1 Overview
1.1 Brief Introduction
HUAWEI E5785Lh-22c Mobile WiFi (hereinafter referred to as the E5785Lh-22c) is a
high-speed packet access mobile hotspot. It is a multi-mode wireless terminal for
SOHO (Small Office and Home Office) and business professionals.
The E5785Lh-22c supports the following standards:
- Long Term Evolution Carrier Aggregation (LTE CA)
- LTE Frequency Division Duplex (FDD)
- LTE Time Division Duplex (TDD)
- Dual Carrier High Speed Packet Access Plus (DC-HSPA+)
- High Speed Packet Access Plus (HSPA+)
- High Speed Uplink Packet Access (HSUPA)
- High Speed Downlink Packet Access (HSDPA)
- Universal Mobile Telecommunications System (UMTS)
- Enhanced Data rates for Global Evolution (EDGE)
- General Packet Radio Service (GPRS)
- Global System for Mobile communications (GSM)
The E5785Lh-22c provides the following services:
- LTE CA packet data service
- LTE FDD packet data service
- LTE TDD packet data service
- DC-HSPA+ packet data service
- HSPA+/HSPA/UMTS packet data service
- Short Message Service (SMS)
You can connect the E5785Lh-22c with the USB interface of a computer, or connect
the E5785Lh-22c with the Wi-Fi. In the service area of the LTE CA/LTE FDD/LTE
TDD/ DC-HSPA+/HSPA+/HSPA/UMTS network, you can surf the Internet and
send/receive messages/emails cordlessly. The E5785Lh-22c is fast, reliable, and
easy to operate. Thus, mobile users can experience many new features and services
with the E5785Lh-22c. These features and services will enable a large number of
HUAWEI E5785Lh-22c Mobile WiFi V200R001
Product Description
Issue 01 (2016-06-02) Commercial in Confidence Page 7 of 21
users to use the E5785Lh-22c and the average revenue per user (ARPU) of operators
will increase substantially.
Figure 1-1 shows the profile of the E5785Lh-22c.
Figure 1-1 E5785Lh-22c profile
1.2 Optional Features
Optional features refer to features that are not supported by the standard version or
are disabled by default. These features can be customized according to operator or
customer requirements. The E5785Lh-22c's optional feature is as follows:
- IPv6/IPv4 dual stack (optional)
- SIM lock (optional)
HUAWEI E5785Lh-22c Mobile WiFi V200R001
Product Description
Issue 01 (2016-06-02) Commercial in Confidence Page 8 of 21
2 Features
2.1 Main Features
The E5785Lh-22c mainly supports the following features:
- LTE FDD CA (DL) data service of up to 300 Mbit/s
- LTE FDD (DL) data service of up to 150 Mbit/s
- LTE FDD (UL) data service of up to 50 Mbit/s
- LTE TDD CA (DL) data service of up to 224 Mbit/s
- LTE TDD (DL) data service of up to 112 Mbit/s
- LTE TDD (UL) data service of up to 20 Mbit/s
- DC-HSPA+ (DL) data service of up to 43.2 Mbit/s
- HSPA+ (DL) data service of up to 21.6 Mbit/s
- HSDPA (DL) data service of up to 14.4 Mbit/s
- HSUPA (UL) data service of up to 5.76 Mbit/s
- UMTS data service of up to 384 kbit/s
- EDGE data service of up to 236.8 kbit/s
- GPRS data service of up to 85.6 kbit/s
- PS domain data service based on LTE/UMTS/GSM
- SMS based on LTE/UMTS/GSM
- Built-in LTE/UMTS and WLAN high gain antenna
- Wi-Fi 2.4 GHz and 5 GHz
- Menu-style LCD UI
- Support for HUAW EI HiLink APP (Mobile WiFi APP)
- Press and Play
- IPv6/IPv4 dual stack (optional)
- Built-in DHCP Server, DNS RELAY and NAT
- Online software upgrade
- Traffic statistic
- WPS
- Standard Micro USB 2.0 interface
- 2D Barcode easy connection
HUAWEI E5785Lh-22c Mobile WiFi V200R001
Product Description
Issue 01 (2016-06-02) Commercial in Confidence Page 9 of 21
- Windows 7, Windows 8, Windows 8.1, Windows 10 (does not support Windows RT),
MAC OS X 10.7, 10.8, 10.9, 10.10 and 10.11 with latest upgrades
2.2 Technical Specifications
2.2.1 Hardware
Table 2-1 lists the hardware specifications.
