IPL, McCulloch, Elite 2.510 B Pro, 953900764, Prefix 01, 2007 03, Brush Cutter 953900764 Mc Culloch,

Elite 2.510 elite 2.510 b pro 953900764

User Manual: 953900764

Open the PDF directly: View PDF PDF.
Page Count: 5

HUSQVARNA OUTDOOR PRODUCTS ITALI
A
PNC Type
/
Model Brand
Prefix/
nd
953900764 01 ELITE 2.510 B-PRO McCulloch
953900782 01 BA 437 BT Partner
953900784 01 BA 477 BT Partner
Number of Pages 1 of 5
Factory: IIQ - Valmadrera Product Group: OP 93
Publication Number: MIPL2007_V100000005 Petrol Portable
Publication Date: 06/03/07 Sub Group 9433
HUSQVARNA OUTDOOR PRODUCTS ITALI
A
Publication No: MIPL2007_V100000005 Page: 2 of 5
FIGURE 1
FIGURE 3
FIGURE 2
HUSQVARNA OUTDOOR PRODUCTS ITALI
A
Publication No: MIPL2007_V100000005
Item P/N McC P/N ELX Qty DESCRIPTION Item P/N McC P/N ELX Qty DESCRIPTION
49 236381 538236381 1screw m5x10
1 243066 538243066 1clamp ass'y 50 236529 538236529 3grower
2z242917 538242917 1knob 51 240151 538240151 1screw M8x10
3z242898 538242898 1handle clamp (upper half) 52 240824 538240824 1gear box ass'y
4z242897 538242897 1handle clamp (lower half) 53 247272 538247272 1spacer
5z242901 538242901 1spring 54 240767 538240767 1flange guard
6z243123 538243123 1shaft clamp (upper half) 55 240688 538240688 3screw+washer
7z242199 538242199 1shaft clamp (lower half) 56 242410 538242410 1flange
8z235803 538235803 4screw m5x25 57 241155 538241155 1string head shield
9 236642 538236642 1nut m6 A 58 248960 538248960 1safety guard ass'y
10 242202 538242202 1clamp 59 z227563 538227563 4screw M5x18
11 235910 538235910 1screw 6x25 60 z242636 538242636 1clamp (upper half)
12 242196 538242196 2antivibration 61 z242752 538242752 1clamp (lower half)
13 242533 538242533 1right handle (right half) 62 z229208 538229208 2nut m5
14 242537 538242537 1throttle trigger 63 z242630 538242630 1string head guard extension
15 242540 538242540 1spring 64 z241973 538241973 1line cutter
16 242538 538242538 1safety trigger 65 z240862 538240862 1screw 4x18 - self threading
17 242534 538242534 1right handle (left half)
18 242648 538242648 1cap
C 19 242607 538242607 1wires ass'y
C20 z242439 538242439 1switch
C21 z243061 538243061 1throttle cable A 1 531025002 531025002 1P 35 trimmer head
22 249249 538249249 1handle bar 2z537421501 537421501 1body
23 240862 538240862 5screw 4x18 - self threading 3z537427901 537427901 1adapter P35
24 242535 538242535 1left handle (right half) C4 z537186001 537186001 1spring T35
25 242536 538242536 1left handle (left half) C5 z537421801 537421801 1knob
26 228011 538228011 1harness ring ass'y C6 z537421701 537421701 1spool (without line)
27 z235911 538235911 1screw m6x12 C7z537419701 537419701 2bushing
28 z236642 538236642 1nut m6 8z537421601 537421601 1cover
29 242726 538242726 1outer shaft
30 236642 538236642 1nut m6
31 241480 538241480 1wires fastener
32 235910 538235910 1screw m6x25
33 242197 538242197 1joint cover
34 242196 538242196 2antivibration
35 235804 538235804 4screw m5x30
36 228139 538228139 1male fast-on A 1 242475 538242475 1flange
37 240688 538240688 1screw m5x14 + washer A 2 241155 538241155 1grass shield
38 242626 538242626 1joint ass'y A 3 229834 538229834 1flange
39 z236642 538236642 1nut m6 A 4 236596 538236596 1cup
40 z236378 538236378 1seeger D. 15 A 5 229842 538229842 1cup screw
41 z235918 538235918 1ball bearing A 6 242410 538242410 1flange
42 z235899 538235899 1seeger D. 32 A 7 241155 538241155 1grass shield
43 z227284 538227284 1clutch drum A 8 229834 538229834 1flange
44 z235910 538235910 1screw m6x25 A 9 240809 538040809 1idle cup
45 240830 538240830 1inner shaft ass'y 10 z240807 538240807 1spacer
46 z236383 538236383 5bushing ass'y A11 z240806 538240806 1idle cup screw
47 229829 538229829 1drive shaft
48 235804 538235804 2screw m5x30
A=ALTA ROTAZIONE A=HIGH MOVING A=HAUTE DEMANDE A=GROBE NACHFRAGE
