HPE Security

Fortify Static Code Analyzer

Software Version: 17.10

Performance Guide

Document Release Date: April 2017

Software Release Date: April 2017

Legal Notices

Warranty

The only warranties for Hewlett Packard Enterprise Development products and services are set forth in the express warranty

statements accompanying such products and services. Nothing herein should be construed as constituting an additional

warranty. HPE shall not be liable for technical or editorial errors or omissions contained herein.

The information contained herein is subject to change without notice.

Restricted Rights Legend

Confidential computer software. Valid license from HPE required for possession, use or copying. Consistent with FAR 12.211

and 12.212, Commercial Computer Software, Computer Software Documentation, and Technical Data for Commercial Items

are licensed to the U.S. Government under vendor's standard commercial license.

The software is restricted to use solely for the purpose of scanning software for security vulnerabilities that is (i) owned by

you; (ii) for which you have a valid license to use; or (iii) with the explicit consent of the owner of the software to be scanned,

and may not be used for any other purpose.

You shall not install or use the software on any third party or shared (hosted) server without explicit consent from the third

party.

Trademark Notices

Adobe® is a trademark of Adobe Systems Incorporated.

Microsoft® and Windows® are U.S. registered trademarks of Microsoft Corporation.

Documentation Updates

The title page of this document contains the following identifying information:

lSoftware Version number

lDocument Release Date, which changes each time the document is updated

lSoftware Release Date, which indicates the release date of this version of the software

To check for recent updates or to verify that you are using the most recent edition of a document, go to:

https://www.protect724.hpe.com/community/fortify/fortify-product-documentation

You will receive updated or new editions if you subscribe to the appropriate product support service. Contact your HPE sales

representative for details.

Performance Guide

HPE Security Fortify Static Code Analyzer (17.10) Page 2 of 32

Contents

Preface 5

Contacting HPESecurity Fortify Support 5

For More Information 5

About the Documentation Set 5

Change Log 6

Chapter 1: Introduction 7

Hardware Recommendations 7

Sample Scans 8

Related Documents

This topic describes documents that provide information about HPE Security Fortify Static Code

Analyzer.

Note: The Protect724 site location is https://www.protect724.hpe.com/community/fortify/fortify-

product-documentation.

All Products

The following documents provide general information for all products.

Document / File Name Description Location

HPE Security Fortify Software

System Requirements

HPE_Sys_Reqs_<version>.pdf

This document provides the

details about the environments

and products supported for this

version of HPE Security Fortify

Software.

Included with product

download and on the

Protect724 site

HPE Security Fortify Software

Release Notes

HPE_FortifySW_RN_

This document provides an

overview of the changes made

to HPE Security Fortify

Included on the Protect724 site

Performance Guide

Chapter 1: Introduction

HPE Security Fortify Static Code Analyzer (17.10) Page 8 of 32

Document / File Name Description Location

<version>.txt Software for this release and

important information not

included elsewhere in the

product documentation.

What’s New in HPE Security

Fortify Software <version>

HPE_Whats_New_

<version>.pdf

This document describes the

new features in HPE Security

Fortify Software products.

Included on the Protect724 site

HPE Security Fortify Open

Source and Third-Party

License Agreements

HPE_OpenSrc_<version>.pdf

This document provides open

source and third-party software

license agreements for software

components used in HPE

Security Fortify Software.

Included with product

download and on the

Protect724 site

HPE Security Fortify Glossary

HPE_Glossary.pdf

This document provides

definitions for HPE Security

Fortify Software terms.

Included with product

download and on the

Protect724 site

HPE Security Fortify Software Security Center

The following documents provide information about HPE Security Fortify Software Security Center.

Document / File Name Description Location

HPE Security Fortify Software

Security Center User Guide

HPE_SSC_Guide_<version>.pdf

HPE_SSC_Help_<version>

This document provides Fortify

Software Security Center users

with detailed information about

how to deploy and use Fortify

Software Security Center. It

provides all of the information

you need to acquire, install,

configure, and use Fortify

Software Security Center.

It is intended for use by system

and instance administrators,

database administrators

(DBAs), enterprise security

leads, development team

managers, and developers.

Fortify Software Security

Center provides security team

leads with a high-level overview

of the history and current status

of a project.

Included with product

download and on the

Protect724 site

Performance Guide

Chapter 1: Introduction

HPE Security Fortify Static Code Analyzer (17.10) Page 9 of 32

Document / File Name Description Location

HP Fortify Software Security

Center User Guide: Legacy

User Interface

HP_Fortify_SSC_User_Guide_

Legacy.pdf

PDFonly; no help file

This document is the user guide

for HP Software Security Center

version 4.30. The legacy (4.30)

user interface is available from

the current Fortify Software

Security Center user interface.

Specific areas of functionality

are available only in the 4.30

interface.

Included with product

download and on the

Protect724 site

HPE Security Fortify Software

Security Center Process

Designer Guide: Legacy User

Interface

HPE_SSC_Proc_Design_Guide_

Legacy_<version>.pdf

HPE_SSC_Proc_Design_Help_

This document provides

information about how to start

the Process Designer, configure

its connection to your Fortify

Software Security Center

instance, and then use it to work

with Fortify Software Security

Center process templates, which

are used only in the Fortify

Software Security Center legacy

(version 4.30) user interface.

