Version 1.4

Business Gateway

Developer pack

Developer guide

1. OVERVIEW .............................................................................................................................................................. 4

1.1 OBJECTIVE ................................................................................................................................................................... 4

1.2 INTENDED AUDIENCE ...................................................................................................................................................... 4

2. ORGANISATION OF THE GUIDE ............................................................................................................................... 4

3. SYSTEM OVERVIEW................................................................................................................................................. 5

3.1 SERVICES EXPOSED VIA BUSINESS GATEWAY ....................................................................................................................... 5

3.1.1 Information services ......................................................................................................................................... 5

3.1.2 electronic Document Registration Service (e-DRS) ........................................................................................... 5

3.1.3 Verification Services ......................................................................................................................................... 5

3.1.4 Local Land Charges Service ............................................................................................................................... 6

3.1.5 Outstanding Requests service .......................................................................................................................... 6

4. PREREQUISITES ....................................................................................................................................................... 7

4.1 PREREQUISITES FOR GENERATING A WEB SERVICE CLIENT ....................................................................................................... 7

4.2 EXPIRY OF CERTIFICATES ................................................................................................................................................. 7

4.3 PREREQUISITES FOR INVOKING BUSINESS GATEWAY’S SERVICES .............................................................................................. 7

4.4 DEVELOPMENT ACTIVITIES ............................................................................................................................................... 8

5. DESIGN CONSTRAINTS ............................................................................................................................................ 9

5.1 UNIQUE MESSAGE ID ..................................................................................................................................................... 9

5.2 PROCESS REQUEST ONLY ONCE ......................................................................................................................................... 9

6. APIS AND SCHEMA ................................................................................................................................................ 10

6.1 INFORMATION SERVICE SCHEMA ................................................................................................................................. 10

6.2 EDOCUMENT REGISTRATION SERVICES ......................................................................................................................... 10

6.3 VERIFICATION SERVICES ............................................................................................................................................ 10

6.4 LOCAL LAND CHARGES SERVICES ................................................................................................................................ 10

6.5 UTILITY SERVICES..................................................................................................................................................... 10

6.6 API REQUEST AND RESPONSE ......................................................................................................................................... 10

6.6.1 Request Type .................................................................................................................................................. 10

6.6.2 Request structure ........................................................................................................................................... 11

6.6.3 Response types ............................................................................................................................................... 12

6.6.4 Response structure ......................................................................................................................................... 13

7.BUSINESS GATEWAY SERVICES URLS ..................................................................................................................... 17

7.1 WSDL AND REQUEST/RESPONSE SCHEMA DOWNLOAD LINKS ............................................................................................... 17

7.2 INFORMATION SERVICES ............................................................................................................................................... 18

7.2.1 Daylist enquiry V2.0........................................................................................................................................ 18

7.2.2 Enquiry by property description V2.0 ............................................................................................................. 18

7.2.3 Land Charges Bankruptcy search V2.0 ........................................................................................................... 18

7.2.4 Land Charges Bankruptcy search V2.1 ........................................................................................................... 19

7.2.5 Land Charges Full search V2.0 ........................................................................................................................ 19

7.2.6 Land Charges Full search V2.1 ........................................................................................................................ 19

7.2.7 Official copy title known V2.0 ......................................................................................................................... 19

7.2.8 Official copy title known V2.1 ......................................................................................................................... 20

7.2.9 Official search of part with priority V2.0 ........................................................................................................ 20

7.2.10 Official search of part with priority V2.1 ...................................................................................................... 20

7.2.11 Official search of whole with priority V2.0 ................................................................................................... 20

7.2.12 Official search of whole with priority V2.1 ................................................................................................... 21

7.2.13 Register extract service V2.0 ........................................................................................................................ 21

7.2.14 Register extract service V2.1 ........................................................................................................................ 21

7.2.15 Search of the index map V2.0 ....................................................................................................................... 22

7.2.16 Search of the index map V2.1 ....................................................................................................................... 22

7.3 E-DRS ...................................................................................................................................................................... 22

7.3.1 Application to change register V2.0 .......................................................................................................... 22

7.3.2 Attachment V2.0 ....................................................................................................................................... 22

7.3.3 Correspondence V1.0 ................................................................................................................................ 23

7.3.4 Early completion V2.0 ............................................................................................................................... 23

7.3.5 Application to change register V2.1 .......................................................................................................... 23

7.3.5 Attachment V2.1 ....................................................................................................................................... 23

7.3.6 Correspondence V2.1 ................................................................................................................................ 24

7.3.7 Early completion V2.1 ............................................................................................................................... 24

7.4 VERIFICATION SERVICES ................................................................................................................................................ 24

7.4.1 Online Ownership Verification V1.0 ............................................................................................................... 24

7.5 LOCAL LAND CHARGES SERVICES .................................................................................................................................... 24

7.5.1 Local Land Charges Search V1.0 ..................................................................................................................... 24

7.6 OUTSTANDING REQUESTS ............................................................................................................................................. 24

7.6.1 Outstanding Requests V2.0 ............................................................................................................................ 25

7.6.2 Outstanding Requests V2.1 ............................................................................................................................ 25

8.0 UPGRADE & CHANGE POLICY - VENDOR SUMMARY ........................................................................................... 26

8.1 NEW WEB SERVICE ...................................................................................................................................................... 26

8.2 WEB SERVICE DEPRECATION .......................................................................................................................................... 26

8.3 EMERGENCY BUG FIX (MINOR VERSION OF THE WEB SERVICE) ............................................................................................... 26

8.4 SCHEDULED UPGRADE (MAJOR VERSION OF THE WEB SERVICE) ............................................................................................. 27

9. ABBREVIATED TERMS ........................................................................................................................................... 28

1. Overview

1.1 Objective

The objective of this document is to provide comprehensive technical information

about Business Gateway for use by third party software vendors.

