST by

pressing the test switch and entering the SYSTEM

TESTS MENU on page 24. Do all of the controls

work? Try playing the game with the volume up

and listen for rattling as you play. Tighten anything

that is making noise.

9. Upon initial power-up, the game will initialize to

factory default settings. These settings affect game

elements such as number of credits per coin,

difficulty settings, etc. The OPERATOR

ADJUSTABLES MODE section will describe how

to alter these settings and view the system audits or

run system tests.

10. If you wish to automatically run a series of system

tests, hold down the START button when you

power up the game cabinet. The game will

automatically perform the FAST GROM, VIDEO

& PALETTE RAM and sound tests, and end on the

player control test screen. This is a good, quick

way to check the integrity of your PCB.

5 Dip Switch Settings

The SW1-Dip switches can be found on the main PCB

near the JAMMA connector.

Dip switch 4 (ON): Always "ON" (DEFAULT)

Dip switch 4 (OFF): *** NOT USED ***

Dip switch 3 (ON): Normal Mode (DEFAULT)

Dip switch 3 (OFF): Cocktail Mode

Dip switch 2 (ON): One Trackball (DEFAULT)

Dip switch 2 (OFF): Two Trackballs (cocktail version)

Dip switch 1 (ON): Normal Game Play (DEFAULT)

Dip switch 1 (OFF): Operator Mode Menu

NOTE:

For Cocktail tables, dip switches 2 and 3 must

be set to OFF.

There are also SW2-Dip switches near the flashing

green LED. Switches #1 and #2 must be "ON" and

switches #3 and #4 should be "OFF"

13 - Golden Tee Golf ‘99

6 Operator Mode

To enter the OPERATOR MODE MENU, press the

Test Button, located just inside the coin door. When

the Test Button is pressed or SW1-DIP Switch 1 is

flipped to the "OFF" position, the screen displays the

OPERATOR MODE MENU.

NOTE:

If you used SW1-DIP switch 1 to enter the

OPERATOR MODE MENU, you will need to

flip SW1-DIP switch 1 back to the ON position

in order to return to the game.

When in OPERATOR MODE, the game's software

version and ITS ID Number are always displayed at

the top of each screen.

Golden Tee ‘99 GolfV1.00 ID 00000001

TRACKBALL UP TO MOVE UP

TRACKBALL DOWN TO MOVE DOWN

PRESS START TO CHOOSE

OPERATOR MODE MENU

EXIT

VOLUME SETTINGS

ITS COLLECTION REPORT AS DOLLARS(*)

ITS COLLECTION REPORT AS COINS(*)

OPERATOR ADJUSTABLES MENU

GAME AUDITS MENU

TOURNAMENT MENU(*)

LEADERBOARD MENU

SYSTEM TESTS MENU

OPERATOR MODE MENU

The OPERATOR MODE MENU allows you to enter

into several different areas:

VOLUME SETTINGS is used to adjust the volume of

your game for your location.

ITS COLLECTION REPORT AS DOLLARS

displays the current tournament coin audits, for use in

separation of ITS fees from your collections. In this

setting the audits are displayed in US dollars.

ITS COLLECTION REPORT AS COINS displays

the current tournament coin audits, for use in separation

of ITS fees from your collections. In this setting, the

audits are displayed in total number of coins.

OPERATOR ADJUSTABLES is used for

customizing your game for your location. Some of the

features in Operator Adjustables are number of coins

per game, sounds on or off when no one is playing,

difficulty settings, etc. These do not effect tournament

play.

GAME AUDITS allows you to check your game's

overall earnings, game times, game scores, etc. The

Audits can be reset through this menu as well.

TOURNAMENT MENU offers adjustables and

settings for low-level tournaments settings.

LEADERBOARD MENU allows you to view the top

scores on the Leaderboard for each golf course. For

Regular play only.

SYSTEM TESTS verifies the operation of the

hardware, controls, and monitor through easy and

automatic procedures accessed through these menus.

Menu items can be highlighted rolling the trackball Up

or Down. The FACE LEFT and FACE RIGHT buttons

highlight menu items as well. To select a highlighted

item, press the START button.

To exit any of these tests and return the game to its

normal state, use the trackball or FACE LEFT and

FACE RIGHT buttons to highlight the line that says

EXIT, and press the START button.

COLOR KEY NOTE:

For easy identification, all test screens have

been color coded. Items displayed in GREEN

are the Menu titles. This is the name of the

menu that is currently displayed. Items

appearing in YELLOW are the menu's

instructions. The BLUE items are choices

available in this menu. The WHITE item is the

selection that is currently highlighted. If RED is

ever displayed, there is a problem with that

item and it should be corrected.

Golden Tee Golf ’99 - 14

Volume Settings

The Volume Settings screen is used to adjust the sounds

that are heard during game play.

TO EXIT PRESS START

MOVE TRACKBALL RIGHT TO INCREASE VOLUME

MOVE TRACKBALL LEFT TO DECREASE VOLUME

VOLUME SETTINGS SCREEN

When this screen appears, music will play. Move the

trackball to the right to increase the game's sounds and

music. Rolling the trackball to the left will make the

game sounds softer. When you have adjusted the

sounds to the appropriate volume, press the START

button to exit back to the main menu.

Your cabinet also comes equipped with volume

increase/decrease push buttons, located inside the coin

door.

ITS Collection Report As Dollars

(Tournament Version Only)

Use this screen to assist in collections during

tournaments.

Golden Tee ‘99 GolfV1.00 ID 00000001

TRACKBALL UP TO MOVE UP

TRACKBALL DOWN TO MOVE DOWN

PRESS START TO CHOOSE

ITS COLLECTION REPORT AS DOLLARS

EXIT REPORT

RESET COLLECTION COUNTS

TOTAL DOLLARS $0.00

ITS PORTION $0.00

OPERATOR/LOCATION $0.00

ITS COLLECTION REPORT AS DOLLARS SCREEN

RESET COLLECTION COUNTS is used to erase all

of the collection counts stored in memory.

TOTAL DOLLARS displays the total number of

dollars on both the tournament and regular games, since

these audits were last reset.

ITS PORTION displays the number of valid

tournament games on your machine, times the ITS fee.

Separate this amount from your collection before you

make your split. Deposit this amount into your debit

account on a timely basis, to ensure proper funds.

OPERATOR/LOCATION displays the total dollars

collected, minus the ITS portion. This is the amount of

your collection that you may split with your location.

ITS Collection Report As Coins

(Tournament Version Only)

Use this screen to assist in collections during

tournaments.

Golden Tee ‘99 GolfV1.00 ID 00000001

TRACKBALL UP TO MOVE UP

TRACKBALL DOWN TO MOVE DOWN

PRESS START TO CHOOSE

ITS COLLECTION REPORT AS COINS

EXIT REPORT

RESET COLLECTION COUNTS

TOTAL COINS 0000

ITS PORTION 0000

OPERATOR/LOCATION 0000

ITS COLLECTION REPORT AS COINS SCREEN

TOTAL COINS displays the total number of coins on

both the tournament and regular games, since these

audits were last reset.

ITS PORTION displays the number of valid

tournament games on your machine, times the ITS fee.

Separate this amount from your collection before you

make your split. Deposit this amount into your debit

account, to ensure proper funds.

OPERATOR/LOCATION displays the total coins

collected, minus the ITS portion. This is the amount of

your collection that you may split with your location.

NOTE:

This collection report is exactly the same as

COLLECTION REPORT AS DOLLARS,

except that the earnings are represented as a

total coin count rather than a dollar value.

15 - Golden Tee Golf ‘99

Operator Adjustables

The OPERATOR ADJUSTABLE MENU is accessed

through the OPERATOR MODE MENU.

Golden Tee ‘99 GolfV1.00 ID 00000001

TRACKBALL UP TO MOVE UP

TRACKBALL DOWN TO MOVE DOWN

PRESS START TO CHOOSE

OPERATOR ADJUSTABLES MENU

EXIT ADJUSTABLES

GAME MODE SELECTION

GAME RESETS

ATTRACT MODE SOUNDS

CREDITS AND COIN DOOR SETTINGS

DELAY TIME ADJUSTMENT

COIN DOOR PROTECTION MENU

SKILL LEVEL ADJUSTMENT

HOLE IN ONE CONTEST MODE

3 HOLE OPERATOR EVENT SETTINGS

OPERATOR ADJUSTABLES MENU SCREEN

There are many customizing procedures that you can

control. Below is a brief description of each adjustable

function and what the screen looks like when displayed.

Remember, to select an item from any menu, use the

trackball to highlight the item in purple, and then press

the START button.

Game Mode Selection

This menu allows you to place the game in standard

COIN MODE, or choose FREE PLAY.

Golden Tee ‘99 GolfV1.00 ID 00000001

TRACKBALL UP TO MOVE UP

TRACKBALL DOWN TO MOVE DOWN

PRESS START TO CHOOSE

GAME MODE SELECTION

COIN MODE

FREE PLAY

GAME MODE SELECTION SCREEN

In COIN MODE, the game will only work if coins are

deposited into the game.

In FREE PLAY, coins are not needed for play, and the

START button is always active.

IMPORTANT:

If FREE PLAY is set to ON when a tournament

is in progress, your machine will not allow

tournament play.

Game Resets

The GAME RESETS menu will cancel or zero out any

custom features or bookkeeping figures that are no

longer wanted.

Golden Tee ‘99 GolfV1.00 ID 00000001

TRACKBALL UP TO MOVE UP

TRACKBALL DOWN TO MOVE DOWN

PRESS START TO CHOOSE

GAME RESETS

EXIT RESETS

RESET ALL TO FACTORY SETTINGS

RESET HIGH SCORES ONLY

RESET AUDITS ONLY

RESET HOLE IN ONE ONLY

GAME RESETS MENU SCREEN

RESET ALL TO FACTORY SETTINGS will change

the game back to the way the game was preset when

new. Any custom features such as Free Play and Skill

Levels will be changed back to the original settings set

at the factory.

RESET HIGH SCORES ONLY is used to erase all of

the high scores stored in memory.

RESET AUDITS ONLY is used when all of your

bookkeeping and statistics have been gathered from the

Audits section, and are no longer needed. If you like to

gather all of your accounting information each week, or

after each collection, it is a good practice to reset all of

the audits so your coin count will match the audit

information.

RESET HOLE IN ONE ONLY is used to erase all of

the Hole-In-Ones that have occurred in the game.

Golden Tee Golf ’99 - 16

Attract Mode Sounds

This menu is used to adjust the sounds that are heard

while no one is playing the game.

