Guide V4
User Manual:
Open the PDF directly: View PDF
.
Page Count: 13
PSPDFKit
PLAYGROUND
an·no·ta·tion
/ˌanəˈtāSH(ə)n/
noun
noun: annotation; plural noun: annotations
a note of explanation or comment added to a text or diagram.
→ “marginal annotations”
synonyms: note, notation, comment, gloss, footnote;
commentary, explanation, interpretation
the action of annotating a text or diagram.
→ “annotation of prescribed texts”
From Wikipedia:
An annotation is metadata (e.g. a comment, explanation, presentational markup) attached to text, im-
age, or other data. Oen annotations refer to a specific part of the original data.
→ read more
Try Some Annotation Drawing Tools
Free Text
Callouts
SIGN HERE
form
/fôrm/
noun
noun: form; plural noun: forms
a printed document with blank spaces for information to be inserted.
→ “an application form”
synonyms: questionnaire, document, coupon, paper, sheet
→ “you have to fill in a form”
From Wikipedia:
A form is a document with spaces (also named fields or placeholders) in which to write or select, for a
series of documents with similar contents. The documents usually have the printed parts in common,
possibly except for a serial number.
→ read more
PDF Forms
First Name Where did you find this form?
Last Name
Which form element do you like most?
Checkboxes!
Radio Buttons
Text Fields
Signature Fields
Do you like forms?
Yes! No!
Sign here, please:
Additional Annotation Styles
Add some text!
PSPDFKit
Quickstart Guide
version 4
Time To Market
PSPDFKit supports blazingly fast PDF viewing, adding annotations, and filling out forms. Our battle-test-
ed code is trusted by Box, Dropbox, Evernote, and hundreds of other companies. Benefit from a solid,
tested codebase and incorporate all those advanced features into your own application. It’ll save you at
least one year in comparison with in-house development.
Easy Integration
Almost every aspect of PSPDFKit is customizable and designed from the ground up to oer maximum
flexibility. The developer-friendly API exposes a lot of features that’ll cover just about every use case you
can think of. Focus on the unique parts of your product and build on a well-documented codebase that
is heavily field tested and “just works”.
Introduction
PSPDFKit is the leading framework for displaying and annotating PDFs in iOS apps.
Features
•Viewing and navigating PDFs
•Full text search
•Annotating PDFs
•PDF Forms
■AcroForms
■Combo Box / List Box
■Form Toolbar
•Embedded Videos
•Share your PDFs via Email
•Encryption and Security
•... and many more!
CocoaPods
PSPDFKit is available via CocoaPods. Just add the ‘PSPDFKit’ pod and you’re good to go.
Binary
Simply drag the PSPDFKit.embeddedframework folder from the PSPDFKit distribution into your Xcode
project and enable the PSPDFKit.xcconfig as seen in FIG. 1 and you’re done.
If you prefer you can instead add the required frameworks manually.
If you have custom values set in your project settings “Other Linker Flags”, you need to clear them or
merge the entries with the contents of PSPDFKit.xcconfig.
FIG. 1: Integrating the binary distribution of PSPDFKit with your project
Getting Started - Integration
PSPDFKit is designed for Xcode 6.1+ (SDK 8) and fully supports iOS 8 and iOS 7.
#import <PSPDFKit/PSPDFKit.h>
// Create the PSPDFDocument.
// This is the container for your PDF file. It can also manage multiple files.
NSURL *documentURL = [NSBundle.mainBundle.resourceURL
URLByAppendingPathComponent:@"Document.pdf"];
PSPDFDocument *document = [PSPDFDocument documentWithURL:documentURL];
// Create the PDF view controller.
// The configuration object is optional and allows further customization.
PSPDFViewController *pdfController = [[PSPDFViewController alloc] initWithDocument:document
configuration:[PSPDFConfiguration configurationWithBuilder:^(PSPDFConfigurationBuilder
*builder) {
builder.thumbnailBarMode = PSPDFThumbnailBarModeScrollable;
builder.pageLabelEnabled = NO;
}]];
// Present the PDF view controller within an UINavigationController to enable the toolbar.
UINavigationController *navController = [[UINavigationController alloc]
initWithRootViewController:pdfController];
[self presentViewController:navController animated:YES completion:NULL];
Objective C
Getting Started - Hello PDF!
A simple example for using PSPDFKit, first in Objective C:
import PSPDFKit
var fileURL = NSBundle.mainBundle().bundleURL.URLByAppendingPathComponent("Document.
pdf")
var document = PSPDFDocument(URL: fileURL)
var configuration = PSPDFConfiguration { (builder) -> Void in
builder.thumbnailBarMode = .Scrollable;
}
var pdfController = PDFViewController(document: document, configuration:
configuration)
self.presentViewController( UINavigationController( rootViewController:
pdfController), animated: true, completion: nil)
Swift
This and many more examples can be found in
the Examples folder in the PSPDFKit distribu-
tion.
Note that while PSPDFDocument accepts a
NSURL, this example only supports local PDF
documents. The PSPDFKiosk example
project (part of the PSPDFCatalog example
project) shows how to download PDFs on-
demand.
Getting Started - Hello PDF! Hello Swift!
The same example as before, this time with Swi:
Getting Started - Next Steps
PSPDFCatalog
A searchable collection of examples of how to use PSPDFKit can be found in the PSPDFCatalog
example project. For instance, there are samples for:
Document Viewing: “Example Applications”
•PSPDFViewControllerPlayground: basic example using one PDF
•KioskGridExample: using a grid of multiple PDFs to select one;
the PDFs are stored in the SAMPLE-Directory of PSPDFCatalog
•Settings for a magazine: example using page curl
•Settings for a scientific paper: scrolling enabled
Multimedia Examples
•Embed YouTube Video into the page
•Image Gallery: multiple images are combined to an Image Gallery
•Simple Audio Annotation: Add an mp3 to the PDF
Annotation
•Programmatically create annotations
•Sign all pages
•XFDF Writing
Forms and Digital Signatures
Toolbar Customization
View Customization
•Night mode: Inverts colors for PDF rendering
•Screen Reader: sample-interface for a screen-reader application
Text Extraction / PDF Creation
•Full-Text Search: perform full-text search across all sample PDFs
Passwords / Security
... and many more examples - all available in PSPDFCatalog!
PSPDFKit - Need more help?
FAQ
support.pspdfkit.com
PSPDFKit API
http://pspdfkit.com/api
PSPDFKit - New Features
For each new version of PSPDFKit, the new features are presented in the following blog:
http://pspdfkit.com/blog
The changelog can be found here: http://pspdfkit.com/changelog
Further Questions?
Write us at support.pspdfkit.com for technical questions or
sales@pspdfkit.com for anything related to licensing and sales.