Included with product

download and on the

Protect724 site

HP Fortify Software Security

Center Installation and

Configuration Guide: Legacy

User Interface

HP_Fortify_SSC_Install_and_

Config_Guide_Legacy.pdf

PDFonly; no help file

This document provides system

and database administrators

with complete instructions on

how to configure Fortify

Software Security Center server

software using the legacy

(v4.30) user interface.

Included with product

download and on the

Protect724 site

HPE Security Fortify Software

Security Center Process

Designer Guide: Legacy User

Interface

HPE_SSC_Proc_Design_Guide_

Legacy_<version>.pdf

HPE_SSC_Proc_Design_Help_

This legacy document provides

information about how to start

the Process Designer, configure

its connection to your Fortify

Software Security Center

instance, and then use it to work

with Fortify Software Security

Center process templates.

Included with product

download and on the

Protect724 site

Performance Guide

Chapter 1: Introduction

HPE Security Fortify Static Code Analyzer (17.10) Page 10 of 32

HPE Security Fortify Static Code Analyzer

The following documents provide information about Static Code Analyzer.

Document / File Name Description Location

HPE Security Fortify Static

Code Analyzer User Guide

HPE_SCA_Guide_

<version>.pdf

HPE_SCA_Help_<version>

This document describes how

to use Fortify Static Code

Analyzer to scan code on many

of the major programming

platforms. It is intended for

people responsible for security

audits and secure coding.

Included with product

download and on the

Protect724 site

HPE Security Fortify Static

Code Analyzer Installation

Guide

HPE_SCA_Install_

<version>.pdf

HPE_SCA_Install_Help_

This document contains

installation instructions for

Fortify Static Code Analyzer

and Applications.

Included with product

download and on the

Protect724 site

HPE Security Fortify Static

Code Analyzer Performance

Guide

HPE_SCA_Perf_Guide_

<version>.pdf

PDF only; no help file

This document provides

guidelines for selecting

hardware to scan different

types of codebases and offers

tips for optimizing memory

usage and performance.

Included with product

download and on the

Protect724 site

HPE Security Fortify Static

Code Analyzer Custom Rules

Guide

HPE_SCA_Cust_Rules_Guide_

<version>.zip

PDF only; no help file

This document provides the

information that you need to

create custom rules for Fortify

Static Code Analyzer. This

guide includes examples that

apply rule-writing concepts to

real-world security issues.

Included with product

download



Performance Guide

Chapter 1: Introduction

HPE Security Fortify Static Code Analyzer (17.10) Page 11 of 32

Chapter 2: Performance Improvement Tips

This section contains different methods of tuning the HPESecurityFortify Static Code Analyzer to

maximize its functionality.

This section contains the following topics:

Hardware Considerations 12

Tuning Options 12

Mobile Build Sessions 13

Memory Tuning 14

Parallel Processing 17

Hardware Considerations

The system requirements are documented in the HPESecurityFortify Software System Requirements

document. However, for large and complex applications, Fortify Static Code Analyzer requires more

capable hardware. This includes:

lDisk I/O—Fortify Static Code Analyzer is I/O intensive so the faster the hard drive, the more savings

on the I/O transaction. HPE recommends a 7,200 RPM drive, although a 10,000 RPM drive (such as

the WD Raptor) or an SSD drive is better.

lMemory—See "Memory Tuning" on page14 for more information about how to determine the

amount of memory required for optimal performance.

lCPU—HPE recommends a 2.1 GHz processor or faster.

Tuning Options

Fortify Static Code Analyzer can take a long time to process complex projects. The time is spent in

different phases:

lTranslation

lAnalysis

The Fortify Static Code Analyzer analysis results can be large and therefore cause a long time to audit

and upload to HPESecurityFortify Software Security Center (Fortify Software Security Center). This is

referred to as the following phase:

lAudit/upload

HPE Security Fortify Static Code Analyzer (17.10) Page 12 of 32

The following table provides tips on how to improve performance in the different time-consuming

phases.

Phase

Options / Property

Name Description More Information

Translation -export-build-

session

-import-build-

session

Translate (and scan)on

different machines

"Mobile Build Sessions" below

Analysis -Xmx<size>M

-Xmx<size>G

Allocate additional RAM "Memory Tuning" on the next

page

Analysis -Xss<size>M

-Xss<size>G

Stack size allocation "Memory Tuning" on the next

page

Analysis -mt Enable parallel analysis mode

to reduce scan time

"Parallel Processing" on

page17

Analysis com.fortify.sca.

ThreadCount

Number of threads used in

multithreaded operations

HPESecurity Fortify Static

Code Analyzer User Guide

Analysis -bin Scan the files related to the

given binary (for C/C++)

"Breaking Down Codebases"

on page18

Analysis -quick Quick scan "Quick Scan" on page19

Analysis

Audit/upload

-filter

Apply a filter using a filter

file

"Filters" on page22

Analysis

Audit/upload

-disable-source-

bundling

Exclude source files in the

FPR file

"Excluding Source Code from

the FPR" on page23

Mobile Build Sessions

With a Fortify Static Code Analyzer mobile build session (MBS), you can translate a project on one

machine and analyze it on a different machine with better hardware. With an MBS, you can perform the

translation on the original computer and then move the build session to a better equipped computer to

perform the scan. The developers can run translations on their own computers and use only one

powerful computer to run large scans.

