365-Day Astronomic
Time Switch
Ideal for:
Schools, Apartments, Offices,
Retail Stores, Security Systems,
Parking Lot Lighting, and Airports
ET90000 Series
Features:
• 365-day astronomic timing
• Automatic input voltage selection from
120 to 277 VAC, 50/60 Hz
• Over 4,000 events plus holiday schedules
• 30 Amp rated contacts
• 100+ hour supercapacitor maintains date and
time in case of power outage
• USB connection for uploading, downloading
and transferring of programs
• Ethernet capable for networking of controls
to other controls and PC tools
• Easy to follow on-screen menus for
programming to-the-minute accuracy
• Non-volatile memory protects
programming indenitely
• Firmware upgradable in-eld via
USB or Ethernet
• CAN connection supports up to 32 additional
circuits or inputs externally
• Available in 1, 2, 4, 8, 12, and 16 circuits
• Internally expandable in 4-circuit increments
up to 16 circuits
http://waterheatertimer.org/Intermatic-ET-series-timers-and-manuals.html#ET90000
©2011 Intermatic Inc.
7777 Winn Road, Spring Grove, IL 60081
Phone: (815) 675-2321
www.intermatic.com
300ET10032
ET90000 Series
Normally Open Contact Normally Closed Contact Load Type Voltage Frequency
30 Amp -- Resistive & Gen. Purpose 12-240 VAC 50/60Hz
20 Amp 10 Amp Resistive & Gen. Purpose 12-240 VAC 50/60Hz
20 Amp 10 Amp Resistive & Gen. Purpose 28 VDC 50/60Hz
20 Amp 3 Amp Ballast 120-277 VAC 50/60Hz
5 Amp -- Tungsten 12-240 VAC 50/60Hz
470 VA 275 VA Pilot Duty 12-240 VAC 50/60Hz
1HP 1/4HP Motor 120 VAC 50/60Hz
2HP 1/2HP Motor 240 VAC 50/60Hz
Large Case Enclosures ET90415CR ET90815CR ET91215CR ET91615CR
Number of Circuits 4 8 12 16
Raintight Enclosure 4 4 4 4
Astronomic Timing 4 4 4 4
Automatic Daylight Saving Time 4 4 4 4
Modifiable Daylight Saving Time 4 4 4 4
Automatic Input Voltage Selection 4 4 4 4
Firmware Upgradable In-Field 4 4 4 4
On-Screen Menu-Based Display 4 4 4 4
Supercapacitor Date and Time Backup 4 4 4 4
External Serial Inputs 4 4 4 4
External CAN Device Support 4 4 4 4
USB Support for Easy Programming 4 4 4 4
USB Support for Firmware Updates 4 4 4 4
Ethernet Support for Status and Control 4 4 4 4
Ethernet Support for Easy Programming 4 4 4 4
Ethernet Support for Firmware Updates 4 4 4 4
Small Case Enclosures ET90115C ET90115CR ET90115CE ET90115CRE ET90215C ET90215CR ET90215CE ET90215CRE
Number of Circuits 1 1 1 1 2 2 2 2
Raintight Enclosure 4 4 4 4
Astronomic Timing 4 4 4 4 4 4 4 4
Automatic Daylight Saving Time 4 4 4 4 4 4 4 4
Modifiable Daylight Saving Time 4 4 4 4 4 4 4 4
Automatic Input Voltage Selection 4 4 4 4 4 4 4 4
Firmware Upgradable In-Field 4 4 4 4 4 4 4 4
On-Screen Menu-Based Display 4 4 4 4 4 4 4 4
Supercapacitor Date and Time Backup 4 4 4 4 4 4 4 4
External Serial Inputs 4 4 4 4 4 4 4 4
External CAN Device Support 4 4 4 4 4 4 4 4
USB Support for Easy Programming 4 4 4 4 4 4 4 4
USB Support for Firmware Updates 4 4 4 4 4 4 4 4
Ethernet Support for Status and Control 4 4 4 4
Ethernet Support for Easy Programming 4 4 4 4
Ethernet Support for Firmware Updates 4 4 4 4
