1 | Data on Demand
Huawei OceanStor 5300, 5500, 5600, and 5800 V3 mid-range storage systems are next-generation unified
storage products specifically designed for enterprise-class applications. Employing a storage operating system
built on a cloud-oriented architecture, a powerful new hardware platform, and a suite of intelligent manage-
ment software, the V3 mid-range storage systems deliver industry-leading functionality, performance,
efficiency, reliability, and ease-of-use.
The V3 mid-range storage systems are ideal for applications such as large-database Online Transaction
Processing (OLTP)/Online Analytical Processing (OLAP), file sharing, and cloud computing. Further, these
systems offer a wide range of efficient backup and disaster recovery solutions.
With a versatile set of capabilities, the V3 mid-range storage systems can be widely applied in industries
ranging from government, finance, telecommunications, energy, to Media and Entertainment (M&E).
Cloud-Oriented Storage Software
Provides elastic storage, simplifies service deployment,
improves storage resource utilization, and reduces Total
Cost of Ownership (TCO). Underlying storage resource
pools provide both block and file services and shorten
storage resource access paths to ensure that the two
services are equally efficient.
Convergence of SAN and NAS
Convergence
Allows resources to be linearly expanded online to a
maximum of eight controllers, 2 TB of cache, and 15 PB of
storage capacity of storage capacity.
Scale-out capability
Implements load balancing among controllers and elimi-
nates single points of failure to ensure high system avail-
ability and the stability of online services. Multiple control-
lers concurrently process the same host service to smash
the performance bottleneck of a single controller, signifi-
cantly improving service processing efficiency.
Load balancing
Multiple Controllers
Cloud-Oriented
Converged Storage
Huawei OceanStor 5300, 5500,
5600, and 5800 V3 Storage Systems
Data Sheet
Highlights
Cloud architecture-oriented operating system,
high-performance hardware platform, and a
complete suite of smart management software.
Convergence of file, flash, backup, high-, mid, and
low-end storage, and third-party storage – allocate
the resources you need, when you need them.
Leading active-active integrated SAN and NAS
solution, ensuring business continuity for
customers
2 | Data on Demand
Smart series efficiency improvement suite
Leverages dynamic storage tiering (SmartTier), intelligent data
migration (SmartMotion), and innovative heterogeneous virtualiza-
tion (SmartVirtualization) to achieve vertical, horizontal, and
cross-system 3D data flow, significantly improving storage
resource utilization.
A built-in virtualization function efficiently manages storage systems
from multiple vendors and unifies resource pools for flexible, central-
ized resource allocation and protects their data. In addition, original
data can be migrated to OceanStor V3 so that services can be
accelerated. OceanStor V3 mid-range storage supports gateway
mode.
Convergence of heterogeneous storage systems
Enable intelligent allocation of storage resources in cloud computing
environments. The systems apply data isolation functions and data
security policies such as data encryption and reliable destruction of
obsolete data. With four service levels, the systems allocate storage
resources based on service priorities. High-priority services thereby
get an assured preference for system resources that minimizes
response times.
Multi-tenant and Service Level Agreement (SLA)
Intelligence
Any size system interworks seamlessly so data can freely flow
among storage products of different models without the assis-
tance of third-party systems.
Convergence of high-end, mid-range,
and entry-level storage systems
Combining the advantages of rotating media and solid-state
storage, the systems offer an optimal balance of performance and
cost. In the case of all-flash configuration, high performance and
a low latency of 1 ms can be reached.
Convergence of SSDs and HDDs
Integrated backup functions achieve efficiency without additional
backup software, simplifying backup management.
Convergence of primary and backup storage
Smart series
Smart
Innovative convergence technologies
SAN and NAS
Convergence
SSD and HDD
Convergence
Heterogeneous
Convergence
Backup
Convergence
High-, Mid-, and
Low-end Convergence
Huawei OceanStor 5300, 5500,
5600, and 5800 V3 Storage Systems
Data Sheet
3 | Data on Demand
Hyper series data protection suite
Hyper
Hyper series
Easy to Manage
Unified management
Powerful storage management software supports global topology
views, capacity analysis, performance analysis, fault diagnosis, and
end-to-end service visualization to simplify management of a wide
range of devices.