Golden Tee ‘99 GolfV1.00 ID 00000001

TRACKBALL UP TO MOVE UP

TRACKBALL DOWN TO MOVE DOWN

PRESS START TO CHOOSE

ATTRACT MODE SOUNDS

ALL ATTRACT MODE SOUNDS ON

OCCASIONAL ATTRACT MODE SOUNDS

ALL ATTRACT MODE SOUNDS OFF

ATTRACT MODE SOUNDS MENU SCREEN

ALL ATTRACT MODE SOUNDS ON will play

sounds during every attract cycle.

OCCASIONAL ATTRACT MODE SOUNDS plays

sounds about every ten to twelve times the attract mode

is repeated.

ALL ATTRACT MODE SOUNDS OFF will not

allow any sounds to be played during the attract mode.

Credits and Coin Door Settings

This menu allows you to change the number of coins

needed to play GOLDEN TEE 3-D GOLF.

Golden Tee ‘99 GolfV1.00 ID 00000001

TRACKBALL DOWN TO MOVE DOWN

PRESS START TO CHOOSE

CREDITS AND COIN DOOR SETTINGS

EXIT CREDITS AND COIN DOOR SETTINGS

DOOR 1 COIN VALUE 1

DOOR 2 COIN VALUE 1

DOOR 3 COIN VALUE 1

COINS NEEDED FOR ONE CREDIT 2

HOLES PLAYED PER CREDIT 3

COINS NEEDED TO PLAY 18 HOLES 10

TO CHANGE VALUES

MOVE TRACKBALL LEFT TO DECREASE

MOVE TRACKBALL RIGHT TO INCREASE

CREDIT AND COIN DOOR SETTING SCREEN

You can set each door to different coin values by

highlighting DOOR 1 COIN VALUE for coin door 1,

DOOR 2 COIN VALUE for coin door 2, etc.. Moving

Trackball left or right will change the number of credits

that each coin represents.

COINS NEEDED FOR ONE CREDIT..... To award a

game credit, the player will need to insert an adjustable

number of coins.

HOLES PLAYED PER CREDIT..... This defines the

number of holes the player is given for each credit.

This value can range from 1 to 3 holes.

COINS NEEDED TO PLAY 18 HOLES..... To play

an entire 18 holes at a reduced cost to the player, you

can set this value to something less than the cost of

buying holes as described above. The default is 10

coins for 18 holes. This is a savings of 2 coins, at a rate

of 2 coins for 3 holes. The player will need to insert all

10 coins at the start of a game to take advantage of this

discount feature.

Delay Time Adjustment

This allows for changing the delay of game time.

Golden Tee ‘99 GolfV1.00 ID 00000001

TRACKBALL UP TO MOVE UP

TRACKBALL DOWN TO MOVE DOWN

PRESS START TO CHOOSE

DELAY TIME ADJUSTMENT

EXIT DELAY TIME ADJUSTMENT

DELAY OF GAME TIMEOUT 0:25

DELAY OF GAME TIMEOUT ON/OFF

TO CHANGE VALUES

MOVE TRACKBALL LEFT TO DECREASE

MOVE TRACKBALL RIGHT TO INCREASE

BUTTON CONFIGURATIONS SCREEN

DELAY OF GAME TIMEOUT (1) .....The game will

give the player a penalty stroke if they have not swung

the club after this amount of time.

DELAY OF GAME TIMEOUT (2) ... The

TIMEOUT can be disabled by selecting "OFF" - We

recommend leaving this "ON" so the game will return to

the attract mode if a player walks away from a game in

progress.

17 - Golden Tee Golf ‘99

Coin Door Protection Menu

Golden Tee ‘99 Golf v1.00 ID 00000001

TRACKBALL UP TO MOVE UP

TRACKBALL DOWN TO MOVE DOWN

PRESS START TO CHOOSE

COIN DOOR PROTECTION MENU

EXIT COIN DOOR PROTECTION

COIN DOOR PROTECTION YES/NO

MAXIMUM PULSE WIDTH COUNT 00

GOOD COIN CLEAR COUNT 00

RESET COIN DOOR ALARM COUNT

COIN DOOR 1 ALARM COUNT 00

COIN DOOR 2 ALARM COUNT 00

COIN DOOR 3 ALARM COUNT 00

TO CHANGE VALUES

MOVE TRACKBALL LEFT TO DECREASE

MOVE TRACKBALL RIGHT TO INCREASE

COIN DOOR PROTECTION MENU

COIN DOOR PROTECTION is implemented by

monitoring the coin switch pulse width. A pulse longer

than the MAXIMUM COUNT sets the game alarm

counter. Each count represents about 4 milliseconds.

If two game alarms occur then the game halts and

displays a coin failure message. Any unused credits in

the game are cleared.

A count of good coin drops is kept and each time the

GOOD COIN COUNT is reached the game alarm

counter is cleared. This allows an occasional coin

switch glitch to be tolerated.

A count of all switch alarms for each coin door is also kept.

These counters can be cleared by selecting RESET COIN

DOOR ALARM COUNTS and RESET COIN SWITCH

COUNTS.

NOTE:

Coin mechanisms and bill acceptors vary

widely. Test your game thoroughly with the

coin protection ON to make sure the software

is compatible with your hardware.

Skill Level Adjustment

(In Regular Play Only)

Golden Tee ‘99 Golf allows for changing the level of

skill needed to play the game. This feature is good for

locations with younger or novice players who are less

skilled at the game, or expert or accomplished players

who demand a greater challenge.

NOTE:

The skill level adjustment will only affect

regular play. Skill level on all Tournament

games is controlled by the ITS, so every

machine plays the same.

Golden Tee ‘99 GolfV1.00 ID 00000001

TRACKBALL UP TO MOVE UP

TRACKBALL DOWN TO MOVE DOWN

PRESS START TO CHOOSE

SKILL LEVEL ADJUSTMENT

SKILL LEVEL 1 - EASIEST

SKILL LEVEL 2

SKILL LEVEL 3

SKILL LEVEL 4

SKILL LEVEL 5 - HARDEST

SKILL LEVEL ADJUSTMENT SCREEN

To set the game to an easy skill level, highlight...

SKILL LEVEL 1 - EASIEST.

To set the game to a difficult skill level,

highlight...SKILL LEVEL 5 - HARDEST.

SKILL LEVEL 2, SKILL LEVEL 3, and SKILL

LEVEL 4 are settings between the easiest and hardest

levels. Sometimes it is best if the skill level is adjusted

gradually over a period of time.

NOTE:

This menu will not affect tournament play. The

skill level of each tournament is set by the ITS

and is the same on every tournament

machine.

Golden Tee Golf ’99 - 18

Hole In One Contest Mode

(In Regular Play Only)

The HOLE IN ONE CONTEST MODE can be used

if you or your location wants to give away prizes for a

hole-in-one during regular play.

Golden Tee ‘99 GolfV1.00 ID 00000001

TRACKBALL UP TO MOVE UP

TRACKBALL DOWN TO MOVE DOWN

PRESS START TO CHOOSE

HOLE IN ONE CONTEST MODE

NO HOLE IN ONE CONTEST

HOLE IN ONE CONTEST- WIN IMMEDIATELY

HOLE IN ONE CONTEST- QUALIFY TO WIN

HOLE IN ONE CONTEST MODE SCREEN

Setting the HOLE-IN-ONE CONTEST "ON" will

cause a loud siren and fanfare to go off if a hole-in-one

is made. The hole-in-one message can be altered

depending on your type of contest.

HOLE IN ONE CONTEST - WIN IMMEDIATELY

will display a "YOU HAVE WON" message.

HOLE IN ONE CONTEST - QUALIFY TO WIN

will display a "YOU HAVE QUALIFIED" message.

This feature will only work in regular play. Hole-in-

ones are handled differently during tournament play.

NOTE:

Unless you are running your own special

contest, apart from ITS Tournaments, this

setting should remain OFF. Players and

locations can become confused when this

message appears during Regular Play,

especially while a Tournament is in progress.

Three Hole Operator Event

Golden Tee 99 comes with a new feature that allows for

in-house league or tournament play. This feature sets

up a 3-hole course for head-to-head competition. 1 to 4

Players select a course, and a random selection of 3

different holes becomes available for play.

After the 3 holes are played, the final scores are

displayed. Great Shot Points and Longest Drive are

used as tie-breakers. This screen will be displayed until

an official presses the start button. Next the course

record screens will appear.

You can run this event in many different ways. You can

have a single elimination system, a winner stays, loser

pays system, a best of 3 system, etc. The 3-hole feature

encourages fast play and allows for a large number of

challengers.

Golden Tee ‘99 GolfV1.00 ID 00000001

TRACKBALL UP TO MOVE UP

TRACKBALL DOWN TO MOVE DOWN

PRESS START TO CHOOSE

3 HOLE OPERATOR EVENT SETTINGS

EXIT 3 HOLE OPERATOR EVENT SETTINGS

3 HOLE OPERATOR EVENT ON/OFF

COINS PER PLAYER 2

TO CHANGE VALUES

MOVE TRACKBALL LEFT TO DECREASE

MOVE TRACKBALL RIGHT TO INCREASE

3 HOLE OPERATOR EVENT SCREEN

To activate the 3 Hole Event, highlight 3 HOLE

OPERATOR EVENT SETTINGS on the Operator

Adjustables screen.

Highlight 3 HOLE OPERATOR EVENT and spin the

trackball to the right to change OFF to ON. OFF de-

activates the 3-hole event and allows regular play. ON

activates the 3-hole event and will NOT allow regular

play. Online ITS Tournament play is NOT available

while the game is in this setting.

You may want to change the coins needed to play in the

3-hole event. Highlight COINS PER PLAYER and

move the trackball to the left or right to adjust the

number of coins needed to begin a 3-hole event game.

The default setting is 2.

19 - Golden Tee Golf ‘99

Game Audits

The GAME AUDITS MENU will supply you with a

detailed accounting of helpful and informative

bookkeeping and statistics. It can be accessed through

the OPERATOR MODE MENU.

Golden Tee ‘99 GolfV1.00 ID 00000001

TRACKBALL UP TO MOVE UP

TRACKBALL DOWN TO MOVE DOWN

PRESS START TO CHOOSE

GAME AUDITS MENU

EXIT AUDITS

DISPLAY COIN AUDITS

DISPLAY GAME SELECTION AUDITS

NUMBER OF GOLFERS AND HOLES PLAYED

ASPEN LAKE AUDITS

COCONUT COVE AUDITS

RANCHO SAGUARO AUDITS

RESET AUDITS

GAME AUDITS SCREEN

Display Coin Audits

When you choose to review the coin audits, the Display

Coin Audits screen will appear.