1.2 Intended audience

Case management software (CMS) vendors and conveyancers.

2. Organisation of the guide

Chapter Name

Chapter contents

1. Overview

Gives an insight into the objectives and intended

audience of the document.

2. Organisation of the guide

Gives an overview of organisation of the chapters

in this document.

3. System overview

Gives a brief overview of HM Land Registry and

Business Gateway services.

4. Prerequisites

Contains a list of prerequisites for generating web

services clients and invoking Business Gateway’s

services.

5. Design constraints

Gives an insight into the design constraints of the

system.

6. APIs and schema

Gives detailed information of the APIs and the XML

structures for input and result parameters.

7. Business Gateway

services URLs

Provides a list of URLs for downloading the WSDL

schemas and the request/response schemas.

8. Upgrade & Change Policy

– vendor summary

Summary of the Business Gateway Upgrade &

Change policy.

9. Abbreviated Terms

Explanation of acronyms used.

3. System overview

The Business Gateway system allows CMS vendors to have a direct interface with

Land Registry e-services. It provides a framework to streamline and improve their

business proficiency. Business Gateway provides an electronic XML interface for

interoperability between CMS and existing HM Land Registry services. A mutual

SSL connection is established between the external system and Business

Gateway’s web services for exchange of information.

3.1 Services exposed via Business Gateway

3.1.1 Information services

• Daylist enquiry.

• Daylist enquiry poll request.

• Enquiry by property description.

• Enquiry by property description poll request.

• Land Charges Bankruptcy search.

• Land Charges Bankruptcy search poll request.

• Land Charges Full search.

• Land Charges Full search poll request.

• Official copy title known.

• Official copy title known poll request.

• Official search of part with priority.

• Official search of part with priority poll request.

• Official search of whole with priority.

• Official search of whole with priority roll request.

• Register extract service.

• Register extract service poll request.

• Search of the index map.

• Search of the index map poll request.

3.1.2 electronic Document Registration Service (e-DRS)

• Application To Change Register

• Application To Change Register Poll Request

• Attachment

• Attachment Poll Request

• Correspondence Poll Request

• Early Completion Poll Request

3.1.3 Verification Services

Online Owner Verification

3.1.4 Local Land Charges Service

• Local Land Charges Search

3.1.5 Outstanding Requests service

• Outstanding Requests

4. Prerequisites

4.1 Prerequisites for generating a web service client

• A valid SSL certificate is required for downloading the WSDL and schema files from

HM Land Registry Business Gateway. This certificate is needed for mutual SSL

authentication.

• A list of URLs for all services provided by Business Gateway to download the

respective WSDL and schema files for a given service.

4.2 Expiry of Certificates

• HM Land Registry Business Gateway certificates expire after 3 years. When this

date is approaching you will need to contact your Account Manager who can raise a

request to have new Certificates issued. If your certificate expires you will not be

able to access the Business Gateway until the new certificate is installed and your

system is configured to use it.

4.3 Prerequisites for invoking Business Gateway’s services

• A valid SSL certificate issued by Business Gateway is required. This certificate is

used to enable mutual SSL authentication. This certificate is installed once at the

CMS client site.

• A list of URLs is required for all services provided by Business Gateway in order to

invoke the required services.

• An active user account to use Business Gateway. The user ID and the password is

the same as for the HM Land Registry portal.

• An active variable direct debit (VDD).

• The request should conform to the request schema.

• The request must contain Business Gateway User ID and password and locale

information as part of the SOAP header.

• A unique message ID generation mechanism should be followed for every request

being sent to Business Gateway (see Note 1).

• A mechanism is required to temporarily store the generated message ID. This

message ID is used to fetch the response when the end user does not receive the

synchronous response from Business Gateway for example when a request is

made out of hours or when the message is lost in transit.

Note 1

Reliable Messaging:

Message ID is used for the reliable messaging mechanism used in Business Gateway.

The external system is required to generate a unique identifier for every request that

has been sent to Business Gateway.

This message ID is used to receive a response from Business Gateway if the original

response is lost due to network issues or other reasons such as if the original request

was submitted out of hours.

Business Gateway uses the following information for determining whether a given

request is a new request.

1. Message ID.

2. Service Type (for example bankruptcy search).

3. User ID.

If the system determines that the given request is not new then the system will

try to find the existing response and return it without processing the request

again.

4.4 Development activities

• Install SSL certificates issued by HM Land Registry as trusted root.

• Install client digital certificate issued by HM Land Registry into client key store.

• Develop a mechanism to generate and store unique message IDs with respect to

the request sent to Business Gateway.

• Consume the WSDL offered by Business Gateway and develop the following

functionality based on the web services exposed.

• Develop a mechanism to send requests to Business Gateway for each web service

that has been exposed.

• Develop a mechanism to submit Outstanding Request requests to get information

about requests where the response is not available synchronously

• Develop a mechanism to send polling requests for the requests returned by the

Outstanding Request service.

• Develop a mechanism to process responses.

• Develop a mechanism to deal with exceptions.

• For each request sent, the SOAP header must contain the user ID, password and

locale information.

• For each request sent, the HTTPS channel will be mutually authenticated using

certificate exchange.