B=MEDIA ROTAZIONE B=MEDIUM MOVING B=MOYENNE DEMANDE B=MITTELMAESSIGE
C=ALTA ROTAZIONE C=SLOW MOVING C=BASSE DEMANDE C=WENIGE NACHFRAGE
NUOVI CODICI NEW P. NUMBERS NOUVELLES REFERENCES NEU CODEX
Page: 3 of 5
FIGURE 1
FIGURE 2
FIGURE 3
HUSQVARNA OUTDOOR PRODUCTS ITALI
A
Publication No: MIPL2007_V100000005 Page: 4 of 5
FIGURE 4
FIGURE 5
FIGURE 6
HUSQVARNA OUTDOOR PRODUCTS ITALI
A
Publication No: MIPL2007_V100000005
Item P/N McC P/N ELX Qty DESCRIPTION Item P/N McC P/N ELX Qty DESCRIPTION
C 80 242855 538242855 1gasket
1 243725 538243725 1crankshaft ass'y C 81 241481 538241481 1carb. Spacer
C 2 501451601 501451601 1needle bearing 82 235806 538235806 2screw M5 X 20 TCE
3 250075 538250075 1Carter kit (starter) A 83 241281 538241281 1gasket
4z227541 538227541 1ball bearing C 84 FIGURE 3
5z240982 538240982 1seeger ring 90 249981 538249981 1air filter box
C6 z243174 538243174 1seal 91 235808 538235808 2screw M5 X 50 TCE
7 250074 538250074 1Carter kit (flyweel) B 92 243782 538243782 air filter 1 (fabric)
C8 z243174 538243174 1seal 93 243750 538243750 1air filter cover
9z240982 538240982 1seeger ring 94 243765 538243765 knob
10 z227541 538227541 1ball bearing B 95 243851 538243851 1air filter 2 (mesh)
11 235804 538235804 2screw M5x30
12 235808 538235808 2screw M5 X 50 TCE
20 242673 538242673 1flywheel
21 235218 538235218 1nut M8 C 1 250072 538250072 1cylinder/piston kit 43 cc
B 22 248808 538248808 1clutch assy B2 z242366 538242366 1gasket 0.8 mm
23 z242369 538242369 2clutch rod B3 z249709 538249709 1piston kit 43 cc
C24 z241270 538241270 1clutch spring elite 4zz 737441000 737441000 2retaining ring
25 z241076 538241076 2washer B5 zz 240085 538240085 1piston ring
27 235806 538235806 2screw M5 X 20 TCE
C 28 242782 538242782 1ignition coil C 1 250073 538250073 1cylinder/piston kit 46 cc
30 242800 538242800 1starter pawl ass'y B2 z242366 538242366 1gasket 0.8 mm
31 z111088 538111088 2snap ring B3 z249710 538249710 1piston kit 46 cc
B32 z241782 538241782 2spring 4zz 737441000 737441000 2retaining ring
B33 z241781 538241781 2pawl B5 zz 240353 538240353 1piston ring
34 235218 538235218 1nut M8
C 40 242806 538242806 1starter assy
41 z242786 538242786 1seeger
42 z227470 538227470 1washer
B43 z249163 538249163 1pulley/rope assy
A44 zz 227703 538227703 1rope
B45 z227300 538227300 1spring rewind
46 z227467 538227467 1shield spring
47 z240884 538240884 1starter-handle
48 235214 538235214 4screw M6x20
A 50 240452 538240452 1pick up fuel
C 51 241541 538241541 1tank mix ass.
C52 z235675 538235675 1fueltank grommet
B53 z229809 538229809 1hose-fuel mm245
B54 z229743 538229743 1hose fuel mm150
B 56 242484 538242484 1fuel cap assy
A57 z236564 538236564 1cap gasket
58 242632 538242632 2grommet fuel tank elite
59 241248 538241248 2fuel tank grommet (flywheel)
C 60 FIGURE 2
A 61 92878 538092878 1spark plug RDJ6J
62 227565 538227565 4screw M5X25
63 94273 538094273 1decompressor valve C - 241268 538241268 1carburettor WJY 183A
65 236322 538236322 1grommet B1
z247955 538247955 1repair kit K20 WYJ
66 249420 538249420 1engine cover A2
zz 247956 538247956 1gasket kit D20 WYJ
67 240688 538240688 2screw m5x14 + washer C3
z225834 538225834 1primer
C 70 242858 538242858 1gasket C4
z247957 538247957 1valve
C 71 241432 538241432 1muffler assy elite C5
z247958 538247958 1spring
72 z227274 538227274 2screw M5X60 C6
z247962 538247962 1pumping body
73 z227236 538227236 1clamp C7
z247961 538247961 1valve
74 z227259 538227259 2washer C8
z247959 538247959 1jet
A=ALTA ROTAZIONE A=HIGH MOVING A=HAUTE DEMANDE A=GROBE NACHFRAGE
B=MEDIA ROTAZIONE B=MEDIUM MOVING B=MOYENNE DEMANDE B=MITTELMAESSIGE
C=ALTA ROTAZIONE C=SLOW MOVING C=BASSE DEMANDE C=WENIGE NACHFRAGE
NUOVI CODICI NEW P. NUMBERS NOUVELLES REFERENCES NEU CODEX
Page: 5 of 5
FIGURE 4
FIGURE 5
FIGURE 6