Performance Guide

Chapter 2: Performance Improvement Tips

HPE Security Fortify Static Code Analyzer (17.10) Page 13 of 32

HPE strongly recommends that you move MBS files with the Fortify Static Code Analyzer export and

import options.

sourceanalyzer -b <build_id> -export-build-session my-session.mbs

sourceanalyzer -import-build-session my-session.mbs

Below is an example of the steps required to use an MBS. This example runs the translation on

MachineT and the scan on MachineS.

1. Machine T: Translate the source files.

sourceanalyzer -b <build_id> <SourceFiles>

2. Machine T: Package and save an MBSto a file called build-session.mbs.

sourceanalyzer -b <build_id> -export-build-session build-session.mbs

3. Transfer build-session.mbs from Machine T to Machine S.

4. Machine S: Import the MBS into the Fortify Static Code Analyzer project root directory on the scan

machine.

sourceanalyzer -import-build-session build-session.mbs

5. Machine S: Perform a scan with the same build ID that was used in the translation.

sourceanalyzer -b <build_id> -scan -f myResults.fpr

You cannot merge multiple mobile build sessions into a single build session. Each exported build session

must use a unique build ID and you must import it under that unique build ID. However, after all of the

build IDs are on the same sourceanalyzer installation, you can scan multiple build IDs in one scan with

the -b option.

For example, assuming all the build IDs were imported to the local machine using mobile build sessions,

you can use the following command to scan:

sourceanalyzer -b BuildID_1 -b BuildID_2 -b BuildID_3 -scan -f myResults.fpr

Note: The resulting FPR (myResults.fpr) covers the same files as if they were all translated into

one build ID. However, there are rare instances where dataflow between the files is lost if they are

not translated together.

Memory Tuning

As discussed in "Hardware Recommendations" on page7, the amount of physical RAM required for a

scan depends on the complexity of the code itself. By default Fortify Static Code Analyzer automatically

allocates the memory it uses based on the physical memory available on the system. This is generally

sufficient.

Performance Guide

Chapter 2: Performance Improvement Tips

HPE Security Fortify Static Code Analyzer (17.10) Page 14 of 32

As described in the HPESecurity Fortify Static Code Analyzer User Guide, you can adjust the Java heap

size with the -Xmx command-line option. Heap sizes between 32GB and 48GB are not advised due to

internal JVM implementations. Heap sizes in this range perform worse than at 32 GB. Heap sizes smaller

than 32GB are optimized by the JVM. If your scan requires more than 32GB, then you probably need

much more than 48GB such as 64GB or higher. As a guideline, assuming no other memory intensive

processes are running, do not allocate more than 2/3 of the available memory.

This section describes suggestions for what you can do if you encounter OutOfMemory errors during

the analysis.

Note: You can set the memory allocation options discussed in this section to run for all scans by

setting the SCA_VM_OPTS environment variable.

Java Heap Exhaustion

Java heap exhaustion is the most common memory problem during Fortify Static Code Analyzer scans

and is the result of allocating too little heap space to the Java virtual machine that Fortify Static Code

Analyzer uses for scanning the project. IdentifyJava heap exhaustion from the following symptom.

Symptom

One or more of these messages appears in the Fortify Static Code Analyzer log file and in the

command-line output:

There is not enough memory available to complete analysis. For details on

making more memory available, please consult the user manual.

java.lang.OutOfMemoryError: Java heap space

java.lang.OutOfMemoryError: GC overhead limit exceeded

Resolution

To resolve a Java heap exhaustion problem, allocate more heap space to the Fortify Static Code

Analyzer Java virtual machine when you start the scan. To increase the heap size, use the -Xmx

command-line option when you run the Fortify Static Code Analyzer scan. For example, -Xmx1G makes

1 GB available. Before you use this parameter, determine the maximum allowable value for Java heap

space. The maximum value depends on the available physical memory.

HPE recommends that the value of -Xmx not exceed either 90% of the total physical memory or the total

physical memory minus 1.5GB to allow for the operating system. If the system is dedicated to running

Fortify Static Code Analyzer, you do not need to change it. However, if the system resources are shared

with other memory-intensive processes, subtract an allowance for those other processes.

Note: You do not need to account for other resident but not active processes (while Fortify Static

Code Analyzer is running)that the operating system might swap to disk. Allocating more physical

memory to Fortify Static Code Analyzer than is available in the environment might cause

“thrashing” which typically slows down the scan along with everything else on the system.

Performance Guide

Chapter 2: Performance Improvement Tips

HPE Security Fortify Static Code Analyzer (17.10) Page 15 of 32

Native Heap Exhaustion

Native heap exhaustion is a rare scenario in which the Java virtual machine is able to allocate the Java

memory regions on startup, but is left with so few resources for its native operations (such as garbage

collection) that it eventually encounters a fatal memory allocation failure that immediately terminates

the process.

Symptom

You can identify native heap exhaustion by abnormal termination of the Fortify Static Code Analyzer

process and the following output on the command line:

# A fatal error has been detected by the Java Runtime Environment:

# java.lang.OutOfMemoryError: requested ... bytes for GrET ...

Because this is a fatal Java virtual machine error, it is usually accompanied by an error log created in the

working directory with the file namehs_err_pidNNN.log.