5. Design constraints

Web service requests over HTTP/HTTPS internet protocols are not reliable

and lead to lost messages between request and response. Hence, a reliable

messaging mechanism (see Note 1 above) is implemented in Business

Gateway to ensure that the responses are not lost between the client CMS

software and Business Gateway. The constraints implemented to ensure

reliable messaging are as follows:

• unique message ID

• process request only once.

5.1 Unique message ID

The client sends a SOAP request with a unique message ID and waits for the

response. In case the client does not receive a response within a specified

period of time, it will send the request with same message ID once again.

The client ensures that all message requests have a unique message ID. It is

the responsibility of Business Gateway to correlate the SOAP request and

response with the same message ID.

5.2 Process request only once

Business Gateway processes the request for the first time and stores the

response in a database. Next time a request arrives as a result of a lost

message, with the same message ID for the same service type and from the

same user ID then the response is sent from the stored data.

6. APIs and schema

6.1 Information service Schema

• Daylist enquiry.

• Enquiry by property description.

• Land Charges Bankruptcy search.

• Land Charges Full search.

• Official copy title known.

• Official search of part with priority.

• Official search of whole with priority.

• Register extract service.

• Search of the index map.

6.2 eDocument Registration Services

• Application To Change Register

• Attachment.

• Correspondence.

• Early Completion

6.3 Verification Services

• Online Ownership Verification

6.4 Local Land Charges Services

• Local Land Charges Search

6.5 Utility Services

• Outstanding requests.

6.6 API request and response

6.6.1 Request Type

Normal Request

A request is considered to be a normal request when it is sent to Business

Gateway during working hours. The original request is stored by Business

Gateway along with the response.

Poll Request

A Poll request can be used in a number of scenarios:

• Collecting Out of Hours applications

When a request is sent to Business Gateway ‘out of hours’ or after the day

list is closed, the system calculates a suggested date and time at which

the response to the request will be made available. The client can then

make a poll request to Business Gateway at the suggested date and time,

with the message ID of the original message, to retrieve the stored

response.

• Manual Processed applications

A poll request may be used to collect the result of a Business Gateway

application that has been processed manually by LR Staff.

For optimal usage the system can be written to automatically call the

Outstanding Request service, which will provide details of requests that have

a new response to be collected. These can then automatically be sent through

the corresponding Poll Request services, enabling the response to be

collected as early as possible. This is the only way to collect some of the

messages sent when using electronic Document Registration Service (e-

DRS). We recommend following this process every couple of hours.

6.6.2 Request structure

Business Gateway’s SOAP request consists of the following elements:

SOAP header must contain (refer to figure 1):

• user ID

• password

• locale information.

The SOAP body contains the web service request as shown in figure 1.

Figure 1

<!-- SOAP envelope starts -->

<soapenv:Envelope xmlns:soapenv="http://schemas.xmlsoap.org/soap/envelope/"

xmlns:drs="http://drsv1_0.ws.bg.lr.gov/"

xmlns:req="http://www.oscre.org/ns/eReg-

Final/2012/RequestApplicationToChangeRegisterV1_0">

<!-- SOAP header starts -->

<soapenv:Header>

<wsse:Security xmlns:wsse="http://docs.oasis-

open.org/wss/2004/01/oasis-200401-wss-wssecurity-secext-1.0.xsd">

<wsse:UsernameToken>

<wsse:Username>userName here</wsse:Username>

<wsse:Password type="http://docs.oasis-open.org/wss/2004/01/oasis-

200401-wss-username-token-profile-1.0#PasswordText">password

here</wsse:Password>

</wsse:UsernameToken>

</wsse:Security>

<i18n:international xmlns:i18n="http://www.w3.org/2005/09/ws-i18n">

<i18n:locale>en</i18n:locale>

</i18n:international>

</soapenv:Header>

<!-- SOAP header ends -->

<!-- SOAP body starts -->

<soapenv:Body>

<!-- SOAP body contains web service request -->

</soapenv:Body>

<!-- SOAP body ends -->

</soapenv:Envelope>

<!-- SOAP envelope ends -->

6.6.3 Response types

Business Gateway sends the following types of responses as part of request

processing:

• Normal response when the request is processed successfully. This

includes the response for a Business Gateway application that has been

processed manually.

• Acknowledgment response when the requested service is not available, or

the application requires manual processing.

• Error response when one or more business rules failed while processing

the request.

• SOAP fault response when some unexpected exception occurred while

processing the request. For example, the submitted request does not

contain a value in a mandatory element of the request schema

corresponding to the requested service. Refer to figure 2 for the structure

of this type of response.

Figure 2

<soapenv:Envelope xmlns:soapenv="http://schemas.xmlsoap.org/soap/envelope/"

xmlns:drs="http://drsv1_0.ws.bg.lr.gov/"

xmlns:req="http://www.oscre.org/ns/eReg-

Final/2012/RequestApplicationToChangeRegisterV1_0">

<soapenv:Fault>

<faultcode>soapenv:SchemaFault</faultcode>

<faultstring>Schema Errors have occured</faultstring>

<detail>

<drs:SchemaException>cvc-pattern-valid: Value '' is not facet-

valid with respect to pattern '[A-Z]{0,3}[0-9]{1,6}[ZT]?' for type

'TitleType'.</drs:SchemaException>

<drs:SchemaException>cvc-type.3.1.3: The value '' of element

'TitleNumber' is not valid.</drs:SchemaException>

</detail>

</soapenv:Fault>

6.6.4 Response structure

Business Gateway’s response structure has the following elements:

Response type code indicates the response type in the response structure. In

Business Gateway the response type code element can have one of the

following values

• 10 (for Acknowledgement).