Industry-leading Storage Hardware
Outstanding performance
V3 mid-range storage systems employ the latest Intel multi-core
processors, 16 Gbit/s Fiber Channel, 10 Gbit/s FCoE, and 56 Gbit/s
InfiniBand host ports, PCIe 3.0 buses, and 12 Gbit/s SAS 3.0 disk
ports. System bandwidth as high as 28 GB/s efficiently handles video
and other large files, and supports million-level IOPS performance.
Exclusive SmartIO cards
Each SmartIO card supports 8 Gbit/s Fibre Channel, 16 Gbit/s Fibre
Channel, 10 Gbit/s Ethernet and 10 Gbit/s FCoE.
Leading active-active integrated SAN and NAS solution
SmartIO interface card
Storage Storage
HyperMetro Active-Active Solution
Unified management
One set of arrays support SAN and NAS active-active protection, guaran-
teeing high availability of databases and files. HyperMetro implements
active-active mirroring with load balancing and cross-site takeover with-
out service interruption, preventing data loss and system breakdown from
occurring in critical application systems. The gateway-free design can
effectively reduce the purchase cost, simplify the deployment, and enable
the active-active solution to be smoothly upgraded to the Disaster Recov-
ery Data Center Solution (Geo-Redundant Mode).
Software for functions such as remote replication, snapshot, and LUN
copy provide local, remote, and multi-branch data protection to offer
99.9999% solution-level availability and maximize business continuity.
Huawei OceanStor 5300, 5500,
5600, and 5800 V3 Storage Systems
Data Sheet
4 | Data on Demand
Technical Specifications
名称
Controller Enclosure Specifications
Storage Processors
System Cache
(expanded by adding controllers)
Maximum Number of Controllers
Supported Storage Protocols
Front-end Port Types
Back-end Port Type
Maximum Number of
Hot Swappable I/O Modules per Controller
Maximum Number of Front-end
Ports per Controller
Maximum Number of Disks
Supported by Two Controllers
Disk Types
Multi-core processors
8 8 8 8
Fibre Channel, FCoE, iSCSI, InfiniBand, NFS, CIFS, HTTP, and FTP
8/16 Gbit/s Fibre Channel, 1/10 Gbit/s Ethernet, 10 Gbit/s FCoE, and 56 Gbit/s InfiniBand
SAS 3.0 (each port supporting 4 x 12 Gbit/s)
32 GB to 256 GB 48 GB to 512 GB 64 GB to 1, 024 GB 128 GB to 2, 048 GB
SSD, SAS, NL - SAS
5300 V3 5500 V3 5600 V3 5800 V3
Model
2 2 8 8
20 20 28 28
500 750 1,200 1,500
Gateway Mode
Supported RAID Levels
Maximum Number of Snapshots (LUN)
Maximum Number of LUNs
Maximum Number of
Snapshots per File System
Maximum Capacity of a Single File
Supported
0, 1, 3, 5, 6, 10, and 50
2,048
256TB
HyperSnap (snapshot) HyperCopy (LUN copy) HyperClone (clone)
HyperMirror (volume mirror) HyperReplication (remote replication) HyperLock (WORM)
HyperMetro (active-active storage arrays) HyperVault (integrated backup)
SmartTier (intelligent storage tiering) SmartThin (intelligent thin provisioning)
SmartMotion (intelligent data migration) SmartMulti-Tenant (multi-tenant)
SmartMigration (LUN migration) SmartCompression (online compression)
SmartDedupe (online deduplication) SmartQuota (quota management)
SmartErase (data destruction)
SmartQoS (intelligent QoS control) SmartPartition (intelligent partitioning)
SmartCache (intelligent SSD caching)
UltraPath (multipathing management) Cloud Service (remote maintenance and management)
BCManager (disaster recovery management software)
DeviceManager (manage single device) eSight (manage multiple devices)
Data Protection Software
Mission-critical Service Protection
Resource Efficiency Improvement
Storage Management Software
Key Software Features
2,048 4,096 8,192 8,192
4,096 8,192 16,384 16,384
Huawei OceanStor 5300, 5500,
5600, and 5800 V3 Storage Systems
Data Sheet
5 | Data on Demand
Virtualization Features
Heterogeneous Virtualization
Block Virtualization
Support for Computing
Virtualization
Physical Specifications
Power Supply
Dimensions (H x W x D)2U disk enclosure: 86.1 mm x 447 mm x 490 mm (3.39 in. x 17.60 in. x 19.29 in.)