Resolution

Because the problem is a result of overcrowding within the process, the resolution is to reduce the

amount of memory used for the Java memory regions (Java heap). Reducing this value should reduce

the crowding problem and allow the scan to complete successfully.

Stack Overflow

Each thread in a Java application has its own stack. The stack holds return addresses, function/method

call arguments, and so on. If a thread tends to process large structures with recursive algorithms, it

might need a large stack for all those return addresses. With the JVM, you can set that size with the

-Xss option.

Symptoms

This message typically appears in the Fortify Static Code Analyzer log file, but might also appear in the

command-line output:

java.lang.StackOverflowError

Resolution

The default stack size is 16 MB. To increase the stack size, pass the -Xss option to the

sourceanalyzer command. For example, -Xss32M increases the stack to 32 MB.

Performance Guide

Chapter 2: Performance Improvement Tips

HPE Security Fortify Static Code Analyzer (17.10) Page 16 of 32

Parallel Processing

Fortify Static Code Analyzer uses parallel processing in the scan phase to reduce scan times by

harnessing all CPU cores available on your system. By default, parallel processing occurs during:

lPre-analysis—Construction of the analysis model used by the security analyzers

lGlobal dataflow analysis—Interprocedural taint propagation to identify dataflow issues

lPost-analysis—Issue filtering and rendering to the FPR file

You can optionally enable parallel processing (parallel analysis mode) for all security analyzers for faster

performance of what is commonly the most time-consuming portion of the analysis phase.

For more information on how to use parallel analysis mode, see the HPESecurity Fortify Static Code

Analyzer User Guide.

Performance Guide

Chapter 2: Performance Improvement Tips

HPE Security Fortify Static Code Analyzer (17.10) Page 17 of 32

Chapter 3: Scan Quality and Performance

This section contains the following topics:

Breaking Down Codebases 18

Limiters 18

Limiting Analyzers and Languages 19

Scanning Complex Functions 21

Breaking Down Codebases

It is more efficient to break down large projects into independent modules. For example, if you have a

portal application that consists of several modules that are independent of each other or have very little

interactions, you can translate and scan the modules separately. The caveat to this is that you might lose

dataflow if some interactions exist.

For C/C++, you might reduce the scan time by using the –bin option with the –scan option. You need

to pass the binary file as the parameter (such as -bin <filename>.exe -scan or -bin

<filename>.dll -scan), and Fortify Static Code Analyzer finds the related files associated with the

binary and scans them. This is useful if you have several binaries in a makefile.

The following table lists useful Fortify Static Code Analyzer command-line options for breaking down

codebases.

Option Description

-bin Specifies a subset of source files to scan. Only the source files that were

linked in the named binary at build time are included in the scan. You can

used this option multiple times to specify the inclusion of multiple binaries in

the scan.

-show-binaries Displays all objects that were created but not used in the production of any

other binaries. If fully integrated into the build, it lists all of the binaries

produced.

-show-build-tree When used with the -bin option, displays all files used to create the binary

and all files used to create those files in a tree layout. If the -bin option is not

present, the tree is displayed for each binary.

Limiters

The depth of the Fortify Static Code Analyzer analysis sometimes depends on the available resources.

Fortify Static Code Analyzer uses a complexity metric to trade off these resources with the number of

HPE Security Fortify Static Code Analyzer (17.10) Page 18 of 32

vulnerabilities that it can find. Sometimes, this means giving up on a particular function when it does not

look like Fortify Static Code Analyzer has enough resources available.

Fortify Static Code Analyzer enables the user to control the “cutoff” point by using Fortify Static Code

Analyzer limiter properties. The different analyzers have different limiters. You can run a predefined set

of these limiters using a Quick Scan. See the quick scan properties in the HPESecurity Fortify Static

Code Analyzer User Guide for description of the full set of limiters.

Quick Scan

Quick Scan Mode provides a way to quickly scan your projects for major defects. Although the Quick

Scan is significantly faster, it does not provide a robust result set. To enable quick scan, use -quick

option with -scan option.

With Quick Scan Mode enabled, Fortify Static Code Analyzer applies the properties from the <sca_

install_dir>/Core/config/fortify-sca-quickscan.properties file, in addition to the

standard <sca_install_dir>/Core/config/fortify-sca.properties file. By default, this scan

searches for high‐confidence, high‐severity issues. You can alter the limiters Fortify Static Code

Analyzer uses by editing the fortify-sca-quickscan.properties file. If you modify fortify-

sca.properties, it also affects quick scan behavior. HPE recommends that you do performance

tuning in quick scan mode, and leave the full scan in the default settings to produce a highly accurate

scan.

Using Quick Scan and Full Scan

lRun periodic full scans—A periodic full scan is important as it might find issues that Quick Scan

does not detect. Run a full scan at least once per software iteration. If possible, run a full scan

periodically when it will not interrupt workflow, such as on a weekend.

lCompare Quick Scan With a Full Scan—To evaluate the accuracy impact of a Quick Scan, perform

a Quick Scan and a full scan on the same code base, then load the Quick Scan results in Audit

Workbench and merge it into the full scan. Group the issues by New Issue to produce a list of issues

found in the full scan but not found in the Quick Scan.

lQuick Scans and Fortify Software Security Center Server—To avoid overwriting the results of a

full scan, by default Fortify Software Security Center does not accept FPR files scanned using Quick

Scan. However, you can configure Fortify Software Security Center so that FPRfiles scanned with

Quick Scan are not blocked for an application version. For more information, see the

HPESecurityFortify Software Security Center User Guide.

