Visit One Of Our Many Brick And Mortar Locations Nationwide!
QUALITY AUTOMOTIVE EQUIPMENT AT
DISCOUNT PRICES
(800) 673-8740
In Business Since 1982 Catalog Code: April-2018
www.GregSmithEquipment.com
2
WE ARE NOT RESPONSIBLE FOR MISPRINTS
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE
www.GregSmithEquipment.com
• 9,000 lb. Capacity
• Light Commercial Grade
• Dual Point Lock Release
• Symmetric Columns
• Asymmetric Arm Design
• Automatic Arm Restraints
• Clear Floor Design
• Powder Coat Finish
• FREE Truck Adapters
• Mounting Hardware
FEATURES
The Elite 9KOH is the perfect choice for those customers who
demand the most lifting capacity at the lowest possible price.
The overhead beam can be adjusted to two different height
settings: 11’ 6” or 11’ 10”.
9KOH Specifications
Capacity 9,000 lb.
Overall Height 142” (11’ 10”) Or 138” (11’ 6”)
Overall Floor Width 134 1/4” (11’ 2 1/4”)
Maximum Lift Height 80 1/4” (6’ 8 1/4”)
Inside Column 109 3/4” (9’ 1 3/4”)
Shipping Weight 1,500 lb.
LIGHT
COMMERCIAL
GRADE
LIGHT COMMERCIAL GRADE
Atlas RimRods
Atlas Single Screw-Up Adapters
Optional adjustable single screw-up lift
pads are now available for all Atlas two
post lifts. Screw-up adapters allow the
operator to “precisely position” the lift
pad in direct contact with the vehicle’s
lifting points. Please make sure of your
arm hole size before you order.
3 Different Kits On Our Website
Atlas PV-9HP Specifications
Capacity 9,000 lb.
Overall Height 166 1/2" - 174 1/2”
(13' 10 1/2" - 14' 6 1/2")
Overall Floor Width 135” (11’ 3”)
Maximum Lift Height 81 3/4” (6’ 9 3/4”)
Inside Column 112 1/4” (9’ 4 1/4”)
Shipping Weight 1,650 lb.
2 Feet Taller!
EXTRA TALL
Perfect For High Prole Vehicles
PV-9P Width Extension Kit
Adds 6 inches to the overall width of the Atlas PV-9P. ATPK-PV9P-WKIT
Add 6 Inches To
Overall Width
Increase The Width Of Your Existing PV-9P!
ELITE 9KOH
• Commercial Grade
• Direct Drive Cylinders
• Single-Point Lock Release
• Front Arms May Be Configured
Symmetric Or Asymmetric
• “Padded” Shut-Off Bar
• Powder Coat Finish
• Adjustable Height
• Clear Floor Design
• FREE Truck Adapters
• Mounting Hardware
• 5-Year Structural, 2-Year
Hydraulic Warranty
FEATURES
PV-9P
PV-9HP
Atlas PV-9P Specifications
Capacity 9,000 lb.
Overall Height 142 1/2” - 150 1/2”
(11’ 10 1/2” - 12’ 6 1/2”)
Overall Floor Width 135” (11’ 3”)
Maximum Lift Height 80 1/2” (6’ 8 1/2”)
Inside Column 112 1/4” (9’ 4 1/4”)
Shipping Weight 1,500 lb.
The Atlas PV-9P is a commercial grade two post lift that incorporates the same
arm and carriage design as our Industry leader PV-10P. The PV-9P has dual
direct drive cylinders and single point lock release.
The Atlas PV-9HP is the taller version of our PV-9P two post above ground lift.
Atlas 90HSC-SS Specifications
Capacity 9,000 lb.
Overall Height 142” (11’ 10”)
Overall Floor Width 134” (11’ 2”)
Maximum Lift Height 81 3/8” (6’ 9 3/8”)
Inside Column 109 1/2” (9’ 1 1/2”)
Shipping Weight 1,450 lb.
90HSC-SS
The Atlas 90HSC-SS features single piece columns and extra long carriages. The Atlas
9OHSC-SS two-post above ground lift is the perfect choice for smaller repair facilities
or Mr. Homeowner who demands the highest quality at the absolute best price.
WATCH OUR
VIDEO
ONLINE
The RimRod tire/wheel support attaches to most above ground lift arms.
For One Set of Four
• 9,000 lb. Capacity
• Light Commercial Grade
• Dual Hydraulic
Chain-Over Cylinders
• Single Piece Columns
• Single-Point Lock Release
• Symmetric Columns
• 3-Stage Super-Symmetric
Front Arms
• Powder Coat Finish
• Clear Floor Design
• FREE Truck Adapters
• Mounting Hardware
• 5-Year Structural Warranty,
1-Year Hydraulic Warranty
FEATURES
COMMERCIAL GRADE
FINANCING
AVAILABLE
FINANCING
AVAILABLE
COMMERCIAL GRADE
9KOH
The Atlas 9KOH has symmetric
columns and specially designed
arms that can be set in either the
symmetric or asymmetric position.
XH-ES-9KOH
XH-9KOHX
ATTD-RIMROD ATTD-RIMROD-KIT
ATPK-PV9PX
ATPK-S-SCREW-KIT1
ATPK-9OHSC-SS
ATPK-PV9PEH
1-Year Structural,
1-Year Hydraulic
Warranty
Mountable Wheel
Holders For Lift Arms
2-Year Structural,
2-Year Hydraulic
Warranty
TWO POST OVERHEAD LIFTS
$199
8 Piece Kit
Starting At
IN STORE PICK-UP PRICE
$2179
OR
$2429
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1725
OR
$1975
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$244
OR
$260
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$70
OR
$85
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$2295
OR
$2545
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1849
OR
$2099
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$132
IN STORE PICK-UP PRICE
$1545
3
WE ARE NOT RESPONSIBLE FOR MISPRINTS.
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE.
800.673.8740
TOLL
FREE
PV-10P OH -10X
Atlas PV-10P Specifications
Capacity 10,000 lb.
Overall Height Low: 142” (11’ 10”)
High: 146” (12’ 2”)
Overall Width 137 3/8” (11’ 5 3/8”)
Maximum Lift Height 82” (6’ 10”)
Between Columns 110 3/4” (9’ 2 3/4”)
Shipping Weight 1,900 lb.
Atlas APEX 10 Specifications
Capacity 10,000 lb.
Overall Height Low: 135 7/8” (11’ 3 7/8”)*
High: 139 7/8” (11’ 7 7/8”)
Overall Height w/ Cylinder 142 1/2” (11’ 10 1/2”)
Overall Width 139” (11’ 7”)
Max Lift Height (w/ adapters) 81 1/2” (6’ 9 1/2”)
Shipping Weight 1,750 lb.
• Commercial Grade
• Direct Drive Cylinders
• Single-Point Lock Release
• Front Arms May Be Configured
Symmetric Or Asymmetric
• “Padded” Shut-Off Bar
• Powder Coat Finish
• Adjustable Height
• Clear Floor Design
• FREE Truck Adapters
• Mounting Hardware
• 5-Year Structural, 2-Year
Hydraulic Warranty
FEATURES
• Commercial Grade
• Double S Column Design
• Direct Drive Cylinders
• Single-Point Lock Release
• Symmetric Columns
• “Padded” Shut-Off Bar
• Powder Coat Finish
• Adjustable Height
• Clear Floor Design
• FREE Truck Adapters
• FREE Screw-Up Adapters
• Mounting Hardware
• 5-Year Structural, 2-Year
Hydraulic Warranty
FEATURES
The Atlas PV10P is a commercial grade two-post lift designed to
lift a wide variety of vehicles. The PV10P has a low pad height to
accommodate passenger vehicles but is built to handle full size pickups.
The PV10P has dual direct drive cylinders and single-point lock release.
The Atlas APEX-10 was engineered and built to offer a commercial grade above
ground lift to those customers who have “fallen in love” with the Double S column
design. The Atlas APEX-10 can be installed with the columns positioned
symmetrically or asymmetrically. When the Apex columns are installed in the
asymmetrical configuration, there may be some benefit to open car doors.
When the Apex columns are installed in
the symmetric configuration there is
more width between the columns.
COMMERCIAL GRADE COMMERCIAL
GRADE
*Requires spacers
Includes These FREE Accessories:
Double Screw-Up Adapter Pads Truck Adapters
PV-10P Height
Extension Kit
Add 2 Feet
To Overall
Height To Your
Existing PV-10P ATPK-PV10PX-EXT
Atlas Wheel Stands
COMMERCIAL GRADE
TALLER
VERSION
AVAILABLE
The Atlas Wheel Stands can support up
to 6,000 lbs. and are the perfect choice
for those smaller shops who want the
advantages of a four post lift but have
only limited floor space. Turntables can
be placed on the wheel stands to turn any
two-post lift into an alignment lift.
*Turntables Sold Separately
WATCH OUR
VIDEO
ONLINE
Double S
Column Design
Direct Drive
Cylinders
Atlas OH-10X Specifications
Capacity 10,000 lb.
Overall Height 151 1/2” (12’ 7 1/2”)
Overall Floor Width 143 3/8” (11’ 11 3/8”)
Max Lift Height 84” (7’)
Inside Column 117 1/2” (9’ 9 1/2”)
Shipping Weight 1,800 lb.
• Commercial Grade
• Direct Drive Cylinders
• 2-Stage Heavy Duty
Symmetric Arms
• Single Piece Columns
• Symmetric Columns
• Extra Long Carriages
• Powder Coat Finish
• 10,000 lb. Capacity
• Clear Floor Design
• FREE Truck Adapters
• Mounting Hardware
• 5-Year Structural, 2-Year
Hydraulic Warranty
FEATURES
EXTRA WIDE
EXTRA TALL
This commercial grade two-post lift is the perfect choice for garages that
demand the highest quality at the absolute best price. The Atlas OH10X is
WIDER and TALLER than most above ground two-post lifts. The OH10X has
dual direct drive cylinders and single-point lock release.
Set Of 4
What ALI Certied Really Means
ALI Certied
APEX 10
APEX 10H
ALI (Automotive Lift Institute) governs the safety standards for
automotive lifts in the U.S. ALI Certified lifts must all pass the
exact same testing, material and operational standards. This
testing covers the structural integrity, proper control function and
even overloading the lift beyond its rated capacity. The procedures
are PASS - FAIL. Either you get the sticker or you do not. Rotary,
Forward, Mohawk and ATLAS Certified Lifts are all subject to the
exact same production and testing standards.
If a product carries the ALI Gold Label you can be assured that the equipment and
the manufacturing facility it is produced in are in compliance with the ALI Standard.
The facilities are audited at least two times, yearly, to guarantee the process and
product adhere to the ALI Guidelines.
IBC or International Building Code is in use in all 50 States. This Code states that for
every region governed by IBC, automotive lifts must adhere to the ALI Standard in
order to obtain permits for lift installation in new construction buildings.
ATPK-PV10PX
ATPK-OHX10000X
ATTD-SLJ-A000
ATTD-APEX10
ATTD-APEX10H
SYMMETRIC OR
ASYMMETRIC
COLUMN
CONFIGURATION
TWO POST OVERHEAD LIFTS
IN STORE PICK-UP PRICE
$2315
OR
$2565
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$357
OR
$482
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$2387
OR
$2637
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1321
OR
$1521
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$2445
OR
$2695
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$2645
OR
$2895
W/ SHIPPING INCLUDED
4
WE ARE NOT RESPONSIBLE FOR MISPRINTS
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE
www.GregSmithEquipment.com
Atlas APEX 12 Specifications
Capacity 12,000 lb.
Overall Height Low: 165” (13’ 9”)
High: 177” (14’ 9”)
Overall Width 155 3/4” (12’ 11 3/4”)
Max Lift Height 86” (7’ 2”)
Drive Thru 109 2/3” (9’ 1 2/3”)
Shipping Weight 2,100 lb.
Atlas APEX 15 Specifications
Capacity 15,000 lb.
Overall Height 174 1/2" (14' 6 1/2")
Overall Width 154 1/2" (12' 10 1/2")
Max Lift Height 87 1/2" (7' 3 1/2")
Drive Thru 107 1/2" (8' 11 1/2")
Shipping Weight 2,400 lb.
The Atlas Apex 12 is an ALI CERTIFIED overhead two-post lift with
two adjustable height settings and single point lock release.
PV-12P EXTRA WIDE
EXTRA TALL
EXTRA WIDE
EXTRA TALL
Atlas PV-12P Specifications
Low Middle High
Capacity 12,000 lb.
Overall Height 148 1/2”
(12’ 4 1/2”)‡
163 1/2”
(13’ 7 1/2”)
175 1/2”
(14’ 7 1/2”)
Height To Shut Off Bar 142” (11’ 10”)‡ 157” (13’ 1”) 169” (14’ 1”)
Overall Width 158” (13’ 2”)
Maximum Lift Height
(With Truck Adapters)
82” (6’ 10”)
Drive Thru 108 5/8” (9’5/8”)
Shipping Weight 2,250 lb.
‡ Requires purchase of additional shorter cables
Atlas PV-15P Specifications
Low Middle High
Capacity 15,000 lb.
Overall Height 150 3/8”
(12’ 6 3/8”)‡
162 3/8”
(13’ 6 3/8”)
177 3/8”
(14’ 9 3/8”)
Height To Shut Off Bar 140 3/4”
(11’ 8 3/4”)‡
152 3/4”
(12’ 8 3/4”)
167 3/4”
(13’ 11 3/4”)
Overall Width 158” (13’ 2”)
Maximum Lift Height
(With Truck Adapters)
79 3/4” (6’ 7 3/4”)
Drive Thru 109” (9’ 1”)
Shipping Weight 2,600 lb.
‡ Requires purchase of additional shorter cables
• Commercial grade
• Single point lock release
• Symmetric design
• Powder coat finish
• Adjustable to three (3) heights
• Free 12 piece truck adapter set
• Anchor bolts included
• 5 Year Structural Warranty,
2 Year Hydraulic Warranty
FEATURES
PV-15P
The Atlas PV-12P and PV-15P are commercial grade lifts designed to accommodate heavy, long wheel base trucks. The low pad height on the PV-12P allows the
operator to lift both cars and trucks. The larger arms and taller pad height on the PV-15P are designed for customers who primarily work on trucks and SUVs. The extra
distance between the columns accommodates wider vehicles or vehicles with wide rear-view mirrors. The extra height is perfect for tall vans and box trucks.
• Commercial Grade
• Direct Drive Cylinders
• Single-Point Lock Release
• “Padded” Shut-Off Bar
• Powder Coat Finish
• Adjustable Height
• Clear Floor Design
• FREE Truck Adapters
• FREE Screw-Up Adapters
• Mounting Hardware
• Professional Grade Arm
Lock Restraint System
FEATURES
• Commercial Grade
• Direct Drive Cylinders
• Single-Point Lock Release
• “Padded” Shut-Off Bar
• Powder Coat Finish
• Clear Floor Design
• FREE Truck Adapters
• FREE Screw-Up Adapters
• Mounting Hardware
• Professional Grade Arm
Lock Restraint System
FEATURES
ALI
Certied
ALI
Certied
COMMERCIAL
GRADE
The Atlas Apex 15 is an ALI CERTIFIED, commercial grade, overhead two-post lift
designed to accommodate both long wheel base trucks and passenger cars.
APEX 12 APEX 15
ATPK-PV12PX ATPK-PV15PX
ATT D-APEX12 ATTD-APEX15
At las 18K
The ALI CERTIFIED Atlas 18,000 lb capacity heavy duty two post lift meets the highest European
and American Lift Institute standards. This electro-hydraulic lift features the finest design,
engineering, and manufacturing that has made the Atlas brand a globally recognized stamp of
quality. Includes safety lowering valve, mechanical safety latch, synchronization cables, and high
quality steel to ensure a safe and powerful lift system. Arms, adapters, and carriages are usually
the first components to show excessive signs of wear on a low quality lift. Atlas takes important
steps to ensure that our components stay working correctly and safely for years to come.
ALI Certied
80" Maximum Lifting Height
IN STORE PICK-UP PRICE
$10195
OR
$10545
W/ SHIPPING INCLUDED
Atlas18k
TWO POST OVERHEAD LIFTS
IN STORE PICK-UP PRICE
$3115
OR
$3465
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$3635
OR
$3985
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$3260
OR
$3560
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$4940
OR
$5290
W/ SHIPPING INCLUDED
5
WE ARE NOT RESPONSIBLE FOR MISPRINTS.
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE.
800.673.8740
TOLL
FREE
The Atlas BP8000 is a base-plate two-post lift designed for low ceiling garages. The
total column height is 108” (9 feet.) This lift features a single-point lock release.
• 8,000 lb. Capacity
• Dual Hydraulic
Chain-Over Cylinders
• Single-Point Lock Release
• 3-Stage Super-Symmetric
Front Arms
• Automatic Arm Restraints
• Base-Plate Design
• Powder Coat Finish
• FREE Truck Adapters
• Mounting Hardware
• 5-Year Structural,
2-Year Hydraulic Warranty
FEATURES
The Atlas BP-12K base-plate style lift is equipped with single-point lock release – a very unique feature
for a base-plate style lift. With an overall column height of 9’ 3” the BP-12K is the ideal solution for a
garage with low ceilings.
Atlas BP-8000 Specifications
Capacity 8,000 lb.
Overall Height 108” (9’)
Overall Floor Width 132” (11’)
Maximum Lift Height 81 3/8” (6’ 9 3/8”)
Inside Column 109 5/8” (9’ 1 5/8”)
Shipping Weight 1,350 lbs.
Atlas BP-12000 Specifications
Capacity 12,000 lb.
Total Ceiling Height Required 122 ½” (10’ 2 ½”)
Overall Height 111 ¼” (9’ 3 ¼”)
Overall Floor Width 150 ¾” (12’ 6 ¾”)
Maximum Lift Height 80 ¾” (6’ 8 ¾”)
Inside Column 123 ½” (10’ 3 ½”)
Shipping Weight 2,300 lbs.
BP-8000
BP-12000
• 12,000 lb. Capacity
• Dual Hydraulic
Chain-Over Cylinders
• Single-Point Lock Release
• Automatic Arm Restraints
• 3-Stage Symmetric Arms
• Base-Plate Design
• Powder Coat Finish
• FREE Truck Adapters
• Mounting Hardware
• 5-Year Structural,
2-Year Hydraulic Warranty
FEATURES
Atlas Frame Adapters
The optional rear frame adapter set (2 pieces) is available for most of our Atlas line of 2-post lifts.
Works Great
For Ford®
Trucks!
PERFECT FOR LOW CEILINGS!
The Atlas BP-10000
commercial grade 2
post lift is built for those
customers who want
to lift heavy vehicles in
a low ceiling garage.
Columns have a middle
welded support gusset
that adds extra strength.
Atlas BP-10000 Specifications
Capacity 10,000 lb.
Overall Height 111 7/8” (9’ 3 7/8”)
Overall Floor Width 139 1/8” (11’ 7 1/8”)
Maximum Lift Height 86 3/8” (7’ 2 3/8”)
Inside Column 112 1/4” (9’ 4 1/4”)
Shipping Weight 1,640 lbs.
BP-10000
• 10,000 lb. Capacity
• Dual Hydraulic
Chain-Over Cylinders
• Single-Point Lock Release
• Automatic Arm Restraints
• 3-Stage Super-Symmetric
Front Arms
• Base-Plate Design
• Powder Coat Finish
• FREE Truck Adapters
• Mounting Hardware
• 5-Year Structural,
2-Year Hydraulic Warranty
FEATURES
ELITE 9KBP
• 9,000 lb. Capacity
• Light Commercial Grade
• Dual Point Lock Release
• Symmetric Arms
• Symmetric Columns
• Automatic Arm Restraints
• Base-Plate Design
• Designed For Low
Ceiling Clearance
• FREE Truck Adapters
• Mounting Hardware
• Powder Coat Finish
• 1-Year Structural, 1-Year
Hydraulic Warranty
FEATURES
Elite 9KBP Specifications
Capacity 9,000 lb.
Overall Height 111 1/2” (9’ 3 1/2”)
Overall Floor Width 134 1/2” (11’ 2 1/2”)
Maximum Lift Height 81” (6’ 9”)
Inside Column 110” (9’ 2”)
Shipping Weight 1,450 lbs.
The Elite 9KBP is a base-plate two-post lift designed for low ceiling garages. The total column height of 111
1/2” (9’ 3 1/2”) allows this lift to be installed in almost any professional or home garage with a ceiling as low
as 9’ 6”.
LIGHT COMMERCIAL GRADE
The Atlas Apex 9BP is an ALI CERTIFIED baseplate
two-post lift designed for low ceiling garages. The
total column height is 111 1/8" (9' 3 1/8").
Atlas APEX 9BP Specifications
Capacity 9,000 lb.
Overall Height 111 1/8" (9' 3 1/8")
Overall Floor Width 138 3/5" (11' 6 3/5")
Max Width (with Power Unit) 144" (12')
Maximum Lift Height 74 5/6" (6' 2 5/6")
Inside Column To Inside Column 111 1/3" (9' 3 1/3")
Drive Thru 97 1/3" (8' 1 1/3")
Shipping Weight 1,700 lbs.
• 9,000 lb. Capacity
• Dual Hydraulic
Chain-Over Cylinders
• Symmetric Arms
• Base-Plate Design
• Powder Coat Finish
• Mounting Hardware
• FREE Truck Adapters
• Dual Point Lock Release
• Automatic Arm Restraints
• Secondary Lock System (SLS)
FEATURES
ALI
Certied
COMMERCIAL GRADE
COMMERCIAL
GRADE
APEX 9BP
per set
IN STORE PICK-UP PRICE
$2290
OR
$2540
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$2395
OR
$2645
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$3100
OR
$3450
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1540
OR
$1790
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1622
IN STORE PICK-UP PRICE
$50
ATPK-BP8000
ATPK-FTA
XH-ES-9KBP
ATPK-BP10000X
ATTD-APEX9BP
ATPK-BP12000X
TWO POST BASEPLATE LIFTS
6
WE ARE NOT RESPONSIBLE FOR MISPRINTS
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE
www.GregSmithEquipment.com
Specifications
Capacity 8,000 LB
Overall Width without Motor 104 ½” (8’ 8 ½”)
Overall Length without Approach Ramps 175 ½” (14’ 7 ½”)
Maximum Wheel Base 153 ½” (12’ 9 ½”)
Garage Pro 8000
Hook Nosed Rack Ramps
The Atlas Garage Pro 8000 is one of our most popular 4-post lifts. These 8,000 lb. capacity lifts
feature a lock ladder column design with a single point lock release. The caster kit can be installed
or removed in just a matter of minutes and requires no tools.