Golden Tee ‘99 GolfV1.00 ID 00000001

PRESS START TO EXIT

DISPLAY COIN AUDITS

COIN DOOR 1 COINS XX

COIN DOOR 2 COINS XX

COIN DOOR 3 COINS XX

TOTAL COINS XX

COINS TO ITS XX

TOURNAMENT GAMES PLAYED XX

REGULAR GAMES STARTED XX

SECONDS PER COIN XX

DISPLAY COIN AUDITS SCREEN

Display Game Selection Audits

This menu will show the audits for each game selection.

Golden Tee ‘99 GolfV1.00 ID 00000001

PRESS START TO EXIT

DISPLAY GAME SELECTION AUDITS

STROKE GAMES XX

SKINS GAMES XX

ASPEN LAKE COURSE XX

COCONUT COVE XX

RANCHO SAGUARO XX

FORWARD ONLY STROKES XX

DISPLAY GAME SELECTION AUDITS SCREEN

Number of Golfers and Holes Played

This menu displays how many games were played by 1,

2, 3, or 4 players and how may holes were played

during a game.

Golden Tee ‘99 GolfV1.00 ID 00000001

PRESS START TO EXIT

NUMBER OF GOLFERS AND HOLES

PLAYED

TOTAL 1 GOLFER GAMES XX

TOTAL 2 GOLFER GAMES XX

TOTAL 3 GOLFER GAMES XX

TOTAL 4 GOLFER GAMES XX

TOTAL 1-8 HOLE GAMES XX

TOTAL 9-17 HOLE GAMES XX

TOTAL 18 HOLE GAMES XX

TOTAL FULL GAMES STARTED XX

NUMBER OF GOLFERS AND HOLES PLAYED SCREEN

Golden Tee Golf ’99 - 20

ASPEN LAKE Audits

This menu displays the audits for the ASPEN LAKE

course.

Golden Tee ‘99 GolfV1.00 ID 00000001

PRESS START TO EXIT

ASPEN LAKE AUDITS

TOTAL GAMES XXX

TOTAL HOLES PLAYED XXX

AVERAGE HOLES PER GAME XXX

TOTAL STROKES XXX

TOTAL PUTTS XXX

TOTAL WATER OR UNPLAYABLE BALLS XXX

TOTAL OUT OF BOUNDS SHOTS XXX

TOTAL DELAY OF GAMES XXX

ASPEN LAKE AUDITS SCREEN

COCONUT COVE Audits

This menu displays the audits for the COCONUT

COVE Audits course.

Golden Tee ‘99 GolfV1.00 ID 00000001

PRESS START TO EXIT

COCONUT COVE AUDITS

TOTAL GAMES XXX

TOTAL HOLES PLAYED XXX

AVERAGE HOLES PER GAME XXX

TOTAL STROKES XXX

TOTAL PUTTS XXX

TOTAL WATER OR UNPLAYABLE BALLS XXX

TOTAL OUT OF BOUNDS SHOTS XXX

TOTAL DELAY OF GAMES XXX

COCONUT COVE AUDITS SCREEN

RANCHO SAGUARO Audits

This menu will display the audits for the RANCHO

SAGUARO course.

Golden Tee ‘99 GolfV1.00 ID 00000001

PRESS START TO EXIT

RANCHO SAGUARO AUDITS

TOTAL GAMES XXX

TOTAL HOLES PLAYED XXX

AVERAGE HOLES PER GAME XXX

TOTAL STROKES XXX

TOTAL PUTTS XXX

TOTAL WATER OR UNPLAYABLE BALLS XXX

TOTAL OUT OF BOUNDS SHOTS XXX

TOTAL DELAY OF GAMES XXX

RANCHO SAGUARO AUDITS SCREEN

Reset Audits

This menu will reset your audits.

Golden Tee ‘99 GolfV1.00 ID 00000001

TRACKBALL UP TO MOVE UP

TRACKBALL DOWN TO MOVE DOWN

PRESS START TO CHOOSE

RESET AUDITS

NO RESET AUDITS

RESET AUDITS

RESET AUDITS SCREEN

If you wish to set all of the game audits (described

above) back to zero, highlight RESET AUDITS from

this menu and press the START button. The screen will

briefly display AUDIT RESET. Be careful, because

once you have reset the Audits, the data is lost forever.

If you change your mind and decide not to reset the

audits to zero, highlight NO RESET AUDITS and you

will exit this screen without making any changes.

21 - Golden Tee Golf ‘99

Tournament Menu

(Tournament Version Only)

Golden Tee ‘99 GolfV1.00 ID 00000001

TOURNAMENT MENU

EXIT TOURNAMENT

TOURNAMENT OPERATOR ADJUSTABLES

DISPLAY TOURNAMENT AUDITS

DISPLAY HARDWARE AUDITS

DISPLAY TIMERS

TOURNAMENT MENU SCREEN

Select TOURNAMENT OPERATOR

ADJUSTABLES to enter into a menu of tournament

settings and options. Most of these settings will not be

necessary for normal tournament access and phone

connections, and should be left at the factory settings as

shown on the screen displayed on page 21.

DISPLAY TOURNAMENT AUDITS displays

detailed tournament audits on the tournament games

played on the machine. Most of these audits are not

necessary for routine information and collection

purposes. This information may be used to help

determine possible tampering or game problems.

DISPLAY HARDWARE AUDITS displays the

voltage readings for the PCB during initial power up of

the game and during play of the game.

DISPLAY TIMERS displays time settings that your

machine is currently using. These settings are set by the

ITS via modem. It also displays game ID and serial

numbers.

Tournament Operator Adjustables

Most of these settings will not need to be changed for

normal tournament access and phone connections in

most locations. The settings should remain as shown in

the screen display below.

Golden Tee ‘99 GolfV1.00 ID 00000001

TOURNAMENT OPERATORS ADJUSTABLES

EXIT ADJUSTABLES

FORCE TOURNAMENT UPLOAD YES/NO

OUTSIDE LINE ACCESS NUMBER 0

OUTSIDE LINE ACCESS DELAY 2

ROTARY DIAL PHONE LINE YES/NO

MODEM CONNECT TIMEOUT 1:30

DISPLAY UPLOAD DIAGNOSTICS YES/NO

DISABLE ITS ACCESS YES/NO

DISABLE MODEM CONNECTION YES/NO

TOURNAMENT OPERATOR ADJUSTABLES MENU

FORCE TOURNAMENT UPLOAD may be used if

you need to force a phone call to the ITS. To force a

call, highlight FORCE TOURNAMENT UPLOAD

using the trackball. Then move the trackball to the right

to display YES. When you exit out of Test Mode, the

game will automatically make a phone call attempt. If

the call is successful, this setting will default back to

NO. If the call is not successful, the game will continue

to call periodically until a successful call is made.

Some phone systems or companies may require an

initial prefix, such as "9", before dialing. Highlight

OUTSIDE LINE ACCESS NUMBER to select your

desired prefix. Moving the trackball left or right will

increase or decrease the number. When the desired

number is displayed, press the START button. Zero

means no prefix is used.

Some phone systems or companies may require a delay

before dialing in order to connect to a dial tone.

Highlight OUTSIDE LINE ACCESS DELAY and

move the trackball left or right to select the desired

delay. The number represents seconds. When the

desired delay time is displayed, press the START

button. The default delay is 2.

Some older locations may still use rotary, or pulse

phone systems. You can change the game to accept

rotary phone lines by highlighting ROTARY DIAL

PHONE LINE and then moving the trackball to the

right to change the setting to YES. If your location uses

the more common tone lines, make sure this setting is

set to NO.

Golden Tee Golf ’99 - 22

MODEM CONNECT TIMEOUT is used to adjust

the amount of time the modem remains on line in order

to complete a phone call. If you notice your game

timing out before a connected call is completed, you

may wish to increase this setting, to allow for longer

connect time. The default setting is 1:30.

DISPLAY UPLOAD DIAGNOSTICS will display de-

bugging code on the screen during a phone call. This

setting should remain on NO.

DISABLE ITS ACCESS will completely disable the

game from trying to make a call. To avoid losing your

tournament capability, this setting should remain on

NO.

DISABLE MODEM CONNECTION is used at the

factory during production and should remain on NO.

Display Tournament Audits

This screen shows a detailed history of tournament

activity on your machine. Normally, you will not need

to access this screen. These audits can not be reset by

the operator. At the start of each tournament, this audits

screen is reset to zero by the ITS. You can use this

screen to verify your total ITS collections, and verify

any power loss or reset claims by players.

Golden Tee ‘99 GolfV1.00 ID 00000001

DISPLAY TOURNAMENT AUDITS

TOTAL GAMES STARTED XXX

TOTAL GAMES COMPLETED XXX

TOTAL GAMES PLAYER QUIT XXX

TOTAL GAMES TIMED OUT XXX

TOTAL GAMES POWER LOSS XXX

TOTAL GAMES RESET LOSS XXX

TOTAL GAMES BELOW CUTOFF XXX

TOTAL NAMES ENTERED XXX

TOTAL NAMES DROPPED XXX

TOTAL NAMES POWER LOSS XXX

TOTAL NAMES RESET LOSS XXX

TOTAL ITS GAMES BILLED XXX

TOTAL ITS COIN XXX

DISPLAY TOURNAMENT AUDITS SCREEN

Display Hardware Audits

This screen displays various voltage readings that your

PCB is at during initial power up and play of the game.

Golden Tee ‘99 GolfV1.00 ID 00000001

PRESS START TO EXIT

DISPLAY HARDWARE AUDITS

POWER ON POWERUPS XX

RESET POWERUPS XX

VOLTAGE OK POWERUPS XX

VOLTAGE LOW POWERUPS XX

VOLTAGE HIGH POWERUPS XX

VOLTAGE OK GAMES XX

VOLTAGE LOW GAMES XX

VOLTAGE HIGH GAMES XX

DISPLAY HARDWARE AUDITS SCREEN

Display Timers

This screen displays various time settings that your

machine is currently using. These settings are set by the

ITS via modem.

Golden Tee ‘99 GolfV1.00 ID 00000001

DISPLAY TIMERS

ITS TIME YY-MM-DD HH:MM:SS

LOCAL TIME YY:MM:DD HH:MM:SS

TOURNAMENT START TIME YY:MM:DD HH:MM:SS

TOURNAMENT END TIME YY:MM:DD HH:MM:SS

SPECIALS START YY:MM:DD HH:MM:SS

SPECIALS END YY:MM:DD HH:MM:SS

CALL IN TIME YY:MM:DD HH:MM:SS

FIRST TRY TIME YY:MM:DD HH:MM:SS

NEXT TRY TIME YY:MM:DD HH:MM:SS

CALL IN ATTEMPTS XX

GAME ID 00000001

BOARD SN 00000001

DISPLAY TIMERS SCREEN

ITS TIME is the current time read by the real time

clock on the PCB using Greenwich Mean Time minus

12 hours.

LOCAL TIME is the current time in your time zone.