• 20 (for Rejection).

• 30 (for Success).

Acknowledgement

This element response type contains the following information:

Expected time when user is supposed to send a poll request to get the

response. (this is only provided if the service was not available when the

application was submitted)

HMLRReference, this is HM Land Registry’s internal reference for the

application (this is only provided when the service was available, but the

application requires manual processing)

Unique message ID, the acknowledgment ID, which must be used to get the

poll response (refer to figure 3).

Figure 3

<!-- SOAP envelope starts -->

<soapenv:Envelope

xmlns:soapenv="http://schemas.xmlsoap.org/soap/envelope/">

<!-- SOAP body starts -->

<soapenv:Body>

<ns3:processLCBankruptcySearchRequestResponse

xmlns:ns1="http://www.oscre.org/ns/eReg-

Final/2011/RequestLandChargesBankruptcySearchV2_0"

xmlns:ns3="http://bankruptcyv2_0.ws.bg.lr.gov/"

xmlns:ns4="http://www.oscre.org/ns/eReg-

Final/2011/ResponseLandChargesBankruptcySearchV2_0">

<return>

<ns4:GatewayResponse>

<!-- Response type code:10 i.e Acknowledgement -->

<ns4:TypeCode>10</ns4:TypeCode>

<ns4:Acknowledgement>

<ns4:AcknowledgementDetails>

<!-- Unique message ID taken from request -->

<ns4:UniqueID>7987dff7666s001</ns4:UniqueID>

<!-- Expected date and time for the response to be available

-->

<ns4:ExpectedResponseDateTime>

2011-09-15T06:40:30</ns4:ExpectedResponseDateTime>

<ns4:MessageDescription>Service is not currently

available.System has queued your request,please poll

at specified time.</ns4:MessageDescription>

</ns4:AcknowledgementDetails>

</ns4:Acknowledgement>

</ns4:GatewayResponse>

</return>

</ns3:processLCBankruptcySearchRequestResponse>

</soapenv:Body>

<!-- SOAP body ends -->

</soapenv:Envelope>

<!-- SOAP envelope ends -->

Rejection

This error response type contains the business rules that have failed while

processing the request (refer to figure 4).

Figure 4

<!-- Soap Envelope starts -->

<soapenv:Envelope

xmlns:soapenv="http://schemas.xmlsoap.org/soap/envelope/">

<!-- Soap Body starts -->

<soapenv:Body>

<ns3:processLCBankruptcySearchRequestResponse

xmlns:ns1="http://www.oscre.org/ns/eReg-

Final/2011/RequestLandChargesBankruptcySearchV2_0"

xmlns:ns3="http://bankruptcyv2_0.ws.bg.lr.gov/"

xmlns:ns4="http://www.oscre.org/ns/eReg-

Final/2011/ResponseLandChargesBankruptcySearchV2_0">

<return>

<ns4:GatewayResponse>

<!-- Response type Code:20 i.e. Rejection -->

<ns4:TypeCode>20</ns4:TypeCode>

<ns4:Rejection>

<ns4:ExternalReference>

<ns4:Reference>Test 1.023</ns4:Reference>

</ns4:ExternalReference>

<ns4:RejectionResponse>

<ns4:Reason>BatchException</ns4:Reason>

<ns4:Code>BatchExceptionCode</ns4:Code>

<!-- Business Rule failed -->

<ns4:ValidationErrors>

<!-- Language independent error code -->

<ns4:Code>bg.fee.feeMismatch</ns4:Code>

<!-- Language dependent description (in this case 'EN') -->

<ns4:Description>Fee Amount provided does not match with

the fee calculated by Land Registry.</ns4:Description>

</ns4:ValidationErrors>

</ns4:RejectionResponse>

</ns4:Rejection>

</ns4:GatewayResponse>

</return>

</ns3:processLCBankruptcySearchRequestResponse>

</soapenv:Body>

<!-- Soap Body ends -->

</soapenv:Envelope>

<!-- Soap Envelope ends -->

Success

This normal response type contains the success result (refer to figure 5).

Figure 5

<!-- Soap Envelope starts -->

<soapenv:Envelope

xmlns:soapenv="http://schemas.xmlsoap.org/soap/envelope/">

<!-- Soap Body starts -->

<soapenv:Body>

<ns3:processLCBankruptcySearchRequestResponse

xmlns:ns1="http://www.oscre.org/ns/eReg-

Final/2011/RequestLandChargesBankruptcySearchV2_0"

xmlns:ns3="http://bankruptcyv2_0.ws.bg.lr.gov/"

xmlns:ns4="http://www.oscre.org/ns/eReg-

Final/2011/ResponseLandChargesBankruptcySearchV2_0">

<return>

<ns4:GatewayResponse>

<!-- Response type Code:30 i.e. Success -->

<ns4:TypeCode>30</ns4:TypeCode>

<!-- Success Results -->

<ns4:Results>

<ns4:ExternalReference>

<ns4:Reference>abc12345</ns4:Reference>

</ns4:ExternalReference>

<ns4:HMLRReference>

<ns4:Reference>09395D</ns4:Reference>

</ns4:HMLRReference>

<ns4:ActualPrice>

<ns4:GrossPriceAmount>2.00</ns4:GrossPriceAmount>

</ns4:ActualPrice>

<ns4:Attachment>

<ns4:EmbeddedFileBinaryObject ns4:format="PDF">Large byte

array here removed for space</ns4:EmbeddedFileBinaryObject>

</ns4:Attachment>

<ns4:ResultTypeCode>10</ns4:ResultTypeCode>

</ns4:Results>

</ns4:GatewayResponse>

</return>

</ns3:processLCBankruptcySearchRequestResponse>

</soapenv:Body>

<!-- Soap Body ends -->

</soapenv:Envelope>

<!-- Soap Envelope ends -->

7.Business Gateway services URLs

7.1 WSDL and request/response schema download links

In the URLs listed below, substitute {PLACE_HOLDER} as follows:

Test Environments:

• Enquiry by Property Description, Office Copy Title Known, Official

Search of Whole with Priority

https://bgtest.landregistry.gov.uk/b2b/ECBG_StubService

• eDocument Registration Service

https://bgtest.landregistry.gov.uk/b2b/ECDRS_StubService

• Online Ownership Verification Service

https://bgtest.landregistry.gov.uk/b2b/EOOV_StubService

• All Other Services

https://bgtest.landregistry.gov.uk/b2b/BGStubService

• Local Land Charges Service

https://bgtest.landregistry.gov.uk/b2b/ECLLC_StubService

Production Environments:

• eDocument Registration Service

https://businessgateway.landregistry.gov.uk/b2b/ECDRS_SoapEngine

• Online Ownership Verification Service

https://businessgateway.landregistry.gov.uk/b2b/EOOV_SoapEngine

• Local Land Charges Service

https://businessgateway.landregistry.gov.uk/b2b/ECLLC_SoapEngine

• All Other Services

https://businessgateway.landregistry.gov.uk/b2b/BGSoapEngine

7.2 Information Services

7.2.1 Daylist enquiry V2.0

• {PLACE_HOLDER}/DaylistEnquiryV2_0WebService?wsdl

• {PLACE_HOLDER}/DaylistEnquiryV2_0WebService/WEB-

INF/wsdl/RequestDaylistEnquiryV2_0.xsd

• {PLACE_HOLDER}/DaylistEnquiryV2_0WebService/WEB-

INF/wsdl/ResponseDaylistEnquiryV2_0.xsd

• {PLACE_HOLDER}/DaylistEnquiryV2_0PollRequestWebService?wsdl

• {PLACE_HOLDER}/DaylistEnquiryV2_0PollRequestWebService/WEB-

INF/wsdl/PollRequest.xsd

7.2.2 Enquiry by property description V2.0

• {PLACE_HOLDER}/EnquiryByPropertyDescriptionV2_0WebService?wsdl

• {PLACE_HOLDER}/EnquiryByPropertyDescriptionV2_0WebService/WEB-

INF/wsdl/RequestSearchByPropertyDescriptionV2_0.xsd

• {PLACE_HOLDER}/EnquiryByPropertyDescriptionV2_0WebService/WEB-

INF/wsdl/ResponseSearchByPropertyDescriptionV2_0.xsd

• {PLACE_HOLDER}/EnquiryByPropertyDescriptionV2_0PollWebService?wsdl

• {PLACE_HOLDER}/EnquiryByPropertyDescriptionV2_0PollWebService/WEB-

INF/wsdl/PollRequest.xsd

7.2.3 Land Charges Bankruptcy search V2.0

• {PLACE_HOLDER}/BankruptcySearchV2_0WebService?wsdl

• {PLACE_HOLDER}/BankruptcySearchV2_0WebService/WEB-

INF/wsdl/RequestLandChargesBankruptcySearchV2_0.xsd

• {PLACE_HOLDER}/BankruptcySearchV2_0WebService/WEB-

INF/wsdl/ResponseLandChargesBankruptcySearchV2_0.xsd

• {PLACE_HOLDER}/BankruptcySearchV2_0PollRequestWebService?wsdl

• {PLACE_HOLDER}/BankruptcySearchV2_0PollRequestWebService/WEB-

INF/wsdl/PollRequest.xsd

7.2.4 Land Charges Bankruptcy search V2.1

• {PLACE_HOLDER}/BankruptcySearchV2_1WebService?wsdl

• {PLACE_HOLDER}/BankruptcySearchV2_1WebService/WEB-

INF/wsdl/RequestLandChargesBankruptcySearchV2_1.xsd

• {PLACE_HOLDER}/BankruptcySearchV2_1PollRequestWebService?wsdl

• {PLACE_HOLDER}/BankruptcySearchV2_1PollRequestWebService/WEB-

INF/wsdl/PollRequest.xsd

7.2.5 Land Charges Full search V2.0

• {PLACE_HOLDER}/FullSearchV2_0WebService?wsdl

• {PLACE_HOLDER}/FullSearchV2_0WebService/WEB-

INF/wsdl/RequestLandChargesFullSearchV2_0.xsd

• {PLACE_HOLDER}/FullSearchV2_0WebService/WEB-

INF/wsdl/ResponseLandChargesFullSearchV2_0.xsd

• {PLACE_HOLDER}/FullSearchV2_0PollRequestWebService?wsdl

• {PLACE_HOLDER}/FullSearchV2_0PollRequestWebService/WEB-

INF/wsdl/PollRequest.xsd

7.2.6 Land Charges Full search V2.1

• {PLACE_HOLDER}/FullSearchV2_1WebService?wsdl

• {PLACE_HOLDER}/FullSearchV2_1WebService/WEB-

INF/wsdl/RequestLandChargesFullSearchV2_1.xsd

• {PLACE_HOLDER}/FullSearchV2_1PollRequestWebService?wsdl

• {PLACE_HOLDER}/FullSearchV2_1PollRequestWebService/WEB-

INF/wsdl/PollRequest.xsd

7.2.7 Official copy title known V2.0

• {PLACE_HOLDER}/OfficialCopyTitleKnownV2_0WebService?wsdl

• {PLACE_HOLDER}/OfficialCopyTitleKnownV2_0WebService/WEB-

INF/wsdl/RequestTitleKnownOfficialCopyV2_0.xsd

• {PLACE_HOLDER}/OfficialCopyTitleKnownV2_0WebService/WEB-

INF/wsdl/ResponseTitleKnownOfficialCopyV2_0.xsd

• {PLACE_HOLDER}/OC1TitleKnownV2_0PollRequestWebService?wsdl

• {PLACE_HOLDER}/OC1TitleKnownV2_0PollRequestWebService/WEB-