Limiting Analyzers and Languages

Occasionally, you might find that a significant amount of the scan time is spent either running one

particular analyzer or analyzing a particular language. It is also possible that this particular analyzer or

language is not of great interest to your security requirements. You can limit the specific analyzers that

run and the specific languages that are translated.

Performance Guide

Chapter 3: Scan Quality and Performance

HPE Security Fortify Static Code Analyzer (17.10) Page 19 of 32

Disabling Analyzers

To disable specific analyzers, include the -analyzers option to Fortify Static Code Analyzer at scan

time with a colon- or comma-separated list of analyzers you want to enable. The full list of analyzers is:

buffer, content, configuration, controlflow, dataflow, findbugs, nullptr, semantic, and

structural.

For example, to run a scan using only the Dataflow, Control Flow, and Buffer analyzers, use the

following scan command:

sourceanalyzer -b <build_id> -analyzers dataflow:controlflow:buffer -scan

-f myResults.fpr

You can also do the same thing by setting com.fortify.sca.DefaultAnalyzers in the Fortify

Static Code Analyzer property file <sca_install_dir>/Core/config/fortify-

sca.properties. For example, to achieve the equivalent of the previous scan command, set the

following in the properties file:

com.fortify.sca.DefaultAnalyzers=dataflow:controlflow:buffer

Disabling Languages

To disable specific languages, include the -disable-language option in the translation phase. This is

followed by a colon-separated list of languages that you want to disable. The full list of language

options is:

abap, actionscript, any_sql, asp, c, cfml, cpp, csharp, cobol, html, java,

javascript, jsp, objc, objcpp, php, plsql, python, ruby, swift, tsql, vb,

vb6, vbscript

For example, to run a scan that excludes all SQL and HTML files, use the following command to perform

the translation:

sourceanalyzer -b <BuildID> <TranslationFiles>

-disable-languages any_sql:html

You can also disable languages by setting the com.fortify.sca.DISabledLanguages property in

the Fortify Static Code Analyzer properties file <sca_install_

dir>/Core/config/fortify-sca.properties. For example, to achieve the equivalent of the

previous translation command, set the following in the properties file:

com.fortify.sca.DISabledLanguages=any_sql:html

Performance Guide

Chapter 3: Scan Quality and Performance

HPE Security Fortify Static Code Analyzer (17.10) Page 20 of 32

Scanning Complex Functions

During a scan Fortify Static Code Analyzer, the Dataflow Analyzer might encounter a function for

which it cannot complete the analysis and reports the following message:

Function <name> is too complex for <analyzer> analysis and will be skipped

(<identifier>)

To see a discussion of a resolution for this issue, see "Function too Complex to Analyze Message" on

page29.

Performance Guide

Chapter 3: Scan Quality and Performance

HPE Security Fortify Static Code Analyzer (17.10) Page 21 of 32

Chapter 4: Optimizing FPRFiles

This chapter describes how to handle performance issues related to the audit results (FPR) file. This

includes reducing the scan time, reducing FPRfile size, and tips for opening large FPR files.

This section contains the following topics:

Filters 22

Excluding Source Code from the FPR 23

Reducing the FPRFile Size 24

Opening Large FPRFiles 25

Filters

Filters are usually part of the issue template and determine how the results from Fortify Static Code

Analyzer are shown. For example, you can have a filter to put SQL Injection issues found into a separate

folder called “SQL Injections”, or you might have a filter so that issues with a confidence below a certain

threshold are hidden. Along with filters, filter sets enable you to have a selection of filters used at any

one time. This enables you to more easily customize your view and allows you to define a different view

for developers, auditors, and managers so that they can more easily see the most important or relevant

information for them.

Each FPR has an issue template associated with it, and in Fortify Software Security Center these are

specified on an application version basis. For further information about issue templates and customizing

them, see the HPESecurityFortify Audit Workbench User Guide.

Filter Files

Filter files are flat files that you can specify along with a scan using -filter option. Use a filter file to

blacklist specified categories, instance IDs, and rule IDs. If you determine that a certain category of

issues or rules are not relevant for a particular scan, you can stop Fortify Static Code Analyzer from

flagging these types of issues and adding them to FPR. You can use a filter file to reduce both the scan

time and the size of the results file.

For example, if you are scanning a simple program that just reads a specified file, you might not want to

see path manipulation issues, since these are likely planned as part of the functionality. To do filter out

path manipulation issues, a file that contains a single line:

Path Manipulation

Save this file as filter.txt. Use the -filter option for the scan as shown in the following example:

sourceanalyzer -b <build_id> -scan -f myResults.fpr -filter filter.txt

The myResults.fpr does not include any issues with the category Path Manipulation.

For more information about filter files, see the HPESecurity Fortify Static Code Analyzer User Guide.

HPE Security Fortify Static Code Analyzer (17.10) Page 22 of 32

Scan-Time Filters

An alternate way to filter at scan-time is to use filter sets to reduce the number of issues based on

conditions you specify with filters in an issue template. A scan-time filter can dramatically reduce the size

of an FPR.