TOURNAMENT START TIME and END TIME

show the current settings for the most current

tournament.

23 - Golden Tee Golf ‘99

SPECIALS START and END refers to any special

contests during a tournament such as a Hole-in-One

contest over a weekend.

CALL IN TIME is the approximate time that your

machine calls in to the ITS.

FIRST TIME TRY and NEXT TIME TRY show

when your game began calling the ITS and when it will

try again. These times will only show if a first attempt

at a call was unsuccessful.

CALL IN ATTEMPTS shows the number of

unsuccessful phone calls, if any.

GAME ID NUMBER should match the ITS number on

your game cabinet. If this number does not match your

game cabinet, call Incredible Technologies service

department immediately, as this problem will hinder

tournament play.

PCB SERIAL NUMBER should match the AAMA

sticker on your PCB. If this number does not match

your PCB, call Incredible Technologies service

department immediately, as an incorrect number will

hinder tournament play.

NOTE:

Your programmed Game ID Number and

AAMA PCB serial number appear on this

screen. Use this information to verify that they

are the same as the stickers on your cabinet

and PCB. If these numbers do not match, you

will not receive correct tournament data.

Contact Incredible Technologies immediately.

Leaderboard Menu

The factory default for Golden Tee ‘99 displays pre-set

initials and scores on the Leaderboard, which allows for

a sense of competition and improvement to the player.

If you are going to run your own league or tournaments,

you may wish to delete these placeholders so only real

players are displayed on the Leaderboard.

Golden Tee ‘99 GolfV1.00 ID 00000001

TRACKBALL UP TO MOVE UP

TRACKBALL DOWN TO MOVE DOWN

PRESS START TO CHOOSE

LEADERBOARD MENU

EXIT LEADERBOARD MENU

DISPLAY LEADERBOARD MENU

CLEAR LEADERBOARD MENU

LEADERBOARD MENU

To view the various course Leaderboards, highlight

DISPLAY LEADER BOARD MENU.

To clear all of the scores and names in the various

course leader boards, select CLEAR LEADER

MENU.

Display Leaderboard Menu

Golden Tee ‘99 GolfV1.00 ID 00000001

TRACKBALL UP TO MOVE UP

TRACKBALL DOWN TO MOVE DOWN

PRESS START TO CHOOSE

EXIT LEADERBOARD MENU

DISPLAY ASPEN LAKE LEADERBOARD MENU

DISPLAY COCONUT COVE LEADERBOARD MENU

DISPLAY RANCHO SAGUARO LEADERBOARD MENU

DISPLAY LEADERBAORD MENU

Select the course you wish to look at, and press the

START button. The screen will stay on until you press

START again to exit. You can use this information to

determine your tournament or league winners. Great

shot points have been included on this screen for use as

tie breakers.

NOTE:

Great Shot Points are not displayed during the

game, so players may not be aware of their

Great Shot Point total.

Golden Tee Golf ’99 - 24

Clear Leaderboard Menu

Golden Tee ‘99 GolfV1.00 ID 00000001

TRACKBALL UP TO MOVE UP

TRACKBALL DOWN TO MOVE DOWN

PRESS START TO CHOOSE

CLEAR LEADERBOARD MENU

CLEAR ASPEN LAKE LEADERBOARD MENU

CLEAR COCONUT COVE LEADERBOARD MENU

CLEAR RANCHO SAGUARO LEADERBOARD MENU

CLEAR LEADERBOARD MENU

When selecting an in-house tournament, you should

clear all of the names and scores from the course you

wish to play on. Highlight the course Leaderboard and

press START. All of the initials and scores will be

cleared, and the Leaderboard will be empty. Players

who complete an 18 hole course on the cleared course

will have their statistics saved on the Leaderboard until

it is cleared again.

System Tests Menu

Golden Tee ‘99 Golf has been inspected and tested at the

factory, and most likely the game will be in perfect

working order when you plug it in. If you are

experiencing any problems with the game, the System

Tests Menu is a good place to start when tracking down

the problem. The System Tests MENU can be found in the

OPERATOR MODE MENU by pressing the test switch

located just inside the coin door of the cabinet, or set DIP

Switch 1 on the Main PCB to the OFF position.

Golden Tee ‘99 GolfV1.00 ID 00000001

TRACKBALL UP TO MOVE UP

TRACKBALL DOWN TO MOVE DOWN

PRESS START TO CHOOSE

SYSTEM TESTS MENU

EXIT TESTS

VIDEO SCREEN TESTS

FULL GROM CHECKSUM TEST

FAST GROM CHECKSUM TEST

VIDEO RAM TEST

PALETTE RAM TEST

BOARD TESTS

SOUND TEST

PLAYER CONTROLS TEST

VOLTAGE ADJUST TEST

SIGN TEST

SERIAL PORT TEST

SYSTEM TESTS MENU

Video Screen Test

You can test your monitor and adjust colors by

choosing VIDEO SCREEN TESTS and pressing the

START button.

Golden Tee ‘99 GolfV1.00 ID 00000001

VIDEO SCREEN TEST

TO VIEW VIDEO TEST SCREENS

PRESS FACE LEFT OR RIGHT BUTTONS

PRESS START AT ANY SCREEN TO EXIT

FOLLOWING SCREENS ARE AVAILABLE

COLOR ADJUSTMENT

SCREEN GRID PATTERN

RED SCREEN

GREEN SCREEN

BLUE SCREEN

WHITE SCREEN

VIDEO SCREEN TEST SCREEN

When the FACE LEFT or FACE RIGHT buttons are

pressed, the screen changes to display a grid of colored

rectangles. Use these colors as a guide and adjust your

monitor so they look as good as possible. This test can

be exited at any time by pressing the START button.

25 - Golden Tee Golf ‘99

Full GROM Checksum Test

Choose Full GROM Checksum Test from the System

Test Menu to test the Graphics chips on the PCB. This

test performs a complete test of the Graphics ROM's.

While the test is in progress the following message is

displayed:

FULL GROM CHECKSUM TEST - 15 SEC TO FINISH

FULL GROM CHECKSUM TEST SCREEN

(Test In Progress)

When the test is completed the GROM Test Screen is

displayed.

Golden Tee ‘99 GolfV1.00 ID 00000001

FULL GROM CHECKSUM TEST

GROM CHECKSUMSTAT GROM CHECKSUMSTAT

GRMA_0 XXXXXX GOOD GRMB_0 XXXXXX GOOD

GRMA_1 XXXXXX GOOD GRMB_1 XXXXXX GOOD

GRMA_2 XXXXXX GOOD GRMB_2 XXXXXX GOOD

GRMA_3 XXXXXX GOOD GRMB_3 XXXXXX GOOD

GRMC_0 XXXXXX GOOD PROM_0 XXXXXX GOOD

GRMC_1 XXXXXX GOOD PROM_1 XXXXXX GOOD

GRMC_2 XXXXXX GOOD PROM_2 XXXXXX GOOD

GRMC_3 XXXXXX GOOD PROM_3 XXXXXX GOOD

FULL GROM CHECKSUM TEST: (PASSED or FAILED)

PRESS START BUTTON TO EXIT

PRESS LEFT BUTTON TO LOOP TEST

FULL GROM CHECKSUM TEST SCREEN

(Test Completed)

• If all checksums are shown in white, the test passed

and your game is in good working order.

• If any checksums are bad, they will be displayed in

red text on this screen. This means that the GROM

is defective and needs to be replaced. Call your

distributor or the Incredible Technologies, Inc.

Service Department for further help.

• To loop this test, press FACE LEFT button.

• To exit this test, press the START button.

Fast GROM Checksum Test

Choose FAST GROM CHECKSUM TEST from the

SYSTEM TEST MENU to test the Graphics chips on the

PCB. This test performs a partial test of the Graphics

ROM's. While the test is in progress the following

message is displayed:

FAST GROM CHECKSUM TEST

FAST GROM CHECKSUM TEST SCREEN

(Test In Progress)

When the test is completed the GROM Test Screen is

displayed.

Golden Tee ‘99 GolfV1.00 ID 00000001

FAST GROM CHECKSUM TEST

GROM CHECKSUMSTAT GROM CHECKSUMSTAT

GRMA_0 XXXXXX GOOD GRMB_0 XXXXXX GOOD

GRMA_1 XXXXXX GOOD GRMB_1 XXXXXX GOOD

GRMA_2 XXXXXX GOOD GRMB_2 XXXXXX GOOD

GRMA_3 XXXXXX GOOD GRMB_3 XXXXXX GOOD

GRMC_0 XXXXXX GOOD PROM_0 XXXXXX GOOD

GRMC_1 XXXXXX GOOD PROM_1 XXXXXX GOOD

GRMC_2 XXXXXX GOOD PROM_2 XXXXXX GOOD

GRMC_3 XXXXXX GOOD PROM_3 XXXXXX GOOD

FULL GROM CHECKSUM TEST: (PASSED or FAILED)

PRESS START BUTTON TO EXIT

PRESS LEFT BUTTON TO LOOP TEST

FAST GROM CHECKSUM TEST SCREEN

(Test Completed)

• If all checksums are shown in white, the test passed

and your game is in good working order.

• If any checksums are bad, they will be displayed in

red text on this screen. This means that the GROM

is defective and needs to be replaced. Call your

distributor or the Incredible Technologies, Inc.

Service Department for further help.

• To loop this test, press FACE LEFT button.

• To exit this test, press the START button.

Golden Tee Golf ’99 - 26

Video RAM Test

This test performs a complete test of the Graphics video

RAM. The video RAM is tested in two pages. The

following message will be displayed as each page is

tested.

RUNNING VIDEO PLANE A/B. PAGE 0

When the test is completed the results will be displayed

as follows.

Golden Tee ‘99 GolfV1.00 ID 00000001

VIDEO RAM TEST

VIDEO PLANE A PAGE 0 STATUS = 0000

VIDEO PLANE A PAGE 1 STATUS = 0000

VIDEO PLANE B PAGE 0 STATUS = 0000

VIDEO PLANE B PAGE 1 STATUS = 0000

U32 GOOD U35 GOOD U30 GOOD U31 GOOD

VIDEO RAM TEST [PASSED or FAILED]

PRESS START BUTTON TO EXIT

PRESS LEFT BUTTON TO LOOP TEST

VIDEO RAM TEST SCREEN

• If the game passes this test, zeros will be displayed

in white along with a VIDEO RAM TEST

PASSED message.

• If the test fails, a non-zero status and VIDEO RAM

TEST FAILED message will be displayed in red.

Call your distributor or the Incredible

Technologies, Inc. Service Department for further

help.

• To loop this test, press the FACE LEFT button.

• To exit this test, press the START button.