INF/wsdl/PollRequest.xsd

7.2.8 Official copy title known V2.1

• {PLACE_HOLDER}/OfficialCopyTitleKnownV2_1WebService?wsdl

• {PLACE_HOLDER}/OfficialCopyTitleKnownV2_1WebService/WEB-

INF/wsdl/RequestTitleKnownOfficialCopyV2_1.xsd

• {PLACE_HOLDER}/OC1TitleKnownV2_1PollRequestWebService?wsdl

• {PLACE_HOLDER}/OC1TitleKnownV2_1PollRequestWebService/WEB-

INF/wsdl/PollRequest.xsd

7.2.9 Official search of part with priority V2.0

• {PLACE_HOLDER}/OfficialSearchOfPartV2_0WebService?wsdl

• {PLACE_HOLDER}/OfficialSearchOfPartV2_0WebService/WEB-

INF/wsdl/RequestOfficialSearchOfPartWithPriorityV2_0.xsd

• {PLACE_HOLDER}/OfficialSearchOfPartV2_0WebService/WEB-

INF/wsdl/ResponseOfficialSearchOfPartWithPriorityV2_0.xsd

• {PLACE_HOLDER}/OfficialSearchOfPartV2_0PollRequestWebService?wsdl

• {PLACE_HOLDER}/OfficialSearchOfPartV2_0PollRequestWebService/WEB-

INF/wsdl/PollRequest.xsd

7.2.10 Official search of part with priority V2.1

• {PLACE_HOLDER}/OfficialSearchOfPartV2_1WebService?wsdl

• {PLACE_HOLDER}/OfficialSearchOfPartV2_1WebService/WEB-

INF/wsdl/RequestOfficialSearchOfPartWithPriorityV2_1.xsd

• {PLACE_HOLDER}/OfficialSearchOfPartV2_1PollRequestWebService?wsdl

• {PLACE_HOLDER}/OfficialSearchOfPartV2_1PollRequestWebService/WEB-

INF/wsdl/PollRequest.xsd

7.2.11 Official search of whole with priority V2.0

• {PLACE_HOLDER}/OfficialSearchV2_0WebService?wsdl

• {PLACE_HOLDER}/OfficialSearchV2_0WebService/WEB-

INF/wsdl/RequestOfficialSearchOfWholeWithPriorityV2_0.xsd

• {PLACE_HOLDER}/OfficialSearchV2_0WebService/WEB-

INF/wsdl/ResponseOfficialSearchOfWholeWithPriorityV2_0.xsd

• {PLACE_HOLDER}/OfficialSearchV2_0PollRequestWebService?wsdl

• {PLACE_HOLDER}/OfficialSearchV2_0PollRequestWebService/WEB-

INF/wsdl/PollRequest.xsd

7.2.12 Official search of whole with priority V2.1

• {PLACE_HOLDER}/OfficialSearchV2_1WebService?wsdl

• {PLACE_HOLDER}/OfficialSearchV2_1WebService/WEB-

INF/wsdl/RequestOfficialSearchOfWholeWithPriorityV2_1.xsd

• {PLACE_HOLDER}/OfficialSearchV2_1PollRequestWebService?wsdl

• {PLACE_HOLDER}/OfficialSearchV2_1PollRequestWebService/WEB-

INF/wsdl/PollRequest.xsd

7.2.13 Register extract service V2.0

• {PLACE_HOLDER}/OfficialCopyWithSummaryV2_0WebService?wsdl

• {PLACE_HOLDER}/OfficialCopyWithSummaryV2_0WebService/WEB-

INF/wsdl/RequestOCWithSummaryV2_0.xsd

• {PLACE_HOLDER}/OfficialCopyWithSummaryV2_0WebService/WEB-

INF/wsdl/ResponseOCWithSummaryV2_0.xsd

• {PLACE_HOLDER}/OfficialCopyWithSummaryV2_0PollRequestWebService?wsdl

• {PLACE_HOLDER}/OfficialCopyWithSummaryV2_0PollRequestWebService/WEB-

INF/wsdl/PollRequest.xsd

7.2.14 Register extract service V2.1

• {PLACE_HOLDER}/OfficialCopyWithSummaryV2_1WebService?wsdl

• {PLACE_HOLDER}/OfficialCopyWithSummaryV2_1WebService/WEB-

INF/wsdl/ResponseOCWithSummaryV2_1.xsd

• {PLACE_HOLDER}/OfficialCopyWithSummaryV2_1PollRequestWebService?wsdl

• {PLACE_HOLDER}/OfficialCopyWithSummaryV2_1PollRequestWebService/WEB-

INF/wsdl/PollRequest.xsd

7.2.15 Search of the index map V2.0

• {PLACE_HOLDER}/SearchOfIndexMapV2_0WebService?wsdl

• {PLACE_HOLDER}/SearchOfIndexMapV2_0WebService/WEB-

INF/wsdl/RequestSearchOfIndexMapV2_0.xsd

• {PLACE_HOLDER}/SearchOfIndexMapV2_0WebService/WEB-

INF/wsdl/ResponseSearchOfIndexMapV2_0.xsd

• {PLACE_HOLDER}/SearchOfIndexMapV2_0PollRequestWebService?wsdl

• {PLACE_HOLDER}/SearchOfIndexMapV2_0PollRequestWebService/WEB-

INF/wsdl/PollRequest.xsd

7.2.16 Search of the index map V2.1

• {PLACE_HOLDER}/SearchOfIndexMapV2_1WebService?wsdl

• {PLACE_HOLDER}/SearchOfIndexMapV2_1WebService/WEB-

INF/wsdl/RequestSearchOfIndexMapV2_1.xsd

• {PLACE_HOLDER}/SearchOfIndexMapV2_1PollRequestWebService?wsdl

• {PLACE_HOLDER}/SearchOfIndexMapV2_1PollRequestWebService/WEB-

INF/wsdl/PollRequest.xsd

7.3 e-DRS

7.3.1 Application to change register V2.0

• {PLACE_HOLDER}/EDocumentRegistrationV2_0WebService?wsdl