To do this, use Audit Workbench to create a filter and a filter set and then run the Fortify Software

Security Center scan with the filter set. For more detailed instructions about how to create filters and

filter sets in Audit Workbench, see HPESecurityFortify Audit Workbench User Guide. The following

example describes the basic steps for how to create and use a scan-time filter:

1. In this example, suppose you use the OWASP Top 10 2013 and you only want to see issues

categorized within this standard. Create a filter in Audit Workbench such as:

If [OWASP Top 10 2013] does not contain A Then hide issue

This filter looks through the issues and if an issue does not map to an OWASP Top 10 2013

category with ‘A’ in the name, then it hides it. Because all OWASP Top 10 2013 categories start

with ‘A’ (A1, A2, …, A10), then any category without the letter ‘A’ is not in the OWASP Top 10

2013. The filter hides the issues from view in Audit Workbench, but they are still in the FPR.

2. In Audit Workbench, create a new filter set called OWASP_Filter_Set that contains the previous

filter, and then export the issue template to a file called IssueTemplate.xml.

3. You can then specify this filter at scan-time with the following command:

sourceanalyzer -b <build_id> -scan -f myScanTimeFilterResults.fpr

-project-template IssueTemplate.xml -Dcom.fortify.sca.FilterSet=OWASP_

Filter_set

In the previous example, the inclusion of the -Dcom.fortify.sca.FilterSet property tells Fortify

Static Code Analyzer to use the OWASP_Filter_Set filter set from the issue template

IssueTemplate.xml. Any filters that hide issues from view are removed and are not written to the

FPR. Therefore, you can reduce the visible number of issues, make the scan very targeted, and reduce

the size of the resulting FPR file.

Note: Although scan-time filters can reduce the size of the FPR, they do not usually reduce the

scan time. Fortify Static Code Analyzer examinesscan-time filters after it calculates the issues to

determine whether or not to write them to the FPR file. The filters in a filter file determine the rule

types that Fortify Static Code Analyzer loads.

Excluding Source Code from the FPR

You can reduce the scan time and the size of the FPRfile by excluding the source code information

from the FPR, especially with large source files or codebases. You generally do not get a scan time

reduction for small source files.

Performance Guide

Chapter 4: Optimizing FPRFiles

HPE Security Fortify Static Code Analyzer (17.10) Page 23 of 32

There are two ways to prevent Fortify Static Code Analyzer from including source code in the FPR. You

can set the property in the <sca_install_dir>/Core/config/fortify-sca.properties file or

specify an option on the command line. The following table describes these settings.

Property Name Description

com.fortify.sca.

FPRDisableSourceBundling=true

Command-line Option:

-disable-source-bundling

Disable source code inclusion in the FPR

com.fortify.sca.

FVDLDisableSnippets=true

Command-line Option:

–fvdl-no-snippets

Exclude code snippets from the FPR

The following command-line example uses both options:

sourceanalyzer -b <build_id> -disable-source-bundling

-fvdl-no-snippets -scan -f mySourcelessResults.fpr

Reducing the FPRFile Size

There are a few ways to reduce the size of FPR files. The quickest way to do this without affecting

results is to exclude the source code from the FPR as described in "Excluding Source Code from the

FPR" on the previous page.

There are a few other options and properties that you can use to select what is excluded from the FPR.

You can set these properties in the Fortify Static Code Analyzer properties file: <sca_install_

dir>/Core/config/fortify-sca.properties or specify them during the scan phase with

-D<Propertyname>=true. Most of these options have an equivalent command-line option.

Property Name Description

com.fortify.sca.

FPRDisableMetatable

=true

Command-line Option:

-disable-metatable

This disables the metatable inside the FPR. Audit

Workbench uses the metatable to map information in

Functions view.

com.fortify.sca.

FVDLDisableDescriptions

=true

Command-line Option:

-fvdl-no-description

This excludes descriptions from theFPR. If you do

not use custom descriptions, descriptions listed in the

HPE Security Fortify Taxonomy

(https://vulncat.hpefod.com) are used.

Performance Guide

Chapter 4: Optimizing FPRFiles

HPE Security Fortify Static Code Analyzer (17.10) Page 24 of 32

Property Name Description

com.fortify.sca.

FVDLDisableEngineData

=true

Command-line Option:

-fvdl-no-enginedata

This excludes engine data from the FPR. This is

useful if your FPR contains a large number of

warnings when you open the file in Audit Workbench.

The caveat of this option is that you need to merge

the FPR with the current audit project locally before

you upload it to Fortify Software Security Center.

Because the FPR does not contain the Fortify Static

Code Analyzer version, Fortify Software Security

Center is unable to merge it on the server.

com.fortify.sca.

FVDLDisableProgramData

=true

Command-line Option:

-fvdl-no-progdata

This excludes the program data section from the

FPR. This removes the Taint Sources information

from the Functions view in Audit Workbench. This

property typically only has a minimal effect on the

overall size of the FPR file.

Opening Large FPRFiles

To reduce the time required to open a large FPR file, there are some properties that you can set in the

<sca_install_dir>/Core/config/fortify.properties configuration file. For more

information about these properties, see the HPESecurity Fortify Static Code Analyzer Tools Property

Reference Guide. The following table describes these properties.