This lift is 20 inches longer (wheelbase) and 3 inches wider than
the Atlas Garage Pro 8000 EXT. Or to compare to the original, this
lift is 20 inches longer (wheelbase), 3 inches wider, and 14 inches
taller than the Atlas Garage Pro 8000! The extra runway length will
accommodate almost all of the longer wheelbase pickup trucks,
except duallys. This is because the dual rear wheels are TOO WIDE
to fit between the column lock assemblies.
The Race Ramp branded Rack Ramps are a lightweight alternative to heavy steel ramps. Rack Ramps are
100% solid, made with a high-density expanded polystyrene that is coated with a hybrid polyurethane.
This patented process results in a product that is extremely lightweight, yet strong and durable. The
ramps will not slide, scratch, or otherwise damage any floor type.
• 8,000 lb. capacity
• Powder coat finish
• Diamond plated runways
• Single point lock release
• Caster kit with polyurethane wheels
• Steel approach ramps included
• Steel jack tray included
• Plastic drip trays included
• Four steel wheel stops included
• Two rubber wheel chocks included
• Perfect for storing or working on vehicles
• 2 year structural, 1 year hydraulic warranty
FEATURES
Garage Pro 8000 E X T- L
11 1/2”
TALLER!
EXTRA TALL EXTRA LONG!
Garage Pro 8000 EXT
The Atlas Garage Pro 8000 EXT incorporates many of the great features of both the Atlas Garage Pro 8000 and
the Atlas Garage Pro 9000. Many of our customers drive an SUV or pick up truck and wanted a storage lift that
would "go higher" to allow them to park their taller vehicles under the elevated ramps.
The Atlas Garage Pro 8000, 8000EXT, 8000EXT-L, And 9000 Include these FREE accessories!
4 DRIP TRAYS
WHEEL
CHOCKS
JACK TRAY
CASTER KIT
LIGHT COMMERCIAL GRADE
Than The
Garage Pro 8000
FEATURES
• 8,000 lb. Capacity
• Powder Coat Finish
• Diamond Plated Runways
• Four Drip Trays Included
• Single Point Lock Release
• Steel Approach Ramps Included
• Caster Kit Included
• Perfect For Storing Or
Working On Vehicles
67 1/2”
Clearance
Under
Runways
No Need To Bolt Down!
79” Clearance
Under Runways
Specifications
Clearance Under Runways 80” (6’ 8”)
Overall Width (Without Motor) 104¾” (8’ 8¾”)
Overall Length
(Without Approach Ramps)
195” (16’ 3”)
Height of Columns
(Including Bolts)
100" (8' 4")
Lifting Height 84 1/4" (7' 1/4")
Runway Width 22 ½ (1' 10 ½")
Runway Length 185” (15’ 5”)
Specifications
Length 48”
Height 5”
Width 14”
XH-PRO8000 XH-PRO8000EXT
XH-PRO8000EXT-L
Set Of 2
Perfect For Our
Garage Pro
Series Lifts
PROUDLY MADE
IN THE USA
BI-RR-RACK-HN14-5
FOUR POST HOBBYIST LIFTS
IN STORE PICK-UP PRICE
$2045
OR
$2395
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$2240
OR
$2590
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$2443
OR
$2793
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$349
7
WE ARE NOT RESPONSIBLE FOR MISPRINTS.
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE.
800.673.8740
TOLL
FREE
• 9,000 lb. capacity
• Powder coat finish
• Ladder lock system
• Extra height AND width
• Light commercial grade
• Single point lock release
• Four wheel stops included
• Steel approach ramps included
• Polyurethane wheels on caster kit
• Perfect for storing or working on vehicles
• 2 year structural, 1 year hydraulic warranty
FEATURES
Aluminum Approach Ramps
These aluminum approach ramps are about 6.5 inches longer than other aluminum approach ramps. The extra length
decreases the angle of the ramp (makes it less steep) to accommodate low ground clearance vehicles. These ramps
have a specially designed “attachment lip” that will only work with our Atlas Garage Pro Four Post Hobbyist Lifts and
the APEX 8 Certified Lift.
The Atlas Garage Pro 9000 portable lift can accommodate a dual-wheel truck.
Long runways support a long wheel base, crew cab dually.
Atlas Garage Pro 9000
Specifications
Capacity 9,000 LB.
Clearance under Runways 80 ½” (6’ 8 ½”)
Between Columns 109 ½” (9’ 1 ½”)
Maximum Wheel Base 187” (15’ 7”)
Shipping Weight 2,300 lb.
SAVE BIG $$$
When You Buy A
4-Post Lift
And Add 2
Rolling Jacks
LIGHT COMMERCIAL GRADE
FINANCING
AVAILABLE
EXTRA
TALL
EXTRA
WIDE
EXTRA
LONG!
80 1/2”
Clearance
Under Runways
No Need To
Bolt Down!
Specifications
Length 43 3/8”
Height 4 3/4”
Width 19”
Atlas APEX 8 Specifications
Clearance Under Runways 67 ½" (5' 7 ½")
Overall Width (Without Motor) 114 ½" (9' 6 ½")
Overall Length (Without Approach Ramps) 186 ½" (15' 6 ½")
Height of Columns (Including Bolts) 87 ½" (7' 3 ½")
Runway Length 165 ½" (13' 9 ½")
Runway Width 18 ¾" (1' 6 ¾")
ST-7000
• 8,000 lb. capacity
• Powder coat finish
• Lock Ladder Design
• Single point lock release
• Free Caster set included
• Double Lock Safety System
• Steel approach ramps included
• Four steel wheel stops included
• Two rubber wheel chocks included
FEATURES
The Atlas Apex 8 is an ALI CERTIFIED four post hobbyist lift. This 8,000 lb.
capacity lift was designed for storage and light vehicle maintenance and
built for use by Mr. Homeowner or restoration shops.
ALI Certied
WATCH OUR
VIDEO
ONLINE
ST-7000 Specifications
Lifting Height To Top Of Runway 147" (12' 3")
Height of Columns 162" (13' 6")
Clearance Under Runways 142" (11' 10")
Clearance Between Columns 100" (8' 4")
Runway Length 194" (16' ")
7000 LB
CAPACITY
SUPER
TALL
SUPER
TALL
12' 3"
LIFTING
HEIGHT!
This is THE lift to have for the customer who has extra tall ceilings and need to store
regular height vehicles on top of extra tall vehicles. The Atlas ST-7000 raises vehicles
weighing up to 7,000 lbs. all the way to over 12 feet (144 inches) under the runway.
WATCH OUR
VIDEO
ONLINE
Perfect For Storing Or
Working On Vehicles
Perfect For
Storing Above
Tall Vehicles
APEX 8
ATTD-APEX8
XH-PRO7000ST
ATPK-40804
XH-PRO9000
Set Of 2
Perfect For Our
Garage Pro
Series Lifts
PROUDLY MADE
IN THE USA
FOUR POST HOBBYIST LIFTS
IN STORE PICK-UP PRICE
$2851
OR
$3201
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$2395
OR
$2745
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$4995
IN STORE PICK-UP PRICE
$299
8
WE ARE NOT RESPONSIBLE FOR MISPRINTS
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE
www.GregSmithEquipment.com
76” Clearance
Under Runways
JACK TRAY
Includes these FREE accessories
Specifications
Capacity 8,000 LB
Overall Width w/o Motor 106 5/8” (8’ 10 5/8”)
Overall Length w/o Approach Ramps 174 ½” (14’ 6 ½”)
Maximum Wheel Base 159” (13’ 3”)
Specifications
Capacity 9,000 LB
Overall Width w/o Motor 121 ¾” (10’ 1 ¾”)
Overall Length
w/o Approach Ramps
194 ¾” (16’ 2 ¾”)
Runway Length 189 ½” (15’ 9 ½”)
Maximum Wheel Base 178” (14’ 10”)
Atlas 408-SL
Atlas 409-HP
Super Deluxe
Storage Lift
Super Deluxe
Storage Lift
The Atlas 408-SL super deluxe portable vehicle storage lift is designed for those car enthusiasts that demand the absolute best look in above ground
storage lifts. The Atlas 408-SL has all the great features of our Atlas Garage Pro Series lifts, but incorporates many features found in our Atlas
commercial grade 4-post lifts. If you are looking for a lift that stands out from all the other storage lifts sold in the USA, then take a good look at the
Atlas 408-SL.
65” Clearance
Under Runways
SAVE BIG $$$ When You Buy A
4-Post Lift And Add 2 Center Jacks
LIGHT COMMERCIAL GRADE
LIGHT
COMMERCIAL
GRADE
No Need
To Bolt Down!
LARGER
COLUMNS • PORTABLE
• 8,000 lb. capacity
• Larger column size
• Steel jack tray included
• Four drip trays included
• Diamond plated runways
• Hidden cables in cross tubes
• High quality powder coat finish
• Steel approach ramps included
• Two steel wheel stops included
• Commercial grade wear blocks
• Perfect for storing or working
on vehicles
• Professional grade single point
lock system
• 2 year structural, 2 year
hydraulic warranty
FEATURES
• PORTABLE
• 9,000 lb. capacity
• Tall columns for extra lift height
• Higher quality powder coat finish
(steel gray color)
• Diamond plated runways
• Professional grade single
point lock system
• Steel approach ramps included
• Steel jack tray included
• Two steel wheel stops included
• Four drip trays included
• Perfect for storing or working
on vehicles
• Hidden cables in cross tubes
• Commercial grade wear blocks
• 2 year structural,
2 year hydraulic warranty
FEATURES
Caster Kit
Extra Long Aluminum
Approach Ramps
The Atlas Portable Caster Kit was designed for those customers who want
the ability to relocate or reposition the Atlas 408-SL or the Atlas 409-HP
4-Post lifts after they have been assembled.
Extra length accommodates low clearance vehicles.
The Atlas 409-HP is a commercial grade portable four post lift built for Mr. Homeowner. The 409-HP incorporates tall columns and a long
hydraulic cylinder that allow the runways to be raised 76 inches (under runway) in the highest lock position. This extra lifting height allows most
SUVs and pickup trucks to be parked underneath the vehicle stored on top and the extra runway width between the columns easily accommodates
one ton dual wheel trucks.
The Atlas 409-HP is built to the same commercial standards as our Atlas 412 and Atlas 414 four post lifts, but also offers portability. (optional
caster kit available) The Atlas 409-HP can be free standing and does not need to be bolted to the concrete.
4 DRIP TRAYS
JACK TRAY
Includes these FREE accessories
No Need To Bolt Down!
EXTRA TALL
EXTRA WIDE
ATPK-408SL
ATPK-409HP
ATPK-TPAL
ATPK-000014KIT
IN STORE PICK-UP PRICE
$153
For 408-SL/409-HP
For 408-SL/409-HP
43 ½”
IN STORE PICK-UP PRICE
$305
4 DRIP TRAYS
FOUR POST HOBBYIST LIFTS
IN STORE PICK-UP PRICE
$2305
OR
$2655
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$2935
OR
$3285
W/ SHIPPING INCLUDED
9
WE ARE NOT RESPONSIBLE FOR MISPRINTS.
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE.
800.673.8740
TOLL
FREE
SAVE BIG $$$ When You Buy A 4-Post Lift And Add 2 Center Jacks
Atlas 412
The Atlas 412 12,000 pound capacity four post lifts are designed and
built to commercial grade standards and will provide many years of
service. Our Atlas lifts offer many exclusive features not found on many
other competitor's lifts.
The Atlas 414 14,000 LB. capacity four post lift incorporates many
structural and cosmetic features that are found on lifts costing
thousands of dollars more money. The Atlas® 414 is tested to ensure
that this lift system will perform flawlessly at its rated capacities. The
Atlas 414 has been manufactured to the same exacting specifications
for many years.
Specifications
Capacity 12,000 LB.
Lifting Height 74” (6’ 2”)
Drive Thru 98 1/2” (8’ 2 1/2”)
Maximum Wheel Base 175” (14’ 7”)
Height of Columns 82” (6’ 10”)
Shipping Weight 2,400LB.
Specifications
Capacity 14,000 LB.
Lifting Height 74” (6’ 2”)
Drive Thru 102” (8’ 6”)
Maximum Wheel Base 186” (15’ 6”)
Height of Columns 86” (7’ 2”)
Shipping Weight 3,200LB.
Atlas 414
2-Foot Front Extension Kits
COMMERCIAL
GRADE
COMMERCIAL
GRADE
Optional Equipment For 412/412A And 414/414A
186 1/2” Runway Length
207” Runway Length
Drive-Off Ramps
The heavy duty diamond plated Atlas drive-off
ramps make the perfect addition to your existing
Atlas 414/414A or 412/412A 4-post lift system.
These ramps give you the option to “drive
through” the lift rather than “backing off” the
lift. The ramp kit contains all the necessary
hardware for installation.
412/412A 414/414A
Add 24” To Your Existing Runway!
For Use With:
Atlas 412, 412A,
414, And 414A
ATPK-412
ATPKP-420003 ATPKP-460028 ATPK-40901
ATPK-414
COMMERCIAL GRADE
ALI Certied
Alignment Kit
Accessory Available
The Atlas Apex 14 is
an ALI CERTIFIED four
post commercial grade
lift is built for years of
dependable service
for the busiest of
automotive shops.
WATCH OUR
VIDEO
ONLINE
ATTD-APEX-ALIKIT
APEX 14 ATTD-APEX14
• Powder Coat Finish
• Automatic Shut-Off Switch
• Lock Ladder Column Design
• Mounting Hardware Included
• Air Operated Single Point Lock Release
• 5 Year Structural, 2 Year Hydraulic Warranty
FEATURES
• ALI Certified
• Powder Coat Finish
• Double Lock Safety System
• Lock Ladder Column Design
• Mounting Hardware Included
• Air Operated Single Point Lock Release
• 5 Year Structural, 2 Year Hydraulic Warranty
FEATURES
Specifications
Capacity 14,000 LB.
Lifting Height 76 ½” (6’ 4 ½”)
Drive Thru 94 ½” (7’ 10 ½”)
Maximum Wheel Base 184” (15’ 4”)
Height of Columns 92 ½” (7’ 8 ½”)
Shipping Weight 3,200LB.
FOUR POST COMMERCIAL LIFTS
Set Of 2 Set Of 2 Set Of 2
IN STORE PICK-UP PRICE
$3291
OR
$3741
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$203
IN STORE PICK-UP PRICE
$305 IN STORE PICK-UP PRICE
$505
IN STORE PICK-UP PRICE
$3806
OR
$4256
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$4075
OR
$4525
W/ SHIPPING INCLUDED
10
WE ARE NOT RESPONSIBLE FOR MISPRINTS
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE
www.GregSmithEquipment.com
The Atlas 412A (12,000 LB. capacity alignment lift) incorporates many structural and cosmetic features
that are found on lifts costing thousands of dollars more money. The Atlas 412A is tested to ensure that this
alignment lift system will perform flawlessly at its rated capacities. The Atlas 412A has been manufactured to
the same exacting specifications for many years.
Atlas 412 A
• Automatic Shut-Off Switch
• Lock Ladder Column Design
• Mounting Hardware Included
• Diamond Plate Runway Surface
• Air operated single point lock release
• Flush-mounted alignment slip plates and
recessed areas in the runways for turntables
• 5 Year Structural, 2 Year Hydraulic Warranty
FEATURES
• Automatic Shut-Off Switch
• Lock Ladder Column Design
• Mounting Hardware Included
• Diamond Plate Runway Surface
• Air operated single point lock release
• Flush-mounted alignment slip plates and
recessed areas in the runways for turntables
• 5 Year Structural, 2 Year Hydraulic Warranty
FEATURES
COMMERCIAL GRADE
At las 414A
COMMERCIAL
GRADE
Specifications
Capacity 12,000 LB.
Lifting Height 76¼” (6’ 4¼”)
4-Wheel Alignment Wheelbase Maximum 154”
2-Wheel Alignment Wheelbase Maximum 157”
Shipping Weight 3,400 LB.
Specifications
Capacity 14,000 LB.
Lifting Height 76 ¼” (6’ 4 ¼”)
4-Wheel Alignment Wheelbase Maximum 172½”
2-Wheel Alignment Wheelbase Maximum 175½”
Shipping Weight 3,500LB.
The Atlas 414A uses a high strength cable system (with a under runway oversized hydraulic cylinder)
powered by a 220 volt (single phase) power unit to raise and lower the lift. Many competitors use an "old
style" chain lifting system with an exposed hydraulic cylinder system. Old style chain lifts are difficult to
"level" properly and the exposed hydraulic cylinder is responsible for numerous "door dings".
INCLUDES 2 TURNTABLES INCLUDES 2 TURNTABLES
BUILT-IN SLIP PLATES BUILT-IN SLIP PLATES
Atlas 14KOF-EXT
The Atlas 14KOF-EXT Garage Pro four post commercial grade open front alignment lift is built for years of dependable service for the busiest of
automotive shops. This heavy duty alignment open front four post lift is two feet (24 inches) LONGER than our Atlas 14KOF open front four post
alignment lift. We added two feet of runway length to accommodate those customers who have the “CAMERA TOWER ALIGNMENT SYSTEM” and are
required to “rollback” long wheel base vehicles. The Atlas 14KOF-EXT alignment lift utilizes top quality aircraft cable actuated by an oversized hydraulic
cylinder (located underneath the runway) to provide the smoothest and safest method of lifting both small cars and large trucks. You can trust the Atlas
name for many years of dependable service.
Specifications
Capacity 14,000 LB.
Lifting Height 69 7/8” (5’ 9 7/8”)
4-Wheel Alignment Wheelbase Maximum 162”
2-Wheel Alignment Wheelbase Maximum 187”
Runway Length 223” (18’ 7”)
Shipping Weight: 3,500 lb.
• Four Post Open Front Alignment Lift
• 14,000 LB. lifting capacity
• Recessed areas in the runways for turntables
• Built In rear slip-plates
• Air operated double lock system
FEATURES
223” (18’ 7”)
Runway Length
COMMERCIAL
GRADE
Open Front Alignment Lift
No Crossbar Open Front
BUILT-IN SLIP PLATES
RECESSED
AREA FOR
INCLUDED
TURNTABLES
FINANCING
AVAILABLE
EXTRA
LONG!
SAVE BIG $$$
When You Buy A 4-Post Lift
And Add 2 Rolling Jacks
ATPK-412A-KIT
XH-PRO14KOFEXT-PKG
ATPK-414A-KIT
186 ½”
Runway Length
198 ¼”
Runway
Length
FOUR POST ALIGNMENT LIFTS
IN STORE PICK-UP PRICE
$4218
OR
$4668
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$4836
OR
$5286
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$6625
OR
$8125
W/ SHIPPING INCLUDED
11
WE ARE NOT RESPONSIBLE FOR MISPRINTS.
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE.
800.673.8740
TOLL
FREE
Make Wheel Service Easy When You Add A Pair Of
Center Jacks To Your 4-Post Or Scissor Alignment Lift!
Atlas RJ-35
For Use With:
Atlas Garage Pro 8000,
8000 EXT, 8000 EXT-L,
9000, And 408-SL
For Use With:
Atlas Garage Pro 9000,
412, 412A, 414, 414A,
14KOF-EXT, And 409-HP
For Use With:
Atlas Garage Pro 9000, 412,
412A, 414, 414A, 14KOF-EXT,
And 409-HP
For Use With:
Atlas 12ASL,
12AWFSL, And 409-HP
For Use With
Atlas Apex 14
For Use With:
Atlas Garage Pro 9000
3,500 lb. Capacity
Atlas RJ-6000
Air / Hydraulic
Rolling Jack
6,000 lb. Capacity
Atlas RJ-6 APEX RJ7
Air / Hydraulic
Rolling Jack
Air / Hydraulic
Rolling Jack
6,000 lb. Capacity
Atlas RJ-8000
Atlas RJ-45
4,500 lb. Capacity
Atlas RJ-6000
6,000 lb. Capacity
Add A Pair Of Jacks To Your 4-Post Or Scissor Lift And SAVE HUNDREDS!
OUR MANUAL AND AIR/HYDRAULIC OPERATED
CENTER JACKS ARE DESIGNED TO WORK WITH
MANY DIFFERENT BRANDS OF FOUR (4) POST LIFTS.
CHECK OUR WEBSITE TO DETERMINE IF OUR JACKS
WILL WORK WITH YOUR FOUR (4) POST LIFT.
Atlas Air/Hydraulic
Power Unit
10,000 PSI
HT3401
Air/Hydraulic Pump
Aluminum Reservoir
For Use With:
Atlas 414, 414A,
14KOF-EXT, PX-16A
Air / Hydraulic
Rolling Jack
Manual Hydraulic
Rolling Jack
XH-PROJACK45
Manual Hydraulic
Sliding Jack
XH-PROJACK35
Manual Hydraulic
Rolling Jack
ATPK-RJ6BK
ATPK-RJ8BKNP-AH-KIT
ATPK-RJ6BK-AH-KITATTD-RJ-6 ATTD-APEXRJ7
8,000 lb. capacity
7,000 lb. Capacity
Convert almost any hydraulic cylinder from hand or foot pump to
air powered simply by adding this Atlas Air/Hydraulic Pump. This
Air-Over-Hydraulic Pump features an aluminum 98cc reservoir and
a strong design making it great for commercial or home use.