Palette RAM Test

Golden Tee ‘99 GolfV1.00 ID 00000001

PALETTE RAM TEST

PALETTE TEST STATUS= 0000

RED 00000000 GREEN 00000000 BLUE 00000000

00000000 00000000 000000000 000000000

00000000 00000000 000000000 000000000

00000000 00000000 000000000 000000000

00000000 00000000 000000000 000000000

PALETTE RAM TEST (PASSED or FAILED)

PRESS START BUTTON TO EXIT

PRESS LEFT BUTTON TO LOOP TEST

PALETTE RAM TEST SCREEN

Board Test

This test will perform all of the system's tests at one time.

PROGRAM MEMORY U45-U48 (GOOD or BAD)

PALETTE RAM TEST

RED GOOD GREEN GOOD BLUE GOOD

PALETTE RAM TEST (PASSED or FAILED)

VIDEO RAM TEST

U32 GOOD U35 GOOD U30 GOOD U31 GOOD

VIDEO RAM TEST [PASSED or FAILED]

GROM TEST

GROM CHECKSUMSTAT GROM CHECKSUMSTAT

GRMA_0 XXXXXX GOOD GRMB_0 XXXXXX GOOD

GRMA_1 XXXXXX GOOD GRMB_1 XXXXXX GOOD

GRMA_2 XXXXXX GOOD GRMB_2 XXXXXX GOOD

GRMA_3 XXXXXX GOOD GRMB_3 XXXXXX GOOD

GRMC_0 XXXXXX GOOD PROM0 XXXXXX GOOD

GRMC_1 XXXXXX GOOD PROM1 XXXXXX GOOD

GRMC_2 XXXXXX GOOD PROM2 XXXXXX GOOD

GRMC_3 XXXXXX GOOD PROM3 XXXXXX GOOD

FAST GROM CHECKSUM TEST: (PASSED or FAILED)

! ! ! BOARD TEST (PASSED or FAILED) ! ! !

PRESS START BUTTON TO EXIT

PRESS LEFT BUTTON TO LOOP TEST

BOARD TESTS SCREEN

Sound Test

Choose SOUND TEST from the System Test Menu to

test the sounds and speakers in the game. The sound

section also controls the coin meter, and you can test it

from this section as well.

Golden Tee ‘99 GolfV1.00 ID 00000001

TRACKBALL UP TO MOVE UP

TRACKBALL DOWN TO MOVE DOWN

PRESS START TO CHOOSE

SOUND TESTS

EXIT SOUND TESTS

COIN METER TEST

TEST ALL SOUND ROMS

SROM0 - BROKEN GLASS

SROM1 - FABULOUS SHOT !

HOLE IN ONE EVENT

MUSIC

SOUND TESTS SCREEN

To test the coin meter, choose COIN METER TEST

from this menu. If everything is working properly, the

meter should increment each time the START button is

pressed while this line is highlighted.

27 - Golden Tee Golf ‘99

Control Panel Test

When CONTROL PANEL TEST is selected, the screen

will display a diagram of a typical GOLDEN TEE ‘99

GOLF control panel. The controls are highlighted on

the diagram when the controls are active. Test all of the

controls, including test and service switches. Press

FACE LEFT and FACE RIGHT together to exit this

test.

CONTROL PANEL TEST SCREEN

Voltage Adjust Test

Use this screen to adjust the voltage to the PCB. It is

important that the voltage be set correctly to avoid reset

games or lost video sync.

Golden Tee ‘99 GolfV1.00 ID 00000001

PRESS START TO EXIT

VOLTAGE ADJUST TEST

VOLTAGE HISTORY IS RESET ON EXIT

RIGHT NOW:

CURRENT VOLTAGE IS OK/HIGH/LOW

VOLTAGE ADJUST TEST SCREEN

CURRENT VOLTAGE shows the current status of

your voltage. If the voltage is low or high, you may

experience some game problems. Adjust your voltage

to read 5.2 volts across an IC on the PCB. Exit this

screen and re-enter to update your voltage history.

Sign Test

(Tournament Version Only)

This test checks the integrity of the connection from the

PCB to the LED sign. Press the LEFT or RIGHT

button to activate the sign test. The LED sign will

display the code version number, followed by a string of

letters and numbers, then a solid bar will scroll across

the display.

Golden Tee ‘99 GolfV1.00 ID 00000001

SIGN TEST

SIGN COMMUNICATION OK

SIGN STATUS XX

PRESS START BUTTON TO EXIT

PRESS LEFT OR RIGHT BUTTON TO RESET SIGN

SIGN TEST SCREEN

Use this test to visually check for non-functioning LED

segments.

The video screen will display the communication status.

If the status is bad, contact your distributor or the IT

service department.

Serial Port Test

(Tournament Version Only)

Golden Tee ‘99 GolfV1.00 ID 00000001

SERIAL PORT TEST

PRESS START TO EXIT

SPECIAL LOOPBACK TEST CABLES MUST BE

CONNECTED FOR TEST TO WORK CORRECTLY

CHANNEL A CONNECTOR [GOOD/BAD]

DATA [GOOD/BAD]

RTS TO CTS [GOOD/BAD]

SIGN CONNECTOR [GOOD/BAD]

DATA [GOOD/BAD]

CHANNEL B GAME CONNECTOR [GOOD/BAD]

DATA [GOOD/BAD]

RTS TO CTS [GOOD/BAD]

TEST PASSED 0 TEST FAILED 0

PRESS START BUTTON TO EXIT

SERIAL PORT TEST SCREEN

NOTE:

Special cables are needed for this test.

(FACTORY USE ONLY).

Golden Tee Golf ’99 - 28

APPENDIX A

General Troubleshooting

Phone Line Connection Problems (Tournament Version Only)

Symptom Probable Cause Solution

Your game is unable to make an initial call

to ITS.

Improper phone connection. Double check all of the cable connections to

make sure they are placed and connected

properly.

Be sure the cables are plugged all the way

into their connectors. A click should be

heard when a proper connection is made.

Make sure the modem is switched ON and

its power supply is connected.

Enter Test Mode and go to the Tournament

Menu. Under Tournament Operator

Adjustables, set FORCE TOURNAMENT

UPLOAD to YES. Exit Test Mode and try

again.

Modem in lost state. Turn the game OFF then ON again.

During setup, the text message on the screen

says MODEM DIALING and quickly

changes to MODEM HANGING UP.

No dial tone. Check for a dial tone by plugging in a

regular telephone into the extra jack on the

modem. A dial tone should also be heard

from the phone.

Double check all of the cable connections.

Be sure the game is connected to a direct

outside line. ITS will not work if connected

through certain phone systems. A fax or

credit card line may be used.

Make sure the modem is switched ON and

its power supply is connected.

Set outside line access number, if needed

(Tournament Operator Adjustables on page

21)

Wrong setting in the Tournament Operator

Adjustables.

Be sure all the settings in the Tournament

Operator Adjustables are correct. Refer to

Tournament Operator Adjustables on page

21 for correct tournament settings.

29 - Golden Tee Golf ‘99

Phone Line Connection Problems (Tournament Version Only)

Symptom Probable Cause Solution

Modem connects but does not transfer data. Bad modem or ID number. Enter Test Mode and verify the ID number

at the top of the screen. If the ID number is

not valid, call Incredible Technologies

Service Department.

Be sure the game is connected to a direct

outside line. ITS will not work if connected

through certain phone systems. A fax or

credit card line may be used.

Line is busy. A normally good call is sometimes cut off

or interrupted by a busy signal or a noisy

line. Wait and the game will try to call

again automatically; or go into Test Mode

and force a phone call from the Tournament

Operator Adjustables menu.

Turn the game OFF then ON again.

Modem transfers data but the screen reads

CALL IN UNSUCCESSFUL.

Improper connection. Be sure the game is connected to a direct

outside line. ITS will not work if connected

through certain phone systems. A fax or

credit card line may be used.

If the line is being shared, the other phone,

fax or credit card machine may be trying to

make a call. Wait a few minutes and try

again.

A loose connection or bad wire may be the

cause. Make sure all connections are

securely in place.

Modem in lost state. Turn the game OFF then ON again.

Golden Tee Golf ’99 - 30

VIDEO PROBLEMS

Symptom Probable Cause Solution

No picture Check Dip switches. SW1-Dip switches, 1 thru 4 must be

“ON”.

SW2-Dip switches 1 and 2 must be ‘ON’,

and 3 and 4 must be ‘OFF’

Bad connection. Make sure there are good connections

from the board's video outputs to the

monitor's video inputs.

Monitor. Make sure the monitor is operating

correctly. (Check it with another

compatible logic board.)

JAMMA Harness connected improperly. Identify Pin 1 on the JAMMA connector

and on the PCB. If installed incorrectly,

damage to the PCB may have occurred.

Scrambled Picture Missing sync connection or misadjusted

monitor.

Check the sync connection - Adjust

monitor

Missing colors or washed out color Bad video connections. Check the video red, green, and blue

connections.

Bright, blurry, or rolling picture Misadjusted monitor. Adjust the monitor, not the board. (Refer

to your monitor manual.)

Picture too large, too small, or off center Misadjusted monitor. Adjust the monitor, not the board. (Refer

to your monitor manual.)

Video image is flipped Misadjusted monitor. Reverse the monitor's convergence wires

or flip the monitor 180º. (Refer to your

monitor manual.)

Bad images in picture Bad GROM. Do GROM test. Check IC pins to make

sure none are bent over.

Diagonal white lines GND problem. Earth and Logic GND's should be

connected at the power supply.

31 - Golden Tee Golf ‘99

SOUND PROBLEMS

Symptom Probable Cause Solution

No sound +12 vdc power supply is bad Try another +12 vdc power supply.

Bad connection to the board. Check for +12 vdc power on the board.

Check for +5 vdc power on the board.

Check the volume setting in the OPERATORS ADJUSTABLE

section of the Operator Mode.

JAMMA Harness connected improperly Check the speaker connection.

Miscellaneous Identify Pin 1 on the JAMMA connector and on the PCB. If

installed incorrectly, damage to the PCB may have occurred.

CONTROL PROBLEMS

Symptom Probable Cause Solution

Buttons do not work or are partly

inoperable. Or the selections keep

scrolling on Operator Mode menus.

Switches not properly connected. Make sure that the common post of the

switch is connected to ground.

Make sure each individual switch is

working by doing the Control Panel Test

found in the SYSTEM TESTS section.

Make sure that the signal wire for that

particular switch is connected to the

normally open post of the switch.

JAMMA Harness connected improperly. Identify Pin 1 on the JAMMA connector

and on the PCB. If installed incorrectly,

damage to the PCB may have occurred.

Coin counter not working Miscellaneous. Make sure that the signal wire has a

connection from the switch to the board.

Make sure +12v is hooked up to the

counter.

The signal wire is not connected to coin

counter. (Check continuity).