Property Name Description

com.fortify.

model.DisableProgramInfo=true

This disables use of the code navigation

features in Audit Workbench.

com.fortify.

model.IssueCutOffStartIndex

=<num> (inclusive)

com.fortify.

model.IssueCutOffEndIndex

=<num> (exclusive)

The IssueCutOffStartIndex property is

inclusive and IssueCutOffEndIndex is

exclusive so that you can specify a subset of

issues you want to see. For example, to see the

first 100 issues, you can specify the following:

com.fortify.model.

IssueCutOffStartIndex=0

com.fortify.model.

IssueCutOffEndIndex=101

Because the IssueCutOffStartIndex is 0 by

default, you do not need to specify this

property.

Performance Guide

Chapter 4: Optimizing FPRFiles

HPE Security Fortify Static Code Analyzer (17.10) Page 25 of 32

Property Name Description

com.fortify.

model.IssueCutOffByCategoryStartIndex=

<num> (inclusive)

com.fortify.

model.IssueCutOffByCategoryEndIndex=

<num> (exclusive)

These are similar to the previous cutoff

properties except these are specified for each

category. For example. if you want to see the

first five issues for every category you would

specify the following:

com.fortify.model.

IssueCutOffByCategoryEndIndex=6

com.fortify.

RestrictIssueLoading=true

This restricts the data that is held in memory,

but it might cause poor performance.

com.fortify.

model.MinimalLoad=true

This minimizes the data loaded in the FPR. This

also restricts usage of the Functions view and

might prevent Audit Workbench from loading

the source from the FPR.

com.fortify.

model.MaxEngineErrorCount=

<num>

This property limits the number of Fortify Static

Code Analyzer reported errors that are loaded

with the FPR. For projects with a large number

of scan warnings, this can reduce both load

time in Audit Workbench and the amount of

memory required to open the FPR.

Performance Guide

Chapter 4: Optimizing FPRFiles

HPE Security Fortify Static Code Analyzer (17.10) Page 26 of 32

Chapter 5: Monitoring Long Running Scans

When you run Fortify Static Code Analyzer, large and complex scans can often take a long time to

complete. During the scan it is not always clear what is happening. While HPE recommends that you

provide your debug logs to the HPESecurityFortify Technical Support team, there are a couple of ways

to see what Fortify Static Code Analyzer is doing and how it is performing in real-time.

This section contains the following topics:

Using the SCAState Utility 27

Using JMX Tools 27

Using the SCAState Utility

The SCAState command-line utility enables you to see up-to-date state analysis information during the

analysis phase. The SCAState utility is located in the <sca_install_dir>/bin directory. In addition

to a live view of the analysis, it also provides a set of timers and counters that show where Fortify Static

Code Analyzer spends its time during the scan. For more information about how to use the SCAState

utility, see the HPESecurity Fortify Static Code Analyzer User Guide.

Using JMX Tools

You can use a variety of tools to monitor Fortify Static Code Analyzer with JMX. These tools have

advantages and disadvantages, however the GUI-based tools can provide a way to track Fortify Static

Code Analyzer performance over time.

Note: These are third-party tools and HPESecurity does not provide or support them .

JConsole

JConsole is an interactive monitoring tool that complies with the JMX specification. The disadvantage of

JConsole is that you cannot save the output.

To use JConsole, you must first set some additional JVM parameters. Set the following environment

variable:

export SCA_VM_OPTS="-Dcom.sun.management.jmxremote

-Dcom.sun.management.jmxremote.port=9090

-Dcom.sun.management.jmxremote.ssl=false

-Dcom.sun.management.jmxremote.authenticate=false"

For more information about these parameters, see the full Oracle documentation available at:

http://docs.oracle.com/javase/8/docs/technotes/guides/management/jconsole.html.

HPE Security Fortify Static Code Analyzer (17.10) Page 27 of 32

After the JMX parameters are set, start a Fortify Static Code Analyzer scan. During the scan, start

JConsole to monitor Fortify Static Code Analyzer locally or remotely with the following command:

jconsole <host_name>:9090

Java VisualVM

Java VisualVM offers the same capabilities as JConsole. It also provides more detailed information on

the JVM and enables you to save the monitor information to an application snapshot file. You can store

these files and open them later with Java VisualVM.

As with JConsole, before you can use Java VisualVM, you must set the same JVM parameters as

described in "JConsole" on the previous page.

After the JVM parameters are set, start the scan. You can then start Java VisualVM to monitor the scan

either locally or remotely with the following command:

jvisualvm <host_name>:9090

For more information about Java VisualVM, see the full Oracle documentation available at:

http://docs.oracle.com/javase/8/docs/technotes/guides/visualvm/.

Performance Guide

Chapter 5: Monitoring Long Running Scans

HPE Security Fortify Static Code Analyzer (17.10) Page 28 of 32

Chapter 6: Troubleshooting

Function too Complex to Analyze Message

During a Fortify Static Code Analyzer scan, an analyzer might encounter a function for which it cannot

complete the analysis and reports the following message:

Function <name> is too complex for <analyzer> analysis and will be skipped

(<identifier>)

where:

l<name> is the name of the source code function

l<analyzer> is the name of the analyzer

l<identifier> is the type of complexity which is one of the following:

ll: Too many distinct locations

lm: Out of memory

ls: Stack size too small

lt: Analysis taking too much time

The depth of analysis Fortify Static Code Analyzer performs sometimes depends on the available

resources. Fortify Static Code Analyzer uses a complexity metric to tradeoff these resources against the

number of vulnerabilities that it can find. Sometimes, this means giving up on a particular function when

Fortify Static Code Analyzer does not have enough resources available. This is normally when you see

the "Function too complex" messages.