HT3501
ROLLING / SLIDING JACKS + POWER UNITS
IN STORE PICK-UP PRICE
$709
OR
$834
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1035
OR
$1160
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1321
OR
$1441
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1179
OR
$1304
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$143
OR
$160
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$811
OR
$936
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1015
OR
$1140
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$827
OR
$952
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$285
OR
$300
W/ SHIPPING INCLUDED
12
WE ARE NOT RESPONSIBLE FOR MISPRINTS
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE
www.GregSmithEquipment.com
At las PX-16A
• Alignment Scissor Lift
• 16,000 LB. lifting capacity
• Recessed areas in the runways for turntables
• Built in rear slip-plates
• Air operated double lock system
FEATURES
The Atlas PX-16A (16,000 lb. capacity) scissor alignment lift is the perfect choice for those service shops that need a space saving alignment lift to
accommodate most all passenger cars up to long up wheel base trucks and extended vans. The Atlas PX-16A allows the operator to perform 4-wheel
alignments for vehicles with wheel bases lengths from 95 inches to 204 inches (with front extensions). (184 inches without front extensions)
The Atlas PX-16A includes a set of turntables and can be used with (optional) rolling jacks and (optional) air line kit.
See Our Alignment Machine Section
COMMERCIAL
GRADE
Specifications
Capacity 16,000 LB.
Lifting Height 71 1/2” (5’ 11 1/2”)
4-Wheel Alignment Wheelbase Maximum 184”
2-Wheel Alignment Wheelbase Maximum 188 1/2”
Runway Length 206" (17' 2")
Shipping Weight: 5,000 lb.
Alignment Scissor Lift
Add A Pair Of Rolling Jacks To Your
Alignment Lift And SAVE BIG $$$
EXTRA
LONG!
12ASL
Specifications
Lifting Capacity 12,000 LB
Lifting Height 84 1/4” (7’ 1/4”)
4-Wheel Alignment Wheelbase Max. 168” - Min. 90”
2-Wheel Alignment Wheelbase Max. 172”- Min. 86”
Motor 220 Volt, 1 Phase
Shipping Weight 5000 lb.
• Can be surfaced mounted or flush mounted
• Very precise platform leveling accuracy
• Mechanical safety lock with air
operated engagement and release
• Emergency manual pump for lowering
• Overload valve included
• Lowering speed control valve included
• Extra Long Slip Plates allow for
aligning of wheelbases from 86” to 172”
FEATURES
Alignment Scissor Lift
WATCH OUR
VIDEO ONLINE!
Air Operated
Locking System
Flush Mounted
Slip Plates
Recessed Area
For Turntables
12AWFSL
Atlas alignment scissor lifts are the perfect choice
for customers who have limited bay space. This lift is
comparable to other lifts costing $15,000 or more.
Specifications
Lifting Capacity 12,000 LB
Lifting Height 84 1/4” (7’ 1/4”)
“Wheels Free” Platform Height 17” (1’ 5”)
4-Wheel Alignment Wheelbase Max. 168” - Min. 90”
2-Wheel Alignment Wheelbase Max. 172”- Min. 86”
Motor 220 Volt, 1 Phase
Shipping Weight 5,400 lb.
Built-in
“Wheels Free” System
COMMERCIAL GRADE
COMMERCIAL
GRADE
Remote
Control
SAVE BIG $$$ When You Buy An Alignment Lift And
An Alignment Machine In A Combo Special!
INCLUDES
TURNTABLES
Color May Vary
*Professional Installation Recommended
*Professional Installation Recommended
ATTD-12ASL-N
ATTD-12AWFSL-N
ATPK-PX16A-CF
SCISSOR ALIGNMENT LIFTS
IN STORE PICK-UP PRICE
$8155
OR
$9655
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$9685
OR
$11185
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$10595
OR
$12095
W/ SHIPPING INCLUDED
13
WE ARE NOT RESPONSIBLE FOR MISPRINTS.
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE.
800.673.8740
TOLL
FREE
TD-6MR
The Atlas TD6MR is a free standing 6,000 lb. capacity portable scissor lift. The Atlas TD6MR is the perfect
lift for body shops and wheel service specialists that need extra lifting height. This portable lift easily raises a
6,000 LB. car or truck to a comfortable working height.
• 6,000 LB. Capacity
• Portable, Easy To Move
• Powder Coated
• Separate Power Unit Stand Included
• Several Locking Positions
• Dual Hydraulic Cylinders
• Truck Adapters Included
• Commercial Grade
• Single Point Lock Release
FEATURES
• 6,000 OR 10,000 LB.
lifting capacities
• Portable
• Low profile design
• Positioning blocks included
• Multiple locking positions
• 110V Power Unit
• Powder Coated
• Commercial Grade
FEATURES
LR-06P/L R -10 P
The Atlas LR-06P portable 6,000 lb., And the LR-10P portable
10,000 lb. low rise lifts make the perfect addition to any garage
that needs a quick method to raise a car to perform wheel
service. The Atlas LR-06P and LR-10P low rise lifts
come with a rubber top lifting surface and a set of four
high density rubber blocks that help to protect the
lifting points of most vehicles.
Kwik Bay
The Atlas Kwik Bay is a free standing 7,000 lb. capacity portable scissor lift. The Atlas Kwik Bay is the perfect
lift for body shops and wheel service specialists that need extra lifting height. This portable lift easily raises
a 7,000 LB. car or truck to a comfortable working height and does not require the customer to position arms
under the lifting points of the car.
• 7,000 LB. Capacity
• Portable
• Open center
• 110V motor
• Air operated locks
• Zerk grease fittings
at hinge points
• Open middle for
easy access
• Four positioning blocks
FEATURES
EM-06
The Atlas EM06 full platform portable mid rise lift is
a great choice for the tire shop or service center that
wants to get a passenger car or light SUV into the air as
quickly as possible. Most full platform portable lifts only
lift the vehicle about 24 inches. The Atlas EM06 raises
the vehicle a full 40 inches (with lift blocks); a very
comfortable working height for the technician.
• 6,000 lb. lifting capacity
• Portable
• Minimum Height: 4 ½”
• Maximum Height
(With Blocks): 40”
• Three locking positions
at heights of:
(w/o rubber blocks)
13 ¾”, 27 ¾”, and 36”
• 110V Power Unit
FEATURES
MR-06
The Atlas MR-06 is a free standing 6,000 lb. capacity portable scissor lift. The Atlas MR-06 is the
perfect lift for body shops and wheel service specialists that need extra lifting height. This portable
lift easily raises a 6,000 LB. car or light truck to a comfortable working height. The unique platform
design of the Atlas MR-06 allows access to some areas on the underside of the car not easily
accessible with other portable mid-rise lifts.
• 6,000 LB. capacity
• Powder coated finish
• Commercial grade
• Portable design
• 110V power unit
• 3 locking heights
• Extension pad included
FEATURES
Maximum
Lifting
Height:
53 1/2”
(w/ truck adapters)
Maximum Lifting Height:
25 1/2”
(w/ positioning blocks)
Maximum
Lifting Height:
41”
(w/ positioning blocks)
Maximum Lifting
Height: 40”
(w/ positioning blocks)
Maximum
Lifting Height:
39 1/2”
(w/ extension pad)
WATCH OUR
VIDEO ONLINE!
COMMERCIAL GRADE
LR-06P LR-10P
6,000 lb. Capacity 10,000 lb. Capacity
6,000 lb.
Capacity
6,000 lb. Capacity
6,000 lb.
Capacity
7,000 lb.
Capacity
COMMERCIAL
GRADE
COMMERCIAL
GRADE
COMMERCIAL GRADE
Call Us
For Current
Pricing And
SPECIALS!
COMMERCIAL
GRADE
Optional Support Bar Set
ATTD-SUPPORTBARKIT
110V
ATPK-LR06
ATPK-LR10
ATPK-MR06
ATP K-EM06-110V
ATTD-6MR ATTD-7K-KWIK-BAY
4" Car Lift Ramps
4" Car Lift Ramps make it easier than ever to get your low-to-the-ground vehicle on a scissor lift.
Featuring a 3.86 degree angle of approach, the ramps are 14" wide and 185" long, accommodating
wheelbases from 80" to 115". Each Car Lift Ramp is comprised of four interlocking pieces that combined
weigh only 40 lbs. Each ramp can hold up to 1,500 lbs, for a total weight capacity of 6,000 lbs.
Specifications
Max Length 185”
Height 4”
Width 14”
Set Of 2 Perfect For Low Cars
PROUDLY MADE
IN THE USA
BI-RR-CLR-4
IN STORE PICK-UP PRICE
$749
LOW-MID RISE SCISSOR LIFTS
IN STORE PICK-UP PRICE
$1350
OR
$1600
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1450
OR
$1700
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1565
OR
$1815
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1525
OR
$1775
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$2341
OR
$2591
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1770
OR
$2020
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$357
OR
$507
W/ SHIPPING INCLUDED
14
WE ARE NOT RESPONSIBLE FOR MISPRINTS
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE
www.GregSmithEquipment.com
FM9SL
Atlas Lawn Mower Adapter
The ATLAS LMA (lawn mower adapter) will transform most two post above ground lifts with symmetric arms into an easy to use lawn
mower lift, golf car lift, snowmobile lift, ATV lift, or a small sports car lift. The LMA is adjustable in width to accommodate the many
different arm configurations found on two post lifts. The ATLAS LMA can be used in an infinite amount of wheel base configurations to
allow the operator great flexibility in lifting different pieces of lawn service equipment with varying wheelbases.
Capacity 5,000 LB.‡
Adjusts In Width 7’ 4¼”- 10’ 2 ½”
Wheel Well Width 12”
Steel Thickness ¼” (12 gauge)
Shipping Weight 600 LBS.
Specifications
‡ Depending on capacity of lift, and adapter
distance from lift columns.
Transform Your 2-Post Lift
Into A 4-Post Lift
• 9,000 lb. capacity
• 71 1/2" maximum lifting height
• Extendable platforms
• Air actuated locks
• Open middle for easy access
• Separate Self-Contained Control Panel
• Mechanical safety locks
• Shipping Weight: 2,500 lbs.
FEATURES
*Lift Not Included
Adjustable Width: 7’ 4 ¼” - 10’ 2 ½”
13”
Flush Mount Scissor Lift
Rotisserie
Threaded
Rod Adjusters
Poly-Coated
Steel Casters
Hand Crank
WATCH OUR
VIDEO ONLINE!
This auto body rotisserie is great for anyone wanting to restore a car or truck body or frame. The
rotisserie allows a full 360º of vehicle movement by just turning the crank. When the vehicle is properly
mounted and positioned, the rotisserie SPINS and allows the operator to have easy access to all parts of
the body for welding, sandblasting, or any other work that needs to be done.
Atlas 412A Two RJ-6000 Rolling
Jacks 501 Alignment Machine
4 Point Clamps
Atlas 414A Two RJ-8000
Rolling Jacks 601 Pro Alignment
Machine 3 Point Clamps
Alignment Lift Instrumentation Combos
A Huge Savings When
Bought Together
A Huge Savings When
Bought Together
Air / Hydraulic Rolling Jacks Air / Hydraulic Rolling Jacks
More Combo
Deals Online!
SAVE HUNDREDS $$$
Visit Our Website
Or Call Us
For Your Best Deal
FINANCING
AVAILABLE
COMMERCIAL
GRADE
SLP-9K
The Atlas SLP-9K full rise scissor lifts combine an extremely low lift
platform height and a full rise scissor jack system. The Atlas SLP-9K
full-rise scissor lifts can be flush mounted. It is the perfect above
ground lift for those customers with ceiling height restrictions, or those
service shops that want to avoid the cluttered look of dozens of vertical
lift columns.
The Atlas 9KFMSL flush mounted scissor
lift has a rated capacity of 9,000 LB. and a
total lifting height of just over 71 inches.
• 9,000 LB. capacity
• Open center for easy access
• 220 volt, full rise
• Powder coat finish
• Commercial grade
• Air operated locks
• Positioning blocks included
FEATURES
COMMERCIAL GRADE
FINANCING
AVAILABLE
CAN BE
FLUSH
MOUNTED
WATCH OUR
VIDEO ONLINE!
Maximum
Lifting Height:
78”
(w/ positioning blocks)
*Lift Not Included
ATLMA
ATTD-FM9SL
HT-ROTI-NEW
ATTD-SLP9K
SPECIALTY LIFTS + COMBOS
IN STORE PICK-UP PRICE
$3361
OR
$3611
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$4395
OR
$4645
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1117
OR
$1267
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1015
OR
$1215
W/ SHIPPING INCLUDED
15
WE ARE NOT RESPONSIBLE FOR MISPRINTS.
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE.
800.673.8740
TOLL
FREE
• Automatic Safety Stops
• Simultaneous operation of all columns
• Electronically ensures synchronization of all columns
• Can be "Expanded" from a four (4) column system to
a six (6) or eight (8) column system
FEATURES
Mobile Column Lift Systems
Don’t waste valuable floor space with a large four post lift. Atlas Mobile Column Lift Systems will save shop space and money versus a four post lift. No
need to buy an extended length 4-post lift. With Atlas mobile column lifts, longer wheel bases are not a problem. Adjustable forks accommodate a wide
range of wheel sizes. All Atlas Mobile Column Lift Systems electronically ensure synchronization of all columns.
MOBILE COLUMN LIFT SYSTEM ACCESSORIES
WATCH OUR
VIDEO
ONLINE
1-Phase
FINANCING
AVAILABLE
CAPACITY SYSTEM
44,000 lb
CAPACITY SYSTEM
74,000 lb
CAPACITY SYSTEM
66,000 lb
CAPACITY SYSTEM
111,000 lb
Battery
Powered
Battery
Powered
Battery Powered
12,000 lb
Capacity
Tripod
Stands
16,500 lb
Capacity
Tripod
Stands
Per Set Of 4 Columns
IN STORE PICK-UP PRICE
$20395
Per Set Of 4 Columns
IN STORE PICK-UP PRICE
$27995
Per Set Of 4 Columns
IN STORE PICK-UP PRICE
$26515
Per Set Of 6 Columns
IN STORE PICK-UP PRICE
$43350
Set Of 4
IN STORE PICK-UP PRICE
$1423 Set Of 4
IN STORE PICK-UP PRICE
$1795
Built-in hydraulic
pallet jack system
allows columns to be
moved easily on level
concrete surface with
a minimum thickness of
six (6) inches.
Adjustable arm
forks support
a wide array of
wheel assemblies.
ATTD-MC11HYD-KIT
ML-4034BC-KIT
ATTDP-SUPPORT-STAND-KIT ML-AXLE-STAND-KIT
ML- 60 51B C
ML-4030BC-KIT
MOBILE COLUMN LIFTS
16
WE ARE NOT RESPONSIBLE FOR MISPRINTS
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE
www.GregSmithEquipment.com
Atlas Cycle Lift
Includes FREE Removable
Rear Section To Make
Wheel Service Easy
Specifications
Weight Capacity 1,200 LB.
Length (w/ ramp) 104" (8' 8")
Center table width
(without side extensions) 29½" (2' 5½")
Center table width
(with side extensions) 48"
Fully Lowered 6”
Specifications
Overall Length
(w/ Ramps)‡ 125” (10’ 5 “)
Center Table Length
(w/o Ramps)‡ 99 ¾” (8’ 3 ¾”)
Side Extension Length
(w/o ramps) 88 ½” (7’ 4 ½”)
Center Table Width
(w/ Side Extensions) 51” (4’ 3”)
Center Table Width
(w/o Side Extensions) 29 ½”
Height Fully Raised 43” (3’ 7”)
Height Lowered 7 ½”
Shipping Weight 800 LB.
93” Long Platform
Motorcycle Jack
The Atlas Cycle Lift is one of the
industry’s longest motorcycle lifts.
The motorcycle lift has platform
length of 93 inches. In addition to
the heavy gauge diamond plated
93 inch platform, the Atlas Cycle
Lift has an additional 20 inch
removable approach ramp.
The Atlas Motorcycle Jack is a lightweight
scissor jack that fits nicely under most
motorcycle and ATV frames.
Motocross Lift
The Motocross Lift HT1007 is a lightweight,
portable lift. This lift is ideal for anyone looking for
an inexpensive way to get their bike off the floor.
The lightweight and compact design also allows
you to take this lift with you on the road.
HT1007
Atlas XLT Kit
The Atlas XLT kit will fit the Atlas Cycle
Lift. The Atlas XLT kit includes two
12” side extensions, a two wheeled
dolly, approach ramp extensions, three
connector rods and clips. In less than
two minutes, you can convert a standard
motorcycle lift into an ATV lift.
• (2) 12” Side Extensions
• (2) Approach ramp extensions
• One two wheeled dolly (used for moving the lift)
• Three rods (used to connect/support the side extensions)
• Set of pins (used to secure the rods in place)
Three Support Bars
For Extra Stability
Fits Atlas Cycle Lifts
Atlas HT-ACL Cycle Lift Atlas EML-1200 Motorcycle Lift
Multiple Colors Available
Lightweight
And Portable
Atlas Hi-Rise 1500 Motorcycle / ATV Lift
• Weight capacity: 1,500 LB.
• Powder coat finish
• Includes removable drop out section
• Includes chopper extension
• Includes side extensions
• Table length with chopper extension: 99”
• Removable approach ramp included
• 6 Locking Positions
• Diamond Plate
• Vise included
FEATURES
Includes:
• Side Extensions
• Chopper Extension
• Motorcycle Vise
• Approach Ramp
• Removable Drop Out Section
Includes:
• Motorcycle Vise
• Approach Ramp
• Removable Drop-In
Roller Plate
ELECTRIC /
HYDRAULIC
The Atlas HI-RISE 1500 is one of our most popular motorcycle and ATV lifts.
‡ These measurements are taken with the FREE chopper extension attached (20 ¾” long)
The Atlas HT-ACL Cycle Lift features a removable (drop in) roller plate with grooved rollers
for better traction. The motorcycle lift has a platform length of over 85 inches.
The Atlas EML-1200 is an electric/hydraulic 1200 lb. capacity motorcycle lift with an extremely smooth ascent and
a platform length of over 88 inches.
Extra Wide 48" Center Table
48" Center Table
85 1/2" Table Length
HT-ACL XLT
EML-1200 XLT
Extra Wide 48"
Center Table
Two Models
Available
ATLAS CYCLE
LIFT XLT
HT-ACL
WATCH OUR
VIDEO ONLINE!
Specifications
Weight Capacity 1,000 LB.
Length (w/ ramp) 107 1/2” (8’ 11 1/2”)
Width 24” (2’)
Full Rise 31 1/4” (2’ 7 1/4”)
Fully Lowered 7”
Removable approach ramp 22 1/2” long
Shipping Weight 500 LB. Extra Wide
Specifications
Weight Capacity 1,000 LB.
Total Length 113” (9’ 5”)
Width 24” (2’)
Full Rise 33” (2’ 9”)
Fully Lowered 7 - 1/4”
Shipping Weight 520 LB.
85 1/2” Long
Platform
HT-CYCLELIFT
HT-CYCLELIFT-XLT
HT-CYCLELIFT-EXT
HT1005-KIT
HT-ACL-JACK
MOTORCYCLE LIFTS
IN STORE PICK-UP PRICE
$764
OR
$914
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$968
OR
$1118
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$764
OR
$914
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1265
OR
$1415
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1321
OR
$1471
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1479
OR
$1629
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$968
OR
$1118
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$91
OR
$136
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$230
OR
$380
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$112
OR
$262
W/ SHIPPING INCLUDED
17
WE ARE NOT RESPONSIBLE FOR MISPRINTS.
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE.
800.673.8740
TOLL
FREE
Atlas Edge 501
The Atlas Edge 501 is an ultra fast and accurate alignment system. The Atlas® 501 is the perfect choice for quick reliable “dead-nut” alignment “full
body” accuracy for an entry level price. The 501 System utilizes eight cameras (these cameras “look at each other” from both sides of the rear of the
vehicle) to provide accurate measurements between rear wheels just as the two front cameras provide measurements between the front wheels. The
eight camera system completes a rectangle which produces a closed 360 degree measured field.
• Only four color coded (arrow) buttons are
required to operate the entire program.
• The system can be operated from any sensor
head and the software is simple.
• Lightweight (8 lb.) sensor heads.
• Bluetooth® Wireless Data Transmission
• 8 Camera Optical System
• Standard Four Point Clamps Included
• Deluxe Cabinetry With Printer Drawer
• Lightweight (8 LB.) Sensor Heads
• Printer, LCD Monitor, Keyboard
• Lipless Wheel Adapters
• 2 Heavy Duty Turntables Included
• 1 Brake Pedal Depressor
• 1 Steering Wheel Lock
• Wireless App Compatible
• Vast Vehicle Database
• Simple 4 Key Operation
• Spoiler Program For Low Air Dams
FEATURES
SAVE BIG $$$ When You Buy
An Alignment Lift And An
Alignment Machine Combo
Servicing or updating your Atlas Edge alignment machine
is simple if you have internet access at your shop!
We can access your alignment computer to provide upgraded software, install
new vehicle data and diagnose software or hardware issues. There is no need
to wait for the “alignment service tech in the little white van”. We stock parts
and can ship quickly. If you can replace parts on a car, then you can replace
any broken part on your Atlas Edge alignment machine.
Clamping method prevents damage to expensive rims
501 W/ Fast Clamp System
The 3 point “Fast Clamp System” offers the finest wheel
reference points in the industry. The operator does
NOT need to perform any lateral runout compensation
procedures or “roll-back” maneuvers when the sensors
are mounted to the patented “Fast Clamp System”. The
technician does not need to disturb the vehicle’s natural
running position by rolling or raising it. A vehicle is most
accurately aligned when it is in the “full rest” position.
Set Of 4
ALIGNMENT
Training Classes
AVAILABLE
V
isit Our Website
FOR DETAILS!
Includes a set of self-centering 4 point clamps, with
removable claws. These clamps will clamp wheels
10”-24” and require runout compensation.
501 W/ Traditional
4-Point Clamp System
Set Of 4
Atlas Edge 601 Pro
W/ Fast Clamps
The Atlas Edge 601 alignment system may be the most user friendly wheel alignment system available. The Atlas Edge 601 combines
low price, simple to use technology, and repeatable accuracy in a machine that is “ready to use” out of the box.
Huge Vehicle data base with
yearly (2) updates available.
Over 28 languages installed
Large, easy to read graphics and illustrations
• The system can be operated from any
sensor head. Software is simple.
• The machine is "ready to go"
out of the box.