Verify that the counter is good.

Trackball mounted correctly but is

swinging 45° out of line

SW1-Dip switch 3, found near the

JAMMA, is not “ON”

Make sure SW1-Dip switch 3 is “ON”.

In a two or more player game, controls

only work for players 1 and 3

SW1-Dip switch 2, found near the

JAMMA, is in the “OFF” position.

SW1-Dip switch 2 must be in the “ON”

position for cabinets with one set of player

controls.

Trackball does not work No +5 voltage. Bad inductor(L7) or bad connection to

trackball.

Golden Tee Golf ’99 - 32

POWER-UP PROBLEMS

Symptom Probable Cause Solution

Bo reaction when game is turned ON Voltage too high. Power supply is too high. Power should

be between +5v & 5.2v. (Measured on the

circuit board).

Cabinet is not connected to earth ground.

(All metal should be connected to the

earth ground).

Short between power and ground. Check

for foreign material.

Disconnect the harness and measure the

resistance between power and ground. It

should read around 600 ohms. (0 ohms is

a dead short).

Make sure the harness is not shorting to

anything, such as bare or frayed wires

shorting out each other or hitting bare

metal.

No power from the power supply. Replace power supply.

Power supply needs adjustment. Power supply too low. (Should ideally be

between +5v & +5.2v). (Measured on the

circuit board).

Short on the board. Check for loose or foreign material on the

board.

JAMMA Harness connected improperly. Identify Pin 1 on the JAMMA connector

and on the PCB. If installed incorrectly,

damage to the PCB may have occurred.

Screen flashes repeatedly Open on socketed IC’s Check for bent pins on socketed parts.

Make sure that all IC's are seated in their

sockets properly.

+5v setting too low. Check voltage. (Measured on the circuit

board).

SW2-Dip switches near the green LED

may not be set correctly.

Make sure SW2-Dip switch #1 and # 2 are

“ON”, and #3 and #4 are “OFF”.

33 - Golden Tee Golf ‘99

LED SIGN Problems (Tournament Version Only)

Symptom Probable Cause Solution

The LED message does not get updated

correctly

Improper connection. Check that the sign cable is plugged into

the jack labeled SIGN on the PCB, and the

other end is plugged into the LED sign.

Check that the power jack is connected

properly to the sign and that the sign is

getting power.

The LED sign is not on No power. Make sure there is +12 volts going to the

sign.

Long screw is used in the top instead of

the bottom.

Bad cable. Verify that the sign cable is good, by

trying a known good cable or by testing

the continuity of the cable.

MISCELLANEOUS PROBLEMS

Symptom Probable Cause Solution

Green LED not blinking Program not running. Make sure all socketed IC’s are seated

correctly. Look for bent pins.

Bad connections. Make sure you have continuity from PCB

to power supply.

Loose pin on ASIC (U1) Call Incredible Technologies, Inc.

Operator adjustables keep changing Low battery voltage Battery should be 2 to 3 volts.

Bad static RAM (U50) Replace.

Sounds Bad Miscellaneous Check the speaker connections.

Game comes up in Test Mode Dip Switch 1 is “OFF” Make sure SW1-Dip Switch 1, near the

JAMMA, is in the “ON” position.

Trackball mounted correctly but is

swinging 45° out of line

SW1-Dip switches are not all “ON” Make sure the SW1-Dip Switches are all

“ON”

Golden Tee Golf ’99 - 34

APPENDIX B

JAMMA Harness Connection and Cabinet Schematic

JAMMA Harness Connection

WIRE COLOR SOLDER SIDE PARTS SIDE WIRE COLOR

Black GND A 1 GND Black

Black GND B 2 GND Black

Red +5 vdc C 3 +5 vdc Red

Red +5 vdc D 4 +5 vdc Red

E 5

Orange +12 vdc F 6 +12 vdc Orange

KEY H 7 KEY

J 8 Coin Counter Red-Green

K 9

Yellow-Green Left Speaker (-) L10 Left Speaker (+) Yellow-Red

M11

Green-Black Video Green N12 Video Red Red-Black

White Video Sync P13 Video Blue Blue-Black

Orange-Black Service R14 Video GND White-Black

S15 Test Blue

Green-Blue Coin2 T16 Coin1 Red-White

Red-Yellow Start 2 U17 Start 1 Red-White

V18

W19

X20

Y21

Brown-Yellow Player 2 - Face Left Z22 Player 1 - Face Left Brown-White

White-Yellow Player 2 - Face Right a23 Player 1 - Face Right Yellow-White

Orange-Yellow Volume Down b24 Volume Up Orange-White

c25 Coin 3 Gray-White

d26

Black GND e27 GND Black

Black GND f28 GND Black

Trackball Harness Connection

Memory Board Connector Trackball Connector

PIN WIRE #6 - Black PIN WIRE #1 - Black

PIN WIRE #1 - Red PIN WIRE #2 - Red

PIN WIRE #2 - Yellow PIN WIRE #3 - Yellow

PIN WIRE #3 - Green PIN WIRE #4 - Green

PIN WIRE #5 - Blue PIN WIRE #5 - Blue

PIN WIRE #4 - Purple PIN WIRE #6 - Purple

NOTE: Remember to connect the trackball cable to JP7 of the Memory Board. (Labeled as Player 1)

35 - Golden Tee Golf ‘99

Cabinet Schematic

Golden Tee Golf ’99 - 36

APPENDIX C

ITS Tournament Overview

The ITS, or International Tournament System , is a networked system of game machines that are hooked up to a

central computer via normal telephone lines. Each dedicated tournament game contains special tournament software and

communications hardware that offers players a choice of regular or tournament play. Tournament play allows players

from all over the U.S. to compete for prizes. Various skill-based tournaments will be held throughout the year, offering

challenges and prizes to players across the country.

The ITS was designed to be as hands-free as possible for the operator and location. Each machine has special

communications hardware that easily hooks up to a normal telephone jack. Each game machine is programmed to make a

short, toll-free phone call during off hours. The toll-free number that the game dials costs nothing to the operator or

location. The tournament machines call the ITS central computer and download statistics from that day's tournament

play. During the same call, the central computer sends the new tournament leaders, previously gathered from all of the

games in the tournament, back to the game machine. Then, throughout the day, the new national and local tournament

leaders are viewed on each game monitor during attract sequences.

The ITS is capable of supporting over 100,000 tournament machines on-line. The ITS will feature a number of

national tournaments throughout the year. These tournaments will vary in length from weekly to monthly, with top prize

awards ranging from one thousand to potentially one-hundred thousand dollars or more. Before each tournament begins,

a message is sent to the LED sign attached to each cabinet, announcing the start dates and prize structure of the upcoming

tournament. At the specified date, the tournament automatically begins on all of the valid tournament games.

The entry fee to join the tournament is about twice the cost as regular play, and is entered into the game by the player

each time he/she plays. About half of this tournament income is shared by the operator and location. The rest of the

tournament fee is sent to the ITS for national, regional and local prize funds, as well as administrative expenses. The

ITS receives a portion of tournament plays only. Any earnings collected from regular and practice play is not

considered tournament income. This income is split between the operator and location as they see fit.

Connecting to the ITS has been made as simple and complete as possible. The game hooks up to a normal telephone

jack using regular telephone wire. Once plugged in, an automatic setup procedure logs the game machine as an active

tournament terminal. A simple form must also be filled out, detailing some specific information for that machine, such as

game ID number, location name, preferred time for phoning into the central computer, and pertinent billing information.

The ITS was designed with the operator in mind. Each ITS-compatible game can act just like a regular video game on

his route. The games can be moved to different locations and will play a regular, non-tournament game even when not

hooked into the ITS. Location change forms and off-line notices are supplied in your operator forms package, to keep

your tournament activities up to date.

37 - Golden Tee Golf ‘99

Game Highlights

• High-earning, successful game.

• Hooks up with a single existing phone line.

• Game machines can be moved from location to location.

• Up to 8 ITS game machines can be linked from modem to modem at a single location and share one phone line.

• Regular play is always available, regardless of tournament status.

• More tournament-compatible games are in development.

Tournament Highlights

• Many tournaments will be held throughout the year.

• Tournaments may vary in length, from one to four weeks.

• Cash prizes will be awarded to national, regional, and local winners.

• Every game machine in a tournament will offer an even playing field.

• Different tournaments can be running at the same time.

• Corporate sponsors are being considered for added prizes and important promotions.

Networking Highlights

• The game machines automatically call the ITS central computer each night on a toll free number.

• The toll free number costs nothing to the operator or location.

• New statistics, such as new leaders and scores, are sent to the central computer.

• Important messages are sent periodically to the LED signs that advertise new tournaments and important information.

• Tournament updates, compiled from all of the collected data of the previous day, are sent to each game machine.

• The entire phone call process takes less than a minute.

• If the game fails to connect with the central computer, it will try again until it is successful.

Accounting Highlights

• Tournament billing is routed through an automatic debit account.

• Statements are faxed or mailed before each debit transaction, detailing the tournament billing.

• Debit transactions take place one time per tournament, after each tournament ends.

• Complete tournament audits and collection procedures assure accurate and easy record-keeping.

Golden Tee Golf ’99 - 38

ITS Game Initialization Form

(Tournament Version Only)

Included with your game is the ITS Game Initialization Form. Fill it out completely and fax or mail it to Incredible

Technologies. The information you supply goes into the tournament database and is necessary for your game to join the

tournament.

IMPORTANT!

Your game will NOT be included in the tournament until this form is received by Incredible Technologies.

ITS Debit Account Form

(Tournament Version Only)

Included in your game is an ITS Debit Account form. All operators must have and maintain a bank account for

automatic payment of the ITS portion of tournament play. Please fill out the form completely and send it back to

Incredible Technologies, Inc. with a voided blank check or deposit slip from the account. You only have to fill out this

form one time, no matter how many ITS games you operate. All of your ITS games can be billed to a single account.

NOTE:

Your game will NOT be included in the tournament until this form is received by Incredible Technologies.

At the end of each tournament, you will be faxed a statement that details the ITS portion of the tournament plays on all

of your ITS machines. Your account will be automatically debited for the full amount about four to seven business days

after each tournament ends. If the correct funds are not available, the next tournament will be unavailable on your games.

The ITS bills for a portion of tournament plays only. Regular play is disregarded by the ITS.

39 - Golden Tee Golf ‘99

APPENDIX D

ITS Tournament Procedures

Official Tournament Rules

Insert coins into an active ITS Tournament game and press Start. A selection screen will appear when a tournament is in

progress. Select Tournament Play and Insert the appropriate tournament entry fee.

Play the entire Official Tournament Course. If your final score qualifies, the game will ask you to enter your full name

and Social Security Number. This information is used for winner verification purposes.