• {PLACE_HOLDER}/EDocumentRegistrationV2_0WebService/WEB-

INF/wsdl/RequestApplicationToChangeRegisterV2_0.xsd

• {PLACE_HOLDER}/EDocumentRegistrationV2_0WebService/WEB-

INF/wsdl/ResponseApplicationToChangeRegisterV2_0.xsd

• {PLACE_HOLDER}/EDocumentRegistrationV2_0PollRequestWebService?wsdl

• {PLACE_HOLDER}/EDocumentRegistrationV2_0PollRequestWebService/WEB-

INF/wsdl/PollRequest.xsd

7.3.2 Attachment V2.0

• {PLACE_HOLDER}/AttachmentV2_0WebService?wsdl

• {PLACE_HOLDER}/AttachmentV2_0WebService/WEB-

INF/wsdl/RequestAttachmentV2_0.xsd

• {PLACE_HOLDER}/AttachmentV2_0WebService/WEB-

INF/wsdl/ResponseAttachmentV2_0.xsd

• {PLACE_HOLDER}/AttachmentV2_0PollRequestWebService?wsdl

• {PLACE_HOLDER}/AttachmentV2_0PollRequestWebService/WEB-

INF/wsdl/PollRequest.xsd

7.3.3 Correspondence V1.0

• {PLACE_HOLDER}/CorrespondenceV1_0PollRequestWebService?wsdl

• {PLACE_HOLDER}/CorrespondenceV1_0PollRequestWebService/WEB-

INF/wsdl/CorrespondenceV1_0.xsd

• {PLACE_HOLDER}/CorrespondenceV1_0PollRequestWebService/WEB-

INF/wsdl/PollRequest.xsd

7.3.4 Early completion V2.0

• {PLACE_HOLDER}/EarlyCompletionV2_0PollRequestWebService?wsdl

• {PLACE_HOLDER}/EarlyCompletionV2_0PollRequestWebService/WEB-

INF/wsdl/ResponseEarlyCompletionV2_0.xsd

• {PLACE_HOLDER}/EarlyCompletionV2_0PollRequestWebService/WEB-

INF/wsdl/PollRequest.xsd

7.3.5 Application to change register V2.1

• {PLACE_HOLDER}/EDocumentRegistrationV2_1WebService?wsdl

• {PLACE_HOLDER}/EDocumentRegistrationV2_1WebService/WEB-

INF/wsdl/RequestApplicationToChangeRegisterV2_1.xsd

• {PLACE_HOLDER}/EDocumentRegistrationV2_1WebService/WEB-

INF/wsdl/ResponseApplicationToChangeRegisterV2_0.xsd

• {PLACE_HOLDER}/EDocumentRegistrationV2_1PollRequestWebService?wsdl

• {PLACE_HOLDER}/EDocumentRegistrationV2_1PollRequestWebService/WEB-

INF/wsdl/PollRequest.xsd

7.3.5 Attachment V2.1

• {PLACE_HOLDER}/AttachmentV2_1WebService?wsdl

• {PLACE_HOLDER}/AttachmentV2_1WebService/WEB-

INF/wsdl/RequestAttachmentV2_1.xsd

• {PLACE_HOLDER}/AttachmentV2_1WebService/WEB-

INF/wsdl/ResponseAttachmentV2_0.xsd

• {PLACE_HOLDER}/AttachmentV2_1PollRequestWebService?wsdl

• {PLACE_HOLDER}/AttachmentV2_1PollRequestWebService/WEB-

INF/wsdl/PollRequest.xsd

7.3.6 Correspondence V2.1

• {PLACE_HOLDER}/CorrespondenceV2_1PollRequestWebService?wsdl

• {PLACE_HOLDER}/CorrespondenceV2_1PollRequestWebService/WEB-

INF/wsdl/CorrespondenceV1_0.xsd

• {PLACE_HOLDER}/CorrespondenceV2_1PollRequestWebService/WEB-

INF/wsdl/PollRequest.xsd

7.3.7 Early completion V2.1

• {PLACE_HOLDER}/EarlyCompletionV2_1PollRequestWebService?wsdl

• {PLACE_HOLDER}/EarlyCompletionV2_1PollRequestWebService/WEB-

INF/wsdl/ResponseEarlyCompletionV2_0.xsd

• {PLACE_HOLDER}/EarlyCompletionV2_1PollRequestWebService/WEB-

INF/wsdl/PollRequest.xsd

7.4 Verification Services

7.4.1 Online Ownership Verification V1.0

• {PLACE HOLDER}/OnlineOwnershipVerificationV1_0WebService?wsdl

• {PLACE HOLDER}/OnlineOwnershipVerificationV1_0WebService/WEB-

INF/wsdl/RequestOnlineOwnershipVerificationV1_0.xsd

• {PLACEHOLDER}/OnlineOwnershipVerificationV1_0WebService/WEB_INF/wsdl/

ResponseOnlineOwnershipVerificationV1_0.xsd

• {PLACE HOLDER}/OnlineOwnershipVerificationV1_0WebService/WEB-

INF/wsdl/PollRequest.xsd

7.5 Local Land Charges Services

7.5.1 Local Land Charges Search V1.0

• {PLACE HOLDER}/LLCSearchV1_0WebService?wsdl

• {PLACE HOLDER}/LLCSearchV1_0WebService/WEB-

INF/wsdl/LLCSearchRequestV1_0.xsd

• {PLACEHOLDER}/LLCSearchV1_0WebService/WEB_INF/wsdl/LLCSearchResponseV

1_0.xsd

• {PLACE HOLDER}/LLCSearchV1_0WebService/WEB-INF/wsdl/PollRequest.xsd

7.6 Outstanding Requests

7.6.1 Outstanding Requests V2.0

• {PLACE_HOLDER}/OutstandingRequestsV2_0WebService?wsdl

• {PLACE_HOLDER}/OutstandingRequestsV2_0WebService/WEB-

INF/wsdl/RequestOutstandingRequestsV2_0.xsd

• {PLACE_HOLDER}/OutstandingRequestsV2_0WebService/WEB-

INF/wsdl/ResponseOutstandingRequestsV2_0.xsd