• Bluetooth technology eliminates the
need for any connecting cables
• Deluxe cabinetry
• Fast set up and unparalleled accuracy
in an alignment system costing
thousands of dollars less than the
Big Name competition ensures a fast
return on your investment.
• Non-proprietary computer hardware
makes replacement or
upgrades affordable.
• Printer, LCD monitor, and keyboard
FEATURES
Servicing or updating your Atlas Edge alignment machine
is simple if you have internet access at your shop!
We can access your alignment computer to provide upgraded
software, install new vehicle data and diagnose software or
hardware issues. There is no need to wait for the “alignment
service tech in the little white van”. We stock parts and can ship
quickly. If you can replace parts on a car, then you can replace
any broken part on your Atlas Edge alignment machine.
WATCH OUR
VIDEO ONLINE!
ALIGNMENT
Training Classes
AVAILABLE
Visit Our Website
FOR DETAILS!
Clamping method prevents
damage to expensive rims
(Set Of 4)
ATEDGE-501-4PT
ATEDGE-601-PRO+3PT
ATEDGE-501-3PT
ALIGNMENT MACHINES
IN STORE PICK-UP PRICE
$14275
OR
$14425
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$10195
OR
$10345
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$12235
OR
$12385
W/ SHIPPING INCLUDED
18
WE ARE NOT RESPONSIBLE FOR MISPRINTS
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE
www.GregSmithEquipment.com
Atlas Wheel Stands And Turntable Package
The Atlas Wheel Stands are the perfect choice for those smaller
shops who want the advantages of a four post lift but have only limited
floor space. The set of Atlas Wheels Stands can support up to 6,000
lbs. and, because they are taller than most other stands, are the
perfect height for hanging wheel alignment sensors.
• Includes 4 Steel Wheel Stands
• 4 Alignment Turntables
• 39 1/2” High
• .38” Thick Top Steel Plating
• 19.5” x 19.5” Solid Steel Surface
• 6,000 LB Capacity (1,500 LB Per Stand)
$350
Includes
4 Turntables
Wheel Stand Package
Use your android or iOS device to not only see
your alignment, but also control your alignment
and perform the entire alignment all from your
device. No need to make unnecessary trips back
and forth to change screens and look at your
alignment numbers when they can be right at
your finger... on a device you already own.
Atlas Edge 701-3D
• Compatible with any alignment lift
• Works flawlessly at any height
• Save valuable bay space
• Wireless communication eliminates
the need to walk to the console
• Portable computer console
• Free InstaCheck system
• 3-Point Non-Runout FastClamps
FEATURES
WATCH OUR
VIDEO ONLINE!
Atlas Cyclops
• The cameras work at any height
• Patented three (3) dimensional sensor
targets eliminate the need for rollback
• Compensates for an unlevel lift
• 3-Point Non-Runout FastClamps
After almost 20 years, a revolutionary new 3-D system is now available. Introducing the Atlas® Cyclops 3-D TowerFree™ Camera alignment system
featuring IC3D technology. The Atlas® 3-D camera system does not require a fixed tower and is easily installed on the alignment lift runways so
the size of the bay space needed is determined by the length of the lift (or vehicle on the lift). No more loss of valuable bay space at the front of your
alignment lift. The “alignment lift” may be a four post lift, a scissor lift, a parallelogram lift, or “the floor”.
Thousands of 3-D camera TOWER alignment machines have been sold in the last 20 years. Hunter® and John Bean® have done a wonderful job
convincing customers that a 3-D camera TOWER system is much more accurate than a portable CCD alignment system. We disagree, but rather than
argue with the thousands of satisfied 3-D camera tower alignment customers, we decided to build a 3-D camera alignment system that was 100%
user friendly. Rather than just copying the status quo 3-D camera TOWER system, we asked dozens of current 3-D alignment owners what features
“they would change” in their current 3-D camera TOWER system. If we were going to build a new product, we thought it best to “engineer out” as many
of the “unwanted” features as possible and “engineer in” every possible feature that would make new 3-D camera system the absolute best.
The InstaCheck system provides
accurate alignment measurements
(on the floor) in less than 80
seconds. Simple to use and a
great way to provide alignment
information to potential alignment
customers. Sell more alignments!
*InstaCheck Stands Not Included*
With IC3D TowerFree™ Technology
With IC3D TowerFree™ Technology
For Alignment Machines
CYCLOPS ALSO
DOUBLES AS AN
SYSTEM
INSTACHECK
Aligner Connect App
Color May Vary
ATEDGE-701-3D
ATEDGE-STDA141
ATEDGE-4PFCU
ATEDGE-CYCLOPS-3D-KIT
ATLAS WHEEL STAND/ TURNTABLE COMBO
• Compatible with virtually any alignment lift
• Valuable space saved in front of the lift
• Works flawlessly at any height
• Does not require an extra long lift
• Four post lifts cannot block the vision
of the Atlas® Stealth 701
• The Atlas® Stealth 701 3-D can
measure extra long vehicles
Built-In VIN Code Scanner
CLAMP
UPGRADE KIT
AVAILABLE
ALIGNMENT EQUIPMENT
IN STORE PICK-UP PRICE
$16845
OR
$16995
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$19995
IN STORE PICK-UP PRICE
$1933
OR
$2083
W/ SHIPPING INCLUDED
19
WE ARE NOT RESPONSIBLE FOR MISPRINTS.
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE.
800.673.8740
TOLL
FREE
Set Of 4
*Turntables Sold Separately
6,000 LB Capacity
(1,500 LB Per Stand)
Atlas Edge 801
FEATURES
• Bluetooth wireless data transfer
• Software lets you choose between
trucks, trailers, buses, coaches, light
trucks and more.
• Allows you to choose between 2, 3,
4, or 5 axle vehicles
• Specifications for thousands of
trucks, C, coaches, and light trucks
are included in software.
• Measures collision angles such as
axle set back and offset to help
diagnose uncommon problems.
• Optional calibration package
• Kingpin fixture assembly and
electronic focal points allow
operator to quickly align trailer axles
using the trailer kingpin as reference
We have the most innovative large truck alignment system on the world market. It features Bluetooth wireless data transmission and is customized for all truck axle configurations
– 2, 3, 4 and 5 axle configurations. This system combines blazing speed, precision accuracy, and reliable Bluetooth ® wireless communication all at a very affordable cost. It is PC Driven
using high quality PC components and managed by Windows XP Pro ®. The system prints detailed alignment reports and stores these reports on its hard drive for future retrieval.
• Non Runout Fast Clamps- Accurately
references the center of the wheel
• Eliminates need for time consuming
runout compensation of all 6 wheel
positions of a 3 axle tractor
• Spoiler program for low
air dams
• Turning angle gauges
• Only four color coded buttons
operate the entire system.
• Program walks the operator
thru the alignment process in
a simple step by step manner.
ALIGNMEN
T
Training Classes
AV
AILABLE
V
isit Our Website
FOR DETAILS!
• TOTAL WHEEL ALIGNMENT-
Performs a total alignment of
the vehicle and looks at all axles
as a whole and not just a single
axle at a time.
• Alignments can be performed
in a service bay or outside
parking area
Atlas 3-Point Fast Clamps
Wheel
Stands
Atlas Traditional
4-Point Clamps Three Point 13”-24” Non-Runout Wheel Clamps (Set Of 4)
Four Point 10”-24”
Self-Centering 4 Point Clamps
(Set Of 4)
The 3 point “Fast Clamp System” offers the finest wheel
reference points in the industry. The operator does
NOT need to perform any lateral runout compensation
procedures or “roll-back” maneuvers when the sensors are
mounted to the patented “Fast Clamp System”.
Traditional
self-centering
4 point clamps
with removable
claws. These
clamps will clamp
wheels 10"-24"
and require runout
compensation.
Set Of 4
Set Of 4
Atlas Alignment
Training Course
Converts a 4 post lift into an alignment lift.
AK-1Alignment Kit
Includes heavy-duty turntable kit,
rear slip plate kit, and wheel stops.
Turntables
(Pair)
Atlas Alignment
Calibration Bar
(For Edge 401,
501, and 601)
Visit Our Website
For Details
The Atlas calibration fixture system allows the
owner of an Atlas Edge 401 or Atlas Edge 601
computer alignment machine to perform sensor
calibration procedures in his shop.
Passenger Light Truck
14 3/8”
14 3/8”
*Color May Vary
COMBO-801+STDA29L
ATTD-SLJ-A000
ATEDGE-4PT-KIT
ATPK-TURNTABLES ATEDGE-CALIBRATION-BAR
ATEDGE-3PT-FAST CLAMPS
XH-ALIKIT
ALIGNMENT EQUIPMENT
IN STORE PICK-UP PRICE
$30340
OR
$30590
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1326
OR
$1366
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$376
OR
$476
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$713
OR
$728
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$3055
OR
$3105
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1321
OR
$1521
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1395
20
WE ARE NOT RESPONSIBLE FOR MISPRINTS
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE
www.GregSmithEquipment.com
WB41
The Atlas WB 41 is the larger version
of our extremely popular Atlas WB-11.
The Atlas WB-HS is the perfect choice for smaller service shops or mobile wheel
service companies. The Atlas WB-HS (with built in wheel assembly) is extremely
portable and can easily be moved from service bay to service bay or can be rolled
up a ramp to the inside of a mobile service truck.
The Atlas WB 49 computer wheel
balancer incorporates all the great
features (AND MORE) of the Atlas
WB41 computer wheel balancer.
Specifications
Max Tire Diameter 39”
Rim Diameter 10”-32”
Rim Width 1 ½”-20”
Max Wheel Weight 165 lb.
Shipping Weight 380 lb.
Specifications
Max Tire Diameter 39”
Rim Diameter 10”-32”
Rim Width 1 ½”-20”
Max Wheel Weight 150 lb.
Shipping Weight 380 lb.
FEATURES
• Automatic and pedal operated brake.
• Automatic start/stop when hood is
lowered/raised.
• Static and dynamic balancing modes.
• Self-diagnosis / Self-calibration
• 1-year limited warranty
FEATURES
• Automatic data entry
• Weight Splitting feature
• Automatic and pedal operated brake
• Automatic start/stop when hood is
lowered/raised
• Static and dynamic balancing modes
• Rapid optimization (OPT)
• Self-diagnosis / Self-calibration
• 1-year limited warranty
AUTOMATIC
DATA ENTRY
Specifications
Max Tire Diameter 39”
Rim Diameter 10”-32”
Rim Width 1 ½”-20”
Max. Wheel Weight 130 lb.
Shipping Weight 225 lb.
Static Bubble
Balancer
• Rugged die-cast
aluminum head cone
• Easy to use self-leveling
stand. No need for
leveling legs
• Shipping Weight: 21 LB
HTBB
WB49
Buy A Tire Changer When
You Buy A Balancer
And SAVE HUNDREDS $$$
Visit Our Website Or
Call Us For Your Best Deal
The Atlas WB 11 is the most popular Atlas wheel balancer that we sell.
Low price, dependability and repeatable accuracy make the Atlas WB-11
the backbone of the entire Atlas line of computer wheel balancers.
Specifications
Max Tire Diameter 39”
Rim Diameter 10”-32”
Rim Width 1 ½”-20”
Max. Wheel Weight 150 lb.
Shipping Weight 355 lb.
FEATURES
• Automatic and pedal operated brake
• Automatic start/stop when hood is
lowered/raised
• Static and dynamic balancing modes
• Self-diagnosis / Self-calibration
• 1-year limited warranty
FEATURES
• Extremely portable
• Operates on both 110V and
12V-24V DC power
• Easily connects to a car battery
• Static and dynamic balancing modes
• 1-year limited warranty
Foot Brake Pedal
Holds wheel in place when
mounting wheel weights
Built In Wheel Assembly
ATWB-HS AT WB11
ATWB41
ATWB49
WB-HS W B -11
WHEEL BALANCERS
IN STORE PICK-UP PRICE
$1015
OR
$1165
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1450
OR
$1600
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1225
OR
$1375
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1729
OR
$1879
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$60
21
WE ARE NOT RESPONSIBLE FOR MISPRINTS.
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE.
800.673.8740
TOLL
FREE
Specifications
Max Tire Diameter 39”
Rim Diameter 10”-32”
Rim Width 1 ½”-20”
Max Wheel Weight 165 lb.
Shipping Weight 400 lb.
Specifications
Max Tire Diameter 35 1/2”
Rim Diameter 10”-28”
Rim Width 1 ½" - 20"
Max Wheel Weight 155 lb.
Shipping Weight 420 lb.
WB55
The Atlas 3-D WB-55 has a 19 inch LED LCD digital flat screen that displays high resolution tire and wheel images, providing a clear
“picture” of tire/wheel assembly and out of balance condition. The Atlas WB-55 incorporates the Insta/Input (I/I) measuring system
that automatically enters all three parameters (rim size, rim width, and distance of rim from machine) when the operator touches the
inside and outside of the mounted rim with the built-in measuring rods. The Atlas Smart/Selector (S/S) allows the operator to turn
one knob and select the desired balancing mode.
WB77
W B T- 210
FEATURES
• 19” Color LED LCD Monitor
• Large weight tray
• Automatic positioning where
to apply weights
• Automatic and pedal
operated brake
• Automatic start/stop when
hood is lowered/raised
• Static and dynamic
balancing modes
• Rapid optimization (OPT)
• Self-diagnosis
• Self-calibration
• Exceptional stability in reading
the unbalance between planes
• Display in grams or ounces,
in mm or inches
• Very fast 7 second cycle time
• Multi user function for up to
4 different users
• Seven (7) ALU settings for
both adhesive and
clip on weight
• 1-year limited warranty
FEATURES
• 17” Color LED LCD Monitor
• Large weight tray
• Self-calibration
• Auto/ALU + S-Drive + Direct3D
• Automatic distance, diameter
and width entry
• Automatic ALU-type entry
(Auto/ALU technology)
• Precise direct measuring of
ALU-rims weight planes
(Direct 3D technology)
• Tire positioning optimization
• Speech synthesizer
• 110 volt (Power Guard technology)
with surge protection
• Automatic pivoting to the weight
placing location (S-Drive technology)
• Precise placement of adhesive
weights with the clip on the
gauge arm
• SPLIT – behind the spoke weight
placement (invisible weight)
• Static imbalance minimizing
• Zero point setting
• High-precision spindle, shaft
diameter 40 mm
FEATURES
• Cone sets for car and light truck tires
• Cone and spacer set for truck, bus
or implement wheels
• Quick release nut
• Heavy duty steel wing nut
• Pneumatic wheel lift capacity: 300 lbs.
• Protective hood
• Self-diagnosis / Self-calibration
• Display in grams or ounces;
• 1-year limited warranty
Specifications
Max Tire Diameter 47”
Rim Diameter 10”-32”
Rim Width 1 ½”-20”
Balance Capacity 440 lb.
Shipping Weight 725 lb.
Standard Accessories
Atlas Universal
Truck Adapter
The Atlas Universal Adapter
(TRUCK)/PF-40000 is designed
for truck wheels that have either
a closed center or wheels that are
made “without a true center” and
classified as lug-centric.
Insta/Input
Automatic Data Entry
Standard
Accessories
The Atlas WBT-210 truck tire wheel balancer is one of the best values in large truck tire computer balancers
sold. This truck tire balancer is priced thousands of dollars less than the Big Name brand truck tire balancers
and offers the same accuracy and reliability as the rest of the Atlas wheel balancer products.
From Car Wheels
To Semi Wheels
LCD Monitor
*Requires manual input of some data between 23” - 32”
The Atlas WB-77 is our absolute top of the line wheel balancer. Please watch our online video
highlighting all the amazing features of this balancer. The Atlas WB-77 guarantees dead nut
accuracy by eliminating the “human error” of rim measurement and weight placement.
ATWB-UA-TRUCK
ATWB55
AT WB77-KI T
ATWBT210
WHEEL BALANCERS
IN STORE PICK-UP PRICE
$2239
OR
$2389
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$4075
OR
$4225
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$3652
OR
$3902
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$509
OR
$559
W/ SHIPPING INCLUDED
22
WE ARE NOT RESPONSIBLE FOR MISPRINTS
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE
www.GregSmithEquipment.com
Atlas “UA” Universal Adapter
(40 mm Shafts)
WBAWL
Pneumatic Wheel Lift
Atlas Universal Adapter (UA) is designed for wheels that have either
a closed center or wheels that are made “without a true center” and
classified as lug-centric. The Atlas UA was specifically designed for
those custom alloy wheels that require a special mounting procedure.
Need to use with most
GMC® Trucks & SUVs
ATWB-UA
WATCH OUR
VIDEO ONLINE!
Truck Adapter Set
(40 mm Shafts
)
This two piece truck adapter set consists of a double sided
center cone for wheel centers up to 6 inches in diameter. A
spacer is also included to help prevent offset wheels from
contacting the side of the balancer. Fits 40mm shafts.
For 4 ¾" Or Larger Center
Holes
ATWB-LTA
For Use with Heavy Truck Wheels
Atlas Metal Wing Nut
Available in
36mm OR 40mm
ATWB-MWN-36
ATWB-MWN-40
Fast
Mounting
Atlas Quick Release Nut
The Atlas Quick Release Nut fits all Atlas brand wheel balancers. Available
in both 40mm and 36mm sizes. Please specify your shaft size.
ATWB-36NUT
ATWB-40NUT-N
Available in
36mm OR 40mm
The Atlas MC adapter kit will allow your Atlas (passenger and light
truck) computer wheel balancer to balance a variety of motorcycle
wheels with hub assemblies up to 9.25 inches wide. The Atlas MC kit
has a 14mm shaft size.
MC Kit MC-XLT Kit
The Atlas MC-XLT adapter kit will allow your Atlas (passenger and light
truck) computer wheel balancer to balance a variety of motorcycle
wheels with hub assemblies up to 13.75 inches wide. The Atlas MC
XLT kit has a 19mm shaft size.
The Atlas SSA offers the needed support for those extra heavy tires and
rear wheel assemblies found on many custom motorcycles. For use with all
Atlas motorcycle wheel balancers.
Spoke Support Adapter
ATWB-SSAATWB-MCXLTKIT-NEWATWB-MCKIT-NEW
Atlas Passenger Wheel Balancers Can Be
Converted Into Motorcycle Wheel Balancers
6 3/8”
8 5/8”
The WBAWL is a pneumatic wheel lift
designed to raise and support (up to
150 lb.) tire/wheel combinations. The
WBAWL’s compact design allows it to
fit under most wheel balancers.
Specifications
Capacity 150 lbs
Max. Lifting Height 20 ½”
Min. Lifting Height 8”
Overall Height 32 ½”
Required Air Pressure 100 psi
Shipping Weight 100 lbs
ATTC-WBAWL
WHEEL BALANCER ACCESSORIES
IN STORE PICK-UP PRICE
$307
OR
$422
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$82
OR
$97
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$203
OR
$223
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$101
OR
$116
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$305
OR
$455
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$306
OR
$321
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$408
OR
$423
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$203
OR
$218
W/ SHIPPING INCLUDED
23
WE ARE NOT RESPONSIBLE FOR MISPRINTS.
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE.
800.673.8740
TOLL
FREE
AP-PWB50
AP-PTC300
AP-PTC500
Heavy Duty,
Side-Swing Tire
Changer With
Tabletop Design
Patented ‘Lever /
No Lever’ System
Specifications
Max Wheel Diameter 43" (1100mm)
Rim Diameter 10"-30"
Rim Width 1 ½"-20"
Max. Wheel Weight 165 lbs (75 kg)
Power Supply 220V 1Ph
Shipping Weight 225 lbs
Specifications
Rim Clamping Range 10" - 26"
Max Tire Diameter 43"
Max Tire Width 15"
Operating Pressure 145 (PSI)
Power Supply 110V
Shipping Weight 620 lbs
Specifications
Rim Clamping Range 12" - 30"
Max Tire Diameter 43"
Max Tire Width 15"
Operating Pressure 145 (PSI)
Power Supply 110V
Shipping Weight 885 lbs
Building on the undoubted reputation for great product and service that has become synonymous with
the Atlas brand, we are excited to introduce ATLAS PLATINUM, the next level of product specification and
warranty, designed to meet the needs of those customers looking for a higher grade of equipment. The
range commences with a line up of wheel service equipment, each model carefully tailored as a result
of direct comparisons with some of the world’s most popular models from leading, famous brands, but
with a price-point that makes Atlas Platinum simply unbeatable for price / performance ratio. Additional
product and an expansion of the range will follow, and you can expect to see Atlas Platinum firmly
establish itself as a recognized name alongside the traditional ‘mid to premium’ equipment suppliers.
The PWB50 is a feature packed, high volume passenger vehicle wheel balancer
that guarantees speed, accuracy, and a long life by combining Italian engineering
and components with the Factory Direct Value that ATLAS is known for around
the World. Optimization of tire and wheel unbalance (match mounting) is
possible with the PWB50 via OPTIMATCH software and makes balancing
even the most difficult assemblies easy and efficient.
The new Atlas Platinum PTC300 represents the evolution
of the most familiar tire changer configuration found in high
volume tire shops around the world. The PTC300 is an Italian
engineered Swing-Arm Tire Changer that comes standard
with a Left-Hand Bead Pressing and Bead Lifting Assist Arm
to make changing the most challenging tires a breeze.
The new Atlas Platinum PTC500 Center Post
Tire Changer is designed for high-volume tire
shops that deal with the most challenging wheel
and tire combinations in the market. The Atlas
Platinum PTC500 features patented, innovative
features that make it stand out from the competition!