Table 2-1 Hardware specifications
Item Specifications
Technical
standard
WAN: LTE CA/LTE FDD/LTE TDD/
DC-HSPA+/HSPA+/HSPA/UMTS/EDGE/GPRS/GSM
WLAN: IEEE 802.11a/b/g/n/ac
Operating
frequency
LTE CA：
- intra-band continuous CA:
-CA_3C -40MHz total
-CA_7C -40MHz total
-CA_38C -40MHz total
- intra-band non-contiguous CA:
CA_3A_3A -40MHz total
- Inter-frequency CA:
-CA_3A-5A -30MHz total
-CA_3A-7A -40MHz total
-CA_3A-8A -30MHz total
-CA_3A-20A -30MHz total
-CA_7A-8A -30MHz total
-CA_7A-20A -30MHz total
-CA_20A-32A -30MHz total
LTE FDD:B1/B3/B5/B7/B8/B20/B32
LTE TDD:B38
DC-HSPA+/HSPA+/HSPA/UMTS:
B1 (2100MHz)/B2 (1900MHz)/B5 (850MHz)/B8 (900MHz)
EDGE/GPRS/GSM: B2 (1900MHz)/B3 (1800MHz)/B5
(850MHz)/B8 (900MHz)
WLAN: 2.4 GHz, 5 GHz
Internal memory 256 MB Flash, 256 MB DDR SDRAM
Maximum LTE: Conform to Power Class 3 Definition
HUAWEI E5785Lh-22c Mobile WiFi V200R001
Product Description
Issue 01 (2016-06-02) Commercial in Confidence Page 10 of 21
Item Specifications
transmitter
power UMTS: Conform to Power Class 3 Definition
WLAN 802.11a: 10 dBm
802.11b: 15 dBm
802.11g: 12 dBm
802.11n
（2.4GHz）
11 dBm（20 MHz）
10 dBm（40 MHz）
802.11n
（5GHz）
10 dBm（20 MHz）
10 dBm（40 MHz）
802.11ac 10 dBm（20 MHz）
9 dBm（40 MHz）
8 dBm（80 MHz）
Receiver
sensitivity
LTE: Conform to 3GPP requirements
UMTS: Conform to 3GPP requirements
WLAN 802.11a: –65 dBm
802.11b: –76 dBm
802.11g: –65 dBm
802.11n: –64 dBm
802.11ac: –64 dBm
WLAN speed 802.11a: Up to 54 Mbit/s
802.11b: Up to 11 Mbit/s
802.11g: Up to 54 Mbit/s
802.11n HT20: Support MCS0–MCS7; Up to 72.2 Mbit/s.
Support MCS8–MCS15; Up to 144.4 Mbit/s.
HT40: Support MCS0–MCS7; Up to 150 Mbit/s.
Support MCS8–MCS15; Up to 300 Mbit/s.
802.11ac: Up to 867 Mbit/s
Maximum power
consumption
3.5 W
Power supply AC: 100–240 V
DC: 5 V, 2 A
HUAWEI E5785Lh-22c Mobile WiFi V200R001
Product Description
Issue 01 (2016-06-02) Commercial in Confidence Page 11 of 21
Item Specifications
Battery Type: Li (rechargeable)
Capacity: 3.8 V, 3000 mAh
Maximum working time: 12 hours (depending on the network)
Maximum standby time: 600 hours (depending on the network)
External
interfaces
Micro USB 2.0 interface
Micro-SIM card interface
Screen TFT-LCD
Key-press Power switch, MENU switch, RESET switch
Antenna Built-in LTE/UMTS/GSM main antenna
Built-in LTE/UMTS/GSM diversity antenna
Built-in WLAN 2 x 2 antenna
Dimensions
(W x D x H)
108.0 mm x 62.0 mm x 17.3 mm
Weight About 127g (including the battery)
Temperature Operating: 0℃ to +35℃
Storage: –20℃ to +70℃
Humidity 5% to 95% (non-condensing)
HUAWEI E5785Lh-22c Mobile WiFi V200R001
Product Description
Issue 01 (2016-06-02) Commercial in Confidence Page 12 of 21
2.2.2 Software
Table 2-2 lists the software specifications.
Table 2-2 software specifications
Item Description
SMS - Writing/Sending/Receiving
- Sending/Receiving extra-long messages
- Storage: Up to 500 messages can be saved in the
internal memory of the E5785Lh-22c.
Network connection
setup
- APN management: create, delete and edit.