Use your real name and Social Security Number or your score may be invalidated.

Players can enter the Tournament as often as desired. A player's best score will be displayed on the Leaderboard.

Profanity, vulgarity, invalid names and invalid Social Security Numbers will be removed from the Leaderboard. Players

who allow their score to be entered under another person's social security number will be banned from all ITS

tournaments.

You must be 18 years or older to enter a Tournament and claim a prize. Misuse of or tampering with tournament

equipment will disqualify the player and/or location from the Tournament.

The Tournament is subject to rules and procedures of the ITS, the tournament location, federal and state law. Void

where prohibited.

A list of winners will be provided to each tournament location when the Tournament ends.

Winners are solely responsible for claiming their winning prize by calling Incredible Technologies at (847) 870-

7027.

Game operators and locations will not pay prizes.

A player can only win one prize per Tournament. Only one National winner per location is allowed for each tournament.

Only one Regional winner per location is allowed for each tournament. Only one Local winner per location is allowed

for each tournament. Tournament rules are subject to change.. New or altered rules from the ITS supersede these

posted rules and may be posted on the game LED displays.

Prize winners must sign a written claim form and present a copy of a driver's license or other picture ID

containing the winner's social security number.

Malfunctions void all plays and refunds are given at the discretion of each tournament location for paid entry fees only.

The ITS Review Board shall decide all filed grievance claims. The Board's decisions are final and claims are limited to

refund of entry fee only.

Employees of Incredible Technologies, Inc. and manufacturers of games used on the ITS system and their immediate

families are not eligible. Rules and regulations specific to each Tournament and winner lists from previous tournaments

are available by sending a self-addressed, stamped envelope to:

Incredible Technologies, Inc.

ITS Information

1600 Hicks Road

Rolling Meadows, IL 60008-1240

http://www.itsgames.com

NOTE:

Tournament Rules are subject to change and will

be updated on the LED signs of participating

tournament games.

Golden Tee Golf ’99 - 40

Beginning a Tournament

The following describes what will happen when a tournament begins on your game.

1. The LED sign displays a new message 3 to 5 days before the tournament start date. The sign message displays the

Tournament name, start and end dates, prize money and tournament rules.

2. Tournament data is downloaded to each machine before the tournament begins. Each machine receives the

Tournament parameters and start and end dates of the Tournament.

3. The Tournament is accessible by players on the start date of the tournament. When a game is started, a special

screen gives players a choice to play Regular Play or Tournament Play. This screen is seen only when a tournament

is running.

4. Players with qualifying scores are asked to enter their full name and social security number at the end of each

tournament game. The player's name is then displayed on the various Tournament Leaderboard, shown during the

game's attract cycle.

5. Each night the game machine calls ITS Central via a toll-free number. During the short call, tournament

information is transferred. Transferred data includes National, Regional and Local leaders and Social Security

numbers, total number of tournament plays, and any special or instant winners.

6. ITS Central processes the data received from all of the tournament machines. After removing duplicate or bogus

entries, updated Leaderboards are generated and sent to each machine during the next call. New LED sign messages

are also sent, updating the various Leaderboards, prize funds, and other important tournament data. Advertising by

corporate sponsors may also appear on the LED sign and game monitor.

Collection Procedure

Although the tournament games have been designed to be as hands free as possible, there is an extra step that must be

addressed during the collection process. You will need to separate the ITS portion of the game's earnings before you

make your location split. The ITS only bills for valid tournament plays. All Regular play is ignored by the ITS.

1. Collect each ITS Machine as usual on your normal route.

2. Press the Test Mode button located inside the coin door. This accesses the game's Test software.

3. From the Main Menu, use the Trackball to highlight ITS COLLECTION REPORT AS DOLLARS or ITS

COLLECTION REPORT AS COINS and press the START button. Both reports will show the same information,

one in total coins and one in total US dollars. You can use either report to match your collection preference.

4. Review the entire report. The total dollars or total coins should agree with your collection. Note the number of

completed tournament games.

5. Review the ITS portion figure. This amount should be separated from your collection before splitting with the

location. ITS coins are calculated from valid tournament games only.

6. After separating the ITS coins and writing down the values, it is advised to reset the audits so each collection gives

accurate data. Highlight RESET COLLECTION COUNTS and press START.

7. When you are finished reviewing the coin reports screen, highlight EXIT and press the START button to return to

the Main Menu.

41 - Golden Tee Golf ‘99

8. Once the ITS portion is separated, split your collection with your location as usual.

9. Deposit the ITS portion of your collection into your ITS Automatic Debit Account regularly to guarantee sufficient

funds and continue Tournament service.

Ending a Tournament

The following describes what happens at the end of a tournament.

1. The Tournament ends on the advertised end date. Each tournament game is programmed to disable Tournament

play at this time. Games in progress are allowed to continue until completed.

2. The disabled game machine will no longer allow Tournament play. Players will no longer have a selection

screen for Regular or Tournament play. Regular play is completely unaffected by the end of the tournament and the

game will play as usual.

3. Final Tournament data is downloaded from each machine during the regularly scheduled call-in time. A new

LED message is sent to each machine at this time, announcing the end of the Tournament.

4. A list of Tournament winners is compiled after all of the games have called the ITS with final data. It may take

three to four days for all of the games to make their final calls. When all of the games have reported in, the final

standings are transferred to each machine.

5. Final Leaderboard and new LED messages continue to appear on each game machine after the Tournament

ends, to allow players to view the final standings.

6. Winners Lists are made available to locations for display. The signs include instructions to the winners on how

to claim their prizes. Incredible Technologies is responsible for distribution of prizes to verified winners. Operators

are responsible for posting the Winners Lists at their locations.

7. The game machines continue to call the ITS each night, even when no tournament is running. Machines

remain on-line in order to monitor for potential problems, as well as be ready to accept new LED sign messages and

starting data for the next tournament.

8. A statement is faxed to the operator at the end of the tournament that details the tournament activity on each of

his machines. The total number of tournament plays and the dollar value of the ITS portion of the tournament plays

appears on the statement, along with the date that the ITS funds will be transferred from the operator's automatic

debit account. Operators are usually given 4 to 7 business days to make their ITS funds available before the funds

are electronically transferred.

Golden Tee Golf ’99 - 42

Prize Claim Procedure

The ITS will send you an official Winners List Poster for each tournament location at the end of a Tournament.

Distributors and Operators are required to distribute the Winners Lists to their locations.

Operators should encourage locations to post the Winners List near the game machine for at least one month or longer

after the end of the Tournament.

Tournament winners must call Incredible Technologies, Inc. at (847) 870-7027 to claim their prizes. Winners will be

asked for name, social security number and winning location, along with their address and phone number.

The ITS will mail Tournament winners a Prize Release form that must be signed and returned with a photocopy of a

valid ID that contains the winners address and social security number, for proper verification.

The ITS will mail the winner their prize after a designated verification period, if no duplicate or false claims have arisen.

All tournament prize winnings will be reported to the IRS as required. Winners of prizes totaling $600 or more will

receive a 1099 tax form at year end.

Tournament winners are solely responsible for claiming their prize and verifying their scores.

Incredible Technologies, Inc. is solely responsible for payments of prizes to valid tournament winners. Distributors,

operators and locations are not responsible for payment of prizes to winners.

If discrepancies or duplicate claims arise, Tournament winners may be subject to validation tests and other forms of

verification by the ITS Review Board.

Tournament winners must be 18 years or older to enter a Tournament and claim a prize.

Misuse of or tampering with tournament equipment will disqualify the player and/or location from the Tournament.

The Tournament is subject to rules and procedures of the ITS, the tournament location, federal and state law. Void

where prohibited.

43 - Golden Tee Golf ‘99

Tournament Icons

Your game contains a simple icon feature that will assist you and your location in monitoring the status of your phone

line connections. During the attract sequence of the game, which is displayed when no one is playing, a number of small

icons are displayed. The displayed icons will help you determine at a glance the working status of the tournament and

your game cabinet.

Tournament Status OK

This icon means that your game is running correctly and

your line connections are good. Your game will make one

toll-free phone call each day, even if there is no tournament

running.

Tournament Disabled.

This icon is displayed when the tournament has been

automatically shut off on the game. The tournament is

disabled if a game was unsuccessful in connecting to the

ITS over a 24 hour period. The tournament also may be

disabled from the ITS if tournament forms have not been

sent, tournament fees have not been paid, or game

tampering is detected.

Often, the game can be restored to the tournament in

progress by forcing a successful phone call using the

tournament menu in test mode. If the tournament has been

reset for other reasons, call your distributor.

Attempting to make a call to ITS

This icon will appear if an attempt to make a scheduled call

was unsuccessful. When an attempted call is unsuccessful,

the game will try again automatically. The number of

attempts is displayed next to the icon at the bottom of the

screen, during the attract mode.

The game will try to call frequently for the first couple of

hours, and occasionally after that. After about twenty-two

hours, the game will frequently try to call again. If the

game has not connected to the ITS within this 24 hour

period, the tournament is automatically disabled from the

tournament. At this point, the only way to enable the

tournament is to force a successful phone call using the

tournament menu in test mode, or to fix whatever problem

is preventing a successful call.

No Dialtone detected, or modem

problem.

This icon is displayed if the game detects a problem with

the modem, or if the game cannot find a dial tone. This is

a good warning to the location manager that the phone

lines may be disconnected and should be checked. It may

also indicate a faulty modem, which should be serviced

immediately.

To verify a dial tone, plug a normal telephone into the

empty jack on the modem. A dial tone should be heard. If

not, there is a problem with the phone line, such as a

broken phone line or disconnection. Check all of your

phone connections and be sure they are correct and secure.

This icon will also appear if the phone line is in use when

the game attempts to make a call. If this situation occurs,

the game will attempt to make the call at a later time.

Golden Tee Golf ’99 - 44

APPENDIX E

Frequently Asked Questions About The ITS

How do I make the game call into ITS at any time?

Go into the test software and choose Tournament Menu with the trackball and START button. Next

select Tournament Operator Adjustables. The top line is Force Tournament Upload. Change that to Yes

by rolling the trackball to the right. Exit the test software by repeatedly pressing the START button. The

game will then make a call to ITS. If the call fails, enter the test software and exit immediately and the

game will attempt to call again.

Does the game call the ITS, or does ITS call the game?

The game is programmed to call into ITS on a toll free line one time each day.

When does the game call ITS and how many times?

The game calls once during the night at a predetermined time selected by ITS. The default calling time is

between 2 and 4 in the morning.

What if the game is turned off and misses its scheduled time to call ITS?

As soon as the game is turned on it will attempt to complete a call to ITS.

Can the operator select a specific time for the game to call ITS?