7.6.2 Outstanding Requests V2.1

• {PLACE_HOLDER}/OutstandingRequestsV2_1WebService?wsdl

• {PLACE_HOLDER}/OutstandingRequestsV2_1WebService/WEB-

INF/wsdl/RequestOutstandingRequestsV2_1.xsd

• {PLACE_HOLDER}/OutstandingRequestsV2_0WebService/WEB-

INF/wsdl/ResponseOutstandingRequestsV2_0.xsd

8.0 Upgrade & Change Policy - vendor summary

The general policy for upgrading and changing Business Gateway is to

introduce new web services and deprecate existing web services gracefully

wherever possible; this should avoid the need for all applications to perform a

hard cutover. Due to the overhead and impact of delivering new schemas HM

Land Registry will endeavour to schedule a maximum of one release per year.

Only where there is a major bug making a web service inoperable will a web

service be replaced with immediate effect.

8.1 New web service

• Notification of the functionality and delivery schedule of a new web

service will be through standard customer communication channels,

combined with the new forum created for users of Business Gateway.

• All technical details will be published on the Business Gateway

developer pack webpage.

• A vendor test facility will go live at the same time as or prior to the web

service itself. This will include Test Stubs, Vendor Test Data,

Workflows providing business rules and message outputs and Schema

Validation Sheets.

8.2 Web service deprecation

• Notification of the schedule for deprecation will come from the standard

customer communication channels.

• The normal deprecation (removal) of a web service will be six months

from the date of notification, but this may vary in exceptional

circumstances.

• All users of a service will receive a final reminder one month before the

service is discontinued.

• Changes and additions to the service will be contained in the Business

Gateway Service release notes on the Business Gateway landing

page. Change details relating to the developer pack will be contained in

the Business Gateway Developer Pack release notes referenced on

the Business Gateway developer pack webpage

8.3 Emergency bug fix (minor version of the web service)

• Notification of an emergency bug fix will be through the Service Desk.

• A new version number will be incorporated into an existing web service

name that is being replaced, for example Version 1.0 will become

Version 1.1. In this emergency example, Version 1.0 will be withdrawn

as soon as Version 1.1 becomes live.

• A new version of the vendor test facility will go live at the same time as

the web service itself. Integrated vendors will be notified if and/or when

they can test the change before it is put live.

8.4 Scheduled upgrade (major version of the web service)

• Notification of the changes being made in a new version of an existing

web service will be from the standard customer communication

channels.

• The new version will run simultaneously with the old, until the old

version is deprecated, to avoid the need for all applications to perform

a hard cutover.

• A new version number will be incorporated into an existing web service

name that is being replaced, for example Version 1.0 (or 1.1) will

become Version 2.0.

• A new version of the vendor test facility (stub) will go live at the same

time as or prior to the new version of the web service.

• Change details will be contained in the Service Business Gateway

release notes on the Business Gateway landing page.

9. Abbreviated Terms

Abbreviation

Full Name

API

Application programming interface

CMS

Case management software

HTTP

Hypertext transfer protocol

HTTPS

Hypertext transfer protocol secure

ID

Identifier

LLC

Local Land Charges

SOAP

Simple object access protocol

SSL

Secure sockets layer

URL

Uniform resource locator

VDD

Variable direct debit

WSDL

Web services description language

XML

Extensible markup language