4U disk enclosure: 175 mm x 447 mm x 490 mm (6.89 in. x 17.60 in. x 19.29 in.)
4U high-density disk enclosure: 176.5 mm x 446 mm x 790 mm (6.95 in. x 17.56 in. x 31.10 in.)
Weight
Operating Temperature5°C to 40°C at altitudes below 1,800 m (5,905.44 ft.)
5°C to 35°C at altitudes from 1,800 m (5,905.44 ft.) to 3,000 m (9,842.40 ft.)
Operating Humidity 5% RH to 90% RH
Consolidates storage resources of mainstream products to manage and allocate resources
in a flexible and unified manner.
Balanced data distribution, quick fault recovery
Supported virtual machines: VMware, Citrix, Hyper-V, and FusionSphere
Value-added features related to virtual environments: support for VMware VAAI and integration
of VSphere and VCenter
AC: 100 V to 240 V
DC: 192 V to 288 V or –48 V to –60 V
AC: 200 V to 240 V
DC: 192 V to 288 V or -48 V to -60 V
2U controller enclosure: 86.1 mm x 447 mm x
750 mm (3.39 in. x 17.60 in. x 29.53 in.)
3U controller enclosure: 130.5 mm x 447 mm x
750 mm (5.14 in. x 17.60 in. x 29.53 in.)
2U controller enclosure: ≤ 37 kg (81.59 lb)
2U disk enclosure: ≤ 20 kg (44.10 lb)
4U disk enclosure: ≤ 40 kg (88.20 lb)
4U high-density disk enclosure: ≤ 91 kg (200.66 lb)
3U controller enclosure: ≤ 50 kg (110.25 lb)
2U disk enclosure: ≤ 20 kg (44.10 lb)
4U disk enclosure: ≤ 40 kg (88.20 lb)
4U high-density disk enclosure: ≤ 91 kg (200.66 lb)
Huawei OceanStor 5300, 5500,
5600, and 5800 V3 Storage Systems
Data Sheet
Copyright © Huawei Technologies Co., Ltd. 2017. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without
prior written consent of Huawei Technologies Co., Ltd.
Trademark Notice
HUAWEI, and are trademarks or registered trademarks of Huawei Technologies Co., Ltd. Other trademarks,
product, service and company names mentioned are the property of their respective owners.
General Disclaimer
The information in this document may contain predictive statements including, without
limitation, statements regarding the future financial and operating results, future
product portfolio, new technology, etc. There are a number of factors that could cause
actual results and developments to differ materially from those expressed or implied in
the predictive statements. Therefore, such information is provided for reference purpose
only and constitutes neither an offer nor an acceptance. Huawei may change the
information at any time without notice.
HUAWEI TECHNOLOGIES CO., LTD.
Address: Huawei Industrial Base Bantian, Longgang Shenzhen, PRC
Tel: (0755) 28780808
Zip code: 518129
www.huawei.com
For More Information
To learn more about Huawei storage, please contact the local office
or visit Huawei Enterprise website http://e.huawei.com.
Huawei Enterprise APP Huawei IT

Navigation menu