Yes, ITS can give the cabinet a specific time within the hour. Example: between 7am and 8am. Specify

this on the Game Initialization Form.

How will I know if a successful call has been made?

When the game is attempting a call, the screen will display an ITS CALL screen. The text near the bottom of

the screen will show the status of the phone call. A typical successful call will display the following status

messages in this order: Modem Found, Modem Dialing, Modem Connected, Connected to ITS, Data

Transfer Successful.

What are the symbols at the bottom of the screen for?

Your game will display a number of icons at the bottom of the screen, to help you know the status of your

game at a glance. There are four different icons that are displayed: The gold ITS logo means that you are

connected to the ITS system and everything is OK.

The blue telephone icon means that your game has tried to make a call, but was unsuccessful, perhaps from a

busy signal or interrupted call. A number will appear next to the icon, showing how many call attempts have

been attempted. If this number is big, you probably have a problem with your phone line or modem and it

should be checked out.

45 - Golden Tee Golf ‘99

The telephone with the red X through it means that your modem is not receiving a dial tone. This may be

caused by the phone cord being disconnected, loss of power to the modem, etc. When this icon is showing, it

means that your game is not calling the ITS and will not receive or transmit tournament data.

The ITS logo with a red X through it means that your game has been disabled and removed from the

tournament. This happens when your game has not been able to call in for more than 24 hours. Often, this

can be remedied by forcing a call or checking your phone connections. This icon may also appear if you

have not sent in your paperwork. Your game will not receive tournament information until your paperwork

has been processed through the ITS.

When I attempt to make a call to ITS, the game comes back and says no dial tone

found. What do I do?

Plug a normal telephone into the extra phone jack on the modem. A dial tone must be heard on the phone. If

no dial tone is heard check your phone line connections. If a dial tone is heard, try dialing a phone number to

make sure you can call out.

Can I use this game on a rotary phone system?

The game is factory set to call out on a tone system, but you can set your game to use rotary or pulse dialing. Enter the

test software and select Tournament Menu with the trackball and START button. Next select Tournament Operator

Adjustables. Highlight the Rotary Dial to yes using the trackball and START button.

I have a dial tone but I never get a successful call into ITS. What do I check first?

Make sure the settings in the Tournament Operator Adjustables menu are correct (Refer to page 21 of the manual). Ask

yourself some questions. Is this location on a rotary phone system? Is the phone line on a computer phone system? (The

tournament may not work on all phone systems.) Do I have to dial something to reach an outside line?

When I force a call into ITS it says modem connected but the game comes back and

says ITS call unsuccessful. Why?

The game may be on a noisy phone line. This can be caused by old phone lines, too many devices on the line, or bad

lines coming from the phone company. A direct connection to the box coming into the building or a new separate phone

line added to the building is a way to rectify this problem.

I made a successful call so why can't I enter the tournament?

The paper work for the game must be sent or faxed to the ITS for processing. Without the paperwork, your game will not

receive tournament data and LED messages. Also, a Tournament must be in progress. A game can be added to the

tournament up to 1 week after the official start of a new tournament so be sure to get your paperwork in early.

If my board fails can I just go to the distributor and get a new board?

NO. Your game PCB has an ID number programmed into it to match your game cabinet. The board ID number that is in

the software must match the cabinet ID number, in order for you to receive tournament data. Contact your distributor for

all advance replacements, which must be properly initialized by Incredible Technologies.

Golden Tee Golf ’99 - 46

If I call the distributor or ITS for service, what information should I have ready in

case the service technician needs it?

The Game ID Number is how your game's status is tracked. The ID number of the cabinet must match the ID number in

the software. You can verify this by going into the test software. The Game ID Number is displayed at the top of every

screen in the test software. It is also displayed in the Tournament Menu, at the bottom of the Display Timers screen. The

number must be 8 digits long, leading with zeros.

Why does the overhead sign have a different name than my location name?

When you send in your paperwork, a sign message is generated for your game. This sign message will display the name

of the location. If the location name on the LED display is wrong, you should first check that you sent in the correct

Game ID Number. The Game ID Number is located on the back of the cabinet and in the test software. Verify that those

numbers are the same. Go into the test software to verify the ID number there. It is displayed at the top of the screen and

must be 8 digits long leading with zeros. If your ID Numbers are correct, call or fax ITS and a corrected message will be

made.

My overhead sign has some kind of test version on it all the time. Why is it doing that

and how do I get a regular message on it?

The ITS pre-loads an introductory message at the factory and should appear when the game is turned on. Sometimes, the

sign may lose this message and default to the sign test. To get your correct sign message back, force a phone call to the

ITS. The new message will be loaded during this successful call. Turn the game off and back on again to make sure the

message stays in memory. Run the sign test in the test software to make sure the main board is communicating to the

sign.

How do I know when there is a tournament?

Upcoming tournament dates and prizes will be announced on the game’s LED sign a week in advance. Your distributor

will most likely supply this information to you on your first tournament. Announcements of subsequent tournaments will

be included with your billing statements at the end of each tournament.

How do the players know when there is a tournament?

Special tournament messages are periodically downloaded to the game's LED message display. These messages

announce new tournaments and prizes. The individual Local prize is also announced. The message board begins

announcing a new tournament about 4 days before the tournament begins.

How often do Tournaments run?

Tournaments are held about once a month. They usually last about 2 1/2 weeks, with about a week and a half between.

Why don't you run tournaments continually, back-to-back?

Time between tournaments is useful for many reasons. It gives the players a feeling of conclusion, and a sense of

anticipation for the next tournament. It gives operators a chance to hook up new games or move their existing games to a

new location. It gives the ITS time to generate and mail winners posters to operators.

47 - Golden Tee Golf ‘99

How does a player enter the tournament?

A player enters any amount of money into the tournament cabinet. If a tournament is active, a special selection screen

appears. This selection screen gives the player a choice to play a regular game of golf at your normal coin settings, or

enter the special tournament course for a specified fee. If the player chooses to enter the tournament, the game asks for

the correct number of coins to be added.

Can I adjust the skill level on the tournament?

The skill level and other parameters such as wind speed and pin placement are controlled and set by the ITS. These

settings are the same on every machine. You can change the skill level on the regular games without affecting

tournament play.

How do I know how much money to send to the ITS?

When collecting your ITS machines, it is important to separate the ITS money from your collection before making your

split, so you don't overpay your locations. During your routine collection, use the ITS Collection Report in the test

software to determine how much money to set aside for the ITS. You can use either the Collection Report as Dollars or

the Collection Report as Coins. It is strongly advised that you reset this report to zero after your collection, so each time

you collect, this report will reflect what is in the cash box.

If I reset my reports after each collection, how can I verify my totals at the end of a

tournament?

A second set of tournament statistics are stored in the test software, in the Tournament Audits screen, accessed from the

Tournament Menu. These numbers cannot be reset by the operator during a tournament and stay up for about a week

after a tournament ends. The statistics on this screen are reset to zero by the ITS before the start of each tournament.

How often do you transfer funds from my account?

The ITS bills one time at the end of each tournament. You will be faxed or mailed a statement about 4 days after the end

of the tournament. This statement shows the tournament activity on each of your ITS machines, and the total amount

owed to the ITS. A transfer date is also displayed, which is usually about 6 days after the statement is faxed or mailed.

You must have the full amount in your account by this date. Any questions or discrepancies should be handled before

this transfer date.

The billing statement doesn't match my collection numbers. What should I do?

A second set of tournament statistics are stored in the test software, in the Tournament Audits screen, accessed from the

Tournament Menu. These numbers cannot be reset by the operator during a tournament and stay up for about a week

after a tournament ends. Use this screen to verify the tournament numbers of your machine. Remember, this screen is

reset to zero by the ITS a few days before the start of each tournament.

How come the standings on the Leaderboards sometimes change after a tournament

ends?

The ITS collects data from all machines at the end of the day. Because of this, the Leaderboards are usually a day behind

and need an extra day to catch up with real-time play. The ITS collects and processes the final data to determine final

standings. Sometimes this takes a few days, due to unattended or off-line games. When the final data is collected, it is

processed to eliminate ineligible players and invalidated entries. The final Leaderboards are then sent back to the games

at the next call. This process may take a few days.

Golden Tee Golf ’99 - 48

How do I let my locations know who won?

After the final data is processed, the ITS generates posters of National, Regional, and Local winners. Winners posters for

each of your locations are mailed to operators about one week after the tournament ends. Operators are required to post

these posters at each location for at least 90 days.

How does a winner claim a prize?

A player calls the ITS to claim his prize. The player's name, address and social security number is taken and a

Verification Form is sent. The form must be signed and sent back, along with some form of proof of social security

number, such as a drivers license. After the Verification Form is returned and processed, the ITS sends the player his

check. The ITS pays all prizes to players. The collected funds sent to the ITS at the end of the tournament are used to

pay out prizes. Players call the ITS to claim their prize. The operator and location do not pay prizes.

APPENDIX F

Warranty Information

If the original purchaser discovers any physical defect in the media (disk, EPROM, tape) on which the software is

distributed or in the documentation, which in the opinion of Incredible Technologies, Inc. (IT) prevents the product from

being used as reasonably intended, IT will replace the media or documentation at no charge. The purchaser must return

the item to be replaced, with proof of purchase, to IT within 90 days after taking delivery of the software.

IT warrants to the original purchaser that the hardware product is in good working condition for a period of 90 days from

taking delivery of the product. Should this product, in IT's opinion, malfunction within the warranty period because of a

defect in design, materials, or workmanship, IT will repair or replace this product without charge under the terms as

follows. Replacement of either the hardware product or its component parts will be only on an exchange basis. Any

replaced parts or components become the property of IT. This warranty does not apply to those products which have been

damaged due to accident, abuse, improper installation, natural disaster, or unauthorized repairs or modifications.

IT excludes any and all implied warranties, including warranties of merchantability and fitness for a particular purpose,

and limits the purchaser's remedy to returning the software, hardware, or documentation to IT for replacement.

IT makes no warranty or representation, either express or implied, with respect to this software, hardware, or

documentation, their quality, performance, merchantability, or fitness for a particular purpose. This software,

hardware, and documentation are licensed "as is," and the purchaser/licensee assumes the entire risk as to their

quality and performance.

In no event will IT be liable for direct, indirect, special, incidental, or consequential damages arising out of the use

or inability to use the software, hardware, or documentation, even if advised of the possibility of such damages.

The warranty and remedies set forth above are exclusive and in lieu of all others, oral or written, express or

implied. No person, seller, dealer, agent, or employee is authorized to make any modification or addition to this

limited warranty.

Some states do not allow the exclusion of implied warranties or liability for incidental or consequential damages, so the

above limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you may also have

other rights that vary from state to state.

- INCREDIBLE TECHNOLOGIES, INC.

06/99