PWB50
PTC300
PTC500
FEATURES
• Pedal brake
• Self-diagnosis
• Self-calibration
• OPTIMACH function
• FES function (Split)
• Special ALU-S program
• Automatic start and stop
• Complete with wheel guard
• Truck adapter set optional
• Standard or Metric Display
• Static and dynamic balancing
• OPF function (Opposite Position)
• Huge combination of ALU programs
• NWN system (no wheel need system)
• 2D Data Entry (Diameter and Offset)
• Automatic measure of wheel
diameter and distance
• Complete with cones and quick
clamping ring nut
FEATURES
• 110v
• Tire Lift Included
• Center Post Design
• Lever-No-Lever System
• High Performance Model
• Smart-Lock Locking System
• Rim Clamping Range: 12”-30”
• Reinforced Vertical Arm And Body
• Ergonomic Position For The Bead
Breaker Pedal
• Oversize Bead Breaker Arm With
Double Axis Blade
• Inflating Pedal With Tool Tray And
External GT Gun
• Left And Right Assist Arms With
Ergonomic Handles
FEATURES
• 110v
• 145 PSI Operating Pressure
• Star-Shaped Turntable Design
• Rim Clamping Range: 10” - 26”
• Complete With Internal Bead
Seating System
• External Locking Rim
Dimension: 12” - 26”
• Internal Locking Rim
Dimension: 10” - 24”
• Max Tire Diameter: 43”
• Max Tire Width: 15”
ATLAS PLATINUM LINE
IN STORE PICK-UP PRICE
$2495
OR
$2645
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$3495
OR
$3645
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$6495
OR
$6695
W/ SHIPPING INCLUDED
24
WE ARE NOT RESPONSIBLE FOR MISPRINTS
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE
www.GregSmithEquipment.com
• Two Speed Hydraulic Chuck
• Portable Control Unit
• Remote controlled
Tilting/Shifting Tool Arm
• Working Tool With
Automatic Rotation System
• Wireless Control (Optional)
FEATURES TTC-306 Specifications
Center Hole Diameter
4 1/4” - 46” (3’ 10”)
[47”(3’ 11”) – 56” (4’ 8”)
With Extensions]
Max. Wheel Weight 3,968 lb.
Max. Tire Diameter 98” (8’ 2”)
Max. Tire Width 53” (4’ 5”)
Shipping Weight 2,260 lb.
The Atlas TTC301 is a heavy duty truck tire changer
designed to accommodate tire diameters in excess of 63”.
This Heavy Duty Atlas truck tire changer is designed and
engineered to handle rim sizes from 3 3/8” to 27” and
can easily accommodate tires with a maximum width of
30 1/2”. The Atlas TTC301 truck tire
changer is the perfect choice for the
large truck tire center that specializes in
mounting and demounting over the road
semi tires.
This Heavy Duty Atlas truck tire changer is designed
and engineered to handle rim bore sizes from 8
inches to 26 inches and tire diameters in excess
of 55 inches. The fully automatic Atlas
TTC-305 truck tire changer can easily
accommodate tires with a maximum
width of 30.5 inches. The TTC-305 truck
tire changer features a single speed hydraulic
chuck with five (5) locking rim positions. The
ergonomic toggle control panel and foot pedals
control the automatic operation of the truck
tire changer.
The Atlas TTC303 is a heavy duty truck tire changer designed and engineered to handle rim sizes
from 4 1/4” to 56” and tire diameters in excess of over 90”. The Atlas Truck Tire Changer can
easily accommodate tires with a maximum width of up to 42”. The TTC303 handles off-road
tires, agricultural tires, super single tires, and skidder tires with ease.
The Atlas TTC 306 features a remote
controlled rotating bead breaker disc and
mount/demount head that are controlled
from either the portable remote console
or (optional) ZigBee® remote control.
This Super Duty Atlas truck tire changer
is designed and engineered to handle
rim sizes from 14” to 56” and tire
diameters in excess of over 97”.
FEATURES
• Available With Either 1-Phase
Or 3-Phase Power Unit
• Handles Rims From
4 1/4” To 56” And Tire
Diameters In Excess Of
Over 90”
• Changes Tires With A
Maximum Width Of Up
To 42 Inches
• 2 Speed (3 Phase Power Unit)
Hydraulic Chuck
• 5 Rim Locking Positions
• 1 Speed Hydraulic Chuck
When Equipped With 220 V,
Single (1) Phase Power
• Portable Control Unit
TTC-303 Specifications
Center Hole Diameter
4 1/4” - 46” (3’ 10”)
[47”(3’ 11”) – 56” (4’ 8”)
With Extensions]
Max. Wheel Weight 3,307 lb.
Max. Tire Diameter 90 1/2” (7’ 6 1/2”)
Max. Tire Width 42” (3’ 6”)
Shipping Weight 1,800 lb.
Included
Accessories Set Included Accessories Set
Heavy Duty Truck Tire Changer Heavy Duty Truck Tire Changer
TTC-301 TTC-305
TTC-306TTC-303 Automatic Super Duty
Truck Tire Changer
Super Duty Truck Tire Changer
WATCH OUR
VIDEO ONLINE!
1 Phase OR
3 Phase Motor
TTC-301 Specifications
Center Hole Diameter 3-3/8” - 27”
Max. Wheel Weight 3,300 lb.
Max. Tire Diameter 63”
Max. Tire Width 30 ½”
Shipping Weight 1,400 lb.
TTC-305 Specifications
Center Hole Diameter 3-3/8” - 27”
Max. Wheel Weight 838 lb.
Max. Tire Diameter 55”
Max. Tire Width 30 ½”
Shipping Weight 1,490 lb.
1 Phase Motor 1 Phase Motor
Accessories Set
Aluminum
Adapter Set
Extension Kit
3 Phase
Motor
Buy A Truck Tire Balancer When
You Buy A Truck Tire Changer And
SAVE HUNDREDS $$$
Wireless
Control Unit
For TTC-306
Aluminum
Adapter Set
• Handles rim bores from 8" to 26" and
tire diameters in excess of over 55"
• Interchangeable Mount/Demount and
Roller Heads
• Accommodates tires with a maximum
width of up to 30.5 inches
• Electric/Hydraulic Self-Centering
Four Jaw Chuck
• 5 different rim locking positions
• Aluminum Rim Accessories Included
• Automatic movement and positioning
of bead tool, carriage, and chuck arm.
• 220 Volt/ 1 Phase Motor
FEATURES
ATTC301/1PH
AT TC3 03-1
ATTC306
ATTC306-WLC
ATTC305A
TRUCK TIRE CHANGERS
IN STORE PICK-UP PRICE
$5605
OR
$5855
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$8155
OR
$8405
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$10195
OR
$10445
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$509
OR
$539
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$6625
OR
$6875
W/ SHIPPING INCLUDED
25
WE ARE NOT RESPONSIBLE FOR MISPRINTS.
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE.
800.673.8740
TOLL
FREE
39 1/2” (3’ 3 1/2”)
Add An Assist
Arm Now Or In
The Future
FEATURES
• 1-year limited warranty
• 4 plastic rim protectors
• Soap reservoir
• Oiler, filter, regulator
• Commercial grade
• Air operated jaw slides
• Steel, aluminum, alloy rims
FEATURES
• 1-year limited warranty
• 4 plastic rim protectors
• Soap reservoir
• Oiler, filter, regulator
• Commercial grade
• Air operated jaw slides
• Steel, aluminum, alloy rims
• Bead blaster system
Specifications
External clamping range
9 3/4” - 23 1/4”
Internal clamping range 11 5/8” - 25 1/4”
Maximum tire diameter 39”
Operating voltage 110V 1Ph
Maximum wheel width
(Bead Breaker)
13”
Shipping weight 500 lb.
Specifications
External clamping range
9 3/4” - 23 1/4”
Internal clamping range 11 5/8” - 25 1/4”
Maximum tire diameter 39”
Operating voltage 110V 1Ph
Maximum wheel width
(Bead Breaker)
13”
Shipping weight 500 lb.
39” (3’ 3”)
77” (6’ 5”)
39 1/2” (3’ 3 1/2”)
49 (4’ 1”)
77” (6’ 5”)
The Atlas TC229 has the same clamping and tire changing capabilities
as the Atlas TC221 wheel clamp tire changer, but has the added,
built-in bead blaster system to help inflate stiff sidewall tires or other
“hard to inflate” tires.
The Atlas TC289 wheel clamp tire changer is the perfect wheel clamp tire changer
for most general automotive service departments and medium sized tire stores. The
powerful, adjustable bead breaker located on the side of the tire changer is designed
to break even the most stubborn and rusted beads without damage to the rim. The
Atlas TC289 is equipped with our powerful bead blast feature.
Specifications
External clamping range
11 7/8” - 28”
Internal clamping range 13 7/8” - 29 7/8”
Maximum tire diameter 47 1/2”
Operating voltage 110V 1Ph
Maximum wheel width
(Bead Breaker)
18 1/2”
Shipping weight 650 lb.
FEATURES
• 1-year limited warranty
• 4 plastic rim protectors
• Soap reservoir
• Oiler, filter, regulator
• Commercial grade
• Air operated jaw slides
• Steel, aluminum, alloy rims
• Bead Blaster System
80 1/2” (6’ 8 1/2”)
44 1/2” (3’ 8 1/2”)
40” (3’ 4”)
The Atlas TC755 wheel clamp tire changer is the perfect wheel clamp tire
changer for most general automotive service departments and tire stores. The
powerful bead breaker located on the side of the tire changer is designed to
break even the most stubborn and rusted beads without damage to the rim.
The Atlas TC755 is equipped with our powerful bead blast feature and has a tilt
back column.
Specifications
External clamping range 11 7/8” - 28”
Internal clamping range 13 7/8” -
29 7/8”
Maximum tire diameter 47 ½”
Operating voltage 110V 1Ph
Maximum wheel width
(Bead Breaker)
13 ½
Shipping Weight 650 lb.
FEATURES
• 1-year limited warranty
• 4 plastic rim protectors
• Soap reservoir
• Oiler, filter, regulator
• Tilt-back column
• Air operated jaw slides
• Bead Blaster System
COMMERCIAL
GRADE
COMMERCIAL
GRADE
Bead Blaster
Not Included
Designed For
Low Profile Tires
Save Hundreds $$$
When You Buy A
Tire Changer/Wheel Balancer
Combo
TC221 TC229
Add An Assist
Arm Now Or In
The Future
76 1/2” (6’ 4 1/2”)
63” (5’ 3”)
w/ column tilted back
58” (4’ 10”)
The Atlas TC221 is the perfect tire changer for a small commercial
garage or an ATV/motorcycle dealer. It is designed to change tires
on both high priced alloy wheels and steel wheels.
FEATURES
• 1-year limited warranty
• 4 plastic rim protectors
• Soap reservoir
• Automatic oiler
• Commercial grade
• Air operated jaw slides
• Steel, aluminum, alloy rims
Specifications
External clamping range
11” - 20"
Internal clamping range 12 1/2” - 12 1/2”
Maximum tire diameter 39”
Operating voltage 110V 1Ph
Maximum wheel width
(Bead Breaker)
13”
Shipping weight 500 lb.
68” (5’ 8”)
COMMERCIAL GRADE
Bead Blaster
Not Included
T C 211
The Atlas TC 211 wheel clamp tire changer is the perfect changer
for a small commercial garage or an ATV/motorcycle dealer.
36 1/2” (3’ 1/2”)
36” (3’)
COMMERCIAL
GRADE
COMMERCIAL
GRADE
AT TC211 ATTC221
ATTC229
ATTC289
ATTC755
TC289 TC755
PASSENGER TIRE CHANGERS
IN STORE PICK-UP PRICE
$1117
OR
$1267
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1423
OR
$1573
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$995
IN STORE PICK-UP PRICE
$1750
OR
$1900
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$2137
OR
$2287
W/ SHIPPING INCLUDED
26
WE ARE NOT RESPONSIBLE FOR MISPRINTS
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE
www.GregSmithEquipment.com
COMMERCIAL
GRADE
TC229LH TC289DAA TC755EZ
The Atlas TC229LH wheel clamp tire changer is the
Atlas TC229 wheel clamp tire changer that has been
equipped with the pneumatic Atlas LH assist arm.
The Atlas TC289 DAA wheel clamp tire changer is
the Atlas 289 wheel clamp tire changer that has been
equipped with the pneumatic Atlas LH assist arm plus the
Atlas RF assist arm that includes a bead roller and second
bead lifting/pressing disc.
COMMERCIAL
GRADE
Save
Hundreds $$$
When You Buy A
Tire Changer/Wheel Balancer
Combo
FEATURES
• Tire Inflater
• 3 Positions For Clamping Jaws
• 90-110 Psi
• Beadblaster
• Left Hand Assist Arm Assembly
• One Year “Parts Only”
Limited Warranty
FEATURES
• Tire Inflater
• Adjustable Bead Breaker
• 3 Positions For Clamping Jaws
• 90-110 Psi
• Beadblaster
• Left & Right Side Assist Arms
• One Year “Parts Only”
Limited Warranty
Dual Assist Arm
The Atlas DAA is the combination
of the Atlas LH assist arm and the
Atlas RH assist arm.
FINANCING
AVAILABLE
Right Assist Arm
The Atlas RH assist arm is the perfect
complement to the Atlas LH assist arm
when you need to change extremely stiff
sidewall and run flat tires.
Left Assist Arm
The ATLAS LH assist arm is designed to be mounted
on wheel clamp tire changers.
E-Z Arm
The Atlas E-Z arm
(mounted on the right
side) performs almost
all the same functions
as the dual arms.
ATTC-RHA-SA
ATTC-LHA
ATTC-DAA-SA
ATTC-DA A-T
ATTC-HP1XLT
Atlas TC229LH Tire Changer
Atlas TC289DAA Tire Changer
Atlas TC755EZ Tire Changer
FEATURES
• Tire Inflater
• 3 Positions For
Clamping Jaws
• 90-110 Psi
• Tilting Column
• Beadblaster
• One Year “Parts Only”
Limited Warranty
The Atlas E-Z arm is the perfect addition to
the Atlas 755 tilt back tire changers. The Atlas
E-Z arm (mounted on the right side) performs
almost all the same functions as the dual arms.
COMMERCIAL
GRADE
Wheel Lift Optional
TIRE CHANGER ASSIST ARMS
IN STORE PICK-UP PRICE
$2137
OR
$2287
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$2785
OR
$2935
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$2744
OR
$2894
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1020
OR
$1170
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$510
OR
$635
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$714
OR
$864
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$607
27
WE ARE NOT RESPONSIBLE FOR MISPRINTS.
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE.
800.673.8740
TOLL
FREE
Motorcycle/ATV
Flip Adapters
ATTC-MC/ATV
Deluxe ATV
Adapters
ATTC-DX-ATV
Deluxe MC
Adapters
ATTC-DX-MC-SPJP
Atlas 200 And 700 Series Tire Changers Can Be Converted Into Motorcycle/ATV Tire Changers
Small Plastic Jaw Protectors
• Set of four
• Helps to prevent rim damage on
custom rims
• Designed for the Deluxe ATV
and Deluxe Motorcycle adapters
ATTC-SPJP
Large Plastic Jaw Protectors
Large Plastic Jaw Protectors are used on the tire changer turntable jaws
to help prevent rim damage on custom aluminum and alloy rims.
Set of four
ATTC-LPJP
Replacement plastic inserts for Atlas 200 and 700 series tire changers.
TAXP-MHPP
Plastic Inserts For
Mount / Demount Heads
Atlas ABS Bead Blaster
Atlas Aluminum Bead Seater
The ABS works well on
ATV tires all the way up to
semi truck tires.
The (ABS) Atlas Bead Seater delivers a large volume of air in a
very short amount of time to help seat the beads on the most
stubborn of tires. The ABS is portable so that it can be used in
the shop or in the field.
The ATLAS wheel lift can be mounted on the Atlas
200 and 700 series wheel clamp tire changer. This
wheel lift is a great back saver. The Atlas wheel
lift can raise a 150 pound wheel assembly into the
correct position for placement onto the turntable.
The ATLAS hands-free clamp is the perfect solution to help mount
the stiff sidewall tires found on many of today’s vehicles.
The Atlas manual bead roller is an
inexpensive upper bead pressing tool that
is perfect for those service centers that
do not specialize in stiff sidewall tires, but
want to be prepared for the occasional
hard to change stiff side wall tire.
Atlas Wheel Lift
The Atlas center post adapter was designed to eliminate the possibility of jaw damage to decorative
automotive rim. Makes any wheel clamp tire changer as versatile as a center post tire changer.
Atlas Center Post Adapter Quick Change Head Assembly
ATTC-QCHAK
Change from a metal head to plastic head in 5 seconds!
WATCH OUR
VIDEO ONLINE!
Hands Free Clamp
Manual Bead Roller Arm
WATCH OUR
VIDEO ONLINE!
ATTC-HFC
ATTC-BPT
Pneumatic Portable Wheel Lift
The Atlas pneumatic portable wheel lift (AEZWL) is the perfect solution to prevent back injuries
when lifting large wheel assemblies onto the shaft of a wheel balancer or on onto tire changer
turntable. Today’s wheels and tires are getting bigger and heavier. Many wheels are expensive
and can be easily scratched or damaged. The Atlas wheel pneumatic wheel lift will lift a 180
pound wheel easily and allow the operator to maneuver the wheel into the correct position
without fear of wheel damage or back strain.
The AEZWL operates on 120 PSI air pressure.
ATTC-AEZWL
• Capacity: 180 LBS.
• Max. Lifting Height: 39 1/8”
• Min. Lifting Height: 4”
• Arm Length: 17 1/2” - 33 1/4”
• Distance Between Arms: 9” - 22”
• Overall Height: 66 7/8”
• Required Air Pressure: 120 psi
• Shipping Weight: 175 LBS.
WATCH OUR
VIDEO ONLINE!
Portable Bead Breaker
• Great for farm and truck tires.
• Dimensions: 19” L x 5 ½” W x 13” T
• Max. Opening of Jaws: 5”
• Size of inlet for coupler or fitting:
5/8” pipe thread
• Fits All Types Of Rims
• Works With Plastic
Air/Hydraulic Pump
• Shipping Weight: 34 lbs.
HTTLA5200
+
RM-DSR7
The Atlas Aluminum Bead Seater delivers a large volume of
air in a very short amount of time to help seat the beads on
the most stubborn of tires, from small passenger tires up to
large over the road semi tires.
Portable
Lightweight
Construction
Fits Atlas 200 And 700
Series Tire Changers
AT T C -A E Z W L-2
AT TC -W L-2
New
Model
Available
ATTC-ABS
• Capacity: 180 LBS.
• 3" Poly Casters
• Max. Lifting Height: 40 1/2”
• Min. Lifting Height: 5 1/2”
• Arm Length: 12”
• Distance Between Arms: 10”
• Overall Height: 67 3/4”
• Required Air Pressure: 120 psi
• Shipping Weight: 175 LBS.
ATTC-CPA
TIRE CHANGER ACCESSORIES
IN STORE PICK-UP PRICE
$254
OR
$269
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$203
OR
$218
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$203
OR
$218
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$16 IN STORE PICK-UP PRICE
$20
IN STORE PICK-UP PRICE
$16
IN STORE PICK-UP PRICE
$499
IN STORE PICK-UP PRICE
$407
OR
$557
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$203
OR
$218
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$203
OR
$229
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$285
OR
$301
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$219
OR
$253
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$305
OR
$430
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$438
OR
$588
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$50
IN STORE PICK-UP PRICE
$101
28
WE ARE NOT RESPONSIBLE FOR MISPRINTS
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE
www.GregSmithEquipment.com
Bench Vises
Great for home shops or commercial applications. These Bench Vises feature serrated jaws for better gripping, a swivel base for versatility, and a built in anvil.
HTVISE-5 HTVISE-6 HT VI SE-10
10 Inch Jaw Width
6 Inch Jaw Width5 Inch Jaw Width
HEAVY DUTY STEEL HEAVY DUTY STEEL
2 Drawer Workbench
HT WS 5911
• L x W x H: 59” x 25” x 34”
• Heavy Duty Steel Construction
• Shipping Weight: 180 lb.
FEATURES
3 Drawer Workbench
HT WS79111
• L x W x H: 79” x 25” x 34”
• Heavy Duty Steel Construction
• Shipping Weight: 210 lb.
FEATURES
LOCKING DRAWERSLOCKING DRAWERS
Sloping top with drain
Transmission
Te a r d ow n
Workbench • 47” Wide x 32” Deep x 41” High
• Heavy Duty Steel Construction
• Lockable Casters
• Lockable Drawer
• Shipping Weight: 200 lb.
FEATURES
5 Drawer With
Wood Top
Wood Top
Workbench
Wood Top
Workbench
Rolling
Work Table
Rolling Cabinet
HTTC321A
HTTSA5405-X
HTTZL2060W-RD HTTZL2060W-GR HTTC304C
HTTTB
RED GRAY
• 750 lb. capacity
• Table Top Dimensions:
19.5” wide x 36” long
• Maximum Height 54”
• Minimum Height 14.5”
• Shipping Weight: 220 Lbs.
• Hydraulic Foot Pedal Operated
• Hand Release Lowering Lever
• 1,100 lb. capacity
• Table Dimensions:
20” wide x 32” long
• Maximum Height 35”
• Minimum Height 11.5”
• Weight 260 lbs.
• Hydraulic Foot Pedal Operated
• Hand Release Lowering Lever
• 325 lb. capacity
• Table Dimensions:
18" wide x 28" long
• Maximum Height 29"
• Minimum Height 9"
• Weight 102 lbs.
• Hydraulic Foot Pedal Operated
• Hand Release Lowering Lever
750 lb. Capacity
Scissor Lift Table
1100 lb. Capacity
Scissor Table Truck
325 lb. Capacity
Scissor Table Truck
Maximum
Height:
54”
Maximum
Height:
29”
Maximum
Height:
35”
*Color May Vary *Color May Vary *Color May Vary
HTTF15 HTTFD35 HTTF50
WORKBENCHES + TABLES + VISES
IN STORE PICK-UP PRICE
$77
OR
$121
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$107
OR
$169
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$275
OR
$425
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$505
OR
$655
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$230
OR
$380
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$332
OR
$482
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$99
IN STORE PICK-UP PRICE
$99
IN STORE PICK-UP PRICE
$347
IN STORE PICK-UP PRICE
$168 IN STORE PICK-UP PRICE
$97
IN STORE PICK-UP PRICE
$260
OR
$410
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$428
OR
$578
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$464
OR
$614
W/ SHIPPING INCLUDED
29
WE ARE NOT RESPONSIBLE FOR MISPRINTS.
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE.