- Set up network connection
WLAN setup - SSID broadcasting and hiding
- None (Open), WEP, WPA2-PSK, and
WPA/WPA2-PSK encryption Automatic adjustment of
ratios
- Display STA status
- Turn off Wi-Fi automatically
- WLAN MAC filter
- Dual SSID
Firewall setup - Firewall Switch
- LAN IP Filter
- Virtual Server
- DMZ Service
- UPnP Service
NAT setup - CONE NAT
- Symmetric NAT
- ALG
DHCP setup - DHCP server enabling and disabling
- Address pool of the DHCP server setup
- DHCP lease time setup
Software installation Automatic installation
IPv6/IPv4 dual stack
(optional)
- DHCPv6/v4 server and client
- DNSv6/v4 server and client
- Display IPv6/v4 WAN address
Other Network connection settings:
- Automatic network selection and registration
- Manual network selection and registration
HUAWEI E5785Lh-22c Mobile WiFi V200R001
Product Description
Issue 01 (2016-06-02) Commercial in Confidence Page 13 of 21
Item Description
Network status display: signal, operator name, system
mode, and so on.
LTE network switch: turn on/off LTE network
PIN management: activate/deactivate PIN, PIN lock,
changing PIN, unblocking by using the PUK.
System requirement - Windows 7, Windows 8, Windows 8.1, Windows 10
(does not support Windows RT)
- Mac OS X 10.7, 10.8, 10.9, 10.10 and 10.11 with latest
upgrades
- Your computer's hardware system should meet or
exceed the recommended system requirements for the
installed version of OS
HUAWEI E5785Lh-22c Mobile WiFi V200R001
Product Description
Issue 01 (2016-06-02) Commercial in Confidence Page 14 of 21
3 Services and Applications
3.1 Data Service
3.1.1 Wireless Modem
The E5785Lh-22c can be used as a wireless modem when the Wi-Fi is enabled. You
can directly use the default settings (or configure APN on the E5785Lh-22c Web page)
and set up a wireless network connection. Then you can access the Internet.
A maximum of 16(Wi-Fi 2.4 GHz)/10(Wi-Fi 5 GHz) wireless users can access the
E5785Lh-22c at the same time. You can set up the WLAN with the access point (AP)
function.
Figure 3-1 Multi-device access via Wi-Fi and USB at the same time
HUAWEI E5785Lh-22c Mobile WiFi V200R001
Product Description
Issue 01 (2016-06-02) Commercial in Confidence Page 15 of 21
3.1.2 USB Modem
After you connect the E5785Lh-22c and PC with a USB data cable, enter
http://192.168.8.1 in the browser address box. You can directly use the default
settings (or configure APN on the E5785Lh-22c Web page) and set up a network
connection. Then you can send or receive E-mail, access the network through
wireless connection, and download files through wireless data channels.
Figure 3-2 One-device access via USB
3.1.3 LTE/3G/Wi-Fi Auto Offload
The E5785Lh-22c allows you to access the Internet via LTE, 3G or Wi-Fi. When you
are using the E5785Lh-22c in areas with a Wi-Fi hotspot, for example, an airport, a
cafe, a hotel, or your home, the E5785Lh-22c switches to Wi-Fi connection
automatically, saving your LTE/3G network traffic fees.
Enabling LTE/3G/Wi-Fi auto offload will decrease the number of concurrent users
allowed to connect to the E5785Lh-22c by 1.
Figure 3-3 LTE/3G/Wi-Fi auto offload
3.2 SMS
The E5785Lh-22c supports message writing/sending/receiving. You can manage
messages through the Web page, such as an inbox, an outbox and a draft.
HUAWEI E5785Lh-22c Mobile WiFi V200R001
Product Description
Issue 01 (2016-06-02) Commercial in Confidence Page 16 of 21
3.3 Menu-Style LCD UI
The E5785Lh-22c provides a menu-style LCD UI with support for multiple languages.
Press the menu button to display the menus, and then use the menu and power
buttons to select or confirm an option. You can browse the information on the LCD or
configure settings. For example, you can:
- Scan a 2D barcode on the E5785Lh-22c's LCD to download the HiLink App
(Mobile WiFi App).
- Scan a 2D barcode on the E5785Lh-22c's LCD use the HiLink App (Mobile WiFi
App) to connect your device to the Internet.
- Turn on or off the automatic switchover between LTE/3G and Wi-Fi Internet
access modes.
- Turn on or off the WPS function.
Figure 3-5 shows the menu-style LCD UI. This figure is for your reference only. The
actual UI may vary.
Figure 3-4 Menu-style LCD UI
3.3.1 Scanning a 2D Barcode to Download the HiLink App(Mobile
WiFi App)
You can scan a 2D barcode on the E5785Lh-22c's LCD to download the HiLink App
(Mobile WiFi App) to your Android devices.