When you see this message, it does not necessarily mean that the function in the program was

completely ignored. For example, the Dataflow Analyzer typically visits a function many times before

completing the analysis, and might not run into this complexity limit in the previous visits. In this case,

the results include anything learned from the previous visits.

You can control the "give up" point using Fortify Static Code Analyzer properties called limiters.

Different analyzers have different limiters.

Dataflow Analyzer Limiters

There are three types of complexity identifiers for the Dataflow Analyzer:

ll: Too many distinct locations

lm: Out of memory

ls: Stack size too small

HPE Security Fortify Static Code Analyzer (17.10) Page 29 of 32

To resolve the issue identified by s, increase the stack size for by setting -Xssto a value greater than

16MB.

To resolve the complexity identifier of m, increase the physical memory for Fortify Static Code Analyzer.

To resolve the complexity identifier of l, you can adjust the following limiters in the Fortify Static Code

Analyzer property file <sca_install_dir>/Core/config/fortify-sca.properties or on the

command line.

Property Name Default Value

com.fortify.sca.

limiters.MaxTaintDefForVar

1000

com.fortify.sca.

limiters.MaxTaintDefForVarAbort

4000

com.fortify.sca.

limiters.MaxFieldDepth

The MaxTaintDefForVar limiter is a dimensionless value expressing the complexity of a function,

while MaxTaintDefForVarAbort is the upper bound for it. Use the MaxFieldDepth limiter to

measure the precision when the Dataflow Analyzer analyzes any given object. Fortify Static Code

Analyzer always tries to analyze objects at the highest precision possible.

If a given function exceeds theMaxTaintDefForVar limit at a given level of precision, the Dataflow

Analyzer analyzes that function with a lower level of precision (by reducing theMaxFieldDepth

limiter).When you reduce the precision, it reduces the complexity of the analysis. When the precision

cannot be reduced any further, Fortify Static Code Analyzer then proceeds with analysis at the lowest

precision level until either it finishes or the complexity exceeds theMaxTaintDefForVarAbort limiter.

In other words, Fortify Static Code Analyzer tries harder at the lowest precision level than at higher

precision levels, to get at least some results from the function. If Fortify Static Code Analyzer reaches

theMaxTaintDefForVarAbort limiter, it gives up on the function entirely and you get the "Function

too complex" warning.

Control Flow and Null Pointer Analyzer Limiters

There are two types of complexity identifiers for both Control Flow and Null Pointer analyzers:

lm: Out of memory

lt: Analysis taking too much time

Due to the way that the Dataflow Analyzer handles function complexity, it does not take an indefinite

amount of time. Control Flow and Null Pointer analyzers, however, can take a very long time when

analyzing very complex functions. Therefore, Fortify Static Code Analyzer provides a way to abort the

analysis when this happens, and then you get the "Function too complex" message with a complexity

identifier of t.

Performance Guide

Chapter 6: Troubleshooting

HPE Security Fortify Static Code Analyzer (17.10) Page 30 of 32

To change the maximum amount of time these analyzers spend analyzing functions, you can adjust the

following property values in the Fortify Static Code Analyzer property file <sca_install_

dir>/Core/config/fortify-sca.properties or on the command line.

Property Name Description

Default

Value

com.fortify.sca.

CtrlflowMaxFunctionTime

Sets the time limit (in milliseconds) for Control Flow

analysis on a single function.

600000

(10minutes)

com.fortify.sca.

NullPtrMaxFunctionTime

Sets the time limit (in milliseconds) for Null Pointer

analysis on a single function.

300000

(5minutes)

To resolve the complexity identifier of m, increase the physical memory for Fortify Static Code Analyzer.

Note: If you increase these limiters or time settings, it makes the analysis of complex functions take

longer. It is hard to characterize the exact performance implications of a particular value for the

limiters/time, because it depends on the specific function in question. If you never want see the

"Function too complex" warning, you can set the limiters/time to an extremely high value , however

it can cause unacceptable scan time.

Performance Guide

Chapter 6: Troubleshooting

HPE Security Fortify Static Code Analyzer (17.10) Page 31 of 32

Send Documentation Feedback

If you have comments about this document, you can contact the documentation team by email. If an

email client is configured on this computer, click the link above and an email window opens with the

following information in the subject line:

Feedback on Performance Guide (HPE Security Fortify Static Code Analyzer 17.10)

Just add your feedback to the email and click send.

If no email client is available, copy the information above to a new message in a web mail client, and send

your feedback to HPFortifyTechPubs@hpe.com.

We appreciate your feedback!

HPE Security Fortify Static Code Analyzer (17.10) Page 32 of 32

HPE Security Fortify Static Code Analyzer Performance Guide SCA Perf 17.10

HPE_SCA_Perf_Guide_17.10

Navigation menu

Versions of this User Manual:

Views

Navigation