800.673.8740
TOLL
FREE
50 TON
Air/Hydraulic
75 TON Air/Hydraulic
45 TON
Air/Hydraulic
40 TON
Air/Hydraulic
FEATURES
• Measurement between uprights: 31 1/2”
• Base measurement: 47 1/4” W x 39 1/4” L
• Overall height: 6’ 10” (82”)
• Includes Pressing Blocks
• Sliding ram assembly
• Shipping weight: 1,550 lb.
HT0813GG HT0812-GG
HT0807-GGHT0811-GG HT0806
30 TON
Air/Hydraulic
20 TON
Air/ Hydraulic
20 TON Air/Hydraulic 20 TON Hydraulic
W/ Gauge
FEATURES
• Measurement between uprights:
21 1/2”
• Working Height: 38 1/2”
• Base measurement: 29” W x 27” L
• Overall height: 6’ (72”)
• Ram assembly position
adjustable side to side
• Includes Pressing Blocks
• Shipping Weight: 217 Lb.
FEATURES
• Measurement between uprights: 21 1/8”
• Working Height: 29 1/2”
• Base measurement: 25” W x 28” L
• Overall height: 5’ (60”)
• Includes Pressing Blocks
• Shipping weight: 174 lb.
FEATURES
• Measurement between uprights: 21 1/2”
• Working Height: 30 1/2”
• Base measurement: 25” W x 28” L
• Overall height: 5’ (60”)
• Includes Pressing Blocks
• Shipping weight: 164 lb.
HT0805
HT0704-KIT
HT070808A
12 TON Hydraulic 9 Piece Press Pin/
Punch Kit
FEATURES
• Measurement between uprights: 20”
• Working Height: 36 1/4”
• Base measurement: 27 W x 20” L
• Overall height: 5’ 6” (66”)
• Includes Pressing Blocks
• Shipping weight: 163 lb.
100 TON Air/Hydraulic
• Measurement between uprights - 31 1/2”
• Base measurement: 45” W x 31 1/2” L
• Overall height: 5’ 10 5/8” (70 5/8”)
• Includes Pressing Blocks
• Sliding ram assembly
• Shipping weight: 1,140 lb.
FEATURES
• Measurement between uprights:
28 1/2”
• Base measurement: 40 3/4” W
x 31 1/2” L
• Overall height: 6’ 10” (76 1/2”)
• Ram assembly position
adjustable side to side
• Includes Pressing Blocks
• Shipping weight: 800 lbs.
FEATURES
• Measurement between uprights:
32 1/4”
• Working Height: 31 1/2”
• Base measurement:
44” W x 31 1/2” L
• Overall height: 5’ 7 1/4”
(67 1/4”)
• Includes Pressing Blocks
• Shipping weight: 730 lbs.
FEATURES
• Measurement between
uprights: 25 1/2”
• Working Height: 41”
• Base measurement:
38” W x 34” L
• Overall height: 6’ 3” (75”)
• Includes Pressing Blocks
• Shipping Weight: 540 Lb.
FEATURES • Pressure gauge
• Air or manual operation
• Pressing blocks
• 6 positions for pressing bed
• Distance between uprights: 21 1/4”
• Working Height: 34 1/4”
• Dimensions of base: 32” L x 27 1/2” W
• Overall Height: 75 1/2” (6’ 3 1/2”)
• Shipping weight: 335 lb.
FEATURES
HT0803
INCLUDES HOLDER
BRACKET WITH
MOUNTING
HARDWARE
Fits the Dynamo
HT070808A, HT0806,
HT0807, HT0811,
HT0812, HT0813, &
HT0882 shop presses
*Color May Vary
HT0702-KIT
HT0882
75 TON
Electric/Hydraulic
• Measurement between uprights: 31 1/2”
• Base measurement: 45” W x 31 1/2” L
• Overall height: 6’ 1” (73”)
• Includes Pressing Blocks
• Sliding ram assembly
• 110V Motor
• Shipping Weight: 1,225 lb.
FEATURES
*Color May Vary
HT-PRESSPIN-KIT
SHOP PRESSES
IN STORE PICK-UP PRICE
$4233
OR
$4483
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$2377
OR
$2627
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$3667
IN STORE PICK-UP PRICE
$2039
OR
$2189
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$301
OR
$451
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$235
OR
$385
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$250
OR
$400
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$101
OR
$121
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1070
OR
$1220
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$811
OR
$961
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$857
OR
$1007
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$408
OR
$558
W/ SHIPPING INCLUDED
30
WE ARE NOT RESPONSIBLE FOR MISPRINTS
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE
www.GregSmithEquipment.com
2 Ton Hydraulic or Air/Hydraulic
Low Profile Floor Jack
This 2 ton capacity low profile floor jack will fit under almost any vehicle and is
great for shop or home use. The long, low design of this floor jack along with the
rear swivel casters make it easy to move and place. Foot pump operated.
• 2 Ton Capacity
• Fully Lowered (Pad Height): 5 1/4”
• Fully Raised: 31”
• Rear Swivel Casters Make
Positioning Under Vehicles Easy
• Foot Pump Operated
• Commercial Grade
• Overall Length: 54”
• Overall Width: 17 1/2”
• Saddle Diameter: 4 7/8”
• Shipping Weight:143 Lb.
FEATURES
The full hydraulic model is operated by either the handle or the foot pedal.
The air/hydraulic model can be operated by air pressure or can be manually operated.
Hydraulic
HTLFJ2
The full hydraulic model is operated by either
the handle or the foot pedal. The air/hydraulic
model can be operated by air pressure or can
be manually operated.
FEATURES
• 5 Ton Capacity
• Fully Lowered: 6 1/2”
• Fully Raised: 26”
• Rear swivel casters
makes positioning under
vehicles easy
• Commercial Grade
• Overall Length: 57”
• Overall Width: 15”
• Saddle Diameter: 5 1/8”
• Shipping Weight 245 lb.
FEATURES
• 35 Ton Capacity
• Fully Lowered: 8 1/4”
• Fully Raised: 17 1/4”
• Two Heavy Duty 8”
Rubber Wheels
• Commercial Grade
• Overall Length: 22”
• Overall Width: 7 7/8”
• Overall Width: 41 1/2”
• Shipping Weight 120 lb.
5 Ton Hydraulic or Air/Hydraulic
Low Profile Jack
HTALFJ5
HT1912
10 Ton Hydraulic or Air/Hydraulic
Low Profile Floor Jack
FEATURES
• 10 Ton capacity
• Fully Lowered: 8 1/2”
• Fully Raised: 23”
• Rear swivel casters
makes positioning under
vehicles easy
• Commercial grade
• Overall Length: 62”
• Overall Width: 20”
• Saddle Diameter: 5 7/8”
• Shipping Weight 366 lb.
The full hydraulic model is operated by either the handle or the foot pedal. The
air/hydraulic model can be operated by air pressure or can be manually operated.
The full hydraulic model is operated by either the handle or the foot pedal. The
air/hydraulic model can be operated by air pressure or can be manually operated.
HTLFJ10
Hydraulic
HTALFJ10
Air/Hydraulic
Air Bumper Jack
FEATURES
• Weight capacity: 2,500 LB.
• Height range: 10”–30”
• Air Pressure: 120-180 psi
• Air operated
• Shipping weight: 250 LB.
HTEL1.5
22 Or 35 Ton Air/Hydraulic Jack
• 3 adapters included
• Minimum height: 10”
• Maximum lifting height
(w/ included adapter)
18” (22 ton) / 25” (35 ton)
HT1902
Shipping Weight: 90 lb.
22 Ton
HT1903
Shipping Weight: 108 lb.
35 Ton
2 Bag Air Jack 3 Bag Air Jack
The 2,500 lb capacity bumper jack has an air control valve for easy raising and lowering of a
load. This vehicle end lift also features an adjustable bumper extension with rubber mounting
pads. This bumper jack has solid rubber tires in the rear, making it easy to move this jack in
and out of position.
HT3101-NEW
• Air operated
• 3,500 LB. capacity
• Maximum height: 15”
HT3102-NEW
• Foam padded seat for maximum comfort
• Five swivel caster wheels for easy moving
• Height adjustable from 15” to 19 1/4”
• Seat swivels 360 degrees
• Shipping Weight: 15 Lb.
Adjustable Air Seat
HTSE AT-1
MORE
MODELS
AVAILABLE
ON OUR
WEBSITE
35/22 Ton Air/Hydraulic
Two Stage Service Jack
Air/Hydraulic
HTALFJ2
• Air operated
• 4,300 LB. capacity
• Maximum height: 12 1/2”
SERVICE JACKS
IN STORE PICK-UP PRICE
$638
OR
$788
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$765
OR
$915
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$454
OR
$604
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$254
OR
$325
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$285
OR
$350
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$36
OR
$53
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$275
OR
$425
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$377
OR
$527
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$245
OR
$395
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$602
OR
$752
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$399
IN STORE PICK-UP PRICE
$495
OR
$645
W/ SHIPPING INCLUDED
31
WE ARE NOT RESPONSIBLE FOR MISPRINTS.
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE.
800.673.8740
TOLL
FREE
FEATURES
• 1,250 Lb. Capacity
• Air/Hydraulic Operated
• Movable Power Unit For
Easier Hands Free Operation
• Fully Adjustable Saddle
• Heavy Duty Steel Swivel
Casters For Easy Positioning
• Shipping weight: 300 LBS.
Power Train Lift
Power Train Lift
2,500 LB. CAPACITY
1,250 LB. CAPACITY
FEATURES
• Scissor lift design provides easy
360˚ access to any component
• Table top height from 33” to 80”
• Four 8” diameter rubber coated
swivel caster wheels for easy
maneuverability with even the
heaviest loads
• Wheels can be locked in position for
steering, rear wheels can be locked
to prevent the lift from rolling
• Removable air/hydraulic power
unit provides hands free operation
anywhere around the lift’s perimeter
• Adjusting screws tilt the table + or -
15 degrees side to side, or fore and
aft, ensures maximum stability of the
table in any position
This lift table handles power train components like
engines and their transmissions, engines with trans-axle
assemblies, rear ends and large electric vehicle batteries.
It will also serve as a work table where components can be
lowered to a convenient work height for repairs.
HT6400
2,000 LB.
Capacity
Folding
Engine Stand
1,250 LB.
Capacity
Engine
Stand
2 Ton Air/Hydraulic
Foldable Engine Crane
3 Ton Hydraulic Engine Crane
• Air/hydraulic operated
• Adjustable telescoping boom - 4 different positions
• Used for maneuvering engines, transmissions, or heavy loads
• Large diameter ram makes lifting easy
• Shipping Weight: 250 LBS.
• Rear swivel
casters
• Rotating
backing plate
• Fully adjustable
mounting head
• Shipping Weight:
67 LBS.
HT72501
HTES2000
HTES1250
• 1000 lb. capacity
• Fits most Small Block Chevy engines
• FOUR heavy duty casters for easy
maneuverability
• Used for storing, transporting, and
working on “in progress” engines
• Low design for maximum stability
when working on engines
• Shipping Weight: 21 LBS.
600 LB. Engine Support Bar
• Minimum Width: 44 1/2”
• Maximum Width: 62”
• Shipping Weight: 33 LBS.
Engine Cradle
1000 LB. Engine Support Bar
• Fully Adjustable Working Width
• Overall Width: 59”
• Shipping Weight: 41 LBS.
HT1703
HT1701
HTEC
• 3 Ton Capacity
• Hydraulic operated
• Used for maneuvering engines, transmissions, or heavy loads
• Adjustable length legs for stability
• Large diameter ram makes lifting easy
• Shipping Weight: 250 LBS.
HT73001
Max.
Lifting
Height:
80” (6’ 8”)
Max.
Lifting
Height:
55” (4’ 7”)
Fully Adjustable
WATCH OUR
VIDEO ONLINE!
• 9 1/2” jack stroke
• 100 - 120 working PSI
• Air or manual operated
• Horizontal and vertical positions
• Spring return rams for fast ram retraction
• 8 Heavy duty cast iron dies from 1/2” to 3”
• Adjustable top rollers for a degree of bends up to 90°
16 Ton
Hydraulic
Pipe Bender
• 9 1/2" jack stroke
• Horizontal and vertical positions
• Spring return rams for fast ram retraction
• 8 Heavy duty cast iron dies from 1/2" to 3"
• Adjustable top rollers for a degree of bends up to 90°
12 Ton
Hydraulic
Pipe Bender
• Heavy duty cast iron
dies, from 1/2” to 2”
• Spring return ram for
fast ram retraction
16 Ton
Air/Hydraulic
Pipe Bender
• Air or manual operated
• Adjustable top rollers for
degree of bends up to 90°
HTPB12
HTPB16
HTPB12-AIR
HTPB16-AIR
12 Ton
Air/Hydraulic
Pipe Bender
The 3 Ton Hydraulic Engine Crane is strong, durable, versatile, and a real space saver!
This Cherry Picker’s strong design allows for maximum lifting power for a minimum of
shop space.
HTPTLIFT
ENGINE SUPPORT EQUIPMENT + PIPE BENDERS
IN STORE PICK-UP PRICE
$1703
OR
$1853
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$867
OR
$1017
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$367
OR
$517
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$454
OR
$604
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$117
OR
$267
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$153
OR
$303
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$250
OR
$400
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$296
OR
$446
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$199
OR
$349
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$101
OR
$168
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$31
OR
$52
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$46
OR
$79
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$61
OR
$102
W/ SHIPPING INCLUDED
32
WE ARE NOT RESPONSIBLE FOR MISPRINTS
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE
www.GregSmithEquipment.com
FEATURES
• 2,600 LB. capacity
• Accommodates wheel
diameters from 39” - 83”
• Maximum wheel width: 31 ½”
• Hydraulic
• Shipping Weight: 330 LBS
SWC-500 Heated
Spray Wash Cabinet
SWC-750 Heated
Spray Wash Cabinet
FEATURES
• 50 Gallon Tank
• Automatic cleaning
• Uses eco-friendly soap
and hot water
• Casters provide mobility
• Parts basket and hang tree
• Timer with auto shut-off
• Front loading design
• Cleans small and large parts
• Oil skimmer
• Turntable rotates at 3 rpm
• 3/16” vents spray solution
at 30-60 GPM
• Solution is filtered and recycled
• One Year Parts Warranty
• Shipping Weight: 750 Lbs.
FEATURES
• 53 Gallon Tank
• Automatic cleaning
• Uses eco-friendly soap and hot water
• Casters provide mobility
• Heavy duty pump
• Timer with auto shut-off
• Front loading design
• Cleans small and large parts
• Oil skimmer
• Turntable rotates at 3 rpm
• 3/16” vents spray solution at
30-60 GPM
• Solution is filtered and recycled
• Load capacity: 1,250 lbs.
• One Year Parts Warranty
• Shipping weight: 960 lbs.
• Solvent Capacity:
3 1/2 gallons
• Pump: 4 GPM
• Motor: 110V
• Flexible stainless
steel nozzle
• Removable tray
• Heavy duty steel
construction
• Water based only
• Lightweight, portable
• Shipping weight: 16 Lb.
FEATURES
3.5 Gallon Parts Washer 40 Gallon Parts Washer20 Gallon Parts Washer
HTPW3.5G
HTPW20G
The SWC-500 Spray Wash Cabinet is the ideal parts washer for
any automotive repair or transmission shop.
The SWC-750 is designed to handle light diesel engines and engine parts for the truck
repair and maintenance trade. It is a full foot taller than our standard SWC-500.
SL-STD-500-KIT SL-STD-750-KIT
*Color May Vary
1,000 LB. Dual Wheel Dolly
The hydraulic system on this Dual Wheel Dolly makes it easy to remove and install dual wheel assemblies.
FEATURES
• 1,000 LB. Capacity
• Working range: 3 ½” – 10 ¾”
• 6 ft. support Chain included
• Two mounting positions for Lift Arms
• Steel wheel casters: two 3 ½”
stationary in front & one 3 ½”
swivel in rear
• Floor Dimensions: 40” L x 40” W
• Height: 29 ¼” – 35 ¼”
• Lift Arm Length: 23 ¾”
• Lift Arm Spread: Outer Position 25”-
Inner Position 21”
• Lift: 6 ¼”
• Shipping Weight: 150 lbs
1,500 LB. Heavy Duty Wheel Dolly
The hydraulic system on this heavy duty Dual Wheel Dolly makes it easy to remove and install dual wheel
assemblies from even the largest truck.
FEATURES
• 1500 lb capacity
• For wheels up to 52” diameter
• 6 ft. Support Chain included
• Steel wheel roller bearing casters:
two 3 ½” in front & one 3” in rear
• Tilt Frame and Rolling Lift Arms for easy
positioning of dual wheel assemblies.
• Overall Dimensions: 43” W x 51” L x 35” H
• Lift Arm Length: 26”
• Lift Arm Spread: 21” – 25”
• Lift: 9 ¼”
• Ram Travel 4 ¾”
• Shipping weight: 155 lbs.
FEATURES
• Adjustable Width makes it easy to
load without using your hands.
• Handles Tires Stacked up to 5 Ft. High
• Maximum Width: 30 inches
• Minimum Width: 12 inches
• Caddy Height: 60 inches
• Shipping Weight: 66 lb.
Heavy Duty Wheel Dolly
This Heavy Duty Wheel Dolly is perfect for farm and shop use. This wheel dolly works with large
truck wheel assemblies, implement tires, farm tractors and machinery, and other equipment
requiring wheel changes. This dolly features hydraulic lifting action and heavy duty rollers which
make it easy to lift tires for moving and the heavy duty swivel casters which make it a snap to
transport wheels from one location to another.
HT90751
Tire Rack Carrier
HTT250
Tire Caddy
Tire Inflation Cage
HTT400
HT400
FEATURES
• 110 volt
• Built in drain
• Water based only
• Shipping Weight: 60 Lb.
• 36” overall height on stand
• Gooseneck spout: 20 1/4” L
• On/off switch with indicator light
• Re-circulates fluid at up to 50 GPH
• Washer dimensions:
30” L x 20” D x 11” H
• 20 gallon steel tank
has operating level of
12 gallons
• Extra powerful, heavy
duty electric pump is
fully enclosed
*Color May Vary FEATURES
• 110 volt
• Built in drain
• Water based only
• 40 gallon steel tank
• Gooseneck spout: 24” L
• Shipping Weight: 109 Lb.
• 34 ¾” overall height on stand
• On/off switch with indicator light
• Re-circulates fluid at
up to 50 GPH
• Washer dimensions:
43 1/8” L x 20½” D
x 10½” H
• Extra powerful, heavy
duty electric pump is
fully enclosed
*Color May Vary
HTPW40G
PORTABLE! LARGER
TANK
HT2301
HT712001
2,600 LB
CAPACITY
PARTS WASHERS + WHEEL DOLLIES
IN STORE PICK-UP PRICE
$51
OR
$67
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$128
OR
$188
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$3565
OR
$3715
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$250
OR
$400
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1010
OR
$1160
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$158
OR
$188
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$556
OR
$706
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$219
OR
$369
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$235
OR
$385
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$4075
OR
$4225
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$184
OR
$334
W/ SHIPPING INCLUDED
33
WE ARE NOT RESPONSIBLE FOR MISPRINTS.
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE.
800.673.8740
TOLL
FREE
AF3
Single Stage 60 Gallon
A
I
R
F
O
R
C
E
Specifications
Motor Peak 6.0 Horsepower
Motor Running 3.2 Horsepower
Delivered-CFM 40PSI 12.0
Delivered-CFM 90PSI 10.5
Pressure Setting 90 lb. - 135 lb.
This compressor utilizes a three cylinder single
stage pump as compared to the two cylinder
pump on the Atlas AF3. The Atlas AF4 also
employs a slightly more efficient motor than
the Atlas AF3. The Atlas AF4 produces “faster”
air for the shop operator who cannot wait. The
no-load recovery time (90 LB. to 135 LB.) for the
Atlas AF4 is twice as fast as the Atlas AF3.
(1 minute and 40 seconds.)
AF4
Single Stage 60 Gallon
A
I
R
F
O
R
C
E
Specifications
Motor Peak 7.0 Horsepower
Motor Running 3.4 Horsepower
Delivered-CFM 40PSI 15.0
Delivered-CFM 90PSI 13.7
Pressure Setting 90 lb. - 135 lb.
This compressor is equipped with an oversized
three (3) cylinder cast iron single stage
reciprocating pump that produces a large volume
of air at a very competitive price. The Atlas AF5 is
our lowest priced air compressor that is capable of
delivering enough air to effectively run our SBC 420
sandblast cabinet (when used with #8 or #10 glass
beads). The Atlas AF5 does not produce enough
air to “run” the sandblast cabinet for an extended
period of time, but does produce a sufficient
volume and pressure to operate the machine for ten
minute intervals.
AF5
Single Stage 60 Gallon
A
I
R
F
O
R
C
E
Specifications
Motor Peak 6.5 Horsepower
Motor Running 4.5 Horsepower
Delivered-CFM 40PSI 20.0
Delivered-CFM 90PSI 18.0
Pressure Setting 90 lb. - 135 lb.
This is our entry level, two-stage air compressor. This
unit operates between 140 LB. and 175 LB. PSI. The
Atlas AF6 will run the SBC 420 sandblast cabinet (when
used with #8 or #10 glass beads). The combination of
the commercial grade low RPM motor and heavy duty 3
cylinder (2 cylinders are low pressure and one cylinder
is high pressure) cast iron reciprocating air compressor
pump delivers an incredible amount of air volume and air
pressure for a very low price.
AF6
Two Stage 80 Gallon
A
I
R
F
O
R
C
E
Specifications
Motor Running 5.0 Horsepower
Delivered-CFM 100PSI 15.0
Delivered-CFM 175PSI 14.0
Pressure Setting 145 lb. - 175 lb.
Power 220V Single Phase
This is the perfect compressor for
the 3-4 man auto shop, or for the
one man shop that wants to be
prepared for future growth.
Specifications
Motor Running 5.0 Horsepower
Delivered-CFM 10PSI 15.0
Delivered-CFM 175PSI 14
Pressure Setting 145 lb. - 175 lb.
Motor Voltage 230VAC 1PH
COMMERCIAL GRADE
AF7
Two Stage 80 Gallon
A
I
R
F
O
R
C
E
AF2
Portable 20 Gallon
A
I
R
F
O
R
C
E
Specifications
Motor Peak 5.0 Horsepower
Motor Running 2.0 Horsepower
Delivered-CFM 40PSI 7.1
Delivered-CFM 90PSI 5.5
Pressure Setting 90 lb.-135 lb.