3.3.2 Scanning a 2D Barcode to Connect to the Internet
If you are using an Android device that has the HiLink App (Mobile WiFi App) installed,
you can quickly connect your device to the E5785Lh-22c to access the Internet by
scanning a 2D barcode on the E5785Lh-22c's LCD.
HUAWEI E5785Lh-22c Mobile WiFi V200R001
Product Description
Issue 01 (2016-06-02) Commercial in Confidence Page 17 of 21
4 System Architecture
4.1 System Architecture
Figure 4-1 shows the system architecture.
Figure 4-1 System architecture
Protocol stack
Bottom layer drivers
(include USB, Wi-Fi and
user interface)
Application
systerm
Web page
Web server
User
interface
USB
Baseband signal
processing
Radio frequency
module
Power module
Software module
PC
Mobile phone/Tablet
USB/Wi-Fi
Hardware module
Wi-Fi
Wi-Fi
HUAWEI E5785Lh-22c Mobile WiFi V200R001
Product Description
Issue 01 (2016-06-02) Commercial in Confidence Page 18 of 21
4.2 Functional Modules
1. Radio frequency module: It sends/receives radio signals and
modulates/demodulates the radio frequency (RF) signals and baseband signals
2. Baseband signal processing: It processes LTE CA/LTE FDD/LTE
TDD/DC-HSPA+/HSPA+/UMTS baseband digital signals, including:
- Modulating/Demodulating LTE CA/LTE FDD/LTE
TDD/DC-HSPA+/HSPA+/UMTS/EDGE/GPRS/GSM baseband signals
- Encoding/Decoding LTE CA/LTE FDD/LTE TDD/LTE
TDD/DC-HSPA+/HSPA+/UMTS/EDGE/GPRS/GSM channel
3. Bottom layer driver: It drives peripherals, including a USB device, Wi-Fi devices,
a screen, buttons and a SIM card.
4. Protocol stack system: It processes protocols of LTE CA/LTE FDD/LTE TDD/
DC-HSPA+/HSPA+/UMTS/EDGE/GPRS/GSM and TCP/IP.
5. Application system: It provides management system, including SMS, PS
domain service, Wi-Fi configuration, network service, Web service and Web page.
The user can set management parameters by Web page.
6. User interface: It provides human-computer interaction, including a screen and
buttons.
HUAWEI E5785Lh-22c Mobile WiFi V200R001
Product Description
Issue 01 (2016-06-02) Commercial in Confidence Page 19 of 21
5 Packing List
This chapter describes the items contained in the package of the E5785Lh-22c.
Table 5-1 lists the items contained in the package of the E5785Lh-22c.
Table 5-1 Packing list of the E5785Lh-22c
Item Quantity Remarks
Mobile WiFi 1 Standard
Rechargeable Battery (3000 mAh) 1 Standard
USB Cable 1 Standard
Quick Start 1 Standard
Safety Information 1 Standard
Charger 1 Optional
Warranty Card 1 Optional
HUAWEI E5785Lh-22c Mobile WiFi V200R001
Product Description
Issue 01 (2016-06-02) Commercial in Confidence Page 20 of 21
A Acronyms and Abbreviations
3G The Third Generation
AES Advanced Encryption Standard
ALG application level gateway
APN access point name
ARPU average revenue per user
ASCII American Standard Code for Information Interchange
DHCP Dynamic Host Configuration Protocol
DMZ demilitarized zone
DNS Domain Name Server
FDD frequency division duplex
HSPA+ High Speed Packet Access Plus
HSUPA High Speed Uplink Packet Access
HSDPA High Speed Downlink Packet Access
IEEE Institute of Electrical and Electronics Engineers
IP Internet Protocol
LCD Liquid Crystal Display
LTE Long Term Evolution
MAC Medium Access Control
Modem Modulator Demodulator
NAT Network Address Translation
OS Operating System
PC personal computer
PIN personal identification number
HUAWEI E5785Lh-22c Mobile WiFi V200R001
Product Description
Issue 01 (2016-06-02) Commercial in Confidence Page 21 of 21
PnP Plug and Play
PS packet switched
PUK PIN unblocking key
SIM subscriber identity module
SMS short messaging service
SOHO small office home office
SSID Service Set Identifier
TFT Thin Film Transistor
TKIP Temporal Key Integrity Protocol
UMTS Universal Mobile Telecommunications System
UPnP Universal Plug and Play
USB Universal Serial Bus
WAN wireless area network
WEP wired equivalent privacy
Wi-Fi Wireless Fidelity
WLAN wireless local area network
WPA Wi-Fi Protected Access

Navigation menu