Power 110V
Shipping Weight 250 Lb.
WATCH OUR
VIDEO
ONLINE
These are belt driven reciprocating air
compressors with a rebuildable cast iron
twin cylinder single stage pumps. This 220 volt single
stage air compressor
is the perfect
compressor for the
one or two man
automotive service
center.
The “PLUS” features for our commercial grade two
stage air compressors include a low oil monitor,
automatic tank drain, and air cooled aftercooler. These
three feature help to extend the life of your Atlas air
compressor while also delivering “better air”.
Specifications
Motor Running 5.0 Horsepower
Delivered-CFM 100PSI 19.6
Delivered-CFM 175PSI 18.4
Pressure Setting 145 lb. - 175 lb.
Motor Voltage 230VAC 1PH
Air Aftercooler
Auto Drain
Low Oil Shut Off
INCLUDES
THESE
ADDITIONAL
FEATURES:
AF8
Two Stage 80 Gallon
A
I
R
F
O
R
C
E
COMMERCIAL GRADE
AF8 Plus
Two Stage 80 Gallon
A
I
R
F
O
R
C
E
FEATURES
• Quiet Operation
• Heavy Duty Metal Belt Guard
• Shipping Weight: 390 lb.
• Vibro-isolator Pads
FEATURES
• Quiet Operation
• Heavy Duty Metal
Belt Guard
• Shipping Weight:
380 lb.
• Vibro-isolator Pads
FEATURES
• Quiet Operation
• Heavy Duty Metal Belt Guard
• Shipping Weight: 485 lb.
• Vibro-isolator Pads
FEATURES
• Quiet Operation
• Heavy Duty Metal Belt Guard
• Shipping Weight: 589 lb.
• Vibro-isolator Pads
FEATURES
• Mounted Magnetic Starter
• Heavy Duty Metal Belt Guard
• Shipping Weight: 485 lb.
• Vibro-isolator Pads
AF1
Portable 20 Gallon
A
I
R
F
O
R
C
E
Specifications
Motor Peak 5.0 Horsepower
Motor Running 2.0 Horsepower
Delivered-CFM 40PSI 7.1
Delivered-CFM 90PSI 5.5
Pressure Setting 90 lb.-135 lb.
Power 110V
These dynamite portable 110 volt electric
air compressors deliver enough air for the
average two man motorcycle shop.
ATAF1
ATAF2
ATAF3
ATAF4
ATAF5
ATAF6 ATAF7
ATAF8
ATAF8PLUS
AIR COMPRESSORS
IN STORE PICK-UP PRICE
$395
OR
$549
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$560
OR
$810
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$866
OR
$1116
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$968
OR
$1218
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1019
OR
$1269
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1274
OR
$1524
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1376
OR
$1626
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1886
OR
$2136
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1631
OR
$1891
W/ SHIPPING INCLUDED
34
WE ARE NOT RESPONSIBLE FOR MISPRINTS
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE
www.GregSmithEquipment.com
FEATURES
• Magnetic Starter
• Auto Drain
• Air Aftercooler
• Heavy Duty Metal Belt Guard
• Automatic Low Oil Shut Off
• Vibro-isolator Pads
• Shipping Weight: 969 lb
The Atlas AF9/17 is capable of providing adequate
air for the medium to large shop owner.
The 120 gallon tank provides 33% more storage capacity than the 80 gallon tank for those shops
that consume a large volume of air at one time. The horizontal tank allows the air compressor to be
located on an overhead storage area.
Specifications
Motor Running 7.5 Horsepower
Delivered-CFM 100PSI 24.8
Delivered-CFM 175PSI 22.8
Pressure Setting 145 - 175
Tank Capacity 80 Gal.
Motor Voltage 230VAC 1PH 60Hz
Specifications
Motor Running 7.5 Horsepower
Delivered-CFM 100PSI 24.8
Delivered-CFM 175PSI 22.8
Pressure Setting 145 - 175
Tank Capacity 120 Gal.
Motor Voltage 230VAC 1PH 60Hz
A F 9/17
Two Stage 80 Gallon
A F9/17 Two Stage 120 Gallon
A
I
R
F
O
R
C
E
A
I
R
F
O
R
C
E
Air Aftercooler
Air Aftercooler
Auto Tank Drain
Auto Tank Drain
Automatic Low Oil Shut Off
Automatic Low Oil Shut Off
COMMERCIAL
GRADE
COMMERCIAL
GRADE
FEATURES
• 1725 RPM Motor
• Quiet Operation
• Magnetic Starter
• Heavy Duty Metal Belt Guard
• Vibro-isolator Pads
• Shipping Weight: 627 lb.
FEATURES
• 1725 RPM Motor
• Quiet Operation
• Magnetic Starter
• Heavy Duty Metal Belt Guard
• Vibro-isolator Pads
• Shipping Weight: 805 lb.
INCLUDES THESE ADDITIONAL FEATURES:
INCLUDES THESE
ADDITIONAL
FEATURES:
A F9/17 P lu s
Two Stage 80 Gallon
AF9/17 Plus Two Stage 120 Gallon
A
I
R
F
O
R
C
E
A
I
R
F
O
R
C
E
The “PLUS” features for our commercial grade two stage air
compressors include a low oil monitor, automatic tank drain, and
air cooled aftercooler. These three feature help to extend the life of
your Atlas air compressor while also delivering “better air”.
The “PLUS” features for our commercial grade two stage air compressors include a low oil monitor, automatic tank
drain, and air cooled aftercooler. These three feature help to extend the life of your Atlas air compressor while also
delivering “better air”.
The Atlas Air Force AF-10 is available in either 1 phase or 3 phase, 10 HP motor
configuration. This air compressor is designed for the service center that demands a lot
of air! The AF-10 has a 120 gallon ASME certified storage tank. The heavy duty extra
large three cylinder two stage pump delivers over 36 CFM @ 175 PSI.
Aftercooler Auto Tank DrainAutomatic Low Oil Shut Off
AF10 Plus
1 Phase And 3 Phase
Two Stage 120 Gallon Specifications
Motor Running 10 Horsepower
Delivered-CFM 100PSI 38
Delivered-CFM 175PSI 36.3
Pressure Setting 145 lb. - 175 lb.
Tank Capacity 120 Gal.
Motor Voltage
230VAC 1PH or 3PH 60Hz
COMMERCIAL
GRADE
COMMERCIAL
GRADE
AF10 3-Phase
INCLUDES THESE ADDITIONAL FEATURES:
AF10 1-Phase
A
I
R
F
O
R
C
E
Available In
1 Phase Or 3 Phase
ATAF9/17
ATAF9/17-120G-H
ATAF9PLUS/17-120G-H
ATAF9PLUS/17
ATAF10PLUS-3PH
ATAF10PLUS-1PH
AIR COMPRESSORS
IN STORE PICK-UP PRICE
$1988
OR
$2238
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$2396
OR
$2646
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$2702
OR
$2952
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$3008
OR
$3258
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$3314
OR
$3564
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$2294
OR
$2544
W/ SHIPPING INCLUDED
35
WE ARE NOT RESPONSIBLE FOR MISPRINTS.
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE.
800.673.8740
TOLL
FREE
A
I
R
F
O
R
C
E
A F17G
Gas Powered 30 Gallon
COMMERCIAL
GRADE
Specifications
Motor Running 13.0 Horsepower
Delivered-CFM
100PSI 23
Delivered-CFM
175PSI 22
Pressure Setting 145 lb. - 175 lb.
Tank Capacity 30 Gal.
Gasoline Engine 4 Cycle Air Cooled OHV
Single cylinder
Starting System 12VDC Electrical or Recoil
Compressor Pump CT51 2 Cylinder 2 Stage
Specifications
Motor Running 8.0 Horsepower
Delivered-CFM
100PSI 18
Delivered-CFM
175PSI 16.5
Pressure Setting 145 lb. - 175 lb.
Tank Capacity 30 Gal.
Gasoline Engine 4 Cycle Air Cooled OHV
Single cylinder
Starting System 12VDC Electrical or Recoil
Compressor Pump CT51 2 Cylinder 2 Stage
This air compressor is equipped with the super reliable Honda GX390 13 HP electric start gas engine. The Atlas AF13 gas powered air compressor features a pneumatic
throttle control, electric start, vibro-isolator pads, charging system, and head unloaders. This is the perfect air compressor for the highway service truck.
This air compressor is equipped with the super
reliable Honda GX240 8.0 HP electric start
gas engine. The Atlas AF17G gas powered air
compressor features a pneumatic throttle control,
electric start, vibro-isolator pads, charging
system, and head unloaders. This is the perfect air
compressor for the highway service truck.
The Atlas AF17G delivers plenty of air to power the
large impact wrenches needed to remove those
stubborn BUDD wheel lug nuts. The dependable
HONDA engine and the Atlas two stage compressor
pump are designed and engineered to provide years
of service.
A F13
Gas Powered 30 Gallon
A
I
R
F
O
R
C
E
FEATURES
• Honda GX390 13 HP Gas Engine
• Electric Start
• Heavy Duty Metal Belt Guard
• Vibro-isolator Pads
• Shipping Weight: 627 lbs
FEATURES
• Honda GX3240 8 HP Electric
Start Gas Engine
• Heavy Duty Metal Belt Guard
• Shipping Weight: 630 lbs
Designed For
Service Trucks
FINANCING
AVAILABLE
COMMERCIAL
GRADE
ATAF17G
ATAF13
FEATURES
• Magnetic Starter
• Auto Drain
• Air Aftercooler
• Heavy Duty Metal Belt Guard
• Automatic Low Oil Shut Off
• Vibro-isolator Pads
A F15 Pl u s
Two Stage 120 Gallon INCLUDES THESE
ADDITIONAL FEATURES:
The Atlas Air Force AF-15 Plus is a 3 phase, 15
HP motor configuration. This air compressor is
designed for the service center that demands
a lot of air! The AF-15 has a 120 gallon ASME
certified storage tank. The heavy duty extra large
three cylinder two stage pump delivers over 49
CFM @ 175 PSI.
Aftercooler
Auto Tank DrainAutomatic Low Oil Shut Off
Specifications
Motor Running 15 Horsepower
Delivered-CFM 100PSI 52
Delivered-CFM 175PSI 49
Pressure Setting 145 lb. - 175 lb.
Tank Capacity 120 Gal.
Motor Voltage
230VAC 3PH 60Hz
COMMERCIAL
GRADE
ATAF15PLUS
AIR COMPRESSORS
IN STORE PICK-UP PRICE
$2090
OR
$2340
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1678
OR
$1928
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$4126
OR
$4376
W/ SHIPPING INCLUDED
36
WE ARE NOT RESPONSIBLE FOR MISPRINTS
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE
www.GregSmithEquipment.com
FEATURES
• Digital oil gun
• 50:1 air operated pump
with 36” suction tube
• 50 Ft., 1/2” in.
retractable hose reel
• For 50:1 ratio Air Grease Pumps
• Heavy Duty Metal Frame
• Rubber Hose
• Retractable
• Available in both
1/4” and 3/8” ID
• 50 Foot Hose length
FEATURES
*Color May Vary
*Color May Vary
This mobile self contained system includes a heavy duty steel trolley
platform that can support up to 400 pounds, up to a 55 gallon drum, a
5:1 ratio oil pump, heavy-duty 50 foot lubrication hose reel (and hose),
and a digital control dispensing hand gun.
HT-K9903
Stainless Steel,
Air Operated
Grease Pump
Practical, functional and compact, the Atlas Stainless Steel Air
Operated Grease Pump can be used in all workplaces. Enables quick,
high pressure greasing on any motor vehicle or mechanism. Equipped
with a grease follower plate that
protects the lubricant and ensures
positive priming.
Air Operated
Grease Pump
Portable Oil Dispenser
Practical, functional and compact, the
Atlas Air Operated Grease Pump can be
used in all workplaces. Enables quick, high
pressure greasing on any motor vehicle
or mechanism. Equipped with a grease
follower plate that protects the lubricant
and ensures positive priming.
Grease dispensing trolley includes: 50:1 air operated pump with 37”
suction tube, 23 ½” drum cover, 23” follower plate, 50 ft., ¼” hose
reel, and grease gun. For use with 400 LB. grease drums.
Practical and functional, with a wheel-mounted 17 gallon tank, the
Portable Oil Dispenser can be used in all workplaces. The Portable
Oil Dispenser has an air-operated pump that is suitable for oils of any
density. The Portable Oil Dispenser comes equipped with an aluminum
digital oil meter gun.
HT-K5001
OIL / GREASE GUNS AVAILABLE
Call For Details
FEATURES
• Portable
• 50:1 pressure ratio
• 5 cu. in./min delivery
• Comes with hose and pump
FEATURES
• Stainless steel
• Portable
• 50:1 pressure ratio
• 5 cu. in./min delivery
• Comes with hose and
pump
FEATURES
• Stainless steel
• Comes with hose, pump,
and digital oil meter gun
• 5 cu. in./min delivery
• 3:1 pressure ratio
• Portable
• Level indicator HT-T726065
Grease Dispensing
Trolley Kit
Grease Dispensing
Trolley Kit
Oil Dispensing
Trolley Kit
*Color May Vary*Color May Vary
Grease dispensing trolley includes: 50:1 air operated pump with 37”
suction tube, 23 ½” drum cover, 23” follower plate, and grease gun. For
use with 400 LB. grease drums.
FEATURES
• 50:1 air operated pump
with 36” suction tube
• 23 1/2” drum cover
• 23” follower plate
• Grease gun
• Portable
FEATURES
• 50:1 air operated pump
with 28” suction tube
• 12” drum cover
• 12” follower plate
• Grease gun
• Portable
FEATURES
• 50:1 air operated pump
with 36” suction tube
• 50 Ft., 1/2” hose reel
• 23 1/2” drum cover
• 23” follower plate
• Grease gun
• Portable
HT-D9306402.015-3/8ID
HT-D9306402.015-1/4ID
50 Ft. Retractable
Grease Hose Reel *Color May Vary
Enclosed
1/4" ID
Enclosed
3/8" ID
HT-A7901HT-A7801
HT-K5002
Grease Dispensing
Trolley Kit
Pivot Hose Reel
Wall Mount
Pivot Hose Reel
Wall Mount
360° Swivel Hose Reel
Wall Mount
HT-A11310
HT-A11330
HT-A11320
Grease dispensing
trolley for use with
400 LB. grease drums
Grease dispensing
trolley for use with
35 LB. grease pails
Grease dispensing
trolley for use with
400 LB. grease drums
HT-A7701
Grease dispensing trolley includes: 50:1
air operated pump with 28" suction
tube, 12" drum cover, 12" follower plate,
13' hose, and grease gun. For use with
35 LB. grease pails.
LUBRICATION EQUIPMENT
IN STORE PICK-UP PRICE
$204
OR
$238
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$230
OR
$264
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$536
OR
$686
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$362
OR
$437
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$281
OR
$327
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$668
OR
$818
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$709
OR
$859
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$235
OR
$285
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$306
OR
$356
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$10
IN STORE PICK-UP PRICE
$10
IN STORE PICK-UP PRICE
$12
37
WE ARE NOT RESPONSIBLE FOR MISPRINTS.
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE.
800.673.8740
TOLL
FREE
Hydraulic Style
• 1500 lb. capacity per dolly
• 22” maximum distance open
“Move-It” Dollies (Set of 4)
MOVING YOUR VEHICLE IS MUCH EASIER WITH A SET OF “MOVE-IT” DOLLIES!
Our “Move-It” dolly system is the easy answer for moving cars in your garage. These dollies
allow operators to lift the car in seconds with the built-in jacking mechanism – then just roll the
car to the desired location. This unique system makes the need for a separate jack obsolete.
HTMD HTMDRS
Ratchet Style “Move-It” Dolly
Storage Rack
• Store and move up to 4 dollies
• Shipping weight: 21 LBS.
HTMD-RACK
33 Ft./50 Ft. Retractable
Air Hose Reel
50 Ft. Retractable
Welding Dual-Hose Reel
75 Ft. Retractable
Welding Dual-Hose Reel
33 Ft.
HTHR-33FT
Shipping Weight:
27 lbs.
50 Ft.
HTHR-50FT
Shipping Weight:
40 lbs.
3/8” ID
3/8” ID
3/8” ID
100 Ft.
HTHR-100FT
Shipping Weight: 63 lbs.
*Color May Vary *Color May Vary
*Color May Vary
Heavy Duty Metal Frame Heavy Duty Metal Frame
65 Ft. Retractable
Air Hose Reel
65 Ft.
HTHR-65FT
Shipping Weight: 57 lbs.
1/2” ID
*Color May Vary
Heavy Duty
Metal Frame
Heavy Duty Metal Frame
50 Ft. 75 Ft.
HT-D3205202.015 HT-D3305202.023
1/4” ID 1/4” ID
100 Ft. Retractable
Air Hose Reel
100 Ft. Manual
Water Hose Reel
Heavy Duty
Metal Frame
100 Ft.
HT-D2105104.30
3/8” ID
Each EachSet Of 4 Set Of 4
200 Ft. Manual
Water Hose Reel
*Color May Vary
Heavy Duty
Metal Frame
200 Ft.
HT-D2205104.60
3/8” ID
*Color May Vary
Heavy Duty Metal Frame
*Color May Vary
• 11” maximum distance closed
• 12” width of wheel guard
• 1250 lb. capacity per dolly
• 23” maximum distance open
• 11” maximum distance closed
• 9” width of wheel guard
Over Engine Creeper/Topsider
HTCREEPER-TS
EXTEND YOUR REACH!
• Adjustable height: 47 1/2” - 58 1/2”
• Heavy duty casters
• Convenient tool drawer
• Deck is padded and covered with
heavy duty vinyl for comfort
FEATURES
Perfect For Working On Truck Engines
Adjustable Height:
47½” - 58½”
HOSE REELS + CREEPER + CAR DOLLIES
IN STORE PICK-UP PRICE
$82
OR
$109
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$102
OR
$147
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$163
OR
$213
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$189
OR
$246
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$122
OR
$162
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$179
OR
$236
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$107
OR
$147
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$189
OR
$246
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$102
OR
$145
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$87
OR
$125
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$403
OR
$553
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$352
OR
$502
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$36
OR
$59
W/ SHIPPING INCLUDED
OR OR
IN STORE PICK-UP PRICE
$173
OR
$323
W/ SHIPPING INCLUDED
38
WE ARE NOT RESPONSIBLE FOR MISPRINTS
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE
www.GregSmithEquipment.com
• Heavy duty steel construction
• Two way rotary pump
(for siphoning and dispensing)
• Fluid level gauge
• 8” solid rubber tires
• 8’ flexible hose
• Shipping weight 75 lb.
FEATURES
25 Gallon Capacity
Steel Gas Caddy
Perfect for homes, shops, marinas, farms, or anywhere you need
to easily transport and dispense fuel. The Atlas gas caddy features
heavy duty steel construction, rugged solid rubber wheels and a
dolly handle for easy portability. Works with gasoline, kerosene,
diesel, or mixed fuels.
HTGC
8 Gallon Oil Drain
• Four swivel casters
make it portable and
easy to maneuver
• Oil drain valve makes
disposal easy
• 17” funnel diameter
• Lightweight Plastic
FEATURES
HTA30L
Shipping Weight: 15 lbs.
Adjustable From
29 1/2” to 55”
HTB75L
Shipping Weight: 20 lbs.
Adjustable From
36” to 72”
18 Gallon Oil Drain
18 Gallon Steel Oil Drain
HTOD18
To evacuate the oil from the container, simply hook an air line to the unit,
turn the valve, and the oil is forced out through the evacuation tube.
PRESSURIZED
To evacuate the oil from the container, simply hook an air line to the unit,
turn the valve, and the oil is forced out through the evacuation tube.
30 Gallon Steel Oil Drain
HTOD30
• 30 gallon capacity
• Adjustable Height from
49 3/4” - 73 1/2”
• Pressurized oil drain allows
oil to be removed in seconds
• Two front swivel casters make it
portable and easy to maneuver
• 15 1/2” funnel diameter
• Shipping Weight: 80 lb.
FEATURES
PRESSURIZED
18 Gallon Oil Extractor
This Atlas 18 gallon capacity Oil Extractor and Oil Drain is
perfect for any commercial or home shop. This oil drain/
extractor features both a standard funnel to catch drained
oil from overhead as well as a vacuum system to suck oil
out of an engine.
HTOD18-EX
FEATURES
• Pressurized oil drain allows
oil to be removed in seconds
• 15” funnel diameter
• Adjustable from 46” to 76”
• Shipping Weight: 56 lb.
4 Gallon Oil
Drain Pan
HTOP15
• Plastic
• 4 Gallon (15L)
Oil Drain Pan
• Shipping Weight: 5 Lb.
• Capacity: 20 Gallons
• Reservoir: 2’ 8 1/2” Long X
2’ 1” Wide X 6” Deep
• 25 1/2” Long T Bar Handle
• Internal Baffles Prevent Spills
• Shipping Weight: 98 Lb.
FEATURES
• Capacity: 17 Gallons
• Low profile design
• Durable lightweight
polypropylene construction
• 4" Heavy-Duty swivel casters
• Ideal for draining oil or antifreeze
• T-Handle easily folds for storage
• Built-In manual pump for fast
fluid draining
• Top wire mesh drain reduces
splashing
• Shipping Weight: 50 lbs.
FEATURES
• Capacity: 17 Gallons
• Low profile design
• Ideal for draining oil or antifreeze
• T-Handle easily folds for storage
• Built-In 12V pump for fast fluid draining
• Durable lightweight polypropylene
construction
• 4" Heavy-Duty swivel casters
• Top wire mesh drain reduces splashing
• Shipping Weight: 50 lbs.
FEATURES
20 Gallon Low Profile Oil Drain
This Atlas Low Profile metal oil drain is perfect for rolling under trucks and buses to change oil and
other fluids. This Low Profile roll around oil drain has less than 8 inch ground clearance. With the
long “T” handle and swivel casters the oil drain is easily maneuvered into position.
HTOD-RU
17 Gallon Low Profile Oil Drain
12V Pump
HTC70 L-2
26 Gallon Oil Drain
To evacuate the oil from the container, simply hook
an air line to the unit, turn the valve, and the oil is
forced out through the evacuation tube.
17 Gallon Low Profile Oil Drain
Manual Pump
HTC70 L-1
PRESSURIZED
HTE100L-1
Lightweight Plastic
PRESSURIZED
• Heavy duty plastic construction
• 26 gallon capacity
• Pressurized evacuation
• Pressurized gauge
• Shipping weight 75 lb.
FEATURES
• Steel
• Dolly handle
• Measuring tank
• 3” Solid rubber
rear swivel casters
FEATURES
• 5” Solid rubber front wheels
• 3 probe adapters – 2 plastic,
1/4” and 5/16” diameter, 1
copper, 1/4” diameter
OIL DRAINS + GAS CADDY
IN STORE PICK-UP PRICE
$291
OR
$366
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$239
IN STORE PICK-UP PRICE
$169
IN STORE PICK-UP PRICE
$10
OR
$25
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$46
OR
$61
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$82
OR
$102
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$143
OR
$199
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$275
OR
$353
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$199
IN STORE PICK-UP PRICE
$286
OR
$436
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$254
OR
$404
W/ SHIPPING INCLUDED
39
WE ARE NOT RESPONSIBLE FOR MISPRINTS.
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE.
800.673.8740
TOLL
FREE
Pallet Jacks
4,400 lb. Capacity
HTPJ20
Shipping Weight: 175 lbs.
5,500 lb. Capacity
HTPJ25
Shipping Weight: 270 lbs.
6,600 lb. Capacity
Easily Transport
Heavy Engines,
Transmissions, Or
Any Other Large Piece
Of Automotive Parts
From Bay To Bay In
Your Service Shop
HTPJ30
Shipping Weight: 300 lbs.
*Color May Vary
FEATURES
• Maximum Height 7 ½”
• Minimum Height 3”
• Overall Width: 27”
• Length of Forks 47 ½”
• Width of Forks 6 ¼”
• Distance Between Forks:
14 ¼”
HT57501/HT512001
These deluxe trailer or truck jack stands
work great with a variety of vehicles because
it features adjustable height and three
different contact adapters. These jack stands
also features three spring loaded swivel
casters, making it easy to move but stable
when weight is applied on top.
Deluxe 6 Ton/12 Ton
HT58001 HIGH
2 Ton Heavy Duty Tripod Stand
The 2 ton heavy duty tripod stand is the perfect choice for
the mechanic who is working on a vehicle that is lifted by a
two post lift or a four post lift. The adjustable 2 ton heavy
duty tripod stand is used to offer additional support to either
the front or the rear of the vehicle. These jack stands can be
placed between the runways of a four post lift and when the
runways of the four post lift are lowered, the jack stands will
support the weight of the vehicle. The wheels will be above
the runway of the four post lift and wheel service can be
easily performed.
• Minimum height: 48 ½”
• Maximum height: 84”
• Shipping Weight: 39 lbs.
HT58001
Each
HT52008 LOW
2 Ton Low Tripod Stand
The 2 ton low tripod stand is the perfect choice for the mechanic who
is working on a vehicle that is lifted by a two post lift or a four post
lift. The adjustable 2 ton low tripod stand is used to offer additional
support to either the front or the rear of the vehicle.
HT52008
Each
10 Ton
SHORT
(Set of 2)
HT510003
Pair
The 1,500 LB. Tall Jack Stand with foot pedal is
used with four post lifts, and two post lifts. This
Atlas jack stand supports up to 1,500 pounds. The
jack stand can easily be placed into position under
the lifting points of cars or trucks.
HT58005 & HT58003
HT510001 & HT510003
Foot pedal “jounces” the saddle
to help line up bolt holes.
• Minimum height - 54”
• Maximum height - 80”
• Shipping Weight: 40 lbs. Each
Perfect For
Frame And
Body Repair
HT58003
Without
Foot Pedal
Each
HT58005
With
Foot Pedal
With & Without Foot Pedal
Pair
HT510001
HT57501
Each
6 Ton
Shipping Weight: 160 lbs.
HT53002/HT56002
3 Ton/6 Ton/(Set of 2)
Pair
6 Ton
HT56002
Pair
3 Ton
HT53002
• Adjustable from
16” to 24”
• Shipping Weight:
38 lbs.
• Adjustable from
11” to 16 1/2”
• Shipping Weight:
23 lbs.
HT512001
Each
12 Ton
Shipping Weight: 190 lbs.
Swivel Casters
Max Height: 84”
Max Height: 53”
Min Height: 30”
Shipping Weight: 26 lbs 10 Ton
TALL
(Set of 2)
4 Ton Porta Power Kit
HT0102
10 Ton Porta Power Kit
20 Ton Porta Power Kit
HT0204
HT0202
FEATURES
• 4 ton Hydraulic Pump and
Ram w/ female coupler
• 5’ hydraulic hose
• 5 extension tubes: 3”, 5”,
8 ½”, 16 ½”, & 19 ¼”
• 1/2 ton capacity Spreader
• Flat base
• Ram toe
• Plunger toe
• Wedge head
• 90° V-base
• Male connector
• Serrated Saddle
• Rubber Head
• Storage case
• 10 ton Hydraulic Pump
and Ram w/ female coupler
• 5’ hydraulic hose
• 4 extension tubes: 4 ¼”,
10 ¼”, 14 ¼”, & 20 ¼”
• Flat base
• Ram toe
• Plunger toe
• Wedge head
• 90° V-base
• Male connector
• Serrated Saddle
• Rubber Head
• 1/2 ton capacity Spreader
• Storage case
FEATURES
• 20 ton Hydraulic
Pump and Ram
• 5’ hydraulic hose
• 4 connective tubes:
5”, 10”, 20”, & 27”
• 3 each, 3” connective
tube & 2 ½” joint
connector tube
• Base
• Ram toe
• Plunger toe
• Wedge toe
• V-base
• Metal Storage Cases
• Collapsed Height:
11 1/8”
• Extended Height: 16”
FEATURES
STANDS + PALLET JACKS+ PORTA POWER KITS
IN STORE PICK-UP PRICE
$117
OR
$267
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$148
OR
$298
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$337
OR
$487
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$418
OR
$568
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$311
OR
$461
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$112
OR
$157
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$158
OR
$203
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$362
OR
$512
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$316
OR
$466
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$321
OR
$471
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$66
OR
$105
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$20
OR
$43
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$41
OR
$79
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$51
OR
$77
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$56
OR
$95
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$56
OR
$90
W/ SHIPPING INCLUDED
40
WE ARE NOT RESPONSIBLE FOR MISPRINTS
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE
www.GregSmithEquipment.com
SBC350
The SBC350 sandblast cabinet features switches for power,
light and dust collector, a regulator and pressure gauge, and
indicator lights. The unit comes with 2 blasting nozzles: a
heavy-duty gun with valve, and a stationary nozzle that is
controlled with the foot switch. Two large side doors make
loading and unloading simple.
• Interior dust filter
• Large side load doors
• Interior fluorescent light
• 37 1/8” W x 23 5/8” D
22 1/2” H work volume
SBC420
The SBC 420 Sandblast Cabinet has an
attached vacuum system. The SBC420
allows you to load parts from both the
side and top of the cabinet.
Sandblast Cabinets allow you to remove scale or heavy rust from automotive
parts, clean up rusty tools, etch glass, and many other special applications.
• Easy operation
• Continually recycles
• Bottom feed system
• Heavy-duty blast gun
• 4 Ceramic nozzles
• Abrasive flexibility
• 24” Gauntlet gloves
• 2 side doors as well
as top load door
• Built-in fluorescent
lamp
• Self-contained dust
collection system
with cartridge filter
FEATURES
SBC990
S BC12 0 0
The SBC 990 Sandblast Cabinet
has an attached vacuum system and
allows you to load large parts through
it’s large folding front door.
The extra wide SBC1200 sandblast cabinet features two large
folding doors (one in the front and one in the back) for easy
loading and unloading of large parts. The SBC1200 has two
foot-operated blasting guns located on each side of the blast
cabinet allowing two people to operate the access ports at the
same time.
• Large folding front door
• Easy operation
• Continually recycles
• Abrasive flexibility
• NE490 Power gun with
foot pedal
• 4 Ceramic nozzles
• 110 Volt
• 24” Gauntlet gloves
• Built-in fluorescent lamp
• Shipping Weight: 490 lb.
FEATURES
• Easy operation
• Two blasting guns
• 2 Ceramic tip sizes
• 24” Gauntlet gloves
• Two large folding doors
• Overall size: 60" Wide x
55" Deep x 72 ½" High
• Work Volume: 47" Wide
x 51" Deep x 33 ½" High
• Built-in fluorescent lamp
FEATURES
SBC220
FEATURES
• Easy operation
• Interior dust filter
• Continually recycles
• Low air supply design
• Interior fluorescent light
• 17" Gauntlet Gloves
SBC90
HTRA20
20 Gallon Roll About
Sandblast Unit
HTSB28
28 Gallon Roll Around
Sandblast Unit
With Vacuum
FEATURES
• Easy operation
• Abrasive flexibility
• Portable
• 110V Power
• 110V Vacuum
• Heavy duty hose
• 6” solid tires
• Concave head for ease of filling
• Carbon steel abrasive mixing
valve for durability and long life
• Shipping Weight: 90 lbs.
HTSBC90 HTSBC220
HTSBC350-KIT
HTSBC420-KIT
HTSBC990-KIT
HTPSBC990-KIT
HTSBC1200-KIT
HTRA20
HTSB28
Includes Free 50 lb. Bag Of Glass Beads
110V
110V
Convenient Table-Top Model
Side
Loading
Includes Free 50 lb.
Bag Of Glass Beads Includes Free 100 lb. Bag Of Glass Beads
Includes Free
50 lb. Bag Of
Glass Beads
Pressurized Model Of The SBC990
Sandblast Cabinets
WATCH OUR
VIDEO
ONLINE
PSBC990
• Easy operation
• Abrasive flexibility
• Portable
• 110V Power
• Heavy duty 8’ 3/8” hose
• 6” solid tires
• Tilt-and-go handle for
increased mobility
• Concave head for ease of filling
• Carbon steel abrasive mixing
valve for durability and long life
• Shipping Weight: 60 lbs.
FEATURES
110V
SANDBLAST CABINETS
IN STORE PICK-UP PRICE
$117
OR
$157
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$337
OR
$487
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$709
OR
$859
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$969
OR
$1119
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$2447
OR
$2597
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$2035
OR
$2185
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$1423
OR
$1573
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$158
OR
$218
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$286
OR
$436
W/ SHIPPING INCLUDED
41
WE ARE NOT RESPONSIBLE FOR MISPRINTS.
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE.
800.673.8740
TOLL
FREE
The HTMB275 tire spreader can be used with most wheel clamp tire
changers. The metal mounting plate is held securely between the
clamping jaws of the tire changer, allowing the operator to position
the tire at the correct working height to make tire repair easy. The
HTMB275 has adjustable spreader arms that fit on the inside beads of
the tire and are spread open by use of the heavy metal arm. The 275
tire spreader is the perfect choice for those customers who need to
perform inside tire repairs on most passenger and light truck tires. This
tire spreader can be bolted to a workbench.
HTMB275
Specifications
Tire Width Capacity: 5 ¾” TO 10 ¾”
Overall Dimensions: 35” L x 12” W x 10 1/2” H
Shipping Weight: 25 Lb.
Passenger and Light Truck Passenger and Light Truck
The HTM275 tire spreader is a heavy duty tire
spreader designed for use in shops that repair
passenger and light truck tires. The HTM275 has
an adjustable four (4) position table that can be
rotated for easy access to the inside of the tire.
The foot pedal controls the position of the table
top. Depressing the spring actuated foot pedal
allows operator to move the table top to the most
desired position. The tire is rotated easily on
the heavy rollers mounted on the table top. The
spreader arms are adjustable to accommodate
passenger and light truck tires.
FEATURES
• Portable
• Adjustable clamping arms
• 4 position table tilt
• Rotatable table design
• Makes tire inspections and repair quick & easy
• Adapts to varying sidewall heights and tire widths
Specifications
Tire Width Capacity: 5 ¾” TO 10 ¾”
Tire Diameter Capacity: 11” TO 24”
Overall Dimensions: 30” L x 12” W x 39 3/4” H
Shipping Weight: 67 Lb.
HTM275
The HTM275 tire spreader is a heavy duty tire spreader designed
for use in shops that repair passenger and light truck tires. The
HTM275 has an adjustable four (4) position table that can be rotated
for easy access to the inside of the tire. The foot pedal controls the
position of the table top. Depressing the spring actuated foot pedal
allows operator to move the table top to the most desired position.
The tire is rotated easily on the heavy rollers mounted on the table
top. The spreader arms are adjustable to accommodate passenger
and light truck tires.
FEATURES
• Portable
• Adjustable clamping arms
• 4 position table tilt
• Rotatable table design
• Makes tire inspections and
repair quick & easy
• Adapts to varying sidewall
heights and tire widths
Specifications
Tire Width Capacity: 5 ¾” TO 10 ¾”
Tire Diameter Capacity: 11” TO 24”
Overall Dimensions: 30” L x 12” W x 39 3/4” H
Shipping Weight: 67 Lb.
HTS275
Passenger and Light Truck
FEATURES
• Easy to use hand operated
controls
• Adjustable clamping arms
• Pressure gauge & regulator
assembly
• Tool Tray
• Adjustable light
• Air outlet for air tool connection
The HTS825 truck tire spreader makes it easy to lift and
repair large truck tires. The powerful pneumatic lifting table
can accommodate tires of up to 250 lbs. and raises them to
the perfect inspection and working height. The adjustable
clamping arms and rollers as well as the pneumatic lift table
allow the operator to repair large and small truck tires (and
passenger tires) easily. If you are a professional tire repair shop
that handles all sizes of tires, then the HTS825 is the perfect
choice for all your tire repair needs. The HTS825 tire spreader
has an adjustable work light and a tool tray.
Specifications
Tire Size Capability: 8.25-20; 14.00-20(9R-16.5R); 11-22.5R
Air Requirements: 110-145 PSI
Work Light: 110V
Overall Dimensions: 64” L x 28” W x 42” H
Shipping Weight: 450 Lb.
HTS825
Large Truck
Air Operated Strut
Spring Compressor Branick 7600
Strut Spring Compressor
Strut Spring Compressor
This Air Operated Strut Spring
Compressor is designed to aid
in replacing strut springs and
strut assembly components.
This Air Operated Strut Spring Compressor is designed to aid
in replacing strut springs and strut assembly components. The
Strut Spring Compressor is adjustable to handle a wide variety
of strut spring sizes.
HTT01-SC
• Heavy duty capacity - handles
the heaviest coil over shocks
• Handles extra long springs -
room to disassemble long struts
• Gives easy strut access
• Independently adjustable upper
and lower hooks
FEATURES
Commercial
Grade
HT1206 BRA7600
TIRE SPREADERS + STRUT COMPRESSORS
IN STORE PICK-UP PRICE
$306
OR
$456
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$393
OR
$543
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$800
IN STORE PICK-UP PRICE
$1168
OR
$1318
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$541
OR
$691
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$92
OR
$117
W/ SHIPPING INCLUDED
IN STORE PICK-UP PRICE
$118
OR
$225
W/ SHIPPING INCLUDED
• Gives easy strut access
• Long handles for Extra Torque
• Max. Spring Compression Capacity: 3000 LB.
• Min. / Max. Spring Diameter: 3 1/2" / 11 1/2"
• Heavy duty capacity - handles the heaviest coil over shocks
• Handles extra long springs - room to disassemble long struts
• Independently adjustable upper and lower hooks
• Shipping Weight: 100 LBS.
42
WE ARE NOT RESPONSIBLE FOR MISPRINTS
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE
www.GregSmithEquipment.com
Atlas Apex 9BP - 2 Post Lift
Our larger products are shipped by a common freight carrier. You (the customer) will need to have the product delivered to place that a 53 foot semi
trailer can easily access. You (the customer) will need to provide the correct equipment to unload your purchase. If you do not have a loading dock,
then you will need a forklift, skid steer, or some similar type of material handling equipment to unload the product. We included representative pictures
of some products packaged for freight shipment below.
Freight Truck Shipping Information
In Store Pick Up Is Available
GREG SMITH
EQUIPMENT
DOES NOT OWN THE
DELIVERY TRUCK LINE.
IF YOU HAVE ANY FREIGHT QUESTIONS REGARDING YOUR PRODUCT,
PLEASE GET THEM ASKED AND ANSWERED BEFORE WE SHIP!
VISIT OUR WEBSITE FOR MORE SHIPPING INFORMATION
For the majority of locations, we may be able to provide a semi truck with a lift gate. The lift gate will assist the customer in unloading products such
as motorcycle lifts, tire changers, wheel balancers, air compressors, sandblast cabinets, etc. Unloading two post or four post lifts (and other products
weighing over 1000 pounds) will require a forklift (or some type of material handling equipment), if the customer does not have a truck-height loading
dock. Remember, the customer is always responsible for providing the necessary equipment to offload their product safely.
If a product is picked up at a local trucking terminal, the truck terminal staff should be able to load the equipment on your trailer or truck. (You must
furnish a vehicle that is large enough to “handle” your product). If you need to locate a terminal in your area, or if you would like a shipping quote,
please contact our office.
Visit any of our nine brick and mortar locations and pick up your purchase. Just make sure that you bring “enough vehicle” and call ahead to make
sure that “your” location has the product in stock.
Atlas WB77 Wheel Balancer
Shipping Weight: 1,700 lbs. Shipping Weight: 400 lbs.
Atlas Apex 8 - 4 Post Lift
Shipping Weight: 1,800 lbs.
THE CUSTOMER IS
ALWAYS RESPONSIBLE FOR
UNLOADING THE PRODUCT
FROM THE DELIVERY TRUCK.
Shipping Weight: 800 lbs.
WE HAVE PACKAGE
DIMENSIONS AND SHIPPING
WEIGHTS ON OUR WEBSITE.
CHECK TO MAKE SURE YOU
BRING THE RIGHT VEHICLE
OR TRAILER TO PICK UP
YOUR EQUIPMENT.
Are you a new or growing business???
Ask our nance department about our 100% commercial lease to own programs.
Benets Include: • Conserve cash
• Little to no money down
• Easier than bank financing
• End of term ownership
or new equipment
upgrade options
• 100% Tax Deductible
off balance sheet lease
options available
Atlas EML-1200
Electric
Motorcycle
Lift
Our company has partnered with lending
institutions to provide our customers with
alternative nancing options.
NEED
FINANCING?
CALL US TODAY!
SHIPPING + FINANCING
43
WE ARE NOT RESPONSIBLE FOR MISPRINTS.
PRICES AND SPECIFICATIONS ARE SUBJECT TO CHANGE.
800.673.8740
TOLL
FREE
VISIT ONE OF OUR
BRICK AND MORTAR
LOCATIONS TODAY!
8399 West Van Buren Street, Suite 210
Tolleson, AZ 85353
salesAZ@gregsmithequipment.com
Showroom Hours
M-F: 8-5:30 (MST)
Saturday: 8-noon (MST)
Tolleson, Arizona
250 Executive Drive, Suite 1
Newark, DE 19702
salesDE@gregsmithequipment.com
Showroom Hours
M-F: 8-5:30 (EST)
Saturday: 8-noon (EST)
Newark, Delaware
3206 Industrial Terrace Suite #102
Austin, TX 78758
salesTX@gregsmithequipment.com
Showroom Hours
M-F: 8-5:30 (CST)
Saturday: 8-noon (CST)
11801 NW 100th Rd., Suite 8
Medley, FL 33178
salesFL@gregsmithequipment.com
Showroom Hours
M-F: 8-5:30 (EST)
Saturday: By Appointment Only
Austin, Texas
Miami, Florida
4685 Troy Court
Jurupa Valley, CA 92509
salesCA@gregsmithequipment.com
Showroom Hours
M-F: 8-5:30 (PST)
Saturday: 8-noon (PST)
3801 S. James Street, Suite 140
Grimes, IA 50111
salesIA@gregsmithequipment.com
Showroom Hours
M-F: 8-5 (CST)
Saturday: Closed
Jurupa Valley, California
Grimes, Iowa
5505 SE International Way, Suite D
Milwaukie, OR 97222
salesOR@gregsmithequipment.com
Showroom Hours
M-F: 8-5:30 (PST)
Saturday: By Appointment Only
5800 Massachusetts Avenue
Indianapolis, IN 46218
salesIN@gregsmithequipment.com
Showroom Hours
M-F: 8-5:30 (EST)
Saturday: 8-noon (EST)
Milwaukie, Oregon
Indianapolis, Indiana
70 Schoolhouse Road
Somerset, NJ 08873
salesNJ@gregsmithequipment.com
Showroom Hours
M-F: 9-4 (EST)
Saturday: Closed
Somerset, New Jersey
1750 Satellite Blvd, Suite 300
Buford, GA 30518
salesGA@gregsmithequipment.com
Showroom Hours
M-F: 8-5:30 (EST)
Saturday: 8-noon (EST)
Buford, Georgia
8 Industrial Drive
Hudson, NH 03051
salesNH@gregsmithequipment.com
Showroom Hours
M-F: 8-4:30 (EST)
Saturday: 8-noon (EST)
Hudson, New Hampshire
Delaware
Indiana
Iowa
Florida
New Hampshire
Georgia
Arizona
Oregon
Texas
New Jersey
California
800-673-8740
LOCATIONS
5800 Massachusetts Ave.
Indianapolis, IN 46218
www.GregSmithEquipment.com
VISIT ONE OF OUR BRICK AND MORTAR LOCATIONS TODAY!
PROUDLY SERVING YOU NATIONWIDE!
PRINTED IN THE USA
Delaware
Indiana
Iowa
Florida
New Hampshire
Georgia
Arizona
Oregon
Texas
New Jersey
California
(800) 673-8740
www.GregSmithEquipment.com
In Business Since 1982 Catalog Code: April-2018

Navigation menu
